HUIZHOU GAOSHENGDA TECHNOLOGY WC1KR2601 WIFI Module User Manual
Hui Zhou Gaoshengda Technology Co.,LTD WIFI Module Users Manual
User Manual
Hui Zhou Gaoshengda Technology Co., LTD WC1KR2601
Address: NO.2 HuaXing RD,ZhongKai High Technology Development Area,Huizhou,Guangdong, China
PAGE 1 OF 3
Version 1.0
WIFI Module
IEEE 802.11 a/b/g/n/ac 2T/2R
Model Number: WC1KR2601
Product Descrition
The WC1KR2601 is a complete dual-band(2.4GHz and 5GHz)WIFI 2×2 MIMO module. This module provides a high level of
integration with a dual-stream IEEE 802.11ac MAC/ base band /radio.The WLAN operation supports 20MHz,40MHz and 80MHz
channels for data rates up to 866.7Mbps. It fully complies with IEEE 802.11 a/b/g/n/ac feature rich wireless connectivity at high
standards,delivers reliable,cost-effective, throughput from an extended distance.
Product Features
Product Specification
Model
WIF Module
Product Name
WC1KR2601
Standard
802.11 a /b/g/n/ac
Interface
USB
Data Transfer Rate
1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,90,120 and maximum of 866.7Mbps
Modulation Method
DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11a)
QPSK,BPSK,16QAM,64QAM,256QAM with OFDM (802.11ac)
Frequency Band
2.4G: 2412~2462 MHz
5G: 5150~5250MHz,5725~5850MHz
Operation Mode
Infrastructure
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
3.3V±10%
Current Consumption
＜1000mA
Antenna Type
PIFA
Operating Temperature
0 ~ 60°C ambient temperature
Storage Temperature
-40 ~ 80°C ambient temperature
Humidity
5 to 95 % maximum (non-condensing)
NOTICE:
◆please keep this product and accessories attached to the places which children can't touch;
◆do not splash water or other liquid onto this product, otherwise it may cause damage;
◆do not put this product near the heat source or direct sunlight, otherwise it may cause deformation
◆or malfunction;
◆please keep this product away from flammable or naked flame;
◆ Complies with IEEE 802.11b/g/n for 2.4GHz and IEEE 802.11a/n/ac 5GHz Wireless LAN.
◆Two transmit and Two receive path(2T2R)
◆ Works with all existing network nfrastructure.
◆Capable of up to 128-Bit WEP Encryption.
◆Freedom to roam while staying connected.
◆ UP to 866.7 Mbps High-Speed Transfer Rate in 802.11ac mode of operation.
◆ Operating Systems：Linux,Win7, Win8, Win10,XP
◆ Low power consumption.
◆ Easy to install and configure.
◆High speed USB 2.0 interface
◆ROHS compliant
Hui Zhou Gaoshengda Technology Co., LTD WC1KR2601
Address: NO.2 HuaXing RD,ZhongKai High Technology Development Area,Huizhou,Guangdong, China
PAGE 2 OF 3
Version 1.0
◆please do not repair this product by yourself. Only qualified personnel can be repaired.
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
The devices must be installed and used in strict accordance with the manufacturer’s instructions as described in the
user documentation that comes with the product. Modular could be only used in mobile or fix device, and could not be
used in any portable device.
The module must be installed in TV set.
In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including
the transmitter) and obtaining a separate FCC authorization.
Caution!
The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user authority to operate the equipment.
Regulation information
(1) This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or
transmitter.
(2) This compliance to FCC radiation exposure limits for an uncontrolled environment, and minimum of 20cm
separation between antenna and body.
(3) The device is going to be operated in 5150~5250MHz frequency range. It is restricted indoor environment only.
(4) Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove
this RF module in the user’s manual of the end product which integrates this module.
(5) The end product must carry a label stating “Contains TX FCC ID: 2AC23-WC1KR2601”.
