User Manual Statement
Safety and
regulatory guide
2 Safety and regulatory guide
Please read before proceeding
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE THE
DEVICE OUT OF THE BOX.
Privacy restrictions
Some countries require full disclosure of recorded telephone
conversations.
Important health information and safety
precautions
When using this product, the safety precautions below must be
taken to avoid possible legal liabilities and damages.
Retain and follow all product safety and operating instructions.
Observe all warnings in the operating instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage
to the equipment, observe the following precautions.
Electrical safety
This product is intended for use when supplied with power from
the designated battery or power supply unit. Other usage may be
dangerous and will invalidate any approval given to this product.
Safety precautions for proper grounding installation
CAUTION
: Connecting to improperly grounded equipment can
result in an electric shock to your device.
This product is equipped with a USB Cable for connecting with
desktop or notebook computer. Be sure your computer is properly
grounded (earthed) before connecting this product to the
computer. The power supply cord of a desktop or notebook
computer has an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate
outlet which is properly installed and grounded in accordance with
all local codes and ordinances.
Safety precautions for power supply unit
Use the correct external power source
A product should be operated only from the type of power
source indicated on the electrical ratings label. If you are not
sure of the type of power source required, consult your
authorized service provider or local power company. For a
product that operates from battery power or other sources,
refer to the operating instructions that are included with the
product.
Safety and regulatory guide 3
This product should be operated only with the following
designated power supply unit(s).
AC adapter:
HTC, Model TC U250
Handle battery packs carefully
This product contains a Lithium-ion polymer or Lithium-ion battery.
There is a risk of fire and burns if the battery pack is handled
improperly. Do not attempt to open or service the battery pack. Do
not disassemble, crush, puncture, short external contacts or circuits,
dispose of in fire or water, or expose a battery pack to temperatures
higher than 60˚C (140˚F).
WARNING
: To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external
contacts, expose to temperature above 60° C
(140° F), or dispose of in fire or water. Recycle or
dispose of used batteries according to the local
regulations or reference guide supplied with your
product.
Take extra precautions
y
Keep the device dry and away from water or any liquid as it
may cause a short circuit.
y
The phone should only be connected to products that bear
the USB-IF logo or have completed the USB-IF compliance
program.
y
Only use the battery with a charging system that has been
qualified with the system per this standard, IEEE-Std-1725.
Use of an unqualified battery or charger may present a risk of
fire, explosion, leakage or other hazard.
y
Avoid dropping the phone. If the phone is dropped, especially
on a hard surface, and the user suspects damage, take it to a
service centre for inspection.
y
If the battery leaks:
y
Do not allow the leaking fluid to come in contact with skin or
clothing. If already in contact, flush the affected area
immediately with clean water and seek medical advice.
y
Do not allow the leaking fluid to come in contact with eyes. If
already in contact, DO NOT rub; rinse with clean water
immediately and seek medical advice.
4 Safety and regulatory guide
y
battery away from
and extreme
as
may occur if earphones or
me.
terference caused by this product to an
t
estrictions
stations, fuel depots, chemical
uel
ir
e an
ntially explosive atmosphere or
off
nded
Take extra precautions to keep a leaking
fire as there is a danger of ignition or explosion.
y precautions for direct sunlight Safet
Keep this product away from excessive moisture
temperatures. Do not leave the product inside a vehicle or in
places where the temperature may exceed 60
°
C (140
°
F), such
on a car dashboard, window sill, or behind a glass that is exposed
to direct sunlight or strong ultraviolet light for extended periods of
time. This may damage the product, overheat the battery, or pose
a risk to the vehicle.
Prevention of hearing loss
CAUTION
: Permanent hearing loss
headphones are used at high volume for prolonged periods of ti
Safety in aircraft
Due to the possible in
aircraft’s navigation system and its communications network,
using this device’s phone function on board an airplane is agains
the law in most countries. If you want to use this device when on
board an aircraft, remember to turn off your phone by switching to
Airplane Mode.
Environment r
Do not use this product in gas
plants or where blasting operations are in progress, or in
potentially explosive atmospheres such as fuelling areas, f
storehouses, below deck on boats, chemical plants, fuel or
chemical transfer or storage facilities, and areas where the a
contains chemicals or particles, such as grain, dust, or metal
powders. Please be aware that sparks in such areas could caus
explosion or fire resulting in bodily injury or even death.
Explosive atmospheres
When in any area with a pote
where flammable materials exist, the product should be turned
and the user should obey all signs and instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or
even death. Users are advised not to use the equipment at
refueling points such as service or gas stations, and are remi
of the need to observe restrictions on the use of radio equipment
in fuel depots, chemical plants, or where blasting operations are in
Safety and regulatory guide 5
progress. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. These include fueling areas, below
deck on boats, fuel or chemical transfer or storage facilities, and
areas where the air contains chemicals or particles, such as grain,
dust, or metal powders.
Road safety
Full attention must be given to driving at all times in order to
n
tures (for example, the
ar strong electromagnetic sources,
accessories may
d.
less phones may interfere with some hearing aids.
fety
proved accessories.
e products or accessories.
ice when connecting a phone interface to
e the phone or its accessory.
Ge ns
how you use your phone and any
reduce the risk of an accident. Using a phone while driving (eve
with a hands free kit) causes distraction and can lead to an
accident. You must comply with local laws and regulations
restricting the use of wireless devices while driving.
Safety precautions for RF exposure
Avoid using your phone near metal struc
steel frame of a building).
Avoid using your phone ne
such as microwave ovens, sound speakers, TV and radio.
Use only original manufacturer-approved accessories, or
accessories that do not contain any metal.
Use of non-original manufacturer-approved
violate your local RF exposure guidelines and should be avoide
earing aids H
Some digital wire
In the event of such interference, you may want to consult your
service provider, or call the customer service line to discuss
alternatives.
Electrical sa
Accessories
y
Use only ap
y
Do not connect with incompatibl
Connection to a car
Seek professional adv
the vehicle electrical system.
Faulty and damaged products
y
Do not attempt to disassembl
y
Only qualified personnel must service or repair the phone or
its accessory.
neral precautio
You alone are responsible for
6 Safety and regulatory guide
consequences of its use. You must always switch off your phone
wherever the use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users and their
environment.
Avoid applying excessive pressure to the device
the device to
at
phone and its accessories with care and
y
s to open flames or
y
try to bend your phone or its
y
rsh chemicals, cleaning solvents, or aerosols to
y
ories.
its accessories,
y
mperatures between
y
cal regulations for disposal of electronic
y
y your phone in your back pocket as it could break
D e
e electrical outlet and refer servicing
n exposed to rain or liquid, dropped,
y
erheating.
you follow the
Av
ld be placed away from heat sources such as
Do not apply excessive pressure on the screen and
prevent damaging them and remove the device from your
pants’ pocket before sitting down. It is also recommended th
you store the device in a protective case and only use the device
stylus or your finger when interacting with the touch screen.
Cracked display screens due to improper handling are not
covered by the warranty.
Protect your phone
y
Always treat your
keep them in a clean and dust-free place.
Do not expose your phone or its accessorie
lit tobacco products.
Do not drop, throw or
accessories.
Do not use ha
clean the device or its accessories.
Do not paint your phone or its access
y
Do not attempt to disassemble your phone or
only authorised personnel must do so.
Store your phone or its accessories at te
0°C to 40°C.
Please check lo
products.
Do not carr
when you sit down.
amage requiring servic
Unplug the product from th
to an authorized service technician or provider under the
following conditions:
y
The product has bee
subject to impact or damaged.
There are noticeable signs of ov
y
The product does not operate normally when
operating instructions.
oid hot areas
The product shou
radiators, heat registers, stoves, or other products (including
Safety and regulatory guide 7
amplifiers) that produce heat.
Avoid wet areas
duct in rain, or near washbasins or other wet or
after a dramatic change in temperature
ce,
en taking the device from low-temperature
rature
abinet slots or other
me before using headphones or other audio
e product from the wall outlet before cleaning. Do not
ur phone and its accessories within the reach of
e.
a
when Texting or playing games with
the phone too tightly
)
tal connectors.
Never use the pro
high humidity locations. If your product gets wet, do not try to
dry the product with the use of an oven or dryer, as this may
damage your product.
Avoid using your device
When you move your device between environments with very
different temperature and/or humidity ranges, condensation
may form on or within the device. To avoid damaging the devi
allow sufficient time for the moisture to evaporate before using
the device.
NOTICE
: Wh
conditions into a warmer environment or from high-tempe
conditions into a cooler environment, allow the device to
acclimate to room temperature before turning on power.
Avoid pushing objects into product
Never push objects of any kind into c
openings in the product. Slots and openings are provided for
ventilation. These openings must not be blocked or covered.
Adjust the volume
Turn down the volu
devices.
Cleaning
Unplug th
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning, but NEVER use water to clean the LCD screen.
Small children
Do not leave yo
small children or allow them to play with it. They could hurt
themselves or others, or could accidentally damage the phon
Your phone contains small parts with sharp edges that may
cause an injury or which could become detached and create
choking hazard. Consult the doctor immediately if the
accessories or battery are swallowed.
Repetitive motion injuries
To minimise the risk of RSI,
your phone:
y
Do not grip
y
Press the buttons lightly
Electrostatic discharge (ESD
Do not touch the SIM card’s me
8 Safety and regulatory guide
y wireless phone, operates using radio signals,
R ncy identifications
Emergency calls
This phone, like an
which cannot guarantee connection in all conditions. Therefore,
you must never rely solely on any wireless phone for emergency
communications.
egulatory age
For regulatory identification purposes, your product is assigned a
and safe operation of your device,
23100
.
2
r
mmunication Commission Interference
t has been tested and found to comply with the
nterference
h
the receiving antenna.
t and receiver.
o or television
F
es or modifications not expressly
id the
model number of
PM23220
.
FCC ID:
NM8PM23220
.
To ensure continued reliable
use only the accessories listed below with your
PM23220
.
The Battery Pack has been assigned a model number of
BM
Operating temperature range: 32°F to 104°F (0°C to 40°C)
NOTE:
This product is intended for use with a certified Class
Limited Power Source, rated 5 Volts DC, maximum 1 Amp powe
supply unit.
Federal Co
Statement
This equipmen
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that i
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, whic
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate
Increase the separation between the equipmen
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radi
technician for help.
CC Caution
: Any chang
approved by the party responsible for compliance could vo
Safety and regulatory guide 9
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
5.25 GHz frequency band is restricted to
z
transmit
mpatibility (HAC) Regulations for
. Federal Communications Commission
lity
re
ise.
has
are
e
to
nes rated M3 or M4 meet FCC requirements and
4meet FCC requirements and are
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Operation on the 5.15-
indoor use only. The FCC requires indoor use for the 5.15-5.25 GH
band to reduce the potential for harmful interference to
co-channel Mobile Satellite Systems. Therefore, it will only
on the 5.25-5.35 GHz, 5.47-5.75 GHz and 5.725-5.825 GHz band
when using outdoors.
FCC Hearing-Aid Co
Wireless Devices
On July 10, 2003, the U.S
(FCC) Report and Order in WT Docket 01- 309 modified the
exception of wireless phones under the Hearing Aid Compatibi
Act of 1988 (HAC Act) to require digital wireless phones be
compatible with hearing-aids. The intent of the HAC Act is to
ensure reasonable access to telecommunications services for
persons with hearing disabilities. While some wireless phones a
used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining no
Some hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of
interference they generate. The wireless telephone industry
developed a rating system for wireless phones, to assist hearing
device users find phones that may be compatible with their
hearing devices. Not all phones have been rated. Phones that
rated have the rating on their box or a label located on the box.
The ratings are not guarantees. Results will vary depending on th
user’s hearing device and hearing loss. If your hearing device
happens to be vulnerable to interference, you may not be able
use a rated phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your personal
needs.
M-Ratings: Pho
are likely to generate less interference to hearing devices than
phones that are not rated. M4 is the better/higher of the two
ratings.
PM23220
is rated M3.
T-Ratings: Phones rated T3 or T
10 Safety and regulatory guide
likely to be more usable with a hearing aid’s telecoil than phones
that are not rated. T4 is the better/higher of the two ratings. Your
PM23220
is rated T4.
Please power off the Bluetooth function while using hearing aid
rated.
devices with your
PM23220
.
Hearing devices may also be
Your hearing device manufacturer or
hearing health professional may help
you find this rating. Higher ratings
mean that the hearing device is
relatively immune to interference
noise.
The hearing aid and wireless phone rating values are then added
fined
is
arks
ed in
ed for use with hearing aids for
ne
together. A sum of 5 is considered acceptable for normal use. A
sum of 6 is considered for better use. A sum of 8is considered for
best use. In the above example, if a hearing aid meets the M2 level
rating and the wireless phone meets the M3 level rating, the sum of
the two values equal M5. This should provide the hearing aid user
with “normal usage” while using their hearing aid with the
particular wireless phone. “Normal usage” in this context is de
as a signal quality that is acceptable for normal operation.
This methodology applies equally for T ratings. The M mark
intended to be synonymous with the U mark. The T mark is
intended to be synonymous with the UT mark. The M and T m
are recommended by the Alliance for Telecommunications
Industries Solutions (ATIS). The U and UT marks are referenc
Section 20.19 of the FCC Rules. The HAC rating and measurement
procedure are described in the American National Standards
Institute (ANSI) C63.19 standard.
This phone has been tested and rat
some of the wireless technologies that it uses. However, there may
be some newer wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is important to try
the different features of this phone thoroughly and in different
locations, using your hearing aid or cochlear implant, to determi
if you hear any interfering noise. Consult your service provider or
the manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange
policies, consult your service provider or phone retailer.
Safety and regulatory guide 11
For information about hearing aids and digital wireless
phones
FCC Hearing Aid Compatibility and Volume Control:
http://www.fcc.gov/cgb/dro/hearing.html
Gallaudet University, RERC:
https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm
SAR Information
0.934 W/kg@1g (HEAD)
1.13 W/kg@1g (BODY)
Body-worn Operation
This device was tested for typical body-worn operations. A
minimum separation distance must be maintained between the
user’s body and the handset, including the antenna:
y
1 cm to comply with the RF exposure requirements in the U.S.
Third-party belt-clips, holsters, and similar accessories used by this
device should not contain any metallic components. Body-worn
accessories that do not meet these requirements may not comply
with RF exposure requirements and should be avoided.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of regulations. Do not use
the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact
your local dealer for replacement antenna.
FCC RF Radiation Exposure Statement
This Transmitter has been demonstrated co-location compliance
requirements with built-in Bluetooth and WLAN.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment.
WEEE notice
The Directive on Waste Electrical and Electronic Equipment
(WEEE), which entered into force as European law on 13th
February 2003, resulted in a major change in the treatment of
electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other
12 Safety and regulatory guide
forms of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or
on its box indicates that this product must not be
disposed of or dumped with your other household
waste. You are liable to dispose of all your electronic
or electrical waste equipment by relocating over to
the specified collection point for recycling of such
hazardous waste. Isolated collection and proper
recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help
conserving natural resources. Moreover, proper
recycling of the electronic and electrical waste
equipment will ensure safety of human health and
environment. For more information about electronic
and electrical waste equipment disposal, recovery,
and collection points, please contact your local city
center, household waste disposal service, shop from
where you purchased the equipment, or
manufacturer of the equipment.
RoHS compliance
This product is in compliance with Directive 2002/95/EC of the
European Parliament and of the Council of 27 January 2003, on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS) and its amendments.
CEC Appliance Efficiency Compliance
The BC logo (shown at the left) indicates that this
product complies with the California Energy
Commission (CEC) energy efficiency standards for
battery charger systems set forth at California Code
of Regulations Title 20, Sections 1601 through 1608.
91H0XXXX-XXM Rev.A
htc.com
