User Manual
Safety and
regulatory guide
2 Safety and regulatory guide
Please read before proceeding
THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE THE
DEVICE OUT OF THE BOX.
Privacy restrictions
Some countries require full disclosure of recorded telephone
conversations.
Important health information and safety
precautions
When using this product, the safety precautions below must be
taken to avoid possible legal liabilities and damages.
Retain and follow all product safety and operating instructions.
Observe all warnings in the operating instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage
to the equipment, observe the following precautions.
Electrical safety
This product is intended for use when supplied with power from
the designated battery or power supply unit. Other usage may be
dangerous and will invalidate any approval given to this product.
Safety precautions for proper grounding installation
CAUTION
: Connecting to improperly grounded equipment can
result in an electric shock to your device.
This product is equipped with a USB Cable for connecting with
desktop or notebook computer. Be sure your computer is properly
grounded (earthed) before connecting this product to the
computer. The power supply cord of a desktop or notebook
computer has an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate
outlet which is properly installed and grounded in accordance with
all local codes and ordinances.
Safety precautions for power supply unit
Use the correct external power source
A product should be operated only from the type of power
source indicated on the electrical ratings label. If you are not
sure of the type of power source required, consult your
authorized service provider or local power company. For a
product that operates from battery power or other sources,
refer to the operating instructions that are included with the
product.
Safety and regulatory guide 3
This product should be operated only with the following
designated power supply unit(s).
AC adapter:
HTC, Model TC U250
Handle battery packs carefully
This product contains a Lithium-ion polymer or Lithium-ion battery.
There is a risk of fire and burns if the battery pack is handled
improperly. Do not attempt to open or service the battery pack. Do
not disassemble, crush, puncture, short external contacts or circuits,
dispose of in fire or water, or expose a battery pack to temperatures
higher than 60˚C (140˚F).
WARNING
: To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external
contacts, expose to temperature above 60° C
(140° F), or dispose of in fire or water. Recycle or
dispose of used batteries according to the local
regulations or reference guide supplied with your
product.
Take extra precautions
Keep the device dry and away from water or any liquid as it
may cause a short circuit.
The phone should only be connected to products that bear
the USB-IF logo or have the completed the USB-IF
compliance program.
If the battery leaks:
Do not allow the leaking fluid to come in contact with skin or
clothing. If already in contact, flush the affected area
immediately with clean water and seek medical advice.
Do not allow the leaking fluid to come in contact with eyes. If
already in contact, DO NOT rub; rinse with clean water
immediately and seek medical advice.
Take extra precautions to keep a leaking battery away from
fire as there is a danger of ignition or explosion.
Safety precautions for direct sunlight
Keep this product away from excessive moisture and extreme
temperatures. Do not leave the product inside a vehicle or in
4 Safety and regulatory guide
places where the temperature may exceed 60
°
C (140
°
F), such as
on a car dashboard, window sill, or behind a glass that is exposed
to direct sunlight or strong ultraviolet light for extended periods of
time. This may damage the product, overheat the battery, or pose
a risk to the vehicle.
Prevention of hearing loss
CAUTION
: Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods of time.
Safety in aircraft
Due to the possible interference caused by this product to an
aircraft’s navigation system and its communications network,
using this device’s phone function on board an airplane is against
the law in most countries. If you want to use this device when on
board an aircraft, remember to turn off your phone by switching to
Airplane Mode.
Environment restrictions
Do not use this product in gas stations, fuel depots, chemical
plants or where blasting operations are in progress, or in
potentially explosive atmospheres such as fuelling areas, fuel
storehouses, below deck on boats, chemical plants, fuel or
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or metal
powders. Please be aware that sparks in such areas could cause an
explosion or fire resulting in bodily injury or even death.
Explosive atmospheres
When in any area with a potentially explosive atmosphere or
where flammable materials exist, the product should be turned off
and the user should obey all signs and instructions. Sparks in such
areas could cause an explosion or fire resulting in bodily injury or
even death. Users are advised not to use the equipment at
refueling points such as service or gas stations, and are reminded
of the need to observe restrictions on the use of radio equipment
in fuel depots, chemical plants, or where blasting operations are in
progress. Areas with a potentially explosive atmosphere are often,
but not always, clearly marked. These include fueling areas, below
deck on boats, fuel or chemical transfer or storage facilities, and
areas where the air contains chemicals or particles, such as grain,
dust, or metal powders.
Safety and regulatory guide 5
Road safety
Full attention must be given to driving at all times in order to
reduce the risk of an accident. Using a phone while driving (even
with a hands free kit) causes distraction and can lead to an
accident. You must comply with local laws and regulations
restricting the use of wireless devices while driving.
Safety precautions for RF exposure
Avoid using your phone near metal structures (for example, the
steel frame of a building).
Avoid using your phone near strong electromagnetic sources,
such as microwave ovens, sound speakers, TV and radio.
Use only original manufacturer-approved accessories, or
accessories that do not contain any metal.
Use of non-original manufacturer-approved accessories may
violate your local RF exposure guidelines and should be avoided.
Hearing aids
Some digital wireless phones may interfere with some hearing aids.
In the event of such interference, you may want to consult your
service provider, or call the customer service line to discuss
alternatives.
Electrical safety
Accessories
Use only approved accessories.
Do not connect with incompatible products or accessories.
Connection to a car
Seek professional advice when connecting a phone interface to
the vehicle electrical system.
Faulty and damaged products
Do not attempt to disassemble the phone or its accessory.
Only qualified personnel must service or repair the phone or
its accessory.
General precautions
You alone are responsible for how you use your phone and any
consequences of its use. You must always switch off your phone
wherever the use of a phone is prohibited. Use of your phone is
subject to safety measures designed to protect users and their
environment.
Avoid applying excessive pressure to the device
Do not apply excessive pressure on the screen and the device to
6 Safety and regulatory guide
prevent damaging them and remove the device from your
pants’ pocket before sitting down. It is also recommended that
you store the device in a protective case and only use the device
stylus or your finger when interacting with the touch screen.
Cracked display screens due to improper handling are not
covered by the warranty.
Protect your phone
Always treat your phone and its accessories with care and
keep them in a clean and dust-free place.
Do not expose your phone or its accessories to open flames or
lit tobacco products.
Do not drop, throw or try to bend your phone or its
accessories.
Do not use harsh chemicals, cleaning solvents, or aerosols to
clean the device or its accessories.
Do not paint your phone or its accessories.
Do not attempt to disassemble your phone or its accessories,
only authorised personnel must do so.
Store your phone or its accessories at temperatures between
0°C to 40°C.
Please check local regulations for disposal of electronic
products.
Do not carry your phone in your back pocket as it could break
when you sit down.
Damage requiring service
Unplug the product from the electrical outlet and refer servicing
to an authorized service technician or provider under the
following conditions:
The product has been exposed to rain or liquid, dropped,
subject to impact or damaged.
There are noticeable signs of overheating.
The product does not operate normally when you follow the
operating instructions.
Avoid hot areas
The product should be placed away from heat sources such as
radiators, heat registers, stoves, or other products (including
amplifiers) that produce heat.
Avoid wet areas
Never use the product in rain, or near washbasins or other wet or
high humidity locations. If your product gets wet, do not try to
dry the product with the use of an oven or dryer, as this may
damage your product.
Safety and regulatory guide 7
Avoid using your device after a dramatic change in temperature
When you move your device between environments with very
different temperature and/or humidity ranges, condensation
may form on or within the device. To avoid damaging the device,
allow sufficient time for the moisture to evaporate before using
the device.
NOTICE
: When taking the device from low-temperature
conditions into a warmer environment or from high-temperature
conditions into a cooler environment, allow the device to
acclimate to room temperature before turning on power.
Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other
openings in the product. Slots and openings are provided for
ventilation. These openings must not be blocked or covered.
Adjust the volume
Turn down the volume before using headphones or other audio
devices.
Cleaning
Unplug the product from the wall outlet before cleaning. Do not
use liquid cleaners or aerosol cleaners. Use a damp cloth for
cleaning, but NEVER use water to clean the LCD screen.
Small children
Do not leave your phone and its accessories within the reach of
small children or allow them to play with it. They could hurt
themselves or others, or could accidentally damage the phone.
Your phone contains small parts with sharp edges that may
cause an injury or which could become detached and create a
choking hazard. Consult the doctor immediately if the
accessories or battery are swallowed.
Repetitive motion injuries
To minimise the risk of RSI, when Texting or playing games with
your phone:
Do not grip the phone too tightly
Press the buttons lightly
Electrostatic discharge (ESD)
Do not touch the SIM card’s metal connectors.
Emergency calls
This phone, like any wireless phone, operates using radio signals,
which cannot guarantee connection in all conditions. Therefore,
you must never rely solely on any wireless phone for emergency
communications.
8 Safety and regulatory guide
Regulatory agency identifications
For regulatory identification purposes, your product is assigned a
model number of
PM59110
.
To ensure continued reliable and safe operation of your device,
use only the accessories listed below with your
PM59110
The Battery Pack has been assigned a model number of
BM59100
.
NOTE:
This product is intended for use with a certified Class 2
Limited Power Source, rated 5 Volts DC, maximum 1 Amp power
supply unit.
Industry Canada Statement
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) this device
must accept any interference, including interference that may
cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
This Category II radio communication device complies with
Industry Canada Standard RSS-310.
The device could automatically discontinue transmission in case of
absence of information to transmit, or operational failure. Note
that this is not intended to prohibit transmission of control or
signaling information or the use of repetitive codes where required
by the technology.
IMPORTANT NOTE:
IC Radiation Exposure Statement
This EUT is compliance with SAR for general
population/uncontrolled exposure limits in IC RSS-102 and had
been tested in accordance with the measurement methods and
procedures specified in IEEE 1528 and IEC 62209-2. This device
was tested for typical head and body-worn operations. The
body-worn operation is limited to use with belt-clips, holsters or
similar accessories that have no metallic component in the
assembly and must provide at least 1 cm separation between the
device and the user's body.
This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter, except
tested built-in radios. The County Code Selection feature is
disabled for products marketed in the US/ Canada.
the device for operation in the band 5150-5250 MHz is only for
indoor use to reduce the potential for harmful interference to
Safety and regulatory guide 9
co-channel mobile satellite systems;
high-power radars are allocated as primary users (i.e. priority
users) of the bands 5250-5350 MHz and 5650-5850 MHz and
that these radars could cause interference and/or damage to
LE-LAN devices.
Federal Communication Commission Interference
Statement
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio or television
technician for help.
FCC Caution
: Any changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Operation on the 5.15-5.25 GHz frequency band is restricted to
indoor use only. The FCC requires indoor use for the 5.15-5.25 GHz
band to reduce the potential for harmful interference to
co-channel Mobile Satellite Systems. Therefore, it will only transmit
on the 5.25-5.35 GHz, 5.47-5.725 GHz and 5.725-5.850 GHz band
10 Safety and regulatory guide
when using outdoors.
FCC RF Radiation Exposure Statement
This Transmitter has been demonstrated co-location compliance
requirements with built-in Bluetooth and WLAN.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
This equipment complies with FCC RF radiation exposure limits
set forth for an uncontrolled environment.
FCC Hearing-Aid Compatibility (HAC) Regulations for
Wireless Devices
On July 10, 2003, the U.S. Federal Communications Commission
(FCC) Report and Order in WT Docket 01- 309 modified the
exception of wireless phones under the Hearing Aid Compatibility
Act of 1988 (HAC Act) to require digital wireless phones be
compatible with hearing-aids. The intent of the HAC Act is to
ensure reasonable access to telecommunications services for
persons with hearing disabilities. While some wireless phones are
used near some hearing devices (hearing aids and cochlear
implants), users may detect a buzzing, humming, or whining noise.
Some hearing devices are more immune than others to this
interference noise, and phones also vary in the amount of
interference they generate. The wireless telephone industry has
developed a rating system for wireless phones, to assist hearing
device users find phones that may be compatible with their
hearing devices. Not all phones have been rated. Phones that are
rated have the rating on their box or a label located on the box.
The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device
happens to be vulnerable to interference, you may not be able to
use a rated phone successfully. Trying out the phone with your
hearing device is the best way to evaluate it for your personal
needs.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and
are likely to generate less interference to hearing devices than
phones that are not rated. M4 is the better/higher of the two
ratings.
PM59110
is rated M3.
T-Ratings: Phones rated T3 or T4meet FCC requirements and are
likely to be more usable with a hearing aid’s telecoil than phones
that are not rated. T4 is the better/higher of the two ratings. Your
PM59110
is rated T3.
Please power off the Bluetooth function while using hearing aid
Safety and regulatory guide 11
devices with your
PM59110
.
Hearing devices may also be rated.
Your hearing device manufacturer or
hearing health professional may help
you find this rating. Higher ratings
mean that the hearing device is
relatively immune to interference
noise.
The hearing aid and wireless phone rating values are then added
together. A sum of 5 is considered acceptable for normal use. A
sum of 6 is considered for better use. A sum of 8is considered for
best use. In the above example, if a hearing aid meets the M2 level
rating and the wireless phone meets the M3 level rating, the sum of
the two values equal M5. This should provide the hearing aid user
with “normal usage” while using their hearing aid with the
particular wireless phone. “Normal usage” in this context is defined
as a signal quality that is acceptable for normal operation.
This methodology applies equally for T ratings. The M mark is
intended to be synonymous with the U mark. The T mark is
intended to be synonymous with the UT mark. The M and T marks
are recommended by the Alliance for Telecommunications
Industries Solutions (ATIS). The U and UT marks are referenced in
Section 20.19 of the FCC Rules. The HAC rating and measurement
procedure are described in the American National Standards
Institute (ANSI) C63.19 standard.
This phone has been tested and rated for use with hearing aids for
some of the wireless technologies that it uses. However, there may
be some newer wireless technologies used in this phone that have
not been tested yet for use with hearing aids. It is important to try
the different features of this phone thoroughly and in different
locations, using your hearing aid or cochlear implant, to determine
if you hear any interfering noise. Consult your service provider or
the manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange
policies, consult your service provider or phone retailer.
For information about hearing aids and digital wireless
phones
FCC Hearing Aid Compatibility and Volume Control:
http://www.fcc.gov/cgb/dro/hearing.html
12 Safety and regulatory guide
Gallaudet University, RERC:
https://fjallfoss.fcc.gov/oetcf/eas/reports/GenericSearch.cfm
SAR Information
0.816 W/kg@1g (HEAD)
1.533 W/kg@1g (BODY)
Body-worn Operation
This device was tested for typical body-worn operations. To
comply with RF exposure requirements, a minimum separation
distance of 1.0 cm must be maintained between the user’s body
and the handset, including the antenna. Third-party belt-clips,
holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do
not meet these requirements may not comply with RF exposure
requirements and should be avoided.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of regulations. Do not use
the phone with a damaged antenna. If a damaged antenna comes
into contact with the skin, a minor burn may result. Please contact
your local dealer for replacement antenna.
WEEE notice
The Directive on Waste Electrical and Electronic Equipment
(WEEE), which entered into force as European law on 13th
February 2003, resulted in a major change in the treatment of
electrical equipment at end-of-life.
The purpose of this Directive is, as a first priority, the prevention of
WEEE, and in addition, to promote the reuse, recycling and other
forms of recovery of such wastes so as to reduce disposal.
The WEEE logo (shown at the left) on the product or
on its box indicates that this product must not be
disposed of or dumped with your other household
waste. You are liable to dispose of all your electronic
or electrical waste equipment by relocating over to
the specified collection point for recycling of such
hazardous waste. Isolated collection and proper
recovery of your electronic and electrical waste
equipment at the time of disposal will allow us to help
conserving natural resources. Moreover, proper
recycling of the electronic and electrical waste
Safety and regulatory guide 13
equipment will ensure safety of human health and
environment. For more information about electronic
and electrical waste equipment disposal, recovery,
and collection points, please contact your local city
center, household waste disposal service, shop from
where you purchased the equipment, or
manufacturer of the equipment.
RoHS compliance
This product is in compliance with Directive 2002/95/EC of the
European Parliament and of the Council of 27 January 2003, on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment (RoHS) and its amendments.
91H0XXXX-XXM Rev.A
htc.com
