HUIZHOU GAOSHENGDA TECHNOLOGY WT38M2001 WIFI+BT Module User Manual

Hui Zhou Gaoshengda Technology Co.,LTD WIFI+BT Module Users Manual

User manual

PRODUCTS USERMANUAL
WT38M2001T
WIFI+BT Module
IEEE
802.11b/g/n/a
2T/2R
Model Number:
WT38M2001T
The WT38M2001T is a high-gain and low power consumption wifi module . It fully complies
with IEEE 802.11n and IEEE 802.11b/g/a feature rich wireless connectivity at high
standards,delivers reliable,cost-effective,throughput from an extended distance.When
3.3V, USB bus and GND were connected,This module is working. The Bluetooth part supports
latest 4.2+HS operation.
Product Features
Product Description
Complies with IEEE 802.11g;
802.11b; 802.11n ; 802.11a standard
for 2.4GHz and5GHz Wireless LAN.
TWO Transmit and TWO Receive
path(2T2R)
Supports Ad-Hoc/Infrastructure modes
Works with all existing network
nfrastructure.
Capable of up to 128-Bit WEP
Encryption.
Freedom to roam while staying
connected.
UP to 300 Mbps High-Speed Transfer
Rate in 802.11n mode of operation.
Operating SystemsWindows XP
32/64,2000,Windows 7,Vista
32/64,Linux,Macintosh
Low power consumption.
Easy to install and configure.
Bluetooth v4.2 Low Energy(LE);
Bluetooth specification v2.1+EDR;
Product Specification
Model
WT38M2001T
Product Name
WIFI+BT Module
Standard
802.11b/g/n /a
Interface
/
Data Transfer Rate
1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,9
0,120 and maximum of 300Mbps
Modulation Method
QPSK , BPSK , CCK(802.11b)
QPSK , BPSK , 16QAM ,64QAM with OFDM
(802.11g)
BPSK , QPSK , 16QAM ,64QAM with
OFDM(802.11n)
QPSK , BPSK , 16QAM ,64QAM with OFDM
(802.11a)
Frequency Band
2.4GHz: CH 1~CH13 for FCC
5GHz: 5150~5250MHz, 5250~5350MHz
5470~5725MHz,5725~5850MHz
Transmit Power
< 18dBm
Operation Mode
Ad hoc, Infrastructure
Operation Range
Up to 300 meters in open space
OS Support
Windows XP 32/64,2000,Windows 7,Vista
32/64,Linux,Macintosh
Security
WEP, TKIP, AES, WPA, WPA2
Operating Voltage
5V±10%
Operating
Temperature
-10 ~ 70°C ambient temperature
Storage Temperature
-55 ~ 125°C ambient temperature
Humidity
5 to 90 % maximum (non-condensing)
PAGE 1 OF 4 Version 1.0
PRODUCTS USERMANUAL
WT38M2001T
FCC Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Caution:Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Country Code selection feature to be disabled for products marketed to the US/Canada.
This device is intended only for OEM integrators under the following conditions:
1. The antenna must be installed such that 20 cm is maintained between the antenna and users, and
2. The transmitter module may not be co-located with any other transmitter or antenna,
As long as the three conditions above are met, further transmitter testing will not be required. However, the OEM integrator
is still responsible for testing their end-product for any additional compliance requirements required with this module
installed.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the FCC authorization is no longer considered valid and the FCC ID cannot be used on the final product.
In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter)
and obtaining a separate FCC authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be
maintained between the antenna and users. The final end product must be labeled in a visible area with the following:
Contains FCC ID: 2AC23-WT38M2001.
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Industry Canada
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the following two conditions:
- This device may not cause interference; and
- This device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
L’exploitation est autorisée aux deux conditions suivantes:
- l’appareil ne doit pas produire de brouillage;
- l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
PAGE 2 OF 4 Version 1.0
PRODUCTS USERMANUAL
WT38M2001T
This radio transmitter (IC: 12290A-WT38M2001) has been approved by Industry Canada to operate with the antenna types
listed below with the maximum permissible gain indicated. Antenna types not included in this list, having a gain greater
than the maximum gain indicated for that type, are strictly prohibited for use with this device.
Le présent émetteur radio (IC: 12290A-WT38M2001) a été approuvé par Industrie Canada pour fonctionner avec les types
d'antenne énumérés ci-dessous et ayant un gain admissible maximal. Les types d'antenne non inclusdans cette liste, et dont
le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
Model Type Connector
Peak gain ( dBi )
2400~2483.5
MHz
5150~5250
MHz
5250~5350
MHz
5470~5725
MHz
5725~5850
MHz
R-SMA
3.53
5.51
5.51
5.51
5.51
R-SMA
3.59
5.47
5.47
5.47
5.47
R-SMA
3.30
4.10
4.10
4.10
4.10
N/A External
N/A External
N/A External
N/A External R-SMA
3.50
4.58
4.58
4.58
4.58
Caution:
(i) The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems;
(ii) Operations in the 5.25-5.35GHz band are restricted to indoor usage only.
Avertissement:
(i) les dispositifs fonctionnant dans la bande de 5150 à 5250MHz sont réservés uniquement pour une
utilisation à l'intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
(ii) Les opérations dans la bande de 5.25-5.35GHz sont limités à un usage intérieur seulement.
Radiation Exposure Statement
This equipment complies with Canada radiation exposure limits set forth for an uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator & your body.
Déclaration d'exposition aux radiations
Cet équipement est conforme Canada limites d'exposition aux radiations dans un environnement non contrôlé. Cet
équipement doit être installé et utilisé à distance minimum de 20cm entre le radiateur et votre corps.
This device is intended only for OEM integrators under the following condition:
The transmitter module may not be co-located with any other transmitter or antenna.
As long as the condition above is met, further transmitter test will not be required. However, the OEM integrator is still
responsible for testing their end-product for any additional compliance requirements required with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions
suivantes:
Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou antenne.
Tant que les 1 condition ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas nécessaires.
Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour toutes exigences de conformité
supplémentaires requis pour ce module installé.
Important Note:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location with another
transmitter), then the Canada authorization is no longer considered valid and the IC ID cannot be used on the final product.
In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter)
and obtaining a separate Canada authorization.
Note Importante:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations d'ordinateur portable ou
de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est plus considéré comme valide et l'ID IC
ne peut pas être utilisé sur le produit final. Dans ces circonstances, l'intégrateur OEM sera chargé de réévaluer le produit
final (y compris l'émetteur) et l'obtention d'une autorisation distincte au Canada.
End Product Labeling
The final end product must be labeled in a visible area with the following: Contains IC: 12290A-WT38M2001.
Plaque signalétique du produit final
Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: Contient des IC:
12290A-WT38M2001.
PAGE 3 OF 4 Version 1.0
PRODUCTS USERMANUAL
WT38M2001T
Manual Information to the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF
module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon d'installer ou
de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements comme
indiqué dans ce manuel.
PAGE 4 OF 4 Version 1.0
