White Paper
Document number PRT011B0998
Publication date: November 1998
PRT011B0998
Prepared by Software Marketing
Compaq Computer Corporation
Summary ....................................3
Installation Requirements
and Dependencies......................3
Terms and Assumptions............4
Installation Scripts .....................5
New Installation ........................5
Upgrading from Windows 95 .....9
Upgrading from Windows
3.1x........................................14
Installing Compaq Drivers
and Enhancements...................19
Compaq Drivers and Support
Software.................................19
SoftPaq Installation
Procedures.............................22
Appendix 1: Downloading
Software from the Compaq
Website.....................................32
Appendix 2: Using the
SoftPaq Utility...........................33
Appendix 3: Installing
Diagnostics and Setup............34
Appendix 4: Determining
Your ROM Version and
Upgrade Version.......................35
Determining Your ROM
Version Using Inspect .............35
Appendix 5: Docking for the
First Time..................................37
Appendix 6: ACPI .....................38
Appendix 7: Enabling Hard
Drive DMA.................................39
Appendix 8: Infrared
Functionality.............................40
Installing Microsoft Windows 98
on Compaq Portable Products
Abstract: This White Paper focuses on the steps necessary for the
successful installation of Microsoft Windows 98 on select Compaq
Armada portable products. The steps outlined herein will provide the
user with complete installation procedures for a clean installation or
an upgrade installation over Windows 3.1x/Windows 95.
Compaq has made available the Windows 98 specific installation
instructions and software enhancements (BIOS, hardware-enabling
drivers, and software applications) for the Armada 1100, 1500,
1700, 3500, 4100, 4200, 7300, 7400, 7700, 7800, SB families, and
LTE 5000 families. This white paper instructs you on installing the
operating system and Compaq enhancements.
Although Compaq will support customers that upgrade to Windows
98 on the Armada 6500, doing so at this time is not recommended.
Compaq continues to test Windows 98 on the Armada 6500 and
intends to release updates to many existing Compaq drivers, BIOS
and other software enhancements specifically for Windows 98 in
4Q98. Windows 98 will install and run on the Armada 6500.
However, it is important to note that without the updated versions of
various Compaq enhancements, users will experience a loss of
functionality.
Please refer to Read This First - Limitations When Using Microsoft
Windows 98 on Compaq Armada Portables before you install
Windows 98.
For details on Compaq’s overall operating system strategy and
operating system features please refer to the white paper titled
Operating System Support for Compaq Portable Platforms.
Installing Microsoft Windows 98 on Compaq Portable Products 2
Document number PRT011B0998
Notice
The information in this publication is subject to change without notice and is provided “AS IS” WITHOUT
WARRANTY OF ANY KIND. THE ENTIRE RISK ARISING OUT OF THE USE OF THIS
INFORMATION REMAINS WITH RECIPIENT. IN NO EVENT SHALL COMPAQ BE LIABLE FOR
ANY DIRECT, CONSEQUENTIAL, INCIDENTAL, SPECIAL, PUNITIVE OR OTHER DAMAGES
WHATSOEVER (INCLUDING WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION OR LOSS OF BUSINESS INFORMATION), EVEN IF
COMPAQ HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
The limited warranties for Compaq products are exclusively set forth in the documentation accompanying
such products. Nothing herein should be construed as constituting a further or additional warranty.
This publication does not constitute an endorsement of the product or products that were tested. The
configuration or configurations tested or described may or may not be the only available solution. This test
is not a determination or product quality or correctness, nor does it ensure compliance with any federal
state or local requirements.
Product names mentioned herein may be trademarks and/or registered trademarks of their respective
companies.
Compaq, Contura, Fastart, Compaq Insight Manager, LTE, ROMPaq, LicensePaq, SmartStart, NetFlex,
RemotePaq, BackPaq, TechPaq, SpeedPaq, QuickBack, PaqFax, Aero, SmartStation, MiniStation, and
PaqRap, registered United States Patent and Trademark Office.
Netelligent, Armada, Cruiser, Concerto, LTE Elite, Vocalyst, PageMate, SoftPaq, FirstPaq, SolutionPaq,
EasyPoint, EZ Help, MaxLight, MultiLock, QuickBlank, QuickLock, UltraView, Innovate logo, Wonder
Tools logo in black/white and color, and Compaq PC Card Solution logo are trademarks and/or service
marks of Compaq Computer Corporation.
Microsoft, Windows, Windows NT, Windows NT Server and Workstation, Microsoft SQL Server for
Windows NT are trademarks and/or registered trademarks of Microsoft Corporation.
NetWare and Novell are registered trademarks and intraNetWare, NDS, and Novell Directory Services are
trademarks of Novell, Inc.
Pentium is a registered trademark of Intel Corporation.
Copyright ©1998 Compaq Computer Corporation. All rights reserved. Printed in the U.S.A.
Installing Microsoft Windows 98 on Compaq Portable Products
White Paper prepared by Software Marketing
Second Edition (November 1998)
Document Number PRT011B0998
Installing Microsoft Windows 98 on Compaq Portable Products 3
Document number PRT011B0998
Summary
This white paper discusses installing Microsoft Windows 98 on Compaq Armada portable
products. The intent of the white paper is to provide step by step instructions for the installation
process either as an upgrade from Windows 3.1, Windows 95, or as a newly installed operating
system on a Compaq Armada portable. When you have completed all the procedures outlined for
your specific platform, you will have successfully installed Windows 98 and all Compaq
provided software deliverables that extend functionality and enhance the overall user experience.
These scripts are for installing Windows 98 with APM (Advanced Power Management) support.
If you wish to enable ACPI (Advanced Configuration and Power Management) on those Armada
notebooks which support ACPI, see Appendix 6, “ACPI.”
Note: You must back up all data and applications before beginning any installation procedures of
Windows 98.
Installation Requirements and
Dependencies
Before beginning the installation scripts for any of the platforms, you have to obtain the items
listed below:
• The Retail Microsoft Windows 98 CD-ROM or Upgrade CD-ROM, or the Compaq Upgrade CD-
ROM, as applicable.
• Microsoft DOS Boot Diskette with FDISK, FORMAT, and SYS utilities if not performing an upgrade
installation. In addition, Microsoft utilities XCOPY and MSCDEX may also be needed if performing a
clean installation or upgrading from Windows 3.1x.
• Windows 98 Drivers and Enhancements from Compaq.
Installing the latest versions of Windows 98 compatible Drivers and Enhancements is very
important. Previous versions may not work or may produce anomalies.
You may obtain the drivers and enhancements in two ways; from the Compaq Support
Software CD or by downloading the driver software from the Compaq website.
− The Compaq Support Software CD version 98.08 (or later) contains all updated drivers and
deliverables listed in the section titled "Installing Compaq drivers and enhancements." The
Compaq Support Software CD is updated monthly and is available either through an annual
subscription or as a one-time purchase.
− The Compaq website at http://www.compaq.com/support/files/portables/us/index.html. has the
downloadable driver software files. For instructions on using the Compaq website see Appendix 1,
“Downloading Software from the Compaq Website.”
• Blank, high-density floppy diskettes, if you choose to make the recommended Windows 98 Startup
Diskette, and for downloading SoftPaqs from the Compaq website.
• ROM version required. For information on determining the current ROM version for your portable
model and how to update if necessary, see Appendix 4, “Determining Your ROM Version and
Upgrade Version.”
Installing Microsoft Windows 98 on Compaq Portable Products 4
Document number PRT011B0998
Table 1. Current Compaq ROM Versions
Portable Family Current ROM Version
Armada 1100 Family 07/18/98
Armada 1500 and SB Families 8/31/98
Armada 1700 Family 09/09/98
Armada 3500 Family 09/09/98
Armada 4100 Family 05/04/98
Armada 4200 Family 05/21/98
Armada 7300/7700 Families 05/13/98
Armada 7400/7800 Families 08/07/98
LTE 5000 Family 05/31/98
Terms and Assumptions
• Secondary-click—Throughout the scripts, the term secondary-click is used. For right-handed mouse
users, this is the right mouse button. For left-handed mouse users, this is the left mouse button.
• Double-click—Throughout the scripts, you are asked to double-click certain items. If you are using
Microsoft’s Internet Explorer 4.x and have turned on the single-click option, you should simply single-
click the selection, not double-click as indicated in these instructions.
• Drive Letters—All drive letters used for hard drives and CD-ROM drives are examples only. Your
individual configuration may vary. D: may be the drive letter used in the example, however the letter
for your CD-ROM drive may actually be E:.
• Web—A term used synonymously with www.compaq.com/support/files/portables/us/index.html, the
Compaq Support Software CD, the Compaq BBS, or the Compaq FTP site. It is important that you
obtain the latest Windows 98 compatible drivers and enhancements from one of these sites.
• Drivers and Enhancement File Locations—Most drivers and enhancements are assumed to be in the
directory C:\~COMPAQ\XXXXXXXX where XXXXXXXX is the subdirectory name created by the
SoftPaq utility for these scripts. If you are unfamiliar with the SoftPaq utility and extracting files, see
Appendix 2, “Using the SoftPaq Utility.” One exception is the Real Mode CD-ROM drivers that may
be on diskette, normally the A: drive.
• Restarting the Computer—During the Windows 98 installation, and the installation of several drivers
and enhancements, you are prompted to restart the computer. Be sure that you have removed any
floppy diskettes from the diskette drive and the Windows 98 disk from the CD-ROM drive, as
applicable, before restarting the computer.
• Real Mode CD-ROM Drivers—Depending on your platform, these can be found on the web
www.compaq.com/support/files/portables/us/index.html either under Windows 3.1 or Windows 95.
They are listed as either “IDE CD-ROM Drivers” under the Storage section or as “Real Mode Support”
under the Utilities section.
Instructions for using the Compaq website and Compaq SoftPaqs are located in the appendices at
the end of this document.
Installing Microsoft Windows 98 on Compaq Portable Products 5
Document number PRT011B0998
Installation Scripts
This scripts apply to the Armada 1100, 1500, 1700, 3500, 4100, 4200, 7300, 7400, 7700, 7800,
SB families, and LTE 5000 families unless otherwise noted.
New Installation
Preliminary Steps
You must prepare an MS-DOS boot diskette with the Compaq Real Mode CD-ROM drivers to
have access to the CD-ROM drive during the installation process.
1. Connect the unit to an AC power source. This prevents it from abruptly shutting down if the battery
power gets too low, which could corrupt the Windows 98 installation.
2. Undock your system and remove any PC cards from the PCMCIA slots. For information on docking
your Armada Portable for the first time, see Appendix 5, “Docking for the First Time.”
3. Obtain the latest Real Mode CD-ROM driver from the web and extract it from the SoftPaq.
4. Copy the CD-ROM driver, the SYS utility, and the MSCDEX file to the MS-DOS boot diskette by
typing the following commands at the DOS prompt, pressing Enter after each command:
a. COPY CPQLTECD.SYS A:
b. COPY MSCDEX.EXE A:
c. COPY SYS.COM A:
5. Create a CONFIG.SYS file and an AUTOEXEC.BAT file on the boot diskette to load the CD-ROM
drivers. Use an editor of your choice to create a one line CONFIG.SYS file containing the entry:
DEVICE=CPQLTECD.SYS /D: IDECD001
Note: An editor is a program for creating and changing simple text files. Two examples are
“EDIT” for DOS and “NOTEPAD” for Windows.
6. Use your editor to create a one line AUTOEXEC.BAT file containing the entry:
MSCDEX /D:IDECD001
If your hard drive does not currently have an operating system installed, or if your current
operating system uses NTFS or HPFS for its file system, or if you have an operating system
installed using the FAT file system and wish to remove it, perform steps 6a, 6b, and 6c to
prepare the hard drive for Windows 98 installation. Otherwise, proceed to step 7.
Note: If you do not have a non-DOS partition as partition 1, Compaq strongly recommends
the installation of Diagnostics and Setup after removing all other partitions and before
proceeding with the operating system installation. For instructions on this installation, see
Appendix 3, “Installing Diagnostics and Setup.”
Exception: The Armada 6500 does not use standard Compaq Diagnostics and Setup.
a. Back up all data and applications before removing any partitions and reformatting the hard drive
or all data will be lost.
b. Boot the system with the MS-DOS boot diskette inserted into the diskette drive.
Installing Microsoft Windows 98 on Compaq Portable Products 6
Document number PRT011B0998
IMPORTANT: Do not delete the non-DOS partition that contains your installed
Compaq Diagnostics and Setup.
To repartition the hard drive with a single Primary DOS partition:
c. Type FDISK and press Enter.
If you are not sure about the use of the FDISK program, refer to Microsoft’s KB article
Q106423 for instructions. This article may be found online at
http://support.microsoft.com/support/kb/articles/q106/4/23.asp.
7. Reformat the hard drive. Boot the system with the MS-DOS boot diskette inserted into the diskette
drive.
8. Type FORMAT C:/S from the MS-DOS A:> prompt and press Enter.
9. When warned that all data on the hard drive will be deleted, press Y and Enter to proceed with
formatting the hard drive.
10. Enter a volume label or simply press Enter. A “system transferred” message should appear.
11. Copy the Real Mode drivers, AUTOEXEC.BAT, and CONFIG.SYS from the boot diskette to the hard
drive.
From the MS-DOS A:> prompt, type each of the following lines, pressing Enter at the end of each
line:
a. COPY AUTOEXEC.BAT C:
b. COPY CONFIG.SYS C:
c. COPY MSCDEX.EXE C:
d. COPY CPQLTECD.SYS C: (You may have to check the floppy drive directory for this file.)
12. Armada SB, 1100, 1500, 1700, 3500, 4100, and 4200 Family users should remove the Boot Diskette
from the floppy drive and restart the system by simultaneously pressing and holding Ctrl, Alt, and
Del.
Armada 7000 and LTE 5000 Family users should power off the system, swap the diskette drive for
the CD-ROM drive, and restart the computer. If you are not sure how to swap the diskette drive for the
CD-ROM drive, see your unit documentation.
After the computer reboots and the C:> prompt is displayed, you are ready to install Windows 98.
Installing Microsoft Windows 98 on Compaq Portable Products 7
Document number PRT011B0998
Installation Procedure
This script relies on using the retail release of Windows 98. If upgrading from Windows 3.1 or
Windows 95, see those respective sections. If using a Windows 98 upgrade CD for this
installation, your results may vary slightly. You will also need the original media for Windows
3.1 or Windows 95 to complete the upgrade.
1. Copy the Windows 98 setup files to the hard drive. You may need them for future additions of new
hardware, such as PC Cards, or for docking the unit for the first time.
a. Type MD WIN98 and press Enter.
b. Type CD WIN98 and press Enter.
2. Place the Windows 98 disk into the CD-ROM drive.
a. Type COPY D:\WIN98\*.* and press Enter.
Note: If you want to install the Microsoft Channel Content, use the following command at
step 2: XCOPY D:\WIN98\*.* /S.
Armada 7000 and LTE 5000 Family users only should now power off the system, swap the
CD-ROM drive for the diskette drive and then restart the computer. If you are not sure how to
swap the diskette drive for the CD-ROM drive, see your unit documentation. After the system
reboots,
b. Type CD WIN98 and press Enter.
3. Type SETUP and press Enter. The next screen informs you how Setup will perform a routine system
check.
4. Press Enter to continue. The Windows 98 Setup screen appears.
5. Click Continue. The License Agreement appears. After reading the License Agreement:
a. Click on ‘I accept the Agreement.’
b. Click Next to accept the Agreement.
6. Enter the Product Key on the Certificate of Authenticity that came with your Windows 98
documentation, then click Next to continue.
7. Select the directory where the operating system will be installed. The recommended directory is the
default directory, C:\WINDOWS.
Click Next to accept the default directory, or,
If you choose to use a directory other than the default directory:
Click Other Directory, enter the directory name, then click Next.
8. Select the type of installation to be performed. If you are unsure of which type to select, contact your
IT department, otherwise:
a. Select Portable.
b. Click Next to continue.
9. Enter your name and, if desired, tab to the Company field and enter your company name, then click
Next to continue.
Installing Microsoft Windows 98 on Compaq Portable Products 8
Document number PRT011B0998
10. Select the Windows Components to be installed. If you are unsure which to install:
Click Next to install the most common components, or,
Click on ‘Show me the list of components so I can choose,’ select the components you want to install,
then click Next to continue.
11. If the unit has an integrated modem, you are asked to enter the computer identification information.
a. Every computer on a network must have a unique name. Accept the default or change the name as
appropriate. Tab to the next field.
b. A Workgroup is a group of related computers. Accept the default or change the Workgroup as
appropriate. Tab to the next field.
c. The Computer Description is just that. Accept the default or change the description as appropriate.
Click Next to continue.
12. Click Next to create a Startup Disk. You may elect to skip this process. However, Compaq strongly
recommends creating a Startup disk.
a. Insert a blank, high-density diskette into the diskette drive and click OK.
b. When prompted, remove the diskette and click OK.
13. The Windows 98 files are copied to their installation directory. Click Next to continue.
14. This phase is now complete and the unit reboots. Click Restart Now or wait.
15. Click Next from the PC Card Setup Welcome screen.
16. Click Next on the second PC Card Wizard screen.
17. Click Finish on the third PC Card Wizard screen.
18. Verify your geographical location, select the correct time zone, and date and time for your area. Click
Next.
19. After Setup finishes this phase, the unit reboots. Click Restart Now or wait.
20. The user name from the Identification setup (step 11) is displayed.
a. To change the user name:
Click the ‘User name’ field, delete the current name, and replace it with the user name you wish to
use.
b. To enter a password:
Tab to the Password field and enter a case sensitive password. Confirm the password by retyping,
then click OK to continue.
21. Windows finalizes your Personalized Settings. The Welcome to Windows 98 screen displays.
If you do not want to see this screen the next time you start Windows, click on ‘Show this screen each
time Windows 98 starts’ to uncheck the box.
22. Click on the X in the upper right corner of the window to close it.
23. After the unit reboots, click on the X in the upper right corner of the Welcome window to close it.
Installing Microsoft Windows 98 on Compaq Portable Products 9
Document number PRT011B0998
24. Remove the Real Mode drivers. To do this, delete the AUTOEXEC.BAT, CONFIG.SYS,
CPQLETCD.SYS, and MSCDEX.EXE files.
a. Double-click on the “My Computer” icon.
b. Click View →→ Folder Options →→ View →→ Show All Files on the menu bar, then click OK
c. Double-click the (C:) icon. You can view the files listed above.
d. Click each file name, then press Delete. Confirm that you are deleting the correct file, then click
YES. Repeat until all the files listed in step 24 have been deleted.
25. Double-click the WINDOWS folder.
26. Click SHOW FILES on the left side of the window.
27. Scroll through the list of files until you see the DOSSTART file.
28. Highlight the DOSSTART file and press Delete. Click YES to confirm deletion of this file.
The Windows 98 operating system installation is now complete. Proceed to the section titled
“Installing Compaq Drivers and Enhancements” to install the other necessary files for your
Compaq portable computer to ensure the system’s complete functionality and stability.
Note: Armada 1700 and 7000 family users may wish to enable DMA. For instructions on
how to enable DMA, see Appendix 7, “Enabling Hard Drive DMA.”
Upgrading from Windows 95
A successful installation requires:
• A stable Windows 95 environment. If you are currently having problems with your Windows 95
operating system, or with applications while in Windows 95, Compaq recommends that these issues be
resolved before upgrading to Windows 98.
• Either the retail version of the Microsoft Upgrade CD-ROM or the Compaq Upgrade CD-ROM, as
applicable.
Please review the README.TXT file located in the root folder on the Windows 98 CD-ROM
and the SETUP.TXT file in the WIN98 folder. README lists other text files that are installed as
part of the operating system installation. These files contain information on known hardware and
software issues that you should be aware of before installing Windows 98. These files are located
in the file WIN98_47.CAB file. You may manually extract these files and review them before
installing Windows 98. For instructions on how manually to extract these files before the
installation, refer to Microsoft KB article Q129/6/05, which may be found online at
http://support.microsoft.com/support/kb/articles/q129/6/05.asp.
Review the Microsoft website for any changes or additions to the README, SETUP, or other
associated files.
Installation Procedure
1. Connect the unit to an AC power source. This prevents it from abruptly shutting down if the battery
power gets too low, which could corrupt the Windows 98 installation.
2. Back up all data and programs before beginning the upgrade process.
3. Undock your system and remove any PC cards from the PCMCIA slots. For information on docking
your Armada Portable for the first time, see Appendix 5, “Docking for the First Time.”
Installing Microsoft Windows 98 on Compaq Portable Products 10
Document number PRT011B0998
4. Swap the diskette drive for the CD-ROM drive. If you are not sure how to swap the diskette drive for
the CD-ROM drive, see your unit documentation.
If you are not running Real Mode PCMCIA drivers, proceed to step 5.
If you are using Real Mode PCMCIA drivers, they should now be disabled; if unsure, please
continue through steps 4a to 4p. These steps are for the Compaq specific version of
SystemSoft’s CardWizard. If you are using another company’s Card & Socket Services,
please consult your documentation on how to disable them.
a. Click Start →→ Run on the Task Bar.
b. Type SYSEDIT and click OK.
c. Click the title bar labeled C:\CONFIG.SYS.
d. Find the line ‘rem SystemSoft CardSoft/16™ PCMCIA Drivers.’ At least four lines may need to
be commented out. If the drivers were installed to the default directory, they all contain
CARDWIZ, or CARDWORKS as part of the text.
e. Type REM and a space at the beginning of each line.
f. Click the title bar labeled C:\WINDOWS\SYSTEM.INI. If it is not visible, click Window on the
title-bar and select the SYSTEM.INI file by clicking on it. Scroll through this file until you see
‘[386Enh]’.
g. Again, look for the lines that contain the phrase ‘C:\CARDWIZ\.’ Place a ; (semicolon) and a
space at the beginning of each line.
h. Close the System Configuration Editor by clicking on the X in the upper right corner of the
windows. You are prompted to save each file. Confirm that you wish to save each file by clicking
YES.
i. Secondary-click the Start on the Taskbar.
j. Click Explore.
k. Double-click Programs.
l. Double-click Start Up.
m. If there is an icon named ‘CardWizard’ in the right pane, highlight it, then press Delete.
n. Click YES to confirm deleting the icon.
o. Exit the window by clicking the X in the upper right corner.
p. Restart the computer by clicking Start →→ Shut Down →→ Restart and click YES.
You are now ready to install Windows 98 by first copying the Windows 98 setup files to the hard
drive. You will need these files for future additions of new hardware or for docking for the first
time.
IMPORTANT: For Armada 4100 and LTE 5000 users only:
You must uninstall Win 95-specific Infra-Red Support before beginning the Win 98 upgrade.
Open the Control Panel and select Add/Remove Programs. Select “InfraRed Support for Win 95
Version x.x” by clicking once with the left mouse button, then click Add/Remove. Close the
Control Panel.
You must uninstall Intelligent Manageability for Win 95 before beginning the Win 98 upgrade.
Open the Control Panel and select Add/Remove Programs. Select “Compaq Insight Manager”
by clicking once with the Left Mouse Button, then click Add/Remove. Close the Control Panel.
Installing Microsoft Windows 98 on Compaq Portable Products 11
Document number PRT011B0998
5. Double-click My Computer.
6. Double-click the hard drive icon ‘(C:)’.
7. Secondary-click in the open area of the My Computer window and choose New →→ Folder.
8. Type WIN98 and press Enter.
9. Double-click on the WIN98 folder.
10. Place the Windows 98 disk into the CD-ROM drive.
Note: If Autoplay (or Auto Insert Notification) is enabled, a dialog box appears informing
you that the ‘…CD-ROM contains a new version of Windows …’ and asks if you would like
to upgrade. Click NO. A window titled ‘Windows 98 CD-ROM’ is displayed. Click ‘Browse
This CD’ and proceed to step 11.
11. Double-click My Computer.
12. Double-click the CD-ROM drive icon ‘(D:)’.
13. Double-click the folder WIN98.
14. Click View →→ List on the Menu bar.
15. Click the file named BASE4. Press and hold Shift and Ctrl, then press End (all listed files are
selected).
Note: If you want to install the Microsoft Channel content, use the following instruction to
replace the one in step 15: Click Edit →→ Select All.
16. Click Edit →→ Copy on the Menu bar.
17. Close this window by clicking on the X in the upper right corner. You should now see the window
labeled C:\WIN98.
18. Click Edit →→ Paste on the Menu bar to copy the files.
19. Armada 7000 and LTE 5000 Family users only—After the files have been copied to the hard drive,
close all open windows, remove the CD-ROM disk from the its drive, and power off the system. Swap
the CD-ROM drive for the diskette drive and then restart the computer.1
− Double-click in the following order: My Computer/the C: icon/Win98 folder.
20. Double-click the SETUP.EXE file in the C:\WIN98 directory. The ‘Windows 98 Setup’ screen
appears.
21. Click Continue. The License Agreement appears.
22. After reading the License Agreement, click on ‘I accept the Agreement’ and click Next to accept the
Agreement.
23. Enter the Product Key on the Certificate of Authenticity that came with your Windows 98
documentation, then click Next to continue.
24. You are asked if you wish to save the existing system files. Compaq strongly recommends doing so.
Click on the appropriate selection, then click Next to continue.
Note: If you have more than one partition on your hard drive, you are prompted where to
save the ‘uninstall’ files. Choose the appropriate drive and click OK.
1 See your documentation if unsure how to swap the diskette drive for the CD-ROM drive.
Installing Microsoft Windows 98 on Compaq Portable Products 12
Document number PRT011B0998
If networking was not installed in your system as part of Windows 95, or if the unit has an
integrated modem, proceed to step 26.
25. If networking was installed in your system as part of Windows 95 (other than Dial-Up Networking
without the Microsoft client) or if the unit has an integrated modem, you are asked to enter the
computer identification information.
a. Every computer on a network must have a unique name. Accept the default or change the name as
appropriate. Tab to the next field.
b. A Workgroup is a group of related computers. Accept the default or change the Workgroup as
appropriate. Tab to the next field.
c. The Computer Description is just that. Accept the default or change the description as appropriate.
Click Next to continue.
26. You are asked to verify your geographical location, select the appropriate time zone, and date and time
for your area. Make your selections and click Next.
27. Click Next to create a Startup Disk. You may elect to skip this process. However, Compaq strongly
recommends creating a Startup disk.
a. Insert a blank, high-density diskette into the diskette drive and click OK.
b. When prompted, remove the diskette and click OK. The Windows 98 files are copied to their
installation directory. 2 Click Next to continue.
28. No user input is required during this next phase. Do nothing while the system updates and finalizes
your settings.
Note: The left margin on your screen informs of the time remaining in this finalization
process.
29. After Setup finishes this phase, the unit reboots. Click Restart Now or wait.
30. After rebooting, if you performed step 25, the user name you entered in that step is shown.3 If you wish
to change this, click the ‘User name’ field, delete the current name, and replace it with the user name
you want to use. If you want to enter a password, Tab to the Password field and enter a password.4
Click OK to continue.
Note: If this is the first time this user name has been used on this computer, you are asked to
reenter the password. Confirm the password by retyping it and click OK. If the passwords do
not match, you are asked to type them again. Click OK to reenter the password. If you
previously had a password for the user name entered, this one must match the previous.
31. Windows finalizes your Personalized Settings and displays the Welcome to Windows 98 screen. If you
do not want to see this screen the next time you start Windows, uncheck the box ‘Show this screen
each time Windows 98 starts’ by clicking on that text. Close this window by clicking on the X in the
upper right corner of the window. The next time the unit reboots, click on the X in the upper right
corner of the Welcome window to close it.
2 You may experience Windows 98 Setup needing to be reminded where the installation directory is. If you are prompted that a file
cannot be found, click OK, reenter the path C:\WIN98, and click OK.
3 In certain instances, this step may be skipped.
4 Passwords are case sensitive.
Installing Microsoft Windows 98 on Compaq Portable Products 13
Document number PRT011B0998
This completes the Windows 98 installation. Proceed to “Installing Compaq Drivers and
Enhancements” to install the other necessary files for your Compaq portable computer.
IMPORTANT: You must install all drivers for your system to have complete functionality.
Note: Armada 1700 and 7000 family users may wish to enable DMA. See Appendix 7,
“Enabling Hard Drive DMA” for instructions on how to enable DMA.
Installing Microsoft Windows 98 on Compaq Portable Products 14
Document number PRT011B0998
Upgrading from Windows 3.1x
A successful installation requires:
• A stable Windows 3.1x environment. If you are currently having problems with your Windows 3.1x
operating system, or with applications while in Windows 3.1x, Compaq recommends that these issues
be resolved before upgrading to Windows 98.
• Either the retail version of the Microsoft Upgrade CD-ROM or the Compaq Upgrade CD-ROM, as
applicable.
• An original Disk One of Windows 3.1x to use the upgrade CD.
Please review the README.TXT file located in the root folder on the Windows 98 CD-ROM
and the SETUP.TXT file in the WIN98 folder. README lists other text files that are installed as
part of the operating system installation. These files contain information on known hardware and
software issues that you should be aware of before installing Windows 98. These files are located
in the file WIN98_47.CAB file. You may manually extract these files and review them before
installing Windows 98. For instructions on how to manually extract these files before the
installation, refer to Microsoft KB article Q129/6/05, which may be found online at
http://support.microsoft.com/support/kb/articles/q129/6/05.asp.
Review Microsoft’s website for any changes or additions to the README, SETUP, or other
associated files.
Installation Procedure
1. Connect the unit to an AC power source. This prevents it from abruptly shutting down if the battery
power gets too low, which could corrupt the Windows 98 installation.
2. Back up all data and programs before beginning the upgrade process.
3. Undock your system and remove any PC cards from the PCMCIA slots. For information on docking
your Armada Portable for the first time, see Appendix 5, “Docking for the First Time.”
4. Swap the diskette drive for the CD-ROM drive. If you are not sure how to swap the diskette drive for
the CD-ROM drive, see your unit documentation.
If you have Compaq Real Mode CD-ROM drivers installed, proceed to step 6.
5. You must have the Compaq Real Mode CD-ROM drivers installed to install Windows 98. Please
perform steps (a) to (g) to install the drivers.
a. Obtain the latest Real Mode CD-ROM drivers from the web and extract them from the SoftPaq.
b. If not already in Windows, type WIN from the DOS prompt.
c. From the File Manager or Program Manager window, click File →→ Run.
d. Type SYSEDIT and click OK.
e. The highlighted window should read C:\AUTOEXEC.BAT. Scroll to the end of this file and type
following line: MSCDEX /D:IDECD001. Make sure that the correct path name is included
f. Click the title bar labeled C:\CONFIG.SYS. If it is not visible, click Window on the menu bar and
select the CONFIG.SYS file by clicking on it. Scroll to the end of this file and add the following
line: DEVICE= CPQLTECD.SYS /D:IDECD001. Make sure that the correct path name is
included.
g. Do not close the System Configuration Editor window. Proceed to step 6.
Installing Microsoft Windows 98 on Compaq Portable Products 15
Document number PRT011B0998
6. Disable the Real Mode PCMCIA drivers. If you are not running any PCMCIA drivers, proceed to
step 7.
If your are using Real Mode PCMCIA drivers, or if unsure, continue through steps 6a to 6n. These
steps are for the Compaq specific version of SystemSoft’s CardWizard. If you are using another
company’s Card & Socket Services, please consult your documentation on how to disable them.
a. If the System Configuration Editor is already running skip to step d.
b. From either the Program Manager or File Manager window, click File →→ Run.
c. Type SYSEDIT and click OK.
d. Click the title bar labeled C:\CONFIG.SYS.
e. Find the line ‘rem SystemSoft CardSoft/16(TM) PCMCIA Drivers.’ At least four lines may need
to be commented out. If the drivers were installed to the default directory, they all contain
CARDWIZ, or CARDWORKS as part of the text.
f. Type REM and a space at the beginning of each of these lines.
g. Place a semicolon (;) before these lines if they exist:
device=c:\dos\monoumb.386
device=c:\cardwiz\pccard.386
device=c:\cardwiz\ssvrdd.386
device=ssvcd.386
device=ssvcd311.386
COM1Base=3F8
COM1Irq=4
COM4Base=2E8
COM4Irq=11
EMMEXCLUDE=C800-CBFF
EMMEXCLUDE=D000-D4FF
And add:
device=*vcd
h. Click the title bar labeled C:\WINDOWS\SYSTEM.INI. If it is not visible, click Window on the
menu bar and select the SYSTEM.INI file by clicking on it. Scroll through this file until you see
‘[386Enh]’.
i. Again, look for the lines that contain the phrase ‘C:\CARDWIZ\.’ Place a ; (semicolon) and a
space at the beginning of each line.
j. Close the System Configuration Editor by clicking on the X in the upper right corner of the
windows. You are prompted to save each file. Confirm that you want to save each file by clicking
YES.
k. Double-click the STARTUP group icon in the Program Manager. If the icon is not visible, click
the word WINDOW on the menu bar and then click on the word MAIN. If the word Main does
not appear when you click the word WINDOW, click the words MORE WINDOWS. A dialog
box with all the groups listed displays. Scroll through until you see the STARTUP group, click it,
and then click OK.
l. Click the icon labeled ‘CardWizard’ and then press Delete.
m. Click YES to confirm deleting the icon.
n. Exit Windows by clicking File →→ Exit Windows from the Program Manager window.
Installing Microsoft Windows 98 on Compaq Portable Products 16
Document number PRT011B0998
o. Restart the computer by pressing, then releasing Ctrl+Alt+Delete simultaneously.
You are now ready to install Windows 98. The Windows 98 setup files must be copied to the hard
drive first. You need them for future additions of new hardware, such as PC Cards, or for docking
the unit for the first time.
7. Type MD WIN98 and press Enter.
8. Type CD WIN98 and press Enter.
9. Place the Windows 98 disc into the CD-ROM drive.
10. Type COPY D:\WIN98\*.* and press Enter.
Note: If you wish to install the Microsoft Channel Content, substitute the following
command in step 10: XCOPY D:\WIN98\*.* /S
11. Armada 7000 and LTE 5000 Family users should now power off the system, swap the CD-ROM
drive for the diskette drive, restart the computer, and proceed to step 20. If you are not sure how to
swap the diskette drive for the CD-ROM drive, see your unit documentation.
Steps 12 to 19 are for Armada 1500 users only. All others should proceed to step 20. The
video driver needs to be reset to the default VGA and a file needs to be renamed.
12. Type CD\WINDOWS and press Enter.
13. Type SETUP and press Enter.
14. Using the arrow keys, highlight the line titled ‘VGA‘ and press Enter.
15. Again, using the arrow keys, scroll through this list until you see VGA and highlight it. Press Enter.
16. Press Enter.
17. You are prompted that the driver is already installed. Press Enter.
Armada 1540, 1560, 1570, 1571, 1572, 1573, 1590, 1592, 1598 users also need to perform
steps 18 and 19. Others should proceed to step 20.
18. Type CD SYSTEM and press Enter.
19. Type REN CHIPSCPL.CPL *.ORG and press Enter.
20. Start Windows by typing WIN and pressing Enter from the command prompt.
21. From the Program Manager or File Manager window, click File →→ Run.
22. Type C:\WIN98\SETUP and click OK.
23. The ‘Windows 98 Setup’ screen appears. Click Continue. The License Agreement appears.
24. After reading the License Agreement, click on ‘I accept the Agreement’ and click Next to continue.
25. Enter the Product Key on the Certificate of Authenticity that came with your Windows 98
documentation, then click Next to continue.
26. Select the directory where the operating system will be installed. The recommended directory is the
default directory, C:\WINDOWS. Click Next to accept the default directory.
To use a directory other than the default directory, click Other Directory, enter the alternate directory,
then click Next.
27. You are asked if you want to save the existing system files. Compaq strongly recommends doing so.
Click on the appropriate selection and click Next to continue.
Installing Microsoft Windows 98 on Compaq Portable Products 17
Document number PRT011B0998
If you have more than one partition on your hard drive, you are prompted where to save the 'uninstall'
files. Choose the appropriate drive and click OK.
28. Select the type of installation to perform. If you are unsure about which type of installation to select,
contact your IT department, otherwise, select PORTABLE and click Next to continue.
29. Click Next to select the Windows Components to be installed. If you are unsure of which to install,
a. Click on ‘Show me the list of components so I can choose’ and click Next.
b. Select the components you wish to install and click Next to continue.
If networking was not installed in your system as part of Windows 3.1x, and if you do not have an
integrated modem, proceed to step 33.
30. If networking was installed in your system as part of Windows 3.1x (other than Dial-Up Networking
without the Microsoft client) or if the unit has an integrated modem, you are asked to enter the
computer identification information.
a. Every computer on a network must have a unique name. Accept the default or change the name as
appropriate. Tab to the next field.
b. A Workgroup is a group of computers that are somehow related. Accept the default or change the
Workgroup as appropriate. Tab to the next field.
c. The Computer Description is just that. Accept the default or change the description as appropriate.
Click Next to continue.
31. Verify that the location is correct and click Next.
32. Click Next to create a Startup Disk. You may elect to skip this process. However, Compaq strongly
recommends creating a Startup Disk.
a. Insert a high-density floppy into the diskette drive and click OK.
b. When prompted, remove the diskette and click OK. The Windows 98 files are copied to their
installation directory. Click Next to continue.
33. This phase is now complete. The unit restarts. Click Restart Now or wait.
34. From the PC Card Setup Welcome screen, click Next.
35. Click Next on the second PC Card Wizard screen.
36. Click Finish on the third PC Card Wizard screen.
37. You are asked to verify your geographical location, select the appropriate time zone, and the date and
time for your area. Make your selections and click Next.
38. After Setup finishes this phase, the unit restarts. Click Restart Now or wait.
39. After rebooting, if you performed step 30, the user name you entered in that step displays. If you want
to change this, click the ‘User name’ field, delete the current name, and replace it with the user name
you want to use. If you want to enter a password, tab to the Password field and enter a case sensitive
password. Click OK to continue.
Note: If this is the first time this user name has been used on this computer, you are asked to
reenter the password. Confirm the password by retyping it and click OK. If the passwords do
not match, you are asked to type them again. Click OK to reenter the password. If you
previously had a password for the user name entered, this one must match the previous.
Installing Microsoft Windows 98 on Compaq Portable Products 18
Document number PRT011B0998
40. Windows finishes its hardware configuration and finalizes your Personalized Settings. The Welcome
to Windows 98 screen displays. If you do not want to see this screen the next time you start Windows,
uncheck the box ‘Show this screen each time Windows 98 starts’ by clicking on that text. Close this
window by clicking on the X in the upper right corner of the window. After the unit restarts, click on
the X in the upper right corner of the Welcome window to close it.
41. Reference to the Real Mode drivers, if added, must now be removed. To do this, remove the lines
added in steps 5e and 5f also using SYSEDIT.
Additionally, the DOSSTART file must be modified to remove Real Mode references.
42. Click Start →→ Run.
43. Type NOTEPAD C:\WINDOWS\DOSSTART.BAT and click OK.
44. Type REM and a space in front of the line
C:\WINDOWS\COMMAND\MSCDEX.EXE /IDECD001.
45. Click File →→ Exit on the Notepad title bar.
46. Click YES to save the file.
The Windows 98 installation is complete. Proceed to “Installing Compaq Drivers and
Enhancements” to install the other necessary files for your Compaq portable computer.
Note: You must install all drivers in order for your system to have complete functionality.
Note: Armada 1700 and 7000 family users may wish to enable Hard Drive DMA. See Appendix
7, “Enabling Hard Drive DMA” for instructions on how to enable DMA.
Installing Microsoft Windows 98 on Compaq Portable Products 19
Document number PRT011B0998
Installing Compaq Drivers and
Enhancements
Compaq Drivers and Support Software
The necessary drivers and enhancements available for the Compaq Armada Portables discussed in
this white paper are summarized in Table 2. The list is current at the date of this publication. You
should always check the Compaq website for the complete, up-to date list of available drivers and
enhancements and their associated SoftPaq numbers. Instructions for obtaining the SoftPaqs is in
Appendix 1, “Downloading Software from the Compaq Website.” After obtaining the necessary
files for your Armada portable, proceed to the installation instructions for each deliverable.
Important Notes
• Make sure that the system is undocked (Standalone) and there are no PC Cards in the PCMCIA slots
when installing drivers. 5
• Any item with an asterisk is considered optional and may not be needed by all users depending upon
their environment.
• Any first step which begins with ‘Double-click SETUP’ assumes that you have used ‘My Computer’
or Explorer to navigate to the directory where the files are located after extraction from the SoftPaq.
• These SoftPaqs are the minimum required for Windows 986. They may be superceded as noted on the
Compaq website.
Table 2. Compaq Drivers and Enhancements SoftPaqs for Windows 98
Family Driver/Enhancement SoftPaq #
Armada 1100 C&T Video Drivers SP2051
Diagnostics SP7445
Real Mode Support* SP7143
Power Management SP7726
Security 32 Support SP7251
Armada 1500 C&T 68554, 655xx Video Drivers SP7141
ESS 1878 Audio Drivers SP7448
Diagnostics SP7445
Real Mode Support* SP7143
Insight Management SP7393
Power Management SP7726
Programmable Keys SP7176
Security 32 Support SP7251
Carbon Copy 32 Host Edition* SP7441
560CL Telephony Modem Drivers SP6468
Intel Ethernet Drivers*7SP7129
5 See APPENDIX 5 DOCKING FOR THE FIRST TIME for information on docking your Armada Portable for the first time.
6 These SoftPaq numbers are for the US English versions. Versions for other language may vary.
Installing Microsoft Windows 98 on Compaq Portable Products 20
Document number PRT011B0998
Family Driver/Enhancement SoftPaq #
Armada SB C & T Video Drivers SP7141
ESS 1869 Audio Drivers SP7156
Diagnostics SP7445
Real Mode Support* SP7143
Insight Management SP7393
Power Management SP7726
Programmable Keys SP7176
Security 32 Support SP7251
Carbon Copy 32 Host Edition* SP7441
Portable Telephony Modem Drivers SP7447
Intel Ethernet Drivers*7SP7129
Armada 1700 C&T Video Drivers SP7141
ESS 1869 Audio Drivers SP7156
Diagnostics SP7142
Real Mode Support* SP7143
Insight Management* SP7393
Programmable Keys SP7176
Security 32 Support SP7251
Carbon Copy 32 Host Edition* SP7441
Compaq 56VL Global Internal Modem Drivers SP7447
Intel Ethernet Drivers*7SP7129
Armada 3500 C&T Video Drivers SP8326
ESS 1869 Audio Drivers SP8301
Diagnostics SP8288
Insight Management* SP7393
Power Management SP8071
Intel Ethernet Drivers*7SP7129
Carbon Copy 32 Host Edition* SP7441
Programmable Keys SP7176
Real Mode Support* SP8289
Security 32 Support SP8086
Armada 4100 C&T Video Drivers SP6853
Diagnostics SP7142
Real Mode Support* SP8058
Insight Management* SP7393
ESS 6/88/1688 Audio Drivers SP2027
continued
7 As no two network setups are the same, it is highly recommended that you do not set up any networking components. You should
contact your Network Administrators and have them properly set up the networking portions of Windows 98.
Installing Microsoft Windows 98 on Compaq Portable Products 21
Document number PRT011B0998
Family Driver/Enhancement SoftPaq #
Armada 4100
(continued) Programmable Keys SP7176
Security 32 Support SP8086
Ethernet Drivers*7SP2761
Armada 4200 C&T 68554, 655XX Video Drivers SP5469
Diagnostics SP7142
Real Mode Support* SP7143
Insight Management* SP7393
Programmable Keys SP7176
Security 32 Support SP7378
Ethernet Drivers*7SP5387
Armada 7300/7700 S3 Display Drivers SP6300
ESS 1878 Audio Drivers SP6299
Diagnostics SP7142
Real Mode Support* SP7143
Insight Management SP7393
Programmable Keys SP7176
Security 32 Support SP7378
Carbon Copy 32 Host Edition* SP7441
Modem Information File SP3716
Armada 7400/7800 S3 M5 Video Drivers SP7411
External Display Configuration Utility SP7578
ESS 1879 Audio Drivers SP7603
Diagnostics SP7142
Real Mode Support* SP8058
Insight Management* SP7393
Programmable Keys SP7176
Security 32 Support SP8086
Carbon Copy 32 Host Edition* SP7441
Compaq Series II Modem Drivers SP6470
LTE 5000 Video Drivers EXCEPT model 5380 SP1859
Video Drivers for model 5380 SP2051
ESS 6/88/1688 Audio Drivers SP1860
Diagnostics SP7445
Real Mode Support* SP8058
Power Management SP7726
Installing Microsoft Windows 98 on Compaq Portable Products 22
Document number PRT011B0998
SoftPaq Installation Procedures
Installing the C & T Video Drivers—Armada SB, 1700 Family, 1505, 1540,
1560, 1570, 1571, 1572, 1573, 1590, 1592, and 1598
1. Secondary-click an open area on the Desktop.
2. Click Properties.
3. Click the SETTINGS tab.
4. Click Advanced Properties.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Next on the first Wizard prompt.
8. Click ‘Display a list of all the drivers in a specific location…’ then click Next.
9. Click Have Disk.
10. Enter the path to the video driver extracted from the SoftPaq.
11. ‘Chips and Tech. 68554 PCI. (COMPAQ)’ displays. Click OK.
12. Click Next.
13. If the Version Conflict dialog appears, click NO to replace the existing files.
14. Click Close to end the installation.
15. Click Finish to return to the Adapter tab.
16. Click the MONITOR tab.
17. If your monitor type is listed as ‘Unknown,’ click Change. If the correct panel is displayed, skip to
step 19.
18. Select either ‘Laptop Display Panel (800x600) or ‘Laptop Display Panel (1024x768) as appropriate for
your computer8 then click OK.
19. Click Close.
20. Click Close again.
21. Click YES to restart the computer and begin using your new video drivers.
Installing the C & T 68554, 655xx Video Driver—Armada 4200 and 1700
1. Secondary-click an open area on the Desktop.
2. Click Properties.
3. Click the SETTINGS tab.
4. Click Advanced Properties.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Next on the first Wizard prompt.
8 If you are unsure of your panel resolution, choose 800x600.
Installing Microsoft Windows 98 on Compaq Portable Products 23
Document number PRT011B0998
8. Click ‘Display a list …’ and then click Next.
9. Click Have Disk.
10. Enter the path or drive letter to the video driver extracted from the SoftPaq and click OK.
11. ‘Chips and Tech. 65555 PCI’ displays. Click OK.
12. Click YES to confirm that you want to install the Compaq video driver.
13. Click Next.
14. Click Finish to return to the Adapter tab.
15. Click the MONITOR tab.
16. If your monitor type is listed as ‘Unknown Monitor,’ click Change. If the correct panel is displayed,
skip to step 19.
17. Select ‘Laptop Display Panel (800x600) then click OK.
18. Click Close.
19. Click Close again.
20. Click YES to restart the computer and begin using your new video drivers.
Installing the S3 Display Driver—Armada 7300 and 7700 Family
1. Secondary-click an open area on the Desktop.
2. Click Properties.
3. Click the SETTINGS tab.
4. Click Advanced.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Next on the first Wizard prompt.
8. Click ‘Display a list…’ then click Next.
9. Click Have Disk.
10. Enter the path to the video driver extracted from the SoftPaq.
11. ‘S3 Inc. 86CM65’ displays. Click OK.
12. Click YES on the warning dialog.
13. Click Next.
14. Click Finish to return to the Adapter tab.
15. Click the MONITOR tab.
16. If your monitor type is listed as ‘Unknown,’ click Change. If the correct panel is displayed, skip to
step 17.
17. Select ‘Laptop Display Panel (1024x768)’ then click OK.
18. Click Close.
19. Click Close again.
20. Click Yes to restart the computer and begin using your new video drivers.
Installing Microsoft Windows 98 on Compaq Portable Products 24
Document number PRT011B0998
Installing the S3 M5 Video Drivers—Armada 7400 and 7800 Family
1. Double-click SETUP.
2. Click OK to restart the computer.
Installing the Cirrus GD7543 Video Drivers—LTE 5000 Family EXCEPT 5380
1. Secondary-click an open area on the Desktop.
2. Select Start →→ Settings →→ Control Panel →→ Display.
3. Click the SETTINGS tab.
4. Click Change Display Type.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Have Disk, then OK.
8. Enter the path to the video driver extracted from the Softpaq, then click OK. The Select Device dialog
appears.
9. Select “Cirrus Logic 7543 2.30a (Cirrus)” then click OK.
10. Click Close.
11. Click Close again.
12. Click Yes to restart the computer and begin using your new video driver.
Installing the Cirrus GD7548 Video Drivers—LTE 5380
1. Secondary-click an open area on the Desktop.
2. Select Start →→ Settings →→ Control Panel →→ Display.
3. Click the SETTINGS tab.
4. Click Change Display Type.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Have Disk, then OK.
8. Enter the path to the video driver extracted from the Softpaq, then click OK. The Select Device dialog
appears.
9. Select “Cirrus Logic 7548 1.35 (Cirrus)” then click OK.
10. Click Close.
11. Click Close again.
12. Click Yes to restart the computer and begin using your new video driver.
Installing Microsoft Windows 98 on Compaq Portable Products 25
Document number PRT011B0998
Installing the Cirrus GD7548 Video Drivers—4100 Family
1. Secondary-click an open area on the Desktop.
2. Select Start →→ Settings →→ Control Panel →→ Display.
3. Click the SETTINGS tab.
4. Click Change Display Type.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Have Disk, then OK.
8. Enter the path to the video driver extracted from the Softpaq, then click OK. The Select Device dialog
appears.
9. Select “Cirrus Logic 7548 1.40m (Cirrus)” then click OK.
10. Click Close.
11. Click Close again.
12. Click Yes to restart the computer and begin using your new video driver.
Installing the Cirrus GD7548 Video Drivers—Armada 1100 Family
1. Secondary-click an open area on the Desktop.
2. Select Start →→ Settings →→ Control Panel →→ Display.
3. Click the SETTINGS tab.
4. Click Change Display Type.
5. Click the ADAPTER tab.
6. Click Change.
7. Click Have Disk, then OK.
8. Enter the path to the video driver extracted from the Softpaq, then click OK. The Select Device dialog
appears.
9. Select “Cirrus Logic 7548 1.35 (Cirrus)” then click OK.
10. Click Close.
11. Click Close again.
12. Click Yes to restart the computer and begin using your new video driver.
Installing the ESS 1879 Audio Drivers
1. Double-click the file SETUP.EXE.
2. Click Next from the Welcome screen.
3. Click Finish to restart the computer and finish the installation.
Installing Microsoft Windows 98 on Compaq Portable Products 26
Document number PRT011B0998
Installing the ESS 1869 Audio Drivers
1. Double-click the file SETUP.EXE.
2. Click Next from the Welcome screen.
3. Click Finish to restart the computer and finish the installation.
Installing the ESS 1878 Audio Drivers—Armada 7300 and 7700
4. Click Start →→ Settings →→ Control Panel.
5. Double-click the System icon.
6. Click the tab labeled ‘Device Manager.’
7. Click the + sign next to ‘Sound, video and game controllers.’
8. Click and highlight the second ‘ES1878 Control Interface (WDM).’
9. Click Properties.
10. Click the DRIVER tab.
11. Click Update Driver.
12. Click Next.
13. Click ‘Display a list of all the drivers in a specific location.’ Select the driver you want, then click
Next.
14. Click Have Disk.
15. Enter the path to the ESS 1878 Audio Drivers.
16. Click OK.
17. Click YES to verify the installation of the Compaq driver.
18. Click Next.
19. Click Finish.
20. Repeat steps 4-16, substituting “ES1878 Plug and Play Audio Drive (WDM)” in step 5.
Installing the ESS 1878 Audio Drivers—Armada SB and Armada 1500
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click ‘Yes, I want to restart my computer now,’ then click OK.
Installing the ESS 6/88/1688 Audio Drivers—LTE 5000 Family
4. Click Start →→ Settings →→ Control Panel.
5. Double-click the System icon.
6. Click the tab labeled ‘Device Manager.’
7. Click the + sign next to ‘Sound, video and game controllers.’
8. Double-click ‘ES688 AudioDrive.’
9. Click the DRIVER tab.
Installing Microsoft Windows 98 on Compaq Portable Products 27
Document number PRT011B0998
10. Click Change Driver.
11. Click Have Disk.
12. Enter the path to the ESS 688 Audio Drivers.
13. Click OK.
14. Click YES to verify the installation of the Compaq driver.
15. Click OK at the Properties tab.
16. Click Close at the System Properties dialog box. You must reboot the system.
Installing the ESS 688/1688 Audio Drivers Armada—4100 Family
1. Click Start →→ Settings →→ Control Panel.
2. Double-click the System icon.
3. Click the tab labeled ‘Device Manager.’
4. Click the + sign next to ‘Sound, video and game controllers.’
5. Double-click ‘ES1788 AudioDrive.’
6. Click the DRIVER tab.
7. Click Change Driver.
8. Click Have Disk.
9. Enter the path to the ESS 688 Audio Drivers.
10. Click OK.
11. Click YES to verify the installation of the Compaq driver.
12. Click OK at the Properties tab.
13. Click Close at the System Properties dialog box. You must reboot the system.
Installing the Compaq Insight Management Agents
1. Double-click SETUP.
2. Click NEXT to continue.
3. If you wish to install DMI 2.0 support, click Next otherwise click None and Next.
4. Accept the destination directory by clicking Next or choose Browse and enter a different destination
directory, click OK, YES, Next, if installing DMI support.
5. When the program finishes, highlight ‘Yes, I want to restart my computer now’ and click Finish to
restart the computer. Remove the diskette from the drive before restarting.
6. The IM Agents Help file displays the next time the unit is rebooted and you log on. Close the file by
clicking on the X in the upper right corner of the window.
Power Management
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click OK to complete the installation.
4. Click OK to restart the computer.
Installing Microsoft Windows 98 on Compaq Portable Products 28
Document number PRT011B0998
External Display Configuration Utility
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click ‘Yes, I want to restart my computer now,’ then click OK.
Installing Diagnostics
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click Finish to complete the installation.
Installing Programmable Keys
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click OK to complete the installation.
4. Click ‘Yes, I want to restart my computer now,’ then OK.
Installing Real-Mode Support
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click OK to complete the installation.
Installing Security 32 Support
1. Double-click the file SETUP.EXE.
2. Click Next to continue.
3. Click OK to complete the installation.
Installing Carbon Copy 32 Host Edition
1. Double-click the file SETUP.EXE.
2. To accept the displayed name and company information, click OK or change the information and then
click OK.
3. If you would like to view the README.TXT9 file, click YES otherwise click NO.
4. When finished reading the README.TXT file, close it by clicking on the X in the upper-right hand
corner.
5. Confirm the installation directory by click OK or type in a new directory and click OK.
6. Click OK to install the files.
7. Remove the diskette from the drive.
8. Click YES to restart the computer and finish the installation.
9 Compaq strongly recommends reading the README.TXT file.
Installing Microsoft Windows 98 on Compaq Portable Products 29
Document number PRT011B0998
Installing the Modem Information File
1. Navigate to the folder that contains the Modem Information File. Double-click on the ‘My Computer’
icon on the Windows desktop.
a. Double-click on the ‘(C:)’ icon.
b. Continue to double-click folders until you are in the folder containing the extracted Modem
Information File. You will see a file named SP7000NT.
2. Highlight the file SP7000NT and click on the ‘Copy’ icon.
3. Click on the change directory icon until you are in the root directory of C:\
4. Double-click on the Windows folder.
5. Click Show Files on the left side of this window.
6. Click View →→ Folder Options →→ View →→ Show All Files on the menu bar, then click OK.
7. Double-click on the INF folder.
8. Click on the paste icon.
9. Click Start →→ Settings →→ Control Panel.
10. Double-click Modems.
11. If prompted, enter your area code and click Close.
12. Click Remove, then click Close.
13. Restart the computer by clicking Start →→ Shut Down →→ Restart the Computer and YES.
Once the computer restarts, it will properly identify your modem.
Installing the Compaq Series II Modem Driver
1. Click Start →→ Programs →→ MS-DOS Prompt on the Start Menu.
2. Type each of the following lines, pressing Enter at the end of each. Be sure to include the complete
correct path and drive letter of the directory into which the drivers were extracted with the name of the
first file.
a. COPY SPQ7000V.INF C:\WINDOWS\INF
b. COPY GBENABLE.VXD C:\WINDOWS\SYSTEM
3. Type Exit and press Enter to return to Windows.
4. Click Start →→ Settings →→ Control Panel on the Start Menu.
5. Double-click Modems.
6. If prompted, enter your area code and click Close.
7. Click Remove, then Close.
8. Restart the computer by clicking Start →→ Shut Down →→ Restart the Computer and YES.
Once the computer restarts, it will properly identify your modem.
Installing Microsoft Windows 98 on Compaq Portable Products 30
Document number PRT011B0998
Installing the 560CL Telephony Modem—Armada SB, 1505, 1540, 1560,
1570, 1571, 1572, 1573, 1590, 1592, and 1598
1. Click Start →→ Settings →→ Control Panel.
2. Double-click the System icon.
3. Click the tab labeled ‘Device Manager.’
4. Click the + sign next to ‘Other devices.’
5. Click Unknown Device.
6. Click Properties.
7. Click Reinstall Driver.
8. Click Next from the Wizard dialog.
9. Click Next to search for a better driver.
10. Click Floppy Disk Drive so that there is a check in the box, then click Next
11. Click Next to continue.
12. Click Next for the Wave Device installation.
13. Click Next to search for a better driver.
14. Click Floppy Disk so that there is a check in the box, then click Next.
15. Click Next to continue.
16. Click Finish on the Voice Modem Serial Wave Device dialog.
17. Scroll through the countries listed in the Country Settings and choose the appropriate country.
18. Click Change Country.
19. Confirm the country by clicking YES.
20. Click Finish on the Update Device Driver Wizard dialog.
21. Click YES.
22. Click Close to return to the System Properties dialog.
23. Click OK to close the System Properties dialog.
Installing the Portable Telephony Modem INF—Models 1510, 1520, 1530,
1535, 1550, 1580
1. Click Start →→ Settings →→ Control Panel.
2. Double-click ‘Add New Hardware’ to add the Communications port.
a. Click Next on this dialog and the next three dialogs.
b. Click Finish.
3. Double-click the Modem icon.
4. Click Other so that the black circle appears in the white circle, then click Next.
5. Click ‘Don’t run the Hardware Installation Wizard’ so that there is a check in the box, then click Next.
6. Click ‘Don’t detect my modem…’ so that there is a check in the box, then click Next.
Installing Microsoft Windows 98 on Compaq Portable Products 31
Document number PRT011B0998
7. Click Have Disk.
8. Enter the path to the Portable Telephony Modem INF file and click OK.
9. Click Next to continue the installation.
10. Click ‘Communications Port (COM2) so that it is highlighted, then click Next.
11. The Location Information dialog must have the area or city code filled in as a minimum. Change and
enter all appropriate information, then click Next.
12. Click Finish.
13. Click OK to close the Modems Properties window.
Installing the Compaq 56VL Telephony Modem Driver
1. Click Start →→ Settings →→ Control Panel.
2. Double-click the System icon.
3. Click the tab labeled ‘Device Manager.’
4. Click the + sign next to ‘Other devices.’
5. Click ‘Unknown Device.’
6. Click Properties.
7. Click Reinstall Driver.
8. Click Next.
9. Click the box ‘Display a list of all the drives in a specific location and select the driver you want.
10. Click Next.
11. Select Modem and Click Next.
12. Click Have disk.
13. Enter the path to the files.
14. Click Finish to complete the installation.
Installing Microsoft Windows 98 on Compaq Portable Products 32
Document number PRT011B0998
Appendix 1: Downloading Software from
the Compaq Website
1. The base URL for all Compaq Portables software is
www.compaq.com/support/files/portables/us/index.html. Enter this location in the browser of your
choice.
2. You are presented three drop-down dialog boxes for Family, Model, and Operating System. Fill in
each box as appropriate and click the Locate button.
a. Family—which series of Armada are you trying to find software for; e.g. Armada 7700, Armada
4200, etc.
b. Model—the specific portable; e.g. 42XX where XX represents the last two digits—as in 4210 or
4220. For the 7800 Armada series, it is in the form of XXXX/Z/XXXX/Z/Z/Z—e.g.
6266/T/5000/D/M/1. See the bottom of your portable to obtain the proper model number.
c. Operating system, in this case “Windows 98”
3. A list of all files currently available displays. Click on each sub-bulleted item.
a. You are shown information on this particular deliverable.
b. Click the DOWNLOAD button.10
c. Place all of the files into a common directory so that they may be extracted for use in the scripts. A
common directory used is C:\~COMPAQ.
See the instructions on how to use the SoftPaq utility in Appendix 2.
10 Consult your browser’s help for instructions on how to download files if necessary.
Installing Microsoft Windows 98 on Compaq Portable Products 33
Document number PRT011B0998
Appendix 2: Using the SoftPaq Utility
Currently, there are two versions of the SoftPaq utility on the Compaq website11. As drivers are
updated and released as SoftPaqs, they are released using the most current version of the utility.
You can tell which version is in use by looking at the application title-bar at the top of the screen.
The procedure for using either version is outlined below.
SoftPaq 2.x
1. When you run the application, you are presented with information as to which software driver or
program you are going to extract to floppy. Press PgDn to view the Licensing Agreement.
2. Type AGREE. The number of required diskettes is displayed.
3. Type the destination drive letter for the software extraction.
4. Insert a 3.5” 1.44 MB diskette into the drive and press Enter.
5. When the software has been extracted, the program exits automatically.
The software is now ready for installation from the diskette prepared according to the steps
outlined in the section titled “Installing Compaq Drivers and Enhancements.” Compaq
recommends viewing the README file for any updates.
SoftPaq 3.x
1. Place the SoftPaq file in a temporary directory where the files will be extracted.
2. When you run the application, you are presented with information as to which software driver or
program you are going to extract to floppy. Press C to continue.
3. Press A to agree to the Licensing Agreement.
4. You are asked if the destination directory for extraction is OK. Type Y to continue.
5. When the software has been extracted, the program exits automatically.
The software is now ready to be used in the steps outlined in the section titled “Installing Compaq
Drivers and Enhancements.” It will be installed from the directory to which it was extracted.
Compaq recommends viewing the README files for any updates.
11 SoftPaqs are a way for Compaq to distribute driver and ROM updates as well as product enhancements.
Installing Microsoft Windows 98 on Compaq Portable Products 34
Document number PRT011B0998
Appendix 3: Installing Diagnostics
and Setup
You need both the Diagnostics and Setup diskettes before beginning. If you do not have them,
you can download them from the Compaq website. Ensure that there are no existing partitions on
the hard drive with the FDISK utility. If you are unsure how to use the FDISK program, refer to
Microsoft’s web page on the subject. This information is available at
http://support.microsoft.com/support/kb/articles/q106/4/23.asp.
1. Start the computer from the Diagnostics diskette.
2. Press Enter on the ‘Create Diagnostics Partition’ dialog.
3. Press Enter to restart the computer.
4. Press Enter to confirm that you have both the Diagnostics and Setup diskettes.
5. Insert the Setup diskette when prompted and press Enter.
6. Insert the Diagnostics diskette when prompted and press Enter.
7. Insert the Setup diskette when prompted and press Enter.
8. Press Enter to complete the installation.
9. Power off your system and restart the operating system installation.
Installing Microsoft Windows 98 on Compaq Portable Products 35
Document number PRT011B0998
Appendix 4: Determining Your ROM
Version and Upgrade Version
To determine your ROM revision, use either the Compaq Inspect utility or Compaq Diagnostics
for Windows.
Determining Your ROM Version Using Inspect
If you have Compaq’s Diagnostics and Setup properly installed on the hard drive, a block cursor
is displayed in the upper right corner of the screen during startup. When you see the block cursor,
press F10. See Appendix 3 for instructions on installing Diagnostics and Setup from a diskette.
1. The Welcome to Compaq Utilities dialog appears. Press Enter.
2. Scroll down using the down arrow key until ‘View system information (INSPECT)” is highlighted,
then press Enter.
3. Wait while information about your system is gathered.
4. Scroll down using the down arrow key until ‘ROM’ is highlighted, then press Enter.
5. Your system ROM revision information is displayed. Make note of the date and compare it to the date
at the beginning of this white paper in the section titled ‘Installation Requirements and Dependencies.”
6. Press F3 to exit the ROM information screen.
7. Scroll down using the down arrow key until ‘Exit…’ is highlighted and press Enter. Repeat this step
to exit from the Compaq Utilities.
8. Press Enter to confirm exiting the Compaq Utilities.
9. If your ROM requires upgrading and you do not have a ROMPaq diskette for your computer, see
‘”Creating a ROMPaq Diskette” in this appendix; otherwise proceed to “Upgrading Your ROM.”
Determining Your ROM Revision using Compaq Diagnostics for Windows
1. Click Start →→ Settings →→ Control Panel on the Taskbar.
2. Double-click the Compaq Diagnostics icon.
3. Once Diagnostics is loaded, press F8.
4. Click the left-most Icon on the icon bar near the top of the window.
5. Scroll through this list until you see the System ROM information. Make note of the date and compare
it to the date at the beginning of this White Paper in the section titled ‘Installation Requirements and
Dependencies.’
6. Close Diagnostics for Windows by clicking on the X in the upper right corner of this window.
7. If your ROM requires upgrading and you do not have a ROMPaq diskette for your computer, go to the
section titled “Creating a ROMPaq Diskette; otherwise proceed to “Upgrading Your ROM.”
Creating a ROMPaq Diskette
The ROMPaq SoftPaq is a version 7.x SoftPaq. After downloading the appropriate SoftPaq from
the Compaq website, follow the instructions in Appendix 2 to extract the image onto a diskette.
Installing Microsoft Windows 98 on Compaq Portable Products 36
Document number PRT011B0998
Upgrading Your ROM
1. Connect your computer to AC power.
2. Place your ROMPaq diskette into your diskette drive and restart the computer.
3. Press Enter on the ‘Welcome to ROMPaq’ screen.
4. Press Enter to select your ‘COMPAQ System ROM.’
5. Press Enter to select the most current firmware image.
6. Press Enter to continue.
7. To start the ROMPaq upgrade, press Enter.
8. When your receive the message that your system ROM has been successfully reprogrammed, power
off your system.
Installing Microsoft Windows 98 on Compaq Portable Products 37
Document number PRT011B0998
Appendix 5: Docking for the First Time
Before docking, you need to ensure that all of the specific drivers and support software for your
specific Armada are installed. See “Installing Compaq Drivers and Enhancements” for the list of
deliverables and instructions on how to install them.
Compaq strongly recommends a ‘cold dock’ for the user’s first docking under Windows 98. Shut
down Windows 98 by clicking Start →→ Shut Down and clicking on YES. Place the computer in
the docking station or convenience base and restart the unit.
Depending on your type of installation, you may or may not be prompted during the “New
Hardware Found” phase of your initial docking. Regardless of your installation type, simply press
Enter when prompted with questions. Continue doing this until the computer reboots and
Windows 98 loads as usual.
If you did not upgrade over Windows 95 together with the Compaq System Enhancements Disk,
you will have one or more unknown devices shown in the device manager. These are cosmetic in
nature only and do not degrade performance in any way.
After docking for the first time, you must reinstall your video drivers. See “Installing Compaq
Drivers and Enhancements” and refer to the section for your family.
Installing Microsoft Windows 98 on Compaq Portable Products 38
Document number PRT011B0998
Appendix 6: ACPI
ACPI (Advanced Configuration and Power Interface) represents a significant innovation in power
and configuration management that allows operating systems and applications to manage power
based on activity and use. Compaq worked closely with Microsoft and Intel on the
implementation of ACPI, and provided Microsoft with one of the first notebook test platforms
with ACPI hardware, the Armada 4200.
The Armada 1700, Armada 3500, Armada 4200, Armada 7400, and the Armada 7800 are all
ACPI-hardware ready. All new Armada platforms will also be ACPI-hardware ready.
Compaq remains committed to ACPI and firmly believes ACPI will become the preferred model
for power and configuration management in the long term. As with introduction of any new
technological innovation, it takes time for it to be adopted by industry. To gain the full benefit of
ACPI, the operating system, applications and hardware must all be ACPI aware. Windows 98 is
the first ACPI-aware operating system. At this time, no ACPI-aware applications have been
developed. It is important to note that once ACPI is enabled it is not possible to switch back to
APM without reinstalling the operating system.
For these reasons, Compaq anticipates that, in the near term, many customers will not want to
switch from the current power management standard, APM (Advanced Power Management).
Compaq continues to work closely with Microsoft to test ACPI extensively to ensure Compaq
customers get comparable battery life with ACPI as they did with APM. We will release ACPI
support for each Compaq platform only after completion of the testing phase, and feel
comfortable with the battery performance under ACPI.
Compaq's ACPI strategy for Armada notebooks is designed to allow customers to continue using
APM until our ACPI testing is complete, then encourage them to choose the power management
model best suited to their particular requirements. To accomplish this, all ACPI-aware notebooks
will be set up to use APM as the default power management model. Then, anytime after the initial
setup, customers will be able to convert their factory-installed version of Windows 98 to ACPI by
means of an easy-to-use tool to be provided by Compaq. This tool will be available as a SoftPaq
on Compaq's website and Support Software CD.
Installing Microsoft Windows 98 on Compaq Portable Products 39
Document number PRT011B0998
Appendix 7: Enabling Hard Drive DMA
Direct Memory Access (DMA) is the process by which information is transferred between two
devices on a bus under the supervision of a direct memory access controller.
By default, Hard Drive DMA is not enabled at installation of Windows 98. Users of the Armada
1700, 3500 and 7000 family series may see some performance improvements if they manually
enable DMA by following the steps outlined below.
1. Click Start →→ Settings →→ Control Panel.
2. Double-click the System icon.
3. Click the tab labeled ‘Device Manager.’
4. Click the ‘+’ next to ‘Disk drives.’
5. Click ‘GENERIC IDE DISK TYPE65.’
6. Click the button labeled ‘Properties.’
7. Click the ‘Settings’ tab.
8. Click the box next to ‘DMA’ so that there is a √ (check) mark in the box.
9. If prompted, click OK to confirm enabling DMA.
10. Click OK to return to the Device Manager.
11. Click Close. You are prompted to restart your computer. Click YES to restart.
Installing Microsoft Windows 98 on Compaq Portable Products 40
Document number PRT011B0998
Appendix 8: Infrared Functionality
The installation of Windows 98 makes infrared communications non-functional and affects all
infrared systems that support Windows 98. The problem is due to a driver conflict caused by the
Win98 installation, which allows the existing IR device to remain in place while a Win98-specific
driver is installed at the same resources.
To resolve this conflict, remove the Win95 IR device by performing the following procedure:
1. Click Control Panel →→ System Properties →→ Device Manager.
2. Click the + (plus) symbol next to the ‘Infrared Devices” category.
3. Note that there are two infrared devices listed:
Windows 95 Built-in Infrared Communication Device
Windows 98 Infrared Communication Device
4. Remove both devices and Close Device Manager.
5. Restart the system and allow the OS to auto-detect IR.
Note: If the OS does not automatically detect the “Infrared Communications Device,” you
have to manually install the device using the “Add New Hardware” feature in the Control
Panel. Make sure you specify COM4 and LPT3 as the default ports.
6. Open the ‘Infrared Monitor’ applet in the Control Panel.
7. Click the ‘Options’ tab.
8. Select ‘Enable infrared communication.’
9. You are now able to use “IR Recipient.”
To set up Direct Cable Connection (DCC), perform the following steps:
1. Open the ‘Network’ applet in the Control Panel.
2. Add ‘Client for Microsoft Networks.’
3. Add the ‘NetBEUI’ protocol.
4. Enable ‘File Sharing.’
5. Make sure the ‘Identification’ tabs on both machines use unique computer names, for example,
HOST/GUEST, and are in the same “Workgroup.”
6. Restart the computer.
7. Share folders on Host computer.
8. Run DCC on both machines.
9. Set up one computer as HOST, the other as GUEST.
10. Select ‘Serial Cable on COM4’ on both systems.
11. Click Finish.
12. The GUEST computer searches for shared folders on the HOSTcomputer and establishes an open link.
