User manual 2
Safety and
regulatory guide
The health and safety warnings in this guide are periodically
updated for accuracy and completeness.
Check www.htcvive.com for the latest version.
2
Important
ImportantImportant
Important
Safety Informat
Safety InformatSafety Informat
Safety Information
ion ion
ion –
––
–
Read Before Use
Read Before UseRead Before Use
Read Before Use
Read the following warnings and information before use of the
Read the following warnings and information before use of the Read the following warnings and information before use of the
Read the following warnings and information before use of the
product and follow all product safety and operating instructions.
product and follow all product safety and operating instructions. product and follow all product safety and operating instructions.
product and follow all product safety and operating instructions.
Failure to do so may cause bodily injury, electric shock, fire, and
Failure to do so may cause bodily injury, electric shock, fire, and Failure to do so may cause bodily injury, electric shock, fire, and
Failure to do so may cause bodily injury, electric shock, fire, and
other damag
other damagother damag
other damage.
e.e.
e.
Ensure You Are Able to
Ensure You Are Able to Ensure You Are Able to
Ensure You Are Able to Safely Use the Prodcut
Safely Use the ProdcutSafely Use the Prodcut
Safely Use the Prodcut
Consult your doctor before using the product if you have pre-existing
serious medical conditions (such as a heart ailment), conditions that
affect your ability to safely perform physical activities, psychiatric
conditions (such as anxiety disorders or post-traumatic stress disorder),
or if you are pregnant or elderly.
Do not use the product if you are sick, fatigued, under the influence of
intoxicants/drugs, or are not feeling generally well, as it may exacerbate
your condition.
En
EnEn
Ensure the Area Around You is Safe for Use of the Product
sure the Area Around You is Safe for Use of the Productsure the Area Around You is Safe for Use of the Product
sure the Area Around You is Safe for Use of the Product
While wearing the product’s headset you are blind to the world around
you. The image displayed in the headset will not match the real world.
Always use the product in a clear and safe area. Do not rely on the
product’s chaperone system for protection.
Do not use near stairways,
large windows, heat sources, or outdoors. Clear the play area of people,
furniture, and other things that may be obstacles or block you from
freely moving around. For example, if a pet comes into the room while
you are using the product, you likely will not be aware of the
pet’s
presence and you could trip over your pet while moving in the virtual
reality environment.
It is recommended that the product be used only while under the
supervision of another person who is ready to warn of hazards that may
arise while the product is being used. Examples of hazards that could
arise include, but are not limited to, tangling of a cable in a manner that
presents a tripping hazard, pets entering the area where the product is
being used, and the user walking too close to a wall or another hazard).
3
Be Aware of the Cable and Connections
Be Aware of the Cable and ConnectionsBe Aware of the Cable and Connections
Be Aware of the Cable and Connections
Keep in mind the location of the cable and connections running from
the headset so that you are not likely to trip over or pull on them while
moving around or walking around the play area. Move your feet slowly
and carefully to avoid tripping, including on the cable. Make sure to
maintain good footing. Tripping over the cable or contacting obstacles
could cause injury or damage.
Take Care of the Controllers
Take Care of the ControllersTake Care of the Controllers
Take Care of the Controllers
While using the hand controllers, always check that you have sufficient
overhead and surrounding clearance to allow you to fully extend your
arms outward and upwards. Hitting persons or objects may cause
injury or damage. Hold the controllers firmly and always use the wrist
straps. If released while using, the controller may cause injury or
damage.
Photosensitive Seizures
Photosensitive SeizuresPhotosensitive Seizures
Photosensitive Seizures
Like other products that produce visual effects (including light flashes),
the product may trigger epileptic seizures, seizures, fainting, or severe
dizziness even in people who have no history of these conditions. If you
have a previous history of epilepsy or seizures, loss of awareness, or
other symptoms linked to an epileptic condition, consult your doctor
before using the product. To reduce the likelihood of a seizure do not
use the product if you are tired or need sleep.
Repetitive Stress Injuries
Repetitive Stress InjuriesRepetitive Stress Injuries
Repetitive Stress Injuries
Operate the product in a comfortable posture. Do not grip the product
too tightly. Press the buttons lightly. If you have tingling, numbness,
stiffness, throbbing, or other discomfort, immediately stop using the
product and consult your doctor.
Physical
PhysicalPhysical
Physical
and P
and Pand P
and Psychological
sychological sychological
sychological E
EE
Effects
ffectsffects
ffects
Content viewed using the product can be intense, immersive, and
appear very life-like and may cause your brain and body to react
4
accordingly. Certain types of content (e.g. violent, scary, emotional, or
adrenaline-based content) could trigger increased heart rate, spikes in
blood pressure, panic attacks, anxiety, PTSD, fainting, and other adverse
effects. If you have a history of negative physical or psychological
reactions to certain real life circumstances, avoid using the product to
view similar content.
Similarly, it is important to remember that simulated objects, such as
furniture, that may be encountered while using the product do not exist
in the real world, and injuries may result when interacting with those
simulated objects as if they were real, for example, by attempting to sit
down on a virtual chair.
Hearing Loss
Hearing Loss Hearing Loss
Hearing Loss
Do not use the earphones at a high volume for prolonged periods of
time, or permanent hearing loss may occur.
Radio Frequency Interference
Radio Frequency Interference Radio Frequency Interference
Radio Frequency Interference
The product can emit radio waves that can interfere with the
operation of nearby electronic devices. If you have a cardiac
pacemaker or other implanted medical device, do not use the
product until you have consulted with your doctor or the
manufacturer of your medical device.
To minimize radio frequency
interference, use only original manufacturer-approved accessories, or
accessories that do not contain any metal. Use of non-original
manufacturer-approved accessories may violate your local radio
frequency exposure guidelines and should be avoided.
Avoid Overuse
Avoid Overuse Avoid Overuse
Avoid Overuse
Prolonged, uninterrupted use of the product should be avoided. It may
negatively impact hand-eye coordination, balance, and/or cause other
negative effects.
While using the product frequently and for
prolonged periods of time, you may experience tiredness or soreness in
your muscles, joints, or other body parts.
Take regular breaks from
5
using the product. The length and frequency of necessary breaks may
vary from person to person.
Stop Using If You Experience Any Discomfort
Stop Using If You Experience Any Discomfort Stop Using If You Experience Any Discomfort
Stop Using If You Experience Any Discomfort
Stop using the product and consult your doctor if you experience any of
the following symptoms:
Seizures, loss of awareness, convulsions, involuntary movements,
dizziness, disorientation, nausea, lightheadedness, drowsiness, or
fatigue;
Eye pain or discomfort, eyestrain, eye twitching, or vision
abnormalities (such as altered, blurred, or double vision);
Excessive sweating, increased salivation, impaired sense of balance,
impaired hand-eye coordination, or other symptoms similar to
motion sickness.
Until fully recovered from these symptoms, do not drive, operate
machinery, or take part in activities that may have potentially serious
consequences.
Before resuming use of the product, make sure that it is properly
configured.
The type of content you were using may cause your symptoms.
Continuing to use such content may make you prone to experiencing
the same symptoms.
Use by Children
Use by Children Use by Children
Use by Children
The product was not designed to be used by children. Do not leave the
product within the reach of young children or allow them to use or play
with it. They could hurt themselves or others, or could accidentally
damage the product.
The product may contain small parts with sharp edges that may cause
an injury or which could become detached and create a choking hazard
6
for young children. Consult your doctor immediately if any parts of the
product or accessories are swallowed.
If older children are permitted to use the product, then adults should
monitor them closely for any negative effects during and after their use
of the product. Do not allow older children to use the product if
negative effects are observed. Adults should also ensure that older
children avoid prolonged use of the product.
General Use and Maintenance Instructions
General Use and Maintenance InstructionsGeneral Use and Maintenance Instructions
General Use and Maintenance Instructions
Electrical safety
This product is intended for use when supplied with power from the
designated batteries or power supply units. Other usage may be
dangerous and will invalidate any approval given to this product.
Safety precautions for proper grounding installation
CAUTION:
Connecting to improperly grounded equipment can result in
electrical damage to the product.
This product is equipped with cables for connecting with a desktop
computer. Be sure your computer is properly grounded (earthed)
before connecting the product to the computer. The power supply cord
of a desktop computer has an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet
which is properly installed and grounded in accordance with all local
codes and ordinances.
Safety precautions for power supply unit
Use the correct external power source
•
A product should be operated only from the type of power
source indicated on the electrical ratings label. If you are not
sure of the type of power source required, consult your
authorized service provider or local power company. For a
product that operates from battery power or other sources,
7
refer to the operating instructions that are included with the
product.
•
This product should be operated only with the following
designated power supply unit(s).
Vive headset AC adapter:
HTC, Model TC NE18W-US
Vive controller AC adapter:
HTC, Model TC NE5W-US
Base stations AC adapter:
HTC, Model TC NE30W-US
Handle battery packs carefully
The product controller contains a lithium-ion polymer or lithium-ion
battery. There is a risk of fire and burns if the battery pack is handled
improperly.
Vive controller WARNING: To reduce risk of fire or burns,
do not disassemble, crush, puncture, short external
contacts or circuits, expose to temperature above 60° C
(140° F), or dispose of in fire or water. Recycle or dispose
of used batteries according to the local regulations or
reference guide supplied with your product.
Do not expose to liquid.
Keep batteries out of the reach of children.
Avoid dropping the product headset, controllers, or base stations.
If dropped, especially on a hard surface, and the user suspects
damage, take it to a service center for inspection.
If the battery leaks:
Do not allow the leaking fluid to come in contact with skin or clothing.
If already in contact, flush the affected area immediately with clean
water and seek medical advice.
Do not allow the leaking fluid to come in contact with eyes. If already
in contact, DO NOT rub; rinse with clean water immediately and seek
medical advice.
Take extra precautions to keep a leaking battery away from fire as there
is a danger of ignition or explosion.
8
Safety precautions for direct sunlight
Keep the product away from excessive moisture and extreme
temperatures. Do not leave the product in places such as on a car
dashboard, window sill, or behind a glass that is exposed to direct
sunlight or strong ultraviolet light for extended periods of time. The
headset contains lenses which may focus and intensify bright light
sources, causing damage to the hardware.
Prevention of hearing loss
CAUTION: Permanent hearing loss may occur if Vive headset
earphones are used at high volume for prolonged periods of
time.
Vive headset have been tested to comply with the Sound Pressure Level
requirement laid down in the applicable EN 50332-1and/or EN 50332-2
standards.
General precautions
Protect the product.
•
When installing base stations, avoid using unstable mounting
accessories or surfaces that are prone to vibration, movement
or chance of impact.
•
A secure structure must support the weight or load of the base
stations.
•
Do not install near a heater, fireplace, direct sunlight, air
conditioning unit or other source of direct energy.
•
Do not attempt to pry open the base stations as it could result
in injury.
•
Use only approved accessories.
•
Do not connect with incompatible products or accessories.
•
Do not attempt to disassemble this product or its accessories.
•
Use only qualified personnel to service or repair this product
and its accessories.
•
Always treat the product and its accessories with care and
keep them in a clean and dust-free place.
•
Do not expose the product or its accessories to open flames or
9
lit smoking products.
•
Do not drop, throw or try to bend the product or its
accessories.
•
Do not use harsh chemicals, cleaning solvents, liquid cleansers
or aerosols to clean the product or its accessories.
•
Do not paint the product or its accessories.
•
Store the product and its accessories at temperatures between
0°C to 40°C
•
Please check local regulations for disposal of electronic
products
Damage requiring service.
Contact an authorized service technician or provider under the
following conditions:
The product has been damaged by exposure to liquid, dropped,
subject to impact or damaged.
There are noticeable signs of overheating.
The product does not operate normally when you follow the
operating instructions.
Avoid hot areas.
The product should be placed away from heat sources such as
radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
Avoid using the product after a dramatic change in temperature.
When you move the product between environments with very
different temperature and/or humidity ranges, condensation may
form on or within the product. To avoid damaging the product, allow
sufficient time for the moisture to evaporate before using the product.
NOTICE: When taking the product from low-temperature conditions
into a warmer environment or from high-temperature conditions into a
cooler environment, allow the product to acclimate to room
temperature before turning on power.
Avoid pushing objects into the product.
Never push objects of any kind into cabinet slots or other openings in
the product. Slots and openings are provided for ventilation. These
openings must not be blocked or covered.
Adjust the volume.
Turn down the volume before using headphones or other audio
devices.
10
Cleaning the product.
Unplug the product from its power source before cleaning. Use a
damp cloth for cleaning, but NEVER use water to clean the product.
Clean and dry skin that regularly comes in contact with the headset. If
there is any itching, eczema, swelling, irritation of the skin, or you
experience any discomfort, please discontinue use and consult your
physician.
About Vive headset regulatory agency identifications
For regulatory identification purposes, your product is assigned a model
number of
0PJT100
.
Your product’s FCC ID is
NM80PJT100
. This FCC ID can also be found
printed on the Vive headset.
To ensure continued reliable and safe operation of your device, use only
the accessories listed below with your
0PJT100
.
NOTE: This product is intended for use with a certified Class 2 Limited
Power Source, rated 12 Volts DC, maximum 1.5 Amp power supply unit.
About Vive controller regulatory agency
identifications
For regulatory identification purposes, your product is assigned a model
number of
2PR7100
.
Your product’s FCC ID is
NM82PR7100
. This FCC ID can also be found
printed on the Vive controller.
To ensure continued reliable and safe operation of your device, use only
the accessories listed below with your
2PR7100
:
The Battery Pack has been assigned a model number of
B0PLH100
.
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE THE
DEVICE OUT OF THE BOX.
NOTE:
This product is intended for use with a certified Class 2 Limited
Power Source, rated 5 Volts DC, maximum 1 Amp power supply unit.
R
RR
RF exposure:
F exposure:F exposure:
F exposure:
To comply with the IC RF exposure compliance requirements, this device and
its antenna must not be co-located or operating in conjunction with any other
antenna or transmitter.
11
Pour se conformer aux exigences de conformité RF canadienne l'exposition,
cet appareil et son antenne ne doivent pas être co-localisés ou fonctionnant
en conjonction avec une autre antenne ou transmetteur.
About Base station regulatory agency identifications
For regulatory identification purposes, your product is assigned a model
number of
2PR8100
.
Your product’s FCC ID is
NM82PR8100
. This FCC ID can also be found
printed on the Base station.
To ensure continued reliable and safe operation of your device, use only
the accessories listed below with your
2PR8100
:
NOTE:
This product is intended for use with a certified Class 2 Limited
Power Source, rated 12 Volts DC, maximum 2.5 Amp power supply unit.
This is a Class 1 laser device.
This product contains Class 3B laser, which can produce hazardous level
of Class 3B and 4 laser radiations. However, the design of this product
incorporates optics, a protective housing and scanning safeguard such
that there is no access to level of laser radiation above Class 1. Only
trained factory service personnel should open the protective housing.
CAUTION- Class 3B LASER RADIATION WHEN OPEN
AVOID EXPOSURE TO THE BEAM.
The laser beams are lo
cated inside the
front face of Base station as indicated at
right.
CAUTION:
Use of controls or adjustments
or performance of procedures other than
those specified herein may result in
hazardous radiation exposure.
12
Status light
Protective housing
Laser beams
Location of the labels on the product:
If this product is not working properly, please call
HTC customer service
for instruction.
CAUTION:
The product is not intended to be serviced except by HTC or
our authorized service providers.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your
body.
13
IC RF Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between
the radiator & your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or
transmitter.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux
rayonnements IC établies pour un environnement non contrôlé.
Cet équipement doit être installé et utilisé avec un minimum de
20 cm de distance entre la source de rayonnement et votre
corps.
About Link box regulatory agency identifications
For regulatory identification purposes, your product is assigned a model
number of
2PU6100
.
Your product’s FCC ID is
NM82PU6100
. This FCC ID can also be found
printed on the Link box.
To ensure continued reliable and safe operation of your device, use only
the accessories listed below with your
2PU6100
:
NOTE:
This product is intended for use with a certified Class 2 Limited
Power Source, rated 12 Volts DC, maximum 1.5 Amp power supply unit.
FCC RF Radiation Exposure Statement:
1. This Transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
2. This equipment complies with FCC RF radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum
distance of 20 centimeters between the radiator and your
body.
14
IC RF Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with minimum distance 20cm between
the radiator & your body. This transmitter must not be co-located
or operating in conjunction with any other antenna or
transmitter.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux
rayonnements IC établies pour un environnement non contrôlé.
Cet équipement doit être installé et utilisé avec un minimum de
20 cm de distance entre la source de rayonnement et votre
corps.
F
ederal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio or television technician for
help.
15
FCC Caution:
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to
operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
Industry Canada Statement
This device complies with Industry Canada license-exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation est
autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas
produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter
tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement."
European Union notice
This device complies with the R&TTE Directive (1999/5/EC) issued by
the Commission of the European Community.
We declare under our sole responsibility that our product and in
combination with our accessories, to which this declaration relates is in
conformity with the appropriate standards EN 55022/24, , EN 301 489-1
-17, EN62471, EN 60950-1
，
EN 62479 EN 300 328 following the
provisions of, radio equipment and telecommunication terminal
equipment directive 1999/5/EC.
16
WEEE notice
The Directive on Waste Electrical and Electronic Equipment (WEEE),
which entered into force as European law on 13th February 2003,
resulted in a major change in the treatment of electrical equipment at
end-of-life.
The purpose of this Directive is, as a first priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other forms
of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or on its
box indicates that this product must not be disposed of or
dumped with your other household waste. You are liable to
dispose of all your electronic or electrical waste equipment
by relocating over to the specified collection point for
recycling of such hazardous waste. Isolated collection and
proper recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help
conserving natural resources. Moreover, proper recycling of
the electronic and electrical waste equipment will ensure
safety of human health and environment. For more
information about electronic and electrical waste equipment
disposal, recovery, and collection points, please contact
your local city center, household waste disposal service,
shop from where you purchased the equipment, or
manufacturer of the equipment.
RoHS compliance
This product is in compliance with Directive 2011/65/EU of the
European Parliament and of the Council of 8 June 2011, on the restriction
of the use of certain hazardous substances in electrical and electronic
equipment (RoHS) and its amendments.
CEC Appliance Efficiency Compliance
The BC logo (shown at the left) indicates that this product
complies with the California Energy Commission (CEC)
energy efficiency standards for battery charger systems set
17
forth at California Code of Regulations Title 20, Sections 1601 through
1608.
Proprietary Notice
© 2015 HTC Corporation. All rights reserved. HTC, the HTC logo, and all
other HTC product and service names are the trademarks or registered
trademarks in the U.S. and/or other countries of HTC Corporation and
its affiliates.
18
91H0XXXX-XXM Rev.A
htc.com
