User Manual

1. Insert the SIM and memory

card

1.With the phone facing down, put your fingernail in

the small recess located on the bottom edge.

2.Bend the cover open and remove it.

3.Slide the nano-SIM card into the SIM slot with the

metal contact area down until it locks into place. If

you have a dual-SIM phone, insert the second SIM

into the SIM2 slot until it locks into place.

4.If you have a microSD memory card, slide the card

into the memory card slot.

5.Press the top edge of the back cover against the

top edge of your phone, and then snap the cover

into place, locking all the hooks around the edges of

the cover.

Warning! Do not open the battery cover, it may

harm your device.

Use only original nano-SIM cards. Use of incompati-

ble SIM cards may damage the card or the device,

and may corrupt data stored on the card.

2. Charge the battery and switch

the phone on

Plug a compatible charger into a wall outlet, and

connect the cable to your phone. Your phone sup-

ports the USB micro-B cable. You can also charge

your phone from a computer with a USB cable, but

it may take a longer time.

If the battery is completely discharged, it may take

several minutes before the charging indicator is dis-

played.

To switch your phone on, press and hold the power

key until the phone vibrates. The phone guides you

through the setup.

3. Learn more about your new

Nokia phone

For a printable user guide, online user guide, and

troubleshooting help, go to www.nokia.com/

phones.

Get Started

Nokia X

TA-1029/ TA-

1007 EN 1.0

PartnumberX

Main camera

Microphone

Loudspeaker

Charger connector

Audio connector

Microphone

Front camera

Earpiece

Power/Lock key

Volume keys

Proximity sensor

ENUS

Dynamo

QSG

DRAFT

Page

Thursday

July

2017

3:10

Product and Safety info

Important: For important info on the safe use of your device and

battery, read the Product and safety info booklet before you take

your device into use.

You can only use your device on the GSM/GPRS/EDGE 850/900/

1800/1900; WCDMA 1/2/5/8; LTE 1/3/5/7/8/20/28/38/40/

networks. You need a subscription with a service provider.

Important: 4G/LTE might not be supported by your network

service provider or by the service provider you are using when

traveling. In these cases, you may not be able to make or receive

calls, send or receive messages or use mobile data connections. To

make sure your device works seamlessly when full 4G/LTE service is

not available, it is recommended that you change the highest

connection speed from 4G to 3G. To do this, on the home screen, tap

Settings > Mobile networks, and switch Preferred network type to

2G/3G.

For more info, contact your network service provider.

Maximum transmit power

Your device has an internal, non-removable rechargeable battery. Do

not attempt to remove the battery, as you may damage the device.

To replace the battery, take the device to the nearest authorised

service facility.

Charge your device with FC0100 (EU plug) / FC0101 (UK plug) /

FC0102 (US plug) / FC0103 (AUS plug) / FC0111 (India plug) charger,

depending on the plug type of your country. HMD Global may make

additional battery or charger models available for this device.

Charging time can vary depending on device capability. Third-party

chargers that comply with the applicable USB requirements, and that

can connect to your device USB connector, may also be compatible.

Some of the accessories mentioned in this user guide, such as

charger, headset, or data cable, may be sold separately.

The surface of the device is nickel-free.

Theoretical talk time: Up to 23.49 hours.

Theoretical standby time: Up to 24 days (display off)

Use only compatible memory cards approved for use with this device.

Incompatible cards may damage the card and the device and corrupt

data stored on the card.

Note: Pre-installed system software and apps use a significant

part of memory space.

Keep a safe distance when using the flash. Do not use the flash on

people or animals at close range. Do not cover the flash while taking

a photo.

Certification information

(SAR)

This mobile device meets guidelines for exposure to radio waves as

set forth by the Council of Europe (CE) and the Federal

Communications Commission (FCC). Refer to the following.

European RF Exposure Information

Your mobile device is a radio transmitter and receiver. It is designed

not to exceed the limits for exposure to radio waves recommended

by international guidelines. These guidelines were developed by the

independent scientific organization ICNIRP and include safety

margins designed to assure the protection of all persons, regardless

of age and health. The guidelines use a unit of measurement known

as the Specific Absorption Rate, or SAR.

The SAR limit for mobile devices is 2.0 W/kg and the highest SAR

value for this device when tested at the ear is 0.289 W/kg*. As mobile

devices offer a range of functions, they can be used in other

positions, such as on the body. In this case, the highest tested SAR

value is 1.530 W/kg* at the separation distance of 0.5 cm from the

body.

For electronic safety, maintain the separation distance with

accessories containing no metal, that position handset a minimum of

the above distance. Use of other accessories may not ensure

compliance with RF exposure guidelines.

*The tests are carried out in accordance with international guidelines

for testing.

FCC RF Exposure Information

Your handset is a radio transmitter and receiver. It is designed and

manufactured not to exceed the emission limits for exposure to

radio frequency (RF) energy set by the Federal Communications

Commission of the U.S. Government. The guidelines are based on

standards that were developed by independent scientific

organization through periodic and thorough evaluation of scientific

studies. The standards include a substantial safety margin designed

to assure the safety of all persons, regardless of age and health. The

exposure standard for wireless handsets employs a unit of

measurement known as the Specific Absorption Rate, or SAR. The

SAR limit set by the FCC is 1.6 W/kg. The tests are performed in

positions and locations (e.g. at the ear and worn on the body) as

required by the FCC for each model. The highest SAR value for this

model handset as reported to the FCC when tested for use at the ear

is x.xxx W/kg, and when worn on the body in a holder or carry case, is

x.xxx W/kg.

Body-worn Operation; This device was tested for typical body-worn

operations with the handset kept 1.5 cm from the body. To maintain

compliance with FCC RF exposure requirements, use accessories that

maintain a 1.5 cm separation distance between the user’s body and

the handset. The use of belt clips, holsters and similar accessories

should not contain metallic components in its assembly. The use of

accessories that do not satisfy these requirements may not comply

with FCC RF exposure requirements, and should be avoided. The FCC

has granted an Equipment Authorization for this model handset with

all reported SAR levels evaluated as in compliance with the FCC RF

emission guidelines. SAR information on this model handset is on file

with the FCC and can be found under the Display Grant section of

www.fcc.gov/oet/ea/ after searching on FCC ID 2AJOTTA-1029 and

FCC ID 2AJOTTA-1007.

Additional information on Specific Absorption Rates (SAR) can be

found on the FCC website at www.fcc.gov/general/radio-frequency-

safety-0.

To send data or messages, a good connection to the network is

needed. Sending may be delayed until such a connection is available.

Follow the separation distance instructions until the sending is

finished.

During general use, the SAR values are usually well below the values

stated above. This is because, for purposes of system efficiency and

to minimise interference on the network, the operating power of

your mobile is automatically decreased when full power is not needed

for the call. The lower the power output, the lower the SAR value.

Device models may have different versions and more than one value.

Component and design changes may occur over time and some

changes could affect SAR values.

For more info, go to www.sar-tick.com. Note that mobile devices

may be transmitting even if you are not making a voice call.

Your mobile device is also designed to meet the United States

Federal Communications Commission (FCC) guidelines. FCC ratings

for your device and more information on SAR can be found at http:/

/transition.fcc.gov/oet/rfsafety/sar.html.

The World Health Organization (WHO) has stated that current

scientific information does not indicate the need for any special

precautions when using mobile devices. If you are interested in

reducing your exposure, they recommend you limit your usage or use

a hands-free kit to keep the device away from your head and body.

For more information and explanations and discussions on RF

exposure, go to the WHO website at www.who.int/peh-emf/en.

This device has an electronic label for certification information. To

access it, select Settings > About Phone > Certification.

Copyrights and other notices

Declaration of Conformity

Hereby, HMD Global Oy declares that this product is in

compliance with the essential requirements and other

relevant provisions of Directive 2014/53/EU. A copy of the

Declaration of Conformity can be found at www.nokia.com/

mobile-declaration-of-conformity.

FCC notice:

This device complies with part 15 of the FCC rules.Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation. For more info, go to www.fcc.gov/engineering-

technology/electromagnetic-compatibility-division/radio-

frequency-safety/faq/rf-safety. Any changes or modifications not

expressly approved by HMD Global could void the user’s authority to

operate this equipment. Note: This equipment has been tested and

found to comply with the limits for a Class B digital device, pursuant

to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Qualcomm and Snapdragon are trademarks of Qualcomm

Incorporated, registered in the United States and other countries.

exclusive licensee of the Nokia brand for phones & tablets. Nokia is a

registered trademark of Nokia Corporation.

GSM 850 33 dBm

GSM 900 33 dBm

GSM 1800 30 dBm

GSM 1900 30 dBm

WCDMA FDD1 24 dBm

WCDMA FDD 2 23.5 dBm

WCDMA FDD 5 24 dBm

WCDMA FDD 8 24 dBm

LTE Band 1 23 dBm

LTE Band 3 23 dBm

LTE Band 5 23 dBm

LTE Band 7 23 dBm

LTE Band 8 23 dBm

LTE Band 20 23 dBm

LTE Band 28 23 dBm

LTE Band 38 23 dBm

LTE Band 40 23 dBm

Bluetooth 10 dBm

WLAN 2.4 G 17.5 dBm
