HYUNDAI MOBIS AC1A3IHAN DIGITAL CAR AUDIO SYSTEM User Manual 07 TF EN IQS UVO2 Cover RC indd
HYUNDAI MOBIS CO., LTD. DIGITAL CAR AUDIO SYSTEM 07 TF EN IQS UVO2 Cover RC indd
Contents
- 1. Warning Statement
- 2. Users Manual
Users Manual
2TENE07
UVO SYSTEM USER'S MANUAL
1-2 PART 1. GETTING STARTED
PART 1 GETTING STARTED
1
DISC EJECT
Ejects the inserted disc.
2
FM/AM
Turns on FM/AM mode. Each press of the
FM
/
AM key will change the band in the
order of FM → AM → FM.
3 SAT
Turns on SIRIUS
TM
mode.
4 MEDIA
Turns on MEDIA mode. Each press of the
MEDIA
key will change the mode in the
order of CD → USB/iPod®/zune®
→JUKEBOX
→ AUX → BT Audio → PANDORA → CD.
5
POWER/VOLUME
Push : Turns Power On/Off.
Dial : Turns Volume Up/Down.
6
∨ SEEK/TRACK ∧
Short (under 0.8 seconds)
In FM/AM mode, automatically searches
and plays the previous or next frequency.
Control Panel
Controls and Features
1
2
3
4
5
6 7
8
9
10
11
13
12
※No will be shown if the exterior Amplifier feature is not supported.
PART 1. GETTING STARTED 1-3
GETTING STARTED
In SIRIUS
TM
mode, automatically searches
and plays the previous or next channel.
In MEDIA mode (CD, MP3, USB, iPod
®
,
zune
®
, BT AUDIO), plays the previous or
next track, song, or file. In PANDORA
Radio, PANDORA Radio skip (Seek up).
In JUKEBOX mode, plays the previous or
next track.
Long (over 0.8 seconds)
In FM/AM mode, quickly moves through
the frequencies when the button is pressed
and held. Once released, automatically
searches and plays the previous or next
frequency.
In SIRIUS
TM
mode, quickly moves to the
previous or next channel.
In MEDIA mode (CD, MP3, USB, iPod
®
,
zune
®
, BT AUDIO), REW/FF the current
track, song, or file.
In JUKEBOX mode, REW/FF the current
track.
7
∨ CATEGORY ∧
In SIRIUS
TM
mode, moves to the previous or
next SIRIUS
TM
category.
8
TUNE
In FM/AM mode, turn the knob to manually
search for frequencies.
In SIRIUS
TM
mode, turn the knob to
manually search for channels. Press the
knob to receive the selected channel.
In MEDIA mode (CD, MP3, USB, iPod
®
,
zune
®
), turn the knob to manually search for
the previous or next track, song, or file.
Press the knob to receive the selected
track, song, or file. In PANDORA Radio,
searches PANDORA Radio stations.
In JUKEBOX mode, turn the knob to
manually search for the previous or next
track. Press the knob to receive the
selected track.
9
SETUP
Displays SETUP mode.
10
PHONE
Displays Bluetooth
®
wireless technology
Phone mode.
11
eServices
Displays UVO eServices mode.
12
DISP
Turns off the screen.
13
RESET
Reset the system to be used if system is
acting abnormally.
1-4 PART 1. GETTING STARTED
PART 1 GETTING STARTED
Steering Wheel
1
∨ SEEK/TRACK ∧
Short (under 0.8 seconds)
In FM/AM mode, automatically searches
and plays the previous or next preset
frequency.
In SIRIUS
TM
mode, automatically searches
and plays the previous or next preset
channel.
In MEDIA mode (CD, MP3, USB, iPod
®
,
zune
®
, BT AUDIO), plays the previous or
next track, song, or file. In PANDORA
Radio, PANDORA Radio skip (Seek up).
In JUKEBOX mode, plays the previous or
next track.
Long (over 0.8 seconds)
In FM/AM mode, quickly moves through
the frequencies when the button is pressed
and held. Once released, automatically
searches and plays the previous or next
frequency.
In SIRIUS
TM
mode, quickly moves to the
previous or next channel.
In MEDIA mode (CD, MP3, USB, iPod
®
,
zune
®
, BT AUDIO), REW/FF the current
1
2
34
5
6 7
PART 1. GETTING STARTED 1-5
GETTING STARTED
track, song, or file.
In JUKEBOX mode, REW/FF the current
track.
2
+ VOLUME -
Turns Volume Up/Down.
3
MODE
Short (under 0.8 seconds)
Changes the mode. Each press will
change
modes in the order of FM → AM →
SIRIUS
TM
→ CD → USB/iPod
®
/zune
®
→
JUKEBOX → AUX → BT Audio →
PANDORA → FM.
Long (over 0.8 seconds)
While the system is off, turn the system on.
While the system is on, turn off the system.
4
MUTE
Mutes the sound.
5
Voice Command
Short (under 0.8 seconds)
If Voice recognition is off, turns on Voice
recognition.
If system is speaking, interrupts speaking
and enters listening mode.
Long (over 0.8 seconds)
If Voice recognition is on, turns off Voice
recognition.
6
SEND (Bluetooth
®
wireless technology
Phone)
Pressing this key will receive an incoming
call. If the Audio is on, the Bluetooth
®
wireless technology phone screen will be
displayed.
When a SMS message is received, reads
back message.
7
END (Bluetooth
®
wireless technology
Phone)
Pressing this key will reject an incoming
call. If pressed during a call, the current call
will be ended.
When a SMS message is received, ignores
message.
1-6 PART 1. GETTING STARTED
PART 1 GETTING STARTED
Basic Features
System Power
1. Turning System Power On
1. Turn on the ignition.
2. While the system is off, press the
POWER/VOL
knob to turn the system on.
3. The system will automatically restore the
most recently played mode. For example,
pressing the
POWER/VOL
knob will turn on
the system and display FM radio mode if
FM mode had been the last operated
mode prior to turning off the system.
4. You can also turn the system on by
pressing the FM
/
AM , SAT and MEDIA
keys.
Note
●
Pressing any one of the FM
/
AM , SAT ,
and MEDIA keys will turn on the system
and display the last mode corresponding to
each key. For example, pressing the MEDIA
key while a CD or other media source is
loaded, will turn on the system and display
CD mode if the last operated MEDIA mode
prior to turning off the system had been CD
mode.
2. Turning System Power Off
1. While the system is on, press the
POWER/VOL
knob to turn off the system.
Note
●
If the system power was on when the ignition
was turned off, the system will turn back on
automatically. Conversely, if the system
power was off when the ignition was turned
off, the system will remain off.
●
If the battery voltage is low, the audio may
take a prolonged time to boot upon turning
on the vehicle.
PART 1. GETTING STARTED 1-7
GETTING STARTED
Select Display Language
The UVO system allows you to select the
preferred display language for maximum
convenience and system usability. The system
provides you with options of three languages -
English, French (Canadian) and Spanish. The
default language is English.
1. Press the SETUP key on the control panel.
2. Press the Main button.
3. Press the English button next to the
Language menu.
4. Select the desired language.
5. The system will reboot and automatically
restore the most recent mode in the new
language.
Resetting and Initializing
UVO system
1. Resetting the system
If the system is behaving abnormally, press the
reset button to reset the system.
1. Use a ball-point pen or similar object to
press the RESET key.
2. The system will reboot and automatically
restore the most recent mode.
Caution
●
The reset button should only be used in case of
system malfunction. Never use the reset key while
the system is operating normally as it may cause
damage to the system.
●
If you wish to reset while the system is operating
normally, turn the power off first then reset.
1-8 PART 1. GETTING STARTED
PART 1 GETTING STARTED
2. Initializing the system
1. Press the SETUP key on the control panel.
2. Press the System button.
3. Press the Factory defaults button.
Note
●
Initializing the system will erase all Phone
settings, and other changes which you have
made to the system.
●
Some songs in the USB or CD may be
misrecognized during the indexing process.
If such problems persist, reset the device
using the Factory Defaults button in
SETUP>System.
●
For updating the system, visit http://www.kia.
com
PART 1. GETTING STARTED 1-9
GETTING STARTED
Sound and Display Settings
Sound Settings
Sound settings can be adjusted from any audio
mode. The system allows you to optimize
various sound settings to add convenience
when listening to the system.
Press the Sound button on the main screen of
each audio mode (FM/AM, SIRIUS
TM
, MEDIA,
PANDORA Radio, JUKEBOX) to enter Sound
Setup.
Note
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
1. FADER/BALANCE
Fader/Balance allows you to adjust the position
of sound within the vehicle. For instance,
adjusting the sound so that it is closer to the
driver-side seat will proportionally lower the
volume in the passenger-side and rear seats.
1. Press the Fader/Balance setting button.
2. Use the
▲
,
▼
,
◀
,
▶
buttons to
make adjustments to the sound position.
3. Press the button to return to Sound
Setup.
Note
●
Press the Default button to restore the
default setting.
1-10 PART 1. GETTING STARTED
PART 1 GETTING STARTED
2. TONE
Tone allows you to make changes to the
Treble, Middle and Bass settings.
1. Press the Tone setting button.
2. Use the
◀
,
▶
buttons to make
adjustments to the Treble, Middle and
Bass. Press the button to return to
Sound Setup.
Note
●
Press the Default button to restore the
default setting.
3. Touch Screen Beep
Touch Screen Beep allows you to turn on/off
the beep that sounds when you touch the
screen.
1. In Sound Setup, press the On or
Off button next to the Touch Screen
Beep menu to turn the feature on or off.
4. Speed Dependent Volume Control
Speed Dependent Volume Control allows you
to automatically control the volume according
to the speed of the vehicle. This feature will
gradually increase the volume as speed
increases to offset outside noise.
1. Press the On or Off button next to
the Speed Dependent Volume Control
menu to turn the feature on or off.
PART 1. GETTING STARTED 1-11
GETTING STARTED
Display Settings
The various Display setup options offered
within the UVO system allow you to change
display settings according to your personal
preference.
1. Press the SETUP key on the control panel.
2. Press the Display button to enter Display
Setup mode.
Note
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
1. Setting Brightness
The UVO system allows you to control the
screen brightness automatically and manually.
●
Automatic Brightness Control
When the Display brightness is set to
automatic, the brightness will be controlled
automatically by assessing the amount of
ambient light.
1. Press the Display button.
2. Press the Automatic button.
●
Manual Brightness Control
1. Press the Display button.
1-12 PART 1. GETTING STARTED
PART 1 GETTING STARTED
2. Press the Daylight or Night
buttons.
3. Use the
◀
,
▶
buttons to make
adjustments to the display brightness.
Note
●
When Brightness control is set to
Automatic
, the manual
◀
,
▶
buttons are not active.
●
Press the Default button to restore the
default setting.
Turning Display On and Off
This feature turns off the display, allowing you
to listen only to the audio. It is a useful feature
when you are driving at night and wish to
eliminate glare from the display. Even when
the display is off, audio will still be played.
1. Press the Display button.
2. Press the Display off button.
PART 1. GETTING STARTED 1-13
GETTING STARTED
3. Press any key on the control panel or
steering wheel controller to turn the display
back on.
Note
●
Touching any place on the screen will also
turn on the display.
2-2 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
FM/AM MODE
FM/AM Mode Screens and Features
1
Mode display
Displays the FM /AM mode.
2
PRESET indicator
If listening to a preset, displays the preset
number.
3
Frequency
Displays the current frequency.
4
Program Type
If data is being transmitted, displays the
program type.
5
Program Service Name
If data is being transmitted, displays the
program service name.
6
Radio text
If data is being transmitted, displays radio
text information.
7
HD RadioTM (Optional)
Changes HD RadioTM
stations
.
Becomes active when an HD RadioTM
broadcast is being received.
8
Radio Icon
When pressed while listening to RDS or
HD Radio(Optional) stations, displays infor-
mation about the current station (frequency,
station, artist, title).
9
Presets
Enters Preset list screen.
10
Scan
Scans all frequencies and plays only fre-
quencies with high quality reception for 5
seconds each.
11
Sound
Enters Sound Setup.
12
HD RadioTM Station Channel Number
(Optional)
Displays the channel number for the cur-
rent HD RadioTM station.
5
4
6
1
8
2
9 7
12
10
14
15
13
3
11
PART 2. AUDIO FEATURES 2-3
AUDIO FEATURES
13
HD RadioTM Station name (Optional)
Displays the name of the HD RadioTM
Station.
14
Artist name (Optional)
Displays the artist name.
15
Song Title (Optional)
Displays the title name.
Listening to the FM/AM radio
1. Press the FM
/
AM key on the control
panel. The most recently played FM/AM
radio band will automatically begin
playing.
2. Press the FM
/
AM key to switch to the
desired radio band.
Note
●
Each press of the FM
/
AM key will change
the band in the order of FM → AM → FM.
●
Even when the system power is off, press
the FM
/
AM key to turn on the most recently
played FM/AM mode.
●
The RDS (Radio Data System) operates in
areas with FM stations broadcasting RDS
signals.
1. Selecting a broadcast frequency
The UVO system provides you with various
ways to search for radio broadcasts. There are
3 ways to select radio broadcasts- selecting
through SEEK, selecting through manual
search, and selecting through presets.
●
Selecting through SEEK
Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel for under 0.8 seconds. As
SEEK operates, the previous or next radio
broadcasts with high quality reception will
automatically be searched and played.
Note
●
While SEEK is operating, pressing the same
SEEK
∨
TRACK
∧
key will terminate SEEK. Pressing
the opposite key will operate SEEK in the
reverse direction.
●
Press and hold the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys
(over 0.8 seconds) to quickly move through
the frequencies while the button is pressed
and held. Once released, the system will
automatically search and play the previous
or next frequency.
2-4 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
●
Selecting through manual search
1. Turn the TUNE knob on the control
panel in clockwise or counter-clockwise
direction. Each click will increase or
decrease the frequency by 1 step (FM:
0.2MHz, AM: 10kHz).
2. When you find the desired radio broad-
cast, stop turning the TUNE knob to lis-
ten to the selected frequency.
●
Selecting through preset
1. Press the Presets button.
2. Select the desired preset and press the
button to start listening.
Note
●
Press the
∧
,
∨
keys (under 0.8 sec-
onds) on the steering wheel controller to flip
through the presets sequentially.
●
Press and hold the
∧
,
∨
keys (over 0.8
seconds) on the steering wheel controller to
operate SEEK.
2. Storing presets
Presets are a way for you to save your favorite
radio broadcasts. Up to 12 presets can be
saved in FM mode while up to 6 frequencies
can be saved in AM mode.
1. Select the desired radio broadcast.
2. Press the Presets button.
3. From the preset list, press and hold (over
0.8 seconds) the preset number button to
which you wish to save.
4. The current radio broadcast will automati-
cally be saved to the preset number. A
beep will signify that the preset has been
saved if the beep is set to ON in the sound
settings.
PART 2. AUDIO FEATURES 2-5
AUDIO FEATURES
3. Scanning FM/AM broadcast
frequencies
Radio broadcasts can be scanned to conve-
niently find radio broadcasts with high quality
reception. Each radio broadcast will be played
for 5 seconds. This feature is particularly use-
ful when traveling in new areas.
1. Press the Scan button.
Note
●
When scanning has completed an entire
revolution, the scan function will terminate
automatically and the previously played fre-
quency will be restored.
4. Preset Scan
Preset scan will scan presets in the current
band (FM-12 presets, AM-6 presets)in
sequential order. Each preset will be played
for 5 seconds.
5. Listening to HD RadioTM Stations
(Optional)
HD RadioTM Technology is a digital radio tech-
nology used by AM and FM radio stations to
transmit audio and data via a digital signal in
conjunction with their analog signals.
1. While listening to the radio, the HD RadioTM
icon will become displayed if receiving an
HD RadioTM broadcast.
2. Press the HD
▶
button to change to a dif-
ferent HD RadioTM station.
6. Viewing FM/AM Station information
When listening to an HD RadioTM station or
RDS radio station, you will be able to view sta-
tion information.
1.Press the Radio icon.
2. Information about the current station (fre-
quency, station, artist, title) will be
displayed.
2-6 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
SIRIUSTM MODE
SIRIUSTM Mode Screen and Features
1
6
3
7 8 9 10
11
24
5
12
1
Mode display
Displays the current mode as SIRIUSTM
mode.
2
Channel number
Displays the current channel number.
3
PRESET indicator
If listening to a preset, displays the preset
number.
4
Category name
Displays the category name.
5
Channel name
Displays the channel name.
6
SIRIUSTM Icon
When pressed, displays information about
the current channel (artist, title, composer
and other information).
7
Presets
Enters Preset list screen.
8
List
Displays the channel or category list.
9
Search
Displays the channel search screen.
10
Sound
Enters Sound Setup.
11
Artist
Displays the artist name.
12
Title
Displays the title.
Listening to the SIRIUSTM radio
Press the SAT key on the control panel.
The most recently played SIRIUSTM channel
will automatically begin playing.
Note
●
Even when the system power is off, pressing
the SAT key will turn on the most recently
played SIRIUSTM channel.
1. Selecting a SIRIUSTM channel
●
Selecting through SEEK
Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel for under 0.8 seconds. As SEEK
operates, the previous or next SIRIUSTM chan-
nel will automatically be searched and played.
Note
●
Press and hold the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys
(over 0.8 seconds) to quickly move through
the channels while the button is pressed and
held. Once released, the system will automat-
ically search and play the previous or next
channel.
PART 2. AUDIO FEATURES 2-7
AUDIO FEATURES
●
Selecting through manual search
1. Turn the TUNE knob on the control panel
in clockwise or counter-clockwise direc-
tion. Each click will display the corre-
sponding channel information.
2. When you find the desired SIRIUSTM chan-
nel, press the TUNE knob to listen to the
selected channel.
●
Selecting through preset
1. Press the Presets button.
2. Select the desired preset and press the
button to start listening.
Note
●
Press the
∧
,
∨
keys (under 0.8 sec-
onds) on the steering wheel controller to flip
through the presets sequentially.
●
Selecting through channel search
1. Press the Search button. The channel
search screen will be displayed.
2. Input the desired channel number and
press the Done button. To delete entries,
press the Delete button.
Note
●
If you input a number where there is no
channel, the Done button will become
inactive.
2-8 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
●
Selecting through SIRIUSTM category list
1. Press the List button.
2. Select the desired channel to start listen-
ing or press the Category List button to
display the channels in the selected
category.
2. Using Skip
1. Press the List button.
2. Press the Skip Setting button.
3. Select the channels you wish to skip.
When selected, an will be displayed
next to the selected channel.
PART 2. AUDIO FEATURES 2-9
AUDIO FEATURES
3. Storing presets
Presets are a way for you to save your favorite
SIRIUSTM channels. Up to 18 presets can be
saved in SIRIUSTM mode.
1. Select the desired SIRIUSTM channel.
2. Press the Presets button.
3. From the preset list, press and hold (over
0.8 seconds) the preset number button to
which you wish to save.
4. The current radio broadcast will automati-
cally be saved to the present number. A
beep will signify that the preset has been
saved if the beep is set to ON in the sound
settings.
4. Viewing SIRIUSTM channel information
1. Press the SIRIUSTM icon.
2. Information about the current channel
(channel, category, artist, title) will be
displayed.
2-10 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
MEDIA MODE
The MEDIA mode within your UVO system
offers a variety of media modes which allow
you convenience and ease in operating your
system. Media mode includes a variety of
modes, such as audio CD, MP3 CD, USB,
iPod®, zune®, BT audio, Aux and PANDORA.
The features listed below describe common
features which you will encounter when oper-
ating Audio CD, MP3 CD, USB, iPod®, zune®,
and JUKEBOX modes.
Common Features
●
Play/Pause
1. Insert or connect the desired media (Audio
CD, MP3 CD, USB, iPod®, zune®) or press
the MEDIA key on the control panel if the
desired media has already been inserted
or connected.
2. Each press of the MEDIA key will change
the mode in the order of CD → USB/
iPod®/zune® → JUKEBOX → AUX → BT
Audio → Pandora → CD.
3. When a desired media is playing and you
wish to pause, press the ll button next
to the progress bar. Press the ▶ button
to restart the song.
●
REW/FF
1. Press and hold the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys (over 0.8 seconds) on the control panel
or the
∧
,
∨
keys (over 0.8 seconds)
on the steering wheel controller.
2. The song will rewind or fast-forward at a
rate 20 times faster than normal while the
key is being held.
3. Release the key to play from the current
position.
Note
●
If you rewind to the beginning of the current
song, the current song will automatically
begin playing.
●
If you fast-forward to the end of the current
song, the next song will automatically begin
playing.
PART 2. AUDIO FEATURES 2-11
AUDIO FEATURES
●
Jump
1. You can jump to different points in a song
by touching the position on the progress
bar.
●
Using Repeat
The repeat setting can be used to repeat
the song that is currently playing.
1. Press the Repeat button. The 'Repeat'
icon will be displayed.
2. Press once to turn on the Repeat setting
and again to turn off.
●
Using Shuffle
The Shuffle setting can be used to play all
song in the current mode randomly.
1. Press the Shuffle button. The 'Shuffle'
icon will be displayed.
2. Press once to turn on the Shuffle setting
and again to turn off.
2-12 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
AUDIO CD MODE
Cautions upon handling Audio CDs
Precautions upon handling discs
●
Store discs within their intended cases to
prevent scratches.
●
Never use heart-shaped, octagon-
shaped or any other abnormally shaped
discs.
●
Never expose discs to direct sunlight for
prolonged periods of time. Such expo-
sure may lead to disc deformation.
●
Never clean with solvents, such as anti-
static sprays, cleaners, benzene, or
thinners.
●
Dust, scratches, and other foreign sub-
stances may cause popping sounds as
well as sound deterioration.
●
Never place paper on either side of the
disc or write on disc surfaces.
●
Clean fingerprints and dust off the signal
surface (coated side) of the disc with a
soft cloth.
●
Copy-protected CDs, such as S-type
CDs may not operate properly in the
system.
●
Data CDs are not supported by the system.
For safe and efficient operation
●
Never disassemble the CD Player(CDP)
for repair purposes. Contact your place
of purchase in case of malfunction. (Full
service assistance will not be provided if
the user disassembles the device.)
●
Never use water to clean the system.
●
Use caution not to introduce foreign sub-
stances into the disc slot.
●
The system may not operate in extremely
hot or cold temperatures. (The opera-
tional temperature range is:
14℉ ~ 149℉).
●
Steam may condense on the fiber optic
lens due to rain, wet conditions, or heat
caused by system operation.
●
Never clean the system with chemical
solvents. Always use a clean and dry
cloth.
1. Supported disc format
●
The disc types supported by this device
are as shown below.
Disc format Disc media Format
CD CD CD-DA
CD-R MP3
CD-RW WMA
CD-ROM
CD-TEXT
Disc Size 5inch (12.7cm)
Disc Format Audio Format
CD LPCM
MP3 MPEG1, Layer3
MPEG2, Layer3
MPEG2.5
WMA Ver. 9
PART 2. AUDIO FEATURES 2-13
AUDIO FEATURES
●
CD-R or CD-RW DISC burned with a
bulk CD without quality guarantees may
not be recognized by the device.
●
Inserting an abnormal disc may result in
faulty operation.
2. Disc/content format and compatibility
Ordinary disc compatibility
●
This system has been designed to be
compatible with software bearing the fol-
lowing logo marks.
●
CD-R/RW discs (Audio CD and MP3 CD)
created with CD-writing devices or per-
sonal computers may not operate
properly.
Special formats or special features
regarding software
CD-R/RW Compatibility
●
This system operates as a CD-ROM and
supports CD-R and CD-RW discs in CD
audio or MP3 CD format.
●
CD-R/RW discs burned as audio CDs
which have not been finalized are not
supported by the device. However, some
information, such as play time, may still
be displayed.
PC-created DISC compatibility
●
When burning a disc with a personal
computer, even discs compatible with the
formats described above may not oper-
ate properly due to software settings
within the burning application. In such
cases, contact the software developer.
●
Additional information regarding compati-
bility can be found on the CD-R/RW soft-
ware disc box.
●
DVD-R/RW discs are not supported by the device.
Compressed audio compatibility
This system plays audio files compressed
by MPEG-1 audio stream layer 3(MP3)
using 32, 44.1 and 48kHz fixed bit rates.
Incompatible files are not supported.
●
Variable bit rate files may operate, but the
play time information may not be properly
displayed.
●
Physical formats of CD: Model 1, Model 2
XA format 1.
●
This system only supports tracks with file
extension of ".MP3" or ".WMA".
●
This system does not support multises-
sion discs.
●
This system supports a maximum of 256
folders and maximum 512 files. Folders
and files which exceed this limit will not
be supported.
●
There are various bit rates which can be
encoded onto MP3 files. This system has
been designed to be compatible with vari-
ous bit rates. Audio which has been
encoded at 128kbps will sound similar to
CD audio sound quality. Although this
device supports low bit rate MP3 files, such
files may result in a low quality sound.
●
For stable operation, the use of files in
95kbps~192kbps bit rate range and 44.1kHz
sampling frequency is recommended.
●
For Mixed CDs (MP3+CD-DA), only
CD-DA files will be recognized and
supported.
2-14 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
AUDIO CD Mode Screen and
Features
1
Mode Display
Displays that the current mode is CD
mode.
2
Repeat
If Repeat is operating, the current track will
be repeated and the corresponding icon
will be displayed.
3
Shuffle
If Shuffle is operating, the tracks will be
played in random order and the
corresponding icon will be displayed.
4
Sound
Enters Sound Setup.
5
Track Number
Displays the track number
6
Play Time
Displays the play time.
7
Current/Total Track Number
Displays the current track number and total
number of tracks on CD.
8
DISC indicator
Displays that a DISC has been inserted.
Inserting/Ejecting a Disc
1. Inserting a Disc
Insert the disc into the slot. The disc will begin
playing automatically after it has been
inserted.
2. Ejecting a Disc
Press the button.
The disc will immediately be stopped and
ejected.
Note
●
If the disc is straddled on the slot without
removing for approximately 10 seconds, the
disc will be re-inserted automatically into the
disc player. In such cases, the disc will not
begin playing automatically.
1
2 3 4
5
7
8
6
PART 2. AUDIO FEATURES 2-15
AUDIO FEATURES
Listening to an Audio CD
1. Insert a CD or press the MEDIA key on
the control panel if the CD has already
been inserted.
2. When a track is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the track.
Note
●
When playing a CD-TEXT, the title and artist
will also be displayed.
Selecting a CD track
1. Selecting through Track Up/Down
1. Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on
the steering wheel controller to play the
desired track.
2. The previous or next track will begin
playing.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller
are pressed and released after the track has
played for more than 3 seconds, the start of
the current track will begin playing. If the
track has been playing for less than 3 sec-
onds, the start of the previous track will
begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control
panel in clockwise or counter-clockwise
direction. Each click will display informa-
tion about the selected track.
2. Press the TUNE knob to play the
selected track.
Note
●
The current track will continue playing even as
you search tracks through the
TUNE
knob.
2-16 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
MP3 CD MODE
Cautions upon handling MP3 CD
1. Precautions upon handling discs
●
Acceptable standard: MPEG1 AUDIO
LAYER 3
●
Acceptable sampling frequency: 32, 44.1,
48 (KHz)
●
Acceptable bit rate: 32, 40, 48, 56, 64,
80, 96, 112, 128, 160, 192, 224, 256, 320
(kbps)
●
Recommended bit rate & reference sam-
pling frequency: sampling frequency
96,128, 192 kbps fixed bit rate /44.1KHz
2. ID3 tag
●
This device supports ID3v1.0, ID3v1.1,
ID3v2.2, ID3v2.3, and ID3v2.4 ID3 tags.
3. Supported media
●
The MP3 media supported by the device
are CD-ROM and USB.
4. Supported media formats
●
This device supports ISO9660 LEVEL1
and LEVEL2. Detailed specification is as
below.
●
Maximum directory layers: 8 layers
●
Maximum folder length: 64 Bytes, file
name length: 64 Bytes
●
Maximum number of folders which can
be stored onto one disc: 256 folders
(including ROOT directory)
●
Maximum number of files which can be
stored onto one disc: 512 files
5. Precautions upon burning MP3 files
●
The use of ISO 9660 LEVEL 2 JULIET
format is recommended when burning
MP3 files. Burning in other formats may
abnormally display the file names.
●
It is possible to display up to 32 charac-
ters for file and folder names in case of
UNICODE, and up to 64 characters in
case of ASCII.
●
The full length of the artist name and the
song title can be displayed by using the
scroll function.
6. Precaution
●
Use an MP3 bit rate which is less than
128 kbps. The sound quality cannot be
guaranteed for MP3s exceeding
128kbps.
PART 2. AUDIO FEATURES 2-17
AUDIO FEATURES
MP3 CD Mode Screen and
Features
1
Mode Display
Displays that the current mode is MP3 CD
mode.
2
Menu
Displays the categories and song lists for
the MP3 CD.
3
Copy
Copies current song into JUKEBOX.
4
Repeat
If Repeat is operating, the current song will
be repeated and the corresponding icon
will be displayed.
5
Shuffle
If Shuffle is operating, the songs will be
played in random order and the corre-
sponding icon will be displayed.
6
Sound
Enters Sound Setup.
7
Play Time
Displays the play time.
8
Artist name
Displays the artist name.
9
Song Title
Displays the song title.
10
Album Art Icon
When pressed, displays information about
the current song (artist, title, album and
other information).
11
Current/Total Track Number
Displays the current track number and total
number of tracks on the current playing list.
12
DISC indicator
Displays that a DISC has been inserted.
Listening to an MP3 CD
1. Insert an MP3 CD or press the MEDIA
key on the control panel if the CD has
already been inserted.
2. When a song is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the song.
Note
●
For some media formats, the system may
require time for media indexing. In the case of
MP3 CDs, the system may take 1.5sec / song.
1
2 3 4 5 6
79
10
11
12
8
2-18 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
Selecting an MP3 CD song
1. Selecting through song Up/Down
1. Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on
the steering wheel controller to play the
desired track or song.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller is
pressed and released after the song has
played for more than 3 seconds, the start of
the current song will begin playing. If the song
has been playing for less than 3 seconds, the
start of the previous song will begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control
panel in clockwise or counter-clockwise
direction. Each click will display informa-
tion about the selected song.
2. Press the TUNE knob to play the
selected song.
3. Selecting from MP3 list
1. Press the Menu button.
2. Press the Now Playing button.
3. Press the name of the song from the list.
The song will automatically start playing.
Note
●
In the MP3 list screen, the
TUNE
knob can
also be used to select songs.
4. By Artists, Albums, Genres, Songs,
Composers
1. Press the Menu button.
2. Choose the category through which you
PART 2. AUDIO FEATURES 2-19
AUDIO FEATURES
wish to select the song. MP3 CD mode
allows you to select by Playlists, Artists,
Albums, Genres, Songs, and Composers.
Explore CD
Explore CD is a feature which allows you to
browse files and folders of the CD by the
names of categories.
1. While in the MP3 CD Menu screen, press
the Explore CD button.
2. Search the corresponding files and folders
to select the desired song.
Viewing song information
When listening to an MP3 CD song, you can
browse through song details and information.
1. Press the Album art icon.
2.
The song information (Artist, Title, Album,
Genre) for the current MP3 song will be
displayed.
3. Press the button to return to the pre-
vious screen.
Note
●
Even as you browse through song information,
you can use the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on
the control panel or
∧
or
∨
keys on the
steering wheel controller to select different MP3
songs. For more information, refer to the
'Selecting an MP3 CD song' section.
Copying songs into JUKEBOX
1. Copying the current song
The UVO system allows you to copy songs
from an MP3 CD into JUKEBOX.
1. Press the Copy button.
2. Once copying is complete, you can listen
to copied music in JUKEBOX mode.
2-20 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
2. Copying songs from list
Copying MP3 songs from lists allows you to simulta-
neously select several songs to copy into JUKEBOX.
1. Press the Menu button.
2. Press the Now Playing button.
3. Press the Edit button.
4. Select the songs you wish to copy. When
selected, a will be displayed next to the
song. To select all songs in the list, press
the Select All button.
5. After selecting the desired songs, press
the Copy button.
6. Once copying is complete, you can listen
to copied music in JUKEBOX mode.
Note
●
If memory is already full and songs can no lon-
ger be copied, the “Memory full! Please delete
music from your JUKEBOX” message will be
displayed and you mus t d el e te s on gs f ro m
JUKEBOOX in order to add additional songs.
For more information on deleting
JUKEBOX
songs, refer to the ‘Deleting
JUKEBOX
’
section.
●
When copying MP3 CD songs, you can lis-
ten to all modes except CD mode and
JUKEBOX mode.
●
Copying can be canceled at anytime. While
copying is in progress, press the Cancel
button.
PART 2. AUDIO FEATURES 2-21
AUDIO FEATURES
USB MODE
Cautions upon handling USB MP3
1. The MP3 file standards supported by
the device are as follows.
●
Acceptable standard: MPEG1 AUDIO
LAYER 3
●
Acceptable sampling frequency: 32, 44.1,
48 (kHz)
●
Acceptable bit rate: 32, 40, 48, 56, 64,
80, 96, 112, 128, 160, 192, 224, 256, and
320 (kbps)
●
Recommended bit rate & reference sam-
pling frequency: 96,128, 192 kbps fixed
bit rate /44.1kHz
2. ID3 tag
●
This device supports ID3v1.0, ID3v1.1,
ID3v2.2, ID3v2.3, and ID3v2.4 ID3 tags.
3. Supported media
●
The MP3 media supported by the device
are CD-ROM and USB.
4. Supported media formats
●
This device supports ISO9660 LEVEL1
and LEVEL2. Detailed specification is as
below.
●
Maximum directory layers: 16 layers
5. Precautions upon formatting USB &
downloading MP3 files
●
The device only supports FAT type USB
file system. The device will not play USB
media content if the USB is NTFS type.
6. Precautions
●
Use an MP3 bit rate which is less than
192kbps and a fixed bit rate. The sound
quality cannot be guaranteed for MP3s
exceeding 192Kbps. Certain features
may operate abnormally when playing
MP3 formats with variable bit rates, such
as being limited to FF/REW.
2-22 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
Precautions upon handling USB
Caution
●
When using an external USB device, make
sure to connect the device after turning on
the ignition. The USB device may be dam-
aged if connected before the ignition is
turned on.
●
The USB device may fail to operate when
playing formats other than MP3 or WMA
formats.
●
Only MP3 files with compression rates
between 8kbps~320kbps are supported.
●
Only WMA files with compression rates
between 8kbps~320kbps are supported.
●
Be cautious of static electricity when
connecting/disconnecting an external
USB device.
●
Encoded MP3 Players will not be recog-
nized when connected as an external
device.
●
When connecting a USB device, the sys-
tem may not properly recognize some
USB states.
●
When formatting an external USB device,
the system may not properly recognize
byte/sector selections other than 512Byte
or 2048Byte.
●
The device will recognize only USB
devices formatted in FAT 12/16/32.
●
Some USB devices may not operate
properly due to compatibility issues.
Verify that the external device is sup-
ported by the system before use.
●
Avoid contact between the USB connec-
tor with bodily parts and foreign
substances.
●
Repeatedly connecting/disconnecting
the USB in a short period of time may
damage the system.
●
A sound may occasionally occur when
disconnecting the USB device.
●
Do not disconnect a USB device when it
is operating. Make sure to disconnect the
USB device only after the audio power is
turned off or when operating a different
mode.
●
The time required to recognize a USB
device may differ depending on the type,
size, or file formats stored on the USB.
Such differences in time are not indica-
tions of malfunction. Please wait until the
system becomes recognized.
●
This system supports only USB devices
used to play music files.
●
Do not use the USB I/F to charge batteries
or USB accessories that generate heat.
This may lead to worsened performance or
system damage.
●
This system may not recognize the USB
device if a separately purchased USB
hub or extension cable is used. Connect
the USB device directly to the terminal in
the vehicle.
●
Some mass storage USB devices may
have multiple logical drives partitioned
for user convenience. In such cases, only
music files within the top-level logical
drive will be supported.
●
This system may not operate normally if
the USB terminal is used to connect MP3
Players, mobile phones, digital cameras,
or other electronic devices (USB devices
not recognized as portable disk drives).
PART 2. AUDIO FEATURES 2-23
AUDIO FEATURES
●
This system may not operate normally
when using a USB memory type other
than a metal cover type USB device.
●
This system may not operate normally
when using HDD, CF, or SD memory
formats.
●
This system does not support DRM
(Digital rights management) locked files.
●
The device may not operate normally
during severe vehicle vibrations.
●
Avoid using USB devices also used as
key chains or mobile phone accessories.
Connecting your USB device
Connect the USB as shown in the picture.
USB Mode Screen and Features
1
Mode Display
Displays that the current mode is USB
mode.
2
Menu
Displays the categories and song lists for
the USB.
3
Copy
Copies current song into JUKEBOX.
4
Repeat
If Repeat is operating, the current song will
be repeated and the corresponding icon
will be displayed.
1
2 3 4 5 6
9
10
11
7
8
2-24 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
5
Shuffle
If Shuffle is operating, the songs will be
played in random order and the corre-
sponding icon will be displayed.
6
Sound
Enters Sound Setup.
7
Play Time
Displays the play time.
8
Artist name
Displays the artist name.
9
Song Title
Displays the song title.
10
Album Art Icon
When pressed, displays information about
the current song (artist, title, album and
other information).
11
Current/Total Track Number
Displays the current track number and total
number of tracks on the current playing list.
Listening to USB music
1. Connect a USB device or press the
MEDIA key on the control panel if a USB
device has already been connected.
2. When a song is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the song.
Note
●
For some media formats, the system requires
time for media indexing. In the case of USB
mp3 songs, the system will take 1.5ms/song
(Flash/HDD) or 40ms/song (mp3 players).
Selecting USB music
1. Selecting through song Up/Down
Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on the
steering wheel controller to play the desired
song.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller is
pressed and released after the song has
played for more than 3 seconds, the start of
the current song will begin playing. If the
song has been playing for less than 3 sec-
onds, the start of the previous song will
begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control panel
in clockwise or counter-clockwise direc-
tion. Each click will display information
about the selected song.
2. Press the TUNE knob to play the
selected song.
PART 2. AUDIO FEATURES 2-25
AUDIO FEATURES
3. Selecting from the list
1. Press the Menu button.
2. Press the Now Playing button.
3. Press the name of the song from the list.
The song will automatically start playing.
Note
●
If in the MP3 list screen, the
TUNE
knob can
also be used to select songs.
4. By Folders, Artists, Albums, Genres,
Songs, Composers
1. Press the Menu button.
2. Choose the category through which you
wish to select a song. USB Mode allows
you to select by Playlists, Artists, Albums,
Genres, Songs, and Composers.
Explore USB
Explore USB is a feature which allows you to
browse files and folders of the USB by the
names of categories.
1. While in the USB Menu screen, press the
Explore USB button.
2-26 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
2. Search the corresponding files and folders
to select the desired song.
Viewing song information
When listening to USB music songs, you can
browse through song details and information.
1. Press the Album art icon.
2. The song information (Artist, Title, Album,
Genre) for the current USB song will be
displayed. Press the button to return
to the previous screen.
Note
●
Even as you browse through song information,
you can use the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on
the control panel or
∧
or
∨
keys on the
steering wheel controller to select different USB
songs. For more information, refer to the
'Selecting music songs' section.
Copying songs into JUKEBOX
1. Copying the current song
The UVO system allows you to copy songs
from your USB device into JUKEBOX.
1. Press the Copy button.
2. Once copying is complete, you can listen
to copied music in JUKEBOX mode.
PART 2. AUDIO FEATURES 2-27
AUDIO FEATURES
2. Copying songs from list
Copying USB music songs from lists allows
you to simultaneously select several songs
to copy into JUKEBOX.
1. Press the Menu button.
2. Press the Now Playing button.
3. Press the Edit button.
4. Select the songs you wish to copy. When
selected, a will be displayed next to the
song. To select all songs in the list, press
the Select All button.
5. After selecting the desired songs, press
the Copy button.
6. Once copying is complete, you can listen
to copied music in JUKEBOX mode.
Note
●
If memory is already full and songs can no
longer be copied, the “Memory full! Please
delete music from your JUKEBOX” message
will be displayed and you must delete songs
from JUKEBOX. For more information on
deleting JUKEBOX songs, refer to the
‘Managing JUKEBOX’ section.
●
When copying USB songs, you can listen to
all modes except USB mode and JUKEBOX
mode.
●
Copying can be canceled at anytime. While
copying is in progress, press the Cancel
button.
2-28 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
iPod® MODE
About iPod®
1. Trademark
iPod®, iPhone® and iTunes® are registered
trademark of Apple, Inc.
2. Connecting your iPod® Device
Connect your iPod® device as shown in the
picture.
The identification of the iPod® device, battery
recharge, and other functions provided by
the iPod® device is normally supported by
using your iPod® connector cable.
Caution
●
If a playing iPod® is connected to the audio
system, a high-pitched tone may occur for
approximately 1-2 seconds. Please pause/
stop the iPod® device prior to connecting it
to the vehicle.
●
iPod® mode will not operate if the connected
iPod® cannot be recognized due to opera-
tion of unsupported versions that do not
support related protocols, iPod® abnormali-
ties, or iPod® device defects.
Note
●
Supported iPod® devices include: iPod Nano
2G/3G/4G/5G/6G, iPod Classic 5G/6G, iPod
Touch 1G/2G/3G/4G, iPhone 3G/3GS/4/4S.
PART 2. AUDIO FEATURES 2-29
AUDIO FEATURES
iPod® Mode Screen and Features
1
Mode Display
Displays that the current mode is iPod®
mode.
2
Menu
Displays the categories and song lists for
the iPod®.
3
Repeat
If Repeat is operating, the current song will
be repeated and the corresponding icon
will be displayed.
4
Shuffle
If Shuffle is operating, the song will be played
in random order and the corresponding icon
will be displayed.
5
Sound
Enters Sound Setup.
6
Play Time
Displays the play time.
7
Artist name
Displays the artist name.
8
Song Title
Displays the song title.
9
Album Art Icon
When pressed, displays information about
the current song (artist, title, album and
other information).
10
Current/Total Track Number
Displays the current track number and total
number of tracks on the current playing list.
Listening to your iPod®
1. Connect an iPod® device or press the
MEDIA key on the control panel if an iPod®
device has already been connected.
2. When a song is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the song.
1
2 3 4 5
6
7
8
9
10
2-30 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
Selecting iPod® music
1. Selecting through song Up/Down
Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on
the steering wheel controller to play the
desired song.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller is
pressed and released after the
song
has
played for more than 3 seconds, the start of
the current
song
will begin playing. If the
song
has been playing for less than 3 seconds, the
start of the previous
song
will begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control panel
in clockwise or counter-clockwise direc-
tion. Each click will display information
about the selected song.
2. Press the TUNE knob to play the
selected song.
3. Selecting from the list
1.
Press the Menu button.
2. Press the Now Playing button.
3. Press the name of the song from the list.
The file will automatically start playing.
Note
●
In the iPod® list screen, the TUNE knob can
also be used to select the desired song.
4. By Artists, Albums, Genres, Songs,
Podcasts, Composers, Audiobooks
1.
Press the Menu button.
PART 2. AUDIO FEATURES 2-31
AUDIO FEATURES
2. Choose the category through which you
wish to select. iPod® mode allows you to
select by Playlists, Artists, Albums,
Genres, Songs, Podcasts, Composers
and Audiobooks.
Viewing song information
When listening to your iPod®, you can browse
through song details and information.
1. Press the Album art icon.
2. The song information (Artist, Title, Album,
Genre) for the current iPod® song will be
displayed.
3. Press the button to return to the
previous screen.
Note
●
Songs in the iPod® can be properly played in
UVO system only when they have been
downloaded through iTunes®.
●
If you receive a call or SMS while playing
music from an iPhone®, the music may not
properly be restored after the call or SMS. In
this case, disconnect and reconnect the
iPhone®.
●
After upgrading the iPod® or iPhone® firm-
ware, reboot the iPod® or iPhone® and con-
nect with the UVO system for normal
operation.
●
Songs cannot be copied from iPod® or
iPhone® to JUKEBOX.
2-32 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
zune® MODE
About zune®
1. Trademark
zune® is a registered trademark of Microsoft
Corporation in the United States and or other
countries.
2. Connecting your zune® Device
Connect your zune® device as shown in the
picture.
zune® Mode Screen and Features
1
Mode Display
Displays that the current mode is zune®
mode.
2
Menu
Displays the categories and song lists for
the zune®.
3
Repeat
If Repeat is operating, the current song will
be repeated and the corresponding icon
will be displayed.
4
Shuffle
If Shuffle is operating, the songs will be
played in random order and the corre-
sponding icon will be displayed.
5
Sound
Enters Sound Setup.
6
Play Time
Displays the play time.
7
Artist name
Displays the artist name.
8
Song Title
Displays the song title.
9
Album Art Icon
When pressed, displays information about
the current song (artist, title, album and
other information).
10
Current/Total Track Number
Displays the current track number and total
number of tracks on the current playing list.
1
2 3 4 5
6
7
9
10
8
PART 2. AUDIO FEATURES 2-33
AUDIO FEATURES
Listening to your zune®
1. Connect zune® device or press the
MEDIA key on the control panel if zune®
device has already been connected.
2. When a song is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the song.
Note
●
When connecting some external media formats,
the system requires time for media indexing. In
the case of zune® files, the system will take
60ms/song.
●
Songs cannot be copied from zune® to
JUKEBOX.
Selecting zune® music
1. Selecting through song up/down
Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on
the steering wheel controller to play the
desired song.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller is
pressed and released after the song has
played for more than 3 seconds, the start of
the current song will begin playing. If the
song has been playing for less than 3 sec-
onds, the start of the previous song will
begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control panel
in clockwise or counter-clockwise direc-
tion. Each click will display information
about the selected song.
2. Press the TUNE knob to play the
selected song.
3. Selecting from the list
1. Press the Menu button.
2. Press the Now Playing button.
2-34 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
3. Press the name of the song from the list.
The song will automatically start playing.
4. By Songs, Genres, Albums, Artists,
Playlists
1. Press the Menu button.
2. Choose the category through which you
wish to select. zune® mode allows you to
select by Songs, Genres, Albums, Artists,
and Playlists.
Viewing song information
When listening to your zune®, you can browse
through song details and information.
1. Press the Album art icon.
2. The song information (Artist, Title, Album,
Genre)
for the current MP3 song will be
displayed.
3. Press the button to return to the pre-
vious screen.
PART 2. AUDIO FEATURES 2-35
AUDIO FEATURES
AUX MODE
AUX Mode Screen
1
Mode Display
Displays that the current mode is AUX
mode.
2
AUX Status
Displays the AUX connection status
3
Sound
Enters Sound Setup.
Connecting an AUX media device
Connect a cable from the headphone jack on
your AUX device to the jack located in your
vehicle.
Note
●
Connecting your AUX device with the vehi-
cle will not provide power to your AUX
device. If you plan on using your AUX
device for long periods of time, make sure to
charge the device using an A/C power
adapter or a separate USB cable.
Listening to AUX media
1. Connect an AUX device or press the
MEDIA key on the control panel if the AUX
device has already been connected.
2. Once in AUX mode, the connected audio
will automatically begin playing from the
car system provided that your external
device is turned on and playing audio.
1
2
3
2-36 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
BT AUDIO MODE
BT Audio mode is a feature which allows you
to stream music stored in your handset device
via a Bluetooth® wireless technology connec-
tion. Music saved in the handset device can
be played in the car through Bluetooth® wire-
less technology audio streaming. BT audio
can be played only when a handset device
has been connected. To play BT audio, pair a
handset device with the system. If Bluetooth®
wireless technology is disconnected while
playing BT audio, music play will be discontin-
ued. The audio streaming function may not be
supported in some handset devices. Only one
function can be used at a time between the
Bluetooth® wireless technology handsfree or
BT audio function. Playing music from the car
is not possible when there are no music files
stored in the handset device.
BT Mode Screen and Features
1
Mode Display
Displays the current mode as BT Audio
mode.
2
Artist name
Displays the artist name.
3
Song Title
Displays the song title.
4
Play/Pause
Plays/pauses the song.
5
Sound
Enters Sound Setup.
6
Phone Battery charge status
Displays the battery charge status of the
connected mobile phone. The battery
charge status may not be displayed in
some mobile phones.
7
Signal Strength
Displays the mobile phone signal strength.
The signal strength may not be displayed in
some mobile phones.
8
Bluetooth® wireless technology
connection state
Becomes displayed when a Bluetooth®
wireless technology enabled phone has
been connected with the car system.
1
2
3
45
6 7 8
PART 2. AUDIO FEATURES 2-37
AUDIO FEATURES
Listening to music from your
Bluetooth® wireless technology
enabled device
1. Pair your Bluetooth® wireless technology
enabled device to the handsfree system.
For more information on pairing your
Bluetooth® wireless technology enabled
devices, refer to the 'Pairing your handset
device to the handsfree system' section.
2. Press the MEDIA key on the control panel
to turn on BT audio mode.
3.
When streaming music from your Bluetooth®
wireless technology enabled device and you
wish to pause, press the button next on
the screen. Press the button to restart
music.
Note
●
While music saved in the Bluetooth® wire-
less technology enabled device will auto-
matically begin playing after converting to
the BT Audio screen, this music player func-
tion may not be supported in some
Bluetooth® wireless technology enabled
devices.
●
If music does not begin playing even after
displaying the Phone music screen, try start-
ing the music directly from the Bluetooth®
wireless technology enabled device.
Selecting a song
1. Press the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys on the
control panel or the
∧
or
∨
keys on
the steering wheel controller to play the
desired song.
2. The previous or next song will begin
playing.
Note
●
File selection may not be supported in some
Bluetooth® wireless technology enabled
devices.
REW/FF a song
1.
Press and hold the
SEEK
TRACK
∧
or
SEEK
∨
TRACK
keys (over 0.8 seconds) on the control
panel or the
∧
,
∨
keys (over 0.8 sec-
onds) on the steering wheel controller.
2. The track will rewind or fast-forward at a
rate 20 times faster than normal while the
key is being held.
3. Release the key to play from the current
position.
Note
●
The play/pause, song selection and REW/
FF features are supported only in handset
devices with AVRCP Ver. 1.3 or higher. If
play control features are not working, first
check the AVRCP version of your Bluetooth®
wireless technology enabled device.
●
When such operations are not supported,
use the handset device to perform these
functions.
2-38 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
JUKEBOX MODE
The UVO system offers you maximum conve-
nience by allowing you to copy songs from
your MP3 CD and USB and store them to the
JUKEBOX within the system. For more infor-
mation on copying songs into JUKEBOX, refer
to the ‘Copying songs into JUKEBOX’ section.
JUKEBOX Mode Screen and
Features
1
Mode Display
Displays that the current mode is
JUKEBOX mode.
2
Menu
Displays the JUKEBOX folder and file lists.
3
Favorite
Adds/removes current song to Favorites
list.
4
Repeat
If Repeat is operating, the current song will
be repeated and the corresponding icon
will be displayed.
5
Shuffle
If Shuffle is operating, the songs will be
played in random order and the corre-
sponding icon will be displayed.
6
Sound
Enters Sound Setup.
7
Play Time
Displays the play time.
8
Artist name
Displays the artist name.
9
Song Title
Displays the song title.
10
Album Art Icon
When pressed, displays information about
the current song (artist, title, album and
other information).
11
Current/Total Track Number
Displays the current track number and total
number of tracks on the current playing list.
1
10
11
2 3 4 5 6
7
8
9
PART 2. AUDIO FEATURES 2-39
AUDIO FEATURES
Listening to JUKEBOX
1. Press the MEDIA key on the control panel
to turn to JUKEBOX mode.
2. The system will automatically restore the
most recently played song.
Selecting a JUKEBOX song
1. Selecting through Track Up/Down
1.
Press the
SEEK
∨
TRACK
∧
keys on the control
panel or the
∧
or
∨
keys on the steer-
ing wheel controller to play the desired track.
2. The previous or next song will begin
playing.
Note
●
If the
SEEK
∨
TRACK
key on the Control panel or
∨
key on the steering wheel controller is
pressed and released after the track has
played for more than 3 seconds, the start of
the current track will begin playing. If the
song has been playing for less than 3 sec-
onds, the start of the previous song will
begin playing.
2. Selecting through manual search
1. Turn the TUNE knob on the control panel
in clockwise or counter-clockwise direc-
tion. Each click will display information
about the selected song.
2. Press the TUNE knob to play the
selected song.
3. Selecting from the list
1. Press the Menu button.
2. Press the Now Playing button.
3. Press the name of the song from the list.
The song will automatically start playing.
2-40 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
4. By Artists, Albums, Genres, Song,
Composers
1. Press the Menu button.
2. Choose the category through which you
wish to select. JUKEBOX mode allows
you to select by Favorites, Artists, Albums,
Genres, Songs, and Composers.
Adding Favorites
The Favorites feature allows you to create a
separate Favorites list of songs.
1. While listening to JUKEBOX, press the
button.
2. The icon will be displayed on the
screen to signify that the song has been
saved in Favorites.
3. To delete a song from Favorites, press the
button.
PART 2. AUDIO FEATURES 2-41
AUDIO FEATURES
Playing Favorites
1. While playing JUKEBOX, press the Menu
button.
2. In the JUKEBOX Menu screen, press the
Favorites button.
3. Press the name of the song from the list.
The song will begin playing.
Note
●
The Favorites button will be inactive when there
are no songs saved as Favorites.
●
When deleting favorites from the Favorites list,
the deleted favorites will be removed from the
favorites list. The songs will not be deleted from
the system.
2-42 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
Memory Management
Checking System Information
1. Press the SETUP key on the control panel.
2. Press the System button.
3. Press the System Information button.
4. The system information screen shows you
the memory currently in use.
Deleting JUKEBOX
1. Deleting JUKEBOX
1. While in JUKEBOX mode, press the
Menu button.
2. Press the Now Playing button.
3. Press the Edit button.
PART 2. AUDIO FEATURES 2-43
AUDIO FEATURES
4. Select the songs you wish to delete. When
selected, a will be displayed next to the
selected song. To select all songs, press
the Select All button. All of the songs in
the play list will be selected.
5. Press the Delete button.
2. Deleting all files
1. Press the SETUP key on the control panel.
2. Press the System button.
3. Press the Delete all copy files button.
4. The system will reboot and automatically
restore the FM mode.
Note
●
When using the Delete all copy files feature,
all JUKEBOX files will be deleted.
2-44 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
PANDORA MODE
About PANDORA
1. Trademark
iPodⓇ is a registered trademark of Apple, Inc.
2. Before Starting PANDORA
1. Connect your iPodⓇ or iPhoneⓇ device as
shown in the picture.
The identification of the iPodⓇ device, battery
recharge, and other functions provided by
the iPodⓇ device is normally supported by
using your iPodⓇ connector cable.
2. Start the PANDORA Radio application.
1. Log into PANDORA Radio.
( This step can be omitted if you are already
logged in.)
Note
●
Supported iPodⓇ devices:iPodⓇ Touch
2G/3G/4G, iPhoneⓇ 3G/3GS/4/4S
●
PANDORA Radio is supported only in iOS
devices.
PART 2. AUDIO FEATURES 2-45
AUDIO FEATURES
PANDORA Mode Screen and eatures
1
Mode Display
Displays that the current mode is
PANDORA mode.
2
Menu
Displays the PANDORA Station lists and
Bookmark options.
3
Thumbs Up
Approves the song and keep it in your
playlist.
4
Thumbs Down
Disapproves the song and prevents that
song from playing again.
5
Skip
EMoves to the next file.
6
Sound
Enters Sound Setup.
7
Play Time
Displays the play time.
8
Station Name
Displays the station name.
8
Artist name
Displays the artist name.
9
Song Title
Displays the song title.
Listening to your PANDORA
1. Press the MEDIA key on the control panel if
an iPod device has already been connected
and the PANDORA application is activated.
2. When a song is playing and you wish to
pause, press the ll button next to the
progress bar. Press the
▶
button to
restart the song.
1
2 3 4 5 6
7
8
9
10
2-46 PART 2. AUDIO FEATURES
PART 2 AUDIO FEATURES
Selecting PANDORA station
1. Press the Menu button.
2. Press the Station List button.
3. Press the name of the station from the list.
The station will automatically start playing.
Note
●
In the station list screen, the
TUNE
knob can
also be used to find the desired station.
●
Upon selecting “Shuffle” from the Station list
screen, stations are selected randomly and
played.
Bookmark Track or Artist
1. Press the Menu button.
2. PPress the Bookmark this track or
Bookmark this artist button.
3. The current track or artist is bookmarked
on the currently connected device.
3-2 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Using your
Bluetooth
®
wireless technology
Handsfree system
Welcome to Kia’s connected world of wireless
personal networking. The UVO system with
Bluetooth
®
wireless technology allows you to
conveniently use various Bluetooth
®
wireless
technology enabled phone features as you
drive your vehicle.
The Bluetooth® wireless technology
handsfree system offers:
●
Pairing mobile phones (Up to 5 phones)
●
Connecting/disconnecting mobile phones
●
Making/Answering phone calls
●
Downloading Contacts
●
Downloading Call history lists
●
Playing music saved in a Bluetooth
®
wireless
technology enabled phone in the vehicle
PART 3. PHONE FEATURES 3-3
PHONE FEATURES
Smart driving practices
Check related laws and regulations on
using mobile devices and their accesso-
ries and always make sure to obey them.
The use of such devices may be prohibited
or restricted in certain areas.
Your mobile device helps you communi-
cate through voice and data almost any-
where and anytime. When driving a car,
driving comes first. If you choose to use
your mobile device while driving, remem-
ber the following:
●
Always drive safely and obey all traffic laws.
●
Some laws do not allow the use of hand-
held devices while driving.
Always obey federal, state and local laws
and, even if permitted, it is recommended
that you do not use your handheld device
while driving to help avoid the risk of acci-
dents, injuries and/or death.
●
Get to know your mobile device and
features.
Knowledge of your mobile device and its fea-
tures will help you to use the features more
easily.
●
Place your mobile device in easy reach.
Be able to access your mobile device with-
out removing your eyes from the road.
●
Do not search for phone numbers while
driving.
●
Let the other person know you are driv-
ing; when necessary, suspend the call to
help avoid risks of accidents or injuries.
Rain, sleet, snow, ice or heavy traffic may
increase the risks of driving.
●
Use your mobile device to call for help.
Dial 911 or other local emergency number in
case of fire, traffic accident, or medical
emergencies.
Warning
●
Driving while distracted can result in a loss
of vehicle control that may lead to an acci-
dent, severe personal injury, and death.
The driver’s primary responsibility is in the
safe and legal operation of a vehicle, and
use of any handheld devices, other equip-
ment, or vehicle systems which take the
driver’s eyes, attention and focus away
from the safe operation of a vehicle or
which are not permissible by law should
never be used during operation of the
vehicle.
3-4 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Pairing your handset
device to the handsfree
system
Before you can use the Bluetooth
®
wireless
technology handsfree system to make hands-
free calls, you must create a Bluetooth
®
wire-
less technology connection between your
handsfree system and handset device. A
Bluetooth
®
wireless technology connection is
made between your handsfree system and
handset device with a paired link.
After setting up a paired link, the handsfree
system will always remember your handset
device. Once the system is paired with the
device, your hand-free system can be set so
that it automatically connects to your handset
each time you start your vehicle.
Caution
●
For safety, make pairings between your
handsfree system and handset only while
the vehicle is parked.
Pairing a Bluetooth® wireless
technology enabled device for the
first time
1. Press the button on the steering
wheel or the PHONE key on the control
panel.
2. Press the Yes button.
3. Perform a device discovery from the
handset device. For details on device dis-
covery for your handset device, refer to
the handset device user's manual.
Non SSP(Secure Simple Pairing) sup-
ported device
4. Once the device is discovered, input the
passkey in the handset device.
SSP(Secure Simple Pairing) supported
device
4. Once the device is discovered, check the
passkey on your handset device and
confirm.
PART 3. PHONE FEATURES 3-5
PHONE FEATURES
5. Once pairing is complete, the handset
device will be shown in the Connections list.
Note
●
Initial pairing may require some time due to initial
uploading of your contacts into the system. The
contacts upload feature may not be supported in
some handset devices.
●
Before connecting the Bluetooth® wireless tech-
nology handsfree system with the handset
device, check to see that the handset device sup-
ports Bluetooth® wireless technology handsfree
and Bluetooth® wireless technology is turned on.
●
The process for initiating Bluetooth® wireless tech-
nology connections may vary depending on the
manufacturer. Use the handset device user's
manual as a reference guide.
●
The UVO system supports up to 5 pairings. After
5 handsets have already been paired, you must
delete a handset in order to pair a new handset.
●
Some phones may offer an option to allow accep-
tance of all future Bluetooth® connection requests
by default.
●
Visit http://www.kia.com/#/bluetooth for additional
information on pairing your Bluetooth® enabled
mobile phone, and to view a phone compatibility
list.
Deleting a paired handset device
1.
While in Phone mode, press the
Connections
button.
2. Select the handset device you want to
delete.
3-6 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
3. Once the phone is selected, press the
Delete button.
4. Press the Yes button.
Note
●
When you delete a paired phone, data will
also be erased. For instance, deleting a
paired phone will also erase recent calls,
contact lists, and SMS data from the
system.
Connecting a handset device
The system automatically connects the Bluetooth
®
wireless technology enabled device set at the
highest priority. As a result, in order to connect a
different phone, follow the following steps.
1. While in Phone mode, press the
Connections button.
2. Select the handset device you want to
connect.
3. Press the Connect button.
Note
●
After initial pairing, your highest priority
handset device will automatically connect
with the handsfree system when you start
your vehicle (if your handset device is pow-
ered on and the relevant Bluetooth
®
priority
settings are not changed).
PART 3. PHONE FEATURES 3-7
PHONE FEATURES
Setting Priority
When more than one device has been paired
to the system, you can set the connection pri-
ority so that a certain phone is connected with
priority starting from the next time you turn on
the system.
1. While in Phone mode, press the
Connections button.
2. Press the Set Priority button.
3. Select the phone you wish to set as pre-
ferred priority.
3-8 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Using the phone features
Phone Mode Screens and Features
1. When a mobile phone is connected
1
Dial Number
Displays the Dial Pad screen.
2
Contacts
Displays the Contacts list
3
Recent Calls
Displays the Recent Calls list.
4
Favorites
Up to 20 frequently used contact saved so
help your fast call.
5
Connections
Displays the Connections screen.
6
Settings
Displays the Settings screen.
2. When making a call
1
Phone Battery charge status
Displays the battery charge status of the
connected mobile phone. The battery
charge status may not be displayed in
some mobile phones.
2
Signal Strength
Displays the mobile phone signal strength.
The signal strength may not be displayed
in some mobile phones.
3
Bluetooth® wireless technology
connection state
Becomes displayed when a Bluetooth
®
wireless technology enabled phone has
been connected with the car system.
4
Dial
Input the phone number through the dial
pad.
5
SEND
Makes the call to the dialed number.
If a number has not been entered into the
phone number input window,
pressing the send button displays the call
history list screen.
6
END
Ends the call. If a number has been input-
ted, then erases the entire number.
7
Delete
Deletes one digit at a time.
123
54
21 3
4
5 6
7
6
PART 3. PHONE FEATURES 3-9
PHONE FEATURES
3. When receiving an incoming call
1
Accept
Accepts the incoming call.
2
Reject
Rejects the incoming call.
4. When on a call
1
Call state
Displays the call state, such as talk time,
phone connection, and end time.
2
END
Ends the call.
3
Name of the other party
Displays the name of the other party. The
name of the caller will not be displayed if
the caller's phone number has not been
saved in contacts.
4
Number of other party
Displays the number of the other party
5
PRIVATE
When talking on the car handsfree, use
this function to switch the call to the mobile
phone.
6
MUTE
Mutes the sound of the call. The caller will
not be able to hear the conversation taking
place in the car.
3
1
12
2
5 6
4
3-10 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Answering an incoming call
1. When there is an incoming call, an incom-
ing call window will be displayed on the
screen. Press the Accept button on the
screen or the key on the steering
wheel controller to answer the call.
2. The call will be connected.
Note
●
You can also accept an incoming call using
your handset device if you wish to talk in pri-
vate mode.
Rejecting an incoming call
1. Press the Reject button on the screen or
the key on the steering wheel
controller.
2. The call will be rejected.
Call waiting
Call waiting is a feature which allows you to
place the current call on hold in order to
receive a second call. When you are in a
call, the incoming call window will be dis-
played to the sound of a beep to signal a
second incoming call.
1. If a second call is received while already
on a call, the incoming call window will be
displayed on the screen.
2. Press the Accept button or the key
on the steering wheel controller to take the
second incoming call. Press the Reject
button to reject the second incoming call.
PART 3. PHONE FEATURES 3-11
PHONE FEATURES
3. To switch again to the other caller, press
the button or the key on the
steering wheel. The other call will be
received and the previous call will switch
back to call waiting.
Note
●
The call waiting function may not be sup-
ported in some handset devices.
Placing a call
1. By dialing a number
1. While in Phone mode, press the
Dial Number button.
2. Use the dial pad on the right side of the
screen to enter the phone number.
3. Press the button on the screen or
the key on the steering wheel con-
troller to connect the call.
Note
●
Pressing and holding the button or
key will redial the most recent number.
●
You can delete digits by pressing the Delete
or button on the screen.
●
The Delete button will delete one digit at a
time while the button will erase all
digits.
●
When placing international calls, press and
hold the “ * ”. A “ +” sign is displayed, allow-
ing you to place an international call.
3-12 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
2. By contact list
1. While in Phone mode, press the Contacts
button.
2. Press the spell you wish to find.
3. Select the contact you want to call from
the list.
4. Press the button on the screen or
the key on the steering wheel con-
troller to connect the call.
3. By recent calls
1. While in Phone mode, press the
Recent Calls button.
2. Select the contact you want to call from the list.
PART 3. PHONE FEATURES 3-13
PHONE FEATURES
Note
●
If you want to connect to the most recent call
you made, press and hold the button
in the 'Dial Number' screen or the key
on the steering wheel.
●
Recent calls will be deleted automatically
when a handset device is disconnected
from the system.
●
Recent calls can be sorted. Use the Sort by
button to sort recent calls by All ,
Dialed ,
Received
and Missed
calls.
●
The recent calls function may not be sup-
ported in some handset devices.
Contact list
1. Downloading contact list (from mobile
phone)
You can store a list of names and phone
numbers in the system contact list. The con-
tact list can support up to 2,000 entries. The
contact list is only available when a handset
device is connected to the handsfree system.
In some phones, the system will automati-
cally download contacts upon pairing.
1. While in Phone mode, press the Contacts
button.
2. Press the spell you wish to find.
3. Press the Download button.
4.
The contacts from the currently paired hand-
set device will automatically be downloaded.
3-14 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Note
●
You can search your contacts to conve-
niently find the desired person.
Searching your contacts
If you have many contacts downloaded in the
device from your handset device, you can
make searches of your contacts to conve-
niently find the desired person.
1. By alphabet
1. While in Phone mode, press the Contacts
button.
2. Press the spell you wish to find.
3. Press the Sort by button.
4. Press the spell you wish to find.
5. Press the contact you want to connect the
call.
PART 3. PHONE FEATURES 3-15
PHONE FEATURES
2. By name
1. While in Phone mode, press the Contacts
button.
2. Press the spell you wish to find.
3. Press the Search button.
4. Press the Search by name .
5. Enter the name you wish to find and press
the Done button.
6. Press the contact you want to connect the
call.
Note
●
When searching contacts by name, you do
not need to enter the entire name to conduct
the search.
3-16 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
3. By number
1. While in Phone mode, press the Contacts
button.
2. Press the spell you wish to find.
3. Press the Search button.
4. Press the Search by number button.
5. Enter the number you wish to find and press
the
Done
button.
6. Press the contact you want to connect the
call.
Note
●
When searching contacts by number, you do
not need to enter the entire number to con-
duct the search.
PART 3. PHONE FEATURES 3-17
PHONE FEATURES
Checking missed calls
1. While in Phone mode, press the
Recent Calls button.
2. Press the Sort by button.
3. Press the Missed button.
4. The list of missed calls will be displayed.
Favorites
1. Placing a call by favorites
1. While in Phone mode, press the Favorites
button.
2. Select the contact you want to call from
the list.
3-18 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Note
●
To save a favorite, contacts should first be
downloaded.
●
Contact saved in Favorites are not automati-
cally changed even if the information was
changed in the mobile phone. In this case,
delete it and save the new information.
2. Adding favorites
1. While in Favorites screen, press the
Add button.
2. Select the contact you want to add from
the list.
3. Press the button to add favorite.
3. Deleting favorites
1. While in Favorites screen, press the
Edit button.
2. Select the contact you want to delete from
the list.
3. Press the Delete button.
PART 3. PHONE FEATURES 3-19
PHONE FEATURES
SMS
1. Downloading SMS messages (from
mobile phone)
When a mobile phone is paired with the
system, unread messages will automatically
be downloaded to the system. While you will
not be able to check SMS messages through
the system due to legal regulations, the
system will read back messages for you for
added convenience. The SMS read back is
also possible when the vehicle is in motion.
2. Checking an SMS message
1. Press the key on the steering
wheel.
2. Say the command ‘Read SMS’.
3. The system will read back the new
message.
Note
●
To listen to the message again, say ‘Read
again’. To listen to the next message, say
‘Next’. To send a reply, say ‘Reply’. To call
the sender, say ‘Call’.
●
When a mobile phone has been paired with
the system, new incoming messages will
automatically be notified through the
system.
●
When the notification window is displayed,
press the Yes button to check the new
incoming message.
3. Sending an SMS message (Custom
Messages)
The UVO system allows you to respond to
incoming messages through voice
commands.
1. After listening to a received message, say
‘Reply’.
2. The UVO system will provide information
pertaining to the 6 Custom Messages.
3. Select the desired message to send a
response.
Note
●
You can modify custom messages through
Phone Settings.
●
The SMS function may not be supported in
some handset devices.
4. Editing Custom Messages
1. In the ‘Phone’ Screen, press the Settings
button.
2. Press the Edit button next to the
Custom Messages menu.
3. From the 6 messages, select the mes-
sage you wish to edit.
Caution
●
The Editing Custom Messages feature is
supported only when the vehicle is parked. If
you need to edit custom messages, first
park your vehicle in a safe and legal
location.
3-20 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
Switching the call
1. Switching the call between handsfree
and handset device
When you receive an incoming call, you
have the option of using the handsfree or
talking privately by using the handset
device.
2. Transferring the handsfree call to your
Handset device
1. After pressing the Accept button for an
incoming call, the following screen will be
displayed.
2. Press the Private button. The call will be
transferred to the handset device.
Note
●
Accepting a call with the handset device will
automatically connect the call in Private
mode.
3. Transferring a call on your Handset
device to handsfree
1. If an incoming call is accepted with the
handset device, the call will be connected
with the handset device while the UVO
system will display the following screen.
2. Press the Use handsfree button to transfer
the call to the handsfree.
PART 3. PHONE FEATURES 3-21
PHONE FEATURES
Phone settings
Setting Phone Volume
1. Press the PHONE key.
2. Press the Settings button.
3. Use the
◀
,
▶
buttons to control the
volume to the desired level.
Note
●
Press the Default button to restore the
default setting.
●
Although the call volume can be changed
during a call, the volume will return to its ini-
tial level as saved in Setup.
●
Call volume can be operated separately
from the audio volume, allowing you to
change the call volume without changing the
audio volume.
●
When call volume is changed, ring volume is
also changed.
3-22 PART 3. PHONE FEATURES
PART 3 PHONE FEATURES
SMS
This feature allows you turn the SMS feature
on or off within the system. When turned on,
the SMS feature will download unread
incoming messages to provide a read back
of new messages.
1. While in Phone Settings, press the
Settings button.
2. Press the On or Off button next
to the SMS menu.
Note
●
Press the Default button to restore the
default setting.
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
Changing passkey
The passkey is the authentication code
needed whenever you pair a new handset
device.
1. While in Phone Settings, press the
Settings button.
2. Press the 0000 button next to the pass-
key menu.
PART 3. PHONE FEATURES 3-23
PHONE FEATURES
Mobile Phone Compatibility
Depending on the manufacturer, product and product specification, some mobile phones func-
tions may not be supported or may not operate to specification. Carefully read the cautions listed
below.
Caution
●
The occurrence of problems upon using mobile phones may be caused by the mobile phone
and not by the Audio unit.
●
Even mobile phones which support Bluetooth
®
wireless technology function may not operate
properly if the mobile phone connection has been locked. Release the connection lock and try
connecting the mobile phone with the system again.
●
The mobile phone battery icon and signal strength icon may not be properly displayed depend-
ing on the type of mobile phone.
●
Call waiting is supported only when connected mobile phones support this feature. The call
waiting pop-up may not be displayed in some mobile phones.
●
Streaming audio mode will operate only when a Bluetooth
®
wireless technology enabled phone
has been connected. Connecting or disconnecting a Bluetooth
®
wireless technology enabled
phone while audio streaming is operating will stop music play.
●
The audio streaming function may not be supported in some mobile phones.
●
The phonebook may take a prolonged period of time to download or may not operate in some
mobile phones.
●
The quality of Bluetooth
®
wireless technology handsfree calls may differ depending on the
mobile phone.
●
SMS read back function may not be supported in some handset devices.
3. Input the new passkey and press the
Done button to save.
Note
●
The default passkey is “0000” .
●
The passkey can be set only when the vehi-
cle is parked.
4-2 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
Conditions for voice
command system
The voice control system includes a special
handsfree microphone mounted above the
driver's seat of your car which helps filter out
ambient noise and helps allow you to operate
system features through voice commands.
There are still a few points you should
observe to help reduce noise interference.
●
Keep doors, windows and the sunroof
closed to help avoid noise interference from
outside the car. Voice command
performance can be improved if the cabin
environment is quiet.
●
Press the voice recognition button and say
the voice command after the sound of the
beep.
●
Speak continuously and at normal volume,
avoiding unnatural emphasis and pauses
between words.
●
Avoid causing background noise in the car
while you are speaking, and ask your
passengers not to speak while you are
giving voice commands.
●
As the handsfree microphone is positioned
to pick up the driver's voice, commands by
other occupants may be understood with
less accuracy, and passengers are advised
to use the handset when making calls.
The Kia Voice Recognition System may have
difficulty understanding some accents or
uncommon names. When using Voice
Recognition to place a call, speak in a
moderate tone, with clear pronunciation.
To help maximize the use of Voice
Recognition, consider these guidelines when
storing contacts:
●
Do not store single-name entries (e.g.,
“Bob”, “Mom”, etc.). Instead, always use full
names (including first and last names) for
these contacts
●
Do not use special characters (e.g., ‘@’, ‘-’,
‘*’, ‘&’, etc.)
●
Do not use abbreviations (i.e., use
“Lieutenant” instead of “Lt.”) or acronyms
(i.e., use “County Finance Department”
instead of “C. F. D.”. Be sure to say the
name exactly as it is entered in the
contacts list.
PART 4. VOICE COMMANDS 4-3
VOICE COMMANDS
Operating Voice Command
Using Voice Command
1. Press the key on the steering wheel
controller. A display
will be shown at the top of the screen
followed by a “Please say a command
after the beep” system comment.
2. Once the icon becomes
displayed, say the desired voice command
(ex: “What's Playing”)
Note
●
Press the key shortly to interrupt the
system command feedback and enter a
voice command.
●
To terminate the voice control system, either
say “Exit” or press the key for over 0.8
second.
●
The system voice comment “Please say a
command after the beep” will not be stated
when the Command Feedback option is
turned off.
●
For more information on the various voice
commands supported by the system, refer to
the “Command Help” or the “Voice
Command List” section.
Voice Command Help
The Voice Command Help section provides
you with lists of commands that can be used
in each mode, adding ease and convenience
using voice commands.
1. Press the Voice button.
2. Press the Help button.
4-4 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
3. Press the mode to view a list of related
Voice Commands.
Note
●
The “help” command can be used even while
voice recognition dialogue is operating. At
such time, help instructions appropriate to
the state of the dialogue will be provided.
Turning Command Feedback On
and Off
1. Press the Voice button.
2. Press the On or Off button next to
the Command Feedback menu.
Note
●
Press the Default button to restore the
default setting.
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
PART 4. VOICE COMMANDS 4-5
VOICE COMMANDS
Adjusting Voice Command
Volume
1. Press the Voice button.
2. Use the
◀
,
▶
buttons to adjust the
voice command volume.
3. Press the button to return to the
Setup screen.
Note
●
Press the Default button to restore the
default setting.
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
4-6 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
Speaker Adaptation
Creating a Voice Profile
The Voice Command feature in the UVO system
allows you to create speaker profiles in order to
help increase voice recognition accuracy.
You will be asked to read a number of
sentences to the system so that it can adapt to
your voice. Creating a profile takes
approximately several minutes and must be
done while the vehicle is parked. You can quit/
resume a reading session, but the system
cannot be interrupted while it is creating the
profile.
1. Press the Voice button.
2. Press the Default button next to the
Speaker Adaptation menu.
3. After reading the instructions, press the
Start
button.
4. Input the name of the profile you wish to
use and press the Done button.
5. Follow the training set as shown on the
screen.
PART 4. VOICE COMMANDS 4-7
VOICE COMMANDS
6. As each of the 10 commands become
displayed on the screen, press the
key then read the displayed sentence in
your natural tone.
Note
●
There are 10 commands in the training set.
For each one, press the speak button and
read the command on the screen.
Selecting a Previous Voice Profile
1. Press the Voice button.
2. Press the profile name button next to the
Speaker Adaptation menu.
3. Press the name of the profile.
Note
●
Press the None
(
Default
)
button to
restore the default profile.
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
4-8 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
Deleting a Voice Profile
1. Press the Voice button.
2. Press the profile name button next to the
Speaker Adaptation menu.
3. Press the Delete button next to the name
of the profile.
4. Press the Yes button.
Note
●
Press the None
(
Default
)
button to
restore the default profile.
●
Changes are saved as they are made. In
other words, once you change a setting, the
new setting will become saved.
PART 4. VOICE COMMANDS 4-9
VOICE COMMANDS
Voice Command List
The voice commands for this system are
divided into Global commands and Local
commands.
●
Global commands (
●
) : Commands that
operate in all modes.
●
Local commands (
○
) : Commands that
operate only in corresponding modes or
when screens of corresponding modes are
displayed.
Command List - General Commands
Command Operation
●
Exit / Quit / Cancel Terminate the voice control system
○
Go back Returns to the previous step.
●
Repeat Repeats the system prompt.
●
Help Provides instruction on the voice command
necessary for the current situation.
●
Voice command feedback {on, off} Turns command feedback on/off.
●
Tutorial Provides guidance on how to use voice
recognition and Bluetooth connections
4-10 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
Command List - Audio Commands
1. FM/AM Radio
2. SIRIUSTM
Command Operation
●
Radio Plays the most recent frequency for the most recent band
●
Radio {FM, AM} Plays the most recent frequency for the corresponding Band.
●
Radio {87.5 - 107.9} FM Plays the selected FM band frequency.
●
Radio {530 - 1710} AM Plays the selected AM band frequency.
●
Radio FM preset {1 - 12} Plays the selected FM preset.
●
Radio AM preset {1 - 6} Plays the selected AM preset.
○
What's playing? Reads back HD RadioTM(Optional) station information.
Command Operation
●
SIRIUSTM Plays the most recent SIRIUSTM channel.
●
SIRIUSTM preset {1 - 18} Plays the selected SIRIUSTM preset.
●
SIRIUSTM channel {0 - 223} Plays the selected SIRIUSTM channel.
●
SIRIUSTM channel {name} Plays the channel searched through the SIRIUSTM channel name.
●
SIRIUSTM category {name} Plays the channel searched through the SIRIUSTM category name.
○
What's playing? Reads back SIRIUSTM channel information.
PART 4. VOICE COMMANDS 4-11
VOICE COMMANDS
3. MEDIA
Command Operation
●
Play {zune®, iPod®, USB, CD} Plays the selected media mode.
●
Play {Bluetooth® audio, AUX} Plays the selected media mode.
●
Play artist {artist name} Plays songs of the selected artist.
●
Play album {album name} Plays songs of the selected album.
●
Play track {track name} Plays the selected track.
●
Play playlist {playlist name} Plays songs of the selected playlist.
●
Play genre {genre} Plays songs of the selected genre
●
Play audiobook {title} (iPod® only) Plays the selected audiobook.
●
Play podcast {podcast} (iPod® only) Plays the selected iPod® podcast.
●
Play composer {composer} Plays songs for the selected composer.
○
What's playing? Reads back the current song information.
○
Repeat {on, off} Turns the repeat feature on or off.
○
Shuffle {on, off} Turns the shuffle feature on or off.
●
Play {CD, zune®, iPod®, USB} artist {name} Plays songs for the selected artist in the selected media mode.
●
Play {CD, zune®, iPod®, USB} album {name} Plays songs for the selected album in the selected media mode.
●
Play {CD, zune®, iPod®, USB} track {name} Plays the selected track in the selected media mode.
●
Play {CD, zune®, iPod®, USB} playlist {name} Plays the selected playlist in the selected media mode.
●
Play {CD, zune®, iPod®, USB} genre {genre} Plays songs for the selected genre in the selected media mode.
●
Play {CD, zune®, iPod®, USB} composer {name} Plays songs for the selected composer in the selected media mode.
●
Play iPod® audiobook {title} (iPod® only) Plays the selected iPod® audiobook.
●
Play iPod® podcast {podcast} (iPod® only) Plays the selected iPod® podcast.
4-12 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
4. JUKEBOX
Command Operation
●
Play JUKEBOX Plays the JUKEBOX mode.
●
Play JUKEBOX Favorites Plays songs of JUKEBOX Favorites
●
Play artist {artist name} Plays songs of the selected artist
●
Play album {album name} Plays songs of the selected album.
●
Play track {track name} Plays the selected track.
●
Play playlist {playlist name} Plays songs of the selected playlist.
●
Play genre {genre} Plays songs of the selected genre
●
Play composer {composer} Plays songs of the selected composer.
○
What's playing? Reads back the current song information.
○
Add to favorites Adds the current song to favorites.
○
Remove from favorites Removes the current song from favorites.
○
Repeat {on, off} Turns the repeat feature on or off.
○
Shuffle {on, off} Turns the shuffle feature on or off.
●
Play JUKEBOX artist {artist name} Plays songs of the selected JUKEBOX artist.
●
Play JUKEBOX album {album name} Plays songs of the selected JUKEBOX album.
●
Play JUKEBOX track {track name} Plays the selected JUKEBOX track.
●
Play JUKEBOX playlist {name} Plays the selected JUKEBOX playlist.
●
Play JUKEBOX genre {genre} Plays songs of the selected JUKEBOX genre.
●
Play JUKEBOX composer {name} Plays songs of the selected JUKEBOX composer.
PART 4. VOICE COMMANDS 4-13
VOICE COMMANDS
5. PANDORA Radio
Command Operation
●
Play PANDORA Plays the PANDORA Radio mode
●
Play PANDORA Station {station name} Plays the station searched through the PANDORA Radio
station name.
○
Shuffle Turns the shuffle feature on
○
Skip Moves to the next song.
○
Thumbs Up Approves the song and keep it in your playlist.
○
Thumbs Down Disapproves the song and prevents that song from
playing again.
○
Bookmark this track The current track is bookmarked on the currently
connected device.
○
Bookmark this artist The current artist is bookmarked on the currently
connected device.
○
What’s playing Reads back the current song information.
Command List - UVO eServices Commands
Command Operation
●
eServices Displays UVO eServices mode.
●
Roadside Assist Makes call to Roadside Assist agent.
●
eServices Guide Receive guidance on methods of using UVO eServices.
●
Vehicle Diagnostics Starts the Vehicle Diagnostics process.
4-14 PART 4. VOICE COMMANDS
PART 4 VOICE COMMANDS
Command List - Phone Commands
Command Operation
●
Call {name} Calls the desired name.
●
Dial {number} Dials the desired number.
●
Call {name} at home Calls the desired person at the home number.
●
Call {name} at office Calls the desires person at the office number.
●
Call {name} on mobile Calls the desires person on the mobile number.
●
Call {name} on Other Calls the desires person on the other number
●
Dial by number Starts dial by number operation.
●
Call a contact Starts call by name operation.
●
Phone Turns on Phone mode screen.
●
Dial international Starts international call operation.
●
Phone connections Turns on Phone connections screen.
●
Phone settings Turns on Phone settings screen.
●
SMS Reads back new SMS message
for Bluetooth® wireless technology SMS capable phones.
●
Read SMS Reads back new SMS message
for Bluetooth® wireless technology SMS capable phones.
●
Recent calls Turns on Recent Calls list screen.
●
Redial Calls the last dialed call.
5-2 PART 5. UVO eServices
PART 5 UVO eServices
Using UVO eServices and Cautions
Download the UVO eServices App and install it on your smart-
phone. The app can be downloaded from the Apple App Store
or Google Play.
Pair and connect your smartphone with the vehicle. For infor-
mation on connecting your Bluetooth® device, refer to the
smartphone user's manual and instructions on the Phone Help
screen on your radio. Up to 5 Bluetooth devices can be paired
with the vehicle.
Login and activate the UVO eServices App on your smart-
phone.
UVO eServices is fully compatible within some smartphones but
may not operate properly within incompatible smartphones.
To view the list of compatible smartphones, please visit
MyUVO.com.
Communication between the vehicle and smartphone app may
temporarily disconnect depending on the phone state.
If the feature is not operating properly, you may need to reset
the UVO eServices App or the smartphone to try again accord-
ing to the following steps.
1. Try again 2. Reset smartphone app
3. Re-connect Bluetooth® 4. Reset smartphone
5. Delete Bluetooth® device and pair again
Some services use the customer’s mobile phone data plan for
data communication. and thus the features will function in
accordance with the cellular plan.
Use of the most up-to-date app version is recommended.
For smartphone related inquiries, please visit MyUVO.com.
●
Driving while distracted can result in a loss of vehicle control that
may lead to an accident, severe personal injury and death. The driv-
er’s primary responsibility is in the safe and legal operation of a
vehicle, and use of any handheld devices, other equipment or vehi-
cle systems which take the driver’s eyes, attention and focus away
from the safe operation of a vehicle or that are not permissible by
law should never be used during operation of the vehicle.
Warning
PART 5. UVO eService 5-3
UVO eServices
When the vehicle ignition is not turned on
When the phone Bluetooth® feature is set to off
When the phone Bluetooth® cannot be connected or becomes
disconnected
When there are no phones paired with the vehicle
When cellular service is unavailable
When the power turns off due to phone power (battery) issues
When a Bluetooth® device without phone feature support has
been connected, such as an MP3 device
When the system is booting
When the system power supply is unstable
When the attempted call is blocked due to user operations
When the 9-1-1 call is unstable due to phone or other commu-
nication network issues
When the call feature is not operating due to phone settings set
by the user
When the phone cannot be controlled via Bluetooth® due to
phone specifications or characteristics
The 911 Connect feature
may not operate in the following situations.
5-4 PART 5. UVO eServices
PART 5 UVO eServices
About UVO eServices
UVO eServices provides the following features through Bluetooth® wire-
less technology communication between the vehicle and your
Smartphone.
UVO eServices is compatible with many popular smartphone devices.
Please see MyUVO.com for phone compatibility.
UVO eServices is an optional feature available in select models, on
select trims.
Name Details
1911
Connect
If an airbag deploys, your vehicle can automatically
initiate a call to 9-1-1 and sends your vehicle’s
location information to the 9-1-1 Operator.
2Roadside
Assist If a diagnostic issue exists, you can connect with a
Roadside Assist agent.
3Vehicle
Diagnostics
Informs you if certain diagnostic issues are found in
your vehicle. If an issue is found, you can contact a
call center through Roadside Assistance or reserve
an appointment with your preferred Kia dealer
through Schedule Service.
4Parking
Minder
Save the location of your parked vehicle on your
UVO eServices app.
You can check where your vehicle is parked through
the UVO eServices App on your smartphone.
5My Car
Zone
Keep track of pre-defined triggered alerts such as
Speed Alert or Curfew Alert from the My Car Zone
feature.
6eServices
Guide Receive guidance on how to use UVO eServices.
PART 5. UVO eService 5-5
UVO eServices
To use UVO eServices, the following conditions
must be met.
1. The UVO eServices smartphone app must be installed and you
must log in using your MyUVO account credentials.
2.
The smartphone must be connected via Bluetooth® wireless technology.
3.
Once this is complete, eServices must be activated (from the eServices
Settings screen)
.
The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by Kia is under
license. A Bluetooth® enabled cell phone is required to use Bluetooth®
wireless technology.
24-hour Roadside Assistance is a service plan provided by Kia Motors
America, Inc. Certain limitations apply. Coverage details are available in
the Kia Warranty and Consumer Information Manual. For access to
Enhanced Roadside Assistance, a connected mobile phone via
Bluetooth® within the cellular service coverage area is required.
Vehicle Diagnostics do not take the place of regularly scheduled
maintenance. Feature checks powertrain, chassis, and airbag
systems only. For factory-recommended maintenance schedule,
see the Maintenance Feature of UVO eServices or the Owner’s
Manual.
911 Connect activates after an airbag deployment. Feature
requires a connected mobile phone via Bluetooth®. Dependant on
cellular service coverage.
●
Driving while distracted can result in a loss of vehicle control that
may lead to an accident, severe personal injury and death. The driv-
er’s primary responsibility is in the safe and legal operation of a
vehicle, and use of any handheld devices, other equipment or vehi-
cle systems which take the driver’s eyes, attention and focus away
from the safe operation of a vehicle or that are not permissible by
law should never be used during operation of the vehicle.
Warning
5-6 PART 5. UVO eServices
PART 5 UVO eServices
Before using UVO
eServices
Installing the UVO eServices App
on your Smartphone
1. Download and install the UVO eServices
App on your smartphone.
The app can be downloaded from the
Apple App Store or Google Play.
2. Register your vehicle and account at
MyUVO.com.
Note: MyUVO.com is accessible from your
smartphone's browser.
3. Start the UVO eServices App on your
smartphone and log in.
Connecting Bluetooth® wireless
technology
1. Press the PHONE key on the UVO eSer-
vices system.
2. Press the Connections icon on the touch
screen.
3. Press the Add Device button to display
the Add Device screen.
4. Turn on the Bluetooth® wireless technol-
ogy feature on your smartphone’s
Bluetooth® settings screen.
5. Wait for “KIA MOTORS” to appear on your
smartphone’s Bluetooth® settings screen.
6. Select “KIA MOTORS” from your phone
and enter the passkey shown on the touch
screen. The default passkey is “0000”.
If your phone supports SSP (Secure Simple
Pairing), confirm the passkey on your phone.
Download and install the UVO
eServices App on your smartphone.
PART 5. UVO eService 5-7
UVO eServices
Note
●
To learn more about Bluetooth® wireless
technology features, refer to the ‘PART 3
PHONE’ section.
Activating UVO eServices
1. Press the eServices key.
2.
Press the
Settings
icon on the touch screen.
3. Press the Activate button on the touch
screen.
4.
After reading the UVO eServices terms of
use displayed on the touch screen, press
the
Activate
button.
Before pressing the
Activate
button,
ensure that you are running UVO eServices
app on your smartphone and are logged in.
5. After pressing the Activate button on the
touch screen, the UVO eServices activa-
tion process will begin.
6. Once UVO eServices activation is com-
plete, ‘UVO eServices activated’ will be
displayed at the bottom of the UVO
eServices main screen.
5-8 PART 5. UVO eServices
PART 5 UVO eServices
911 Connect
If an airbag deploys, your vehicle can auto-
matically initiate a call to 9-1-1 and will read
your vehicle's location information to the 9-1-1
Operator.
The 911 Connect feature is available only
when the mobile phone is connected via
Bluetooth® wireless technology. By default,
this feature is turned off. To turn it on, you
must turn it on in the eServices Settings
menu. By enabling this feature, you are agree-
ing the 911 Connect terms of use.
An icon is displayed at the top of the
touch screen as shown below when 911
Connect is enabled and a mobile phone is
connected via Bluetooth® wireless technology.
Note
●
For more information on setting the 911
Connect feature, refer to ‘911 Connect
Setting’.
Initiating a 9-1-1 Call
1. If an airbag deploys, the following screen
is displayed and a call is automatically
placed to 9-1-1 after 10 seconds.
2. Once a call is connected with a 9-1-1
Operator, it is possible to request emer-
gency services to be dispatched to your
location.
PART 5. UVO eService 5-9
UVO eServices
3. The 9-1-1 Operator may request informa-
tion on the current location of your vehicle.
When the 9-1-1 Operator requests your
vehicle location, the following icon is dis-
played on the screen and the vehicle loca-
tion is automatically sent to the 9-1-1
Operator.
4. If the 9-1-1 Operator attempts to call the
driver again, the following icon is dis-
played and allows the driver to speak with
the 9-1-1 Operator.
5-10 PART 5. UVO eServices
PART 5 UVO eServices
Roadside Assist
If a diagnostics issue is found, you can con-
nect with a Roadside Assist agent.
Enhanced Roadside Assistance feature can
be used only when your phone is connected
via Bluetooth® wireless technology. 1. Press the eServices key.
2. Press the Roadside Assist icon on the touch
screen to connect with a Roadside Assist
agent.
PART 5. UVO eService 5-11
UVO eServices
Vehicle Diagnostics
Conducting Vehicle Diagnostics
Vehicle Diagnostics is available only when the
ignition is turned on and the vehicle is parked.
It also requires that UVO eServices is acti-
vated, and the Phone is connected through
Bluetooth® wireless technology before starting
Vehicle Diagnostics.
1. Press the eServices key.
2. Press the Vehicle Diagnostics icon on the
touch screen.
3.
The Vehicle Diagnostics process will begin.
When a diagnostics check is in progress,
keep the vehicle in park with the ignition on.
To cancel diagnostics, press the
Cancel
button on the touch screen or any key.
4. Once vehicle diagnostics is complete, the
diagnostic results are displayed on the
screen.
5. If diagnostic issues are found, press the
Send Report button to send the diagnos-
tics results to your MyUVO account or
press the Schedule Service button to
schedule an appointment with your pre-
ferred or nearby Kia dealer.
6. When scheduling an appointment using
the Schedule Service button, pressing the
Preferred Dealer button will allow you to
request an appointment with your pre-
ferred Kia dealer and send your vehicle’s
diagnostics information.
Pressing the Nearest Dealer button will
allow you to request an appointment with
the nearest Kia dealer and your vehicle’s
diagnostics information.
5-12 PART 5. UVO eServices
PART 5 UVO eServices
7. Even if diagnostic issues are not found
after Vehicle Diagnostics, it is recom-
mended that you send the diagnostic
results to your MyUVO account.
Press the Send Report button to send the
diagnostics results to your MyUVO
account.
Scheduled Diagnostics
If you have set up Scheduled Diagnostics on
your UVO eServices app, a vehicle diagnos-
tics check will automatically start on the day
you selected.
1. On the day of the Scheduled Diagnostics,
the following window will be displayed.
2. Press the Yes button on the touch
screen to proceed with a diagnostics check.
Note
●
If you didn’t use eService via smartphone
app frequently, scheduled diagnostics may
start at date you didn’t set.
Conducting Auto Diagnostics
If a critical diagnostics issue with your vehi-
cle’s powertrain is detected, the vehicle will
automatically start the diagnostics.
PART 5. UVO eService 5-13
UVO eServices
Parking Minder
Sending Parking Location
The location where your vehicle is currently
parked can be sent to your smartphone.
The Parking Minder feature is only available
when the ignition is turned on and the vehicle
is parked.
Ensure that the UVO eServices system is acti-
vated and the Phone is connected via
Bluetooth® wireless technology with the UVO
eServices app running on your smartphone
before using this feature.
1. After parking the vehicle, press the
eServices key.
2. Press the Parking Minder icon on the touch
screen to send the vehicle’s location to
your smartphone.
3. Once the parking location has been sent,
you can view your vehicle’s location from
the UVO eServices app on your smartphone.
Note
●
When the parking location is being sent, do
not drive the vehicle or turn off the ignition.
●
Parking Minder feature operates with certain
smartphone devices with activation of App.
Normal cellular service rates apply.
5-14 PART 5. UVO eServices
PART 5 UVO eServices
My Car Zone
My Car Zone is a feature that provides alerts
and driving history for Curfew Limits and
Speed Alerts set by the user.
Name Description
Curfew Limit
Alert
Curfew Limit Alerts are alerts
that are triggered when a
driver is driving within a pre-
dened time range.
Speed Alert
Speed Alerts are alerts that
are triggered when a driver
exceeds the pre-dened maxi-
mum speed.
My Car Zone feature is supported only when
UVO eServices has been activated.
1. Press the eServices key.
2. Press the My Car Zone icon on the touch
screen.
Curfew Limit Alert
You can check the Curfew Limit Alert History
for a list of past triggered curfew alerts.
1. Press the Curfew Limit Alert button on the
touch screen.
2.
Press the corresponding alert to view
detailed alert information.
PART 5. UVO eService 5-15
UVO eServices
Name Description
1
Phone Name of phone connected
upon triggered Curfew Limit
2
Alert Time Initial alert time
3
Duration Total duration of driving while
Curfew Limit was triggered
4
Driving Time
Total driving time from turning
ignition on until turning ignition
off
Speed Alert
You can check the Speed Alert History for trig-
gered speed limit alerts of the vehicle.
1. Press the Speed Alert button on the
touch screen.
2. Press the corresponding alert to view
detailed alert information.
Name Description
1
Phone Name of phone connected
upon triggered speed limit alert
2
Max. Speed Maximum vehicle speed upon
triggered speed limit alert
3
Alert Time Time from first triggered alert
until last triggered alert
4
Duration
Total triggered alert time from
turning ignition on to turning
ignition off
1
2
3
4
1
2
3
4
5-16 PART 5. UVO eServices
PART 5 UVO eServices
To check My Car Zone alert history from your
smartphone, you must first send the alert his-
tory to your MyUVO account.
1. Press the Send Data button on the touch
screen.
Note
●
Before using Send Data , ensure your
phone is connected via Bluetooth® wireless
technology.
PART 5. UVO eService 5-17
UVO eServices
eServices Guide
eServices Guide provides guidance on how to
use UVO eServices.
This feature is only available when the mobile
phone is connected via Bluetooth® wireless
technology. 1. Press the eServices key.
2. Press the eServices Guide icon to receive
guidance on how to use UVO eServices.
5-18 PART 5. UVO eServices
PART 5 UVO eServices
UVO eServices Settings
Within the eServices Settings screen, UVO
eServices related features can be set, such as
activating UVO eServices.
Warning
●
Settings can not be adjusted while driving.
Park the vehicle in a safe and legal location
before making any changes to your
Settings.
UVO eServices Activation
1. Press the eServices key and then the
Settings button on the touch screen.
2 . If UVO eServices has not yet been acti-
vated, press the Activate button to start
the process.
Note
●
For more information on UVO eServices
activation, refer to ‘Activating UVO
eServices’.
911 Connect Setting
1. Press the eServices key and then the
Settings button on the touch screen.
2. To enable 911 Connect, ensure that the
On button is selected. To disable this
feature, ensure the Off but ton is
selected.
PART 5. UVO eService 5-19
UVO eServices
3. When enabling this feature, you must first
agree to the 911 Connect terms of use.
After reading the terms of use, press the
Agree button on the touch screen to
accept.
Trip Info Sync Reminder Setting
UVO eServices sends trip information (i.e.
Driving Distance, Driving Speed, Driving Time
and etc.) to MyUVO.com regularly.
Trip Info Sync Reminder feature is the function
that give a notice when trip information needs
to be transmitted to MyUVO.com.
1 . Press the eServices key and then the
Settings button on the touch screen.
2. To enable Trip Info Sync Reminder, ensure
that the On button is selected. To dis-
able this feature, ensure the Off button
is selected.
5-20 PART 5. UVO eServices
PART 5 UVO eServices
My Car Zone Setting
This feature is used to set My Car Zone
(Curfew Limit, Speed) alert conditions.
My Car Zone Setting is unavailable when UVO
eServices has not been activated.
1. Press the eServices key and then the
Settings button on the touch screen.
2. Press the My Car Zone setting button.
3. The PIN must be entered to use My Car
Zone Settings.
4. Press the Change button to change
Curfew Limit and Speed Alert conditions.
Within Curfew Limit Alert Settings, you can set
the Start and End Time for Curfew Limit. You
can also set alert interval of Curfew Limit.
To enable Curfew Limit Alert, ensure that the
On button is selected.
PART 5. UVO eService 5-21
UVO eServices
Within Speed Alert Settings, you can set the
vehicle speed limit. You can also set alert
interval of the speed limit.
To enable Speed Alert, ensure that the On
button is selected.
Change PIN
This feature is used to change the PIN to enter
My Car Zone Settings.
1. Press the Change button of PIN.
2. Enter new 4 digit PIN.
3. After changing the PIN, press the
Change button to transmit the new PIN to
your MyUVO.com account.
5-22 PART 5. UVO eServices
PART 5 UVO eServices
Time Zone Setting
This feature is used to set Time Zone for My
Car Zone.
1. Press the Time Zone setting button.
2. Select the Time Zone that you want to set.
Daylight Saving Setting
This feature is used to set Daylight Saving
Time for My Car Zone.
To enable Daylight Saving, ensure that the
On button is selected.
Restore Factory Settings
This feature is used to restore all My Car Zone
alert history and settings back to default state.
1. Press the Restore button.
6-2 PART 6. Rear Camera Display
PART 6 Rear Camera Display
Rear Camera Display
●
The UVO system is equipped with a Rear
Camera Display.
●
The Rear Camera Display System uses an
exterior camera integrated to the rear of the
vehicle that sends video to the UVO
system.
●
Regardless of the mode you are in, placing
the gear shifter is set to Reverse, or "R",
will automatically display the rear view
camera screen.
1. Place the transmission in Reverse “ R ”.
Warning
Check surroundings for your safety.
●
The Rear Camera Display is equipped with
an optical lens necessary to help acquire a
wider field of vision and may result in a
display which differs from the actual
distance.
Always check the rear and left/right
directions when driving in reverse.
●
The Rear Camera Display is not a substitute
for proper and safe backing-up procedures.
The Rear Camera Display may not display
every object behind the vehicle. Always drive
safely and use caution when backing up.
2. The Rear Camera Display will activate.
