User Manual.pdf
Your HTC Phone
User guide
HTC CONFIDENTIAL
Only for certification review
Unboxing
HTC Phone
Front panel
1. Dual speakers
2. nano SIM card tray with eject hole
3. USB connector
4. 3.5mm headset jack
5. VOLUME
6. microSD™ card tray with eject hole
7. Proximity sensor
8. Front camera
9. POWER and IR SENSOR
10. Notification LED
§HTC Phone is available in either a 3G-only or 3G-and-LTE version, depending on
what's supported by the phone you purchased and your mobile operator. You
need an LTE plan to use your operator's 4G/LTE network for voice calls and data
services. Check with your operator for details.
§If you want to use a case, please don't cover and block the proximity sensor.
Purchase a case designed for HTC Phone.
7 Unboxing
HTC CONFIDENTIAL
Only for certification review
Back panel
1. Camera
2. LED flash
nano SIM card
HTC Phone uses a nano SIM card. The nano SIM card contains your phone number,
service details, and memory for storing phonebook contacts and/or text messages.
Inserting the nano SIM card
Use a standard nano SIM card only. Inserting a modified card may cause the card to
not fit properly or damage the card slot.
1. Hold the phone face up.
2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject
hole next to the nano SIM card tray slot.
3. Push the tip all the way into the hole until the nano SIM card tray ejects.
8 Unboxing
HTC CONFIDENTIAL
Only for certification review
4. Pull the nano SIM card tray out, and place the nano SIM card (contacts facing
down) into the tray.
5. Insert the nano SIM card tray back into the slot.
Removing the nano SIM card
Make sure to switch off HTC Phone before removing your nano SIM card.
1. Hold the phone face up and the top panel facing you.
2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject
hole next to the nano SIM card tray slot.
3. Push the tip all the way into the hole until the nano SIM card tray ejects.
4. Pull the nano SIM card tray out, and remove the nano SIM card.
After removing the nano SIM card, make sure that you insert the empty nano SIM card
tray back into the slot.
9 Unboxing
HTC CONFIDENTIAL
Only for certification review
Storage card
Use a storage card to store your photos, videos, and music.
Inserting the microSD card
1. Hold the phone face up.
2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject
hole next to the microSD card tray slot.
3. Push the tip all the way into the hole until the microSD card tray ejects.
4. Pull the microSD card tray out, and place the microSD card (contacts facing
down) into the tray.
5. Insert the microSD card tray back into the slot.
Unmounting the storage card
When you need to remove the storage card while HTC Phone is on, unmount the
storage card first to prevent corrupting or damaging the files in the storage card.
1. Go to Settings, and then tap Storage.
2. Tap Unmount SD card.
10 Unboxing
HTC CONFIDENTIAL
Only for certification review
Removing the microSD card
Make sure to unmount your microSD card before removing it.
1. Hold the phone face up and the top panel facing you.
2. Insert the tip of the tray eject tool (or a small bent paperclip) into the tray eject
hole next to the microSD card tray slot.
3. Push the tip all the way into the hole until the microSD card tray ejects.
4. Pull the microSD card tray out, and remove the microSD card.
After removing the microSD card, make sure that you insert the empty microSD card
tray back into the slot.
11 Unboxing
HTC CONFIDENTIAL
Only for certification review
Charging the battery
Before you turn on and start using HTC Phone, it is recommended that you charge the
battery.
Use only the adapter and the USB cable that came with HTC Phone to charge the
battery. When the battery power is too low, make sure to use the power adapter to
charge, not the USB cable connection with your computer.
1. Insert the small end of the USB cable into the USB connector.
2. Insert the other end of the USB cable into the power adapter.
3. Plug in the power adapter to an electrical outlet to start charging the battery.
§As a safety precaution, the battery may stop charging to avoid overheating.
§When you're using the Internet and charging the battery, HTC Phone may become
warmer. This is normal.
§To conserve energy, unplug the power adapter from the electrical outlet after you
finish charging.
Switching the power on or off
Switching the power on
Press the POWER button until HTC Phone vibrates.
When you turn on HTC Phone for the first time, you’ll need to set it up.
Switching the power off
1. If the display is off, press the POWER button to turn it back on. If you've set up
a lock screen, you need to unlock it.
2. Press and hold the POWER button for a few seconds.
3. Tap Power off on the options menu.
12 Unboxing
HTC CONFIDENTIAL
Only for certification review
Want some quick guidance on your phone?
Check out the friendly walkthroughs and the FAQs in the Tips & Help app to learn
how to use your phone.
§When you see a Tips & Help tile in HTC BlinkFeed™, just tap the tile to know
more about the tip.
§To open Tips & Help from the Home screen, tap > Tips & Help.
You can then browse by subject matter and topic. Or tap , and then enter
what you want to search for.
13 Unboxing
HTC CONFIDENTIAL
Only for certification review
Phone setup and transfer
Transferring content from an Android phone
On your old Android™ phone, download the HTC Transfer Tool and use it to transfer
your content to your new HTC phone. The types of locally stored content on your old
phone that the tool can transfer include contacts, messages, calendar events, web
bookmarks, music, photos, and videos. Some settings can also be transferred.
§You need Android version 2.2 or later to use the HTC Transfer Tool on your old
phone.
§If your old phone has Android version 2.1 or an earlier version, you need to use
Bluetooth® transfer. For details, see Transferring contacts from your old phone
through Bluetooth on page 15.
1. Do one of the following:
§If you're setting up your new HTC phone for the first time, choose to
transfer content, and then select Transfer from old phone on the Set up
phone screen.
§Go to Settings, and then tap Get content from another phone.
2. Choose whether to transfer from an old HTC Android phone or other Android
phone.
3. Tap Full transfer.
4. Follow the steps shown on your new phone to download the HTC Transfer Tool
from Google Play™ to your old phone, install it, and open the tool.
5. When you see a PIN on your old phone, make sure the same PIN also appears
on your new phone before you continue.
If the PIN code doesn't appear, this may mean that your old phone is unable to
connect to your new phone. If this happens, tap Try another transfer method on
your new phone to use Bluetooth for transferring contacts from your old phone.
6. On your old phone, choose the types of content you want to transfer, and then
tap Transfer.
7. Wait for the transfer to finish.
8. Tap Done on both phones.
14 Phone setup and transfer
HTC CONFIDENTIAL
Only for certification review
Transferring content from an iPhone
If you have an iPhone, it's fast and easy to transfer your contacts, messages, and other
content when you use HTC Sync Manager.
To find out how, see .
If you only need to migrate your contacts, you can also use Bluetooth transfer. For
details, see Transferring contacts from your old phone through Bluetooth on page
15.
Transferring contacts from your old phone
through Bluetooth
Use Bluetooth to transfer contacts from an iPhone, a phone that has Android version
2.1 (or earlier version), or other types of phones. Depending on the capabilities of your
old phone, you may be able to transfer not only contacts but also other data such as
calendar events and text messages to your new HTC phone.
Use HTC Sync Manager to transfer more types of content from an iPhone.
1. Do one of the following:
§If you're setting up your new phone for the first time, choose to transfer
content, and then select Transfer from old phone on the Set up phone
screen.
§Go to Settings, and then tap Get content from another phone.
2. Choose whether to transfer from an Android phone, iPhone, or other phone
types. If you chose to transfer from an Android phone, tap Quick transfer.
3. Choose your old phone's name and model.
4. On your old phone, turn Bluetooth on and set it to discoverable mode.
5. Follow the onscreen instructions on your old and new phones to pair them and
start the data transfer.
15 Phone setup and transfer
HTC CONFIDENTIAL
Only for certification review
Getting contacts and other content into
HTC Phone
Aside from the HTC Transfer Tool, there are other ways you can add contacts and
other content to HTC Phone.
Sync with your
computer
Use HTC Sync Manager to sync contacts, documents, playlists,
and more between HTC Phone and your computer running a
Windows® or Mac OS operating system.
You can also use it to transfer contacts, messages, and other
content from an iPhone to your computer, and then to your
HTC Phone.
Google® Account Google contacts are imported to HTC Phone after you sign in to
your Google Account. You can also create more Google
contacts right from HTC Phone.
Social network
accounts
Log in to your favorite social networks to sync contact
information from them.
Microsoft®
Exchange
ActiveSync®
HTC Phone syncs your work contacts from the Microsoft
Exchange ActiveSync Server in your workplace.
Phone contacts You can create contacts locally on HTC Phone, if you don't prefer
to store them on your online accounts.
nano SIM card Copy all your nano SIM contacts to HTC Phone.
Transferring photos, videos, and music
between your phone and computer
There are two ways you can transfer your media from or to your computer.
§Connect HTC Phone to your computer. Your computer will recognize it just like
any removable USB drive, and you can copy your media between them.
§Download and use the HTC Sync Manager software on your computer. You can
set it up to automatically get music, photos, and videos off HTC Phone to your
computer. You can also sync playlists from your computer to the phone.
If you have an iPhone, you can even connect it and transfer camera roll photos
to your computer. Then reconnect HTC Phone and copy them over.
Tired of keeping copies of your media in several places? Use online storage services
to put your media in one place so you can manage them anywhere — on your
computer, HTC Phone, and other mobile devices.
Go to Settings, and then tap Accounts & sync > to check first what online storage
accounts are available on HTC Phone and sign in to the one you want to use. Use the
Gallery app to access media in your online storage.
16 Phone setup and transfer
