HON HAI PRECISION IND T77H262 802.11b/g/n WLAN Module User Manual
HON HAI Precision Ind. Co., Ltd. 802.11b/g/n WLAN Module
User Manual
COMPANY CONFIDENTIAL
T77H262.00
SDIO WiFi Module
Rev. 1.0
Prepared by Reviewed by Approved by
Frey Ai-ning Robin
COMPANY CONFIDENTIAL
1. Revision History
Date Change Note REV
Note
2011-05-08 Initial Release 1.0
COMPANY CONFIDENTIAL
2. Introduction
Project Name: 802.11 b/g/n wireless card
The T77H262.00 802.11b/g/n module provides wireless modem functionality
utilizing direct sequence spread spectrum and OFDM/CCK technology. This module is
based on Broadcom BCM4319GKUBG P20 solution which is integrated 2.4GHz
IEEE802.11 b/g/n (MAC/baseband/radio), power amplifiers (PA), and power
management unit (PMU).
2.1 Scope
The wireless LAN is compliant to IEEE 802.11b and IEEE 802.11g and IEEE
802.11n standard. The data rate of 802.11b is up to 11Mbps and fallback rates of 5.5, 2,
1Mbps. The data rate of 802.11g is up to 54Mbps and fallback rates of 48,36,24,18,12,9,
6Mbps. The data rate of 802.11n HT20 with 800ns GI is up to 65Mbps and fallback rates
of 58.5, 52, 39, 26, 19.5, 13, 6.5Mbps; the data rate of 802.11n HT20 with 400ns GI is
up to 72.2Mbps and fallback rates of 65, 57.8, 43.3, 28.9, 21.7, 14.4, 7.2Mbps.
The data rate of 802.11n HT40 with 800ns GI is up to 135Mbps and fallback rates of
121.5, 108, 81, 54, 40.5, 27, 13.5Mbps. The data rate of 802.11n HT40 with 400ns GI is
up to 150Mbps and fallback rates of 135, 120, 90, 60, 45, 30, 15Mbps.
2.2 Function
¾ IEEE802.11b/g/n (1X1) based on Broadcom 4319 solution.
¾ SDIO 2.0 Interface.
¾ Module is powered by the host with a 3.3V +/- 10% supply.
¾ Two PCB printed antennas.
¾ One DPDT switch for antenna diversity.
¾ RoHS and Green Compliant.
3. Product Specification
3.1 Electrical Characteristics
Parameter Minimum Typical Maximum Units
Frequency Range 2.4 ~ 2.5 GHz
Input Supply
Voltage Absolute maximum
Voltage 3.0 3.3 3.6 V
CCK 15.5 17 18.5 dBm
OFDM BPSK 12.5 14 15.5 dBm
OFDM QPSK 12.5 14 15.5 dBm
OFDM 16QAM 12.5 14 15.5 dBm
OFDM 64QAM 12.5 14 15.5 dBm
Tx Output
MCS0~7 12.5 14 15.5 dBm
Storage Temperature -20 ~ 85 ℃
Storage Humidity 0 ~ 90 %
HBM - TBD - V
ESD Level MM - TBD - V
3.2 WiFi RF Specification
3.2.1 IEEE802.11b Mode
COMPANY CONFIDENTIAL
Radio Technology Direct Sequence Spread Spectrum (DSSS)
Operating Frequency 2412 ~ 2484MHz ISM band
Modulation Schemes DQPSK, DBPSK and CCK
Channel Numbers 11 channels for United States
13 channels for Europe Countries
14 channels for Japan
Data Rate 1Mbps , 2Mbps, 5.5Mbps and 11Mbps
Media Access Protocol
(MAC)
CSMA/CA (Carrier Sense Multiple Access with Collision
Avoidance)
Transmitter Output Power 17.0 dBm+/-1.5dBm for all data rate.
Frequency Accuracy +/-25ppm
Minimum Receiver
Sensitivity Level
Typical –97dBm for 1Mbps @ 8% PER
Typical –94dBm for 2Mbps @ 8% PER
Typical –91dBm for 5.5Mbps @ 8% PER
Typical –88dBm for 11Mbps @ 8% PER
Maximum Receiver
Sensitivity Level
Maximum –20dBm
EVM Typical 18% for 1Mbps @17dBm output power
Typical 18% for 2Mbps @17dBm output power
Typical 18% for 5.5Mbps @17dBm output power
Typical 18% for 11Mbps @17dBm output power
3.2.2 IEEE802.11g Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2412 ~ 2472MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 11 channels for United States
13 channels for Europe Countries
Data Rate 6 Mbps,9, 12, 18, 24, 36, 48, and 54Mbps
Media Access Protocol
(MAC)
CSMA/CA (Carrier Sense Multiple Access with Collision
Avoidance)
Transmitter Output
Power
14.0 dBm+/-1.5dBm for all data rate.
Frequency Accuracy +/-25ppm
Minimum Receiver
Sensitivity Level
Typical –89dBm for 6Mbps @ 10% PER
Typical –89dBm for 9Mbps @ 10% PER
Typical –88dBm for 12Mbps @ 10% PER
Typical –86dBm for 18Mbps @ 10% PER
Typical –84dBm for 24Mbps @ 10% PER
Typical –80dBm for 36Mbps @ 10% PER
Typical –76dBm for 48Mbps @ 10% PER
Typical –75dBm for 54Mbps @ 10% PER
Maximum Receiver
Sensitivity Level
Maximum –20dBm
COMPANY CONFIDENTIAL
EVM Typical –30dB for 6Mbps @14dBm output power
Typical –30dB for 9Mbps @14dBm output power
Typical –30dB for 12Mbps @14dBm output power
Typical –30dB for 18Mbps @14dBm output power
Typical –30dB for 24Mbps @14dBm output power
Typical –30dB for 36Mbps @14dBm output power
Typical –30dB for 48Mbps @14dBm output power
Typical –30dB for 54Mbps @14dBm output power
3.2.3 IEEE802.11n (HT20) Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2412 ~ 2472MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 11 channels for United States
13 channels for Europe Countries
Data Rate 800ns GI: 6.5Mbps, 13, 19.5, 26, 39, 52, 58.5 and 65Mbps
400ns GI:7.2Mbps, 14.4, 21.7, 28.9, 43.3, 57.8, 65.0 and
72.2Mbps
Media Access Protocol
(MAC)
CSMA/CA (Carrier Sense Multiple Access with Collision
Avoidance)
Transmitter Output
Power
14.0 dBm+/-1.5dBm for all data rate
Frequency Accuracy +/-25ppm
Minimum Receiver
Sensitivity Level
Typical –89dBm for 6.5Mbps @ 10% PER
Typical –87dBm for 13Mbps @ 10% PER
Typical –85dBm for 19.5Mbps @ 10% PER
Typical –80dBm for 26Mbps @ 10% PER
Typical –79dBm for 39Mbps @ 10% PER
Typical –75dBm for 52Mbps @ 10% PER
Typical –73dBm for 58.5Mbps @ 10% PER
Typical –71dBm for 65Mbps @ 10% PER
Maximum Receiver
Sensitivity Level
Maximum –20dBm
EVM Typical –31dB for MCS0 @14dBm output power
Typical –31dB for MCS1 @14dBm output power
Typical –31dB for MCS2 @14dBm output power
Typical –31dB for MCS3 @14dBm output power
Typical –31dB for MCS4 @14dBm output power
Typical –31dB for MCS5 @14dBm output power
Typical –31dB for MCS6 @14dBm output power
Typical –31dB for MCS7 @14dBm output power
IEEE802.11n (HT40) Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2422 ~ 2462MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 9 channels for all countries
COMPANY CONFIDENTIAL
Data Rate 800ns GI: 13.5 Mbps, 27, 40.5, 54, 81, 108, 121.5
and 135Mbps
400ns GI: 15Mbps, 30, 45, 60, 90, 120, 135 and
150Mbps
Media Access Protocol
(MAC) CSMA/CA (Carrier Sense Multiple Access with
Collision Avoidance)
Transmitter Output
Power 14.0 dBm+/-2dBm for all data rate
Frequency Accuracy +/-25ppm
Minimum Receiver
Sensitivity Level
Typical –83dBm for 13.5Mbps @ 10% PER
Typical –82dBm for 27Mbps @ 10% PER
Typical –81dBm for 40.5Mbps @ 10% PER
Typical –80dBm for 54Mbps @ 10% PER
Typical –72dBm for 81Mbps @ 10% PER
Typical –71dBm for 108Mbps @ 10% PER
Typical –69dBm for 121.5Mbps @ 10% PER
Typical –67dBm for 135Mbps @ 10% PER
Maximum Receiver
Sensitivity Level Minimum –7dBm @ 10% PER
EVM
Typical –30dB for MCS0 @14dBm output power
Typical –30dB for MCS1 @14dBm output power
Typical –30dB for MCS2 @14dBm output power
Typical –30dB for MCS3 @14dBm output power
Typical –30dB for MCS4 @14dBm output power
Typical –30dB for MCS5 @14dBm output power
Typical –30dB for MCS6 @14dBm output power
Typical –30dB for MCS7 @14dBm output power
Remark: The minimum sensitivity level is measured in FOXCONN RD Lab in shielding room. We
will back off about 3dB as manufacture test due to bad background noise and interference in our
production line.
4. Product Requirements and Characteristic
4.1 Hardware Characteristic
Form factor 44.5x40(mm
2) module with 1x11 pin connector
Host Interface SDIO 2.0
PCB 4-layer single side
Antenna &RF connector Two printed Antenna, with one for diversity.
4.2 Hardware Architecture
The T77H262.00 802.11b/g/n module is based on Broadcom BCM4319 solution which is with integrated
2.4GHz IEEE802.11 b/g/n (MAC/baseband/radio), power amplifiers (PA), and power management unit
COMPANY CONFIDENTIAL
(PMU).This module is powered from the host (3.3V) and interfaces to the host with SDIO 2.0 and with two
printed antennas for diversity and one on-board 26MHz XTAL.
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
This device is intended only for OEM integrators under the following
conditions:
1) The antenna must be installed such that 20 cm is maintained between the
antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or
antenna,
3) For all products market in US, OEM has to limit the operation channels in
CH1 to CH11 for 2.4G band by supplied firmware programming tool. OEM
shall not supply any tool or info to the end-user regarding to Regulatory
COMPANY CONFIDENTIAL
Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for
any additional compliance requirements required with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for
example certain laptop configurations or co-location with another transmitter),
then the FCC authorization is no longer considered valid and the FCC ID can not
be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and
obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may
be installed such that 20 cm may be maintained between the antenna and users.
The final end product must be labeled in a visible area with the following: “Contains
FCC ID: MCLT77H262”.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the end
product which integrates this module.
The end user manual shall include all required regulatory information/warning as
show in this manual.
Canadian Regulatory Wireless Notice
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils
radio exempts de licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le
dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce dispositif doit accepter
tout brouillage reçu, y compris un brouillage susceptible de provoquer un fonctionnement
indésirable.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
NOTE IMPORTANTE: (Pour l'utilisation de dispositifs mobiles)
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un
COMPANY CONFIDENTIAL
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de
20 cm de distance entre la source de rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions: (For module device
use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and
users, and
2) The transmitter module may not be co-located with any other transmitter or antenna,
3) For all products market in Canada, OEM has to limit the operation channels in CH1 to
CH11 for 2.4G band by supplied firmware programming tool. OEM shall not supply any tool
or info to the end-user regarding to Regulatory Domain change.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions
suivantes: (Pour utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée
entre l'antenne et les utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou
antenne,
3) Pour tous les produits vendus au Canada, OEM doit limiter les fréquences de
fonctionnement CH1 à CH11 pour bandes de fréquences 2.4G grâce aux outils de
microprogrammation fournis. OEM ne doit pas fournir d'outil ou d'informations à
l'utilisateur final en ce qui concerne le changement de réglementation de domaine.
Tant que les 3 conditions ci-dessus sont remplies, des essais supplémentaires sur
l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours
responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the Canada authorization is
no longer considered valid and the IC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines
configurations d'ordinateur portable ou de certaines co-localisation avec un autre
COMPANY CONFIDENTIAL
émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne peut
pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera
chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation
distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The final
end product must be labeled in a visible area with the following: “Contains IC:
2878D-T77H262”.
Plaque signal
é
tique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où
l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue
entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit
visible avec l'inscription suivante: "Contient des IC: 2878D-T77H262".
