HP Web Jetadmin 10.4
Installation and Setup Guide
Copyright and License
© Copyright 2017 HP Development Company,
L.P.
Reproduction, adaptation, or translation without
prior written permission is prohibited, except as
allowed under the copyright laws.
The information contained herein is subject to
change without notice.
The only warranties for HP products and
services are set forth in the express warranty
statements accompanying such products and
services. Nothing herein should be construed as
constituting an additional warranty. HP shall not
be liable for technical or editorial errors or
omissions contained herein.
Publication Date: 11/2017
Trademark Credits
Microsoft and Windows are either registered
trademarks or trademarks of Microsoft
Corporation in the United States and/or other
countries.
VMware® is a registered trademark of VMware,
Inc.
Table of contents
Install and Set Up HP Web Jetadmin .......................................................................................................................................................... 1
System Requirements ............................................................................................................................................................. 1
HP Web Jetadmin Server Application ............................................................................................................... 1
HP Web Jetadmin Client Application ................................................................................................................. 2
Virtual Machine (Optional Platform) ................................................................................................................. 3
Server Hardware .................................................................................................................................................. 3
Client Hardware .................................................................................................................................................... 4
Database ............................................................................................................................................................... 4
Network ................................................................................................................................................................. 4
Installations and Upgrades ................................................................................................................................. 5
Client Application ................................................................................................................................................. 5
Supported Devices ............................................................................................................................................... 5
Host Access ........................................................................................................................................................... 5
Client/Server Security .......................................................................................................................................... 6
Install HP Web Jetadmin .......................................................................................................................................................... 6
Install HP Web Jetadmin from the Command Line ............................................................................................................. 6
Install HP Web Jetadmin in Blocking Mode ........................................................................................................................... 9
Post-installation Tasks ............................................................................................................................................................ 9
Recommended Initial Conguration Steps .................................................................................................... 10
Congure the HP Web Jetadmin Service to Restart Automatically ........................................................... 10
Ports ......................................................................................................................................................................................... 11
Implement SSL ....................................................................................................................................................................... 13
Enable Secure Sockets Layer (SSL) ................................................................................................................ 13
Important Points to Remember When Implementing SSL ......................................................................... 14
Congure HTTPS (Server Certicates or SSL) ............................................................................................... 14
Use a Separate Instance of Microsoft SQL Server ............................................................................................................. 15
Deploy the Smart Client ........................................................................................................................................................ 15
Change the Default HTTP or HTTPS Port for the HP Web Jetadmin Smart Client Application ............. 16
Run the Smart Client Application in a Workgroup ........................................................................................ 16
Start an HP Web Jetadmin Client Session ..................................................................................................... 17
Congure HP Web Jetadmin to Bind to a Specic NIC .................................................................................. 17
HP Web Jetadmin Client Connection .......................................................................................... 18
HP Web Jetadmin Alerts and SNMP Traps Registration ......................................................... 19
HP Web Jetadmin Web Service ................................................................................................... 20
Congure the Port for Event Notications .................................................................................................... 20
Congure the Firewall Software ...................................................................................................................... 21
ENWW iii
Restart the HP Web Jetadmin Service Manually ............................................................................................................... 21
Back Up and Restore HP Web Jetadmin ............................................................................................................................. 22
Upgrade HP Web Jetadmin ................................................................................................................................................... 22
Import Feature Packs ............................................................................................................................................................ 22
Enable FIPS on the HP Web Jetadmin Server .................................................................................................................... 24
Uninstall HP Web Jetadmin .................................................................................................................................................. 29
Manage Licenses .................................................................................................................................................................... 30
Appendix A End-User License Agreement ............................................................................................................................................. 31
Index ............................................................................................................................................................................................................. 32
iv ENWW
Install and Set Up HP Web Jetadmin
When you install HP Web Jetadmin, you only need to install it on one hardware platform that meets the
recommended minimum requirements (System Requirements on page 1) and is centrally accessible on the
network. You may then access the software from any supported Windows desktop on the network and manage
all supported network-connected peripherals.
HP Web Jetadmin oers several installation options. If you have installed a previous version of HP Web Jetadmin,
you can choose to upgrade the previous version or install a new copy. Upgrading an older version preserves your
settings for discovery options and groups and is most likely the best choice if you have already been using
HP Web Jetadmin.
Every release of HP Web Jetadmin contains new features and improvements to existing features. In an
environment where a previous release of HP Web Jetadmin is integrated into critical business operations,
HP recommends that you fully test and qualify a new release before implementing that release into full
production.
Read all of the support materials before you implement HP Web Jetadmin. For current information about
HP Web Jetadmin, see the Late Breaking News for HP Web Jetadmin 10.4 and the HP Web Jetadmin 10.4
Supported Devices Readme. These documents are available from the HP Web Jetadmin support page (click the
ag icon on the bottom of the page, and then select your country/region).
System Requirements
HP Web Jetadmin includes network device communication protocols and internal components that manage
application and device data. These components extend the capabilities of HP Web Jetadmin and improve usage
and performance in device lists, columns, and ltering functions.
HP Web Jetadmin is supported on platforms that have Microsoft Windows and .NET Framework high-priority
updates. During each development cycle, HP regularly tests HP Web Jetadmin on platforms that have the
current Microsoft updates. HP investigates all post-release software issues that customers report. For more
information about the current software issues, see the Late Breaking News for HP Web Jetadmin 10.4. This
document is available from the HP Web Jetadmin support page (in English).
HP Web Jetadmin requires the Windows HTTP SSL service. HP Web Jetadmin uses SSL to communicate with
newer HP devices through port 8050.
HP Web Jetadmin Server Application
Supported operating systems
●Microsoft Windows Server 2016
●Microsoft Windows Server 2012 R2
●Microsoft Windows Server 2012
●Microsoft Windows Server 2008 R2 SP1
●Microsoft Windows 10 (64-bit edition only)
ENWW System Requirements 1
●Microsoft Window 8.1 (64-bit edition only)
●Microsoft Window 8 (64-bit edition only)
●Microsoft Windows 7 SP1 (64-bit edition only)
For more information about a specic Microsoft operating system, go to www.microsoft.com.
Notes
●HP no longer supports or tests HP Web Jetadmin installations on Microsoft operating systems that were
released prior to the operating systems that are supported for the current release.
●Beginning with HP Web Jetadmin 10.3 SR6, Microsoft .NET Framework 4.5 or later is required in addition
to .NET Framework 3.5 SP1 because HP Web Jetadmin supports Transport Layer Security (TLS) 1.1 and 1.2.
Some of the operating systems that are supported for the current release already ship with .NET
Framework 4.5 or later.
If the HP Web Jetadmin installer does not detect .NET Framework 3.5 SP1 and .NET Framework 4.5 or later,
the installer provides the appropriate installation instructions and Microsoft URL to download .NET
Framework.
●The operating systems that are supported for the current release include Windows Installer 4.5. If Windows
Installer 4.5 is not already installed, the HP Web Jetadmin installer provides the appropriate Microsoft URL
to download Windows Installer 4.5.
●Local administrator access is required to install or upgrade HP Web Jetadmin.
●Production HP Web Jetadmin installations are restricted to dedicated hosts. Running HP Web Jetadmin on
systems that are also mail servers, DNS servers, domain controllers, and so on is not supported.
HP Web Jetadmin Client Application
Supported operating systems
●Microsoft Windows Server 2016
●Microsoft Windows Server 2012 R2
●Microsoft Windows Server 2012
●Microsoft Windows Server 2008 R2 SP1
●Microsoft Windows 10
●Microsoft Windows 8.1
●Microsoft Windows 8
●Microsoft Windows 7 SP1
For more information about a specic Microsoft operating system, go to www.microsoft.com.
Notes
●Beginning with HP Web Jetadmin 10.3 SR6, Microsoft .NET Framework 4.5 or later is required in addition
to .NET Framework 3.5 SP1 because HP Web Jetadmin supports Transport Layer Security (TLS) 1.1 and 1.2.
Some of the operating systems that are supported for the current release already ship with .NET
Framework 4.5 or later.
2 Install and Set Up HP Web Jetadmin ENWW
If the HP Web Jetadmin installer does not detect .NET Framework 3.5 SP1 and .NET Framework 4.5 or later,
the installer provides the appropriate installation instructions and Microsoft URL to download .NET
Framework.
Virtual Machine (Optional Platform)
Recommended requirements
HP recommends the following virtualization solutions:
●VMware ESX
●Microsoft Hyper-V
Notes
●For a VMware server, the virtual machine network must be set to bridged to facilitate HP Web Jetadmin
communications.
●It is very important to congure VMware so that its guest or virtual systems have enough resources to
support HP Web Jetadmin and Microsoft SQL Server. To ensure that the appropriate resources are
provisioned, see the support documentation for the version of VMware you are using.
Server Hardware
Recommended requirements
HP recommends the following hardware conguration for the server:
●4 or more processor cores
●2.8 GHz or higher processor speed
●4 GB or more of RAM
●4 GB of available storage
Minimum requirements
Although you can use the following hardware conguration for the server, HP does not recommend that you use
it for production installations. HP does not test HP Web Jetadmin on this hardware conguration and, therefore,
cannot guarantee the results.
●2 processor cores
●2.33 GHz processor speed
●5 GB of RAM (2 GB is required for the HP Web Jetadmin Service, and 2 GB is the default SQL memory
reservation)
HP Web Jetadmin uses a value of 3,072 MB to qualify a system as having 3 GB of RAM.
●4 GB of available storage
ENWW System Requirements 3
Notes
●Recent software improvements have increased resource capacity requirements. HP strongly recommends
the 64-bit editions of Windows and 4 GB or more of RAM for production HP Web Jetadmin installations.
●Storage requirements vary depending on the implementation, database, and migration from previous
versions.
●NTFS is the only supported le system.
●If the HP Web Jetadmin installer determines that less than 1 GB of RAM is installed, the installer displays a
message stating that 3 GB of RAM is required.
Client Hardware
Recommended requirements
HP recommends the following hardware conguration for the client:
●PC with 2.4 GHz processor
●64-bit system with 4 GB of RAM
●Client display with a minimum resolution of 1024 x 768
●Optimized for Normal font size
●Default DPI only
Minimum requirements
Although you can use the following hardware conguration for the client, HP does not recommend that you use
it for production installations. HP does not test HP Web Jetadmin on this hardware conguration and, therefore,
cannot guarantee the results.
●PC with 1.8 GHz processor
●32-bit or 64-bit system with 2 GB of RAM
●Client display with a minimum resolution of 1024 x 768
●Optimized for Normal font size
●Default DPI only
Database
For new installations of HP Web Jetadmin 10.3 SR8 or later, the installation package contains and automatically
installs the database for Microsoft SQL Server 2012 Express SP2 (product version 11.0.5058.0). Existing
installations of HP Web Jetadmin prior to 10.3 SR8 and installations that have been upgraded to 10.3 SR8 or
later use the database for Microsoft SQL Server 2008 Express (product version 10.00.2531.00).
NOTE: HP has successfully tested HP Web Jetadmin with Microsoft SQL Server 2014.
TIP: For more information about conguring HP Web Jetadmin to use a separate Microsoft SQL instance, see
the Using Microsoft SQL Server with HP Web Jetadmin white paper. This white paper is available from the
HP Web Jetadmin support page (in English).
4 Install and Set Up HP Web Jetadmin ENWW
Network
The HP Web Jetadmin installer requires one active IPv4 connection. If an active IPv4 connection is not available,
the installer fails.
For rmware upgrades with HP Web Jetadmin, a minimum bandwidth of 1 MB/s is required. If there are multiple
devices upgrading at the same time, then the minimum bandwidth of 1 MB/s will be equal to the number of
concurrent rmware upgrades. For example, four simultaneous upgrades requires at least 4 MB/s.
Installations and Upgrades
Local administrator access is required to install or upgrade HP Web Jetadmin.
Client Application
The HP Web Jetadmin client application requires the following:
●Internet Explorer 8, 9, 10, or 11
●Display with a minimum resolution of 1024 x 768
Notes
●Internet Explorer is required to start the HP Web Jetadmin client application. For more information about
Internet Explorer requirements and limitations, see the support documentation for the Windows operating
system that you are using.
●Administrator access is not required to run the HP Web Jetadmin client application.
●A maximum of 15 concurrent client sessions are allowed.
Supported Devices
HP Web Jetadmin supports HP devices and third-party devices that are connected through HP Jetdirect print
servers. HP Web Jetadmin also supports third-party devices that are standard printer MIB compliant and are
connected to the network. For third-party devices, HP Web Jetadmin provides basic capabilities as well as more
robust capabilities if the devices are used with HP-certied plug-ins for HP Web Jetadmin.
IMPORTANT: If the following devices use a Universal Plug-in (UPI), WS-Discovery must be enabled on the
devices:
●HP LaserJet Pro
●HP Ocejet Pro
●HP FutureSmart with a rmware version earlier than 3.2.3
If WS-Discovery is disabled on HP LaserJet Pro and HP Ocejet Pro devices, HP Web Jetadmin uses the correct
UPI and displays a status of Device Communication Error for the devices after a device discovery or full refresh is
performed.
If WS-Discovery is disabled on HP FutureSmart devices with a rmware version earlier than 3.2.3,
HP Web Jetadmin uses a generic device model instead of the correct UPI after a device discovery or full refresh is
performed.
ENWW System Requirements 5
Host Access
For the application host, local administrator access is required to install or upgrade HP Web Jetadmin.
For the client host, local user access is required to access the HP Web Jetadmin client application and
administrator access is required to install Microsoft .NET Framework.
Client/Server Security
Microsoft domain or locally managed Windows users and passwords are required.
Notes
●HP tests HP Web Jetadmin in Microsoft Active Directory domains.
●Users must be a member of an HP Web Jetadmin server administrator group or designated as one of the
following in the HP Web Jetadmin User settings:
–Windows local security group
–Active Directory security group
–Local individual user account
–Active Directory domain user account
Install HP Web Jetadmin
To install HP Web Jetadmin, perform the following steps:
1. Go to www.hp.com/go/webjetadmin, and then download the HP Web Jetadmin software.
2. Double-click the EXE le.
3. Follow the instructions in the wizard.
4. If the installation stops with a warning that a reboot is required, reboot the host on which the
HP Web Jetadmin installer is running. Then relaunch the installer to continue the installation.
5. When the installation is complete, click the Finish button.
IMPORTANT: If the HP Web Jetadmin installer does not install Microsoft SQL Server Express Edition, the most
common reason for the failure is that Windows updates, such as service packs or hotxes, were installed on the
machine and the machine was not restarted after the updates completed. Restart the machine, and then install
HP Web Jetadmin again.
Install HP Web Jetadmin from the Command Line
You can install HP Web Jetadmin from a command line, through a script, or through an automated process. The
following is the command syntax:
<filename>.exe [/L"<LanguageID>"] [/S /v/qn] </V"[Property1=Value1]
[Property2=Value2] [...]">
6 Install and Set Up HP Web Jetadmin ENWW
Command-line parameters
●<filename>.exe
Species the name of the EXE le that you downloaded from www.hp.com/go/webjetadmin.
●/L"<LanguageID>"
Species the ID of the language the installer uses (Optional). If the language dialog is enabled and you
specify a valid language ID, the installer automatically suppresses the language dialog. If you specify an
invalid language ID or a language ID that the installer does not support, the installer ignores this parameter.
The following are the language IDs. The default is the local system language.
Language Language ID
Chinese (Simplied) 2052
Chinese (Traditional) 1028
English (Worldwide) 1033
French (European) 1036
German 1031
Italian 1040
Japanese 1041
Korean 1042
Portuguese (Brazilian) 1046
Russian 1049
Spanish (Mid-Atlantic) 1034
●/S /v/qn
Performs a silent installation (Optional).
To perform a silent installation, the following properties are required:
–WJA_EULA
–ENABLE_ANONYMIZED_DATA_COLLECTION
●/V"[Property1=Value1] [Property2=Value2] [...]"
Species a list of properties the installer uses (Required). The following are the properties and values.
Property and Value Description
WJA_EULA=ACCEPT | REJECT Species whether you accept or reject the HP Web Jetadmin End User License
Agreement (EULA).
This property is required for silent installations.
ENABLE_ANONYMIZED_DATA_COLLEC
TION=TRUE | FALSE
Species whether the Data Collection feature is enabled or disabled. This feature
collects data about your printers and implementation of HP Web Jetadmin and
anonymizes the data. HP Web Jetadmin uses an Internet connection to transmit the
anonymized data to HP. HP uses the anonymized data to improve products and
services.
This property is required for silent installations.
ENWW Install HP Web Jetadmin from the Command Line 7
Property and Value Description
IMPORTANT: HP is committed to protecting your privacy and the integrity of your
computer. You can enable and disable this feature at any time. Your name, address,
email address, and other sensitive data are not sent to HP.
WJA_BACKUP_CONFIRM=YES | NO Species whether a backup of HP Web Jetadmin was performed prior to the
installation.
This property is required for upgrade installations.
WJA_SUPPLY_GROUP_REMOVAL_CONF
IRM=YES | NO
Species whether the existing Supplies Groups are removed. In HP Web Jetadmin
10.2, the Supplies Groups functionality was removed as a product feature. Regular
device groups will not be removed or altered during the installation.
This property is required when upgrading from all versions of HP Web Jetadmin 10.1
and earlier.
YES—Conrms that you understand and agree that all Supplies Groups functionality
as well as existing groups will be removed during the installation.
NO—Causes the installation to terminate and end without the software being
installed.
WJA_COLUMN_CONFIRM=YES | NO Species whether the column data is upgraded, which might aect lters, groups
with lters, and device list exporting.
This property is required for silent upgrade installations prior to HP Web Jetadmin
10.2 SR 5.
WJA_SKIP_DB_INSTALL=1 | 0 Species whether the database installation is skipped. To skip the database
installation, specify 1.
This property is required only if you want the installer to skip the database
installation.
INSTALLDIR=\"<Path>\" Species the HP Web Jetadmin installation path. The following is the default path:
C:\Program Files\HP Inc\Web Jetadmin 10\
This property is optional for silent installations.
The path must be enclosed with \". In addition, the properties specied for the /V
option must be enclosed with quotes. The following is an example of the correct
syntax:
/V"WJA_EULA=ACCEPT INSTALLDIR=\"C:\Program Files\HP Inc
\Web Jetadmin 10\""
CAUTION: If the path contains spaces and is not enclosed with \", the installer
fails.
DATABASEDIR=\"<Path>\" Species the database installation path. The following is the default path:
C:\Program Files\Microsoft SQL Server\
This property is optional for silent installations.
If the directory name contains spaces, you must use the Windows short-path
notation. To nd the short-path notation, issue the following command:
Dir *. /x
The path must be enclosed with \". In addition, the properties specied for the /V
option must be enclosed with quotes.
The following are examples of the correct syntax:
–/V"WJA_EULA=ACCEPT DATABASEDIR=\"C:\SQLServer\""
8 Install and Set Up HP Web Jetadmin ENWW
Property and Value Description
–/V"WJA_EULA=ACCEPT DATABASEDIR=\"C:
\Program~1\SQLServer\""
CAUTION: If the path contains spaces and is not enclosed with \", the installer
fails.
Examples of the command-line syntax
The following examples assume that the name of the installation le is WjaSetup-x64.exe.
●To perform a basic silent installation, enter the following command:
WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT
ENABLE_ANONYMIZED_DATA_COLLECTION=TRUE"
●To start the installer in Spanish, enter the following command:
WjaSetup-x64.exe /L"1034"
●To perform a silent installation with HP Web Jetadmin installed on C:\WJA, enter the following command:
WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT
ENABLE_ANONYMIZED_DATA_COLLECTION=TRUE INSTALLDIR=\"C:\WJA\""
●To perform a silent installation with HP Web Jetadmin installed on C:\WJA and the database installed on C:
\WJADB, enter the following command:
WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT
ENABLE_ANONYMIZED_DATA_COLLECTION=TRUE INSTALLDIR=\"C:\WJA\"
DATABASEDIR=\"C:\WJADB\""
●To perform a silent upgrade, enter the following command:
WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT
ENABLE_ANONYMIZED_DATA_COLLECTION=TRUE INSTALLDIR=\"C:\WJA\"
DATABASEDIR=\"C:\WJADB\" WJA_BACKUP_CONFIRM=YES
WJA_SUPPLY_GROUP_REMOVAL_CONFIRM=YES WJA_COLUMN_CONFIRM=YES"
Install HP Web Jetadmin in Blocking Mode
You can run a silent installation in blocking mode from the command line. The following is the command syntax:
start /wait <ProgramAndArguments>
The following examples assume that the name of the installation le is WjaSetup-x64.exe.
●start /wait WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT INSTALLDIR=
\"C:\wja\" DATABASEDIR=\"C:\wjadb\""
●start /wait "C:\temp\WjaSetup-x64.exe /S /v/qn /V"WJA_EULA=ACCEPT
ENABLE_ANONYMIZED_DATA_COLLECTION=TRUE INSTALLDIR=\"C:\wja\"
DATABASEDIR=\"C:\wjadb\"""
ENWW Install HP Web Jetadmin in Blocking Mode 9
Post-installation Tasks
The HP Web Jetadmin server will start automatically as a Microsoft Service. The HP Web Jetadmin server cannot
accept HP Web Jetadmin client connections until the HP Web Jetadmin server has fully loaded all services into
memory. Dependent upon your HP Web Jetadmin server available system resources, it may take 1-2 minutes for
all services to completely load after initial server installation or server reboot.
The rst time you launch HP Web Jetadmin after installation, a pop-up dialog is displayed stating that no devices
have been discovered. You can opt to launch discovery settings at this point.
Once the installation is complete, HP Web Jetadmin can be launched from a supported browser by entering the
hostname or IP address of the computer on which it is installed, followed by the port number and path. Typical
default port numbers for Web services have a value of 80. Since HP Web Jetadmin may be running
simultaneously with another Web service on the same computer, HP Web Jetadmin uses a port number of 8000.
If desired, the port value may be altered.
Here is an example of the URL used to activate HP Web Jetadmin on a supported Windows desktop:
http://myhost:8000
Recommended Initial Conguration Steps
After HP Web Jetadmin is installed, some of the initial steps that you should take to begin managing devices and
the print environment include conguring the options that are shared throughout HP Web Jetadmin, running a
discovery, and conguring various other features.
Shared conguration options include the database, network (for example, SNMP and HTTPS), discovery, server
maintenance, and credentials. To congure these options, go to Tools > Options > Shared, and then navigate to
the appropriate category. For more information about a specic option, see the online Help for that option.
Finding devices on the network might be as simple as enabling HP Web Jetadmin to passively listen for devices
on the network. Finding devices might be as complex as working with the IT team to map the entire IP network,
and then running an IP Range discovery to compile a complete inventory of network-connected devices. You can
also use many of the same settings and techniques to discover PC-connected devices. Before you plan and
implement a device discovery strategy, carefully review the information about discoveries in the
HP Web Jetadmin documentation and white papers.
You should congure features such as Roles, Users, Alerts, and Device Groups before you begin using
HP Web Jetadmin. For more information about a specic feature, see the appropriate section in the
HP Web Jetadmin documentation and the HP Web Jetadmin white papers.
The HP Web Jetadmin documentation and white papers are available from the HP Web Jetadmin support page
(click the ag icon on the bottom of the page, and then select your country/region).
Congure the HP Web Jetadmin Service to Restart Automatically
It is recommended to congure HP Web Jetadmin to restart automatically whenever the HP Web Jetadmin
service fails. If, for example, the database is inaccessible, the HP Web Jetadmin service will be stopped and then
automatically restarted. The HP Web Jetadmin service will wait for the database to become accessible and then
the HP Web Jetadmin service becomes live.
HP Web Jetadmin installs an additional service named HPWSProAdapter. The HPWSProAdapter service facilitates
communication with certain HP device models and must be left running. You must also perform the steps in this
section for the HPWSProAdapter service.
10 Install and Set Up HP Web Jetadmin ENWW
To congure the HP Web Jetadmin service to restart automatically, follow these steps.
1. Access the Windows Control Panel and select Administrative Tools.
2. Select Services and then select HPWJA Service.
3. Right-click and select Properties from the menu.
4. Click the Recovery tab. For the First failure, Second failure, and Subsequent failures, select Restart the
service.
5. Click OK.
Ports
HP Web Jetadmin listens continuously on several ports and opens other ports for specic functionality. The
following table lists the ports that HP Web Jetadmin uses.
NOTE: HP Web Jetadmin uses Internet Control Message Protocol (ICMP) in the discovery process.
HP Web Jetadmin sends an ICMP echo request to determine if the IP is active.
Port number Type
Inbound (I) or
Outbound (O)1Description
69 UDP I TFTP Incoming Port: HP Web Jetadmin uses this port as a staging area for
rmware images during HP Jetdirect rmware updates. Through SNMP,
HP Web Jetadmin triggers HP Jetdirect to retrieve rmware through this port.
80 TCP O HP Web Jetadmin uses this port to qualify the link to the HP Embedded Web
Server on the device and to retrieve the rmware images from the web.
161 UDP O SNMP: HP Web Jetadmin and other management applications use SNMP to
communicate with and manage devices. HP Web Jetadmin uses this port on
the printer to issue Set and Get commands to the SNMP agent.
427 UDP I SLP Listen: HP Jetdirect-connected devices use Service Location Protocol
(SLP) to advertise their existence. When the passive SLP discovery feature is
enabled on HP Web Jetadmin, devices send multicast packets to this port on
the HP Web Jetadmin server.
443 TCP O HTTPS: The HP Web Jetadmin service and HPWSProAdapter service send
device congurations and queries to this port over HTTPS.
HPWSProAdapter uses this port to communicate with devices that do not
support Web Services and are congured to redirect all of the network trac
to HTTPS.
843 TCP O HP Web Jetadmin uses this port to congure some settings, such as fax and
digital sending, on some HP MFP device models.
1433 UDP O Microsoft SQL Server: By default, HP Web Jetadmin installs the SQL Server
database on the same host. Optionally, you can congure HP Web Jetadmin
to communicate with a SQL Server database on a dierent host.
HP Web Jetadmin uses this port to facilitate communication with a remote
SQL Server database.
2493 UDP I/O Build Monitor: This is an HP Web Jetadmin server port that is kept open. Other
HP Web Jetadmin servers use this port to discover running instances of
HP Web Jetadmin.
37022UDP O WS Discovery: HP Web Jetadmin uses this port to perform a Web Services
discovery on newer HP devices.
ENWW Ports 11
Port number Type
Inbound (I) or
Outbound (O)1Description
39102, 3911 TCP O WS Discovery: HP Web Jetadmin uses this port to retrieve details about the
device Web Services during a discovery. HP Web Jetadmin uses these details
to establish the WS communication paths that it needs to manage devices.
HP Web Jetadmin uses port 3910 to retrieve print requests and uses port
3911 to retrieve the printer status.
4088 TCP I Remoting: HP Web Jetadmin uses this port as the primary communication
channel between a started HP Web Jetadmin client and its corresponding
HP Web Jetadmin server.
4089 TCP I Client Event Notication: HP Web Jetadmin uses this port to communicate
change events from the HP Web Jetadmin server to the client. These events
trigger the client to pull updates from the server through the Remoting
interface. In previous releases of HP Web Jetadmin, Windows assigned this
port.
76272TCP O Web Services (HTTPS): HP Web Jetadmin uses this port to communicate with
HP FutureSmart devices and older laser devices for some operations, such as
OXPd.
For devices that do not support Web Services, the HPWSProAdapter Service
acts as a gateway between HP Web Jetadmin and the devices. The
HPWSProAdapter Service receives Web Services requests from
HP Web Jetadmin, and then sends the translated requests to the devices over
port 8080 (an unsecure connection, an HP Embedded Web Server password is
not congured on the devices) or port 443 (a secure connection, an
HP Embedded Web Server password is congured on the devices).
8000 UDP O HP Web Jetadmin Discovery Listen: HP Web Jetadmin uses this port on
remote IP hosts to detect earlier versions of the HP Web Jetadmin software.
8000 TCP I Web Server: HP Web Jetadmin provides an HTTP listener for the initial client
launch and online Help content.
8050 TCP I Device Eventing Callback (HTTPS): Newer HP devices use a WS eventing
protocol for management communications.
8080 TCP O HPWSProAdapter: HPWSProAdapter uses this port to communicate with
devices that do not support Web Services and are not congured to redirect
all of the network trac to HTTPS. HP Web Jetadmin sends device
congurations and queries to this port.
8140 TCP I OXPm Web Services (HTTP): This is the communication port for HP Open
Extensibility Platform (management operations).
8143 TCP I OXPm Web Services (HTTPS): This is a secure communication port for
HP Open Extensibility Platform (management operations).
8443 TCP I Secure Web Server (HTTPS): HP Web Jetadmin provides a secure HTTPS
listener for the initial client launch, Help content, and device le transfer
operations.
9100 TCP O Printer Firmware Upgrade and Test File Operation: HP Web Jetadmin uses this
printer port to transfer printer rmware les, test job les, and PJL
conguration les.
27892 UDP I Traps Listener: HP Web Jetadmin uses this port for SNMP-based alerts and for
By User Data Collections.
27893 UDP I WS Hello Listener: HP Web Jetadmin monitors this port for incoming WS Hello
packets from the HP WS Pro Proxy Agent software that is installed on hosts in
the enterprise. When HP Web Jetadmin detects a packet, it follows up to
determine whether there are any printers to discover on the sending host. For
12 Install and Set Up HP Web Jetadmin ENWW
Port number Type
Inbound (I) or
Outbound (O)1Description
more information, see the HP Web Jetadmin 10.4 Proxy Agents Readme. This
document is available from the HP Web Jetadmin support page (in English).
59113 TCP O Microsoft SQL Server: By default, HP Web Jetadmin installs the SQL Server
database on the same host. Optionally, you can congure HP Web Jetadmin
to communicate with a SQL Server database on a dierent host.
HP Web Jetadmin uses this port to facilitate communication with a remote
SQL Server database.
1The I/O column represents the communication direction with respect to the HP Web Jetadmin server host. HP Web Jetadmin uses
random source ports when communicating with ports on remote IP addresses.
2HP Web Jetadmin uses ports 7627, 3702, and 3910 internally to communicate with devices. To ensure proper communication, these
ports must be kept open for communication directly with the device and with the internal HPWSProAdapter service.
When using WMI discovery (discovering PC-connected printers without an HP proxy installed on the PC), several
ports have to be opened for the WMI communication (DCOM ports, WMI ports, and WMI connection applications
(UnsecApp or WMI_OUT)). For more information, see: https://msdn.microsoft.com/en-us/library/aa822854.aspx
Open the ports in the Windows rewall by using a batch le
HP Web Jetadmin opens the ports listed in the table to communicate with devices. However, the rewall that you
are using might block the connection and prevent HP Web Jetadmin from communicating with the network.
Instead of adding rewall rules for these ports one at a time, you can create a batch le that opens all of the
ports that HP Web Jetadmin requires for the Windows rewall at one time. For instructions, see the Create a
Batch File to Open HP Web Jetadmin Required Ports in the Windows Firewall white paper. This white paper is
available from the HP Web Jetadmin support page.
Implement SSL
By default, the HP Web Jetadmin HTTP service runs without certicates. If you add a certicate, the HTTP server
runs in HTTPS mode and Secure Sockets Layer (SSL) communication is enforced. In HTTPS mode, the user and
the HTTP server are authenticated to one another and the trac between them is encrypted. This adds an extra
layer of security to the Smart Client download and other HTTP transactions.
HP Web Jetadmin does not self-generate certicates. You must obtain a certicate from a certicate authority
(CA). CAs can exist inside or outside of an organization. Many companies have their own CAs. The
HP Web Jetadmin Signing Request feature generates a le that you can send to the CA. When the CA sends you a
certicate, use the Install Certicate feature to enable HTTPS.
IMPORTANT: For new server certicates, you must install 2048-bit certicates. Any previously installed 1024-
bit server certicates continue to function correctly.
Enable Secure Sockets Layer (SSL)
HP Web Jetadmin administrators enable SSL by adding a certicate to the HP Web Jetadmin application. This
certicate forces the browser to use the more secure HTTPS protocol when a user accesses the client logon
page. The administrator must enable SSL from the console or host that runs the application by using the
procedure in Congure HTTPS (Server Certicates or SSL) on page 14. When a remote administrator accesses
Tools > Options > Shared > Network > HTTPS, a message appears stating that certicates can only be installed
from an HP Web Jetadmin client that runs on the console or server that hosts HP Web Jetadmin.
ENWW Implement SSL 13
In some environments, SSL is required when an HTTP interface or service is used for communication. In these
cases, SSL can be enabled and enforced by HP Web Jetadmin. SSL provides a high level of assurance regarding
the authentication and encryption of HTTP communication. That is, a user who requests access to the
HP Web Jetadmin Smart Client download can be reasonably assured that the system hosting HP Web Jetadmin
is authentic and the communication between the two systems is encrypted so that it cannot be easily read by
eavesdroppers.
The SSL protocol uses certicates to accommodate both authentication and encryption. HP Web Jetadmin can
generate a signing request that can be used by a certicate authority (CA) to generate a certicate. Using Tools >
Options > Shared > Network > HTTPS, the user can generate a Signing Request.
Once the request has been fullled by the CA, the certicate is ready to be installed on HP Web Jetadmin.
Remember, you must be at the application console to use Tools > Options > Shared > Network > HTTPS. Use
Install Certicate to browse and upload the certicate le.
Once the certicate is installed, the HTTP service enforces SSL. Any browser contact with HP Web Jetadmin
should indicate HTTPS on the URL when a certicate is installed. Using Remove Certicate uninstalls the
certicate and SSL is no longer enforced.
Important Points to Remember When Implementing SSL
Client communication with SSL enforced requires one or more of the following considerations.
●For new server certicates, you must install 2048-bit certicates. Any previously installed 1024-bit server
certicates continue to function correctly.
●When SSL has been implemented on HP Web Jetadmin with an internal certicate authority (CA), the CA’s
authorizing certicate must be installed in the client browser. If this certicate is not installed in the client
browser the HP Web Jetadmin Smart Client page will fail to load up in SSL mode.
●Proxy servers tend to use the standard SSL port 443. If the HP Web Jetadmin Smart Client page is being
called through a proxy server, a redirect error may occur. This is due to the URL being redirected to 443
rather than 8443 which is the port used by the HP Web Jetadmin SSL. The workaround for this is to place
the HP Web Jetadmin fully qualied domain name (FQDN) into the browsers exceptions list under Tools >
Internet Options > Connections > LAN Settings > Advanced. This causes the browser to pull HTTP and
HTTPS content directly from the HP Web Jetadmin server.
TIP: HP Web Jetadmin HTTP and HTTPS port numbers can be customized to something other than 8000
and 8443.
●When you have implemented SSL on HP Web Jetadmin, a redirect occurs when the browser URL uses port
8000. Here is an example:
The known URL prior to SSL implementation is http://servername.domain.xxx:8000.
After SSL implementation, HP Web Jetadmin will redirect this to a new URL: https://
servername.domain.xxx:8443.
The URLs shown here use FQDN. In most cases the certicate issued and installed in the HP Web Jetadmin
SSL implementation will contain an FQDN for the host on which HP Web Jetadmin is installed. If a non FQDN
is used in the browser, certicate failure will occur. As a general rule, form the HP Web Jetadmin URL with
FQDN when HP Web Jetadmin is implemented with SSL.
To congure HTTPS, access Tools > Options > Shared > Network > HTTPS.
14 Install and Set Up HP Web Jetadmin ENWW
Congure HTTPS (Server Certicates or SSL)
1. To congure HTTPS, access Tools > Options > Shared > Network > HTTPS.
2. To associate a certicate with the HP Web Jetadmin server and enable HTTPS, select Install Certicate.
IMPORTANT: When using the HP Web Jetadmin client to install a certicate on a Vista host with UAC
enabled, you must launch the client from the installer (just after install is nished and from the checkbox
that enables client launch) or from an IE that was Run as Administrator.
-or-
To remove the installed certicate from the server and disable HTTPS, select Remove Certicate.
-or-
To generate a certicate request that can be sent to a signing authority to generate a certicate that can be
installed to enable HTTPS, select Signing Request.
IMPORTANT: For new server certicates, you must install 2048-bit certicates. Any previously installed
1024-bit server certicates continue to function correctly.
3. To save these settings and continue setting other options, click Apply. Then click the next option to
congure in the left menu bar. To save these settings and close this window, click OK.
Use a Separate Instance of Microsoft SQL Server
By default, HP Web Jetadmin installs and uses a database that runs under Microsoft SQL Server Express. An
existing installation of HP Web Jetadmin can be congured to use the full version of SQL Server instead of SQL
Server Express. However, HP does not support or test HP Web Jetadmin installations with SQL Server databases
other than the version listed in Database on page 4 and, therefore, cannot guarantee the results.
For more information about conguring HP Web Jetadmin to use a separate Microsoft SQL instance, see the
Using Microsoft SQL Server with HP Web Jetadmin white paper. This white paper is available from the
HP Web Jetadmin support page (in English).
Deploy the Smart Client
HP Web Jetadmin uses the Microsoft ClickOnce Smart Client technology. This technology runs a Microsoft .NET
Framework application by automatically downloading and starting the application through a web browser. The
Smart Client application runs as a local .NET Framework application on the host and uses .NET Remoting to
communicate with the HP Web Jetadmin service. The following describes the interaction between the
HP Web Jetadmin server and the Smart Client application:
●The Smart Client application uses HTTP or HTTPS to initially contact the HP Web Jetadmin server. The
default HTTP port is 8000. The default HTTPS port is 8443. For instructions on changing the default ports,
see Change the Default HTTP or HTTPS Port for the HP Web Jetadmin Smart Client Application
on page 16.
●The HP Web Jetadmin server transfers approximately 2 MB of les for the Smart Client application to the
client.
●The Smart Client application runs on the client as the user who is logged in to the computer, executes
commands that download approximately 50 MB of HP Web Jetadmin client les, and starts the graphical
user interface for the HP Web Jetadmin client application. The web browser is now inactive.
ENWW Use a Separate Instance of Microsoft SQL Server 15
After the Smart Client application starts, the web browser is no longer required. Although HP Web Jetadmin
also uses the web browser to deliver online Help and proactive Product Update notications, the
HP Web Jetadmin client application runs locally on the computer.
●The HP Web Jetadmin server downloads all of the relevant information to the client. When new information
is available, the HP Web Jetadmin server contacts the client and downloads the new information.
The HP Web Jetadmin installer builds a shortcut on the installation host to http://<ip_address>:8000/, where
<ip_address> is the host where HP Web Jetadmin is installed. Use this URL to access HP Web Jetadmin remotely
from anywhere on the company's intranet or WAN.
To start the Smart Client session, only a web browser is required. Administrator rights are not required to run
Smart Client applications. However, .NET Framework must be installed. Local administrator rights might be
required to install .NET Framework.
In most cases, the Smart Client session starts automatically. However, the local security settings on the
workstation might prevent the application from starting automatically. For more information about manually
starting the Smart Client, see Start an HP Web Jetadmin Client Session on page 17. For more information
about changing the local security settings, see the Microsoft documentation.
Change the Default HTTP or HTTPS Port for the HP Web Jetadmin Smart Client
Application
Use the following steps to change the default HTTP or HTTPS port that is used to start the HP Web Jetadmin
Smart Client application:
1. Use Notepad or a similar text editor to open the HP.Imaging.Wjp.Core.WebServer.cong.xml le. This
conguration le is available in the following directory:
C:\Windows\ServiceProles\NetworkService\AppData\Local\HP Inc\HPWebJetadmin\WjaService\cong
2. Update the <value> attribute for the HTTP or HTTPS port in the following entries:
<property name="HttpsPort">
<type>HP.Imaging.Wjp.Sdk.Core.Framework.ConfigurationItemString
</type>
<value>8443</value>
</property>
<property name="HttpPort">
<type>HP.Imaging.Wjp.Sdk.Core.Framework.ConfigurationItemString
</type>
<value>8000</value>
</property>
3. Close and save the le.
Run the Smart Client Application in a Workgroup
Use the following steps to change the Microsoft security settings:
TIP: For more information about the security policy settings, see the Microsoft documentation.
1. On the HP Web Jetadmin server, go to Start > Control Panel > System and Security > Administrative Tools,
and then double-click Local Security Policy.
2. In the left navigation pane, expand Local Policies, and then select Security Options.
16 Install and Set Up HP Web Jetadmin ENWW
3. In the right pane, double-click Network access: Sharing and security model for local accounts.
4. From the list, select the Classic - local users authenticate as themselves option.
5. Click the OK button.
Start an HP Web Jetadmin Client Session
After the HP Web Jetadmin installation is complete, use one of the following methods to start an
HP Web Jetadmin client session:
●On the host where HP Web Jetadmin is installed, go to Start > All Programs > HP Web Jetadmin 10, and
then select HP Web Jetadmin.
●In Internet Explorer, browse to the following URL on the host where HP Web Jetadmin is installed:
http://<ip_address>:8000
●From the command line, issue the following command:
rundll32 dfshim.dll, ShOpenVerbApplication http://<ip_address>:
8000/wja/wja.application?InternalErrorDetails=true
To start the HP Web Jetadmin client session in a specic language, use the following URLs. If the
corresponding Windows language pack is installed, the HP Web Jetadmin client session displays in that
language. If the corresponding Windows language pack is not installed, the HP Web Jetadmin client session
displays in a mixture of English and the specied language.
Language URL
Chinese (Simplied) http://<ip_address>:8000/wja/wja.application?lang=zh-cn
Chinese (Traditional) http://<ip_address>:8000/wja/wja.application?lang=zh-tw
English (Worldwide) http://<ip_address>:8000/wja/wja.application?lang=en-us
French (European) http://<ip_address>:8000/wja/wja.application?lang=fr-fr
German http://<ip_address>:8000/wja/wja.application?lang=de-de
Italian http://<ip_address>:8000/wja/wja.application?lang=it-it
Japanese http://<ip_address>:8000/wja/wja.application?lang=ja-jp
Korean http://<ip_address>:8000/wja/wja.application?lang=ko-kr
Portuguese (Brazilian) http://<ip_address>:8000/wja/wja.application?lang=pt-pt
Russian http://<ip_address>:8000/wja/wja.application?lang=ru-ru
Spanish (Mid-Atlantic) http://<ip_address>:8000/wja/wja.application?lang=es-es
In some cases, you might need to add the URL for HP Web Jetadmin to the trusted security zone in the Web
browser.
Congure HP Web Jetadmin to Bind to a Specic NIC
HP Web Jetadmin can run on a multi-homed server or on a server that has multiple network interfaces. In many
cases, a multi-homed server is connected to more than one network and has multiple IP addresses. A multi-
ENWW Deploy the Smart Client 17
homed server with multiple IP addresses can cause problems because HP Web Jetadmin tends to use only one
address for various reasons.
HP Web Jetadmin is a collection of features that administrators can use to manage devices. Each of these
features might require communications on the network or convey the IP address through which communications
should take place to other features either on or o the HP Web Jetadmin server. These features facilitate
learning the HP Web Jetadmin server IP address when the HPWJA service starts. These features do so in
isolation and might not select the correct IP address. The following sections describe situations where features
might not detect and select the correct IP address and provide a workaround that forces HP Web Jetadmin to
select the correct IP address.
HP Web Jetadmin Client Connection
The HP Web Jetadmin client startup is initiated from Internet Explorer using HTTP. Immediately after the startup
sequence, the HP Web Jetadmin client sends an HTTP message to the client host. The HTTP message points to a
Microsoft .NET Framework remote connection. The client host then initiates a relatively secure connection to the
HP Web Jetadmin server based on the HTTP message.
If HP Web Jetadmin is installed on a multihomed server and the HP Web Jetadmin (HPWJA) service selects an
incorrect IP address, the .NET Framework remote connection fails because the system that hosts the client
cannot communicate by using the IP address provided. Use the following steps to force the HPWJA service to use
the correct IP address:
1. Stop the HPWJA service by using Windows Service Manager.
CAUTION: Be careful when stopping the HPWJA service. Critical tasks might be running and clients might
be logged in to HP Web Jetadmin. To view the running tasks, go to Application Management > Overview >
Application Management - Active Tasks. To view the clients that are logged in, go to Application
Management > Overview > Client Management - Active Clients.
2. Use Notepad or a similar editor to open the System.Remoting.cong le. This conguration le is available
in the following directory:
C:\Program Files\HP Inc\Web Jetadmin 10\cong\WjaService
IMPORTANT: Make sure that Notepad is running with sucient privileges to update and save the le.
3. Find the following code in the System.Remoting.cong le:
<application>
<channels>
<channel ref="tcp" port="4088" name="CMRemotingChannel"
rejectRemoteRequests="false"
tokenImpersonationLevel="Impersonation" secure="true"
protectionLevel="EncryptAndSign" impersonate="false">
4. Add the machineName="xxx.xxx.xxx.xxx" entry, changing the value to the IP address of the
HP Web Jetadmin server that facilitates client communication. The following is an example of the edited
code:
<application>
<channels>
<channel ref="tcp" port="4088" name="CMRemotingChannel"
rejectRemoteRequests="false"
tokenImpersonationLevel="Impersonation" secure="true"
protectionLevel="EncryptAndSign" impersonate="false"
machineName="xxx.xxx.xxx.xxx">
18 Install and Set Up HP Web Jetadmin ENWW
CAUTION: Make sure that the new entry and value are entered exactly as shown here. Use the quotes
that the editor generates. Do not copy and paste this text because incorrect characters, such as quotes,
cause the HPWJA service to fail at startup. Observe all of the rules for editing XML. If the le is incorrectly
formatted, the HP Web Jetadmin XML parser fails.
5. Close and save the le.
6. Start the HPWJA service by using Windows Service Manager.
HP Web Jetadmin Alerts and SNMP Traps Registration
In rare cases, HP Web Jetadmin detects and uses an incorrect IP address for SNMP traps registration at the
device. When HP Web Jetadmin alert subscriptions are created, HP Web Jetadmin registers its IP address in the
SNMP traps destination table on the HP device. This registration causes the device to send a notication in the
form of SNMP trap packets back to the HP Web Jetadmin server. HP Web Jetadmin uses these notications to
trigger alerts for device conditions such as toner out or paper jam.
If an HP Web Jetadmin instance on a multi-homed server populates the SNMP traps destination table with the
incorrect IP address, follow these steps to force HP Web Jetadmin to select and use the correct IP address:
1. Stop the HPWJA service by using Windows Service Manager.
CAUTION: Be careful when stopping the HPWJA service. There might be critical tasks running. To view the
running tasks in HP Web Jetadmin, go to Application Management > Overview > Application Management -
Active Tasks. To view the client logins in HP Web Jetadmin, go to Application Management > Overview >
Client Management - Active Clients.
2. Open Notepad or a similar text editor that has the appropriate create and edit permissions.
3. Enter the following text:
<ipmc:configuration
xmlns:ipmc="www.hp.com/schemas/imaging/ipmc/config/2004/02/24">
<property name="LocalIPV4Address">
<type>HP.Imaging.Wjp.Sdk.Core.Framework.ConfigurationItemString
</type>
<value>xxx.xxx.xxx.xxx</value>
</property>
</ipmc:configuration>
CAUTION: Make sure that the new eld and values are entered exactly as shown here. Use the quote
marks that the editor generates. Do not copy and paste from this document because incorrect characters
cause the HPWJA service to fail at startup. Observe all the rules regarding XML editing. If the les are
incorrectly formatted, the HP Web Jetadmin XML parser fails.
4. Change the <value>xxx.xxx.xxx.xxx</value> entry to the correct HP Web Jetadmin server IP
address through which the device can communicate.
5. Select File > Save As.
6. On the Save as window, navigate to the following directory on the HP Web Jetadmin server host:
C:\Windows\ServiceProles\NetworkService\AppData\Local\HP Inc\HPWebJetadmin\WjaService\cong
7. In the File name text box, enter
HP.Imaging.Wjp.Alerts.Library.AlertsHelpers.config.xml.
8. From the Save as type drop-down list, select All Files (*.*).
ENWW Deploy the Smart Client 19
9. Click Save.
10. Start the HPWJA service by using Windows Service Manager.
HP Web Jetadmin now uses the IP address specied during SNMP traps registration. You must update any SNMP
traps registrations created prior to this procedure by using the HP Web Jetadmin Conguration feature or by
creating additional alerts subscriptions.
HP Web Jetadmin Web Service
The HP Web Jetadmin web or HTTP service uses the server IP addresses for various reasons, including
communicating with other processes, nodes, services, and the IP address of the actual HTTP server. In rare
cases, HP Web Jetadmin detects the incorrect IP address on multi-homed systems. A conguration le that
includes the HP Web Jetadmin IP address is built during the rst HPWJA service startup. Follow these steps to
correct the IP address value in the conguration le:
1. Stop the HPWJA service by using Windows Service Manager.
CAUTION: Be careful when stopping the HPWJA service. There might be critical tasks running. To view the
running tasks in HP Web Jetadmin, go to Application Management > Overview > Application Management -
Active Tasks. To view the client logins in HP Web Jetadmin, go to Application Management > Overview >
Client Management - Active Clients.
2. Open Notepad or a similar text editor that has the appropriate create and edit permissions.
3. Select File > Open.
4. On the Open window, navigate to the following directory:
C:\Windows\ServiceProles\NetworkService\AppData\Local\HP Inc\HPWebJetadmin\WjaService\cong
5. Open the HP.Imaging.Wjp.Core.WebServer.cong.xml le.
6. Find the following portion of the le:
<property name="HostIPv4Address">
<type>HP.Imaging.Wjp.Sdk.Core.Framework.ConfigurationItemString
</type>
<value>xxx.xxx.xxx.xxx</value>
</property>
7. Change the <value>xxx.xxx.xxx.xxx</value> entry to the correct server IP address.
8. Select File > Save.
9. Start the HPWJA service by using Windows Service Control Manager.
HP Web Jetadmin now uses the specied IP address with reference to the HTTP or web services.
Congure the Port for Event Notications
HP Web Jetadmin directs clients to a TCP connection to receive event notications. After the client establishes
the TCP connection, HP Web Jetadmin sends event notications that prompt the client to update itself via the
standard Microsoft .NET Remoting channel on port 4088. The HP Web Jetadmin server communicates the port
number that is established for event notications to the client when the client rst establishes a connection to
the HP Web Jetadmin server. The port number that HP Web Jetadmin communicates to the client is somewhat
random, which might cause a problem if a rewall is congured on the HP Web Jetadmin server.
20 Install and Set Up HP Web Jetadmin ENWW
If a rewall is congured on the HP Web Jetadmin server, the event notication port must be set to static and the
rewall must be congured to accept connections through this port. If a rewall is congured on the client, the
rewall on the client does not have to be congured to launch the client.
Use the following steps to congure a static port for event notications:
CAUTION: Be careful when restarting the HP Web Jetadmin service. Critical tasks might be running and clients
might be logged in to HP Web Jetadmin. To view the running tasks, go to Application Management > Overview >
Application Management - Active Tasks. To view the clients that are logged in, go to Application Management >
Overview > Client Management - Active Clients.
1. Use Notepad or a similar editor to create a le that contains the following XML section:
<ipmc:configuration
xmlns:ipmc="www.hp.com/schemas/imaging/ipmc/config/2004/02/24">
<property name="ClientEventRouter.ServerPort">
<type>HP.Imaging.Wjp.Sdk.Core.Framework.ConfigurationItemString
</type>
<value>8099</value>
</property>
</ipmc:configuration>
The port number specied for the <value> attribute can be any unused port.
2. From the File menu, select Save.
3. On the Save As window, navigate to the following directory on the HP Web Jetadmin server:
C:\Windows\ServiceProles\NetworkService\AppData\Local\HP Inc\HPWebJetadmin\WjaService\cong
4. In the File name box, enter Global.config.xml, and then click the Save button.
5. Restart the HP Web Jetadmin service (HPWJAService). For instructions, see Restart the HP Web Jetadmin
Service Manually on page 21.
6. Use any rewall application or a similar application to open the port.
Congure the Firewall Software
You must congure the rewall on the HP Web Jetadmin server host to allow client trac and other trac to
pass through the correct ports. The rewall monitors HP Web Jetadmin for the ports that it uses and allows
trac.
In some rewall applications, such as Microsoft Firewall, you can specify a program or executable le as a
rewall exception. In these cases, you can dene the following le as an exception:
C:\Program Files\HP Inc\Web Jetadmin 10\bin\HPWJAService.exe
The rewall on the client system does not require any special consideration because the client application does
not listen to a specic port.
Restart the HP Web Jetadmin Service Manually
It may be necessary to stop and restart the HP Web Jetadmin service. An example of this would be when a
network is switched from hard-wired to wireless. Once the network is switched, HP Web Jetadmin must be
restarted in order for the application to realize the change.
ENWW Restart the HP Web Jetadmin Service Manually 21
CAUTION: Restarting HP Web Jetadmin services may interrupt background tasks and user sessions. Always
check the application before restarting.
To script the stop of all HP Web Jetadmin services, use these command strings in this order:
●Net stop HPWSProAdapter
●Net stop HPWJAService
●Net stop mssql$HPWJA
To script the start of all HP Web Jetadmin services, use these command strings in this order:
●Net start mssql$HPWJA
●Net start HPWJAService
●Net start HPWSProAdapter
1. Uninstall HP Web Jetadmin.
2. Use Windows Service Manager to set the older HP Web Jetadmin service (listed as HP Web Jetadmin in the
Services MMC) to activate and to also start the service.
Back Up and Restore HP Web Jetadmin
Scripts for backing up and restoring HP Web Jetadmin are available. These scripts provide examples of the
recommended method for backing up and restoring the HP Web Jetadmin settings and data, including the
Microsoft SQL Server database. The WJABackupRestoreInstructions_<language_code>.txt le provides
instructions for running the scripts. The scripts and instructions are available in the following directory:
C:\Program Files\HP Inc\Web Jetadmin 10\WJABackupRestore
Upgrade HP Web Jetadmin
The current HP Web Jetadmin installation must be backed up before an upgrade is started. The
WJABackupRestoreInstructions_<language_code>.txt le provides instructions for backing up HP Web Jetadmin.
This le is located in the following directory on the HP Web Jetadmin server:
C:\Program Files\HP Inc\Web Jetadmin 10\WJABackupRestore
In HP Web Jetadmin, go to Help > About, and then write down the current version as 10.4. nnnnn, where nnnnn
is the build number. This version of the installer is required to perform a recovery.
Before you begin an upgrade, go to Application Management > Overview > Application Management – Active
Tasks, and then check for any paused or pending tasks. You must stop or resolve these tasks before you run the
installer.
To upgrade HP Web Jetadmin, obtain the HP Web Jetadmin installation executable from www.hp.com/go/
webjetadmin. Then run the executable on the system that hosts HP Web Jetadmin.
22 Install and Set Up HP Web Jetadmin ENWW
Import Feature Packs
Feature Packs provide support for dynamically adding new conguration options and new device images to
HP Web Jetadmin. Feature Packs are imported and applied on an existing installation of HP Web Jetadmin. This
means that you can gain access to the new functionality without installing and qualifying a new version of the
full HP Web Jetadmin application. HP Web Jetadmin Administrator rights are required to apply Feature Packs.
Feature Packs are cumulative. A new Feature Pack includes the new functionality that is being released and all of
the functionality that was released in previous Feature Packs.
Each Feature Pack has a minimum version of HP Web Jetadmin that must be installed before the Feature Pack
can be imported and applied. If you import a Feature Pack on a version of HP Web Jetadmin that is earlier than
the minimum required version, HP Web Jetadmin displays a message that species the minimum required
version.
Feature Packs are available from www.hp.com/go/webjetadmin as signed HP Binary (HPb) les. After you
download an HPb le, you must import the HPb le into the existing installation of HP Web Jetadmin, and then
apply the HPb le. You must restart the HP Web Jetadmin service before the new functionality is available in
HP Web Jetadmin.
CAUTION: After a Feature Pack is applied, it cannot be removed from HP Web Jetadmin. HP recommends that
you back up HP Web Jetadmin before you apply a Feature Pack.
When a Feature Pack is initially released, the software and online Help for the new features are available only in
English. The localized software and online Help for the new features will be provided at a later time, either in a
new Feature Pack or a new version of HP Web Jetadmin.
Import and apply a Feature Pack
CAUTION: After a Feature Pack is applied, it cannot be removed from HP Web Jetadmin. HP recommends that
you back up HP Web Jetadmin before you apply a Feature Pack.
1. Go to www.hp.com/go/webjetadmin, and then download the HP Web Jetadmin Feature Pack le.
2. Go to Tools > Feature Packs.
3. Click the Import button.
4. On the Open window, browse to and select the HPb le, and then click the Open button.
5. On the Success window, click the OK button. The HPb le is listed on the Feature Packs window with a
status of Imported (Apply Pending).
-or-
If a Feature Pack has already been imported, but has not been applied yet, HP Web Jetadmin displays the
Warning window.
To overwrite the existing Feature Pack, click the Yes button.
To cancel the import process, click the No button.
6. Select the Feature Pack from the list, and then click the Apply button.
The status of the selected Feature Pack must be Imported.
7. On the Conrm Feature Pack apply window, click the OK button.
8. On the Success window, click the OK button. The Feature Pack is listed on the Feature Packs window with a
status of Applied (Service Restart Required).
9. Restart the HP Web Jetadmin service (HPWJAService).
ENWW Import Feature Packs 23
CAUTION: Restarting the HP Web Jetadmin service can interrupt critical processes. Before you restart the
HP Web Jetadmin service, use the HP Web Jetadmin Broadcast Message feature to notify the active users,
and then make sure that all of the users are logged o and that there are no active tasks running on the
HP Web Jetadmin server.
Delete an imported Feature Pack
1. Go to Tools > Feature Packs.
2. Select the Feature Pack from the list, and then click the Delete button.
The status of the selected Feature Pack must be Imported.
3. On the Delete Feature Pack window, click the OK button.
4. On the Success window, click the OK button.
Display the Release Notes for a Feature Pack
The Release Notes for Feature Packs are provided only in English.
1. Go to Tools > Feature Packs.
2. Select the Feature Pack from the list, and then click the Details button. The Release Notes are displayed in
Notepad.
Enable FIPS on the HP Web Jetadmin Server
Federal Information Processing Standard (FIPS) can be enabled only after you upgrade to HP Web Jetadmin 10.4
or later. This topic provides instructions for upgrading HP Web Jetadmin, making the required changes to the
settings in HP Web Jetadmin, and then enabling FIPS. These instructions must be followed in the order provided.
The MD5 and DES protocols are blocked after FIPS is enabled. Communication over SNMPv1/SNMPv2 is still
possible after FIPS is enabled.
Upgrade to HP Web Jetadmin 10.4 or later
1. On the HP Web Jetadmin server, go to www.hp.com/go/webjetadmin, and then download the
HP Web Jetadmin software.
2. Double-click the EXE le.
3. Follow the instructions in the wizard.
4. If the installation stops with a warning that a reboot is required, reboot the HP Web Jetadmin server.
Launch the installer again to continue the installation.
5. When the installation is complete, click the Finish button.
Make the required changes to the settings in HP Web Jetadmin and on the devices
If you omit the following steps, HP Web Jetadmin might not be able to communicate with the devices after FIPS
is enabled. HP Web Jetadmin displays a status of Device Communication Error for these devices.
1. If HP Web Jetadmin has already discovered devices by using an SNMPv3 credential that species the MD5
and DES protocols, SNMP communication with those devices will not work after FIPS is enabled. The
SNMPv3 credential for these devices must be changed to the SHA-1 and AES-128 protocols. However, you
24 Install and Set Up HP Web Jetadmin ENWW
cannot use HP Web Jetadmin to determine if the SNMPv3 credential for the devices uses the MD5 and DES
protocols.
Use the following steps to update the SNMPv3 credential on all of the devices that use SNMPv3:
a. In the Device Management navigation pane, right-click Conguration, and then select Create
conguration template. The Create Device Conguration Template wizard starts.
b. On the Select Template Models page, select the device models to congure, and then click the right
arrow button.
c. Select the network cards to congure, and then click the right arrow button.
d. Click the Next button.
e. On the Specify template options page, enter a name for the template in the Name box (up to 48
characters).
f. In the Device settings navigation pane, go to Security > SNMP Version Access Control.
g. Select the Modify SNMPv3 option.
h. In the Current SNMPv3 Credential section, enter the user name, authentication protocol,
authentication passphrase, privacy protocol, and privacy passphrase that are currently congured for
SNMPv3. The current SNMPv3 credentials are required.
i. In the New SNMPv3 Credential section, select SHA-1 from the Authentication Protocol list, and select
AES-128 from the Privacy Protocol list.
j. If required, enter the new values for the user name, authentication passphrase, and privacy
passphrase.
CAUTION: To change the authentication and privacy passphrases, the current passphrases must be
specied in the device conguration template even if global SNMPv3 credentials are stored in
HP Web Jetadmin. If the current passphrases are not specied, the conguration fails.
k. Click the Next button.
l. On the Conrm page, verify that the information is correct, and then click the Create Template button.
m. On the Results page, click the Done button.
n. In the Device Management navigation pane, right-click Conguration, and then select Apply
conguration template. The Apply Device Conguration Template wizard starts.
o. Select the device conguration template that you just created from the list, and then click the Next
button.
p. On the Select devices page, select the devices to congure from the Available devices list, and then
click the > button.
q. Click the Next button.
r. On the Conrm page, verify that the information is correct, and then click the Apply Template button.
s. On the Results page, click the Done button.
2. Use the following steps to delete the SNMPv3 global credentials that use the MD5 and DES protocols:
a. Go to Tools > Options > Shared > Credentials > Device > SNMPv3.
b. Select the SNMPv3 credential that uses the MD5 and DES protocols from the list, and then click the
Remove button.
ENWW Enable FIPS on the HP Web Jetadmin Server 25
c. On the Conrm Delete window, click the Yes button.
d. Repeat steps b through c for each SNMPv3 credential that uses the MD5 and DES protocols.
3. Run a discovery to rediscover all of the SNMPv3-congured devices.
4. Trap forwarding that is congured to use SNMPv3 credentials with the MD5 and DES protocols does not
work after FIPS is enabled. Use one of the following procedures to update the alert subscriptions that are
congured to forward SNMP traps to a server using SNMPv3 credentials with the SHA-1 and AES-128
protocols.
NOTE: Alert subscriptions that are congured to only write alerts to the alert history log or to send email
notications when alerts occur do not need to be updated.
Update the alert subscriptions that were created by using an alert subscription template that is congured
to forward SNMP traps
a. In the Device Management navigation pane, go to Alerts > All Subscriptions.
b. At the top of the All Subscriptions pane, click the Expand all button to display the details for each alert
subscription.
c. To identify the alert subscription templates that must be updated, look for alerts that have SNMPv3
Trap Forwarding in the Notication Type column and have Linked in the Linked to Template column.
The name of the alert subscription template is shown in the Subscription Name column.
d. In the Device Management navigation pane, go to Alerts > Templates.
e. In the Alerts - Subscription Templates pane, select the alert subscription template from the list, and
then click the Edit button. The Edit Subscription Template wizard starts.
f. Click the Next button until the Specify notication settings page appears.
g. In the SNMPv3 credential section, select SHA-1 from the Authentication protocol list, and select
AES-128 from the Privacy protocol list.
h. If required, enter the new values for the user name, authentication passphrase, and privacy
passphrase.
i. Click the Next button until the Conrm page appears.
j. On the Conrm page, verify that the information is correct, and then click the Save Template button.
k. On the Results page, click the Done button.
All of the alert subscriptions that are linked to this alert subscription template are automatically
updated with the new SNMPv3 credentials.
l. Repeat steps c through k for each of the alert subscription templates.
Update the alert subscriptions that were created without using an alert subscription template and are
congured to forward SNMP traps
a. In the Device Management navigation pane, go to Alerts > All Subscriptions.
b. In the All Subscriptions pane, select the alert subscription from the list, and then click the Edit
Subscription button. The Edit Subscription wizard starts.
c. Click the Next button until the Specify notication settings page appears.
d. In the SNMPv3 credential section, select SHA-1 from the Authentication protocol list, and select
AES-128 from the Privacy protocol list.
26 Install and Set Up HP Web Jetadmin ENWW
e. If required, enter the new values for the user name, authentication passphrase, and privacy
passphrase.
f. Click the Next button until the Conrm page appears.
g. On the Conrm page, verify that the information is correct, and then click the Edit Subscription button.
h. On the Results page, click the Done button.
i. Repeat steps b through h for each alert subscription that was created without using an alert
subscription template.
-or-
If any future changes are made to the alert subscriptions, all of the alert subscriptions must be changed. To
prevent this in the future, HP recommends that you use the following steps to create new alert
subscriptions that are linked to alert subscription templates:
a. In the Device Management navigation pane, go to Alerts > All Subscriptions.
b. In the All Subscriptions pane, select the alert subscription from the list, and then click the Unsubscribe
button. The Delete Alert Subscriptions wizard starts.
c. On the Conrm page, click the Unsubscribe button.
d. On the Results page, click the Done button.
e. In the Device Management navigation pane, go to Alerts > Templates.
f. In the Alerts - Subscription Templates pane, select the alert subscription template from the list, and
then click the Apply button. The Apply Alert Subscription Template wizard starts.
NOTE: If an alert subscription template is not available, create an alert subscription template that
meets your specic needs.
g. On the Select devices page, select the devices from the Available devices list, and then click the >
button.
h. Click the Next button.
i. To link the selected alert subscription template to this alert subscription, select the Link template to
subscription option. Changes that are made to the selected alert subscription template are
automatically applied to the devices that are associated with this alert subscription.
-or-
To create an alert subscription that is not linked to the selected alert subscription template, select the
Do NOT link template to subscription option, and then enter a name for this alert subscription in the
Subscription name box. Changes that are made to the alert subscription template are not applied to
the devices that were previously congured with this alert subscription template.
j. Click the Next button.
k. On the Conrm page, verify that the information is correct, and then click the Apply Template button.
l. On the Results page, click the Done button.
m. Repeat steps b through l for each of the alert subscriptions that were created without using an alert
subscription template.
5. On the client machines where the HP Web Jetadmin client is launched, use the following steps to enable
the TLS protocol:
ENWW Enable FIPS on the HP Web Jetadmin Server 27
a. Open an Internet Explorer browser.
b. Go to Tools > Internet options, and then click the Advanced tab.
c. Scroll down to the Security section, and then select the checkboxes for one or more of the TLS
versions (TLS 1.0, TLS 1.1, and TLS 1.2).
6. Use the following steps to verify that the devices are congured to communicate with the TLS protocol:
a. Select the device from any device list.
b. On the Cong tab, go to Network > Mgmt Protocol.
c. Verify that any version of TLS (TLS 1.0, TLS 1.1, and TLS 1.2) is enabled.
d. Repeat steps a through c for each device.
7. Use the following steps to enable FIPS-140 mode on the devices. Enabling FIPS-140 mode aects only the
following device conguration options:
●SNMP Version Access Control conguration option: The SHA-1 authentication protocol and AES-128
privacy protocol must be congured.
●Mgmt Protocol conguration option: The TLS 1.0, TLS 1.1, or TLS 1.2 protocol must be enabled.
TIP: The following steps are not required. However, you can use these steps to troubleshoot any FIPS-
related problems.
a. Select the device from any device list.
b. On the Cong tab, go to Security > FIPS-140 Mode.
c. Select the Enabled option.
d. Click the Apply button.
e. Repeat steps a through d for each device.
If any of the following device conguration options are congured on a device, enabling FIPS-140 mode
fails for that device:
●SNMP Version Access Control conguration option: The MD5 authentication and DES privacy protocols
must not be specied.
●IPsec/Firewall Policy conguration option: The DES-CBC-MD5 algorithm must not be specied for the
Kerberos setting.
●Upload Jetdirect Certicate conguration option: Certicates must not be signed by using MD5 or
earlier (MD2 or MD4).
●Upload CA Certicate conguration option: Certicates must not be signed by using MD5 or earlier
(MD2 or MD4).
●Mgmt Protocol conguration option: The SSL 3.0 or earlier protocol must not be enabled.
HP Web Jetadmin does not report the exact reason for the failure. However, if you enable FIPS-140 mode
by using the device HP Embedded Web Server (EWS), the EWS does report the exact reason for the failure.
The FIPS-140 mode setting is available in the EWS from the Networking tab > Security link > Settings page.
Enable FIPS on the HP Web Jetadmin server
1. Stop the following services. These services must be stopped in the specied order.
28 Install and Set Up HP Web Jetadmin ENWW
a. HPWSProAdapter
b. HPWJAService
c. mssql$HPWJA
2. Use the following steps to enable FIPS on the HP Web Jetadmin server as a local security policy:
TIP: For more information about the System cryptography setting, see the “System cryptography: Use
FIPS compliant algorithms for encryption, hashing, and signing" security setting eects in Windows XP and in
later versions of Windows document. This document is available from the Microsoft support page.
a. Go to Control Panel > Administrative Tools > Local Security Policy > Local Policies > Security Options.
b. Right-click System cryptography: Use FIPS compliant algorithms for encryption, hashing and signing,
and then select Properties.
c. On the Local Security Setting tab, select the Enabled option, and then click the OK button.
3. Start the following services. These services must be started in the specied order.
a. mssql$HPWJA
b. HPWJAService
c. HPWSProAdapter
4. Use the following steps to verify that HP Web Jetadmin can communicate with all of the devices:
a. In the All Devices list, look for any devices that have Device Communication Error in the Status
column.
b. Verify that you can congure a device by using HP Web Jetadmin.
c. In the All Devices list, right-click a device, and then select Refresh Selection (Full). Verify that the
refresh completed.
If there are any devices that have a status of Device Communication Error or you cannot complete step b or
c, access the device EWS, and then verify the following settings:
●Click the Networking tab, and then click the Network Settings link. If SNMPv3 is enabled, verify that
the authentication protocol is SHA x and the privacy protocol is AES.
●Click the Security tab, and then click the Certicate Management link. Select a certicate, and then
click the View Details button. Verify that the self-signed certicate uses a signature algorithm other
than MD5. Repeat this step for each self-signed certicate.
Uninstall HP Web Jetadmin
When you uninstall HP Web Jetadmin, the Microsoft SQL Server Express Edition instance of the HP Web Jetadmin
database is also removed. You can restore the HP Web Jetadmin database if you ran the appropriate backup
procedures and stored the backup les in a secure location.
To uninstall HP Web Jetadmin, perform the following steps:
1. Go to Start > Control Panel > Uninstall a program.
2. Right-click HP Web Jetadmin 10.4, and then select Change. The HP Web Jetadmin 10.4 - InstallShield
Wizard starts.
3. Click the Next button.
ENWW Uninstall HP Web Jetadmin 29
4. Select the Remove option, and then click the Next button.
5. Follow the instructions in the wizard.
6. Review the MSI <xxxxx>.LOG le, where <xxxxx> is a randomly generated string. The log le is available in
the following directory:
C:\Users\<username>\AppData\Local\Temp
TIP: You can uninstall HP Web Jetadmin from the command line. For instructions, see the Uninstall
HP Web Jetadmin from the Command Line white paper. This white paper is available from the HP Web Jetadmin
support page (in English).
Manage Licenses
There are some features for HP Web Jetadmin that require a license. After you obtain the license for a feature,
you must install the license to enable the functionality.
To manage the licenses, perform the following steps:
1. Go to Start > All Programs > HP Web Jetadmin 10, and then select HP Web Jetadmin License Manager.
2. To install a license, perform the following steps:
a. Click the Add button.
b. On the Enter License window, enter the license key, and then click the Apply button.
3. To delete a license, select the license from the list, and then click the Remove button.
4. To refresh the list of licenses, click the Refresh button.
5. Click the Exit button.
6. Restart the HP Web Jetadmin service (HPWJA Service).
30 Install and Set Up HP Web Jetadmin ENWW
A End-User License Agreement
When you download, register, and install HP Web Jetadmin, you must read the End-User License Agreement
(EULA) and acknowledge that you agree to the terms.
After HP Web Jetadmin is installed, the EULA is available from the online Help. To view the EULA, go to Help >
About, and then click the View the End-User License Agreement link.
ENWW 31
Index
A
address for certicates 14
alerts
selecting correct IP address 19
authorizing certicate 14
automatically restarting 10
B
backing up HP Web Jetadmin 22
binding to specic NIC 17
C
ClickOnce Smart Client
overview 15
client application
operating system requirements
2
other requirements 5
client connection
selecting correct IP address 18
client hardware requirements 4
client ports 11
client security requirements 6
client sessions, HP Web Jetadmin
starting 17
command line
uninstall from 29
command-line, installing from
in blocking mode 9
syntax 6
conguration
recommended initial steps 10
conguration le
correcting IP address 20
conguring
automatic service restart 10
D
database requirements 4
devices
supported 5
E
End-User License Agreement (EULA)
31
event notications
conguring port 20
F
Feature Packs
importing 23
Release Notes 23
FIPS
enabling on HP Web Jetadmin
server 24
rewall software, conguring 21
H
host access requirements 6
HP Web Jetadmin client sessions
starting 17
HP Web Jetadmin server
enabling FIPS 24
HPWJA service
selecting correct IP address 18
HTTP
changing the default port for the
Smart Client application 16
HTTPS
changing the default port for the
Smart Client application 16
conguring 15
I
importing
Feature Packs 23
Installation
one hardware platform 1
upgrading 1
installation
subsequent tasks 10
installation requirements 5
installing
Feature Packs 23
installing HP Web Jetadmin
from command line 6
from command line in blocking
mode 9
recommended initial steps 10
using installer 6
IP addresses
selecting on multi-homed
servers 17
L
license agreement, software 31
License Manager 30
M
manually restarting 21
Microsoft SQL Server
using separate instance 15
multi-homed servers
selecting correct IP address 17
N
network requirements 5
NIC, binding to specic 17
P
port numbers 10
standard SSL port 14
ports 11
event notications 20
post-installation steps 10
R
Release Notes
Feature Packs 23
remote ports 11
requirements, system 1
restart 10, 21
restoring HP Web Jetadmin 22
S
Secure Sockets Layer (SSL)
implementing 13
secure sockets layer (SSL) 13
server application requirements 1
server hardware requirements 3
server security requirements 6
server, HP Web Jetadmin
enabling FIPS 24
32 Index ENWW
service
restarting automatically 10
restarting manually 21
Smart Client
deploying 15
Smart Client application
changing default HTTP and HTTPS
ports 16
running in workgroups 16
SNMP traps registration
selecting correct IP address 19
software license agreement 31
SQL Server
using separate instance 15
SSL (Secure Sockets Layer)
implementing 13
SSL (secure sockets layer) 13
supported devices 5
system requirements 1
U
uninstalling HP Web Jetadmin
from command line 29
from Control Panel 29
upgrade requirements 5
upgrading 1
upgrading HP Web Jetadmin 22
URL for certicates 14
V
virtual machine requirements 3
ENWW Index 33

Navigation menu
