HYUNDAI MOBIS AV230F6AN DIGITAL CAR AVN SYSTEM User Manual

HYUNDAI MOBIS CO., LTD. DIGITAL CAR AVN SYSTEM

User Manual

CAR MULTIMEDIA SYSTEM
USER'S MANUAL
1-4 I Basics
Display
Wide TFT-LCD Display
•Provides high quality video through a Wide TFT-
LCD Display using an LED Back Light.
•Touch screen for maximum user convenience.
Radio
Digital Tuner Feature
•Digital Tuner using PPL method that supports
memory of 12 broadcast stations for each AM
and FM modes.
Radio broadcast station name
•Displays broadcast station names for key loca-
tions.
HD Radio™/Satellite Radio feature
•Supports HD Radio™ reception and Satellite
Radio (SiriusXM™).
Key Product Features
This device is a Multimedia system equipped with a multifunctional
disc player that supports Radio (FM, AM), HD Radio™ technology,
SiriusXM™, Audio CD, MP3, USB, iPod
®
, Audio AUX, Bluetooth
®
Audio and My Music features. The WIDE VGA LCD provides a
high quality resolution while the powerful and rich sound system
adds to the driving enjoyment.
Multimedia
Player
Support for various Media Formats
•Support for various media formats, including
Radio, Audio CD, MP3, USB, iPod, AUX and
Bluetooth
®
Audio Streaming modes
My Music
•Supports copying of music stored within USB
devices into My Music (internal memory) mode
Navigation
Voice Guidance
•Voice route guidance to safely and conveniently
reach set destinations
•Various map scales that enable drivers to accu-
rately view map and surrounding areas
Automatic Correction for Current Location
•Automatically corrects current position using
map matching and GPS information.
Miscellaneous
Bluetooth
®
Wireless Technology
•Convenient use of Bluetooth
®
Handsfree by
using buttons within the steering wheel remote
controller
Digital Screen Control Features
•Easy control of features through touch screen
options
Steering Wheel Remote Controller
•Control over audio features, voice recognition
and Bluetooth
®
through the steering wheel
remote controller for maximum convenience
K_UM_G4.0[EN]AVN PART 1.indd 1-4K_UM_G4.0[EN]AVN PART 1.indd 1-4 2014-10-02 오전 11:05:452014-10-02 오전 11:05:4
Head Unit
Name Description
Press to insert or eject disc
SD Card insert slot
PWR/
VOL
•When power is off, press to turn power on
•When power is on, press and hold (over 0.8
seconds) to turn power off
•When power is on, press shortly (under 0.8
seconds) to turn Audio off
•Turn left/right to control volume
MAP
Displays the map for the current position
NAVI
Moves user to the menu screen where you can
find your destination and set the route.
PHONE
Takes user to phone screen
INFO
Displays the information mode
SETUP
Displays the Setup mode
TUNE
•FM/AM mode : changes the frequency
•SiriusXM™ mode : changes the channel
•MEDIA (Disc/USB/iPod/My Music) mode :
changes the track, file or title (except USB
Image, Bluetooth Audio and AUX)
RESET
Resets the system settings. (Preset radio chan-
nels and other data will not be deleted.)
575
Name Description
RADIO
Converts to FM/AM/SiriusXM™ mode
• Each time the key is pressed, the mode is
changed in order of FM → AM → SiriusXM™ →
FM
MEDIA
Converts to MEDIA mode
• If the media is not connected or is or CD player
not available for Model, Media mode will not be
activated.
• Press this key to move to the last mode that you
accessed in Media. Press it once again to dis-
play the screen where you can select a Media
mode.
UVO
Displays the UVO mode
When key is pressed shortly. (under 0.8 seconds)
• FM/AM mode : plays previous/next frequency
• SiriusXM™ mode : plays the previous/next chan-
nel
• MEDIA (Disc/USB/iPod/My Music) mode :
changes the track, file or title (except USB Image
and AUX)
When key is pressed and held. (over 0.8 seconds)
• FM/AM mode : continuously changes the fre-
quency until the key is released
• SiriusXM™ mode : continuously changes the chan-
nel until the key is released and plays the current
channel
• MEDIA (Disc/USB/iPod/My Music) mode :
rewinds or fastforwards the track or file (except
USB Image, Bluetooth Audio and AUX)
01
Name Description
MODE
•Each time this key is pressed, mode is changed
in order of FM → AM → SiriusXM™ → Disc →
USB Music or iPod → AUX → Bluetooth Audio
→ My Music
•If the media is not connected, corresponding
modes will be disabled
•Press and hold the key (over 0.8 seconds) to
turn the Audio system on/off
•When power is off, press the key to turn power
back on
+
,
-
Controls the volume
When keys are pressed shortly. (under 0.8 sec-
onds)
•FM/AM mode : searches broadcast frequencies
saved to Presets
•SiriusXM™ mode : searches broadcast chan-
nels saved to Presets
•MEDIA(Disc/USB/iPod/My Music) mode :
changes the track, file or chapter (except USB
Image, AUX)
When keys are pressed and held. (over 0.8 sec-
onds)
•FM/AM Mode : Automatically searches broad-
cast frequencies
•SiriusXM™ mode : automatically searches
broadcast channels
•MEDIA(Disc/USB/iPod/My Music) mode :
Quickly looks up songs (excluding USB images,
AUX, and Bluetooth audio files)
Name Description
When pressed shortly. (under 0.8 seconds)
•Activates voice recognition
When pressed and held. (over 0.8 seconds)
•Ends voice recognition
•Activates Siri Eyes Free
Steering Wheel Remote Controller
When pressed shortly. (under 1.2 seconds)
• When pressed in the dial screen, makes a call
• When pressed in the incoming call screen,
answers the call
• When pressed during call waiting, switches to
waiting call (Call Waiting)
When pressed and held. (over 1.2 seconds)
• When pressed in the Bluetooth
®
Handsfree, redi-
als the last call
• When pressed during a Bluetooth
®
Handsfree
call, switches call back to mobile phone (Private)
• When pressed while calling on the mobile phone,
switches call back to Bluetooth
®
Handsfree
(Operates only when Bluetooth
®
Handsfree is
connected)
• When pressed during a call, ends the phone call
• When pressed in the incoming call screen, rejects
the call
※The actual feature in the vehicle may differ from the illustration.
10-2 I Appendix
Product Specification
TFT-LCD
Screen Size Navigation Device - 8 inch(176.4 x 99.36mm)
Resolution
Navigation Device - 384,000 pixels (Resolution: 800 x 480)
Operating
Method TFT(Thin Film Transistor) Active Matrix
Viewing
Angle Left/Right, Top/Bottom : ALL 89°
Internal Lighting
LED
Radio
Channels
FM : 87.5 MHz ~ 107.9 MHz(Step : 200 kHz)
AM : 530 kHz ~ 1710 kHz(Step : 10 kHz)
Sensitivity FM : Under 10dBu/AM : Under 35dBu
Distortion Factor
Within 2%
Common
Name Car TFT LCD Display Navigation Unit
Power Supply DC 14.4V Operating
Power DC 9V ~ DC 16V
Current
Consumption 2.5A Sleep
Current
0.5mA
(Head Unit Only)
Operating
Temperature
-20 ~ +70℃
(-4 ~ +158
℉
)
Storage
Temperature
-40 ~ + 85℃
(-40 ~ +185
℉
)
Dimensions 178 X 102 X138mm ( Main BOX)
Weight 3.0 kg
Appendix
K_UM_G4.0[EN]AVN PART 10.indd 10-2K_UM_G4.0[EN]AVN PART 10.indd 10-2 2014-10-02 오후 1:22:562014-10-02 오후 1:22:5
10
Wi-Fi Details
Frequency 2412 ~ 2462MHz
Specification 802.11b/g/n
Number of
Channels 11 channels
Operating
Temperature -20 ~ + 70℃ (-4 ~ +158
℉
)
Bluetooth®
Wireless Technology
Frequency
Range 2402 ~ 2480 MHz
Supported
Bluetooth
®
Specification
3.0
Supported
Profile Handsfree(1.6), A2DP(1.2), AVRCP(1.4), PBAP(1.0)
Output 0.125mW
Number of
Channels 79 channels
CAUTION
• The producer and installer cannot provide services related to life
safety as the concerned radio equipment is liable to radio interference.
10
Important Safety Information
Before using your Multimedia system, read and follow all instructions and safety information provided in this end user manual ("User's
Guide"). Not following precautions found in this User's Guide can lead to an accident or other serious consequences.
Keep User's Guide in Vehicle
When kept in the vehicle, the User's Guide will be a ready reference for you and other users unfamiliar with the Multimedia system. Please
make certain that before using the system for the first time, all persons have access to the User's Guide and read its instructions and
safety information carefully.
Warning:
Operating certain parts of this system while driving can distract your attention away from the road, and possibly cause an accident or other
serious consequences. Do not change system settings or enter data non-verbally (using your hands) while driving. Stop the vehicle in a
safe and legal manner before attempting these operations. This is important since while setting up or changing some functions you might
be required to distract your attention away from the road and remove your hands from the wheel.
General Operation
K_UM_G4.0[EN]AVN PART 10.indd 10-13K_UM_G4.0[EN]AVN PART 10.indd 10-13 2014-10-02 오후 1:22:592014-10-02 오후 1:22:5
Voice Command Control
Functions within the Multimedia system may be accomplished using only voice commands. Using voice commands while driving allows
you to operate the system without removing your hands from the wheel.
Prolonged Views of Screen
Do not access any function requiring a prolonged view of the screen while you are driving. Pull over in a safe and legal manner before
attempting to access a function of the system requiring prolonged attention. Even occasional short scans to the screen may be hazardous
if your attention has been diverted away from your driving task at a critical time.
Volume Setting
Do not raise the volume excessively. Keep the volume at a level where you can still hear outside traffic and emergency signals while
driving. Driving while unable to hear these sounds could cause an accident.
Navigation Features
Any navigation features included in the system are intended to provide turn by turn instructions to get you to a desired destination. Please
make certain all persons using this system carefully read and follow instructions and safety information fully.
K_UM_G4.0[EN]AVN PART 10.indd 10-14K_UM_G4.0[EN]AVN PART 10.indd 10-14 2014-10-02 오후 1:22:592014-10-02 오후 1:22:5
10
Distraction Hazard
Some navigation features may require manual (non-verbal) setup. Attempting to perform such set-up or insert data while driving can seri-
ously distract your attention and could cause an accident or other serious consequences. Stop the vehicle in a safe and legal manner
before attempting these operations.
Let Your Judgment Prevail
Any navigation features are provided only as an aid. Make your driving decisions based on your observations of local conditions and exist-
ing traffic regulations. Any such feature is not a substitute for your personal judgment. Any route suggestions made by this system should
never replace any local traffic regulations or your personal judgment or knowledge of safe driving practices.
Route Safety
Do not follow the route suggestions if doing so would result in an unsafe or illegal maneuver, if you would be placed in an unsafe situation,
or if you would be directed into an area that you consider unsafe. The driver is ultimately responsible for the safe operation of the vehicle
and therefore, must evaluate whether it is safe to follow the suggested directions.
Potential Map Inaccuracy
Maps used by this system may be inaccurate because of changes in roads, traffic controls or driving conditions. Always use good judg-
ment and common sense when following the suggested routes.
K_UM_G4.0[EN]AVN PART 10.indd 10-15K_UM_G4.0[EN]AVN PART 10.indd 10-15 2014-10-02 오후 1:22:592014-10-02 오후 1:22:5
Emergency Services
Do not rely on any navigation features included in the system to route you to emergency services. Ask local authorities or an emergency
services operator for these locations. Not all emergency services such as police, fire stations, hospitals and clinics are contained in the
map database for navigation features.
Use of Speech Recognition Functions
Speech recognition software is inherently a statistical process which is subject to errors. It is your responsibility to monitor any
speech recognition functions included in the system and address any errors.
K_UM_G4.0[EN]AVN PART 10.indd 10-16K_UM_G4.0[EN]AVN PART 10.indd 10-16 2014-10-02 오후 1:22:592014-10-02 오후 1:22:5
10
FCC Warning
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this
equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum 20 cm between the radiator and your body.
This transmitter must not be collocated or operating in conjunction with any other antenna or transmitter unless authorized to do so by the
FCC.
K_UM_G4.0[EN]AVN PART 10.indd 10-17K_UM_G4.0[EN]AVN PART 10.indd 10-17 2014-10-02 오후 1:22:592014-10-02 오후 1:22:5

Navigation menu
