HUIZHOU GAOSHENGDA TECHNOLOGY WF7E WiFi Module User Manual manual
Hui Zhou Gaoshengda Technology Co.,LTD WiFi Module manual
User Manual
PRODUCTS USERMANUAL
WIFI Module
IEEE
802.11b/g/n
1T/1R
Model Number:
WF7ERL1500
WF7ERL1500 is a high-gain and low power consumption wifi mudule . You can use
it on IEEE802.11b/g/n wireless Local Area Networks and USB 2.0 Wi-Fi Dongle.It
fully complies with IEEE 802.11n and IEEE 802.11b/g feature rich wireless
connectivity at high standards,delivers reliable,cost-effective,throughput from an
extended distance.
◆ Complies with IEEE 802.11g; 802.11b; 802.11n standard for 2.4GHz Wireless
LAN.
◆ Supports Ad-Hoc/Infrastructure modes
(This device supports Ad-Hoc mode, however Ad-Hoc is only possible in the
channels 2412-2462MHz and 2422-2452MHz as this is fixed in the firmware of the
module, it can not operate outside the certified channels as indicated in this FCC
certification filing.)
◆ Supports PC Card hot-SWAP and true Plug & Play.
◆ Works with all existing network infrastructure.
◆ Supports Wi-Fi Protected Setup (WPS) configuration function
◆ Capable of up to 128-Bit WEP Encryption.
◆ Freedom to roam while staying connected.
◆ 22-Mbps Packet Binary Convolution Coding (PBCC)
(according to the IEEE Std 802.11b high-rate specification ).
◆ UP to 54 Mbps High-Speed Transfer Rate in 802.11g mode of operation.
◆ Integrated Antenna.
◆ Supports Windows 2000, XP32/64,Vista32/64,Linux
◆ Low power consumption.
◆ Easy to install and configure.
Product Features
Product Description
PRODUCTS USERMANUAL
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Caution:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
FCC Important Notes:
(1)
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This transmitter should be installed and operated with a
minimum distance of 20 centimeters between the radiator and your body and must
not be co-located or operating in conjunction with any other antenna or transmitter.
This equipment complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
The devices must be installed and used in strict accordance with the manufacturer’s
instructions as described in the user documentation that comes with the product.
Modular could be only used in mobile or fix device, and could not be used in any
portable device.
Caution!
PRODUCTS USERMANUAL
The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the
user authority to operate the equipment.
(2)
Co-location Warning:
This device and its antenna(s) must not be co-located or operating in conjunction
with any other antenna or transmitter.
(3)
Limited Channels fixed for use in the US:
IEEE 802.11b or 802.11g or 802.11n(HT20) operation of this product in the U.S. is
firmware-limited to Channel 1 through 11.
IEEE 802.11n(HT40) operation of this product in the U.S. is firmware-limited to
Channel 3 through 9.
(4)
OEM integration instructions:
This device is intended only for OEM integrators under the following conditions:
The antenna must be installed such that 20 cm is maintained between the antenna
and users, and the transmitter module may not be co-located with any other
transmitter or antenna. The module shall be only used with the intergral antenna(s)
that has been originally tested and certified with this module.
As long as 3 conditions above are met, further transmitter test will not be required.
However, the OEM integrator is still responsible for testing their end-product for any
additional compliance requirements required with this module installed (for example,
digital device emissions, PC peripheral requirements, etc.).
(5)
Validity of using the module certification:
In the event that these conditions cannot be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization
for this module in combination with the host equipment is no longer considered valid
and the FCC ID of the module cannot be used on the final product. In these
circumstances, the OEM integrator will be responsible for re-evaluating the end
product (including the transmitter) and obtaining a separate FCC authorization.
(6)
End product labeling:
This transmitter module is authorized only for use in device where the antenna may
be installed such that 20 cm may be maintained between the antenna and users.
The final end product must be labeled in a visible area with the following:
Contains FCC ID: 2AC23WF7E
(7)
Information that must be placed in the end user manual:
PRODUCTS USERMANUAL
The OEM integrator has to be aware not to provide information to the end user
regarding how to install or remove this RF module in the user's manual of the end
product which integrates this module. The end user manual shall include all
required regulatory information/warning as show in this manual.
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
