HTC TITA100 Pocket PC Phone User Manual Titan AKU3 Generic English Manual indb

HTC Corporation Pocket PC Phone Titan AKU3 Generic English Manual indb

User manual revised part 1

Pocket
User Manual
2
Please Read Before Proceeding
THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT
OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS
CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR
TAMPER WITH THE DEVICE’S OUTER CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone
conversations, and stipulate that you must inform the person
with whom you are speaking that the conversation is being
recorded. Always obey the relevant laws and regulations of
your country when using the recording feature of your Pocket
PC Phone.
INTELLECTUAL PROPERTY RIGHT INFORMATION
Copyright © 2006 High Tech Computer Corp. All Rights
Reserved.
, , , and ExtUSB are trademarks and/
or service marks of High Tech Computer Corp.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server,
Windows Mobile, ActiveSync, Excel, Internet Explorer, MSN,
Hotmail, Outlook, PowerPoint, Word, and Windows Media
are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by
Bluetooth SIG, Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance,
Inc.
microSD is a trademark of SD Card Association.
Java, J2ME and all other Java-based marks are trademarks or
registered trademarks of Sun Microsystems, Inc. in the United
States and other countries.
3
Copyright © 2006, Adobe Systems Incorporated.
Copyright © 2006, Macromedia Netherlands, B.V.
Macromedia, Flash, Macromedia Flash, Macromedia Flash
Lite and Reader are trademarks and/or registered trademarks
of Macromedia Netherlands, B.V. or Adobe Systems
Incorporated.
Copyright © 2006, JATAAYU SOFTWARE (P) LTD. All Rights
Reserved.
Copyright © 2006, Dilithium Networks, Inc. All Rights
Reserved.
Copyright © 2006, Tao Group Limited. All Rights Reserved.
ArcSoft MMS Composer™ Copyright © 2003-2006, ArcSoft, Inc.
and its licensors. All Rights Reserved. ArcSoft & the ArcSoft
logo are registered trademarks of ArcSoft, Inc. in the United
States and/or other countries.
Licensed by QUALCOMM Incorporated under one or more of
the following patents:
4,901,307 5,490,165 5,056,109 5,504,773 5,101,501 5,778,338
5,506,865 5,109,390 5,511,073 5,228,054 5,535,239 5,710,784
5,267,261 5,544,196 5,267,262 5,568,483 5,337,338 5,659,569
5,600,754 5,414,796 5,657,420 5,416,797
All other company, product and service names mentioned
herein are trademarks, registered trademarks or service marks
of their respective owners.
HTC shall not be liable for technical or editorial errors
or omissions contained herein, nor for incidental or
consequential damages resulting from furnishing this
material. The information is provided as is” without warranty
of any kind and is subject to change without notice. HTC also
reserves the right to revise the content of this document at
any time without prior notice.
No part of this document may be reproduced or transmitted
in any form or by any means, electronic or mechanical,
including photocopying, recording or storing in a retrieval
system, or translated into any language in any form without
prior written permission of HTC.
4
Important Health Information and Safety
Precautions
When using this product, the safety precautions below must
be taken to avoid possible legal liabilities and damages.
Retain and follow all product safety and operating
instructions. Observe all warnings in the operating
instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and
damage to the equipment, observe the following precautions.
ELECTRICAL SAFETY
This product is intended for use when supplied with power
from the designated battery or power supply unit. Other
usage may be dangerous and will invalidate any approval
given to this product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING
INSTALLATION
CAUTION: Connecting to an improperly grounded equipment
can result in an electric shock to your device.
This product is equipped with a USB cable for connecting the
product to a desktop or notebook computer. Be sure your
computer is properly grounded (earthed) before connecting
the product to the computer. The power supply cord of a
desktop or notebook computer has an equipment-grounding
conductor and a grounding plug. The plug must be plugged
into an appropriate outlet which is properly installed and
grounded in accordance with all local codes and ordinances.
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
Use the correct external power source
A product should be operated only from the type
of power source indicated on the electrical ratings
label. If you are not sure of the type of power source
required, consult your authorized service provider or
local power company. For a product that operates from
battery power or other sources, refer to the operating
instructions that are included with the product.
5
Handle battery packs carefully
This product contains a Li-ion Polymer battery. There
is a risk of fire and burns if the battery pack is handled
improperly. Do not attempt to open or service the
battery pack. Do not disassemble, crush, puncture, short
external contacts or circuits, dispose of in fire or water,
or expose a battery pack to temperatures higher than
60˚C (140˚F).
WARNING: Danger of explosion if battery is
incorrectly replaced. To reduce risk of fire or
burns, do not disassemble, crush, puncture, short
external contacts, expose to temperature above
60˚C (140˚F), or dispose of in fire or water. Replace
only with specified batteries. Recycle or dispose of
used batteries according to the local regulations or
reference guide supplied with your product.
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme
temperatures. Do not leave the product or its battery inside a
vehicle or in places where the temperature may exceed 60°C
(140°F), such as on a car dashboard, window sill, or behind a
glass that is exposed to direct sunlight or strong ultraviolet
light for extended periods of time. This may damage the
product, overheat the battery, or pose a risk to the vehicle.
PREVENTION OF HEARING LOSS
CAUTION: Permanent hearing loss may occur if earphones or
headphones are used at high volume for prolonged periods
of time.
SAFETY IN AIRCRAFTS
Due to the possible interference caused by this product to an
aircraft’s navigation system and its communications network,
using this device’s phone function on board an airplane is
against the law in most countries. If you want to use this
6
device when on board an aircraft, remember to turn off the
phone by switching to Flight Mode.
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical
plants or where blasting operations are in progress, or in
potentially explosive atmospheres such as fuelling areas, fuel
storehouses, below deck on boats, chemical plants, fuel or
chemical transfer or storage facilities, and areas where the air
contains chemicals or particles, such as grain, dust, or metal
powders. Please be aware that sparks in such areas could
cause an explosion or fire resulting in bodily injury or even
death.
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere
or where flammable materials exist, the product should be
turned off and the user should obey all signs and instructions.
Sparks in such areas could cause an explosion or fire resulting
in bodily injury or even death. Users are advised not to use
the equipment at refueling points such as service or gas
stations, and are reminded of the need to observe restrictions
on the use of radio equipment in fuel depots, chemical plants,
or where blasting operations are in progress. Areas with a
potentially explosive atmosphere are often, but not always,
clearly marked. These include fueling areas, below deck on
boats, fuel or chemical transfer or storage facilities, and areas
where the air contains chemicals or particles, such as grain,
dust, or metal powders.
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony
services with handheld devices, except in the case of
emergency. In some countries, using hands-free devices as an
alternative is allowed.
SAFETY PRECAUTIONS FOR RF EXPOSURE
Avoid using your device near metal structures (for
example, the steel frame of a building).
7
Avoid using your device near strong electromagnetic
sources, such as microwave ovens, sound speakers, TV
and radio.
Use only original manufacturer-approved accessories, or
accessories that do not contain any metal.
Use of non-original manufacturer-approved accessories
may violate your local RF exposure guidelines and
should be avoided.
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction.
The use of this device is forbidden in most hospitals and
medical clinics.
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information.
Turn the phone OFF in health care facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing
aids. In the event of such interference, you may want to
consult your service provider, or call the customer service line
to discuss alternatives.
NONIONIZING RADIATION
This product should be operated in the suggested normal
condition only to ensure the radiative performance and safety
of the interference. As with other mobile radio transmitting
equipment, users are advised that for satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that no part of the human body be allowed
to come too close to the antenna during operation of the
equipment.
8
GENERAL PRECAUTIONS
Heed service markings
Except as explained elsewhere in the Operating or
Service documentation, do not service any product
yourself. Service needed on components inside the
device should be done by an authorized service
technician or provider.
Damage requiring service
Unplug the product from the electrical outlet and refer
servicing to an authorized service technician or provider
under the following conditions:
Liquid has been spilled or an object has fallen into
the product.
The product has been exposed to rain or water.
The product has been dropped or damaged.
There are noticeable signs of overheating.
The product does not operate normally when you
follow the operating instructions.
Avoid hot areas
The product should be placed away from heat sources
such as radiators, heat registers, stoves, or other
products (including, but limited to, amplifiers) that
produce heat.
Avoid wet areas
Never use the product in a wet location.
Avoid using your device after a dramatic change in
temperature
When you move your device between environments
with very different temperature and/or humidity ranges,
condensation may form on or within the device. To
avoid damaging the device, allow sufficient time for the
moisture to evaporate before using the device.
9
NOTE: When taking the device from low-temperature
conditions into a warmer environment or from high-
temperature conditions into a cooler environment,
allow the device to acclimate to room temperature
before turning on the power.
Avoid pushing objects into product
Never push objects of any kind into cabinet slots or
other openings in the product. Slots and openings are
provided for ventilation. These openings must not be
blocked or covered.
Mounting Accessories
Do not use the product on an unstable table, cart,
stand, tripod, or bracket. Any mounting of the product
should follow the manufacturer’s instructions, and
should use a mounting accessory recommended by the
manufacturer.
Avoid unstable mounting
Do not place the product with an unstable base.
Use product with approved equipment
This product should be used only with personal
computers and options identified as suitable for use
with your equipment.
Adjust the volume
Turn down the volume before using headphones or
other audio devices.
Cleaning
Unplug the product from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning, but NEVER use water to
clean the LCD screen.
10
Contents
Chapter 1 Getting Started 15
1.1 Getting to Know Your Device and Its
Accessories ...................................................... 16
1.2 Battery Information ....................................... 22
1.3 Starting Up ...................................................... 24
1.4 The Today Screen ............................................ 26
1.5 Using the Programs ........................................ 30
1.6 Device Settings ............................................... 32
Chapter 2 Entering and Searching
Information 35
2.1 Using the Hardware Keyboard ...................... 36
2.2 Entering Information ..................................... 38
2.3 Using On-screen Keyboard ............................ 39
2.4 Using Letter Recognizer ................................. 39
2.5 Using Block Recognizer ................................. 40
2.6 Using Transcriber ............................................ 40
2.7 Using Symbol Pad ........................................... 42
2.8 Using Notes to Draw, Write, and
Record Voice Notes ......................................... 43
2.9 Searching Information ................................... 43
11
Chapter 3 Using Phone Features 45
3.1 Using the Phone ............................................. 46
3.2 Making a Call .................................................. 48
3.3 Receiving a Call ............................................... 50
3.4 Smart Dialing .................................................. 50
3.5 In-call Options ................................................ 54
3.6 Additional Dialing Information ..................... 55
Chapter 4 Synchronizing Information and
Setting Up E-mail Security 57
4.1 Setting Up ActiveSync .................................... 58
4.2 Synchronizing Information ........................... 62
4.3 Synchronizing via Infrared and Bluetooth ... 67
4.4 Synchronizing Music, Video, and Pictures .... 68
4.5 Setting Up E-mail Security ............................. 69
Chapter 5 Managing Your
Pocket PC Phone 73
5.1 Personalizing Your Pocket PC Phone ............ 74
5.2 Adding and Removing Programs .................. 81
5.3 Managing Memory ......................................... 83
5.4 Copying Files ................................................... 84
5.5 Protecting Your Pocket PC Phone ................. 86
5.6 Resetting Your Pocket PC Phone ................... 87
12
Chapter 6 Getting Connected 89
6.1 Connecting to the Internet ............................ 90
6.2 Internet Explorer Mobile ............................... 92
6.3 Using Comm Manager .................................... 95
6.4 Using Bluetooth .............................................. 96
6.5 Using Wi-Fi .................................................... 105
6.6 Using Internet Sharing ................................. 109
6.7 Using Terminal Services Client .................... 110
Chapter 7 Exchanging Messages and
Using Outlook 113
7.1 E-mail and Text Messages ............................ 114
7.2 MMS Messages ............................................. 123
7.3 Pocket MSN ................................................... 130
7.4 Calendar ........................................................ 132
7.5 Contacts ........................................................ 133
7.6 Tasks .............................................................. 137
7.7 Notes ............................................................. 139
Chapter 8 Experiencing Multimedia 143
8.1 Using Camera ................................................ 144
8.2 Using Pictures & Videos ...............................158
8.3 Using Windows Media Player ...................... 162
8.4 Using Streaming Media Player .................... 169
13
Chapter 9 Using Other Applications 173
9.1 Word Mobile ................................................. 174
9.2 Excel Mobile .................................................. 175
9.3 Viewing Slide Shows with
PowerPoint Mobile ....................................... 175
9.4 Using Adobe Reader LE ................................ 177
9.5 Using Java .....................................................179
9.6 Using ZIP ....................................................... 183
9.7 Using Voice Speed Dial ................................ 185
Appendix 189
A.1 Regulatory Notices ....................................... 190
A.2 PC Requirement to Run ActiveSync 4.x ...... 197
A.3 Specifications ............................................... 198
Index 201
14
1.1 Getting to Know Your Device and Its
Accessories
1.2 Battery Information
1.3 Starting Up
1.4 The Today Screen
1.5 Using the Programs
1.6 Device Settings
Chapter 1
Getting Started
16 Getting Started
1.1 Getting to Know Your Device and Its
Accessories
5
1
3
42
7
6
12
9
10
11
13
8
Getting Started 17
No. Item Function
1 MESSAGING Button Press to access your messages.
2 Notification LED 1 This LED shows the following:
A blinking Blue light for Bluetooth
system notification of powered-
up and ready to transmit radio
frequency signal.
A blinking Green light for Wi-Fi
status.
When both Bluetooth and Wi-Fi
are enabled, their lights blink
alternately.
3 Earpiece Listen to phone call.
4 Notification LED 2 This LED shows Green and Amber
lights for CDMA standby and network
status, notification, and battery
charging status.
5 INTERNET EXPLORER
Button
Press to open Internet Explorer
Mobile.
6 Hardware Keyboard This is a QWERTY-style keyboard just
like the computer keyboard. Slide
the touch-screen panel to the left to
reveal the keyboard.
7 Touch Screen Tap the screen with the stylus to
write, draw, or make a selection.
8 Left and Right SOFT
KEYS
Press to execute the command shown
in the label above the button.
9 TALK Button Press to answer an incoming call or
dial a number.
10 START Button Press to open the Start menu.
11 NAVIGATION Control/
ENTER
Press this multi-directional control up,
down, left, or right to move through
menus and program instructions;
carry out the selection by pressing
the center of this control.
12 OK Button Press to confirm your data entries, or
to exit the program in use.
13 END Button Press to end a call or to return to the
Today screen.
18 Getting Started
18 19
24
27
15
32
31 33
14
16
23
17
25
26
30
28 29
21
20
22
Getting Started 19
No. Item Function
14 Jog Wheel While on the Today screen or using
applications, scroll up or down to
navigate through menus or program
instructions; press the wheel to carry out
a selection. During a call or while playing
music, scroll up or down to adjust the
sound volume.
15 OK Button Press to confirm your data entries, or to
exit the program in use.
16 VOICE COMMAND
Button
Press to start Voice Speed Dial; press and
hold to record a voice note.
17 WLAN Switch Slide up to turn Wi-Fi on, down to turn
Wi-Fi off.
18 Camera Use the camera to take still photos and
record video clips.
19 Flash Light When turned on, it illuminates your
subject and allows you to capture clear
photos or video in dark-lit environments.
20 Speaker Listen to media.
21 Car Antenna
Connector
Connect your device to the car antenna
while in a car to have better reception
quality.
22 Battery Cover
Latch
Press downward to release the battery
cover.
23 Battery Cover After pressing down the cover latch,
remove the battery cover to access the
battery compartment.
24 POWER Button Press and hold to turn on the device.
Press to turn off the display
temporarily. This switches your device
to Sleep mode. You can still receive
calls and messages when your device
is in Sleep mode.
Press and hold (for about 5 seconds)
to turn off the power completely. All
functions including the phone will be
unavailable for use.
20 Getting Started
No. Item Function
25 COMM MANAGER
Button
Press to open the Comm Manager.
Comm Manager lets you easily turn
on/off your devices connections (such
as Bluetooth, Wi-Fi, and cellular data
connection), ringer, phone, etc.
26 CAMERA Button Press to launch the Camera; press again
to take a photo or video clip, depending
on the specified capture mode.
27 Stylus Use the stylus to write, draw, or select
items on the touch screen.
28 microSD Card Slot Insert a microSD memory card for
storing data.
29 Microphone Speak into the microphone when
receiving or making a phone call or
voice recording.
30 Strap Holder Attach a strap for carrying your device.
31 Infrared Port Exchange files or data with other devices
wirelessly.
32 RESET Button With the stylus, press the RESET button
to soft-reset your device.
33 Sync Connector/
Earphone Jack
Use this connector to synchronize
data by connecting the provided USB
Sync cable or to recharge the battery
via the provided AC adapter. You can
also connect the provided USB stereo
headset for hands-free conversation or
for listening to audio media.
Accessories
21
Getting Started 21
3 4
5 6
78< Stylus drawing not yet
available. To be inserted
soon... >
No. Accessory Function
1 AC adapter Recharges the battery.
2 USB Sync
cable
Connects your device to a PC and
synchronizes data.
3 Mini-USB
Stereo
headset
Provides a volume control slider and a Send/
End button. Press the Send/End button to
pick up a call or put a call on hold; press and
hold the button to end the call.
4 USB Cradle Allows you to recharge the battery contained
in your device and a second battery (if
purchased), as well as synchronize data
between your device and the PC via
ActiveSync.
To recharge the battery, connect the cradle
to the electrical outlet.
To synchronize data, connect the cradle to
the USB port in your PC.
5 One-to-two
Splitter
Adapter
Lets you connect the supplied AC adapter
and mini-USB stereo headset to your device
at the same time.
6 One-to-two
Y-Splitter
Cable
Lets you connect the supplied AC adapter
and a standard 2.5mm stereo headset to your
device at the same time.
22 Getting Started
No. Accessory Function
7 Pouch Comes with belt clip. Store your device in the
pouch to keep it from dust and scratches.
8 Stylus An extra stylus pen is provided.
1.2 Battery Information
Always turn off your device before installing or replacing the
battery. Follow the instructions in the Quick Start Guide to
install the battery.
Your device contains a rechargeable Li-ion polymer battery.
This device is designed to use only manufacturer-specified
original batteries and accessories. Battery performance
depends on many factors, including your wireless service
provider’s network configuration, signal strength, the
temperature of the environment in which you operate your
device, the features and/or settings you select and use, items
attached to connecting ports, and your voice, data, and other
program usage patterns.
Warning! To reduce risk of fire or burns:
Do not attempt to open, disassemble, or service the
battery pack.
Do not crush, puncture, short external contacts, or
dispose of in fire or water.
Do not expose to temperatures above 60oC (140oF).
Replace only with the battery pack designated for
this product.
Recycle or dispose of used battery as stipulated by
local regulation.
Getting Started 23
To check the battery power
Do one of the following:
Tap the battery level icon ( ) on the Today screen.
Alternatively, tap Start > Settings > Systems tab >
Power.
Battery power information
Charge the battery
New batteries are shipped partially charged. Before you start
using your device, it is recommended that you install and
charge the battery. Some batteries perform best after several
full charge/discharge cycles. You can charge the battery in
two ways:
Charging your devices battery by using the power
adapter.
Connecting your device to a PC via the provided USB
Sync cable.
Warning! Do not remove the battery from the device while
you are charging it using the AC or car adapter.
As a safety precaution, the battery stops charging
when it overheats.
24 Getting Started
Low battery
When the low-battery warning appears, do the following:
Immediately save your current data.
Synchronize with your PC or connect the power adapter
to charge the battery.
Turn off your device.
1.3 Starting Up
Turn your device on and off
To turn on your device, press and hold the POWER button.
When you turn on your device for the first time, a Quick
Start Wizard will guide you through the calibration process
and the setup of regional settings, date and time, password,
Outlook e-mail, and POP3/IMAP4 e-mail accounts. For more
information about touch screen calibration, see “Calibrate the
device”. For information about setting up Outlook e-mail and
POP3/IMAP4 e-mail accounts, see Chapter 7.
To turn off your device, press and hold the POWER button for
a few seconds. A message will then be displayed, prompting
you whether or not to turn off the device completely.
Switching your device to Sleep mode
Quickly pressing the POWER button turns off the display
temporarily and switches your device to Sleep mode. Sleep
mode suspends your device to a low power state while the
display is off in order to save battery power.
Your device also automatically goes into Sleep mode when
you leave the device idle after a certain amount of time.
To specify the timeout period before your device goes into
Sleep mode
1. Tap Start > Settings > System tab > Power >
Advanced tab.
2. Under On battery power, make sure the Turn off
device if not used for check box is selected.
Getting Started 25
3. Select the battery timeout period, then tap OK.
You will still be able to receive messages and calls while your
device is in Sleep mode. Pressing the POWER button again or
new incoming calls/messages will wake up your device.
Calibrate the device
Calibrating the device screen involves tapping the center of
a cross with the stylus as the cross moves around the screen.
This process ensures that when you tap the screen with your
stylus, the tapped item is activated.
If your device does not accurately respond to screen taps,
follow these steps to re-calibrate it:
1. Tap Start > Settings > System tab > Screen.
2. On the General tab, tap Align Screen, then follow the
on-screen instructions to complete the calibration.
Manage screen settings
The devices display has two orientation modes: Portrait and
Landscape. Portrait mode allows you to get a better view or a
better operation of certain programs, while Landscape mode
may be optimal for viewing lengthy files.
To change the orientation, tap Start > Settings >
System tab > Screen, and select the orientation you
want.
To smooth the edges of screen fonts for many programs,
on the ClearType tab, select the Enable ClearType
check box.
To increase the readability or to see more content on
the screen, on the Text Size tab, adjust the text size by
moving the slider.
26 Getting Started
1.4 The Today Screen
The Today screen displays important information, such as
upcoming appointments and status indicators. You can tap a
section on the screen to open the associated program.
To access the Today screen, tap Start > Today.
To customize the Today screen display, including the
background image, tap Start > Settings > Personal tab
> Today.
1
6
15
7
8
9
2 3 4 5
16
11
10
12
13
14
1Tap to open the Start menu.
2Tap to view connectivity status.
3Indicates the radio signal strength. Tap to configure the phone
settings.
4Tap to adjust device/ringer volume.
5Displays the current time. Tap to check the current date and
upcoming appointments. Tap and hold to change the clock
mode to Analog or Digital.
6Displays the current date and time. Tap to set up date, time,
alarm, and more.
7Tap to set owner information.
8Your day at a glance with reminders. Tap to open the related
program: messages, tasks, and appointments.
Getting Started 27
9
Tap to lock the device. The icon changes to .
Tap Unlock on the Today screen to unlock again.
10 Tap to sign in to Pocket MSN.
11 Indicates the battery status. Tap to open the Power Settings
screen.
12 Tap to toggle the screen between portrait and landscape
orientation.
13 Tap to open Comm Manager.
14 Tap to open the Backlight Settings screen.
15 Tap to open Calendar.
16 Tap to open Contacts.
Indicators
The following are some of the status icons that you may see
on the device.
Icon Description
New e-mail or text messages
New voice mail
New multimedia (MMS) message
New MSN message
There are more notifications. Tap the icon to view all.
Speakerphone on
Voice call in progress
Missed call
Maximum signal strength
No signal
Phone is turned off
No phone service
28 Getting Started
Icon Description
Searching for phone service
1xRTT available
EVDO available
Data connection is active and transmitting data
Data connection is active but idle
Roaming
Connection is active
Connection is not active
Synchronization in progress
Synchronization error
ActiveSync notification
Wi-Fi function enabled, but device not connected to a
wireless network yet
Wireless network(s) detected
Connecting to wireless network (arrows moving);
Connected to wireless network
Synchronizing via Wi-Fi
Vibration mode
Sound on
Sound off
Alarm
Battery is fully charged
Battery power is very low
Battery charging
Getting Started 29
Icon Description
Device is locked
Device is unlocked
Bluetooth headset detected
Serial USB connection active
Note The USB to PC ( ) icon appears on the Today Screen when
your device is connected to your computer and you enable a
serial USB connection between them. For more information
about USB to PC, see “Device Settings” later in this chapter.
The Start menu
The Start menu, located at the top left corner of the Today
screen, displays a list of programs. You can start a program by
scrolling through the programs list and then pressing ENTER,
or by tapping a program with the stylus.
1Tap to switch to the
Today screen.
2Tap to start a program.
The items displayed in
the Start menu can be
customized by tapping
Start > Settings >
Personal tab > Menus.
3Tap to start a recently-
used program.
4Tap to view and select
more programs that are
installed on your device.
5Tap to change device
settings.
6Tap to see a Help topic
for the current screen.
1
2
5
4
6
3
30 Getting Started
1.5 Using the Programs
The following are some of the programs that are already
installed on your device.
Icon Description
ActiveSync Synchronizes information between your
device and a PC or the Exchange Server.
Adobe Reader LE Enables you to view PDF (Portable
Document Format) files on your device.
Calculator Lets you perform basic arithmetic and
calculations, such as addition, subtraction, multiplication,
and division.
Calendar Allows you to keep track of your appointments
and create meeting requests.
Camera Snaps photos or shoots video clips
accompanying audio.
Contacts Allows you to keep track of your friends and
colleagues.
Download Agent Provides information about the
download status and the downloaded content from the
Internet.
Excel Mobile Creates new workbooks or lets you view
and edit Excel workbooks.
File Explorer Enables you to organize and manage files
on your device.
Games Lets you play two pre-installed games: Bubble
Breaker and Solitaire.
Help Enables you to see Help topics for a program on
your device.
Internet Sharing Allows you to connect your notebook
computer to the Internet using your device's data
connection.
Internet Explorer Mobile Allows you to browse Web
and WAP sites as well as download new programs and
files from the Internet.
Java Enables you to download and install Java
applications, such as games and tools, on your device.
Getting Started 31
Icon Description
Messaging Allows you to send and receive e-mail, MMS,
and text messages.
Notes Allows you to create handwritten or typed notes,
drawings, and recordings.
Phone Lets you make and receive calls, switch between
calls, and set up conference calling.
Pictures & Videos Lets you view, organize, and sort
picture and video files on your device or a storage card.
Captured photos are stored in the My Pictures folder,
and video clips are saved in the My Videos folder of your
device.
Pocket MSN Lets you send and receive instant messages
with your MSN Messenger contacts, as well as access your
Hotmail account, if you have one.
PowerPoint Mobile Lets you view PowerPoint slides and
presentations.
Search Enables you to search contacts, data, and other
information on your device.
Streaming Media Allows you to stream live or on-
demand video.
Tasks Allows you to keep track of your tasks.
Terminal Services Client Allows you to log on a PC
running Terminal Services or Remote Desktop, and use
all of the programs available on that PC from your mobile
device.
Text Messages Retry Resends SMS messages that failed
delivery.
Voice Speed Dial Allows you to record voice tags so that
you can dial a phone number or launch programs simply
by speaking a word.
Windows Media Player Mobile Lets you play back
audio and video files.
Word Mobile Lets you create, view, and edit Word
documents.
ZIP Enables you to save memory and free up storage
space on your device by compressing files in the
conventional ZIP format.
32 Getting Started
1.6 Device Settings
You can adjust the device settings to suit the way you work.
To see all available settings, tap Start > Settings, then tap
the Personal, System, and Connections tabs located at the
bottom of the screen.
Personal tab
Icon Description
Buttons Assigns a program to a hardware button.
Input Sets options for each of the input methods.
Lock Sets a password for your device.
Menus Sets what programs will appear in the Start
menu.
MSN Options Allows you to customize settings for
the applications included in Pocket MSN such as MSN
Hotmail and MSN Messenger.
Owner Information Allows you to enter your personal
information on your device.
Phone Allows you to customize phone settings such as
ring tone, optional phone services, and more.
Sounds & Notifications Enables sounds for events,
notifications, and more, and allows you to set the type of
notification for different events.
Today Allows you to customize the appearance and the
information to be displayed on the Today screen.
Voice Speed Dial Allows you to create voice tags for
voice dialing contacts as well as for launching programs.
Getting Started 33
System tab
Icon Description
About Allows you to specify a name for your device.
Also shows the Windows Mobile version and copyright
information.
Backlight Sets the backlight timeout and brightness.
Certificates Shows information about certificates that
are installed on your device.
Clear Storage Removes all your data and files from
the memory and resets your device to factory default
settings.
Clock & Alarms Switches the device clock to the date
and time of your locale or to a visiting time zone when
you're traveling. Alarms can also be set at specified days
and times of a week.
Device Information Shows information about the
firmware version, hardware, identity, and the duration of
calls made on your device.
Error Reporting Enables or disables the device's error
reporting function. When this function is enabled and a
program error occurs, technical data about the state of
the program and your computer will be logged in a text
file and delivered to Microsoft's technical support if you
choose to send it.
Key Lock Locks the buttons on your device except for
the POWER button when the device is in Sleep mode.
This ensures you will not switch the device on by
accident and consume unnecessary power.
Memory Shows the device memory allocation status
and memory card information. Also allows you to stop
currently running programs.
Microphone AGC Adjusts the volume of your voice
automatically when you are recording.
Power Shows the current battery level. Also allows you
to set the timeout for turning off the display (switching
device to Sleep mode) to conserve battery power.
34 Getting Started
Icon Description
Regional Settings Sets the regional format to use for
displaying numbers, currency, date, and time on your
device.
Remove Programs Lets you remove programs that you
installed on your device.
Screen Allows you to change the screen orientation, re-
calibrate the screen, and change the screen text size.
Connections tab
Icon Description
Beam Enables your device to receive incoming infrared
and Bluetooth beams.
Bluetooth Turns Bluetooth on, sets your device to
visible mode, and allows you to scan for other Bluetooth
devices.
Comm Manager
Allows you to manage the device’s
connections (including Bluetooth, Wi-Fi, and cellular data
connection), turn the phone function on or off, change to
ringer or vibration mode, and more
.
Connections Sets up one or more types of modem
connections for your device, such as phone dial-up,
Bluetooth, and more, so that your device can connect to
the Internet or a private local network.
USB to PC Sets the USB connection between your device
and PC, and helps with problems connecting ActiveSync.
Wi-Fi Allows your device to scan for available wireless
networks.
Wireless LAN Shows information about the active
wireless network, and allows you to customize Wi-Fi
settings.
2.1 Using the Hardware Keyboard
2.2 Entering Information
2.3 Using On-screen Keyboard
2.4 Using Letter Recognizer
2.5 Using Block Recognizer
2.6 Using Transcriber
2.7 Using Symbol Pad
2.8 Using Notes to Draw, Write, and
Record Voice Notes
2.9 Searching Information
Chapter 2
Entering and Searching
Information
36 Entering and Searching Information
2.1 Using the Hardware Keyboard
Your device provides you with a QWERTY keyboard, which is
similar to a standard keyboard on your PC.
Slide the screen
panel to the left to
reveal the keyboard.
Shift Key /
Caps Lock LED
Function Key
LED
Left SOFT KEY Right SOFT KEY
Function Key
When you slide open the hardware keyboard, the screen
automatically changes to landscape view. The screen changes
back to portrait view when you close the hardware keyboard.
You can do the following with the QWERTY keyboard:
To type lowercase letters, press the keys using your
thumbs or fingers.
To turn on Caps Lock mode so that you can type all
uppercase letters, press the Function Key ( ) first,
then press . The Shift Key/Caps Lock LED lights up
to indicate that Caps Lock mode is enabled. To turn off
Caps Lock mode, press these buttons again.
Entering and Searching Information 37
To type a single uppercase letter, press
and then
press the desired letter.
To enter a number or symbol (labeled in color on the
keys), press and then press the corresponding key.
To open the Symbol Pad, press
and then press .
Press the Left/Right SOFT KEY ( / ) to
perform the command shown in the label above the key.
Press to verify your data entries or exit the program
in use.
Press to open the Start menu.
Press the arrow keys for directional
movement.
To type accented characters (like á, ã, ç, ê, í, ó, ü, etc),
press the letter key first, then hold
and at the same
time press the space bar several times until you
find the correct character you need.
38 Entering and Searching Information
2.2 Entering Information
When you start a program or select a field that requires text
or numbers, the Input Panel icon becomes available on the
menu bar.
Tap the Input Selector arrow (that appears next to the Input
Panel icon) to open a menu where you can select a text
input method and customize input options. After selecting
a text input method, the corresponding Input Panel is then
displayed and you can use it to enter text. To toggle between
showing and hiding the Input Panel, simply tap the Input
Panel icon.
Input Panel
(Keyboard)
Input Selector
arrow
Input Panel icon
Icon Input method
On-screen Keyboard
Letter Recognizer or Block Recognizer
Symbol Pad
Transcriber
Note Some text input methods may not be available in certain
language versions of the device.
Entering and Searching Information 39
2.3 Using On-screen Keyboard
The on-screen Keyboard is available when text entry is
possible. You can enter text by tapping keys on the keyboard
that are displayed on the screen.
To enter text using the on-screen Keyboard
1. In a program, tap the Input Selector arrow, and tap
Keyboard.
2. Enter text by tapping keys on the on-screen Keyboard.
To enlarge the on-screen Keyboard
1. Tap the Input Selector arrow, then tap Options.
2. In the Input method list, select Keyboard.
3. Tap Large keys.
2.4 Using Letter Recognizer
With Letter Recognizer, you can write individual letters,
numbers, and punctuation, which are then converted into
typed text.
To use Letter Recognizer
1. From a program, tap the Input Selector arrow, and tap
Letter Recognizer.
2. Write characters, numbers, and symbols in the
designated writing area.
Enter capital letters by writing in the ABC (left) area
of the box.
Enter lower case letters by writing in the abc
(middle) area of the box.
Enter numbers by writing in the 123 (right) area of
the box.
Enter punctuation and symbols by tapping in
either area of the box and then writing the desired
character.
40 Entering and Searching Information
Note Letter Recognizer is available when text entry is possible.
Tip For help with writing characters, tap the question mark near
the writing area.
2.5 Using Block Recognizer
With Block Recognizer, you use a single stroke to write
letters, numbers, symbols, and punctuation, which are then
converted into typed text.
To use Block Recognizer
1. From a program, tap the Input Selector arrow, and tap
Block Recognizer.
2. Write characters, numbers, and symbols in the
designated writing area.
Enter letters by writing in the abc (left) area of the
box.
Enter numbers by writing in the 123 (right) area of
the box.
Enter symbols and punctuation by tapping in
either area of the box and then writing the desired
character.
Note Block Recognizer is available when text entry is possible.
Tip For help with writing characters with Block Recognizer, tap
the question mark near the writing area.
2.6 Using Transcriber
Transcriber is a handwriting recognition program that
allows you to write in cursive, print, or a combination of
both. Transcriber works transparently in the background of
programs, recognizing words with its integrated dictionary.
When Transcriber is turned on, it interprets stylus movement
anywhere on the screen as handwriting input. For more
information about using Transcriber, see Help on your device.
Entering and Searching Information 41
To start Transcriber
1. Start a program that accepts user input, such as Word
Mobile.
2. Tap the Input Selector arrow, and tap Transcriber. The
Transcriber introductory screen appears.
To write using Transcriber
1. In a program, position the cursor where you want text
to appear.
2. Use the stylus to write anywhere on the screen. The
handwriting will be converted to text shortly after you
lift the stylus from the screen.
To enter punctuation and symbols
Transcriber comes with an on-screen keyboard that provides
an easy way to add punctuation or a special symbol to
existing text.
From a program, tap on the Transcriber toolbar.
The keyboard remains visible until you tap the button again.
Tips To reposition the keyboard, tap and hold the title bar, then
drag to the desired location.
When no text is selected, you can also open the keyboard
by doing the gesture. For more information about using
Transcriber gestures, see Help on your device.
To edit text
1. In a program, draw a line across the text you want to
edit.
2. After you lift the stylus from the screen, the line will
disappear and the selected text will be highlighted.
3. Do either of the following:
Rewrite the text.
Use gestures to capitalize letters, insert a space,
and so on. For information about using Transcriber
gestures, see Help on your device.
42 Entering and Searching Information
2.7 Using Symbol Pad
Symbol Pad provides a comprehensive list of common
symbols such as parentheses, brackets, currency signs, and
more, as well as punctuation marks and special characters.
Tap a symbol to select it. Use the
Navigation Control or press the
arrow keys
on
the hardware keyboard to navigate
through the available symbols,
then press ENTER to select a
symbol.
Tap to display the previous page
of symbols.
Tap to display the next page of
symbols.
Tap to close the Symbol Pad
without selecting any symbol.
This indicates the current page and
the total number of symbol pages.
To open the Symbol Pad and select a symbol
1. Create or open a document, such as a Word document.
2. To open the Symbol Pad:
Tap the Input Selector arrow, then tap Symbol Pad;
or
Using the hardware keyboard, pres
s
and then
press .
3. To browse through the pages of symbols, tap /
on the Symbol Pad screen.
4. Tap a symbol to select it and close the Symbol Pad. The
selected symbol will then be inserted in your document.
Entering and Searching Information 43
2.8 Using Notes to Draw, Write, and Record
Voice Notes
Using Notes, you can draw directly on the screen, or write on
the screen and save notes in your own handwriting. You can
also create a stand-alone recording (voice note) or you can
add a recording to a note.
For more information on what you can do with Notes, see
“Notes” in Chapter 7.
2.9 Searching Information
You can search for files and other items stored in My
Documents folder or on an installed storage card of your
device. You can search by file name or by words located in the
item. For example, you can search in e-mail messages, notes,
appointments, contacts, and tasks, as well as in online Help.
To search for a file or an item
1. Tap Start > Programs > Search.
2. In the Search for field, you can:
Enter the file name, word, or other information you
want to search for.
Tap the down arrow icon ( ), and from the list,
select one item that you have looked for before.
3. In the Type field, you can tap the down arrow icon ( )
and select a data type from the list to help narrow your
search.
4. Tap Search. The system then starts searching the
matched files in the My Documents folder and
subfolders.
5. In the Results list, tap the item you want to open.
Note The storage card symbol is displayed next to the names
of files saved on a storage card.
44 Entering and Searching Information
3.1 Using the Phone
3.2 Making a Call
3.3 Receiving a Call
3.4 Smart Dialing
3.5 In-call Options
3.6 Additional Dialing Information
Chapter 3
Using Phone Features
46 Using Phone Features
3.1 Using the Phone
Like a standard mobile phone, you can use your device to
make, receive, and keep track of calls and send SMS/MMS
messages. You can also dial directly from Contacts.
The Phone screen
From the Phone screen, you can access Call History, Speed
Dial, and Phone settings. To open the Phone screen, do one of
the following:
Press the TALK button ( ).
TALK button
Directly dial the phone number by pressing numeric
keys on the hardware keyboard.
Tap Start > Phone.
Turn the phone function on and off
In many countries, you are required by law to turn off your
phone while on board an aircraft.
To turn off the phone function, do one of the following:
Tap the Signal icon ( ) then tap
Comm Manager
, or
tap the Comm Manager icon ( ) on the Today screen.
On the Comm Manager screen, tap the Phone button to
turn off the phone function
.
To resume call function, turn on the phone function
by tapping the Phone button again on the Comm
Manager screen.
Using Phone Features 47
Adjust the device volume
1. Tap the Speaker icon ( ).
2. Under Volume, do the following:
Adjust the phone volume ( ) or device volume
( ) by moving the slider to the desired volume
level.
Tap On, Vibrate, or Off to change both the system
and ringer volume settings.
Volume adjustment
Notes
To adjust the conversation phone volume, you must do
it during a call. Adjusting the volume at another time will
affect the ring, notification, and MP3 sound levels.
When you activate Vibrate mode, sound will automatically
be muted and your device will vibrate when an incoming
call is received. The Vibrate icon ( ) will appear in the
title bar to indicate that Vibrate mode is activated.
48 Using Phone Features
3.2 Making a Call
With your device, you can make a call from Phone, Contacts,
Speed Dial, and Call History.
Make a call from Phone
1. Tap Start > Phone.
2. On the Phone screen, tap the desired phone number,
and tap Talk.
Talk button
Voice Privacy notification indicator
Location Setting indicator
Battery Power indicator
Phone screen
Tips If you tap a wrong number, tap the Back arrow ( )
to erase each subsequent digit of a number. To erase the
entire number, tap and hold the Back arrow.
The icons on the upper right of the Phone screen indicate
the battery power level and optional phone services. For
more information about optional phone services, see
Chapter 5.
Make a call from Contacts
Tap Start > Contacts, then do one of the following:
Tap the desired contact in the contacts list, and tap the
phone number that you want to call.
Tap and hold the desired contact, and on the shortcut
menu, tap Call Work, Call Home, or Call Mobile.
Using Phone Features 49
Press NAVIGATION up or down or roll the Jog Wheel to
select a contact, and press TALK twice (once to send
the number to the Phone keypad, and once to dial the
number).
To choose one of the numbers of a contact to dial
By default, the mobile telephone number (m) of a contact is
dialed when you make a call from Contacts. However, you can
specify that a different phone number is dialed instead.
1. Tap Start > Contacts.
2. Press NAVIGATION up or down to select a contact.
3. Press NAVIGATION left or right. The letters representing
the number will change as you scroll through them.
Make a call from Call History
1. On the Phone screen, tap Call History.
2. Scroll to the desired contact or phone number, and tap
Call.
Make a call from Speed Dial
Use Speed Dial to call frequently-used numbers with a single
tap. For example, if you assign a contact to the location 2 in
Speed Dial, you can simply tap and hold on the Phone
screen to dial the contact’s number. Before you can create a
Speed Dial entry, the number must already exist in Contacts.
To create a Speed Dial entry
1. On the Phone screen, tap Menu > Speed Dial.
2. Tap Menu > New.
3. Tap a contact. Select the phone number that you want
to add to Speed Dial.
4. In the Location box, select an available location for the
new Speed Dial entry.
Note Location 1 is generally reserved for your voice mail, and
Speed Dial will designate the next available location by
default. If you want to place a phone number in a position
that is already occupied, the new number will replace the
number that is already there.
50 Using Phone Features
Tips
To create a Speed Dial entry from Contacts, tap and hold
the contact name, tap Add to Speed Dial, then select the
phone number for which to create a Speed Dial and an
available location for the new Speed Dial entry.
To delete a Speed Dial entry, in the Speed Dial list, tap
and hold the desired entry, and tap Delete.
3.3 Receiving a Call
When you receive a phone call, a message will appear, giving
you the option to either answer or ignore the incoming call.
To answer or reject an incoming call
To answer the call, tap Answer, or press TALK ( ) on
the device.
To reject the call, tap Ignore, or press END ( ) on the
device.
To end a call
Once an incoming or outgoing call is in progress, you can tap
End or press END ( ) on the device to hang up.
3.4 Smart Dialing
Smart Dialing is a program that makes it easy for you to
dial a phone number. When you start entering numbers or
characters, Smart Dialing will automatically search and sort
the contact entries in Contacts and the phone numbers in
Call History (including incoming, outgoing, and missed calls).
You can then select the desired number or contact from the
filtered list to dial.
Start Smart Dialing
Open the Phone screen, then tap the keys on the Phone
keypad that correspond to the phone number or contact you
want to call.
When you start entering a number or letter, the Smart Dialing
panel will appear automatically on the Phone screen. You can
Using Phone Features 51
change the panel size according to your needs by tapping the
arrow icon .
Portrait view with minimized
Smart Dialing panel
Landscape view with expanded Smart
Dialing panel
Tap to minimize or expand
the Smart Dialing panel
Tips on using Smart Dialing
Smart Dialing starts looking for numbers or contacts that
match the sequence you have entered. Below are some tips
on how to use Smart Dialing to quickly find a desired phone
number or contact.
To find a phone number
Simply enter the first one or two digits to find a phone
number in Call History.
Enter the first three digits or more if you want to find a
phone number from the saved contacts on your device.
To find a contact name
You can just enter the first letter of a contacts first name
or surname. Smart Dialing will search for the letter starting
from the first character of a contact name as well as from the
character that appears after a space, dash, or underscore in
a contact name. For example, if you tap number “2” which is
associated with [a, b, c] on the Phone keypad, contact names
such as the following will be considered matches: Ben Miller”,
52 Using Phone Features
“George Adams, John-Carter”, Carter, Ellen”, “Dixon, Allan”,
Thomas_Clark”, JaneCampbell”.
If the matching list is long and you want to narrow down the
search further, enter another letter. Using the same example
above, if you continue to tap “3” which is associated with [d, e,
f], the matching list will be narrowed down to the following
names: Ben Miller”, “George Adams”, Carter, Ellen”, Dixon,
Allan.
Make a call or send a text message using
Smart Dialing
1. Begin entering the first few numbers or characters.
2. In the Smart Dialing panel, browse the list by tapping
the arrows
( / ), pressing NAVIGATION up or down, or rolling
the Jog Wheel to select the desired contact or phone
number. When a contact is selected, it expands to also
show the corresponding phone number.
3. The highlighted item will move one line when you press
NAVIGATION up or down or roll the Jog Wheel; the
highlighted item will scroll one page when you tap the
arrows.
4. Do one of the following:
When the correct contact is selected, tap Talk or
press the TALK button ( ) to make a voice call.
To call a different phone number associated with the
selected contact, tap and hold the selected contact,
and tap the phone number you want to call.
Using Phone Features 53
Tap and hold the contact to pop up the shortcut menu
To send a text message to the selected contact, tap
and hold the contact, and tap Send Text Message.
Tip
To view or edit information associated with the selected
contact, tap the contact’s name on the shortcut menu.
Set up Smart Dialing
1. On the Phone screen, tap Menu > Smart Dialing
Options.
2. On the Options tab, select the Enable Smart Dialing
check box.
Select the Automatically expand selected contact
check box to enable a contact’s name and phone
number to be displayed when the contact is selected
in the matching list.
Select the Enable drag-scroll check box to scroll in
the matched list by dragging.
Select the Enable double-click for dialing check
box to make a voice call by double-tapping the item
in the matched list.
Select the Expand panel when using hardware
keyboard check box to automatically expand the
Smart Dialing panel when you are using the sliding
keyboard to input.
54 Using Phone Features
In Scroll unit, you can set the amount of scrolling
when tapping the arrows ( / ).
3.5 In-call Options
To put a call on hold
Your device notifies you when you have another incoming
call, and gives you the choice of rejecting or accepting the
call. If you are already on a call and accept the new call, you
can choose to switch between the two callers, or set up a
conference call between all three parties.
1. Tap Answer to take the second call, and put the first one
on hold.
2. To end the second call and return to the first call, tap
End or press END ( ) on the device.
To switch between two calls
Press TALK ( ) on your device.
To set up a conference call
To set up a conference call, the second call must be an
outgoing call.
1. Place the first call or take an incoming call.
2. Put the call on hold then dial a second number.
3. Press TALK ( ) on your device to join the two calls into
a conference call.
Note Not all service providers support conference calling. Contact
your service provider for details.
To turn on and off the Speakerphone
The built-in Speakerphone on your device allows you to talk
hands-free or lets other people listen to the conversation.
During a call, tap Speaker On, or press and hold
TALK ( ) until the speakerphone turns on. The
speakerphone icon ( ) appears in the title bar.
Using Phone Features 55
To turn off the speakerphone, tap Speaker Off, or press
and hold TALK ( ) again until the speakerphone turns
off.
Warning! To avoid damage to your hearing, do not hold your device
against your ear when the Speakerphone is turned on.
To mute a call
You can turn off the microphone during a call, so that you can
hear the caller but the caller cannot hear you.
During a call, tap Mute.
When the microphone is turned off, the mute icon
( ) appears on the screen. Tap Unmute to turn on
the microphone again.
3.6 Additional Dialing Information
Make an emergency call
Enter the international emergency number for your
locale, and tap Talk.
Make an international call
1. Tap and hold on the Phone keypad until the + sign
appears. The + replaces the international prefix of the
country that you are calling.
2. Enter the full phone number you want to dial, and tap
Talk. The full phone number includes country code,
area code (without the leading zero, if any) and phone
number.
56 Using Phone Features
4.1 Setting Up ActiveSync
4.2 Synchronizing Information
4.3 Synchronizing via Infrared
and Bluetooth
4.4 Synchronizing Music, Video,
and Pictures
4.5 Setting Up E-mail Security
Chapter 4
Synchronizing Information
and Setting Up E-mail
Security
58 Synchronizing Information and Setting Up E-mail Security
4.1 Setting Up ActiveSync
Microsoft ActiveSync synchronizes information on your
device with information on your PC, such as Outlook content.
ActiveSync can also synchronize over a wireless or cellular
network with Microsoft Exchange Server, if your company or
service provider is running Microsoft Exchange Server with
Exchange ActiveSync.
Specifically, you can use ActiveSync to:
Synchronize information, such as Outlook E-mail,
Contacts, Calendar, or Tasks information, as well as
media files such as pictures, video, and music between
your device and your PC.
Synchronize Outlook E-mail, Contacts, Calendar
appointments, and Tasks on your device directly with
Exchange Server so that you can stay up-to-date even
when your PC is turned off.
Copy files between your device and your PC without
synchronizing.
Select which types of information are synchronized
and specify how much information is synchronized.
For example, you can choose how many weeks of past
Calendar appointments to synchronize.
Add and remove programs on your device. For details,
see Chapter 5, Adding and Removing Programs.
To install and set up ActiveSync on the computer
1. Install ActiveSync on your PC, as described in the
Getting Started Disc.
2. After ActiveSync is installed, the Synchronization Setup
Wizard automatically starts when you connect your
device to the PC. The wizard will guide you to create a
synchronization relationship between your computer
and device. Click Next.
Synchronizing Information and Setting Up E-mail Security 59
3. Do not select the Synchronize directly with a server
running Microsoft Exchange Server check box if you
want to synchronize your device with a computer. Just
click Next, then skip to step 8.
4. If you want to synchronize your device with Exchange
Server, select the Synchronize directly with a server
running Microsoft Exchange Server check box, then
click Next.
5. On the Exchange server credentials screen, enter the
Exchange server address, your user name and password,
and the domain name.
If you do not know the Exchange server address and the
domain name, check with your network administrator,
or do the following to find them in your computer:
a. In Outlook, click Tools > E-mail Accounts.
b. Select View or change existing e-mail accounts.
c. Double-click Microsoft Exchange Server.
d. On the Exchange Server Settings screen, you will see
the Exchange Server name.
60 Synchronizing Information and Setting Up E-mail Security
e. To check the domain name, click Start > Settings >
Control Panel, then double-click System.
f. In the System Properties dialog box, click the
Computer Name tab. You will then see the domain
name.
6. On your device, you also need to enter the Exchange
server settings. For information about this, see
“Synchronize Outlook information with Exchange
Server.
7. On the Synchronization Setup Wizard, click Next.
8. Select the information types to synchronize between
your device and computer.
If you want to synchronize your device with both your
computer and Exchange Server, do the following:
Synchronizing Information and Setting Up E-mail Security 61
a. For the Contacts, Calendar, E-mail, and Tasks items,
choose whether to synchronize them with the
computer or with the Exchange Server. These items
cannot be synchronized to both.
b. Select the check boxes of the other information
types if you want to synchronize them with your
computer.
Information types on the PC and Exchange Server
9. Click Next.
10. Click Finish.
When you finish the wizard, ActiveSync synchronizes your
device automatically. Once synchronization completes, you
can disconnect your device from your PC.
62 Synchronizing Information and Setting Up E-mail Security
4.2 Synchronizing Information
When you connect your device to the PC using a USB cable,
an infrared connection, or a Bluetooth connection, ActiveSync
will immediately synchronize. While your device is connected,
ActiveSync synchronizes every time you make a change on
either the PC or your device.
To manually start and stop synchronization
1. Connect your device to the PC:
To synchronize Outlook information and other
local information on the PC, including media files,
connect your device to the PC using Bluetooth,
infrared (IR) or a USB cable.
If you are synchronizing directly with Exchange
Server, you can use this connection to the PC
to "pass through" to the network, or you can
synchronize without connecting to the PC over a
cellular network.
2. In ActiveSync, tap Sync. To end synchronization before
it completes, tap Stop.
Note ActiveSync 4.x utilizes a network type of connection with
Windows Mobile powered devices, since this allows faster
data transfer than a serial USB connection. When the PC is
connected to the Internet or a local network, in some cases,
the PC may disconnect the ActiveSync connection with your
device in favor of the Internet or network connection. If this
happens, tap Start > Settings > Connections tab > USB to
PC, then clear the Enable advanced network functionality
check box. This makes ActiveSync utilize a serial USB
connection with your device.
The USB to PC ( ) icon appears on the Today Screen when
your device is connected to your computer and you enable a
serial USB connection between them.
Synchronizing Information and Setting Up E-mail Security 63
Synchronize Outlook information with the
computer
If you have set up a synchronization relationship between
your device and the PC, synchronization keeps Outlook
information up-to-date on both your device and PC.
You can also set up your device to synchronize with more
than one PC or with a combination of one or more PCs
and Exchange Server. When synchronizing with multiple
computers, the items that you synchronize will appear on
all of the computers with which they are synchronized. For
example, if you have set up synchronization with two PCs (PC1
and PC2), which have different items, and you synchronize
Contacts and Calendar on your device with both computers,
the result is as follows:
Location New state
PC1 All Outlook contacts and calendar appointments
that were on PC2 are now also on PC1.
PC2 All Outlook contacts and calendar appointments
that were on PC1 are now also on PC2.
Pocket PC
Phone
All Outlook contacts and calendar appointments
from both PC1 and PC2 are on your device.
Note Outlook e-mail can be synchronized with only one computer.
To change which information is synchronized
ActiveSync synchronizes a limited amount of information by
default to save storage space on your device. You can change
the amount of information that is synchronized by performing
the following steps.
Note Before changing synchronization settings on your device,
disconnect it from your PC.
1. In ActiveSync on your device, tap Menu > Options.
2. Do one or both of the following:
Select the check box for any items you want to
synchronize. If you cannot select a check box, you
might have to clear the check box for the same
information type elsewhere in the list.
64 Synchronizing Information and Setting Up E-mail Security
Clear the check box for any items you want to stop
synchronizing.
To stop synchronizing with one PC completely, tap
the PC and tap Delete.
Note To change available synchronization settings, select the type
of information and tap Settings.
Synchronize Outlook information with
Exchange Server
You can set up synchronization with Exchange Server on
your device, if it is available to you through your company or
wireless service provider. However, you should first gather
information, such as Exchange Server name, domain name,
your user name, and password, and then carry on with the
steps. (For information about how to check the Exchange
server name and domain on your PC, see To install and set up
ActiveSync on the computer.”)
Note Before changing synchronization settings on your device,
disconnect it from your PC.
To synchronize directly with Exchange Server
1. Do one of the following:
Tap Start > Messaging, then tap Menu > Tools >
New Account. On the E-mail Setup screen, select
Outlook E-mail in the Your e-mail provider list,
then tap Next.
In ActiveSync on your device, tap
Menu > Add
Server Source. If you have previously set up
synchronization with Exchange Server, this appears as
Configure Server.
2. In Server address, enter the name of the server running
Exchange Server, and tap Next.
3. Enter your user name, password, and domain, and tap
Next. To change the rules for resolving synchronization
conflicts, tap Advanced.
Synchronizing Information and Setting Up E-mail Security 65
4. Select the check boxes for the types of information
items that you want to synchronize with Exchange
Server.
5. To change available synchronization settings, select the
type of information, and tap Settings.
6. Tap Finish.
Schedule synchronization with Exchange
Server
You can schedule information to be synchronized
automatically between your device and the Exchange Server,
or schedule synchronization at regular time intervals. Choose
between these two methods, depending on your e-mail
volume and which method you think is more cost-effective.
To receive e-mails and synchronize other information
instantly
Direct Push technology (push e-mail feature) enables you to
receive new e-mails on your device as soon as they arrive in
your Inbox on the Exchange Server. With this feature, items
such as contacts, calendar and tasks are also immediately
updated onto your device when these items have been
changed or new entries have been added on the Exchange
Server. To make Direct Push work, you need to have a data
connection on your device.
The Direct Push feature works for your device only if it is
connected to a private network (corporate network) that
is using Microsoft Exchange Server Service Pack 2 (SP2)
with Exchange ActiveSync. You need to perform a full
synchronization between your device and the Exchange
Server first before Direct Push can be enabled.
Using Comm Manager to enable Direct Push
1. On the Today screen, tap the Comm Manager icon ( ).
2. On the Comm Manager screen, tap the Microsoft
Direct Push button. The button will turn to
, which indicates that you will receive e-mails as
they arrive.
66 Synchronizing Information and Setting Up E-mail Security
When the button is in the state, you need to
manually retrieve your e-mails.
Using ActiveSync to enable Direct Push
1. In ActiveSync on your device, tap Menu > Schedule.
2. Select As items arrive in the Peak times and Off-peak
times boxes.
Note When both Wi-Fi and the data connection are active at the
same time, the Direct Push feature will always opt for the
data connection, for which you could be charged per your
network operator’s service plan.
To schedule synchronization at regular time intervals
You can set how often to synchronize during Peak times
(which usually refer to your working hours) when e-mail
volume is high, as well as Off-peak times when e-mail
volume is low.
1. In ActiveSync on your device, tap Menu > Schedule.
2. Select a shorter time interval in the Peak times box for
you to be able to receive e-mails more frequently.
3. Select a longer interval in the Off-peak times box.
Tip To set the days and hours that make up your peak and off-
peak times, tap Adjust peak times to fit your schedule.
Synchronizing Information and Setting Up E-mail Security 67
4.3 Synchronizing via Infrared and
Bluetooth
You can connect your device to the PC and synchronize
wirelessly via infrared (IR) or Bluetooth.
To synchronize with a computer via infrared
1. Follow the instructions in ActiveSync Help on the
computer for setting up your computer to receive
infrared beams.
2. Line up the infrared (IR) ports of your device and your
computer so that they are unobstructed and within
close range.
3. On your device, tap Start > Programs > ActiveSync.
4. Tap Menu > Connect via IR.
To synchronize with a computer via Bluetooth
1. Follow the instructions in ActiveSync Help on the
computer for configuring Bluetooth on your computer
to support ActiveSync.
2. On your device, tap Start > Programs > ActiveSync.
3. Tap Menu > Connect via Bluetooth. Make sure
the Bluetooth function of both your device and the
computer are turned on, and they are within close
range.
4. If this is the first time you have connected to this
computer via Bluetooth, you must first complete the
Bluetooth wizard on your device and set up a Bluetooth
partnership between your device and the computer.
For more information about creating a Bluetooth
partnership, see “Bluetooth partnerships” in Chapter 6.
Notes To preserve battery power, turn off Bluetooth when not in
use.
To connect and synchronize your device with a computer
via Bluetooth, your computer must have a Bluetooth
adapter or dongle.
68 Synchronizing Information and Setting Up E-mail Security
4.4 Synchronizing Music, Video, and
Pictures
If you want to carry your music or other digital media along
with you while you travel, ActiveSync works with Windows
Media Player to synchronize music, video, and pictures with
your device.
Other than selecting the Media information type in
ActiveSync to be synchronized, all media synchronization
settings must be set in Windows Media Player. Before media
can be synchronized, you must do the following:
Install Windows Media Player Version 10 on the PC.
(Windows Media Player 10 works only in Windows XP or
later versions).
Connect your device to the PC with a USB cable. If
your device is currently connected using Bluetooth or
infrared, you must end that connection before media
can be synchronized.
Insert a storage card into your device (32MB or larger is
recommended).
Set up a sync partnership between the storage card and
Windows Media Player.
Change Media synchronization settings
Once you select the Media information type in ActiveSync to
be synchronized, any of your favorite music, video, and picture
files in Windows Media Player playlists can be synchronized.
All you have to do is set up synchronization in Windows Media
Player for those media files.
To set up a sync relationship with a storage card
1. On the computer, open Windows Media Player.
2. Click the Sync tab.
3. Select the storage card.
Synchronizing Information and Setting Up E-mail Security 69
4. Click Set up Sync.
5. Choose whether to synchronize automatically or
manually.
For more information about Windows Media Player on your
device, see “Using Windows Media Player” in Chapter 8.
4.5 Setting Up E-mail Security
Windows Mobile on your device protects your Outlook e-
mails through Secure/Multipurpose Internet Mail Extension
(S/MIME), which allows you to digitally sign your messages as
well as encrypt them.
Using authorization keys and certificates, S/MIME allows you
to digitally sign your e-mail messages to prove your identity
to the recipients. Authorization keys are also used when
encrypting messages to improve privacy and prevent undue
tampering or hacking of your messages. You can encrypt a
message with or without a certificate. However, to read an
encrypted message, you need a valid certificate to decrypt it.
70 Synchronizing Information and Setting Up E-mail Security
Note S/MIME encryption and digital signatures for Windows
Mobile-based devices are available only with Exchange
Server 2003 Service Pack 2 or a later version that supports
S/MIME. If you are not using one of these products, or have
not yet synchronized, these options are unavailable.
Digitally sign and encrypt all messages
ActiveSync allows you to set up S/MIME e-mail encryption and
signing. You must obtain a valid certificate to sign and encrypt
e-mail messages successfully
.
1. Tap Start > Programs > ActiveSync.
2. Tap Menu > Options.
3. Select the E-mail information type, and tap Settings.
On the E-mail Sync Options screen, tap Advanced.
4. Do one or both of the following:
To sign all your outgoing e-mail messages so that
recipients can be certain that the messages were
sent by you and have not been altered in any way,
select the Sign all outgoing e-mail messages
check box.
To encrypt all your outgoing e-mail messages so that
the contents of your messages are protected from
being viewed by anyone other than the intended
recipients, select the Encrypt all outgoing e-mail
messages check box.
Synchronizing Information and Setting Up E-mail Security 71
5. Tap Choose Certificate to select a certificate for signing
or encrypting outgoing e-mail messages.
You can select certificates to sign or encrypt e-mail
messages individually if you do not choose to sign or
encrypt all outgoing e-mail. For information about
signing and encrypting individual messages, see
“Individually sign and encrypt a message” in Chapter 7.
72 Synchronizing Information and Setting Up E-mail Security
5.1 Personalizing Your Pocket PC Phone
5.2 Adding and Removing Programs
5.3 Managing Memory
5.4 Copying Files
5.5 Protecting Your Pocket PC Phone
5.6 Resetting Your Pocket PC Phone
Chapter 5
Managing Your Pocket PC
Phone
74 Managing Your Pocket PC Phone
5.1 Personalizing Your Pocket PC Phone
Customize the Today screen
The Today screen shows your upcoming appointments, active
tasks, and information about incoming messages. You can
customize the Today screen on your device.
To customize the Today screen
1. Tap Start > Settings > Personal tab > Today.
2. On the Appearance tab, select the desired theme for
the background of the Today screen.
3. On the Items tab, select the items you want to appear
on the Today screen.
Tip To change the order of items displayed on the Today screen,
tap the item, and tap Move Up or Move Down.
To add a custom background image
You can use one of your own pictures as the background
image on the Today screen. Be aware that pictures can affect
the readability of text on the Today screen.
1. Tap Start > Settings > Personal tab > Today.
2. Select the Use this picture as the background check
box, and tap Browse to view a list of your picture files.
3. Tap the file name of the picture you want to use.
4. Tap OK.
To set options for displaying appointments on the Today
screen
If you have a large number of appointments, you may want
to specify the kind of appointments that are displayed on the
Today screen.
1. Tap Start > Settings > Personal tab > Today.
2. Tap the Items tab.
3. Select Calendar and tap Options.
Managing Your Pocket PC Phone 75
4. Do any of the following:
Select Next appointment to show only the next
appointment in your schedule, or Upcoming
appointments to show multiple appointments.
Clear the Display all day events check box if you do
not want to display all-day events.
To set options for displaying tasks on the Today screen
If you have a large number of tasks, you may want to specify
the kind of tasks that are displayed on the Today screen.
1. Tap Start > Settings > Personal tab > Today.
2. Tap the Items tab.
3. Select Tasks and tap Options.
4. Do any of the following:
Under Display number of, select the type of tasks
you want to appear on the Today screen.
In the Category list, select whether to display only
tasks assigned to a specific category or to display all
tasks.
Customize the Start menu
You can choose which items appear in the Start menu.
1. Tap Start > Settings > Personal tab > Menus.
2. Select the check boxes of the items you want to appear
in the Start menu. You can select up to seven items.
Tip You can also create folders and shortcuts to appear on the
Start menu. In ActiveSync on your PC, click Explore. In the
Mobile Device window, double-click My Windows Mobile-
Based Device > Windows > Start Menu, then create the
folders and shortcuts that you want. You will see the added
items after you synchronize.
76 Managing Your Pocket PC Phone
Why is the device name important?
The device name is used to identify the device in the following
situations:
Synchronizing with a PC
Connecting to a network
Restoring information from a backup
Note If you synchronize multiple devices with the same PC, each
device must have a unique name.
To change the device name
1. Tap Start > Settings > System tab > About.
2. Tap the Device ID tab.
3. Enter a name.
Note The device name must begin with a letter, consist of letters
from A to Z, numbers from 0 to 9, and cannot contain spaces.
Use the underscore character to separate words.
Set Date / Time / Regional Options
You can set up the correct date, time, and regional settings
according to your use.
To set the time and date
1. Tap Start > Settings > System tab > Clock & Alarms >
Time tab.
2. Select the correct time zone and change the date or
time.
Note During synchronization, the time on your device is updated
with the time on your PC.
To set the time and date for a different location
If you visit or communicate with someone in a particular time
zone often, you can select it as your visiting time zone.
1. Tap Start > Settings > System tab > Clock & Alarms >
Time tab.
2. Tap Visiting.
Managing Your Pocket PC Phone 77
3. Select the correct time zone and change the time or
date.
To set an alarm
1. Tap Start > Settings > System tab > Clock & Alarms >
Alarms tab.
2. Tap <Description> and enter a name for the alarm.
3. Tap the day of the week for the alarm. You can select
multiple days by tapping each desired day.
4. Tap the time to open a clock and set the time for the
alarm.
5. Tap the alarm icon ( ) to specify the type of alarm
you want. You can choose a flashing light, a single
sound, a repeating sound, or vibration.
6. If you choose to play a sound, tap the list next to the
Play sound check box and tap the sound you want.
To change regional settings
The style in which numbers, currency, dates, and times are
displayed is specified in regional settings.
1. Tap Start > Settings > System tab > Regional
Settings.
2. On the Region tab, select your region from the list.
Note This does not change the Operating System language
of your device.
3. The region you select determines which options will be
available on the other tabs.
4. To customize settings further, tap the appropriate tabs
and select the desired options.
Personal and system settings
To reassign programs or shortcuts to program buttons
Your device may come with programs already assigned to
hardware buttons. You can customize these buttons to open
the programs you use most, or to perform certain shortcuts
78 Managing Your Pocket PC Phone
such as changing the screen orientation, opening the Today
screen, or opening Input Panel.
1. Tap Start > Settings > Personal tab > Buttons.
2. A list of buttons and their current assignments are
displayed on the Program Buttons tab.
3. Tap the button you want to reassign. To help you
identify the buttons, there are numbers and icons
representing the original function of the button.
4. In the Assign a program box, tap the program or
shortcut you want to assign.
5. Tap OK.
To increase or decrease the size of text on the screen
1. Tap Start > Settings > System tab > Screen > Text Size
tab.
2. Move the slider to increase or decrease the text size.
To choose how to be notified about events or actions
1. Tap Start > Settings > Personal tab > Sounds &
Notifications.
2. On the Sounds tab, choose how you want to be notified
by selecting the appropriate check boxes.
3. On the Notifications tab, in Event, tap an event name
and choose how you want to be notified by selecting
the appropriate check boxes. You can choose from
several options, such as a special sound, a message, or a
flashing light.
Tip Turning off sounds and the flashing light helps conserve
battery power.
To adjust the speed for scrolling
Pressing and holding NAVIGATION up or down (Up/Down
control) scrolls through the items in a list. Follow these steps
to set the scrolling speed.
1.
Tap Start > Settings > Personal tab > Buttons > Up/
Down Control tab
.
2. Do one of the following:
Managing Your Pocket PC Phone 79
Under Delay before first repeat, move the slider
to shorten or lengthen the time that elapses before
scrolling begins.
To change the time it takes to scroll from one item
to the next, under Repeat rate, move the slider to
adjust the speed.
To find the operating system version number
Tap Start > Settings > System tab > About.
The version of the operating system on your device is shown
near the top of the About screen.
To get detailed device information
Tap Start > Settings > System tab > About.
The Version tab displays important device information,
including the type of processor and the amount of memory
that is installed.
To make the battery last longer
Tap the battery icon ( ) on the Today screen. On
the Advanced tab of the Power settings screen, you
can specify when your device turns off the display to
conserve battery power.
For optimum conservation, specify 3 minutes or less.
Use the AC adapter to plug your device into external
power whenever possible, especially when using
a storage card or when using a modem or other
peripherals.
Adjust the backlight settings.
To adjust the brightness of the backlight
1. Tap the Backlight icon ( ) on the Today screen, or tap
Start > Settings > System tab > Backlight.
2. On the Brightness tab, move the slider right to increase
the brightness, or left to decrease the brightness.
80 Managing Your Pocket PC Phone
To set the backlight to dim after a time delay
1. Tap the Backlight icon ( ) on the Today screen, or tap
Start > Settings > System tab > Backlight.
2. Tap the Battery power tab, or the External power tab.
3. Select the Turn off backlight if device is not used for
check box, and specify the time delay.
Phone settings
You can customize phone settings, such as the ring type and
ring tone to be used for incoming calls, and the keypad tone
to be used when entering phone numbers. Open the Phone
program to customize these settings.
To change the ring tone
1. On the Phone screen, tap Menu > Options > Phone
tab.
2. In the Ring tone list, tap the sound you want to use.
Tip
To use custom *.wav, *.mid, *.mp3, or *.wma files as ring
tones, use ActiveSync on your PC to copy the files to the ../
Windows/Rings folder on your device. Next, select the sound
from the Ring tone list. For more information about copying
files to your device, see "Copying Files" later in this chapter
.
To change the ring type
You can change the way you are notified of incoming calls. For
example, you can choose to be notified by a ring, a vibration,
or a combination of both.
1. On the Phone screen, tap Menu > Options > Phone
tab.
2. In the Ring type list, tap the desired option.
To change the keypad tone
You can change the tone you hear when entering a phone
number on the keypad. If set to Long tones, the tone
is heard continuously for as long as the number on the
keypad is pressed. Use this setting if you are having trouble
accomplishing tasks that rely on tones from your phone such
as accessing messages from an answering machine. If set to
Managing Your Pocket PC Phone 81
Short tones, the tone is heard only for one or two seconds. If
set to Off, no tone will be heard
.
1. From the Phone keypad, tap Menu > Options > Phone
tab.
2. In the Keypad list, tap the option you want.
Optional phone services
Optional phone services can be easily activated and used
on your device if provided by your wireless service provider.
Contact your service provider first to ask about the availability
of these services.
To enable optional phone services
1. Tap Start > Settings > Personal tab > Phone >
Services tab.
2. Select the service you want to use, then tap Get
Settings.
3. Select desired options for the service, then tap OK.
Tip For more information about how to customize the settings of
optional phone services, see Help on your device.
5.2 Adding and Removing Programs
Before you purchase additional programs for your device,
you should note the model name of your device, the version
of Windows Mobile software running on it, and the type of
processor. This information will help you select a program that
is compatible with your device. For more information, see To
get detailed device information and To find the operating
system version number” in this chapter.
Programs available for purchase usually include a Setup
program (commonly named "setup.exe") that you must first
run on your PC. You can then use ActiveSync to add programs
to your device, or add a program directly from the Internet.
82 Managing Your Pocket PC Phone
To add programs
1. Download the program to your PC (or insert the CD or
disk that contains the program into your PC). You may
see a single *.exe file, a *.zip file, a Setup.exe file, or
several versions of files for different device types and
processors. Be sure to select a program designed for
your device and processor type.
2. Read any installation instructions or documentation
that comes with the program. Many programs provide
special installation instructions.
3. Connect your device to the PC.
4. Double-click the *.exe file.
If the executable file is an installation wizard, follow
the instructions on the screen. The wizard will
automatically install the program to your device.
If an installation wizard does not start, you will
see an error message stating that the program
is valid but that it is designed for a different type
of computer. You will need to copy this program
directly to your device. If you cannot find any
installation instructions for the program, use
ActiveSync to copy the program file to the Program
Files folder on your device.
To remove programs
You can only remove programs that you installed. Programs
that come with your device cannot be removed.
1. Tap Start > Settings > System tab > Remove
Programs.
2. In the Programs in storage memory list, select the
program you want to remove, and tap Remove.
3. Tap Yes. If another confirmation message appears, tap
Yes again.
Managing Your Pocket PC Phone 83
5.3 Managing Memory
You may need to stop a program if it becomes unstable or the
program memory is low.
To see how much memory is available
Tap Start > Settings > System tab > Memory.
On the Main tab, the amount of memory allocated
to file and data storage versus program storage is
displayed, as well as the amount of memory in use
versus the available memory.
To see available storage card memory
You can see how much memory is available on a storage card
that is inserted in your device.
1. Tap Start > Settings > System tab > Memory.
2. Tap the Storage Card tab.
To free up program memory
Try the following to free memory on your device:
Close programs you are not currently using.
Move e-mail attachments to a storage card.
Move files to a storage card. Tap Start > Programs >
File Explorer. Tap and hold the file, and tap Cut. Browse
to the storage card folder and tap Menu > Edit > Paste.
Delete unnecessary files. Tap Start > Programs > File
Explorer. Tap and hold the file, and tap Delete.
Delete large files. To find your largest files, tap Start >
Programs > Search. In the Type list, tap Larger than 64
KB, and tap Search.
In Internet Explorer Mobile, delete temporary Internet
files and clear history information. For more information,
see “Internet Explorer Mobile” in Chapter 6.
Remove programs you no longer use.
Reset your device.
84 Managing Your Pocket PC Phone
To close a program
Tapping the button in a program may just close the
program screen. In this case, the program continues to run in
the background. You can end running programs manually by
following these steps:
1. Tap Start > Settings > System tab > Memory >
Running Programs tab.
2. In the Running Programs List, tap the program you
want to close, and tap Stop.
Tip In most programs, you can also tap the keyboard shortcut
Ctl+q on the on-screen keyboard to close the program.
5.4 Copying Files
You can copy files to your PC using ActiveSync, or copy files to
a storage card you insert into your device. Your device has an
expansion slot for inserting a microSD card.
Using ActiveSync, you can copy or move information from
the PC to your device and vice versa. Copying a file results in
separate versions of a file on your device and PC. Because the
files are not synchronized, changes made to one file will not
affect the other.
Note If you want to automatically update information on both
your device and PC, synchronize the information instead. For
more information about copying and synchronizing files, see
ActiveSync Help on your PC.
To copy files to a storage card
1. Make sure the storage card is properly inserted into
your device.
2. Tap Start > Programs > File Explorer and navigate to
the appropriate folder.
3. Tap and hold the file you want to copy, and tap Copy.
4. Tap the folder list (labeled My Documents by default)
and tap Storage Card.
5. Tap Menu > Edit > Paste.
Managing Your Pocket PC Phone 85
To copy a file between your device and the PC
1. Connect your device to the PC.
2. In ActiveSync, click Explore, which opens the Mobile
Device folder of your device.
3. To copy a file from your device to your PC:
a. In the Mobile Device folder, go to the file that you
want to copy.
b. Right-click the file, then click Copy.
c. Locate the destination folder on your PC. Right-click
the folder, then click Paste.
4. To copy a file from your PC to your device:
a. On your PC, navigate to the folder that contains the
file you want to copy.
b. Right-click the file, then click Copy.
c. Right-click the destination folder under Mobile
Device, then click Paste.
To automatically save files on a storage card
In the Word Mobile, Excel Mobile, and Notes programs, you
may find it helpful to save all new documents, notes, and
workbooks directly on a storage card.
1. From the program file list, tap Menu > Options.
2. With a storage card inserted in your device, in the
Save to box, select the appropriate storage card to
automatically save new files on the storage card.
3. Tap OK.
Note In the file or note list, a storage card symbol is displayed
next to the names of files saved on a storage card.
86 Managing Your Pocket PC Phone
5.5 Protecting Your Pocket PC Phone
You can prevent unauthorized access to your device by using
password protection. To keep your data more secure, you
can set your device to prompt for a password every time the
device is turned on or when your device has been idle after a
specified amount of time.
To protect your device with a password
1. Tap Start > Settings > Personal tab > Lock.
2. Select the Prompt if device unused for check box,
and in the box to the right, select how long your device
must be idle before a password is required. In the
Password type box, select the type of password you
would like to use. Enter the password and, if necessary,
confirm the password.
If your device is configured to connect to a network, use
an alphanumeric password for increased security for
your device.
3. On the Hint tab, enter a phrase that will help you
remember your password, but does not allow others to
guess your password.
The hint will be displayed after the wrong password is
entered four times.
4. Tap OK. The next time the device is turned on, you will
be prompted to enter your password.
Notes
Each time a wrong password is entered, the device
response time gets longer until the device appears to be
not responding.
If you forget your password, you must follow the
instructions in this user manual to clear the memory
before you can access your device.
To change your password
1. Tap Start > Settings > Personal tab > Lock. You will be
prompted to enter your current password.
2. In the Password box, enter your new password.
3. Tap OK.
Managing Your Pocket PC Phone 87
To display owner information on the ‘my info’ screen
Having your contact information displayed on the my info
screen on startup allows for easy identification of the device
in case it is lost.
1. Tap Start > Settings > Personal tab > Owner
Information.
2. On the Options tab, select the Identification
information check box.
3. If you want additional text displayed, tap the Notes tab
and enter the text (for instance: Reward if found).
4. On the Options tab, select the Notes check box.
5. Tap OK.
Tip To display owner information on the Today screen, tap Start
> Settings > Personal tab > Today. On the Items tab, select
the Owner Info check box.
5.6 Resetting Your Pocket PC Phone
Occasionally, you may need to reset your device. A soft (or
normal) reset of your device clears all active program memory
and shuts down all active programs. This can be useful when
your device is running slower than normal, or a program is
not performing properly. A soft reset is also necessary after
the installation of some programs. If a soft reset is performed
when programs are running, unsaved work will be lost.
To perform a soft reset
Use the stylus to press the RESET button found at the
bottom center part of your device. Your device restarts
and displays the Today screen.
RESET button
88 Managing Your Pocket PC Phone
You can also perform a hard reset (also known as a full reset).
A hard reset should be performed only if a soft reset does
not solve a system problem. After a hard reset, the device is
restored to its default settings — the way it was when you first
purchased it and turned it on. Any programs you installed,
data you entered, and settings you customized on your device
will be lost. Only Windows Mobile software and other pre-
installed programs will remain.
To perform a hard reset
1. Press and hold the Left SOFT KEY and the Right SOFT
KEY, and at the same time, use the stylus to press the
RESET button at the bottom center part of your device.
RESET buttonLeft SOFT KEY Right SOFT KEY
2. Release the stylus, but continue pressing the two soft
key buttons. Release them only when you see the
following message on your device screen:
“Do you want to erase all user data and restore to
manufacture default?“
3. Slide open the hardware keyboard, then press R to do a
hard reset.
Warning! Your device will be set back to factory default settings.
Please ensure any additional installed programs and/or user
data have been backed up before a hard reset is performed.
6.1 Connecting to the Internet
6.2 Internet Explorer Mobile
6.3 Using Comm Manager
6.4 Using Bluetooth
6.5 Using Wi-Fi
6.6 Using Internet Sharing
6.7 Using Terminal Services Client
Chapter 6
Getting Connected
90 Getting Connected
6.1 Connecting to the Internet
Your device is equipped with powerful networking functions
that enable you to connect to the Internet through Wi-Fi or
the mobile phone network.
Connecting your device to the Internet through a private or
free wireless network is your best choice since this will not
incur any cost. Take note, however, that using Wi-Fi on your
device will drain battery power faster. For more information
about setting up a Wi-Fi connection, see “Using Wi-Fi” later in
this chapter.
In times when you are not within the coverage of a wireless
network, use phone dial-up to connect your device to the
Internet or your corporate network. Your device has two
groups of connection settings: My ISP (Internet Service
Provider) and My Work Network. The My ISP settings are used
to connect to the Internet, while My Work Network settings
can be used to connect to any private, corporate network.
To set up a dial-up connection to your ISP
When you use your device to dial up to your ISP and connect
to the Internet, you will be billed by the number of minutes
that you use.
To establish a dial-up connection on your device, you need
the same settings that you normally use when you dial up
from your computer. This includes the ISP server phone
number, your user name and password.
1. Tap Start > Settings > Connections tab >
Connections.
2. Under My ISP, tap Add a new modem connection.
3. On the Make New Connection screen, enter a name for
the connection.
4. In the Select a modem list, select Cellular Line, then
tap Next.
5. Enter the ISP server phone number, then tap Next.
6. Enter your user name, password, and any other
information required by your ISP.
Getting Connected 91
7. Tap Finish.
Notes To view help information for any screen, tap the Help icon
( ).
To modify your connection settings, tap Manage existing
connections on the Connections screen, and complete
the connection wizard.
To set up a connection to a private network
1. Obtain the following information from your network
administrator:
Server phone number
User name
Password
Domain (and other required settings, such as IP
address)
2. Tap Start > Settings > Connections tab >
Connections.
3. In My Work Network, follow the instructions for each
type of connection.
4. Complete the connection wizard, then tap Finish.
92 Getting Connected
To start a connection
After setting up a data connection on your device, you can
now connect your device to the Internet. The connection is
started automatically when you begin using a program that
requires an Internet connection. For example, when you start
Internet Explorer Mobile to browse the Internet, your device
connects automatically.
If you have set up multiple types of connections on your
device, you can manually start a connection.
1. Tap Start > Settings > Connections tab >
Connections.
2. Tap Manage existing connections.
3. Tap and hold the name of the desired connection, then
tap Connect.
To disconnect a data connection
Do one of the following:
Press and hold END ( ) on your device for at least
three seconds.
Tap the Comm Manager icon ( ) on the Today screen,
then tap the Data Connection button ( ).
6.2 Internet Explorer Mobile
Internet Explorer Mobile is a full-featured Internet browser,
optimized for use on your device.
To start Internet Explorer Mobile
Tap Start > Internet Explorer.
To set a Home page
1. In the address bar on top of the Internet Explorer Mobile
screen, enter the desired Web page address. Tap to
open the Web page.
2. Tap Menu > Tools > Options > General tab.
3. Do one of the following:
Getting Connected 93
To use the displayed page as the Home page, tap
Use Current.
To use the default Home page, tap Use Default.
Tip To go to your Home page, tap Menu > Home.
To transfer favorites from your PC
You can transfer the favorites you have stored on your PC to
your device by synchronizing the Internet Explorer favorites
on your PC with your device.
1. In ActiveSync on your PC, on the Tools menu, click
Options, and select Favorites.
2. In Internet Explorer on your PC, click Favorites > Add to
Favorites and save or move favorite links to the Mobile
Favorites subfolder in the Favorites list.
3. Connect your device to your PC. If synchronization does
not start automatically, click Sync.
To add a favorite
1. In Internet Explorer Mobile, go to the page you want to
add.
2. Tap and hold the page, and tap Add to Favorites.
3.
Confirm or change the name, and select a folder for
storing the favorite
.
4. Tap Add.
To delete a favorite or folder
1. In Internet Explorer Mobile, tap Menu > Favorites >
Add/Delete tab.
2. Select the item you want to delete, and tap Delete.
To change the size of text on Web pages
In Internet Explorer Mobile, tap Menu > Zoom, and tap the
size you want
.
To change how Web pages fill the screen
1. In Internet Explorer Mobile, tap Menu > View.
2. Tap one of the following:
94 Getting Connected
One Column. Arranges the content into one column
that is as wide as the screen. This means that you will
rarely have to scroll horizontally.
Default. Maintains a layout similar to what you see
on a desktop computer, but it makes items smaller
and arranges the content so that you can see most
of it without having to scroll horizontally.
Desktop. Keeps the same layout and size as on
a desktop computer, which will require both
horizontal and vertical scrolling.
To clear the History list
1.
In Internet Explorer Mobile, tap Menu > Tools > Options >
Memory tab
.
2. Tap Clear History.
To save a picture from a Web page
1.
In Internet Explorer Mobile, tap and hold the picture, and
tap Save Image
.
2. Do one of the following:
To save the picture in My Pictures on your device,
tap Yes.
To save the picture in another location, such as a
storage card, tap Save As.
To delete temporary Internet files
Your device temporarily stores Web pages that you frequently
visit or have visited recently to speed up the display of these
Web pages when you access them. You may want to delete
these files to free storage space.
1. In Internet Explorer Mobile, tap Menu > Tools >
Options > Memory tab.
2. Tap Delete Files. All pages stored on your device,
including offline favorites content, will be deleted.
To set up Internet security settings
Cookies are small files containing information about your
identity and preferences so that a page can tailor information
Getting Connected 95
to your needs. The page sends the file, and it is stored on your
device.
1. In Internet Explorer Mobile, tap Menu > Tools >
Options > Security tab.
2. To prevent Internet Explorer Mobile from accepting any
cookies, clear the Allow cookies check box.
3. Select the check boxes for the other security options
you want, and tap OK.
6.3 Using Comm Manager
Comm Manager acts like a central switcher that lets you
enable or disable phone features as well as manage your data
connections easily.
To open Comm Manager
Tap the Comm Manager icon ( ) on the Today screen.
Simply tap the corresponding button to enable or disable a
feature.
1
2
3
4
5
6
1Tap to toggle between enabling or disabling the phone.
2Tap to toggle between automatically receiving (as items arrive)
or manually retrieving Outlook e-mails. For more information,
see "Schedule synchronization with Exchange Server" in Chapter
4.
96 Getting Connected
3Tap to toggle between turning on the phone's ringer or setting
the phone to vibration/mute mode.
4Tap to toggle between turning on or off Bluetooth. Tap Settings
> Bluetooth to configure Bluetooth on your device. See "Using
Bluetooth" for details.
5Tap to disconnect active data connections. You cannot reconnect
data connections in Comm Manager.
6
Tap to open ActiveSync so you can synchronize the device and
computer. For more information about the configuration settings
for ActiveSync, see Chapter 4
.
6.4 Using Bluetooth
Bluetooth is a short-range wireless communications
technology. Devices with Bluetooth capabilities can
exchange information within a distance of about 10 meters
without requiring a physical connection. You can even beam
information to a device in a different room, as long as it is
within the Bluetooth signal coverage range.
Bluetooth can be used in the following ways:
Beam information, such as files, appointments, tasks,
and contact cards, between devices that have Bluetooth
capabilities.
Synchronize information between your device and
computer via Bluetooth.
Use a Bluetooth-enabled headset (or other Bluetooth-
enabled hands-free device such as a car kit) with your
device for hands-free phone conversations.
Use a Bluetooth service. Once you connect to another
device or computer using Bluetooth, you can locate and
use any of the services available on that device.
Getting Connected 97
Create a connection between your device and another
Bluetooth-enabled phone to use that phone as a
modem.
Note Normally, you will need another phone as a modem only if
your Pocket PC device has no integrated phone capability.
Bluetooth modes
Bluetooth on your device operates in three different modes:
On. Bluetooth is turned on. Your device can detect other
Bluetooth-enabled devices, but not vice versa.
Off. Bluetooth is turned off. In this mode, you can
neither send nor receive information using Bluetooth.
You might want to turn Bluetooth off at times in order
to conserve battery power, or in situations where using
a wireless device is prohibited, such as on board an
aircraft and in hospitals.
Visible. Bluetooth is turned on, and all other Bluetooth-
enabled devices can detect your device.
Note By default, Bluetooth is turned off. If you turn it on, then turn
off your device, Bluetooth also turns off. When you turn on
your device again, Bluetooth automatically turns on.
To turn Bluetooth on and make your device visible
1. On your device, tap Start > Settings > Connections tab
> Bluetooth.
2. Select the Turn on Bluetooth and Make this device
visible to other devices check boxes.
3. Tap OK.
Bluetooth partnerships
A Bluetooth partnership is a relationship that you create
between your device and another Bluetooth-enabled device
in order to exchange information in a secure manner. Creating
a partnership between two devices involves entering the
same Bluetooth passcode on both devices.
Creating a partnership between two devices is a one-time
process. Once a partnership is created, the devices can
98 Getting Connected
recognize the partnership and exchange information without
entering a passcode again. Make sure that on the two devices,
Bluetooth is turned on and in visible mode.
To create a Bluetooth partnership
1. On your device, tap Start > Settings > Connections
tab > Bluetooth.
2. On the Devices tab, tap Add new device. Your device
searches for other Bluetooth devices and displays them
in the box.
3. Tap the desired device name in the box.
4. Tap Next.
5. Specify a passcode to establish a secure connection.
The passcode can be 1 up to 16 characters.
6. Tap Next.
7. Wait for the paired device to accept the partnership.
The receiving party needs to enter the same passcode
that you specified.
8. The name of the paired device is then displayed. You
may edit and enter a new name for that device.
9. Select the check boxes of services that you want to use
from the paired device.
10. Tap Finish.
To accept a Bluetooth partnership
1. Ensure that Bluetooth is turned on and in visible mode.
2. Tap Yes when prompted to establish a partnership with
the other device.
3. Enter a passcode (the same passcode that is entered
on the device requesting the partnership) to establish
a secure connection. The passcode must be between 1
and 16 characters.
4. Tap Next.
5. Tap Finish. You can now exchange information with the
paired device.
Getting Connected 99
To rename a Bluetooth partnership
1. Tap Start > Settings > Connections tab > Bluetooth.
2. Tap and hold the partnership on the Devices tab.
3. On the shortcut menu, tap Edit.
4. Enter a new name for the partnership.
5. Tap Save.
To delete a Bluetooth partnership
1. Tap Start > Settings > Connections tab > Bluetooth.
2. Tap and hold the partnership on the Devices tab.
3. Tap Delete.
Connect a Bluetooth hands-free or stereo
headset
For hands-free phone conversations, you can use a Bluetooth
hands-free headset such as a car kit with your device.
Your device also supports A2DP (Advanced Audio Distribution
Profile) which is for stereo audio over Bluetooth. This means
that you can use a Bluetooth stereo headset with your device
for hands-free phone conversations as well as for listening
to stereo music. Make sure that your stereo headset also
supports A2DP.
Just like when connecting to any Bluetooth device, you also
need to enter a passcode when connecting to a Bluetooth
hands-free or stereo headset. The passcode is fixed and
cannot be changed on a Bluetooth headset. Before you
connect it to your device, check for the proper passcode in the
manufacturers documentation.
To connect a Bluetooth hands-free or stereo headset
1. Make sure that both your device and the Bluetooth
headset are turned on and within close range, and
that the headset is visible. Refer to the manufacturer’s
documentation to find out how to set the headset in
visible mode.
2. Tap Start > Settings > Connections tab.
100 Getting Connected
3. Tap Bluetooth > Devices tab > Add new device. Your
device searches for other Bluetooth-enabled devices
and displays them in the list.
4. Tap the name of the Bluetooth headset, then tap Next.
5. Enter the passcode of the Bluetooth headset, then tap
Next.
6. Make sure the Hands Free check box is selected.
If you have a Bluetooth stereo headset, also make sure
the Wireless Stereo check box is selected.
7. Tap Finish.
Note If the Bluetooth stereo headset becomes disconnected, turn
the headset on and repeat steps 1 to 3 above. Tap and hold
the name of the Bluetooth stereo headset and tap Set as
Wireless Stereo.
Beam information using Bluetooth
You can beam information, such as contacts, calendar items,
and tasks, as well as files from your device to your computer or
to another Bluetooth-enabled device.
Note If your computer does not have built-in Bluetooth capability,
you need to connect and use a Bluetooth adapter or dongle
on your computer.
Getting Connected 101
To beam information from your device to a computer
1. Turn on Bluetooth on your device, and make your
device visible. For information about this, see To turn
Bluetooth on and make your device visible.
2. You also need to set Bluetooth on your computer to
visible mode. Do one of the following:
If your computer has Windows XP SP2 and your
computer’s built-in or external Bluetooth adapter
is supported by Windows XP SP2, open Bluetooth
Devices from the Control Panel. Click the Options
tab, then select the Turn discovery on and the
Allow Bluetooth devices to connect to this
computer options.
If the Bluetooth adapter on your computer was
installed using a third-party provided driver, open
the Bluetooth software that came with the Bluetooth
adapter. This software varies by manufacturer, but in
most cases, you will find a Bluetooth Configuration
utility which you can open from the Control Panel.
After Bluetooth Configuration opens, click the
Accessibility tab, then select Let other Bluetooth
devices to discover this computer. Refer to the
Bluetooth adapter’s documentation for more
information.
3. Create a Bluetooth partnership between the two
devices. For information about creating a partnership,
see “Bluetooth partnerships”.
After a partnership has been created successfully, your
computer is ready to receive Bluetooth beams.
4. On your device, tap and hold an item to beam. The
item can be an appointment in your calendar, a task, a
contact card, or a file.
5. To beam a contact, tap Menu > Send Contact > Beam.
To beam other types of information, tap Menu > Beam
[type of item].
102 Getting Connected
6. Tap the device name to which you want to send the
beam.
7. If you beamed an Outlook item and it is not
automatically added to Outlook, select File > Import
and Export in Outlook to import it.
To beam information to a Bluetooth-enabled device such as
another Pocket PC, follow steps 3 to 6 in the above procedure.
Note If the computer or device you want to beam to does not
appear in your device's Bluetooth list, make sure that its
Bluetooth is turned on and set to visible mode.
To receive a Bluetooth beam
Your device will not detect and notify you of incoming
Bluetooth beams unless you set it up to do this.
1. Tap Start > Settings > Connections tab > Beam.
2. Select the Receive all incoming beams check box.
3. Make sure your device is turned on, visible, and
within close range of the device that is beaming the
information.
4. When prompted to receive an incoming beam, tap Yes
to receive the beamed information.
Tip Selecting the Receive all incoming beams check box also
allows the device to detect and receive infrared beams.
Use the device as a Bluetooth modem
You can connect your device to a notebook or desktop
computer through Bluetooth and use the device as a modem
for the computer.
Note If your computer does not have built-in Bluetooth capability,
you need to connect and use a Bluetooth adapter or dongle
on your computer.
For the computer to use the Internet connection of your
device, activate Internet Sharing on your device, then set
up a Bluetooth Personal Area Network (PAN) between the
computer and your device.
Getting Connected 103
1. On your device, turn on Bluetooth and set it to visible
mode.
2. Initiate a Bluetooth partnership from your device
by following the steps in To create a Bluetooth
partnership.
Alternatively, you can initiate a Bluetooth partnership
from the computer by following these steps (based on
Windows XP SP2):
a. In the Control Panel or System Tray, double-click the
Bluetooth Devices icon.
b. In the Bluetooth Devices window, click Add.
c. The Add Bluetooth Device Wizard opens. Select the
My device is set up and ready to be found check
box, then click Next.
d. The wizard then detects your device and displays
its name in the dialog box. Select the device name,
then click Next.
e. Select Let me choose my own passkey, then enter
a passcode (1 up to 16 digits) that will serve as an
identification number for establishing a secure
connection between your device and the computer.
Click Next.
f. A confirmation message then appears on your
device. Tap Yes to accept the connection, enter the
same passcode, then tap Next.
g. On the computer, click Finish to exit the wizard.
h. On your devices Partnership Settings screen, you
can change the display name for the computer, then
tap Finish.
3. Now, open the Internet Sharing program on your
device. Tap Start > Programs > Internet Sharing.
4. Select Bluetooth PAN as the PC Connection.
5. From the Network Connection list, select the name of
the connection that your device uses to connect to the
Internet.
104 Getting Connected
6. Tap Connect.
7. On your computer, set up a Bluetooth Personal Area
Network (PAN) with your device:
a. Tap Start > Control Panel > Network Connections.
b. Under Personal Area Network, click the Bluetooth
Network Connection icon.
c. Under Network Tasks, click View Bluetooth
network devices.
d. In the Bluetooth Personal Area Network Devices
dialog box, select your device, then click Connect.
8. On the Internet Sharing screen on your device, check
if a connected status is displayed, which indicates that
your computer has been successfully connected to the
Internet using your device as a Bluetooth modem.
Use another Bluetooth phone as a modem
You can use another phone that has Bluetooth as a modem
for your device to browse the Internet or to transfer other
information.
To do this, create a Bluetooth modem connection on your
device and then send information to the phone by using
Bluetooth. The phone relays the information over the mobile
phone network and then sends back to your device any
information that you had requested over the connection.
Once you create a modem connection to the Bluetooth
phone, you can reuse it whenever you want to use the phone
as a modem. Make sure that Bluetooth is turned on and visible
mode is enabled on both your device and the phone, and that
the two are within close range.
Note Normally, you will need another phone as a modem only if
your Pocket PC device has no integrated phone capability.
To use a Bluetooth phone as a modem for your device
1. On your device, tap Start > Settings > Connections
tab > Connections.
2. Tap Add a new modem connection.
Getting Connected 105
3. Enter a name for the connection.
4. In the Select a modem list, tap Bluetooth.
5. Tap Next.
6. If the phone appears in the My Connections list, skip
to step 11.
7. If the phone does not appear in the My Connections
list, tap Add new device, and follow the remaining
steps.
8. Select the phone from the list and tap Next.
9. Enter a passcode and tap Next.
10. Enter the same passcode on the phone and tap Finish.
11. In the My Connections list on your device, select the
phone and tap Next.
12. Enter the phone number to dial for this connection and
tap Next.
13. Enter the required logon information for this
connection and tap Finish.
6.5 Using Wi-Fi
Wi-Fi provides wireless Internet access over distances of up to
100 meters. To use Wi-Fi on your device, you need access to a
wireless access point of your service provider. When you are
in public places, such as in a coffee shop or restaurant, you
will need access to their public wireless access points (also
referred to as “hotspots”).
Note The availability and range of your device’s Wi-Fi signal
depends on the number, infrastructure, and other objects
through which the signal passes.
To turn Wi-Fi on
At the lower left side of your device, slide the WLAN Switch
upward. The icons on the switch represent the following:
: Wi-Fi is turned on.
: Wi-Fi is turned off.
106 Getting Connected
To connect to a wireless network
1. After Wi-Fi has been turned on, your device then
scans for available wireless networks in your area. The
network names of the detected wireless networks will
be displayed on a pop-up message window. Tap the
desired wireless LAN, then tap OK.
2. On the next pop-up message window, tap The Internet
if the wireless LAN connects your device to the Internet.
Otherwise, tap Work if the wireless LAN connects your
device to a private network.
3. If the wireless LAN is secured by a network key, enter
this key, then tap Connect.
Next time you use your device to detect wireless
networks, you will not see the pop-up message
windows again, and you will not be prompted to enter
Getting Connected 107
the network key of the previously accessed wireless
network (unless you perform a hard reset which will
erase custom settings on your device).
Note Wi-Fi networks are self-discoverable, which means no
additional steps are required for your device to connect to
a Wi-Fi network. It may be necessary to provide a username
and password for certain closed wireless networks, however.
To save battery power while connected to a wireless
network
1. Tap Start > Settings > Connections tab > Wireless
LAN to open the Wireless LAN Settings screen.
2. On the Power Mode tab of
the Wireless LAN Settings
screen, move the Power
Save Mode slider to a
position that optimizes
performance with the least
power consumption.
For example, move the
slider to the left (Best
Performance) to have
the optimal WLAN
performance; move to
the right (Best Battery)
to obtain the maximum
battery usage.
To check the wireless LAN status
You can check the current wireless connection status from the
following three screens of your device:
Title bar. When you enable Wi-Fi on your device, the
Wi-Fi ON icon ( ) will appear on the title bar.
After Wi-Fi is turned on, your device scans for available
wireless networks and the wireless signal icon
( ) appears on the title bar. The arrows in this icon
will move back and forth while your device is scanning
for a wireless LAN signal. Once your device successfully
connects to a wireless LAN, the arrows stop moving.
108 Getting Connected
Wireless LAN screen - Main tab. Here, it shows the
name of the wireless network that your device is
currently connected to. The configuration and signal
quality of the wireless network are also shown.
Configure Wireless Networks screen. Tap Start >
Settings > Connections tab > Wi-Fi > Wireless tab.
This screen displays the wireless networks currently
available.
Wi-FI: Wireless tabWireless LAN: Main tab
To connect to a wireless network in the list, tap and
hold on the desired network, then tap Connect.
Tap a wireless network in the list to view or change
its connection settings.
You can also add new wireless networks, if available,
by tapping Add New.
Getting Connected 109
6.6 Using Internet Sharing
Internet Sharing connects your PC or notebook computer to
the Internet by using your devices data connection. You can
choose to connect via USB or Bluetooth.
Follow the procedure in this section to set up your device
as a USB modem. To learn how to set up your device as a
Bluetooth modem, see “Use the device as a Bluetooth modem
in this chapter.
Notes Make sure you have set up a phone dial-up modem
connection on your device. If your device has not been set
up with a data connection yet, tap Menu > Connection
Settings on the Internet Sharing screen. For more
information about setting up a phone dial-up connection,
see "To set up a dial-up connection to your ISP".
If you want to use a USB cable connection, you must first
install Microsoft ActiveSync version 4.2 or later on the
computer.
Before using Internet Sharing, disable ActiveSync on your
computer.
To set up your device as a USB
modem
1. On your device, tap Start
> Programs > Internet
Sharing.
2. In the PC Connection list,
select USB.
3. In the Network
Connection list, select the
name of the connection
that your device uses to
connect to the Internet.
4. Plug in the USB cable between your device and the
computer.
5. Tap Connect.
To end the Internet connection
On the Internet Sharing screen, tap Disconnect.
110 Getting Connected
6.7 Using Terminal Services Client
The Terminal Services Client allows you to log on to a PC
running Terminal Services or Remote Desktop, and use all
the resources available on that PC. For example, instead of
running Word Mobile on your device, you can run the PC
version of Word and access the .doc files available on that PC.
To connect to a Terminal Server
1. On your device, tap Start > Programs > Terminal
Services Client.
2. Enter the server name.
3. You can also select a server name in Recent servers if
you have recently connected to a server.
4. Select the Limit size of server desktop to fit on this
screen check box if you want to use programs that have
been specifically sized for use with your device.
5. Tap Connect.
To navigate within Terminal Services Client
When connected to a remote server, you may notice that the
screen is displaying more than one horizontal and vertical
scroll bar. Use these scroll bars to either scroll the contents
on the PC, or to scroll the PC display through the Terminal
Services Client window.
To make sure you are scrolling the PC display through
Terminal Services Client, use the five directional buttons at
the bottom of the Terminal Services Client window. To better
fit information on the screen, select the Limit size of server
desktop to fit on this screen check box. For best results, the
programs on your desktop PC should be maximized.
To disconnect without ending a session
1. From the Terminal Services Client screen on your device,
tap Start > Shutdown.
2. Tap Disconnect.
Getting Connected 111
Notes Do not use the Start menu on your device.
If a network administrator has configured Terminal
Services Client on your device to reconnect to
disconnected sessions, and you previously disconnected
from a Terminal Server without ending the session, the
Terminal Services Client reconnects to that session.
To disconnect after ending a session
1. From the Terminal Services Client screen on your device,
tap Start > Shutdown.
2. Tap Log Off.
112 Getting Connected

Navigation menu
