Haier Telecom 1005HG-M180 Mobile Phone User Manual
Haier Telecom (Qingdao) Co., Ltd. Mobile Phone
user manual
![](/img.php?id=1335434&img=bg1.png)
- 1 -
Safety Instructions
These instructions are intended for safe and effective use of your
phone. Please follow these guidelines. Failure to do so might cause
the product to malfunction or even become a potential hazard to
your health.
Do not use your mobile phone while driving. Park the car before
making a call.
Turn off your phone when refueling.
Do not use your phone near a gas station, flammable, or chemical
substances.
Warning! It may explode when exposed to fire.
Do not use your phone during a flight, it is dangerous.
Do not use your phone near medical equipments like
pacemaker and hearing aids without requesting permission from
the physician or medical staff.
Radio signals may affect the performance of the phone.
Do not touch any exposed parts of the antenna during a call;
otherwise it will affect the call reception and waste battery power.
Do not attempt to disassemble or modify the phone by yourself.
Only authorized personnel should perform this service.
When you connect accessories to your phone, please read the
safety guidelines carefully.
Do not use unauthorized products or accessories with phone.
Please use only the original accessories or products that are
authorized by our company.
Keep out of children's reach.
![](/img.php?id=1335434&img=bg2.png)
- 2 -
Phone Overview (Picture for reference only)
Description of Keys
Key Description
Left Soft key Activates/selects the menu function at the
left bottom side of the LCD screen.
Right Soft key Activates/selects the Contacts menu
function at the right bottom side of the
LCD screen.
Answer/Dial key Dial and answer calls. In standby mode,
press to view recently dialed calls.
End/Power key
Ends or reject calls; Power on/Power off;
In the menu programming, press to return
to standby mode.
Navigation key
In standby mode, press;
Left – Calendar
Right – Create Message
Down – Contact list.
Long press up torch on/off
Left Soft key
Answer/Dial key
Right Soft key
End/Power key
Navigation key
- 3 -
Getting Started
Inserting SIM card and Battery
WARNING!
Keep SIM Card out of children's reach.
Any abrasions or bend might easily cause damage. Please take
extra care.
Make sure the phone is power off when you remove the SIM
Card.
Remove the battery cover by sliding it downward.
Insert the SIM Card into the SIM card slot as per figure on
slot.
Place the battery into the phone. Make sure that the charge
pins are in contact with the battery terminals.
Slide the battery cover until it locks into place.
Taking out the battery
Remove the battery cover. Insert your fingernail at the bottom slot
of the battery compartment and then pull out the battery.
Charging the Battery
Insert the connector of the charger into the top-left side of the
phone (Note: Ensure that the charger connector is plugged in).
Plug the charger into the AC wall outlet.
When the power turns on, “Charging…” will be displayed on the
LCD screen, and the battery indicator will start scrolling. It will
only stop when the battery is fully charged. If a battery is
completely discharged, it may take a few minutes before the
charge indicator appears on the LCD screen.
- 4 -
After charging is completed, disconnect charger from phone
and the socket of the alternating current.
Notice:
When charging, please place the phone in an environment that
has a normal room temperature and good ventilation. It is
recommended to charge the phone in an environment with a
temperature that ranges from 5℃~40℃. Please ensure to use
only the charger offered by the manufacturer. Using
unauthorized charger may cause danger and violate the
authorization of the phone and the guarantee.
When the phone automatically turns off or indicates the alarm
information of power shortage, please charge the battery on
time.
The duration time of the standby and conversation of the
phone offered by manufacturer is based on ideal working
environment. It may vary according to the network condition,
working environment, and application methods.
Warnings!
• Do not take the battery out when it is being charged.
• To ensure best performance, please use original
accessories.
• Using any unauthorized accessories may affect your
mobile phone’s performance.
Personal data and settings in your phone and SIM card may be
lost when you take out the battery.
Security number
PIN
PIN (Personal Identity Number), usually provided to a SIM Card by
the network operator.
If you enter the wrong PIN three times in a row, it will be locked.
You need to enter your PUK (Personal Unblocking Key) number to
![](/img.php?id=1335434&img=bg5.png)
- 5 -
unlock. Please contact your network operator for more details.
PIN2
PIN2 is provided to some SIM. If you enter the wrong PIN for
another three times in a row, it will be locked. You need to enter
your PUK2 to unlock. This PUK2 may be different from previous
PUK. Thus, please contact your network operator for more
information.
PUK
PUK (Personal Unblocking Key) is used to unblock the PIN. PUK is
provided to a SIM card. If you lose or forget the password, contact
your network operator.
Phone code
Protects your phone against unauthorized usage. You can turn on
the Phone code for your personal security use.
General Features
Turn on the phone
1. Press and hold (End key) to turn on the phone. The LCD
screen will turn on.
2. If SIM card is not properly installed, a warning prompt will
appear on the screen. Press and hold (End key) to turn off,
and re-install the SIM card properly.
3. If you have set a phone password, you will be asked to enter your
password.
4. If your SIM card is protected by PIN, the phone will instruct you
to enter the PIN number.
5. You will be asked to enter the PUK number if SIM card is locked.
6. The phone will search for network automatically once turned on.
Warning!
If the phone has found an authorized network operator, the
name of the network and signal intensity will be displayed.
![](/img.php?id=1335434&img=bg6.png)
- 6 -
If not, you can only use the emergency calls and other
non-communication service.
To make Domestic calls
In standby mode, enter a phone number (with region code and area
code), Press (Right Soft Key) to delete a wrong entry. Then
press (Dial Key) to dial the number. When the call gets
connected, the call status will be displayed.
To reject a call
When you have incoming call, press (End Key) to reject it.
To answer a call
When a call comes in, phone will ring and/or vibrate. It will show
the caller's name if the network supports it. The caller’s name
display depends on whether you have saved it in your phonebook
or not. Press (Dial Key) to answer, or press
Option -> Accept
.
To end a call conversation
When you have finished talking, press (End Key) to end a call
Also, you can press (End Key) if you want to terminate a call
after dialing a number.
Emergency calls
You do not need to own a SIM card to make emergency calls.
Emergency calls may differ for different network operators, please
contact your network operator to get your local emergency call
numbers.
To make an international call
To make an international call, press and hold【0】key until a + sign
appears.
Then enter the country/region code, area code (without the first
![](/img.php?id=1335434&img=bg7.png)
- 7 -
zero), and the phone number:
After you have entered the + sign, enter the country code and the
number you want to dial. For example, +91 for India.
As you dial a common international code, you don’t have to enter 0
of the city code.
To dial from contacts
Find the number you want to call in your phone book, press
(Dial Key) to automatically dial the displayed contact.
To dial from the Call list
All the numbers that you have dialed are saved in the call records.
When the calls memory is full, the old numbers are automatically
deleted. To scroll the call list:
In standby mode, press (Dial Key). The call records will
display starting from the most recently called number. Press
(Dial Key) key to automatically dial the displayed record.
Or
Press Up or Down key to scroll the list and then press (Dial
Key) key to automatically dial the selected record.
Incoming Call Options
While the phone is ringing, press (Left Soft Key) to enter the
calling options or press (Right Soft key) to activate the Mute
mode.
In the call options, you can
Accept
Reject
Power off
In standby mode, press and hold (End Key) to turn off your
phone.
- 8 -
Menu
Messages
1. Create message
2. Inbox
3. Outbox
4. Draftbox
5. Templates
6. Message settings
7. Memory status
Contacts
1. New contact
2. View contacts
3. Search
4. View groups
i. Family
ii. Friends
iii. Office
iv. Others
5.Special numbers
i. My numbers
ii. Voice mail
6. Advanced
i. Speed dial
ii. Choose contacts
iii. Copy
iv. Delete all contacts
7. Memory status
8. Fixed dial
9. Enable FDN
Calls
1. Incoming calls
2. Outgoing calls
- 9 -
3. Missed calls
4. Call duration
Tools
1. Games
1. Sokoban
2. Minesweeper
2. Alarm
i. Alarm 1
ii. Alarm 2
iii. Alarm 3
3.Calculator
4.Calendar
Settings
1. General
i. Language
ii. Time and date
Date & time settings
Date display format
Date separator
Time display format
iii. Answer mode
Normal answer
Any key answer
iv. Security
PIN protection
Phone lock
Keypad locking settings
change password
2. Display
i. Idle display
- 10 -
ii. Contrast
iii. Backlight
3. Sounds
i. Ringtones
Incoming call
Message
Key tone
ii. Volume
Call
Ring tone
Key tone
iii. Alert type
Ring only
Vibrate only
Vibrate and ring
4. Call setup
Call divert
Call barring
Call waiting
Auto redial
Caller ID
5. Network settings
Automatic mode
Manual mode
6. Factory default
FM Radio
SIM Tool Kit
4. FM Radio
Note: The FM radio function can only be activated after inserting
the headset. Use only the headset type that comes with this phone.
- 11 -
FM Channel manual search
In the FM radio display, use Left or Right arrow keys to scan for
an active FM channel station.
To save an active FM channel
1. After scanning an active FM channel, press
Options -> Save
channel.
2. Input the name
3. Press OK key
FM Channel Auto Search
1. In the FM radio display, press
Options -> Auto Search.
2. The phone will automatically search for clear FM channels
and stores them all in the FM Channel memory.
Note: This operation may take a few minutes.
Changing channels
While tuned in to a current channel, press Up or Down key to
change channels, Or;
1. Press
Option -> Channel List
.
2. Select the desired channel and then press
Options-> Play.
Adjusting the receiver volume
While tuned in to a current channel, press # or * key to increase
or decrease the receiver volume.
Listening to the FM radio over the phone speaker
1. While tuned in to a current FM channel, press
Option ->
Loud speaker -> On
2. To return listening to the earphone, press
Option -> Loud
- 12 -
speaker -> Off
Important: While tuned in, do not unplug the headphone.
Maintenance:
Battery instructions
When the phone automatically turns off or indicates the alarm
information of power shortage, please charge the battery on time.
For the first few times, please fully charge the battery.
When not in use, please separate the battery from the Phone.
Overcharging will shorten the life of the battery.
Do not expose your products to extreme high or low
temperatures. Do not expose the battery to temperatures
above +40℃.
Do not use damaged battery.
Do not expose your mobile phone to direct sunlight or in hot
areas. High temperatures can shorten the life of electronic
devices.
Do not expose the battery to fire and neither throw it away.
Return the battery to the provider or put it in the appointed
recycling place.
Follow these guidelines to protect your product:
keep the product out of children's reach.
Keep your product dry. Do not expose it to liquid or moisture.
Do not short-circuit the battery, as this can cause excessive
heat, enough to bring about fire.
Do not expose your mobile phone to direct sunlight or in hot
areas. High temperatures can shorten the life of electronic
devices.
Do not attempt to disassemble the phone and battery by
- 13 -
yourself.
Prevent any liquid from leaking into your phone.
Use original accessories only. Using any unauthorized
accessory may affect your mobile phone’s performance.
Security Requirements
Before making or answering a call, you should pay attention to the
local laws about the use of wireless mobile phones and take them
into account in practical use.
Traffic safety
Pay attention to traffic safety. Do not use your mobile phone
while driving. Park before making or answering a call.
Without enough shield, some electronic devices in the car may
cause interference to the radio frequency of your phone.
If you have to use your phone in a car, make sure it has an
antenna.
Only qualified technician can install your phone into your
automobile.
Flight Safety
Please turn off your GSM mobile phone before the airplane takes
off. In order to protect airplane’s communication system from
interference, it is never allowed to use a mobile phone in a flight.
Using mobile phone before the plane is taking off; user should get
aircrew’s permission according to safety regulations.
Do not use your phone where a potentially dangerous atmosphere
exists.
Operating of mobile phone may interfere with medical devices like
hearing aids and pacemakers.
Please strictly observe with the restrictions on the use of wireless
devices.
- 14 -
Warning!
1. The performance of your phone depends on your local network
operator’s card and how you actually use it.
2. We are not responsible for any damages due to inappropriate
usage.
3. We reserve the right to make any modifications on this manual
without prior notice.
- 15 -
RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types HG-M180
(FCC ID: SG71005HG-M180) has also been tested against this SAR limit. The highest SAR value reported
under this standard during product certification for use at the ear is 1.455 W/kg and when properly worn on
the body is 0.695 W/kg. This device was tested for typical body-worn operations with the back of the
handset kept 1.5cm from the body. To maintain compliance with FCC RF exposure requirements, use
accessories that maintain a 1.5cm separation distance between the user's body and the back of the handset.
The use of belt clips, holsters and similar accessories should not contain metallic components in its
assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user’s authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
