User manual 1
Trademarks and copyrights
© 2013 HTC Corporation. All rights reserved. The HTC logo
and the HTC quietly brilliant logo are trademarks of HTC
Corporation.
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc.
All other trademarks included herein are the property of
their respective owners.
HTC shall not be liable for technical or editorial errors
or omissions contained herein, nor for incidental or
consequential damages resulting from furnishing this
material. The information is provided “as is” without
warranty of any kind and is subject to change without
notice. HTC also reserves the right to revise the content of
this document at any time without prior notice.
No part of this document may be reproduced or
transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording or storing
in a retrieval system, or translated into any language in any
form without prior written permission of HTC.
HTC Confidential
for Certification
HTC Confidential
for Certification
3
English
About your HTC Mini+
Your HTC Mini+ is a convenient way for you to control your
phone from a distance. You can handle incoming calls,
make calls, read text messages, view calendar events, find
your phone, and more.
earpiece end call/back
laser pointer keypad
LED key lock
volume USB connector
navigation/enter mic
call
HTC Confidential
for Certification
HTC Confidential
for Certification
4
English
Using the navigation controls
The navigation controls on the HTC
Mini+ are used to browse and select
items in the menu. They are also used to
remotely control your phone’s camera,
media player, and more.
The navigation controls consist of a
4-way navigation ring (up, down, left,
and right) and an enter button.
Charging your HTC Mini+
Before using your HTC Mini+ for the first time, you should
give it a full charge. Charging time depends on the power
source. Use an ocial HTC AC adaptor for a faster charging
time.
To charge your HTC Mini+, connect one end of the USB
cable to the USB connector on the HTC Mini+, and the
other end to the power source.
Red LED charging
Green LED fully charged
Important:
The HTC Mini+ will not charge if its battery temperature is greater than
50°C or less than 0°C.
Checking the battery level
When your HTC Mini+ is on and not in sleep mode, you’ll
see a battery status indicator at the top of the display.
0% – 24%
25% – 49%
50% – 74%
75% – 99%
100%
4-way navigation
enter
HTC Confidential
for Certification
HTC Confidential
for Certification
5
English
Turning your HTC Mini+ on or o
To turn your HTC Mini+ on, press .
To turn your HTC Mini+ o, press and hold .
Pairing your HTC Mini+ via NFC
1. Turn your HTC Mini+ on, and press and hold .
2. On your phone, turn NFC on.
3. Place your HTC Mini+ back-to-back with your phone.
4. Tap Ye s when you’re prompted to pair your HTC Mini+.
Pairing your HTC Mini+ via Bluetooth
1. Turn your HTC Mini+ on. Then press and hold to make
your HTC Mini+ discoverable.
2. On your phone, turn Bluetooth on and then tap
Bluetooth to see the list of available Bluetooth devices.
3. Tap HTC Mini+ to pair.
When pairing is successful, you’ll see in the status bar
and app icons on your HTC Mini+.
You only need to pair HTC Mini+ to your phone once. The
next time you turn on your HTC Mini+, it automatically
reconnects to your phone.
Pairing your HTC Mini+ with your PC
Your HTC Mini+ can also be paired to a Windows® 8 (or 7)
PC that has Bluetooth® turned on.
1. On your PC, turn Bluetooth on.
1. Turn your HTC Mini+ on. Then press and hold to make
your HTC Mini+ discoverable.
2. On your PC, add a new Bluetooth device.
• In Windows 8, go to PC settings > Devices, and then
click Add a device.
• In Windows 7, open the Control Panel. Under
Hardware and Sound, click Add a device.
3. Select HTC Mini+ (then click Next in Windows 7).
HTC Confidential
for Certification
HTC Confidential
for Certification
6
English
4. Install the HTC Mini+ PC application, and then start it.
5. Right-click the system tray icon ( ), and then click
Connect.
Note:
You can download the PC application from www.htc.com/support.
Locking the keypad
You can lock the keypad to prevent accidental button
presses.
• To lock the keypad, press and hold . The screen will go
into sleep mode.
• To unlock the keypad, press twice.
Note:
To wake the screen, press . You will see a lock icon in the status bar if
the keypad is locked.
What you can do with HTC Mini+
View your call history and frequent callers. You can
also use the lists to make calls.
View text messages and send a quick reply using a
preset response.
View ongoing and upcoming calendar events.
See how many new emails you received and be
notified if your phone’s battery is critically low.
Remotely control the camera shutter on your phone,
the Music app, and more.
Access the settings for your HTC Mini+.
Some icons show the number of new notifications (such as
number of missed calls on the Phone icon).
To select an icon, use the navigation control. The navigation
control consists of an enter button and an outer ring. The
enter button is used for selecting items. The outer ring is
used to navigate up, down, left, and right.
HTC Confidential
for Certification
HTC Confidential
for Certification
7
English
Making and receiving calls
You can use your HTC Mini+ to answer incoming calls,
redial, and more.
answer an incoming call press
reject an incoming call press
mute an incoming call press volume up or volume
down
end a call press
redial press and hold
change in-call volume press volume up or volume
down
mute microphone on/o While in a call, press to
open Call options, and then
select Mute on or Mute o.
To make a phone call, you can:
• Directly dial the number using the keypad.
• Use Smart dial to quickly place a call. Smart dial
searches and calls a stored/synced contact or a number
from your call history.
• Press and hold a number on the keypad to use the
corresponding speed dial on your phone.
• Select , and then select an item in Call history or
Frequent.
Note:
Smart dial and speed dial features are automatically inherited from
your phone.
Conference calls
To make a conference call, do the following:
1. While in a call, enter the phone number of the second
contact, and then press .
2. When the second call has connected, select Call options
> Merge calls.
HTC Confidential
for Certification
HTC Confidential
for Certification
8
English
Swapping calls
If you’re connected to two callers, but aren’t conference
calling, one call will be on hold while the other is active. To
swap between the callers, press .
Reading text messages
Whenever you receive a text message on your phone, you’ll
see a notification over . Your HTC Mini+ displays the most
recent text messages.
To read a message, select and then select the message
you want to read. While viewing a message, you can scroll
through your messages by pressing left or right on the
4-way navigation ring.
To quickly reply to a message using a preset response
stored in your phone, press and then select a reply.
To call the sender, press while viewing the message.
Viewing calendar events
You can view summaries of the most recent ongoing and
upcoming events in .
To view an event, select and then select the event you
want to view. You can scroll through the events by pressing
left or right on the 4-way navigation ring. Events are listed
in chronological order.
Checking other notifications
You’ll see a notification over when:
• You receive an email in your phone’s Mail app.
• Your phone’s battery is critically low.
To clear the notifications, select and then select Clear
notification.
Handling alarms
If an alarm sounds on your phone, you will see the
notification on the screen. You’ll be able snooze the alarm
or dismiss it.
HTC Confidential
for Certification
HTC Confidential
for Certification
9
English
Listening to music
Use your HTC Mini+ to remotely control your phone’s Music
app.
Select and then select Media player.
start the Music app press
play/pause press
change the volume press volume up or volume
down
fast forward press and hold
rewind press and hold
play the next song press
play the previous song press
Note:
If the song has been playing for over
3 seconds, pressing will replay
the current song from the beginning.
Taking photos
You can use your HTC Mini+ to remotely operate the
camera shutter on your phone.
1. On your phone, open the Camera app.
2. On your HTC Mini+, select and then select Camera.
3. To take a shot, press .
Note:
If your phone supports continous shooting, press and hold to take
multiple shots.
HTC Confidential
for Certification
HTC Confidential
for Certification
10
English
Controlling a presentation on your
phone
You can use your HTC Mini+ to remotely control a
PowerPoint® presentation in Polaris Oce.
1. On your phone, open the PowerPoint presentation in
Polaris Oce.
2. Tap the screen to show the controls, and then tap .
3. On your HTC Mini+, select and then select
Presentation.
4. Press or to go to the next slide. Press or to go
to the previous slide.
Controlling a presentation on your PC
1. Make sure your HTC Mini+ is connected to the PC
application.
2. Open the PowerPoint presentation.
3. Press or to go to the next slide. Press or to go
to the previous slide.
Using the laser pointer
While controlling a PowerPoint presentation, press to
activate the laser pointer.
Note:
You can also activate the laser pointer when your HTC Mini+ is o.
Browsing an album in Gallery
Your HTC Mini+ can be used to browse an album in Gallery.
1. On your phone, open the album in Gallery.
2. Tap a photo in the album to view it in fullscreen.
3. On your HTC Mini+, select and then select
Presentation.
4. Press to view the next photo. Or press to view the
previous photo.
Tip:
Use Media Link HD to share your photo slide show on a big screen.
HTC Confidential
for Certification
HTC Confidential
for Certification
11
English
Controlling your TV
1. On your phone, open the TV app.
2. On your HTC Mini+, select and then select TV.
browse channels select CH & VOL and then
press or
enter channels enter the channel number
using the keypad
see previous channel select CH & VOL, press , and
then select Jump
change volume select CH & VOL and then
press or
mute volume select CH & VOL and then
press
open TV menu select CH & VOL, press , and
then select Menu
exit TV menu select CH & VOL, press , and
then select Exit
navigate onscreen
menu
select D-Pad, and press ,
, or
control DVR playback select DVR, and press , ,
, or
open DVR menu select DVR, press , and then
select My DVR
exit DVR menu select DVR, press , and then
select Exit
start/stop recording select DVR, press , and then
select Rec
Note:
You need to set up a TV remote on your phone before HTC Mini+ can
control your TV.
HTC Confidential
for Certification
HTC Confidential
for Certification
12
English
Finding your phone
Can’t remember where you put your phone? Your HTC
Mini+ can make your phone ring to help you find it.
Select and then select Find my phone.
Finding your HTC Mini+
If you don’t remember where you put your HTC Mini+, you
may be able to find it with your phone. Your HTC Mini+ will
need to be connected to your phone for this to work.
1. On your phone, go to Settings > Bluetooth.
2. Under Paired devices, locate HTC Mini+.
3. Tap > Find me.
Settings
When you select , you’ll find these settings:
Find my phone make your phone ring
Sleep time set the display timeout
Sound turn sound on or o
Vibration turn vibration on or o
Disconnect disconnect from your phone
Software upgrade update the firmware
About view firmware information
Note:
Check www.htc.com/support for how to update the firmware.
HTC Confidential
for Certification
HTC Confidential
for Certification
HTC Confidential
for Certification
HTC Confidential
for Certification
91H0xxxx-xxM Rev.A
htc.com
HTC Confidential
for Certification
HTC Confidential
for Certification
