Haefele and KG 917120 Energy Saving Control Passive User Manual
Haefele GmbH&Co.KG; Energy Saving Control Passive
User Manual
System Components
Energy Saving Control
All rights to modify specications without notice are reserved.
Function and Features
Insert any Mifare card to get power
Technical Data
Installation
Technology
Mifare
Dimension
86x86x46mm
Part No Working Voltage Working Current Ambient Temperature
(operation) Relative Humidity Finish
917.56.907 < 100mA -20°C ~ +70°C 5% ~ 95 %
(not condensed)
White
917.56.909 Silver
917.56.917 White
917.56.917 Silver
110-120VAC,50/60Hz,
30A
220-240VAC,50/60Hz,
30A
Energy Saving Control Passive
FCC Warning:
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Declaration Of Conformity
Hereby, Haefele GmbH&Co.KG declares that this Energy Saving Control Passive is
in compliance with the essential requirements and other relevant provisions of
directive 1999/5/EC.
