Haier US Appliance Solutions SBCA001 SBC with WiFi Transceiver User Manual and Intergration Instructons

Haier US Appliance Solutions, Inc. SBC with WiFi Transceiver and Intergration Instructons

User manual and Intergration Instructons

Haier US Appliance Solutions, Inc.
GE Appliance Park
4000 Buechel Bank Rd.
Louisville, KY 40225, United States
Regulatory Module Integration Instructions
This module has been granted modular approval for mobile applications. OEM integrators for host
products may use the module in their final products without additional FCC / IC (Industry Canada)
certification if they meet the following conditions. Otherwise, additional FCC / IC approvals must
be obtained.
The host product with the module installed must be evaluated for simultaneous
transmission requirements.
The users manual for the host product must clearly indicate the operating requirements
and conditions that must be observed to ensure compliance with current FCC / IC RF
exposure guidelines.
To comply with FCC / IC regulations limiting both maximum RF output power and human
exposure to RF radiation, the maximum antenna gain including cable loss in a mobile-
only exposure condition must not exceed 2dBi.
A label must be affixed to the outside of the host product with the following statements:
This device contains FCCID: ZKJ-SBCA001
This equipment contains equipment certified under ICID: 10229A-SBCA001
The final host / module combination may also need to be evaluated against the FCC Part 15B
criteria for unintentional radiators in order to be properly authorized for operation as a Part 15
digital device.
If the final host / module combination is intended for use as a portable device (see classifications
below) the host manufacturer is responsible for separate approvals for the SAR requirements
from FCC Part 2.1093 and RSS-102.
Device Classifications
Since host devices vary widely with design features and configurations module integrators shall
follow the guidelines below regarding device classification and simultaneous transmission, and
seek guidance from their preferred regulatory test lab to determine how regulatory guidelines will
impact the device compliance. Proactive management of the regulatory process will minimize
unexpected schedule delays and costs due to unplanned testing activities.
The module integrator must determine the minimum distance required between their host device
and the user’s body. The FCC provides device classification definitions to assist in making the
correct determination. Note that these classifications are guidelines only; strict adherence to a
device classification may not satisfy the regulatory requirement as near-body device design
details may vary widely. Your preferred test lab will be able to assist in determining the
appropriate device category for your host product and if a KDB or PBA must be submitted to the
FCC.
Note, the module you are using has been granted modular approval for mobile applications.
Portable applications may require further RF exposure (SAR) evaluations. It is also likely that the
host / module combination will need to undergo testing for FCC Part 15 regardless of the device
classification. Your preferred test lab will be able to assist in determining the exact tests which
are required on the host / module combination.
FCC Definitions
Portable: (§2.1093) — A portable device is defined as a transmitting device designed to be used
so that the radiating structure(s) of the device is / are within 20 centimeters of the body of the
user.
Mobile: (§2.1091) (b) — A mobile device is defined as a transmitting device designed to be used
in other than fixed locations and to generally be used in such a way that a separation distance of
at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and
the body of the user or nearby persons. Per §2.1091d(d)(4) In some cases (for example, modular
or desktop transmitters), the potential conditions of use of a device may not allow easy
classification of that device as either Mobile or Portable. In these cases, applicants are
responsible for determining minimum distances for compliance for the intended use and
installation of the device based on evaluation of either specific absorption rate (SAR), field
strength, or power density, whichever is most appropriate.
Simultaneous Transmission Evaluation
This module has not been evaluated or approved for simultaneous transmission as it is
impossible to determine the exact multi-transmission scenario that a host manufacturer may
choose. Any simultaneous transmission condition established through module integration into a
host product must be evaluated per the requirements in KDB447498D01(8) and
KDB616217D01,D03 (for laptop, notebook, netbook, and tablet applications).
These requirements include, but are not limited to:
Transmitters and modules certified for mobile or portable exposure conditions can be
incorporated in mobile host devices without further testing or certification when:
The closest separation among all simultaneous transmitting antennas is >20 cm,
Or
Antenna separation distance and MPE compliance requirements for ALL simultaneous
transmitting antennas have been specified in the application filing of at least one of the
certified transmitters within the host device. In addition, when transmitters certified for
portable use are incorporated in a mobile host device, the antenna(s) must be >5 cm
from all other simultaneous transmitting antennas.
All antennas in the final product must be at least 20 cm from users and nearby persons.
OEM Instruction Manual Content
Consistent with §2.909(a), the following text must be included within the user’s manual or
operator instruction guide for the final commercial product (OEM-specific content is displayed in
italics.)
Operating Requirements and Conditions:
The design of the GEA Single Board Computer (SBCA001) complies with U.S. Federal
Communications Commission (FCC) guidelines respecting safety levels of radio frequency (RF)
exposure for (OEM manufacturer to insert device classification: Mobile or Portable) devices.
FCC/IC ID:
This product contains FCCID: ZKJ-SBCA001
This product contains ICID: 10229A-SBCA001
Note: In the case where the Host / Module combination has been re-certified the FCCID shall
appear in the product manual as follows:
FCCID: ZKJ-SBCA001
ICID: 10229A-SBCA001
Mobile Device RF Exposure Statement (If Applicable):
RF Exposure - This device is only authorized for use in a mobile application. At least 20 cm of
separation distance between the GEA Single Board Computer (SBCA001) device and the
user's body must be maintained at all times.
Caution Statement for Modifications:
CAUTION: Any changes or modifications not expressly approved by Haier US Appliance
Solutions, Inc. could void the user’s authority to operate the equipment.
FCC Part 15 Statement (Only Include if FCC Part 15 is Required on the End Product):
Note: This equipment has been tested and found to comply with the limits for a (OEM to insert
device type: Class A or Class B) digital device, pursuant to Part 15 of the FCC Rules. (OEM must
follow Part 15 guidelines (§15.105 and §15.19) to determine additional statements required in this
section for their device class)
Note 2 : This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions.
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including interference that may cause
undesired operation.
a. That module is limited to OEM installation ONLY.
b. That OEM integrators are responsible for ensuring that the end-user has no manual
instructions to remove or install module.
c. That module is limited to installation in mobile or fixed applications, according to Part 2.1091(b).
d. That separate approval is required for all other operating configurations, including portable
configurations with respect to Part 2.1093 and different antenna configurations.
e. That grantee shall provide guidance to the host manufacturer for compliance with Part 15
subpart B requirements.
This device complies with Industry Canada’s license-exempt RSSs. Operation is subject to the
following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
Note 3: The user’s manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment. In cases where the
manual is provided only in a form other than paper, such as on a computer disk or over the
Internet, the information required by this section may be included in the manual in that alternative
form, provided the user can reasonably be expected to have the capability to access information
in that form.
Mentions Règlementaires
Déclaration de Conformité FCC/IC:
Cet appareil a été testé et déclaré conforme à la section 15 du règlement de la FCC ainsi qu’à la
norme RSS-210 édictée par le Ministère canadien des Sciences et de l’Industrie. Son
fonctionnement est soumis aux deux conditions suivantes:
(1) l’équipement concerné ne doit pas causer d’interférences dangereuses, et
(2) il doit accepter toute interférence reçue, y compris les interférences risquant d’engendrer un
fonctionnement indésirable.
Ce produit a été testé et déclaré conforme aux limitations prévues dans le cadre de la catégorie B
des appareils numériques défini par la section 15 du règlement de la FCC. Ces limitations sont
stipulées aux fins de garantir une protection raisonnable contre les interférences gênantes en
installation résidentielle. Cet équipement génère, utilise et diffuse des ondes radio, et s’il n’est
pas installé ni utilisé en conformité avec les instructions dont il fait l’objet, peut causer des
interférences gênantes avec les communications radio.
Cependant, nous ne pouvons vous garantir qu’une interférence ne se produira pas dans une
installation particulière. Si cet équipement produit des interferences graves lors de réceptions
radio ou télévisées qui peuvent être détectées en allumant et en éteignant l’équipement, vous
êtes invités à les supprimer de plusieurs manières suivantes:
• Réorientez ou déplacez l’antenne de réception.
• Augmentez la distance séparant l’équipement et le récepteur.
• Connectez l’équipement à un circuit différent de celui auquel le récepteur est connecté.
• Contactez votre revendeur ou un technicien radio/TV qualifié.
Avertissement FCC/IC:
Toutes modifications ou tous changements effectués sans l’accord exprès de la partie
responsable de la conformité aux normes pourraient contraindre l’utilisateur à ne plus utiliser son
équipement.
Exposition aux RF – Cet appareil ne peut qu’être utilisé pour des applications mobiles. Une
distance d’au moins 20 cm doit toujours séparer l’appareil et le corps de l’utilisateur.
