Windows® 7 64-bit Hardware Matrix for HP Z8 G4, Z6 G4, and Z4 G4
Workstations
General Notes
How to Use this Document
This document lists the hardware devices that have been tested on HP Z8 G4, Z6 G4, and Z4 G4 Workstations.
The platform-specific pages in this matrix are formatted as follows:
* The platform is identified at the top of the page.
* Built-in (onboard) and optional components are listed in the left-hand column. This is the set of components that have been tested by HP.
Built-in and optional components that are not listed have not been tested by HP. They may or may not work with Windows 7. The list of
components may be updated periodically as additional testing is completed.
* A solid circle in a cell represents usable functionality with Windows 7.
* A number in parentheses represents a reference to a footnote. Footnotes are located at the bottom of the page.
© Copyright 2017 HP Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express
warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not
be liable for technical or editorial errors or omissions contained herein.
AMD is a trademark of Advanced Microdevices, Inc.
Intel is a trademark of Intel Corporation or its subsidiaries in the U.S. and other countries.
NVIDIA is a trademark and/or registered trademark of NVIDIA Corporation in the U.S. and other countries.
Windows is a trademark of Microsoft Corporation.
First Edition: December 2017
Document part number: L13282-001
Windows 7 64-bit Hardware Matrix for HP Workstations
HP Z8 G4 Workstation
Product Items/Features
(Unlisted components have not been tested by HP)
Windows 7 64-bit
HP Workstation Base System
Base system includes: Chassis, System Board, Power Supply, etc.
•
HP Localization Kit
(1)
Supported Processors
•
Front I/O Module
Base Front I/O module
• (2)
Premium Front I/O module
• (2)
Graphics Card (Video Card)
• (3)
AMD FirePro W2100 1st and 2nd GFX
•
AMD Radeon Pro WX 3100 1st and 2nd GFX
•
AMD Radeon Pro WX 4100 1st and 2nd GFX
•
AMD Radeon Pro WX 7100 1st and 2nd GFX
•
NVIDIA® Quadro P1000 1st and 2nd GFX
•
NVIDIA Quadro P2000 1st and 2nd GFX
•
NVIDIA Quadro P400 1
st
and 2
nd
GFX •
NVIDIA Quadro P4000 1st and 2nd GFX
•
NVIDIA Quadro P5000 1st and 2nd GFX
•
NVIDIA Quadro P600 1st and 2nd GFX
•
NVIDIA Quadro P6000 1st and 2nd GFX
•
System RAM
Minimum (GB)
8GB
Maximum (GB)
192GB
Hard Disks
All supported SATA Disk Drives (4TB or less only)
•
All supported SATA Solid State Drives
•
SAS Disk Drives
(4)
All supported USB Drive Keys
• (2)
All supported HP Z Turbo Drive and Z Turbo QuadPro PCIe-attached storage (1 TB/module or less only)
• (5)
Network Cards
Intel® Ethernet I210-T1 PCIe NIC
•
Intel I350-T2 Dual-Port and I350-T4 Quad-Port 1GbE PCIe NIC
•
HP Dual Port 10GBase-T NIC Module
•
Intel X550-T2 Dual-Port 10GbE NIC Module
•
Onboard Components
Integrated Intel SATA and sSATA Controllers
•
Wired LAN - Intel i219-LM Gigabit Ethernet, X722 1Gb Module
•
Onboard Audio (Realtek ALC221 codec)
•
Onboard SATA RAID 0, 1, 5 and 10
•
Removable CD/DVD Media
9.5mm DVD-ROM SATA 1st ODD
•
DVD-Writer 9.5mm 1st ODD
•
9.5mm Blu-ray Writer SATA 1st ODD
•
Input/Output Devices (no Spaceball support)
HP USB Optical Mouse
• (2)
HP USB Business Slim Keyboard
• (2)
TPM Module/Smart Card
• (6)
All supported HP Printers
•
All Supported Monitors
•
Footnote (1) – Only US English localization. Other localizations may be added later as testing is completed.
Footnote (2) – USB support in Z8/Z6/Z4 G4 is not native to Windows 7. A USB driver must be installed.
Footnote (3) – Up to 2 graphics cards of the same type are supported.
Footnote (4) – SAS disk drives and controllers have not been tested with Windows 7.
Footnote (5) – NVMe storage is not native to Windows 7. An NVMe driver must be installed. The Samsung NVMe driver is
supported.
Footnote (6) – TPM 2.0 is not native to Windows 7. Microsoft provides support for TPM 2.0 through a Hotfix.
Windows 7 64-bit Hardware Matrix for HP Workstations
HP Z6 G4 Workstation
Product Items/Features
(Blank box or unlisted component has not been tested by HP)
Windows 7 64-bit
HP Workstation Base System
Base system includes: Chassis, System Board, Power Supply, etc.
•
HP Localization Kit
(1)
Supported Processors
•
Front I/O Module
Base Front I/O module
• (2)
Premium Front I/O module
• (2)
Graphics Card (Video Card)
• (3)
AMD FirePro W2100 1st and 2nd GFX
•
AMD Radeon Pro WX 3100 1st and 2nd GFX
•
AMD Radeon Pro WX 4100 1st and 2nd GFX
•
AMD Radeon Pro WX 7100 1st and 2nd GFX
•
Intel X550-T2 Dual-Port 10GbE NIC
•
NVIDIA Quadro P1000 1st and 2nd GFX
•
NVIDIA Quadro P2000 1st and 2nd GFX
•
NVIDIA Quadro P400 1st and 2nd GFX
•
NVIDIA Quadro P4000 1st and 2nd GFX
•
NVIDIA Quadro P5000 1st and 2nd GFX
•
NVIDIA Quadro P600 1st and 2nd GFX
•
NVIDIA Quadro P6000 1st and 2nd GFX
•
System RAM
Minimum (GB)
8GB
Maximum (GB)
192GB
Hard Disks
All supported SATA Disk Drives (4TB or less only)
•
All supported SATA Solid State Drives
•
SAS Disk Drives
(4)
All supported USB Drive Keys
• (2)
All supported HP Z Turbo Drive and Z Turbo QuadPro PCIe-attached storage (1 TB/module or less only)
• (5)
Network Cards
Intel Ethernet I210-T1 PCIe NIC
•
Intel I350-T2 Dual-Port and I350-T4 Quad-Port 1GbE PCIe NIC
•
HP Dual Port 10GBase-T NIC Module
•
Intel X550-T2 Dual-Port 10GbE NIC
•
Onboard Components
Integrated Intel sSATA Controller
•
Wired LAN - Intel i219-LM Gigabit Ethernet, X722 1Gb Module
•
Onboard Audio (Realtek ALC221 codec)
•
Onboard sSATA RAID 0, 1, 5 and 10
•
Removable CD/DVD Media
9.5mm DVD-ROM SATA 1st ODD
•
DVD-Writer 9.5mm 1st ODD
•
9.5mm Blu-ray Writer SATA 1st ODD
•
Input/Output Devices (no Spaceball support)
HP USB Optical Mouse
• (2)
HP USB Business Slim Keyboard
• (2)
TPM Module/ Smart Card
• (6)
All supported HP Printers
•
All Supported Monitors
•
Footnote (1) – Only US English localization. Other localizations may be added later as testing is completed.
Footnote (2) – USB support in Z8/Z6/Z4 G4 is not native to Windows 7. A USB driver must be installed.
Footnote (3) – Up to 2 graphics cards of the same type are supported.
Footnote (4) – SAS disk drives and controllers have not been tested with Windows 7.
Footnote (5) – NVMe storage is not native to Windows 7. An NVMe driver must be installed. The Samsung NVMe driver is
supported.
Footnote (6) – TPM 2.0 is not native to Windows 7. Microsoft provides support for TPM 2.0 through a Hotfix.
Footnote (1) – Only US English localization. Other localizations may be added later as testing is completed.
Footnote (2) – USB support in Z8/Z6/Z4 G4 is not native to Windows 7. A USB driver must be installed.
Footnote (3) – Up to 2 graphics cards of the same type are supported where noted.
Footnote (4) – SAS disk drives and controllers have not been tested with Windows 7.
Footnote (5) – NVMe storage is not native to Windows 7. An NVMe driver must be installed. The Samsung NVMe driver is
supported.
Footnote (6) – TPM 2.0 is not native to Windows 7. Microsoft provides support for TPM 2.0 through a Hotfix.
Windows 7 64-bit Hardware Matrix for HP Workstations
HP Z4 G4 Workstation
Product Items/Features
(Blank box or unlisted component has not been tested by HP)
Windows 7 64-bit
HP Workstation Base System
Base system includes: Chassis, System Board, Power Supply, etc.
•
HP Localization Kit
(1)
Supported Processors
•
Front I/O Module
Base Front I/O module
• (2)
Premium Front I/O module
• (2)
Graphics Card (Video Card)
• (3)
AMD FirePro W2100 1st and 2nd GFX
•
AMD Radeon Pro WX 3100 1st and 2nd GFX
•
AMD Radeon Pro WX 4100 1st and 2nd GFX
•
AMD Radeon Pro WX 7100 1st and 2nd GFX
•
NVIDIA Quadro P1000 1st and 2nd GFX
•
NVIDIA Quadro P2000 1st and 2nd GFX
•
NVIDIA Quadro P400 1st and 2nd GFX
•
NVIDIA Quadro P4000 1st and 2nd GFX
•
NVIDIA Quadro P5000 1st GFX only
•
NVIDIA Quadro P600 1
st
and 2
nd
GFX •
NVIDIA Quadro P6000 1st GFX only
•
System RAM
Minimum (GB)
8GB
Maximum (GB)
192GB
Hard Disks
All supported SATA Disk Drives (4TB or less only)
•
All supported SATA Solid State Drives
•
SAS Disk Drives
(4)
All supported USB Drive Keys
• (2)
All supported HP Z Turbo Drive and Z Turbo QuadPro PCIe-attached storage (1 TB/module or less only)
• (5)
Network Cards
Intel Ethernet I210-T1 PCIe NIC
•
Intel I350-T2 Dual-Port and I350-T4 Quad-Port 1GbE PCIe NIC
•
Intel X550-T2 Dual-Port 10Gbe NIC
•
Onboard Components
Integrated Intel SATA Controller
•
Wired LAN - Intel i219-LM and i210AT Gigabit Ethernet
•
Onboard Audio (Realtek ALC221 codec)
•
Onboard SATA RAID 0, 1, 5 and 10
•
Removable CD/DVD Media
9.5mm DVD-ROM SATA 1st ODD
•
DVD-Writer 9.5mm 1st ODD
•
9.5mm Blu-ray Writer SATA 1st ODD
•
Input/Output Devices (no Spaceball support)
HP USB Optical Mouse
• (2)
HP USB Business Slim Keyboard
• (2)
TPM Module/ Smart Card
•(6)
All supported HP Printers
•
All Supported Monitors
•
