Haojiehua Technology H20 Mini keyboard User Manual
Shenzhen Haojiehua Technology Co., Ltd. Mini keyboard
User Manual
VER: 1.3
Thank you for purchasing this mini keyboard. You can use it for emails, chat ,
remote control, message input and games . It is compatible with PC, Laptop ,Mac
OS, Linux, HTPC, IPTV, Google Android Smart TV Box, XBMC, Windows 2000 XP
/Vista/7/8/10.Use it with your Android box or smart TV on your sofa or browse
the internet in the most comfortable fashion.
Overview
Function Overview
Quick Start
- Plug the USB receiver into USB interface of host device(PC, laptop, smartTV etc)
- Turn on this touchpad by toggling the up side switch.
System Requirements
- HID compatible USB HOST device
- Window XP, Vista,7/8/10, Linux, Android OS (With standard USB interface)
Function Overview
-Touch Function (negative side): mouse function, including
The touch functions: mouse moving, left /right mouse button , screen scroll,
task switch
Atmosphere lamp adjustment.
(The coordinate axis of the touch panel rotates automatically depending on the grip.)
-Keyboard function(positive side):
Keyboard function which can supply the letter input.
Infrared emission & learning
Keys Descriptions
Shortcut key combinations:
a) “Fn” + “ ” : Enter Infrared learning status.(press any key to quit)
b) “Fn” + “ “ : Keyboard backlit adjustment.
Brightness is divided into high, medium, low, and close
In the keyboard mode(postive side), we can press the key “Fn“ +“ ” to learn the
infrare code. For the details of learning. Pls refer to the following steps.
1. Press the “Fn“ +“ ” and the led starts flashing to indicate that it has entered
the infrared learning status. If there is no any operation, it will exit the learning status
in 6 seconds.(press the any key can quit from learning status)
2. Close the infrared emitting diode of IR remote control to the top of this product
within 5cm.
3. Press and hold the IR key of remote control that needs to be learned. If the study is
IR Learning
3. Press and hold the IR key of remote control that needs to be learned. If the study is
successful, the led will keep bright for 2 second (Otherwise, please repeat step
3.)and product will quit from IR learning status automatically.
Notes:
1.Press the “Fn” and at the same time and hold them for over 3 seconds to
erase all stored infrared code and other configuration. The product will restore factory
defaults.
2. Only part of TV infrared codes can be learned.
This touchpad can support the following touch gestures.
Note: zoom in, zoom out and show desktop are valid only on windows 7 or above operating system.
Touch Gestures
- Drag and Drop:
As if you were clicking and holding the mouse button down while moving it. Perform a double tap
and move your finger. Release it when you’re done.
-Atmosphere lamp adjustment
Four fingers touch and hold for over 2 second to change the color of atmosphere.
The touch panel adjusts the touch direction automatically according to the user's
grip(similar to the auto-rotate function of a mobile phone). Please make sure that the
red LED lights in the top right corner before use. If not, please follow the figure
below(tilt the machine towards the body):
Auto-rotate Of Touch Panel
Indicators
Positive side:
- : It blinks slowly means product is in low voltage status and be on in charging
status.
- : It blinks fast means wireless part can not be connected(make sure the dongle is
plugged into usb port).
- : It keep on means the key is down.
- backlit(“Fn” + “ “ to adjust brightness)
Negative side:
-Atmosphere lamp : It breaths means that the product is working properly
- For power saving, the touchpad will enter into sleep mode when there is no any
operation in 3 minutes or there is wirelss disnnection in 10 seconds.
- There are three mathods to wake it up from sleep status:
Pick it up Tap it Press any key
-Atmosphere lamp : It breaths means that the product is working properly
: It blinks means that the product is working properly
-Touch direction led : There are four direction LEDs, but only one of them lights at a
time that indicates the direction of the coordinate axis of the touch panel.
Power Saving
- The extension usb cable can be used for charging. It can not be used for digital
connection.
- Re-pair: If the red LED flash fast , It means the product needs to be paired with usb-
receiver. As for how to pair, please try the following steps:
- Step1: Pull out the usb receiver and turn off the mini keyboard.
- Step2: press and hold the key “Fn” and “PgDn” at the same time, and then turn
it on. The top three leds flashing at the same time indicate the product is in re-
pair status. (you can release the keys now)
- Step3: Insert the usb receiver into your main device’s usb port and put the
Please Note
- Step3: Insert the usb receiver into your main device’s usb port and put the
remote closer to the receiver within 20cm. The red LED will be off in 1s which
means the pairing succeeds. If it fails for the first time, you need repeat Step1-3
again. (note: Please keep the keyboard full power before pairing.)
-About signal interference: specialling for android TV box and smart TV. Large size
monitor device always has some signal do not work as well . When you press
a, ”AAAAA …” will appear. In this case you can use the a extension cable to solve
it. Please plug USB receiver to the available port, then pair and use remote
keyboard.
- Receiver(dongle): Nano style
- Connection port: With USB2.0 or above
-Transmission mode: GFSK 2.4GHz wireless, up to 10 meters
-Transmission frequency : 2411-2476MHZ(16 channels)
-Transmission Power : Less than +4bd
- Power supply: Rechargeable polymer Lithium-ion battery
- Charging voltage: 4.4V-5.25V Charging current: 300mA
- Operating current: < 15mA(backlit off)
Specifications
- Operating current: < 15mA(backlit off)
- Sleeping current: < 100uA
- Net weight: 93g
- Size : 145*75*13.5mm
Warnings
- When charging finishes, pull out the charging cable.
- Never try to open or repair this product yourself.
- Keep this device away from fluids, such as water.
- Not attempt to disassemble the device or replace the rechargeable battery yourself.
- The battery will discharge when it is stored for a long time without operation.
- Use the specified charger. Disconnect the device when the battery is fully charged.
Maintenance
- Use the specified charger. Disconnect the device when the battery is fully charged.
- Overcharging will shorten the battery life.
Charging The Battery
- The device uses unremovable lithium-ion battery. Please use a cables with micro-
USB interface as charges.
Note: Fully charge the unit before initial operation. This device can be used when
charging. But charging time will be extended. When the battery is low, the led
will blink to warn the user. The unit will be automatically turned off if battery has
been depleted.
Always dispose the used appliance at a recycling center. Do not dispose
the used appliance together with the household waste.
Note:
Due to 2.4G wave technology adoption, the connection can be subject to
interference from obstacles, like wails, metals, or other electronic devices. Please keep
the space between the keyboard and USB receiver free of obstacle.
In line with the policy of continued development, the manufacturer reserves the right
to manual are for reference only. Please operate according to the real design.
Disposal
