user manual 1 of 2
Your HTC phone
User guide
For FCC
2011/01/24
2
Conventions used in this guide
In this user guide, we use the following symbols to indicate useful and important
information:
This is a note. A note often gives additional information, such as what happens on
your phone when you choose to do or not to do a certain action. A note also provides
information that may only be applicable to some situations.
This is a tip. A tip gives you an alternative way to do a particular step or procedure, or
lets you know of an option that you may find helpful.
This indicates that something is very important. Important information is something that
you need to do in order to accomplish a certain task or to get a phone feature to work
properly.
This provides safety precaution information, that is, information that you need to be
careful about to prevent potential problems when using your phone.
For FCC
2011/01/24
3 Basics
Basics
Inside the box
You will find the following inside the box:
Phone
Battery (preinstalled)
microSD™ card (preinstalled)
USB cable
3.5mm stereo headset
Power adapter
Quick start guide
Safety and regulatory guide
Your phone
Front panel
You’ll see the HOME, MENU, BACK, and SEARCH buttons when your phone is switched on.
And when you turn your phone sideways, these buttons rotate along with the screen.
3
8
19
2
4 5 6 7
1 Earpiece
2 Touch screen
3 HOME
4 Microphone
5 MENU
6 BACK
7 SEARCH
8 1.3 megapixel front camera
9 Notification LED
For FCC
2011/01/24
4 Basics
Top panel
2
13
1 3.5mm headset jack
2 Microphone
3 POWER
Left panel
1
2
3
1 VOLUME UP
2 VOLUME DOWN
3 USB connector
Back panel
3
2
1
4
1 8 megapixel camera
2 Dual LED flash
3 Back cover
4 Speaker
For FCC
2011/01/24
5 Basics
Back cover
Removing the back cover
Remove the back cover to access the battery compartment, SIM card slot, and
storage card slot.
With the phone switched off, hold your phone securely with the front facing
down.
Starting from the small opening at the bottom of the phone, lift the back cover
and remove it completely.
Replacing the back cover
Please handle the back cover with care since your phone’s antennas are placed underneath it.
Avoid twisting or bending the back cover.
To get the best signal for calls, data connection, or GPS navigation, be sure to secure the back
cover tightly to the phone.
Align the back cover onto the phone’s top panel.
Press all sides of the back cover towards the phone.
You’ll hear clicks when the small tabs underneath the back cover are locked in
place.
1.
2.
1.
2.
For FCC
2011/01/24
6 Basics
SIM card
The SIM card contains your phone number, service details, and phonebook/message
memory. Your phone supports both 1.8 V and 3 V SIM cards.
Some legacy SIM cards may not function with your phone. You should consult with your
mobile operator for a replacement SIM card. There may be fees for this service.
Inserting the SIM card
Take the back cover off. See “Back cover” for details.
2. Take the battery out. See “Battery” for details.
3. With the SIM card’s gold contacts facing down and its cut-off corner facing out,
insert the SIM card all the way into the SIM card slot.
Removing the SIM card
1. Take the back cover off. See “Back cover” for details.
2. Take the battery out. See “Battery” for details.
3. Press and hold the SIM card tab, then push the SIM card out from the opposite
end.
4. Slide the SIM card out.
1.
For FCC
2011/01/24
7 Basics
Storage card
Use the microSD card to store your photos, videos, and music. You’ll find the microSD
card already inserted in your phone.
Inserting the storage card
1. Take the back cover off. See “Back cover” for details.
2. Insert the microSD card into the storage card slot with its gold contacts facing
down and push it until it clicks into place.
Removing the storage card
If your phone is on you must first “unmount” the storage card before removing it to prevent
corrupting or damaging the files in the storage card.
1. Take the back cover off. See “Back cover” for details.
2. Push the storage card in to eject it from its slot.
3. Slide the storage card out.
Removing the storage card while the phone is on
When you need to remove the storage card while the phone is on, unmount the
storage card first to prevent corrupting or damaging the files in the storage card.
On the Home screen, press MENU, and then tap Settings.
Scroll down the screen, and then tap SD & phone storage.
Tap Unmount SD card.
Remove the storage card by following the steps in “Removing the storage card”.
1.
2.
3.
4.
For FCC
2011/01/24
8 Basics
Battery
Your phone uses a rechargeable battery. Please use only original batteries and
accessories that came with your phone or replacements that we recommend.
How long the battery can last before it needs recharging depends on how you use
your phone. Among these are the phone features and accessories you use (for
example, leaving your Bluetooth connection always on uses more power). Long phone
calls and frequent web browsing use up much battery. Also, consider your location:
poor signal strength from your mobile network and extreme temperature make the
battery work harder.
Removing the battery
When you take your phone out from the box, make sure to peel off the thin film of the battery
that’s inside your phone. Pull the flap of the film to release the battery.
1. Take the back cover off. See “Back cover” for details.
2. Lift the battery from the groove at the top of the battery compartment.
Inserting the battery
1. Take the back cover off. See “Back cover” for details.
2. Insert the battery (with its exposed copper contacts first) into the battery
compartment.
3. Replace the back cover.
For FCC
2011/01/24
9 Basics
Charging the battery
The battery is partially charged when shipped. Before you turn on and start using your
phone, it is recommended that you charge the battery. Some batteries perform best
after several full charge/discharge cycles.
Only the power adapter and USB sync cable provided with your phone must be used to
charge the battery.
Do not remove the battery from the phone while you are charging it using the power or car
adapter.
1. Plug the power adapter into the USB connector of your phone.
2. Plug in the power adapter to an electrical outlet to start charging the battery.
As the battery is being charged, the notification LED shows a solid orange light. The
light turns to solid green when the phone is fully charged.
When you charge the battery while the phone is on, the charging battery icon
( ) is displayed in your phone’s status bar. After the battery has been fully charged,
the charging battery icon turns to a full battery icon ( ).
As a safety precaution, the battery stops charging when it overheats.
For FCC
2011/01/24
10 Basics
Switching your phone on or off
Switching your phone on
Press and hold the POWER button. Easy.
When you turn on the phone for the first time, you’ll need to set it up. See the Getting started
chapter for details.
Switching your phone off
1. If the display is off, press the POWER button to turn it back on, then unlock the
screen by sliding down the bar on the lock screen.
See “Unlocking the screen” in the Getting started chapter for details.
2. Press and hold the POWER button for a few seconds.
3. When the Power options menu appears, tap Power off.
Entering your PIN
Most SIM cards come with a PIN (personal identification number) set by your mobile
operator. If you’re asked for a PIN, enter it and then tap OK.
To find out how to enable, disable, or change the PIN, see “Protecting your SIM card
with a PIN” in the Security chapter.
If you enter the wrong PIN three times, your SIM card is blocked. No problem. Just contact
your mobile operator and ask for the PUK (PIN Unblocking Key).
Finger gestures
Tap When you want to type using the keyboard, select items onscreen such as
application and settings icons, or press onscreen buttons, simply tap them
with your finger.
Press and hold To open the available options for an item (for example, a contact or link in a
web page), simply press and hold the item.
Swipe or slide To swipe or slide means to quickly drag your finger vertically or horizontally
across the screen.
Drag Press and hold your finger with some pressure before you start to drag.
While dragging, do not release your finger until you have reached the
target position.
Flick Flicking the screen is similar to swiping, except that you need to swipe your
finger in light, quicker strokes. This finger gesture is always in a vertical
direction, such as when flicking the contacts or message list.
Rotate For most screens, you can automatically change the screen orientation
from portrait to landscape by turning the phone sideways. When entering
text, you can turn the phone sideways to bring up a bigger keyboard.
Pinch In some apps, like Gallery or the web browser, you can “pinch” the screen
using two fingers (for example, thumb and index finger) to zoom in or
zoom out when viewing a picture or a web page.
For FCC
2011/01/24
11 Getting started
Getting started
Setting up your phone for the first time
When you switch on your phone for the first time, you’ll be asked to set up your
phone. You can choose your language, how you want to connect to the Internet,
and whether you want your current location to be automatically detected. If you still
have personal contacts and calendar events stored on your old phone, you can easily
transfer them to your new phone through Bluetooth as well.
Be sure to sign in to your Google Account so you can use Google apps like
Gmail™. You can also set up your other email accounts, favorite social networks like
Facebook® and Twitter™, and more.
Just follow the onscreen instructions and you’ll be up and running with your phone in
no time.
Some features that need to connect to the Internet such as location-based services and
auto-sync of your online accounts may incur extra data fees from your mobile operator. Don’t
worry. You can enable or disable them in your phone’s settings as you go along later on. To
find out how, see the Settings chapter.
Home screen
Your Home screen is where you make your phone your own. It comes with a weather
clock widget that shows the time and weather in your current location. You can also
add your favorite apps, shortcuts, folders and widgets so they’re always just a tap
away.
To find out how, see the Personalizing chapter.
Extended Home screen
As you start to do more things with your phone, you might find that one Home screen
is not enough. No problem. You can use up to six extra screens. It should be plenty.
Slide your finger horizontally to the left or right and you’ll discover more space for
adding icons, widgets, and more.
Press HOME to return to the main Home screen (that is, the center home screen).
Using Leap view
To jump straight to the screen that you want, press HOME while on the main Home
screen or pinch the screen to show the Leap view. It reveals all seven Home screens as
thumbnails.
Just tap the one you want and you’ll leap right there.
For FCC
2011/01/24
12 Getting started
Status and notifications
Status icons
You can tell a lot about your phone by checking the icons in its status bar. Here’s what
each one means:
Signal strength Battery is full
GPRS connected Battery is charging
GPRS in use Battery is low (20% remaining)
EDGE connected Battery is very low (10% remaining)
EDGE in use Silent mode
3G connected Vibrate mode
3G in use Phone microphone is mute
HSDPA connected Speakerphone on
HSDPA in use Wired microphone headset connected
Roaming Wired headset connected
No signal Bluetooth is on
No SIM card installed Connected to a Bluetooth device
Connected to a Wi-Fi network Airplane mode
Data synchronizing GPS is on
Network sharing is on Alarm is set
For FCC
2011/01/24
13 Getting started
Notification icons
A busy life means a busy phone. Notification icons on the status bar make it easy for
you to keep on top of your messages, calendar events and alarms. Here’s what each
one means:
New Gmail/Google Mail message Call in progress
New Microsoft Exchange
ActiveSync or POP3/IMAP email Missed call
Problem with email delivery Call on hold
New SMS/MMS Call forwarding on
Problem with SMS/MMS delivery Message forwarding on
New Google Talk instant message The phone is connected to a computer via
USB cable
New voicemail Wi-Fi is on and wireless networks are
available
Upcoming event Portable Wi-Fi Hotspot is on
New updates from your social
networks Uploading data (animated)
New tweet Downloading data (animated)
Matched contacts suggestion Waiting to upload
New push message Downloaded Android Market app installed
successfully
Bluetooth pairing request Update available for an app downloaded
from Android Market
Phone software update available Storage card is safe to remove or storage
card is being prepared
TV out No storage card installed on the phone
Song is playing Storage card is low on free space
FM Radio app in use General notification
Voice recording is on More (not displayed) notifications
Compass needs orientation
For FCC
2011/01/24
14 Getting started
Notification LED
The notification LED shows a:
Solid green light when the phone is connected to the power adapter or a
computer and the battery is fully charged.
Flashing green light when you have a pending notification.
Solid orange light when the battery is being charged.
Flashing orange light when the battery level reaches very low.
Notifications panel
When you get a new notification, you can open the Notifications panel to see the
message, reminder or event notification. The Notifications panel also lets you switch
between recently-opened apps as quickly as possible.
Opening the Notifications panel
Press and hold the status bar, then slide your finger downward to open the
Notifications panel.
If you have several notifications, you can scroll down the screen to see them all.
You can also open the Notifications panel on the Home screen by pressing MENU and then
tapping Notifications.
For FCC
2011/01/24
15 Getting started
Switching between recently-opened apps
On the Notifications panel, you can easily access up to eight apps you just recently
opened.
1. Press and hold the status bar, then slide your finger downward to open the
Notifications panel.
2. In the Recent apps section, slide your finger left or right to see recently-opened
apps.
3. Tap an app to open it.
You can also go to the Recent apps screen when you press and hold HOME.
Closing the Notifications panel
Press and hold the bottom bar of the Notifications panel, then slide your finger up the
screen. Or just press BACK.
Connecting your phone to a computer
Whenever you connect your phone to a computer using the USB cable, the Connect
to PC screen opens and lets you choose the type of USB connection. Select one of the
following choices, and then tap Done:
Charge only Select this option if you only want to charge the battery while your
phone is connected to your computer.
HTC Sync Select this option to synchronize contacts, calendar, and other
information between your computer and your phone. For more
information, see “Synchronizing with your computer” in the Accounts
and sync chapter.
Disk drive This mode is available only when there’s a microSD card on your
phone. Select this mode when you want to copy files between your
phone’s storage card and your computer. For more information, see
“Copying files to or from the storage card” in this chapter.
When Disk drive mode is enabled while your phone is connected
to the computer, you will not be able to use apps on your phone to
access the storage card.
USB tethering When you do not have Internet connection on your computer, you
can select this mode to share your phone’s mobile data connection
with your computer. For more information, see “Using your phone as a
modem (tethering)” in the Internet connections chapter.
For FCC
2011/01/24
16 Getting started
Internet pass-through If you don’t have a data plan for your phone or you don’t have access
to a Wi-Fi network, you can select this mode to share your computer’s
Internet connection with your phone. For more information, see the
Internet connections chapter.
You can also change the type of USB connection on-the-fly, without having to
disconnect and reconnect your phone. Slide open the Notifications panel, and then
tap the notification that says “Select to change USB connection type” to open the
Connect to PC screen again.
To change the default connection type or choose between showing and hiding the Connect to
PC screen, press MENU from the Home screen, and then tap Settings > Connect to PC.
Copying files to or from the storage card
You can copy your music, photos, and other files to your phone’s storage card.
1. Connect your phone to your computer using the supplied USB cable.
2. On your phone’s Connect to PC screen, tap Disk drive, and then tap Done.
On your computer, the connected phone is recognized as a removable disk.
3. Navigate to the removable disk and open it.
4. Do one of the following:
Copy the files from the computer to the phone’s storage card’s root folder.
Copy the files from the phone’s storage card to a folder in your computer.
5. After copying the files, unmount the removable disk (that is, the connected
phone) as required by your computer’s operating system to safely remove your
phone.
6. Do one of the following:
Disconnect the phone from the computer.
If you want to keep the phone connected to the computer but want the
phone to be able to access the storage card, open the Notifications panel,
tap Disk drive, select an option except Disk drive, and then tap Done.
For FCC
2011/01/24
17 Getting started
Searching your phone and the Web
Find all types of information on your phone and the Web. Search Anywhere sifts
through different files, information, and apps on your phone. You can also choose to
search the Web using your favorite web search service.
Simply press SEARCH from the Home screen. Then enter the first few letters of what
you want to search for. Matching items will be shown as you type.
3
4
1
2
1 This icon ( ) indicates that your phone will search for all types of information.
Tap it if you want to choose and search only for one type of item, for example, Mail.
2 Type in what you want to search for.
3 Matching search suggestions and results. You can:
Scroll down to see more search results.
Tap to see more results for a particular category.
Tap a search result item to open its app.
4 After entering a word or phrase in the search box, tap to search the Web using your
favorite search service. To find out how to select a search service to use, see “Setting your
phone’s search options”.
Setting your phone’s search options
From the Home screen, press SEARCH.
When the search box appears, press MENU, and then tap Settings.
Tap any of the following:
Web search engine Choose a web search service you want to use.
Select areas to search Choose the types of items or apps to include in the search.
You can also press and hold and arrange items according
to search priority.
1.
2.
3.
For FCC
2011/01/24
18 Getting started
Quickly looking up information on the Web
Quick Lookup helps you learn about something right on the spot. When you enter a
new word or phrase, you can readily look it up in popular websites or search services
such as Google Search, Wikipedia, YouTube, Google Translate, and Google Dictionary.
1. From the Home screen, tap > Quick Lookup.
2. If the onscreen keyboard is open, press BACK to close it first so you’ll see the
bottom tabs.
3. Slide across the tabs to pick where you want to look up information. Then in the
search box, enter what you want to search for.
If, for example, you’ve found the information you were looking for in one tab such as
Wikipedia, you can switch to the other tabs to automatically search the same item in
Google Search on the Web, watch related videos in YouTube, or look up translations
and meanings in Google Translate and Google Dictionary.
Translating words to other languages
1. From the Home screen, tap > Quick Lookup.
2. Press BACK to hide the onscreen keyboard first, then slide to the Google
Translate tab.
3. Under From language, choose the original language, then enter the word or
phrase you want to translate.
4. Under To language, choose from the languages available for translation.
5. Tap Translate.
For FCC
2011/01/24
19 Getting started
Adjusting the volume
Adjusting the ringer volume changes the volume level of the phone ringtone, while
adjusting the media volume changes the volume level of sound notifications and music
or video playback.
Adjusting the ringer volume
Press the VOLUME UP or VOLUME DOWN button on the left panel of the
phone to adjust the ringer volume to your desired level. The Ringer volume
window appears on the screen to display the volume levels.
While in the lowest ringer volume level (Silent mode), press VOLUME DOWN
once to set your phone to Vibrate mode. The phone vibrates and the vibrate
mode icon ( ) appears in the status bar.
While in Vibrate mode, press VOLUME UP once to switch to silent mode. The
speaker mute icon ( ) displays in the status bar.
Adjusting the media volume
When playing music or watching video, press the VOLUME UP or VOLUME DOWN
button on the left panel of the phone to adjust the media volume. The Media volume
window appears on the screen to display the volume level.
Adjusting the earpiece volume for phone calls
During a phone call, press the VOLUME UP or VOLUME DOWN button.
Adjusting the volume via settings
1. From the Home screen, press MENU, and then tap Settings > Sound > Volume.
2. Drag the volume sliders to the left or right to adjust the volume levels of your
phone’s ringtone, media playback, alarms, and notifications.
Your phone briefly plays a sample tone with the volume being adjusted as you
drag a slider.
3. If you want the same volume for your ringtone and notifications, select Use
incoming call volume for notifications.
4. When you’re done, tap OK.
For FCC
2011/01/24
20 Getting started
Sleep mode
Sleep mode saves battery power by putting your phone into a low power state while
the display is off. It also stops accidental button presses when the phone’s in your bag
or pocket. You’ll still receive messages and calls though.
To change the delay before your screen turns off, see “Adjusting the time before the screen
turns off” in the Settings chapter.
Switching to Sleep mode
Quickly press the POWER button to turn off the display and switch your phone to
Sleep mode. Your phone also automatically goes into Sleep mode when it’s idle for a
while.
Waking up from Sleep mode
Your phone automatically wakes up when you have an incoming call. To wake it up
manually, press the POWER button. You’ll need to unlock the screen.
Unlocking the screen
Press the bar on the lock screen and then slide your finger down to unlock the screen
or answer an incoming call.
If you have set up a screen unlock pattern, pin, or password, you will be asked to draw the
pattern on the screen or enter the PIN or password before it unlocks. See “Protecting your
phone with a screen lock” in the Security chapter for details.
For FCC
2011/01/24
21 Phone calls
Phone calls
Making calls
Most SIM cards come with a PIN (personal identification number) set by your mobile operator.
If you’re asked for a PIN, enter it and then tap OK.
If you enter the wrong PIN three times, your SIM card is blocked. To unlock your SIM card, see
“Restoring a SIM card that has been locked out” in the Security chapter.
Your phone’s antennas are placed underneath the back cover. To get the best signal for calls,
be sure to secure the back cover tightly to the phone.
Making a call on the Phone dialer screen
You can either dial a number directly, or use the Smart dial feature to search and call a
stored contact or a number from your call history.
1. On the Home screen, tap Phone.
2. Begin entering the first few digits of a phone number or characters of a contact
name on the phone keypad.
The Phone dialer screen then displays a list of matching numbers and names.
If you enter a wrong digit or letter, tap to delete it. To erase the entire entry,
press and hold .
3. Tap to close the phone keypad and to see if there are more matching
numbers or contacts. To browse through the filtered list, flick through the list or
slide your finger up or down the list slowly.
4. To place a call, do one of the following:
Tap a phone number or contact from the list.
After entering a complete number, tap Call.
To call a different phone number associated with the contact, you can tap
at the right side of the contact name. On the contact details screen, tap
the number you want to call.
While dialing or when the call is in progress, the status bar displays the Call in progress
icon ( ) and its color changes to pulsing green.
For FCC
2011/01/24
22 Phone calls
What is Smart dial?
The phone dialer’s Smart Dial feature makes it quick and easy for you to place a call.
Simply enter the phone number or first few letters of the person’s name you want
to call. Smart Dial automatically searches and filters your contacts list (stored on
your phone, SIM card, and online accounts such as Google Account and Exchange
ActiveSync) and the phone numbers from the call history.
Using Speed dial
Use Speed dial to call a phone number with a single tap. For example, if you assign a
contact’s number to the number 2 key, you can simply press and hold this key on the
Phone dialer keypad to dial that number.
Assigning a speed dial key
On the Home screen, tap Phone.
Press MENU, and then tap Speed dial > Add new.
Enter the name of the contact you want to add. When the name comes up in the
list, tap the name.
On the Speed dial screen, choose the phone number of the contact to use, and a
speed dial key to assign.
Tap Save.
Calling a speed dial number
On the Home screen, tap Phone.
On the phone keypad:
The number 1 key is generally reserved for your voicemail. Press and hold
this key to call voicemail and retrieve your voicemail messages.
Press and hold the key that is associated with the contact you want to call.
Calling a phone number in a text message
From the Home screen, tap > Messages.
Tap the number or name of the person who sent you the text message.
Tap the phone number within the message.
4. Edit the phone number if needed, and then tap Call.
To call the message sender, press and hold the sender or the received message, and then tap
Call on the options menu.
To find out more about text messaging, see the Messages chapter.
1.
2.
3.
4.
5.
1.
2.
1.
2.
3.
For FCC
2011/01/24
23 Phone calls
Calling a phone number in an email
From the Home screen, tap > Mail.
In your email account’s inbox, tap the email that contains the phone number to
call.
In the email body, tap the phone number. A selection menu then pops up and
the phone number is highlighted.
The phone will recognize a number as a phone number if the number has a
minimum of 5 digits and have at least one of the following:
Numbers starting with a plus sign (+). For example, +1-987-654-321 or
+1987654321.
Numbers starting with an area or country code enclosed in a parenthesis.
For example, (02)987654321 or (02)987-654-321.
Numbers separated by dashes. For example, (02)-987-654-321 or
0987-654-321.
4. Tap Call.
5. When the phone dialer screen opens with the phone number already entered,
tap Call.
To find out more about using email on your phone, see the Email chapter.
Making an emergency call
You can make emergency calls from your phone even if you don’t have a SIM card
installed or your SIM card has been blocked.
From the Home screen, tap Phone.
Dial the international emergency number for your locale (for example, 000),
and then tap Call.
Additional emergency numbers may be included in your SIM card. Contact your mobile
operator for details.
If you’ve enabled but forgotten your lock screen password, lock pattern, and/or the
SIM lock, you can still make emergency calls by tapping Emergency call on the screen.
1.
2.
3.
1.
2.
For FCC
2011/01/24
24 Phone calls
Receiving calls
When you receive a phone call from a contact, the Incoming call screen appears and
displays the caller ID icon, name, and phone number of the calling party.
When you receive a phone call from someone who is not stored in People, only the
default caller ID icon and phone number appear on the Incoming call screen.
You can use your phone’s polite ringer and pocket mode features for receiving calls. To find
out how, see “Turning on or off automatic ring volume adjustment” in the Settings chapter.
Answering or rejecting an incoming call
If To answer the call To reject the call
Display is on Tap Answer. Tap Decline.
Display is off When the Lock screen appears, drag the
bar that shows the caller name or number
downward.
Drag the bar upward.
Or, press MENU and then tap
Decline.
You can also do one of the following to reject an incoming call:
Press the POWER button twice.
To reject the call and send a text message, press MENU, and then tap Send
message.
Changing the text message to send out for rejected calls
On the Phone dialer screen, press MENU.
Tap Settings > Edit default message.
Enter the new message, and then tap OK.
1.
2.
3.
For FCC
2011/01/24
25 Phone calls
Muting the ringing sound without rejecting the call
Do one of the following:
Press the VOLUME DOWN or VOLUME UP button.
Press the POWER button.
Place the phone face down on a leveled surface.
If the phone is already facing down, the phone will still ring when there are subsequent
incoming calls.
HTC Caller ID
Everytime you make a call or your friend gives you a ring, you get to see your friend’s
latest status update from social networks like Facebook or Twitter right on the call
screen.
You also won’t miss people’s birthdays. You’ll see a birthday reminder, if your friend’s
birthday will occur sometime within the next seven days.
Using in-call options
When a call is in progress, use the buttons onscreen to mute or unmute the
microphone or to turn on or off the speakerphone. You can also press MENU and
choose whether to add a call, place the call on hold, mute the microphone, and more.
Putting a call on hold
Press MENU and then tap Hold to put the call on hold. When you put a call on hold,
the status bar displays the Hold call icon ( ) and its color changes to pulsing red.
Press MENU, and then tap Unhold to resume the call.
For FCC
2011/01/24
26 Phone calls
Switching between calls
If you’re already on a call and accept another call, you can choose to switch between
the two calls.
1. When you receive another call, tap Answer to accept the second call, and to put
the first call on hold.
2. To switch between the calls, tap the person you want to talk to on the screen.
3. To end the current call and return to the other call, tap End call.
Setting up a conference call
Conference calling with your friends, family, or co-workers is easy. Make the first call
(or accept a call), and then simply dial each subsequent call to add to the conference.
Make sure your SIM card is enabled with conference calling service. Contact your mobile
operator for details.
Make a call to the first conference call participant.
When connected, press MENU, tap Add call, and then dial the number of the
second participant. The first participant is put on hold when you dial the second
participant.
When connected to the second participant, tap (merge).
To add another participant to the conference call, tap on the conference
call screen, and then dial the number of the contact you want to invite to the
conference call.
5. When connected, tap to add the participant to the conference call.
When you want to talk to a person in the conference call in private, tap , and
then select Private call on the options menu.
6. When finished, tap End call.
1.
2.
3.
4.
For FCC
2011/01/24
27 Phone calls
Turning the speakerphone on or off during a call
To turn the speakerphone on, you can do any of the following:
Flip your phone over during a call (be sure that Flip for speaker is selected in
HOME > MENU > Settings > Sound).
On the call screen, tap .
The speakerphone icon ( ) appears in the status bar when the speakerphone
is on.
To turn the speakerphone off, just flip the phone over again, facing it up. Or tap
again.
To decrease potential damage to your hearing, do not hold your phone against your ear when
the speakerphone is on.
Muting the microphone during a call
On the call screen, tap to toggle between turning the microphone on or off.
When the microphone is turned off, the Mute icon ( ) appears in the status bar.
Ending a call
Do one of the following to end the call:
On the call screen, tap End call.
If the phone display is off, press POWER to turn on the screen so you can tap End call.
Slide open the Notifications panel, then tap .
If you are using the provided wired headset, press the button to end the call.
If the phone number of the person who called is not in your contacts list, you can
choose to save the number to your contacts list after you hang up.
For FCC
2011/01/24
28 Phone calls
Using Call history
Use the Call history to check missed calls, your dialed numbers and received calls.
Checking a missed call
You will see the missed call icon in the status bar when you miss a call.
1. Slide open the Notifications panel to check who the caller is.
2. To return the call, tap the missed call notification. Then tap the caller’s name or
number on the Call history screen.
Checking calls in the call history
From the Home screen, tap > Call history. You can also tap on the
Phone dialer screen.
On the Call history screen, you can:
Tap a name or number in the list to call.
Press and hold a name or number in the list to display the options menu
where you can select to check the call history details, view contact
information (if the number is stored in your contacts list), send a text
message, delete from call history, or block the caller.
Tap to check only the call history of a particular contact.
Press MENU, then tap View to display just a particular type of calls such as
Missed calls or Outgoing calls.
You can also access Call history from the People app. For details, see the People chapter.
Adding a new phone number to your contacts from call history
On the Call history screen, press and hold a phone number that you want to save
to your contacts, and then tap Save to People.
2. Choose whether to create a new contact or to save the number to an existing
contact on your phone.
3. Do any of the following:
When creating a new contact, enter the contact name, contact type, and
other information in the blank contact record that appears. The phone
number is automatically added to the Mobile field in the Phone section.
To store it as another type of number, for example a home number, tap the
Mobile button.
When saving the number to an existing contact, tap a contact stored on your
phone, and then select the number type.
4. Tap Save.
To find out how to add new contacts or edit the contact information, see the People chapter.
1.
2.
1.
For FCC
2011/01/24
29 Phone calls
Clearing the call history list
On the Call history screen, you can do the following:
To remove one name or number from the list, press and hold the name or
number, and then tap Delete from call history.
To clear the entire list, press MENU, and then tap Delete all.
Call services
Your phone can directly link to the mobile phone network, and enable you to access
and change the settings of various phone services for your phone. Call services
may include call forwarding, call waiting, voicemail, and more. Contact your mobile
operator to find out about the availability of call services for your phone.
To open call services, press MENU from the Home screen, and then tap Settings > Call.
Fixed Dialing Numbers Restrict outgoing calls to a fixed set of numbers. To enable this
feature, you must know your SIM card’s PIN2 code.
Voicemail service Shows the current voicemail service being used.
Voicemail settings Specify another voicemail number aside from the voice mail number
on your SIM card.
Clear voicemail
notification
If you have a notification of a new voicemail, you can clear the
notification with this option.
Phone settings Edit the call reject message, choose whether to open the message
editor when you reject a call with a message, and choose whether to
allow automatic saving of an unknown contact number when a call
with that number ends.
Cell broadcast Enable or disable receipt of cell broadcast messages from your
service provider.
Cell broadcast settings Configure channels and language for cell broadcast messages.
Call forwarding Select how you want your phone to handle busy, unanswered, and
unreachable calls. You can also set the call forwarding option for all
incoming calls.
Call barring settings Choose whether to block various categories of incoming and
outgoing call.
Additional call settings Enable or disable operator services such as caller ID and call waiting.
For FCC
2011/01/24
30 Phone calls
Turning Airplane mode on or off
In many countries, you are required by law to turn off the phone while on board an
aircraft. A way to turn off the phone function is to switch your phone to Airplane
mode. When you enable Airplane mode, all wireless radios on your phone are turned
off, including the call function, data services, Bluetooth, and Wi-Fi.
To turn Airplane mode on or off, you can:
Press and hold POWER, and then tap Airplane mode.
From the Home screen, press MENU. Tap Settings > Wireless & networks, and
then select or clear the Airplane mode check box.
When enabled, the Airplane mode icon ( ) is displayed in the status bar.
When you disable Airplane mode, the call function is turned back on and the previous state of
Bluetooth and Wi-Fi is restored.
For FCC
2011/01/24
31 People
People
About People
With the People app, you can sync your phone with contacts from your Google
Account, computer, and Facebook. You can also sync with work contacts from the
Exchange ActiveSync Server in your workplace. To find out how, see “Ways of getting
contacts into your phone.”
Per contact, link the person’s information from all these different sources as one so
you won’t have duplicated entries in your contacts list. To find out how to link, see
“Merging contact information”.
And that’s not all. You can manage your communications with your contacts via
phone, messaging, and email without the need to jump from one app to another. After
you’ve linked contacts to their social network accounts like Facebook, Twitter, and
Flickr, you’ll also see their updates and events from these accounts all in one place.
Adding a new contact
From the Home screen, tap > People.
On the All tab, tap Add contact.
3. Select the Contact type, for example Google or Microsoft Exchange ActiveSync.
This determines which account the contact will sync with. For more information,
see “Ways of getting contacts into your phone” in this chapter.
Some fields may not be supported when you’re adding contacts to your SIM card.
4. In the Name field, enter the first and last name of the contact, then tap OK.
5. Enter the contact information in the fields provided.
Press BACK if you want to close the onscreen keyboard first and easily scroll
through the other fields.
6. Tap Save.
Importing contacts from your SIM card
You can copy all your SIM contacts to your phone. You can import them as Phone
contacts, Google contacts, or Exchange ActiveSync contacts, if you have set up the
relevant accounts.
From the Home screen, tap > People.
On the All tab, press MENU, and then tap Import/Export > Import from SIM card.
If you have Google or Exchange ActiveSync accounts set up on your phone, tap
the type for the imported contacts.
1.
2.
1.
2.
3.
For FCC
2011/01/24
32 People
Do one of the following:
To import all contacts, press MENU, and then tap Select all.
To import a contact, tap the contact.
5. Tap Save.
Importing a contact from an Exchange ActiveSync account
You can search for a work contact from your Exchange ActiveSync account, and then
copy it to your phone.
You need to have your Exchange ActiveSync account set up on your phone first. To
find out how, see “Adding a Microsoft Exchange ActiveSync account“ in the Email
chapter.
From the Home screen, tap > People.
On the Online directories tab, tap Company directory.
Enter the name, and then tap .
In the list, tap the name of the contact you want to copy to your phone.
Tap Save to People.
Filtering your contacts list
You can choose to display contacts of a particular type only, for example Google
contacts or Facebook contacts.
From the Home screen, tap > People.
On the All tab, press MENU, then tap View.
Select the types of contacts you want to show in your contacts list.
You can also choose how you want to display and sort your contacts.
4. Tap Done.
4.
1.
2.
3.
4.
5.
1.
2.
3.
For FCC
2011/01/24
33 People
Searching for a contact
From the Home screen, tap > People.
Press SEARCH, then enter the first few letters of a contact’s first or last name,
email, or company name.
You can also type in the first few digits of your contact’s phone number.
Matching contacts are displayed.
3. Tap the contact to open his or her contact details screen. See “Contact
information and conversations” in this chapter for details.
Backing up your contacts to the storage card
From the Home screen, tap > People.
Press MENU, and then tap Import/Export > Export to SD card.
Select an account or type of contacts to export, then tap OK.
Importing contacts from the storage card
From the Home screen, tap > People.
Press MENU, and then tap Import/Export > Import from SD card.
You can only import contacts that were exported to the storage card using the Export to SD
card feature on the phone. See “Backing up your contacts to the storage card.”
3. If you have Google or Exchange ActiveSync accounts set up on your phone, tap
the type for the imported contacts.
Deleting contacts
From the Home screen, tap > People.
On the All tab, press MENU, and then tap Delete.
Select the contacts you want to delete, and then tap Delete.
When prompted, tap OK.
1.
2.
1.
2.
3.
1.
2.
1.
2.
3.
4.
For FCC
2011/01/24
34 People
Contact groups
Assign contacts to groups so you can easily send a message or email to a whole
group. You can also sync groups on your phone with the groups in your Google
account, accessible via your computer’s web browser.
We’ve also added the Frequent group as a special group type that automatically
stores the contacts you dial or get calls from the most.
Creating a group
From the Home screen, tap > People.
On the Groups tab, tap Add group.
Enter a name for the group, and then tap Add contact to group.
Select the contacts you want to add to the group, and then tap Save.
If your contacts list is long, you can use the search bar to search for contacts quickly, or press
BACK to hide the onscreen keyboard and scroll through the list.
5. Tap to select a photo for the group.
6. Tap Save.
Editing a contact group
From the Home screen, tap > People.
On the Groups tab, press and hold the group, and then tap Edit group.
You can:
Tap the group name to change the name. You can only change the name for
groups that you have created.
Tap the icon beside the group name to change or remove the group photo.
To add contacts to the group, tap Add contact to group, select the contacts
you want to add, and then tap Save.
To remove a contact from the group, tap at the right side of the contact
name.
4. Tap Save.
1.
2.
3.
4.
1.
2.
3.
For FCC
2011/01/24
35 Keyboard
Keyboard
Using the onscreen keyboard
When you start an app or select a field that requires text or numbers, the onscreen
keyboard becomes available.
After entering your text, you can tap or press BACK to close the onscreen
keyboard.
Selecting a keyboard layout
You can choose from three different keyboard layouts to suit your typing style.
1. On the onscreen keyboard, tap the Language key (for example, tap if you’re
currently using the English onscreen keyboard). Then on the International
keyboard options menu, tap Settings.
If tapping the Language key doesn’t display the International keyboard menu,
press HOME > MENU, and tap Settings > Language & keyboard > Touch Input.
2. Tap Keyboard types, and then select the keyboard layout that you want to use.
Choose one from the following:
QWERTY This layout is similar to a desktop computer keyboard. This is
the default keyboard layout.
Phone Keypad This layout resembles the traditional mobile phone keypad.
Compact QWERTY This layout features two letters on each key. The key size is
slightly bigger than on the full QWERTY layout.
Entering text
Use the following keys while entering text using the onscreen keyboard:
Press and hold keys with gray characters at the top to enter numbers, symbols, or
accented letters. The gray character displayed on the key is the character that will be
inserted when you press and hold that key. Some keys have multiple characters or
accents associated with them.
Shift key. Tap to enter an uppercase letter. Tap twice to turn on caps lock.
Tap to switch to the numeric and symbol keyboard.
Enter key. Tap to create a new line.
Tap the Up, Down, Left, or Right key to move the text cursor in the direction that you want
while you are entering or editing text.
For FCC
2011/01/24
36 Keyboard
Backspace key. Tap to delete the previous character.
Language key. The key you see depends on the keyboard language you are currently
using. Tap to switch to another keyboard language (see “Enabling multiple keyboard
languages”). You can also access onscreen keyboard settings.
Tap to toggle between Multitap and XT9 predictive modes when using the Compact
QWERTY or Phone keypad layout. For more information, see “Entering words with
predictive text.”
Tap to hide the onscreen keyboard.
Enabling multiple keyboard languages
If there are multiple keyboard languages available on your phone, you can choose
which languages to enable in the onscreen keyboard so that you can switch to these
languages and use them to enter text.
1. On the onscreen keyboard, tap the Language key (for example, tap if you’re
currently using the English onscreen keyboard). Then on the International
keyboard options menu, tap Settings.
If tapping the Language key doesn’t display the International keyboard menu,
press HOME > MENU, and tap Settings > Language & keyboard > Touch Input.
2. Tap International keyboard.
3. Choose the languages that you want.
Available languages depend on the region where you purchased the phone.
Changing to the landscape onscreen keyboard
When entering text, you can choose to use the landscape orientation of the onscreen
keyboard. Turn your phone sideways to use a larger keyboard for easy typing.
The Auto-rotate screen check box in HOME > MENU > Settings > Display needs to be
selected for the screen orientation to automatically change.
The landscape orientation keyboard is not supported in all apps.
For FCC
2011/01/24
37 Keyboard
Entering words with predictive text
The onscreen keyboard has predictive text to help you type quickly and accurately.
Predictive text input is enabled by default, and word suggestions are displayed as you
type.
To enter a word in predictive mode, do any of the following:
If you see the word you want highlighted in green or orange, you can simply
tap the space bar to insert the word into your text.
If you see the word you want shown in the suggestions before you have
finished typing the entire word, tap the word to insert it into your text.
If an arrow is shown to the right of the suggestion list, tap the arrow to see
more suggestions.
Setting a second language for the keyboard
Aside from the keyboard language you are currently using, you can set the predictive
text to be bilingual. As you type, you’ll get word suggestions in two languages that
you’ve selected.
1. On the onscreen keyboard, tap the Language key (for example, tap if you’re
currently using the English onscreen keyboard). Then on the International
keyboard options menu, tap Settings.
If tapping the Language key doesn’t display the International keyboard menu,
press HOME > MENU, and tap Settings > Language & keyboard > Touch Input.
2. Tap Bilingual prediction, and then choose the language you want.
Adding a word to the predictive text dictionary
Your phone comes with a list of words that it references for predictive text
suggestions. Sometimes you may need to add a word to the predictive text dictionary,
for example a name or a specialized technical word.
While entering text using the QWERTY keyboard layout, if you tap any word on the
suggestion list, it is automatically added to the predictive text dictionary if it was not
in the dictionary already.
You can also add a word to the list manually:
From the Home screen, press MENU, and then tap Settings > Language &
keyboard > Touch Input.
Tap Personal dictionary > Edit personal dictionary > Add new.
Enter the word to add, and then tap OK.
1.
2.
3.
For FCC
2011/01/24
38 Keyboard
Editing or deleting a word in the predictive text dictionary
You can edit or remove words that you previously added to the predictive text
dictionary.
From the Home screen, press MENU, and then tap Settings > Language &
keyboard > Touch Input.
Tap Personal dictionary > Edit personal dictionary.
To edit a word, tap the word itself.
To delete words from the dictionary, press MENU and tap Delete. Then
choose the words to remove and tap OK.
Backing up your personal dictionary to your storage card
You can use your storage card to back up the new words you’ve added to the
predictive text dictionary.
From the Home screen, press MENU, and then tap Settings > Language &
keyboard > Touch Input.
Tap Personal dictionary > Sync personal dictionary > Copy to storage card.
When prompted, tap OK.
Importing your personal dictionary from your storage card
From the Home screen, press MENU, and then tap Settings > Language &
keyboard > Touch Input.
Tap Personal dictionary > Sync personal dictionary > Restore from storage card.
When prompted, tap OK.
Entering text by speaking
No time to type? Try speaking the words to enter it in most text fields that let you use
the onscreen keyboard.
Simply press and hold the Language key. When your phone cues you to “Speak now”,
tell your phone what you want to be typed in.
First make sure to select the language you’ll be using in the Voice input & output settings.
See “Setting the voice input language”.
Since your phone uses Google’s speech-recognition service, you need to be connected to
the Internet to enter text by speaking.
Setting the voice input language
1. From the Home screen, press MENU, then tap Settings > Voice input & output >
Voice recognizer settings.
2. Tap Language, then choose the language you want.
Available languages depend on the voice input languages supported by Google.
1.
2.
1.
2.
3.
1.
2.
3.
For FCC
2011/01/24
39 Keyboard
Editing text
You can select, copy, or cut the text you enter using the onscreen keyboard, then
paste it in another text field within or across apps.
Some apps may offer their own way of selecting or copying text.
Selecting text
Highlight a portion of a text or select all that you want to copy or cut.
Press and hold the text field that contains the text to select. Don’t lift your finger
just yet to display the magnifier.
2. Drag your finger to move the text cursor to a letter within the text that you want
to select. It should be easy since the magnifier gives you a bigger view of the
text.
3. After positioning the text cursor, lift your finger. The text selection menu then
pops up.
4. Do one of the following:
Tap Select text. When the word where you’ve placed the text cursor is
highlighted, drag the start and end markers to select the text you want.
Tap Select all to select everything in the text field.
Copying and pasting text
1. After you have selected the text you want to copy, tap Copy or Cut.
The selected text is then copied to the clipboard.
2. Within the same or another app, press and hold a text field where you want to
paste the text. Don’t lift your finger just yet to display the magnifier.
1.
For FCC
2011/01/24
40 Keyboard
3. Drag your finger to move the text cursor to where you want to paste the text.
4. After positioning the text cursor, lift your finger. The text selection menu then
pops up.
5. Tap Paste.
Adjusting touch input settings
Open the Touch Input settings by doing one of the following:
On the onscreen keyboard, tap the Language key (for example, tap
if you’re currently using the English onscreen keyboard). Then on the
International keyboard options menu, tap Settings.
From the Home screen, press MENU and then tap Settings > Language &
keyboard > Touch Input.
Touch Input settings
Keyboard types Select the keyboard layout to use. You can choose from QWERTY,
Phone Keypad, or Compact QWERTY.
International keyboard Add or remove languages from the onscreen keyboard language
list.
Bilingual prediction Select a secondary keyboard language to use. See “Setting a
second language for the keyboard”.
Text input Set text input options when entering text, calibrate the keyboard,
and set a sound and/or vibration feedback whenever you tap a
key. See “Text input” for details.
Tutorial Learn how to use the onscreen keyboard with this interactive
tutorial.
Personal dictionary Add, edit or remove words in the predictive text dictionary. See
“Entering words with predictive text.”
Text input
QWERTY
Prediction Select to enable the word prediction feature which provides a list
of possible words that reflect the characters of the keys you have
tapped as well as characters of nearby keys.
Spell correction Select to correct typographical errors by selecting from a list of
possible words that reflect the characters of the keys you have
tapped as well as characters of nearby keys.
Phone keypad & compact QWERTY
Spell correction Select to correct typographical errors by selecting from a list of
possible words that reflect the characters of the keys you have
tapped as well as characters of nearby keys.
Word completion When using the Compact QWERTY or Phone keypad, lets you
select from a list of possible combinations based on the characters
that appear on the keys that you tapped.
For FCC
2011/01/24
41 Keyboard
Other settings
Sound feedback Select to hear a clicking sound whenever you tap a key on the
keyboard.
Vibrate when typing Select to enable vibration feedback whenever you tap a key on
the keyboard.
Finger touch precision
Calibration tool Tap to re-calibrate the keyboard touch accuracy. Re-calibrate the
keyboard if you feel that the keyboard keys are not responding
accurately to your taps.
Reset calibration Tap to reset the calibration back to factory default.
For FCC
2011/01/24
42 Messages
Messages
About Messages
Keep in touch with important people in your life. Use the Messages app to compose
and send text (SMS) and multimedia messages (MMS).
From the Home screen, tap > Messages.
On the All messages screen, all your sent and received messages are neatly grouped
into conversations, by contact name or phone number. You can:
Scroll up or down the list of conversations by swiping your finger on the
screen.
Tap a contact name or number to view the exchange of messages.
Tap the photo or icon to open a menu where you can quickly choose how to
communicate with the contact.
You can also view your messages on the Home screen with the Messages widget. If
this widget is not there already, you can add it by following the steps in “Personalizing
your Home screen with widgets” in the Personalizing chapter.
For FCC
2011/01/24
43 Messages
Sending a text message (SMS)
If you exceed the limit on the number of characters for a single text message, your text
message will be delivered as one but will be billed as more than one message.
From the Home screen, tap > Messages.
On the All messages screen, tap Compose message.
3. Fill in one or more recipients. You can:
Enter the first few letters of a contact name or starting digits of a mobile
number. As you type, matching names with phone numbers from your
stored contacts are displayed. Tap a name or one of the contact’s number.
Tap the icon, and then select the phone numbers of the contacts to
whom you want to send the message. You can also select contact groups as
recipients.
When you have selected all the message recipients, tap Done.
Enter the complete phone numbers directly in the To field.
4. Tap the box that says “Add text”, and then enter your message.
5. Tap Send.
Or press BACK to save it as a draft. To open and edit a draft message, see
“Resuming a draft message.”
Your text message automatically becomes a multimedia message when you enter an email
address as the recipient, add a message subject, attach an item, or compose a very long
message.
1.
2.
For FCC
2011/01/24
44 Messages
Sending a multimedia message (MMS)
To compose a multimedia message, start by creating a new text message. Then
choose the type of attachment to include in your message.
From the Home screen, tap > Messages.
On the All messages screen, tap Compose message.
3. Fill in one or more recipients. You can:
Enter the first few letters of a contact name or starting digits of a mobile
number. As you type, matching names with phone numbers and email
addresses from your stored contacts are displayed. Tap a contact’s number
or email address.
Email addresses will be displayed when Show email address is selected
in Recipient list settings. To find out more about message settings, see
“Setting message options”.
Tap the icon, and then select the phone numbers of the contacts to
whom you want to send the message. You can also select contact groups as
recipients.
When you have selected all the message recipients, tap Done.
Enter the complete phone numbers or email address directly in the To field.
4. To add a subject line, press MENU and then tap Add subject.
5. Tap the box that says “Add text”, and then enter your message.
6. Tap and then choose the type of attachment.
7. To make changes to your attachment, tap or (depending on the type of
file you’ve attached).
You can also press MENU, then tap Remove to start over.
8. Tap Send.
Or press BACK to save it as a draft. To open and edit a draft message, see
“Resuming a draft message.”
Replying to another phone number of the contact
When a contact has multiple phone numbers stored on your phone, you’ll see the
particular phone number used within the message. There’s also a bold letter before the
phone number to indicate the number type (for example, M stands for Mobile).
Keep in mind that your response will be sent to the phone number of the latest
message you’ve received from this contact.
1.
2.
For FCC
2011/01/24
45 Messages
If you want to change the phone number before you send out your reply, press MENU,
then tap More > Recipient phone number. Select another phone number of this
contact, and then tap OK.
Viewing and saving an attachment from a multimedia message
If you are concerned about the size of your data downloads, check the multimedia
message size first before you download it.
When Auto-retrieve in MMS settings is disabled, only the message header is downloaded. To
download the entire message, tap the Download button at the right side of the message. To
find out more about message settings, see “Setting message options.”
If there’s a media attachment such as a photo or video in a received message,
tap it to view the content.
If the attachment is a contact (vCard), tap it to view the contact information,
then tap Save to add to your contacts.
Open the People app to view the contact. See the People chapter.
If the attachment is an appointment or event (vCalendar), tap it and then
choose the calendar where to save it. Tap Import.
Open the Calendar app to view the appointment or event. See the Calendar
chapter.
To save the attachment to your storage card, press and hold the multimedia
message, and then tap Save [attachment type] on the options menu.
Viewing push messages
Push messages contain a web link. Often, the link will be to download a file that you
have requested, for example a ringtone.
When you receive a push message, a notification icon is displayed in the status bar.
Opening and reading a new push message
Press and hold the status bar, and then slide the status bar down to open the
Notifications panel.
Tap the new message.
Tap Visit website.
Viewing all your push messages
From the Home screen, tap > Messages.
Press MENU, and then tap Push messages.
1.
2.
3.
1.
2.
For FCC
2011/01/24
46 Calendar
Calendar
Creating calendar events
You can create events that sync with your Google Calendar, your computer’s Outlook
Calendar, or Exchange ActiveSync calendar, as well as events that appear on your
phone only.
1. From the Home screen, tap , and then tap Calendar.
2. On any Calendar view, press MENU and then tap Add event.
When you are in the Month or Agenda view, you can also tap at the bottom-right of the
screen to create a new event.
3. If you have more than one calendar, select a calendar in which to add the event:
Select your Google Account to create a Google Calendar event. If you have
several Google Calendars on the Web, select one in which to add your
event.
Select PC Sync to create calendar events on your phone. You can sync them
with your computer using HTC Sync. For details, see the Accounts and sync
chapter.
Select your Exchange ActiveSync account to create an Exchange
ActiveSync calendar event.
4. Enter a name for the event.
5. To specify the date and time of the event, do one of the following:
If there is a time frame for the event, tap the From and To date and time to
set them.
If it is a special occasion such as a birthday or a whole-day event, set the
From and To date, then select the All day check box.
6. Enter the event location and description.
7. Set the reminder time.
You can add another reminder time in a Google Calendar event. Press MENU and then tap
Add reminder.
8. If the event occurs on a regular basis, tap the Repetition box and then choose
how often the event occurs.
9. Tap Save.
For FCC
2011/01/24
47 Calendar
Managing calendar events
You can view, edit, delete, or share events that you created. You can also view and
share event invitations that other people sent to you.
Viewing an event
1. From the Home screen, tap , and then tap Calendar.
2. In Month view, tap the day when the event takes place, and then tap the event to
open it.
The Event details screen then opens and shows the summary of the event.
3. When viewing the event summary, you can do the following:
Find the event’s location in Maps.
Call any phone number included in the event location or description.
Check the participants of the event you sent or are invited to.
Respond whether you’ll attend the event you’re invited to.
If it’s an Exchange ActiveSync calendar event, reply by email to the
organizer or to all the guests. Press MENU, and then either tap Reply or
Reply all.
Select any text and look it up on the web. To learn more, see “Selecting text”
in the Keyboard chapter and “Quickly looking up information on the Web” in
the Getting started chapter.
Tap the reminder time to change it. Press BACK to save changes.
Editing an event
1. While viewing an event, press MENU, and then tap Edit event.
2. Make your changes to the event.
3. When you’re done editing, tap Save.
Deleting an event
There are a number of ways to delete an event.
While viewing the summary of an event on the Event details screen, press
MENU and then tap Delete event.
In Day, Agenda or Week view, press and hold an event and then tap Delete
event.
When editing an event, tap Delete.
If the event repeats, you’ll be asked whether you want to delete just that
occurrence, this and all future occurrences, or all past and future occurrences in
your Calendar.
For FCC
2011/01/24
48 Calendar
Sharing an event (vCalendar)
You can share a calendar event as a vCalendar to someone’s phone using Bluetooth or
by sending it as a file attachment with your email or message.
While viewing an event, press MENU, and then tap Share vCalendar.
Do one of the following:
Tap Bluetooth. you’ll be asked to turn on Bluetooth on your phone and
connect to the receiving Bluetooth device. Follow the steps in “Sending
information using Bluetooth” in the Bluetooth chapter.
Tap Mail. A new message window opens and automatically includes the
vCalendar as an attachment. Your default email account that’s selected
in the Mail app will be used to send. For more information, see the Email
chapter.
Tap Message. A new message window opens and automatically includes
the vCalendar as a multimedia attachment. For more information, see the
Messages chapter.
Calendar event reminders
If you have set at least one reminder for an event, the upcoming event icon will
appear in the notifications area of the status bar to remind you of the upcoming event.
Dismissing or snoozing event reminders
1. Tap the status bar, then slide your finger down the screen to open the
Notifications panel.
2. Do one of the following:
Tap Clear to dismiss event reminders and all other notifications. Other types
of notifications such as new messages and missed calls will also be deleted.
After sliding open the Notifications panel, tap the calendar event reminder.
You’ll then see a list of all pending event reminders. Tap Snooze all to
snooze all event reminders for five minutes, or tap Dismiss all to dismiss all
event reminders.
Press BACK to keep the reminders pending in the notifications area of the
status bar.
1.
2.
For FCC
2011/01/24
49 Calendar
Changing Calendar settings
You can change Calendar settings to specify how it displays events and how it notifies
you of upcoming events. In any Calendar view, press MENU and then tap More >
Settings to access Calendar’s settings.
Reminder settings
Choose how you want Calendar to issue event reminders when there are upcoming
events.
All calendars Select this check box to use the same event reminder settings
for all types of calendars. If you clear this check box, you can
set different reminder settings for each calendar.
Alerts & notifications Configure event reminders to open an alert, send you a
notification, or turn off event notifications on your phone.
Default reminder time Choose how soon before an event you want to be notified.
Select ringtone Choose a ringtone to sound when you receive an event
reminder.
Vibrate Choose whether you want your phone to vibrate when you
receive an event notification.
Hide declined events Choose whether to show or hide events to which you’ve
declined invitations.
Calendar view settings
Choose what appears in Calendar when opened and what’s shown in Day, Week, and
Month views.
Start in Choose the default Calendar view that is displayed when you
open Calendar.
Day views Choose whether to display Day view in the form of an event
list or time list.
First day of week Set the Month and Week views to start on a Sunday or
Monday.
Include weather Make sure this check box is selected so that weather
information is shown in Day view’s event list.
City By default, Day view displays your current location’s weather.
You can change it to display the weather of another city.
About the Calendar widget
There’s a Calendar widget available that you can add to your Home screen, and it
comes in different calendar views. Tapping a day or event on the widget brings you
to the Calendar app. To find out how you can add a widget, see “Personalizing your
Home screen with widgets” in the Personalizing chapter.
For FCC
2011/01/24
50 Clock and Weather
Clock and Weather
About the HTC Clock widget
Use the HTC Clock widget to see your current date, time, and location. It’s added by
default on your Home screen. Tap the weather image to open the Weather app and
check for more weather forecasts. See “Checking weather” for details.
If you want to show the time of another city, you can:
Edit the widget settings. Press and hold the HTC Clock widget on the Home
screen, then drag it to the Edit button. Select the city you want to show.
Add another clock widget to the extended Home screen. Select from a
variety of looks and designs. To find out how you can add a widget, see
“Personalizing your Home screen with widgets” in the Personalizing chapter.
About the Clock app
Get more from the Clock app than just the regular date and time. Use your phone as
a desk clock complete with weather information. Or let it serve as a night clock or a
screensaver. As a world clock, see what time it is in several cities across the globe. You
could also use it as an alarm clock, stopwatch, and countdown timer.
To open the Clock app, you can:
Tap the HTC Clock widget on the Home screen.
From the Home screen, tap , and then tap Clock.
For FCC
2011/01/24
51 Clock and Weather
Tap the tabs at the bottom row or slide your finger across the tabs to switch between
the different functions of the Clock app.
2 3 451
1 Desk Clock tab
2 World Clock tab
3 Alarms tab
4 Stopwatch tab
5 Timer tab
Using Desk Clock
Opening the Clock app brings you directly to the Desk Clock screen.
The Desk Clock displays the current date, time, and weather. It also has an alarm clock
indicator and a battery charging indicator. You can dim the screen to show only the
time and date on the Desk Clock.
2
3
4
5
1
1 Shows whether the alarm clock is on or off. To find out how to turn on and set the alarm
clock, see “Setting the alarm clock.”
2 Shows the weather information of your current location. Tapping it brings you to the
Weather app where you can see weather forecasts of the next few days. See “Checking
weather” for more information about the Weather app.
3 Shows the battery charge level. You’ll see it only when your phone is plugged with the
power adapter or connected to your computer.
4 Tap to dim the screen and display only the time and date on the Desk Clock. To light up the
screen again, tap anywhere on the screen or press the BACK button on your phone.
5 Tap to dim the screen and go into screensaver mode. When in screensaver mode, the time
and date will change position on the screen after every few minutes. To light up the screen
again, tap anywhere on the screen or press the BACK button on your phone.
For FCC
2011/01/24
52 Clock and Weather
You can change the Desk Clock screen to display the date and time of another time
zone. To find out how to select a different time zone, see “Setting the time zone, date,
and time.”
Using World Clock
Use the Clock app’s World Clock screen to check the current time in several places
around the globe simultaneously. You can also set your home city, add more cities to
the world clock list, and manually set your time zone, date, and time.
Setting your home city
Tap the HTC Clock widget on the Home screen.
Tap the World Clock tab.
Press MENU and then tap Home settings.
Enter your home city’s name. As you enter letters, the list is filtered to show
matching cities and countries.
Scroll through the list and tap your home city.
Setting the time zone, date, and time
To set the time zone, date, and time on your phone manually, you need to turn off auto
time synchronization first.
Tap the HTC Clock widget on the Home screen.
Tap the World Clock tab.
Press MENU and then tap Local time settings to open the Date & time settings
screen.
Clear the Automatic check box.
Tap Select time zone. Scroll through the list and then tap the time zone that you
want.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
For FCC
2011/01/24
53 Clock and Weather
To change the date, tap Set date. Adjust the date by rolling the day, month, and
year scroll wheels onscreen and then tap OK.
To change the time, tap Set time. Adjust the time by rolling the hour and minute
scroll wheels onscreen and then tap OK.
Tap the Use 24-hour format check box to toggle between using a 12-hour or a
24-hour time format.
Tap Select date format then select how you want dates to be displayed. (The
selected date format also applies to the date displayed in the alarm clock.)
From the Home screen, you can also press MENU and then tap Settings > Date & time to open
the Date & time settings screen.
Adding a city to the World Clock screen
Add more cities to the World Clock screen so you can instantly check the date and
time in these cities. In addition to the current and home cities, the World Clock screen
can display up to 15 cities.
Tap the HTC Clock widget on the Home screen.
Tap the World Clock tab.
Tap Add city. Enter the city name you want to add. As you enter letters, the list
is filtered to show matching cities and countries.
Scroll through the matching list and tap the city that you want to add.
Setting the alarm clock
You can use the Clock app’s Alarms screen to set up one or more wake-up alarms.
6.
7.
8.
9.
1.
2.
3.
4.
For FCC
2011/01/24
54 Clock and Weather
Setting an alarm
1. Tap the HTC Clock widget on the Home screen.
2. Tap the Alarms tab.
3. Select the check box of an alarm, and then tap that alarm.
4. On the Set alarm screen, drag your finger up or down to roll the time scroll
wheels and set the alarm time.
5. Scroll through the Set alarms screen to see all the available alarm options. You
can:
Enter the alarm Description and choose the Alarm sound to use.
Tap Repeat. Select what days of the week to sound the alarm and then tap
OK.
Select the Vibrate check box if you want your phone to also vibrate when
the alarm goes off.
6. When you’ve finished setting the alarm, tap Done.
To turn off an alarm, clear the check box of that alarm.
If you need to set more than three alarms, press MENU while you’re on the Alarms screen
and then tap Add alarm.
Deleting an alarm
Tap the HTC Clock widget on the Home screen.
Tap the Alarms tab.
On the Alarms screen, press MENU and then tap Delete.
Select the alarms you want to delete and then tap Delete.
Changing alarm sound settings
If you’ve set one or more alarms, you can change their settings such as the alarm
volume, how long to snooze the alarm, and more.
Tap the HTC Clock widget on the Home screen.
Tap the Alarms tab.
On the Alarms screen, press MENU and then tap Settings. You can change the
following settings:
Alarm in silent mode Selected by default, this option allows the alarm to sound
even when your phone’s volume is set to silent mode.
Clear this check box if you want to silence the alarm when
the volume is in silent mode.
Alarm volume Set the volume level that you want for the alarm.
Snooze duration Set how long to snooze between alarms.
1.
2.
3.
4.
1.
2.
3.
For FCC
2011/01/24
55 Clock and Weather
Side button behavior Choose what happens to the alarm when pressing the side
button (VOLUME UP/DOWN) of your phone. You can set
the button to snooze, dismiss the alarm, or disable the
button.
The side button works only when the phone’s screen is not
locked. While on the lock screen, tap the onscreen Snooze
button to snooze, or slide down the screen to dismiss the
alarm.
Checking weather
If you consented to turn location service on when you were setting up your phone for
the first time, you’ll see the weather of your current location right on the HTC Clock
widget of your Home screen.
You can also use the Weather app and widget to check the current weather and
weather forecasts for the next four days of the week. In addition to your current
location’s weather, this app also displays the weather forecasts of other cities around
the globe.
If you declined to turn location service on during first-time setup of your phone, turn location
service on in your phone’s settings so that you’ll be able to check your current location’s
weather on the HTC Clock widget, Weather app, and the Weather widget. From the Home
screen, press MENU, tap Settings > Location, and then select the Use wireless networks check
box.
1. Connect to the Internet using your phone’s Wi-Fi or data connection. To find out
how, see the Internet connections chapter.
2. From the Home screen, tap , and then tap Weather.
3. On the Weather screen, you’ll first see your current location’s weather. To check
the weather in other cities, swipe your finger up or down the screen.
4. The Weather app automatically downloads and displays the latest weather
updates. Tap to update the information anytime.
5. To see more weather details on the Web, tap Weather at the bottom center of
the Weather screen.
For FCC
2011/01/24
56 Clock and Weather
Adding a city to the Weather screen
Add more cities to the Weather screen so you can instantly check the weather
forecasts in these cities. In addition to your current location, the Weather screen can
display up to 15 cities.
On the Weather screen, tap .
Enter the location you want to add. As you type, the list is filtered to show the
possible locations based on the letters you entered.
Tap the desired city to select it.
Changing the order of cities on the Weather screen
On the Weather screen, press MENU and then tap Rearrange.
Press and hold at the end of the item you want to move. When the row is
highlighted in green, drag it to its new position, then release.
Tap Done.
Deleting cities from the Weather screen
On the Weather screen, press MENU and then tap Delete.
Select the cities you want to remove and then tap Delete.
Changing weather options
On the Weather screen, press MENU and then tap Settings.
You can change the following weather settings:
Update when opened Select this check box to refresh weather updates every
time you open the Weather app.
Update automatically Select this check box to automatically download weather
updates.
Update schedule Set an auto update schedule.
Temperature scale Choose whether to display weather in Celsius or
Fahrenheit.
About the Weather widget
Use the Weather widget to instantly check weather forecasts of your current location
and other cities without having to open the Weather app. The Weather widget comes
in different looks and styles.
You can add this widget to the Home screen, if it’s not yet added. To find out how
you can add a widget, see “Personalizing your Home screen with widgets” in the
Personalizing chapter.
1.
2.
3.
1.
2.
3.
1.
2.
1.
2.
For FCC
2011/01/24
57 Internet connections
Internet connections
Data connection
Your phone will be automatically set up to use your mobile operator’s data connection
when you turn on your phone (if the SIM card is inserted) for the first time.
Checking the data connection you are using
From the Home screen, press MENU, and then tap Settings
Tap Wireless & networks > Mobile networks > Network operators or Access
Point Names.
Turning the data connection on or off
Turning your data connection off can help save battery life and save money on data
charges. However, if you don’t have data connection turned on and you’re also not
connected to a Wi-Fi network, you won’t receive automatic updates to your email,
social network accounts, and other synchronized information.
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks.
Select the Mobile network check box to turn on the data connection; clear the
check box to turn off the data connection.
Creating a new access point
Before you add another data connection on your phone, have the access point name
and settings (including username and password if required) from your mobile operator
ready.
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > Mobile networks > Access Point Names.
On the APNs screen, press MENU and then tap New APN.
On the Edit access point screen, enter the APN settings. Tap the APN setting
item to edit it.
Press MENU and then tap Save.
1.
2.
1.
2.
3.
1.
2.
3.
4.
5.
For FCC
2011/01/24
58 Internet connections
Enabling data roaming
Connect to your mobile operator’s partner networks and access data services when
you’re out of your mobile operator’s coverage area.
Using data services while roaming will be costly. Check with your mobile operator for data
roaming rates before you use data roaming.
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > Mobile networks, and then select the Data roaming
check box.
Select the Data roaming sound check box if you’d like your phone to play a
sound so you’ll know when it’s connecting to a roaming network.
Wi-Fi
To use Wi-Fi on your phone, you need access to a wireless access point or “hotspot”.
The availability and strength of the Wi-Fi signal will vary depending on objects, such
as buildings or simply a wall between rooms, the Wi-Fi signal has to pass through.
Turning Wi-Fi on and connecting to a wireless network
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks, and then select the Wi-Fi check box to turn Wi-Fi on.
The phone then scans for available wireless networks.
Tap Wi-Fi settings. The network names and security settings of detected Wi-Fi
networks are displayed in the Wi-Fi networks section.
If the wireless network you want to connect to is not in the list of detected
networks, scroll down the screen, and then tap Add Wi-Fi network. Enter the
wireless network settings, and then tap Save.
Tap the Wi-Fi network you want to connect to.
If you selected an open network, you’ll be automatically connected to the
network.
If you selected a network that is secured with WEP, enter the key and then
tap Connect.
Depending on the network type and its security settings, you may also need to enter more
information or choose a security certificate.
When your phone is connected to a wireless network, the Wi-Fi icon appears in the
status bar and tells you the approximate signal strength (number of bands that light
up).
The next time your phone connects to a previously accessed secured wireless network,
you won’t be asked to enter the key or other security information again, unless you
reset your phone to its factory default settings.
1.
2.
1.
2.
3.
4.
5.
For FCC
2011/01/24
59 Internet connections
Connecting to a Wi-Fi network with EAP-TLS security
You may need to install a network certificate (*.p12) to your phone before you can
connect to a Wi-Fi network with EAP-TLS authentication protocol.
Save the certificate file to the root folder of the storage card.
From the Home screen, press MENU, and then tap Settings.
Tap Security > Install from SD card.
Select the network certificate needed to connect to the EAP-TLS network.
Follow the steps in the previous section to connect to the Wi-Fi network.
Checking the wireless network status
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks.
On the Wireless & networks screen, tap Wi-Fi settings, and then tap the wireless
network that the phone is currently connected to.
A message box is then displayed showing the Wi-Fi network name, status, speed,
signal strength, and more.
If you want to remove the wireless network settings on your phone, tap Forget. You’ll need to
enter the settings again if you want to connect to this wireless network.
Connecting to another Wi-Fi network
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > Wi-Fi settingsWi-Fi settings. Detected Wi-Fi networks are displayed
in the Wi-Fi networks section.
To manually scan for available Wi-Fi networks, on the Wi-Fi settings screen,
press MENU and then tap Scan.
Tap another Wi-Fi network to connect to it.
Adding connection widgets
Add the Mobile Network and Wi-Fi widgets or the Data dashboard widget to the
Home screen to make it faster for you to turn on or off these connections. Tap the
widget or icon on the dashboard to turn on or off the connection.
To find out how to add widgets, see “Adding a widget” in the Personalizing chapter.
1.
2.
3.
4.
5.
1.
2.
3.
1.
2.
3.
4.
For FCC
2011/01/24
60 Internet connections
Connecting to a virtual private network (VPN)
Add, set up, and manage virtual private networks (VPNs) so you can connect and
access resources inside a secured local network, such as your corporate network.
Depending on the type of VPN you’re using at work, you may be asked to enter
your login credentials and install security certificates before you can connect to
your company’s local network. You can get this information from your network
administrator.
Also, your phone must first establish a Wi-Fi or data connection before you can start
a VPN connection. For information about setting up and using these connections on
your phone, see “Data connection” and “Wi-Fi” in this chapter.
Setting up secure credential storage
If your network administrator tells you to download and install security certificates,
you must first set up the phone’s secure credential storage.
From the Home screen, press MENU, and then tap Settings.
Tap Security > Set password.
Enter a new password for the credential storage.
Scroll down and confirm the password, and then tap OK.
Select the Use secure credentials check box.
You can then download and install the certificates needed to access your local
network. Your network administrator can tell you how to do this.
Adding a VPN connection
From the Home screen, press MENU, and then tappress MENU, and then tap Settings.
Tap Wireless & networks > VPN settings.
Tap Add VPN, and then tap the type of VPN you want to add.
Tap the VPN settings and set them up according to the security details your
network administrator gave you.
Press MENU, and then tap Save.
The VPN is then added to the VPNs section of the VPN settings screen.
Connecting to a VPN
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > VPN settings.
In the VPNs section, tap the VPN that you want to connect to.
When asked, enter your login credentials, and then tap Connect.
When you’re connected, the VPN connected icon appears in the notification
area of the status bar.
You can then open the web browser to access resources such as your corporate
network intranet.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
1.
2.
3.
4.
For FCC
2011/01/24
61 Internet connections
Disconnecting from a VPN
Press and hold the status bar, and then slide down your finger to open the
Notifications panel.
Tap the VPN connection to return to the VPN settings screen, and then tap the
VPN connection to disconnect from it.
When your phone has disconnected from the VPN, the VPN disconnected icon is
displayed in the notification area of the status bar.
Using your phone as a modem (tethering)
No Internet connection available for your computer? No problem. Use your phone’s
data connection to connect to the Internet using your computer.
You need your SIM card inserted on your phone to use the data connection. To find
out how to set up and use the data connection, see “Data connection” earlier in this
chapter.
Before you can use your phone as a modem, be sure to install HTC Sync on your
computer first. To find out how to install HTC Sync, see “Synchronizing with your
computer” in the Accounts and sync chapter.
Make sure your phone’s data connection is turned on. See “Turning the data
connection on or off” earlier in this chapter to find out how to turn on the
phone’s data connection.
Connect the phone to the computer using the provided USB cable.
On the Connect to PC screen, select USB tethering, and then tap Done.
Connecting your phone to the Internet through
a computer (Internet Pass-through)
If you don’t have a data plan for your phone or you don’t have access to a Wi-Fi
network, you can still go online on your phone by using your computer’s Internet
connection.
Before you can use your computer as a modem, be sure to install HTC Sync on your
computer first. To find out how to install HTC Sync, see “Synchronizing with your
computer” in the Accounts and sync chapter.
Make sure your computer is connected to the Internet.
Two things to check for your computer’s Internet connection. One, we recommend that you
turn off your local network’s firewall. Two, if your computer connects to the Internet via PPP
(e.g. Dial UP, xDSL, or VPN), Internet Pass-through will only support TCP protocol.
2. Connect the phone to the computer using the provided USB cable.
3. On the Connect to PC screen, select Internet Pass-through, and then tap Done.
4. On the message window, tap OK.
1.
2.
1.
2.
3.
1.
For FCC
2011/01/24
62 Internet connections
Using your phone as a wireless router
Share your data connection with other devices by turning your phone into a wireless
router. Make sure your phone’s data connection is turned on before you use it as a
wireless router. To find out how to turn on your phone’s data connection, see “Data
connection” earlier in this chapter.
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > Portable Wi-Fi hotspot settings.
The first time you open Portable Wi-Fi hotspot, a brief introduction describing the app is
displayed. Tap OK.
3. Enter a name in Router name (SSID), or use the default router name.
4. Choose the type of Security and set the Password (key) for your wireless router.
If you selected None in Security, you don’t need to enter a password.
The password is the key other people need to enter on their device so they can
connect and use your phone as a wireless router.
5. Select the Portable Wi-Fi Hotspot check box to turn on your phone’s wireless
router.
Your phone is ready to be used as a wireless router when you see on the status bar.
1.
2.
For FCC
2011/01/24
63 Bluetooth
Bluetooth
Bluetooth basics
Turning Bluetooth on or off
From the Home screen, press MENU, and then tap Settings > Wireless &
networks.
Select or clear the Bluetooth check box.
An even easier way to turn Bluetooth on or off is with the Bluetooth widget or
Bluetooth setting shortcut on the Home screen. To find out how to add widgets and
shortcuts to the Home screen, see the Personalizing chapter.
Turn off Bluetooth when not in use to save battery power, or in places where using a wireless
device is prohibited, such as on board an aircraft and in hospitals.
Changing the phone name
The phone name identifies your phone to other devices.
From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
If the Bluetooth check box is not selected, select it to turn Bluetooth on.
Tap Device name.
Enter the name for your phone in the dialog box, and then tap OK.
Connecting a Bluetooth headset or car kit
You can listen to music over a Bluetooth stereo headset, or have hands-free
conversations using a compatible Bluetooth headset or car kit. It’s the same procedure
to set up stereo audio and hands-free.
For you to listen to music with your headset or car kit, the headset or car kit
must support the A2DP Bluetooth profile.
Before you connect your headset, you need to make it discoverable so your
phone can find it. You can find out how to do this by referring to your headset
manual.
1. From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
2. If the Bluetooth check box is not selected, select it to turn Bluetooth on.
3. Make sure that the headset is discoverable.
1.
2.
1.
2.
3.
4.
For FCC
2011/01/24
64 Bluetooth
4. Tap Scan for devices. Your phone will start to scan for Bluetooth devices within
range.
5. When you see the name of your headset displayed in the Bluetooth devices
section, tap the name. Your phone then automatically tries to pair with the
headset.
6. If automatic pairing fails, enter the passcode supplied with your headset.
The pairing and connection status is displayed below the hands-free headset or car
kit name in the Bluetooth devices section. When the Bluetooth headset or car kit is
connected to your phone, the Bluetooth connected icon is displayed in the status
bar. Depending on the type of headset or car kit you have connected, you can then
start using the headset or car kit to listen to music and/or make and receive phone
calls.
Reconnecting a headset or car kit
Normally, you can easily reconnect your headset by switching on Bluetooth on your
phone, and then turning on the headset. However, you might have to connect manually
if your headset has been used with another Bluetooth device.
From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
If the Bluetooth check box is not selected, select it to turn Bluetooth on.
Make sure that the headset is discoverable.
Tap the headset’s name in the Bluetooth devices section.
If prompted to enter a passcode, try 0000 or 1234, or consult the headset/car kit
documentation to find the passcode.
If you still cannot reconnect to the headset or car kit, follow the instructions in
“Unpairing from a Bluetooth device”, and then follow the steps under “Connecting a
Bluetooth headset or car kit.”
Disconnecting or unpairing from a Bluetooth
device
Disconnecting a Bluetooth device
From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
In the Bluetooth devices section, press and hold the device to disconnect.
Tap Disconnect.
Unpairing from a Bluetooth device
You can make your phone forget its pairing connection with another Bluetooth device.
To connect to the other device again, you may need to enter or confirm a passcode
again.
1.
2.
3.
4.
5.
1.
2.
3.
For FCC
2011/01/24
65 Bluetooth
From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
In the Bluetooth devices section, press and hold the device to unpair.
Tap Disconnect & unpair.
Or, tap Unpair if the Bluetooth device is currently not connected to your phone.
Sending information using Bluetooth
You can use Bluetooth to send information from your phone to another Bluetooth
enabled device such as a phone or notebook computer. Depending on the device youDepending on the device you
are sending to, you can send the following types of information:ou can send the following types of information:
Photos and videos
Calendar events
Contacts
Audio files
Before you begin, set the receiving device to discoverable mode. You may also need
to set it to “Receive Beams” or “Receive Files”. Refer to the device’s documentation for
instructions on receiving information over Bluetooth.
The first time you transfer information between your phone and another device, you
need to enter or confirm a security passcode. After that, your phone and the other
device are paired, and you will not need to exchange passcodes to transfer information
in the future.
1. On your phone, open the app that contains the information or file you want to
send.
2. Follow the steps for the type of item you want to send:
Captured photo
or video
After capturing, on the Camera preview screen, tap the Share
button , and then tap Bluetooth.
Photos or videos 1. On the Albums tab of the Gallery app, choose an album.
2. Tap the Share button , and then tap Bluetooth.
3. Choose the photos and videos you want to share, and then tap
Next.
Contact 1. On the All tab of the People app, press and hold a contact,
and then tap Send contact as vCard.
2. Tap the down arrow icon, and then select Bluetooth from the
displayed list.
Calendar event In Day view, Agenda view, or Week view, press and hold the event,
and then tap Share vCalendar > Bluetooth.
Music track With the track displayed on the Music app’s Now playing screen,
press MENU, and then tap Share > Bluetooth.
Voice recording On the main Voice Recorder screen, tap the Share button , and
then tap Bluetooth.
1.
2.
3.
For FCC
2011/01/24
66 Bluetooth
3. Turn on Bluetooth if you’re asked to do so.
4. If you haven’t paired with the receiving device before, tap Scan for devices.
5. Tap the name of the receiving device.
6. If prompted, accept the pairing request on your phone and the receiving device.
Also enter the same passcode on both your phone and the other device, or
confirm the auto-generated passcode.
7. On the receiving device, accept the file.
Where sent information is saved
When you send information from your phone using Bluetooth, the location where it’s
saved depends on the type of information and the receiving device.
If you send a calendar event or contact, it is normally added directly to the
corresponding app on the receiving device. For example, if you send a calendar event
to a compatible phone, the event is shown in that phone’s calendar app.
If you send another file type to a Windows computer, it is normally saved in the
Bluetooth Exchange folder within your personal document folders.
On Windows XP, the path may be:
C:\Documents and Settings\[your username]\My Documents\Bluetooth
Exchange
On Windows Vista, the path may be:
C:\Users\[your username]\Documents
On Windows 7, the path may be:
C:\Users\[your username]\My Documents\Bluetooth Exchange Folder
If you send a file to another device, the saved location may depend on the file type.
For example, if you send an image file to another mobile phone, it may be saved in a
folder named “Images.”
Receiving information using Bluetooth
Your phone is capable of receiving a wide variety of file types with Bluetooth,
including photos, music tracks, and documents such as PDFs.
The first time you transfer information between your phone and another device, you
need to enter or confirm a security passcode. After that, your phone and the other
device are paired, and you will not need to exchange passcodes to transfer information
in the future.
To receive files using Bluetooth, you need to have a microSD card on your phone.
From the Home screen, press MENU, and then tap Settings > Wireless &
networks > Bluetooth settings.
If the Bluetooth check box is not selected, select it to turn Bluetooth on.
Select the Discoverable check box.
On the sending device, send one or more files to your phone. Refer to the
device’s documentation for instructions on sending information over Bluetooth.
1.
2.
3.
4.
For FCC
2011/01/24
67 Bluetooth
5. If prompted, accept the pairing request on your phone and the receiving device.
Also enter the same passcode on both your phone and the other device, or
confirm the auto-generated passcode.
A Bluetooth authorization request is then displayed on your phone.
6. If you want to automatically receive files from the sending device in the future,
select the Always check box.
7. Tap Accept or OK.
8. When your phone receives a file transfer request notification, slide down the
Notifications panel, tap the incoming file notification, and then tap Accept.
9. When a file is transferred, a notification is displayed. To open the file immediately,
slide down the Notifications panel, and then tap the relevant notification.
When you open a received file, what happens next depends on the file type:
Media files and documents are usually opened directly in a compatible app.
For example, if you open a music track, it starts playing in the Music app.
For a vCalendar file, choose the calendar where you want to save the event,
and then tap Import. The vCalendar is added to your Calendar events. For
information on using Calendar, see the Calendar chapter.
For a vCard contact file, if there are multiple vCard files on your storage
card, you can choose to import one, several, or all of those contacts to your
contacts list.
Adding the Bluetooth received folder to the Home screen
You can add a folder to the Home screen that shows all files you have received with
Bluetooth.
From the Home screen, tap .
On the Personalize screen, tap Folder > Bluetooth received.
Press and hold the Bluetooth received folder icon, and drag it to the Home
screen position you want.
To view the folder contents, tap the folder icon. To open a file, tap the file name.
1.
2.
3.
For FCC
2011/01/24
68 Security
Security
Protecting your SIM card with a PIN
Add another layer of security for your phone by assigning a PIN (personal
identification number).
Make sure you have the default SIM PIN provided by your mobile operator before
continuing.
From the Home screen, press MENU, and then tap Settings > Security.
Tap Set up SIM card lock, then select Lock SIM card.
Enter the default SIM card PIN, and then tap OK.
To change the SIM card PIN, tap Change SIM PIN.
Emergency calls can be placed at any time without requiring a PIN. See “Making an
emergency call” in the Phone calls chapter for more details.
Restoring a SIM card that has been locked out
If you enter the wrong PIN more times than the maximum number of attempts
allowed, your SIM card will become “PUK-locked.” You need a PUK code to restore
access to the phone. This code may have been provided by your mobile operator
when you received your SIM card.
On the Phone dialer screen, enter the PUK code, and then tap Next.
Enter the new PIN you want to use, and then tap Next.
Enter the new PIN again, and then tap Next.
1.
2.
3.
4.
1.
2.
3.
For FCC
2011/01/24
69 Security
Protecting your phone with a screen lock
Protect your personal information and prevent others from using your phone without
your permission by setting a screen lock password, a PIN, or a lock pattern.
Your screen lock will be asked every time your phone is turned on or when it’s idle for
a certain period of time.
From the Home screen, press MENU, and then tap Settings > Security.
Tap Set up screen lock.
Tap one of the following:
None Disable the screen lock you’ve previously created.
Pattern Set a screen lock pattern by following the onscreen instructions.
PIN Set a numeric password of at least four digits.
Password Set an alpha-numeric password.
4. On the Security screen, tap Lock phone after, then specify the idle time you can
allow before the screen is locked.
You can also clear the Use visible pattern or Visible passwords on the Security screen if you
don’t want your screen lock to display as you enter it onscreen.
Changing your screen lock
From the Home screen, press MENU, and then tap Settings > Security.
Tap Change screen lock.
Enter your current screen lock to confirm that you want to change it.
Choose a different screen lock type, then enter your new pattern, PIN, or
password.
Or tap None if you don’t want to use a screen lock.
Forgot your screen lock pattern?
If you’ve forgotten your screen lock pattern, you have up to five attempts to try and
unlock your phone. If this fails, you can unlock your phone by entering your Google
Account user name and password.
On the unlock screen, enter your lock pattern.
After the fifth attempt and you’re asked to wait for 30 seconds, tap OK.
If the display goes off, press the POWER button to turn the display back on, and
then press the bar on the lock screen and slide your finger down to unlock the
screen.
Tap the Forgot pattern? button in the lower right corner when it appears.
Enter your Google Account name and password, and then tap Sign in.
You’ll then be asked to create a new screen lock pattern. If you no longer want to do
so, tap Cancel.
1.
2.
3.
1.
2.
3.
4.
1.
2.
3.
4.
5.
For FCC
2011/01/24
70 Settings
Settings
Settings on your phone
Control and customize phone settings on the Settings screen.
From the Home screen, press MENU, and then tap Settings.
Personalize Choose a scene, set the Home screen wallpaper to use, apply a
skin, and set sound options.
Wireless & networks Set up your phone’s wireless connections, such as Wi-Fi and
Bluetooth, enable the Airplane mode, or set the options for
mobile networks, roaming, Wi-Fi hotspot, Virtual Private
Networks, and more.
Call Set up call services such as voicemail, call forwarding, call
waiting, and caller ID.
Sound Choose sounds to use for your phone ringtone and
notifications.
Adjust media playback volume. See “Adjusting the volume”
in the Getting started chapter.
Set to lower the ring volume when you move the phone
when it’s ringing, make the phone ring louder when inside a
bag or pocket, and turn on the speakerphone when you flip
over the phone.
Display Set up display settings such as automatic screen orientation,
brightness, screen timeout, and more.
Accounts & sync Log in or out of your social network accounts, Google Account,
Exchange ActiveSync account, and HTCSense.com acount. You
can also manage synchronization and other settings for your
accounts. See the Accounts and sync chapter for details.
Location Select the sources to use when determining your location.
Select Phone finder so you can use HTCSense.com to locate
your phone.
Search Select items to include when you do a search on your phone
and set Google search options.
Privacy Choose to automatically back up some settings on the phone
(e.g. Wi-Fi passwords or Bookmarks) to Google servers using
your Google Account so you can restore them when needed.
Connect to PC Set the default USB connection type to use whenever you
connect your phone to your computer.
Or, select the Ask me check box to set your phone to always
display the screen for selecting the USB connection type. To
find out more, see “Connecting your phone to a computer”
in the Getting started chapter.
Security Set a screen lock, enable the SIM card lock, or manage the
phone’s credential storage. See the Security chapter for details.
For FCC
2011/01/24
71 Settings
Dock If you purchased the car kit, choose the behavior when you
mount your phone to the car kit.
Power Turn on power saver to automatically switch to power saving
mode when the battery level goes down to the level that you
set. See “Optimizing your phone’s battery life” in this chapter
for details.
Applications Manage running applications, move applications to or from the
storage card, and install or uninstall programs.
SD & phone storage Check the available storage card and phone memory.
From this screen, be sure to unmount your microSD card
before you remove it from your phone.
You can also do a factory reset. See the Update and reset
chapter for more details.
Date & time Set the date and time, time zone, and date or time format. To
turn off auto time synchronization and be able to manually
change time zone settings, see “Setting the time zone, date,
and time” in the Clock and weather chapter.
Language & keyboard Set the operating system language and region. You can also set
onscreen keyboard options.
Accessibility Use these settings when you’ve downloaded and installed an
accessibility tool, such as a screen reader that provides voice
feedback. You can turn accessibility functions or services on or
off.
Voice input & output Set up the voice input options of your phone. Also, if you’ve
installed a text-to-speech (voice data) app, use this to set the
text-to-speech settings.
About phone Turn on or off scheduled checks for system software
updates, or manually check for updates.
Turn Tell HTC on or off. When enabled, you’re helping us
know if your phone encounters a technical problem.
View different information about your phone, such as the
mobile network type, signal strength, battery level, battery
use of individual applications, software version of your
phone, and more. See “Checking information about your
phone” in this chapter.
Changing display settings
Adjusting the screen brightness manually
From the Home screen, press MENU, and then tap Settings.
Tap Display > Brightness.
Clear the Automatic brightness check box.
Drag the brightness slider to the left to decrease or to the right to increase the
screen brightness. Tap OK.
1.
2.
3.
4.
For FCC
2011/01/24
72 Settings
Adjusting the time before the screen turns off
After a period of inactivity, the phone screen turns off to conserve battery power. You
can set the idle time before the screen turns off.
From the Home screen, press MENU, and then tap Settings.
Tap Display > Screen timeout.
Tap the time before the screen turns off.
Turning automatic screen rotation off
By default, the screen orientation automatically adjusts depending on how you hold
the phone.
Automatic rotation is not supported in all application screens.
From the Home screen, press MENU, and then tap Settings .
Tap Display, and then clear the Auto-rotate screen check box.
Recalibrating the G-sensor
Recalibrate the screen if you feel that the screen orientation does not respond
properly to the way you hold the phone.
From the Home screen, press MENU, and then tap Settings.
Tap Display > G-Sensor calibration.
Place the phone on a flat and level surface, and then tap Calibrate.
After the recalibration process, tap OK.
Keeping the screen on while charging the phone
You can keep the phone screen from turning off while you’re charging the phone.
From the Home screen, press MENU, and then tap Settings.
Tap Applications > Development.
Select the Stay awake check box.
Switching animation effects on or off
You can turn off the animation or enable only some animations when switching
between screens.
From the Home screen, press MENU, and then tap Settings.
Tap Display > Animation.
On the options menu, select the animation setting you want.
1.
2.
3.
1.
2.
1.
2.
3.
4.
1.
2.
3.
1.
2.
3.
For FCC
2011/01/24
73 Settings
Changing sound settings
Switching between silent, vibration, and normal modes
To change back from silent to normal mode, simply press the VOLUME UP
button.
To change back from vibration to normal mode, press the VOLUME UP button
twice.
From the Home screen, press MENU, and then tap Settings > Sound > Sound
profile.
You can also add the Profile widget to your Home screen. To find out how
to add a widget, see “Personalizing your Home screen with widgets” in the
Personalizing chapter.
Enabling or disabling audible selection
You can choose to play a sound when you’re selecting items onscreen.
From the Home screen, press MENU, and then tap Settings.
Tap Sound, and then select the Audible selection check box.
Turning on or off automatic ring volume adjustment
Quiet ring on pickup
Your phone has a quiet ring feature that automatically lowers the ring volume when
you move your phone.
From the Home screen, press MENU, and then tap Settings.
Tap Sound, and then select or clear the Quiet ring on pickup check box.
Turning on Pocket mode
To help avoid missing incoming calls when your phone is in your pocket or bag, the
pocket mode feature gradually increases the ring volume and vibrates when you
receive a call. When not in your pocket or bag, the phone will ring at the normal
volume you set.
From the Home screen, press MENU, and then tap Settings.
Tap Sound, and then select or clear the Pocket mode check box.
Switching to speakerphone automatically
You can switch to speakerphone by simply flipping over your phone.
From the Home screen, press MENU, and then tap Settings.
Tap Sound, and then select or clear the Flip for speaker check box.
1.
2.
1.
2.
1.
2.
1.
2.
For FCC
2011/01/24
74 Settings
Changing the phone language
When you turn your phone on for the first time, you’re asked to choose the language
you want to use for your phone. If you want, you can still change the phone language
after you set up your phone. Changing the language adjusts the keyboard layout, date
and time formatting, and more.
The languages available to choose from may depend on the version of phone you
have.
From the Home screen, press MENU, and then tap Settings.
Tap Language & keyboard > Select language.
Tap the language and corresponding region you want to use.
Press HOME to return to the Home screen. You may need to wait a few seconds
for the new language to be applied.
Optimizing your phone’s battery life
You can set the phone to automatically switch to power saving mode when the
battery level reaches a certain level.
From the Home screen, press MENU, and then tap Settings.
Tap Power.
Select the Enable power saver check box.
Tap Turn power saver on at, and then select when to switch to power saver
mode.
In the Power saver settings section, set and select the phone behavior when the
phone switches to power saving mode.
Using the GSM network of your mobile operator
Switch to using the GSM network of your mobile operator if you’re not using a data
connection to connect to the Internet. Connecting to your mobile operator’s GSM
network consumes less battery power.
From the Home screen, press MENU, and then tap Settings.
Tap Wireless & networks > Mobile networks > Network Mode.
Tap GSM only.
Checking the power usage of applications
From the Home screen, press MENU, and then tap Settings.
Tap About phone > Battery > Battery use.
1.
2.
3.
4.
1.
2.
3.
4.
5.
1.
2.
3.
1.
2.
For FCC
2011/01/24
75 Settings
Managing memory
Checking how much phone memory is available for use
From the Home screen, press MENU, and then tap Settings.
Tap SD & phone storage. The available phone memory is displayed in the Internal
phone storage section.
Checking the available storage card space
From the Home screen, press MENU, and then tap Settings.
Tap SD & phone storage. The total and available storage card space is displayed
in the SD card section.
Clearing application cache and data
From the Home screen, press MENU, and then tap Settings.
Tap Applications > Manage applications.
On the Manage applications screen, switch to the Running tab, and then tap the
application whose cache and/or data you want to delete.
4. In the Application info screen, tap Clear data and/or Clear cache.
Uninstalling third-party applications
You cannot uninstall applications that are preinstalled on the phone.
From the Home screen, press MENU, and then tap Settings.
Tap Applications > Manage applications.
On the Downloaded tab, tap the application you want to uninstall.
On the Application info screen, tap Uninstall.
Moving applications to or from the storage card
Move applications that you’ve downloaded to the phone to the storage card if your
phone’s memory is getting low. Or, if your storage card is getting full, you can also
move applications that are on your storage card to the phone.
You can only move applications that are not preinstalled on your phone.
From the Home screen, press MENU, and then tap Settings.
Tap Applications > Manage applications.
On the Downloaded tab, tap the application you want to move.
On the Application info screen, tap Move to SD card or Move to phone.
1.
2.
1.
2.
1.
2.
3.
1.
2.
3.
4.
1.
2.
3.
4.
For FCC
2011/01/24
76 Settings
Checking information about your phone
From the Home screen, press MENU, and then tap Settings.
Tap About phone.
Select one of the following:
System software updates Enable or disable the automatic check feature for software
updates for your phone. You can also tap Check now to
manually check for software updates.
Tell HTC Turn Tell HTC on or off. When enabled, you’re helping us
know if your phone encounters a technical problem.
You can also choose when you want to send error reports.
Network Check information about your mobile operator and its
service status.
Phone identity Check information about your phone and the SIM card
you’re using.
Battery Check information about the battery such as its current
battery level, status, and what programs are using the
battery.
Hardware information Check the Wi-Fi MAC and Bluetooth addresses.
Software information Check the version and other information about the
Android platform being used by the phone. You can also
check the version of the web browser.
Legal information Read legal information from HTC and Google, and licenses
used by the phone.
1.
2.
3.
For FCC
2011/01/24
77 Update and reset
Update and reset
Updating the phone software
From time to time, software updates for your phone may be available. Your phone can
check and then notify you if there’s a new update. You can then download and install
the software update using your phone’s Wi-Fi or data connection.
Checking and downloading phone software updates may incur additional data transfer fees
from your mobile operator.
Make sure your phone has a microSD card inserted. The update will be downloaded to the
microSD card.
Depending on the type of update, the update may erase all your personal data and
customized settings, and also remove any applications you’ve installed. Make sure that
you’ve backed up the information and files you want to keep.
When there is an update available, the Install system software update dialog
box will appear onscreen. Select Install now and then tap OK.
If you’re in the middle of a call and there’s an update available, you’ll receive
an update notification. After you end the call, slide open the Notifications
panel (see “Opening the Notifications panel” in the Getting started chapter).
Then tap the update notification to download and install the software update.
Wait for the update process to finish. When the update is finished, the phone will
automatically reset.
Checking for phone system software updates manually
From the Home screen, press MENU, and then tap Settings.
Tap About phone > System software updates.
On the System software updates screen, tap Check now.
1.
2.
3.
For FCC
2011/01/24
78 Update and reset
Restarting or factory resetting your phone
Restarting your phone (soft reset)
If your phone is running slower than normal, an application is not performing properly,
or your phone becomes unresponsive, try restarting your phone and see if that helps
solve the problem.
If the display is off, press the POWER button to turn it back on.
Unlock your phone if the Lock screen is displayed. See “Unlocking the screen” in
the Getting started chapter.
Press and hold the POWER button, and then tap Restart.
When asked to confirm, tap Restart.
If you can’t restart the phone following the above steps, remove the battery, wait for a
few seconds, reinsert the battery, and then turn the phone on.
Performing a factory reset (hard reset)
If you’re passing your phone on to someone else or your phone has a persistent
problem that cannot be solved, you can do a factory reset (also called a hard reset).
This returns your phone to the state it was in before the first time you turned it on.
Factory reset will not erase the data and files that are on the storage card.
Factory reset is not a step to be taken lightly. It’ll permanently delete all your data
and customized settings, and will remove any applications you’ve downloaded and
installed. Be sure to back up any data and files you want to keep before you do a
factory reset.
Performing a factory reset via settings
From the Home screen, press MENU, and then tap Settings.
Tap SD & phone storage > Factory data reset.
On the Factory data reset screen, tap Reset phone, and then tap Erase
everything.
Performing a factory reset using phone buttons
If you can’t turn on your phone or access the phone settings, you can still perform a
factory reset by using the buttons on the phone.
Remove the battery, wait for a few seconds, then reinsert the battery.
Press and hold the VOLUME DOWN button, and then briefly press the POWER
button.
Wait for the screen with the three Android images to appear, and then release
the VOLUME DOWN button.
Press VOLUME DOWN to select FACTORY RESET, and then press the POWER
button.
1.
2.
3.
4.
1.
2.
3.
1.
2.
3.
4.
For FCC
2011/01/24
