Page 2 For technical questions, please call 1-800-444-3353. Item 95736

Specifications

Overall Assembled

Rack Dimensions 37"L x 11-1/4"W x 45-1/4"H

Small Bin Dimensions (32) 6-1/2"L x 4-1/8"W x 3"H

Large Bin Dimensions (15) 9-1/4"L x 6"W x 5”H

Maximum Weight Capacity Overall Parts Rack: 171 Lb.

Large Bin: 5 Lb. each

Small Bin: 3 Lb. each

IMPORTANT SAFETY INFORMATION

Assembly Precautions

1. Assemble only according to these instructions.

Improper assembly can create hazards.

2. Wear ANSI-approved safety goggles and

heavy-duty work gloves during assembly.

3. Keep assembly area clean and well lit.

4. Keep bystanders out of the area during assembly.

5. Do not assemble when tired or when under the

influence of alcohol, drugs or medication.

6. Weight capacity and other product capabilities apply

to properly and completely assembled product only.

7. Stay alert. Watch what you are

doing and use common sense during

assembly and use of this product.

8. During assembly dress properly. Do not wear

loose clothing or jewelry. Contain long hair.

9. Do not overreach. Keep proper

footing and balance at all times.

Page 3For technical questions, please call 1-800-444-3353.Item 95736

Use Precautions

1. This product is not a toy. Do not allow

children to play with or near this item.

2. Use as intended only.

3. Inspect before every use; do not use

if parts are loose or damaged.

4. Do not exceed listed weight capacity.

5. Maintain product labels and nameplates.

These carry important safety information.

If unreadable or missing, contact

Harbor Freight Tools for a replacement.

6. Do not force the product. Use the correct product

for your application. The correct product will do

the job better and safer at the rate for which it is

designed. Do not force the product and do not

use it for a purpose for which it is not intended.

7. Locate the Parts Rack out of reach of children

and other untrained persons. The Parts Rack is

designed to hold small parts which can be easily

swallowed by small children. Keep children away.

8. Maintain this product with care.

9. Use only accessories that are recommended by

the manufacturer for your model. Accessories

that may be suitable for one product may become

hazardous when used on another product.

10. Use on a flat, level surface capable of

supporting the Parts Rack and its contents.

11. Load hardware evenly. As much as

possible, distribute the weight of all materials

stored in this Parts Rack evenly.

12. Do not use this Parts Rack as a stepping stool or

ladder. Never sit, stand, or climb on this Parts Rack.

13. Do not overload or over-stack this Parts Rack.

Overloading can damage bins and could possibly

result in tipping and personal injury. Over-

stacking can result in tools or other objects

sliding or falling from the Parts Rack and could

result in damaged tools and/or personal injury.

SAVE THESE INSTRUCTIONS.

Page 4 For technical questions, please call 1-800-444-3353. Item 95736

Assembly Instructions

Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this document

including all text under subheadings therein before set up or use of this product.

Note: For additional information regarding the parts listed in the following

pages, refer to Parts List and Assembly Diagram on page 6.

1. Attach ends of Hanging Bars (4) to left Column (2).

Secure with Bolts (5) and Nuts (8). Attach other ends

to right Column. Secure with Bolts (5) and Nuts (8).

(See Figure A.)

Column

(2)

Hanging

Bar (4)

Bolts

(5)

Figure A

2. Attach Hanging Bar Support (7) to center of Hanging

Bars. Secure with Bolts (6). (See Figure B.)

Hanging Bar

Support (7)

Bolt

(6)

Figure B

3. Secure one Column Support (3) to each Column

with Bolts (9) and Spring Washers (11).

4. Secure Columns to Bottom Plate (10) with

Bolts (9) and Spring Washers (11).

5. Secure Column Supports to Bottom Plate with Bolts

(9) and Spring Washers (11). (See Figure C.)

Column

Support

(3)

Bolt

(9) and

Spring

Washer

(11)

Column

(2)

Bolt

(9) and

Spring

Washer

(11)

Bottom

Plate

(10)

Figure C

6. Secure Top Cover (1) to Columns with

Bolts (9) and Spring Washers (11).

7. Arrange Bins as desired. Slide Bin Lip over

Hanging Bar, making certain Bin is

securely in place. (See Figure D.)

Hanging

Bar

Bin

Lip

.

Figure D

8. Set up the Parts Rack in desired location. Make

certain it is on a flat, even and stable surface

capable of supporting rated weight capacity.

9. Fill Bins as desired.

Page 5For technical questions, please call 1-800-444-3353.Item 95736

Maintenance

Cleaning

1. Clean the Floor Rack with a damp cloth. Do not use abrasives, harsh chemicals

or detergents as these will scratch and damage the Bins and frame.

PLEASE READ THE FOLLOWING CAREFULLY

THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM

IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR

MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS

QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE

ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY

STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND

LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY

ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS

THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.

Page 6 For technical questions, please call 1-800-444-3353. Item 95736

Parts List and Assembly Diagram

Parts List

Part Description Qty

1 Top Cover 1

2 Column 2

3 Column Support 2

4 Hanging Bar 7

5 Bolt (M4x8) 28

6 Bolt (M4x16) 7

7 Hanging Bar Support 1

Part Description Qty

8 Nut (M4) 28

9 Bolt (M4x14) 12

10 Bottom Plate 1

11 Spring Washer 12

12 Small Bin 32

13 Large Bin (not shown) 15

Record Serial Number Here:

Note: If product has no serial number, record month and year of purchase instead.

Note: Some parts are listed and shown for illustration purposes only, and

are not available individually as replacement parts.

Page 7For technical questions, please call 1-800-444-3353.Item 95736

Assembly Diagram

9

11

1

5

3

2

4

8

6

7

10

12

911

9

11

9

11

9

11
