9.6 VOLT CORDLESS
VARIABLE SPEED
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright© 2012 by Harbor Freight Tools®� All rights reserved�
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools�
Diagrams within this manual may not be drawn proportionally� Due to continuing
improvements, actual product may differ slightly from the product
described herein� Tools required for assembly and service may not be included�
When unpacking, make sure that the product is intact
and undamaged� If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible�
Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures� Write the product’s serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number)�
Keep this manual and the receipt in a safe and dry place for future reference�
Owner’s Manual & Safety Instructions
REV 14i
![](asset-2.png)
Page 2 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Table of Contents
Safety �������������������������������������������������2
Specifications �������������������������������������8
Setup ��������������������������������������������������8
Operation ��������������������������������������������9
Maintenance ��������������������������������������13
Parts List and Diagram ����������������������15
Warranty ��������������������������������������������16
WARNING SYMBOLS AND DEFINITIONS
This is the safety alert symbol� It is used to alert you to
potential personal injury hazards� Obey all safety messages
that follow this symbol to avoid possible injury or death�
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury�
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury�
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury�
Addresses practices not related to personal injury�
IMPORTANT SAFETY INFORMATION
General Power Tool Safety Warnings
Read all safety warnings and instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term ″power tool″ in the warnings refers to your battery-operated (cordless) power tool.
Work area safety
1� Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
2� Do not operate power tools in
explosive atmospheres, such as in the
presence of flammable liquids, gases
or dust. Power tools create sparks
which may ignite the dust or fumes.
3� Keep children and bystanders
away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of electric shock.
![](asset-3.png)
Page 3For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
Personal safety
1� Stay alert, watch what you are doing
and use common sense when operating
a power tool. Do not use a power
tool while you are tired or under the
influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
2� Use personal protective equipment.
Always wear eye protection.
Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or
hearing protection used for appropriate
conditions will reduce personal injuries.
3� Prevent unintentional starting.
Ensure the Switch is in the off-position
before connecting to power source, picking
up or carrying the tool.
Carrying power tools with your finger on
the Switch or energizing power tools that
have the Switch on invites accidents.
4� Do not overreach. Keep proper
footing and balance at all times.
This enables better control of the power
tool in unexpected situations.
5� Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing
and gloves away from moving parts.
Loose clothes, jewelry or long hair
can be caught in moving parts.
6� If devices are provided for the connection
of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of these devices
can reduce dust-related hazards.
7� Only use safety equipment
that has been approved by an
appropriate standards agency.
Unapproved safety equipment may
not provide adequate protection.
Eye protection must be ANSI-approved and
breathing protection must be NIOSH-approved
for the specific hazards in the work area.
Power tool use and care
1� Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job better
and safer at the rate for which it was designed.
2� Do not use the power tool if the Switch
does not turn it on and off.
Any power tool that cannot be controlled with
the Switch is dangerous and must be repaired.
3� Disconnect the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
4� Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power tool
or these instructions to operate the
power tool. Power tools are dangerous
in the hands of untrained users.
5� Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many accidents
are caused by poorly maintained power tools.
6� Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to
bind and are easier to control.
7� Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to
be performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
![](asset-4.png)
Page 4 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Battery tool use and care
1� Recharge only with the charger
specified by the manufacturer. A
charger that is suitable for one type of
battery pack may create a risk of fire
when used with another battery pack.
2� Use power tools only with specifically
designated battery packs. Use
of any other battery packs may
create a risk of injury and fire.
3� When battery pack is not in use, keep
it away from other metal objects, like
paper clips, coins, keys, nails, screws
or other small metal objects, that can
make a connection from one terminal
to another. Shorting the battery terminals
together may cause burns or a fire.
4� Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact accidentally
occurs, flush with water. If liquid
contacts eyes, additionally seek
medical help. Liquid ejected from the
battery may cause irritation or burns.
Service
Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
Safety Warnings Common for Grinding, Sanding,
Wire Brushing, or Polishing Operations
1� This power tool is intended to function as
a grinder, sander, wire brush, or polisher.
Read all safety warnings, instructions,
illustrations and specifications
provided with this power tool.
Failure to follow all instructions
listed below may result in electric
shock, fire and/or serious injury�
2� Use as intended only. Operations for
which the power tool was not designed may
create a hazard and cause personal injury�
3� Do not use accessories which are not
specifically designed and recommended
by the tool manufacturer. Just because
the accessory can be attached to your
power tool, it does not assure safe operation�
4� The rated speed of the accessory
must be at least equal to the maximum
speed marked on the power tool.
Accessories running faster than their
RATED SPEED can break and fly apart�
5� The outside diameter and the thickness
of your accessory must be within the
capacity rating of your power tool.
Incorrectly sized accessories cannot be
adequately guarded or controlled�
6� The arbor size of wheels, flanges, backing
pads or any other accessory must
properly fit the collet of the power tool.
Accessories with arbor holes that do not
match the mounting hardware of the power
tool will run out of balance, vibrate excessively
and may cause loss of control�
7� Do not use a damaged accessory.
Before each use inspect the accessory
such as abrasive wheels for chips and
cracks, backing pad for cracks, tear or
excess wear, wire brush for loose or
cracked wires. If power tool or accessory
is dropped, inspect for damage or install
an undamaged accessory. After inspecting
and installing an accessory, position
yourself and bystanders away from the
plane of the rotating accessory and run
the power tool at maximum no-load speed
for one minute. Damaged accessories will
normally break apart during this test time�
8� Wear personal protective equipment.
Depending on application, use face
shield, safety goggles or safety glasses.
As appropriate, wear dust mask, hearing
protectors, gloves and workshop apron
capable of stopping small abrasive or
![](asset-5.png)
Page 5For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
workpiece fragments. The eye protection
must be capable of stopping flying debris
generated by various operations.
The eye protection must be capable of
stopping flying debris generated by various
operations� The dust mask or respirator must
be capable of filtering out particles generated
by your operation� Prolonged exposure to
high intensity noise may cause hearing loss�
9� Keep bystanders a safe distance away
from work area. Anyone entering the
work area must wear personal protective
equipment. Fragments of workpiece or of a
broken accessory may fly away and cause
injury beyond immediate area of operation�
10� Hold power tool by insulated gripping
surfaces only, when performing an
operation where the accessory may
contact hidden wiring or its own cord.
An accessory contacting a ″live″ wire may
make exposed metal parts of the power
tool ″live″ and shock the operator.
11� Never lay the power tool down until the
accessory has come to a complete stop.
The spinning accessory may grab the surface
and pull the power tool out of your control.
12� Do not run the power tool while carrying
it at your side. Accidental contact with the
spinning accessory could snag your clothing,
pulling the accessory into your body.
13� Regularly clean the power tool’s air vents.
The motor’s fan will draw the dust inside
the housing and excessive accumulation of
powdered metal may cause electrical hazards.
14� Do not operate the power tool
near flammable materials.
Sparks could ignite these materials.
15� Do not use accessories that require
liquid coolants. Using water or other liquid
coolants may result in electrocution or shock.
16� Maintain labels and nameplates on the tool�
These carry important safety information�
If unreadable or missing, contact
Harbor Freight Tools for a replacement�
17� Avoid unintentional starting�
Prepare to begin work before
turning on the tool�
18� Do not depress the spindle lock when
starting or during operation�
19� Do not leave the tool unattended when the
Battery Pack is connected� Turn off the tool,
and remove the Battery Pack before leaving�
20� The battery Charger gets hot
during use� The Charger’s heat
can build up to unsafe levels
and create a fire hazard if it
does not receive adequate
ventilation, due to an electrical fault, or if it is
used in a hot environment�
Do not place the Charger on a flammable
surface� Do not obstruct any vents on the
Charger� Especially avoid placing the
Charger on carpets and rugs; they are not
only flammable, but they also obstruct
vents under the Charger.
Place the Charger on a stable, solid,
nonflammable surface (such as a stable metal
workbench or concrete floor) at least 1 foot
away from all flammable objects, such as
drapes or walls� Keep a fire extinguisher and
a smoke detector in the area�
Frequently monitor the Charger and
Battery Pack while charging�
21� This product is not a toy�
Keep it out of reach of children�
22� People with pacemakers should
consult their physician(s) before use�
Electromagnetic fields in close proximity to
heart pacemaker could cause pacemaker
interference or pacemaker failure�
23� WARNING: The cord of this product contains
lead and/or di (2-ethylhexyl) phthalate
(DEHP), chemicals known to the State
of California to cause cancer, and birth
defects or other reproductive harm� Wash
hands after handling� (California Health
& Safety Code § 25249�5, et seq.)
24� The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur�
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator�
![](asset-6.png)
Page 6 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Safety Warnings Specific for Grinding and
Abrasive Cutting-off Operations
1� Use only wheel types that are
recommended for your power tool and
the specific guard designed for the
selected wheel. Wheels for which the
power tool was not designed cannot be
adequately guarded and are unsafe.
2� Wheels must be used only for
recommended applications. For example:
do not grind with the side of cut-off wheel.
Abrasive cut-off wheels are intended for
peripheral grinding, side forces applied to
these wheels may cause them to shatter.
3� Always use undamaged wheel flanges
that are of correct size and shape for your
selected wheel. Proper wheel flanges support
the wheel thus reducing the possibility of
wheel breakage. Flanges for cut-off wheels
may be different from grinding wheel flanges.
4� Do not use worn down wheels from larger
power tools. Wheel intended for larger
power tool is not suitable for the higher
speed of a smaller tool and may burst.
5� Dress appropriately.
Do not wear pants with cuffs,
shirts with open pockets, or any clothing that
can catch and hold molten metal or sparks.
Safety Warnings Specific for Wire Brushing Operations
Be aware that wire bristles are thrown by the brush even during ordinary operation.
Do not overstress the wires by applying excessive load to the brush.
The wire bristles can easily penetrate light clothing and/or skin.
Vibration Safety
This tool vibrates during use� Repeated or
long-term exposure to vibration may cause
temporary or permanent physical injury,
particularly to the hands, arms and shoulders�
To reduce the risk of vibration-related injury:
1� Anyone using vibrating tools regularly or for
an extended period should first be examined
by a doctor and then have regular medical
check-ups to ensure medical problems are
not being caused or worsened from use�
Pregnant women or people who have impaired
blood circulation to the hand, past hand
injuries, nervous system disorders, diabetes,
or Raynaud’s Disease should not use this
tool� If you feel any medical or physical
symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible�
2� Do not smoke during use� Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury�
3� Wear suitable gloves to reduce the
vibration effects on the user�
4� Use tools with the lowest vibration when there
is a choice between different processes�
5� Include vibration-free periods
each day of work�
6� Grip tool as lightly as possible
(while still keeping safe control of it)�
Let the tool do the work�
7� To reduce vibration, maintain the tool as
explained in this manual� If any abnormal
vibration occurs, stop use immediately�
SAVE THESE INSTRUCTIONS.
![](asset-7.png)
Page 7For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
Grounding
TO PREVENT ELECTRIC SHOCK AND DEATH FROM
INCORRECT GROUNDING WIRE CONNECTION:
Check with a qualified electrician if you are in doubt as to whether the outlet is
properly grounded. Do not modify the power cord plug provided with the tool.
Never remove the grounding prong from the plug. Do not use the tool if the power cord or plug
is damaged. If damaged, have it repaired by a service facility before use. If the plug will not fit
the outlet, have a proper outlet installed by a qualified electrician.
Double Insulated Tools: Tools with Two Prong Plugs
Figure A: Outlets for 2-Prong Plug
1� Tools marked “Double Insulated” do not
require grounding� They have a special
double insulation system which satisfies OSHA
requirements and complies with the applicable
standards of Underwriters Laboratories, Inc�,
the Canadian Standard Association,
and the National Electrical Code�
2� Double insulated tools may be used in
either of the 120 volt outlets shown in the
preceding illustration� (See Figure A.)
Extension Cords
Note: Extension cords must not be used with this item’s Charger�
Symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc�
VAC Volts Alternating Current
AAmperes
n0 xxxx/min. No Load Revolutions per Minute (RPM)
WARNING marking concerning Risk
of Eye Injury� Wear ANSI-approved
safety goggles with side shields�
Read the manual before
set-up and/or use�
WARNING marking
concerning Risk of Fire�
Do not cover ventilation ducts�
Charge on fireproof surface only�
WARNING marking concerning
Risk of Electric Shock�
Properly connect Charger’s power
cord to appropriate outlet�
WARNING marking concerning
Risk of Explosion�
Do not puncture, short, or open
battery packs and do not charge
damaged battery packs�
![](asset-8.png)
Page 8 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Specifications
Battery Pack 9�6V NiCd
Charge Adapter 120 VAC to 12 VDC
Tool Speed 5,000 - 25,000 RPM
LED Source (2) CR927 3V batteries
Setup - Before Use:
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
Functions
Charge
Base
AC
Transformer
LED
Collar
Cutoff
Discs
Drill Bits Buffing
Mandrel
Diamond
Burrs
Grinding
Stones
Flexible
Shaft
Wrench
Sanding
Drum
Buffing
Wheels
Stone
Dresser
Disc
Mandrel
Spare
Collet
Collet
Spindle
Lock
Speed
Control
Battery
Pack
![](asset-9.png)
Page 9For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
Operating Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section
at the beginning of this manual including all text under
subheadings therein before set up or use of this product.
TOOL SET UP
Battery Charging
Charging the Battery Pack
Battery packs are normally shipped with low or
no charge to prevent potential problems during
shipment� Charge the battery pack before use�
Note: Batteries will not reach full charge the
first time they are charged� Allow several
cycles (operation followed by recharging)
before the battery will become fully charged�
WARNING! Battery explosion may cause serious
personal or property injury including death�
Charge the battery only within a 50° to 100° F
room temperature� Lower temperatures
may inhibit charging� Higher temperatures
increase chance of battery failure�
1� Charge the battery pack only with the included
Charger Base (25)� Use of other chargers
may cause battery failure including explosion�
2� Ensure that the Charger Base (25) is
connected to a circuit breaker protected
120 VAC, 60 Hz power supply only�
3� Plug Charger Base cord into
Transformer cord� Plug the Transformer
into a 120 VAC wall outlet�
4� Insert the battery pack into the
Charger Base (25) by aligning
the ribs on the Charger Base with
the grooves in the battery pack�
Press the battery pack into place�
5� Press down on the battery pack to make sure
that the contacts on the battery pack are fully
engaged with the contacts in the charger unit�
6� While being charged, the green LED will be lit,
indicating that the charger is in operation�
During recharging, the battery pack
will become slightly warm to the touch�
This is normal and not a cause for concern�
7� Do not place the battery and charger in
an environment of extreme heat or cold�
They will work best at room temperature�
Note: The Charger Base (25) will not shut off
automatically. When the battery is fully charged
(after 3 to 5 hours), unplug the battery charger
and remove the battery pack� Do not leave the
battery in the Charger Base (25) indefinitely�
![](asset-a.png)
Page 10 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Installing the Battery Pack
1� Place the battery pack in the tool,
aligning the arrows on the battery
pack with the arrows on the tool�
2� Press the battery pack into the tool�
Make sure that the battery pack snaps
into place, and that the battery pack is
secure in the tool before beginning use�
Removing the Battery Pack
1� Press the Release Tabs (19) on
both sides of the battery pack to
release the battery from the tool�
2� Remove the battery pack from the
tool by pulling straight out�
Inserting a Bit in the Tool
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off, wait for the motor to stop, and remove
the battery pack before adjusting tool or installing accessories.
TO PREVENT SERIOUS INJURY FROM ACCESSORY FAILURE:
Only use accessories that are rated at or above the RPM rating of the Cordless Rotary Tool.
1� Depress the Spindle Lock (10)�
Rotate collet until shaft is engaged by the lock�
2� Loosen the Collet Nut (1) by turning it
counterclockwise, using the Wrench provided�
WARNING! If you are changing a bit immediately
after use, be careful not to touch the bit� It may
be very hot from use, possibly causing injury�
Allow the bit time to cool before handling it�
3� To remove a bit: Pull the bit straight out
of the Collet once the Collet Nut is loose�
To insert a bit: Insert the shank end if the bit
into the Collet once the Collet Nut is loose�
Collet Nut Collets
NOTE: Your tool is provided with two collets,
1/8″ and 3/32″ diameter. These are precision
manufactured to fit comparably sized bits�
Do not force a bit into the wrong sized collet, and
do not modify a mismatched collet or bit�
Severe personal or property damage may
result from using mismatched collets or bits.
4� Tighten Collet Nut securely using the
provided wrench� Ensure that the spindle
lock is released before turning on the tool�
![](asset-b.png)
Page 11For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
Installing the Flexible Shaft
1� Turn the Rotary Tool OFF (the “O” position),
and remove the Battery from
the Handle before attaching the
Flexible Shaft Attachment (26)�
2� Remove any bits that might be installed�
Remove the Collet Lock Nut and the Collet�
3� Remove the Collar or LED Collar from the
tool Body by turning it counterclockwise�
4� Pass the end of the Flexible Shaft Core
through the Collet Nut, and into the 1/8″ Collet.
Depress the Spindle Lock (10), and
hold it down while tightening the
Collet Nut with the Wrench�
5� When the Collet Nut is tight, release
the Spindle Lock (10) and turn the
Flexible Shaft Attaching Nut clockwise
onto the tool body until hand tight�
Installing a Bit in the Flexible Shaft
1� Use the Round “L” Tool to prevent the Flexible
Shaft Core from turning by inserting it into the
hole in the side of the Flexible Shaft Handle�
2� Once “L” tool is in place, remove
the Collet locking nut by turning it
counterclockwise with the Wrench�
3� Place the bit into the appropriate sized collet�
4� Place the collet into the end of
the Flexible Shaft Handle�
5� Place the Collet Locking Nut over the bit,
and tighten it by turning clockwise�
6� Tighten in place using the Wrench
and the Round “L” Tool�
Wrench
“L” Tool
Loosen
Tighten
Installing or Removing Collars
The Front Collar (3) is interchangeable
with the LED Collar (23)�
1� Remove the previous collar by
turning counterclockwise�
2� Install the LED Collar or standard
collar by turning clockwise�
Note: When installing or removing, use only
hand pressure and tighten firmly by hand�
Do not overtighten, as this may damage the part�
![](asset-c.png)
Page 12 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
WORKPIECE AND WORK AREA SET UP
1� Designate a work area that is clean
and well-lit� The work area must not
allow access by children or pets to
prevent distraction and injury�
2� Route the power cord along a safe route
to reach the work area without creating a
tripping hazard or exposing the power cord
to possible damage� The power cord must
reach the work area with enough extra length
to allow free movement while working�
3� Secure loose workpieces using
a vise or clamps (not included)
to prevent movement while working�
4� There must not be objects,
such as utility lines, nearby that will
present a hazard while working�
GENERAL OPERATING INSTRUCTIONS
1� Charge the Battery Pack (18) and insert it in
the tool, as described in the previous section�
2� Select an appropriate bit or attachment
for the job� Insert the bit or attachment
as described in the previous section�
3� The LED Collar may be turned on by
moving the switch on the collar�
4� Rotate the Switch (8) to the ON position�
This is a variable speed switch� The tool
bit speed is dependent on the position of
the Switch� Use a speed appropriate to
the bit and the material being worked on�
In general, harder materials require faster
speeds and softer materials require slower
speeds� Relative speeds are indicated
by the numbers on the Switch�
5� Apply the tool bit to the work
material as needed�
6� When the task has been completed, stop the
tool by rotating the Switch (8) to the OFF (“O”)
position� If the LED Collar is ON, switch it OFF�
Unplug the rechargeable battery�
Remove the bit or attachment as
discussed in the previous section�
7� Store the tool, its battery, and its bits and
attachments in their case in a safe location�
![](asset-d.png)
Page 13For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn the Power Switch of the tool off and remove the battery pack before
performing any inspection, maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY FROM TOOL FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
Cleaning, Maintenance, and Lubrication
1� BEFORE EACH USE, inspect the general
condition of the tool� Check for:
• loose hardware,
• misalignment or binding of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation�
2� AFTER USE, wipe external surfaces
of the tool with clean cloth�
3� Protect the tool and its parts and
accessories from moisture and humidity�
4� Some of the bits provided are “grinding bits”
using stone abrasives� During use, these
may clog up with removed material or
lose their shape� To clean and reshape
these bits, run them against the provided
Dressing Stone� The Dressing Stone will
abrade away the clogging materials and will
reshape the Grinding Bits as appropriate�
5� NiCd BATTERY MUST BE RECYCLED
OR DISPOSED OF PROPERLY�
Do not short, incinerate or open battery�
6� Dispose of used batteries properly�
Consult your local hazardous waste
authority for disposal guidelines�
7� To change the batteries in the LED Collar:
a� Remove it from the Rotary Tool�
b� Using a cross head screwdriver, open the
battery compartment�
c� Replace the batteries with the same type as
originally installed (Two CR-927, 3V
batteries)� Be sure to match the polarity
marking in the battery compartment�
![](asset-e.png)
Page 14 For technical questions, please call 1-888-866-5797. Item 69336
SAFETY OPERATION MAINTENANCESETUP
Troubleshooting
Problem Possible Causes Likely Solutions
Tool will not start� 1� Cord not connected�
2� No power at outlet�
3� Internal damage or wear�
(Carbon brushes or
switch, for example�)
1� Check that cord is plugged in�
2� Check power at outlet� If outlet is unpowered,
turn off tool and check circuit breaker�
If breaker is tripped, make sure circuit is right
capacity for tool and circuit has no other loads�
3� Have technician service tool�
Performance
decreases
over time�
1� Accessory dull
or damaged�
2� Carbon brushes
worn or damaged�
1� Keep cutting accessories sharp�
Replace as needed�
2� Have qualified technician replace brushes�
Excessive noise
or rattling�
Internal damage or wear�
(Carbon brushes or
bearings, for example�)
Have technician service tool�
Overheating� 1� Forcing tool to
work too fast�
2� Accessory dull
or damaged�
3� Blocked motor
housing vents�
1� Allow tool to work at its own rate�
2� Keep cutting accessories sharp�
Replace as needed�
3� Wear ANSI-approved safety goggles and
NIOSH-approved dust mask/respirator while
blowing dust out of motor using compressed air�
Follow all safety precautions whenever diagnosing or servicing the tool.
Disconnect power supply before service.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY� NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT� IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER� THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO�
![](asset-f.png)
Page 15For technical questions, please call 1-888-866-5797.Item 69336
SAFETYOPERATIONMAINTENANCE SETUP
819
18
12 17
21
22
20
2
3
413 14
15
6
7
910
11
516
1
Part Description
1 Collet nut
2 Collet
3 Front end nut
4 Driver shaft
5 Bearing
6 Sleeve
7 Motor
8 Switch
9 Shaft lock spring
Part Description
10 Shaft lock Button
11 Left cover
12 Left mark
13 Rubber buffer
14 Right cover
15 Screw
16 Right mark
17 Battery cover
18 Battery
Part Description
19 Release tab
20 Back moving spring
21 End cover
22 Hanger
23 LED Collar*
24 Transformer*
25 Charger Base*
26 Flexible Shaft*
*Not shown.
Parts List and Diagram
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead�
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts�
![](asset-10.png)
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797
Limited 90 Day Warranty
Harbor Freight Tools Co� makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase� This
warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or
accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance� We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product� Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to
you� THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS�
To take advantage of this warranty, the product or part must be returned to us with
transportation charges prepaid� Proof of purchase date and an explanation of the complaint
must accompany the merchandise� If our inspection verifies the defect, we will either repair or
replace the product at our election or we may elect to refund the purchase price if we cannot
readily and quickly provide you with a replacement� We will return repaired products at our
expense, but if we determine there is no defect, or that the defect resulted from causes not
within the scope of our warranty, then you must bear the cost of returning the product�
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state�
