ITEM 97576

6-PIECE A/C &

FUEL LINE QUICK

DISCONNECT SET

WARNING

To prevent serious injury:

Wear ANSI-approved safety goggles and heavy-duty 1.

work gloves during use.

Relieve line pressure before use.2.

Service of air conditioning systems must be done 3.

only by trained and experienced technician.

Technicians opening refrigeration circuit in 4.

automotive air conditioning systems MUST be

certied in refrigerant recovery and recycling

procedures in compliance with section 609 of Clean

Air Act Amendments of 1990.

Inspect before use; do not use if parts loose or 5.

damaged.

Use for intended purposes only.6.

Read vehicle service manual before use.7.

Includes: 7/8”, 3/4”, 5/8” 1/2”, 3/8” and

5/16” Sizes

08a SAVE THESE WARNINGS. Made in China.

INSTRUCTIONS:

1. Select the correct size connector by matching

tool’s inner lip to diameter of spring or open side of

tting.

2. Slip connector over line with inner lip facing spring

or open line tting. See Fig. A, above. Press inner

lip of connector into line tting until it “clicks” into

place as line releases.

3. Disconnect the line sections. To reconnect, push

line ttings together. See Fig. B, below.

Fitting

Inner Lip

Figure A

Figure B
