Hui Zhou Gaoshengda Technology Co., LTD W7ZM1100
PAGE 1 OF 3
Version 1.0
WIFI Module
IEEE
802.11 b/g/n
1T/1R
Model Number:
W7ZM1100
The W7ZM1100 is a 2.4GHz WIFI 1×1 module. The WLAN operation supports 20MHz,40MHz channels for data
rates up to 150Mbps. It fully complies with IEEE 802.11 b/g/n feature rich wireless connectivity at high
standards,delivers reliable,cost-effective, throughput from an extended distance.
Product Name
WIFI Module
Model
W7ZM1100
Standard
802.11 b/g/n
Interface
USB
Data Transfer Rate
1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,90 and maximum of 300Mbps
Modulation Method
DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
Frequency Band
2412~2462 MHz
Operation Mode
Infrastructure
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
3.3V±10%
Current Consumption
<
1000mA
Antenna Type
PIFA
Operating
Temperature
0 ~ 60°C ambient temperature
Storage Temperature
-40 ~ 80°C ambient temperature
Humidity
5 to 95 % maximum (non-condensing)
Product Features
Product Description
◆
Complies with IEEE 802.11b/g/n for 2.4GHz Wireless LAN.
◆One transmit and One receive path(1T1R)
◆ Works with all existing network nfrastructure.
◆Capable of up to 128-Bit WEP Encryption.
◆Freedom to roam while staying connected.
◆ UP to 150Mbps High-Speed Transfer Rate in 802.11n mode of operation.
◆ Operating Systems:Android,Linux,Win7,XP
◆ Low power consumption.
◆ Easy to install and config ure.
◆High speed USB 2.0 interface
◆ROHS com pliant
Product Specification
![](/img.php?id=4116266&img=bg2.png)
Hui Zhou Gaoshengda Technology Co., LTD W7ZM1100
PAGE 2 OF 3
Version 1.0
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Caution: The user is cautioned that changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
If power exceeds the limit and the distance(Over 20cm distance in actual use between the device and user) is
compliant with the requirement
FCC RF Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with a minimum distance of 20cm between the radiator and any part
of your body.
The device must be professionally installed
The intended use is generally not for the general public.It is generally for industry/commercial use.
The connector is within the transmitter enclosure and can only be accessed by disassembly of the transmitter that is not
normally required. the user has no access to the connector.
Installation must be controlled. Installation requires special training
Canada Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the
device.
L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes :
1)L'appareil ne doit pas produire de brouillage;
2)L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
![](/img.php?id=4116266&img=bg3.png)
Hui Zhou Gaoshengda Technology Co., LTD W7ZM1100
PAGE 3 OF 3
Version 1.0
Please notice that if the ISED certification number is not visible when the module is installed inside another
device, then the outside of the device into which the module is installed must also display a label referring to the
enclosed module. This exterior label can use wording such as the following: “Contains IC:12290A-W7Z” any
similar wording that expresses the same meaning may be used.
l'appareil hôte doit porter une étiquette donnant le numéro de certification du module d'Industrie Canada, précé
dé des mots « Contient un module d'émission », du mot « IC:12290A-W7Z » ou d'une formulation similaire
exprimant le même sens, comme suit
The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102 and
compliance with RSS-102 RF exposure, users can obtain Canadian information on RF exposure and
compliance.
Le dispositif rencontre l'exemption des limites courantes d'évaluation dans la section 2.5 de RSS 102 etla
conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne surl'exposition et la
conformité de rf.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant en même temps qu'aucune autre antenne ouémetteur.
Cet équipement devrait être installé et actionné avec une distance minimum de 20 centimètres entre le
radiateur et votre corps.
This radio transmitter 12290A-W7Z has been approved by Innovation, Science and Economic
Development Canada to operate with the antenna types listed below, with the maximum permissible
gain indicated. Antenna types not included in this list that have a gain greater than the maximum gain
indicated for any type listed are strictly prohibited for use with this device.
Le présent émetteur radio 12290A-W7Z a été approuvé par Innovation, Sciences et Développement
économique Canada pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal. Les types d'antenne non inclus dans cette liste, et dont le gain est supérieur au
gain maximal indiqué pour tout type figurant sur la liste, sont strictement interdits pour l'exploitation de
l'émetteur.
The concrete contents to check are the following three points.
1) Must use a PIFA antenna such as RFMTA340758IMAB701 with gain not exceeding 3.52 dBi
2) Should be installed so that the end user cannot modify the antenna;
3) Feed line should be designed in 50ohm
Fine tuning of return loss etc. can be performed using a matching network.
Le contenu concret à vérifier sont les trois points suivants.
1) doit utiliser une antenne comme rfmta340758imab701 avec pifa gain n'excédant pas 3,52 dbi
2) doivent être installés de façon que l'utilisateur final ne peut pas modifier l'antenne
3) La ligne d’alimentation doit être conçue en 50ohm
Le réglage précis de la perte de rendement, etc. peut être effectué en utilisant un réseau correspondant.
Frequency (MHz)
fréquences Antenna Type
types d'antenne
Antenna Gain (dBi)
Gain maximal
d'antenne
2412-2462 PIFA Antenna 3.52
![](/img.php?id=4116266&img=bg4.png)
Hui Zhou Gaoshengda Technology Co., LTD W7ZM1100
PAGE 4 OF 3
Version 1.0
Notice to OEM integrator
Must use the device only in host devices that meet the FCC/ISED RF exposure category of mobile, which means the
device is installed and used at distances of at least 20cm from persons.
The end user manual shall include FCC Part 15 /ISED RSS GEN compliance statements related to the transmitter as
show in this manual.
Host manufacturer is responsible for compliance of the host system with module installed with all other applicable
requirements for the system such as Part 15 B, ICES 003.
Host manufacturer is strongly recommended to confirm compliance with FCC/ISED requirements for the transmitter
when the module is installed in the host.
Must have on the host device a label showing Contains FCC ID: 2AC23-W7Z,IC:12290A-W7Z
l'hôte doit utiliser l'instrument uniquement dans des dispositifs qui répondent à la fcc / (catégorie d'exposition rf
mobile, ce qui signifie le dispositif est installé et utilisé à une distance d'au moins 20 cm de personnes.
le manuel de l'utilisateur final doit inclure la partie 15 / (fac rss gen déclarations de conformité relatives à
l'émetteur que de montrer dans ce manuel.
le fabricant est responsable de la conformité de l'hôte, le système d'accueil avec le module installé avec toutes
les autres exigences applicables du système comme la partie 15 b, ices - 003.
accueillir le fabricant est fortement recommandé de confirmer la conformité avec les exigences de la fcc /
(émetteur lorsque le module est installé dans l'hôte.
le dispositif d'accueil doivent avoir une étiquette indiquant contient FCC ID: 2AC23-W7Z,IC:12290A-W7Z
