Explorer 9800 Multi-Screen Gateway Series Safety Sheet
78-4041467-01C0
INLET
Page Size: 8.5 x 11
Color process: Black (1/1) double sided
Paper weight: 20#
Paper type: Opaque
Varnish: N/A
Number of Pages: 1 page (N/A signatures)
COVER N/A
BINDING N/A
![](/img.php?id=3071313&img=bg2.png)
Safety Instructions and Regulatory Notices
Notice to Installers
The servicing instructions in this notice are for use by qualified service personnel only. To reduce
the risk of electric shock, do not perform any servicing other than that contained in the operating
instructions, unless you are qualified to do so.
Outdoor Grounding System
If this product connects to an outdoor antenna or cable system, be sure the antenna or cable
system is grounded (earthed). This provides some protection against voltage surges and built-
up static charges.
Article 810 of the National Electric Code (NEC) ANSI/NFPA No. 70-1990, provides the
following information:
•
Grounding of the mast and supporting structure
•
Grounding the lead-in wire to an antenna discharge unit
•
Size of the grounding conductors
•
Location of the antenna-discharge unit
•
Connection to grounding electrodes
•
Requirements for the grounding electrodes (see the following antenna grounding diagram
as recommended by NEC ANSI/NFPA 70)
IMPORTANT SAFETY INSTRUCTIONS
1)
Read these instructions.
2)
Keep these instructions.
3)
Heed all warnings.
Protect the Product from Lightning
T11518
4)
Follow all instructions.
5)
Do not use this apparatus near water.
6)
Clean only with dry cloth.
7)
Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8)
Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9)
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
10)
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11)
Only use attachments/accessories specified by the manufacturer.
12)
Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13)
Unplug this apparatus during lightning storms or when unused for long periods of time.
14)
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as a power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Power Source Warning
A label on this product indicates the correct power source for this product. Operate this product
only from an electrical outlet with the voltage and frequency indicated on the product label. If
you are uncertain of the type of power supply to your home or business, consult your service
provider or your local power company.
The AC inlet on the unit must remain accessible and operable at all times.
Ground the Product
In addition to disconnecting the AC power from the wall outlet, disconnect the signal inputs.
Verify the Power Source from the On/Off Power Light
When the on/off power light is not illuminated, the apparatus may still be connected to the
power source. The light may go out when the apparatus is turned off, regardless of whether it is
still plugged into an AC power source.
Eliminate AC Power/Mains Overloads
Handling Disposable Batteries
This product may contain disposable batteries. Heed the following warning and follow the Battery
Safety and Battery Disposal instructions below.
Battery Safety
•
Insert batteries correctly. There may be a risk of explosion if the batteries are incorrectly
inserted.
•
Do not attempt to recharge ‘disposable’ or ‘non-reusable’ batteries.
•
Please follow instructions provided for charging ‘rechargeable’ batteries.
•
Replace batteries with the same or equivalent type that we recommend.
•
Do not expose batteries to excessive heat (such as sunlight or fire).
•
Do not expose batteries to temperatures above 100°C (212°F).
Battery Disposal
•
The batteries may contain substances that could be harmful to the environment.
•
Recycle or dispose of batteries in accordance with the battery manufacturer’s instructions
and local/national disposal and recycling regulations.
•
The batteries may contain perchlorate, a known hazardous substance, so special handling
and disposal of this product might be necessary. For more information about perchlorate
and best management practices for perchlorate-containing substance, see
www.dtsc.ca.gov/
hazardouswaste/perchlorate
WARNING: There is danger of explosion if the battery is mishandled or
incorrectly replaced. Replace only with the same type of battery. Do not disassemble
it or attempt to recharge it outside the system. Do not crush, puncture, dispose of in
fire, short the external contacts, or expose to water or other liquids. Dispose of the
battery in accordance with local regulations and instructions from your service provider.
WARNING: Avoid electric shock and fire hazard! Do not overload AC power/
mains, outlets, extension cords, or integral convenience receptacles. For products that
require battery power or other power sources to operate them, refer to the operating
instructions for those products.
WARNING: Avoid electric shock and fire hazard! Do not locate an outside
antenna system in the vicinity of overhead power lines or power circuits. Touching
power lines or circuits might be fatal.
WARNING: Avoid electric shock and fire hazard! If this product connects to
cable wiring, be sure the cable system is grounded (earthed). Grounding provides
some protection against voltage surges and built-up static charges.
Note to System Installer
For this apparatus, the coaxial cable shield/screen
shall be grounded as close as practical to the
point of entry of the cable into the building.For
produc ts so ld in th e US and Ca na d a , th is
reminder is provided to call the system installer's
attention to Article 820-93 and Article 820-100
of the NEC (or Canadian Electrical Code Part 1),
which provides guidelines for proper grounding CAUTION: To reduce the risk of electric shock, do not
of the coaxial cable shield.
remove cover (or back). No user-serviceable parts
inside. Refer servicing to qualified service personnel.
WARNING
TO PREVENT FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS UNIT TO RAIN OR MOISTURE.
This symbol is intended to alert y ou that
uninsulated voltage within this product may have
suffcient magnitude to cause electric shock.
Therefore, it is dangerous to make any kind of
contact with any inside part of this product.
Ce symbole a pour but d’alerter toute personne
qu’un contact avec une pièce interne de ce
produit, sous tension et non isolée, pourrait être
This symbol is intended to alert you of the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying this product.
suffsant pour provoquer un choc électrique. Il Ce symbole a pour but de vous avertir qu’une documentation
est donc dangereux d’être en contact avec importante sur le fonctionnement et l’entretien accompagne
toute pièce interne de ce produit.
ce produit.
![](/img.php?id=3071313&img=bg3.png)
WARNING: Avoid electric shock! Do not open the cover of this product. Opening
or removing the cover may expose you to dangerous voltages. If you open the cover,
your warranty will be void. This product contains no user-serviceable parts.
WARNING: Avoid electric shock and fire hazard! Never push objects through
the openings in this product. Foreign objects can cause electrical shorts that can result
in electric shock or fire.
Provide Ventilation and Select a Location
•
Remove all packaging material before applying power to the product.
•
Do not place this apparatus on a bed, sofa, rug, or similar surface.
•
Do not place this apparatus on an unstable surface.
•
Do not place this apparatus in excessive heat or moisture.
•
Do not install this apparatus in an enclosure, such as a bookcase or rack, unless the installation
provides proper ventilation.
•
Do not place entertainment devices (such as VCRs or DVDs), lamps, books, vases with
liquids, or other objects on top of this product.
•
Do not block ventilation openings.
Operating Environment
This product is designed for operation indoors with a temperature range from 32° to 104° F (0°
to 40°C). Each product should have adequate spacing on all sides so that the cooling air vents
on the chassis are not blocked.
Protect from Exposure to Moisture and Foreign Objects
Service Warnings
Check Product Safety
Upon completion of any service or repairs to this product, the service technician must perform
safety checks to determine that this product is in proper operating condition.
Protect the Product When Moving It
Always disconnect the power source when moving the apparatus or connecting or disconnecting cables.
United States FCC Compliance
This device has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
such interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy. If not installed and used in accordance with the instructions, it may cause
harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment OFF and ON, the
user is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
•
Consult the service provider or an experienced radio/television technician for help.
The information shown in the FCC Declaration of Conformity paragraph below is a requirement of the
FCC and is intended to supply you with information regarding the FCC approval of this device. The
phone numbers listed are for FCC-related questions only and not intended for questions regarding
the connection or operation for this device. Please contact your service provider for any questions
you may have regarding the operation or installation of this device.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.
RF Exposure - This device is only authorized for use in a mobile application. At least
20 cm of separation distance between the set top device and the user's body must be
maintained at all times.
Responsible Party: Technicolor, 101W. 103rd St., Indianapolis, IN 46290 USA, 317-587-5466.
Declaration of Conformity
This device complies with Part 15 of FCC Rules. Operation is subject to the following two
conditions: 1) the device may not cause harmful interference, and 2) the device must accept any
interference received, including interference that may cause undesired operation.
Canada EMI Regulation
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la class B est conforme à la norme NMB-003 du Canada.
AVC Video License
With respect to each AVC/H.264 product, we are obligated to provide the following notice:
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE
FOR THE PERSONAL USE OF A CONSUMER OR OTHER USES IN WHICH IT DOES
NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO IN COMPLIANCE WITH
THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT
WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/
OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM..
Accordingly, please be advised that service providers, content providers, and broadcasters may
be required to obtain a separate use license from MPEG LA prior to any use of AVC/H.264
encoders and/or decoders.
Rovi Corporation Copyright Notice
This product incorporates copyright protection technology that is protected by U.S. patents
and other intellectual property rights of Rovi Corporation. Use of this copyright protection
technology must be authorized by Rovi Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering and
disassembly are prohibited.
Disclaimer
Technicolor will not be responsible for any licensing fees payable to Rovi Corporation, and
Technicolor will not have any indemnification obligations relating to any claims asserted by Rovi
Corporation, or by any entity controlled by, controlling, or under common control with Rovi
Corporation (“Rovi Entities”), or any entity used to license intellectual property of the Rovi Entities,
and the successors and assigns of the foregoing entities, including any claim related to electronic
programming guides alone or in combination with any equipment provided by Technicolor.
Open Source Software Notification
This product may contain certain open source software modules which are subject to Open
Source Software license terms.
A list of the Open Source Software used or provided under this release and their corresponding
Licenses and version number are available on Technicolor’s website at the following address: http://
www.technicolor.com/en/hi/minisites/open-software or at another address as Technicolor may
provide from time to time.
If and where applicable, depending on the terms of the applicable Open Source Software licenses,
the source codes of the Open Source Software are available for free on Technicolor’s website at
the following address: http://www.technicolor.com/en/hi/minisites/open-software.
For avoidance of doubt, Open Source Software is only licensed by the original owner of the
Open Source Software under the terms set forth in the designated Open Source License.
Trademark Statements
The terms HDMI and HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC
in the United States and other countries.
Rovi is a trademark of Rovi Corporation.
78 -4041467- 01C0
TECHNICOLOR
1-5, rue Jeanne d’Arc
92130 Issy-les-Moulineaux
France
www.technicolor.com
Copyright 2016 Technicolor. All rights reserved.
All tradenames referenced are service marks,
trademarks, or registered trademarks of their
respective companies. Specifications subject to
change without notice.
DMS3-SAF-25-263 v1.0
WARNING: Avoid electric shock and fire hazard! Unplug this product before
cleaning. Do not use a liquid cleaner or an aerosol cleaner. Do not use a magnetic/
static cleaning device (dust remover) to clean this product.
WARNING: Avoid electric shock and fire hazard! Do not expose this product
to dripping or splashing liquids, rain, or moisture. Objects filled with liquids, such as
vases, should not be placed on this apparatus.
