HMD global TA-1012 Smart Phone User Manual

HMD global Oy Smart Phone

User Manual

1. Insert the SIM and memory
card
1. Open the SIM tray and memory card tray by
putting the provided tray opener into the hole next
to the tray.
2. Put the nano-SIM into slot 1 located on the tray
with the contact area face down. If you have a dual
SIM variant, you can either put a second SIM or a
memory card into slot 2. If you have a single SIM
variant, you can only put a memory card into slot 2.
3. Slide the SIM and memory card trays back into
the slots.
Use only original nano-SIM cards. Use of
incompatible SIM cards may damage the card or the
device, and may corrupt data stored on the card.
2. Charge the battery and switch
the phone on
Plug a compatible charger into a wall outlet, and
connect the cable to your phone. Your phone
supports the USB-C cable. You can also charge your
phone from a computer with a USB cable, but it may
take a longer time.
If the battery is completely discharged, it may take
several minutes before the charging indicator is
displayed.
To switch your phone on, press and hold the power
key until the phone vibrates. The phone guides you
through the setup.
3. Learn more about your new
Nokia phone
For a printable user guide, online user guide, and
troubleshooting help, go to www.nokia.com/
mobile-support.
Get Started
Nokia 8
TA-1012/TA-1004 DS EN 0.17
Main cameras
Loudspeaker
Microphone
Charger connector
Fingerprint sensor/Home
Audio connector
Microphone
SIM card/MicroSD card
Front camera
Earpiece
Power/Lock key
Volume keys
Microphone
USB-C USB micro-B
Product and Safety info
Important: We invite you to read the enclosed instructions before
installing your equipment. For valuable information on the safe use
of the device and battery, read the Product and safety info booklet
before you take your device into use. For important info on the safe
use of your device and battery, read the Product and safety info
booklet before you take your device into use.
You can only use your device on the GSM/GPRS/EDGE 5,8,2,3 850/
900/1800/1900; HSPA 1,2,4,5,8 2100/1900/1700/850/900; LTE 1/
2/3/4/5/7/8/20/28/38/40/41 networks. You need a subscription
with a service provider.
Important: 4G/LTE might not be supported by your network
service provider or by the service provider you are using when
traveling. In these cases, you may not be able to make or receive
calls, send or receive messages or use mobile data connections. To
make sure your device works seamlessly when full 4G/LTE service is
not available, it is recommended that you change the highest
connection speed from 4G to 3G. To do this, on the home screen, tap
Settings > Mobile networks, and switch Preferred network type to
2G/3G.
For more info, contact your network service provider.
Maximum transmit power
Your device has an internal, non-removable rechargeable battery. Do
not attempt to remove the battery, as you may damage the device.
To replace the battery, take the device to the nearest authorised
service facility.
Charge your device with FC0300 (EU plug) / FC0301 (UK plug) /
FC0302 (US plug) / FC0303 (AUS plug) / FC0311 (India plug) / FC0304
(CN plug) charger, depending on the plug type of your country. HMD
Global may make additional battery or charger models available for
this device. Charging time can vary depending on device capability.
Third-party chargers that comply with the applicable USB
requirements, and that can connect to your device USB connector,
may also be compatible. Some of the accessories mentioned in this
user guide, such as charger, headset, or data cable, may be sold
separately.
Note: The device is restricted to indoor use only when operating
in the 5150 to 5350 MHz frequency range in the following
countries:The surface of the device is nickel-free.
Theoretical talk time: Up to 23.5 hours.
Theoretical standby time: Up to 8.7 days (display off)
Use only compatible memory cards approved for use with this device.
Incompatible cards may damage the card and the device and corrupt
data stored on the card.
Note: Pre-installed system software and apps use a significant
part of memory space.
Keep a safe distance when using the flash. Do not use the flash on
people or animals at close range. Do not cover the flash while taking
a photo.
Certification information
(SAR)
This mobile device meets guidelines for exposure to radio waves as
set forth by the Council of Europe (CE) and the Federal
Communications Commission (FCC). Refer to the following.
European RF Exposure Information
Your mobile device is a radio transmitter and receiver. It is designed
not to exceed the limits for exposure to radio waves recommended
by international guidelines. These guidelines were developed by the
independent scientific organization ICNIRP and include safety
margins designed to assure the protection of all persons, regardless
of age and health. The guidelines use a unit of measurement known
as the Specific Absorption Rate, or SAR.
The SAR limit for mobile devices is 2.0 W/kg and the highest SAR
value for this device when tested at the ear is 0.711 W/kg*. As mobile
devices offer a range of functions, they can be used in other
positions, such as on the body. In this case, the highest tested SAR
value is 1.330 W/kg* at the separation distance of 0.5 cm from the
body.
For electronic safety, maintain the separation distance with
accessories containing no metal, that position handset a minimum of
the above distance. Use of other accessories may not ensure
compliance with RF exposure guidelines.
*The tests are carried out in accordance with international guidelines
for testing.
FCC RF Exposure Information
Your handset is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limits for exposure to
radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. The guidelines are based on
standards that were developed by independent scientific
organization through periodic and thorough evaluation of scientific
studies. The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and health. The
exposure standard for wireless handsets employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The
SAR limit set by the FCC is 1.6 W/kg. The tests are performed in
positions and locations (e.g. at the ear and worn on the body) as
required by the FCC for each model. The highest SAR value for this
model handset as reported to the FCC when tested for use at the ear
is 1.09 W/kg, and when worn on the body in a holder or carry case, is
0.49 W/kg.
Body-worn Operation; This device was tested for typical body-worn
operations with the handset kept 1.5 cm from the body. To maintain
compliance with FCC RF exposure requirements, use accessories that
maintain a 1.5 cm separation distance between the user’s body and
the handset. The use of belt clips, holsters and similar accessories
should not contain metallic components in its assembly. The use of
accessories that do not satisfy these requirements may not comply
with FCC RF exposure requirements, and should be avoided. The FCC
has granted an Equipment Authorization for this model handset with
all reported SAR levels evaluated as in compliance with the FCC RF
emission guidelines. SAR information on this model handset is on file
with the FCC and can be found under the Display Grant section of
www.fcc.gov/oet/ea/ after searching on FCC ID 2AJOTTA-1012 and
FCC ID 2AJOTTA-1004.
Additional information on Specific Absorption Rates (SAR) can be
found on the FCC website at www.fcc.gov/general/radio-frequency-
safety-0.
To send data or messages, a good connection to the network is
needed. Sending may be delayed until such a connection is available.
Follow the separation distance instructions until the sending is
finished.
During general use, the SAR values are usually well below the values
stated above. This is because, for purposes of system efficiency and
to minimise interference on the network, the operating power of
your mobile is automatically decreased when full power is not needed
for the call. The lower the power output, the lower the SAR value.
Device models may have different versions and more than one value.
Component and design changes may occur over time and some
changes could affect SAR values.
For more info, go to www.sar-tick.com. Note that mobile devices
may be transmitting even if you are not making a voice call.
Your mobile device is also designed to meet the United States
Federal Communications Commission (FCC) and Industry Canada SAR
(IC) guidelines. FCC ratings for your device and more information on
SAR can be found at http://transition.fcc.gov/oet/rfsafety/
sar.html. Information on IC SAR can be found at http://www.ic.gc.ca.
The World Health Organization (WHO) has stated that current
scientific information does not indicate the need for any special
precautions when using mobile devices. If you are interested in
reducing your exposure, they recommend you limit your usage or use
a hands-free kit to keep the device away from your head and body.
For more information and explanations and discussions on RF
exposure, go to the WHO website at www.who.int/peh-emf/en.
This device has an electronic label for certification information. To
access it, select Settings > About Phone > Certification.
Electrical information of the device
Copyrights and other notices
Declaration of Conformity
Hereby, HMD Global Oy declares that this product is in
compliance with the essential requirements and other
relevant provisions of Directive 2014/53/EU. A copy of the
Declaration of Conformity can be found at www.nokia.com/
mobile-declaration-of-conformity.
FCC notice:
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation. For more info, go to www.fcc.gov/engineering-
technology/electromagnetic-compatibility-division/radio-
frequency-safety/faq/rf-safety. Any changes or modifications not
expressly approved by HMD Global could void the user’s authority to
operate this equipment. Note: This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The list of importers in Mexico can be found in the Spanish version of
this guide.
Importer (this information applies only in Mexico):
Grand Cel S.A. de C.V.
106 Avenida Via Gustavo Baz, Int. 302
Colonia Cervecería Modelo
Naucalpan de Juárez
Edo de México
CP 53330
RFC: GCE1410146Y9
PEGASO PCS S.A. DE C.V
Prolongación Paseo de la Reforma No. 1200 Piso 14
Colonia Cruz Manca
Delegación Cuajimalpa de Morelos
México, Ciudad de Mexico C.P. 05349
RFC PPC980624U16
PARKTEL MEXICO, S.A. DE C.V.
Leibnitz 185
Colonia Anzures
11590 CDMX
RFC PME170503EK0
PACIFIC. COM. MX SA DE CV
Versalles 63
Colonia Juárez
Delegación Cuauhtémoc
CP 06600
México DF.
RFC PCM020219JQ6
Made in China
Qualcomm and Snapdragon are trademarks of Qualcomm
Incorporated, registered in the United States and other countries.
ZEISS, the ZEISS logo, Tessar and T* are registered trademarks of
Carl Zeiss AG used under license of Carl Zeiss Vision GmbH.
© 2017 HMD Global. All rights reserved. HMD Global Oy is the
exclusive licensee of the Nokia brand for phones & tablets. Nokia is a
registered trademark of Nokia Corporation.
GSM 850 32.5 dBm
GSM 900 32.5 dBm
DCS 1800 30 dBm
PCS 1900 30 dBm
WCDMA FDD I 24 dBm
WCDMA FDD II 24 dBm
WCDMA FDD IV 24 dBm
WCDMA FDD V 24 dBm
WCDMA FDD VIII 24 dBm
LTE Band 1 23 dBm
LTE Band 2 23 dBm
LTE Band 3 23 dBm
LTE Band 4 23 dBm
LTE Band 5 23 dBm
LTE Band 7 23 dBm
LTE Band 8 23 dBm
LTE Band 20 23 dBm
LTE Band 28 23 dBm
LTE Band 38 23 dBm
LTE Band 40 23 dBm
LTE Band 41 23 dBm
Bluetooth 10 dBm
WLAN 2.4 G 18 dBm
WLAN 5 G 16 dBm
NFC 420 mW
AT BE BG HR CY CZ DK
EE FI FR DE EL HU IE
IT LV LT LU MT NL PL
PT RO SK SI ES SE UK
Product Mobile phone
Supplier HMD Global
Model TA-1004/DS, TA-1012/SS
Charger FC0302
The following electrical characteristics apply to HMD Global
FC0302 chargers only:
Input 100-240 Vca, 50-60 Hz,
0-500 mA
Output 5,0 Vcc 0-2500 mA
9,0 Vcc 0-2000 mA
12,0 Vcc 0-1500 mA
Rechargeable battery
supplier
HMD Global
Phone power
consumption
3,8 mW

Navigation menu
