HTC NEON400 POCKET PC PHONE User Manual USERS MANUAL
HTC Corporation POCKET PC PHONE USERS MANUAL
HTC >
USERS MANUAL
HTC
User Manual
2
Please Read Before Proceeding
THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER
CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and stipulate that you must
inform the person with whom you are speaking that the conversation is being recorded. Always obey the
relevant laws and regulations of your country when using the recording feature of your PDA Phone.
INTELLECTUAL PROPERTY RIGHT INFORMATION
Copyright © 2008 HTC Corporation. All Rights Reserved.
, , and ExtUSB are trademarks and/or service marks of HTC Corporation.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, Windows XP, Windows
Vista, ActiveSync, Windows Mobile Device Center, Internet Explorer, Windows Live, MSN, Hotmail, Outlook,
Excel, PowerPoint, Word, and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
microSD is a trademark of SD Card Association.
Copyright © 2008, Adobe Systems Incorporated.
Copyright © 2008, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are trademarks and/or registered
trademarks of Macromedia Netherlands, B.V. or Adobe Systems Incorporated.
Opera® Mobile from Opera Software ASA. Copyright 1995-2008 Opera
Software ASA. All Rights Reserved. Copyright © 2008, Macromedia Netherlands, B.V.
Copyright © 2008, JATAAYU SOFTWARE (P) LTD. All Rights Reserved.
Copyright © 2008, Dilithium Networks, Inc. All Rights Reserved.
Copyright © 2008, Esmertec AG. All Rights Reserved.
Licensed by QUALCOMM Incorporated under one or more of the following patents:
4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,778,338
5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,710,784
5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,659,569
5,600,754 5,414,796 5,657,420 5,416,797
This device is licensed under patented keyboard technology of Research In Motion Limited including the
following US Patents and foreign counterparts: 6,278,442; 6,396,482; 6,452,588; 6,489,950; 6,611,254;
6,611,255; 6,876,763; 6,873,317; 6,891,529; 6,919,879; 7,056,043; 7,073,964; 7,106,306; 7,113,111; 7,153,049;
7,158,120; 7,227,536; 6,891,529; 7,083,342; 7,096,036; 7,106,306; 7109973; and 7,220,069.
All other company, product and service names mentioned herein are trademarks, registered trademarks or
service marks of their respective owners.
HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or
consequential damages resulting from furnishing this material. The information is provided “as is” without
3
warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content
of this document at any time without prior notice.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording or storing in a retrieval system, or translated into any
language in any form without prior written permission of HTC.
Disclaimers
THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY
OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or
implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other
Products and services, including without limitation any express or implied warranty of merchantability,
express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy,
completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation
will be error-free, or implied warranties arising from course of dealing or course of performance.
Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your
use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and
its Providers make no express or implied warranties, guarantees or affirmations that weather information
will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall
have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any
inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or
occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER
INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE COMMON
SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER
INFORMATION, DATA OR DOCUMENTATION.
Limitation of Damages
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS
BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR
PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF
REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS
ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE
OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER
REGARDLESS OF THE FORESEEABILITY THEREOF.
Important Health Information and Safety Precautions
When using this product, the safety precautions below must be taken to avoid possible legal liabilities and
damages.
Retain and follow all product safety and operating instructions. Observe all warnings in the operating
instructions on the product.
To reduce the risk of bodily injury, electric shock, fire and damage to the equipment, observe the following
precautions.
4
ELECTRICAL SAFETY
This product is intended for use when supplied with power from the designated battery or power supply unit.
Other usage may be dangerous and will invalidate any approval given to this product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION
CAUTION: Connecting to an improperly grounded equipment can result in an electric shock to your device.
This product is equipped with a USB Cable for connecting with desk-top or notebook computer. Be sure your
computer is properly grounded (earthed) before connecting this product to the computer. The power supply
cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with
all local codes and ordinances.
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
• Use the correct external power source
A product should be operated only from the type of power source indicated on the electrical ratings
label. If you are not sure of the type of power source required, consult your authorized service provider
or local power company. For a product that operates from battery power or other sources, refer to the
operating instructions that are included with the product.
• Handle battery packs carefully
This product contains a Li-ion battery. There is a risk of re and burns if the battery pack is handled
improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture,
short external contacts or circuits, dispose of in re or water, or expose a battery pack to temperatures
higher than 60˚C (140˚F).
WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external contacts, expose to temperature above 60˚C (140˚F), or
dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries
according to the local regulations or reference guide supplied with your product.
• Take extra precautions
• Keep the battery or device dry and away from water or any liquid as it may cause a short circuit.
• Keep metal objects away so they don’t come in contact with the battery or its connectors as it may
lead to short circuit during operation.
• Do not use a battery that appears damaged, deformed, or discolored, or the one that has any rust on
its casing, overheats, or emits a foul odor.
• Always keep the battery out of the reach of babies and small children, to avoid swallowing of the
battery. Consult the doctor immediately if the battery is swallowed.
• If the battery leaks:
• Do not allow the leaking uid to come in contact with skin or clothing. If already in contact, ush
the aected area immediately with clean water and seek medical advice.
• Do not allow the leaking uid to come in contact with eyes. If already in contact, DO NOT rub; rinse
with clean water immediately and seek medical advice.
• Take extra precautions to keep a leaking battery away from re as there is a danger of ignition or
explosion.
• Communicate the appropriate steps immediately in case a hazard occurs.
5
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or
its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car
dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for
extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.
PREVENTION OF HEARING LOSS
CAUTION – Permanent hearing loss may occur if earphones or headphones are used at high volume for
prolonged periods of time.
SAFETY IN AIRCRAFT
Due to the possible interference caused by this product to an aircraft’s navigation system and its
communications network, using this device’s phone function on board an airplane is against the law in
most countries. If you want to use this device when on board an aircraft, remember to turn off the phone by
switching to Flight Mode.
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in
progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on
boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles,
such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or
fire resulting in bodily injury or even death.
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere or where flammable materials exist, the product
should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at
refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the
use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas
with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas,
below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals
or particles, such as grain, dust, or metal powders.
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the
case of emergency. In some countries, using hands-free devices as an alternative is allowed.
SAFETY PRECAUTIONS FOR RF EXPOSURE
• Avoid using your device near metal structures (for example, the steel frame of a building).
• Avoid using your device near strong electromagnetic sources, such as microwave ovens, sound
speakers, TV and radio.
• Use only original manufacturer-approved accessories, or accessories that do not contain any metal.
• Use of non-original manufacturer-approved accessories may violate your local RF exposure guidelines
and should be avoided.
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction. The use of this device is forbidden in most
hospitals and medical clinics.
6
If you use any other personal medical device, consult the manufacturer of your device to determine if it
is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this
information.
Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may
want to consult your service provider, or call the customer service line to discuss alternatives.
NONIONIZING RADIATION
Your device has an internal antenna. This product should be operated in its normal-use position to ensure
the radiative performance and safety of the interference. As with other mobile radio transmitting equipment,
users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is
recommended that no part of the human body be allowed to come too close to the antenna during operation
of the equipment.
Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and
damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as
result in non-compliance with local regulatory requirements in your country.
2
.
0
M
E
G
A
P
I
X
E
L
S
C
A
M
E
R
A
Internal antenna
location
To assure optimal phone performance and ensure human exposure to
RF energy is within the guidelines set forth in the relevant standards,
always use your device only in its normal-use position. Do not touch
or hold the antenna area unnecessarily when placing or receiving a
phone call. Contact with the antenna area may impair call quality and
cause your device to operate at a higher power level than needed.
Avoiding contact with the antenna area when the phone is IN USE
optimizes the antenna performance and the battery life.
General Precautions
• Avoid applying excessive pressure to the device
Do not put heavy objects or apply excessive pressure on the device to prevent damaging the device or
distorting the touch screen display. Also avoid carrying the device inside your pocket for extensive lengths of
time.
• Heed service markings
Except as explained elsewhere in the Operating or Service documentation, do not service any product
yourself. Service needed on components inside these compartments should be done by an authorized
service technician or provider.
• Damage requiring service
Unplug the product from the electrical outlet and refer servicing to an authorized service technician or
provider under the following conditions:
• Liquid has been spilled or an object has fallen into the product.
• The product has been exposed to rain or water.
• The product has been dropped or damaged.
• There are noticeable signs of overheating.
• The product does not operate normally when you follow the operating instructions.
7
• Avoid hot areas
The product should be placed away from heat sources such as radiators, heat registers, stoves, or other
products (including, but not limited to, amplifiers) that produce heat.
• Avoid wet areas
Never use the product in a wet location.
• Avoid using your device after a dramatic change in temperature
When you move your device between environments with very different temperature and/or humidity ranges,
condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the
moisture to evaporate before using the device.
NOTICE: When taking the device from low-temperature conditions into a warmer environment or from high-
temperature conditions into a cooler environment, allow the device to acclimate to room temperature before
turning on power.
• Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are
provided for ventilation. These openings must not be blocked or covered.
• Mounting accessories
Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product
should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the
manufacturer.
• Avoid unstable mounting
Do not place the product with an unstable base.
• Use product with approved equipment
This product should be used only with personal computers and options identified as suitable for use with
your equipment.
• Adjust the volume
Turn down the volume before using headphones or other audio devices.
• Cleaning
Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning, but NEVER use water to clean the LCD screen.
8
Contents
Chapter 1 Getting Started 11
1.1 Getting to Know Your Device and Accessories .........................................12
1.2 The Battery and the Storage Card .............................................................16
1.3 Starting Up ....................................................................................................18
1.4 The Today Screen ........................................................................................19
1.5 The Start Menu ............................................................................................20
1.6 Quick Menu .................................................................................................21
1.7 Quick Tasks ..................................................................................................21
1.8 HTC Home ....................................................................................................22
1.9 TouchFLO™ ..................................................................................................25
1.10 Status Icons .................................................................................................30
1.11 Programs .....................................................................................................31
1.12 Settings ........................................................................................................33
1.13 Using your Device as a USB Drive ..............................................................35
Chapter 2 Entering and Searching Information 37
2.1 Entering Information ..................................................................................38
2.2 Using the 20-key QWERTY Hardware Keyboard ......................................39
2.3 Using the On-screen Keyboard ..................................................................40
2.4 Using Touch Keyboard ................................................................................40
2.5 Using Touch Keypad ...................................................................................41
2.6 Using Symbol Pad .......................................................................................42
2.7 Using Letter Recognizer .............................................................................42
2.8 Using Block Recognizer ..............................................................................43
2.9 Using Transcriber ........................................................................................43
2.10 Searching Information................................................................................44
Chapter 3 Using Phone Features 45
3.1 Using the Phone ..........................................................................................46
3.2 Making a Call ...............................................................................................47
3.3 Receiving a Call ...........................................................................................49
3.4 Smart Dialing ..............................................................................................50
3.5 Additional Dialing Information .................................................................52
9
Chapter 4 Setting Up Your Device 53
4.1 Basic Settings ..............................................................................................54
4.2 Personalizing the Today Screen .................................................................56
4.3 Customizing Phone Services ......................................................................58
4.4 Protecting Your Device ...............................................................................58
Chapter 5 Synchronizing Information With Your Computer 61
5.1 About Synchronization ..............................................................................62
5.2
Setting Up Windows Mobile® Device Center on Windows Vista® ........................62
5.3 Setting Up ActiveSync® on Windows XP® ..................................................64
5.4 Synchronizing With Your Computer ..........................................................64
5.5 Synchronizing via Bluetooth .....................................................................65
5.6 Synchronizing Music and Video ................................................................66
Chapter 6 Organizing Contacts, Appointments, Tasks, and Other
Information 67
6.1 Contacts .......................................................................................................68
6.2 Calendar ......................................................................................................70
6.3 Tasks ............................................................................................................72
6.4 Notes ............................................................................................................73
6.5 Voice Recorder ............................................................................................74
Chapter 7 Exchanging Messages 75
7.1 Messaging ...................................................................................................76
7.2 Text Messages .............................................................................................77
7.3 Types of E-mail Accounts ............................................................................78
7.4 E-mail Setup Wizard ....................................................................................79
7.5 Using E-mail ................................................................................................81
Chapter 8 Working With Company E-mail and Meeting
Appointments 87
8.1 Synchronizing Your Device with the Exchange Server ............................88
8.2 Working With Company E-mail ..................................................................89
8.3 Managing Meeting Requests .....................................................................91
8.4 Finding Contacts in the Company Directory ............................................92
8.5 E-mail Security ............................................................................................93
10
Chapter 9 Working With Documents and Files 97
9.1 Microsoft® Office Mobile ............................................................................98
9.2 Adobe® Reader® LE .....................................................................................98
9.3 Copying and Managing Files .....................................................................99
9.4 ZIP ............................................................................................................. 100
Chapter 10 Getting Connected 103
10.1 Comm Manager ........................................................................................ 104
10.2 Connecting to the Internet ...................................................................... 104
10.3 Internet Explorer® Mobile ....................................................................... 104
10.4 Windows Live™ ......................................................................................... 106
10.5 Bluetooth .................................................................................................. 109
10.6 Using Your Device As a Modem (Internet Sharing) ................................ 113
10.7 Using RSS Hub .......................................................................................... 114
Chapter 11 Experiencing Multimedia 119
11.1 Camera ...................................................................................................... 120
11.2 Camera Album .......................................................................................... 126
11.3 Pictures & Videos ...................................................................................... 129
11.4 Windows Media® Player Mobile .............................................................. 131
11.5 Audio Booster ........................................................................................... 134
Chapter 12 Managing Your Device 137
12.1 Adding and Removing Programs ............................................................ 138
12.2 Using Task Manager ................................................................................. 138
12.3 Resetting Your Device .............................................................................. 139
12.4 Managing Memory .................................................................................. 140
12.5 Windows Update ...................................................................................... 141
12.6 Battery Saving Tips .................................................................................. 141
Chapter 13 Using Other Applications 143
13.1 Voice Command ....................................................................................... 144
13.2 Using Java ................................................................................................. 145
Appendix 1 48
A.1 Specifications ........................................................................................... 149
A.2 Regulatory Notices .................................................................................. 151
A.3 Additional Safety Information ................................................................ 155
Index 160
12 Getting Started
1.1 Getting to Know Your Device and Accessories
Front panel
Notification LEDs
* See description below.
Earpiece
Listen to a phone
call from here.
Touch Screen
TALK
Press to answer an
incoming call or dial a
number.
4-WAY NAVIGATION CONTROL with
ENTER button
Press this multi-directional control up,
down, left, or right to move through
menus and program instructions; carry
out the selection by pressing the center
button.
END
Press to end a call or to return to the
Today screen. Press and hold to open
the Quick List where you can choose an
action to do.
In the Quick List, touch Settings (or tap
Start > Settings > System tab > Long
Press End Key) to set the behavior
when pressing and holding the END key.
20-key keyboard
Slide up the front panel
of the device to reveal
the keyboard. Use to
dial phone numbers or
enter information.
* Right LED: Shows Green and Amber lights for CDMA standby, message, and network status as well as
for notification and battery charging status. Shows a flashing red light when the battery
level reaches 5% or lower.
Left LED: Shows a flashing Blue light when the Bluetooth system is powered up and ready to
transmit Bluetooth radio signal.
Getting Started 13
Left panel
microSD Slot
See "To install the
microSD™ card" for
details.
Lanyard/Strap holder
Volume Up Button
• Press to increase the
speaker volume (or the
earpiece volume during
a call).
• Press and hold to launch
the Voice Notes recorder.
Volume Down Button
• Press to decrease the
speaker volume (or the
earpiece volume during
a call).
• Press and hold to start
the Voice Command
feature.
Right panel
POWER
Press to turn
off the display
temporarily.
To turn off the
power, press and
hold for about 5
seconds.
Stylus
CAMERA
Press to launch
the Camera.
14 Getting Started
Back Panel
Speaker
2 Megapixel
Camera
See Chapter 12 for
details.
Back Cover
Remove to install the
battery.
Self-portrait Mirror
Use it when taking
self-portrait shots.
Bottom Panel
RESET
Open the rubber cover to access the
RESET button. With the stylus, press the
RESET button to soft-reset your device.
Sync Connector/Earphone Jack/AC adapter connector
Open the rubber cover to connect the supplied USB cable
to synchronize information or plug in the AC adapter to
recharge the battery. You can also connect the supplied USB
stereo headset for hands-free conversation or for listening to
audio media.
Getting Started 15
Inside the box
The product package includes the following items and accessories:
Touch Phone
AC Adapter
Battery
Extra Stylus
Getting Started Disc
Multifunction Audio Cable
Pouch
Quick Start Guide and Read First Poster
Screen Protector
USB Sync Cable
Wired Stereo Headset
The Multifunction Audio Cable
The supplied multifuntion audio cable enables you to use a stereo headset to listen to music while the device
is connected to an AC adapter or the USB sync cable. You can use the USB stereo headset that comes with
your device, or connect a headset with either a 2.5 mm or 3.5 mm jack.
1. Connect the multifuntion audio cable to the
device’s Sync connector.
4. Connect the supplied
wired stereo headset to
the multifuntion audio
cable’s audio connector.
2. Connect the AC adapter to the
multifuntion audio able’s power
connector.
3. Plug the AC adapter into
an electrical outlet or the
USB sync cable to your
computer.
•
•
•
•
•
•
•
•
•
•
•
16 Getting Started
1.2 The Battery and the Storage Card
Your device contains a rechargeable Li-ion battery. It is designed to use only manufacturer-specified original
batteries and accessories. Battery performance depends on many factors, including network configuration,
signal strength, the temperature of the environment in which you operate your device, the features and/or
settings you select and use, items attached to connecting ports, and your voice, data, and other program
usage patterns.
Battery life estimates (approximations):
Standby time: Up to 360 hours.
Talk time: Up to 6.4 hours.
Media playback time: Up to 8 hours for WMV; up to 12 hours for WMA.
Warning! To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire or water.
• Do not expose to temperatures above 60oC (140oF).
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulation.
Install the battery
To remove the back cover
Before installing the battery, you have to remove the back
cover.
1. Make sure your device is turned o.
2. Slide the back cover upward to remove it as shown in
the illustration on the right.
To install the battery
1. Install the battery by inserting it with its exposed
copper part aligned with the protruding copper
conductor on the lower-left side of the battery
compartment.
Insert the bottom side of the battery rst, then gently
push the battery into place.
2. Replace the back cover.
To remove the battery
1. Make sure your device is turned o.
2. Remove the back cover.
3. To remove the battery, lift it up from the top end of
the battery.
•
•
•
Getting Started 17
Battery Information
To charge the battery
New batteries are shipped partially charged. Before you start using your device, it is recommended that you
charge the battery. Some batteries perform best after several full charge/discharge cycles.
1. Connect one end of the USB sync cable to the sync connector on your device.
2. Connect the other end of the USB sync cable to the USB port of the AC adapter.
3. Plug in the AC adapter to an electrical outlet to start charging the battery. The battery is fully charged
after 3 hours of charging.
Note Only the AC adapter and USB cable provided with your device should be used to charge the device.
Charging is indicated by a solid amber light on the left LED indicator. As the battery is being charged while
the device’s power is on, a charging icon ( ) will be shown on the title bar of the Today screen. After the
battery has been fully charged, the left LED becomes green and a full battery icon ( ) appears on the
Today screen’s title bar.
Warning! • Do not remove the battery from the device while you are charging it using the AC or car adapter.
• As a safety precaution, the battery stops charging when it overheats.
To check the battery power
1. Power on your device.
2. Tap Start > Settings > Systems tab > Power. The Power Settings screen will then open where you can
see the current battery power level.
When the battery power gets very low, a warning message will be displayed. When you see this,
immediately save your data by synchronizing with your PC, or save your data on a secondary storage
card, and then turn off your device. Do not attempt to restart your device until you have connected it
with the power adapter.
Low battery
When the low-battery warning appears, do the following:
1. Immediately save your current data.
2. Synchronize with your PC or connect the power adapter to charge the battery.
3. Turn o your device.
18 Getting Started
Install the microSD™ card (not included)
If you need more storage for your device, you
can use a microSD™ card (not included) to save
media and other files.
1. Pry open the rubber cover at the bottom-
left side of the device.
2. Insert the microSD card with the gold
contacts facing up.
3. Close the rubber cover.
Tip Press the microSD card to pop it out of the
slot.
1.3 Starting Up
Turn your device on and off
To turn on the power
Press and hold the POWER button for a few seconds.
When you turn on your device for the rst time, a Quick Start Wizard will guide you through the calibration
process and the setup of regional settings, date and time, and password. For more information about touch
screen calibration, see “Calibrate the device”.
To turn off the power
Press and hold the POWER button for a few seconds. A message will then be displayed, prompting you
whether or not to turn off the device completely.
Calibrate the device
Calibrating the touch screen involves tapping the center of a cross with the stylus as the cross moves around
the screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated.
If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:
1. Tap Start > Settings > System tab > Screen.
2. On the General tab, tap Align Screen, then follow the onscreen instructions to complete the
calibration.
Manage screen settings
The device’s display has the following orientation modes: Portrait and Landscape. To change the orientation,
tap Start > Settings > System tab > Screen, and select the orientation you want.
Tip To quickly change the screen orientation, you can also tap the Rotate Screen icon in HTC Home’s Launcher. See
“HTC Home” later in this chapter for details.
To smooth the edges of screen fonts for many programs, on the ClearType tab, select the Enable ClearType
check box.
To increase the readability or to see more content on the screen, on the Text Size tab, adjust the text size by
moving the slider.
Getting Started 19
Switch your device to Sleep mode
Quickly pressing the POWER button turns off the display temporarily and switches your device to Sleep
mode. Sleep mode suspends your device to a low power state while the display is off in order to save battery
power. Your device also automatically goes into Sleep mode when you leave the device idle after a certain
amount of time.
You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER
button again or new incoming calls/messages will wake up your device.
To specify the timeout period before your device goes into Sleep mode
1. Tap Start > Settings > System tab > Power > Advanced tab.
2. Under On battery power, make sure the Turn off device if not used for check box is selected.
3. Select the battery timeout period, then tap OK.
1.4 The Today Screen
The Today screen displays important information, such as upcoming appointments and status indicators. You
can touch or tap a section on the screen to open the associated program.
To access the Today screen, tap Start > Today.
To customize the Today screen display, including the background image, tap Start > Settings >
Personal tab > Today.
Your upcoming
appointments.
Open Start Menu.
Notification
Signal strength
Adjust volume
Battery status
HTC Home
(See “HTC Home” in this
chapter for details.)
Open Quick Menu
(See “Quick Menu” in
this chapter for details.)
Connection status
Open the Getting Started
application to view a list
of “how to’s” that you can
reference to learn basic
features and settings of your
device.
Tip For more information about customizing the Today screen, see Chapter 4.
•
•
20 Getting Started
Enlarged Title Bar
Touch the area in the Title bar where the icons are to show the enlarged title bar. In the enlarged Title bar,
touch the item to activate it. The enlarged Title bar is available in all screens.
1.5 The Start Menu
The Start menu, located at the top left corner of the Today screen, displays a list of programs. You can start a
program by scrolling through the programs list and then pressing ENTER, or by tapping a program with the
stylus.
View Help information for
the current screen.
View and change settings.
Open a recently-used program.
Open a program. (The items
displayed in the Start menu
can be customized by tapping
Start > Settings > Personal
tab > Menus.)
Switch to the Today screen.
Access more programs.
Enlarged Title Bar
Getting Started 21
Disable Large Start menu
By default, the Start menu is set to Large. You can choose to set the Start menu size to normal.
1. Tap Start > Settings > Personal tab > Large Start Menu.
2. Clear the Enable large Start menu check box.
3. Tap OK.
1.6 Quick Menu
The Quick Menu, located at the top right corner of the Today screen, shows the currently running programs.
You can quickly switch between running programs and stop programs when you do not need to use them.
Tap this button to open the Quick Menu.
• To switch to a running program, tap
the program name.
• To stop running a program, tap .
Customize Task Manager
settings. (See “Using Task
Manager” in Chapter 12.)
Stop all currently
running programs. Display the percentage of memory in use.
Tap this icon to view more information
about memory usage.
1.7 Quick Tasks
QuickTasks lets you quickly access frequently-used tasks by
simply opening the front panel of the device.
The QuickTasks only opens when you open the keyboard
while on the Today screen.
You can disable the Quick Tasks by tapping Start > Settings
> System tab > Keypad QuickTasks and clearing the
Enable QuickTasks when keypad is opened check box.
Note QuickTasks will not open when the screen orientation is in
Landscape mode.
Touch to activate the item
22 Getting Started
1.8 HTC Home
HTC Home is a Today screen plug-in that gives you up-to-date local information at a glance, such as time,
day and weather information, and shows new messages and missed calls. It also has a customizable launcher
where you can add your favorite applications for one-touch access and a Profile selector where you can
quickly change the profile or ring tone of your device.
HTC Home has four components: Home, Weather, Launcher, and Sound. At the bottom of HTC Home, there
is a toolbar that allows you to switch between these components.
Home Launcher Sound
Weather
To switch between the different components of HTC Home
Do any of the following:
Touch the tabs in the toolbar using your nger.
Tap the tabs in the toolbar using the stylus.
Use the NAVIGATION Control. If the toolbar is not selected, press NAVIGATION up/down rst to select
the toolbar. Press NAVIGATION left/right to select a tab and then press ENTER.
Home
Home displays the current day, date and local time. When you have new incoming messages and calls, it
shows you the number of new e-mails, text messages, and missed calls. If you have set up the alarm, it also
shows the Alarm icon.
Number of new e-mails.
Touch this icon to view
your e-mails.
Number of new text messages.
Touch this icon to view your text messages.
Alarm icon.
Number of missed calls.
Touch this icon to view
the Call History.
Time display. Touch this
display area when you
want to change the date
or time, or to enable the
alarm.
Current day and date.
Weather
Weather shows you the current weather as well as weather information of the next four days of the week. The
first time you use this feature, you need to select your city first to get the weather information of your city.
•
•
•
Getting Started 23
To select your city
1. Select the Weather tab ( ).
2. Tap the area that shows Select your city here.
3. On the Select City screen, type in the city namewhose weather
information you want to track, then tap .
You can also browse through the list of cities to choose your city.
4. Select the city on the list and tap Select.
Note Downloading weather forecast data may incur additional data transfer fees from
your service provider.
To view weather information
After selecting your city, your device automatically connects to the Internet
via the data connection and downloads weather information of the current
day and the next four days of the week. The current temperature, the highest
and lowest temperatures, and a visual indicator of the climate (showing if it’s a
cloudy or rainy day, etc.) will be displayed in the Weather tab.
Weather for the next four days.
Tap this area to
return to the current
day’s weather.
Current day’s weather.
Tap this area to view weather
information of the next four
days of the week.
Tap this area if
you want to select
another city.
Shows the time or days that have passed since
the last download of weather information. Touch
this item to download the latest weather data.
Note If you have not connected to the Internet and downloaded weather information for five days, the following
error message will be displayed: "Unable to retrieve data for selected city. Select here to retry." Use the data
connection to connect your device to the Internet, then touch the area that shows the error message to
download weather data.
To customize weather settings
1. Tap the area that shows the city name.
2. On the Select City screen, select Menu > Weather Options.
3. You can enable or disable the following options:
24 Getting Started
Download weather data automatically.
When this check box is selected, weather information will
automatically be downloaded from the AccuWeather Web site
whenever you select the Weather tab, if the data has not been
updated within the last three hours. Weather data will also
be downloaded every time an ActiveSync connection occurs
(through over-the-air or USB connection).
Clear this check box if you prefer to manually download weather
information.
Download when roaming. Select this check box only if you
want to allow automatic download of weather data when you’re
roaming. This may incur additional costs.
Temperature Scale. Choose whether to display temperature in
Celsius or Fahrenheit.
•
•
•
Tip To check for more detailed weather information on the AccuWeather Web site, select Menu > About Weather
on the Select City screen and then touch the link that shows AccuWeather.com. Internet Explorer Mobile then
opens and brings you to the AccuWeather Web site.
Launcher
Launcher allows you to add quick shortcuts to your favorite programs and settings for one-touch access.
Quick settings such as Adjust Backlight, Rotate Screen and Lock Device, and a few program shortcuts are
added by default. They can be replaced with your preferred settings and programs.
Touch a shortcut to remove it.
Return
Remove
shortcuts.
Touch a quick shortcut
to open the associated
program or apply the
associated setting.
Touch an empty slot to add a shortcut
to a setting or your favorite program.
Note To replace a shortcut, you need to delete it first and then add a shortcut to your favorite program or setting.
Sound
Sound lets you quickly set the device volume and change the ring tone of your device.
Tap a button to set the
device volume.
Tap to open the
phone sound
settings.
Note To learn more about setting device volume, see Chapter 3.
Getting Started 25
1.9 TouchFLO™
TouchFLO™ is a special feature that gives you better touch panel experience on your device. With TouchFLO,
you can simply use your finger to scroll and pan the screen.
TouchFLO also features Touch Cube where you can launch messaging programs, Internet Explorer® Mobile,
and more. You can also add your favorite contacts, play music, and access your pictures and videos.
Note Touch Cube is displayed in portrait view only. To be able to open Touch Cube, make sure your display is set to
portrait mode.
Touch Cube
To open Touch Cube
Slide your finger upward, starting from the logo at the
bottom of the touch screen.
To close Touch Cube
To close Touch Cube and return to the screen prior to
opening Touch Cube, slide your finger downward on the
touch screen.
To navigate the Touch Cube
Touch Cube is a three-dimensional, cubic user interface. To flip the interface from one side to another, slide
your finger left or right on the touch screen.
26 Getting Started
Touch Cube screens
There are three sides to the Touch Cube interface:
On the rst side of the interface, you can add up to nine favorite contacts. If you make calls to certain
people frequently, you can add them as favorite contacts for quicker access.
Select a favorite contact to
remove it.
Return to your list of
favorite contacts.
Select an empty slot to add
a favorite contact. If the
contact has more than one
contact number, select the
number to call when you
touch the contact.
Open Call History.
(See Chapter 3 for details.)
Tap to call the number
associated with the
contact.
Open the Phone
program. (See
Chapter 3 for details.)
Delete favorite
contacts.
Open Contacts.
(See Chapter 6 for details)
When you add a favorite contact and
there is no photo associated to that
contact, the contact’s first name (or
last name) will be displayed.
When you have different phone
numbers assigned to the same
contact, an icon appears on the
top left corner of the contact
square to tell you which number
is assigned to the particular
square.
Tip You should already have contacts created or synchronized on your device before you can add them as favorite
contacts.
For more information about creating contacts, see Chapter 6.
For more information about synchronizing your device with the PC, see Chapter 5
For information about synchronizing your device with the Exchange Server, see Chapter 8.
•
Getting Started 27
The second side of the interface provides quick
shortcuts to Live TV, Video Clips, Satellite Radio and
GPS Nav. Simply touch the icons on the screen to
open the corresponding program.
•
On the third side of the interface, you can download music and access the images and video les on
your device.
Touch this icon to open Windows Media Player and
play back music files (For more information about using
Windows Media Player, see Chapter 11.)
Touch these buttons to
control music playback.
From left to right:
Backward, Play/Pause,
Forward
While playback is in
progress in Windows
Media Player, return to
this screen. You will then
see playback controls and
the music title, artist, and
remaining playback time of
the current music.
Open Camera Album for still
images. (See Chapter 11 for
details.)
Open Camera Album for videos.
(See Chapter 11 for details.)
Finger scrolling and finger panning
With TouchFLO, you can use finger scrolling and finger panning when viewing content that cannot be fit
entirely on the screen, such as Web pages, documents, and messages. Finger scrolling can also be used to
scroll up and down lists such as the contacts list, file list, message list, and calendar appointments list.
Note Finger scrolling and panning works in both portrait and landscape modes.
•
28 Getting Started
To use finger scrolling
Slide your nger downward to scroll up the screen.
Slide your nger upward to scroll down the screen.
When finger scrolling
up and down, slide
anywhere within this
area.
To scroll towards the left, slide your nger to the right.
To scroll towards the right, slide your nger to the left.
While the screen is scrolling, you can stop the scrolling by pressing your nger on the touch screen.
Note Scrollbars shown on the screen indicate that there is more content that cannot be fit on the screen. You can
finger-scroll up and down only when there's a vertical scrollbar shown on the screen. Likewise, you can finger-
scroll left and right only when there's a horizontal scrollbar.
To use finger panning
To pan downward, touch and hold on the touch screen then drag your nger upward.
To pan upward, touch and hold on the touch screen then drag your nger downward.
To pan towards the right, touch and hold on the touch screen then drag your nger to the left.
To pan towards the left, touch and hold on the touch screen then drag your nger to the right.
You can also pan diagonally.
To continuously pan
1. Drag your nger towards the boundary and hold. The Web page, document, or message that you are
viewing then continuously pans.
Vertical boundaries
Horizontal boundary
2. Release your nger to stop panning.
•
•
•
•
•
•
•
•
•
•
Getting Started 29
Enhanced features
TouchFLO provides enhanced features when you use E-mail and Contacts applications on the device.
To go to the next or previous message
While reading a message, you can slide your finger across the screen to go to the next or previous message.
To go to the next message, slide your nger from right to left on the screen.
To go to the previous message, slide your nger from left to right on the screen.
Tip If you slide to the right and you are on the first e-mail message, or slide to the left and you are on the last e-mail
message, you will be returned to the e-mail list screen.
To random access in Contacts
When you open the Contacts list, the Random Access bar allows you to quickly scroll through the list.
Random
Access bar
On the Random Access bar, tap a
letter or scroll to a letter to contacts
beginning with that letter.
To go to the next or previous messaging account
While on a messaging account screen, you can slide your finger across the screen to go to next or previous
messaging account.
•
•
30 Getting Started
TouchFLO settings
You can enable or mute the finger scrolling and panning sound. Tap Start > Settings > System tab >
TouchFLO then select or clear the Enable sound when finger scrolling and panning check box.
1.10 Status Icons
The following are some of the status icons that you may see on the title bar of the device.
Icons that appear in this area
Vibration mode
Sound on
Sound off
Icons that appear in this area
Battery charging
Battery full
Battery very low
Icons that appear in this area
Data connection is active but idle
Data connection is active and
transmitting data
Maximum signal strength
No signal
Phone is turned off
No phone service.
Searching for phone service
Voice call in progress
Icons that appear in this area
1xRTT available
EVDO available
Connection is active
Connection is not active
Synchronization in progress
Getting Started 31
Icons that appear in this area
There are more
notifications.
Tap the icon to view all.
New e-mail or text
messages
New voice mail
New instant message
from Live Messenger
Missed call
Speakerphone on
Roaming
Alarm
Bluetooth stereo
headset detected
ActiveSync notification
Synchronization error
1.11 Programs
The following are programs that are preinstalled on your device.
Programs in the Start Menu
Icon Description
Today Customize the appearance and the information to be displayed on the Today screen.
Calendar Keep track of your appointments and create meeting requests.
Contacts Keep track of your friends and colleagues.
Internet Explorer Mobile Browse Web and WAP sites as well as download new programs and files from the
Internet.
Messaging Send and receive e-mail and text messages.
Music Go online to access the music store and download your favorite music.
TV & Radio Bell Media Player provides you with your favorite TV and radio content.
Help See Help topics for the current screen or program.
32 Getting Started
Programs screen
Icon Description
Games Play two pre-installed games: Bubble Breaker and Solitaire.
Office Mobile Use the complete suite of Microsoft® Office applications for your mobile device.
Excel Mobile Create new workbooks or view and edit Microsoft® Office Excel® workbooks.
PowerPoint Mobile View Microsoft® Office PowerPoint® slides and presentations.
Word Mobile Create, view, and edit Microsoft® Office Word documents.
OneNote Mobile Create OneNote files on your device and then synchronize them with your PC.
ActiveSync Synchronize information between your device and a PC or the Exchange Server.
Adobe Reader LE View PDF (Portable Document Format) files on your device.
Audio Booster Enhances your music experience by providing you with controls for adjusting equalizer, 3D
sound, treble, and bass settings.
Audio Manager Browse and play back music files.
Bluetooth Explorer Search for other Bluetooth devices that have file sharing enabled and access their
Bluetooth shared folder.
Calculator Perform basic arithmetic and calculations, such as addition, subtraction, multiplication, and division.
Camera Album View your photos and videos.
Camera Take photos or shoots video clips with accompanying audio.
File Explorer Organize and manage files on your device.
Getting Started Provide a list of “how to’s” that you can reference to learn basic features and settings of your
device. Tap one of the items onscreen to learn how to do the task.
GPSNav TeleNav GPS Navigator™ provides you with driving directions and a host of other services.
Internet Sharing Connect your computer to the Internet using your device's data connection.
Java Download and install Java applications, such as games and tools, to your device.
Messenger Use this mobile version of Windows Live Messenger to send and receive instant messages on your
device.
Notes Create handwritten or typed notes, drawings, and voice recordings.
Opera Browser This is the mobile version of the Opera browser.
Phone Make and receive calls, switch between calls, and set up conference calling.
Pictures & Videos View, organize, and sort pictures, animated GIFs, and video files on your device or a storage
card.
Remote Desktop Mobile Connect and control your desktop computer remotely from your device.
RSS Hub Download and read the latest web feeds from the Internet. See Chapter 10 for details.
Search Search contacts, data, and other information on your device.
Getting Started 33
Icon Description
SelfServe Check and keep track of your mobile phone bill.
Tasks Keep track of your tasks.
Text Messages Retry Resend SMS messages that failed delivery.
Voice Recorder Record your voice, play it back, and then send it via e-mail or Bluetooth. You can also set the
recorded voice as your ring tone.
Windows Live Use this mobile version of Windows Live™ to find information on the Web. It also lets you sign
into your Windows Live account so that you can access your Live Mail messages and send/receive instant
messages in Live Messenger.
Windows Media Player Mobile Play back audio and video files.
ZIP Save memory and free up storage space on your device by compressing files in the conventional ZIP format.
1.12 Settings
You can adjust the device settings to suit the way you work. To see all available settings, tap Start > Settings,
then tap the Personal, System, and Connections tabs located at the bottom of the screen.
Personal tab
Icon Description
Buttons Assign a program or function to the hardware button.
Input Set options for each of the input methods.
Large Start Menu Enlarge the Start menu to make it easier to touch menu items with your fingers.
Lock Set a password for your device.
Menus Set what programs will appear in the Start menu.
Owner Information Enter your personal information on your device.
Phone Customize phone settings such as ring tone, and more.
Sounds & Notifications Enable sounds for events, notifications, and more, and set the type of notification for
different events.
Today Customize the appearance and the information to be displayed on the Today screen.
Voice Command Choose which functions you want to access by speaking out voice commands. See Chapter 13
for details.
34 Getting Started
System tab
Icon Description
About This is where you can see basic information such as the Windows Mobile version and type of processor
used on your device. You can also specify a name for your device.
Certificates See information about certificates that are installed on your device.
Clear Storage Tap this icon only when you need to remove all your data and files from the memory and reset
your device to factory default settings.
Clock & Alarms Set the device clock to the date and time of your locale or to a visiting time zone when you’re
traveling. Alarms can also be set at specified days and times of a week.
Customer Feedback Send feedback to the Customer Experience Improvement Program of Microsoft.
Device Information See information about the firmware version, hardware, identity, and the duration of calls
made on your device.
Encryption Allow files on your storage card to be encrypted. Encrypted files will be readable only on your
device.
Error Reporting Enable or disable the device's error reporting function. When this function is enabled and a
program error occurs, technical data about the state of the program and your computer will be logged in a text
file and delivered to Microsoft's technical support if you choose to send it.
External GPS Set the appropriate GPS communication ports, if required. You may need to do this when there
are programs on your device that access GPS data or you have connected a GPS receiver to your device. See
Help for details.
Key Lock Lock the buttons on your device except for the POWER button when the device is in Sleep mode. This
ensures you will not switch the device on by accident and consume unnecessary power.
Keypad QuickTasks Enable or disable the QuickTasks screen when you open the front panel of the device.
Long Press End Key Set the behavior of the END key when it is held down.
Managed Programs Download and install applications that are deployed by the System Center Mobile Device
Manager. Managed Programs also lets you view programs that were installed from the System Center Mobile
Device Manager.
Memory Check the device memory allocation status and memory card information. You can also stop currently
running programs.
Microphone AGC Adjust the volume of your voice automatically when you are recording.
Power Check the remaining battery power. You can also set the timeout for turning off the display (switching
device to Sleep mode) to conserve battery power.
Regional Settings Set the regional configuration to use, including the format for displaying numbers,
currency, date, and time on your device.
Remove Programs Remove programs that you installed on your device.
Screen Change the screen orientation, re-calibrate the screen, and change the screen text size.
Task Manager Stop running programs and set the Exit button ( ) to end programs immediately when you
tap the button. For more information, see "Using Task Manager" in Chapter 12.
TouchFLO You can enable or mute the finger scrolling and panning sound. See "TouchFLO settings" in this
chapter for details.
Windows Update Update Windows Mobile® on your device with security patches or fixes, if they are available.
Getting Started 35
Connections tab
Icon Description
Beam Set your device to receive incoming Bluetooth signals.
Bluetooth Turn Bluetooth on, set your device to visible mode, and scan for other Bluetooth devices.
Comm Manager Manage your device’s connections (including Bluetooth and ActiveSync), turn the phone on
or off, switch to ringer/vibration mode, enable or disable the Direct Push function, and more.
Connections Set up one or more types of modem connections for your device, such as phone dial-up, and
more, so that your device can connect to the Internet or a private local network.
Domain Enroll Enable the System Center Mobile Device Manager to manage your device by enrolling the
device in your company’s domain.
Network Cards Configure the network adapter of the device.
USB to PC Set the type of USB connection to your PC. Select the ActiveSync option for synchronizing data, or
use Disk Drive mode for transferring files.
1.13 Using your Device as a USB Drive
To easily carry media and other files with you, you can use your device’s storage card as a USB flash drive.
Touch Start > Settings > Connections tab > USB to PC and then select Disk Drive mode. This allows you to
copy files from your computer to the device’s storage card and vice versa faster.
Note You need to have a storage card installed on your device to be able to use your device as a disk drive.
When Disk Drive mode is used:
You will not be able to use your device to access les from the storage card or run applications that are
installed on the storage card while the device is connected to your PC.
Your PC will only connect to the device’s storage card. When you access your device from the PC, you
will only see the contents of the device’s storage card.
Remember to change back to ActiveSync mode when you need to synchronize data between your device
and your PC.
•
•
36 Getting Started
Chapter 2
Entering and Searching
Information
2.1 Entering Information
2.2 Using the 20-key QWERTY
Hardware Keyboard
2.3 Using the On-screen Keyboard
2.4 Using Touch Keyboard
2.5 Using Touch Keypad
2.6 Using Symbol Pad
2.7 Using Letter Recognizer
2.8 Using Block Recognizer
2.9 Using Transcriber
2.10 Searching Information
38 Entering and Searching Information
2.1 Entering Information
When you start a program or select a field that requires text or numbers, you can either use the 20-key
QWERTY hardware keyboard or one of the onscreen input methods to enter information.
20-key QWERTY hardware keyboard
To reveal the 20-key QWERTY keyboard, slide up the front panel of the device.
Slide up the front panel
Tip When dialing phone numbers, use the 20-key QWERTY keyboard.
Onscreen input methods
When you start a program or select a field that requires text or numbers, the Input Panel icon becomes
available on the menu bar.
Tap the Input Selector arrow (that appears next to the Input Panel icon) to open a menu where you
can select a text input method and customize input options. After selecting a text input method, the
corresponding Input Panel is then displayed and you can use it to enter text. To toggle between showing and
hiding the Input Panel, simply tap the Input Panel icon.
Input Panel
(Keyboard)
Input Selector
arrow
Input Panel icon
Icon Input method
Onscreen Keyboard
Touch Keyboard
Touch Keypad
Letter Recognizer or
Block Recognizer
Transcriber
Note Some text input methods may not be available in certain language versions of the device.
Entering and Searching Information 39
2.2 Using the 20-key QWERTY Hardware Keyboard
You can enter text, numbers, and symbols by using the 20-key QWERTY keyboard. When you select a field that
requires entering text or numbers, the phone automatically selects the appropriate input mode.
To change the input method, press and hold and select the input method you want to use on the menu.
You can do the following with the 20-key QWERTY keyboard:
• To use all uppercase letters, press twice. To change back to all lowercase letters, press again.
• To use a single uppercase letter, press and then press the corresponding key.
• To enter a number or symbol (labeled in white color), press and then press the corresponding key.
• Press to open the Symbol pad.
• Press to insert a hard return. Press to delete the previous character.
• Press and hold to access your voicemail.
• Press and hold to toggle between Vibrate and Ringer modes.
Multipress mode
In Multipress mode, you enter a character by pressing the key on which the character appears.
To enter text in Multipress mode
• To enter the rst character, press once. To enter the second character, press twice, and so on.
• To enter characters that are on the same key, wait for the highlight on the character to disappear before
you press the key again.
XT9 mode
To form a word in XT9 mode, press the keys that contain the letters you want. As you enter letters, XT9
analyses your keypresses and attempts to complete the word. XT9 also tries to predict your next word based
on previous sentences you have type.
To enter text in XT9 mode
1. Press and hold the key.
2. On the menu, select XT9 English.
To change XT9 settings, press and hold and on the menu, select XT9 Settings.
Tip To type in all uppercase letters, press the key twice.
While typing, words will appear at the bottom of the screen. Use the NAVIGATION CONTROL to choose the
word you want to insert and press ENTER.
Numeric mode
Input numbers by changing the input method to Numeric mode.
To enter numbers
1. Press and hold the key and select 123 on the menu.
2. On the keyboard, enter the number(s) you want.
40 Entering and Searching Information
2.3 Using the On-screen Keyboard
The on-screen Keyboard is available when text entry is possible. You can enter text by tapping keys on the
keyboard that are displayed on the screen.
To enter text using the on-screen Keyboard
1. In a program, tap the Input Selector arrow, and tap Keyboard.
2. Enter text by tapping keys on the on-screen Keyboard.
To enlarge the on-screen Keyboard
1. Tap the Input Selector arrow, then tap Options.
2. In the Input method list, select Keyboard.
3. Tap Large keys.
2.4 Using Touch Keyboard
The Touch Keyboard is an onscreen keyboard layout similar to the 20-key hardware keyboard of your device.
With the enlarged keys and input enhancement, you can type faster and more accurately using the Touch
Keyboard.
Tap to enter
letters or symbols.
Tap and hold to
immediately enter
the symbol on top
of the key.
Tap to enter
uppercase letters;
Tap twice to caps
lock.
Tap to cycle through the input
methods: XT9, multitap, and numeric.
The keyboard changes to a numeric
keyboard when in numeric mode.
Tap to open the Symbol pad.
See “Using Symbol Pad.”
Tap to create a
new line.
Tap to delete the
previous character.
Displays the word
candidate list in XT9
mode. Tap to insert
the word into the
message. Tap the
+ symbol to add a
word.
To use the Touch Keyboard
1. Start a program that accepts user input, such as Word Mobile.
2. Tap the Input Selector arrow, and tap Touch Keyboard.
3. Enter text by tapping keys on the onscreen Keyboard. The way you enter characters using the Touch
Keyboard is similar to using the 20-key keyboard; please see “Using the 20-key Hardware Keyboard”
earlier in this chapter for details.
Entering and Searching Information 41
To change Touch Keyboard and XT9 settings
1. Tap the Input Selector arrow, and tap Options.
2. In the Input Method tab, select Touch Keyboard in Input method and tap Options.
You can change the keyboard layout by changing the Language.
3. Tap XT9 Settings. On the XT9 Settings screen, select the options you want and tap Done.
2.5 Using Touch Keypad
The Touch Keypad is an onscreen keypad layout similar to a 12-key keypad with some additional keys. With
the enlarged keys and input enhancement, you can input text faster and more accurately using the Touch
Keypad.
Tap to enter letters or
numbers. Tap and hold
to immediately enter the
number on top of the key.
Tap to enter uppercase
letters; tap twice to caps
lock.
Tap to cycle through
the input methods: XT9,
multitap, and numeric.
The keypad changes to a
numeric keyboard when in
the numeric mode.
Tap to open the Symbol pad.
See “Using Symbol Pad.”
Tap to create a
new line.
Tap to delete the
previous character.
Displays the word
candidate list in XT9
mode. Tap to insert
the word into the
message. Tap the
+ symbol to add a
word.
To use the Touch Keypad
1. Start a program that accepts user input, such as Word Mobile.
2. Tap the Input Selector arrow, and tap Touch Keypad.
3. Enter text by tapping keys on the onscreen keypad. See “Multipress mode”, “XT9 mode”, and “Numeric
mode” to learn how to enter characters.
To change Touch Keypad and XT9 settings
Refer to “To change Touch Keyboard and XT9 settings.” Select Touch Keypad instead of Touch Keyboard in
Input method.
42 Entering and Searching Information
2.6 Using Symbol Pad
Symbol Pad provides a comprehensive list of common symbols such as parentheses, braces, currency signs,
and more, as well as punctuation marks and special characters. The Symbol pad is available for both Touch
Keyboard and Touch Keypad.
Tap a symbol to insert it into the message.
Tap to display the previous page of symbols.
Tap to display the next page of symbols.
Tap to close the Symbol Pad without
selecting any symbol.
Indicates the current page and the total
number of symbol pages. Tap to go to the
next page of symbols.
To open the Symbol Pad
While using Touch Keyboard or Touch Keypad, tap .
To change Symbol Pad settings
1. Tap the Input Selector arrow, and tap Options.
2. In the Input Method tab, select Touch Keyboard in Input method and tap Options.
3. Select the Turn on one-touch symbol entry check box to select only one symbol at a time and
immediately close the Symbol Pad after your selection. To be able to input several symbols at a time,
clear this check box.
2.7 Using Letter Recognizer
With Letter Recognizer, you can write individual letters, numbers, and punctuation, which are then
converted into typed text.
Note Letter Recognizer is available when text entry is possible.
To use Letter Recognizer
1. From a program, tap the Input Selector arrow, and tap Letter Recognizer.
2. Write characters, numbers, and symbols in the designated writing area.
• Enter uppercase letters by writing in the ABC (left) area of the box.
• Enter lowercase letters by writing in the abc (middle) area of the box.
• Enter numbers by writing in the 123 (right) area of the box.
• Enter punctuation and symbols by tapping in either area of the box and then writing the desired
character.
Tip For help with writing characters, tap the question mark near the writing area.
Entering and Searching Information 43
2.8 Using Block Recognizer
With Block Recognizer, you use a single stroke to write letters, numbers, symbols, and punctuation, which
are then converted into typed text.
Note Block Recognizer is available when text entry is possible.
To use Block Recognizer
1. From a program, tap the Input Selector arrow, and tap Block Recognizer.
2. Write characters, numbers, and symbols in the designated writing area.
• Enter letters by writing in the abc (left) area of the box.
• Enter numbers by writing in the 123 (right) area of the box.
• Enter symbols and punctuation by tapping in either area of the box and then writing the desired
character.
Tip For help with writing characters with Block Recognizer, tap the question mark near the writing area.
2.9 Using Transcriber
Transcriber is a handwriting recognition program that allows you to write in cursive, print, or a combination of
both.
To write using Transcriber
1. Start a program that accepts user input, such as Word Mobile.
2. Tap the Input Selector arrow, and tap Transcriber. The Transcriber introductory screen appears.
3. Position the cursor where you want text to appear.
4. Use the stylus to write anywhere on the screen. The handwriting will be converted to text shortly after
you lift the stylus from the screen.
To enter punctuation and symbols
Transcriber comes with an onscreen keyboard that provides an easy way to add punctuation or a special
symbol to existing text. To use this onscreen keyboard, tap on the Transcriber toolbar.
The keyboard remains visible until you tap the button again.
Tips • To reposition the keyboard, tap and hold the title bar, then drag to the desired location.
• When no text is selected, you can also open the keyboard by doing the gesture. For more information about
using Transcriber gestures, see Help on your device.
To edit text
1. In a program, draw a line from left to right across the text you want to edit.
2. After you lift the stylus from the screen, the line will disappear and the selected text will be highlighted.
3. Do either of the following:
• Rewrite the text.
• Use gestures to capitalize letters, insert a space, and so on. For information about using Transcriber
gestures, see Help on your device.
44 Entering and Searching Information
2.10 Searching Information
You can search for files and other items stored in My Documents folder or on an installed storage card of your
device. You can search by file name or by words located in the item. For example, you can search in e-mail
messages, notes, appointments, contacts, and tasks, as well as in online Help.
To search for a file or an item
1. Tap Start > Programs > Search.
2. In the Search for eld, you can:
• Enter the le name, word, or other information you want to search for.
• Tap the down arrow icon ( ), and from the list, select one item that you have looked for before.
3. In the Type eld, you can tap the down arrow icon ( ) and select a data type from the list to help
narrow your search.
4. Tap Search. The system then starts searching the matched les in the My Documents folder and
subfolders.
5. In the Results list, tap the item you want to open.
Note The storage card symbol ( or ) is displayed next to the names of files saved on a storage card.
46 Using Phone Features
3.1 Using the Phone
Like a standard mobile phone, you can use your device to make, receive, and keep track of calls and send
messages.
The Phone screen
From the Phone screen, you can access Call History, Speed Dial, and Phone settings. To open the Phone
screen, do one of the following:
• Tap Start > Programs > Phone; or
• Press the TALK button.TALK button.
• While on the Today screen, open the
keyboard and then press a numeric key.
TALK
button
Turn the phone function on and off
In many countries, you are required by law to turn off the phone while on board an aircraft.
To enable or disable the phone function
1. Tap Start > Settings > Connections tab > Comm Manager.
2. On the Comm Manager screen, tap the Phone button to enable or disable the phone function. When
enabled, the ON indicator is activated.
Airplane Mode
Another way to turn off the phone function is to switch your device to Airplane Mode.
To enable or disable Airplane Mode
When you enable Airplane Mode, it turns off all wireless radios on your device, which include the phone
function and Bluetooth. When you disable Airplane Mode, it turns the phone function back on. This also
restores the previous state of Bluetooth.
1. Tap Start > Settings > Connections tab > Comm Manager.
2. On the Comm Manager screen, tap the Airplane Mode button to enable or disable Airplane Mode.
When enabled, the ON indicator is activated.
Adjust the device volume
1. Tap the Speaker icon ( ).
2. Under Volume, do the following:
• Adjust the phone volume ( ) or device volume ( )
by moving the slider to the desired volume level..
• Tap On, Vibrate, or Off to change both the system and
ringer volume settings.
Using Phone Features 47
Notes To adjust the conversation phone volume, you must do it during a call. Adjusting the volume at another time will
affect the ring, notification, and MP3 sound levels.
When you activate Vibrate mode, sound will automatically be muted and your device will vibrate when an
incoming call is received. The Vibrate icon ( ) will appear in the title bar to indicate that Vibrate mode is
activated.
You can also use the VOLUME BUTTONS on the left side of the device to adjust the device volume or the volume
during a call.
3.2 Making a Call
With your device, you can make a call from Phone, Contacts, TouchFLO, Speed Dial, and Call History.
Make a call from Phone
1. While on the Today screen, open the keyboard of the device.
2. Start pressing the numeric keys on the keyboard to enter the
phone number.
3. Press the TALK button on your device to place the call.TALK button on your device to place the call.
Tip If you press a wrong number, press to erase each subsequent
digit of a number. To erase the entire number, press and hold .
Make a call from Contacts
Tap Contacts on the Today screen or tap Start > Contacts, then do one of the following:
• Press NAVIGATION up or down to select a contact, and press TALK.
• Tap the desired contact in the contacts list, and tap the phone number that you want to call.
• Tap and hold the desired contact, and on the shortcut menu, tap Call Work, Call Home, or Call Mobile.
To choose one of the numbers of a contact to dial
By default, the mobile phone number (m) of a contact is dialed when you make a call from Contacts. However,
you can specify that a different phone number is dialed instead.
1. Tap Start > Contacts.
2. Press NAVIGATION up or down to select the contact.
3. Press NAVIGATION left or right. The letters representing the number will change as you scroll through
them.
48 Using Phone Features
Make a call from TouchFLO
To place a call to a favorite contact that you added to TouchFLO’s Touch
Cube, follow these steps:
1. Open the Touch Cube by sliding your nger upward, starting
from the bottom of the touch screen where it shows a logo
image. (See Chapter 1 for detailed instructions.)
2. Slide your nger left or right to rotate the cube and navigate to
the screen where it shows your favorite contacts.
3. Touch the photo or name of the favorite contact to dial the
phone number.
Tip Touch and hold the contact to open the contact's summary.
Make a call from Call History
1. On the Phone screen, tap the Call History button ( ) or tap Menu > Call History.
2. You can either nger-scroll through all calls in Call History, or tap Menu > Filter and select from a
category of call types.
3. Finger-scroll to the desired contact or phone number, and tap Call.
One-touch Speed Dial
Use Speed Dial to call frequently-used numbers with a single tap. For example, if you assign a contact to the
location 2 in Speed Dial, you can simply tap and hold the key on the Phone screen to dial the contact’s
number.
To create a Speed Dial entry
Before you can create a Speed Dial entry, the number must already exist in Contacts.
1. On the Phone screen, tap Menu > Speed Dial.
2. Tap Menu > New.
3. Tap a contact. Select the phone number that you want to add to be assigned with a speed dial key.
4. In the Location box, select an available key to use as the speed dial key.
Note If you want to place a phone number in a position that is already occupied, the new number will replace the
number that is already there.
Tip To delete a Speed Dial entry, in the Speed Dial list, tap and hold the desired entry, and tap Delete.
To call voicemail
The location 1 is generally reserved for your voicemail. Tap and hold the key on the Phone screen to
call voicemail.
Using Phone Features 49
3.3 Receiving a Call
When you receive a phone call, a message will appear, giving you the option to either answer or ignore the
incoming call.
To answer or reject an incoming call
• To answer the call, tap Answer, or press TALK on the device.
• To reject the call, tap Ignore, or press END on the device.
• Open the keyboard.
Note For you to be able to answer calls by opening the keyboard, the Slide keypad to answer call check box must be
selected. To check, tap Start > Settings > Personal tab > Phone > Advanced tab.
To reject a call and send a text message
When you reject a call, you can choose to automatically send a text message to the caller.
1. On the Phone screen, tap Menu > Options > Advanced tab.
2. Select the Reject call with text message check box. Change the default message if needed.
After enabling Reject call with text message, you can:
• Tap Send Text when you receive a call to reject the call and send a text message to the caller.
• Tap Silence when you receive a call to mute the ringing sound without rejecting the call.
Note When the Reject call with text message option is selected, you need to press the TALK button on the device to
answer calls.
To end a call
Once an incoming or outgoing call is in progress, you can tap End or press END on the device to hang up.
To add a new phone number to your Contacts list after a call
If the number of the person who called is not in your Contacts list, you can choose to save the number after
you hang up. To enable this feature, tap Start > Settings > Personal tab > Phone > Advanced tab and select
the Add new phone number to Contacts at end of call check box. Selecting the checkbox will pop up a
message after a phone call ends to let you add the number to your Contacts list.
To check a missed call
You will see the icon on top of the screen when you missed a call. To check who the caller is:
• Tap the icon, then tap View.
• On the Phone screen, tap the Call History button ( ). You can view missed calls as well as incoming
and outgoing calls in Call History.
To put a call on hold
Your device notifies you when you have another incoming call, and gives you the choice of rejecting or
accepting the call. If you are already on a call and accept the new call, you can choose to switch between the
two callers, or set up a conference call between all three parties.
1. Tap Answer to take the second call, and put the rst one on hold.
2. To end the second call and return to the rst call, tap End or press END on the device.
50 Using Phone Features
To switch between two calls
Tap Swap.
To set up a conference call
1. Either put a call on hold, and dial a second number; or, accept a second incoming call when you already
have one in progress.
2. Tap Menu > Conference.
Note Not all service providers support conference calling. Contact your service provider for details.
To turn on and off the Speakerphone
The built-in Speakerphone on your device allows you to talk hands-free or lets other people listen to the
conversation.
• During a call, tap Speaker On, or press and hold TALK until the speakerphone turns on. The
speakerphone icon ( ) appears in the title bar.
• To turn o the speakerphone, tap Speaker Off, or press and hold TALK again until the speakerphone
turns o.
Warning! To avoid damage to your hearing, do not hold your device against your ear when the Speakerphone is
turned on.
To mute a call
You can turn off the microphone during a call, so that you can hear the caller but the caller cannot hear you.
• During a call, tap Mute.
• When the microphone is turned o, the mute icon ( ) appears on the screen. Tap Unmute to turn on
the microphone again.
To mute a call
You can turn off the microphone during a call, so that you can hear the caller but the caller cannot hear you.
• During a call, tap Mute.
• When the microphone is turned o, the mute icon ( ) appears on the screen. Tap Unmute to turn on
the microphone again.
3.4 Smart Dialing
Smart Dialing makes it easy for you to dial a phone
number.
When you start entering a phone number or contact name,
Smart Dialing will automatically search and sort the contact
entries in Contacts and the phone numbers in Call History
(including incoming, outgoing, and missed calls). You can
then select the desired number or contact from the filtered
list to dial.
Smart Dialing panel
Using Phone Features 51
Tips on using Smart Dialing
Smart Dialing starts looking for numbers or contacts that match the sequence you have entered. Below are
some tips on how to use Smart Dialing to quickly find a desired phone number or contact.
To find a phone number
• Simply enter the rst one or two digits to nd a phone number in Call History.
• Enter the rst three digits or more if you want to nd a phone number from the saved contacts on your
device.
To find a contact name
You can just enter the first letter of a contact’s first name or surname. Smart Dialing will search for the letter
starting from the first character of a contact name as well as from the character that appears after a space,
dash, or underscore in a contact name. For example, if you tap number “2” which is associated with [a, b, c]
on the Phone keypad, contact names such as the following will be considered matches: “Ben Miller”, “George
Adams”, “John-Carter”, “Carter, Ellen”, “Dixon, Allan”, “Thomas_Clark”, “JaneCampbell”.
If the matching list is long and you want to narrow down the search further, enter another letter. Using the
same example above, if you continue to tap “3” which is associated with [d, e, f], the matching list will be
narrowed down to the following names: “Ben Miller”, “George Adams”, “Carter, Ellen”, “Dixon, Allan”.
Tip You can also use the hardware keyboard to enter the name or number of the contact. Please note that the letters
assigned to numeric keys on the hardware keyboard is dierent from the onscreen keypad.
Make a call or send a text message using Smart Dialing
1. Press the TALK button on your device to open the Phone screen.
2. Begin entering the rst few numbers or characters.
When you start entering a number or letter, the Smart Dialing panel will display matches found.
3. In the Smart Dialing panel, browse the list by sliding your nger or the stylus up or down or by pressing
NAVIGATION up or down.
4. You can do one of the following:
• When the desired contact is selected, press the TALK button to place a call.the TALK button to place a call.TALK button to place a call.
• To send a text message to the selected contact, tap and hold the contact, and tap Send Text
Message, or tap Menu > Send Text Message.
• To call a different phone number associated with the selected contact, tap and hold the selected
contact, and tap the phone number you want to call.
Tip To view or edit information associated with the selected contact, tap the contact’s name on the shortcut menu
(applies only to entries stored in Contacts on your device).
Set up Smart Dialing
1. On the Phone screen, tap Menu > Smart Dialing Options.
2. On the Options tab, select the Enable Smart Dialing check box.
• Select the Automatically expand selected contact check box to enable a contact’s name and
phone number to be displayed when the contact is selected in the matching list.
• Select the Enable drag-scroll check box to scroll in the matched list by dragging.
• Select the Enable double-click for dialing check box to make a voice call by double-tapping the
item in the matched list.
52 Using Phone Features
3.5 Additional Dialing Information
Make an emergency call
Enter the international emergency number for your locale, and press the TALK button on your device.
Tip Additional emergency numbers may be included in your SIM card. Contact your service provider for details.
Make an international call
1. Press and hold on the hardware keyboard (or tap and hold the number 0 key on the phone screen)
until the + sign appears.
The + replaces the international prex of the country that you are calling.
2. Enter the full phone number you want to dial and press the TALK button on your device. The full phone
number includes country code, area code (without the leading zero, if any) and phone number.
54 Setting Up Your Device
4.1 Basic Settings
Time and date
To set the time and date
1. Tap Start > Settings > System tab > Clock & Alarms > Time tab.
2. Select the correct time zone and change the date or time.
Note During synchronization, the time on your device is updated with the time on your PC.
To set the time and date for a different location
If you visit or communicate with someone in a particular time zone often, you can select it as your visiting
time zone.
1. Tap Start > Settings > System tab > Clock & Alarms > Time tab.
2. Tap Visiting.
3. Select the correct time zone and change the time or date.
Regional settings
The style in which numbers, currency, dates, and times are displayed is specified in regional settings.
1. Tap Start > Settings > System tab > Regional Settings.
2. On the Region tab, select your region from the list.
Note This does not change the Operating System language of your device.
3. The region you select determines which options will be available on the other tabs.
4. To customize settings further, tap the appropriate tabs and select the desired options.
Display settings
To adjust screen brightness
On the Today screen, tap the Launcher tab of HTC Home, and then tap the Backlight Adjust icon
( ) to toggle among the brightness levels.
To set the backlight to dim after a time delay
1. Tap Start > Settings > System tab > Power > Advanced tab.
2. Under On external power select the Turn o backlight if device is not used for check box, and specify
the time delay.
To increase or decrease the size of text on the screen
1. Tap Start > Settings > System tab > Screen > Text Size tab.
2. Move the slider to increase or decrease the text size.
Setting Up Your Device 55
Device name
The device name is used to identify your device in the following situations:
• Synchronizing with a PC
• Connecting to a network
• Restoring information from a backup
Note If you synchronize multiple devices with the same PC, each device must have a unique name.
To change the device name
1. Tap Start > Settings > System tab > About.
2. Tap the Device ID tab.
3. Enter a name.
Note The device name must begin with a letter, consist of letters from A to Z, numbers from 0 to 9, and cannot
contain spaces. Use the underscore character to separate words.
Ringer settings
To change the ring type and ring tone
1. On the Phone screen, tap Menu > Options > Phone tab.
2. In the Ring type list, choose whether to be notied of incoming calls by a ring, a vibration, or a
combination of both.
3. In the Ring tone list, tap the sound you want to use.
Tip You can use *.wav, *.mid, *.mp3, *.wma, or other types of sound files that you downloaded from the Internet
or copied from your PC as ring tones. For a complete list of supported audio file formats for ring tones, see
"Specifications" in the Appendix.
To use your sound files as ring tones, copy them first to the /My Documents/My Ringtones folder on your
device, then select the sound from the Ring tone list of your device. For more information about copying files,
see Chapter 9.
Alarms and notifications
To set an alarm
1. Tap Start > Settings > System tab > Clock & Alarms > Alarms tab.
2. Tap <Description> and enter a name for the alarm.
3. Tap the day of the week for the alarm. You can select multiple days by tapping each desired day.
4. Tap the time to open a clock and set the time for the alarm.
5. Tap the alarm icon ( ) to specify the type of alarm you want. You can choose a ashing light, a
single sound, a repeating sound, or vibration.
6. If you choose to play a sound, tap the list next to the Play sound check box and tap the sound you
want.
56 Setting Up Your Device
To choose how to be notified about events or actions
1. Tap Start > Settings > Personal tab > Sounds & Notifications.
2. On the Sounds tab, choose how you want to be notied by selecting the appropriate check boxes.
3. On the Notifications tab, in Event, tap an event name and choose how you want to be notied by
selecting the appropriate check boxes. You can choose from several options, such as a special sound, a
message, or a ashing light.
Tip Turning off sounds and the flashing light helps conserve battery power.
4.2 Personalizing the Today Screen
The Today screen shows your upcoming appointments, active tasks, and information about incoming
messages. You can customize what to display on the Today screen.
To customize the Today screen
1. Tap Start > Settings > Personal tab > Today.
2. On the Appearance tab, select the desired theme for the background of the Today screen.
3. On the Items tab, select the items you want to appear on the Today screen.
To use a custom background image
You can use one of your own pictures as the background image on the Today screen.
1. Tap Start > Settings > Personal tab > Today.
2. Select the Use this picture as the background check box, and tap Browse to view a list of your
picture les.
3. Tap the le name of the picture you want to use.
4. Tap OK.
To display owner information
Having owner information displayed on the Today screen makes it easier for someone to return your device to
you if it is lost.
1. Tap Start > Settings > Personal tab > Owner Information.
2. Enter your personal information.
Tips • If you don’t see owner information on the Today screen, tap Start > Settings > Personal tab > Today. On the Items
tab, select the Owner Info check box.
• You can set your device to display the 'my info’ screen when your device is turned on. This screen shows your
complete personal information. To display the 'my info' screen, tap Start > Settings > Personal tab > Owner
Information > Options tab then select the Identification information check box.
To set options for displaying appointments on the Today screen
If you have a large number of appointments, you may want to specify the kind of appointments that are
displayed on the Today screen.
1. Tap Start > Settings > Personal tab > Today.
2. Tap the Items tab.
3. Select Calendar and tap Options.
4. Do any of the following:
Setting Up Your Device 57
• Select Next appointment to show only the next appointment in your schedule, or Upcoming
appointments to show multiple appointments.
• Clear the Display all day events check box if you do not want to display all-day events.
For more information about using Calendar, see Chapter 6 and 8.
To set options for displaying tasks on the Today screen
If you have a large number of tasks, you may want to specify the kind of tasks that are displayed on the Today
screen.
1. Tap Start > Settings > Personal tab > Today.
2. Tap the Items tab.
3. Select Tasks and tap Options.
4. Do any of the following:
• Under Display number of, select the type of tasks you want to appear on the Today screen.
• In the Category list, select whether to display only tasks assigned to a specific category or to
display all tasks.
For more information about creating tasks on your device, see Chapter 6.
Customize the Start menu
To customize the Start Menu
You can choose which items appear in the Start menu.
1. Tap Start > Settings > Personal tab > Menus.
2. Select the check boxes of the items you want to appear in the Start menu. You can select up to seven
items.
Tip You can also create folders and shortcuts to appear on the Start menu. Using Windows Explorer on your PC,
navigate to the /Windows/Start Menu folder of your device, then create the folders and shortcuts that you
want. You will see the added items on your device after you synchronize. For information about synchronizing
your device with the computer, see Chapter 5.
To change the Start Menu display size
The Large Start Menu feature enlarges the Start menu to make it easier to touch menu items with your fingers.
When the Large Start Menu is enabled, recently accessed programs are displayed as icons at the top of the
Start menu.
1. Tap Start > Settings > Personal tab > Large Start Menu.
2. Select the Enable large Start menu check box to enlarge the Start menu or clear the check box to
resume the normal display of the Start menu.
The End Key and the Quick List
Use the Long Press End Key setting to set the behavior of the END Key when it is held down.
1. Tap Start > Settings > System tab > Long Press End Key.
2. Do one of the following:
• Select the Always display the Quick List option to display the Quick List screen when you hold
down the END Key.; or
• Select the Automatically execute the selected action option and then select which function will
be executed automatically when you hold down the END Key. The functions available for selection
are the same as the ones in the Quick List.
58 Setting Up Your Device
4.3 Customizing Phone Services
To access phone settings and services
• Tap Start > Programs > Phone, then tap Menu > Options on the Phone screen; or
• Tap Start > Settings > Phone.
To enable optional phone services
Optional phone services can be easily activated and used on your device if provided by your wireless service
provider. Some of these services may not be available on your device. Contact your service provider first to ask
about the availability of these services.
1. Tap Start > Settings > Personal tab > Phone > Services tab.
2. Select the service you want to use, then tap Get Settings.
3. Select desired options for the service, then tap OK.
The following are some of the optional phone services that you may find on your device. For more
information about how to customize the settings of each service, see Help on your device.
Phone Services Usage
Location Setting Allow the mobile phone network to detect your current location via your device’s built-in GPS
chip. This is especially useful in times of emergency.
On the upper right of the Phone screen, one of these icons will be shown:
ON (your location can be detected)
OFF (your location cannot be detected except by 911)
Network Service Choose whether to restrict your device to phone calls from your home network only.
TTY Mode Allow the use of a TTY (teletypewriter) device with the PDA phone for users who are visually
or hearing impaired.
Time Synchronization Choose whether or not to synchronize the time on your device with the mobile network.
Tip For more information about how to customize the settings of optional phone services, see Help on your device.
4.4 Protecting Your Device
Protect your device with a password
You can help keep your data more secure by requiring a password every time the device is turned on.
To set a device password
1. Tap Start > Settings > Personal tab > Lock.
2. Select the Prompt if device unused for check box, and in the box to the right, select how long your
device must be idle before a password is required.
3. In the Password type box, select the type of password you would like to use. If your device is
congured to connect to a network, use an alphanumeric password for increased security for your
device.
4. Enter the password in both the Password and Confirm boxes.
5. Tap OK. The next time the device is turned on, you will be prompted to enter your password.
Setting Up Your Device 59
Notes • To ensure you can always make emergency calls, do not begin your password with the digits of your local
emergency number.
• If you entered a hint, the hint will be displayed after the wrong password is entered five times.
• Each time a wrong password is entered, the device response time gets longer until the device appears to be not
responding.
• If you forget your password, you can hard reset or clear the device memory. Before you do this, make sure you
back up your data and files so that you can restore them back to your device. For more information about hard
resetting the device and clearing the memory, see Chapter 12.
Encrypt files on your storage card
You can set your device to encrypt files as they are saved on the storage card.
1. Tap Start > Settings > System tab > Encryption.
2. Select Encrypt files placed on storage cards.
Notes • Encrypted files can be read only on the device that encrypted them.
• Encrypted files are opened just like other files, provided you are using the device that encrypted them. There is
no separate step for you to take to read these files.
60 Setting Up Your Device
62 Synchronizing Information With Your Computer
5.1 About Synchronization
You can take information from your computer wherever you go by synchronizing it to your device. The
following types of information can be synchronized between your computer and your device:
• Microsoft Outlook® information, which includes Outlook e-mail, contacts, calendar, tasks, and notes
• Media, such as pictures, music and video
• Favorites, which are the bookmarked links to your favorite Web sites
• Files, such as documents and other les
Before you can synchronize, you will first need to install and set up the synchronization software on your
computer. For more information, see “Setting Up Windows Mobile Device Center on Windows Vista®” and
“Setting Up ActiveSync® on Windows XP®”.
Ways to synchronize
After you have installed the synchronization software to your computer, connect and synchronize your device
with your computer by using one of the following methods:
• Connect and synchronize using the supplied USB sync cable.
Upon connecting the sync cable to your device and your computer, the synchronization process starts
automatically.
• Connect and synchronize using Bluetooth.
You must rst set up a Bluetooth partnership between your device and your computer before you
can synchronize information between them using Bluetooth. For more information about setting up
a Bluetooth partnership, see Chapter 10. For information about synchronizing through Bluetooth, see
“Synchronizing via Bluetooth” later in this chapter.
Try to synchronize frequently in order to keep information up-to-date in both your device and your computer.
Note You can also synchronize Outlook e-mail, contacts, calendar, and tasks on your device with the Exchange Server at
work. For more information about setting up your device to synchronize with your Exchange Server, see Chapter 8.
5.2
Setting Up Windows Mobile® Device Center on Windows Vista®
Microsoft Windows Mobile® Device Center is the replacement for Microsoft® ActiveSync® on Windows
Vista®.
Note Some versions of Windows Vista come with Windows Mobile Device Center already installed. If Windows Mobile
Device Center is not available on your Windows Vista, you can install it from the Getting Started Disc that came
with your device.
Set up synchronization in Windows Mobile Device Center
When you connect your device to your PC and start Windows Mobile Device Center for the first time, you
are asked to create a Windows Mobile partnership with your device. Follow the steps below to create a
partnership.
1. Connect your device to your PC. Windows Mobile Device Center congures itself and then opens.
2. On the license agreement screen, click Accept.
3. On the Windows Mobile Device Center’s Home screen, click Set up your device.
Synchronizing Information With Your Computer 63
Note Choose Connect without setting up your device if you only want to transfer media files, check for updates, and
explore your device but not sync Outlook information.
4. Select the items you want to synchronize, then click Next.
5. Enter a device name and click Set Up.
When you finish the setup wizard, Windows Mobile Device Center synchronizes your device automatically.
Notice that Outlook e-mails and other information will appear on your device after synchronization.
Use Windows Mobile Device Center
To open Windows Mobile Device Center, click Start > All Programs > Windows Mobile Device Center on
your Windows Vista computer.
On Windows Mobile Device Center, you can do the following:
• Click Mobile Device Settings to change synchronization settings.
• When you click Pictures, Music and Video > ___ new pictures/video clips are available for import,
a wizard guides you to tag and transfer photos from your device to the Photo Gallery on your Windows
Vista PC.
• Click Pictures, Music and Video > Add media to your device from Windows Media Player to
synchronize music and video les using Windows Media™ Player. For more information, see “Windows
Media® Player Mobile” in Chapter 11.
• Click File Management > Browse the contents of your device to view documents and les from your
device.
Note See Windows Mobile Device Center Help for more information.
64 Synchronizing Information With Your Computer
5.3 Setting Up ActiveSync® on Windows XP®
The Getting Started Disc that comes with your device contains Microsoft ActiveSync 4.5 or later. Follow the
steps in this section to install and set up ActiveSync on Windows XP or other compatible Windows systems.
Note For a list of compatible Windows systems, please go to
http://www.microsoft.com/windowsmobile/activesync/activesync45.mspx.
Install ActiveSync
1. Insert the Getting Started Disc into the disc drive on your PC.
2. Click Setup and Installation.
3. Select the ActiveSync check box and click Install.
4. Read the license terms and click Accept.
5. When installation is complete, click Done.
6. On the Getting Started with Windows Mobile screen, click Close.
Set up synchronization in ActiveSync
Follow the steps below to set up a synchronization partnership.
1. Connect your device to your PC. The Synchronization Setup Wizard automatically starts and guides you
to create a synchronization partnership. Click Next to proceed.
2. To synchronize your device with your PC, clear the Synchronize directly with a server running
Microsoft Exchange check box then click Next.
3. Select the information types that you want to synchronize then click Next.
4. Select or clear the Allow wireless data connections check box according to your preference.
5. Click Finish.
When you finish the wizard, ActiveSync synchronizes your device automatically. Notice that Outlook e-mails
and other information will appear on your device after synchronization.
5.4 Synchronizing With Your Computer
Connect and synchronize your device with your PC using the USB cable or Bluetooth connection.
Start and stop synchronization
You can manually synchronize either from your device or PC.
From your device
Tap Start > Programs > ActiveSync., then tap Sync.
To end synchronization before it completes, tap Stop.
Tip To delete a partnership with one PC completely, disconnect your device from that PC first. In ActiveSync on your
device, tap Menu > Options, tap the computer name, then tap Delete.
From Windows Mobile Device Center
1. Click Start > All Programs > Windows Mobile Device Center.
2. Click at the lower left of the Windows Mobile Device Center.
To end synchronization before it completes, click .
Synchronizing Information With Your Computer 65
From ActiveSync on your PC
When you connect your device to your PC, ActiveSync automatically opens on your PC and synchronizes.
• To manually start synchronization, click .
• To end synchronization before it completes, click .
Change which information is synchronized
You can change the information types and the amount of information to synchronize for each type either on
your device or your PC. Follow the steps below to change synchronization settings on your device.
Note Before changing synchronization settings on your device, disconnect it from your PC.
1. In ActiveSync on your device, tap Menu > Options.
2. Select the check box for any items you want to synchronize. If you cannot select a check box, you might
have to clear the check box for the same information type elsewhere in the list.
3. To change synchronization settings for an information type, for instance, E-mail, select it and tap
Settings.
You can then set the download size limit, specify the time period of information to download, and
more.
Notes • Some information types such as Favorites, Files and Media cannot be selected in ActiveSync Options on your
device. You can only select or clear these items from your PC’s Windows Mobile Device Center or ActiveSync.
• A PC can have sync partnerships with many different Windows Mobile powered devices, but a device can
have sync partnerships with at most two PCs only. To ensure that your device will synchronize properly with
both PCs, set up the second PC using the same synchronization settings you used on the first PC.
• Outlook e-mail can be synchronized with only one computer.
Troubleshoot sync connection problem
When the PC is connected to the Internet or a local network, in some cases, the PC may disconnect the
connection with your device in favor of the Internet or network connection.
If this happens, tap Start > Settings > Connections tab > USB to PC, then clear the Enable advanced
network functionality check box. This makes your PC utilize a serial USB connection with your device.
The USB to PC ( ) icon appears on the Today Screen when serial USB connection is used.
5.5 Synchronizing via Bluetooth
You can connect and synchronize your device with the PC using Bluetooth.
To synchronize with a computer via Bluetooth
1. Set up Windows Mobile Device Center or ActiveSync on your PC to synchronize through Bluetooth. See
the program’s Help for instructions.
2. On your device, tap Start > Programs > ActiveSync.
3. Make sure that Bluetooth on both your device and the computer are turned on and set to visible mode.
For more information, see “Bluetooth” in Chapter 10.
4. Tap Menu > Connect via Bluetooth. Make sure the Bluetooth function of both your device and the
computer are turned on and set to visible mode.
5. If this is the rst time you have connected to this computer via Bluetooth, you must rst complete the
Bluetooth wizard on your device and set up a Bluetooth partnership between your device and the
computer. For more information about creating a Bluetooth partnership, see “Bluetooth partnerships”
in Chapter 10.
66 Synchronizing Information With Your Computer
Notes • To preserve battery power, turn off Bluetooth when not in use.
• To connect and synchronize your device with a computer via Bluetooth, your computer must have built-in
Bluetooth or installed with a Bluetooth adapter or dongle.
5.6 Synchronizing Music and Video
If you want to carry your music or other digital media along with you while you travel, set up Microsoft®
Windows Media® Player on your computer to synchronize music and video with your device.
Other than selecting the Media information type to be synchronized, all media synchronization settings must
be set in Windows Media Player. Before media can be synchronized, you must do the following:
• Install Windows Media Player Version 11 on the PC. (Windows Media Player 11 works only in Windows
XP or later versions).
• Connect your device to the PC with a USB cable. If your device is currently connected using Bluetooth,
you must end that connection before media can be synchronized.
• Set up a sync partnership between your device and your PC’s Windows Media® Player.
For more information about using Windows Media® Player Mobile, see Chapter 11.
68 Organizing Contacts, Appointments, Tasks, and Other Information
6.1 Contacts
Contacts Contacts is your address book and information storage for the people and businesses you
communicate with. Store phone numbers, e-mail addresses, home addresses, and any other information that
relates to a contact, such as a birthday or an anniversary date. You can also add a picture or assign a ring tone
to a contact.
From the contact list, you can quickly communicate with people. Tap a contact in the list for a summary of
contact information. From there, you can call or send a message.
There are two types of contacts that you can create on your device:
• Outlook contacts. Contacts that are stored on your device, which can be created on your device or
synchronized with your PC or the Exchange Server.
• Windows Live contacts. Contacts that you communicate with using Windows Live Messenger or MSN.
Just like Outlook contacts, you can also enter complete information for a Windows Live contact. For
more information, see “Add Windows Live contacts” in Chapter 10.
Tip If you use Outlook on your PC, you can synchronize contacts between your device and PC.
Note You can only add Windows Live contacts after you have set up Windows Live on your device.
Add new contacts
To add a contact on your device
1. Tap Start > Contacts.
2. Tap New, then enter the contact information.
3. In the File as eld, choose how you want the contact name
to appear in the contact list.
4. To add a photo of the contact, tap Select a picture, then
select the picture le or tap Camera to take a photo of the
contact. This photo appears on the Phone screen when you
receive a call from the contact.
5 To assign a ring tone to the contact, tap the Ring tone eld,
scroll through the list of tones, then select a desired tone.
6. When nished, tap OK.
Notes • If someone who is not in your list of contacts calls you, you can create a contact from Call History by tapping
and holding a phone number and then tapping Save to Contacts from the shortcut menu.
• To save a phone number that is contained in a message, tap the phone number, then tap Menu > Save to
Contacts.
• To edit contact information, tap the contact name then tap Menu > Edit.
View, organize and search
To view contact information
1. Tap Start > Contacts.
2. Slide your nger upward on the touch screen to scroll down the contact list.
To scroll up the contact list, slide your nger downward on the touch screen.
Note For detailed instructions on how to use finger scrolling, see "Finger scrolling and finger panning" in Chapter 1.
Organizing Contacts, Appointments, Tasks, and Other Information 69
3. Touch the name of a contact to open his or her contact card.
4. On the contact card, you will see the last outgoing or incoming
call as well as detailed information such as phone numbers of the
contact, e-mail address, and more.
To group similar contacts
You can group similar contacts for easier management by assigning them to categories.
1. Create a new Outlook contact or edit an existing Outlook contact.
2. Tap Categories.
3. Select a preset category such as Business or Personal, or tap New to create your own category.
4. When nished, tap OK.
To view contacts by category
Tap Menu > Filter then select the desired category.
To find a contact on your device
There are several ways to find a contact when your contact list is long.
1. Tap Start > Contacts.
2. Do one of the following:
• On the Quick Scroll bar on the right of the screen (black vertical bar), scroll to or touch a letter to
go directly to the part of the Contacts list where contact names start with that letter.
Note You can disable the Quick Scroll bar by tapping Menu > Options and selecting the Show alphabetical index
check box. This will show the alphabetical index on top of the Contacts list. Begin entering a contact name in the
provided text box until the contact you want is displayed.
• Filter the list by categories. In the contact list, tap Menu > Filter, then tap a category you’ve
assigned to a contact. To show all contacts again, select All Contacts.
Share contact information
To send a contact’s details
You can quickly send contact information to another mobile phone or device through Bluetooth.
1. Tap Start > Contacts, then select a contact.
2. Tap Menu > Send Contact > Beam then select a device to send the contact to.
Note Before you can send, make sure Bluetooth is turned on and set to visible mode on your device and the target
mobile device. You can also send contact information to your PC. See "Bluetooth" in Chapter 10 for details.
70 Organizing Contacts, Appointments, Tasks, and Other Information
6.2 Calendar
Use Calendar to schedule appointments, including meetings and other events. Your appointments for the
day can be displayed on the Today screen. If you use Outlook on your PC, you can synchronize appointments
between your device and PC. You can also set Calendar to remind you of appointments with a sound or
flashing light, for example.
You can look at your appointments in several different views (Day, Week, Month, Year, and Agenda). To see
detailed appointment information in any view, tap the appointment.
Create appointments
To schedule an appointment
1. Tap Start > Calendar.
2. Tap Menu > New Appointment.
3. Enter a name for the appointment.
4. Do one of the following:
• If it is a special occasion such as a birthday or a daylong event, set the All Day option to Yes.
• If there is a time frame for the appointment, select the start and end dates and time.
5. Specify the type of category for your appointment, so that it can be grouped with other related
appointments. Tap Categories, then select a preset category (Business, Holiday, Personal, or Seasonal),
or tap New to create your own category.
6. When nished, tap OK to return to the calendar.
Notes • All-day events do not occupy blocks of time in Calendar; instead, they appear in banners at the top of the
calendar.
• To cancel an appointment, tap Menu > Delete Appointment.
Tip To have the time entered automatically in Day view, tap the time slot for the new appointment, and tap Menu >
New Appointment.
To set a default reminder for all new appointments
You can have a reminder automatically turned on for all new appointments you schedule.
1. Tap Start > Calendar.
2. Tap Menu > Tools > Options > Appointments tab.
3. Select the Set reminders for new items check box.
4. Set the time when you want the reminder to alert you.
5. Tap OK to return to the calendar.
Organizing Contacts, Appointments, Tasks, and Other Information 71
View appointments
By default, Calendar displays appointments in Agenda view. You can also look at your appointments in Day,
Week, Month, and Year views.
The highlighted hours
here indicate the time of
your appointments.
Tap to view appointment
details.
Agenda view
Tap to switch views.
Indicates that there is
a conflict with another
appointment.
• To see detailed appointment information in any view, tap the appointment.
• To view appointments by category, tap Menu > Filter then select the desired category.
• To change the default view that Calendar uses to display appointments, tap Menu > Tools > Options >
General tab. Tap the Start in box then choose the calendar view.
• When in Month view, you will see the following indicators:
Morning appointment Afternoon or evening appointment
All-day event Both morning and afternoon/evening appointments
Send appointments
To send a meeting request
Use Calendar to schedule meetings via e-mail with contacts who use Outlook or Outlook Mobile.
1. Tap Start > Calendar.
2. Schedule a new appointment, or open an existing one and tap Menu> Edit.
3. Tap Attendees, then tap Add Required Attendee or Add Optional Attendee and add the contacts
whom you want to invite.
You can specify if an attendee is required or optional only if your device is connected to a Microsoft
Exchange 2007 server. Otherwise, all attendees are designated as required. For more information, see
Chapter 8.
4. When you have nished adding attendees, tap Done.
5. Tap OK to send.
Tip To choose the e-mail account to use for sending meeting requests, tap
Menu > Tools > Options > Appointments tab. Tap the Send meeting requests via box and choose to send via
your Outlook E-mail, POP3/IMAP4 or Windows Live account.
Notes • If you’re sending the meeting request using your Outlook E-mail account, it will be sent to the attendees the
next time you synchronize your device with your PC or Exchange Server.
• When attendees accept your meeting request, the meeting is automatically added to their schedules. When
their response is sent back to you, your calendar is updated as well.
72 Organizing Contacts, Appointments, Tasks, and Other Information
6.3 Tasks
Use Tasks to keep track of things you need to do. A task can occur once or repeatedly (recurring). You can set
reminders for your tasks and you can organize them using categories.
Your tasks are displayed in a task list. Overdue tasks are displayed in red.
To create a task
1. Tap Start > Programs > Tasks.
2. Tap Menu > New Task, enter a subject for the task, and ll in information such as start and due dates,
priority, and so on.
3. Specify the type of category for your task, so that it can be grouped with other related tasks. Tap
Categories, then select a preset category (Business, Holiday, Personal, or Seasonal), or tap New to
create your own category.
4. When nished, tap OK.
Tip You can easily create a short, to-do type task. Simply tap the Tap here to add a new task box, enter a subject, and
tap the Enter button on the on-screen keyboard. If the task entry box is not available, tap Menu > Options and
select the Show Tasks entry bar check box.
To change the priority of a task
Before you can sort tasks by priority, you need to specify a priority level for each task.
1. Tap Start > Programs > Tasks.
2. Tap the task you want to change the priority for.
3. Tap Edit, and in the Priority box, tap a priority level.
4. Tap OK to return to the task list.
Note All new tasks are assigned a Normal priority by default.
To set a default reminder for all new tasks
1. Tap Start > Programs > Tasks.
2. Tap Menu > Options.
3. Select the Set reminders for new items check box.
4. Tap OK to return to the task list.
Note The new tasks must have due dates set in order for the reminder to take effect.
To show start and due dates in the task list
1. Tap Start > Programs > Tasks.
2. Tap Menu > Options.
3. Select the Show start and due dates check box.
4. Tap OK.
To locate a task
When your list of tasks is long, you can display a subset of the tasks or sort the list to quickly find a specific
task.
1. Tap Start > Programs > Tasks.
2. In the task list, do one of the following:
• Sort the list. Tap Menu > Sort By, and tap a sort option.
• Filter the list by category. Tap Menu > Filter, and tap the category you want displayed.
Tip To filter your tasks further, tap Menu > Filter > Active Tasks or Completed Tasks.
Organizing Contacts, Appointments, Tasks, and Other Information 73
6.4 Notes
Notes helps you to quickly capture thoughts, questions, reminders, to-do lists, and meeting notes. You
can create handwritten and typed notes, record voice notes, convert handwritten notes to text for easy
readability, and send notes to others.
To create a note
1. Tap Start > Programs > Notes. In the note list, tap New.
2. Tap the Input Selector arrow next to the Input Method icon on the menu bar, tap the input method
you want, and enter your text.
3. If the Input Selector arrow is not displayed, tap the Input Method icon.
4. When nished, tap OK to return to the note list.
Notes • To select handwritten text, tap and hold next to the writing. As soon as dots appear, and before they form a
complete circle, quickly drag across the writing.
• If a letter crosses three ruled lines, it is treated as a drawing rather than text.
To draw in a note
1. Tap Start > Programs > Notes.
2. In the note list, tap New.
3. To draw on the screen, use the stylus like a pen.
4. A selection box appears around your drawing.
5. When nished, tap OK to return to the note list.
Note To select a drawing (for example, to copy or delete it), tap and hold
the drawing briefly. When you lift the stylus, the drawing is selected.
To record a voice note
You can create a stand-alone recording (voice note) or you can add a recording to a note.
1. Tap Start > Programs > Notes.
2. Do one of the following:
• To create a stand-alone recording, record from the note list.
• To add a recording to a note, create or open a note.
3. If you do not see the Recording toolbar, tap Menu > View Recording Toolbar.
4. Tap the Record icon ( ) to begin recording your voice. Tap the Stop icon ( ) when nished
recording.
To change recording formats
1. Tap Start > Settings > Personal tab > Input.
2. Tap the Options tab, and select the desired format you want in the Voice recording format list.
3. Tap OK.
Note
You can also change recording formats from within Notes. In the note list, tap Menu > Options > Global Input
Options link (at the bottom of the page), then tap the Options tab.
74 Organizing Contacts, Appointments, Tasks, and Other Information
6.5 Voice Recorder
Voice Recorder lets you record your voice and then quickly send it in an e-mail message, send it via
Bluetooth, or set the recorded voice as your ringtone.
Note
Voice Recorder saves voice recordings in AMR-NB (Adaptive Multi-Rate Narrowband) format only. This is a common
speech audio format used in mobile devices.
To record your voice
1. Tap Start > Programs > Voice Recorder.
2. Hold the device’s microphone near your mouth.
3. Tap Record or to start recording a voice clip. Tap Stop to end the recording.
All recordings are saved in the My Voices folder by default. You can choose another folder to save voice
recordings by tapping beside the folder name on the top-left of the screen and then in the menu, choose the
folder where to save future recordings.
To play back a voice recording
• On the Voice Recorder screen, select a voice recording then tap .
Ti[s • Tap to increase the volume; tap to decrease the volume.
• Tap to toggle between muting and unmuting the volume.
To send the voice recording via e-mail
• Select a voice recording then tap Menu > Send > Outlook E-mail. This creates a new Outlook e-mail
message with the voice recording inserted as a le attachment.
See “Using E-mail” in Chapter 7 to learn how to send e-mail.
To send the voice recording via Bluetooth
1. Select the voice recording(s) you want to send, and then tap Menu > Beam File.
2. Tap the device you want to send the voice recording(s) to.
3. On the other device, accept the le transfer to receive the le.
To set the voice recording as a ring tone
Select the desired voice recording then tap Menu > Set as Ringtone.
To rename or move a recording
1. Select a voice recording then tap Menu > Rename/Move.
2. Enter the new Name for the voice recording.
3. To move the voice recording, select the new destination Folder and Location.
4. Tap OK.
76 Exchanging Messages
7.1 Messaging
Messaging is where your text messages (SMS) and e-mails are located. When you receive new messages, you
can open them from the Today screen. Simply tap the type of message that you want to open.
New e-mail messages New text messages
To select a messaging account
Do one of the following:
• Tap Start > Messaging. The Account Picker screen then
appears where you can select an account.
• While you are in a message list of a certain account, for
example Text/Multimedia, tap Menu > Go To to switch to
other types of messaging accounts.
To configure message account settings
• Tap Menu > Options on the Account Picker screen; or
• Tap Menu > Tools > Options while you’re in a message list. Account Picker screen
To automatically add a signature in outgoing messages
You can automatically add your name and other information as your signature in outgoing SMS and e-mail
messages by following these steps:
Tip You need to specify your signature for each type of messaging accounts.
1. Tap Start > Messaging, then tap Menu > Options.
2. Tap Signatures.
3. Select a type of messaging account in which to add a signature.
4. Select the Use signature with this account check box.
5. In the provided text box, enter the information that will be displayed as your signature.
6. If you want the signature to be added whenever you reply or forward messages, select the Use when
replying and forwarding check box.
7. Repeat steps 3 to 6 to add a signature to the other types of messaging accounts.
Exchanging Messages 77
7.2 Text Messages
Send text messages
To compose and send a text message
1. You can select a contact either from TouchFLO’s Touch Cube or from Contacts.
Select a favorite contact from TouchFLO’s Touch Cube:
a. Open the Touch Cube by sliding your nger upward, starting from the bottom of the touch screen
where it shows a logo image. (See Chapter 1 for detailed instructions.)
b. Slide your nger left or right to rotate the cube and navigate to the screen where it shows your
favorite contacts.
c. Touch and hold the photo or name of the favorite contact to whom you want to send a text
message. The contact card of your selected contact is then displayed.
Touch and hold
d. Touch the item that shows Send text message.
Select from Contacts:
a. Tap Start > Contacts.
b. Slide your nger upward on the touch screen to scroll down the contact list. See “Finger scrolling
and nger panning” in Chapter 1 for more details on nger scrolling.
c. Touch the contact’s name to open his or her contact card.
d. On the contact card, touch the item that shows Send text message.
2. A new text message is then created.
To add more recipients,
enter their mobile phone numbers
in the To eld, separating them with a semicolon. You can
also tap To if you want to add mobile phone numbers from
Contacts.
3. Enter your message.
•
To quickly add common messages, tap Menu > My
Text and tap a desired message.
• To check the spelling, tap Menu > Spell Check.
4. Tap Send.
78 Exchanging Messages
Notes • For more information about entering text and symbols, see Chapter 2.
• If you want to know when a text message is received, before sending the message that you are composing, tap
Menu > Message Options then select the Request message delivery notification check box.
• To always receive a delivery notification, tap Menu > Tools > Options in the text message list, tap Text Messages
then select the Request delivery notifications check box.
Manage text messages
Text messages that are sent to and received from a contact (or number) are grouped as a single thread in
your inbox. Threaded SMS lets you see exchanged messages (similar to a chat program) with a contact on the
screen
To reply to a text message
1. In the Text Messages inbox, tap a message thread to open it.
2. At the bottom of the screen, type your reply message and then tap Send.
Enter your reply
message here
To delete a message in the thread
1. In the Text Messages inbox, tap a message thread to open it.
2. Use the Navigation Up or Down control to select a message in the thread that you want to delete.
3. Tap Menu > Delete.
To delete all messages in a thread
1. In the Text Messages inbox, select a message thread using the Navigation Up or Down control.
2. Tap Delete.
7.3 Types of E-mail Accounts
You can set up the following types of e-mail accounts on your device:
• Outlook e-mail that you sync with your PC or the Exchange Server.
• E-mail account that you have from an Internet Service Provider (ISP).
• Web-based e-mail accounts such as Yahoo!® Mail, AOL®, etc.
• Work account that you access using a VPN connection.
Exchanging Messages 79
Set up your device to synchronize Outlook e-mail with the computer
If you have installed the synchronization software on your PC and created a partnership with your device,
then your device is ready to send and receive Outlook e-mail.
If you have not yet installed the synchronization software nor created a partnership, please do so by following
the procedures in Chapter 5.
Tip To set up your company e-mail account so that you can access Outlook e-mail messages wirelessly, you must set
up your device to synchronize via an over-the-air connection with your company’s Exchange Server. For more
information about synchronizing with your company e-mail server, see Chapter 8.
7.4 E-mail Setup Wizard
Windows Mobile’s E-mail Setup wizard walks you through the processof setting up your e-mail account. It
has an Auto Setup feature which can automatically set up your e-mail account based on the e-mail address
and password that you enter, if your e-mail provider settings are preconfigured on your device. If the settings
are not found on your device, Auto Setup then attempts to retrieve the settings online for which you may be
charged when your device connects to the Internet and downloads them. If it cannot find the e-mail settings
online, you need to enter them manually.
Tip For more information about synchronizing with your company e-mail server, see Chapter 8.
Set up a POP3 or IMAP4 e-mail account
Set up a POP3 or IMAP4 e-mail account on your device if you have an e-mail account from an Internet service
provider (ISP) or other e-mail provider, or a web-based account such as Gmail, Yahoo! Mail Plus, etc. You can
also add a work account that you access using a VPN server connection as a POP3/IMAP4 account.
1. Tap Start > Messaging > Setup E-mail.
2. Enter your E-mail address and the Password for your e-mail account and select the Save password
option. Tap Next.
3. If e-mail provider settings are found precongured on your device, the E-mail Setup wizard shows a
successful message. Tap Next.
If the settings are not found on your device, select the Try to get e-mail settings automatically from
the Internet checkbox to nd and download e-mail server settings from the Internet and then tap
Next.
4. Enter Your name and the Account display name and then tap Next.
Note If the E-mail Setup wizard was unsuccessful in finding and downloading settings from the Internet, select
Internet e-mail from the Your e-mail provider list on the next screen. You will be asked to enter e-mail
server settings. See “To specify e-mail server settings” for details.
5. In the Automatic Send/Receive list, choose how frequent you want e-mail messages to be
automatically sent and downloaded on your device.
Note Tap Review all download settings to select download options, set the e-mail format as HTML or plain
text, and more. For more information, see “To customize download and format settings."
6. Tap Finish.
To specify e-mail server settings
If Auto Setup is unsuccessful, contact your ISP or e-mail provider for the Incoming mail server and outgoing
mail server settings so you can enter them on your device.
Other options that you can select include the following:
• Select the Outgoing server requires authentication check box, if required by your provider.
80 Exchanging Messages
• If the outgoing e-mail server requires a dierent user name and password for sending e-mail, clear the
Use the same user name and password for sending e-mail check box. You will be prompted to enter
these information.
• Tap Advanced Server Settings, then select the Require SSL check boxes if your e-mail provider
uses an SSL connection for more secured e-mail. From the Network connection list, select the data
connection that you use for connecting to the Internet.
To customize download and format settings
Before you tap Finish when setting up your POP3 or IMAP4 e-mail account, you can tap Review all download
settings to choose download options, message format, and other settings.
Options Description
Automatic Send/Receive You can select a time interval for connecting to the Internet automatically to send
and receive messages.
Download messages Set the number of days of messages that you want to be downloaded to your
device.
Send/receive when I click Send By default, messages are immediately delivered when you tap Send. If you prefer
to save outgoing messages to the Outbox folder first, clear the check box. (In this
case, you will need to manually send messages by tapping Menu > Send/Receive).
Use automatic send/receive
schedule when roaming
This allows your device to data roam when there is a set time interval for
connecting to the Internet automatically. Since this may result in higher
connection costs, you may want to leave the check box cleared.
When deleting messages Choose whether to delete messages from the mail server when you delete them on
your device.
Message format Select HTML or Plain Text.
Message download limit Select the e-mail download size. If you have large volumes of e-mail, use a lower
size or select to download headers only.
Download attachments Select the attachment download size. You can also select to download all
attachments or none at all.
Set up a custom domain e-mail
When you are using an e-mail domain name that is hosted by a different e-mail provider (for example, your
e-mail address may be Benjamin@startup.com but Email.com hosts the e-mail account and provides e-mail
services), select the Custom Domain option in the E-mail Setup wizard to set up your e-mail account on your
device.
1. Add a new e-mail account. See “Add an e-mail account” for instructions.
2. Enter your E-mail address and the Password for your e-mail account and select the Save password
option. Tap Next.
3. Clear the Try to get e-mail settings automatically from the Internet and then tap Next.
4. In Your e-mail provider, select Custom domain and then tap Next.
5. Enter the domain of your e-mail provider and then tap Next.
6. The E-mail Setup wizard then tries to nd the e-mail provider settings on your device or from the Internet.
If the settings are found, it shows a successful message. Tap Next.
7. Enter Your name and the Account display name and then tap Next.
Note If the E-mail Setup wizard was unsuccessful in nding the settings, you will be prompted to enter e-
mail server settings on the succeeding screens. See “To specify e-mail server settings” for details.
8. In the Automatic Send/Receive list, choose how frequent you want e-mail messages to be automatically
sent and downloaded on your device.
Exchanging Messages 81
Note Tap Review all download settings to select download options, set the e-mail format as HTML or plain
text, and more. For more information, see “To customize download and format settings."
9. Tap Finish.
7.5 Using E-mail
After setting up e-mail accounts on your device, you can start sending and receiving e-mail messages.
Create and send messages
To compose and send a message
1. You can select a contact either from TouchFLO’s Touch Cube or from Contacts.
Select a favorite contact from TouchFLO’s Touch Cube:
a. Open the Touch Cube by sliding your nger upward, starting from the bottom of the touch screen
where it shows a logo image. (See Chapter 1 for detailed instructions.)
b. Slide your nger left or right to rotate the cube and navigate to the screen where it shows your
favorite contacts.
c. Touch and hold the photo or name of the favorite contact to whom you want to send an email.
The contact card of your selected contact is then displayed.
Touch and hold
d. Touch the item that shows Send e-mail.
Select from Contacts:
a. Tap Start > Contacts.
b. Slide your nger upward on the touch screen to scroll down the contact list. See “Finger scrolling
and nger panning” in Chapter 1 for more details on nger scrolling.
c. Touch the contact’s name to open his or her contact card.
d. On the contact card, touch the item that shows Send e-mail.
2. If you have several e-mail accounts, the Account Picker screen will appear. Select an e-mail account that
you want to use.
3. A new e-mail message is then created.
To add more recipients, enter their e-mail addresses, separating them with a semicolon. You can also
tap To if you want to add e-mail addresses stored in Contacts.
4. Enter a subject and compose your message. To quickly add common messages, tap Menu > My Text
and tap a desired message.
5. To check the spelling, tap Menu > Spell Check.
6. Tap Send.
82 Exchanging Messages
Tips • To set the priority, tap Menu > Message Options.
• If you are working offline, e-mail messages are moved to the Outbox folder and will be sent the next time you
connect.
To add an attachment to a message
1. In the message that you are composing, tap Menu > Insert and tap the item you want to attach:
Picture, Voice Note, or File.
2. Select the le you want to attach, or record a voice note.
Filter the Inbox message list
When the Inbox on your device is full of messages, it may be hard to browse and locate a desired message.
You can filter your Inbox to only display the messages that contain a particular sender or subject you are
searching for.
To filter your Inbox
Enter the sender name or e-mail subject you want to look for using the on-screen keyboard. As you tap keys,
the message list narrows down to the conditions you have set.
For example, tapping “S”, then “A” narrows
the list to only the e-mails that contain
sender names and e-mail subjects that
start with “SA.”
View and reply to messages
To read an incoming message
By default, only the first few kilobytes of a message are shown when you open an incoming message. To read
the whole message do one of the following:
• Finger-scroll to the end of the message and tap Get entire message and any attachments (POP3 e-
mail account) or Get the rest of this message (Outlook/IMAP4 e-mail account).
• Tap Menu > Download Message.
The message will be downloaded the next time you tap Menu > Send/Receive to send and receive e-mail.
Note The Fetch Mail feature, which is avaiable for POP3 and IMAP4 Internet e-mail accounts, downloads an
entire e-mail without the need for you to performa full synchronization. This limits the download to just
the e-mail message that you want and helps save data cost.
Fetch Mail is also available for Outlook E-mail. See "Instant download through Fetch Mail" in Chapter 8 for
details.
Download may take some time, depending on the speed of your Internet connection, size of the whole
e-mail, and whether file attachments are automatically downloaded.
Exchanging Messages 83
To download an attachment
An attachment appears below the subject of the message. Tapping the attachment opens the attachment if it
has been fully downloaded or marks it for download the next time you send and receive e-mail.
Notes • If there are multiple attachments in the message, all attachments are downloaded.
• For information about setting your device to automatically download file attachments, see "Customize e-mail
settings".
• If your company is running Microsoft Exchange Server 2007, the attachment downloads immediately, without
waiting until the next time you synchronize. For more information about working with company e-mails, see
Chapter 8.
To reply to or forward a message
1. Open the message and tap Menu > Reply, Menu > Reply All, or Menu > Forward.
2. Enter your response then tap Send.
Tip Whenever you reply to all the recipients of an Outlook e-mail, your own e-mail address will also be added to the
recipient list. You can customize ActiveSync so that your e-mail address will be excluded. To do so, tap Menu >
Options in ActiveSync, select the E-mail item, tap Settings, then tap Advanced. In the My e-mail addresses
text box, enter your e-mail address(es). If you want to enter more than one e-mail address, separate the e-mail
addresses with a semi-colon.
To view and reply to HTML e-mails
You can receive, view and reply to HTML e-mails from any type of e-mail account. The HTML format is retained,
without layout shifting or resizing.
Note HTML e-mail support in Outlook Mobile is available only if your company is using Microsoft Exchange Server
2007.
1. Set the message format to HTML. To nd out how to set the message format, see “Customize e-mail
settings”.
2. Tap Start > Messaging, select your e-mail account, and open an HTML e-mail that you received.
3. Tap the Tap to scroll right option to be able to scroll sideways and get a complete horizontal view of
the message.
4. Tap Get the rest of this message that’s shown at the bottom of the message to download and view
the whole message.
5. If the e-mail does not download immediately, tap Menu > Send/Receive.
6. If images do not immediately appear on the message, tap Internet pictures blocked then tap
Download Internet pictures.
7. Tap Menu and choose whether to reply or forward the message.
8. Enter your response then tap Send.
Tip E-mail can contain hyperlinks to Web pages.
Download messages
The manner in which you download messages depends on the type of e-mail account you have.
To send and receive e-mail for an Outlook account
1. Tap Start > Programs > ActiveSync.
2. Connect your device to your PC using the USB cable or Bluetooth.
Otherwise, connect wirelessly if you are synchronizing Outlook e-mail with the Exchange Server. For
more information, see Chapter 8.
3. Synchronization automatically begins, and your device sends and receives Outlook e-mail.
84 Exchanging Messages
Tip You can also manually synchronize anytime by tapping Sync in ActiveSync or Menu > Send/Receive in Outlook
Mobile.
To send and receive e-mail for an Outlook account
1. Connect your device to your PC using the USB cable or Bluetooth.
Otherwise, connect wirelessly if you are synchronizing Outlook
e-mail with the Exchange Server. For more information, see Chapter 8.
2. Synchronization automatically begins, and your device sends and receives Outlook e-mail.
Tip You can also manually synchronize anytime by tapping Sync in ActiveSync or Menu > Send/Receive in Outlook
Mobile.
To send and receive e-mail for a POP3/IMAP4 account
If you have an e-mail account with an ISP or a work account that you access using a VPN server connection,
you send and receive messages through a remote e-mail server. Before sending and downloading messages,
you need to connect to the Internet or your corporate network.
1. Tap Start > Messaging and tap your POP3 or IMAP4 e-mail account.
2. Tap Menu > Send/Receive. Messages on your device and e-mail server are synchronized: new
messages are downloaded to the device Inbox folder, messages in the Outbox folder are sent, and
messages deleted from the server are removed from the device Inbox.
Customize e-mail settings
To change the download size and format for Outlook e-mail
1. Disconnect your device from the computer.
2. Tap Start > Programs > ActiveSync.
3. Tap Menu > Options, select E-mail, then tap Settings.
4. On the E-mail Sync Options screen:
• Under Download size limit, select the desired e-mail size.
• Under Message format, select HTML or Plain text.
5. Close ActiveSync and reconnect your device to the computer.
To change the download size and format for POP3/IMAP4 e-mail
1. Tap Menu > Options on the Account Picker screen, or tap Menu > Tools > Options while you’re in a
message list.
2. Tap your e-mail account.
3. Tap Download Size Settings.
4. Under Message format, select HTML or Plain text.
5. Under Download size limit, select the desired e-mail size.
6. Tap Done.
To automatically receive attachments on Outlook e-mails
1. Tap Start > Programs > ActiveSync.
2. Tap Menu > Options.
3. Tap E-mail > Settings, then select Include file attachments.
Exchanging Messages 85
To automatically receive attachments on IMAP4 e-mails
1. Tap Start > Messaging.
2. Tap Menu > Options.
3. Tap the name of your IMAP4 account.
4. Keep tapping Next until you see the Download attachments item on the screen.
5. Select a download size from the Download attachments smaller than list box.
6. Tap Finish.
To store attachments on a storage card
1. Tap Start > Messaging.
2. Tap Menu > Options > Storage tab.
3. Select the When available, use the storage card to store attachments check box.
86 Exchanging Messages
88 Working With Company E-mail and Meeting Appointments
8.1 Synchronizing Your Device with the Exchange Server
To keep up-to-date with your company e-mail while you’re out of the office, you can connect your device
to the Internet wirelessly and synchronize it with your company’s Exchange Server. You can also access your
company addressbook anytime. Your company must have a mail server that is running Microsoft Exchange
Server with Exchange ActiveSync.
Set up an Exchange Server connection
Before you can synchronize or access information on the Exchange Server, you need to set up an Exchange
Server connection on your device. You need to get the following information from your network administrator
and enter them on your device:
• Exchange Server name (must be the Outlook Web Access server name)
• Domain name
• User name and password that you use at work
If you have not synchronized your device with your PC, follow these steps to set up an Exchange Server
connection.
1. Tap Start > Messaging > Setup E-mail.
2. Enter the E-mail address and Password for the e-mail account and select the Save password option.
Tap Next.
3. Clear the Try to get e-mail settings automatically from the Internet option and tap Next.
4. In Your e-mail provider, select Exchange server and tap Next.
5. Tap Next again.
6. Select the Attempt to detect Exchange Server Settings automatically option and tap Next.
7. Enter the Domain name and tap Next.
8. In Server address, enter the Exchange Server address and tap Next.
9. Select the items that you want to sync with the Exchange Server.
Tips • To change synchronization settings of an information item, for example, E-mail, select the item, then tap
Settings.
• To change the rules for resolving synchronization conflicts, tap Menu > Advanced.
10. Tap Finish.
Start synchronization
Before you start synchronizing with the Exchange Server, make sure your device has been set up with a data
connection to the Internet so that you can synchronize wirelessly. For more information about connections,
see Chapter 10.
After you finish setting up an Exchange Server connection, your device automatically starts synchronization.
You can manually start synchronization anytime by tapping Sync in ActiveSync.
Note If you connect your device to your office computer via a USB or Bluetooth connection, you can use this
connection to the PC to “pass through” to the network and download Outlook e-mails and other information to
your device.
Working With Company E-mail and Meeting Appointments 89
8.2 Working With Company E-mail
Your device gives you instant access to your company e-mail and lets you manage your messages easier.
Direct Push, Fetch Mail, Remote e-mail search, and e-mail flags are just some of the tools you can use to
manage your e-mails.
Note Some messaging features depend on the Microsoft Exchange Server version used in your company. Please
check with your network administrator for the availability of these features.
Automatic synchronization through Direct Push
Direct Push technology (push e-mail feature) enables you to receive new e-mails on your device as soon as
they arrive in your Inbox on the Exchange Server. With this feature, items such as contacts, calendar and tasks
are also immediately updated onto your device when these items have been changed or new entries have
been added on the Exchange Server. To make Direct Push work, you need to have a data connection on your
device.
You need to perform a full synchronization between your device and the Exchange Server first before Direct
Push can be enabled.
Requirement The Direct Push feature works for your device only if your company is using Microsoft Exchange
Server 2003 Service Pack 2 (SP2) with Exchange ActiveSync or higher version.
To enable Direct Push via Comm Manager
1. Tap Start > Settings > Connections tab > Comm Manager.
2. On the Comm Manager screen, tap the Microsoft Direct Push button to enable or disable the Direct
Push function. When enabled, the ON indicator is activated.
To enable Direct Push via ActiveSync
1. In ActiveSync on your device, tap Menu > Schedule.
2. Select As items arrive in the Peak times and Off-peak times boxes.
Scheduled synchronization
If you do not want to use Direct Push, you can set a regular schedule for synchronizing Outlook e-mail and
information.
1. In ActiveSync on your device, tap Menu > Schedule.
2. Select a shorter time interval in the Peak times box for you to be able to receive e-mails more
frequently. (Peak times which usually refer to your working hours when e-mail volume is high).
3. Select a longer interval in the Off-peak times box.
Tip To set the days and hours that make up your peak and off-peak times, tap Adjust peak times to fit your schedule.
90 Working With Company E-mail and Meeting Appointments
Instant download through Fetch Mail
The Fetch Mail feature downloads an entire e-mail immediately without the need for you to perform a full
Send/Receive action. This limits the download to just the e-mail message that you want and helps save data
cost.
Requirement Fetch Mail works for your device only if your company is using Microsoft Exchange Server 2007 or
higher.
1. Tap Start > Messaging > Outlook E-mail.
2. Tap an e-mail message to open it.
3. By default, only the rst few kilobytes of the message is shown. To download the whole e-mail, nger-
scroll to the end of the message then tap Get the rest of this message.
4. A “Downloading message” status appears. Wait for the remainder of the message body to be
downloaded.
Tip For information about changing e-mail sync options such as the initial download size limit for e-mail, see
"Customize e-mail settings" in Chapter 7.
Note When you receive an e-mail that contains a link to a document such as a PDF or Microsoft Office document
located on SharePoint or an internal file server, you can tap the link to view the document on your device. You
can view the document only if you have a Microsoft Outlook account that synchronizes with Microsoft Exchange
Server 2007 or later. Exchange Server must also be set up to allow access to SharePoint document libraries or
internal file servers.
Search for e-mails on the Exchange Server
You can access messages that are not available on your device by searching your Microsoft Exchange Server
mailbox. The search results will be downloaded and displayed in a Search Results folder.
Requirement Your company must be using Microsoft Exchange Server 2007 or higher.
1. Tap Start > Messaging > Outlook E-mail.
2. Tap Menu > Tools > Search Server.
3. In the Look for text box, enter the search keyword.
4. Choose the date range of messages to search from.
5. From the Look in list, choose whether to search from your inbox or outbox only or to search all folders.
6. Tap Search.
Flag your messages
Flags serve as a reminder for you to follow-up on important issues or requests contained in the e-mail
messages. Flagging messages, which has been a useful feature on desktop Outlook E-mail, can also be done
in Outlook Mobile on your device. You can flag received e-mail messages on your device.
Requirement Flags are enabled only if e-mails are synchronized with Microsoft Exchange Server 2007 or higher.
Flags are disabled or hidden if e-mails are synchronized with earlier versions of Microsoft Exchange
Server.
Working With Company E-mail and Meeting Appointments 91
To flag or unflag message
1. Tap Start > Messaging > Outlook E-mail.
2. Select a message or open a message.
3. Tap Menu > Follow Up and select one of the following
options:
• Set Flag Mark the message with a red flag to indicate
that it needs follow up.
• Complete Flag Mark the message with a check mark to
indicate that the issue or request in the e-mail is already
completed.
• Clear Flag Remove the flag to unmark the message.
Note E-mail message reminders are displayed on your device if the messages are flagged with reminders and
synchronized from the Exchange Server.
Out-of-office auto-reply
Outlook Mobile allows you to retrieve and change your out-of-
office status. Just like desktop Outlook E-mail, Outlook Mobile
automatically sends an auto-reply message when you’re not
available.
To send out-of-office auto-reply messages
1. Tap Start > Messaging > Outlook E-mail.
2. Tap Menu > Tools > Out of Office.
3. From the I am currently list, select Out of the Office.
4. Enter your auto-reply message then tap Done.
Requirement Your company must be using Microsoft Exchange Server 2007 or higher.
8.3 Managing Meeting Requests
When you schedule and send meeting requests from your device, you can invite attendees to your meeting
and check their status to know about their availability.
When you receive a meeting request, you can reply by accepting or declining the request. The meeting
request also clearly indicates whether or not there are conflicting or adjacent meetings.
Requirement Your company must be using Microsoft Exchange Server 2007 or higher.
To reply to a meeting request
1. When you receive a meeting request e-mail, a notication will be displayed on the Today screen. Open
the e-mail.
2. Tap Accept to reply and accept the meeting request, or tap Menu > Decline if you cannot attend the
meeting.
Tips • Before responding, you can check your availability during the time of the requested meeting by tapping
View your calendar.
• If the time of the meeting conflicts with your other appointments, a “Scheduling Conflict” status appears on
top of the e-mail.
92 Working With Company E-mail and Meeting Appointments
3. Choose whether or not to edit your response e-mail before sending then tap OK.
4. If you accepted the meeting request, it will automatically be added as an appointment in Calendar on
your device.
To view the list of meeting participants
1. Tap Start > Calendar.
2. Tap a meeting request that you previously sent, then tap Attendees. The list of required and optional
attendees will be listed.
Notes • For information about creating a meeting request, see “To send a meeting request” in Chapter 6.
• If you select a meeting that you have organized, the list shows who has accepted or declined the meeting.
• To view an attendee’s contact information, tap the attendee’s name. If the attendee is included in your
contacts list, you will see the contact information immediately. If the attendee is not in your contacts list, tap
Company Directory to view the contact information.
8.4 Finding Contacts in the Company Directory
In addition to having contacts on your device, you can access contact information from your organization’s
Company Directory. By having over-the-air access to the Company Directory, you can easily send e-mail
messages and meeting requests to anyone in your company.
Requirement Access to the Company Directory is available only if your organization is running Microsoft Exchange
Server 2003 SP2 or higher, and you have completed your first synchronization with the Exchange
Server.
1. Synchronize with Exchange Server if you have never done so.
2. Do any of the following:
• In Contacts, tap Menu > Company Directory.
• In a new e-mail message, tap the To box (or tap Menu > Add Recipient) then tap Company
Directory.
Working With Company E-mail and Meeting Appointments 93
• In a new meeting request using Calendar, tap Attendees and then tap Company Directory at the
top of the list.
3. Enter the part or full contact name and tap Search. In the search results list, tap a contact to select it.
Notes • You can save a contact from the Company Directory to your device by selecting the contact then tapping
Menu > Save to Contacts.
• You can search on the following information as long as that information is included in the Company
Directory: First name, Last name, E-mail name, Display name, E-mail address, or Office location.
8.5 E-mail Security
Windows Mobile protects your Outlook e-mails through Secure/Multipurpose Internet Mail Extension
(S/MIME), which allows you to digitally sign and encrypt your messages.
Digitally signing a message applies your certificate with the authorization key to the message. This proves to
the recipient that the message is from you and not from an impostor or a hacker, and that the message has
not been altered.
Encryption protects the privacy of your message by converting it from plain, readable text into cipher
(scrambled) text. Only the recipient who has the authorization key can decipher the message.
Requirement S/MIME encryption and digital signatures for Windows Mobile-based devices are available only with
Exchange Server 2003 SP2 or a later version that supports S/MIME. If your company is not using
one of these products, or you have not completed your first synchronization with the Exchange Server,
these options are unavailable.
Note You can encrypt a message with or without a certificate. However, to read an encrypted message, you need a
valid certificate to decrypt it.
94 Working With Company E-mail and Meeting Appointments
To individually sign and encrypt a new message
1. Tap Start > Messaging > Outlook E-mail.
2. Tap Menu > New to create a new message.
3. Tap Menu > Message Options.
4. From the Security list, select whether to encrypt only, sign the message only, or do both.
5. Tap OK.
To verify the digital signature on a signed message you receive
1. Open the Outlook e-mail message that has been digitally signed.
2. At the top of the message, tap View Signature Status.
3. Tap Menu > Check Certificate. To view the details of the certificate in the message, tap Menu > View
Certificate.
Note There can be several reasons why a digital signature is not valid. For example, the sender’s certificate may
have expired, it may have been revoked by the certificate authority, or the server that verifies the certificate is
unavailable. Contact the sender to report the problem.
To digitally sign and encrypt all messages
You can set up ActiveSync to digitally sign and encrypt all outgoing messages. You must obtain a valid
certificate to sign and encrypt e-mail messages successfully.
1. Tap Start > Programs > ActiveSync.
2. Tap Menu > Options.
3. Select the E-mail information type, and tap Settings. On the E-mail Sync Options screen, tap
Advanced.
4. Do one or both of the following:
• To sign all your outgoing e-mail messages so that recipients can be certain that the messages
were sent by you and have not been altered in any way, select the Sign all outgoing e-mail
messages check box.
• To encrypt all your outgoing e-mail messages so that the contents of your messages are protected
from being viewed by anyone other than the intended recipients, select the Encrypt all outgoing
e-mail messages check box.
5. Tap Choose Certificate to select a certicate for signing or encrypting outgoing e-mail messages.
You can select certicates to sign or encrypt e-mail messages individually if you do not choose to sign
or encrypt all outgoing e-mail. For information about signing and encrypting individual messages, see
“To individually sign and encrypt a new message.”
Working With Company E-mail and Meeting Appointments 95
Set Permissions on an E-mail Message
Another way of protecting your e-mail messages is to send messages with restricted permissions using
Information Rights Management (IRM).
Note This works only with a Microsoft Outlook e-mail account and if your company is using RMS Server SP1.
1. Tap Start > Messaging > Outlook E-mail.
2. Create a message, and then tap Menu > Message Options.
3. In Permissions, do one of the following:
• To allow anyone to read the message, select Unrestricted access.
• To prevent the message from being forwarded, printed, or copied, select Do not forward.
4. Tap OK.
Tip An IRM-protected message received on your device can only be replied to or forwarded if the message permits
it.
96 Working With Company E-mail and Meeting Appointments
98 Working With Documents and Files
9.1 Microsoft® Office Mobile
Microsoft® Office Mobile consists of the following applications:
• Microsoft® Office Excel® Mobile lets you create and edit Excel workbooks and templates on your
device.
• Microsoft® Office OneNote® Mobile lets you create notes with text, photos, and voice recordings for
synchronization later with Microsoft® Oce OneNote® 2007 on your computer.
• Microsoft® Office PowerPoint® Mobile allows you to view (not create) slide show presentations in
*.ppt and *.pps formats.
• Microsoft® Office Word Mobile lets you create and edit documents and templates in Word Mobile and
save them as *.doc, *.rtf, *.txt, and *.dot les.
To use Microsoft Office Mobile
1. Tap Start > Office Mobile.
2. Tap the Oce Mobile application that you want to use.
Word Mobile and Excel Mobile do not fully support some features of Microsoft® Office Word and Microsoft®
Office Excel®. To see a complete list of features that are not supported in Word Mobile and Excel Mobile, see
Help on your device.
Tips • By default, Word Mobile saves documents in .docx format, while Excel Mobile saves workbooks in .xlsx format.
If you want to open these types of files on a computer that uses Microsoft Office 2000, Office XP, or Office 2003,
you need to download and install the File Format Converter in your computer. You can find this converter at
http://www.microsoft.com/downloads/details.aspx?FamilyId=941B3470-3AE9-4AEE-8F43-C6BB74CD1466&displ
aylang=en.
• If you want Word Mobile to save documents in .doc format, tap Menu > Tools > Options (or Menu > Options
when no document is opened), then change the Default template to Word 97-2003 Document (.doc).
• If you want Excel Mobile to save workbooks in a format that is compatible with Microsoft Office 2000, Office
XP, or Office 2003, tap Menu > Options (with no workbook opened), then change the Template for new
workbook to Blank 97-2003 Workbook.
9.2 Adobe® Reader® LE
Adobe® Reader® LE is an application for viewing PDF (Portable Document Format) documents on your
device. It supports a subset of the features found in the PC versions of Adobe Reader.
To open Adobe Reader LE
Tap Start > Programs > Adobe Reader LE.
To open a PDF file on your device
Do one of the following:
• Open a PDF le in Adobe Reader LE.
• Open File Explorer and nd the desired PDF le, then tap the le to open it.
To navigate through a PDF document
When you are viewing a PDF document, you can do any of the following:
• Use the vertical and horizontal scroll bars (including the Up, Down, Right and Left arrow keys on the
bars) to move to the desired direction of the page.
• Press NAVIGATION up/down/right/left to move to the desired direction of the page.
Working With Documents and Files 99
• Tap to move to the previous page; tap to move to the next page. Tap to jump to the rst page;
tap to jump to the last page.
• Tap Tools > Go To to select the desired page to view.
To search for text in the document
1. Tap Tools > Find > Text or tap on the toolbar.
2. Type in the text to be searched, then tap Find.
3. The matched text in the document will be highlighted.
4. To search for the next occurrence of the text, tap Tools > Find > Next.
Tips • Adobe Reader LE displays a bookmark pane for the PDF files that contain bookmarks. Tap the bookmarks to go
to a specific section/page within the file.
• Adobe Reader LE supports password-protected PDF files with up to 128-bit encryption. When you open a
password-protected PDF file, you will be prompted to enter the password before the file can be opened.
9.3 Copying and Managing Files
You can copy files between your device and PC using Windows Mobile Device Center or ActiveSync, or copy
files to a storage card that is inserted on your device. You can also efficiently manage your files and folders
using File Explorer.
Copy files using Windows Mobile Device Center or ActiveSync
Using Windows Mobile Device Center or ActiveSync, you can copy files from your PC to your device and vice
versa.
To copy a file between your device and the PC
1. Connect your device to the PC.
2. Click File Management > Browse in Windows Mobile Device Center or click Explore in ActiveSync on
your PC. This opens the Mobile Device folder for your device.
3. Browse your device for les that you want to copy to your PC.
4. To copy a le from your device to your PC:
a. In the Mobile Device folder, go to the le that you want to copy.
b. Right-click the le, then click Copy.
c. Locate the destination folder on your PC. Right-click the folder, then click Paste.
5. To copy a le from your PC to your device:
a. On your PC, navigate to the folder that contains the le you want to copy.
b. Right-click the le, then click Copy.
c. Right-click the destination folder under Mobile Device, then click Paste.
Copying a file results in separate versions of a file on your device and PC. Because the files are not
synchronized, changes made to one file will not affect the other. If you want to file changes to be
automatically updated on your device and PC, you can synchronize files between your device and PC. For
more information about synchronizing with a computer, see Chapter 5.
100 Working With Documents and Files
Use File Explorer
File Explorer lets you browse the contents of folders on your device. The root folder on the device is named
My Device. My Device is similar to My Computer on the PC and contains the My Documents, Program Files,
Temp, Storage Card, and Windows folders, among others.
To use File Explorer
1. Tap Start > Programs > File Explorer.
2. Tap a folder or le to open it.
3. To return to an upper level folder, tap the Down arrow ( ) and select the folder.
4. To delete, rename, or copy a le quickly, tap and hold the le then choose the desired operation from
the shortcut menu. To select multiple les, tap and drag over the desired les.
Store files to a storage card
To copy files to a storage card
1. Make sure the storage card is properly inserted into your device.
2. Tap Start > Programs > File Explorer and navigate to the appropriate folder.
3. Tap and hold the le you want to copy, and tap Copy.
4. Tap the Down arrow ( ) then tap Storage Card from the list.
5. Tap Menu > Edit > Paste.
Tip You can configure programs such as Word Mobile and Excel Mobile to directly save edited files on your storage
card. In the program's file list, tap Menu > Options then select the storage card in the Save to box.
9.4 ZIP
The ZIP program increases the storage capacity of your device by allowing you to compress files in the
conventional ZIP format. It also allows you to extract files from a zip file.
To start ZIP on your device
Tap Start > Programs > ZIP.
Each time you start ZIP, it searches for files that have the .zip file extension, and displays these files on the
Archive List screen.
To open a ZIP file and extract files
1. Open a zip le by doing one of the following:
• Tap and hold a file and tap Open Archive.
• Double-tap a file.
Note You cannot select multiple ZIP files.
2. From the zip le, select les by doing one of the following:
• Tap to select a file.
• To select several files, tap Menu > Action and make sure Multi-Select Mode is selected. Select
files by tapping each file. (Tap a selected file to deselect it).
• To select all files, tap Menu > Action > Select All.
Working With Documents and Files 101
3. Tap Menu > Action > Extract.
4. Choose a folder in which les will be extracted to, then tap Extract.
To create a zip archive
1. Tap File > New Archive.
2. On the Save As screen, enter a zip le name and choose a folder in which to save the zip le. You can
also choose whether the zip le will be saved on the device’s main memory or a storage card.
3. Tap Save.
4. Tap Menu > Action > Add.
5. Double-tap the folder that contains the les you want to archive.
6. Select les by doing one of the following:
• Tap to select a file.
• To select several files, tap and hold on the screen, then select Multi-Select Mode. Select files by
tapping each file. (Tap a selected file to deselect it).
• To select all files, tap and hold on the screen, then tap Select All.
7. Tap Add.
8. Tap Menu > File > Close Archive.
102 Working With Documents and Files
104 Getting Connected
10.1 Comm Manager
Comm Manager acts like a central switch that lets you enable or disable phone features as well as manage
your data connections easily.
To open Comm Manager
Tap Start > Settings > Connections tab > Comm Manager.
Airplane Mode
Tap to switch on or off. Turning on
Airplane mode turns off the phone
and Bluetooth functions. For more
information, see "Airplane Mode" in
Chapter 3.
Bluetooth
Tap to switchon or off. Tap Settings
> Connections tab > Comm
Manager to configure Bluetooth on
your device. See "Bluetooth" in this
chapter for details.
Data Connection
Tap to disconnect active data
connections. You cannot reconnect a
data connection in Comm Manager.
Phone
Tap to switch the phone
on or off. Tap Settings
> Phone to set the ring
tone and other phone
settings. See Chapter 4
for details.
DirectPush
Tap to switch between
automatically receiving
(as items arrive) or
manually retrieving
Outlook e-mails. See
Chapter 8 for details.
Off/Disabled
On/Enabled
10.2 Connecting to the Internet
Your device’s networking capability allows you to access the Internet through the dial-up connection. Settings
for connecting to your service provider’s 1xRTT/EVDO network are already preconfigured on your device, and
your device is ready to connect to the Internet. Please do not change these settings as this may cause your
data connection to stop working.
10.3 Internet Explorer® Mobile
Internet Explorer Mobile is a full-featured Internet browser, optimized for use on your device.
To start Internet Explorer Mobile
Tap Start > Internet Explorer.
To set a Home page
1. In the address bar on top of the Internet Explorer Mobile screen, enter the desired Web page address.
Tap to open the Web page.
2. Tap Menu > Tools > Options > General tab.
Getting Connected 105
3. Do one of the following:
• To use the displayed page as the Home page, tap Use Current.
• To use the default Home page, tap Use Default.
Tip To go to your Home page, tap Menu > Home.
To transfer favorites from your PC
You can transfer the favorites you have stored on your PC to your device by synchronizing the Internet
Explorer favorites on your PC with your device.
1. In ActiveSync on your PC, on the Tools menu, click Options, and select Favorites.
2. In Internet Explorer on your PC, click Favorites > Add to Favorites and save or move favorite links to
the Mobile Favorites subfolder in the Favorites list.
3. Connect your device to your PC. If synchronization does not start automatically, click Sync.
To add a favorite
1. In Internet Explorer Mobile, go to the page you want to add.
2. Tap and hold the page, and tap Add to Favorites.
3.
Conrm or change the name, and select a folder for storing the favorite
.
4. Tap Add.
To delete a favorite or folder
1. In Internet Explorer Mobile, tap Menu > Favorites > Add/Delete tab.
2. Select the item you want to delete, and tap Delete.
To change the size of text on Web pages
In Internet Explorer Mobile, tap Menu > Zoom, and tap the size you want.
To change how Web pages fill the screen
1. In Internet Explorer Mobile, tap Menu > View.
2. Tap one of the following:
• One Column. Arranges the content into one column that is as wide as the screen. This means that
you will rarely have to scroll horizontally.
• Default. Maintains a layout similar to what you see on a desktop computer, but it makes
items smaller and arranges the content so that you can see most of it without having to scroll
horizontally.
• Desktop. Keeps the same layout and size as on a desktop computer, which will require both
horizontal and vertical scrolling.
To clear the History list
1.
In Internet Explorer Mobile, tap Menu > Tools > Options > Memory tab
.
2. Tap Clear History.
106 Getting Connected
To save a picture from a Web page
1.
In Internet Explorer Mobile, tap and hold the picture, and tap Save Image
.
2. Do one of the following:
• To save the picture in My Pictures on your device, tap Yes.
• To save the picture in another location, such as a storage card, tap Save As.
To delete temporary Internet files
Your device temporarily stores Web pages that you frequently visit or have visited recently to speed up the
display of these Web pages when you access them. You may want to delete these files to free storage space.
1. In Internet Explorer Mobile, tap Menu > Tools > Options > Memory tab.
2. Tap Delete Files. All pages stored on your device, including offline favorites content, will be deleted.
To set up Internet security settings
Cookies are small files containing information about your identity and preferences so that a page can tailor
information to your needs. The page sends the file, and it is stored on your device.
1. In Internet Explorer Mobile, tap Menu > Tools > Options > Security tab.
2. To prevent Internet Explorer Mobile from accepting any cookies, clear the Allow cookies check box.
3. Select the check boxes for the other security options you want, and tap OK.
10.4 Windows Live™
Windows Live™ gives you full Internet experience on your device. It helps you to find information, pursue
your interests, and get in touch with friends and family on the Internet easier.
Windows Live™ offers the following key features:
• Live Search Bar, which lets you search for information on the Web.
• Live Messenger, the next generation of MSN Messenger Mobile.
• Live Mail, the next generation of Hotmail.
• Live Contacts, your address book for storing Live Mail, Live Messenger and Hotmail contacts.
Set up Windows Live™
The first time you use Windows Live™, sign in by using your Windows Live ID, which is your Windows Live Mail
or Hotmail address, and password.
Getting Connected 107
To set up Windows Live for the first time
1. Tap Start > Programs > Windows Live.
2. Tap Sign in to Windows Live.
3. On the next screen, tap the links to read the Windows Live™
Term of Use and the Microsoft Privacy Statement. After
reviewing them, tap Accept.
4. Enter your Windows Live™ Mail or Hotmail address and
password, select the Save password checkbox, then tap Next.
5. Choose whether or not to show Windows Live™’s search bar
and applications on the Today screen then tap Next.
6. Choose what information you want to sync online with your
device.
If you sync Contacts and Messenger, your Windows
Live contacts will be added to the contact list and to Live
Messenger on your device.
If you sync E-mail, your Windows Live Mail or Hotmail inbox
messages will be downloaded to your device.
7. Tap Next.
8. After synchronization is complete, tap Done.
The Windows Live™ interface
On the main interface of Windows Live™, you will see a search bar, navigation bar, and an area where you can
customize to show your picture.
1Live Search Bar.
2Tap the Left or Right arrow to switch between
Windows Live Messenger, Live Mail, and Sync
status.
3Tap to access Windows Live Messenger settings.
4Tap Menu to access and change settings.
3
2
1
4
Tip If you chose to display the search bar and Windows Live™ applications on the Today screen when you were
setting up Windows Live™, you’ll also see them on the Today screen: To show or hide them from the Today
screen, open Windows Live and tap Menu > Options > Today screen options.
108 Getting Connected
Windows Live Messenger
With this mobile version of Windows Live Messenger, you enjoy many of the same cool features that you get
from the desktop version, which include the following:
• Instant messaging via text and voice
• Multiple conversations
• Add emoticons
• Contact list with presence
• Send and receive les including photos
• Change status/display name
• View contacts by online status, groups, and more
• Send messages even when a contact is oine
Note Before you can use Windows Live Messenger, your device must be connected to the Internet. For information
about setting up an Internet connection, see “Connecting to the Internet” in this chapter.
Launch the messenger and sign in
To open Windows Live Messenger
• Tap Start > Programs > Messenger; or
• On Windows Live™ or the Today screen, tap the Left or Right arrow until you see Messenger, then tap
it.
To sign in and out
1. Tap Sign in on the messenger screen.
2. If this is your rst time to sign in, a message appears to inform you that your messenger contacts will
be added to the contact list on your device. Tap OK to add them.
Signing in may take several minutes, depending on your connection speed.
3. To sign out, tap Menu > Sign Out.
To start and end conversations
1. In the contact list, select a contact then tap Send IM to open a message screen.
2. Enter your text message in the text entry area of the message screen.
3. To add an emoticon, tap Menu > Add emoticon then tap an icon from the list of emoticons.
4. Tap Send.
5. To end a conversation with the current contact, tap Menu > End conversation.
Tips • To send a file, tap Menu > Send. You can choose to send a picture, voice clip or any file.
• To invite one or more contacts to the conversation, tap Menu > Options > Add participant.
• To send a voice message, tap Voice Clip on a message screen then start talking. After you have spoken a
message, tap Send.
Add Windows Live contacts
You can add new Windows Live contacts in Live Messenger or in Contacts.
Getting Connected 109
To add a Windows Live contact in Live Messenger
1. Tap Menu > Add new contact.
2. Enter the e-mail address of the contact then tap OK.
To add a Windows Live contact in Contacts
1. Tap Start > Contacts.
2. Tap New then tap Windows Live.
3. In the IM box, enter the e-mail address of the contact, which can be a Windows Live ID or any other
e-mail address.
Tip You can fill in other information about the contact, if desired. This is not absolutely necessary if you will
communicate with the contact only through Windows Live Messenger or Live Mail.
4. Tap OK.
5. Follow the remaining instructions to add the new contact to your Windows Live contact list.
10.5 Bluetooth
Bluetooth is a short-range wireless communications technology. Devices with Bluetooth capabilities can
exchange information over a distance of about eight meters without requiring a physical connection.
Bluetooth modes
Bluetooth on your device operates in three different modes:
• On. Bluetooth is turned on. Your device can detect other Bluetooth-enabled devices, but not vice versa.
• Off. Bluetooth is turned o. In this mode, you can neither send nor receive information using
Bluetooth. Turn o Bluetooth when not in use to conserve battery power, or in places where using a
wireless device is prohibited, such as on board an aircraft and in hospitals.
• Visible. Bluetooth is turned on, and all other Bluetooth-enabled devices can detect your device.
Note By default, Bluetooth is turned off. If you turn it on, then turn off your device, Bluetooth also turns off. When you
turn on your device again, Bluetooth automatically turns on.
To turn Bluetooth on and make your device visible
1. On your device, tap Start > Settings > Connections tab > Bluetooth > Mode tab.
2. Select the Turn on Bluetooth and Make this device visible to other devices check boxes.
3. Tap OK.
Bluetooth partnerships
A Bluetooth partnership is a relationship that you create between your device and another Bluetooth-enabled
device in order to exchange information in a secure manner.
To create a Bluetooth partnership
1. On your device, tap Start > Settings > Connections tab > Bluetooth.
2. On the Devices tab, tap Add new device. Your device searches for other Bluetooth devices and
displays them in the box.
3. Tap the desired device name in the box, then tap Next.
4. Specify a passcode to establish a secure connection. The passcode can be 1 up to 16 characters.
110 Getting Connected
5. Tap Next.
6. Wait for the paired device to accept the partnership. The receiving party needs to enter the same
passcode that you specied.
7. The name of the paired device is then displayed. You may edit and enter a new name for that device.
8. Select the check boxes of services that you want to use from the paired device.
9. Tap Finish.
Note Creating a Bluetooth partnership between two devices is a one-time process. Once a partnership is created, the
devices can recognize the partnership and exchange information without entering a passcode again.
To accept a Bluetooth partnership
1. Ensure that Bluetooth is turned on and in visible mode.
2. Tap Yes when prompted to establish a partnership with the other device.
3. Enter a passcode (the same passcode that is entered on the device requesting the partnership) to
establish a secure connection. The passcode must be between 1 and 16 characters.
4. Tap Next.
5. Tap Finish. You can now exchange information with the paired device.
Tips • To rename a Bluetooth partnership, tap and hold the partnership’s name on the Devices tab of the Bluetooth
Settings screen, then tap Edit.
• To delete a Bluetooth partnership, tap and hold the partnership’s name on the Devices tab, then tap Delete.
Connect a Bluetooth hands-free or stereo headset
For hands-free phone conversations, you can use a Bluetooth hands-free headset such as a car kit with your
device. Your device also supports A2DP (Advanced Audio Distribution Profile) which allows you to use a
Bluetooth stereo headset for hands-free phone conversations and for listening to stereo music.
To connect a Bluetooth hands-free or stereo headset
1. Make sure that both your device and the Bluetooth headset are turned on and within close range,
and that the headset is visible. Refer to the manufacturer’s documentation to nd out how to set the
headset in visible mode.
2. Tap Start > Settings > Connections tab.
3. Tap Bluetooth > Devices tab > Add new device. Your device
searches for other Bluetooth-enabled devices and displays
them.
4. Tap the name of the Bluetooth headset, then tap Next. The
device will automatically pair the device with the Bluetooth
headset.
Windows Mobile will automatically try one of the
precongured passcodes (0000, 1111, 8888, 1234) to pair the
Bluetooth headset with the device. If this fails, you have to
enter the passcode delivered with your headset manually.
5. Tap Done. While the Bluetooth stereo headset is connected,
the Headset icon
( ) will appear on the title bar.
Note If the Bluetooth stereo headset becomes disconnected, turn the headset on and repeat steps 1 to 3 above. Tap
and hold the name of the Bluetooth stereo headset and tap Set as Wireless Stereo.
Getting Connected 111
Beaming information using Bluetooth
You can beam information, such as contacts, calendar items, and tasks, as well as files from your device to your
computer or to another Bluetooth-enabled device.
Note If your computer does not have built-in Bluetooth capability, you need to connect and use a Bluetooth adapter or
dongle on your computer.
To beam information from your device to a computer
1. Turn on Bluetooth on your device, and make your device visible. For information about this, see “To
turn Bluetooth on and make your device visible”.
2. Next, set Bluetooth on your computer to visible mode, create a Bluetooth partnership, then enable
your computer to receive Bluetooth beams.
Note If the Bluetooth adapter or dongle on your computer was installed using a third-party provided driver, open
the Bluetooth software that came with the Bluetooth adapter/dongle and enable the adapter/dongle to be
discovered by other devices. Refer to the Bluetooth adapter’s documentation for more information.
If your computer has Windows Vista or Windows XP SP2 and your computer’s Bluetooth adapter is
supported by your Windows version, do the following steps:
a. On your computer, open Bluetooth Devices from the Control Panel then click the Options tab.
b. For Windows Vista, select Allow Bluetooth devices to find this computer.
For Windows XP, select Turn discovery on and Allow Bluetooth devices to connect to this
computer.
c. Create a Bluetooth partnership between your device and computer. For information about creating
a partnership, see “Bluetooth partnerships”.
d. In the Options tab of Bluetooth Devices, select Show the Bluetooth icon in the notification
area.
e. To enable your computer to receive Bluetooth beams, right-click the Bluetooth icon at the bottom-
right of your computer screen and select Receive a File.
3. Now you are ready to beam. On your device, select an item to beam. The item can be an appointment
in your calendar, a task, a contact card, or a le.
4. To beam a contact, tap Menu > Send Contact > Beam.
To beam other types of information, tap Menu > Beam [type of item].
5. Tap the device name to which you want to send the beam.
6. If you beamed a calendar, task, or contact item to your computer and it is not automatically added to
Outlook, select File > Import and Export in Outlook to import it.
To beam information to a Bluetooth-enabled device such as another Windows Mobile powered device, follow
steps 1 to 5 in the above procedure.
Tips • The default folder on your computer where beamed items are stored may be C:\Documents and Settings\your_
username\My Documents in Windows XP or C:\Users\your_username\My Documents in Windows Vista.
• For your device to receive Bluetooth beams, tap Start > Settings > Connections tab > Beam and make sure the
Receive all incoming beams check box is selected.
Bluetooth Explorer and Bluetooth file sharing
Bluetooth Explorer searches for other Bluetooth devices that have file sharing enabled and lets you access
their Bluetooth shared folder. You can copy files from and to their shared folder, and create subfolders in it.
When you enable Bluetooth file sharing on your device, other Bluetooth-enabled devices will also be able to
access your Bluetooth shared folder.
112 Getting Connected
To enable Bluetooth Explorer and Bluetooth file sharing on your device
1. Tap Start > Settings > Connections tab > Bluetooth > FTP tab.
2. Select the Enable Bluetooth Explorer check box. This makes the \Bluetooth device folder visible in
the File Explorer.
3. Select the Enable File Sharing check box.
You can use the default Bluetooth shared folder, or tap Browse to use another folder as your shared
folder.
Note To use the Bluetooth file sharing feature on your device, tap Start > Settings > Connections tab > Beam and
make sure the Receive all incoming beams check box is selected. If you disable the Receive all incoming
beams option, the Enable File Sharing feature will be disabled automatically.
To use Bluetooth Explorer
1. Bluetooth Explorer is integrated with the File Explorer
program. You can open it by tapping Start > Programs >
Bluetooth Explorer or by tapping Down arrow ( ) on the
upper left of File Explorer then tapping Bluetooth.
2. Bluetooth Explorer then scans for other Bluetooth devices
that have le sharing enabled. From the list, tap to select a
Bluetooth device you want to connect to. You may need to
enter a passcode in order for you to connect to the selected
device.
3. If there are les contained in the Bluetooth shared folder on
the other device, you will be able to see them on the Bluetooth
Explorer screen. Select one or more les, then tap Menu > Edit
and choose to cut or copy the les.
4. Tap Up twice.
5. Navigate to the folder where you want to paste the les on your device, then tap Menu > Edit > Paste.
Print files via Bluetooth
Connect your device to a Bluetooth printer to print contact information, appointment details, messages, and
other file types.
Note You can print files in the .txt, .jpg, .xhtml, .vcf, .vcs file formats.
Before you start printing, make sure to turn on the Bluetooth printer and to turn on Bluetooth on your device.
To turn on Bluetooth, tap Start > Settings > Connections tab > Comm Manager and then tap the Bluetooth
button. When enabled, the ON indicator is activated.
To print contact information
1. Tap Start > Contacts and then select the contact whose information you want to print.
2. Tap Menu > Print via Bluetooth.
3. Tap Menu > Search Device. Your device starts to search for Bluetooth devices.
4. Select the Bluetooth printer and tap Menu > Send File.
5. Set the printing options you want and then tap Print.
To print a calendar appointment
1. Tap Start > Calendar and then select the appointment whose details you want to print.
2. Follow steps 2 to 5 in the “To print contact information” procedure.
Getting Connected 113
To print a message
1. Tap Start > Messaging and then select the messaging account where the message you want to print is
located.
2. Select the message you want to print.
3. Follow steps 2 to 5 in the “To print contact information” procedure.
To print a JPEG file
1. Do one of the following:
• In Pictures & Videos, select the JPEG file and then tap Menu > Print via Bluetooth.
• In File Explorer, tap and hold the JPEG file and then on the menu, tap Print via Bluetooth.
2. Follow steps 3 to 5 in the “To print contact information” procedure:
10.6 Using Your Device As a Modem (Internet Sharing)
Internet Sharing connects your PC or notebook computer to the Internet by using your device’s data
connection. You can choose to connect via USB or Bluetooth.
Follow the procedure below to set up your device as a USB modem. To learn how to set up your device as a
Bluetooth modem, see “To use your device as a Bluetooth modem.”
Tips • Make sure you have subscribed to a Data plan and have set up a phone dial-up modem connection on your
device. If your device has not been set up with a data connection yet, tap Menu > Connection Settings on
the Internet Sharing screen.
• If you want to use a USB Sync cable connection, you must first install Microsoft ActiveSync version 4.5 or later
on the computer.
• If you want to use a Bluetooth connection, make sure your computer has built-in Bluetooth capability. If
your computer does not have Bluetooth, you can connect and use a Bluetooth adapter or dongle on your
computer.
• Before using Internet Sharing, disable ActiveSync on your computer.
To set up your device as a USB modem
1. On your device, tap Start > Programs > Internet Sharing.
2. In the PC Connection list, select USB.
3. In the Network Connection list, select the name of the connection that your device uses to connect to
the Internet.
4. Plug in the USB cable between your device and the computer.
5. Tap Connect.
114 Getting Connected
To use your device as a Bluetooth modem
For the computer to use the Internet connection of your device, activate Internet Sharing on your device, and
then set up a Bluetooth Personal Area Network (PAN) between the computer and your device.
1. On your device, turn on Bluetooth and set it to visible mode.
2. Initiate a Bluetooth partnership from your device by following the steps in “To create a Bluetooth
partnership“ in this section.
3. Tap Start > Programs > Internet Sharing.
4. Select Bluetooth PAN as the PC Connection.
5. From the Network Connection list, select the name of the connection that your device uses to
connect to the Internet.
6. Tap Connect.
7. On your computer, set up a Bluetooth Personal Area Network (PAN) with your device:
For Windows Vista:
a. Click Start > Control Panel > Network and Internet > Network and Sharing Center.
b.
Click Manage network connections and then under Personal Area Network, double-click
Bluetooth Network Connection.
c.
In the Bluetooth Personal Area Network Devices dialog box, select your phone, and then click
Connect.
For Windows XP:
a. Tap Start > Control Panel > Network Connections.
b. Under Personal Area Network, click the Bluetooth Network Connection icon.
c. Under Network Tasks, click View Bluetooth network devices.
d.
In the Bluetooth Personal Area Network Devices dialog box, select your device, and then click
Connect.
8. On the Internet Sharing screen on your device, check that a connected message is displayed, indicating
that your computer has been successfully connected to the Internet using your device as a Bluetooth
modem.
To end the Internet connection
On the Internet Sharing screen, tap Disconnect.
10.7 Using RSS Hub
RSS Hub is an RSS reader that keeps you up-to-date with the latest news from the Internet. It monitors
Internet news channels and downloads the most current news updates and podcasts so you are instantly
informed of breaking news and events.
For more information and tips on using RSS Hub, see Help on your device.
Note Make sure you have an active Internet connection before using RSS Hub.
Getting Connected 115
Subscribe to and organize news channels
You must subscribe to news channels before you can receive RSS feeds.
To subscribe to news channels
1. Tap Start > Programs > RSS Hub, then tap Continue.
2. In the New Channel Wizard screen, select the Choose from a list of known Channels option, then tap
Next. A list of RSS channels is displayed.
Channels
Category
Tap to load pre-selected RSS channels.
Note If the RSS channel you want to subscribe to is not in the list of known channels, tap Back, then select another
option on the New Channel Wizard screen. For more information on these other options, see the Help on
your device.
3. Select the checkboxes of the RSS channels you want to subscribe to, then tap Finish.
Tip Channels are grouped by categories. If you want to select all channels in a category, select the category
check box.
4. The channel list appears. Tap Refresh to update the channels.
Tap to cancel
channel updating
Channel is
updated. Tap
it to view the
headlines.
Tap to select the channel
category to display
Headline count
Tap to
update the
channels
Channel
list
To add new channels
1. In the channel list, tap Menu > Channel > New to open the New Channel Wizard screen.
2. Select an option, then follow screen instructions to add new channels. For more information on New
Channel Wizard options, see Help on your device.
To filter the channels in the display
In the channel list, tap Menu > View, then select:
• Updated to display only those channels with unread headlines.
• All to display all subscribed channels.
116 Getting Connected
Manage channel categories
To view all the channels in a particular category, tap All Categories in the upper left area of the channel list,
then tap the category you want to display.
To add a new category, tap Menu > Categories in the channel list to display all categories, then tap Menu >
New.
To rename or delete a category, tap Menu > Categories in the channel list to display all categories, select a
category, then tap Menu > Rename or Menu > Delete.
If you want to change the channel category, tap and hold the channel in the channel list, then tap Change
Category. Select a new category and tap OK.
View and organize headlines
Tap a channel in the channel list to display the headlines for that channel.
Tap a headline to open the
news summary screen
Headline or news summary
contains a keyword
Tap to download audio/video
file attachment
Audio/Video/Image file
attachment is downloading
Tap to play back or view the
file attachment.
New or unread headline
Headline has been read
Tap to return to the
channel list
New or unread headlines display in bold and are marked with a blue newspaper icon. Headlines that have
been read are marked with a gray newspaper icon.
View the news summary
Tap a headline in the headline list to display the news summary.
Headline and
read status
Audio/Video/Image
file attachment. Tap to
download the file.
News summary
Tap to open the
news item in
Opera Mobile.
Channel name
Tap to return to the
headline list
To change view options
In the news summary screen, tap Menu to change the text size, fit the text to the screen (text wrap), or enable
ClearType for better viewing.
Getting Connected 117
To download, play, or save podcasts
1. When you see an audio or video le attachment
in the news summary, do one of the following to
download the le:
• Tap Menu > Podcasts > Start Download.
• Tap the Download audio/Download video link
below the audio/video file icon.
Tip To cancel the file download, tap Menu > Podcasts >
Cancel Download, or tap Cancel download below
the audio/video file icon.
2. After downloading the le, do one of the following:
• Tap Menu > Podcasts > Play or tap Play audio/Play video below the audio/video file icon to play
back the file.
• Tap Menu > Podcast > Save to save a copy of the file to the device main memory or internal
storage.
To send the headline link via e-mail
1. In the news summary screen, tap Menu > Send Link via Email.
2. Messaging opens and displays the Account Picker screen. Tap the e-mail account you want to use to
send the headline link.
A new e-mail message is then created with the headline link.
3. Specify the e-mail recipients, then send it.
Note For more information on how to compose e-mails, see “Using E-mail” in Chapter 6.
To view the next or previous news summary
In the news summary screen, tap Menu > Next or Menu > Previous, or press NAVIGATION left or right.
For more information about the features and configuring RSS Hub, refer to the online help. To open the online
help, tap Start > Help while in RSS Hub.
118 Getting Connected
120 Experiencing Multimedia
11.1 Camera
Taking photos and recording video clips along with audio are easy with your device’s built-in camera.
To open the Camera screen
• Press the CAMERA button on your device; or
• Tap Start > Programs > Camera.
The screen orientation automatically switches to landscape
mode when you open Camera.
To exit the Camera
Tap the Exit icon ( ) on the Camera screen.
CAMERA button
Capture modes
The camera on your device allows you to capture pictures and video clips by using various built-in modes
with flexibility. The Camera mode is set to the Photo capture mode by default. The upper left corner of the
screen displays the active capture mode.
To change the capture mode
Current capture mode
Tap to change the capture mode.
You can also press NAVIGATION right or left to change the capture mode.
The available capture modes of the camera are as follows:
Icon Capture Mode
Photo: Captures standard still images.
Video: Captures video clips, with or without accompanying audio.
Contacts Picture: Captures a still image and gives you the option to immediately assign it as a
Photo ID for a contact.
Picture Theme: Captures still images and places them within frames.
Panorama: Captures a sequence of still images continuously in one direction, and allows stitching
of all the images to create a panoramic view of a scenery.
Sports: Captures consecutive photo shots (3, 5, 7, or 10).
Burst: Captures a sequence of still images (maximum 30) as long as the CAMERA button on the
device or the ENTER button on the NAVIGATION CONTROL is kept pressed.
Experiencing Multimedia 121
File formats supported
Using the available capture modes, the camera in your device captures files in the following formats:
Capture type Format
Still image / Contacts Picture / Panorama /
Sports / Burst
JPEG
Video H.263+AMR-NB(.3gp), MPEG4+AMR-NB(.mp4),
MPEG4+QCELP(.3g2)
Camera controls
• Press CAMERA or ENTER to take a photo or contacts picture.
• Press CAMERA or ENTER to start recording video; press it again to stop recording.
• Press CAMERA or ENTER each time when taking photos for a picture theme.
• To take consecutive shots in Sports or Panorama mode, press CAMERA or ENTER shortly, then move
your device to follow the movement of your subject.
• Press and hold the CAMERA button or the ENTER button when taking consecutive shots in Burst mode.
On-screen controls and indicators
The onscreen controls and indicators disappear after about 3 seconds. To make the controls and indicators
reappear, touch or tap the screen.
4
7
Video mode
6
1 3
5
Photo mode
2
1 Mode Switching control. Tapping the left/right arrow ( / ) on the screen allows you to switch the
capture mode.
2 Auto-focus indicator. Displays a ashing bracket ( ) when focusing. When focus is set, the flashing
bracket changes to a steady green bracket ( ).
3 Remaining information indicator. In Photo, Contacts Picture, Picture Theme, Sports, and Burst modes,
this shows the remaining, available shots of pictures based on current settings. In Video mode, this
shows the remaining duration that can be recorded. While recording video, this shows the recorded
duration.
4 Zoom control. Tapping / on the screen allows you to zoom in or zoom out.
Note This control only appears when zooming is supported by the Resolution you have selected.
5 Album. Tap to open Camera Album. See “Camera Album” for details.
6 Menu. Tap to open the Camera Settings screen.
7 Recording indicator. This shows a red, ashing indicator while video recording is in progress.
122 Experiencing Multimedia
Picture Theme mode 8
10
Sports mode
9
8 Template Selector icon. In Picture Theme mode, tap to toggle among the dierent templates.
9 Progress indicator. In Picture Theme, Sports and Burst modes, this shows the number of consecutive
shots.
10 Exit. Tap to exit the Camera program.
Zooming
Before capturing a still image or a video clip, you can zoom in to make the object in focus move closer or
zoom out to make the object move farther away.
Note The zoom control only appears onscreen when zooming is supported by the Resolution you have selected.
To zoom in
Press NAVIGATION up or tap .
To zoom out
Press NAVIGATION down or tap .
The camera zoom range for a picture or a video clip depends on the capture mode and capture size. The
following table is a summary.
Capture mode Capture size setting Zoom range
2M (1600 x 1200) No zooming available
1M (1280 x 960) 1.0x to 2.0x
Large (640 x 480) 1.0x to 2.0x
Medium (320 x 240) 1.0x to 4.0x
Small (160 x 120) 1.0x to 8.0x
Video
CIF (352 x 288) 1x and 2x
Large (320 x 240) 1x and 2x
Medium (176 x 144) 1x and 2x
Small (128 x 96) 1x and 2x
Contacts Picture Large (640 x 480) 1.0x to 2.0x
Medium (320 x 240) 1.0x to 4.0x
Picture Theme Determined by the current template Depends on the size of the template currently
loaded
Panorama Large (640 x 480) 1x and 2x
Medium (320 x 240) 1x, 2x and 4x
Sports Large (640 x 480) 1x and 2x
Medium (320 x 240) 1x, 2x and 4x
Burst Large (640 x 480) 1x and 2x
Medium (320 x 240) 1x, 2x and 4x
Experiencing Multimedia 123
Quick Settings Panel
The Quick Settings Panel provides a quick way of adjusting the most common camera settings. Tap on the
screen to open the Quick Settings Panel. Keep tapping a button on the panel, for instance, Resolution, to
cycle through the available settings.
Note The available settings on the menu depend on the Capture mode selected.
2
15
4
3
1 Resolution. Available resolutions include: .
See the table in the previous page for the detailed capture sizes.
2 Storage. Tap to toggle between saving captured photos or video clips on the device memory ( ) or on
the storage card ( ).
3 White Balance. White balance settings include:
Auto ( ), Daylight ( ), Night ( ), Incandescent ( ), and Fluorescent ( ).
4 Self-timer. Tap to set the Self-timer to 2 seconds, 10 seconds, or Off when in the Photo or Contacts
Picture mode. When you press the CAMERA or ENTER button to capture a still image, it starts to count
down, and then captures a still image after the assigned time.
5 Brightness. Tapping the minus/plus icon ( / ) decreases or increases the brightness level.
The Review screen
Review screen
After taking a still image or recording
a video clip, you can view the image or
video clip on the Review screen.
You can also tap the following icons at the bottom of the Review screen:
Icon Function
Back Go back to the live Camera screen.
Delete Remove the captured image or video.
Send Send via e-mail.
View View the image in the Camera Album program, or play the captured video in Windows Media®
Player.
Assign to
Contacts Associate the photo to a selected contact.
Browse
After capturing in Sports or Burst mode, the total
number of consecutive shots is shown in the top
right corner of the Review screen. Tap the up/down arrow to browse through the sequence of
photos.
Tip You can set the Review screen duration by tapping on the Camera screen and then tapping Advanced tab >
Review Duration.
124 Experiencing Multimedia
Camera settings
Tap the Menu icon ( ) to open the Camera Settings screen. The Camera Settings screen allows you to
configure capture and camera settings.
The Camera settings consist of two tabs: Capture Settings and Advanced. Use the Capture Settings tab to
adjust options for your selected capture mode. Use the Advanced tab to set the Camera program preferences.
You can either tap onscreen or press the Navigation Control buttons to navigate the Camera Settings screen.
Capture Settings tab
The available options in this tab depend on the capture mode selected.
• Effect. Choose a special eect such as Grayscale, Sepia, etc., to apply to your photos or video clips.
• Time Stamp (Photo, Sports and Burst modes). Choose whether or not to include the shooting date and
time on captured photos.
• Template (Picture Theme mode). Select a template.
• Capture Speed (Burst and Sports modes). This determines the interval between shots. Fast captures
consecutive shots at the shortest interval.
• Snapshots (Sports mode). Select the number of consecutive shots to capture.
• Direction (Panorama mode). Choose in what direction images will be stitched in a panorama.
• Stitch Count (Panorama mode). Select the number of snapshots to be taken and stitched into a
panorama.
• Quality. Select the JPEG image quality level for all captured still images. Choose from Basic, Normal,
Fine, and Super Fine.
• Metering Mode. Select a metering mode to allow the camera to measure the amount of light and
calculate the best-t exposure value before capturing. Choose either Center Area to measure light
using the centre area of the image or Average to measure light using the area all around the image.
• Storage. Select where you want to save your les. You can either save the les to the main memory or
to a storage card.
Experiencing Multimedia 125
Advanced tab
The available options in this tab depend on the capture mode selected.
• Capture Format. Select the desired le format.
• Shutter Sound. Choose whether or not you want the camera to make a shutter sound when you press
the ENTER or CAMERA button.
• Shoot Option. The camera comes with an auto-focus feature that is activated when the CAMERA or
ENTER button is pressed. Selecting Full Press requires you to press the CAMERA button all the way to
take the shot after auto-focus is set. Selecting Half Press automatically takes the shot after auto-focus is
set.
This option only applies to the CAMERA button. Pressing the ENTER button automatically takes the
shot.
• Grid (Photo mode only). Choose whether or not to show a grid on the Camera screen. Showing a grid
helps you frame and centre your subject more easily and accurately.
Grid
• Keep Backlight. Turn the backlight on or o. This overrides your device backlight settings while you are
using the camera.
• Review Duration. Set a time length for displaying the captured image/video on the Review screen.
Select No Limit if you do not want to impose a time limit. Select No Review to immediately return to
the live Camera screen after capturing and saving.
• Flicker Adjustment. When taking indoor shots, icker on the camera screen may be caused by
inconsistencies between the vertical scan rate of the camera display and the icker frequency of
uorescent lighting. To reduce icker, you can change the icker adjustment setting to the proper
frequency (50Hz or 60Hz) of the country where your device is being used.
• Record with Audio (Video mode only). Select On to record audio with the captured video clips, or
select Off to capture video without audio.
• Prefix. When Default is selected as the prex, the le name of each new captured le is set to “IMAGE”
or “VIDEO” followed by a sequential number, for example: IMAGE_001.jpg. You may also choose to name
les using either the current Date or Date & Time as the prex.
126 Experiencing Multimedia
If you set the Camera to save captured photos to a storage card, the prex cannot be selected. Captured
photos will be named using the convention IMAGnnnn.jpg (where 'nnnn' is the counter) which is the
DCIM (Digital Camera Images) naming standard, and will be saved to the \DCIM\100MEDIA folder on
the storage card.
• Counter. To reset the le naming counter back to 1, tap Reset.
• Recording Limit (Video mode only). Set the duration or le size for recording video.
• Template Folder (Picture Theme mode only). By default, templates are stored in the \My Documents\
Templates folder on the device’s Main Memory. If you transferred some templates to a storage card
(via File Explorer), set this option to Main + Card to specify that templates are located in both the main
memory and the storage card.
• Image Properties. This option allows you to adjust the camera display properties, such as Contrast,
Saturation, Hue, and Sharpness.
1Tap a property to adjust.
2Tap the left/right arrow icon or press NAVIGATION left/right to increase/
decrease the value.
3Tap to close the submenu without applying and saving the changes.
4Tap to reset all properties to their default values.
5Tap to save the settings.
2
3
4
1
5
• Show Reminder (Contacts Picture mode). Select On if you want the Camera to always display a
message that conrms whether or not to assign the captured picture to a contact.
• Help. Tap to open the Camera program help le.
• About. Tap to view information about the Camera program.
11.2 Camera Album
View your images and videos that you captured using the Camera program in Camera Album. Camera Album
offers a host of features that let you rotate images, view your images as a slide show, use images as contact
pictures, and more.
Note Only files supported by the Camera program are displayed in Camera Album. To know which file formats are
supported, see “File formats supported" in the Camera section.
To open Camera Album
Do one of the following:
• Tap Start > Programs > Camera Album.
• In the Touch Cube, touch Photos or Videos.
• In the Camera program, tap . Depending on the capture mode you are in, Camera Album will either
show still images or video files in your device. For example, if you are in Photo mode, only still images
will be shown in Camera Album. To view video files, switch first to Video mode before tapping .
Experiencing Multimedia 127
Touch to go to the Camera
program
Opened from a still image capture mode
Opened from a video capture mode
Tip If you have a lot of images in your device, scroll up or down by sliding your finger upward or downward on the
touch screen.
To view an image
On the main Camera Album screen, touch the thumbnail of the image you want to view. While viewing the
image, you can zoom in or rotate the image. To learn how to zoom and rotate the image, see the succeeding
procedures.
While viewing an image, touch the screen to pop up the onscreen menu.
Icon Function Icon Function
Touch to send the
image via one of
your Messaging
accounts.
Touch to start
the slide show.
Touch to assign
the image as a
contact picture.
Touch to
delete the
image.
Touch to return to
the main Camera
Album screen.
Touch to show
you how to
use gestures
when viewing
photos.
While viewing an image, you can advance to the next image or go back to the previous image; rotate the
image; zoom in or out on the image, and more.
To go to the next or previous image
• Go to the next image by sliding your
finger across the screen from right to
left.
• Go back to the previous image by
sliding your finger from left to right.
128 Experiencing Multimedia
To rotate the image
1. View the image you want to rotate.
2. With your nger, make a half-circle motion on the screen.
To zoom in or out of an image
With your finger, make a full-circle motion on the screen.
• Slide your finger clockwise to zoom in; or
• Slide your finger counter-clockwise to zoom out.
Tips • When you zoom in on an image, you can double tap the screen to automatically zoom out and fit the image to
the screen.
• When you zoom in on an image, touch and hold the screen so you can pan the image.
To view the images as a slide show
On the Camera Album screen, touch Slide Show. While viewing the slide show, touch the screen to show
playback controls.
Touch to go back to the
previous image.
Touch to open the slide show
options where you can set the
transition effect to use, time per
slide, and orientation of the images.
Touch to return to
the main Camera
Album screen.
Touch to play or pause
slideshow playback.
Touch to go to the next
image.
Experiencing Multimedia 129
To play back video files
On the main Camera Album screen, touch the thumbnail of the video file you want to play back. Windows
Media Player then plays back the file.
Tip You can also select the video file and tap Play to play back the file in Windows Media Player.
To close Camera Album and go to the Camera program
Go back to the main Camera Album screen and touch or .
To close Camera Album
When you open Camera Album from Start > Programs, you can close Camera Album by going back to the
main Camera Album screen and tapping .
Note When you open Camera Album from the Camera program, tapping takes you back to the Camera program.
11.3 Pictures & Videos
Pictures & Videos allows you to manage the following types of media files on your device:
File Type File Extensions
Image *.bmp, *.jpg, *.gif, *.png
GIF animation *.gif
Video *.avi, *.wmv, *.mp4, *.3gp, *.3g2
Audio *.wma
To open Pictures & Videos
Tap Start > Programs > Pictures & Videos.
To copy media files to your device
• Copy pictures and GIF animation les from your PC or a storage card to the My Pictures folder on your
device.
• Copy video les to the My Videos folder.
For more information about copying and managing files on your device, see Chapter 9.
130 Experiencing Multimedia
To view pictures
1. The images in the My Pictures folder appear as thumbnails
by default.
2. Select a picture and tap View. If you cannot find a picture
in the default My Pictures folder, go to another folder by
tapping the Down arrow ( ).
Down arrow
Tap to view the selected image.
GIF animation
icon
To play GIF animation files
1. Select a GIF animation le (marked with a icon) and tap View.
2. The GIF Animation program then opens and plays the animation.
To play videos
1. By default, the contents of the My Pictures folder will be shown.
2. To find the video clips that you captured, tap the down arrow ( ) next to the My Pictures folder and
tap My Documents > My Videos. Video clips are displayed as thumbnails by default, which appear
with a media icon ( ).
3. Tap to select a video and play it in Windows Media® Player Mobile.
Pictures & Videos menu
Select a media file and then tap Menu to choose from a list
of options that you can do with the selected media file.
You can send the selected media file via one of your
messaging accounts or beam it to another device. If you
selected a picture, you can associate it to a contact, set it as
your Today screen background, send it to your Windows Live
Space account, and more. You can also view the images in
the My Pictures folder as a slide show.
To edit a picture
You can rotate, crop, and adjust the brightness and color contrast of your pictures.
1. On the Pictures & Videos screen, tap the picture you want to edit.
2. Tap Menu > Edit, and do any of the following:
• To rotate a picture 90 degrees clockwise, tap Rotate.
Experiencing Multimedia 131
• To crop a picture, tap Menu > Crop. Next, tap and drag to select the area to crop. Tap inside the
box to crop, or tap outside the box to cancel cropping.
• To adjust the brightness and contrast levels of a picture, tap Menu > Auto Correct.
Note To undo an edit, tap Menu > Undo. To cancel all unsaved edits you made to the picture, tap Revert to Saved.
11.4 Windows Media® Player Mobile
You can use Windows Media® Player Mobile to play digital audio and video files that are stored on your device
or on a network, such as on a Web site.
Video File Formats Supported File Extensions
Windows Media Video
MPEG4 Simple Profile
H.263
H.264
Motion JPEG
.wmv, .asf
.mp4
.3gp, .3g2
.mp4, .3gp, .3g2, .m4v
.avi
Audio File Formats Supported File Extensions
Windows Media Audio
WAV
MP3
MIDI
AMR Narrow Band
AMR Wide Band
AAC, AAC+ and eAAC+
MPEG4 audio
QCELP
.wma
.wav
.mp3
.mid, .midi, .rmi
.amr
.awb
.aac, .mp4, .m4a
.mp4, .m4a
.qcp
To open Windows Media® Player Mobile
Tap Start > Programs > Windows Media.
About the controls
The following are available controls on the Windows Media® Player Mobile.
Play/Pause
Full screen
Visit WindowsMedia.com
Tap and drag to jump to
any part of the video or
audio
Skip to the beginning of
the current file or to the
previous file
Skip to the next file
Mute/Unmute
Increase Volume
Decrease Volume
132 Experiencing Multimedia
About the screens and menus
Windows Media® Player Mobile has three primary screens:
• Playback screen. The screen that displays the playback controls (such as Play, Pause, Next, Previous,
and Volume) and the video window. You can change the appearance of this screen by choosing a
dierent skin.
• Now Playing screen. The screen that displays the Now Playing playlist. This special playlist indicates the
current le being played and any les that are “queued up” to play next.
• Library screen. The screen that lets you quickly nd your audio les, video les, and playlists. It contains
categories such as My Music, My Videos, My TV, and My Playlists.
At the bottom of each screen, you can open a Menu. The commands on this menu vary, depending upon
which screen you are viewing. For more information about the commands in these menus, see Help on your
device.
Synchronize video and audio files
Use the latest version of Windows Media® Player on your PC to synchronize digital media files from your PC to
your device. This ensures that protected files and album art (for skins) are copied to your device correctly.
To synchronize content to your device automatically
1. On your PC, start Windows Media® Player and then connect your device to your PC.
2. In the Device Setup Wizard, select Yes, search my computer now.
If you have previously opened Windows Media® Player and searched for media on your computer, you
will not be prompted to search your computer.
3. You will then see the name of your device (or “Storage Card” if you have inserted one on your device).
Click Finish.
4. On the left panel of Windows Media® Player, right-click the name of your device then click Set Up Sync.
To set up media synchronization on a storage card, right-click Storage Card in the left panel of
Windows Media® Player, then click Set Up Sync.
5. On the Device Setup dialog box, select Sync this device automatically.
6. Select the playlist(s) that you want to sync between your PC and device, then click Add.
7. Click Finish.
The files begin synchronizing to your device. The next time you connect your device to your PC while
Windows Media® Player is running, synchronization will start automatically.
To synchronize content manually to your device
1. If you have not set up media synchronization between your device and PC, follow steps 1 to 3 in “To
synchronize content to your device automatically”.
2. Click the Sync tab on the Windows Media® Player of your PC. Select a Playlist or a Library on the left
panel of the Windows Media® Player.
3. From the Content List, drag the media les that you want to sync to your device and drop them to the
Sync List.
4. Click Start Sync to start synchronizing the selected les to your device.
Notes • Use Windows Media® Player 11 or higher on your PC to synchronize media files to your device.
• Audio files copy faster if Windows Media® Player is configured to automatically set the quality level for audio
files copied to your device. For more information, see the Windows Media® Player Help.
Experiencing Multimedia 133
Playlists and Library List Sync ListContent List
Play media
Use the Library to find and play songs, videos, and playlists that are stored on your device or removable
storage card.
To update the Library
1. If you are not on the Library screen, tap Menu > Library.
2. On the Library screen, tap the Library arrow (near the top of the screen), then tap the media storage
that you want use, for example, Storage Card.
3. In most cases, Windows Media® Player Mobile automatically updates the library. However, you can
manually update the library to ensure that it contains new les that you recently copied to your device
or storage card. Tap Menu > Update Library to manually update the library list.
To play video and audio files on your device
1. Select a category (for example, My Music or My Playlists).
2. Tap and hold the item that you want to play (such as a song, album, or artist name), then tap Play.
Tips • To play a media file that is stored on your device but is not in a library, on the Library screen, tap Menu > Open
File. Tap and hold the item that you want to play (such as a file or a folder), then tap Play.
• To play a media file from the Internet or a network server, tap Menu > Library then tap Menu > Open URL.
Playlists
In Windows Media® Player Mobile, you can create a new playlist by saving the current Now Playing playlist and
giving it a new name.
To save a new playlist
1. If you are not on the Library screen, tap Menu > Library.
2. Tap to select a category (for example, My Music or My Playlists).
3. Select a media le that you want, then tap Menu > Queue Up. This adds the le to the Now Playing list.
Repeat this step until you have added all desired media les to the Now Playing list. Please note that
you cannot select multiple les simultaneously.
4. After adding the media les, tap Menu > Now Playing.
5. On the Now Playing screen, tap Menu > Save Playlist.
134 Experiencing Multimedia
6. Enter the playlist name then tap Done.
7. To play back the playlist you created, tap My Playlists in the Library, select your playlist, then tap Play.
6. Enter the playlist name then tap Done.
7. To play back the playlist you created, tap My Playlists in the Library, select your playlist, then tap Play.
Troubleshooting
If you encounter a problem while using the Windows Media® Player Mobile, a number of resources are
available to help you troubleshoot the issue.
For more information, see the Troubleshooting Windows Media® Player Mobile page at the Microsoft Web site
(http://www.microsoft.com/windows/windowsmedia/player/windowsmobile/troubleshooting.aspx).
11.5 Audio Booster
Audio Booster enhances your music experience by providing you with controls for adjusting sound settings
while you are listening to music. It adds 3D sound, treble and bass effects, and provides controls for adjusting
them. It even has an equalizer with presets as well as a control panel for fine tuning sound.
To access Audio Booster
Tap Start > Programs > Audio Booster.
Note You need to connect a headset to the device to open Audio Booster.
.
4
1
3
2
5
Equalizer
The Equalizer optimizes sound for a better listening experience. It provides preset moods, such as hip hop,
jazz, rock, etc., and several enhancement presets that suit different types of music. It also has a 10-band
graphic equalizer that lets you adjust the loudness of sound by frequency.
1. Equalizer presets Tap to choose the Equalizer preset to use.
2. Done Tap to apply the modified settings.
3. Menu Tap Menu > Cancel to exit Audio Booster without applying
the modified settings. Tap Menu > Save as Preset or Delete Preset
to save or delete preset equalizer settings.
4. Frequency band Drag the sliders to adjust the frequency.
5. On Select the check box to enable or disable the equalizer.
Experiencing Multimedia 135
To apply a preset
1. Select the Equalizer check box to
enable the equalizer.
2. Tap the Equalizer drop-down menu,
then select a desired preset.
To create a custom equalizer preset
1. Select the Equalizer check box to enable the equalizer.
2. Tap .
3. Adjust the frequency bands to your desired values by dragging the
equalizer controls. The selected values are indicated on top of the
sliders.
4. Save your equalizer settings as a preset by tapping Menu > Save as
Preset.
5. Enter a preset name then tap Done.
The preset you created will be added to the list box.
To delete a custom equalizer preset
1. Select the Equalizer check box then tap .
2. Tap the Equalizer drop-down menu, then select the preset you want to delete.
3. Tap Menu > Delete Preset.
Note You can only delete custom equalizer presets. Equalizer presets that are pre-installed cannot be deleted.
136 Experiencing Multimedia
138 Managing Your Device
12.1 Adding and Removing Programs
Before you purchase additional programs for your device, make sure that they are compatible with your
device.
To add programs
1. Download the program to your PC (or insert the CD or disk that contains the program into your PC).
You may see a single *.exe le, a *.zip le, a Setup.exe le, or several versions of les for dierent
device types and processors. Be sure to select a program designed for your device and processor type.
2. Read any installation instructions or documentation that comes with the program. Many programs
provide special installation instructions.
3. Connect your device to the PC.
4. Double-click the *.exe le.
To remove programs
1. Tap Start > Settings > System tab > Remove Programs.
2. In the Programs in storage memory list, select the program you want to remove, and tap Remove.
12.2 Using Task Manager
Task Manager lets you view and stop running programs, configure the button, and enable the Quick
Menu on the Today screen.
To open Task Manager
Do one of the following:
• Tap the Quick Menu button on the top right corner of the Today screen to open the Quick Menu, then
tap .
• Tap Start > Settings > System tab > Task Manager.
To switch back to a running program
Do one of the following:
• Tap the program name in the Quick Menu.
• On the Task Manager screen, tap and hold the program name in the Running tab, then tap Activate.
To configure the Exit ( ) button
You can configure the Exit button to shut down running programs when the button is tapped, or to just
temporarily close the program screen but keep the program running.
1. On the Task Manager screen, tap the Button tab.
2. Select the Enable the “X” button to end running programs check box.
When the Enable the “X” button to end running programs check box is not selected, tapping the
Exit button will only close a program screen. The program is not ended and continues to run in the
background.
3. Choose the action for shutting down programs (by tapping the button, tapping and holding the
button, or both).
4. Tap OK.
Managing Your Device 139
To close running programs from the Task Manager
1. Tap the Running tab.
2. Do one of the following:
• Select the check box of the programs that you want to close, and then tap Stop Selected to close
them.
• Tap Stop All to close all programs in the list.
• Tap Menu > Stop All but Selected to close all programs except for those whose check boxes are
selected.
Tip You can also close running programs from the Quick Menu on the Today screen. See "Quick Menu" in Chapter 1 for
details.
To add a running program to the exclusive list
If you add a running program to the Exclusive Programs List, it will not be closed when you tap Stop
Selected or Stop All and will not be listed in the Quick Menu on the Today Screen.
1. On the Task Manager screen, tap the Running tab.
2. Tap and hold the program name in the list, then tap Add Exclusive.
Tip To remove a program from the exclusive list, tap the Exclusive tab, select the check box of that program, then tap
Remove.
To set the sorting preference for running programs in the Quick Menu
1. On the Task Manager screen, tap the Advanced tab.
2. Choose whether to sort according to Program name or Memory usage. The list will be sorted in
ascending order.
12.3 Resetting Your Device
Soft reset
Occasionally, you may need to reset your device. A soft (or normal) reset of your device clears all active
program memory and shuts down all active programs. This can be useful when your device is running slower
than normal, or a program is not performing properly. A soft reset is also necessary after the installation of
some programs. If a soft reset is performed when programs are running, unsaved work will be lost.
To perform a soft reset
Open the rubber cover at the bottom of the device and then with the stylus, press the RESET button. Your
device restarts and dispalys the Today screen.
140 Managing Your Device
Hard reset
You can also perform a hard reset (also known as a full reset). A hard reset should be performed only if a
normal reset does not solve a system problem. After a hard reset, the device is restored to its default
settings - the way it was when you first purchased it and turned it on. Any programs you installed, data you
entered, and settings you customized on your device will be lost. Only Windows Mobile® software and other
pre-installed programs will remain.
To perform a hard reset
1. Press and hold the TALK and END buttons, and at the same time, use the stylus to press the RESET
button at the bottom of your device.
2. Release the stylus, but continue pressing the TALK and END buttons until you see the following
message on the screen:
This operation will delete all
your personal data, and reset
all settings to the manufacturer
default settings. Press Enter to
restore manufacturer defaults, or
press any other button to cancel.
3. Release the TALK and END buttons, and then press ENTER on your device.
Warning Your device will be set back to factory default settings. Please ensure any additional installed programs and/
or user data have been backed up before a hard reset is performed.
Important If Encrypt files placed on storage cards is or was enabled before, then backup all files from the storage card
before using Clear Storage, hard reset or updating the ROM system software. Otherwise you will no longer be
able to access the encrypted files on the storage card. Use ActiveSync or Windows Mobile Device Center to
transfer files between your storage card and computer. After the procedure, copy your files back to the
storage
card.
Clear Storage
Another way of clearing the device storage and reset all settings back to factory default settings is to use the
Clear Storage feature. You will lose all your data and files on the device storage when you use Clear Storage,
so make sure to do a backup first.
1. Tap Start > Settings > System tab > Clear Storage.
2. Enter “1234” then tap Yes.
12.4 Managing Memory
To see how much memory is available for use, tap Start > Settings > System tab > Memory. On the Main
tab, the amount of memory allocated to le and data storage versus program storage is displayed, as well as
the amount of memory in use versus the available memory.
To see available storage card memory, tap Start > Settings > System tab > Memory > Storage Card tab.
If your device is running low on memory, try the following to free memory on your device:
• Close programs you are not currently using.
• Move e-mail attachments to a storage card.
• Move les to a storage card. Tap Start > Programs > File Explorer. Tap and hold the le, and tap Cut.
Browse to the storage card folder and tap Menu > Edit > Paste.
• Delete unnecessary les. Tap Start > Programs > File Explorer. Tap and hold the le, and tap Delete.
• Delete large les. To nd your largest les, tap Start > Programs > Search. In the Type list, tap Larger
than 64 KB, and tap Search.
Managing Your Device 141
•
In Internet Explorer Mobile, delete temporary Internet les and clear history information. For more
information, see “Internet Explorer
®
Mobile” in Chapter 10.
• Remove programs you no longer use.
• Reset your device.
12.5 Windows Update
You can update Windows Mobile® on your device with the latest updates, security patches or fixes, if they are
available.
To set up Windows Update
The first time you run Windows Update, you need to set up how you want Windows Update to check for
patches on the Microsoft Web site.
1. Tap Start > Settings > Systems tab > Windows Update.
2. On the Update Setup screen, tap Next.
3. Select how you want to check for updates, Manual or Automatic, then tap Next.
If you select Automatic, you will be asked if you want to use your current data plan to check for
updates. Select or clear the Use my data plan to check for and download updates check box and tap
Next.
4. Tap Finish.
To check for updates
1. Tap Start > Settings > Systems tab > Windows Update.
2. Tap Check Now.
Note Windows Mobile® updates may not be available at all times. You can check the Windows Mobile® Web site for
update information.
To change Windows Update options
1. Tap Start > Settings > Systems tab > Windows Update.
2. Tap Menu and select the option you want to change.
• Tap Connections to change how the device connects to the
Internet when checking for updates.
• Tap Change Schedule to change how Windows Update checks for
Windows Mobile® updates.
12.6 Battery Saving Tips
How long your battery power lasts depends on battery type and how you use your device. Try the following to
help preserve battery life:
• When the device is not in use, press POWER to switch o the display.
• Tap Start > Settings > System tab > Power to open the Power settings screen. On the Advanced tab
of the Power settings screen, you can specify when your device automatically turns o the display to
conserve battery power. For optimum conservation, specify 3 minutes or less.
• Use the AC adapter to plug your device into external power whenever possible, especially when using a
storage card or when using a modem or other peripherals.
142 Managing Your Device
• Adjust the backlight settings. For more information, see “To set the backlight to dim after a time delay”
in Chapter 4.
• Turn Bluetooth o when you are not using it. Make your device visible to other devices only when you
are trying to establish a Bluetooth partnership. For more information about Bluetooth, see Chapter 10.
• Lower the volume.
• Close battery-intensive programs, such as the Camera, when you are done using them. Make sure the
programs are ended and are not continuously running in the background.
144 Using Other Applications
13.1 Voice Command
Voice Command lets you make phone calls, open programs, play back music, get calendar information, and
more, just by using your voice. It only responds to a set of predefined commands and does not allow you to
record your own commands.
To use Voice Command
1. Hold your device a few inches away from your mouth.
2. Press and hold the Volume Down button that is located on the upper left
side of your device.
You will then hear a sound, and you will see a Microphone icon ( ) on
the title bar.
Press and hold
to launch Voice
Command
3. In a clear voice, say a command. For example, say “Help“ to ask for information about using Voice
Command.
4. Voice Command then asks you a question. Speak out your answer.
To place a call
You can call contacts that are stored on your device, dial a phone number, redial, and place a return call.
1. Press and hold the Volume Down button until the Microphone icon ( ) appears on the title bar.
2. In a clear voice, say one of the following commands:
• “Call [contact name]” to call a device contact.
• “Dial [number]” to dial a phone number.
• “Redial” to repeat the last call made.
• “Callback” to return the last call received.
• “Call [contact name] at [location]” to call a contact at a specific number. For example, say:
“Call Ann at mobile”
“Call Ann at home”
“Call Ann at work”
3. Voice Command will then conrm with you the contact or number to call. Say “Yes” or “Correct.”
If Voice Command is wrong about the contact or number to call, say “No” or “Incorrect” to try again.
4. Your device starts to call the contact or number.
To open a program
1. Press and hold the Volume Down button until the Microphone icon ( ) appears on the title bar.
2. In a clear voice, say “Start“, “Open”, or “Show” then the program name.
To request information from your calendar
1. Press and hold the Volume Up button until the Microphone icon ( ) appears on the title bar.
2. In a clear voice, ask for the information you want to retrieve. For example, say:
“What’s my next appointment?”
“What’s my next meeting?”
“What’s my schedule tomorrow?”
Using Other Applications 145
To request for date and time
1. Press and hold the Volume Up button until the Microphone icon ( ) appears on the title bar.
2. In a clear voice, say “What date is it?” Voice Command then tells you the current date.
3. Press and hold the Volume Up button again, and then say “What time is it?”
4. Voice Command then tells you the current time.
13.2 Using Java
MIDlets are Java applications such as games and tools that can run on mobile devices, while a MIDlet suite is a
collection of one or more MIDlets. The Java program lets you download, install and manage MIDlets or MIDlet
suites on your device. Your device supports Java 2 Micro Edition, J2ME.
To open the Java program
Tap Start > Programs > Java.
Install and launch MIDlets/MIDlet suites
There are two ways to install a MIDlet/MIDlet suite.
To download and install via Internet Explorer Mobile
1. On the Java screen, tap Menu > Install > Browser to open Internet Explorer Mobile.
2. Locate the MIDlet/MIDlet suite while connected to the Internet.
3. Select the MIDlet/MIDlet suite to download.
4. Information about the MIDlet/MIDlet suite is then displayed. Tap Continue.
5. Conrm to start downloading.
6. Select <root> or a folder where to install the MIDlet suite to, then tap OK.
To install from your device
You can copy MIDlets/MIDlet suites from the PC to your device using the USB sync cable, infrared, or
Bluetooth connection. Copy them to the root folder or any subfolder on your device.
1. On the Java screen, tap Menu > Install > Local Files. The program then searches for MIDlets/MIDlet
suites on your device and displays them in a list.
2. From the list, tap the MIDlet/MIDlet suite that you want to install.
3. Conrm to start the installation.
4. Select <root> or a folder where to install the MIDlet suite to, then tap OK.
To run a MIDlet/MIDlet suite
Do one of the following:
• After installation of the MIDlet/MIDlet suite is complete, tap Yes.
• On the Java screen, open the folder that contains the MIDlet/MIDlet suite. Select the MIDlet/MIDlet
suite then tap Launch.
To stop running a MIDlet/MIDlet suite
Tap Exit or Quit if presented on the MIDlet/MIDlet suite’s screen or menu.
146 Using Other Applications
Manage MIDlets/MIDlet suites
You can organize MIDlets/MIDlet suites into folders for easy identification, renaming, updating, and more. If
the device memory is full, uninstall some MIDlets/MIDlet suites to free up memory space.
To create folders
1. On the Java screen, tap Menu > New Folder.
2. Enter a folder name, then tap Create.
To update a MIDlet/MIDlet suite
Tap and hold a MIDlet/MIDlet suite, then tap Update. Alternatively, you can tap Menu > Edit > Update.
Java will search for updates for the selected MIDlet/MIDlet suite where it was installed from before.
To uninstall MIDlets
Before you uninstall a MIDlet, make sure that it is not running.
1. Tap and hold the MIDlet, then tap Erase.
2. Tap OK to conrm.
Note To uninstall all MIDlets and folders from the current folder, tap Menu > Uninstall All.
Using Other Applications 147
Appendix 149
A.1 Specifications
System Information
Processor Qualcomm® MSM7501A™, 528 MHz
Memory - ROM : 256 MB
- RAM : 160 MB DDR
(Figures are the total ROM and RAM memory available for use and storage. Since the memory is
shared by the Operating System, applications, and data, the actual available memory is less than
what is written).
Operating System Windows Mobile® 6.1 Professional
Power
Battery Rechargeable Lithium-ion polymer battery, 1350 mAh
Charging Time 3 hours
Battery Life (estimates) Standby time: Up to 360 hours
Talk time: Up to 6.4 hours
Media playback time: Up to 8 hours (WMV); up to 12 hours (WMA)
AC Adapter Voltage range/frequency: 100 - 240V AC, 50/60 Hz
DC output: 5V and 1A
Display
LCD Type 2.6” TFT-LCD with backlight LEDs, touch-sensitive screen
Resolution 240 x 320 with 65,536 colors
Alignment Portrait and Landscape
Phone
Functionality CDMA2000 1xRTT / 1xEVDO/ 1xEVDO Rev. A and IS-95A/B voice or data
Mode Dual-band (800 and 1900 MHz)
Internal Antenna Yes
Physical
Dimensions 107 mm (L) x 55 mm (W) x 17.1 mm (T)
Weight 120g (with battery)
Camera Module
Type 2 megapixel color CMOS camera
Resolution Photo: 1600x1200 (UXGA), 1280x960 (SXGA), 640x480 (VGA), 320x240 (QVGA), 160x120 (QQVGA)
Video: 352 x 288 (CIF), 320 x 240 (QVGA), 176 x 144 (QCIF), 128 x 96 (Sub-QCIF)
Digital Zoom Up to 8x
150 Appendix
Connections
I/O Port HTC ExtUSB™ : 11-pin mini-USB and audio jack in one
Full-speed USB 2.0
(ExtUSB is a proprietary connection interface that is trademarked by HTC.)
Wireless
Connections
Bluetooth 2.0
GPS Internal GPS antenna
Controls and Lights
Navigation Buttons • HTC TouchFLO™
• 4-Way NAVIGATION Control / ENTER button
• Two phone functions : TALK and END
• Volume button
• CAMERA button
• POWER button
• RESET button
Hardware Keyboard 20-key QWERTY keyboard
LEDs The right LED shows Green and Amber lights for CDMA standby, message, and network status as
well as for notification and battery charging status. Shows a flashing red light when the battery level
reaches 5% or lower.
The left LED shows a flashing Blue light when the Bluetooth system is powered up and ready to
transmit Bluetooth radio signal.
Audio
Microphone/
Speaker
Built-in microphone and loud speaker for hands-free supported
Ring Tone Formats • Supports AAC, AAC+, eAAC+, MP3, WMA, WAV, QCELP, MPEG4, AMR-NB, AMR-WB
• 40 polyphonic and Standard MIDI format 0 and 1 (SMF) / SP MIDI
Expansion Slots
Card Slot microSD™ (SD 2.0 compatible)
Appendix 151
A.2 Regulatory Notices
Regulatory Agency Identifications
For regulatory identification purposes, your product is assigned a model number of NEON400.
FCC ID: NM8NEON400. IC: 4115A-NEON400.
To ensure continued reliable and safe operation of your device, use only the accessories listed below with
your NEON400.
The Battery Pack has been assigned a model number of NEON161.
This product is intended for use with a certified Class 2 Limited Power Source, rated 5 Volts DC, maximum 1
Amp power supply unit.
Federal Communications Commission Notice
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or TV reception, which can be
determined by turning the equipment on and off, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio or television technician for help.
Modifications
The FCC requires the user to be notified that any changes or modifications made to the device that are not
expressly approved by HTC Corporation may void the user’s authority to operate the equipment.
FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices
On July 10, 2003, the U.S. Federal Communications Commission (FCC) Report and Order in WT Docket 01-
309 modified the exception of wireless phones under the Hearing Aid Compatibility Act of 1988 (HAC Act)
to require digital wireless phones be compatible with hearing-aids. The intent of the HAC Act is to ensure
reasonable access to telecommunications services for persons with hearing disabilities.
While some wireless phones are used near some hearing devices (hearing aids and cochlear implants), users
may detect a buzzing, humming, or whining noise. Some hearing devices are more immune than others to
this interference noise, and phones also vary in the amount of interference they generate.
The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device
users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones
that are rated have the rating on their box or a label located on the box.
152 Appendix
The ratings are not guarantees. Results will vary depending on the user’s hearing device and hearing loss.
If your hearing device happens to be vulnerable to interference, you may not be able to use a rated phone
successfully. Trying out the phone with your hearing device is the best way to evaluate it for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate less interference to
hearing devices than phones that are not labeled. M4 is the better/higher of the two ratings. NEON400 is
rated M3.
Please power off the Bluetooth function while using hearing aid devices with your NEON400.
Hearing devices may also be rated. Your hearing device manufacturer or hearing health professional may
help you find this rating. Higher ratings mean that the hearing device is relatively immune to interference
noise. The hearing aid and wireless phone rating values are then added together. A sum of 5 is considered
acceptable for normal use. A sum of 6 is considered for better use. A sum of 8 is considered for best use.
In the above example, if a hearing aid meets the M2 level rating and the wireless phone meets the M3 level
rating, the sum of the two values equal M5. This should provide the hearing aid user with “normal usage”
while using their hearing aid with the particular wireless phone. “Normal usage” in this context is defined as a
signal quality that is acceptable for normal operation.
The M mark is intended to be synonymous with the U mark. The T mark is intended to be synonymous
with the UT mark. The M and T marks are recommended by the Alliance for Telecommunications Industries
Solutions (ATIS). The U and UT marks are referenced in Section 20.19 of the FCC Rules. The HAC rating and
measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard.
For information about hearing aids and digital wireless phones
FCC Hearing Aid Compatibility and Volume Control:
http://www.fcc.gov/cgb/dro/hearing.html
Gallaudet University, RERC:
http://tap.gallaudet.edu/DigWireless.KS/DigWireless.htm
SAR Information
SAR: 1.19 W/kg@1g (Head), 0.751 W/kg@1g (Body)
THIS MODEL DEVICE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
For body worn operation, this phone has been tested and meets the FCC RF exposure guidelines when used
with the HTC Corp. accessories supplied or designated for this product. Use of other accessoies may not
ensure compliance with the FCC RF exposure guidelines.
Your wireless mobile CDMA phone is a radio transmitter and receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish
permitted levels of RF energy for the general population. The guidelines are based on the safety standards
previously set by both U.S. and international standards bodies:
• American National Standards Institute (ANSI) IEEE. C95.1-1992.
• National Council on Radiation Protection and Measurement (NCRP). Report 86. 1986.
• International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1996.
• Ministry of Health (Canada), Safety Code 6. The standards include a substantial safety margin designed
to assure the safety of all persons, regardless of age and health.
Appendix 153
The exposure standard for wireless mobile CDMA phone employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg*.
The FCC has granted an Equipment Authorization for this model device with all reported SAR levels evaluated
as in compliance with the FCC RF exposure guidelines. SAR information on this model device is on file with
the FCC and can be found under the Display Grant section of https://gullfoss2.fcc.gov/prod/oet/cf/eas/
reports/GenericSearch.cfm after searching on FCC ID: NM8NEON400.
* In the U.S. and Canada, the SAR limit for mobile CDMA phone used by the public is 1.6 Watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional
protection for the public and to account for any variations in usage.
Normal condition only to ensure the radiative performance and safety of the interference. As with other
mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and
for the safety of personnel, it is recommended that no part of the human body be allowed to come too close
to the antenna during operation of the equipment.
IC Statement
Operation is subject to the following two conditions:
1. This device may not cause interference; and
2. This device must accept any interference, including interference that may cause undesired operation of
the device.
Important Note
IC Radiation Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. End
users must follow the specic operating instructions for satisfying RF exposure compliance.
This Class B digital apparatus complies with Canadian ICES-003.
Telecommunications & Internet Association (TIA) Safety Information
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum separation of six inches be
maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent research by and recommendations
of Wireless Technology Research. Persons with pacemakers:
• Should ALWAYS keep the phone more than six inches from their pacemaker when the phone is turned
ON.
• Should not carry the phone in a breast pocket.
• Should use the ear opposite the pacemaker to minimize the potential for interference. If you have any
reason to suspect that interference is taking place, turn the phone OFF immediately.
Hearing Aids
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may
want to consult your service provider, or call the customer service line to discuss alternatives.
154 Appendix
Other Medical Devices
If you use any other personal medical device, consult the manufacturer of your device to determine if it
is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this
information.
Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
WEEE Notice
The Directive on Waste Electrical and Electronic Equipment (WEEE), which entered into force as European law
on 13th February 2003, resulted in a major change in the treatment of electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of WEEE, and in addition, to promote the
reuse, recycling and other forms of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or on its box indicates that this product must not
be disposed of or dumped with your other household waste. You are liable to dispose of all your
electronic or electrical waste equipment by relocating over to the specified collection point for
recycling of such hazardous waste. Isolated collection and proper recovery of your electronic and
electrical waste equipment at the time of disposal will allow us to help conserving natural resources.
Moreover, proper recycling of the electronic and electrical waste equipment will ensure safety
of human health and environment. For more information about electronic and electrical waste
equipment disposal, recovery, and collection points, please contact your local city center, household
waste disposal service, shop from where you purchased the equipment, or manufacturer of the
equipment.
RoHS Compliance
This product is in compliance with Directive 2002/95/EC of the European Parliament and of the Council of
27 January 2003, on the restriction of the use of certain hazardous substances in electrical and electronic
equipment (RoHS) and its amendments.
Appendix 155
A.3 Additional Safety Information
This section provides more safety information in addition to the information at the beginning of the
user manual.
When Driving
Do Not Use The PC Functions Of Your Pocket PC While Driving Or Walking
Never use the personal computer functions of your device while driving an automobile or any other moving
vehicle. Always pull out of trac and come to a stop in a legally permissible and safe location before using
your device. Failure to do so could result in serious bodily injury in a trac accident.
When driving:
• Always secure your device in its leather pouch.
• Never place your device on the passenger seat or anyplace else in the car where it can become a
projectile during a collision or stop.
• An air bag inflates with great force. DO NOT place objects, including either installed or portable
wireless equipment, in the area over the air bag or in the air bag deployment area. If in-vehicle wireless
equipment is improperly installed and the air bag inflates, serious injury could result.
Never store or transport flammable liquids, gases or explosive materials in the same compartment of your
automobile as the device or any of its accessories, as possible sparking in the device could cause ignition or
explosion.
Never use your device while walking. Usage while walking could result in bodily injury caused by inattention
to automobile traffic or other pedestrian hazards.
Using The Phone Function Of Your Pocket PC While Driving Is Extremely Dangerous
Talking on or using your PDA phone while driving is extremely dangerous and is illegal in some states.
Remember, safety comes rst. Check the laws and regulations on the use of phones in the areas where you
drive. Always obey them.
If you must use the phone function while driving, please:
• Give full attention to driving. Driving safely is your first responsibility.
• Use hands-free operation and/or one-touch, speed dialing, and auto answer modes.
• Pull off the road and park before making or answering a call.
WARNING: Failure to follow these instructions could lead to serious personal injury and possible property damage.
When Using Your Device Near Other Electronic Devices
Your wireless handheld portable PDA phone is a low power radio transmitter and receiver. When it is ON, it
receives and also sends out radio frequency (RF) signals.
Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may
not be shielded against the RF signals from your wireless PDA phone; therefore, use of your PDA phone must
be restricted in certain situations.
In addition, the computer portion of your device produces low levels of RF energy due to the generation of
digital timing pulses by its clock oscillator circuits. Your device has been equipped with internal shielding
to minimize stray emissions of RF energy. However, use of the computer functions of your device must be
restricted in certain situations.
156 Appendix
PACEMAKERS
The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be
maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent research by and recommendations
of Wireless Technology Research.
Never come closer than six (6) inches to a person with a heart pacemaker implant when using your device.
Doing so could result in interference with the function of the pacemaker.
Persons with pacemakers:
• Should ALWAYS keep the phone more than six inches from their pacemaker when the phone is
turned ON.
• Should not carry the phone in a breast pocket.
• Should use the ear opposite the pacemaker to minimize the potential for interference.
Note: This is not necessary if the PDA phone is not held to the ear.
• If you have any reason to suspect that interference is taking place, turn the phone OFF immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may
want to consult your service provider, or call the customer service line to discuss alternatives.
For more regulatory information about hearing devices, see “FCC Hearing-Aid Compatibility (HAC)
Regulations for Wireless Devices”.
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of your device to determine if it
is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this
information.
HOSPITALS AND HEALTH CARE FACILITIES
Turn your device OFF in health care facilities when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
ELECTRONIC DEVICES IN VEHICLES
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles.
Check with the manufacturer or its representative regarding your vehicle. You should also consult the
manufacturer of any equipment that has been added to your vehicle.
POSTED FACILITIES
Turn your device OFF where posted notices so require.
Turn Off Your Device Before Flying
AIRCRAFT
FCC regulations prohibit using the transmitting and phone functions of your device while in the air. In
addition, most airline regulations prohibit the on-board use of portable PCs (and all other portable electronic
devices that could potentially emit stray RF energy), particularly during take-offs and landings, to prevent any
possible interference with the reception of signals by airborne electronic navigational devices.
Appendix 157
Turn your device OFF before boarding an aircraft. Always request and obtain prior consent and approval of an
authorized airline representative before using your device aboard an aircraft. Always follow the instructions of
the airline representative whenever using your device aboard an aircraft, to prevent any possible interference
with airborne electronic equipment.
Turn Off Your Device in Dangerous Areas
BLASTING AREAS
To avoid interfering with blasting operations, turn your device OFF when in a “blasting area” or in areas posted
“Turn off two-way radio”. Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your device OFF when in any area with a potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling
areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using
liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or articles, such
as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your
vehicle’s engine.
General Safety
Your pocket PC is a high quality piece of equipment. Before operating, read all instructions and cautionary
markings on the product, battery and adapter/charger.
Failure to follow the directions below could result in serious bodily injury and/or property damage due to
battery liquid leakage, fire or rupture.
DO NOT use or store this equipment in a place where it will be exposed to high temperatures, such as near an
open flame or heat-emitting equipment.
DO NOT drop your device or subject it to severe shock. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the device or its accessories. If service or repair is required, return unit to an authorized
cellular service center. If the unit is disassembled, the risk of electric shock or fire may result.
Never allow metallic objects, such as staples and paper clips, to get into the inside of your device.
Never touch the liquid that might leak from a broken liquid crystal display. Contact with this liquid could
cause a skin rash. If the crystal display liquid should come into contact with the skin or clothing, wash it
immediately with clean water.
In the event that the device emits an unusual odor or sound or generates smoke, immediately disconnect the
AC adapter from the power outlet, then detach the battery.
Antenna Safety
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or
attachments could impair call quality, damage your device, or result in violation of FCC regulations. Please
contact your local dealer for replacement antenna.
Do not use the device with a damaged antenna. If a damaged antenna comes into contact with the skin, a
minor burn may result. Please contact your local dealer for replacement antenna.
158 Appendix
Battery Safety
Your device uses a removable and rechargeable lithium ion battery. Please contact customer service for
assistance should you need a replacement battery.
DOs
• Only use the battery and charger approved by the manufacturer.
• Only use the battery for its original purpose.
• Try to keep batteries in a temperature between 41°F (5°C) and 95°F (35°C).
• If the battery is stored in temperatures above or below the recommended range, give it time to warm
up or cool down before using.
• Completely drain the battery before recharging. It may take one to four days to completely drain.
• Store the discharged battery in a cool, dark, and dry place.
• Purchase a new battery when its operating time gradually decreases after fully charging.
• Properly dispose of the battery according to local regulations.
DON’Ts
• Don’t attempt to disassemble the battery – it is a sealed unit with no serviceable parts.
• Don’t expose the battery terminals to any other metal object (e.g., by carrying it in your pocket or purse
with other metallic objects such as coins, clips and pens). This can short circuit and critically damage
the battery.
• Don’t leave the battery in hot or cold temps. Otherwise, it could signicantly reduce the capacity and
lifetime of the battery.
• Don’t dispose of the battery into a re.
Lithium ion batteries are recyclable. When you replace the removable battery, please request the repair center
to recycle the battery in accordance with RBRC standards. When disposing of the battery by yourself, please
call RBRC at (800) 822-8837 for proper disposal tips.
Never touch any fluid that might leak from the built-in battery. Such liquid when in contact with the eyes or
skin, could cause injury to the skin or eyes. Should the liquid come into contact with the eyes, irrigate the
eyes thoroughly with clean water and immediately seek medical attention. In the event the liquid comes into
contact with the skin or clothing, wash it away immediately with clean water.
Adapter/Charger
Use the Correct External Power Source
A product should be operated only from the type of power source indicated on the electrical ratings label. If
you are not sure of the type of power source required, consult your authorized service provider or local power
company. For a product that operates from battery power or other sources, refer to the operating instructions
that are included with the product.
The AC Adapter/Charger designed for this unit requires the use of a standard 120 V AC power source for
device operation.
Never attempt to disassemble or repair an AC adapter/charger. Never use an AC adapter/charger if it has a
damaged or worn power cord or plug. Always contact an authorized service center, if repair or replacement is
required.
Never alter the AC cord or plug on an AC adapter/charger. If the plug will not fit into the available outlet, have
a proper outlet installed by a qualified electrician.
Appendix 159
Never allow any liquids or water to spill on an AC adapter/charger when it is connected to an AC power
source.
Always use the authorized AC adapter/charger to avoid any risk of bodily injury or damage to your cellular
phone or battery.
Never attempt to connect or disconnect the AC adapter/charger with wet hands. Always unplug the AC
adapter/charger from the power source before attempting any cleaning. Always use a soft cloth dampened
with water to clean the equipment, after it has been unplugged.
Handling the cord on this product or cords associated with accessories sold with this product, will expose you
to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. Wash
hands after handling.
Always disconnect the travel charger or desktop charger from the power source when it is not in use.
Index
Symbols
3D sound 134
A
A2DP 110
ActiveSync
- copy les 99
- install 64
- overview 32
- set up 64
- synchronize with Exchange Server 88
- synchronize with PC 64
Add and remove programs 138
Adobe Reader LE 32, 98
Airplane mode 104
Alarm 55
Answer/end a call 49
Appointment search 44
Attachment
- add to e-mail 82
- download 83
Audio Booster 32, 134
B
Backlight 54
Basic settings 54
Bass effects 134
Battery
- battery information 16
- save battery power 141
Beam
- via Bluetooth 111
Block Recognizer 43
Bluetooth
- Bluetooth Explorer 32, 111
- Bluetooth le sharing 111
- Bluetooth shared folder 111
- hands-free headset 110
- modes 109
- overview 109
- partnership (pairing) 109
- stereo headset 110
- synchronize 65
- turn on and o 104
- visible 109
Burst capture mode 120
Button controls and LEDs 150
C
Calculator 32
Calendar 31, 70
Calendar search 44
Calibration 18
Camera
- capture modes 120
- controls 121
- le formats 121
- icons 121
- overview 32
- Quick Settings Panel 123
- settings 123
- specications 149
Camera Album 126
Clear Storage 140
Clock & Alarms 34, 54
Comm Manager 32, 35, 104
Company Directory 92
Conference call 50
Contacts 31, 68
Contacts Picture capture mode 120
Contacts search 44
Cookies 106
Copy
- les between device and PC 99
- les to storage card 99
- media les from PC to device 132
Customize
- Start menu 57
- Today screen 56
D
Device ID 55
Device name 55
Digitally sign messages 94
Digital signature
- sign and encrypt 94
- verify 94
Dimensions and weight 149
Direct Push 89
Disconnect data connections 104
Download
- web feeds 114
Download e-mail 83
Draw 73
E
E-mail
- IMAP4 79
- mail server settings 79
- POP3 79
- search 44
- security 93
- send 81
- settings (POP3/IMAP4) 80
- setup wizard 79
- types of e-mail accounts 78
Edit picture 130
Index 161
Landscape 18
Launcher 24
Letter Recognizer 42
Library screen (Windows Media Player Mobile) 132
Live Messenger 108
Long Press End Key 34
M
Mail search 44
Make call
- from Call History 48
- from Contacts 47
- from Phone program 47
- from Speed Dial 48
- from TouchFLO 48
Memory 140, 149
Messaging
- about 31, 76
- e-mail 78, 79, 81
- text (SMS) 77
Messenger 32, 108
Microsoft Office Mobile 32, 98
Multimedia 27, 131
Multipress mode 39
Music 31
Mute 50
N
News channels (web feeds) 115
Notes 32, 73
Notes search 44
Now Playing screen (Windows Media Player Mobile) 132
Numeric mode 39
O
Office Mobile 32, 98
OneNote Mobile 32, 98
Onscreen input methods 38
Open PDF file 98
Owner information 56
P
Panning
- nger panning 27
Panorama capture mode 120
Password 58
Phone 32, 46, 47
Photo capture mode 120
Pictures & Videos
- edit picture 130
- le formats 129
- overview 32
- play GIF animation 130
- play videos 130
- view pictures 130
Picture Theme capture mode 120
Emergency call 52
Encrypt messages 94
Equalizer 134
Excel Mobile 32, 98
Exchange Server 89
F
Favorite contacts 26
Favorites (Internet Explorer) 105
File Explorer 32
Find contact
- Company Directory 92
- on device 69
Finger panning 27
Finger scrolling 27
Forward e-mail 83
G
Games 32
GIF animation 130
H
Hard reset 140
Help 31
Help search 44
Home 22
Home page (Internet Explorer) 104
HTC Home 22
I
IMAP4 79
Input methods
- Block Recognizer 43
- Keyboard 40
- Letter Recognizer 42
- Symbol Pad 42
- Transcriber 43
Input Panel 38
International call 52
Internet Explorer Mobile 31, 104
Internet security settings 106
Internet Sharing 32
J
Java
- create folders 146
- manage MIDlets/MIDlet suites 146
- uninstall MIDlets 146
- update a MIDlet/MIDlet suite 146
K
Keyboard
- on-screen 40
L
162 Index
Playback screen (Windows Media Player Mobile) 132
Play GIF animation 130
Playlists
- Windows Media Player Mobile 133
Play media 133
Play videos 130
Plug-in
- HTC Home 22
Podcasts 117
POP3 79
Portrait 18
PowerPoint Mobile 32, 98
Programs 31
- Audio Booster 134
- Text Messages Retry 33
Put call on hold 49
Q
Quick menu 21
Quick Tasks 21
QWERTY keyboard 38, 39
R
Receive call 49
Record
- voice note 73
Regional settings 54
Regulatory notices 151
Reply
- e-mail 83
- text (SMS) 78
Reset
- clear storage 140
- hard reset 139
- soft reset 139
Review screen (Camera) 123
Ring tone 55
Ring type 55
RSS Hub
- about 32, 114
- headline list 116
- news channels 115
- podcasts 117
S
Save picture from Web page 106
Screen text size 54
Scrolling
- nger scrolling 27
Search 32, 33, 44
Secure/Multipurpose Internet Mail Extension (S/MIME) 93
Security settings (Internet Explorer) 106
Send
- e-mail 81
- text message (SMS) 77
Settings 54
- camera 123
Settings (Connections tab)
- Beam 35
- Bluetooth 35, 109
- Comm Manager 35, 104
- Connections 35
- Network Cards 35
- USB to PC 35, 65
Settings (Personal tab)
- Buttons 33
- Input 33
- Lock 33
- Menus 33, 57
- Owner Information 33, 56
- Phone 33, 55
- Sounds & Notications 33, 56
- Today 31, 33, 56
- Voice Commander 33
Settings (System tab)
- About 34, 55
- Backlight 54
- Certicates 34
- Clear Storage 34, 140
- Clock & Alarms 34, 54, 55
- Customer Feedback 34
- Device Information 34
- Encryption 34, 59
- Error Reporting 34
- External GPS 34
- Key Lock 34
- Keypad QuickTasks 34
- Memory 34, 140
- Microphone AGC 34
- Power 19, 34, 141
- Regional Settings 34, 54
- Remove Programs 34, 138
- Screen 18, 34, 54
- Task Manager 34, 138
- TouchFLO 30, 34
Shortcuts 24, 27
Smart Dialing 50
SMS 77
Soft reset 139
Sound 24
Sounds & Notifications 56
Speakerphone 50
Specifications 149
Speed Dial 48
Sports capture mode 120
Start menu 20, 57
Status icons 30
Storage Card 16
Storage card
- check available space 140
- copy les 100
- encrypt 59
- install 18
Swap/switch calls 50
Synchronize
Index 163
- ActiveSync 64
- change information types 65
- via Bluetooth 65
- Windows Media Player 66, 132
- with computer 64
- with Exchange Server 88
System information 149
T
Task Manager 138
Tasks 33, 72
Tasks search 44
Temporary Internet files 106
Text messages 77
Text size
- Web pages 105
Text size (screen) 54
Today screen 19, 56
Touch Cube (TouchFLO) 25
TouchFLO 25, 34, 48
Touch Keypad 41
Transcriber 43
Treble effects 134
Troubleshoot
- sync connection 65
- Windows Media Player Mobile 134
Turn Bluetooth on and off 104
Turn device on and off 18
Turn DirectPush on and off 104
Turn Phone fiunctoin on and off 104
Turn phone function on and off 46
TV & Radio 31
U
USB to PC 35, 65
Using Java 145
V
Verify digital signature 94
Vibrate 46, 55
Video capture mode 120
View
- pictures 130
Voice call 47
Voice Command 144
Voicemail 48
Voice Recorder 33, 73
Volume 46
W
Weather 22
Web pages
- layout 105
- text size 105
Windows Live 33, 106
Windows Live Messenger 32, 108
Windows Media Player Mobile
- le formats 131
- menus 132
- overview 33
- playlists 133
- troubleshoot 134
Windows Mobile Device Center 62
Windows Update 34, 141
Word Mobile 32, 98
X
xT9 mode 39
Z
ZIP
- create archive 101
- open zip le and extract les 100
- overview 33, 100
Zoom (Camera) 122
