Haier Telecom 20150318M220 GSM digital mobile phone User Manual DF5310 English 20110315
Haier Telecom (Qingdao) Co., Ltd. GSM digital mobile phone DF5310 English 20110315
User Manual
User Manual
M220
Contents
Basic Information ................................................................................................... 3
Brief Introduction ..................................................................................................... 3
Safety Notice ............................................................................................................. 3
Cleaning and Maintaining ........................................................................................ 3
Before Using ........................................................................................................... 3
SIM ........................................................................................................................... 4
Phone Unlock ........................................................................................................... 4
SIM Unlock ............................................................................................................... 4
Function menu Introduction .................................................................................. 4
Call center ................................................................................................................ 4
Call history ........................................................................................................... 4
Call settings .......................................................................................................... 5
Messaging ................................................................................................................. 7
Write message ...................................................................................................... 7
Inbox ..................................................................................................................... 7
Drafts .................................................................................................................... 8
Outbox .................................................................................................................. 8
Sent messages ....................................................................................................... 8
Message settings ................................................................................................... 8
Multimedia ................................................................................................................ 8
Camera.................................................................................................................. 8
Image viewer ........................................................................................................ 9
Video recorder ...................................................................................................... 9
Video player ......................................................................................................... 9
Audio player ......................................................................................................... 9
Sound recorder.................................................................................................... 10
FM radio ............................................................................................................. 10
Settings ................................................................................................................... 10
Profiles ................................................................................................................ 10
Phone settings ..................................................................................................... 11
Security settings.................................................................................................. 13
Network settings ................................................................................................. 14
Connectivity ....................................................................................................... 14
Restore settings ................................................................................................... 14
Shortcuts ............................................................................................................. 14
Phonebook .............................................................................................................. 14
Fun .......................................................................................................................... 15
Games ................................................................................................................. 15
File manager .......................................................................................................... 15
Services ................................................................................................................... 16
Internet service ................................................................................................... 16
SIM tool kit ........................................................................................................ 16
Organizer ................................................................................................................ 17
Calculator ........................................................................................................... 17
Bluetooth ............................................................................................................ 17
Calendar.............................................................................................................. 17
Alarm .................................................................................................................. 18
Torch .................................................................................................................. 18
3
Basic Information
Brief Introduction
Thank you for choosing M220 mobile phone. You can read the manual,
a comprehensive understanding of the use of mobile phones and enjoy its
perfect functionality and simple method of operation.
M220 supports one SIM card function.In addition to basic call functions,
but also to provide you with phone book, personalized ring tones, alarm,
camera, image viewer, video recorder, video player, audio player, FM, One
Memory Card (T-Flash card), calculator, calendar etc. A variety of
practical features to facilitate your work and leisure activities, in addition,
M220 interface with personalized mobile phone design, its perfect
functionality to meet your needs.
Our Company reserves without any prior notice the contents of this
manual under the right to make changes.
Safety Notice
If your phone is lost or stolen, immediately notify the
telecommunications sector, or its outlet, to disable the SIM. This will allow
you to take phone calls from other economic loss arising. To make you
more secure use of mobile phones, please take precautionary measures,
such as:
- Set up mobile phone SIM card PIN password, PIN password to prevent
your SIM is unauthorized use by others.
Cleaning and Maintaining
Do not use the bathroom where high humidity, cell phone, battery and
charger, the same should also avoid the rain. Use a soft, dry cloth to clean
the phone, battery and charger. Dirt outlet will lead to poor contact,
power-down, which does not charge, regular cleaning.
Before Using
4
SIM
Before using your phone you must insert a valid SIM (Subscriber
Identity Module) card. SIM card provide by the network provider.
Warning: Be sure to remove the SIM phone off before. There is
absolutely prohibited in the case of an external power supply connected to
insert or remove the SIM, or SIM card and mobile phone may be damaged.
Phone Unlock
In order to prevent illegal use, your phone can set the phone lock
password protected. Use this function,you must enter the phone lock
password so that you can unlock the phone into the normal use state.
Enter the phone lock password, press the LSK to confirm. For example,
if the phone lock password is set to 0000, then the following input: 0000.
SIM Unlock
In order to prevent illegal use of your SIM with PIN (Personal
Identification Number) password encryption protection. Use this function,
if you have set the PIN password protection, every time you must enter the
PIN password at boot time, so that you can unlock the SIM card and phone
to normal use. Enter the PIN password，press the LSK to confirm. For
example, if the PIN is set to 1234, then the following input: 1234.If there
consecutive incorrect, your SIM will be network locked, the phone will ask
for PUK password.
Function menu Introduction
Call center
Call history
Missed calls
Enter the missed call menu, will display the missed calls list. Select
missed call records，press the OK key to enter "Options":
- View View the details.
5
- Call Call the record number.
- Send text message Send SMS to record number.
- Save to Phonebook Save the number to the phone or SIM card.
-Add to Blacklist Save the number to phonebook block list.
- Delete Delete the number.
Dialled calls
Enter the dialed calls menu to display the current record of outgoing
phone list of phone numbers. Please refer to missed calls for details.
Received calls
Enter the received calls menu to display the current record has been
received mobile phone number list. Please refer to missed calls for details.
All calls
Enter the all call menu, will display the all calls list. Please refer to
missed calls for details.
Delete call logs
Delete all calls from dialled calls、missed calls、receive calls and all
calls.
Call timers
See SIM call times.
Call settings
Enter the call set up sub-menu，you can make the following settings:
Call waitting
Open this feature，during the call if the new call, the network will
notify you. Specific use with your network provider.
Avtivate lanch the function.
Deactivate Close the function.
Query status Query the function‟s status.
6
Call divert
Network Call Transfer service allows you to call a business case in a
default transferred to a phone number you specify. The features include:
Divert all voice calls，Divert if unreachable,Divert if no answer, Divert if
busy,Divert all data calls.
Call barring
Into the "Call barring" sub-menu, you can set the following call barring
any combination to improve security. Some network providers may not
provide this service call restrictions, specific use, please contact your
network provider. Network provider will provide a four-ban password so
that you can enable call restrictions.
Change the password to enter the old call barring password, set new
restrictions on the password.
Line switching
Switch between line1 and line2. line 1 can be a normal call, send text
messages and so on. select line2, you can answer the phone but not ring up.
Advanced settings
Blacklist:
This feature allows you to use in case of do not want to be disturbed,
add the number to open the blacklist after blacklist, the number can not dial
your phone.Reject unknown calls can open and close.Refused to blacklist
calls can open and close.The blacklist Number can enter your own can also
be joined from the phone book.
Auto redial：
Through on / off settings, to activate or disable the feature.Turned on
and when your phone call after another failed attempt to connect up to
redial 10 times. This feature can save you the trouble of repeated calls.
Call time reminder:
In this menu can prompt a certain length of time to set up the call,
according to the menu function mode in order to select the following tips:
Off Close the function.
Single Enter any numbers between 1-3000
（sec）
, which arrived at the
7
selected time (seconds) of talk time when prompted.
Periodic Enter any number between 30-60（sec）, from the input
time (in seconds), the intervals of 1 minute for talk time tips.
Connect notice:
When switched on the phone will vibrate.
Answer mode:
Any key and Anto answer when headset mode two choices for
selecting.When you select any key, press any key outside power key and
RSK can answer the call.
Messaging
Make sure that the information in writing before the message center
number is set correctly. Access to an information menu, you can edit the
SMS and Multimedia message.
Write message
Send to After editing the information, select the operation, enter the
number manually, or add records from the phonebook, you can do send,
Edit recipient, Remove recipient, Remove all recipients, Save
oprations.Sent SMS to one or more persons, and storage to Drafts.
Input method Offer many kinds of input methods to choose from
method.
Advanced:
Insert number Insert number into SMS from phonebook.
Insert name Insert the name of the record into SMS from
phonebook.
Save save to drafs.
Inbox
In list of inbox, you can press the OK key to read the message details, In
the inbox interface, press LSK "Options" to enter the menu:
View Enter the message reading interface to view the message‟s
details.
Reply Send SMS to the sender.
Call sender Make a call to the sender.
Forward Send the message to other people.
8
Delete Delete the message.
Delete all Delete all messages.
Save to Phonebook Save the number to phonebook.
Drafts
Edit the SMS not sended but stored in the draft, the detail features,
please refer to "Inbox".
Outbox
Go to the Outbox list view your SMS are not sent successfully. the detail
features, please refer to "Inbox".
Sent messages
Open the message set in the "Save sent message", send the information
after the success of information stored in the Sent, detail features, please
refer to "Inbox".
Message settings
SIM This menu can set SMS address、delivery report、reply path and
voicemail server function。
Memory status View the SIM and Phone capacity information.
Save sent message Open the "Save sent message", messages sent
after a successful save the sent message, if you turn off this feature, you
will not be saved.
Preferred storage: Can set preferred storage as SIM or phone.
Multimedia
Camera
The phone includes high-definition camera, you can take pictures
anytime, anywhere, and to save the photos to your phone or memory card.
State in the preview, press the LSK to enter "Options" you can do this to
conduct a more detailed set of parameters.
Switch to video recorder: Switch to the video recorder.
Photos: Photo album shows the current list of files.
Camera settings: Including Shutter sound,EV,Contrast,Anti-flicker
9
and Delay timer, setting operation contents of the regulation. Been adjusted,
press the LSK "OK" to save the current settings.
Image settings: Include the Image size and image quality regulation.
Storage: storage location can be set as Phone, Memory card，the
captured image will be saved to the specified location.
Restore default: Set all parameters to default settings.
Image viewer
Select an album sub-menu, you can easily view stored in the camera
album picture list, and press the LSK to enter to "Options" to choose the
pictures to do the View, Send, Use as, Rename, Delete, change Storage and
check Image information operations. View pictures, by pressing on the left
and right navigation buttons to switch pictures.
Video recorder
Switch to camera: Switch to the camera.
Camcorder settings: Recorder settings includingAnti-flicker setting.
Video settings： Include video quality.
Storage: storage location can be set Phone and Memory card, shooting
the video will be saved to the specified location.
Video player
Choose video player sub-menu, you can easily view the saved video
player in the video list, press the LSK to enter "Options" to select the video
files to do the play, send(send the video via Bluetooth or multimedia
message if you want) ,rename, delete etc operations.
Audio player
In the Audio player interface, you can press left and right keys to switch
the music; press * and # keys to adjust the play volume. In the Audio
player interface, press the left soft key to enter "list" menu and enter the
current playlist to play in the option list can be any of a music file to play.
Select a music file to enter the settings options，you can top of the screen
prompts the items content specific settings of each item:
Pre.playlist: Can select the preferred list, Phone or Memory card. If
you choose a memory card, then show the all music files in memory.
10
List auto gen.: To switch to this setting. When this feature is set on,
you can perform the "Refresh Playlist" operation.
Repeat: Can be set as off (no repeat), one，all.
Shuffle: Random order of play set, respectively, can be set to on and
off.
Background play: Set the background play on, you can make mobile
phone in other user interface and also play music. Set as off, the music will
not play when out of the Audio player.
Sound recorder
In the sound recorder interface press “option”, it shows the items of
record.
New record Start a new record. If you press stop，it will pop up a
dialog box to prompt you save it or not. If you press pause, it will suspend
recording, and then press continue，it can record again.
List Display the sound that you recorded and saved in the memory
card.
Settings you can set the file format and audio quality of the record.
FM radio
FM interface, press the OK key to turn on / off FM play, press the right
navigation key to automatic search，press *and # keys to adjust the FM
playing volume. Press the left soft key "Options" can show FM options
menu, the content were:
Channel list: Shows FM channel list.
Manual input: Can be their own editors to manually enter the channel
frequency, the effective value of 87.5 ~ 108.0.
Auto search: Auto search FM channels in the channel list.
Settings: Can on/off the background and loudspeaker play.Also can
set FM record audio quality and storage operations.
Record: Record your favorite FM audio sound.
File list: You get recoded audio.
Settings
Profiles
11
Profiles including General、Silent、Meeting and Outdoor. First, based on
the current scene, select a different profile, then you only need a personal
profile can be set and activated.
General: General environment.
Silent: For Silent environment.
Meeting: For meeting the environment, to be pre-set (for example:
ring mode can be set to vibration).
Outdoor: For outdoor activities, need to pre-set (for example, ring
volume can be set to a higher state).
Press the left soft key "Options":
Activate: Enable the selected profile.
Customize:
Alert type: Can choose to Ring only, Vib. Only，Vib.and ring, Vib.
Then ring as the current method.
Ring type: You can choose repeat and beep once two type.
Ringtone According to their own preferences set ringtones 1-5,
can also be set from the memory card custom ringtones
Ringtone volume In the volume control interface, you can volume
up and down navigation keys on the set. Volume level is divided into seven,
1-7, followed by increases.
Message According to their own preferences set ringtones 1-5.
Message volume In the volume control interface, you can volume
up and down navigation keys on the set. Volume level is divided into seven,
1-7, followed by increases.
Keypad you can set keypad as silent、press and tone
Keypad volume In the volume control interface, you can volume
up and down navigation keys on the set. Volume level is divided into seven,
1-7, followed by increases.
System alert can on\off system alert.
Reset: Reset profiles by defults.
Phone settings
Into the phone settings sub-menu, you can make the following settings:
Time and Date
In this menu, you can move the phone time and date settings. The menu
12
consists of three sub-menu:
Set home city: Set the mobile phone home city.
Set time/data You can set time and date. Phone allows you to set a
calendar from 2000 to 2030 between the dates.
Set format: You can set time and date‟s format.
Schedule power on/off
There are two powered on and two powered off time for you to edit.
every time item includes: enable , disable, content and ect. Finish the
setting , you must open this item. when time is up, the phone will execute
relevance operation.
Notice: if you set the time of powered on and the time of powered off
are same, it isn‟t active at the same time!
Language
Phone supports many kinds of language for you to select. Set the current
language type, then menu and interface refresh for the corresponding
language.
Pref. input method
The phone supports many kinds of methods, to choose an input method
as the default when the initial input.
Display
Wallpaper: Wallpaper set in two ways: First, through the navigation
system comes with the wallpaper and select; the second is user defined, by
browsing the [File manager] photos folder identified as a wallpaper.
Screen auto lock: Set the screen auto unlocked time.
Power on display: Power on display set in two ways: First, through
the navigation system comes with the wallpaper and select; the second is
user defined, by browsing the [File manager] photos folder identified as a
wallpaper.
Power off display：Power off display set in two ways: First, through the
navigation system comes with the wallpaper and select; the second is user
defined, by browsing the [File manager] photos folder identified as a
wallpaper.
13
Show date and time: Display date and time to do On / Off settings, to
determine whether the date and time displayed on the idle screen.
Dedicated keys
Set up,down,left and right key for any functions of you want.
Flight mode
Turn On/Off the Normal or Flight mode. If you select Flight mode, SIM
cards‟ function will not active.
Misc. settings
Set the brightness and time . LCD brightness settings are divided into
five level, the time can be set to any time between 5-60 seconds. When you
set the time interval without any operation, LCD backlight will turn black
light.
Security settings
Into the "Security Settings" menu, you can set the phone's security
options, mobile phone or SIM card to avoid unauthorized use.
SIM security
PIN lock
SIM card PIN password to lock the completion of your SIM card to
prevent unauthorized use. If the current SIM card lock is closed, select
Open to open the SIM card, enter the PIN lock password, the next boot
requires that you enter the correct PIN password to enter; If the current
SIM card lock is On, select Off to close the PIN lock protection.
Change PIN: If the current PIN password lock has been activated,
you can re-set on the PIN password
Change PIN2: PIN2 old to enter the correct password, you can set on
the PIN2 password.
Phone security
Phone lock: Phone lock password can prevent your mobile phone
stolen by others. Select On to open phone lock password to enter the
correct password-protected phone lock open, the next boot requires that
14
you enter the correct password to enter the phone lock.
Change password: Change the phone password, enter the old
password and then enter a new password. Phone default password is 0000.
Network settings
Network selection
Press the left soft key to select automatic or manual mode. Automatic,
mobile phone SIM card information is automatically selected according to
service provider; manually, choose manually select the network services,
mobile phone search to get the current list of service providers for users to
select the service provider SIM card type.
GPRS transfer pref.
Press the left soft key to select data prefer or call prefer.
Connectivity
Data accounts
For network access point may choose to modify settings.
Restore settings
In this menu, enter the password, once determined, the phone
automatically reboot the phone after the relevant parameters can be set to
return to the case of mobile phone factory. The default password is 0000.
Shortcuts
Shortcuts interface，Press LSK key into option，it display add、edit、
delete、delete all and change order.
Phonebook
You can use the phonebook to store recordes, can store the following:
name and phone number.In the phonebook list, select a record, to make a
call when you press the dial keys.Select a record in the phonebook, you
can do the following:
-View View the contact details or edit record.
15
-Send text message Send text message to this number.
-Call Make a call to the number.
-Edit Can edit and save record.
-Delete Delete the record.
-Copy Copy the current record to Phone/SIM.
-Add to Blacklist Save the number to phonebook black list.
-Mark several Mark several or all records can send text message or
delete.
-Phonbook settings:
-Preferred storage can be in the SIM, Phone and All to switch, and
phonebook list will change accordingly, such as select SIM, the phonebook
list will only show SIM records .
-Speed dial Open speed dial. If you long press number keys on the
dialing interface, you can call up.
-Extre numbers can be set SIM owner numbers and fixed dialing
numbers.
-Memory status View the usag and free Phonebook capacity
information.
-Copy contacts If select SIM to phone, the SIM card records of all
telephone numbers copied to the phone.
-Move contacts You can select the SIM records of all mobile
phone numbers move to the phone, also you can switch the option to
operate.
-Delete all contacts You can delete all contacts in SIM card or phone
and all records are deleted.
Fun
Games
Into this menu display game and games settings.
File manager
Into the File manager menu, the menu display Phone and Memory card.
Root directory, select "Phone", press the LSK to enter "Options" can be
as follows:
- Open Open the root directory lists the directories and files.
16
- Format Format the memory card, this action will remove all
current flash memory data.
Root directory, select “Memory Card”, press the LSK to enter
"Options" can be as follows:
-Open Open the root directory lists the directories and files.
-Format Format the memory card, this action will remove all current
flash memory data.
-Details more information you can view, such as Name, Total size,
free size.
You can paly the music or video files, view Photo, copy/move/delete
files, remame files and so on.You can send the file through Bluetooth.
Services
Internet service
In the internet service interface, it has includes the following items:
Homepage Log on homepage, you will find it is a WAP website that
you setted.user can set it by themselves.
Bookmarks It doesn‟t have default bookmarks. Users can add
bookmarks by themselves. You can go to relevant website conveniencly.
Search or input URL You can search or edit any website you want,
but it is effective.
Recent pages Display the recent pages.
Settings it includes following items to users to set: data account ,
browser options and preferences.
Data accout: Set the SIM cards‟ network.
Browser options: Including following operations.
Clear cookies: Select the clear cookies to clear cookies data.
Clear authentication info: To clear the authentication info
Preferences: Can modify web browser preferences, Including wait
time and display pictures.
Note: GPRS service requires network support, must be after the opening
and in a GPRS network coverage area, you can use GPRS services
SIM tool kit
17
STK, insert the SIM card, will show STK, if not insert the SIM card
does not display this menu.
Organizer
Calculator
Your phone provides you with the basic arithmetic operations can be a
function of the calculator, easy simple operation. Press the left soft key
"Clear", Press the right softkey "Back" to exit the calculator.
Note: This calculator has limited accuracy and rounding errors will be
generated, especially in addition to endless time. When the calculation of
range, the display area will use the letter "E" to represent.
Bluetooth
Power: Activate Bluetooth on or off the Bluetooth function.
Visibility: If set as On, other devices can search this Bluetooth device;
if set as Off, other devices can not search this Bluetooth device.
My device: Can search for nearby Bluetooth devices.
Search audio device: Free devices to search for near-free decoration,
such as Bluetooth headsets.
My name: The Bluetooth device name can be modified.
Advanced:
Audio path Set the sound path can be set to stay in the sound and go
hands-free cell phone devices. If set to go hands-free device, connected to
the phone, the sound will be automatically transferred to the handsfree
device.
Storage To receive the file will be automatically transferred to the
specified path, the path can be set as phone or memory card.
My address Display device Bluetooth physical address.
Calendar
Enter calendar sub-menu, the screen will show a calendar month, and
other background box with the current date marked.Press the up, down, left,
and right navigation keys to change the date, calendar information on the
screen will be updated accordingly. Press the left soft key "Options" option
to display the calendar menu, and content as follows:
18
Jump to date: quickly jump to a specified date.
Go to today: switch the current date that system setted.
Alarm
Five alarm can be set up (turned off the alarm is still valid).Select and
edit an alarm clock: Can edit the setting of alarm on / off, Time,
Snooze,Repeat ,Alarm tone and Alert type. You can choose to set to repeat:
Once,Everyday, Custom.
Torch
Select the on or off state to turn on or turn off the torch light.
19
FCC Regulations:
This mobile phone complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This mobile phone has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiated radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user„s authority to operate the
equipment.
RF Exposure Information (SAR)
This model phone meets the government‟s requirements for exposure to
radio waves.
This phone is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by the Federal
Communications Commission of the U.S. Government.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. *Tests for SAR are conducted using
standard operating positions accepted by the FCC with the phone
transmitting at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest certified power
20
level, the actual SAR level of the phone while operating can be well below
the maximum value. This is because the phone is designed to operate at
multiple power levels so as to use only the poser required to reach the
network. In general, the closer you are to a wireless base station antenna,
the lower the power output.
The highest SAR value for the model phone as reported to the FCC
when tested for use at the ear is 0.164W/kg and when worn on the body, as
described in this user guide, is 0.204W/kg (Body-worn measurements
differ among phone models, depending upon available enhancements and
FCC requirements.)
While there may be differences between the SAR levels of various
phones and at various positions, they all meet the government requirement.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
http://www.fcc.gov/oet/fccid after searching on FCC ID:
SG720150318M220.
For body worn operation, this phone has been tested and meets the FCC
RF exposure guidelines for use with an accessory that contains no metal
and the positions the handset a minimum of 1.0 cm from the body. Use
of other enhancements may not ensure compliance with FCC RF exposure
guidelines. If you do no t use a body-worn accessory and are not holding
the phone at the ear, position the handset a minimum of 1.0 cm from your
body when the phone is switched on.
