HON HAI PRECISION IND T77H332 WLAN Module User Manual for T77H332
HON HAI Precision Ind. Co., Ltd. WLAN Module for T77H332
User Manual
COMPANY CONFIDENTIAL
1
T77H332 User Manual
Project Name NFC (Near Field Communication) Module
Rev. 00
FOXCONN Part No. T77H332
Module Rev. 00
Revision History
Revision Date Originator Comment
0.0 2012/12/20 Wei.Liao Initial
COMPANY CONFIDENTIAL
2
Content
REVISION HISTORY ....................................................................................................................................................... 1
1. INTRODUCTION .......................................................................................................................................................... 3
2. WIFI ALLIANCE CONFORMANCE .......................................................................................................................... 6
3. HARDWARE SPECIFICATION ................................................................................................................................. 7
4. PRODUCT REQUIREMENTS .................................................................................................................................. 11
COMPANY CONFIDENTIAL
3
1. Introduction
The T77H332.XX IEEE802.11b/g/n module is based on Marvell 88W8782UB0-NAP2C000
solution that is provide the combined functions of DSSS and OFDM baseband modulation,
MAC, CPU, OTP (one time programmable) memory, host interfaces, power management
unit (PMU) and direct conversion WLAN RF radio.
1.1 Scope
The wireless LAN is compliant to IEEE 802.11b and IEEE 802.11g and IEEE 802.11n
standard. The data rate of 802.11b is up to 11Mbps and fallback rates of 5.5, 2, 1Mbps.
The data rate of 802.11g is up to 54Mbps and fallback rates of 48,36,24,18,12,9, 6Mbps.
The data rate of 802.11n HT20 with 800ns GI is up to 65Mbps and fallback rates of 58.5,
52, 39, 26, 19.5, 13, 6.5Mbps; the data rate of 802.11n HT20 with 400ns GI is up to
72.2Mbps and fallback rates of 65, 57.8, 43.3, 28.9, 21.7, 14.4, 7.2Mbps. The data rate of
802.11n HT40 with 800ns GI is up to 135Mbps and fallback rates of 121.5, 108, 81, 54,
40.5, 27, 13.5Mbps. The data rate of 802.11n HT40 with 400ns GI is up to 150Mbps and
fallback rates of 135, 120, 90, 60, 45, 30, 15Mbps.
1.2 Function
• IEEE802.11b/g/n (1X1) based on Marvell 88W8782U solution.
• USB 2.0 Interface, High and Full Speeds supported.
• Powered by the host with a 3.3V +/- 10% supply.
• Two PCB printed antennas.
• One SPDT switch for antenna diversity.
• RoHS and Green Compliant.
• Linux supported with drivers based on Fedora Core 8.
COMPANY CONFIDENTIAL
4
1.3 Electrical Characteristics
Parameter Minimum Typical Maximum Units
Frequency Range 2.4 ~ 2.5 GHz
Current Consumption - - 600 mA
Input Supply
Voltage
Absolute
maximum voltage 2.97 3.3 3.63 V
Tx Output Power
11b 16.5 18 19.5 dBm
11g 12.5 14 15.5 dBm
11n-HT20 11.5 13 14.5 dBm
11n-HT40 10.5 12 13.5 dBm
Storage Temperature -20 ~ 85 ℃
Storage Humidity 0 ~ 90 %
Operation Temperature 0 ~ 60 ℃
ESD Level HBM - 1.5K - V
MM - 200 - V
Remark: The TX output powers just depend on conduct band-edge limit.
COMPANY CONFIDENTIAL
5
1.4 USB 2.0 Characteristics
Low / Full Speed
Parameter Minimum Typical Maximum Units
Input levels
Input high voltage (driven) 2.0 - - V
Input high voltage (floating) 2.7 - 3.6 V
Input low voltage - - 0.8 V
Differential input sensitivity 0.2 - - V
Differential common mode range 0.8 - 2.5 V
Output level
Output low voltage - - 0.3 V
Output high voltage (driven) 2.8 - 3.6 V
Output SE1 voltage 0.8 - V
Output signal crossover voltage 1.3 - 2.0 V
Driver
characteristics
Rise time 4 - 20 ns
Fall time 4 - 20 ns
Clock timing Full speed data rate - 12.0 - Mb/s
High Speed
Parameter Minimum Typical Maximum Units
Input levels
High-speed squelch detection
threshold
(differential signal amplitude) 100 - 150 mV
High-speed disconnect detection
threshold
(differential signal amplitude) 525 - 625 mV
High-speed data signaling
common mode voltage range -50 - 500 mV
Output level
High-speed idle level -10.0 - 10.0 mV
High-speed data signaling high 360 - 440 mV
High-speed data signaling low -10.0 - 10.0 mV
Chirp J level (differential voltage) 700 - 1100 mV
Chirp k level (differential voltage) -900 - -500 mV
Driver
characteristics
Rise time (10% - 90%) 500 - - ps
Fall time (10% - 90%) 500 - - ps
Clock timing Full speed data rate - 480 - Mb/s
COMPANY CONFIDENTIAL
6
2. WIFI ALLIANCE CONFORMANCE
The Module is certified by the Wi-Fi Alliance. The Module and standard PC driver passes
the Wi-Fi System Interoperability Test Plan including the following:
A. IEEE 802.11-2007 Standard for LAN/MAN
Specific requirements Part 11: Wireless LAN Medium Access Control (MAC) and
Physical Layer (PHY) Specifications
B. IEEE P802.11n-2009 Standard for Information Technology
Telecommunications and information exchange between systems - Local and
metropolitan area networks – Specific requirements - Part 11: Wireless LAN Medium
Access Control (MAC) and Physical Layer (PHY) Specifications Amendment 5:
Enhancements for Higher Throughput
C. Supported Encryption
• WEP64- and 128-bit encryption with hardware TKIP processing (WPA)
• AES-CCMP hardware implementation as part of 802.11i security standard (WPA2)
• AES-Cipher-Based Message Authentication Code (CMAC) as part of the 802.11w
security standard
• WLAN Authentication and Privacy Infrastructure (WAPI)
COMPANY CONFIDENTIAL
7
3. Hardware Specification
3.1 IEEE802.11b Mode
Radio Technology Direct Sequence Spread Spectrum (DSSS)
Operating Frequency 2412 ~ 2484MHz ISM band
Modulation Schemes DQPSK, DBPSK and CCK
Channel Numbers 11 channels for United States
13 channels for Europe Countries
14 channels for Japan
Data Rate 1Mbps, 2Mbps, 5.5Mbps and 11Mbps
Media Access Protocol
(MAC) CSMA/CA (Carrier Sense Multiple Access with
Collision Avoidance)
Transmitter Output Power 18.0 dBm+/-1.5dBm for all data rate.
Frequency Accuracy +/-15ppm
Minimum Receiver
Sensitivity Level
Typical –99dBm for 1Mbps @ 8% PER
Typical –96dBm for 2Mbps @ 8% PER
Typical –92dBm for 5.5Mbps @ 8% PER
Typical –89dBm for 11Mbps @ 8% PER
EVM (peak)
Typical 4% for 1Mbps @18dBm output power
Typical 4% for 2Mbps @18dBm output power
Typical 4% for 5.5Mbps @18dBm output power
Typical 4% for 11Mbps @18dBm output power
3.2 IEEE802.11g Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2412 ~ 2472MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 11 channels for United States
13 channels for Europe Countries
Data Rate 6 Mbps, 9, 12, 18, 24, 36, 48, and 54Mbps
Media Access Protocol
(MAC) CSMA/CA (Carrier Sense Multiple Access with
Collision Avoidance)
Transmitter Output Power 14.0 dBm+/-1.5dBm for all data rate.
Frequency Accuracy +/-15ppm
Minimum Receiver Typical –91dBm for 6Mbps @ 10% PER
COMPANY CONFIDENTIAL
8
Sensitivity Level
Typical –87dBm for 18Mbps @ 10% PER
Typical –75dBm for 54Mbps @ 10% PER
EVM
Typical –31dB for 6Mbps @15dBm output power
Typical –31dB for 54Mbps @15dBm output power
3.3 IEEE802.11n (HT20) Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2412 ~ 2472MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 11 channels for United States
13 channels for Europe Countries
Data Rate 800ns GI: 6.5Mbps, 13, 19.5, 26, 39, 52, 58.5 and
65Mbps
400ns GI: 7.2Mbps, 14.4, 21.7, 28.9, 43.3, 57.8, 65.0
and 72.2Mbps
Media Access Protocol
(MAC) CSMA/CA (Carrier Sense Multiple Access with
Collision Avoidance)
Transmitter Output Power 13.0 dBm+/-1.5dBm for all data rate
Frequency Accuracy +/-15ppm
Minimum Receiver
Sensitivity Level
Typical –91dBm for 6.5Mbps @ 10% PER
Typical –83dBm for 26Mbps @ 10% PER
Typical –72dBm for 65Mbps @ 10% PER
EVM Typical –32dB for MCS0 @15dBm output power
Typical –32dB for MCS7 @15dBm output power
3.4 IEEE802.11n (HT40) Mode
Radio Technology Orthogonal Frequency Division Multiplexing
(OFDM)
Operating Frequency 2422 ~ 2462MHz ISM band
Modulation Schemes BPSK, QPSK, 16QAM, 64QAM
Channel Numbers 9 channels for all countries
Data Rate 800ns GI: 13.5 Mbps, 27, 40.5, 54, 81, 108, 121.5 and
135Mbps
400ns GI: 15Mbps, 30, 45, 60, 90, 120, 135 and
150Mbps
Media Access Protocol
(MAC) CSMA/CA (Carrier Sense Multiple Access with
Collision Avoidance)
Transmitter Output Power 12.0 dBm+/-1.5dBm for all data rate
COMPANY CONFIDENTIAL
9
Frequency Accuracy +/-15ppm
Minimum Receiver
Sensitivity Level
Typical –88dBm for 13.5Mbps @ 10% PER
Typical –79dBm for 54Mbps @ 10% PER
Typical –69dBm for 135Mbps @ 10% PER
EVM
(Test condition:
Enable full packet channel
estimate)
Typical –31dB for MCS0 @15dBm output power
Typical –31dB for MCS7 @15dBm output power
Remark: The minimum sensitivity level is measured in FOXCONN RD Lab in shielding
room. We will back off about 3dB as manufacture test due to bad background noise and
interference in our production line.
3.5 Antenna Electrical Specification
Parameter Typical Units
Operating frequency range 2400 ~ 2500 MHz
Antenna gain (max) TBD TBD
3.6 Antenna Pattern
Main port
Frequency
(MHz)
Vertical Horizon
Peak gain
(dBi) Average gain
(dBi) Peak gain
(dBi) Average gain
(dBi)
2412 TBD TBD TBD TBD
2442 TBD TBD TBD TBD
2472 TBD TBD TBD TBD
Aux port
Frequency
(MHz)
Vertical Horizon
Peak gain
(dBi) Average gain
(dBi) Peak gain
(dBi) Average gain
(dBi)
2412 TBD TBD TBD TBD
2442 TBD TBD TBD TBD
2472 TBD TBD TBD TBD
COMPANY CONFIDENTIAL
10
3.7 Return Loss Measurement for S11
Return Loss Measurement for S11
Main antenna -20.536dB@2412MHz
-27.920dB@2442MHz
-38.556dB@2484MHz
Aux antenna -17.771dB@2412MHz
-26.397dB@2442MHz
-19.879dB@2484MHz
Main antenna
Aux antenna
Remark: the return loss measurement is base on air without any materials.
COMPANY CONFIDENTIAL
11
3.8 Radiated Emission
Remark: we will provide the official regulatory test report from 3rd party lab.
4. Product Requirements
4.1 Hardware Requirements
Form factor 40 mm x40mm module with 8-pin B.T.B connector
Host Interface USB2.0 interface
PCB 4-layer design
Antenna connector RF switch connector
4.2 Hardware Architecture
The T77H332.XX IEEE802.11b/g/n module is based on Marvell 88W8782UB0-NAP2C000
solution that is provide the combined functions of DSSS and OFDM baseband modulation,
MAC, CPU, OTP (one time programmable) memory, host interfaces, power management
unit (PMU) and direct conversion WLAN RF radio. This module is powered from the host
(3.3V) and interfaces to the host with USB 2.0 signals and with two printed antennas for
diversity and one on-board 40 MHz XTAL.
The functional block diagram is shown as below.
1
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux
appareils radio exempts de licence. Son fonctionnement est sujet aux deux conditions
suivantes: (1) le dispositif ne doit pas produire de brouillage préjudiciable, et (2) ce
dispositif doit accepter tout brouillage reçu, y compris un brouillage susceptible de
provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance
20cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour
un environnement non contrôlé. Cet équipement doit être installé et utilisé avec un
minimum de 20 cm de distance entre la source de rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions:
(For module device use)
1) The antenna must be installed such that 20 cm is maintained between the antenna and
users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions
suivantes: (Pour utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 20 cm est respectée entre
l'antenne et les utilisateurs, et
2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur
l'émetteur ne seront pas nécessaires. Toutefois, l'intégrateur OEM est toujours
responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations
or co-location with another transmitter), then the Canada authorization is no longer
considered valid and the IC ID can not be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines
configurations d'ordinateur portable ou de certaines co-localisation avec un autre
émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC ne peut
pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé
de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une autorisation distincte
au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
2
installed such that 20 cm may be maintained between the antenna and users. The final
end product must be labeled in a visible area with the following: “Contains IC: 2878D-
T77H332”.
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où
l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue
entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible
avec l'inscription suivante: "Contient des IC: 2878D- T77H332".
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding
how to install or remove this RF module in the user’s manual of the end product which
integrates this module.
The end user manual shall include all required regulatory information/warning as show in
this manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final
quant à la façon d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur
du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises
et avertissements comme indiqué dans ce manuel.
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
3
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 20 cm is maintained between the antenna
and users, and
2) The transmitter module may not be co-located with any other transmitter or
antenna.
As long as 2 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for example
certain laptop configurations or co-location with another transmitter), then the FCC
authorization is no longer considered valid and the FCC ID can not be used on the
final product. In these circumstances, the OEM integrator will be responsible for
reevaluating
the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be
installed such that 20 cm may be maintained between the antenna and users. The
final end product must be labeled in a visible area with the following: “Contains FCC
ID: MCLT77H332”. The grantee's FCC ID can be used only when all FCC compliance
requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user’s manual of the end
product which integrates this module.
The end user manual shall include all required regulatory information/warning as show
in this manual.
Europe – EU Declaration of Conformity
ThisdevicecomplieswiththeessentialrequirementsoftheR&TTEDirective1999/5/EC.Thefollowingtestmethodshavebeen
appliedinordertoprovepresumptionofconformitywiththeessentialrequirementsoftheR&TTEDirective1999/5/EC:
‐ EN60950‐1:2006+A11:2009+A1:2010+A12:2011
SafetyofInformationTechnologyEquipment
‐ EN62311:2008
Assessmentofelectronicandelectricalequipmentrelatedtohumanexposurerestrictionsforelectromagneticfields(0
Hz‐300GHz)
(IEC62311:2007(Modified))
EN300328V1.8.1:2012
‐ ElectromagneticcompatibilityandRadiospectrumMatters(ERM);WidebandTransmissionsystems;Datatransmission
equipmentoperatinginthe2,4GHzISMbandandusingspreadspectrummodulationtechniques;HarmonizedENcovering
essentialrequirementsunderarticle3.2oftheR&TTEDirective
EN301489‐1V1.9.2:2011
ElectromagneticcompatibilityandRadioSpectrumMatters(ERM);ElectroMagneticCompatibility(EMC)standardforradio
4
equipmentandservices;Part1:Commontechnicalrequirements
EN301489‐17V2.1.12009
ElectromagneticcompatibilityandRadiospectrumMatters(ERM);ElectroMagneticCompatibility(EMC)standardforradio
equipmentandservices;Part17:Specificconditionsfor2,4GHzwidebandtransmissionsystemsand5GHzhighperformance
RLANequipment
NationalAuthoritieswereinformedaccordingtoArticle6.4ofFrequencyNotification.
SpecialRequirementsareconsidered.TheproductislabeledwithCEMarking.
Česky
[Czech]
[Jméno výrobce] tímto prohlašuje, že tento [typ zařízení] je ve shodě se
základními požadavky a dalšími příslušnými ustanoveními směrnice 1999/5/ES.
Dansk
[Danish]
Undertegnede [fabrikantens navn] erklærer herved, at følgende udstyr
[udstyrets typebetegnelse] overholder de væsentlige krav og øvrige relevante
krav i direktiv 1999/5/EF.
Deutsch
[German]
Hiermit erklärt [Name des Herstellers], dass sich das Gerät [Gerätetyp] in
Übereinstimmung mit den grundlegenden Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet.
Eesti
[Estonian]
Käesolevaga kinnitab [tootja nimi = name of manufacturer] seadme [seadme
tüüp = type of equipment] vastavust direktiivi 1999/5/EÜ põhinõuetele ja
nimetatud direktiivist tulenevatele teistele asjakohastele sätetele.
English Hereby, [name of manufacturer], declares that this [type of equipment] is in
compliance with the essential requirements and other relevant provisions of
Directive 1999/5/EC.
Español
[Spanish]
Por medio de la presente [nombre del fabricante] declara que el [clase de
equipo] cumple con los requisitos esenciales y cualesquiera otras disposiciones
aplicables o exigibles de la Directiva 1999/5/CE.
Ελληνική
[Greek]
ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ [name of manufacturer] ΔΗΛΩΝΕΙ ΟΤΙ [type of equipment]
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ
ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français
[French]
Par la présente [nom du fabricant] déclare que l'appareil [type d'appareil] est
conforme aux exigences essentielles et aux autres dispositions pertinentes de la
directive 1999/5/CE.
Italiano
[Italian]
Con la presente [nome del costruttore] dichiara che questo [tipo di
apparecchio] è conforme ai requisiti essenziali ed alle altre disposizioni
pertinenti stabilite dalla direttiva 1999/5/CE.
Latviski
[Latvian]
Ar šo [name of manufacturer / izgatavotāja nosaukums] deklarē, ka [type of
equipment / iekārtas tips] atbilst Direktīvas 1999/5/EK būtiskajām prasībām un
citiem ar to saistītajiem noteikumiem.
Lietuvių
[Lithuanian]
Šiuo [manufacturer name] deklaruoja, kad šis [equipment type] atitinka
esminius reikalavimus ir kitas 1999/5/EB Direktyvos nuostatas.
Nederlands
[Dutch]
Hierbij verklaart [naam van de fabrikant] dat het toestel [type van toestel] in
overeenstemming is met de essentiële eisen en de andere relevante
bepalingen van richtlijn 1999/5/EG.
Malti
[Maltese]
Hawnhekk, [isem tal-manifattur], jiddikjara li dan [il-mudel tal-prodott]
jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm
5
fid-Dirrettiva 1999/5/EC.
Magyar
[Hungarian]
Alulírott, [gyártó neve] nyilatkozom, hogy a [... típus] megfelel a vonatkozó
alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
Polski
[Polish]
Niniejszym [nazwa producenta] oświadcza, że [nazwa wyrobu] jest zgodny z
zasadniczymi wymogami oraz pozostałymi stosownymi postanowieniami
Dyrektywy 1999/5/EC.
Português
[Portuguese
]
[Nome do fabricante] declara que este [tipo de equipamento] está conforme
com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Slovensko
[Slovenian]
[Ime proizvajalca] izjavlja, da je ta [tip opreme] v skladu z bistvenimi zahtevami
in ostalimi relevantnimi določili direktive 1999/5/ES.
Slovensky
[Slovak]
[Meno výrobcu] týmto vyhlasuje, že [typ zariadenia] spĺňa základné požiadavky
a všetky príslušné ustanovenia Smernice 1999/5/ES.
Suomi
[Finnish]
[Valmistaja = manufacturer] vakuuttaa täten että [type of equipment = laitteen
tyyppimerkintä] tyyppinen laite on direktiivin 1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen mukainen.
Svenska
[Swedish]
Härmed intygar [företag] att denna [utrustningstyp] står I överensstämmelse
med de väsentliga egenskapskrav och övriga relevanta bestämmelser som
framgår av direktiv 1999/5/EG.
