This technical reference guide provides information about the HP LaserJet 1010 series printer

software and troubleshooting tips. This reference is also presented in an electronic format to serve

as a quick reference tool for Customer Care Center (CCC) agents, support engineers, system

administrators, and second-level management information system (MIS) personnel.

Copyright

© 2003 Copyright Hewlett-Packard Development Company, LP

Reproduction, adaptation or translation without prior written permission is prohibited, except as

allowed under the copyright laws.

The information contained herein is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements

accompanying such products and services. Nothing herein should be construed as constituting an

additional warranty. HP shall not be liable for technical or editorial errors or omissions contained

herein.

Part number: Q2460-90930

First Edition: 8/2003

Trademark notices

Adobe®, Acrobat™ and PostScript® are registered trademarks of Adobe Systems Incorporated.

TrueType™ is a registered trademark of Apple Computer, Inc.

Microsoft®, MS-DOS®, Windows®, Windows NT®, Windows 2000®, Windows XP®, and Internet

Explorer® are U.S. registered trademarks of Microsoft Corporation.

Netscape® is a registered trademark of Netscape, Inc.

Java™ is a U.S. trademark of Sun Microsystems, Inc.

UNIX® is a registered trademark of The Open Group.

Notice

The information contained in this document is subject to change without notice.

8 Chapter 1 - Purpose ENWW

ENWW 9

2Software overview

The HP LaserJet 1010 series printers deliver LaserJet printing through a direct (local) universal

serial bus (USB) (or a parallel port on the HP LaserJet 1015). Network connections are supported

for the 1012 and 1015 models only via HP Jetdirect devices.

The printer comes with software for the following operating systems:

!Windows 95 (HP LaserJet 1015 only, printer driver only, not USB compatible)

!Windows 98 first edition (printer driver only)

!Windows 98 Second Edition (SE)

!Windows NT 4.0 (Service Pack 3 or higher, HP LaserJet 1015 only, printer driver only, not

USB compatible)

!Windows Me

!Windows 2000

!Windows XP (32-bit)

!Mac OS 9.x (v 9.1 and higher)

!Mac OS X v10.1 and v10.2 (Apple encourages OS X v10.0 users to upgrade to v10.1)

!Linux and Unix (drivers for the HP LaserJet 1015 are available on the web at http://

www.linuxprinting.org)

!DOS is supported only by the HP LaserJet 1015

The most recent printer drivers, additional printer drivers, and other software and documentation

are available from http://www.hp.com/support/lj1010. Not all software is available in all languages.

See the Late-breaking Readme document for the latest software information.

Note Linux drivers for the HP LaserJet 1015 are supported by the Linux community. See http://

www.linuxprinting.org for more information.

Note Unix drivers are model scripts. See http://www.hp.com/go/unixmodelscripts for more information.

Note HP does not support networking for the 1010 model, even through HP Jetdirect devices.

Note Because the 1010 and 1012 models have no parallel port, they are not usable with DOS, Windows

95, 98 (first edition), or NT. These operating systems do not support USB connections.

10 Chapter 2 - Software overview ENWW

Printer configurations

The HP LaserJet 1010 series printers include the following configurations.

HP LaserJet 1010

!12 ppm for letter-size paper, 12 ppm for A4-size paper

!First page out in less than 8 seconds

!600 x 600 dpi with HP Resolution Enhancement technology (REt)

!150-sheet enclosed input tray

!Priority input tray

!8 MB RAM

!2000-page print cartridge

!Host-based printing

!USB version 2.0

!Windows 98SE, Me, 2000, and XP

!Mac OS 9.x

!Mac OS X v10.1 and v10.2

!HP Toolbox provides printer status information, troubleshooting information, and printer

configuration information (Windows only)

HP LaserJet 1012

The HP LaserJet 1012 printer includes all the features of the 1010 model, plus:

!14 ppm for letter-size paper, 15 ppm for A4-size paper

!1200 dpi effective output quality [600 x 600 x 2 dpi with HP Resolution Enhancement

technology (REt)]

HP LaserJet 1015

The HP LaserJet 1015 printer includes all the features of the 1012 model, plus:

!Parallel port

!16 MB RAM

!PCL5e printing

!Windows 95, 98 (first edition), DOS, and Windows NT 4.0 driver-only install

ENWW Printer software components 11

Printer software components

The following tables indicate which printer drivers are supported by each operating system. In the

tables:

T = Typical Installation

A = Add Printer Installation

W = Web Download

Note Printer software for Windows 95 and Windows NT 4.0 must be installed on the HP LaserJet 1015

printer using the Add Printer installation method.

Note In a network environment where the HP LaserJet 1015 printer has been installed on a Windows

2000 or Windows XP operating system, driver vending to a Windows NT 4.0 operating system is

not supported. That is, the printer driver cannot be installed from the Windows 2000 or Windows XP

operating system to the Windows NT 4.0 operating system. However, the printer driver can be

installed to a Windows 98 SE, Windows Me, or Window 95 operating system. Refer to “Configuration

for Windows sharing” on page 40.

HP LaserJet 1010 and 1012

Printer drivers (installation type) Win 95 Win 98

SE/Me Win NT

4.0 Win

2000 Win

XP-32 Mac

OS 9.x Mac

OS X Linux/

Unix

Host-based driver (custom) T T T

Mac Host-based driver (typical) T T

HP LaserJet 1015

Printer drivers (installation type) Win

95/98/

DOS

Win

98 SE/

Me

Win

NT 4.0 Win

2000 Win

XP-32 Win

XP-64 Mac

OS

9.x

Mac

OS X Linux/

Unix

Host-based driver (custom) T T T

Mac Host-based driver (typical) T T

PCL 5e driver (custom) A A A W W W

Linux/Unix PCL 5e W

12 Chapter 2 - Software overview ENWW

The HP LaserJet 1010 series printer software includes the following components.

Host-based printing

Host-based printing differs from PCL printing by computing the print job on the host computer,

rather than computing the print job in the formatter as in PCL printing.

PCL printing

Use the PCL 5e printer driver (HP LaserJet 1015 only) if you need print results to look consistent

with those from older HP LaserJet printers. Certain features are not available in this printer driver.

Note Do not use the PCL 5e printer driver for this printer with previous printer models.

Windows software components

Components Description

Add/modify/remove

utility Installs, adds components, or uninstalls software for the HP LaserJet 1010

series printer software based on the hardware it detects from the host computer

(Windows 95 and NT 4.0).

HP Toolbox Provides printer status, configuration, troubleshooting, and alert configuration for

the HP LaserJet 1010 series printer. It can also be used to print configuration

reports and save custom configuration settings in customer-defined INI files for

later use.

Printer driver software Allows the computer to communicate with and configure the HP LaserJet 1010

series printer. This software includes the following printer drivers:

!Host-based printer driver

!The HP LaserJet 1015 printer drivers for PCL 5e

(HP LaserJet 1015 only)

Online Help Provides help for using the HP LaserJet 1010 series software.

The HP LaserJet 1010 series printer documentation is included on the

installation CD-ROM as both CHM (online Help) files and Adobe Acrobat PDF

files. The CD-ROM uses a version of Adobe Acrobat Reader that remains on the

CD-ROM and does not need to be installed. However, you will need a Web

browser installed on your PC to view the contents from any CHM file.

Online user guide Provides additional information about the HP LaserJet 1010 series printer.

PDF version of user

guide Provides additional information about the HP LaserJet 1010 series printer.

ENWW Printer software components 13

Mac software

The HP LaserJet 1010 series printers include the following software components for Apple

Computer's Mac OS 9.x, Mac OS X v10.1, and Mac OS X v10.2 (Macintosh) operating systems.

Printer drivers for Windows

The following printer drivers are included with the printer.

*Default printer driver, Windows only

Mac software components

Components Description

Printer driver software This software includes the following printer drivers:

!Host-based driver

USB components This software includes the following USB components:

!HP IO

Mac documentation This software includes the following documentation:

!HP LaserJet Utility Help

!Installation notes

!HP LaserJet printing help

HP LaserJet Manual

Duplex & Booklet

printing application

This application allows the user to do manual duplexing and create booklets with

the HP LaserJet 1010 series printer

PDF version of user

guide Provides additional information about the HP LaserJet 1010 series printer

Available printer drivers

HP LaserJet 1010 and 1012 printer HP LaserJet 1015 printer

!host-based !host-based

!PCL 5e*

14 Chapter 2 - Software overview ENWW

Additional information about software features

Printer driver only for Windows 95 and Windows NT 4.0

The HP LaserJet 1015 printer offers printer driver only support for Windows 95 and Windows NT

4.0.

Note Because USB is not available for Windows 95 and Windows NT 4.0, HP LaserJet 1015 is required

for these operating systems.

To install printer software for Windows 95 and Windows NT 4.0

To install the printer software for Windows 95 and Windows NT 4.0, you must use the Add Printer

Wizard.

1Click Start, and then point to Settings.

2Click Printers.

3Double-click Add Printer.

4Select the port that the printer is connected to, and then click Next.

5Click Have Disk, and then click Browse.

6On the CD-ROM, perform the following procedure to browse to the printer driver you want to

install:

aFrom the directory tree, double-click the language.

bFrom the directory tree, double-click drivers.

cFrom the directory tree, double-click the operating system.

dFrom the directory tree, double-click the printer driver.

eClick OK to select the INF file.

fClick the HP LaserJet 1010 series printer, and click OK to begin the installation.

7Follow the on-screen instructions to complete the software installation.

ENWW Product comparison with HP LaserJet 1000, 1005, and 1200 series printers 15

Product comparison with HP LaserJet 1000, 1005, and 1200 series

printers

The following table highlights some of the differences in features among the HP LaserJet 1000

series printer, the HP LaserJet 1005 series printer, the HP LaserJet 1200 series printer, and the

HP LaserJet 1010 series printers.

Note Not all printers are available in all areas.

General features

Feature HP LaserJet

1000 series HP LaserJet

1005 series

(Europe and

Asia only)

HP LaserJet

1200 series HP LaserJet 1010

series

Standard device

memory 1 MB of RAM (not

expandable) 1MB of RAM (not

expandable) 8 MB of RAM on

HP LaserJet 1200

and HP LaserJet

1220 (expandable

to 72 MB)

HP LaserJet

1200n comes with

16 MB standard

8 MB of RAM

16 MB of RAM on

the HP LaserJet

1015

(not expandable)

Printer languages Windows host-

based printing

PCL 5e emulation

for MS-DOS

printing

Windows host-

based printing

PCL 5e emulation

for MS-DOS

printing

PCL 6

PCL 5e

PostScript® Level

2 emulation

Host-based printing

PCL 5e printing on

the HP LaserJet

1015

Connectivity

options USB cable pod 1284-B parallel

and USB 1284-B parallel

and USB USB

USB and parallel on

the HP LaserJet

1015

Networking Direct (local)

connection with

network sharing

through Windows-

sharing only

Direct (local)

connection with

network sharing

through Windows-

sharing only

Networking

through an

optional Jetdirect

print server

Networking through

an optional Jetdirect

print server

No networking

supported on the HP

LaserJet 1010

Jetdirect support None None Jetdirect support Jetdirect support

Cable 2-meter USB

cable with

attached formatter

pod

No cable in box No cable in box No cable in box

Formatter Resides in an

attachable pod

connected to USB

cable

Resident in printer Resident in printer Resident in printer

Control panel Two LEDs Two LEDs Two LEDs and

one lighted button Three LEDs and two

buttons

Power switch No power switch Power switch Power switch on

220 and 240-volt

printers only

Power switch

16 Chapter 2 - Software overview ENWW

Upgradability None None One DIMM slot for

memory, fonts,

and printer

languages

None

Supported

operating systems Windows 98 SE

Windows Me

Windows 2000

Windows XP (32-

bit)

Windows 95

Windows 98 SE

Windows Me

Windows NT 4.0

Windows 2000

Windows XP (32-

bit)

Windows 95

(printer driver

only)

Windows 98 SE

Windows 2000

Windows Me

Windows NT 4.0

Mac OS 9.x, Mac

OS X v10.1 and

v10.2

Linux/Unix

Windows 98 SE

Windows 2000

Windows Me

Windows XP

Mac OS 9.x

Mac OS X v10.1 and

v10.2

In addition, on the

HP LaserJet 1015:

Linux/Unix

Windows 95/98

(printer driver only)

DOS

Windows NT 4.0

(printer driver only)

Print features

Feature HP LaserJet

1000 series HP LaserJet

1005 series HP LaserJet

1200 series HP LaserJet 1010

series

Print speeds 10 pages per

minute (ppm)

<15 seconds, first

page out

14 ppm

<10 seconds, first

page out

15 ppm on U.S.

letter sheets

14 ppm on A4

<10 seconds, first

page out

14 ppm on U.S.

letter sheets. 15

ppm on A4

HP LaserJet 1010:

12 ppm on U.S.

letter sheets. 12

ppm on A4

<8 seconds, first

page out

Print quality 600 dpi 600 dpi 1200 dpi 600 x 600 x 2 dpi

(effective 1200 dpi)

HP LaserJet 1010:

600 dpi

Paper handling

capabilities

250-sheet paper

input tray 250-sheet paper

input tray

10-sheet priority

feed tray

250-sheet paper

input tray

10-sheet priority

feed tray

150-sheet enclosed

input tray

priority input tray

Duty cycle (pages

per month)

Up to 7000 pages

maximum

Averages 1000

pages per month

Up to 7000 pages

maximum

Averages 1000

pages per month

Up to 10,000

pages maximum

Averages 1000

pages per month

Up to 7,000 pages

maximum

Averages 1000

pages per month

Print cartridge 2500-page

cartridge included 2500-page

cartridge included

3500-page

cartridge available

2500-page

cartridge included

3500-page

cartridge available

2000-page print

cartridge included

General features (continued)

Feature HP LaserJet

1000 series HP LaserJet

1005 series

(Europe and

Asia only)

HP LaserJet

1200 series HP LaserJet 1010

series

ENWW Product comparison with HP LaserJet 1000, 1005, and 1200 series printers 17

Paper path Enclosed, C-

shaped horizontal

main paper path

Straight-through

horizontal optional

paper path

Enclosed, C-

shaped horizontal

main paper path

Straight-through

horizontal optional

paper path

Enclosed, C-

shaped horizontal

main paper path

Straight-through

horizontal optional

paper path

Enclosed, C-shaped

horizontal main

paper path

Dimensions Width: 415 mm

(16.3 in.)

Depth: 486 mm

(19.1 in.)

Height: 253 mm

(10.0 in.)

Width: 415 mm

(16.3 in.)

Depth: 486 mm

(19.1 in.)

Height: 253 mm

(10.0 in.)

Width: 415 mm

(16.3 in.)

Depth: 486 mm

(19.1 in.)

Height: 253 mm

(10.0 in.)

Width: 370 mm

(14.6 in.)

Depth: 230 mm

(9.1 in.)

Height: 208 mm

8.2 in.)

Print features (continued)

Feature HP LaserJet

1000 series HP LaserJet

1005 series HP LaserJet

1200 series HP LaserJet 1010

series

18 Chapter 2 - Software overview ENWW

ENWW Product requirements 19

3Product requirements

This section lists the supporting operating systems and configurations for the HP LaserJet 1010

series software, and the requirements needed to run the software on a network.

Supported platforms

For easy printer setup and access to the full range of printer features, HP strongly recommends

that you install the software provided. Not all software is available in all languages. Install the

software before setting up the printer. See the Readme for the latest software information.

The most recent printer drivers, additional printer drivers, and other software are available from

www.hp.com\support\lj1010 and HP Software Fulfillment.

See page 9 for a list of the operating systems supported by printer software.

20 Chapter 3 - Product requirements ENWW

Supported configurations

Direct (local) connections

The HP LaserJet 1010 series printer is connected directly to the host computer with Universal

Serial Bus (USB) cable or a parallel (HP LaserJet 1015 only) cable. In this configuration, the

printer is not shared; a single user has complete physical control over the printer. Most users are

familiar with using peripherals that are directly connected to their computers. A user can gain

access to all of the capabilities of the printer in this configuration.

Network connections

The HP LaserJet 1010 series printer also supports network connections with an HP Jetdirect print

server. This print server is optional for the HP LaserJet 1010 series printer.

Wireless connections

The HP LaserJet 1010 series printer models also support the IEEE 802.11b standard for wireless

networking and Bluetooth™ wireless connectivity options. The available HP Jetdirect wireless

print servers and HP Bluetooth printer adapters attach on the back of the printer to either the USB

or parallel port.

IEEE 802.11b standard

With the wireless HP Jetdirect 802.11b print server, HP peripherals can be placed anywhere in the

office or home and connected to a wireless network running Microsoft, Apple, Netware, UNIX, or

Linux network operating systems. This wireless technology provides a high-quality printing

solution without the physical constraints of wiring. Data transmission rates vary according to

system architecture and distance from the access point.

Use the HP Install Network Printer Wizard to install the network software.

Note HP Jetdirect 802.11b print servers are available for USB and parallel connections.

ENWW System requirements for HP LaserJet 1010 series printer software 21

System requirements for HP LaserJet 1010 series printer software

For both direct and network connection, all of the computers that use the printer must meet the

following minimum requirements as listed below.

IBM-compatible computer with an available USB or parallel port (HP LaserJet 1015 only) and the

following:

!Windows 95 (printer driver only, parallel connections only, HP LaserJet 1015 only): Pentium

90 MHz processor or faster and 32 MB or more of RAM

!Windows NT 4.0 (Service Pack 3 or higher, printer driver only, parallel connections only, HP

LaserJet 1015 only): Pentium 90 MHz processor or faster and 32 MB or more of RAM

!Windows 98: Pentium 90 MHz processor or faster and 32 MB or more of RAM

!Windows Me: Pentium 150 MHz processor or faster and 32 MB or more of RAM

!Windows 2000: Pentium 133 MHz processor or faster and 64 MB or more of RAM

!Windows XP (32-bit): Pentium II 300 MHz processor or faster and 128 MB or more of RAM

Note Windows 95 and Windows NT 4.0 do not support USB. You must use a parallel connection (HP

LaserJet 1015 only) or network connection to use one of these operating systems.

For Windows systems

The HP LaserJet 1012 and 1015 series software has the following additional requirements for

network connections:

!TCP/IP protocol installed

22 Chapter 3 - Product requirements ENWW

For Mac OS systems

Any Macintosh computer using the HP LaserJet 1010 series software has the following minimum

system requirements:

!Mac OS 9.1 and higher: PowerPC processor and 96 MB of RAM.

!Mac OS X v10.1 and v10.2: Power Mac G3, G4, iBook, or eMac and 128 MB or more of

physical RAM. A built-in display or a display connected to Apple-supplied video card is

required.

!100 MB or more of free hard disk space

!A USB port

Note For a direct connection to a Macintosh computer, the computer must have a USB port. Parallel cable

connections are not supported.

!A CD-ROM drive (required for installation)

Note Mac OS X does not support PowerBook G3 or processor upgrade cards.

ENWW Requirements for network connection 23

Requirements for network connection

Requirements for end-user client computers

The network computers that will be using the HP LaserJet 1010 series software need to meet the

minimum system requirements listed in the previous section.

Note Certain Novell NetWare configurations are not supported by the HP LaserJet 1010 software.

Note Windows Terminal Server and Citrix MetaFrame should use the latest Windows 2000, Windows XP,

or Windows 9X PCL drivers available from http://www.hp.com.

Network requirement

The following are required for the HP LaserJet 1010 series printer to work on a network:

For Windows systems

!A cable for your type of network connection (not included). (This cable is used to connect the

HP Jetdirect print server to a network port.)

!An installed network using the TCP/IP or IPX/SPX network protocol.

If the TCP/IP protocol will be used, you must configure the HP Jetdirect print server for a direct

peer-to-peer connection from the computer to the printer for network users to have the full

print functionality of the HP LaserJet 1010 series printer.

If the IPX/SPX protocol will be used, you must configure the HP Jetdirect print server for a

direct peer-to-peer connection (sometimes called IPX direct mode) from the computer to the

printer for network users to have the only print functionality of the HP LaserJet 1010 series

printer.

In order to have full functionality, including the HP Toolbox, you also need TCP/IP.

Note Novell NetWare server configurations (Queue Server, IPX NDPS, IP NDPS, and so on) are not

supported.

24 Chapter 3 - Product requirements ENWW

For Mac systems

!A cable for your type of network connection (not included). This cable is used to connect the

HP Jetdirect print server to a network port.

Note Peer-to-peer sharing may work but is not supported on Mac OS systems.

HP Jetdirect print servers

The following table shows the HP Jetdirect print servers that are supported by the HP LaserJet

1010 series printers.

HP Jetdirect print servers

HP Jetdirect

model Description Firmware

HP Jetdirect 500x

(J3265A) This model connects the HP LaserJet 1015 printer to a

10Base-T or 100Base-TX Ethernet network via a bi-directional

parallel port. It supports Windows, Novell, Apple, and OS/2

operating systems.

Version 9.x or

later upgradable

HP Jetdirect 500x

TR (J3264A TR) This model connects the HP LaserJet 1015 printer to a Token

Ring network via a direct-to-network connection using a

parallel port. It supports Windows, Novell, Apple, and OS/2

operating systems.

Version 9.x or

later upgradable

HP Jetdirect 310X

(J6038A) This model connects the HP LaserJet 1012 printer to a 10/

100Base-TX Ethernet network. It is an external network print

server that connects to the printer via the printer’s USB port. It

supports several Windows, Apple, Novell, and other operating

systems.

Upgradable

HP Jetdirect 300x

(J3263A) This model connects the HP LaserJet 1015 printer to a 10/

100Base-TX Ethernet network. It is an external print server

that connects to the printer via a parallel port. It supports

Windows, Apple, Novell, and OS/2 operating systems.

Version 9.x or

later upgradable

HP Jetdirect 170X

(J3258B or later) This model connects the HP LaserJet 1015 printer via a

parallel port. It is an external print server that has a high-

speed, bi-directional parallel port (IEEE 1284) that connects

the device. It supports Ethernet or IEEE 802.3 type 10Base-T

networks using unshielded twisted-pair cable and RJ-45

connectors. It supports Windows and several Novell network

environments, but does not support a Macintosh environment.

Version 8.x or

later. Not

upgradable

HP Jetdirect 380x

(J6061A) This model connects the HP LaserJet 1012 printer to a

802.11b wireless network. It is an external network print

server that connects to the printer’s USB port.

Upgradable

HP Jetdirect WP110

(J6061A) This model connects the HP LaserJet 1015 printer to a

802.11b wireless network. It is an external network print

server that connects to the printer’s parallel port.

Upgradable

ENWW Installing the HP LaserJet 1010 series software 25

4Installing the HP LaserJet 1010

series software

Note HP recommends installing the HP LaserJet 1010 series software before connecting the printer to

the computer. Wait for the prompt to connect the printer.

Overview of software installation

This section provides information for installing the HP LaserJet 1010 series printing system

software using Windows and Macintosh operating systems. See page 9 for a list of the operating

systems supported by printer software.

The HP LaserJet 1010 series software is shipped on one CD-ROM. On Windows systems, the

Setup program installs the HP LaserJet 1010 series software from the CD-ROM to the hard disk

and updates Windows files. On Mac OS systems, the HP LaserJet 1010 series Installer program

installs the HP LaserJet 1010 series software from the CD-ROM to the hard disk.

On installation, you are presented with the following options:

!Typical installation (installs all of the basic components in the default locations)

!Custom installation (allows you to specify components and locations for installation)

On Mac OS systems, the HP LaserJet 1010 series printers use the HP LaserJet 1010 Installer.

Also, printer software will only install on the current system startup drive that contains the active

System folder.

Note Moving the HP LaserJet Software folder after installation may cause the program not to work.

On all of the supported platforms, each install option presents you with a series of query dialog

boxes that guide you through the installation. The Installer will guide you through the installation,

whether you are configuring a directly-connected or networked HP LaserJet 1010 series printer.

The installer has the ability to detect hardware and network connections and help guide the

installation. For instance, if the installer detects an HP LaserJet 1010 series printer, it can

automatically configure the software’s connection to that printer. This saves the user several

steps.

26 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Installation options for Windows

To install the printer driver for Windows 95

To install the printer driver for Windows 95 and Windows NT 4.0, you must use the Add Printer

Wizard.

1Click Start, and then point to Settings.

2Click Printers.

3Double-click Add Printer.

4Select local printer, and then click Next.

Note Windows 95 does not support USB connections. You must use a parallel connection (HP LaserJet

1015 only) to use this operating system.

5Click Have Disk, and then click Browse.

6On the CD-ROM, perform the following procedures to browse to the printer driver you want to

install:

aFrom the directory tree, double-click the language.

bFrom the directory tree, double-click drivers.

cFrom the directory tree, double-click the Win9X_ME folder.

dFrom the directory tree, double-click the PCL 5e driver folder.

eClick hp130025.inf to select the INF file.

fClick OK to begin the installation.

7Follow the on-screen instructions to complete the software installation.

To install the printer driver for Windows NT 4.0

To install the printer driver for Windows NT 4.0, you must use the Add Printer Wizard.

Note Windows NT 4.0 does not support USB connections. You must use a parallel connection (HP

LaserJet 1015 only) to use this operating system.

1Click Start, and then point to Settings.

2Click Printers.

3Double-click Add Printer.

4Select My Computer, and then click Next.

5Select the appropriate port, and click Next.

Note For a local connection, the port is LPT1.

6Click Have Disk.

7Click Browse and select the appropriate letter for the CD-ROM drive. If the letter for the CD-

ROM drive does not appear in the drop down list, type the correct letter followed by a colon

and a forward slash. For example, type E:/.

8Double-click the folder for your language.

9Double-click Drivers.

ENWW Installation options for Windows 27

10 Double-click the WinNT folder.

11 Double-click the PCL 5e driver folder.

12 Click hp130025.inf to select the INF file.

13 Click Open.

14 In the Install from Disk dialog box, click OK.

15 Click Next.

16 Choose the printer name (this is optional), and the default printer options. Click Next.

17 Select whether the printer will be shared, and click Next.

18 Select Yes, print a test page, and click Finish to complete the driver installation.

To install printer software for all other Windows operating systems

1Close all programs.

2Place the HP LaserJet 1010 series printer software CD-ROM into the CD-ROM drive.

3Wait for autorun to begin the software installation. If the Welcome screen does not open, click

Start on the Windows task bar, click Run, type Z:\hpsetup (where Z is your CD-ROM drive

letter), and then click OK.

4Read the information on the Welcome screen, and then click install printer.

5Read the software licensing agreement, and then click Next.

6Select the printer connection method, and then click Next.

7Select the connector type, and then click Next.

8Select the installation type, and then click Next.

9To accept the default printer name and default printer, click Next, or type a new name and

select a different default printer, and then click Next.

10 Select a shared printer option, and then click Next.

11 In the text box, type a location and comment (optional), and then click Next.

12 Click Install to install the software.

13 Connect the printer to the computer.

Note New Hardware Found messages are not visible in Windows XP.

14 On-screen check boxes allow you to print a printer driver test page, read release notes, check

for Web updates, and register the printer online. The print a driver test page check box is

selected by default. You can accept one or all of these settings, and then click Finish. The

following options are available:

• To print a test page, a dialog box asks if the test page printed correctly. Click Yes to close

the dialog box and finish the installation, or click Troubleshoot (or click No in Windows 98

SE and Windows Me) to launch the Windows print-troubleshooting tool.

• If you chose to read release notes, select the read release notes check box.

• To check for Web updates, select the check for web updates check box.

• If you chose to register the printer online, your browser launches and displays the online

registration screen at http://www.hp.com. Follow the on-screen directions to register your

printer.

28 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Once you have completed the registration or if you did not choose to register the printer

online, and a dialog box that describes the benefits of registering the printer appears, click

OK to finish.

15 You must restart the computer for the configuration changes to be made to the HP LaserJet

1010 series printer to take effect. Click Yes to restart now, or click No to restart later.

For Windows XP

HP recommends installing the HP LaserJet 1010 series software before connecting the printer to

the computer. However, if you do connect the hardware first on Windows XP using a USB

connection, it is recommended that you accept the default settings that appear in the New

Hardware wizard for correct installation.

For Windows 2000

HP recommends installing the HP LaserJet 1010 series software before connecting the printer to

the computer. However, if you do install the hardware first on Windows 2000 using a parallel port,

a warning dialog box may appear that states that the software you are installing has not passed

Windows Logo testing. Click Continue Anyway, and a signed printer driver will be installed

successfully.

Note If the New Hardware Found message appears on the screen, click Cancel. Insert the software CD-

ROM that came with the printer into the computer CD-ROM drive. Follow the on-screen installation

instructions.

Installation text options (Windows 98 SE, Me, 2000, and XP only)

After inserting the CD-ROM, the Welcome screen appears. The following text options are

available during installation in Windows operating systems.

Windows installation text options

Screen/Field Description Default

Welcome screen Use this screen to select from the following options:

!install printer

Click this option to start the installation process, and open the

HP LaserJet 1010 Setup Wizard.

!customization utility

Click this option to start the customization utility.

!register product

Click this option to register the HP LaserJet 1010 series

printer software.

!view documentation

Click this option to view the HP LaserJet 1010 series product

documentation.

!support

Click this option to access HP online support and order

supplies online.

N/A

HP LaserJet 1010 Series Setup

Software License

Agreement Click this button to view the HP Software License Agreement.

Click OK to accept or close the window to return to the HP

LaserJet 1010 Setup window.

N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

ENWW Installation options for Windows 29

Installation Notes Click this button to open the Printing System Late-breaking

Readme file. N/A

Printer Connection To connect the printer, select one of the following options:

!Connected directly to this computer

!Connected via the network

Connected

directly to

this

computer

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Connector Type To select a connector type, select one of the following options:

!Parallel Cable

Select the port from the drop-down list.

!USB Cable

!Other

Select the port from the drop-down list.

Parallel

Cable

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Installation Type To select an installation type, select one of the following options:

!Typical Installation

Includes: Screen Fonts, HP LaserJet Toolbox, and an hp

1010 Series LaserJet printer driver (printer driver varies

depending on printer model)

!Custom Installation

Lists all available installation options

Typical

Installation

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Custom Installation group

Features Select the features you want to install from the drop-down list.

Click the arrow to the left of each feature, and then select one of

the following options:

!This feature will be installed on local hard drive.

!This feature, and all subfeatures, will be installed on the

local hard drive.

!This feature will not be available.

Clicking this option will prevent the feature from being

installed.

N/A

Help Click Help to open the Custom Setup Tips window. This window

describes and contains information about the install state icons.

Click OK to return to the Setup Wizard.

N/A

Windows installation text options (continued)

Screen/Field Description Default

30 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Space Click this button to view the disk space requirements and

available space for the selected features.

Click OK to return to the Setup Wizard.

N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Replace Drivers If HP LaserJet 1010 series software has previously been installed

and uninstalled, this window may appear. Select one of the

following options:

!Keep existing drivers

!Replace existing drivers

Replace

existing

drivers

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Name Specify a name for this printer or use the default name.

Clear the check box if you do not want this printer as the default

printer.

Varies

depending

on the

printer

model.

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Sharing Select one of the following options:

!Not Shared

!Share as:

If this option is selected, specify a name for each printer

driver type.

Not Shared

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Location and

Comment Enter a text description of the printer and location if desired. N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Ready to Install Click Install to begin the installation N/A

Windows installation text options (continued)

Screen/Field Description Default

ENWW Installation options for Windows 31

Back Click Back to return to the previous screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Installing HP LaserJet

1010 status window This window displays the status of the installation process. This

process may take several minutes. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Looking for new

hardware If this window appears, connect the printer to the computer and

turn the printer on. N/A

Cancel Clicking this button cancels the installation process and displays

the HP LaserJet 1010 Setup Interrupted screen. Click Finish to

exit the Setup Wizard.

Finish

Finish This window displays the following options:

!Print Driver Test Page

To print a test page, select this option.

!Read Release Notes

To display the Late-breaking Readme file, select this option.

!Check for Web Updates

To open the HP Software Update Wizard, select this option.

!Register Product

To register this product, select this option.

Select or clear any or all check boxes, and then click Finish.

Selected

Test Page This window appears if Print Driver Test Page was selected. If

the test page printed correctly, click OK. If the test page did not

print, click Troubleshoot. The Windows Print Troubleshooter

opens.

N/A

HP LaserJet 1010

Installer Information This screen prompts the user to restart the computer to make the

configuration changes. To restart now, click Yes. To restart later,

click No.

N/A

customization utility Click this option to start the customization utility. N/A

Customization Utility group

HP LaserJet 1010 Setup

Wizard To continue, click Next. To stop the installation process, click

Cancel. The HP LaserJet 1010 Setup Interrupted screen

displays. Click Finish to exit the Setup Wizard.

N/A

Language From the drop-down list, select the language. English

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Port To select the printer port, select one of the following options:

!Queue Name\Path

Browse and select the printer name and path.

!Local Port

!New TCP/IP Port

!New IPX Port

NA

Windows installation text options (continued)

Screen/Field Description Default

32 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Connector Type To select the connector type, select one of the following options:

!Parallel Cable

Select the port from the drop-down list.

!USB Cable

!Other

Select the port from the drop-down list.

Parallel

Cable

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Features Select the program features to install from the following HP

LaserJet 1010 series options:

!HP LaserJet 1010 Series Driver

!HP LaserJet Toolbox

!Screen Fonts

Note: These options vary depending on the printer model.

N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Name Specify a name for this printer, or use the default name.

Clear the check box if you do not want this printer as the default

printer.

From the drop-down list, select the default printer driver.

Varies

depending

on the

printer

model.

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Printer Sharing Select one of the following options:

!Not Shared

!Share as:

Specify a name for each printer driver type.

Not Shared

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Windows installation text options (continued)

Screen/Field Description Default

ENWW Installation options for Windows 33

Printer Location and

Comment Enter a text description of the printer and location (optional). N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Custom Installer

Location Enter the location for the customized installer, or click Change to

browse to the location. N/A

Back Click Back to return to the previous screen. N/A

Install Click Install to start the installation process. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Change Current

Destination Folder Browse to and then click the destination folder, and then click OK.

The Custom Installer Location window displays again. To start

the installation process, click Install.

N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Click this button to cancel the installation process and display the

HP LaserJet 1010 Setup Interrupted screen. Click Finish to exit

the Setup Wizard.

Finish

Finish Click View readme file to open and display the HP LaserJet

Installer Customization Wizard Readme File Contents.

Click FInish to complete installation of the customization utility

and return to the Welcome screen.

N/A

register product To register a product, select one of the following options:

!WWW Registration

Click this option to open the HP registration Web page in your

browser. Follow the instructions on the Web page to register

your HP LaserJet 1010 series software.

!Exit

Click this option to open a window. Select one of the following

options:

•Continue

Continues the registration process.

•Exit

Click to return to the Welcome screen.

!Electronic Registration

Click this option to start the electronic HP registration

process.

N/A

Windows installation text options (continued)

Screen/Field Description Default

34 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

view documentation To view the documentation, select one of the following options:

!view user guide

This option opens the online user guide.

!print user guide

This option allows the user to print the user guide from an

Adobe Acrobat PDF file.

Note: Adobe Acrobat must be installed on the computer to

use this feature.

!release notes

This option displays the Printing system Late-breaking

Readme file.

N/A

support Select one of the following options:

!hp.com

This option opens the Web browser to the hp.com Web site.

!product information

This option allows the user to select online support for either

the HP LaserJet 1010 series printer and opens the

HP customer care Web page.

!supplies

This option opens the Web browser to the HP order supplies

Web page.

N/A

Windows installation text options (continued)

Screen/Field Description Default

ENWW Installation log files (Windows systems) 35

Installation log files (Windows systems)

The main logging file (product monitoring file) for the HP LaserJet 1010 series installer is

hplj1010.his. If multiple installs are attempted or completed, the older log files will be designated

hplj1010.hi1 or .hi2, and so on. This file is located in the Windows or WinNT directory, depending

on the operating system. The file contains a list of actions performed during the installation

process.

Other log files

During the installation process, the following two additional files are created that may be useful for

troubleshooting.

!hpgeneral.ini (contains a log of settings selected by the user during installation)

!compdata.ini (contains driver setting information)

Note These files are only available while the installer is running and the installer deletes them during

cleanup.

Since their location varies from system to system, the best way to locate these files is to perform a

file search. They are placed in the temp directory, defined by the %TEMP% variable.

36 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Installation for Mac OS (Network or Direct)

HP LaserJet 1010 series

Mac OS 9.1 or later

To install the software on a Mac computer running Mac OS 9.1 or higher, perform the following

procedure:

1Connect the HP LaserJet 1010 series printer to the computer.

2Insert the printer software CD-ROM into your CD-ROM drive.

3If the CD-ROM does not auto-launch, go to the desktop, and then double-click the HP

LaserJet 1010 CD-ROM icon.

4Double-click the HP LaserJet 1010 folder.

5Double-click the HP LaserJet Installer Classic icon.

6Click Continue, click Accept, click Continue, and then click Install.

7From the Apple menu, select the Chooser.

8On the top-left side of the Chooser dialog box, click the HP LaserJet icon.

9Do one of the following, depending on how the computer and printer are connected:

aTCP/IP: Select yes to scan for TCP/IP network printers in the pop-up dialog.

bUSB: Go to step c.

c AppleTalk: In the lower left side of the Chooser dialog box, select the correct AppleTalk

Zone for your printer. On the right side of the Chooser dialog box, click the HP LaserJet

1010 printer name.

10 Close the Chooser.

Mac OS X v10.1 or higher

To install the software on a Mac computer running Mac OS X v10.1 or higher, perform the

following procedure:

1Connect the HP LaserJet 1010 series printer to the computer.

2Insert the printer software CD-ROM into your CD-ROM drive.

3If the CD-ROM does not auto-launch, go to the desktop, and then double-click on the HP

LaserJet 1010 CD-ROM icon.

4Double-click the HP LaserJet 1010 folder.

5Double-click the HP LaserJet Installer OS X icon.

6Enter your password and click Continue.

7Click Continue, click Accept, click Continue, and then click Install.

8Print Center should launch automatically. If it does not:

aDouble-click the hard drive icon.

bClick Applications, and then click Utilities.

cDouble-click Print Center.

9Click Add Printer. The Add Printer List dialog box appears.

10 Do one of the following, depending on how the computer and printer are connected:

ENWW Installation for Mac OS (Network or Direct) 37

aUSB: Go to step 11.

b AppleTalk: Select the correct AppleTalk Zone.

cTCP/IP: Select "hp ip printing" for connecting to your TCP/IP printer.

11 Select the printer name from the printer list.

12 Click Add.

38 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Installation instructions for networked computers

This section contains instructions for installing the HP LaserJet 1012 or 1015 printer software on

network computers running Windows 95, 98, Me, NT 4.0, 2000, XP, or Mac OS 9.x, or OS X

(version 10.1 or later).

Note Each computer system must have the appropriate printer driver for the operating system installed.

PCL 5e printer drivers can be shared between Windows 2000 and Windows XP operating systems

and between Windows 95, Windows NT 4.0, Windows 98 SE, and Windows Me operating systems.

However, the printer drivers cannot be shared between the two groups of operating systems. For

more information, see information in “Printer software components” on page 11.

Using an HP Jetdirect external print server

The HP LaserJet 1010 series printer must be set up and connected to the network through an HP

Jetdirect print server, and turned on before installing the HP LaserJet 1010 series software.

Also, if you are using HP Web Jetadmin to set up the HP Jetdirect print server, make sure you do

not create an HP Jetdirect port when you connect the printer to the print server.

To connect an HP LaserJet 1010 series printer to a network using an HP Jetdirect external print

server, perform the following procedure:

Note You must complete the procedure in order, or the Installer's discovery utility will fail to see the printer.

1Turn off power to the printer before connecting the HP Jetdirect print server.

2Connect the HP Jetdirect print server to the printer’s appropriate port (parallel or USB).

3Plug in the HP LaserJet 1010 series printer to a power source.

4To print an HP Jetdirect test page, press the Test button on the HP Jetdirect print server.

5To complete the printer installation, install the HP LaserJet 1010 series1010 series software.

Use the information from the test pages to complete the network variables during installation.

Network installation for Windows systems

This software is available only when the printer is connected to a network.

1If the welcome screen does not open, click Start, click Run, type X:\SETUP (where X is the

letter of your CD-ROM disk drive), and then click OK.

2When the installation is nearly complete, a setup screen appears that asks whether or not you

want to print a test page. Click Yes.

ENWW Installation instructions for networked computers 39

Network installation for Mac systems (HP LaserJet 1010 printer)

To install the software on a Mac computer for a printer connected to a network through an HP

Jetdirect print server, see page 39.

Discovery process during installation

During the HP LaserJet 1010 series software installation, the software searches for an HP

LaserJet 1010 series printer on the network. If the HP Jetdirect print server does not have the

supported firmware, the print server will not be detected during discovery. After the discovery

process is complete, the printer will appear to be connected to the HP Jetdirect print server.

40 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Configuration for Windows sharing

This section contains instructions for using Windows sharing to make the printer available to

network users when the printer is directly connected to a computer.

Note Peer-to-peer sharing is not available for Mac OS systems.

Once the printer is shared, install the printer drivers on all the computers you want to print to the

printer. For Windows 95, 98, Me, NT 4.0, 2000, or XP, perform the following procedure to enable

sharing.

Note You might need the printer software CD-ROM to complete the printer driver installations.

Perform the following procedure at the computer directly connected to the printer:

1Click Start, click Settings, and then click Printers.

2From the File menu, select the HP LaserJet 1010 series printer, and then click Properties.

3On the Sharing tab, type a name for the printer in the Share Name field, and then click OK.

4 For Windows XP only: On the Port tab, click to clear the enable bi-directional support

check box.

Perform the following procedure at the computers of other network users who want to use the

printer:

1From the Start menu, click Settings, and then click Printers.

2Double-click Add Printer, and then click Next.

3Follow the directions on the screen.

a When asked if the printer is a local or network printer, select Network Printer.

b Click Browse, locate the printer name that was assigned to the shared printer, and then

click OK.

c When prompted, print a test page to ensure the printer driver is installed properly.

Note A host-based printer driver must be installed on each computer accessing the printer. The printer

driver cannot be shared between computers.

ENWW Installing the printer driver only 41

Installing the printer driver only

Windows

Note If the printer is directly connected to another user’s computer, the printer must be shared from that

computer using Windows sharing.

To install the printer driver, perform the following procedure:

1From the Start menu, click Settings, and then click Printers.

2Double-click Add Printer, and then click Next.

3When asked if the printer is a local or network printer, select Network Printer, and then click

Next.

4To copy printer files onto your system, complete one of the following options:

• If using Windows 2000 or XP, you may need to first choose your printer from the list of

printers or enter an IP address. If the printer driver is not available, the Add Printer Wizard

dialog box will appear. Click Have Disk from the wizard screen.

• If using Windows NT, Me, 98, or 95, click Have Disk from the wizard screen that appears.

5Insert the CD-ROM into the drive. Complete one of the following options:

•For Windows 95 and Windows 98 SE: Double-click the INF file located on the CD-ROM

in X:\<language>\DRIVERS\9X_ME (replace the “X” with the letter of your CD-ROM drive).

•For Windows NT 4.0 and Window 2000: Double-click the INF file located on the CD-ROM

in X:\<language>\DRIVERS\WinNT40 (replace the “X” with the letter of your CD-ROM

drive).

•For Windows XP: Double-click the INF file located in the CD-ROM in

X:\<language>\DRIVERS\Win2000_XP (replace the “X” with the letter of your CD-ROM

drive).

6Complete the installation. When prompted, print a test page to ensure the printer driver is

installed properly.

42 Chapter 4 - Installing the HP LaserJet 1010 series software ENWW

Installing the customization utility

To install the customization utility, perform one of the following procedures:

Procedure 1

1If the Welcome screen does not open, click Start on the Windows task bar.

2Click Run.

3Type Z:\hpsetup (where Z is your CD-ROM drive letter).

4Click OK.

Procedure 2

1Quit all programs.

2Place the HP LaserJet 1010 series printer software CD-ROM into the CD-ROM drive.

3Wait for autorun to begin the software installation.

Note If the Welcome screen does not open, click Start on the Windows task bar, click Run, type ó (where

Z is your CD-ROM drive letter), and then click OK.

4On the Welcome screen, click customization utility.

5The HP LaserJet 1010 Setup screen appears. To continue, click Next.

6In the Language window, select the language from the drop-down list, and then click Next.

7In the Printer Port window, select the type of printer port from the list of options, or browse to

select another port in the field. Click Next.

8In the Connector Type window, select the type of printer connection, and then click Next.

9From the list of printer models, select your printer, and then click Next.

10 From the Features window, select the features you wish to install, and then click Next.

11 Click Next to accept the default printer name, or type a new printer name in the field.

12 If you want this printer to be the default printer, make sure the check box is checked, and then

click Next.

13 In the Printer Sharing window, select from the list of options, and then click Next. (If you select

Share as:, type the name for the shared printer in the field.)

14 Type in the location and a comment if you wish, and then click Next.

15 In the Custom Installer Location window, type in the location or click Change to browse to the

location, and then click Install.

16 When installation of the customization utility is complete, click Finish. The Welcome screen

displays again.

ENWW Configuration 43

5Configuration

Software configuration settings

Software configuration settings, such as sharing properties and port management, apply to the

printer in general. To alter software configuration settings after installation, you must gain access

to the printer properties by opening the printer driver. Follow these steps to access configurations

settings:

Windows 95, Windows 98 SE, Windows NT 4.0, and Windows Me

1Click Start, select Settings, and then click Printers.

2Right-click the HP LaserJet 1010 series printer icon.

3Click Printer Properties (Document Defaults... in Windows NT.4.0).

Windows 2000 and Windows XP

1Click Start, select Settings, click Printers (in Windows XP, click Printers and Faxes), and

then right-click the HP LaserJet 1010 series printer icon.

2Click Printing Preferences.

Mac OS 9.x

In the application you wish to print from, use the following steps to configure the HP LaserJet 1010

series printer settings:

1Click File, and then click Print.

2Using the drop-down list, select the printing options to configure and make changes to the

print settings.

3To use these settings for the current job only, after making printing option selections, click

Print.

4To use these setting for the current and future jobs, click Save Settings, and then click Print.

44 Chapter 5 - Configuration ENWW

Mac OS X

In the application you wish to print from, use the following steps to configure the HP LaserJet 1010

series printer settings:

1Click File, and then click Print.

2Using the drop-down list, select the printing options to configure and make changes to the

print settings.

3To use these settings for the current job only, after making printing option selections, click

Print.

4To use these setting for the current and future jobs, select Save As from the presets menu,

type in a name, click OK, then click Print.

ENWW Printing preferences 45

Printing preferences

Printing preferences are a subset of the software configuration settings. These settings control

specific instructions for each print job such as media size and type, resolution, and watermarks.

You can gain access to printing preferences through the software application you are using or

through the printer driver.

Gaining access to printing preferences through the current

software application

This changes the settings only for the current software application. Follow these steps to gain

access to printing preferences through the software application:

Note The steps for gaining access to printer preferences can vary among software applications. The

following steps cover the most common methods for applications running on Windows 95,

Windows 98 SE, Windows Me, Windows NT 4.0, Windows 2000, and Windows XP.

1From the File menu in the software application, click Print.

2On the print dialog box, verify that the HP LaserJet 1010 series printer is the selected printer.

If it is not, click the drop-down arrow, and click the printer name to select it.

3Click Properties.

Gaining access to printing preferences through the printer driver

Windows 95, Windows 98 SE, and Windows Me

1Click Start, select Settings, click Printers, and then right-click the HP LaserJet 1010 series

printer icon.

2Click Printer Properties to open the printer driver dialog box.

Windows NT 4.0

Note In Windows NT 4.0, this feature is called "Document Defaults" rather than "Printing Preferences".

1Click Start, select Settings, click Printers, and then right-click the HP LaserJet 1010 series

printer icon.

2Click Document Defaults to open the printer driver dialog box.

Note To access the Configure tab, right-click the HP LaserJet 1010 series printer icon, and then click

Properties.

Windows 2000 and Windows XP

1Click Start, select Settings, click Printers (in Windows XP, click Printers and Faxes), and

then right-click the HP LaserJet 1010 series printer icon.

2Click Printing Preferences.

46 Chapter 5 - Configuration ENWW

Host-based printing preference tabs in Windows 98 SE, Me, 2000,

and XP

The following tabs are available in the Printing Properties:

!Finishing

!Effects

!Paper

!Basics

Paper

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a new

Quick Sets name.

Quick Sets allow you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Defaults from the Quick Sets drop-down

list.

Untitled

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Defaults.

N/A

ENWW Host-based printing preference tabs in Windows 98 SE, Me, 2000, and XP 47

Paper Options group

Size is This drop-down list contains the following options:

!Letter

!Legal

!A4

!Executive

!B5 (ISO)

!Envelope #10

!Envelope Monarch

!Envelope C5

!Envelope DL

!Envelope B5

!A5

!A6

!B5 (JIS)

!Post Card (JIS)

!Double Post Card (JIS)

!8.5 x 13

!16K

Note: Paper sizes larger than what the printer

supports (such as 11 x 17) are scaled to fit.

Letter

Custom To open the Custom Paper Size window, click

Custom.N/A

Source Tray is This drop-down list contains the following options:

!Automatically Select

!Manual Feed

Automatically Select

Paper (continued)

Field Description Default

48 Chapter 5 - Configuration ENWW

Type is This drop-down list contains a list of supported

media. You can use this list to select the type of

media you want to use.

This setting adjusts the printer speed and fuser

temperature for the paper or other print media that

you select.

CAUTION: Using inappropriate media settings can

cause damage to the printer. Options to select are:

!Plain Paper

!Preprinted

!Letterhead

!Transparency

!Prepunched

!Labels

!Bond Paper

!Envelope

!Recycled

!Color

!Light <75 g/m2

!Heavy (90 -105 g/m2)

!Cardstock (105 - 76 g/m2)

!Rough Paper

Note: For a list of supported media types, see the HP

media guide at http://www.hp.com/support/

ljpaperguide.

Plain

Custom Paper Size details

Name This drop-down list contains five options you can use

to customize the document paper size. Custom 1

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Size group

Width Enter the desired paper width in this field. 8.5

Length Enter the desired paper length in this field. 11.0

Use Inches/Use

Millimeters To change units from inches to millimeters, or vice

versa, click Use Inches/Use Millimeters.Inches

Help Click this button before closing the dialog box to open

the online Help. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Paper (continued)

Field Description Default

ENWW Host-based printing preference tabs in Windows 98 SE, Me, 2000, and XP 49

Finishing tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Print Task Quick Set name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Defaults from the Quick Sets drop-down

list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Document Options group

Print on Both Sides

(Manually)

Note: This option is

sometimes called

"manual duplexing."

This setting allows you to print a document on both

sides of a page.

The printer will print the first side of each page, then

wait for you to put the paper back into the printer and

then print the second side of the page.

When this check box is selected, the following option

becomes available:

!Flip Pages Up

Pages can be flipped up like a notebook.

Unselected

Unselected

Unselected

Booklet Printing This option becomes available when Print on Both

Sides (Manually) is selected and Pages per Sheet

is set for 1. From the drop-down list, you can select

from the following options:

!Off

!Letter (Left Binding)

!Letter (Right Binding)

Off

50 Chapter 5 - Configuration ENWW

Pages per Sheet This drop-down list specifies the number of pages per

sheet to be printed on one sheet of paper. The

supported selections are:

!1

!2

!4

!6

!9

!16

Note: This feature is also known as N-up printing.

1

Print Page Borders This control becomes available if Pages per Sheet is

set for more than 1.

Selecting this check box prints a border around each

page on the sheet.

Unselected

Page Order This control becomes available when Pages per

Sheet is set for more than 1.

This drop-down list allows you to select the order and

placement of the pages on the sheet.

The supported options are:

!Right, then Down

!Down, then Right

!Left, then Down

!Down, then Left

Unselected

Print Quality group

Print quality field Use this drop-down list to select the print quality:

either 600 dpi or FastRes 1200 600dpi

EconoMode Selecting this check box allows the printer to use less

toner on each page. Selecting this option extends the

life of your print cartridges and reduces costs per

page. However, using EconoMode also reduces print

quality.

Print all Text as Black Selecting this check box allows the printer to print all

text characters as black, regardless of the

document's text color setting. The exception is white

text, which stays white.

Unselected

Help Clicking this button before closing the dialog box

opens the online Help. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel Clicking Cancel to close the dialog box without

saving the changes you have made. N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Finishing tab (continued)

Field Description Default

ENWW Host-based printing preference tabs in Windows 98 SE, Me, 2000, and XP 51

Effects tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a new

Print Task Quick Set name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Defaults from the Quick Sets drop-down

list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task Quick

Set selections except Default Print Settings.

N/A

Fit to Page group

Print Document On Selecting this check box causes the document to be

printed on a paper size other than the one for which it

is formatted.

When Print Document On is selected, a drop-down

list displays the types of media available. The

supported media types are:

!Letter

!Legal

!A4

!Executive

!B5 (ISO)

!Envelope #10

!Envelope Monarch

!Envelope C5

!Envelope DL

!Envelope B5

!A5

!A6

!B5 (JIS)

!Post Card (JIS)

!Double Post Card (JIS)

!8.5 x 13

!16K

Unselected

Letter

Scale to Fit This control becomes available if the Print

Document On check box is selected. Selecting this

check box enables the printer to reduce or enlarge a

document to fit on the selected paper size.

Unavailable

52 Chapter 5 - Configuration ENWW

% of Normal Size This control becomes available when Print

Document On is clear.

This field allows you to specify the percentage of

normal size that the printer will enlarge or reduce the

document on the page.

-Or -

Move the slider right or left to increase or decrease

the percentage of normal size.

Normal size refers to the document page size (check

the application's page size settings). You can also

use the slider bar beneath the field to choose a

percentage.

Available

100

Watermarks group

Watermarks This drop-down list displays a list of words or phrases

that the printer can then use to print a watermark on

the document. The supported options are:

!(none)

!DRAFT

!CONFIDENTIAL

!SAMPLE

(none)

First Page Only This control box becomes available when text other

than (none) is shown in the Watermarks drop-down

list.

Selecting this check box enables the printer to print

the specified watermark on only the first page of the

document. No watermarks are printed on the second

and subsequent pages.

Unselected

Edit Clicking this button opens the Watermark Details

screen. N/A

Watermark Details

Current Watermarks This control lists the available watermarks.

The watermark that is highlighted in this list box also

shows up as alterable text in the Watermark

Message control.

N/A

New Clicking this button allows you to create a new

watermark by highlighting the (Untitled) option and

allowing you to type text for your new watermark. This

text then appears in the current watermarks list.

N/A

Delete To delete the selected watermark from the current

watermarks list, click Delete.N/A

Watermark Message Allows you to change the text of any highlighted

watermark listed in the Current Watermarks list, or

type the text for your new watermark.

(none)

Effects tab (continued)

Field Description Default

ENWW Host-based printing preference tabs in Windows 98 SE, Me, 2000, and XP 53

Message Angle This control consists of three options and a spin box:

!Diagonal: Selecting this option causes the

selected watermark to print diagonally on the

page.

!Horizontal: Selecting this option causes the

selected watermark to print horizontally on the

page.

!Angle: Selecting this option enables the spin box,

which you can use to choose the angle of the

watermark on the printed page.

Angle

(Windows 2000 and

Windows XP)

Diagonal

(Windows 98 SE and

Windows Me)

45

Font Attributes group

Name Clicking a font name from this drop-down list specifies

which font to use for the selected watermark.

The supported font options consist of all the installed

fonts on your computer.

Default font for the

document

Color Gray is the only supported color option. Gray

Shading Clicking a setting from this drop-down list specifies

how dark the selected watermark appears on the

printed page. The supported shading options are:

!Lightest

!Very Light

!Light

!Medium Light

!Medium

!Medium Dark

!Dark

!Very Dark

!Darkest

Very Light

Size Use this spin box to specify the font size for the

selected watermark. 150

Style Clicking a setting from this drop-down list specifies

the specific style for the selected font you chose for

this watermark. The supported options available in

this list depend on the fonts installed on the computer.

Typical choices include:

!Regular

!Bold

!Italic

!Bold Italic

Regular

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Effects tab (continued)

Field Description Default

54 Chapter 5 - Configuration ENWW

Basics tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a new

Quick Sets name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Defaults from the Quick Sets drop-down

list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task Quick

Set selections except Defaults.

N/A

Orientation group

Portrait Selecting this option enables the printer to print a

page or envelope that is taller than it is wide when

viewing the text right-side-up.

Feed the paper as usual; the image is rotated on the

page if necessary.

Selected

Landscape Selecting this option enables the printer to print a

page or envelope that is wider than it is tall when

viewing the text right-side-up.

Feed the paper as usual; the image is rotated on the

page if necessary.

Unselected

Rotated Selecting this check box enables the printer to reverse

the image or document top to bottom. Unselected

Copies group

Copy This spin box allows you to use the up and down

arrows to choose a number or to type the number of

copies you want to print (1 to 999).

The copies setting in the application usually overrides

the copies setting in the printer driver.

1

Collated This control box becomes available when more than

one copy is shown in the Copy spin box. Selecting

this box enables the printer to collate your copies.

ENWW Host-based printing preference tabs in Windows 98 SE, Me, 2000, and XP 55

About group

About... To view the About This Driver window, including

copyright and software versions, click About. N/A

Software Update To automatically open your browser and go to http://

www.hp.com, click Software Update.N/A

OK To close the dialog box, click OK.N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Basics tab (continued)

Field Description Default

56 Chapter 5 - Configuration ENWW

Printing preferences tabs using PCL 5e printer drivers in Windows

95, NT 4.0, 98, and Me

The following tabs are available in the Properties dialog box (Document Defaults... in Windows

NT 4.0):

!Finishing tab

!Effects tab

!Paper tab

!Basics tab

Finishing tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a new

Print Task Quick Set name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick Sets

drop-down list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task Quick

Set selections except Default Print Settings.

N/A

Document Options group

Print on Both Sides

(Manually)

Note: This option is

sometimes called

"manual duplexing."

This setting allows you to print a document on both

sides of a page.

The printer will print the first side of each page, then

wait for you to put the paper back into the printer, and

then print the second side of the page.

When this check box is selected, the following options

become available:

!Flip Pages Up

Pages can be flipped up like a notebook.

Unselected

Unselected

Booklet Printing This option requires and automatically selects 2

Pages per Sheet and Print on Both Sides. From the

drop-down list, select from the following options:

!Off

!Letter (Left Binding)

!Letter (Right Binding)

Off

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 95, NT 4.0, 98, and Me 57

Pages per Sheet This drop-down list specifies the number of pages per

sheet to be printed on one sheet of paper. The

supported selections are:

!1

!2

!4

!6

!9

!16

Note: This feature is also known as N-up printing.

1

Print Page Borders This control becomes available if Pages per Sheet is

set for more than 1.

Selecting this check box prints a border around each

page on the sheet.

Unselected

Page Order This control becomes available when Pages per

Sheet is set for more than 1.

This drop-down list allows you to select the order and

placement of the pages on the sheet.

The supported options are:

!Right, then Down

!Down, then Right

!Left, then Down

!Down, then Left

Unselected

Print Quality group

Best Quality Selecting this option enables the printer to print a

document at its optimal resolution.

This option (600 dpi) provides the best print quality.

Changing resolution might change the formatting of

text documents.

Selected default for

PCL 5e printer driver

300 dpi Selecting this option specifies that the printer is using

the 300 dpi setting for printing.

Use this option if the document was formatted for an

earlier model HP LaserJet printer and you are getting

unexpected results.

Changing resolution might change the formatting of

text documents.

Unselected

Custom Clicking this button opens the Print Quality Details

window and allows you to select custom print quality

settings.

Unselected

Details Clicking this button opens the Print Quality Details

screen. N/A

EconoMode

(Save Toner) Selecting this check box allows the printer to use less

toner on each page. Selecting this option extends the

life of your print cartridges and reduces costs per

page. However, using EconoMode also reduces print

quality.

Unselected

Print Quality Details screen

Finishing tab (continued)

Field Description Default

58 Chapter 5 - Configuration ENWW

Current Setting This read-only control denotes the quality setting

currently applied to the printer. N/A

Graphic Settings group

Complex Graphics This control consists of two options:

!Use HP MEt

!Use More Memory

Note: The Use More Memory option is not intended

for general use. Use it only if you receive printer

memory error messages while printing complex

pages.

Use HP MEt

Rendering Mode This control consists of the following options:

!Automatic

!Send Graphics as Vector

!Send Graphics as Raster

!Send Page as Raster

Automatic

Output Settings group

Resolution Clicking this drop-down list allows you to select from

the following options:

!600 dpi

!FastRes 1200

As resolution is increased, the quality of print on the

page is improved. However, using higher resolution

might also result in longer printing times.

600 dpi

Resolution

Enhancement

technology (REt)

This control consists of two options:

!On

Selecting this option allows the printer to refine

the print quality of the characters by smoothing

out jagged edges that can occur with longer

printing times.

!Off

Selecting this option disables the REt function of

the printer. Use this option if graphics or images,

particularly scanned images, are not printing

clearly.

On

Scale Patterns

(WYSIWYG) Select this check box for the most reliable printing.

Clearing this check box may cause differences

between on-screen appearance and printed output.

Selected

Print all Text as Black Selecting this check box allows the printer to print all

text characters as black, regardless of the

document's text color setting. The exception is white

text, which stays white.

Unselected

Font Settings Select this check box to print TrueType as Bitmaps. Unselected

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Finishing tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 95, NT 4.0, 98, and Me 59

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Effects tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Print Task Quick Set name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick

Sets drop-down list.

Type new Quick Set

name here

Save Click Save to save the new or changed Print Task

Quick Set N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Finishing tab (continued)

Field Description Default

60 Chapter 5 - Configuration ENWW

Fit To Page group

Print Document On Selecting this check box causes the document to be

printed on a paper size other than the one for which it

is formatted.

When Print Document On is selected, a drop-down

list displays the types of media available. The

supported media types are:

!Letter

!Legal

!Executive

!A5

!A4

!B5 (ISO)

!Envelope #10

!Envelope DL

!Envelope C5

!Envelope B5

!Envelope Monarch

!B5 (JIS)

!A6

!Double Post Card

!Post Card

!8.5 by 13 inch

!16K

Unselected

Letter

Scale to Fit This control becomes available if the Print

Document On check box is selected. Selecting this

check box enables the printer to reduce or enlarge a

document to fit on the selected paper size.

Unavailable

% of Normal Size This control becomes available when Print

Document On is clear.

This field allows you to specify the percentage of

normal size that the printer will enlarge or reduce the

document on the page.

-Or -

Move the slider right or left to increase or decrease

the percentage of normal size.

Normal size refers to the document page size (check

your application's page size settings). You can also

use the slider bar beneath the field to choose a

percentage.

Available

100

Watermarks group

Watermarks This drop-down list displays a list of words or phrases

that the printer can then use to print a watermark on

the document. The supported options are:

!(none)

!Confidential

!Draft

!SAMPLE

(none)

Effects tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 95, NT 4.0, 98, and Me 61

First Page Only This control box becomes available when text other

than (none) is shown in the Watermarks drop-down

list.

Selecting this check box enables the printer to print

the specified watermark on only the first page of the

document. No watermarks are printed on the second

and subsequent pages.

Unavailable

Edit Clicking this button opens the Watermark Details

screen. N/A

Watermark Details

Current Watermarks This control lists the available watermarks.

The watermark that is highlighted in this list box also

shows up as alterable text in the Watermark

Message control.

N/A

New Clicking this button allows you to create a new

watermark by highlighting the (Untitled) option and

allowing you to type text for your new watermark.

This text then appears in the current watermarks list.

N/A

Delete Clicking this button allows you to delete the selected

watermark from the Current Watermarks list. N/A

Watermark Message Allows you to change the text of any highlighted

watermark listed in the Current Watermarks list. (none)

Message Angle This control consists of three options and a spin box:

!Diagonal

Selecting this option causes the selected

watermark to print diagonally on the page.

!Horizontal

Selecting this option causes the selected

watermark to print horizontally on the page.

!Angle

Selecting this option enables the spin box, which

you can use to choose the angle of the

watermark on the printed page.

Diagonal

Font Attributes group

Name Clicking a font name from this drop-down list

specifies which font to use for the selected

watermark.

The supported font options consist of all the installed

fonts on the computer.

Default font for the

document

Color Gray is the only supported color option. Gray

Effects tab (continued)

Field Description Default

62 Chapter 5 - Configuration ENWW

Shading Clicking a setting from this drop-down list specifies

how dark the selected watermark appears on the

printed page. The supported shading options are:

!Lightest

!Very Light

!Light

!Medium Light

!Medium

!Medium Dark

!Dark

!Very Dark

!Darkest

Very Light

Size Use this spin box to specify the font size for the

selected watermark. 150

Style Clicking a setting from this drop-down list specifies

the specific style for the font chosen for this

watermark. The supported options available in this

list depend on the fonts installed on the computer.

Typical choices include:

!Regular

!Italic

!Bold

!Bold Italic

Regular

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Paper tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a new

Quick Sets name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick Sets

drop-down list.

Type new Quick Set

Name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Effects tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 95, NT 4.0, 98, and Me 63

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task Quick

Set selections except Default Print Settings.

N/A

All Pages group

Size is This drop-down list allows you to select the paper

size for the document from the list of supported paper

sizes, which includes saved custom paper sizes.

The paper size for all pages of a print job must be the

same.

The application settings override the settings in the

printer driver.

The supported paper-size options are:

!Letter

!Legal

!Executive

!A5

!A4

!B5ISO (JIS)

!Envelope #10

!Envelope DL

!Envelope C5

!Envelope B5

!Envelope Monarch

!B5 (JIS)

!A6

!Double Post Card

!Post Card

!8.5 by 13 inches

!16K

Letter

Note: Varies by

country/region.

Custom Clicking this button allows you to create or modify

custom paper-size information. N/A

Source is This drop-down list contains the following options:

!AutoSelect

!Manual Feed

!Tray 1

AutoSelect

Paper tab (continued)

Field Description Default

64 Chapter 5 - Configuration ENWW

Type is This drop-down list contains a list of supported media.

You can use this list to select the type of media you

want to use.

This setting adjusts the printer speed and fuser

temperature for the paper or other print media that

you select.

CAUTION: Using inappropriate media settings can

cause damage to the printer. Options to select are:

!Unspecified

!Plain

!Preprinted

!Letterhead

!Transparency

!Prepunched

!Labels

!Bond

!Recycled

!Color

!Cardstock (105 -176 g/m2)

!Rough

!Heavy (90 -150 g/m2)

!Envelope

!Light < 75 g/m2

Note: For a list of supported media types, see the

HP media guide at http://www.hp.com/support/

ljpaperguide.

Plain

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Custom Paper Size Details

Name Clicking this drop-down list allows you to type a name

for your custom paper size. Untitled

Save Clicking this button allows you to save the custom

settings you have specified on this dialog box.

Click OK and then Close to go back to the Paper tab.

The custom size now appears in the Size is drop-

down list.

N/A

Delete Clicking this button allows you to delete the custom

setting you specified in this dialog box.

This button is available only when there are custom

paper sizes in the drop-down list.

N/A

Paper tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 95, NT 4.0, 98, and Me 65

Width Use this spin box to select the width of a custom

paper size.

If you enter a size that is too small or too large, the

printer driver automatically adjusts the size for you.

8.5 inches (if Size is

set to Letter)

- Or -

216.0 mm (if Size is

set to A4)

Height Use this spin box to select the length of a custom

paper size.

If you enter a size that is too small or too large, the

printer driver automatically adjusts the size for you.

11.0 inches (if Size is

set to Letter)

- Or -

279.0 mm (if Size is

set to A4)

Use Millimeters/Use

Inches Clicking this button allows you to view custom-size

dimensions in either inches or millimeters. Inches (if Size is set

to Letter)

- Or -

Millimeters (if Size is

set to A4)

Close Clicking this button closes the Custom Paper Size

window and returns to the Paper tab. N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Basics tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Quick Sets name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Printer Settings from the Quick

Sets drop-down list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Copies group

Copies This spin box allows you to use the up and down

arrows to choose a number or to type in the number

of copies you want to print (1 to 999).

The copies setting in your application usually

overrides the copies setting in the printer driver.

1

Paper tab (continued)

Field Description Default

66 Chapter 5 - Configuration ENWW

Note In Windows NT 4.0, Windows 2000, and Windows XP, the Configure tab is grouped with the main

printer driver tabs, not in the Printing Preferences or Document Defaults group.

Orientation group

Portrait Selecting this option enables the printer to print a

page or envelope that is taller than it is wide when

viewing the text right-side-up.

Feed the paper as usual; the image is rotated on the

page if necessary.

Selected

Landscape Selecting this option enables the printer to print a

page or envelope that is wider than it is tall when

viewing the text right-side-up.

Feed the paper as usual; the image is rotated on the

page if necessary.

Unselected

Rotate by 180 degrees

Note: This feature is

unavailable if Print on

Both Sides or Pages per

Sheet is selected.

Selecting the Rotate by 180 degrees check box

enables the printer to rotate the document image on

the paper 180 degrees.

If the return address on an envelope is smudged, try

this setting and feed the envelope so that the return

address area is fed first into the printer.

Unselected

About Clicking this button displays printer driver version

information. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Help Clicking this button before closing the dialog box

opens the online Help. N/A

Basics tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 2000 and XP 67

Printing preferences tabs using PCL 5e printer drivers in Windows

2000 and XP

The following tabs are available in the Printing preferences:

!Advanced

!Paper/Quality

!Finishing

!Effects

Advanced tab

Field Description Default

HP LaserJet 1010 PCL 5e Advanced Document Settings

Paper Output group

Paper Size Click Paper Size to display a drop-down list and

select from the following options:

!11 x 17

!16K

!8.5 x 13 inches

!8K

!A3

!A4

!A5

!A6

!B4 (JIS)

!B5 (ISO)

!B5 (JIS)

!Double Postcard (JIS)

!Envelope #10

!Envelope B5

!Envelope C5

!Envelope DL

!Envelope Monarch

!Executive

!Legal

!Letter

!Postcard (JIS)

Note: Paper sizes larger than what the printer

supports (such as 11 x 17) are scaled to fit.

Letter

Copy Count Click Copy Count to display a spin box to specify the

number of copies printed.

When 2 or more is selected, a Collated check box

becomes available. Select this check box if you want

the pages collated.

1 Copy

68 Chapter 5 - Configuration ENWW

Document Options group

Advanced Printing

Features Click Advanced Printing Features to display a drop-

down list. Select either Enable or Disable.

When this feature is enabled, Page Order, Booklet

Printing, and Pages Per Sheet are available. If

disabled, some of these options might not be

available.

Enabled

Print Optimizations Click Print Optimization to display a drop-down list.

Select either Enable or Disable.

When this feature is disabled, some features might

not be available.

Enabled

Printer Features group

Print All Text as Black Click Print All Text as Black to display a drop-down

list to enable or disable this feature.

Selecting Enable allows the printer to print all text

characters as black, regardless of the document's

text color setting. The exception is white text, which

stays white.

Disabled

Send TrueType as

Bitmap Click Send TrueType as Bitmap to display a drop-

down list. Select Enabled to print TrueType as

Bitmaps.

Disabled

Graphics Mode Click Graphics Mode to display a drop-down list and

select from the following options:

!Send Graphics as Vector

This setting may produce higher quality graphics

output.

!Send Graphics as Raster

Use this setting if the file is not printing correctly.

Send Graphics As

Raster

REt Click REt to display a drop-down list and select either

On or Off.

!On

Selecting this option allows the printer to refine

the print quality of the characters by smoothing

out jagged edges that can occur with longer

printing times.

!Off

Selecting this option disables the REt function of

the printer. Use this option if graphics or images,

particularly scanned images, are not printing

clearly.

On

Advanced tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 2000 and XP 69

Layout Options group

Orientation Click Orientation to display a drop-down list. The

following options are available:

!Portrait: Selecting this option enables the printer

to print a page or envelope that is taller than it is

wide when viewing the text right-side-up.

Feed the paper as usual; the image is rotated on

the page if necessary.

!Landscape: Selecting this option enables the

printer to print a page or envelope that is wider

than it is tall when viewing the text right-side-up.

Feed the paper as usual; the image is rotated on

the page if necessary.

Portrait

Page Order Click Page Order to display a drop-down list with the

following options:

!Front to Back

(Page 1 is on the top of the stack)

!Back to Front

(Page 1 is on the bottom of the stack)

Front to Back

Paper/Quality tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Quick Sets name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick

Sets drop-down list.

Untitled

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Advanced tab (continued)

Field Description Default

70 Chapter 5 - Configuration ENWW

Paper Options group

Use different paper Selecting this check box allows you to select a

different page source and type settings for the

following options:

!First Page

!Other Pages

!Back Cover

The paper size settings should be made within the

application.

Unselected

Source is This drop-down list contains the following options:

!Automatically Select

!Manual Feed (Tray 1)

!Printer Auto Select

!Tray 1

Automatically Select

Type is This drop-down list contains a list of supported

media. You can use this list to select the type of

media you want to use.

This setting adjusts the printer speed and fuser

temperature for the paper or other print media that

you select.

CAUTION: Using inappropriate media settings can

cause damage to the printer. Options to select are:

!Unspecified

!Plain

!Preprinted

!Letterhead

!Transparency

!Prepunched

!Labels

!Bond

!Recycled

!Color

!Light <75 g/m2

!Heavy (90 -105 g/m2)

!Cardstock (105 -176 g/m2)

!Envelope

!Rough

Note: For a list of supported media types, see the

HP media guide at http://www.hp.com/support/

ljpaperguide.

Note: If Print on Both Sides is selected, a warning

icon will appear next to Transparency, Labels, and

Envelope to warn the user that there are limitations

when doing manual duplexing.

Plain

Paper/Quality tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 2000 and XP 71

Print Quality group

Print quality field

Not available with PCL 5e

printer driver in Windows

2000 and XP

Use this drop-down list to select the print quality from

the following options:

!ProRes 1200 (141 lpi)

!ProRes 1200 (180 lpi)

!FastRes 1200

!600 dpi

600 dpi

EconoMode Selecting this check box allows the printer to use less

toner on each page. Selecting this option extends the

life of the print cartridges and reduces your costs per

page. However, using EconoMode also reduces

quality.

Unselected

Help Clicking this button before closing the dialog box

opens the online Help. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Finishing tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Quick Sets name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick

Sets drop-down list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Paper/Quality tab (continued)

Field Description Default

72 Chapter 5 - Configuration ENWW

Document Options group

Print On Both Sides

(Manually)

Note: This option is

sometimes called

"manual duplexing."

This setting allows you to print a document on both

sides of a page.

The printer will print the first side of each page, then

wait for you to put the paper back into the printer, and

then print the second side of the page.

When this check box is selected, the following

options become available:

!Flip Pages Up

Pages can be flipped up like a notebook.

Unselected

Unselected

Booklet Layout This option requires and automatically selects

2 Pages per Sheet and Print on Both Sides. From

the drop-down list, you can select from the following

options:

!Off

!Left Edge Binding

!Right Edge Binding

Off

Pages per Sheet This drop-down list specifies the number of pages per

sheet to be printed on one sheet of paper. The

supported selections are:

!1

!2

!4

!6

!9

!16

Note: This feature is also known as N-up printing.

1

Print Page Borders This control becomes available if Pages per Sheet is

set for more than 1.

Selecting this check box prints a border around each

page on the sheet.

Unselected

Page Order This control becomes available when Pages per

Sheet is set for more than 1.

This drop-down list allows you to select the order and

placement of the pages on the sheet.

The supported options are:

!Right, then Down

!Down, then Right

!Left, then Down

!Down, then Left

Unselected

Rotate

Note: This feature is

unavailable if Print on

Both Sides or Pages per

Sheet is selected.

Selecting the Rotate by 180 degrees check box

enables the printer to rotate the document image on

the paper 180 degrees.

If the return address on an envelope is smudged, try

this setting and feed the envelope so that the return

address area is fed first into the printer.

Unselected

Finishing tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 2000 and XP 73

Help Clicking this button before closing the dialog box

opens the online Help. N/A

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Apply Clicking this button applies the new settings, leaving

the dialog box open. N/A

Effects tab

Field Description Default

Quick Sets group

Quick Sets This drop-down list displays a list of user-defined

Quick Sets. This control also allows you to type a

new Print Task Quick Set name.

Quick Sets allows you to save the current printer

driver settings, such as page orientation, resolution,

and paper source, for reuse. After choosing the

settings, type a name for the quick set, and then click

Save. When you save Quick Sets, all current printer

driver settings are saved.

You can also restore printer driver default settings by

selecting Default Print Settings from the Quick

Sets drop-down list.

Type new Quick Set

name here

Save To save the new or changed Print Task Quick Set,

click Save.N/A

Delete To delete the selected Print Task Quick Set, click

Delete.

This button becomes available for all Print Task

Quick Set selections except Default Print Settings.

N/A

Finishing tab (continued)

Field Description Default

74 Chapter 5 - Configuration ENWW

Resizing Options group

Print Document On Selecting this check box causes the document to be

printed on a paper size other than the one for which it

is formatted.

When Print Document On is selected, a drop-down

list displays the types of media available. The

supported media types are:

!16K

!8.5 by 13 inch

!A4

!A5

!A6

!B5 (ISO)

!B5 (JIS)

!Double Postcard (JIS)

!Envelope #10

!Envelope B5

!Envelope C5

!Envelope DL

!Envelope Monarch

!Executive

!Legal

!Letter

!Postcard (JIS)

Unselected

Letter

Scale to Fit This control becomes available if the Print

Document On check box is selected. Selecting this

check box enables the printer to reduce or enlarge

the document to fit on the selected paper size.

Unavailable

% of Normal Size This control becomes available when Print

Document On is clear.

This field allows you to specify the percentage of

normal size that the printer will enlarge or reduce the

document on the page.

-Or -

Move the slider right or left to increase or decrease

the percentage of normal size.

Normal size refers to the document page size (check

the application's page size settings). You can also

use the slider bar beneath the field to choose a

percentage.

Available

100

Watermarks group

Watermarks This drop-down list displays a list of words that the

printer can then use to print a watermark on the

document. The supported options are:

!(none)

!Confidential

!Draft

!SAMPLE

(none)

Effects tab (continued)

Field Description Default

ENWW Printing preferences tabs using PCL 5e printer drivers in Windows 2000 and XP 75

First Page Only This control box becomes available when text other

than (none) is shown in the Watermarks drop-down

list.

Selecting this check box enables the printer to print

the specified watermark on only the first page of the

document. No watermarks are printed on the second

and subsequent pages.

Unavailable

Edit Click Edit to open the Watermark Details screen. N/A

Watermark Details

Current Watermarks This control lists the available watermarks.

The watermark that is highlighted in this list box also

shows up as alterable text in the Watermark

Message control.

N/A

New Clicking this button allows you to create a new

watermark by highlighting the (Untitled) option and

allowing you to type in text for your new watermark.

This text then appears in the Current Watermarks

list.

N/A

Delete Clicking this button allows you to delete the selected

watermark from the Current Watermarks list. N/A

Watermark Message Allows you to change the text of any highlighted

watermark listed in the Current Watermarks list. (none)

Message Angle This control consists of three options and a spin box:

!Diagonal

Selecting this option causes the selected

watermark to print diagonally on the page.

!Horizontal

Selecting this option causes the selected

watermark to print horizontally on the page.

!Angle

Selecting this option enables the spin box, which

you can use to choose the angle of the

watermark on the printed page.

Diagonal

Font Attributes group

Name Clicking a font name from this drop-down list

specifies which font to use for the selected

watermark.

The supported font options consist of all the installed

fonts on the computer.

Default font for the

document

Color Gray is the only supported color option. Gray

Effects tab (continued)

Field Description Default

76 Chapter 5 - Configuration ENWW

Shading Clicking a setting from this drop-down list specifies

how dark the selected watermark appears on the

printed page. The supported shading options are:

!Lightest

!Very Light

!Light

!Medium Light

!Medium

!Medium Dark

!Dark

!Very Dark

!Darkest

Very Light

Size Use this spin box to specify the font size for the

selected watermark. 80

Style Clicking a setting from this drop-down list specifies

the specific style for the font chosen for this

watermark. The supported options available in this

list depend on the fonts installed on the computer.

Typical choices include:

!Regular

!Italic

!Bold

!Bold Italic

Regular

OK To update any changed settings on the printer and

close the dialog box, click OK.N/A

Cancel To close the dialog box without saving the changes

you have made, click Cancel.N/A

Effects tab (continued)

Field Description Default

ENWW HP Toolbox 77

HP Toolbox

Note The HP LaserJet 1010 series printers introduce with HP Toolbox 2.0.

CAUTION To avoid HP Toolbox conflicts, when installing the HP LaserJet 1010 series printer on a system with

an HP Color LaserJet 2500, install the HP Color LaserJet 2500 first, and then install the HP LaserJet

1010 series printer.

The HP Toolbox is a Web application that you can use for the following tasks:

!Check the printer status.

!Configure the printer settings.

!View troubleshooting information.

!View online documentation.

You can view the HP Toolbox when the printer is directly connected to your computer or when it is

connected to a network. You must have performed a complete software installation to use the

HP Toolbox.

Note You do not have to have Internet access to open and use the HP Toolbox. However, if you click a

link in the Other Links area, you must have Internet access in order to go to the site associated

with the link. See “Other links” on page 78 for more information. TCP/IP is required for HP Toolbox.

Note Toolbox features a debug mode for troubleshooting. To enable debug mode, see page 112.

Supported operating systems

HP Toolbox is supported for Windows 98 SE, 2000, Me, and XP.

Supported browsers

To use the HP Toolbox, you must have one of the following browsers:

!Microsoft Internet Explorer 5.5 or later recommended

!Netscape Navigator 6.3 or later

!Opera version 7 or later

All pages can be printed from the browser.

HP Toolbox components

HP Toolbox has the following components:

!HP Toolbox utility

!Apache Tomcat Web server

!Java Runtime Environment

!Status Client

Viewing HP Toolbox

1On the Start menu, point to Programs, point to HP LaserJet 1010 series, and choose the

HP LaserJet Toolbox.

78 Chapter 5 - Configuration ENWW

2The HP Toolbox opens in a Web browser.

OR

1Double-click the icon in the system tray.

Viewing HP Toolbox using the system tray icon

When viewing the HP Toolbox using the system tray icon, the following operations are available:

!If you double-click the icon when there is no alert, the browser opens the main page of HP

Toolbox.

!If you double-click the icon when there is an existing alert, the browser opens the HP Toolbox

current alerts page.

!If you right-click the icon and select Exit, the icon in the system tray disappears. This operation

does not effect the HP Toolbox. (This shuts down only the UI/graphics part of the Status

Client, but does not shut down Status Client completely. Status Client will still be able to

enumerate printers.)

Note Once you open the URL, you can bookmark it so that you can return to it quickly in the future.

HP Toolbox sections

The HP Toolbox software contains the following sections:

!Status tab

!Troubleshooting tab

!Alerts tab

!Documentation tab

!Advanced Printer Settings window

HP Toolbox Links

Each page in the HP Toolbox contains links to these main pages:

!Select a Device.Switch to a different printer.

!View Current Alerts.View printer status information.

!Text Only Page.View links to the main pages of the Toolbox as text.

Other links

Each page in the HP Toolbox contains links to the HP Web site for product registration, product

support, and for ordering supplies. You must have Internet access in order to use any of these

links. If you use a dial-up connection and did not connect when you first opened the HP Toolbox,

you must connect before you can visit these Web sites.

Status tab

The Status tab has links to these main pages:

!Device Status. View printer status information. This page will indicate printer conditions such

as a paper jam or an empty tray. After you correct a problem with the printer, click Refresh to

update the device status.

!Print Info pages. Print the configuration page, PCL Font List, and various other information

pages that are available for the printer.

ENWW HP Toolbox 79

Troubleshooting tab

The Troubleshooting tab provides links to these main pages:

!Problem Solving: Provides various printer troubleshooting information. Click the arrow

buttons to scroll through steps to troubleshoot printing problems.

!Status Light Patterns: Provides illustrations and a table of status light conditions.

!Print Quality Tools: Enter Cleaning Mode.Click the arrow buttons to scroll through steps in

Cleaning Mode.

Alerts tab

The Alerts tab allows you to configure the printer to automatically notify you of printer alerts. The

Alerts tab has links to this main page:

!Set up status alerts

Note Status alerts are only sent during printing to the person who sends the print job.

Set up status alerts

On the Set up status alerts page you can choose to turn alerts on or off, specify when the printer

should send an alert when they occur, and choose from two different types of alerts:

!a pop-up message

!a task bar icon

Click Apply to activate the settings.

80 Chapter 5 - Configuration ENWW

Documentation tab

The Documentation tab contains links to these information sources:

!User Guide. Contains the information about the printer usage, warranty, specifications, and

support that you are currently reading. The user guide is available in both HTML and PDF

format.

!Read Me. Contains late-breaking information about the printer, discovered after other

documentation such as the user guide was developed. In English only.

Advanced Printer Settings window

When you click the Advanced Printer Settings link, a new window opens. The Advanced Printer

Settings window has two tabs:

!Information tab

!Settings tab

To access the HP Toolbox Information tab and Settings tab, on any HP Toolbox page, click

Advanced Printer Settings. See the text options below for features in the HP Toolbox

Information tab and Settings tab.

Information tab

The Information tab provides quick links to the following information:

!Device status

!Configuration

!Event log

!Print Info pages

Settings tab

The Settings tab has links to several pages that allow you to view and change the printer’s

configuration.

Note Software application settings can override settings made in the HP Toolbox.

!Device Information. View basic information about the printer.

!Paper Handling. View and change the settings for the printer’s input tray.

!Printing. View and change the default printer job settings.

!PCL. View and change the PCL font information.

!Print Quality. View and change the print quality settings.

!Print Modes. View and change the print modes for various media types.

!System Setup. View and change system information.

!I/O. View and change the I/O timeout setting.

!Service. Access service related functions, such as cleaning mode and resets.

ENWW HP Toolbox 81

Settings tab text options

Item Description Default

Device Information Group

Device Description The printer name is displayed in the text box. Printer model

Asset Number In the text box, type the asset number. N/A

Company Name In the text box, type the company name. N/A

Contact Person In the text box, type the name of contact person. N/A

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Paper Handling group

Default Paper Size From the drop-down list, select from the following

options:

!A4

!A5

!B5 (Envelope)

!B5 (ISO)

!C5

!COM10

!Custom

!DL

!Exec

!Foolscap

!JB5

!JDoublePostcard

!JPostcard

!Legal

!Letter

!Monarch

!16K

Letter

Default Paper Type From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176g/m2)

!Colored

!Envelope

!Heavy (90-105 g/m2)

!Labels

!Letterhead

!Light (<75 g/m2)

!Plain

!Preprinted

!Prepunched

!Recycled

!Rough

!Transparency

Plain

Manual Feed To set the manual feed option, from the drop-down

list, select either On or Off.Off

82 Chapter 5 - Configuration ENWW

Apply To save any settings changed, click Apply.

Cancel To cancel any changes made, click Cancel.

Printing Group

Copies In the text box, type the number of copies to print (1-

999). 1

Wide A4 From the drop-down list, select either Yes or No.No

Courier Font From the drop-down list, select either Regular or

Dark.Regular

Orientation To select the paper orientation, select either Portrait

or Landscape.Portrait

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Settings tab text options (continued)

Item Description Default

ENWW HP Toolbox 83

Symbol Set From the drop-down list, select from the following

options:

!ARABIC8

!GREEK8

!DESKTOP

!LEGAL

!PC-1004

!PC-8TK

!PS TEXT

!Roman-8

!HPWARA

!HEBREW7

!HEBREW8

!ISO-11

!ISO-15

!ISO-17

!ISO-21

!ISO-4

!ISO-6

!ISO-60

!ISO-69

!ISOCYR

!ISOGRK

!ISOHEB

!ISO L1

!ISO L2

!ISO L5

!ISO L6

!MC TEXT

!PC-775

!PC-8

!PC-850

!PC851GRK

!PC862HEB

!PC864ARA

!PC866CRY

!PC866UKA

!PC-8 DN

!PC8GRK

!PC-852

!WINCYR

!WINGRK

!WINBALT

!WIN 3.0

!WIN L1

!WIN L2

!WIN L5

PC-8

Append CR to LF From the drop-down list, select either Yes or No.No

Form Length In the text box, type the form length value (5-128). 60

Settings tab text options (continued)

Item Description Default

84 Chapter 5 - Configuration ENWW

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Print Quality group

Resolution From the drop-down list, select from the following

options:

!FastRres1200

!600

FastRes 1200

RET From the drop-down list, select either On or Off.On

Density From the drop-down list, select the density value (1=

Light; 5=Dark). 3

Economode From the drop-down list, select either On or Off.Off

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Print Modes group

Color From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176 g/m2)

!Heavy (90-105 g/m2)

!Light (<75 g/m2)

!Plain

!Rough

Plain

Letterhead From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176 g/m2)

!Heavy (90-105 g/m2)

!Light (<75 g/m2)

!Plain

!Rough

Plain

Preprinted From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176 g/m2)

!Heavy (90-105 g/m2)

!Light (<75 g/m2)

!Plain

!Rough

Plain

Settings tab text options (continued)

Item Description Default

ENWW HP Toolbox 85

Prepunched From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176 g/m2)

!Heavy (90-105 g/m2)

!Light (<75 g/m2)

!Plain

!Rough

Plain

Recycled From the drop-down list, select from the following

options:

!Bond

!Card Stock (105-176 g/m2)

!Heavy (90-105 g/m2)

!Light (<75 g/m2)

!Plain

!Rough

Plain

Restore Modes To restore the print modes, select the check box. Unchecked

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

System Setup group

Jam Recovery From the drop-down list, select from the following

options:

!Auto

!Off

!On

Auto

Auto Continue From the drop-down list, select either Off or On.Off

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

I/O group

I/O Timeout In the text box, type the number of seconds (5-300). 15 seconds

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Settings tab text options (continued)

Item Description Default

86 Chapter 5 - Configuration ENWW

Service group

Cleaning Mode To start the cleaning mode, click Start.N/A

Resets To restore all advanced printer settings to the factory

defaults, select the check box and click Apply.Unchecked

Apply To save any settings changed, click Apply.N/A

Cancel To cancel any changes made, click Cancel.N/A

Settings tab text options (continued)

Item Description Default

ENWW System changes through installation 87

6System changes through

installation

Installation changes to Windows systems

The tables in the following sections detail the changes to the system as new folders and files are

added when the HP LaserJet 1010 series software is installed on computers running Windows

operating systems.

Note This listing does not include files that are created, and then deleted, during the installation process.

For a complete list of files installed to Windows systems, see the HP LaserJet 1010 series

software technical reference addendum.

Changes to *.INI and Windows registry changes

For a complete list of these files, see the HP LaserJet 1010 series software technical reference

addendum.

Win.ini changes after installation

For a complete list of these files, see the HP LaserJet 1010 series software technical reference

addendum.

Windows registry changes

For a complete list of these files, see the HP LaserJet 1010 series software technical reference

addendum.

Registry entries are made based upon a ROOTKEY\Key\Name = value format. The root keys are:

Installation changes to Mac systems

For a complete list of these files, see the HP LaserJet 1010 series software technical reference

addendum.

Root key Description

HKLM HKEY_LOCAL_MACHINE

HKCR HKEY_CLASSES_ROOT

HKCU HKEY_CURRENT_USER

HKU HKEY_USERS

88 Chapter 6 - System changes through installation ENWW

ENWW Uninstallation 89

7Uninstallation

Uninstall in Windows 95 and Windows NT 4.0

To uninstall the software from Windows 95 and Windows NT, use the following method:

1Click Start, click Settings, and then click Printers.

2In the Printers window, right-click the printer icon, and click Delete.

Note To uninstall the software from Windows NT 4.0, you must log on with administrator privileges.

Uninstall methods in Windows 98 SE, Me, 2000, and XP

Two methods are available to uninstall the HP LaserJet 1010 series software using the Add/

Remove Programs feature:

!Program group method

!Control panel method

Program group method

To uninstall using this method, click Start, select Programs, select HP LaserJet 1010, and then

click Add or Remove. This starts the uninstallation program. Follow the instructions on the

screen. When all the files are removed, you are prompted to restart the computer.

Note If using the program group method for uninstalling the HP LaserJet 1010 series software, you need

the software CD-ROM.

90 Chapter 7 - Uninstallation ENWW

Control panel method

To uninstall using this method, click Start, select Settings, click Control Panel, and then double-

click Add/Remove Programs (Add or Remove Programs in Windows XP). Select HP LaserJet

1010 series from the list of programs, and then click Remove. This starts the uninstallation

program. Follow the instructions on the screen. When all the files are removed, you are prompted

to restart the computer.

Uninstallation text options using the program group method

Windows 98 SE, Me, 2000, and XP

After inserting the CD-ROM, the Welcome screen appears. The following text options are

available during uninstallation in Windows operating system:

Files not removed, and manual uninstall

For a complete list of these files, see the HP LaserJet 1010 series software technical reference

addendum.

Screen/Field Description Default

Welcome screen This screen indicates that Setup has detected that there is

already an HP LaserJet 1010 series printer installed. N/A

Next Click Next to continue to the next screen. N/A

Cancel Clicking this button cancels the uninstallation process and

displays the HP LaserJet 1010 Setup Interrupted screen. Click

Finish to exit the Setup Wizard.

Finish

Setup Maintenance Select from the following options and then click Next:

!Add an additional printer or printer driver

Use this option to run the HP LaserJet 1010 series Setup

Wizard.

!Modify the existing installation

Use this option to add or remove features.

!Remove All

Use this option to uninstall the HP LaserJet 1010 series

software.

N/A

Back Click Back to return to the previous screen. N/A

Next Click Next to continue to the next screen. N/A

Cancel Clicking this button cancels the uninstallation process and

displays the HP LaserJet 1010 Setup Interrupted screen. Click

Finish to exit the Setup Wizard.

Finish

Remove the Program This screen lists the printer software installed on the computer. N/A

Back Click Back to return to the previous screen. N/A

Remove Click Remove to start the uninstallation process. N/A

Cancel Clicking this button cancels the 1010 Setup Interrupted screen.

Click Finish to exit the Setup Wizard. Finish

Finish Click Finish to complete the uninstallation process. N/A

HP LaserJet 1010 Installer

Information This screen prompts the user to restart the computer to make the

configuration changes. To restart now, click Yes. To restart later,

click No.

N/A

ENWW Software uninstall (Mac) 91

Scrubber Utility

A scrubber utility is provided to remove files and entries that may not be properly handled by the

uninstaller. The scrubber runs in the following operating systems: Windows 95, 98, Me, NT 4.0,

2000, and XP.

The scrubber program ("scrubber.exe") is an ini file driven program. The ini file ("scrubber.ini")

contains the specific information the scrubber executable needs in order to "scrub" any trace of a

product from the PC. The scrubber goes through the following functions in the order below.

1Run the uninstaller - The scrubber checks the system to see if it should first launch the

uninstaller. If so, the uninstaller is launched and run before the scrubber finishes.

2End problem applications - Any "problem" applications which are known can be added to this

list and ended when the scrubber runs.

Then the scrubber procedes to remove any remaining items. In steps 3-11, only the items that are

specific to the HP LaserJet 1010 series printers are removed.

3Remove printers and drivers - The scrubber enumerates the printers on the system and

removes any printers that use the specified driver. Print jobs pending for those printers are

canceled before attempting to delete the printer. After the printer is deleted the printer driver

is removed. The spooler is restarted on NT systems if an error is returned stating that the

printer driver is in use. The scrubber then reattempts to delete the printer driver.

4Remove language monitors.

5Remove print processors.

6Remove devices from the device manager.

7Remove inf files.

8Remove directories.

9Remove files.

10 Remove strings from the device path key.

11 Remove registry keys.

The scrubber utility is available in the HewlettPackard directory on the Software CD. The ini file

and the exe file must be in the same location when running the scrubber. Execute the scrubber

from the DOS command line or Windows Run line.

When the scrubber is executed, no dialogs appear. It takes just a few seconds to run. The user

must restart after running the scrubber. If the scrubber is run from the host machine, a

scrubber.log file is created in the same location as the scrubber which helps diagnose issues if

they occur.

Software uninstall (Mac)

The Uninstall program removes the HP LaserJet 1010 software from the computer.

Uninstall for Mac OS 9.x and Mac OS X v10.1 and v10.2

Use the instructions below to uninstall the software on a Mac computer running Mac 9.x, OS X

v10.1 and higher:

1Insert the printer software CD-ROM into your CD-ROM drive.

2If the CD-ROM does not auto-launch, on the desktop, double-click the HP LaserJet 1010 CD-

ROM icon.

3Double-click the HP LaserJet 1010 folder.

92 Chapter 7 - Uninstallation ENWW

4Double-click the HP LaserJet Installer (Classic or OS X) for the appropriate OS.

5Click Continue, click Accept, and then click Continue.

6From the drop-down list, select UnInstall.

7For OS X only, Print Center will auto-launch to give you the opportunity to delete the HP

LaserJet 1010 print queue after uninstalling the software.

ENWW Software availability and fulfillment 93

8Software availability and

fulfillment

Ordering software

To order the software if your CD-ROM is damaged or missing, contact Hewlett-Packard Support.

Part numbers for the software CD-ROMs for the HP LaserJet 1010 series printers, and which

languages are on them, are given in the table below.

The CD-ROM Key refers to the software and documentation language sets included on the CD..

*Denotes partial localization

Note The complete software for this printer is not provided on the Web due to licensing restrictions. If a

replacement CD-ROM or newer version of the software than what shipped with the printer is needed,

go to http://www.hp.com/support/lj1010 and click the CD-ROM order page to order.

For a current list of telephone numbers to use for ordering software, go to

http://search1.external.hp.com:8087/

krs?method=viewfile&filename=c00001126&application=csso_web and select HP Hardcopy

Support -Worldwide Software Fulfillment Support Phone List and document number

c00001126.

CD-ROM ordering information

CD-ROM key

Number Version Languages included on CD-ROM Part number

For HP LaserJet 1010 series

1 1.0 English, French, German, Italian,

Spanish, Dutch, Portuguese, Greek,

Arabic, *Farsi

Q2460-60101

2 1.0 English, Swedish, Finnish, Danish,

Norwegian, *Estonian, *Lithuanian,

*Latvian

Q2460-60102

3 1.0 English, Polish, Hungarian, Czech,

Slovakian, *Slovenian, *Croatian,

*Romanian, Russian, *Kazakh,

*Ukrainian, Turkish, *Bulgarian,

Hebrew, Arabic

Q2460-60103

4 1.0 English, Traditional Chinese, Simplified

Chinese, Korean, Thai, *Bahasa

Indonesian

Q2460-60104

5 1.0 English, Simplified Chinese Q2460-60105

94 Chapter 8 - Software availability and fulfillment ENWW

Languages

The following tables detail the language options for the HP LaserJet 1010 series printers.

Localization and part numbers

User guides for HP LaserJet 1010 series printers

Languages included in the guides Part number

English Q2460-90909

French Q2460-90910

Italian Q2460-90911

German Q2460-90912

Spanish Q2460-90913

Danish Q2460-90914

Greek Q2460-90915

Finnish Q2460-90916

Hebrew Q2460-90917

Hungarian Q2460-90918

Korean Q2460-90919

Dutch Q2460-90920

Norwegian Q2460-90921

Polish Q2460-90922

Portuguese Q2460-90923

Russian Q2460-90924

Swedish Q2460-90925

Simplified Chinese Q2460-90926

Traditional Chinese Q2460-90927

Croatian Q2460-online

Czech Q2460-online

Romanian Q2460-online

Slovak Q2460-online

Slovenian Q2460-online

Turkish Q2460-online

Arabic Q2460-online

Farsi Q2460-online

Bahasa Indonesian Q2460-online

Thai Q2460-online

ENWW Languages 95

Welcome mats for HP LaserJet 1010 printers

Languages included in the

welcome mats Part number

English

French

German

Italian

Spanish

Dutch

Portuguese

Greek

Q1336-90901

English

Danish

Finnish

Norwegian

Swedish

Estonian

Latvian

Lithuanian

Q1336-90902

English

Polish

Hungarian

Czech

Slovakian

Slovenian

Croatian

Romanian

Q1336-90903

English

Russian

Kazakh

Ukrainian

Bulgarian

Turkish

Hebrew

Q1336-90904

English

French

Arabic

Farsi

Q1336-90905

English

Bahasa Indonesian

Traditional Chinese

Korean

Thai

Vietnamese

Q1336-90906

English

Simplified Chinese Q1336-90907

English

Spanish

Portuguese

French

Q1336-90908

96 Chapter 8 - Software availability and fulfillment ENWW

ENWW Port communication 97

9Port communication

The HP LaserJet 1015 printer includes both an IEEE-1284 (parallel) port and a USB port.

Note Do not connect the printer to the computer using both ports because printing results may be

unpredictable and this configuration is not supported.

Parallel port connections

If you are connecting the HP LaserJet 1015 using the parallel port, then the computer must

include a bidirectional data bus and cable. Ports are designated as enhanced capabilities port

(ECP), IEEE-1284, or PS/2 qualify.

Extended parallel port only (EPP-only) or unidirectional ports are not supported. However, some

ports can be set to EPP/ECP through the CMOS setup or a jumper setting, which is supported.

See Troubleshooting (page 105) in this document for parallel port issues and solutions.

Other parallel port devices

If connecting the HP LaserJet 1015 directly to the computer’s parallel port, then it is recommended

that you do not use devices such as a switch box, security dongle, or other device connected to

the same parallel port. Disconnect such devices prior to connecting and using the HP LaserJet

1015 series printer. Another option would be to have two parallel ports installed in the computer.

Parallel port expansion cards may be used, but they are not supported by Hewlett-Packard.

98 Chapter 9 - Port communication ENWW

Changing parallel port modes

This section provides the steps to make sure that the parallel port is configured to provide the best

performance with the HP LaserJet 1015 printers.

The mode for the parallel port determines how the parallel port performs with the HP LaserJet

1015 series printers. This mode can default to a number of different settings. Unfortunately, the

HP LaserJet 1015 software cannot automatically select the best setting. (ECP mode generally

provides the best printing and scanning performance.) Therefore, you need to check this setting

yourself.

Different basic input/output system (BIOS) options frequently exist within the computer

manufacturer’s range of products. Changing the parallel port mode is similar for all computers if

they have the capability built in. However, see the computer documentation for specific

instructions on changing the parallel mode for the computer.

Even though the label on the parallel port mode says ECP, it might not follow the protocol. If the

port mode option you choose does not work, then try another option in the Setup. If the computer

does not have the ECP capability built in, an external parallel port card can be installed to add this

functionality.

In addition to the parallel port mode being set incorrectly, there might be other areas of potential

parallel port conflict involving software and hardware from other manufacturers. If none of the

options in the Setup allow the HP LaserJet 1015 printer to talk to the computer, or you have other

devices that need a parallel port, you can add an external ECP parallel port card to your computer.

Then, connect the HP LaserJet 1015 printer to one of the parallel ports and connect the other

devices you have to the other parallel port. These parallel port cards are available at computer

stores and allow your HP LaserJet 1015 printer to communicate with the computer without

conflicting with other devices. For basic information on identifying and resolving device conflicts,

see “To receive the most current printer status in HP Toolbox, on the Status tab, click Refresh

Status. To run Toolbox with debugging enabled, see page 112.” on page 99.

USB port connections

The Universal Serial Bus (USB), version 2.0 full speed, is also available for both PCs and Macs.

There is a distinction between a “USB Host” and a “USB Device.” The HP LaserJet 1010 series

printer is a “USB Device.” It can connect only to a USB Host or a USB Hub.

Note Windows 95 and Windows NT 4.0 do not support USB cable connections and require HP LaserJet

1015.

ENWW HP Toolbox and embedded Web server communication 99

HP Toolbox and embedded Web server communication

The HP Toolbox includes an embedded Web server to provide the Advanced Printer Settings

functions of the HP Toolbox.

An embedded Web server resides in the HP LaserJet 1010 series printers and the HP Toolbox

communicates with this embedded Web server. The HP Toolbox is installed during the standard

install process and runs in the Apache Tomcat Server (v. 4.03) and the Sun™ Java Runtime

Environment (JRE) version 1.3.1, allowing the HP Toolbox status and device configuration to

simulate an embedded Web server in a printer that does not contain a Web server. Status Client is

a native application that is part of the HP Toolbox software and runs on the user’s computer. It

communicates with the main HP Toolbox application. In addition to the HP Toolbox and Status

Client applications, the installer installs the Tomcat server and the JRE v.1.3.1, if it is not already

installed on the user’s computer. For more information on the Apache Tomcat Server, go to http://

jakarta.apache.org/tomcat/index.html. The Apache Tomcat Server is open source software. For

more information on the Sun™ Java Runtime Environment (JRE) v. 1.3.1, go to http://

java.sun.com/j2se/1.3./.

HP Toolbox communication

HP Toolbox is available for Windows 98 SE, Windows Me, Windows 2000, and Windows XP.

HP Toolbox works with a Web browser to provide information about the printer status, as well as

configure and send alerts, provide troubleshooting, and provide user documentation. You can also

register the printer, order supplies, and access the user guide and product support.

To receive the most current printer status in HP Toolbox, on the Status tab, click Refresh Status.

To run Toolbox with debugging enabled, see page 112.

HP Toolbox embedded Web server features

Description HP Toolbox

Supported browsers The following browsers are supported:

!Microsoft Internet Explorer 5.0 and later

!Netscape Navigator 4.75 and later

Supported operating

systems

!Windows 98 SE

!Windows Me

!Windows 2000

!Windows XP

!Mac OS X v10.1 and v10.2

Connection Any direct or network connection method.

Access Requires a supported browser and network or Internet access.

Note: If the HP LaserJet 1010 series printer is behind a firewall, Internet

access may not be possible.

Supported languages For HP Toolbox supported languages, see “Ordering software” on page 93.

Installation HP Toolbox software must be installed.

Status alerts Status alert available.

Documentation and

troubleshooting

information

Available.

100 Chapter 9 - Port communication ENWW

ENWW Appendix 101

Appendix

Late-breaking Readme file

Printing System Late-breaking Readme for the

HP LaserJet 1010 series printer

***************************************************************

Late-breaking Readme Contents:

I. Introduction

- Operating Systems

- Minimum System Requirements

II. Software

III Installation

- Installation Overview

- Installation Instructions

- Installation Options

IV. HP Toolbox Functions

V. Known Issues

VI. Technical Assistance

VII. Legal Statements

- Trademark Notices

- Legal Notice

- Copyright

*****************

I. INTRODUCTION

*****************

OPERATING SYSTEMS

This readme file provides specific installation instructions and other information for the

HP LaserJet 1010 printers. Installation instructions are provided for the following operating

systems:

- Windows NT 4.0, Windows 95

- Windows 98, Windows Me, Windows 2000, Windows XP

- Macintosh 9.x, 10.1, 10.2

102 Appendix ENWW

- UNIX/Linux, DOS, OS2

For additional information on the printer features and driver features, refer to the online Help

included with each software component and to the printer online user guide on the software CD.

MINIMUM SYSTEM REQUIREMENTS

- Windows 95: (print driver only) Pentium® 90 MHz with 16 MB RAM

- Windows NT 4.0 (print driver only), Win 98, Win Me, Win 2000:

Pentium® 166 MHz with 32 MB RAM

- Windows XP: 233 MHz with 64 MB RAM

- Macintosh operating system 9.x (print driver only), or OS X (OS 10)

- 150 MB free hard disk space for full software installation, including HP toolbox

- CD-ROM drive

- USB 2.0 port or dedicated IEEE 1284-B compliant bi-directional parallel port (both ports cannot

be used concurrently)

Cables

- 2-meter parallel cable, C2950A

- 3-meter parallel cable, C2951A

- USB cable, C6518A CPC

**************

II. SOFTWARE

**************

The software included with this product is:

- PCL 5e driver

- Host-based driver

- PS driver (HP LaserJet 1015 only)

- HP toolbox 2.0

TCP/IP networking must be installed and enabled.

ENWW Late-breaking Readme file 103

*******************

III. INSTALLATION

*******************

INSTALLATION OVERVIEW

Hewlett-Packard recommends that you install the printer software before connecting the printer to

your computer with a parallel or USB cable.

INSTALLATION INSTRUCTIONS

Windows 95 and Windows NT

Only printer driver installation is supported on these operating systems. The HP toolbox software

is not supported on these operating systems. You may use the Windows operating system's Add

Printer utility to install the printer drivers. The printer drivers for a particular language and

operating system (OS) can be found in the corresponding folder on the software CD:

<language>\drivers\<OS>

Windows 98, Windows 2000, Windows Me, and Windows XP

The full HP LaserJet 1010 series software installation is supported on these operating systems.

If the 'New Hardware Found' message appears on the computer screen and you have not installed

the printer software, insert the software CD, browse and select the drive with the software CD,

click 'Next', and follow the instructions.

Macintosh Operating Systems 9.x

Only printer driver installation is supported on the Macintosh 9.x operating systems.

The HP LaserJet 1010 software is not supported on the following operating systems:

- Windows 3.x

- DOS

- Linux

- UNIX

- OS/2

- Macintosh Operating Systems earlier than version 9.1

104 Appendix ENWW

INSTALLATION OPTIONS

JAVA Runtime Environment

If the Java Runtime Environment (JRE) V1.3.1 is not found on your system during installation of

the software on Windows 98, Windows 2000, or Windows XP, the JRE is installed in the

HP toolbox 2.0 folder.

The JRE does not have a separate installer. It can be removed only if HP toolbox is uninstalled.

The JRE folder in the 'Toolbox2.0' folder (where the HP toolbox software is installed) can be

removed and another version can be installed. THE JAVA_HOME environment variable should

contain the location of the JRE.

Information about the latest version of JRE is available at the following Web site:

http://java.sun.com/j2se/1.3/

Apache Tomcat Web Server

Apache Tomcat 4.03, which is compatible with the software, will be installed in the HP toolbox 2.0

software folder.

Older Files

If HP toolbox 1.0 is installed, some files may be replaced with newer, compatible versions in the

HP toolbox 2.0 software.

Removing Printing Software Components (in Windows)

If you wish to remove printing software components, such as HP toolbox, follow these instructions:

Select 'Start', 'Programs', 'HP LaserJet 1010' group, 'Add or Remove', and then follow the

instructions. Be sure to select the components that you wish to remove.

Customization Utility

To create a custom installer, please refer to the instructions in the document, cu_readme.rtf, in the

appropriate language folder on the software CD.

ENWW Late-breaking Readme file 105

**************************

IV. HP TOOLBOX FUNCTIONS

**************************

The HP toolbox 2.0 software is available for Windows 98, Windows Me, Windows 2000, Windows

XP, and Macintosh OS X (web only). HP toolbox contains the following functions:

- check printer status

- check consumables status

- configure for printer status alerts

- troubleshooting assistance and status light patterns help

- user documentation for printer

- other helpful external web links

HP toolbox 2.0 is not available for any other operating systems. See the Installation Instruction

section, above, for details. However, in a network environment where the HP LaserJet 1010 is

connected to an HP Jetdirect print server, the HP LaserJet 1010's embedded web server can be

accessed for printer management.

HP toolbox works with a web browser and has been optimized for the following browser versions:

Windows:

- IE 5.5 and later

- Netscape 6.2 and later

- Opera 7 and later

Macintosh: (OS 10 only)

- IE 5.1 and later

- Netscape 6.23 and later

For optimal browser display of HP toolbox content, set the browser language to the language in

which the content is being displayed.

*****************

V. KNOWN ISSUES

*****************

- During installation, a 'File in use' warning may occur. If it does, click 'Ignore', and the

installation will continue and complete correctly.

- If your browser is set up to connect through a proxy server and you are unable to access

HP toolbox, add 'localhost' or '127.0.0.1' as an address for which to bypass the proxy server. (For

Internet Explorer, from the 'Tools' menu, select 'Internet Options...'. On the Connections tab, click

the 'LAN Settings' button and then click the 'Advanced...' button. For Netscape, from the 'Edit'

menu, select 'Preferences', select 'Advanced', and then select 'Proxies'.)

106 Appendix ENWW

- On Windows operating systems, Windows Networking (TCP/IP) must be enabled for

HP toolbox to work properly.

- If MS PowerPoint color text prints as black text, uncheck the 'Grayscale' or 'Black & White'

check box on the application's 'File\Print' dialog and reprint the document. (Uncheck the

'Grayscale' or 'Black & White' check box before printing each time.)

- HP recommends 'Software First' installation of the printer software on all Windows operating

systems. However, if you do a'Hardware First' installation:

1. to the USB port on Windows XP, it is recommended that you accept the default selections

that appear on the 'Found New Hardware' wizard dialogs to install the printer correctly.

2. to the parallel port on Windows 2000, and if a 'Hardware Installation' warning dialog,

which states that the software you are installing for the hardware 'has not passed Windows

Logo testing...' appears, click the 'Continue Anyway' button, and a signed driver will be installed

successfully.

- HP toolbox cannot access an HP LaserJet 1010 printer that is shared (MS Networking) by a

print server or directly connected to another computer.

- If, after installing the HP LaserJet 1010 software (including HP toolbox) with the 'Directly

connected to this computer' option, you wish to install another driver for the same printer, two

options are available (in Windows):

1. Use the Windows 'Add Printer' feature and select the DOT4 port, (e.g. DOT4_01) on

which the printer is already installed.

2a. Insert the software CD in your CD-ROM drive

b. Select the 'Add or Remove' feature in the 'HP LaserJet 1010' program group OR

Double-click 'Setup.exe' in the root of the software CD to start the installer.

c. Follow the instructions. Be sure to select the HP toolbox and the print driver you wish to

install.

d. Select 'Other', and then the DOT4 port (for example, DOT4_01) on which the printer is

already installed. Do not select USB or LPTx, where 'x' is the LPT port number.

- If, after installing the HP LaserJet 1010 software (including HP toolbox) with the 'Connected

via the network' or 'Directly connected to this computer' option, you wish to install another printer

(to a different port) and you want to access the printer with HP toolbox, you must use the software

installer on the CD. You must select HP toolbox and the print driver you wish to use in the options

provided in the installation.

- If, after installing the HP LaserJet 1010 software, you upgrade your Windows Me/98

operating system to Windows XP Pro or you upgrade your Windows 2000 operating system to

Windows XP Home, the HP toolbox software will not work properly. It is recommended that you do

the following:

1. Uninstall the HP LaserJet 1010 software.

2a. Change your Win Me/98 operating system to Win XP Pro, OR b. Change your Win

2000 operating system to Win XP Home.

3. Reinstall the HP LaserJet 1010 software.

ENWW Late-breaking Readme file 107

- When text that is printed with the HP PCL 5e driver is not optimal, try one of the following,

depending on your driver and operating system, and reprint your document:

1. To use the HP LaserJet PCL 5e print driver:

a. Win 9x, Win Me, Win NT: Check the 'Send TrueType as Bitmaps' box on the

'Finishing\Print Quality Details' page in the driver's 'Printing Preferences' or 'Properties'.

b. Win 2000, Win XP: Enable the 'Send TrueType as Bitmaps' feature on the 'Advanced'

page of the print driver's 'Printing Preferences' or 'Properties'.

2. Use the host-based driver.

- The host-based driver does not support print driver vending (point 'n print).

- When uninstalling the HP LaserJet 1010 software, if you use the 'Add or Remove' feature in

the 'HP LaserJet 1010' program group, you will need the software CD. However, if you use the

'Add/Remove Programs' feature in the Windows Control Panel group, you will not need the

software CD.

- If you use the Opera browser to access HP toolbox, please use the latest version of the

browser for best results.

- With Windows 98/Me, if the HP LaserJet 1010 software installer does not give you an option

to select the Customization Utility, run the following command from the software CD drive: '<CD

Drive>:\hpsetup.exe /a', where <CD Drive> is the letter of the drive in which the CD is installed.

- To have full printer driver functionality when printing a document to file using the

HP LaserJet PCL 5e, or the HP LaserJet PS driver with Win XP or Win 2000, you must create a

'Local Port' and map the printer driver to that port.

- In the Windows or Mac OS X environments, the printer symbol set can be set by accessing

the printer's embedded web server directly or through the HP toolbox. In the DOS environment,

set the symbol set as follows:

1. Find the '.pjl' file for your language in the 'DOS' folder at the root of the software CD.

2. From a DOS window, copy the file to the printer port (for example, 'copy /b <filename>

LPTx', where x is your LPT port number). Please read the 'SYMreadme.txt' file at the root of the

software CD for detailed instructions.

- Windows XP 64-bit print drivers for HP LaserJet 1010 printers will be available only on the

web.

- HP toolbox for Mac OS X is available only on the web. The print drivers for the Mac

operating system are available on the software CD and the web.

- Installation of the software on a Novell network using the HP software installer is not

supported. To install print drivers on a Novell Network, use Novell's driver installer.

108 Appendix ENWW

***************************

VI. TECHNICAL ASSISTANCE

***************************

OBTAINING ADDITIONAL INFORMATION FROM HP SERVICES

See the flyer that shipped in the box with the product.

OBTAINING INFORMATION VIA THE INTERNET

HP provides technical assistance and support 24 hours a day, 7 days a week, at no charge. For

updated HP printer software, product and support information, and printer drivers in several

languages, use the following URLs to reach HP via the internet.

HP LaserJet 1010: http://www.hp.com/support/lj1010

(Site is in English.)

General HP access: http://www.hp.com

***********************

VII. LEGAL STATEMENTS

***********************

TRADEMARK NOTICES

Microsoft®, MS-DOS®, Windows®, and Windows NT® are U.S. registered trademarks of Microsoft

Corporation.

TrueType(TM) is a U.S. trademark of Apple Computer, Inc.

Adobe® and PostScript® are trademarks of

Adobe Systems Incorporated.

LEGAL NOTICE

This software is owned and copyrighted by Hewlett-Packard or its third-party suppliers.

Additional copies of the software are available through the Windows Installer Disk Copy utility or at

the HP website:

http://www.hp.com.

NO WARRANTY. This software is provided "As Is" with no warranty.

ENWW Late-breaking Readme file 109

LIMITATION OF LIABILITY. IN NO EVENT WILL HP OR HP SUPPLIERS

BE RESPONSIBLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

CONSEQUENTIAL (INCLUDING LOSS OF USE OR LOSS OF DATA) OR

OTHER DAMAGES ALLEGED TO BE CAUSED BY THE USE OF THIS SOFTWARE.

U.S. GOVERNMENT RESTRICTED RIGHTS: The software and any accompanying

documentation have been developed entirely at private expense. They are delivered and licensed

as "commercial computer software" as defined in DFARS 252.227-7013 (Oct 1988), DFARS

252.211-7015 (May 1991) or DFARS 252.227-7014 (Jun 1995), as a "commercial item" as defined

in FAR 2.101(a), or as "restricted computer software" as defined in FAR 52.227-19 (Jun 1987) (or

any equivalent agency regulation or contract clause), whichever is applicable. You have only

those rights provided for such software and any accompanying documentation by the applicable

FAR or DFARS clause or the HP standard software agreement for the product involved. The

owner is Hewlett-Packard Company, 3000 Hanover Street, Palo Alto, California 94304.

COPYRIGHT

Copyright (c) 2003 Hewlett-Packard Company

110 Appendix ENWW

ENWW 111

Index

Symbols

*.INI and Windows registry changes 87

A

Alerts tab 78

availability, software 93

C

cables 15

capabilities, paper handling 16

cartridges, print 16

changes, *.INI and Windows registry 87

changing parallel port modes 98

communication

HP toolbox 99

port 97

comparison, product 15

configuration 43

HP LaserJet 1010 10

HP LaserJet 1012 10

HP LaserJet 1015 10

printer 9

settings 43

supported 20

Windows sharing 40

Configure tab

PCL 5e printer driver 66

connecting to the network 20

connections

direct (local) 20

network 20

parallel port 97

requirements for network connection 23

wireless 20

connectivity options 15

control panel 15

copyright information 7

custom installation 25

D

device memory 15

devices, other 97

direct connection 20

requirements for Mac systems 22

requirements for Windows systems 21

discovery process during installation 39

duty cycle (pages per month) 16

E

Easy Install (Macintosh) 25

Effects tab

PCL 5e printer driver 59, 73

end-user client computers, requirements 23

F

features 15

networking 15

print 16

files

not removed 90

Finishing tab

host-based printing 49

PCL 5e printer driver 56, 71

folders

default installation, Macintosh 25

formatter 15

H

host-based printing 12, 46

Finishing tab 49

Paper/Quality tab 46

HP Jetdirect external print server

using 38

HP LaserJet 1010

configuration 10

printer drivers 13

software components 11

user guides 94

HP LaserJet 1010 series

printer drivers 13

system requirements 21

HP LaserJet 1012

configuration 10

software components 11

HP LaserJet 1015

configuration 10

HP toolbox 77

browsers 77

communication 99

to view 77

I

IEEE 802.11b standard 20

installation

custom (Windows) 25

discovery process 39

Mac, system changes 87

network 38

networked computers 38

overview 25

printer drivers only 41

settings, changing 25

software 25

system changes 87

typical (Windows) 25

Windows 95 14

Windows NT 4.0 14

Windows system changes 87

installation options

Mac systems 36

Windows systems 26

issues

service 101

J

Jetdirect print servers, support 15

L

languages

printer 15

late-breaking readme file 109

limited support

Windows 95 and Windows NT 4.0 14

local connections 20

localization 94

Index

112 ENWW

M

Mac

installation changes 87

software 13

software uninstall 91

systems installation options 36

Mac OS 9.x

system requirements 22

Mac OS X 10.x

system requirements 22

manual uninstall 90

N

network

connections 20

installation 38

requirements for connection 23

networked computers

installation instructions 38

networking 15

O

operating systems supported 16

options

connectivity 15

ordering software 93

overview

software 9

software installation 25

P

pages per month (duty cycle) 16

paper handling capabilities 16

paper path 17

Paper/Quality tab

host-based printing 46

PCL 5e printer driver

Paper/Quality tab 69

parallel port

changing modes 98

other devices 97

part numbers 94

PCL 5e printer driver

Configure tab 66

Effects tab 59, 73

Finishing tab 56, 71

Paper/Quality tab 69

PCL printing 12

platforms, supported 19

port

communication 97

connections 97

parallel connections 97

USB connections 98

power switch 15

preferences, printing 45

print

features 15, 16

quality 16

speeds 16

print cartridges 16

print server

HP Jetdirect external print server 38

printer

configurations 9

languages 15

software installation, Windows 95 and Windows NT 4.0 26

printer driver software, overview 12

printer drivers

HP LaserJet 1010 13

installation 41

Windows 13

Windows installation 41

printer software components

HP LaserJet 1010 11

software components 11

printing

host-based 12

PCL 12

printing preference tabs 46

printing preferences 45

host-based 46

printing preferences, gaining access

through current software application 45

through the printer driver 45

product

comparison 15

monitoring file 87

requirements 19

Q

quality, print 16

R

readme file, late-breaking 109

registry changes

Windows 87

requirements

end-user client computers 23

for direct connection 21, 22

for network connection 23

product 19

S

service

issues 101

settings, configuration 25

software

availability and fulfillment 93

configuration settings 43

features 14

installation 25

installation, overview 25

Mac 13

ordering 93

overview 9

uninstall, Mac 91

uninstall, Windows 89

speeds, print 16

support, Jetdirect print servers 15

supported

browsers, HP toolbox 77

configurations 20

operating systems 16

operating systems, HP Toolbox 77

platforms 19

system changes through installation 87

Mac 87

Windows 87

system requirements

HP LaserJet 1010 series 21

Mac OS 9.x 22

Mac OS X 10.x 22

Index

ENWW 113

T

trademark notices 7

typical installation 25

U

uninstall, manual 90

uninstallation 89

upgradability 16

USB

port connections 98

user guides 94

using

HP Jetdirect external print server 38

V

view, HP toolbox 77

W

welcome mats 95

Win.ini changes after installation 87

Windows

custom installation 25

installation changes 87

installation options 26

printer driver installation 41

printer drivers 13

software uninstall 89

Windows 2000

host-based printing preference tabs 46

Windows 95

installation 14

limited support 14

software installation 26

Windows 98

host-based printing preference tabs 46

Windows Me

host-based printing preference tabs 46

Windows NT 4.0

installation 14

limited support 14

software installation 26

Windows registry changes 87

Windows sharing, configuration 40

Windows XP

host-based printing preference tabs 46

wireless connections 20

wireless printing

IEEE 802.11b standard 20

wireless technology, Bluetooth 21

Index

114 Index ENWW
