User Manual

Pocket

User Manual

2 |

Please Read Before Proceeding

Trademarks

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile,

ActiveSync, Excel, Internet Explorer, MSN, Outlook, PowerPoint, and Word

are either registered trademarks or trademarks of Microsoft Corporation in the

United States and/or other countries.

All trademarks are the properties of their respective owners.

THIS DEVICE IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

WHEN INSERTING YOUR SIM CARD, MAKE SURE THE DEVICE IS

POWERED OFF, AND THAT THE SIM CARD SNAPS INTO THE SOCKET.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE

DEVICE’S OUTER CASING.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable

materials exist, the product should be turned off and the user should obey

all signs and instructions. Sparks in such areas could cause an explosion or

fire resulting in bodily injury or even death. Users are advised not to use the

equipment at refueling points such as service or gas stations, and are reminded

of the need to observe restrictions on the use of radio equipment in fuel depots,

chemical plants, or where blasting operations are in progress. Areas with a

potentially explosive atmosphere are often, but not always, clearly marked.

These include fueling areas, below deck on boats, fuel or chemical transfer or

storage facilities, and areas where the air contains chemicals or particles, such

as grain, dust, or metal powders.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and

stipulate that you must inform the person with whom you are speaking that the

conversation is being recorded. Always obey the relevant laws and regulations

of your country when using the recording feature of your Pocket PC Phone.

| 3

Important Safety Precautions

When using this product, the safety precautions below must be taken to offset

possible legal liabilities and damages.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the battery.

Other usage may be dangerous and will invalidate any approval given to this

product.

SAFETY IN AIRCRAFTS

Due to the possible interference caused by this product to an aircraft's

navigation system and its communications network, using this product on board

an airplane is against the law in most countries.

ENVIRONMENT RESTRICTIONS

Do not use this product at gas or refueling stations. The use of this product is

also prohibited in fuel storehouses, chemical plants, and locations containing

explosives.

SAFETY FOR ENVIRONMENTS

Do not use this product in gas stations, fuel depots, chemical plants or where

blasting operations are in progress, or in potentially explosive atmospheres

such as fuelling areas, below deck on boats, fuel or chemical transfer or storage

facilities, and areas where the air contains chemicals or particles, such as grain,

dust, or metal powders. Please be aware that Sparks in such areas could cause

an explosion or fire resulting in bodily injury or even death.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with

handheld devices, except in the case of emergency. In some countries, using

hand-free devices as an alternative is allowed.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this

device is forbidden in most hospitals and medical clinics.

4 |

NONIONIZING RADIATION

This product should be operated in the suggested normal condition only to

ensure the radiative performance and safety of the interference. As with other

mobile radio transmitting equipment, users are advised that for satisfactory

operation of the equipment and for the safety of personnel, it is recommended

that no part of the human body be allowed to come too close to the antenna

during operation of the equipment.

| 5

Contents

Chapter 1 Getting Started

1.1 Getting to Know your Device and its Accessories ... 10

1.2 Battery Information ..................................................... 15

1.3 Starting Up ................................................................... 16

1.4 The Today Screen ........................................................ 18

1.5 Using the Start Menu ................................................... 20

Chapter 2 Entering and Searching Information

2.1 Introduction .................................................................. 24

2.2 Using the Keyboard .................................................... 25

2.3 Using Letter Recognizer ............................................. 25

2.4 Using Block Recognizer ............................................. 26

2.5 Using Transcriber ........................................................ 26

2.6 Using Phone Pad ......................................................... 30

2.7 Drawing and Writing on the Screen ........................... 33

2.8 Recording a Note ......................................................... 34

2.9 Searching Information ................................................ 35

6 |

Chapter 3 Using Phone Features

3.1 Using the Phone .......................................................... 38

3.2 Making a Call ............................................................... 39

3.3 Receiving a Call ........................................................... 41

3.4 In-call Options ............................................................. 42

3.5 Additional Dialing Information ................................... 43

Chapter 4 Synchronizing Your Pocket PC

Phone

4.1 Using ActiveSync ........................................................ 46

4.2 Synchronizing Information ......................................... 47

4.3 Synchronizing via Infrared and Bluetooth ................ 50

4.4 Synchronizing Music, Video, and Pictures ............... 51

Chapter 5 Managing Your Pocket PC Phone

5.1 Personalizing Your Pocket PC Phone ....................... 54

5.2 Adding and Removing Programs ............................... 61

5.3 Managing Memory ....................................................... 62

5.4 Backing Up Files ......................................................... 64

5.5 Protecting Your Device ............................................... 65

5.6 Resetting Your Pocket PC Phone .............................. 67

| 7

Chapter 6 Getting Connected

6.1 Connecting to the Internet .......................................... 70

6.2 Internet Explorer Mobile ............................................. 72

6.3 Using Bluetooth ........................................................... 75

6.4 Using Wireless Modem ............................................... 79

6.5 Using Wireless LAN Manager ..................................... 82

6.6 Using Terminal Services Client .................................. 85

Chapter 7 Exchanging Messages and Using

Outlook

7.1 E-mail and Text Messages .......................................... 88

7.2 Pocket MSN Messenger .............................................. 94

7.3 Calendar ....................................................................... 96

7.4 Contacts ....................................................................... 97

7.5 Tasks ............................................................................. 99

7.6 Notes .......................................................................... 101

Chapter 8 Experiencing Multimedia

8.1 Using Camera and Camcorder ................................. 104

8.2 Using Pictures & Videos ............................................113

8.3 Using Windows Media Player ....................................117

8 |

Chapter 9 Using Other Applications

9.1 Word Mobile ............................................................... 124

9.2 Excel Mobile ............................................................... 126

9.3 Viewing Slide Shows with PowerPoint Mobile ....... 128

9.4 Using MIDlet Manager ............................................... 129

Appendix

A.1 Regulatory Notices .................................................... 136

A.2 Specifications ........................................................... 142

A.3 Index ........................................................................... 144

1.1 Getting to Know your Device and its Accessories

1.2 Battery Information

1.3 Starting Up

1.4 The Today Screen

1.5 Using the Start Menu

Chapter 1

Getting Started

10 | Getting Started

1.1 Getting to Know your Device and its Accessories

Front, top, and left-side view

Getting Started | 11

1 POWER/Backlight Press to turn on and off your device or backlight.

2 MiniSD Card Slot Lets you insert a storage card (miniSD card) for storing data.

3 Antenna

4 Notification LED 1

Bi-color LED on the left side: Blue and Green for Bluetooth system

notification of powered-up and ready to transmit radio frequency

signal, and Wi-Fi status.

5 Notification LED 2

Bi-color LED on the right side: Green and Orange for GSM standby,

SMS message, GSM network status, notification, battery charging

status.

6 Speaker Listen to a phone call from here.

7 Touch Screen Use to write, draw, or make a selection with the stylus.

8 Left SOFT KEY Press to perform the command shown in the label above the button.

9 Start Button Press to open the Start menu.

10 OK Button Press to verify your data entries, or to exit the program in use.

11 Right SOFT KEY Press to perform the command shown in the label above the button.

12 END Button Press to end a call.

13 Navigation Pad

Press this multi-directional control up, down, left, or right to move

through menus, program instructions; carry out the selection by

pressing ENTER (the center button).

14 TALK Button Press to answer an incoming call or dial a number.

15 Infrared Port Lets you exchange file(s) or data with other devices wirelessly.

16 Voice Recognition Press to start the voice recognition program (if installed).

17 Volume Press up or down to adjust the volume.

18 Voice Recorder Press to record a voice note.

12 | Getting Started

Back, bottom, and right view

Getting Started | 13

1 Stylus and Stylus Slot

2 Camera Lens

3 Flash Light Allows you to capture images even in a dark environment. To turn on

the flash light, tap the Flash icon when in Camera mode.

4 Self-Portrait Mirror Position your device until this mirror reflects the image you want to

capture.

5External Antenna

Connector

You can connect your device to an external antenna to utilize the

superior reception quality.

6 Microphone Speak into the microphone when receiving or making a phone call or

voice recording.

7 Earphone Jack Allows you to listen to audio media or use the phone’s hands-free kit.

8 Sync Connector Use this connector for synchronizing data or recharging the battery.

9 Reset Button With the stylus, press the Reset button to soft-reset your device.

10 Camera Button Press to launch the camera. Press again to take a picture.

Accessories

AC adapter Recharge the device battery.

USB cable Connect your device to a PC and synchronize data.

Stereo-wired headset with

volume control, jog dial,

and Send and End buttons

Pick up and hang up incoming and outgoing calls.

USB cradle

Allows you to recharge your device and the second battery (if have),

as well as using ActiveSync to synchronize data between your device

and the PC.

• To recharge the device (or battery), connect the cradle to the

electrical outlet.

• To synchronize, connect the cradle to the USB port on your PC.

14 | Getting Started

The QWERTY keyboard

Your device provides you with a QWERTY keyboard, which is similar to a standard

keyboard on your PC. To use the hardware keyboard, slide the main screen rightward to

reveal the keyboard.

You can do the following with the hardware keyboard:

• To type lowercase letters, press the keys using your thumbs or ﬁngers.

• To use all uppercase letters, press ﬁrst, and then .

• To type a single uppercase letter, press and then press the corresponding key.

• To enter a number or symbol (labeled in red color), press and then press the

corresponding key.

• Press the Left/Right SOFT KEY to perform the command shown in the label above

the key.

• Press to verify your data entries or exit the program in use.

• Press to open the Start menu.

• Press the arrow keys for directional movement.

Getting Started | 15

1.2 Battery Information

Your device contains a rechargeable Li-ion polymer battery. Your device is designed to

use only manufacturer-specified original batteries and accessories. Battery performance

depends on many factors, including your wireless service provider’s network configuration,

signal strength, the temperature of the environment in which you operate your device, the

features and/or settings you select and use, items attached to your device’s connecting

ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

• Talk-time: 2.5 – 5 hours

• Standby time: up to 200 hours

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or water.

• Do not expose to temperatures above 60˚C (140˚F).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulation.

Install and charge the battery

New batteries are shipped partially charged. Before you can use your device, you need

to install and charge the battery. To install the battery, remove the battery cover first, and

then insert the battery by aligning the exposed copper part of the battery pack with the

protruding copper conductor. Then, gently push the battery into place, and replace the

battery cover.

Some batteries perform best after several full charge/discharge cycles. The time needed

to fully charge the battery is less than 4 hours. You can charge the battery by:

• Connecting your device directly to an external power source.

• Plugging the device sync cable into the USB port on your PC.

16 | Getting Started

Low battery

When the low-battery warning appears, do the following:

1. Immediately save your current data.

2. Synchronize with your PC.

3. Turn off your device.

To check the battery power

• Tap Start > Settings > System tab > Power.

• Tap the Battery icon on the Today screen.

1.3 Starting Up

Turn the device on and off

To turn on the device, press the POWER button. When you turn on the device for the

first time, you are asked to complete a calibration process. For more information, see

“Calibrate the device” in this chapter.

To turn off the device, press POWER again.

Note Pressing POWER turns off your device temporarily and switches the device to sleep

mode. However, you can still receive messages and calls while your device is in sleep

mode.

Calibrate the Device

Calibrating the device screen involves tapping with the stylus the center of a cross as it

moves around the screen. This process ensures that when you tap the screen with your

stylus, the tapped item is activated.

Getting Started | 17

If your device does not accurately respond to screen taps, please follow these steps to

re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the General tab, tap Align Screen, and follow the instructions on the screen.

Manage screen settings

The device touch screen has three orientation modes: Portrait, Landscape (right-handed),

and Landscape (left-handed). Portrait mode allows you to get a better view or a better

operation of certain programs on your device, while Landscape mode may be optimal for

viewing longer text files.

• To change the orientation, tap Start > Settings > System tab > Screen, and select the

orientation you want: Portrait, Landscape (right-handed), or Landscape (left-handed).

• To smooth the edges of screen fonts for many programs, on the ClearType tab, select

the Enable ClearType check box.

• To increase the readability or to see more content on the screen, on the Text Size tab,

adjust the text size by moving the slider.

18 | Getting Started

1.4 The Today Screen

The Today screen displays important information, such as upcoming appointments and

status indicators. You can tap a section on the screen to open the associated program.

• To access the Today screen, tap Start > Today.

• To customize the Today screen display, including the background image, tap Start >

Settings > Personal tab > Today.

1Tap to open the Start menu.

2Tap to view call status information.

3Tap to view network status and related

options.

4Tap to control device volume level.

5Displays the current time. Tap and hold

to change the clock mode: Analog or

Digital.

6Displays the current date. Tap to setup

date, time, alarm, and more.

7Tap to set owner information.

8Your day at a glance with reminders. Tap

to open the related program: messages,

tasks, and appointments.

9Tap to open MSN sign-in screen.

10 Tap to start Wireless LAN Manager.

11 Tap to open the Calendar screen.

12 Tap to open the Contacts screen.

13 Tap to open the Power Settings screen.

1 2 3 5

11 12 13

Note You can access the Today screen from anywhere by tapping Start > Today.

Getting Started | 19

Indicators

Following are some of the status icons that you may see on your device.

Icon Description

Sound on

Ringer in vibration mode

Sound off

Battery level

Battery very low

Battery empty

Battery charging

Connection is active

Connection is not active

Synchronization in progress

Synchronization error

Indicates maximum signal strength

No signal

Radio is turned off

No phone service

Roaming

Voice call

Voice call in progress

Data call in progress

Calls are forwarded

20 | Getting Started

1.5 Using the Start Menu

The Start menu, located at the top left corner of the Today screen, displays a list of

programs. It lets you close a screen and switch from one program to another. You can

start a program by scrolling through the programs list and then pressing ENTER, or by

tapping a program with the stylus.

1Tap to start a program. The items displayed

in Start menu can be customized by tap

Start > Settings > Personal tab > Menus.

2Tap to start a recently-used program.

3Tap to view and select more programs that

are installed in your device.

4Tap to change device settings.

5Tap to see a Help topic for the current

screen.

Icon Description

Call on hold

Missed call

New e-mail or text messages

New voice mail

New MSN messages

Getting Started | 21

Icon Description

ActiveSync Synchronizes information between your device and a PC.

Calculator Performs basic arithmetic and calculations, such as addition, subtraction,

multiplication, and division.

Calendar Keeps track of your appointments and creates meeting requests.

Camera Snaps photos or shoots video clips with accompanying audio.

Contacts Keeps track of your friends and colleagues.

Download Agent Provides information about the download status and the downloaded

content from the Internet.

Enroller Enables you to install and use certificates to connect to your Wi-Fi network.

Excel Mobile Creates new workbooks or lets you view and edit Excel workbooks.

File Explorer Enables you to organize and manage files on your device.

Games Lets you play two pre-installed games: Bubble Breaker and Solitaire..

Help Enables you to see Help topics for a program on your device.

Internet Explorer Internet Explorer browses Web and WAP sites, and downloads new

programs and files from the Internet.

Messaging Sends and receives e-mail and text messages.

MIDlet Manager Enables you to download and install Java applications, such as games

and tools, on your device.

Notes Creates handwritten or typed notes, drawings, and recordings.

Phone Makes and receives calls, switches between calls and sets up conference calling.

Pictures & Videos Collects, organizes, and sorts picture and video files in the My Pictures

folder of your device or on a storage card.

Pocket MSN Sends and receives instant messages with your MSN Messenger contacts.

Indicators

Following are some of the icons for the programs that are already installed on your device.

22 | Getting Started

Icon Description

PowerPoint Mobile Lets you view and edit PowerPoint slides and presentations.

Search Enables you to search contacts, data, and other information on your device.

Tasks Keeps track of your tasks.

Windows Media Enables the multimedia function on your device.

Wireless Manager Allows you to manage the Wi-Fi connection.

Wireless Modem Enables your device as an external modem for a PC by using a serial

port, USB port, or infrared port.

Word Mobile Creates new documents or lets you view and edit Word documents.

2.1 Introduction

2.2 Using the Keyboard

2.3 Using Letter Recognizer

2.4 Using Block Recognizer

2.5 Using Transcriber

2.6 Using Phone Pad

2.7 Drawing and Writing on the Screen

2.8 Recording a Note

2.9 Searching Information

Chapter 2

Entering and Searching Information

24 | Entering and Searching Information

2.1 Introduction

When you start a program or select a field that requires text or numbers, Input Panel

automatically becomes available. Input Panel provides access to the various input

methods available on your device, including Block Recognizer, Keyboard, Letter

Recognizer, Phone Pad, and Transcriber. By default, the Input Panel icon appears on

the menu bar to indicate which input method is currently selected. The Input Selector

arrow (shown at the right side of the Input Panel icon) opens a list of available input

methods.

Example:

To show or hide Input Panel

• Tap the Input Panel icon on the menu bar.

Input Panel (Keyboard)

Input Selector arrow

Input Panel icon

Icon Input method

The on-screen keyboard.

Letter Recognizer or Block Recognizer.

Phone Pad

Transcriber

Entering and Searching Information | 25

2.2 Using the Keyboard

To enter text, symbols, and numbers, you can either type using the QWERTY keyboard or

the standard on-screen keyboard. For use of the hardware keyboard, see the instruction

in Chapter 1.

Use the standard on-screen keyboard

The on-screen keyboard is available when text entry is possible. You can enter text by

tapping keys on the keyboard that is displayed on the screen.

To enter text using the on-screen keyboard

1. In a program, tap the Input Selector arrow, and then tap Keyboard.

2. Enter text by tapping keys on the on-screen keyboard.

To enlarge the on-screen keyboard

1. Tap the Input Selector arrow, and then tap Options.

2. In the Input method list, select Keyboard.

3. Tap Large Keys.

2.3 Using Letter Recognizer

With Letter Recognizer, you can write individual letters, numbers, and punctuation, which

are then converted into typed text.

To use Letter Recognizer

1. In a program, tap the Input Selector arrow, and then tap Letter Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

• Enter capital letters by writing in the ABC (left) area of the box.

• Enter lower case letters by writing in the abc (middle) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter punctuation and symbols by tapping in either area of the box and then writing

the desired character.

26 | Entering and Searching Information

2.4 Using Block Recognizer

With Block Recognizer, you use a single stroke to write letters, numbers, symbols, and

punctuation, which are then converted into typed text.

To use Block Recognizer

1. In a program, tap the Input Selector arrow, and then tap Block Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

• Enter letters by writing in the abc (left) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter symbols and punctuation by tapping in either area of the box and then writing

the desired character.

Note Letter Recognizer and Block Recognizer are available when text entry is possible.

Tip For help with writing characters with Letter Recognizer and Block Recognizer, tap the

question mark near the writing area.

2.5 Using Transcriber

Transcriber is a handwriting recognition program that allows you to write in cursive, print,

or a combination of both. Transcriber works transparently in the background of programs,

recognizing words with its integrated dictionary. When Transcriber is turned on, it interprets

stylus movement anywhere on the screen as handwriting input. For more information

about using Transcriber, see Help on your device.

To start Transcriber

1. Start a program that accepts user input, such as Word Mobile.

2. Tap the Input Selector arrow, and then tap Transcriber. The Transcriber introductory

screen appears.

Entering and Searching Information | 27

To write using Transcriber

1. In a program, position the cursor where you want text to appear.

2. Use the stylus to write anywhere on the screen. The handwriting will be converted to

text shortly after you lift the stylus from the screen.

To enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to add

punctuation or a special symbol to existing text.

• In a program, tap on the Transcriber toolbar. The keyboard remains visible until you

tap the button again.

Tips To reposition the keyboard, tap and hold the title bar, then drag to the desired location.

When no text is selected, you can also open the keyboard by doing the gesture.

To edit text

1. In a program, draw a line across the text you want to edit.

2. After you lift the stylus from the screen, the line 2. will disappear and the selected text

will be highlighted.

3. Do either of the following:

• Rewrite the text.

• Use gestures to capitalize letters, insert a space, and so on. For information about

using gestures, see “Transcriber Gestures” in this chapter.

Transcriber Gestures

Use quick strokes of the stylus to edit your text or to insert returns, spaces, or tabs.

Tip You can also use the Enter, Space, and Backspace buttons on the Transcriber toolbar.

28 | Entering and Searching Information

Do To

Insert a paragraph return at the cursor.

The horizontal portion of the gesture must be at least two times longer than

the vertical portion.

Insert a space at the cursor.

The horizontal portion of the gesture must be at least two times longer than

the vertical portion.

Move the cursor one space back and erase any text.

Do the gesture by drawing a line from right to left.

Open the menu of alternate words if a word is selected or the on-screen

Transcriber keyboard if no text is selected.

Do the gesture by drawing a line straight down and back up.

Change the capitalization of a selected letter, word, or block of text.

Do the gesture by drawing a line straight up.

Undo the last action.

Do the gesture by drawing a line straight up and back down.

Copy the selected text.

Do the gesture by drawing a line from left to right and back.

Cut the selected text.

Do the gesture by drawing a line from right to left and back.

Paste copied or cut text.

Do the gesture by drawing a line from the lower left of the screen diagonally

up toward the right and back down to the right.

Insert a tab.

The horizontal portion of the gesture must be at least two times longer than

the vertical portion.

Entering and Searching Information | 29

The Transcriber toolbar

The Transcriber toolbar, which appears at the bottom of the screen when Transcriber is

open, provides easy access to several tools, Enter, Space, and Backspace buttons, and

Left and Right arrow buttons.

Tap To

Open the Options dialog box, where you can set options such as writing

direction, text entry, and shorthand.

Open Letter Shapes, where you can set your personal writing styles to

maximize recognition.

Use the miniature keyboard to quickly enter numbers, punctuation, and

other symbols.

Change the character recognition mode.

• a mode. This is the default for optimum handwriting recognition.

• 123 mode. Numbers and some letters are allowed and the calculator is

activated.

• A mode. All letters are automatically capitalized.

If you are in A or 123 mode, recognition returns automatically to the default

mode once you lift the stylus.

Insert a space at the cursor.

Insert a paragraph return at the cursor.

Move the cursor one space to the left.

Move the cursor one space to the right.

Move the cursor one space back and erase any text.

Open Transcriber Help.

30 | Entering and Searching Information

2.6 Using Phone Pad

Phone Pad provides a flexible, alternate method for entering information. Using Phone

Pad, you can easily switch between three input modes: T9, Multi-Tap, and Numeric,

including a list of symbols for greater convenience.

To start Phone Pad

1. Start a program that accepts user input, such as Word Mobile.

2. Tap the Input Selector arrow, and then tap Phone Pad.

Tip Phone Pad can be started at any time, except when your device is in Camera mode or

displaying the Today screen.

Use T9 input mode

By default, the device Phone Pad is in T9 mode. It is the easiest and most convenient way

to enter text in English because it has the capability to enter text in alphanumeric format.

As you tap alphanumeric keys on the keypad, T9 tries to automatically match the letters

you have selected with the most likely completed word.

Entering and Searching Information | 31

You can do the following by using the T9 input mode:

• To enter a word, tap the keys on the keypad.

• To insert a word in the current program screen:

1. Tap any word in the wordlist (directly above the keypad).

2. Tap .

3. Select a word, and then tap to insert the word.

• To enter a number, do any of the following:

• Tap and hold on the desired number key on the keypad.

• Select the numeric mode, and tap the number.

• To insert a space or tab, tap .

• To scroll through the wordlist, tap or .

• To enter a capital letter, tap .

• To add symbols, do any of the following:

• Tap to display the most frequently used symbols on the wordlist.

• Tap to choose a symbol from the entire list.

Use Multi-Tap input mode

Multi-Tap input mode is an alphabetic mode that allows you to manually enter individual

letters to form words.

Use Numeric input mode

Numeric input mode allows you to enter a number each time you tap a number key. You

can compile several numbers on the wordlist, and then tap to insert the numbers at the

current cursor position on the screen.

32 | Entering and Searching Information

Use the Options screen

You can customize various behaviors for Phone Pad, including the language database on

the Options screen. To access the Phone Pad Options screen, do any of the following:

• Tap and hold on the keypad.

• Tap the Input Panel icon at the bottom of the screen, and tap Options.

• On the Input Method tab of the Input screen, tap Options.

The Options screen provides you with the following check boxes to setup:

• Turn on one-touch symbol entry. Select this check box to choose one symbol at a

time.

• Auto-hide matching wordlist. Select this check box to hide the wordlist after you

choose a word.

• Turn on screen tap sound. Select this check box to play a sound each time you tap a

key.

• Automatically add a space after selecting a word. Select this check box to add a

space automatically at the end of every word.

• Enable shortcut menu for deleting user-deﬁned words. Select this check box to

display a pop-up (shortcut) menu whenever you tap a word that is in the user database.

Tip Tapping Help takes you to the Phone Pad Help topics.

Entering and Searching Information | 33

2.7 Drawing and Writing on the Screen

With your Pocket PC Phone, you can draw directly on the screen, or write on the screen

and save notes in your own handwriting. To do this, you must set the input mode in Notes

to Writing. If you prefer to use handwriting or frequently add drawings to your notes, you

may find it helpful to set Writing as the default input mode. If you prefer typed text, set

Typing as the default input mode.

To set the input mode for Notes

1. Tap Start > Programs > Notes.

2. In the note list, tap Menu > Options.

3. In the Default mode box, tap one of the following:

• Writing if you want to draw or enter handwritten text in a note.

• Typing if you want to create a typed note.

4. Tap OK.

To write a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. Write your text on the screen.

4. When ﬁnished, tap OK to return to the note list.

Notes To select handwritten text, tap and hold next to the writing. As soon as dots appear, and

before they form a complete circle, quickly drag across the writing.

If a letter crosses three ruled lines, it is treated as a drawing rather than text.

To draw a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. Draw on the screen, crossing at least three ruled lines.

34 | Entering and Searching Information

4. A selection box labeled Drawing appears around your drawing.

5. When ﬁnished, tap OK to return to the note list.

Note To select a drawing (for example, to copy or delete it), tap and hold the drawing briefly.

When you lift the stylus, the drawing is selected.

2.8 Recording a Note

You can create a stand-alone recording (voice note) or you can add a recording to a note.

For more information about creating, changing, or saving Notes, see “Notes” in Chapter 7.

To create a voice note

1. Tap Start > Programs > Notes.

2. Do one of the following:

• To create a stand-alone recording, record from the note list.

• To add a recording to a note, create or open a note.

3. If you do not see the Recording toolbar, tap Menu > View Recording Toolbar.

4. Tap the record icon ( ) to begin recording.

5. Hold your device’s microphone near your mouth or other source of sound.

6. Tap the stop icon ( ) when ﬁnished recording.

7. If you are adding a recording to a note, tap OK to return to the note list when ﬁnished.

8. If you are recording in an open note, an icon will appear in the note.

9. If you are creating a stand-alone recording, the recording will appear in the note list.

Tip To quickly create a recording, press the RECORD button. When you hear the beep,

begin your recording. Release the button when you are finished.

Entering and Searching Information | 35

To change recording formats

1. Tap Start > Settings > Personal tab > Input.

2. Tap the Options tab, and in the Voice recording format list, tap the format you want.

3. Tap OK.

Note You can also change recording formats from within Notes. In the note list, tap Menu >

Options > Global Input Options link (at the bottom of the page).

2.9 Searching Information

You can search for files and other items stored on your device in the My Documents folder

or on a storage card. You can search by file name or by words located in the item. For

example, you can search in e-mail messages, notes, appointments, contacts, and tasks,

as well as in online Help.

To search for a ﬁle or an item

1. Tap Start > Programs > Search.

2. In Search for, enter the ﬁle name, word, or other information you want to search for.

3. If you have looked for this item before, tap the Search for arrow and select the item

from the list.

4. In Type, select a data type to help narrow your search.

5. Tap Search.

6. The My Documents folder and subfolders are searched.

7. In the Results list, tap the item you want to open.

Note The storage card symbol ( ) is displayed next to the names of files saved on a storage

card.

36 | Entering and Searching Information

3.1 Using the Phone

3.2 Making a Call

3.3 Receiving a Call

3.4 In-call Options

3.5 Additional Dialing Information

Chapter 3

Using Phone Features

38 | Using Phone Features

3.1 Using the Phone

Like a standard mobile phone, you can use your Pocket PC Phone to make, receive, and

keep track of calls and send SMS messages. You can also take notes while talking, and

dial directly from Contacts.

The Phone screen

From the Phone screen, you can access Call History, Speed Dial, and Phone settings. To

open the Phone screen, do one of the following:

• Use the stylus and tap Start > Phone.

• Press TALK on the device.

• Directly dial the phone number by pressing numeric keys on the hardware keyboard.

Turn on/off flight mode

In many countries you are required by law to turn off your phone on board an aircraft.

Turning off the power doesn’t turn off the phone. You must enable flight mode in order to

turn off the phone.

You can turn on flight mode and still keep your device turned on and use other functions.

• Tap the Signal icon, and tap Turn on ﬂight mode to turn the phone off.

• To resume call function, disable ﬂight mode by tapping Turn off ﬂight mode.

Adjust the device volume

1. Tap the Speaker icon .

2. Under Volume, do the following:

• Adjust the phone volume ( ) or device volume ( )

by moving the slider to the desired volume level.

• Tap On, Vibrate, or Off to change both the system and

ringer volume settings.

Using Phone Features | 39

Notes To adjust the conversation phone volume, you must do it during a call. Adjusting the

volume at another time will affect the ring, notification, and MP3 sound levels.

When you enable Vibrate mode, sound will automatically be muted and the device will

vibrate when an incoming call is received. The Vibrate icon ( ) will appear in the title

bar to indicate that Vibrate mode is enabled.

3.2 Making a Call

With your device, you can make a call from Phone, Contacts, Call History, and Speed Dial.

Make a call from Phone

• On the Phone keypad, tap the desired phone number, and tap Talk at the lower right of

the screen.

Tip If you tap a wrong number, tap the Back arrow to erase individual numbers one at a time.

To delete all the numbers, tap and hold the Back arrow.

40 | Using Phone Features

Make a call from Contacts

• Tap Start > Contacts.

• Tap the desired contact, and press TALK twice (once to send the number to the Phone

keypad, and once to dial the number).

• You can also tap the desired contact in the contacts list, and tap the phone number that

you want to call. Or, tap and hold the desired contact, and on the shortcut menu, tap

Call Work, Call Home, or Call Mobile.

To specify the number to dial

By default, the work telephone number for that contact is dialed when you make a call

from Contacts. However, you can specify that a different phone number is used instead.

1. Tap Start > Contacts.

2. Press NAVIGATION up or down to select the contact.

3. Press NAVIGATION left or right. The letters representing the number will change as

you scroll through them.

Make a call from Call History

1. On Phone keypad, tap Call History.

2. Tap Menu > Filter and tap a category.

3. Scroll to the desired contact or phone number, and tap Call.

Make a call from Speed Dial

Use Speed Dial to call frequently-used numbers with a single tap. For example, if you

assign a contact to the Location 2 in Speed Dial, you can simply tap and hold 2 on Phone

screen to dial the contact’s number. The number must already exist in Contacts before you

can create a Speed Dial entry.

To create a Speed Dial entry

1. On Phone keypad, tap Menu > Speed Dial.

2. Tap Menu > New.

Using Phone Features | 41

3. Tap a contact. Tap the phone number for which you want to create a speed dial.

4. In the Location box, select an available location for the new speed dial.

Note Location 1 is generally reserved for your voice mail, and Speed Dial will designate the

next available location by default. If you want to place a number in a position that is

already occupied, the new number will replace the number that is already there.

Tips To create a Speed Dial entry from Contacts, tap and hold the contact name, tap Add to

Speed Dial, and select an available location for the new Speed Dial.

To delete a Speed Dial, in the Speed Dial list, tap and hold the desired entry, and tap

Delete.

3.3 Receiving a Call

To answer or reject an incoming call

When you receive a phone call, a message will appear, giving you an option to either

answer or ignore the incoming call.

• To answer the call, tap Answer, or press TALK on your device.

• To reject the call, tap Ignore, or press END on your device.

To end a call

Once an incoming or outgoing call is in progress, you can press END on your device or

tap End to hang up.

42 | Using Phone Features

3.4 In-call Options

To put a call on hold

Your device notifies you when you have another incoming call, and gives you the choice of

rejecting or accepting the call. If you are already on a call and accept the new call, you can

choose to switch between the two callers, or set up a conference call between all three

parties.

1. Tap Answer to take the second call, and put the ﬁrst one on hold.

2. To end the second call and return to the ﬁrst call, tap End or press END on your

device.

To switch between two calls

• Tap Swap.

To set up a conference call

1. Either put a call on hold, and dial a second number; or, accept a second incoming call

when you already have one in progress.

2. Tap Conference.

Tips If the conference connection is successful, the word “Conference” will appear at the top

of the screen.

To add additional people to your conference call, tap Hold, enter the phone number, and

then tap Resume to return and continue.

Note Not all service providers support conference calling. Contact your service provider for

details.

Using Phone Features | 43

To turn on or off the speakerphone

The built-in speakerphone on your device allows you to talk hands-free or lets other

people listen to the conversation.

• During a call, press and hold TALK until the speakerphone turns on, and the

speakerphone icon ( ) appears in the title bar.

• To turn off the speakerphone, press and hold TALK again until the speakerphone turns

off.

Warning! To avoid damage to your hearing, do not hold your device against your ear when the

speakerphone is turned on.

To mute a call

You can turn off the microphone during a call, so that you can hear the caller but the caller

cannot hear you.

• During a call, tap Mute.

• When the microphone is turned off, the mute icon ( ) appears on the screen. Tap

Unmute to turn on the microphone again

3.5 Additional Dialing Information

Make an emergency call

• Enter the international emergency number for your locale, and tap Talk.

Make an international call

1. Tap and hold the 0 key on the Phone keypad until the + sign appears. The + replaces

the international preﬁx of the country that you are calling.

2. Enter the full phone number you want to dial, and tap Talk. The full phone number

includes country code, area code (without the leading zero, if any) and phone number.

44 | Using Phone Features

4.1 Using ActiveSync

4.2 Synchronizing Information

4.3 Synchronizing via Infrared and Bluetooth

4.4 Synchronizing Music, Video, and Pictures

Chapter 4

Synchronizing Your Pocket PC Phone

46 | Synchronizing Your Pocket PC Phone

4.1 Using ActiveSync

ActiveSync synchronizes information on your device with information on your PC, such

as Outlook content. ActiveSync can also synchronize over a wireless or cellular network

with Microsoft Exchange Server, if your company or service provider is running Microsoft

Exchange Server with Exchange ActiveSync. When you synchronize, ActiveSync

compares the information on your device with the information on your PC and/or

Exchange Server and updates all locations with the most recent information.

With ActiveSync, you can:

• Synchronize information, such as Outlook E-mail, Contacts, Calendar, or Tasks

information on your device with your PC, as well as pictures, video, and music.

• Synchronize Outlook E-mail, Contacts, Calendar appointments, and Tasks on your

device directly with Exchange Server so that you can stay up to date even when your

PC is turned off.

• Exchange ﬁles between your device and your PC without synchronizing.

• Select which types of information are synchronized and specify how much information

is synchronized. For example, you can choose how many weeks of past Calendar

appointments to synchronize.

Before you can synchronize information with a PC, you must first install ActiveSync on

your PC and create a synchronization relationship between your device and the PC.

You can install ActiveSync from the Getting Started disc that comes with your device.

ActiveSync is already installed on your device.

Once you have installed ActiveSync and set up a synchronization relationship, ActiveSync

on the PC recognizes your device when you connect it, and automatically transfers the

synchronization settings you specified on your device.

You may be able to synchronize your device with Exchange Server through your company

or wireless service provider. If you plan to do so, obtain the name of the Exchange Server,

your user name, password, and domain name from your administrator before starting the

Sync Setup Wizard.

Synchronizing Your Pocket PC Phone | 47

To install and set up ActiveSync

1. Install ActiveSync on your PC, as described on the Getting Started disc. After Setup

completes, the Sync Setup Wizard automatically starts when you connect your device

to the PC.

2. Follow the instructions on the screen to complete the wizard. In the Sync Setup Wizard,

do one or both of the following:

• Create a synchronization relationship between your PC and the device.

• Conﬁgure an Exchange Server connection to synchronize directly with Exchange

Server.

3. Choose information types to synchronize.

Note When you finish the wizard, ActiveSync synchronizes your device automatically. Once

synchronization completes, you can disconnect your device from your PC.

4.2 Synchronizing Information

When you connect your device to the PC using a USB or serial cable, an infrared

connection, or a Bluetooth connection, ActiveSync will immediately synchronize. While the

device is connected, ActiveSync synchronizes every time you make a change on either

the PC or the device.

Synchronizing Outlook information

If you have set up a synchronization relationship between your device and the PC,

synchronization keeps Outlook information up-to-date on both computers. ActiveSync

synchronizes a limited amount of information by default to save storage space on your

device. You can change the amount of information synchronized for a given information

type in Settings for the information type.

48 | Synchronizing Your Pocket PC Phone

You can set up your device to synchronize with more than one PC or with a combination

of one or more PCs and Exchange Server. When synchronizing with multiple computers,

the items that you synchronize will appear on all of the computers with which they are

synchronized. For example, if you have set up synchronization with two PCs (PC1 and

PC2), which have different items, and you synchronize Contacts and Calendar on the

device with both computers, the result is as follows:

Location New state

PC1 All Outlook contacts and calendar appointments that were on PC2

are now also on PC1.

PC2 All Outlook contacts and calendar appointments that were on PC1

are now also on PC2.

Device All Outlook contacts and calendar appointments from both PC1 and

PC2 are on the device.

Note Outlook e-mail can be synchronized with only one computer.

To start and stop synchronization

• To synchronize Outlook information and other local information on the PC, including

media ﬁles, connect your device to the PC using Bluetooth, infrared (IR) or a cable or

cradle.

• If you are synchronizing directly with Exchange Server, you can use this connection to

the PC to “pass though” to the network, or you can synchronize without connecting to

the PC over a cellular or Wi-Fi network.

• In ActiveSync, tap Sync. To end synchronization before it completes, tap Stop.

To change which information is synchronized

1. In ActiveSync on the device, tap Menu > Options.

2. Do one or both of the following:

Synchronizing Your Pocket PC Phone | 49

• Select the check box for any items you want to synchronize. If you cannot select

a check box, you might have to clear the check box for the same information type

elsewhere in the list.

• Clear the check box for any items you want to stop synchronizing.

3. To stop synchronizing with one PC completely, tap the PC, and then tap Delete.

Notes Outlook e-mail can be synchronized with only one computer.

To change available synchronization settings, select the type of information and tap

Settings.

To synchronize directly with Exchange Server

You can set up synchronization with Exchange Server on your device, if it is available to

you through your company or wireless service provider. However, you should first ask your

administrator for the following information and then carry on with the steps: Exchange

Server name, your user name, password, and domain name.

1. In ActiveSync on the device, tap Menu > Conﬁgure Server. If you have not yet set up

synchronization with Exchange Server, this will say Add Server Source.

2. In Server address, enter the name of the server running Exchange Server, and tap

Next.

3. Enter your user name, password, and domain, and tap Next. To change the rules for

resolving synchronization conﬂicts, tap Advanced.

4. Select the check boxes for the types of information items that you want to synchronize

with Exchange Server.

5. To change available synchronization settings, select the type of information, and tap

Settings.

6. Tap Finish.

50 | Synchronizing Your Pocket PC Phone

4.3 Synchronizing via Infrared and Bluetooth

You can connect your device to the PC to synchronize using the local wireless

technologies, such as infrared (IR) and Bluetooth. These technologies have almost similar

but slightly differing requirements.

To synchronize with a PC via infrared

1. Follow the instructions in ActiveSync Help on the PC for setting up your PC to receive

infrared beams.

2. Line up the infrared (IR) ports according to the instructions in the manufacturer’s

documentation for your device so that they are unobstructed and within close range.

3. On the device, tap Start > Programs > ActiveSync.

4. Tap Menu > Connect via IR.

5. Tap Sync.

To synchronize with a PC via Bluetooth

1. Follow the instructions in ActiveSync Help on the PC for conﬁguring Bluetooth on your

PC to support ActiveSync.

2. On the device, tap Start > Programs > ActiveSync.

3. Tap Menu > Connect via Bluetooth. Make sure that Bluetooth is turned on at the

device and the PC, and that they are within close range.

4. If this is the ﬁrst time you have connected to this PC via Bluetooth, you must ﬁrst

complete the Bluetooth wizard on the device and set up a Bluetooth partnership

between your device and the PC.

For more information about enabling and configuring Bluetooth, see Chapter 6.

Note You can also use the Sync Setup Wizard to set up the device to synchronize remotely

with Exchange Server. This wizard is started when you connect your mobile device to

your PC after installing ActiveSync on the PC.

Synchronizing Your Pocket PC Phone | 51

4.4 Synchronizing Music, Video, and Pictures

If you want to carry your music or other digital media with you along while you travel,

ActiveSync works with Windows Media Player to synchronize music, video, and pictures

with your device.

Other than selecting the Media information type in ActiveSync to be synchronized, all

media synchronization settings must be set in Windows Media Player. Before media can

be synchronized, you must do the following:

• Install Windows Media Player Version 10 on the PC.

• Connect your device to the PC with a USB cable. If the device is currently connected

using Bluetooth or infrared, you must end that connection before media can be

synchronized.

• Insert a storage card into your device (32MB or larger is recommended).

• Set up a sync partnership between the storage card and Windows Media Player.

Change Media synchronization settings

Once you select the Media information type in ActiveSync to be synchronized, any of

your favorite music, video, and picture files in Windows Media Player playlists can be

synchronized. All you have to do is set up synchronization in Windows Media Player for

those media files.

To set up a sync relationship with a storage card

1. Open Windows Media Player.

2. Click the Sync tab.

3. Select the storage card.

4. Click Set up Sync.

For information about using Windows Media Player on the device, see Chapter 8.

52 | Synchronizing Your Pocket PC Phone

5.1 Personalizing Your Pocket PC Phone

5.2 Adding and Removing Programs

5.3 Managing Memory

5.4 Backing Up Files

5.5 Protecting Your Device

5.6 Resetting Your Pocket PC Phone

Chapter 5

Managing Your Pocket PC Phone

54 | Managing Your Pocket PC Phone

5.1 Personalizing Your Pocket PC Phone

Today screen settings

The Today screen shows your upcoming appointments, active tasks, and information

about e-mail messages. You can customize the Today screen on your device.

To customize the Today screen

1. Tap Start > Settings > Personal tab > Today.

2. On the Appearance tab, select the desired theme for the background of the Today

screen.

3. On the Items tab, select the items you want to appear on the Today screen.

Tip To change the order of items displayed on the Today screen, tap the item, and then tap

Move Up or Move Down.

To add a custom background image

You can use one of your own pictures as the background image on the Today screen. Be

aware that pictures can affect the readability of text on the Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Select the Use this picture as the background check box, and tap Browse to view a

list of your picture ﬁles.

3. Tap the ﬁle name of the picture you want to use.

4. Tap OK.

To set options for displaying appointments on the Today screen

If you have a large number of appointments, you may want to specify the kind of

appointments that are displayed on the Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Tap the Items tab.

3. Select Calendar, and then tap Options.

Managing Your Pocket PC Phone | 55

4. Do any of the following:

• Select Next appointment to show only the next appointment in your schedule, or

Upcoming appointments to show multiple appointments.

• Clear the Display all day events check box if you do not want to display all-day

events.

To set options for displaying tasks on the Today screen

If you have a large number of tasks, you may want to specify the kind of tasks that are

displayed on the Today screen.

1. Tap Start > Settings > Personal tab > Today.

2. Tap the Items tab.

3. Select Tasks, and then tap Options.

4. Do any of the following:

• Under Display number of, select the type of tasks you want to appear on the Today

screen.

• In the Category list, select whether to display only tasks assigned to a speciﬁc

category or to display all tasks.

Customize the Start menu

You can choose which items appear in the Start menu.

1. Tap Start > Settings > Personal tab > Menu.

2. Select the check boxes of the items you want to appear in the Start menu. You can

select up to seven items.

Tip You can also create folders and shortcuts to appear on the Start menu. In ActiveSync on

your PC, click Explore. In the Mobile Device window, double-click My Windows Mobile-

Based Device > Windows > Start Menu, and then create the folders and shortcuts that

you want. You will see the added items after you synchronize.

56 | Managing Your Pocket PC Phone

Set up Date / Time / Language / Regional options

You can set up the correct date, time, language, and regional settings according to your

use.

To set the time and date

1. Tap Start > Settings > System tab > Clock & Alarms.

2. Select the correct time zone and change the date or time.

Note During synchronization, the time on your device is updated with the time on your PC.

To set an alarm

1. Tap Start > Settings > System tab > Clock & Alarms > Alarms tab.

2. Tap <Description> and enter a name for the alarm.

3. Tap the day of the week for the alarm. You can select multiple days by tapping each

desired day.

4. Tap the time to open a clock and set the time for the alarm.

5. Tap the alarm icon ( ) to specify the type of alarm you want. You can choose a

ﬂashing light, a single sound, a repeating sound, or vibration.

6. If you choose to play a sound, tap the list next to the Play sound check box and tap

the sound you want.

To set the time and date for a different location

If you visit or communicate with someone in a particular time zone often, you can select it

as your visiting time zone.

1. Tap Start > Settings > System tab > Clock & Alarms.

2. Tap Visiting.

3. Select the correct time zone and change the time or date.

Managing Your Pocket PC Phone | 57

To change language and regional settings

The style in which numbers, currency, dates, and times are displayed is specified in

Regional Settings.

1. Tap Start > Settings > System tab > Regional Settings.

2. On the Region tab, select your region and language.

3. The region you select determines which options will be available on the other tabs.

4. To customize settings further, tap the appropriate tabs and select the desired options.

Personal and system settings

Your device may come with programs already assigned to hardware buttons. You can

customize these buttons to open the programs you use most, or to perform certain

shortcuts such as changing the screen orientation, opening the Today screen, or opening

Input Panel.

To reassign programs or shortcuts to program buttons

1. Tap Start > Settings > Personal tab > Buttons.

2. A list of buttons and their current assignments is displayed on the Program Buttons

tab.

3. Tap the button you want to reassign. To help you identify the buttons, there are

numbers and icons representing the original function of the button.

4. In the Assign a program box, tap the program or shortcut you want to assign.

5. Tap OK.

To increase or decrease the size of text on the screen

1. Tap Start > Settings > System tab > Screen > Text Size.

2. Move the slider to increase or decrease the text size.

To enter owner information

1. Tap Start > Settings > Personal tab > Owner Information.

2. On the Identiﬁcation tab, enter your personal information.

58 | Managing Your Pocket PC Phone

Note Entering and displaying owner information are best practices; they allow someone to

return the device to you in case it is lost.

Tip If owner information is displayed on the Today screen, you can open and edit the

information directly from the Today screen. Just tap that section of the screen.

To choose how to be notiﬁed about events or actions

1. Tap Start > Settings > Personal tab > Sounds & Notiﬁcations.

2. On the Sounds tab, choose how you want to be notiﬁed by selecting the appropriate

check boxes.

3. On the Notiﬁcations tab, in Event, tap an event name and choose how you want to

be notiﬁed by selecting the appropriate check boxes. You can choose from several

options, such as a special sound, a message, or a ﬂashing light.

Tip Turning off sounds and the flash light helps conserve battery power.

To adjust the speed for scrolling

Pressing and holding NAVIGATION up or down (Up/Down control) scrolls through the

items in a list.

1. Tap Start > Settings > Personal tab > Buttons > Up/Down Control tab.

2. Do one of the following:

• Under Delay before ﬁrst repeat, move the slider to shorten or lengthen the time

that elapses before scrolling begins.

• To change the time it takes to scroll from one item to the next, under Repeat rate,

move the slider to adjust the speed.

To ﬁnd the operating system version number and detailed device information

• Tap Start > Settings > System tab > About.

The Version tab displays the operating system information and important device

information, including the type of processor and the amount of memory that is installed.

Managing Your Pocket PC Phone | 59

To change the device name

1. Tap Start > Settings > System tab > About > Device ID tab.

2. Enter a name.

The device name must begin with a letter, consist of letters from A to Z, numbers from 0 to

9, and cannot contain spaces. Use the underscore character to separate words.

Why is the device name important?

The device name is used to identify the device in the following situations:

• Synchronizing with a PC

• Connecting to a network

• Restoring information from a backup

Note If you synchronize multiple devices with the same PC, each device must have a unique

name.

To make the battery last longer

The device battery power lasts based on the battery type and how you use your device.

Try the following to help preserve battery life:

• Tap Start > Settings > System tab > Power. On the Advanced tab, you can specify

when your device turns off to conserve battery power. For optimum conservation,

specify 3 minutes or less.

• Use the AC adapter to plug your device into external power whenever possible,

especially when using a CompactFlash card or when using a modem or other

peripherals.

• Adjust the backlight settings.

To adjust the brightness of the backlight

1. Tap Start > Settings > System tab > Backlight > Brightness tab.

2. Move the sliders up to increase and down to decrease the brightness.

60 | Managing Your Pocket PC Phone

To set the backlight to dim after a time delay

1. Tap Start > Settings > System tab > Backlight.

2. Tap the Battery Power tab or the External Power tab.

3. Select the Turn off backlight if device is not used for check box, and specify the

time delay.

Phone settings

You can customize phone settings, such as the ring type and ring tone to be used for

incoming calls, and the keypad tone to be used when entering phone numbers.

To change the ring tone

1. Tap Start > Settings > Personal tab > Phone > Phone tab.

2. In the Ring tone list, tap the sound you want to use.

Tip To use custom .wav, .mid, or .wma files as ring tones, use ActiveSync on your PC to copy

the file to the /Windows/Rings folder on your device. Then, select the sound from the

Ring tone list. For more information about copying files to your device, see ActiveSync

Help on your PC.

To change the ring type

You can change the way that you are notified of incoming calls. For example, you can

choose to be notified by a ring, a vibration, or a combination of both.

1. Tap Start > Settings > Personal tab > Phone > Phone tab.

2. In the Ring type list, tap the desired option.

To change the keypad tone

You can change the tone you hear when entering a phone number on the keypad. If set

to Long tones, the tone is heard continuously for as long as the number on the keypad is

pressed. Use this setting if you are having trouble accomplishing tasks that rely on tones

from your phone such as accessing messages from an answering machine. If set to Short

tones, the tone is heard only for one or two seconds. If set to Off, no tone will be heard.

Managing Your Pocket PC Phone | 61

1. Tap Start > Settings > Personal tab > Phone > Phone tab.

2. In the Keypad list, tap the desired option.

Phone services

Services, such as Call Waiting enable you to choose how to handle all incoming calls on

your device.

To display Caller ID, block calls, use Call Waiting, or use Call Forwarding

1. Tap Start > Settings > Personal tab > Phone > Services tab.

2. Tap the service you want to use, and tap Get Settings.

5.2 Adding and Removing Programs

Before you purchase additional programs for your device, you should note the name

of your device, the version of Windows Mobile software running on it, and the type of

processor. This information will help you select a program that is compatible with your

device. For more information, see “To get detailed device information” and “To find the

operating system version number” in this chapter.

Programs available for purchase usually include a Setup program (commonly named

“setup.exe”) that you must first install on your PC. You can then use ActiveSync to add

programs to your device, or add a program directly from the Internet.

To add programs

1. Download the program to your PC (or insert the CD or disk that contains the program

into your PC). You may see a single *.exe ﬁle, a *.zip ﬁle, a Setup.exe ﬁle, or several

versions of ﬁles for different device types and processors. Be sure to select a program

designed for your device and processor type.

2. Read any installation instructions or documentation that comes with the program. Many

programs provide special installation instructions.

3. Connect your device and PC.

62 | Managing Your Pocket PC Phone

4. Double-click the *.exe ﬁle.

• If the executable ﬁle is an installation wizard, follow the instructions on the screen.

Once the program has been installed on your PC, the wizard will automatically

transfer the program to your device.

• If an installation wizard does not start, you will see an error message stating that the

program is valid but that it is designed for a different type of computer. You will need

to copy this program to your device. If you cannot ﬁnd any installation instructions

for the program, use ActiveSync to copy the program ﬁle to the Program Files folder

on your device.

To remove programs

You can only remove programs that you installed. Programs that come with your device

cannot be removed.

1. Tap Start > Settings > System tab > Remove Programs.

2. In the Programs in storage memory list, select the program you want to remove, and

tap Remove.

3. Tap Yes. If another conﬁrmation message appears, tap Yes again.

5.3 Managing Memory

You may need to stop a program if it becomes unstable or the program memory is low.

To see how much memory is available

• Tap Start > Settings > System tab > Memory.

On the Main tab, the amount of memory allocated to file and data storage versus program

storage is displayed, as well as the amount of memory in use versus the available

memory.

To see available storage card memory

You can see how much memory is available on a storage card that is inserted in your

device.

Managing Your Pocket PC Phone | 63

1. Tap Start > Settings > System tab > Memory.

2. Tap the Storage Card tab.

Tip If you have more than one card inserted, tap the list box and then the storage card whose

information you want to see.

To free up program memory

Try the following to free memory on your device:

• Close programs you are not currently using.

• Move e-mail attachments to a storage card.

• Move ﬁles to a storage card. Tap Start > Programs > File Explorer. Tap and hold the

ﬁle, and then tap Cut. Browse to the storage card folder and tap Edit > Paste.

• Delete unnecessary ﬁles. Tap Start > Programs > File Explorer. Tap and hold the ﬁle,

and then tap Delete.

• Delete large ﬁles. To ﬁnd your largest ﬁles, tap Start > Programs > Search. In the

Type list, tap Larger than 64 KB, and then tap Search.

• In Internet Explorer Mobile, delete temporary Internet ﬁles and clear history information.

For more information, see “Internet Explorer Mobile” in Chapter 6.

• Remove programs you no longer use.

• Reset your device.

To close a program

In most cases, programs automatically close to free needed memory, however, you can

close programs manually, if you prefer.

1. Tap Start > Settings > System tab > Memory > Running Programs tab.

2. In the Running Programs list, tap the program you want to close, and then tap Stop.

Tip In most programs, you can also use the keyboard shortcut CTRL+Q to close the

program.

64 | Managing Your Pocket PC Phone

5.4 Backing Up Files

You can back up files to your PC using ActiveSync, or copy files to a storage card you

insert into your device. Your device has an expansion slot compatible with a range of

secure digital (SD) and multimedia (MMC) storage cards.

Using ActiveSync, you can copy or move information from the PC to the device and

vice versa. Changes you make to the information on one computer will not affect the

information on the other computer. If you want to automatically update information on both

your device and PC, synchronize the information instead. For more information about

copying and synchronizing files, see ActiveSync Help on your PC.

To copy ﬁles to a storage card

1. Push the storage card into the storage card slot until it clicks into place. The card is

secure when it does not protrude from the base.

2. Tap Start > Programs > File Explorer and navigate to the appropriate folder.

3. Tap and hold the desired ﬁle, and then tap Copy.

4. Tap the folder list (labeled My Documents by default), and then tap Storage Card.

5. Tap Menu > Edit > Paste.

To copy a ﬁle using ActiveSync

Copying a file results in separate versions of a file on your device and PC. Because the

files are not synchronized, changes made to one file will not affect the other.

1. Connect your device to your PC.

2. In ActiveSync, click Explore to open the Mobile Device window for your device.

3. In the Mobile Device window, go to the ﬁle that you want to copy on your device or PC.

4. Do one of the following:

• To copy the ﬁle to your device, right-click the ﬁle and click Copy. Then, right-click

the desired folder under Mobile Device, and click Paste.

• To copy the ﬁle to your PC, right-click the ﬁle and click Copy. Then, right-click the

desired folder on your PC, and click Paste.

Managing Your Pocket PC Phone | 65

To automatically save ﬁles on a storage card

In the Word Mobile, Excel Mobile, and Notes programs, you may find it helpful to save all

new documents, notes, and workbooks directly on a storage card.

1. From the program ﬁle list, tap Menu > Options.

2. With a storage card inserted in the device, in the Save to box, tap the appropriate

storage card to automatically save new items on the storage card.

3. Tap OK.

Note In the file or note list, a storage card symbol is displayed next to the names of files saved

on a storage card.

5.5 Protecting Your Device

You can prevent unauthorized access to any part of the device by using password

protection. You create your own password when you begin using your device.

To protect your device with a password

You can help keep your data more secure by requiring a password every time the device

is turned on.

1. Tap Start > Settings > Personal tab > Password.

2. Select the Prompt if device unused for check box, and in the box to the right,

select how long your device must be turned off before a password is required. In the

Password type box, select the type of password you would like to use. Enter the

password and, if necessary, conﬁrm the password. If your device is conﬁgured to

connect to a network, use a strong password to help protect network security.

3. On the Hint tab, enter a phrase that will help you remember your password, but

doesn’t allow others to guess your password. The hint will be displayed after the wrong

password is entered four times.

4. Tap OK.

The next time the device is turned on, you will be prompted to enter your password.

66 | Managing Your Pocket PC Phone

Notes Each time a wrong password is entered, the time the device takes to respond will get

longer and longer until the device appears to be not responding.

If you forget your password, you must follow the instructions in your owner’s manual to

clear memory before you can access your device.

To change your password

1. Tap Start > Settings > Personal tab > Password. You will be prompted to enter your

current password.

2. In the Password box, enter your new password.

3. On the Hint tab, enter a phrase that will help you remember your new password, but

doesn’t allow others to guess your password. The hint will be displayed after the wrong

password is entered four times.

4. Tap OK.

To display owner information on the Today screen

Having your contact information displayed on the Today screen on startup allows for easy

identification of the device in case it is lost.

1. Tap Start > Settings > Personal tab > Owner Information.

2. On the Options tab, select the Identiﬁcation information check box. S

3. On the Options tab, select the Notes check box if you want additional text displayed,

such as: Reward if found. When you select the check box, you need to enter the

additional text on the Notes tab.

Tip To display owner information on the Today screen, tap Start > Settings > Personal tab >

Today. On the Items tab, select the Owner Info check box.

Managing Your Pocket PC Phone | 67

5.6 Resetting Your Pocket PC Phone

Occasionally you may need to reset your Pocket PC Phone. A normal (or soft) reset

of your device clears all active program memory and shuts down all active programs.

This can be useful when the device is running slower than normal, or a program is not

performing properly. A soft reset is also necessary after the installation of some programs.

If a soft reset is performed when programs are running, unsaved work will be lost.

You can also perform a hard reset (also known as a full reset). A hard reset should be

performed only if a normal reset does not solve a system problem. After a hard reset, the

device is restored to its default settings—the way it was when you first purchased it and

turned it on. Any programs you installed, data you entered, and settings you customized

on the device will be lost. Only Windows Mobile software and other pre-installed programs

will remain.

To perform a soft reset

• Use the stylus to lightly press and hold the RESET button on the left side of your

device. The device restarts, and then displays the Today screen.

To perform a hard reset

Press and hold both SOFT KEYS on the device. Keep these keys pressed, and at the

same time, use the stylus to lightly press and hold the RESET button on the left side of

your device. Press either 0 to restore to factory default or X to exit the hard reset process.

Reset button

68 | Managing Your Pocket PC Phone

6.1 Connecting to the Internet

6.2 Internet Explorer Mobile

6.3 Using Bluetooth

6.4 Using Wireless Modem

6.5 Using Wireless LAN Manager

6.6 Using Terminal Services Client

Chapter 6

Getting Connected

70 | Getting Connected

6.1 Connecting to the Internet

Your device is equipped with powerful networking functions that enable you to connect

to the Internet. You can set up connections to the Internet or to a corporate network to

browse the Internet, and exchange e-mail or instant messages. Your device has two

groups of connection settings: My ISP (Internet Service Provider) and My Work Network.

The My ISP settings are used to connect to the Internet, while My Work Network settings

can be used to connect to any private, corporate network.

To connect to the Internet via ISP

1. Obtain the following information from your ISP:

• ISP server phone number

• User name

• Password

• Access point name (required for CDMA connection)

2. Tap Start > Settings > Connections tab > Connections.

3. Tap Add a new modem connection.

4. Enter a name for the connection.

5. Select a modem from the list. For example, if you want to use the mobile phone

network, select Cellular Line.

6. Tap Next.

7. Complete the connection wizard by entering the required information and tap Finish.

Notes To view additional information for any screen, tap Help.

To modify your connection settings, tap Manage existing connections on the Connections

screen, and complete the connection wizard.

To connect to a private network

1. Obtain the following information from your network administrator:

• Server phone number

• User name

Getting Connected | 71

• Password

• Domain (If provided by an ISP or a network administrator)

2. Tap Start > Settings > Connections tab > Connections.

3. In My Work Network, follow the instructions for each type of connection.

4. Complete the connection wizard, and then tap Finish.

To start browsing the Internet

• When the connection settings are completed, tap Start > Programs > Internet

Explorer.

To reset or modify the network card settings on your device

1. Tap Start > Settings > Connection tab > Network Cards.

2. In the My network card connects to list, select the appropriate item:

• If you want to connect to the Internet using your ISP, select The Internet.

• If you want to connect to a private network, select Work.

3. In Tap an adapter to modify settings, tap the appropriate adapter. The ﬁelds on the

IP Address tab are populated automatically.

4. Conﬁgure the TCP/IP settings (if required). If your ISP or private network does not

use dynamically-assigned IP addresses, tap Use speciﬁc IP address and enter the

requested information. Contact your ISP or network administrator to obtain the IP

address, subnet mask, and/or default gateway (if required).

5. Conﬁgure the DNS and WINS settings (if required). If your ISP or private network

does not use dynamically-assigned IP addresses, enter the requested information on

the Name Servers tab. Servers that require an assigned IP address may also require

a way to map computer names to IP addresses. DNS and WINS are the resolution

options supported on your device.

72 | Getting Connected

6.2 Internet Explorer Mobile

Internet Explorer Mobile is a full-featured Internet browser, optimized for use on your

mobile device.

To start Internet Explorer Mobile

• Tap Start > Internet Explorer.

To choose a Home page

1. In Internet Explorer Mobile, tap Menu > Tools > Options > General tab.

2. Do one of the following:

• To use the displayed page as your Home page, tap Use Current.

• To use the default Home page, tap Use Default.

Tip To go to your Home page, tap Menu > Home.

To transfer favorites from your PC

You can transfer the favorites you have stored on your PC to your device by synchronizing

the Internet Explorer favorites on your PC with your device.

1. In ActiveSync on your PC, click Options on the Tools menu, and then select Favorites.

2. In Internet Explorer on your PC, save or move favorite links to the Mobile Favorites

subfolder in the Favorites list.

3. Connect your mobile device to your PC. If synchronization does not start automatically,

click Sync.

Use Internet Explorer Mobile

In Internet Explorer Mobile, you can operate any of the following functions:

To change the size of text on Web pages

• Tap Menu > Zoom, and then tap the size you want.

Getting Connected | 73

To add a favorite

1. Go to the page you want to add.

2. Tap and hold the page, and then tap Add to Favorites.

3. Conﬁrm or change the name, and select a folder for storing the favorite.

To delete a favorite or folder

1. Tap Menu > Favorites > Add/Delete tab.

2. Select the desired item, and then tap Delete.

To change how Web pages ﬁll the screen

1. Tap Menu > View.

2. Do one of the following:

• One Column. Arranges the content into one column that is as wide as the screen.

This means that you will rarely have to scroll horizontally.

• Default. Maintains a layout similar to what you see on a desktop computer, but

it makes items smaller and arranges the content so that you can see most of it

without having to scroll horizontally.

• Desktop. Keeps the same layout and size as on a desktop computer, which will

require both horizontal and vertical scrolling.

To show or hide pictures on Web pages

• Tap Menu > View > Show Pictures. A check mark next to Show Pictures indicates

that pictures will be displayed on Web pages.

To save a picture from a Web page

1. Tap and hold the picture, and then tap Save Image.

2. Do one of the following:

• To save the picture in My Pictures on your device, tap Yes.

• To save the picture in another location, such as a storage card, tap Save As.

74 | Getting Connected

To clear the History list

1. Tap Menu > Tools > Options > Memory tab.

2. Tap Clear History.

To change cookies and security settings

Internet Explorer Mobile supports the protocols used by Secure Sockets Layer (SSL). A

connection that uses SSL helps you to send personal information more safely.

Cookies are small files containing information about your identity and preferences so that

a page can tailor information to your needs. The page sends the file, and it is stored on

your mobile device.

1. Tap Menu > Tools > Options > Security tab.

2. Select the check boxes for the options you want, and then tap OK.

Tip To prevent Internet Explorer Mobile from accepting any cookies, clear the Allow cookies

check box.

To delete temporary Internet ﬁles

Some Web content is stored as you view it to speed up the display of pages you frequently

visit or have already seen. You may want to delete these files to free storage space.

1. Tap Menu > Tools > Options > Memory tab.

2. Tap Delete Files. All pages stored on your device, including ofﬂine favorites content,

will be deleted.

Getting Connected | 75

6.3 Using Bluetooth

Bluetooth is a short-range wireless communications technology. Devices with Bluetooth

capabilities can exchange information over a distance of about 10 meters without requiring

a physical connection. You can even beam information to a device in a different room, as

long as it is within range.

The software included with your device allows you to use Bluetooth in the following ways:

• Beam information, such as ﬁles, appointments, tasks, and contact cards, between

devices that have Bluetooth capabilities.

• Create a dial-up modem connection between your device and a Bluetooth-enabled

phone, and then beam information using the Bluetooth phone as a modem.

To turn on or off Bluetooth on your device

1. On your device, tap Start > Settings > Connections tab > Bluetooth.

2. Select the Turn on Bluetooth and Make this device discoverable to other devices

check boxes.

3. Tap OK.

Note To add an extra layer of security while beaming information with other devices, or to set

up Bluetooth synchronization, tap Start > Settings > System tab > Bluetooth Setting.

Bluetooth modes

Bluetooth on your device operates in three different modes:

• On. Bluetooth is turned on and you can use Bluetooth features.

• Off. Bluetooth is turned off. In this mode, you can neither send nor receive information

using Bluetooth. You might want to turn the radio off at times in order to conserve

battery power, or in situations where radio use is prohibited, such as onboard an

aircraft and in hospitals.

• Discoverable. Bluetooth is turned on, and all other Bluetoothenabled devices within a

range of 10 meters can detect your device.

76 | Getting Connected

Note By default, Bluetooth is turned off. If you turn it on, and then turn off your device,

Bluetooth also turns off. When you turn on your device again, Bluetooth automatically

turns on.

To make your device discoverable

1. On your device, tap Start > Settings > Connections tab > Bluetooth.

2. Select the Turn on Bluetooth and Make this device discoverable to other devices

check boxes.

3. Tap OK.

Bluetooth partnerships

A Bluetooth partnership is a relationship that you create between your device and another

Bluetooth-enabled device in order to exchange information in a secure manner. Creating

a partnership between two devices involves entering the same personal identification

number (PIN) on both devices. Creating a partnership between two devices is a one-time

process. Once a partnership is created, the devices can recognize the partnership and

exchange information without entering a PIN again. Make sure the two devices are within

a range of 10 meters from one another, and Bluetooth is turned on and in discoverable

mode.

To create a Bluetooth partnership

1. On your device, tap Start > Settings > Connections tab > Bluetooth.

2. On the Devices tab, tap New Partnership. Your device searches for other Bluetooth

devices and displays them in the box.

3. Tap the desired device name in the box.

4. Tap Next.

5. Enter a passkey to establish a secure connection. The passkey must be between 1 and

16 characters.

6. Tap Next.

Getting Connected | 77

7. Enter the same passkey that is entered on the other device. You can, however, edit and

enter a new name for the other device.

8. Tap Finish.

To accept a Bluetooth partnership

1. Ensure that Bluetooth is turned on and in discoverable mode.

2. Tap OK when prompted to establish a partnership with the other device.

3. Enter a passkey (the same passkey that is entered on the device requesting the

partnership) to establish a secure connection. The passkey must be between 1 and 16

characters.

4. Tap Next.

5. Tap Finish.

You can now exchange information with the other device.

To rename a Bluetooth partnership

1. Tap Start > Settings > Connections tab > Bluetooth.

2. Tap and hold the partnership on the Devices tab.

3. On the shortcut menu, tap Edit.

4. Enter a new name for the partnership.

5. Tap Save.

To delete a Bluetooth partnership

1. Tap Start > Settings > Connections tab > Bluetooth.

2. Tap and hold the partnership on the Devices tab.

3. On the shortcut menu, tap Delete.

78 | Getting Connected

Beam information using Bluetooth

1. On the device, tap and hold an item to beam. The item can be an appointment in your

calendar, a task, a contact card, or a ﬁle.

2. Tap Beam [type of item].

3. Tap the device name to which you want to send the beam.

The item is beamed to the device you selected.

Note If the device you want to beam to does not appear in the box, make sure that it is turned

on, discoverable, and within close range (10 meters) of your device.

Use a Bluetooth device as a modem

You can use a phone that has Bluetooth capabilities as a modem for your device.

To do so, create a Bluetooth modem connection on your device and then send information

to another device by using Bluetooth. The device relays the information over the network

and then sends back to your device any information that you had requested over the

connection. Once you create a modem connection to the Bluetooth phone, you can reuse

it whenever you want to use the phone as a modem. Make sure that your device and the

destination device are turned on, Bluetooth is turned on, and that the devices are within

close range.

To accept a Bluetooth partnership

1. On your device, tap Start > Settings > Connections tab > Connections.

2. Tap Add a new modem connection.

3. Enter a name for the connection.

4. In the Select a modem list, tap Bluetooth.

5. Tap Next.

6. If the device appears in the My Connections list, skip to step 11.

7. If the device does not appear in the My Connections list, tap New, and follow the

remaining steps.

Getting Connected | 79

8. Select the device name from the list and tap Next.

9. Enter a passkey and tap Next.

10. Enter the same passkey on the device and tap Finish.

11. In the My Connections list, tap the device and tap then Next.

12. Enter the phone number to dial for this connection and tap Next.

13. Enter the required logon information for this connection and tap Finish.

You can start using this service for the program that uses the Bluetooth connection, such

as Inbox on your device, to send and receive e-mail, or Internet Explorer to browse the

Web.

6.4 Using Wireless Modem

Wireless Modem activates your device as a wireless modem and lets you connect

your PC to a wireless network. Before you create and configure a new modem using a

connection, you must install the drivers on your PC.

To establish a connection using Wireless Modem

1. On your device, tap Start > Programs > Wireless Modem.

2. In the Connection Type list, select IrDA. This allows you to connect your device via

infrared to a PC.

3. Tap Start.

Set up your PC

Before you start using Wireless Modem with an IrDA connection, you must configure a

new modem on your PC and obtain the APN (Access Point Name) from your Internet

service provider (ISP).

To conﬁgure a modem on your PC

1. On your PC, select Start > Settings > Control Panel.

2. Double-click Phone and Modem Options.

80 | Getting Connected

3. On the Modems tab, click Add.

4. Select the Don’t detect my modem; I will select it from a list check box.

5. In the Manufacturers list, select Standard Modem Types.

6. Select Standard 33600 bps Modem and click Next.

7. Select the modem port on which you want to install the drivers.

8. Click Next.

9. Click Finish. Now, when you check the Modems tab in the Phone and Modem

Options dialog box, a Standard 33600 bps Modem appears in the modem list.

10. Select Standard 33600 bps Modem.

11. Click Properties.

12. Click the Advanced tab.

13. Enter the following string in the Extra initialization commands ﬁeld: AT+CGDCONT=1,”I

P”,”APN”,””,0,0.

14. Click Change Default Preferences.

15. On the General tab, select Float control to None.

16. Click OK until the modem installation wizard exits.

To create a new dial-up connection

After a new standard modem has been set up on your PC, you must create a new dial-up

connection.

1. On your PC, select Start > Settings > Control Panel.

2. Double-click Network and Dial-up Connections.

3. Double-click Make New Connection.

4. Click Next to continue.

5. Click Dial-up to the Internet.

6. Click Next.

7. Click I want to set up my Internet connection manually, or I want to connect

through a local area network (LAN), and then click Next.

8. Click I connect through a phone line and a modem, and then click Next.

9. Select the Use area code and dialing rules check box.

Getting Connected | 81

10. Enter the telephone number as *99# and click Next.

11. Enter the user name and password you use to log on to your ISP and click Next.

12. Enter a name for this connection and click Next.

13. Select No when the installation wizard prompts you to set up an Internet mail account,

and then click Next.

14. Click Finish to exit the wizard.

Connect through a USB Port

To connect through a USB port, you need to first set up a USB modem on your PC. Before

setting up a USB modem, verify that you have the following files:

• USBMDM

• USBModem_Dialer

Both files are available on the Getting Started CD. Run the Getting Started CD from the

CD-ROM of your PC and do the following on your device:

1. On your device, tap Start > Programs > Wireless Modem.

2. Select USB as the connection type, and insert the USB cable adapter.

3. Tap Start on the Wireless Modem screen of your device. The Found New Hardware

message appears on your PC.

4. On your PC, select Display a list of the known drivers for this device so that I can

choose a speciﬁc driver and click Next.

5. In the Hardware types list, select Modem and click Next.

6. Click Next.

7. Click Have Disk.

8. Click Next.

9. Select the recognized USB Modem from the Modems list.

10. Click Next.

11. Click Finish.

12. On your PC, select Start > Settings > Control Panel.

13. Double-click Phone and Modem Options.

82 | Getting Connected

14. Select the new USB modem from the Modems list.

15. Double-click the USB Modem Dialer ﬁle on the Getting Started CD.

16. Enter the GPRS settings (enter the APN assigned by your ISP).

17. Click Dial to start the connection.

18. Click Finish to exit the wizard.

Once you set up a USB modem on your PC, you are ready to establish a connection using

Wireless Modem via a USB port.

To establish a connection using Wireless Modem via a USB port

1. On your device, tap Start > Programs > Wireless Modem.

2. In Connection Type, select USB.

3. Tap Start.

To establish a connection using Wireless Modem via Bluetooth

1. On your device, tap Start > Programs > Wireless Modem.

2. In Connection Type, select Bluetooth.

3. Tap Start.

6.5 Using Wireless LAN Manager

Wireless LAN Manager (WLAN Manager) allows you to

manage Wi-Fi Internet connections on your device. You can

use the device’s Power Save Mode to make optimal use of

the battery under the WLAN networking environment, view a

variety of data related to the current configuration and signal

quality, and increase network security.

To run WLAN Manager on your device, you need access

to broadband Internet, and the necessary access point or

router that emits WLAN signals. If you do not have access to

broadband Internet, consult your ISP before you try to run this

utility.

Getting Connected | 83

Note The availability and range of your device’s WLAN signal depends on the number,

infrastructure, and other objects through which the signal passes.

Check for a Wireless LAN signal

Before you start WLAN Manager, verify that your device has access to a Wireless LAN

channel signal. You can check the current wireless connection status from the following

two screens of your device.

• Today screen. If your device detects a WLAN network connection, the WLAN

connection icon appears at the top of the Today screen.

• Wireless LAN Manager screen. The current connection status and signal quality for

each speciﬁc wireless channel appears on the Wireless LAN Manager screen with the

current conﬁguration.

To connect to a Wi-Fi network

1. Tap Start > Programs > WirelessMgr. This opens the Wireless LAN Manager screen.

2. Tap the On/Off button to turn on/off the wireless function. The WLAN Manager icon

indicates the wireless status.

• : Wi-Fi is turned on.

• : Wi-Fi is turned off.

3. Tap the tool icon ( ) to conﬁgure the required settings.

When the conﬁguration is completed, you can connect to

a Wi-Fi network using your Pocket PC Phone.

Note Tap the Network Cards icon ( ) on the Wireless LAN Manager Settings screen to

configure wireless networks and network adapters.

84 | Getting Connected

To save battery power while connected to a Wi-Fi network

1. On the Settings tab of the Wireless LAN Manager Settings screen, move the Power

Save Mode slider to a position that optimizes performance with the least power

consumption.

2. Select the Auto turn off WLAN if not connected check box to allow your device to

turn off the WLAN function automatically when no signal is detected.

To increase security of the Wi-Fi network

The LEAP (Lightweight Extensible Authentication Protocol) feature of Wireless LAN

Manager increases security on your device, and ensures that nobody is able to access

your network without your permission.

1. On the Wireless Manager Settings screen, tap the LEAP tab.

2. Tap New. By default, the LEAP screen displays data that you entered previously.

However, you can modify or delete the data as required by tapping Modify or Delete.

3. Enter the SSID (Service Set Identiﬁer).

4. Enter the user name, password, and domain.

5. Select an Authentication Type. By default, the Authentication Type for your device is

Open System.

Note For LEAP to work correctly, both the access point and the receiving device (your device)

must be set with the same SSID, user name, and password.

Getting Connected | 85

6.6 Using Terminal Services Client

Terminal Services Client allows you to log on to a PC running Terminal Services or

Remote Desktop, and use all the resources available on that PC. For example, instead of

running Word Mobile on your device, you can run the PC version of Word and access the

*.doc files available on that PC.

Connect to a Terminal Server

1. On your device, tap Start > Programs > Terminal Services Client.

2. Enter the server name.

3. You can also select a server name in Recent servers if you have recently connected

to a server.

4. Select the Limit size of server desktop to ﬁt on this screen check box if you want to

use programs that have been speciﬁcally sized for use with your device.

5. Tap Connect.

The next time the device is turned on, you will be prompted to enter your password.

Navigate within Terminal Services Client

When connected to a remote server, you may notice that your device screen is displaying

more than one horizontal and vertical scroll bar. Use these scroll bars to either scroll

the contents on the PC, or to scroll the PC display through the Terminal Services Client

window. To make sure you are scrolling the PC display through Terminal Services Client,

use the five directional buttons at the bottom of the Terminal Services Client window. To

better fit information on your device screen, select the Limit size of server desktop to fit

on this screen check box. For best results, the programs on your desktop PC should be

maximized.

Disconnect without ending a session

1. From the Terminal Services Client screen on your device, tap Start > Shutdown.

2. Tap Disconnect.

86 | Getting Connected

Notes Do not use the Start menu on your device.

If a network administrator has configured Terminal Services Client on your device to

reconnect to disconnected sessions, and you previously disconnected from a Terminal

Server without ending the session, the Terminal Services Client reconnects to that

session.

Disconnect after ending a session

1. From the Terminal Services Client screen on your device, tap Start > Shutdown.

2. Tap Log off.

7.1 E-mail and Text Messages

7.2 Pocket MSN Messenger

7.3 Calendar

7.4 Contacts

7.5 Tasks

7.6 Notes

Chapter 7

Exchanging Messages and Using Outlook

88 | Exchanging Messages and Using Outlook

7.1 E-mail and Text Messages

Messaging is where all of your e-mail accounts and your text message account are

located. You can send and receive Outlook e-mail, Internet e-mail through an Internet

service provider (ISP), and text messages. You can also access e-mail from work using a

VPN connection. For more information about e-mail and text messages, see Help on the

device.

To set up an e-mail account

You need to set up an e-mail account that you have with an Internet service provider (ISP)

or an account that you access using a VPN server connection (typically a work account)

before you can send and receive mail.

1. Tap Start > Messaging.

2. Tap Menu > Tools > New Account.

3. Enter your e-mail address, and then tap Next. Auto conﬁguration attempts to

download necessary e-mail server settings so that you do not need to enter them

manually.

4. Once Auto conﬁguration has ﬁnished, tap Next.

5. Enter your name (the name you want displayed when you send e-mail), user name,

and password; tap Next. Select the Save Password check box if you want to save

your password so that you do not need to enter it again.

If Auto configuration was successful, the Your name and User name fields automatically

get populated. Tap Next, and then Finish to complete setting up your account, or tap

Options to access additional settings. For example:

• Change the time intervals for downloading new messages.

• Limit the amount of messages that are downloaded and authentication method for

outgoing mails.

• Download attachments or parts of messages.

If Auto configuration is unsuccessful or you have an account you access using a VPN

server connection, contact your ISP or network administrator for the following information

and enter it manually:

Exchanging Messages and Using Outlook | 89

Setting Description

User name

Enter the user name assigned to you by your ISP or network

administrator. This is often the first part of your e-mail address,

which appears before the at sign (@).

Password

Choose a strong password. You have the option to save your

password so you do not need to enter it each time you connect to

your e-mail server.

Domain Not required for an account with an ISP. May be required for a work

account.

Account type Select POP3 or IMAP4.

Account name Enter a unique name for the account, such as Work or Home. This

name cannot be changed later.

Incoming mail server Enter the name of your e-mail server (POP3 or IMAP4).

Outgoing mail server Enter the name of your outgoing e-mail server (SMTP).

Require SSL connection

Select this to ensure that you always send e-mail from this account

using an SSL connection. This enables you to send personal

information more securely. Note that if you select this and your ISP

does not support an SSL connection, you will not be able to send

e-mail.

Outgoing mail requires

authentication

Select this if your outgoing e-mail server (SMTP) requires

authentication. Your user name and password from above will be

used.

Use separate settings Select this if your outgoing e-mail server requires a different user

name and password than the ones you entered before.

Outgoing server settings:

User name Enter your user name for the outgoing e-mail server.

Password Enter your password for the outgoing e-mail server.

Domain Enter the domain of the outgoing e-mail server.

Require SSL for

outgoing mail

Select this to ensure you always send e-mail from this account

using an SSL connection. This enables you to send personal

information more securely. Note that if you select this and your ISP

does not support an SSL connection, you will not be able to send

e-mail.

Tip You can set up several e-mail accounts in addition to your Outlook Email account.

90 | Exchanging Messages and Using Outlook

To compose and send a message

1. In the message list, tap Menu > Switch Accounts to select an account.

2. Tap New.

3. Enter the e-mail address or text message address of one or more recipients,

separating them with a semicolon. To access addresses and phone numbers from

Contacts, tap To.

4. Enter your message. To quickly add common messages, tap Menu > My Text, and

then tap a desired message.

5. To check the spelling, tap Menu > Spell Check.

6. Tap Send.

Tips To enter symbols, tap Shift using the on-screen keyboard.

To set the priority, tap Menu > Message Options.

If you are working offline, e-mail messages are moved to the Outbox folder and will be

sent the next time you connect.

If you are sending a text message and want to know if it was received, before sending

the message, tap Menu > Tools > Options. Tap Text and select the Request delivery

notification check box.

To reply to or forward a message

1. Open the message and tap Reply, or Menu > Reply All, or Menu > Forward.

2. Enter your response. To quickly add common messages, tap Menu > My Text, and

then tap a desired message.

3. To check the spelling, tap Menu > Spell Check.

4. Tap Send.

Tips To see more header information, scroll up.

To always include the original message, from the list view, tap Menu > Tools > Options

> Message tab, and select the When replying to e-mail, include body check box.

In the Outlook E-mail account, you will send less data if you do not edit the original

message. This may reduce data transfer costs based on your rate plan.

Exchanging Messages and Using Outlook | 91

To add an attachment to a message

1. In an open message, tap Menu > Insert, and then tap the item you want to attach:

Picture, Voice Note, or File.

2. Select the ﬁle you want to attach, or record a voice note.

To receive attachments

An attachment sent with an e-mail message or downloaded from the server appears below

the subject of the message. Tapping the attachment opens the attachment if it has been

fully downloaded, or marks it for download the next time you send and receive e-mail. You

can also download attachments automatically with your messages if you have an Outlook

E-mail or IMAP4 E-mail account.

If you have an Outlook E-mail account, do the following:

1. Tap Start > ActiveSync.

2. Tap Menu > Options.

3. Tap E-mail > Settings, and then select Include File Attachments.

If you have an IMAP4 E-mail account with an Internet service provider (ISP) or an

account that you access using a VPN server connection (typically a work account), do the

following:

1. Tap Start > Messaging.

2. Tap Menu > Tools > Options.

3. Tap the name of the IMAP4 account.

4. Tap Next until you reach Server information, and then tap Options.

5. Tap Next twice, and select Get full copy of messages and When getting full copy,

get attachments.

Tip To store attachments on a storage card rather than on the device, tap Menu > Tools >

Options > Storage tab, and select the Store attachments on a storage card check

box.

92 | Exchanging Messages and Using Outlook

Download messages

The manner in which you download messages depends the type of account you have:

• To send and receive e-mail for an Outlook E-mail account, begin synchronization

through ActiveSync. For more information, see “Synchronizing Outlook information” in

Chapter 4.

• To send and receive e-mail messages for an e-mail account that you have with an

Internet Service Provider (ISP) or that you access using a VPN server connection

(typically a work account), download messages through a remote e-mail server. For

more information, see “To download messages from the server” later in this chapter.

• Text messages are automatically received when your phone is turned on. When your

phone is turned off (in ﬂight mode), messages are held by your service provider until

the next time your phone is turned on.

To download messages from the server

To send and receive e-mail messages for an e-mail account that you have with an Internet

Service Provider (ISP) or that you access using a VPN server connection (typically a work

account), you first need to connect to the Internet or your corporate network, depending on

the account.

1. Tap Menu > Switch Accounts to select the account you want to use.

2. Tap Menu > Send/Receive. The messages on your device and e-mail server are

synchronized: new messages are downloaded to the device Inbox folder, messages

in the device Outbox folder are sent, and messages that have been deleted from the

server are removed from the device Inbox folder.

Tip If you want to read the entire message, tap Menu > Download Message while in the

message window. If you are in the message list, tap and hold the message, and tap

Menu > Download Message. The message will download the next time you send and

receive e-mail. This will also download message attachments if you selected those

options when you set up the e-mail account.

Exchanging Messages and Using Outlook | 93

Manage folders

Each Messaging account has its own folder hierarchy with five default Messaging folders:

Inbox, Outbox, Deleted Items, Drafts, and Sent Items. The messages you receive and

send through the account are stored in these folders. You can also create additional

folders within each hierarchy. The Deleted Items folder contains messages that have been

deleted on the device. The behavior of the Deleted Items and Sent Items folders depends

on the Messaging options you have chosen.

If you use an Outlook E-mail account, e-mail messages in the Inbox folder in Outlook

will be synchronized automatically with your device. You can select to synchronize

additional folders by designating them for synchronization. The folders you create and the

messages you move will then be mirrored on the e-mail server. For example, if you move

two messages from the Inbox folder to a folder named Family, and you have designated

Family for synchronization, the server creates a copy of the Family folder and copies the

messages to that folder. You can then read the messages while you are away from your

PC.

If you use a text message account, messages are stored in the Inbox folder. If you use a

POP3 account and you move e-mail messages to a folder you created, the link is broken

between the messages on the device and their copies on the e-mail server. The next time

you connect, the e-mail server will detect that the messages are missing from the Inbox

folder on the device and will delete them from the e-mail server. This prevents having

duplicate copies of a message, but it also means that you will no longer have access to

messages that you move to folders created from anywhere except the device.

If you use an IMAP4 account, the folders you create and the e-mail messages you move

are mirrored on the e-mail server. Therefore, messages are available to you anytime you

connect to your e-mail server, whether it is from your device or PC. This synchronization

of folders occurs whenever you connect to your e-mail server, create new folders, or

rename/delete folders when connected. You can also set different download options for

each folder.

94 | Exchanging Messages and Using Outlook

7.2 Pocket MSN Messenger

MSN Messenger delivers the features of MSN Messenger to your mobile device. With

Pocket MSN Messenger you can do the following:

• Send and receive instant messages.

• See which contacts are online or ofﬂine.

• Subscribe to status updates for selected contacts so you know when they come online.

• Block contacts from seeing your status or sending you messages.

Before you can use MSN Messenger, your device must be connected to the Internet. For

information about setting up an Internet connection, see “Connecting to the Internet” in

Chapter 6, “Getting Connected.”

Note You must have either a Microsoft .NET Passport or Hotmail account to use MSN

Messenger. If you have a Hotmail.com or MSN.com e-mail address, you already have a

Passport. To get a Passport account, go to http://www.passport.com. To get a Hotmail

account, go to http://www. hotmail.com.

To start MSN Messenger

1. Tap Start > Programs > Pocket MSN.

2. Tap MSN Messenger.

To sign in or out

• To sign in, tap anywhere on the MSN Messenger screen.

Enter the e-mail address and password for your Passport

or Hotmail account, and then tap Sign In. Signing in may

take several minutes, depending on your connection

speed.

• To sign out, tap Menu > Sign Out. Your status changes to

Ofﬂine.

Exchanging Messages and Using Outlook | 95

To add or delete contacts

• To add a contact, tap Menu > Add a Contact, and then follow the instructions on the

screen.

• To delete a contact, tap and hold the contact’s name, and then tap Delete Contact

from the shortcut menu.

To send an instant message

1. Tap the contact to whom you want to send a message.

2. Enter your message in the text entry area at the bottom of the screen, and tap Send.

Tip To quickly add common phrases, tap Menu > My Text and select a phrase in the list.

To block or unblock contacts

• To block a contact from seeing your status and sending you messages, tap and hold

the contact, and then tap Block from the shortcut menu.

• To unblock a contact, tap and hold the name of the blocked contact, and then tap

Unblock from the shortcut menu.

To check your own Messenger status

• Tap and hold your own name at the top of the page. Your current status is indicated in

the displayed list by a bullet point.

To change your display name

1. Tap Menu > Options > Messenger tab.

2. Enter the name you want to display to others in MSN Messenger.

To get more help about MSN Messenger

• When in MSN Messenger, tap Start > Help.

96 | Exchanging Messages and Using Outlook

7.3 Calendar

Use Calendar to schedule appointments, including meetings and other events. Your

appointments for the day can be displayed on the Today screen. If you use Outlook on

your PC, you can synchronize appointments between your device and PC. You can also

set Calendar to remind you of appointments with a sound or flashing light, for example.

You can look at your appointments in several different views (Day, Week, Month, Year, and

Agenda). To see detailed appointment information in any view, tap the appointment.

To schedule an appointment

1. Tap Start > Calendar.

2. Tap Menu > New Appointment.

3. Enter a name for the appointment, and enter information such as start and end times.

4. To schedule an all-day event, in the All Day box, tap Yes.

5. When ﬁnished, tap OK to return to the calendar.

Note All-day events do not occupy blocks of time in Calendar; instead, they appear in banners

at the top of the calendar. To cancel an appointment, tap the appointment, and then tap

Menu > Delete.

Tip To have the time entered automatically in Day view, tap the time slot for the new

appointment, and then tap Menu > New Appointment.

To send a meeting request

Use Calendar to schedule meetings via e-mail with contacts who use Outlook or Outlook

Mobile.

1. Tap Start > Calendar.

2. Schedule a new appointment, or open an existing one and tap Edit.

3. Tap Attendees.

4. Tap the name of the contact you want to invite.

5. To invite each additional attendee, tap Add, and then tap the name.

Exchanging Messages and Using Outlook | 97

6. Tap OK.

7. The meeting request will be sent to the attendees the next time you synchronize your

device with your PC.

Note When attendees accept your meeting request, the meeting is automatically added to their

schedules. When their response is sent back to you, your calendar is updated as well.

To set a default reminder for all new appointments

You can have a reminder automatically turned on for all new appointments you schedule.

1. Tap Start > Calendar.

2. Tap Menu > Options > Appointments tab.

3. Select the Set reminders for new items check box.

4. Set the time when you want the reminder to alert you.

5. Tap OK to return to the calendar.

7.4 Contacts

Contacts is your address book and information storage for the people and businesses

you communicate with. Store phone numbers, e-mail addresses, home addresses, and

any other information that relates to a contact, such as a birthday or an anniversary date.

You can also add a picture or assign a ring tone to a contact.

From the contact list, you can quickly communicate with people. Tap a contact in the list

for a summary of contact information. From there, you can call or send a message.

If you use Outlook on your PC, you can synchronize contacts between your device and

PC.

To create a contact

1. Tap Start > Contacts.

2. Tap New, and then enter the contact information.

98 | Exchanging Messages and Using Outlook

3. When ﬁnished, tap OK.

Tips If someone who is not in your list of contacts calls you or sends you a message, you can

create a contact from Call History, or from the message by tapping Menu > Save to

Contacts.

In the list of contact information, you’ll see where you can add a picture or assign a ring

tone to a contact.

To change contact information

1. Tap Start > Contacts.

2. Tap the contact.

3. Tap Menu > Edit and enter the changes.

4. When ﬁnished, tap OK.

To work with the contact list

There are several ways to use and customize the contact list. Here are a few tips:

1. Tap Start > Contacts.

2. In the contact list, do any of the following:

• In Name view, you can search for a contact by entering a name or number, or by

using the alphabetical index. To switch to Name view, tap Menu > View By > Name.

• To see a summary of information about a contact, tap the contact. From there you

can also make a call or send a message.

• To see a list of available actions for a contact, tap and hold the contact.

• To see a list of contacts employed by a speciﬁc company, tap Menu > View By >

Company. Then, tap the company name.

To ﬁnd a contact

There are several ways to find a contact when your contact list is long.

1. Tap Start > Contacts.

2. If you are not in Name view, tap Menu > View By > Name.

Exchanging Messages and Using Outlook | 99

3. Do one of the following:

• Begin entering a name or phone number in the provided text box until the contact

you want is displayed. To show all contacts again, tap the text box and clear the

text, or tap the arrow to the right of the text box.

• Use the alphabetical index displayed at the top of the contact list.

• Filter the list by categories. In the contact list, tap Menu > Filter. Then tap a

category you’ve assigned to a contact. To show all contacts again, select All

Contacts.

7.5 Tasks

Use Tasks to keep track of things you need to do. A task can occur once or repeatedly

(recurring). You can set reminders for your tasks and you can organize them using

categories.

Your tasks are displayed in a task list. Overdue tasks are displayed in red.

To create a task

1. Tap Start > Programs > Tasks.

2. Tap New, enter a subject for the task, and ﬁll in information such as start and due

dates, priority, and so on.

3. When ﬁnished, tap OK.

Tip You can easily create a short, to-do-type task. Simply tap the Tap here to add a new

task box, enter a subject, and press ENTER. If the task entry box is not available, tap

Menu > Options and select the Show Tasks entry bar check box.

To change the priority of a task

Before you can sort tasks by priority, you need to specify a priority level for each task.

1. Tap Start > Programs > Tasks.

2. Tap the task you want to change the priority for dates, priority, and so on.

100 | Exchanging Messages and Using Outlook

3. Tap Edit, and select a priority level in the Priority box.

4. Tap OK to return to the task list.

Note All new tasks are assigned a Normal priority by default.

To set a default reminder for all new tasks

You can have a reminder automatically turned on for all new tasks you create.

1. Tap Start > Programs > Tasks.

2. Tap Menu > Options.

3. Select the Set reminders for new items check box.

4. Tap OK to return to the task list.

Note The new tasks must have due dates set in order for the reminder to take effect.

To show start and due dates in the task list

1. Tap Start > Programs > Tasks.

2. Tap Menu > Options.

3. Select the Show start and due dates check box.

4. Tap OK.

To locate a task

When your list of tasks is long, you can display a subset of the tasks or sort the list to

quickly find a specific task.

1. Tap Start > Programs > Tasks.

2. In the task list, do one of the following:

• Sort the list. Tap Menu > Sort by, and tap a sort option.

• Filter the list by category. Tap Menu > Filter, and tap the category you want

displayed.

Note To filter your tasks further, tap Menu > Filter > Active Tasks or Completed Tasks.

Exchanging Messages and Using Outlook | 101

7.6 Notes

Notes helps you to quickly capture thoughts, questions, reminders, to-do lists, and

meeting notes. You can create handwritten and typed notes, record voice notes, convert

handwritten notes to text for easy readability, and send notes to others.

With Notes, you can also record a voice note. For more instructions about recording a

voice note, see “Recording a Note” in Chapter 2.

Enter information in Notes

There are several ways to enter information in a note. You can enter typed text by using

the on-screen keyboard or handwriting recognition software. You can also use the stylus to

write or draw directly on the screen. On devices that support recording, you can create a

standalone recording or embed a recording in a note.

To set the default input mode for Notes

If you frequently add drawings to your notes, you may find it helpful to set Writing as the

default input mode. If you prefer typed text, select Typing.

1. Tap Start > Programs > Notes.

2. In the note list, tap Menu > Options.

3. In the Default mode box, tap one of the following:

• Writing if you want to draw or enter handwritten text in a note.

• Typing if you want to create a typed note.

4. Tap OK.

To create a note

1. Tap Start > Programs > Notes.

2. In the note list, tap New.

3. Tap the Input Selector arrow to select the input method you want, and enter your text.

4. If the Input Selector arrow is not displayed, tap the Input Panel icon.

5. When ﬁnished, tap OK to return to the note list.

102 | Exchanging Messages and Using Outlook

8.1 Using Camera and Camcorder

8.2 Using Pictures & Videos

8.3 Using Windows Media Player

Chapter 8

Experiencing Multimedia

104 | Experiencing Multimedia

8.1 Using Camera and Camcorder

Taking photos and recording video clips along with audio is easy with your device’s built-in

camera.

To switch to any of the Camera modes

• Tap Start > Programs > Camera.

• Tap Start > Programs > Pictures & Videos >

Camera icon.

• Press CAMERA on your device.

To exit the Camera

• Tap the exit icon ( ).

• Tap OK on your device.

Use the camera

The camera on your device allows you to capture pictures and video clips by using various

built-in modes with flexibility. The Camera mode is set to the Photo capture mode by

default. The lower right corner of the screen displays the active capture mode. To switch to

other capture modes, do any of the following:

• Tap or on the screen.

• Press NAVIGATION left or right.

The available capture modes of the camera are as follows:

• Photo: Captures standard still images.

• Video: Captures video clips, with or without accompanying audio.

• Contacts Picture: Captures a still image and gives you the option to immediately

assign it to a Photo ID for a contact.

• Picture Theme: Captures still images and places them within frames.

• Panorama: Captures a sequence of still images continuously in one direction, and

allows stitching of all images to create a collage.

Experiencing Multimedia | 105

• Sport: Captures a sequence of still images (5 ~ 30) automatically for a short duration

at a deﬁned frequency.

• Burst: Captures a sequence of still images (maximum 30) as long as CAMERA on the

device or ENTER on the NAVIGATION is kept pressed.

File formats supported

Using the above capture modes, the camera in your device captures files in the following

formats:

Capture type Format

Still image BMP, JPEG

Video Motion-JPEG AVI (.avi), MPEG-4 (.mp4)

Burst / Sport JPEG

Use shortcuts in Camera mode

While in Camera mode, you can use the following buttons and icons on your device as a

shortcut when performing operations.

The ENTER button

Press ENTER on the NAVIGATION to take a picture when you are capturing still image.

Press this button to start recording an incoming video stream; press it again to stop

recording.

The NAVIGATION control

• Press NAVIGATION up or down to increase or decrease the zoom level.

• Press NAVIGATION left or right to go to the previous next or sequential capture mode.

The CAMERA button

Press CAMERA on the device to switch to Camera mode. If already in Camera mode,

press once to take a still image or to start recording a video clip. In Photo capture mode,

point your device and press this button to capture more still images.

106 | Experiencing Multimedia

Camera mode icons

• Current time indicator. The time indicator tells you the current time (for example, the

time shown in the previous screenshot is ).

• Remaining information indicator. The ﬁlm icon ( ) displays the remaining,

available shots of pictures based on current settings.

• Resolution indicator. The resolution icon ( / / / / ) indicates the current

resolution.

• Ambience indicator. The ambience icon ( / / / / / ) indicates the

current ambience.

• Zoom-Ratio indicator. Tapping the up/down arrow ( / ) on the screen allows you

to zoom in and zoom out.

• Mode Switching button. Tapping the left/right arrow ( / ) on the screen allows

you to switch the capture mode.

• Self-Time indicator. The timer icon ( ) indicates the current setting of Self-Timer

while capturing images or videos.

• Previous/Next Template button. In Picture Theme mode, tap the template selector

icon ( / ) to display the previous/next sequential template.

• Reset Status button. In Panorama mode, tap the reset icon ( ) to stop the current

Panorama capture progress and revert to normal preview. The icon appears if

the Auto-stitch the snapped images while in Panorama mode check box on the

Camera Settings screen is not be selected.

• Camera Settings. Tap the tool icon ( ) to open the Camera Settings screen. Tap

OK to return to Camera mode.

• Flash. Tap the ﬂash icon to turn on/off the ﬂash light. The icon indicates the ﬂash

light is turned on; the icon indicates the ﬂash light is turned off.

• Picture Viewer. Tap the viewer icon ( ) to view the picture or video in Pictures &

Videos.

• Exit. Tap the exit icon ( ) to exit the Camera program.

Experiencing Multimedia | 107

Review mode icons

• Back to Preview. Tap to go back to Camera mode to capture an image.

• Send. Tap to send the captured image to someone via e-mail.

• Delete. Tap to remove the captured image.

• View in Pictures. Tap to switch to Pictures & Videos program. The captured image

will be displayed in the Detailed View.

• View in Windows Media. In Video capture mode, tap to switch to Windows Media

Player to play back the new video you just recorded.

• Assign to Contacts. Tap to send the new ﬁle immediately to a contact in the

contact list.

Use Still Image capture modes

While using Still Image capture modes, such as Photo, Contacts Picture, Picture

Theme, Panorama, Sport, and Burst, you can capture a single still image by pressing

CAMERA on the device or ENTER on the NAVIGATION control. The Still Image capture

modes support either BMP or JPEG format, as specified by you on the Camera Settings

screen.

While capturing an image in the Picture Theme capture mode, you can select a built-in

template from the default template folder. To browse and select different templates, tap the

template selector icon or tool icon to select a template from the Camera Settings screen.

Use Video capture modes

While using the Video capture mode, you can press CAMERA on the device or ENTER

on the NAVIGATION control to start recording a video clip (with audio if desired). To stop

recording, press CAMERA or ENTER again. Your device displays the first frame of the

captured video clip by default on the Review screen.

108 | Experiencing Multimedia

Before you capture a video clip, you can specify the recording limit in terms of time and

file size on the Camera Settings screen so that the recording stops automatically when the

clip size reaches that limit.

You can set the capture format to either Motion-JPEG AVI or MPEG-4 on the Camera

Settings screen.

Use the Review screen

To access the icons on the Review mode screen

1. In Camera mode, tap Tools > Options > General tab.

2. Select the Review after capture check box.

Note that this check box is selected by default to allow you to review the image or video

clip after it has been captured.

Use zooming

While capturing a still image or a video clip by using the main camera, you can zoom in

to make the object in focus move closer, and you can zoom out to make the object move

farther away. In all capture modes, use NAVIGATION on your device, or tap the triangular

Up arrow next to the Zoom Ratio indicator, to zoom in a still image or an incoming video

stream. When the zooming limit is reached, you will hear a beep. To zoom out, press

NAVIGATION down, or tap the Down arrow. The main camera zoom range for a picture or

a video clip depends on the capture mode and capture size. Following is a summary.

Capture mode Capture size setting Zoom range


2M (1600 x 1280) No zooming available.

1M (1280 x 1024) 1.0x to 2.0x

Large (640 x 480) 1.0x to 2.0x

Medium (320 x 240) 1.0x to 4.0x

Small (160 x 120) 1.0x to 8.0x

Experiencing Multimedia | 109

Capture mode Capture size setting Zoom range

Video

Large (320 x 240) 1.0x to 2.0x

Medium (176 x 144) 1.0x to 2.0x

Small (128 x 96) 1.0x to 2.0x

Contacts Picture

1M (1280 x 1024) 1.0x to 2.0x

Large (640 x 480) 1.0x to 2.0x

Medium (320 x 240) 1.0x to 4.0x

Small (160 x 120) 1.0x to 8.0x

Picture Theme Determined by the current template. Depends on the size of the

template currently loaded.

Panorama

1M (1280 x 1024) 1.0x to 2.0x

Large (640 x 480) 1.0x to 2.0x

Medium (320 x 240) 1.0x to 4.0x

Small (160 x 120) 1.0x to 8.0x

Sport

Large (640 x 480) 1.0x to 2.0x

Medium (320 x 240) 1.0x to 4.0x

Small (160 x 120) 1.0x to 8.0x

Burst

1M (1280 x 1024) 1.0x to 2.0x

Large (640 x 480) 1.0x to 2.0x

Medium (320 x 240) 1.0x to 4.0x

Small (160 x 120) 1.0x to 8.0x

Note The capture sizes available for certain capture formats also vary from one capture mode

to another. The zoom range has been calculated based on the following ratio:

• 1.0x = normal size (no zooming)

• 2.0x = double enlargement

• 4.0x = quadruple enlargement

• 8.0x = octuple enlargement

110 | Experiencing Multimedia

Use the Camera Settings screen

While capturing a still image or video clip using any capture

modes, tap the tool icon to access the Camera Settings

screen. The Camera Settings screen allows you to configure

the capture settings.

You can configure the following settings on the Camera Settings screen.

Setting Allows you to

Capture mode Select a capture mode.

Capture format Select a capture format.

Capture size Select a capture size.

Capture frequency Select a capture frequency.

Record limitation Specify the maximum time or file size for recording.

Template Select a template.

Browse Navigate to a folder containing templates.

Direction Select a capture direction.

Stitch count Select a count of snapped images.

Burst count Select a count of automatic capturing.

Ambience Select an ambience type.

After you configure the settings, tap OK or Start Camera on the Camera Settings screen

to go back to the Camera screen.

Experiencing Multimedia | 111

Use the Tools menu

The Tools menu on the Camera Settings screen provides the

following advanced options for configuring and customizing the

Camera mode functions.

The Adjust item

Tap Tools > Adjust to adjust the camera display properties, such as Contrast, Brightness,

Saturation, Hue, and Sharpness. Select one of these properties from the list and move

the slider (or tap the slider) to change the value. The preview window on the Adjust

screen displays the effect of changes you make on the Adjust screen. Tap OK to save the

settings.

Note You can tap Reset at any time to reset all properties to their default.

The Options item

Tap Tools > Options to display the Options screen with the following three tabs:

• General tab. This ﬁeld includes the following options:

• Disable shutter sound. Select this check box to disable all default sounds played

while capturing a still image or recording a video clip.

• Keep backlight on while in viewﬁnder. Select this check box to ensure that the

backlight remains turned on while you view the incoming video stream, overriding

your device backlight settings.

112 | Experiencing Multimedia

• Review after capture. Select this check box to display the captured image

immediately after you take a picture. The Review screen provides options for

performing various operations on the new ﬁle. Clearing this check box saves any

newly captured ﬁle using the default ﬁle name, and returns to the Camera screen.

• Apply “Date and time stamp” while capturing images. Select this check box to

automatically compose the current date and time in the captured images.

• Flicker adjustment. Select the proper power frequency of the country where the

device is being used. The default setting is Auto.

• Save. Select where you want to save your captured ﬁles. You can either save the

ﬁles to main memory or to a storage card.

• Image tab. This ﬁeld provides image-related settings for captured ﬁles.

• Preﬁx type and Preﬁx string. By default, the ﬁle name of each new captured

image ﬁle is set to “IMAGE” followed by a sequential number, for example: IMAGE_

00001.jpg. To change this preﬁx, select String in the Preﬁx type list, and then enter

the desired characters in the Preﬁx string box.

• Counter Index. By default, the newly captured image ﬁles are named with a preﬁx

and some sequential numbers, such as 00000, 00001, 00002, and so on. To reset

the numbering to “00001” for your captured image ﬁles, tap Reset counter.

• JPEG Quality. Select the JPEG image quality level for all captured still images. You

can choose from SuperFine, Fine, Normal, and Basic.

• Self-Timer. Select the Self-Timer option for capturing images: Off, 5 seconds,

or 10 seconds. Selecting 5 seconds or 10 seconds delays the capturing by the

speciﬁed time after you press CAMERA or ENTER.

• Auto-stitch the snapped images while in Panorama mode. When this check box

is selected, the camera automatically stitches all snapped images into one single

ﬁle. If you do not select this check box while capturing images in Panorama mode,

the snapped images are saved as separate ﬁles.

• Video tab. The options in this ﬁeld are for conﬁguring the advanced settings of the

captured video ﬁles.

• Preﬁx type and Preﬁx string. By default, the ﬁle name of each new, captured

video ﬁle is set to “VIDEO” followed by a sequential number, for example: VIDEO_

00001.avi. To change this preﬁx, select String in the Preﬁx type list and enter the

desired characters in the Preﬁx string box.

Experiencing Multimedia | 113

• Counter Index. By default, the newly captured video ﬁles are named with a preﬁx

and some sequential numbers, such as 00000, 00001, 00002, and so on. To reset

the numbering to “00001” for your captured video ﬁles, tap Reset counter.

• Recording with Audio. Select this check box to record audio with the captured

video clips. This check box is selected by default. If you clear this check box and

then capture a video clip, it would have no audio.

8.2 Using Pictures & Videos

The Pictures & Videos program collects, organizes, and sorts images and video clips in

the following formats on your device.

File type File extensions

Image *.bmp, *.jpg

Video *.avi, *.wma, *.mp4, *.3gp

You can view the pictures as a slide show, bean them, send them via e-mail, edit them, or

set them as the background on the Today screen.

To copy a picture or video clip to your device

You can copy pictures from your PC and view them on your device.

• Copy the pictures from your PC or a storage card to the My Pictures folder on your

device.

For more information about copying files from your PC to your device, see ActiveSync

Help on your PC.

Note You can also copy pictures from your PC to your device using a memory card. Insert the

memory card into the memory card slot on your device, and then copy the pictures from

your PC to the folder you created on the memory card.

114 | Experiencing Multimedia

To view pictures

1. Tap Start > Programs > Pictures & Videos.

The images in the My Pictures folder appear as

thumbnails by default.

2. Select a picture and tap View. If you cannot ﬁnd

a picture in the default My Pictures folder, go to

another folder by tapping the Down arrow.

To play videos with audio

1. Tap Start > Programs > Pictures & Videos.The videos in the My Pictures folder

appear as thumbnails by default, while the audio ﬁles appear with a media icon ( ).

2. Select a video and tap the thumbnail to play it with the built-in Windows Media Player.

To view slideshows

You can view your pictures as a slide show on your device. Pictures are shown in full-

screen view with 5-second intervals between slides.

1. Tap Start > Programs > Pictures & Videos.

2. Tap Menu > Play Slide Show.

Note You can specify how pictures are scaled to optimize their display in a slide show. Tap

Menu > Options, and then tap Portrait Pictures or Landscape Pictures on the Slide

Show tab.

Tap anywhere on the screen to display the Slide Show toolbar, which you can use to stop

or pause the slide show, rotate the view, and more. Press NAVIGATION right or left to

move forward or backward through the slides.

To sort pictures and video clips

If you store a large number of pictures or video clips on your device, you may find it helpful

to sort them to quickly find a specific picture or clip. You can sort by name, date, and size.

Experiencing Multimedia | 115

1. Tap Start > Programs > Pictures & Videos.

2. Tap the sort list (labeled Date by default), and select the item you want to sort by.

To delete a picture or video clip

Do any of the following to remove a picture or a video clip:

• Select a picture or video clip on the Pictures & Videos screen, and tap Menu > Delete.

Tap OK to conﬁrm the deletion.

• Tap and hold the thumbnail of the picture you want to delete, and then tap Delete.

To edit a picture or video clip

You can rotate, crop, and adjust the brightness and color contrast of your pictures.

1. Tap Start > Programs > Pictures & Videos.

2. Tap the picture you want to edit.

3. Tap Menu > Edit, and do any of the following:

• To rotate a picture 90 degrees counterclockwise, tap Rotate.

• To crop a picture, tap Menu > Crop. Then, tap and drag to select the area to crop.

Tap outside the box to stop cropping.

• To adjust the brightness and contrast levels of a picture, tap Menu > AutoCorrect.

Note To undo an edit, tap Menu > Undo. To cancel all unsaved edits you made to the picture,

tap Revert to Saved.

To set a picture as the Today screen background

1. Tap Start > Programs > Pictures & Videos.

2. Select the picture you want to set as the background.

3. Tap Menu > Set as Today Background.

4. In Transparency level, select a higher percentage for a more transparent picture, or a

lower percentage for a more opaque picture. Then, tap OK.

Note Pictures and video clips are saved automatically before they are sent.

116 | Experiencing Multimedia

To beam a picture

You can beam a picture to your friends or a family member using Infrared.

1. Tap Start > Programs > Pictures & Videos.

2. Select the picture you want to beam.

3. Tap Menu > Beam.

4. Select a device to beam the picture.

5. Tap OK.

To assign pictures to contacts

You can assign a picture to a contact so that you can easily identify the contact at any

point of time.

1. Tap Start > Programs > Pictures & Videos.

2. Select the picture you want to assign to a contact.

3. Tap Menu > Save to Contact.

4. Tap the contact, or navigate and tap Select to choose the contact from your Contacts

list.

To use advance options

You can assign a picture to a contact so that you can easily identify the contact at any

point of time.

1. Tap Start > Programs > Pictures & Videos.

2. Select the picture for which you want to conﬁgure further settings.

3. Tap Menu > Options. The Options screen appears, allowing you to:.

• Resize a picture so that you can send it faster to someone using your e-mails.

• Conﬁgure the view settings during slide shows and activate screensaver options.

• Conﬁgure your device camera and camcorder settings.

Experiencing Multimedia | 117

8.3 Using Windows Media Player

You can use Microsoft Windows Media Player 10 Mobile for Pocket PC to play digital

audio and video files that are stored on your device or on a network, such as on a Web

site.

Using Windows Media Player, you can play both audio and video files. These are the

following file formats that are supported by this version of Windows Media Player.

Supported video file Supported audio file

File formats

• Windows Media Video

• MPEG4 Simple Profile

• H.263

• Motion JPEG

• 3GPP2

File extensions

*.wmv, *.asf

*.mp4

*.3gp

*.avi

*.3g2

Supported audio ﬁles

• Windows Media Audio

• MP3

• MIDI

• AMR Narrow Band

• AMR Wide Band

• AAC

• 3GPP2

File extensions

*.wma

*.mp3

*.mid, *.midi, *.rmi

*.amr

*.awb

*.m4a

*.gcp

About the controls

The following are available controls on the Pocket PC Player.

This control Does this This control Does this

/ Plays/pauses a file. /

Increases/decreases the

volume level.

Skips to the beginning of the

current file or to the previous

file.

Turns the sound on or off.

Skips to the next file. Displays a video by using the

entire screen (full screen).

Adjusts the playback

progress of a selected file.

Displays a Web site where

you can find music and

videos to play.

118 | Experiencing Multimedia

About the screens and menus

Windows Media Player has three primary screens:

• Playback screen. The default screen that displays the playback controls (such as Play,

Pause, Next, Previous, and Volume), the album art window, and the video window. You

can change the appearance of this screen by choosing a different skin.

• Now Playing screen. The screen that displays the Now Playing playlist. This special

playlist indicates the currently playing ﬁle and any ﬁles that are “queued up” to play

next.

• Library screen. The screen that lets you quickly ﬁnd your audio ﬁles, video ﬁles, and

playlists. It contains categories such as My Music, My Video, My TV, and My Playlists.

At the bottom of each screen is a menu called Menu. The commands on this menu

change depending upon which screen you are viewing.

Playback screen menu

When you are viewing the Playback screen, the following commands appear on Menu.

This control Does this

Play/Pause Starts or pauses playback.

Repeat Plays the items in the Now Playing playlist repeatedly.

Stop Stops playback.

Full Screen When a video is playing, displays it by using the entire screen.

Library Displays the Library screen so you can choose a file to play.

Open URL Lets you play a file on a network, such as the Internet.

Options Lets you adjust various Windows Media Player options, including network,

skin, and hardware button options.

Properties Displays information about the currently playing file.

About Displays information about Windows Media Player, such as the version

number.

Experiencing Multimedia | 119

Now Playing screen menu

When you are viewing the Now Playing screen, the following commands appear on Menu.

This control Does this

Library Displays the Library screen so you can choose a file to play.

Move Up Moves the selected item up in the playlist order.

Move Down Moves the selected item down in the playlist order.

Remove from Playlist Deletes the selected item from the playlist.

Clear Now Playing Deletes all items from the Now Playing playlist.

Error Details Displays error information about the selected item (an exclamation

mark appears before the item name if error details are available).

Properties Displays information about the selected file.

Library screen menu

When you are viewing the Library screen, the following commands appear on Menu.

This control Does this

Queue Up Adds the selected item to the end of the current (Now Playing) playlist.

Delete from Library Deletes the selected item from the library.

Update Library Adds new items to the library by searching your device or storage card.

Open File Lets you find and play files that are stored on your device or storage

card but that are not in the library.

Properties Displays information about the selected file.

120 | Experiencing Multimedia

About licenses and protected files

Some content (such as digital media files downloaded from the Internet, CD tracks, and

videos) have associated licenses that protect them from being unlawfully distributed or

shared. Licenses are created and managed by using digital rights management (DRM),

which is the technology for securing content and managing its access rights. Some

licenses may prevent you from playing files that have been copied to your device. Files

that have licenses associated with them are called “protected files.”

If you want to copy a protected file from your PC to your device, use the desktop Player to

synchronize the file to your device (instead of dragging the file from a folder on your PC to

a folder on your device, for example). This will ensure that the license is copied along with

the protected file. For more information about synchronizing files to your device and other

mobile devices, see desktop Player Help.

Note You can view the protection status for a file by checking its file properties (tapping Menu

> Properties).

To play items on your device

Use the library to find and play songs, videos, and playlists that are stored on your device

or removable storage card.

1. If you are not on the Library screen, tap Menu > Library.

2. On the Library screen, tap the Library arrow (near the top of the screen), and then tap

the library that you want use (for example, My Device or Storage Card).

3. Tap a category (for example, My Music or My Playlists), tap and hold the item that you

want to play (such as a song, album, or artist name), and then tap Play.

Note To play a file that is stored on your device but is not in a library, on the Library screen, tap

Menu > Open File. Tap and hold the item that you want to play (such as a file or a

folder), and then tap Play.

Experiencing Multimedia | 121

To play an item on a network

Use the Open URL command to play a song or video that is stored on the Internet or on a

network server.

1. If you are not on the Playback screen, tap OK to close the current screen and display

the Playback screen.

2. Tap Menu > Open URL.

3. Do one of the following:

• In the URL box, enter a network address.

• In the History box, tap a URL that you have previously used.

Note To play an item on a network, you must be connected to a network. For more information

about creating a remote connection between your device and a network, see

Connections Help on your device.

Copy files to your device

Use the latest version of the desktop Player (Windows Media Player 10 or later) to

synchronize digital media files to your device (instead of dragging a file from a folder on

your PC to a folder on your device, for example). Using the desktop Player ensures that

licenses are copied with protected files.

When synchronizing files, always synchronize the files to a storage card that is inserted

into your device. Do not synchronize to a storage card that is inserted into a storage card

reader. In addition, do not synchronize to the internal storage location (RAM) in your

device. For more information about synchronizing files to mobile devices, see desktop

Player Help on the PC.

Note Audio files copy faster if the desktop Player is configured to automatically set the quality

level for audio files copied to your device. For more information, see desktop Player Help

on the PC.

122 | Experiencing Multimedia

Accessibility for people with disabilities

Microsoft is committed to making its products and services easier for everyone to use.

Many accessibility features have been built into Microsoft products, including features for

individuals who have difficulty typing or using a mouse, who are blind or have low vision,

or who are deaf or hard-of-hearing. For more information about the following topics, see

the Accessibility section of the Microsoft Web site (http://www.microsoft.com/enable/

default.aspx).

• Accessibility in Microsoft Windows

• Adjusting Microsoft products for people with accessibility needs

• Free step-by-step tutorials

• Microsoft documentation in alternative formats

• Assistive technology for Windows

• Customer service for people who are deaf or hard-of-hearing

Note The information in this section applies to users who license Microsoft products in

the United States. If you obtained this product outside the United States, your package

contains a subsidiary information card that you can use to contact your subsidiary about

the products and services available in your area.

Accessibility for people with disabilities

If you encounter a problem while using the Pocket PC Player, a number of resources are

available to help you troubleshoot the issue.

For more information, see the Troubleshooting Windows Media Player Mobile page at

the Microsoft Web site (http://www.microsoft.com/windows/windowsmedia/player/

windowsmobile/troubleshooting.aspx).

9.1 Word Mobile

9.2 Excel Mobile

9.3 Viewing Slide Shows with PowerPoint Mobile

9.4 Using MIDlet Manager

Chapter 9

Using Other Applications

124 | Using Other Applications

9.1 Word Mobile

Word Mobile is a streamlined version of Microsoft Word. Word documents created

on your PC can be opened and edited on your device. You can also create and edit

documents and templates in Word Mobile and save them as *.doc, *.rtf, *.txt, and *.dot

files.

You can have only one document open at a time. When you open a second document, the

first one is saved and closed automatically.

When you close a newly created document, it is automatically named after the first several

words in the document and placed in the Word Mobile document list. You can easily

rename the document with a more meaningful name and move it to another folder or a

storage card.

To create a ﬁle

1. In Word Mobile, tap New.

2. You’ll see either a blank document or template, depending on what you’ve selected as

the default template.

3. Enter text as desired.

4. When ﬁnished, tap OK to save the ﬁle.

Unsupported features in Word Mobile

Word Mobile does not fully support some features of Microsoft Word such as revision

marks and password protection. Some data and formatting may be lost when you save the

document on your device.

The following features are not supported in Word Mobile.

• Backgrounds

• Shapes and text boxes

• Artistic page borders

• Smart tags

• Metaﬁles

Using Other Applications | 125

• Bi-directional text. While Word Mobile will open documents containing bi-directional

text, the indentations and alignment may be displayed and saved incorrectly.

• Password-protected ﬁles. Word Mobile does not support opening password-

protected documents. You must ﬁrst remove the password protection in Word on the

PC if you want to view the document on the device.

• Document protection. Word Mobile does not support displaying ﬁles that have been

protected in Word on the PC.

The following features are partially supported in Word Mobile.

• Picture bullets

• Revision marks

• Underline styles. Underline styles not supported by Word Mobile are mapped to one

of the four supported styles: regular, dotted, wavy, or thick/bold/wide.

• Legacy Pocket Word ﬁles. You can open *.psw ﬁles in Word Mobile; however, if you

edit a ﬁle, you will need to save it in *.doc, *.rtf, *.txt, or *.dot format.

The following features are not supported on the device; however, they are retained in the

file so that when a file is opened on the PC again, they appear as expected.

• Footnotes, endnotes, headers, footers

• Page breaks

• Lists

• Fonts and font sizes. Fonts not supported by the device are mapped to the closest

font available, although the original font will be listed on the device.

To get more help about Word Mobile

• When in Word Mobile, tap Start > Help.

126 | Using Other Applications

9.2 Excel Mobile

Excel Mobile makes it easy for you to open and edit Excel workbooks and templates

created on your PC. You can also can create new workbooks and templates on your

device.

Tips Work in full-screen mode to see as much of your workbook as possible.

Tap View > Zoom and select a percentage so that you can easily read the worksheet.

Unsupported features in Excel Mobile

Excel Mobile does not fully support some features such as formulas and cell comments.

Some data and formatting may be lost when you save the workbook on your device. Note

the following Excel Mobile formatting considerations:

• Alignment. Horizontal, vertical, and wrap-text attributes remain the same, but vertical

text appears horizontal.

• Borders. Appear as a single line.

• Cell patterns. Patterns applied to cells are removed.

• Fonts and font sizes. Fonts not supported by your device are mapped to the closest

font available. The original font is listed on your device. When the workbook is opened

in Excel on your PC again, the data is displayed in the original font.

• Number formats. Numbers formatted using the Microsoft Excel 97 conditional

formatting feature are displayed in Number format.

• Formulas and functions. If an Excel ﬁle contains a function that is not supported

by Excel Mobile, the function is removed, and only the returned value of the function

appears. The following formulas are also converted to values: formulas entered as

an array or containing an array argument, for example, =SUM({1;2;3;4}); formulas

containing external link references or an intersection range reference; and formulas

containing references past row 16384 are replaced with #REF!

• Protection settings. Most worksheet and workbook protection features are disabled

but not removed. However, support for password protection has been removed.

Workbooks that are password-protected or workbooks in which one or more

worksheets are password-protected cannot be opened. You must remove the password

protection in Excel on the PC and then synchronize to open the ﬁle on the device.

Using Other Applications | 127

• Zoom settings. Are not retained. Excel supports a per worksheet zoom setting, while

the Excel Mobile zoom setting is applied to the entire workbook.

• Worksheet names. Names that reference worksheets within the same workbook are

displayed accurately, but names that refer to other workbooks, arrays, for example,

={1;2;3;4}, array formulas, or intersection ranges are removed from the name list.

If a name is removed from the list, it is left in formulas and functions, causing those

formulas to be resolved as “#NAME?” All hidden names are not hidden.

• AutoFilter settings. Are removed. However, you can use the AutoFilter command

in Excel Mobile to perform similar functions. If you have an AutoFilter applied to a

worksheet that causes rows to be hidden, the rows remain hidden when the ﬁle is

opened in Excel Mobile. Use the Unhide command to display the hidden rows

• Chart formatting. All charts will be saved the way they are shown in Excel Mobile.

Unsupported chart types are changed to one of these supported types: Column, Bar,

Line, Pie, Scatter, and Area. Background colors, gridlines, data labels, trend lines,

shadows, 3D effects, secondary axes, and logarithmic scales are turned off.

• Worksheet features. The following features are not supported in Excel Mobile and are

removed or modiﬁed when a workbook is opened on the device: hidden sheets are not

hidden; VBA modules, macro sheets, and dialog sheets are removed and replaced with

a place holder sheet; text boxes, drawing objects, pictures, lists, conditional formats,

and controls are removed; pivot table data is converted to values.

To get more help about Excel Mobile

• When in Excel Mobile, tap Start > Help.

128 | Using Other Applications

9.3 Viewing Slide Shows with PowerPoint Mobile

With PowerPoint Mobile, you can open and view slide show presentations created on

your PC in *.ppt and *.pps format with PowerPoint ‘97 and later.

Many presentation elements built into the slide shows such as slide transitions and

animations will play back on the device. If the presentation is set up as a timed slide show,

one slide will advance to the next automatically. Links to URLs are also supported.

PowerPoint features not supported on the device include:

• Notes. Notes written for slides will not be visible.

• Rearranging or editing slides. PowerPoint Mobile is a viewer only.

• File formats. Files created in *.ppt format earlier than PowerPoint ‘97 and HTML ﬁles

in *.htm and *.mht formats are not supported.

To start a slide show presentation

1. Tap Start > Programs > PowerPoint Mobile.

2. In the presentation list, tap the slide show you want to view.

3. Tap the current slide to advance to the next slide.

If the presentation is set up as a timed slide show, slides will advance automatically.

To stop a slide show

• In a PowerPoint Mobile presentation, tap > End Show.

To navigate between slides

You can advance to the next slide if a presentation is not set up as a timed slide show,

return to the previous slide, or go to any slide out of sequence.

1. Tap Start > Programs > PowerPoint Mobile.

2. Open the presentation you want to view.

3. Tap > Next or Previous; or tap Go to Slide, and then tap the slide you want to

view.

Using Other Applications | 129

Notes If you have zoomed in to see a slide in more detail, you cannot navigate to another slide

until you zoom out.

Tapping Next or Previous may play an animation on a slide rather than navigate to

another slide.

Tip Simply tap the current slide to go to the next one.

9.4 Using MIDlet Manager

MIDlets are Java applications that can run on mobile devices. Your device supports Java

2 Micro Edition, J2ME. The MIDlet Manager allows you to download Java applications,

such as games and tools that are specifically designed for mobile devices. Although some

Java applications and games have already been installed on your device, the Java MIDlet

Manager gives you the flexibility of installing and managing additional J2ME applications

from the Internet.

To install MIDlets from the Internet

1. Locate the MIDlet/MIDlet suite while connected to the Internet.

2. Select the MIDlet/MIDlet suite to download.

3. Conﬁrm to start downloading.

4. Run the ﬁle(s) to install.

Note You can cancel the installation at any time.

To install MIDlets from a PC

You can install the MIDlets/MIDlet suites on your device from a PC using the USB sync

cable, the optional cradle, infrared, or Bluetooth. MIDlets copied to your device using

infrared, Bluetooth, or e-mail attachments are automatically saved in the My Documents

folder. However, you can copy the MIDlet file(s) from a PC to any of the following

temporary folders on your device from where MIDlet Manager can install them.

130 | Using Other Applications

• Device memory: ../My device/My Documents/My MIDlets

• Storage card: ../My device/Storage Card

Note If the My MIDlets folder does not exist in My Documents, you can create one with the

same folder name. However, a folder named Storage Card automatically appears after

you insert an storage card into your device.

To install a MIDlet/MIDlet suite

1. Tap Start > Programs > MIDlet Manager > Menu > Install.

2. Select the MIDlet/MIDlet suite from the list.

3. Tap Install from the shortcut menu.

4. Conﬁrm to complete the installation.

Note To remove the MIDlet files from the temporary folder, tap Delete from the shortcut menu.

To run MIDlets on your device

1. Tap Start > Programs > MIDlet Manager.

2. Tap a MIDlet to run.

To view the MIDlets currently running

• On the MIDlet Manager screen, tap Show > Running.

To stop running a MIDlet

1. Tap Start > Programs > MIDlet Manager.

2. Tap Show > Running.

3. Tap and hold a MIDlet on the Running MIDlets screen, and then tap Stop.

Tips To view the most recently used MIDlets, tap Show > Recent.

To stop all MIDlets currently running on your device, tap Menu > Stop All.

Using Other Applications | 131

Manage MIDlets/MIDlet suites

You can organize the MIDlets into groups and define custom groups. You can also change

the default settings for a MIDlet.

To customize the display settings

1. Tap Sort By at the top of the MIDlet Manager screen.

2. Choose to sort by Name or by Size.

To change the display name of a MIDlet

1. Tap and hold a MIDlet, and then tap Rename.

2. Enter a new name for the MIDlet.

3. Tap OK.

Note You cannot change the name of a MIDlet suite.

To uninstall a MIDlet/MIDlet suite

Before you uninstall a MIDlet/MIDlet suite, make sure that it is not running.

1. Tap and hold the MIDlet/MIDlet suite on the MIDlet Manager screen, and then tap

Uninstall.

2. Tap OK to conﬁrm.

Note You cannot uninstall a single MIDlet from a MIDlet suite; you can uninstall only the

complete MIDlet suite.

To check storage space

• Tap Menu > System Info on the MIDlet Manager screen to see how much device

storage space is used by MIDlets.

To select a network type

• Tap Menu > Choose Network Type on the MIDlet Manager screen, and select a

network type from the list.

132 | Using Other Applications

To conﬁgure MIDlet security

You can adjust security settings for each MIDlet/MIDlet suite.

1. Tap and hold a MIDlet.

2. Tap Security from the shortcut menu.

Note that some features may not be available for all MIDlets/MIDlet suites. Following are

the security options that you can set for a running MIDlet/MIDlet suite.

Security Option Description

Net Access Determines whether a MIDlet/MIDlet suite can access the Internet.

Local Connectivity Enables a MIDlet/MIDlet suite to access services, such as infrared and

Bluetooth.

App Auto Run Enables a MIDlet/MIDlet suite to run at specified times, or any time.

Messaging Determines whether a MIDlet/MIDlet suite can send and/or receive

SMS messages.

Multimedia Recording Enables a MIDlet/MIDlet suite to record sounds and images.

Error messages

The following is a list of error messages that you may receive while managing and using

MIDlets/MIDlet suites on your device.

Error Message Description

Either RAM shortage,

or insufﬁcient space on

the ﬁle system

There is not sufficient memory on your device.

Network out There is no network connection available.

The jar size does not

match that speciﬁed in

the jad

The installation information provided by the MIDlet manufacturer is

inaccurate.

The jar manifest does

not match the jad

The installation information provided by the MIDlet manufacturer is

inaccurate.

Using Other Applications | 133

Error Message Description

Invalid Java application

descriptor (jad)

There is a problem with the installation file provided by the MIDlet

manufacturer.

Invalid Java archive

(jar)

There is a problem with the installation file provided by the MIDlet

manufacturer.

This Java application is

not compatible with this

device

One or more features required by this MIDlet is not available on your

device.

134 | Using Other Applications

Appendix

A.1 Regulatory Notices

A.2 Specifications

A.3 Index

136 | Appendix

A.1 Regulatory Notices

Regulatory Agency IDs

For regulatory identification purposes, your product is assigned a

model number of PA10A.

To ensure continued reliable and safe operation of your device, use

only the accessories listed below with your PA10A.

The “x” portion of the above model number(s) could be any

alphanumeric character (or blank) denoting external cosmetic

changes.

This product is intended for use with a certified Class 2 Limited

Power Source, rated 5 Volts DC, maximum 2 Amp power supply unit.

European Union Notice

• FCC Part 15.21

Any changes or modiﬁcations not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment.

• FCC ID: NM8PA10A

• FCC Part 15.19

“This device complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may

not cause harmful interference, and (2) this device must accept

any interference received, including interference that may cause

undesired operation.” should be put in a conspicuous location on

the device. If the device is so small or for such use that it is not

practicable to place the statement on it, the above information

shall be placed in a prominent location in the instruction manual

or pamphlet supplied to the user or, alternatively, shall be placed

on the container in which the device is marketed.

• FCC Part 15.105 (b)

For a Class B digital device or peripheral, the instructions

furnished the user shall include the following or similar

Appendix | 137

statement, placed in a prominent location in the text of the

manual: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can

radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference

to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference

by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

Important Health and Safety Information

Retain and follow all product safety and operating instructions.

Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to

the equipment, observe the following precautions.

General Precautions

• Heed service markings

Except as explained elsewhere in the Operating or Service

documentation, do not service any product yourself. Service

needed on components inside these compartments should be

done by an authorized service technician or provider.

138 | Appendix

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to

an authorized service technician or provider under the following

conditions:

• Liquid has been spilled or an object has fallen into the

product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the

operating instructions.

• Avoid hot areas

The product should be placed away from heat sources such as

radiators, heat registers, stoves, or other products (including

ampliﬁers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other

openings in the product. Slots and openings are provided for

ventilation. These openings must not be blocked or covered.

• Mounting Accessories

Do not use the product on an unstable table, cart, stand,

tripod, or bracket. Any mounting of the product should follow

the manufacturer’s instructions, and should use a mounting

accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and

options identiﬁed as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio

devices.

Appendix | 139

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not

use liquid cleaners or aerosol cleaners. Use a damp cloth for

cleaning, but NEVER use water to clean the LCD screen.

Safety Precautions for Power Supply Unit

• Use the correct external power source

A product should be operated only from the type of power source

indicated on the electrical ratings label. If you are not sure of the

type of power source required, consult your authorized service

provider or local power company. For a product that operates

from battery power or other sources, refer to the operating

instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-Ion Polymer battery. There is a risk of

ﬁre and burns if the battery pack is handled improperly. Do not

attempt to open or service the battery pack. Do not disassemble,

crush, puncture, short external contacts or circuits, dispose of

in ﬁre or water, or expose a battery pack to temperatures higher

than 60˚C (140˚F).

Warning! DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. TO REDUCE RISK OF FIRE OR BURNS, DO NOT

DISASSEMBLE, CRUSH, PUNCTURE, SHORT EXTERNAL

CONTACTS, EXPOSE TO TEMPERATURE ABOVE 60˚C (140˚F),

OR DISPOSE OF IN FIRE OR WATER. REPLACE ONLY WITH

SPECIFIED BATTERIES. RECYCLE OR DISPOSE OF USED

BATTERIES ACCORDING TO THE LOCAL REGULATIONS OR

REFERENCE GUIDE SUPPLIED WITH YOUR PRODUCT.

140 | Appendix

SAR Information

SAR: 1.098 W/kg @1g (USA)

THIS MODEL DEVICE MEETS THE GOVERN-MENT’S

REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.

Your wireless mobile CDMA phone is a radio transmitter and

receiver. It is designed and manufactured not to exceed the emission

limits for exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the U.S. Government. These limits

are part of comprehensive guidelines and establish permitted levels

of RF energy for the general population. The guidelines are based

on the safety standards previously set by both U.S. and international

standards bodies:

• American National Standards Institute (ANSI) IEEE. C95.1-1992.

• National Council on Radiation Protection and Measurement

(NCRP). Report 86. 1986.

• International Commission on Non-Ionizing Radiation Protection

(ICNIRP) 1996.

• Ministry of Health (Canada), Safety Code 6. The standards

include a substantial safety margin designed to assure the safety

of all persons, regardless of age and health.

The exposure standard for wireless mobile CDMA phone employs

a unit of measurement known as the Specific Absorption Rate, or

SAR. The SAR limit set by the FCC is 1.6W/kg*.

For body worn operation, this phone has been tested and meets

the FCC RF exposure guidelines when used with an accessory that

contains no metal and that position the antenna of the CDMA phone

a minimum of 1.5cm from the body. The SAR values of this CDMA

phone are 0.573 W/g (body) and 1.003 W/g (head). Use of other

accessories may not ensure compliance with the FCC RF exposure

guidelines.

The FCC has granted an Equipment Authorization for this model

device with all reported SAR levels evaluated as in compliance with

Appendix | 141

the FCC RF exposure guidelines. SAR information on this model

device is on file with the FCC and can be found under the Display

Grant section of http://www.fcc.gov/oet/fccid after searching on

FCC ID: NM8PA10A. Additional information on Specific Absorption

Rates (SAR) can be found on the Cellular Telecommunications &

Internet Association (CTIA) web-site as http://www.devicefacts.net.

* In the U.S. and Canada, the SAR limit for mobile CDMA phone

used by the public is 1.6 Watts/kg (W/kg) averaged over one gram

of tissue. The standard incorporates a substantial margin of safety

to give additional protection for the public and to account for any

variations in usage.

Normal condition only to ensure the radiative performance and

safety of the interference. As with other mobile radio transmitting

equipment, users are advised that for satisfactory operation of the

equipment and for the safety of personnel, it is recommended that

no part of the human body be allowed to come too close to the

antenna during operation of the equipment.

142 | Appendix

A.2 Specifications

System Information

Processor Intel Bulverde 416/ 520Mhz

Memory - ROM : M-System 128MB NAND Flash

- RAM : 64/ 128MB SDRAM

Operating System Microsoft Windows Mobile Pocket PC Phone

Edition Magneto update

Display

LCD Type 2.8” transflective TFT-LCD with back-light LEDs,

touch-sensitive screen

Resolution 240 x 320 pixels

Alignment Support Portrait and Landscape

GSM/GPRS (Tri-band) Module

Functionality CDMA2000

Mode Dual band: 800, 1900 MHz

External Antenna Yes

Camera Module

Type 1.3 mega-pixel camera with macro and camera

flash (place in the back)

Resolution

SXGA 1280x1024, VGA 640x480, QVGA

320x240, QQVGA 160x120, CIF352x288, QCIF

176x144

Physical

Dimensions 108 (L) x 59 (W) x 23.7 (T) mm

Weight 285g (with battery)

Appendix | 143

Expansion Slot

MiniSD card Yes

Controls and Lights

Buttons

- 5-way navigation pad:

- Three program buttons: Voice Recorder, Voice

Recognition, Camera

- Two phone functions : Call, End

- Volume control slider

- Power On/Off

- OK button

- Start button

- Reset switch

Keyboard QWERTY type, 39 keys

LED

Right: Bi-color (Green and Red) LED for CDMA

network status, PDA notification, and PDA

charging status

Left: Bi-color (Blue and Green) LED for Bluetooth

and Wi-Fi status

Audio

Audio Controller AGC

Microphone/

Speaker Built-in/Dual, Hands-free

Headphone AMR/AMRWB/AACMP3 stereo

Connections

Infrared IrDA SIR

I/O port MiniUSB, MiniSD

Antenna External connector for WCDMA

Audio Stereo earphone/microphone jack

144 | Appendix

A.3 Index

Accessibility 166

Accessing MMS 124

ActiveSync 63

Adding and Removing Programs 79

Adding Canned text 128

Appointment search 43

Audio 194

Backing Up Files 82

Battery 16

Beaming Information 99

Block calls 78

Block Recognizer 31

Bluetooth 66

Bluetooth partnership 97

Calendar 133

Calendar search 43

Calibration 18

Caller ID 78

Call barring 78

Call forwarding 78

Call waiting 78

Camera 193

Capture formats 143

capture modes 143

Change MMS settings 129

Charging Battery 17

Composing MMS messages 125

Composing MMS messages from

Templates 126

conference call 59

Configuring MIDlet Security 178

Configuring MMS message settings

129

Connection 194

Connect to Internet 90

Connect to private network 91

Connect to Terminal Server 115

Contacts 135

Contacts search 43

Controls & Lights 194

Cookies, Security Settings (Internet

Explorer) 95

Copy media files 165

copy pictures from a PC 155

Customizing the Start menu 71

Deleting pictures & videos 157

Desktop player 160

Digital Rights Management 164

Display 193

Drawing and Writing on the Screen

E-mail and Text Messages 118

E-mail search 43

Editing pictures & videos 157

Excel Mobile 170

Exchange Server 65

Expansion Slots 194

Appendix | 145

Favorites, transferring from PC 93

Favorites (Internet Explorer) 93

flight mode 47

GSM/GPRS Module 193

Handwriting 40

Help search 43

History list (Internet Explorer 94

Home page (Internet Explorer) 93

Images, showing on Web pages 94

Indicators 21

Infrared (IR) 66

Input mode 40

Input Panel 28

Input Selector 30

Inserting audio 128

Inserting photo & video 127

Installing ActiveSync 63

Installing MIDlets from a PC 176

Installing MIDlets from the Internet

175

Installing SIM Card 15

Internet Explorer Mobile 93

Introduction 28

Keypad tone 77

Launching camera 157

Letter Recognizer 31

Library screen 162

Licensed media 164

Mail search 43

Main camera zoom range 148

Managing Memory 81

Managing MIDlets/MIDlet suites

178

Managing ZIP files 183

Media synchronization settings 67

MSN Messenger 131

Navigating through PDF Documents

174

Network settings 78

Notes 139

Notes search 43

Now Playing screen 162

On-Screen Keyboard 30

Opening .ZIP files 180

Opening a PDF file 174

Password 84

Personalizing Your Pocket PC

Phone 70

146 | Appendix

Personal and system settings 73

Phone settings 77

Physical 194

Pictures, on Web pages 94

PIN 46, 84

Playback screen 162

Playing videos 156

Play media 164

Pocket PC player 160

PowerPoint Mobile 172

Protected files 164

Protecting Your Device 84

Recording a Note 42

Regulatory Notices 188

Replying to MMS messages 129

Resetting Your Pocket PC Phone

Ring tone 77

Ring type 77

Running GPRS Monitor 111

Safety Information 190

Searching 43

Second camera zoom range 150

Security Settings (Internet Explorer)

Sending pictures & videos 158

Setting advanced options 127

Setting Date / Time / Language /

Regional Options 71

Setting pictures as Today

backgrounds 158

Setting up MMS account 124

Smart Dialing 56

Sorting pictures & videos 157

Specifications 193, 195

Starting Up 18

Starting ZIP 180

Start Phone Pad 36

Start WLAN Manager 107

Storage card 67

Synchronizing Information 63

Synchronizing music, video, and

pictures 67

Synchronizing via Infrared and

Bluetooth 66

Synchronizing with Exchange

Server 65

Sync Setup Wizard 63

System Information 193

Tasks 137

Tasks search 43

Temporary Internet files, deleting

(Internet Explorer) 95

Text size, Web pages 94

Today Screen 20

Today screen settings 70

Transcriber 32

Troubleshooting Windows Media

Player 166

Type text 30

Uninstalling MIDlets/MIDlet suites

178

Use main camera 142

Appendix | 147

Use MMS Video capture mode 147

Use Multi-Tap input mode 38

Use Numeric input mode 38

Use Phone Pad Options screen 38

Use second camera 143

Use shortcuts 144

Use Still Image capture modes 146

Use T9 Input mode 37

Use the Review screen 148

Use the Tools menu 151

Use Video capture mode 147

Use zooming 148

Using ActiveSync 62

Using Bluetooth 96

Using Camera and Camcorder 142

Using ClearVue PDF 174

Using GPRS Monitor 109

Using MIDlet Manager 175

Using MMS Messages 124

Using Pictures & Videos 155

Using Start Menu 25

Using Terminal Services Client 115

Using the Camera Settings screen

150

Using Wireless LAN Manager 106

Using Wireless Modem 101

Using ZIP 167, 180

Video Call 51

Viewing Archive List Screen 181

Viewing MMS messages 129

Viewing pictures 156

Viewing slideshows 156

Web browsing (Internet Explorer)

Web pages, layout 94

Web pages, showing pictures on 94

Web pages, text size 94

Windows Media Player 67, 160

Windows Media Player accessibility

166

Windows Media Player menus 162

Windows Media Player

troubleshooting 166

Word Mobile 168

Writing on the screen 40

148 | Appendix

HTC PA10A PDA Phone User Manual Apache generic indb

HTC Corporation PDA Phone Apache generic indb

Contents

User Manual

Navigation menu

Namespaces

Views

Navigation
