HangZhou XiongMai Technology XM-JPIDG1 SMART VIDEO DOORBELL User Manual 1
HangZhou XiongMai Technology CO., LTD SMART VIDEO DOORBELL 1
Users Manual
Warranty period:one year.
This warranty card is only for our company's products.
Warranty Card
3
SMART VIDEO DOORBELL
02.Device preparation
After the doorbell is installed, short-press the
bell button to wake the doorbell.(Figure 2)
Indicator Introduction
Blue light
always on
Startup
Blue light
flashes slowly
APP remote monitor
and setup
Red light
flashes slowly
Batter y lower power
User Manual
After opening it, please check whether the product is in
good condition or not; confirm whether the accessories
are complete as below.
Packing list
Machine
Screws Package *2
Appearance introduction
Before use, please be familiar with the interface
and button of the doorbell.
Notes: Long-press the RESET button for 5 seconds, loosen
it when hear the voice prompt "restore factory settings,
please don't power off". Then it can be restored to the factory
default configuration.
3.Device network configuration
User login
Open “iCSee”, sign up a new account and log in(Figure1）;
(Figure 1)
Click "sign up" and input the
corresponding information.
Notes: There is voice instruction throughout the process of
device configuration. After hearing the voice prompt "wait
to be configured", you can start configuring the device.
1.Device ready
Operation manual
First step: Install the backplane where you need to install
the doorbell. (Expansion screws need to be used on
cement and stone walls, wood screws or 3M glue can
be used on wooden walls.)
Second step: Install the doorbell body into the backplane.
Indicator
Front
Back
MIC
AC24V Charging port
Photosensitive
sensor
PIR Sensor
Bell button
Speaker
RESET button USB Charging port
Infrared fill Light
Camera
2.Download APP
Tips one: Scan QR code to download;
Tips two: Search and download “iCSee” in the Appstore
or Googleplay;
iCSee
(Figure 2)
04.Access device The video doorbell supports 32GB maximum TF card,
whic h will au to mat ica lly loo p reco rd ing whe n
it's fulfilled.
● After login successfully, click "Add My Camera"
(Figure 3), input “WiFi password” (Figure 4). Finish
the network configuration of the camera according
to the APP operation hint.
03.Add device
Why do people hover, but the doorbell did not
push the alarm?
Q:
Alarm push may be turned off, or user login the device
remotely already.
(Figure 3) (Figure 4)
Click to check if
the WiFi password
is right
05.Message push
W h e n a v i s i t o r p r e s s e s a b u t t o n o r a n a l a r m i s
generated, the device sends a message to the phone. You
can receive the message in the following two ways:
FAQ
How does the device store video?
How to fix the problem of device offline?
Check whether the device electricity is exhausted.
Reconfigure the device.
Check if the home network broadband is normal.
How to switch the network environment?
When used in a new network environment, please
long-press the RESET button for 3~5 seconds, loosen
it when hear the voice prompt "restore factory settings,
please don't power off". After reset successfully,
configure the network again.
Why does the device do not respond when press the
RESET button after startup?
Q:
It needs to wait 8 seconds to press the RESET button,
please wake the device startup via pressing the bell
button.
App and device firmware will have new update irregularly,you
could upgrade it online at app setting,instructions are for
reference only.
Directions
While using this product, please modify the user password.
Do not install the device in damp, dusty, children easy
access to the venue.
Please place it under the specified condition of temperature
and humidity, do not disassemble it at all.
Notice
Volume button
Indicator
Second step: Short-press the bell button of the Video
Doorbell; if the bell is ringing at the same time, the
configuration is successful.
4
2
1Add My Camera (recommended): Connect the device to the
router.
Add My Camera (AP mode): Connect the device to the router via
AP mode.
Add Shared Camera: Add a device that others share to you.Add
the camera via inputting the device serial number or sharing
information code or scanning device QR code.
5
4
3
2
1
5
Add device in the same WLAN: When the device and your smart
phone have been connected to the same router, you can use this
way to add the camera.
AP hotspot stand-alone mode: The device can also can view real-
time video, which does not need to connect to the external
network.
Notes: This device does not support the AP mode and
the AP hotspot stand-alone mode.
Fittings:
Wooden Screw *4
Click the"WeChat"icon
to set "WeChat shortcut
login".
After login success, you can use the mobile phone
access the device through the APP, The device has the
following states: 1.Receive the message via the APP
If you have Wechat ,You can use” WeChat shortcut login"
directly (Figure1）;
Offline
Dormancy
Deep
dormancy
Device or network failure;
The device does not suppor t remote wake-up
(or be set to prohibit remote wake-up),you can
p r e s s t h e b u t t o n f o r m a n u a l a w a k e n i n g
and access the device.
The device is in low-power mode state, it needs
to be awakened then access.
Online
Awaking
The device is being awakened
In this state, The mobile phone can make
various accesses to the device;
Set up in the device use
APP notification message.
Confirm the current
account.
06.Bell Device Configuration
If you buy a Bell Device, you can associate the Bell
Device with the Video Doorbell, and the bell device
will also ring when you press the bell button.
F i r s t s t e p : L o n g - p r e s s t h e v o l u m e b u t to n o f t h e
Bell Device until the indicator of the bell is no longer
flashing.
Log in APP with
WeChat
Set up in the device
use Wechat notification
message.
Search in WeChat and
flow the "ICSEE" official
Account.
2.Receive the message via WeChat.
notes：If the Mobile phone is set up to power saving mode, such as
screen off & network off , it will not receive the message in time, Since
android p h ones do no t agree on the def ault han dling of mes sage
intercep tions , it is recommend ed to use WeChat recei v e message
except the iPhone and Huawei phones.
notes：The device would only send the message to the account which
has the contact permission, please ensure that current account has
been assigned to the contact person.
Notes: If the configuration fails, reset the device.
FCC Statement
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
To assure continued compliance, any changes or modifications not
expressly approved by the party.
Responsible for compliance could void the user’s authority to operate
this equipment. (Example- use only shielded interface cables when
connecting to computer or peripheral devices).
This equipment complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
FCC Radiation Exposure Statement:
The equipment complies with FCC Radiation exposure limits set forth
for uncontrolled enviroment. This equipment should be installed and
operated with minimum distance 20cm between the radiator and your
body.
