Users Manual 2
65 People
Adding People widgets
Stay in touch with different circles of friends or colleagues in your life. Using the
People widget, you can instantly place a call, send a message, view details of a favorite
contact, and even check Facebook and Twitter updates. You can add several People
widgets on the Home screen, with a different group of contacts on each widget.
From the Home screen, tap > Widget > People.
Choose the widget style, and then tap Select.
Select the group you want to add as a widget.
Drag the widget to a blank space on a Home screen. When the widget is where
you want it, lift your finger.
5. Repeat the above steps to add another People widget.
Setting the default communication method
On the Home screen, go to the People widget.
Tap a contact on the widget.
On the Select default action screen, tap the communication method you want
for the contact.
Changing the default communication method
On the Home screen, go to the People widget.
Tap the name of a contact on the widget to open the person’s contact card.
Press , and then tap More > Set default action.
On the Select default action screen, tap the communication method you want
for the contact.
1.
2.
3.
4.
1.
2.
3.
1.
2.
3.
4.
HTC Confidential
66 People
Getting in touch with a contact
On the Home screen, go to the People widget.
Tap a contact (photo not the name) on the widget. The default communication
method will be performed.
Tap the name of the contact to open the contact details screen for that contact.
1.
2.
HTC Confidential
67 Email
Email
Gmail
Using Gmail
When you first set up your phone, make sure you sign into your Google Account to
use Gmail. If you didn’t do so, go to the Accounts & sync setting to sign in.
You can also set up more than one Google Account on your phone, and then switch
between accounts in Gmail.
Viewing your Gmail Inbox
All your received emails are delivered to your Inbox.
From the Home screen, tap > Gmail. Your Gmail inbox then opens.
Archive or
delete multiple
conversations
Tap before the email or conversation.
Then tap the onscreen buttons at the bottom
to choose what to do with the selected
messages or conversations.
Display drafts,
sent messages,
and other labels
Tap Inbox at the top left of the screen, and
then tap another label (such as Sent, Drafts,
or your created label) to view its messages
and conversations.
Switch to your
other Gmail
account
Tap the current account at the top right of
the screen, and then tap another account
you want to switch to.
Refresh the Inbox Press , and then tap Refresh.
Sending a new message
1. In the Gmail inbox, press and then tap Compose.
2. If you’ve set up multiple Google Accounts on your phone, choose which Gmail
address you want to use for sending your email. Tap the box that shows your
current Gmail address, and then tap another address that you want to use for
sending.
3. Enter the message recipient’s email address in the To field. If you are sending the
email to several recipients, separate the email addresses with a comma.
If you want to send a carbon copy (Cc) or a blind carbon copy (Bcc) of the email to other
recipients, press and then tap Add Cc/Bcc.
4. Enter the email subject, and then compose your email.
HTC Confidential
68 Email
5. If you want to attach a picture, press and then tap Attach.
6. Locate and then tap the picture you want to attach.
7. After composing your message, tap .
While composing the message, tap to save it as a draft. Or press to discard the
message.
Replying to or forwarding an email message
1. In the Gmail inbox, tap the email message or conversation.
2. To reply to the sender, tap . Or, tap and choose whether to Reply all or
Forward.
3. Do one of the following:
If you selected Reply or Reply all, enter your reply message.
If you selected Forward, specify the message recipients.
Tap Respond inline if you want to interleave your new message with the received email. But
this removes any attachments or formatting in the original email.
4. Tap .
Getting help
To find out more about using Gmail, press , and then tap More > Help. The web
browser will take you to the Google Mobile Help site.
HTC Confidential
69 Email
Mail
About the Mail app
Use the Mail app to add your webmail and other POP3 or IMAP email accounts. You
can also set up and use your Exchange ActiveSync email on your phone.
You can add the Mail widget to view your POP3/IMAP or Exchange ActiveSync emails on the
Home screen.
Adding a POP3/IMAP email account
From the Home screen, tap > Mail.
Do one of the following:
If this is your first time to add an email account in Mail, tap Other (POP3/
IMAP) on the Choose a mail provider screen.
If you’ve already added an email account in Mail, press , and then tap
More > New account. If the Choose a mail provider screen is displayed, tap
Other (POP3/IMAP).
3. Enter the email address and password for your email account and then tap Next.
4. If the account type you want to set up is not in the phone database, you’ll be
asked to enter more details.
5. Enter the account name and your name and then tap Finish setup.
Adding a Microsoft Exchange ActiveSync account
You can add one or more Microsoft Exchange ActiveSync accounts on your phone.
You can sync with Microsoft Exchange Server 2003 Service Pack 2 (SP2) or later.
You can add up to 15 Exchange ActiveSync accounts on your phone.
From the Home screen, tap > Mail.
Do one of the following:
If this is your first time to add an email account in Mail, tap Microsoft
Exchange ActiveSync on the Choose a mail provider screen.
If you’ve already added an email account in Mail, press , and then tap
More > New account. If the Choose a mail provider screen is displayed, tap
Microsoft Exchange ActiveSync.
3. Enter the Exchange ActiveSync account details, and then tap Next. Your
corporate Exchange Server must support auto-detect for the phone to
automatically set up the Exchange ActiveSync account. If your corporate
Exchange Server does not support auto-detect, you’ll need to enter your
Exchange Server settings after you tap Next. Ask your Exchange Server
administrator for details.
1.
2.
1.
2.
HTC Confidential
70 Email
4. Choose the types of information you want to sync. Also choose how often you
want to update and sync email to your phone, then tap Next.
5. Enter the account name, then tap Finish setup.
Checking your Mail inbox
When you open the Mail app, it displays the inbox of one of your email accounts that
you’ve set up on your phone.
To switch between email accounts, tap the bar that shows the current email account,
and then tap another account.
Viewing the unified inbox of all your email accounts
You can view email messages from all your accounts just in one place without having
to switch to different accounts.
Just tap the bar that shows the current email account, and then tap All accounts.
Email messages are color coded so you can easily distinguish which email accounts
they belong to.
Up to 15 email accounts can be shown in the unified inbox.
Switching between different views of your inbox
If you have lots of email messages, it may take you some time to browse through the
long list and find a single email or related email messages. Use the tabs of the Mail app
to sort your emails into different categories.
To skim through your email messages easier, tap one of the following tabs to change
the view of your inbox:
Inbox
Displays email messages as individual items.
Conversations
Displays email messages as conversations, grouped according to the subject line. Tap
a subject in the list to show the email conversation.
HTC Confidential
71 Email
Group
Displays all email messages from a contact group. To choose which contact group to
display, press , tap View, and then select a group.
Unread
Displays unread messages.
Marked (Exchange ActiveSync only)
Displays all flagged messages.
Invites (Exchange ActiveSync only)
Displays meeting invitations which you have not yet accepted or declined.
Attachments
Displays all messages that have attachments.
Refreshing an email account
Whatever your automatic synchronization settings are, you can also synchronize your
sent and received emails manually at any time.
While in the account you want to synchronize, press , and then tap Refresh.
If you have several email accounts, you can refresh them all at the same time. Go
to the unified inbox first. Then press and tap Refresh.
Sorting email messages
You can sort email messages by date received, priority, subject, sender, or size.
On the inbox, press , tap Sort, and select from the sorting options.
Quickly browsing your inbox
If you have a long list of email messages in your inbox, it may not be easy to browse
the list and find an email that you want. You can quickly browse through your inbox by
using finger gestures.
Choose a sorting order for displaying your email messages.
Press and hold two fingers on any email message, and then drag upward or
downward without lifting your fingers. Your screen then jumps to the set of email
messages based on your chosen sorting order.
Managing email messages
Deleting an email message
On the inbox, press and hold the message you want to delete.
On the options menu, tap Delete.
Selecting several email messages
Tap the check boxes of email messages to select them.
Choose what you want to do with the selected messages: Mark unread, Delete,
or Move to another folder.
You cannot move email messages when you’re in the unified (All accounts) inbox.
1.
2.
1.
2.
1.
2.
HTC Confidential
72 Email
Moving several email messages to another folder
Switch to the email account you want to use.
Tap the check boxes of email messages you want to move.
Tap Move to, and then tap the folder where to move the email messages.
Moving an email message after reading
In the open message, press , and then tap More > Move to.
Tap the folder where you want to move the email message.
Deleting all messages
First tap the check box of any email message.
Press , and then tap Select all.
Tap Delete.
Switching to other mail folders
Press , and then tap Folders.
Tap the mail folder whose messages you want to view.
Sending an email message
From the Home screen, tap > Mail.
Switch to the email account that you want to use for sending email.
On the email account inbox, tap Compose mail.
Fill in one or more recipients. You can:
Enter email addresses directly in the To field, separating them with a
comma. As you enter email addresses, any matching addresses from your
contacts list are displayed. Tap a match to enter that address directly.
Tap the icon, and then choose the contacts to whom you want to send
the message. You can also select contact groups as recipients, or search and
add contacts from the company directory if you have set up an Exchange
ActiveSync account on your phone.
If you want to send a carbon copy (Cc) or a blind carbon copy (Bcc) of the email to other
recipients, press , and then tap Show Cc/Bcc.
5. Enter the subject, and then compose your message.
6. To add an attachment, press , tap Attach, and choose from the following
options:
Picture Select Camera to take a photo and attach it, or Gallery to attach a
photo from your storage card.
Video Select Camcorder to capture a video and attach it, or Videos to
attach a video from your storage card.
Audio Select Voice Recorder to make a voice recording and attach it, or
Files to attach a music file or voice recording from your storage card.
1.
2.
3.
1.
2.
1.
2.
3.
1.
2.
1.
2.
3.
4.
HTC Confidential
73 Email
App
recommendation
Choose an app you’ve installed from Android Market that you want
to tell other people about. The URL from which the app can be
downloaded will be inserted in your email.
Location You can attach location information. Send your current location
(requires GPS to be turned on) or a location you pick on a map.
Document Attach a PDF file or an Office document such as a text file or a
spreadsheet.
Contact (vCard) Attach someone’s contact information.
Appointment
(vCalendar)
Attach a calendar event.
File Attach any file from your storage card.
7. Tap Send to send the message immediately, or tap Save as draft to send it later.
If there’s no Wi-Fi or data connection available or Airplane mode is on when you send your
email, the email will be saved to the Outbox folder. Once there’s Wi-Fi or data connection
available, the saved email will be sent automatically next time your phone syncs.
Resuming a draft email message
In the email account inbox, press , and then tap Folders > Drafts.
Tap the message.
When you finish editing the message, tap Send.
Reading and replying to an email message
From the Home screen, tap > Mail.
Switch to the email account you want to use.
On the email account inbox, tap the email you want to read.
Do any of the following:
Reply to the message Tap Reply or Reply all.
Forward the message Press , and then tap More > Forward.
Delete the message Press , and then tap Delete.
Mark the message as unread Press , and then tap Mark unread.
Setting the priority for an email message
You can set the priority for an email message that you send.
While composing the message, press .
Tap Set priority.
Select the priority for the message.
If you selected High or Low priority, the priority appears below the subject line of the
message.
1.
2.
3.
1.
2.
3.
4.
1.
2.
3.
HTC Confidential
74 Email
Working with Exchange ActiveSync email
If you sync your phone with your work Exchange ActiveSync account, you can read,
reply, send, and manage email in the same easy way as with a POP3/IMAP account. In
addition, you can also use some powerful Exchange features.
Flagging an email
While viewing the inbox, tap the white flag icon that appears on the right of
an email message. The icon turns red after you flagged the email.
While reading an email, you can also tap the flag icon in the email.
Setting your Out of the office status
You can set your Out of office status and auto-reply message right from your phone.
Switch to your Exchange ActiveSync account.
Press and then tap More > Out of the office.
Tap the box, and then select Out of the office.
Set the dates and times for the period when you will be out of the office.
Enter the auto-reply message.
Tap Save.
Sending a meeting request
Switch to your Exchange ActiveSync account.
Go to the Invites tab, and then tap New meeting invitation.
Enter the meeting details.
Tap Send.
Changing email account settings
Switch to the email account whose settings you want to change.
Press , and then tap More > Settings.
Select from the following:
Account settings Change the email account settings such as the name, email
address, password, and description.
General settings Set the font size when reading emails, enable, disable or set the
signature, set the account as the default email account, and set
where to save email attachments.
Send & Receive Set the sync settings for incoming and outgoing emails such as
maximum size limit, update schedule, and more.
Notification settings Set email notification settings.
Delete account Tap to delete the email account.
4. Press to save your changes.
Deleting an email account
Switch to the email account you want to delete.
Press , and then tap More > Settings > Delete account.
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.
1.
2.
3.
1.
2.
HTC Confidential
75 Calendar
Calendar
About Calendar
Never miss an important date again. Use the Calendar app to schedule your events,
meetings, and appointments.
You can set up your phone to stay in sync with the following types of calendars:
On your phone, sign in to your Google Account so you’ll be able to sync the
Calendar app with your Google Calendar online. You can add multiple Google
Accounts.
If you’re using Microsoft Outlook® on your computer, you can set up HTC Sync
on your computer to sync Outlook Calendar with the Calendar app.
If you have a Microsoft Exchange ActiveSync account and you have added it
on your phone, you can sync the Calendar app with your Exchange ActiveSync
calendar events.
If you’ve signed in to your social network accounts such as Facebook, birthdays and
events of friends will appear in Calendar.
Creating an event
You can create events that sync with your Google Calendar, your computer’s Outlook
Calendar, or Exchange ActiveSync calendar, as well as events that appear on your
phone only.
1. From the Home screen, tap > Calendar.
2. On any Calendar view, press , and then tap New event.
When you are in the month or agenda view, you can also tap to create a new event.
3. If you have more than one calendar, select a calendar in which to add the event:
Select your Google Account to create a Google Calendar event. If you have
several Google calendars on the Web, select one in which to add your event.
Select PC Sync to create calendar events on your phone. You can sync them
with your computer’s Outlook Calendar using HTC Sync.
Select your Exchange ActiveSync account to create an Exchange
ActiveSync calendar event.
4. Enter a name for the event.
HTC Confidential
76 Calendar
5. To specify the date and time of the event, do one of the following:
If there is a time frame for the event, tap the From and To date and time to
set them.
If it is a whole-day event, such as a birthday, set the From and To date, then
select the All day check box.
6. Enter the event location and description.
7. Set the reminder time.
You can add another reminder time in a Google Calendar event. Press and then tap Add
reminder.
8. If the event occurs on a regular basis, tap the Repetition box and then choose
how often the event occurs.
9. Tap Save.
Inviting guests to your event (Google Calendar only)
After you invite guests to your event, an invitation email will be sent using your Google
Account.
If you want to invite guests to your event, you need to create and add the event in
your Google Calendar.
1. Open Calendar and create a new event. Tap the Calendar field and then select
your Google Account (or one of your other Google Calendars).
2. Add details about the event, such as date and time, location, and more.
3. In the Guests field, enter the email addresses of everyone you want to invite to
the event. Separate multiple addresses with commas (,). If the people to whom
you send invitations use Google Calendar, they’ll receive an invitation in Calendar
and by email.
4. Tap Save to add the event to your Google Calendar.
Sending a meeting request using Calendar (Exchange ActiveSync only)
If you have an Exchange ActiveSync account set up on your phone, you can use
Calendar to create a meeting appointment and send a meeting request email to the
people you want to invite to your meeting.
1. Open Calendar and create a new event. Tap the Calendar field and then select
your Exchange ActiveSync account.
2. Add details about the meeting, such as date and time, location, and more.
3. Press and then tap Meeting invitation.
4. Tap and choose attendees from your contacts or the company directory.
5. Enter your message and then tap Send.
HTC Confidential
77 Calendar
Changing Calendar viewsCalendar views views
When you open Calendar, it displays the month view by default. You can also use
agenda, day, or week view. To change between views, press , and then choose the
type of view that you want.
Using month view
In Month view, you’ll see markers on days that have events.
Do any of the following in month view:
Tap on the bottom left of the screen to switch to agenda view. Tap on
the bottom right to create a new event.
Tap a day to view the events for that day.
Press and hold a day to open an options menu from which you can also
choose to create an event or switch to either day or agenda view.
Slide your finger up or down the screen to view earlier or later months.
Using day and agenda views
Day view displays a list of the events of one day and also shows weather information
at the bottom of the screen when you’re viewing events of the current day.
In day view, the weather information appears only if the event is within the fiveday forecast
of the Weather app.
Weather information does not appear in day view when you change day view to display as a
time list.
Agenda view shows a list of all your events in chronological order.
The colored bars on the left side of the events indicate the type of calendar the
event is part of. To find out what each color represents, press and then tap
More > Calendars.
When in day view, slide left or right across the screen to view earlier or later
days.
Using week view
Week view displays a chart of the events of one week.
When in week view, you can:
Press and hold on a time slot to create a new event at that time.
Tap an event (shown as colored blocks) to view its details.
Slide left or right across the screen to view earlier or later weeks.
HTC Confidential
78 Calendar
Managing Calendar events
Viewing an event
You can view your own events as well as events that other people have shared with
you.
1. In day view or agenda view, tap an event. The Event details screen then opens
and shows the summary of the event.
2. Depending on the event information, do any of the following:
Find the event’s location in Maps.
Call any phone number included in the event location or description.
Check the participants of the event.
If the event was sent as a meeting invitation, respond to the invitation.
If it’s an Exchange ActiveSync calendar event, reply by email to the
organizer or to all the guests. Press , and then either tap Reply or Reply
all.
Select any text and look it up on the Web.
Tap the reminder time to change it. Press to save changes.
Editing an event
You can edit events that you have created.
1. While viewing an event, press , and then tap Edit event.
2. Make your changes to the event.
3. When you’re done editing, tap Save.
Deleting an event
Do any of the following:
While viewing the summary of an event on the Event details screen, press
and then tap Delete event.
In day, agenda or week view, press and hold an event and then tap Delete event.
When editing an event, tap Delete.
If the event repeats, you’ll be asked whether you want to delete just that occurrence,
this and all future occurrences, or all past and future occurrences in your Calendar.
HTC Confidential
79 Calendar
Sharing an event (vCalendar)
You can share a calendar event as a vCalendar to someone’s phone using Bluetooth or
by sending it as a file attachment with your email or message.
While viewing an event, press , and then tap Share vCalendar.
Do one of the following:
Tap Bluetooth. you’ll be asked to turn on Bluetooth on your phone and
connect to the receiving Bluetooth device.
Tap Mail. A new message window opens and automatically includes the
vCalendar as an attachment. Your default email account will be used to send
the message.
Tap Message. A new message window opens and automatically includes the
vCalendar as a multimedia attachment.
Dismissing or snoozing event reminders
If you have set at least one reminder for an event, the upcoming event icon will
appear in the notifications area of the status bar to remind you of the upcoming event.
1. Tap the status bar, then slide your finger down the screen to open the
Notifications panel.
2. Do one of the following:
Tap Clear to dismiss event reminders and all other notifications. Other types
of notifications such as new messages and missed calls will also be deleted.
After sliding open the Notifications panel, tap the calendar event reminder.
You’ll then see a list of all pending event reminders. Tap Snooze all to
snooze all event reminders for five minutes, or tap Dismiss all to dismiss all
event reminders.
Press to keep the reminders pending in the notifications area of the
status bar.
1.
2.
HTC Confidential
80 Calendar
Displaying and synchronizing reminders
You can select which calendars to show or hide on your phone’s Calendar, and which
ones to keep synchronized.
Showing or hiding calendars
In any Calendar view, press , tap More > Calendars, and then select or clear a
calendar to show or hide it.
Calendars are kept synchronized on your phone, whether or not you hide them.
Tap All calendars to display all calendars.
Adding a Google calendar to sync with
You can choose which Google calendars to keep synchronized on your phone.
You cannot create a new Google calendar on your phone. You can only sync with Google
calendars that you created or subscribed to on the Web.
In any Calendar view, press and then tap More > Calendars.
Press again and then tap Add calendars.
Select a Google calendar to add to your calendars list, and then tap OK.
Press to update Calendar.
Stop synchronizing a Google calendar
You can choose which Google calendars to stop synchronizing.
In any Calendar view, press and then tap More > Calendars.
Press again and then tap Remove calendars.
Select a Google calendar to remove from your calendars list, and then tap OK.
Press to update Calendar.
The calendars that you remove from your calendars list will no longer be synchronized
on your phone, but you remain subscribed to them and can work with them in Google
Calendar on the Web.
1.
2.
3.
4.
1.
2.
3.
4.
HTC Confidential
81 Calendar
Changing Calendar settings
You can change Calendar settings to specify how it displays events and how it notifies
you of upcoming events.
In any Calendar view, press and then tap More > Settings to access the Calendar
settings.
Reminder settings
All calendars Select this check box to use the same event reminder settings
for all types of calendars. If you clear this check box, you can
set different reminder settings for each calendar.
Set alerts & notifications Configure event reminders to open an alert, send you a
notification, or turn off event notifications on your phone.
Default reminder time Choose how soon before an event you want to be notified.
Select ringtone Choose a ringtone to sound when you receive an event
reminder.
Vibrate Choose whether you want your phone to vibrate when you
receive an event notification.
Hide declined events Choose whether to show or hide events for which you’ve
declined invitations.
Calendar view settings
Start in Choose the default view to display when you open Calendar.
Day views Choose whether to display day view in the form of an event list
or time list.
First day of week Set the month and week views to start on a Sunday or Monday.
Include weather Select this check box to show weather information in the day
view events list.
City If weather is included, by default, day view displays your
current location’s weather. You can change it to display the
weather of another city.
About the Calendar widget
You can add a Calendar widget to your Home screen. The widgets offer different
calendar views.
Tapping a day or event on the widget brings you to the Calendar app.
HTC Confidential
82 Search and Web browser
Search and Web browser
Searching your phone and the web
You can search for information on your phone and on the web by using Google
Search. Some applications, such as People or Mail, have their own search box, which
you can use to search within those applications (the application’s icon is at the left of
the search box.)
Setting search options
From the Home screen, press , and then tap Settings.
Scroll down the screen, and then tap Search.
Tap Google search, and then do the following:
Select Show web suggestions if you want to include suggestions from
Google when doing a search.
Select Search history to enable personalized search history. You need
to sign in to your Google Account to use this feature. The Show web
suggestions check box needs to be selected for this option to be enabled.
4. Press .
5. Tap Searchable items, and then select the items you want included when doing a
search.
Performing searches on the web and your phone
From the Home screen, press .
Enter the search item in the search box. As you type, matching items on your
phone and suggestions from Google web search are shown as a list.
Do one of the following:
To narrow your search, tap , select another search location (for example,
Apps), and then tap .
If what you’re searching for is in the list of suggestions, tap it in the list. The
item opens in the appropriate application.
To edit an item in the list, tap . The item will appear in the search box,
where you can edit it.
If what you’re searching for is not in the list, tap to search the web. The
web browser opens, displaying the results of a Google search.
1.
2.
3.
1.
2.
3.
HTC Confidential
83 Search and Web browser
Quickly looking up information on the Web
Quick Lookup helps you learn about something right on the spot. When you enter a
new word or phrase, you can easily look it up in popular websites or search services
such as Google Search, Wikipedia, YouTube, Google Translate, and Google Dictionary.
From the Home screen, tap > Quick Lookup.
2. If the onscreen keyboard is open, press to close it first so you’ll see the
bottom tabs.
3. Slide across the tabs to pick where you want to look up information. Then in the
search box, enter what you want to search for.
4. Tap .
After looking up the item on one tab, you can slide to other tabs to automatically look up the
same term there.
Translating words to other languages
From the Home screen, tap > Quick Lookup.
2. If the onscreen keyboard is open, press to close it first so you’ll see the
bottom tabs.
3. Slide to the Google Translate tab.
4. Under From language, choose the original language, then enter the word or
phrase you want to translate.
5. Under To language, choose from the languages available for translation.
6. Tap Translate.
Using your phone’s web browser
You must have an active data connection or Wi-Fi connection to access the Internet.
Do one of the following to open the web browser and start surfing the Web:
On the Home screen, tap Internet.
From the Home screen, tap > Internet.
1.
1.
HTC Confidential
84 Search and Web browser
Going to a webpage
From the browser screen, press and then tap the URL field on top of the
screen.
2. Enter the webpage address using the keyboard. As you enter the address,
matching webpage addresses will appear on the screen.
3. Do one of the following:
Tap an address to go directly to that webpage.
Continue typing in the webpage address, then tap .
Changing the screen orientation
The phone automatically changes the screen orientation depending on how you’re
holding your phone.
Turn your phone sideways to display the web browser in landscape orientation.
If the screen orientation doesn’t change automatically, turn on automatic screen orientation.
From the Home screen, press , tap Settings > Display, and then select the Auto-rotate
screen check box.
Navigating and zooming on a webpage
You can swipe your finger on the screen to navigate and view other areas of the
webpage.
Tap the screen twice quickly to zoom in, then tap the screen twice quickly again
to zoom out. You can also use your fingers to spread or pinch the screen to
zoom in and out.
Selecting a link on a webpage
You can tap a link to open it, or press and hold a link for more options.
Link What to do
Webpage address
(URLs)
Tap the link to open the webpage.
Press and hold the link to open a menu that allows you to open,
bookmark, copy to the clipboard, or share the link.
Email address Tap to send an email message to the email address.
Press and hold, then tap Copy on the menu to copy the email
address to the clipboard. You can paste the email address later
when creating a new contact or sending a new email message.
Selecting an address or phone number on a webpage
You can map an address or call a phone number on a webpage.
Link What to do
Location address Tap the address to copy it or map it using Google Maps.
Phone number Tap the phone number to copy, call, send a text message to that
number, or save the number to a contact in People.
1.
HTC Confidential
85 Search and Web browser
Opening a new browser window
Open multiple browser windows to make it easier for you to switch from one website
to another.
While viewing a webpage, press and then tap Windows.
Tap .
A new browser window opens and goes to your set home page.
Switching between browser windows
While viewing a webpage, do one of the following:
Press and then tap Windows.
Pinch the screen (zoom out) until you see the other browser windows.
2. Select the browser window you want to view by sliding your finger on the screen
from right to left.
3. Tap a webpage to display it in full screen.
Tap to close a webpage.
1.
2.
1.
HTC Confidential
86 Search and Web browser
Downloading from the Web
Do more than just browsing the Web. You can download web files such as photos and
apps then save them on your storage card.
Downloading apps from the Web
You can download apps directly from your favorite websites. Apps downloaded from
the Web can be from unknown sources. To protect your phone and personal data, we
strongly recommend that you download and install only apps you trust.
All downloaded files will be saved to your storage card. Before downloading apps from the
Web, be sure that you have your storage card on your phone. The app you want to download
should also be compatible with your phone.
1. Open your web browser, then go to the website where you can download the
app you want.
2. Follow the website’s instructions for downloading the app.
Before you can install the downloaded app, you need to set your phone to allow
installation of third-party apps. From the Home screen, press , then tap Settings >
Applications > Unknown sources.
Viewing your downloads
While viewing a webpage, press and then tap More > Downloads.
Viewing bookmarks and previously visited
pages
You can store as many bookmarks as you want on your phone. You can also access a
convenient list of the sites you have visited, or quickly view the pages that you access
most often.
Bookmarking a webpage
While viewing a webpage, press , and then tap Add bookmark.
Edit the bookmark name if needed, and then tap Add.
Opening a bookmark
While viewing a webpage, press , and then tap Bookmarks.
On the Bookmarks tab , navigate to the bookmark you want to open, and
then tap it.
1.
2.
1.
2.
HTC Confidential
87 Search and Web browser
Editing a bookmark
While viewing a webpage, press , and then tap Bookmarks.
On the Bookmarks tab , press and then tap Edit.
Tap the bookmark you want to edit.
Enter your changes, and then tap Edit.
Viewing a previously visited page
While viewing a webpage, press , and then tap Bookmarks.
On the History tab , navigate to the page you want to view and then tap the
page.
Clearing the list of previously visited pages
While viewing a webpage, press , and then tap Bookmarks.
On the History tab , press , and then tap Clear history.
Viewing a page that you often visit
While viewing a webpage, press , and then tap Bookmarks.
On the Most visited tab , navigate to the page you want to view, and then
tap the page.
Clearing the list of most visited pages
While viewing a webpage, press , and then tap Bookmarks.
On the Most visited tab , press , and then tap Clear all.
Changing the view of bookmarks or most visited pages
While viewing a webpage, press , and then tap Bookmarks.
On the Bookmarks tab or the Most visited tab , press , and then tap
Thumbnails, List, or Grid to change the view.
For example, if you are in Thumbnails view and you want to view bookmarks in a
grid, press and tap List, then press and tap Grid.
1.
2.
3.
4.
1.
2.
1.
2.
1.
2.
1.
2.
1.
2.
HTC Confidential
88 Search and Web browser
Setting browser options
Customize the web browser to suit your browsing lifestyle. Set display, privacy, and
security options when using the web browser.
From the browser screen, press , and then tap More > Settings.
Setting your home page
From the browser screen, press , and then tap More > Settings > Set home
page.
2. Select the home page you want to use.
Browsing full versions of all websites
Some websites display a mobile version of their pages on phone web browsers. You
can choose to view the full version of all pages, even for these sites.
From the browser screen, press , tap More > Settings, and then clear the Mobile
view check box.
Choosing when to show Flash content
Choose which Flash® content you want to see on a webpage, and when you want to
view it.
1. From the browser screen, press , and then tap More > Settings > Enable
plugins.
2. Tap On demand.
After selecting On demand, you can show the Flash content by tapping on the
webpage.
1.
HTC Confidential
89 Camera
Camera
Camera basics
Whether traveling for business or fun, enjoy taking photos and videos of your trip and
encounters with your phone’s camera.
Be sure to plug in your storage card before you use your phone’s camera. Photos and videos
captured with the camera will be stored onto your storage card.
To open the camera in photo mode and take photos, tap from the Home
screen, and then tap Camera.
To open the camera directly in video mode so you can immediately start
capturing videos, tap from the Home screen, and then tap Camcorder.
Viewfinder screen
When you’re in photo mode and you turn your phone left or right, the camera
onscreen controls automatically rotate to how you hold the phone.
You’ll find the following onscreen controls on the Viewfinder screen:
Zoom bar
Auto focus indicator
Photo/Video mode switch
Flash button
Shutter release/Record button
Effects button
Gallery button
or Switch to front or main camera
button
HTC Confidential
90 Camera
Zooming
Before taking a photo or video, you can first use the onscreen zoom bar to zoom in or
out of your subject.
Simply slide your finger up or down the zoom bar to zoom in or out.
When you’re recording video, the zoom bar is always shown onscreen. You can freely
zoom in or out while recording.
Auto focusing
Whenever you point the camera at a different subject or location, it shows the auto
focus indicator at the center of the Viewfinder screen.
Let the camera auto focus on the center of the screen. Or you can tap another area on
the screen that you want to focus on.
Using the front camera
Take a picture or shoot a video of yourself using the front camera.
To switch to the front camera, on the camera screen, tap or . To switch back to
the main camera, tap or again.
Some camera features are not available when you’re using the front camera, such as auto
focusing, zooming, using flash, face detection, and HD 720P recording.
Taking a photo
1. From the Home screen, tap > Camera.
2. Before taking the photo, you can zoom in or out first on your subject.
3. Tap the flash button repeatedly to choose a flash mode depending on your
lighting conditions.
Auto flash
Flash on
Flash off
4. Choose the resolution and other camera settings you want to use.
5. Choose an effect to apply to your photo.
HTC Confidential
91 Camera
6. Point the camera and focus on your subject.
If you’re taking people’s photo, the camera will automatically recognize faces
and adjust the focus. You’ll see boxes on people’s faces.
Make sure the Auto focus and Face detection check boxes are selected in the camera settings.
7. When you’re ready to take the photo, tap .
8. Choose what you want to do with the photo you’ve just taken.
Recording video
1. From the Home screen, tap > Camcorder.
2. Choose the video quality and other camera settings you want to use. To record
video in HD, set Video quality to HD 720P (1280 x 720). Or for sharing on the
Web, select Online (HD, 10 minutes).
3. Choose an effect to apply to your video.
4. Frame your subject on the Viewfinder screen.
5. Tap to start recording.
6. You can freely zoom in or out while recording video.
7. You can change focus to a different subject or area by just tapping it on the
Viewfinder screen.
8. Tap the flash button to switch the camera light on or off during recording.
Light on
Light off
9. To stop recording, tap again.again.
10. Choose what you want to do with the video you’ve just recorded.
HTC Confidential
92 Camera
Adding effects
Want to make your photos look more interesting? Easy. Use the available camera
effects to make your photos look like they’ve been taken through special lenses and
filters. You can also add certain effects to videos.
Choose an effect first before you start taking a photo or video.
Tap .
Scroll through the available effects and tap one that you like.
When you choose certain photo effects such as depth of field, distortion, or vignette,
drag the bar that appears on the right side of the screen to adjust the intensity of the
effect.
After capturing
After capturing a photo or video, the Review screen will display the photo or the
starting image of the video that you have just captured. Tap the onscreen buttons to
choose what you want to do next.
Return to the Viewfinder screen.
Delete the photo or video.
Send the photo or video to another phone or your computer using Bluetooth,
send it by email, or select a social network where you want to upload it to.
Choose how you want to use the photo, such as to use it as your wallpaper.
Watch the video.
1.
2.
HTC Confidential
93 Camera
Changing camera settings
Open the menu panel to access and change camera settings.
To open the camera settings, press .
Some camera features are not available when you’re using the front camera, such as auto
focusing, zooming, using flash, and face detection.
Self-timer
(photo mode only)
Set a time delay before your camera automatically takes the
photo.
Image adjustments Slide your finger across each of the slider bars to adjust the
exposure, contrast, saturation, and sharpness.
White balance White balance enables the camera to capture colors more
accurately by adjusting to your current lighting environment.
Resolution/Video quality Choose a photo or video resolution to use.
ISO (photo mode only) Choose an ISO level or set it back to Auto. Higher ISO numbers
are better for taking pictures in low light conditions.
Review duration Set the time for a captured photo or video to be displayed on the
Review screen before the camera changes back to the Viewfinder
screen.
Widescreen
(photo mode only)
When this check box is selected (default), photo resolutions
available for selection are in 5:3 ratio and you can use the entire
Viewfinder screen to frame your subject. When not selected,
photo resolutions available for selection are in standard 4:3 ratio.
Geo-tag photos
(photo mode only)
Select to store GPS location in your captured photos.
Mirror mode
(front camera only)
Select to show the mirror image on the viewfinder screen.
Auto enhance
(photo mode only)
Select to reduce noise when using a high ISO setting and to
automatically adjust photo brightness.
Auto focus
(photo mode only)
Enables or disables centered auto focus.
Face detection
(photo mode only)
Select to automatically recognize faces and adjust the focus
when you take people photos. Face detection will be turned off if
you disable auto focus.
Shutter sound Select to play a sound when you press the shutter release or
record button.
Grid (photo mode only) Select to display a grid on the Viewfinder screen so you can
easily frame and center your subject before taking the photo.
Record with audio
(video mode only)
Select to record audio when capturing videos.
Reset to default Change the camera settings back to default.
HTC Confidential
94 Photos, videos, and music
Photos, videos, and music
Gallery
About the Gallery app
Relive the fun while viewing photos and videos of your latest travels or your pet’s
newest tricks. Get an audience by tagging your Facebook and Flickr friends. You can
even play your media on a TV screen.
To start using Gallery, check first if you have photos or videos copied on your storage card.
What’s more, you can edit and add effects to your photos. You can also easily use a
photo as your contact icon, location icon, or wallpaper.
Selecting an album
From the Home screen, tap > Gallery. The Gallery app opens on the Albums
screen where your photos and videos are organized by albums for easy viewing.
The following are preset albums:
Camera shots lets you view photos and videos
that are stored in the camera’s folder.
My favorites lets you group photos and videos
that you set as your favorites.
All photos lets you view all photos that are stored
in all the folders on the storage card.
All videos lets you view all videos that are stored
in all the folders on the storage card.
All downloads lets you view photos and videos
that you downloaded.
Folders in your storage card that contain photos and videos will also be treated as
albums and will be listed below the preset albums. The actual folder names will be
used as the album names.
If there are photos or videos under the root path of your storage card (that are not contained
in folders), they will be grouped under the Other album.
HTC Confidential
95 Photos, videos, and music
Viewing photos
After you’ve selected an album, you can browse through your photos and videos.
Depending on how you hold your phone, the screen automatically switches to either
grid view or filmstrip view:
While in grid view, slide your finger up or down to scroll through the
thumbnails. Tap a photo or video to view it in full screen.
While in filmstrip view (when you turn your phone sideways), slide your finger
left or right across the screen to go through your photos and videos. Tap a
photo or video to view it in full screen.
HTC Confidential
96 Photos, videos, and music
Zooming in or out on a photo
There are two ways you can zoom in or out of a photo.
Tap the screen twice quickly to zoom in, then tap the screen twice quickly
again to zoom out.
Press your thumb and index finger on the screen and then spread your fingers
apart to zoom in; pinch your fingers together to zoom out.
Watching videos
Video is always displayed in landscape mode when you play it.
While browsing an album, tap a video to play it.
Another way to easily get to your videos is to tap from the Homescreen, and then tapthen tap
Videos.
Use the onscreen controls to play, pause, or stop the video.
For an enhanced audio experience, tap to turn on SRS. (Not available whento turn on SRS. (Not available when
you’re using a Bluetooth headset.)
Tap to toggle between full and best-fit screens.to toggle between full and best-fit screens.
HTC Confidential
97 Photos, videos, and music
Editing your photos
Do basic editing tasks on your photos such as rotate and crop. You can also enhance
your photos by applying effects such as high contrast, vintage, and more.
Rotating a photo
On the Gallery app’s Albums screen, tap an album.
Press and hold on the photo that you want to rotate.
In the menu that opens, tap Edit, and then tap either Rotate left or Rotate right.
Cropping a photo
On the Gallery app’s Albums screen, tap an album.
Press and hold on the photo that you want to crop.
In the menu that opens, tap Edit, and then tap Crop. You’ll see a crop box around
the photo.
To adjust the crop box size, press and hold the edge of the box.
5. When directional arrows appear, drag your finger inward or outward to resize the
crop box.
6. To move the crop box to the part of the photo that you want to crop, drag the
crop box to the desired position.
7. Tap Save to keep the changes.
The cropped photo is saved in the storage card as a copy. The original photo remains
unedited.
Adding effects
1. On the Gallery app’s Albums screen, tap an album.
2. Press and hold on the photo that you want to add effects to.
3. In the menu that opens, tap Edit, and then tap Effects. On the panel that opens,
you’ll see options available to you.
4. Tap an effect to apply on the photo.
5. Tap Save to keep the changes.
The enhanced photo is saved in the storage card as a copy. The original photo remains
unedited.
1.
2.
3.
1.
2.
3.
4.
HTC Confidential
98 Photos, videos, and music
Sending your photos and videos
Send photos and videos via email or MMS or to another phone or your computer using
Bluetooth.
Sending photos or videos by email
You can send several photos, videos, or both in an email message. They are added as
file attachments in your email.
From the Home screen, tap > Gallery.
Tap the album that has the photos or videos you want to share.
Tap , and then tap Gmail or Mail.
Select the photos or videos you want to share and then tap Next.
Compose your message and then tap (Gmail) or Send (Mail).
If you selected Mail and you have multiple email accounts, the default email account will be
used.
Sending a photo or video by MMS
From the Home screen, tap > Gallery.
Tap the album that has the photos or videos you want to share.
Tap and then tap Messages.
Tap the photo or video you want to send. The photo or video is automatically
added into the MMS message.
To add another photo or video to your slideshow attachment, tap and then
tap Picture or Video.
6. Compose your message and then tap Send.
Sending photos or videos using Bluetooth
You can select several photos, videos, or both and send them to someone’s phone or
your computer using Bluetooth.
From the Home screen, tap > Gallery.
Tap the album that has the photos or videos you want to share.
Tap and then tap Bluetooth.
Select the photos or videos you want to share and then tap Next.
In the next few steps, you’ll be asked to turn on Bluetooth on your phone and connect
to the receiving Bluetooth device so the files can be sent.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
1.
2.
3.
4.
HTC Confidential
99 Photos, videos, and music
Sharing your photos and videos on the Web
Using the Gallery app, you can share photos and videos on your social networks, as
well as post videos on YouTube.
You can also use the Camera or Camcorder app to share a photo or video right after you’ve
captured it.
Sharing photos or videos on Facebook
You need to be logged in to your account to be able to upload photos or videos.
From the Home screen, tap > Gallery.
Tap the album that has the photos or videos you want to share.
Tap and then tap Facebook for HTC Sense.
Select the photos or videos you want to share and then tap Next.
Enter a different caption on each photo or video. You can also tag friends on
your photos. Tap Tag this photo, and then tap the part where your friend is.
From the list that shows, select who you want to tag.
6. Slide to the left to go to the next photo or video.
7. Tap Upload.
8. Select which album to upload to and set privacy settings for the uploaded
photos or videos.
9. Tap Done.
Sharing photos and videos on Flickr
You need to be logged in to your Flickr account to be able to upload photos or videos.
From the Home screen, tap > Gallery.
Tap the album that has the photos or videos you want to share.
Tap , and then tap Flickr.
Select the photos or videos you want to share and then tap Next.
Enter a different title and description on each photo or video. You can also tag
friends on your photos. Tap Tag this photo, and then tap the part where your
friend is. From the list that shows, select who you want to tag.
6. Slide to the left to go to the next photo or video.
7. Tap Upload.
8. Select which album to upload to and set privacy settings for the uploaded
photos or videos.
9. Tap Done.
1.
2.
3.
4.
5.
1.
2.
3.
4.
5.
HTC Confidential
100 Photos, videos, and music
Sharing photos on Picasa
You need to be signed in to a Google Account to be able to upload photos to the Picasa
photo organizing service.
From the Home screen, tap > Gallery.
Tap the album that has the photos you want to share.
Tap and then tap Picasa.
Select the photos or videos you want to share and then tap Next.
Enter a caption for the photos you’re uploading.
Select the online album where you want to upload the photos, or tap to
create a new album.
Tap Upload.
You can view the photos online at http://picasaweb.google.com.
Sharing videos on YouTube
You can share your videos by uploading them to YouTube.
From the Home screen, tap > Gallery.
Tap the album that has the videos you want to share.
Tap and then tap YouTube.
Select the photos or videos you want to share and then tap Next. Sign in to your
YouTube or Google Account, if you’re asked to do so.
Enter a title for the videos you’re uploading.
Tap More details where you can enter information such as description and tags,
and select a privacy option.
Tap Upload.
Viewing photos in your social networks
Right in the Gallery app, check what you and your friends have uploaded to your social
networks (Facebook and Flickr only).
Viewing photos on Facebook
You need to be logged in to your Facebook account to view Facebook photos.
From the Home screen, tap > Gallery.
Tap the Facebook tab.
Tap your account name or your friend’s account on the list to view the photos in
the account.
You can view photos in your online albums in the same way as you view photos on
your storage card.
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
HTC Confidential
101 Photos, videos, and music
Viewing photos on Flickr
You need to be logged in to your Flickr account to view Flickr photos.
1. From the Home screen, tap > Gallery.
2. Tap the Flickr tab. You may be asked to give authorization for the app to
connect to the Flickr website. If this happens, you need to give authorization to
access your Flickr account.
3. Tap your account name or your friend’s account on the list to view the photos in
the account.
You can view photos in your online albums in the same way as you view photos on
your storage card.
Commenting on photos in your social networks
Add comments to your uploaded photos as well as your friends’ photos.
1. Do one of the following:
While browsing online albums, press and hold a photo and then tap Add
comment.
While viewing a photo in full screen, tap anywhere on the screen, and then
tap .
2. Tap the box that says “Write a comment.”
3. Enter your text, and then tap Comment.
Music
Listening to music
Enjoy listening to songs and music on your phone using the Music app.
You need to copy music files to your storage card first to use the Music app to play music.
From the Home screen, tap > Music. The Music app opens in the Now
playing screen.
Swipe your finger left or right across the screen to go to the next or previous
music album.
Tap the onscreen icons to control music playback, select a song to play, repeat
songs, and more.
1.
2.
3.
HTC Confidential
102 Photos, videos, and music
Turn shuffle on or off. (Shuffle is off when button is
gray.)
Press and drag your finger across the progress bar to
jump to any part of the song.
Tap to check out featured albums from HTCSense.com.
(Availability depends on your country.)
Go to the library.
Switch between showing the Now playing list and Now
playing screen. You can rearrange songs in the Now
playing list.
Enjoy listening to your music with SRS. Or, if you’re
using a wired headset, you can also choose from various
preset equalizer settings. (SRS and equalizer are not
available when you’re using a Bluetooth stereo headset.)
Cycle through the repeat modes: repeat all songs,
repeat current song, and don’t repeat.
Playing music from the Lock screen
When you’re listening to music and the screen turns off, press POWER to turn the
screen back on and control the music playback directly on the Lock screen.
If you don’t see the playback controls on the Lock screen, tap anywhere on the screen
to display them.
You can also pause music playback right from the Notifications panel.
HTC Confidential
103 Photos, videos, and music
Browsing albums in landscape view
When you turn your phone sideways, you get a wider view of your screen and can
skim through your albums easily.
If you have lots of albums, flick left or right across the screen to quickly skim
through them.
To look at one album at a time, slide your finger left or right.
Tap to see the song list of the current album.
About the Music widget
You can use the Music widget to play music right from your Home screen.
Browsing music in the library
Tap on the Music app’s Now playing screen or Now playing list to go to the
library. In the library, your music is organized by categories such as Artists and
Albums. Choose a category by tapping one of the tabs at the bottom of the screen.
Tap a song in a category to play it. The Now playing list is updated with the song
list from your selected category.
You can add, remove, or rearrange the tabs in the library.
Creating a playlist
Personalize your music experience by creating music playlists. Make a playlist
containing just your favorite songs or create one to match your mood for the day.
You can make as many playlists as you like.
From the Home screen, tap > Music.
Tap to go to the library.
In the library, tap or slide your finger on the bottom row to go to the Playlists
category.
Tap Add playlist.
Enter a playlist name, and then tap Add songs to playlist.
Choose a category.
Select the check boxes of songs you want to add to the playlist and then tap
Add.
Tap Save.
1.
2.
1.
2.
3.
4.
5.
6.
7.
8.
HTC Confidential
104 Photos, videos, and music
Playing the songs in a playlist
In the library, tap or slide your finger on the bottom row to go to the Playlists
category.
Tap a playlist to open it.
Tap the first song or any song in the playlist.
When you tap a song in the list to play it, the Now playing screen is updated with the
songs from your playlist.
Managing playlists
After creating a playlist, you can add more songs to it, rearrange their order, and more.
In the library, tap or slide your finger on the bottom row to go to the Playlists
category.
Tap a playlist to open it.
Press , and then choose what you want to do:
Add more songs to a
playlist
Tap Add songs.
Go to the Songs category or any other category.
Select the songs you want to add to the playlist and then
tap Add.
1.
2.
3.
Rearrange songs Tap Change order.
Press and hold at the end of the song title you want
to move. When the row is highlighted, drag it to its new
position, then release.
1.
2.
Delete songs from a
playlist
Tap Remove songs.
Select the songs you want to delete and then tap
Remove.
1.
2.
Change playlist name Tap Rename playlist.
Deleting playlists
In the library, tap or slide your finger on the bottom row to go to the Playlists
category.
Press and then tap Delete playlists.
Select the playlists to delete and then tap Delete.
1.
2.
3.
1.
2.
3.
1.
2.
3.
HTC Confidential
105 Photos, videos, and music
Setting a song as a ringtone
You can choose a song from the Music app’s library and set it as your phone’s ringtone
or a ringtone for a certain contact.
From the Home screen, tap > Music.
Tap to go to the library.
In the library, choose the song that you want to use as ringtone and then play it
back.
On the Now playing screen, press and then tap More > Set as ringtone.
If you chose an MP3 song, you can trim it first and set the part that you trimmed
as the ringtone.
In the Set as ringtone options menu, tap Phone ringtone or Contact ringtone.
If you select Contact ringtone, you need to choose the contacts you want to
associate the song with in the next screen.
Trimming an MP3 ringtone
The Music app has a built-in ringtone trimmer. You can trim an MP3 song and set a
part of it as your ringtone.
1. On the Now playing screen, press MENU, and then tap More > Set as ringtone >
Trim the ringtone.
2. Use the onscreen controls to trim your ringtone.
Drag the two trim sliders
approximately to the part where
you want the ringtone to begin
and end.
Tap the left and right arrow
buttons to more precisely set
the start and end points of the
ringtone.
The markers show where the
ringtone starts and ends.
3. After you’ve finished trimming, tap Set as. Then choose whether to set the
trimmed song as your Phone ringtone or Contact ringtone.
Checking if the song was added as a ringtone
From the Home screen, press , and then tap Settings.
On the Settings screen, tap Sound > Phone ringtone.
The song should be in the ringtone list and selected.
1.
2.
3.
4.
5.
6.
1.
2.
HTC Confidential
106 Photos, videos, and music
Sharing music using Bluetooth
You can choose a song from the Music app’s library and send it to someone’s phone or
your computer using Bluetooth.
From the Home screen, tap > Music.
Tap to go to the library.
In the library, choose the song that you want to send via Bluetooth and then play
it back.
On the Now playing screen, press and then tap Share > Bluetooth.
In the next few steps, you’ll be asked to turn on Bluetooth on your phone and connect
to the receiving Bluetooth device so the music can be sent.
Finding music videos on YouTube
You can find music videos of the song you’re listening to on YouTube. It’s simple. On
the Now playing screen, just press and then tap Find videos.
1.
2.
3.
4.
HTC Confidential
107 Photos, videos, and music
Connected Media
Sharing media on your home network
Sharing photos, videos, and music with a bigger circle of friends is easy on your home
network. Simply connect your phone to the network and instantly show your captured
photos and videos on a big TV, or start streaming your favorite music tracks on hi-fi
speakers — all via DLNA®. For more information about DLNA, visit www.dlna.org.
Before you share media through the network:
Connect your phone to the network via Wi-Fi. To find out how to connect to a
Wi-Fi network, see the Internet chapter.
Connect the TV or speakers to the network. Check the documentation that came
with your TV or speakers to know how.
1. Open the Gallery or Music app.
2. Locate the media that you want to share, and then tap it.
3. While viewing the photo or playing the video or music, press , and then tap
Select player.
4. Choose the device on your network where you want to play the media.
5. Once connected to the other device, your phone opens up the Controller screen
where you can tap:
Controls To
Play the media on the other device.
Pause the music or video playback.
Play the previous photo or music track.
Play the next photo or music track.
Shuffle your music playlist.
Select a repeat mode for photos or music tracks.
Show available media that you can share.
View the media information such as the file name, title, and duration.
HTC Confidential
108 Photos, videos, and music
Controls To
Connect to another photo/video player on the network.
Connect to another music player on the network.
/ Adjust the volume of the video or music you’re playing on the other
device. You can also drag the volume slider to adjust the volume.
Disconnect your phone from the other device and stop sharing
media.
While playing a media on another device, you can press and do other things on your
phone. To return to the Controller screen, slide open the Notifications panel, and then tap
the device you’re connected to.
Until you disconnect the phone from the other device, other media that you open from the
Gallery or Music app are shared on the other device.
HTC Confidential
109 Accounts and sync
Accounts and sync
About online accounts
Your phone can sync with various online social networking and email accounts.
These are some of the types of information your phone can sync with your online
accounts:
Gmail, Exchange ActiveSync, and other POP3/IMAP email.
Google and Exchange ActiveSync contacts, as well as your friends’ contact
information in Facebook and their Twitter profiles.
Calendar events from your Google Account(s), from Exchange ActiveSync, and
from your Facebook account.
Status updates and links shared by your friends and yourself on social networks
such as Facebook and Twitter.
Flickr and Facebook photo uploads.
You can set up your Exchange ActiveSync and POP3/IMAP email accounts on your phone
either in the Mail app or the Accounts & sync settings.
Synchronizing with a Google Account
Signing in to your Google Account lets you sync Gmail and your Google contacts and
calendars between your phone and the Web. You also need to sign in to a Google
Account to use Google apps such as Google Talk and Android Market.
If you skipped signing in to a Google Account when you first set up your phone, you may
encounter problems when using some Google apps. If these problems persist, you may need
to factory reset your phone and enter your Google Account details when you set up the
phone again.
Adding more Google Accounts
You can add more than one Google Account on your phone. However, subsequent
Google Accounts can only sync contacts, emails, and calendar events. Other Google
services use the first Google Account you added.
From the Home screen, press , and then tap Settings > Accounts & sync.
Tap Add account > Google.
Follow the onscreen instructions to sign in to an account or create a new
account.
1.
2.
3.
HTC Confidential
110 Accounts and sync
Forgot your Google Account password?
If you have forgotten your Google Account password, you can try to recover it by
going to the Google website.
1. On your phone or computer, open your web browser and go to
https://www.google.com/accounts/ForgotPasswd.
2. Enter the email address or username that you use to sign in to your Google
Account and click Submit.
3. Follow the instructions on the screen to reset your password.
If you don’t have an alternate email address or cannot access the email account
you used to create your Google Account, you can reset your Google Account after
24 hours by answering the security question for password recovery.
Adding a social network account
If you skipped setting up your social network account (such as Facebook, Twitter, or
Flickr) when you first turned on and set up your phone, you can still sign in to these
accounts through your phone’s settings.
From the Home screen, press , and then tap Settings > Accounts & sync.
Tap Add account, and then tap the account type you want to add.
Follow the onscreen instructions to enter the account information.
Your social network account is then added to the list on the Accounts & sync screen.
Depending on how you configured the account, the new information may start
synchronizing with your phone.
Managing your online accounts
Changing general sync settings
From the Home screen, press , and then tap Settings > Accounts & sync.
Select or clear the following:
Background data If this is selected, apps can send and receive online account
information even if you are not currently using them.
Auto-sync If this is selected, apps can use the sync schedule defined in the
account settings. If this is cleared, you will need to sync accounts
manually.
1.
2.
3.
1.
2.
HTC Confidential
111 Accounts and sync
Synchronizing an account manually
From the Home screen, press , and then tap Settings > Accounts & sync.
Tap the account that you want to sync.
Tap Sync now.
Changing account settings
You can change settings such as the sync frequency and the types of information
synchronized, the kinds of notification you receive, and the way that account
information is displayed.
From the Home screen, press , and then tap Settings > Accounts & sync.
On the Accounts & sync screen, tap the account that you want to edit.
Tap the type of information you want to sync or select an item to edit its
settings.
Removing an account
You can remove an account to delete it and all information associated with it from
your phone, for example messages, contacts, or settings. Removing an account does
not delete information from the online service itself.
You cannot remove some accounts, such as the first Google account you signed into on the
phone, except by deleting all personal information from your phone with a hard reset.
From the Home screen, press , and then tap Settings > Accounts & sync.
Tap the account that you want to remove.
Tap Remove account, and then confirm that you want to remove the account.
1.
2.
3.
1.
2.
3.
1.
2.
3.
HTC Confidential
112 Social
Social
Facebook for HTC Sense
If you signed in to your Facebook account when you turned on and set up your phone
for the first time, that means your Facebook account is linked to Facebook for HTC
Sense on your phone.
With Facebook for HTC Sense, you can:
See all your Facebook contacts and their instant status updates in People.
When you tap a contact on the All tab, slide to
the Updates and events tab to see updates such
as posted status messages, uploads, and profile
changes.
When there is a notification of the contact’s birthday,
you can tap the notification to send a greeting.
See Facebook photos right on the Gallery app.
You can also upload one or more photos from your
storage card to Facebook, then tag and add captions
that go with it.
When you’re viewing the albums of a Facebook
friend, you can also share a link to a particular album,
or comment on the album photos.
Check your friends’ Facebook status updates in Friend Stream.
Add your Facebook events and your friends’ birthdays to the Calendar app.
HTC Confidential
113 Social
What’s the difference between Facebook app and Facebook for HTC
Sense?
Facebook for HTC Sense is not a standalone app. It is integrated in People,
Friend Stream, Gallery, and Calendar to give you up-to-date information about
your Facebook contacts (their status updates, shared links, and photos) in these
apps.
The Facebook app is a standalone app. Use this app to do most of the things
that you would do when you’re using your computer’s web browser to access
your Facebook account, such as adding a friend and sending Facebook
messages.
The two do not share the same login credentials. Signing in to Facebook for HTC
Sense does not sign you in to the Facebook app and vice versa. If you want to
use the same Facebook account for both, you’ll have to sign in to both using the
same login credentials.
If you have more than one Facebook account, you may sign in to the Facebook app using
your second account, since the Facebook app does not share the same login credentials as
Facebook for HTC Sense.
Facebook app
The Facebook app on your phone lets you keep up and stay close with your friends
in Facebook. It offers most of the features that you are familiar with when using
Facebook on your computer.
With the Facebook app, you can:
Share your thoughts and check other people’s status updates.
View your friends list and write on someone’s wall.
Comment on and like a friend’s post.
View someone’s personal information, including photo albums.
Check your Facebook notifications.
Take a photo and upload it straight to your Facebook account.
Using the Facebook app
1. From the Home screen, tap > Facebook.
2. If this is your first time to use Facebook, follow the onscreen instructions to sign
in to your Facebook account.
3. On the News Feed screen, tap to access the other functions.
While on the Facebook home screen, press , and then tap Settings to set refresh and
notification options.
On some Facebook screens, you can press and hold an item to open an options menu.
HTC Confidential
114 Social
Adding the Facebook widget
Add the Facebook widget to the Home screen so you can easily post updates and
check status updates of your friends.
The widget will only link to the Facebook account that you logged into on the Facebook app.
Tweeting on your phone using Peep
You can post and read tweets, send and receive direct messages, search for new
Twitter users to follow using the Peep app. Peep is a Twitter client that lets you enjoy
“tweeting” on your phone. You can also link your contacts in People to their Twitter
profiles (if you’re following them).
If you did not sign in to your Twitter account when you first turned on the phone, you
can do one of the following:
Sign in to your Twitter account from Peep. From the Home screen, tap
> Peep, then follow the onscreen instructions.
Add the Twitter for HTC Sense account in Settings > Accounts & sync.
Twitter for HTC Sense and Peep share the same login credentials. This means that when you
use Peep on your phone for tweeting, you can also link your contacts to their Twitter profiles
via Twitter for HTC Sense.
From the Home screen, tap > Peep. Peep opens in the All tweets tab.
HTC Confidential
115 Social
Tap to compose and send a tweet.
Tap a person’s name to check profile details and
all of his or her tweets.
If you have linked the contact in People, tap the
photo or icon to open a menu where you can
quickly choose how to communicate with the
contact.
Press and hold a tweet to open an options menu
to reply, send a direct message, retweet, and
more.
View all the tweets from people you follow and
tweets that you have posted.
View all tweets that mention your username using
the “@[your username]” convention.
View all private/direct messages that you have
received or sent.
View tweets that you have marked as favorites.
Sending a tweet
On the All tweets tab, tap the text box that says What’s happening.
Type your tweet.
Add a picture or location to your tweet.
Tap to post a picture from Gallery or Camera to your default photo
hosting site and add the link to the picture in your tweet.
Tap to insert your location into the tweet. You can choose to add a map
link, insert your location name, or insert your position coordinates.
4. Tap Post.
Sending a direct message
You can only send a direct message to someone who is following you.
In any of the tabs in Peep, press , and then tap New message.
2. Tap the text box at the top of the screen, and then enter the name. As you enter
characters, the names of the Twitter users that match the characters you enter
will appear. Tap the name when you see it.
3. Enter your message, and then tap Post.
You can also send a direct message when you press and hold a tweet of the person
you want to send the direct message to, and then tap Send direct message on the
options menu.
1.
2.
3.
1.
HTC Confidential
116 Social
Setting Peep options
In any of the tabs in Peep, press , and then tap More > Settings. You can set these
options:
Account settings Sign out of your Twitter account.
General settings Choose whether to show the screen name or the real name of the
people you follow.
Send & receive Set the frequency to check for new tweets and set the number of
tweets to download.
Services Set your photo hosting site, photo quality, location options, and URL
shortening host.
Notification settings Select when and how you want to be notified.
Searching for Twitter users to follow
In any of the tabs in Peep, press the button.
Type a Twitter name in the search box. You can also narrow down the search
when you tap > Users.
3. Tap .
4. In the list of search results, tap the Twitter user you want to follow.
5. Press , and then tap Follow.
Unfollowing a Twitter user
On the All tweets tab, tap the Twitter user you want to stop following.
Press , and then tap Unfollow.
Using Friend Stream
Friend Stream connects you to your social networks. Share and get updates
from friends in popular networks like Facebook and Twitter in a single feed. With
Friend Stream, you can easily track your friends’ status messages, photo uploads,
notifications, and more — or comment and post your own.
You must be signed in to at least one social network account to use Friend
Stream.
To use your Facebook account on Friend Stream, you need to be signed in via
Facebook for HTC Sense.
From the Home screen, tap > Friend Stream. Friend Stream opens on the All
updates tab.
1.
2.
1.
2.
HTC Confidential
117 Social
When you tap someone’s status update, you can:
View all tweets.
Write a comment. Like or unlike someone’s
Facebook posts.
Look at someone’s album photos.
When you tap someone’s photo or name, you can:
Check the person’s profile details.
Look at the person’s Facebook wall.
Check the person’s posted tweets.
Slide to the other tabs to view social network updates grouped as status updates only,
photo uploads, links, updates from members of your Facebook list, or social network
notifications.
Updating your status
You can update your status simultaneously on all the social network accounts you are
signed in to.
From the Home screen, tap > Friend Stream.
On the All updates tab, tap the text box that says What’s on your mind.
Enter your status update.
4. If you do not want to send the status update to all your social network accounts,
tap and clear the check boxes of the social networks to exclude.
5. Tap and then choose what you want to attach to your tweet or status update.
Picture Select From Camera to take a photo and attach it or From
Gallery to attach a photo from your storage card.
Location Add your current location or a location you pick on a map.
App
recommendation
Choose an app you’ve installed from Android Market that you
want to share with others. The URL from which the app can be
downloaded will be inserted to your status.
6. Tap Post.
1.
2.
3.
HTC Confidential
118 Social
Commenting on and liking Facebook posts
Tap someone’s status update on the All updates tab, and do any of the following:
Tap a photo or the album name shown in the
status update to view and comment on the album
photos using the Gallery app.
Tap Like or Unlike to like or unlike the person’s
status update.
Tap the text box that says Write a comment, and
then enter what you think about the person’s
status update.
Checking notifications from your social networks
Slide to the Notifications tab to easily see a single feed of your notifications from
different social networks. It can be a comment on your Facebook post, a mention or
direct message in Twitter, a tagged photo of you, and more.
About the Friend Stream widget
Use the Friend Stream widget so you can easily update your status and view other
people’s status updates right on the Home screen. If you want to keep up with just one
person’s Facebook updates, you can add the Friend Channel widget. You can find it in
the Friend Stream widget layout options.
HTC Confidential
119 Social
Chatting in Google Talk
Google Talk is Google’s instant messaging program. It lets you communicate with
other people that also use Google Talk. If you signed in to your Google Account when
you first set up the phone, you are already signed in to Google Talk.
Chatting with a friend
In Google Talk, tap a friend in the Friends list.
Enter your message in the text box. You can also insert a smiley by pressing ,
and then tapping More > Insert smiley.
Tap Send.
While chatting, press and then tap any of these options:
Chat off record Your Google Talk messages are stored in the Chats folder of your
Gmail account. Tap this option if you don’t want to store your chatyour chat
messages.
Switch chats If you have more than one chat going, tap to switch chat with another
friend.
Friends list Return to the Friends list.
Add to chat Add another friend to your chat. The friend you invited and the friend
you’re currently chatting will receive an invitation to a group chat.
Each one who accepts the invitation joins the group chat.
End chat End your current chat.
More Clear the chat history, insert a smiley or view your friend’s contact
details.
Accepting a chat invitation
When a friend sends you a Google Talk message, you receive a notification. Their entry
in the Friends list displays the message.
Do one of the following:
In the Friends list, tap the friend who sent you the invitation to chat.
Open the Notifications panel, and then tap the chat notification.
Changing your online status and picture
In Google Talk’s Friends list, tap your name to open the Set Status screen.
Enter your new status message. Or press to choose a custom status from the
list.
Tap the online status beside your picture, and then select the status you want on
the menu.
Tap your picture, and then do one of the following:
Tap Remove to remove your photo.
Tap Change to select another picture on the storage card.
5. Tap Done.
1.
2.
3.
4.
1.
2.
3.
4.
HTC Confidential
120 Social
Your online status, message, and picture appear in your contacts’ Friends list and in
other apps where your Google Talk status are displayed.
Adding and managing friends
The Friends list is where you add and manage your friends in Google Talk.
In Google Talk’s Friends list, you can:
Invite a friend 1. Press , and then tap Add friend.
2. Enter the Google Talk instant messaging ID or Gmail address of the
friend you want to add.
3. Tap Send invitation.
View all friends Initially, only those friends that you often chat with — the most popular
— are shown in the Friends list. To view all your friends, press , and
then tap All friends. To view only friends that you often chat with, press
, and then tap Most popular.
Make a friend
popular 1. Press , and then tap All friends.
2. Press and hold a friend’s name, and then tap Always show friend.
Block a friend You can block a friend from sending you messages. When blocked, your
friend is removed from the Friends list and is added to the Blocked friends
list.
1. Press , and then tap All friends.
2. Press and hold a friend’s name, and then tap Block friend.
Unblock a friend Press , and then tap More > Blocked.
View all invited
friends Press , and then tap More > Invites. Friends who have not yet accepted
your invitation are listed on the screen.
Changing settings or signing out
In Google Talk’s Friends list, press and then tap:
Settings to change the app and notification settings.
Sign out to sign out.
HTC Confidential
121 Maps and location
Maps and location
Location settings
Turning on location services
In order to find your location on your phone, you need to enable location sources.
From the Home screen, press and then tap Settings > Location.
Select one or both of the following:
Use wireless networks Uses Wi-Fi or your mobile data connection to find your
approximate location.
Use GPS satellites Finds your exact GPS location. This requires a clear view
of the sky and more battery power.
Locations
About Locations
Search for places of interest, get directions to places you want to go to, and drive
using turn-by-turn GPS navigation with Locations. Locations is also your perfect
travel companion, whether you’re at home or when you’re in a different country. With
Locations, you can download maps to your phone beforehand so you don’t have to
worry about having an Internet connection while on the road or costly data roaming
charges when abroad. Have your map ready before you start your journey.
If you are in an area where there are a lot of surrounding buildings, Locations may have a hard
time pinpointing your location.
Your phone comes with a map installed. The map on your phone will depend on the
country where you bought your phone. Don’t worry, you can download other maps
when you need them.
1.
2.
HTC Confidential
122 Maps and location
Finding your location and what’s around you
From the Home screen, tap > Locations. You can see your current location
right below the tab name.
2. Press , and then tap My location to update your current location or tap Map
to show your current location on the map.
3. Select a category that you’re interested in to see the places that are close by.
The places are listed according to the distance from your current location.
Searching for a place of interest
You can search using a name of an establishment, street, or city. As you enter the
place to look for, suggested matches from the database, footprints, and previously
searched items are displayed.
In Locations, press the button.
Enter the place you want to search in the search box. Matching establishments
are shown sorted by the distance from your current location.
If you don’t see what you are looking for, keep entering characters to narrow
down the search.
Search is done in your current country. If you want to do a search on a different country on
your phone, tap Current search region.
Tap if you don’t see any suggestions or if you don’t see the place you are looking for in
the list.
4. Tap an establishment to get directions, call them, add it as a footprint, and more.
Searching for an address
Enter the street or city name you want to find (you don’t need to enter the complete
address). A list of suggestions will appear to guide you to what you’re looking for.
For example, to find “321, Church Street, London, UK”, just enter “Church” or “London”
to start your search.
You can also search by entering a zip code. To search using a zip code, enter the zip code, and
then tap .
1.
1.
2.
3.
HTC Confidential
123 Maps and location
Viewing maps
In Locations, press , and then tap Map.
Tap to switch between 2D and 3D views.
Point of interest. Tap to see details, call, get
directions, or share.
Your current location.
Tap to use or not use the compass.
Tap the screen to show the zoom buttons and My location button.
Using the compass
Should I turn left or right? By using the compass, the map adjusts depending on where
you’re facing so you know where to go.
Moving around the map
Swipe your finger on the screen to view other areas of the map.
Zooming in or out of a map
Do one of the following:
Spread your thumb and index finger across the map to zoom in.
Pinch your thumb and index finger on the map to zoom out.
Double-tap a location on the map to zoom in to that location.
Choosing which places of interest to show on the map
While viewing a map, press , and then tap View.
Choose the points of interest you want or don’t want to see when you’re viewing
a map.
You can also choose to show or not show footprints and 3D buildings on the map.
3. Tap Done.
Pinning a location on the map
Pin a favorite location on the map and add it as a footprint, get directions to it, or
share it with friends. Sharing is a great way to let your friends know about that little
place you found that has the best sandwiches in town.
While viewing a map, press and hold an area on the map that you want to pin.
Tap and then choose if you want to add the location as a footprint, get
directions to it, or share it.
1.
2.
1.
2.
HTC Confidential
124 Maps and location
To remove all the pins on the map, while viewing a map, press , and then tap More > Clear
pin.
Changing the language of street names and places of interest
From the Home screen, tap > Locations.
On the Nearby tab, press , and then tap Settings > Map > Map language.
Choose one of the following.
Use native map language Use this if you want to use the local language of the map.
For example, if you are looking at a map of Japan, it will
use Japanese characters.
Use language that fits best Use this if you want to use the language of your phone.
This may not be available for all maps.
Recording favorite places as footprints
A footprint consists of a photo of a location such as a restaurant, a sightseeing
destination, etc., stored together with a precise GPS position and other information
about that location such as the street address and phone number.
The next time you want to visit the same place, just open the footprint. You can then
dial the phone number or view the location in the map.
Adding a location as a footprint
Search for the destination you want to go to.
Tap Save to Footprints.
3. You can:
Tap to take a picture and add it as a photo for the footprint.
Tap to fine tune the position of the footprint on the map.
Tap to add a note for the footprint.
Tap Select categories, and then choose the appropriate labels for the location.
Press , and then tap Record voice to add a voice memo to the footprint.
4. Tap Done.
Setting a footprint as your home location
Save your home address as a footprint to make it easier to set it as your destination.
1. While at your home location, open Locations, and then go to the Footprints tab.
2. Tap Save to Footprints.
The address shown should be your current location. If it doesn’t show your home address,
press , and then tap My location.
3. Tap Done.
4. Tap Set my home, select your home address from the list, and then tap Done.
To change your home address at any time, tap .
1.
2.
3.
1.
2.
HTC Confidential
125 Maps and location
Revisiting a footprint
1. On the Footprints tab, tap a category.
2. Tap the footprint you want to revisit.
3. Tap the information fields to get directions, share the footprint, call a stored
phone number, and more.
Editing or deleting a footprint
1. On the Footprints tab, tap a category.
2. Press and hold the footprint you want to edit or delete.
3. Tap Edit or Delete on the options menu.
Sharing your footprints
1. Create a footprint.
2. On the Footprints tab, tap the footprint that you have just created.
3. Tap Share, and then choose how you want to share the footprint.
Deleting multiple footprints
1. On the Footprints tab, tap a category.
2. Press , and then tap Delete.
3. Select the footprints you want to delete, and then tap Delete.
Exporting your footprints
Back up footprints by exporting them to the storage card. You can also open exported
footprints files in other applications such as Google Earth™ on your PC.
1. On the Footprints tab, tap a category.
2. Press , and then tap Export.
Press and then tap Deselect all to deselect all the footprints.
Exported footprints are saved as .kmz files in the Footprints folder on your storage
card. If you exported multiple footprints at one time, they are saved together in one
.kmz file.
Importing footprints
Bring back footprints you previously backed up to the storage card to your phone.
You can also import .kmz files that you saved in other applications, or use a photo as a
footprint.
1. On the Footprints tab, press , and then tap Import.
2. Do one of the following:
To import a photo, tap Photos, navigate to the photo you want to import,
and then tap the photo. You can then add Footprints information such as
location and category.
To import a saved footprint or another .kmz file from the storage card, tap
Footprints data, and then tap the file you want to import.
HTC Confidential
126 Maps and location
Getting directions
Get detailed driving or walking text instructions on how to get to your destination.
Getting directions from your current location
In Locations, search for the destination you want to go to.
You have footprints saved? You can also set a footprint as your destination. Just go to the
Footprints tab, and then choose a footprint.
2. Tap Directions.
3. Choose how you want to get to your destination. The map opens showing the
route to your destination.
4. Do one of the following:
At the bottom of the screen, tap or to follow the route to your
destination.
Slide up the directions bar, and then tap the instructions to follow the route
to your destination.
If you have turn-by-turn navigation for that country, press , and then tap Premium Navi to
start turn-by-turn navigation.
Getting directions by setting a start and end location
While viewing the map, press , and then tap Directions.
Tap the My location text box, and then search for the starting location you want.
Tap the End point text box, and then search for the destination you want.
Tap Driving or Walking depending on how you want to get to your destination.
Do one of the following:
At the bottom of the screen, tap or to follow the route to your
destination.
Slide up the directions bar, and then tap the instructions to follow the route
to your destination.
If you have turn-by-turn navigation for that country, press , and then tap Premium Navi to
start turn-by-turn navigation.
1.
1.
2.
3.
4.
5.
HTC Confidential
127 Maps and location
Using turn-by-turn navigation (Premium navigation)
To use turn-by-turn navigation, the Use GPS Satellites option in Location sources
needs to be selected.
Check if you have the turn-by-turn navigation for the country or region you’re
using.
Using Locations to navigate to a destination
In Locations, search for the destination you want to go to.
You have footprints stored? You can also set a footprint as your destination. Just go to the
Footprints tab, and then choose a footprint.
2. Tap Premium navigation.
While navigating, you can tap the screen to see what other options are available.
Setting navigation preferences
Choose how you want Locations to map your route. You can tell Locations to avoid
highways or toll roads, show lane information, choose your route preference, and more.
While using turn-by-turn navigation, tap the screen.
Tap Car Panel > Settings > Navigator.
Set your preferences by selecting or tapping an item.
Turning off speed and safety camera alerts
If you have the safety camera service, you can choose to turn this service off
temporarily.
While using turn-by-turn navigation, tap the screen.
Tap Car Panel > Settings > Warnings.
Clear the Speed warning and Safety camera warning check boxes.
Answering a call while using navigation
When a call comes in, the whole map nudges up a bit so you can see the incoming call
and answer it. Don’t worry, you’ll still be able to use navigation as we made sure that
the call screen just occupies as little space as possible at the bottom of the screen.
1.
1.
2.
3.
1.
2.
3.
HTC Confidential
128 Maps and location
Using Car Panel
Easily access footprints, points of interest, and places nearby with Car Panel, and then
start navigation to show you how to get there.
From the Home screen, tap > Car Panel.
Search for a destination to go to.
Check the places you’ve search before, and then
choose one to set as your destination.
Download or purchase additional services such as
navigation, safety camera, and turn-by-turn voice
instructions.
Select a footprint to set as a destination.
Make a phone call.
Set Car Panel options.
Car Panel keeps opening by itself when you’re using a mini-to-micro
USB converter?
If you connect a mini-USB power adapter or car charger to your phone through
a mini-to-micro USB converter, your phone may misinterpret this to be a car kit
connection (due to the dierent connector PIN assignment on the mini-USB power
adapter or car charger) and automatically display the Car Panel.
You can prevent Car Panel from automatically opening by:
1. From the Home screen, press , and then tap Settings.
2. Tap Dock, and then clear the Auto-launch check box.
Using your phone with the car kit
If you purchased the dedicated car kit for your phone, you can use the included in-
car holder to mount your phone securely inside your car and use your phone on the
road. Refer to the car kit guide for instructions on how to install the in-car holder and
properly mount your phone to the holder.
When you mount your phone on the car kit, the Car Panel automatically opens.
When your phone is in the holder and is not connected to a Bluetooth car kit or headset, the
phone’s speakerphone is automatically turned on when you make or answer a phone call.
HTC Confidential
129 Maps and location
Automatically connecting to a Bluetooth car kit or headset
You can set your phone to connect to your Bluetooth car kit or Bluetooth headset
automatically, if one is paired with your phone, whenever you mount the phone on the
in-car holder.
In Car Panel, tap Settings > Car kit.
Select the Auto-connect check box.
If you have more than one Bluetooth car kit or headset paired with your phone,
tap Default device to choose the Bluetooth car kit or headset to use.
Before mounting your phone on the in-car holder, make sure that Bluetooth on your
phone and the paired Bluetooth car kit or headset is turned on.
Managing Locations services
Check the maps, navigation, safety camera information, and voices for turn-by-turn
voice instructions that are already on your phone.
From the Home screen, tap > Locations.
Press , and then tap Get more. In the My licenses & content tab, you’ll see a
list of services that are already on your phone.
Downloading maps or purchasing services
Going to a different country for vacation? You can download the map of the country
you’re going to for free. You can also download or purchase additional services such
as navigation, safety camera, and turn-by-turn voice instructions.
You need a data or Wi-Fi connection to download or purchase maps and services.
From the Home screen, tap > Locations.
Press , and then tap Get more.
Slide to the tab of the item or service that you want to download.
Depending on what you selected, tap Download or Purchase.
Depending on the country where you bought your phone, you may only need to enter
a voucher code to activate turn-by-turn navigation. If you have a voucher code, enter
it by tapping Voucher code at the top of the Purchase navigation tab.
Adding navigation widgets
Add a favorite destination and places of interest that are nearby and your footprints
as widgets on your Home screen. Add the Navigate widget to start turn-by-turn
navigation to your favorite destination. Add the Locations widget to let you browse
places of interest and your footprints right on the Home screen.
1.
2.
3.
1.
2.
1.
2.
3.
4.
HTC Confidential
