Owner’s Manual & Safety Instructions

Save This Manual Keep this manual for the safety warnings and precautions, assembly,

operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the

back of the manual near the assembly diagram (or month and year of purchase if product has no number).

Keep this manual and the receipt in a safe and dry place for future reference.

When unpacking, make sure that the product is intact

and undamaged. If any parts are missing or broken,

please call 1-888-866-5797 as soon as possible.

Copyright© 2008 by Harbor Freight Tools®. All rights reserved.

No portion of this manual or any artwork contained herein may be reproduced in

any shape or form without the express written consent of Harbor Freight Tools.

Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein.

Tools required for assembly and service may not be included.

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

Visit our website at: http://www.harborfreight.com

Email our technical support at: productsupport@harborfreight.com

REV 14e

Table of Contents

1. Safety Precautions and Warnings.......................................1

2. General Information ............................................................2

2.1 On-Board Diagnostics (OBD) II...............................2

2.2 Diagnostic Trouble Codes (DTCs) ...........................2

2.3 Location of the Data Link Connector (DLC)..........3

2.4 OBD II Readiness Monitors .....................................4

2.5 OBD II Monitor Readiness Status ...........................5

2.6 OBD II Definitions.....................................................6

3. Using the Code Reader.........................................................8

3.1 Tool Description ........................................................8

3.2 Specifications .............................................................9

3.3 Accessories Included .................................................9

3.4 Navigation Characters ..............................................9

3.5 Vehicle Power.............................................................9

3.6 Product Setup...........................................................10

3.7 Vehicle Coverage .....................................................13

4. OBD II Diagnostics.............................................................14

4.1 Reading Codes .........................................................15

4.2 Erasing Codes ..........................................................16

4.3 Viewing Freeze Frame Data ...................................17

4.4 Retrieving I/M Readiness Status............................19

4.5 Viewing Vehicle Information..................................22

4.6 Exiting OBDII Test .................................................23

5. Warranty and Service ........................................................25

1

1. Safety Precautions and Warnings

To prevent personal injury or damage to vehicles and/or the code

reader, read this instruction manual first and observe the

following safety precautions at a minimum whenever working on

a vehicle:

z Always perform automotive testing in a safe environment.

z Wear safety eye protection that meets ANSI standards.

z Keep clothing, hair, hands, tools, test equipment, etc. away from

all moving or hot engine parts.

z Operate the vehicle in a well ventilated work area: Exhaust gases

are poisonous.

z Put blocks in front of the drive wheels and never leave the vehicle

unattended while running tests.

z Use extreme caution when working around the ignition coil,

distributor cap, ignition wires and spark plugs. These components

create hazardous voltages when the engine is running.

z Put the transmission in PARK (for automatic transmission) or

NEUTRAL (for manual transmission) and make sure the parking

brake is engaged.

z Keep a fire extinguisher suitable for gasoline/chemical/ electrical

fires nearby.

z Don’t connect or disconnect any test equipment while the ignition

is on or the engine is running.

z Keep the code reader dry, clean, free from oil/water or grease. Use

a mild detergent on a clean cloth to clean the outside of the code

reader, when necessary.

FCC Statement:

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

z WARNING: This product contains or, when used, produces a

chemical known to the State of California to cause cancer and birth

defects or other reproductive harm. (California Health & Safety Code

§ 25249.5, et seq.)

2

2. General Information

2.1 On-Board Diagnostics (OBD) II

The first generation of On-Board Diagnostics (called OBD I) was

developed by the California Air Resources Board (ARB) and

implemented in 1988 to monitor some of the emission control

components on vehicles. As technology evolved and the desire to

improve the On-Board Diagnostic system increased, a new generation of

On-Board Diagnostic system was developed. This second generation of

On-Board Diagnostic regulations is called "OBD II".

The OBD II system is designed to monitor emission control systems

and key engine components by performing either continuous or

periodic tests of specific components and vehicle conditions. When a

problem is detected, the OBD II system turns on a warning lamp (MIL)

on the vehicle instrument panel to alert the driver typically by the

phrase of “Check Engine” or “Service Engine Soon”. The system will

also store important information about the detected malfunction so that

a technician can accurately find and fix the problem. Here below

follow three pieces of such valuable information:

1) Whether the Malfunction Indicator Light (MIL) is

commanded 'on' or 'off';

2) Which, if any, Diagnostic Trouble Codes (DTCs) are stored;

3) Readiness Monitor status.

2.2 Diagnostic Trouble Codes (DTCs)

OBD II Diagnostic Trouble Codes are codes that are stored by the

on-board computer diagnostic system in response to a problem found

in the vehicle. These codes identify a particular problem area and are

intended to provide you with a guide as to where a fault might be

occurring within a vehicle. OBD II Diagnostic Trouble Codes consist

of a five-digit alphanumeric code. The first character, a letter,

identifies which control system sets the code. The other four characters,

all numbers, provide additional information on where the DTC

originated and the operating conditions that caused it to set. Here

below is an example to illustrate the structure of the digits:

3

2.3 Location of the Data Link Connector (DLC)

The DLC (Data Link Connector or Diagnostic Link Connector) is the

standardized 16-cavity connector where diagnostic code readers

interface with the vehicle's on-board computer. The DLC is usually

located 12 inches from the center of the instrument panel (dash), under

or around the driver’s side for most vehicles. If Data Link Connector is

not located under dashboard, a label should be there telling location.

For some Asian and European vehicles, the DLC is located behind the

ashtray and the ashtray must be removed to access the connector. If the

DLC cannot be found, refer to the vehicle’s service manual for the

location.

Identifying specific

malfunctioning

section of the

s

y

stems

Systems

B=Body

C=Chassis

P=Powertrain

U=Network

DTC Example

P0202

Code Type

Generic (SAE):

P0, P2, P34-P39

B0, B3

C0, C3

U0, U3.

Manufacturer Specific:

P1, P30-p33

B1, B2

C1, C2

U1, U2

Sub-systems

1= Fuel and Air Metering

2= Fuel and Air Metering

3= Ignition System or Engine Misfire

4= Auxiliary Emission Controls

5= Vehicle Speed Control and Idle

Controls

6= Computer Output Circuits

7= Transmission Controls

8= Transmission Controls

2.4 OBD II Readiness Monitors

An important part of a vehicle’s OBD II system is the Readiness

Monitors, which are indicators used to find out if all of the emissions

components have been evaluated by the OBD II system. They are

running periodic tests on specific systems and components to ensure

that they are performing within allowable limits.

Currently, there are eleven OBD II Readiness Monitors (or I/M

Monitors) defined by the U.S. Environmental Protection Agency

(EPA). Not all monitors are supported by all vehicles and the exact

number of monitors in any vehicle depends on the motor vehicle

manufacturer’s emissions control strategy.

Continuous Monitors -- Some of the vehicle components or systems

are continuously tested by the vehicle’s OBD II system, while others

are tested only under specific vehicle operating conditions. The

continuously monitored components listed below are always ready:

1）Misfire

2）Fuel System

3）Comprehensive Components (CCM)

Once the vehicle is running, the OBD II system is continuously

checking the above components, monitoring key engine sensors,

watching for engine misfire, and monitoring fuel demands.

Non-Continuous Monitors -- Unlike the continuous monitors, many

emissions and engine system components require the vehicle to be

4

5

operated under specific conditions before the monitor is ready. These

monitors are termed non-continuous monitors and are listed below:

1) EGR System

2) O2 Sensors

3) Catalyst

4) Evaporative System

5) O2 Sensor Heater

6) Secondary air

7) Heated Catalyst

8) A/C system

2.5 OBD II Monitor Readiness Status

OBD II systems must indicate whether or not the vehicle’s PCM’s

monitor system has completed testing on each component.

Components that have been tested will be reported as “Ready”, or

“Complete”, meaning they have been tested by the OBD II system. The

purpose of recording readiness status is to allow inspectors to

determine if the vehicle’s OBD II system has tested all the components

and/or systems.

The powertrain control module (PCM) sets a monitor to “Ready” or

“Complete” after an appropriate drive cycle has been performed. The

drive cycle that enables a monitor and sets readiness codes to “Ready”

varies for each individual monitor. Once a monitor is set as “Ready” or

“Complete”, it will remain in this state. A number of factors, including

erasing of diagnostic trouble codes (DTCs) with a code reader or a

disconnected battery, can result in Readiness Monitors being set to

“Not Ready”. Since the three continuous monitors are constantly

evaluating, they will be reported as “Ready” all of the time. If testing of

a particular supported non-continuous monitor has not been completed,

the monitor status will be reported as “Not Complete” or “Not Ready.”

In order for the OBD monitor system to become ready, the vehicle

should be driven under a variety of normal operating conditions. These

operating conditions may include a mix of highway driving and stop

and go, city type driving, and at least one overnight-off period. For

specific information on getting your vehicle’s OBD monitor system

ready, please consult your vehicle owner’s manual.

6

2.6 OBD II Definitions

Powertrain Control Module (PCM) -- OBD II terminology for the

on-board computer that controls engine and drive train.

Malfunction Indicator Light (MIL) -- Malfunction Indicator Light

(Service Engine Soon, Check Engine) is a term used for the light on the

instrument panel. It is to alert the driver and/or the repair technician

that there is a problem with one or more of vehicle's systems and may

cause emissions to exceed federal standards. If the MIL illuminates

with a steady light, it indicates that a problem has been detected and the

vehicle should be serviced as soon as possible. Under certain

conditions, the dashboard light will blink or flash. This indicates a

severe problem and flashing is intended to discourage vehicle

operation. The vehicle onboard diagnostic system can not turn the MIL

off until the necessary repairs are completed or the condition no longer

exists.

DTC -- Diagnostic Trouble Codes (DTC) that identify which section

of the emission control system has malfunctioned.

Enabling Criteria -- Also termed Enabling Conditions. They are the

vehicle-specific events or conditions that must occur within the engine

before the various monitors will set, or run. Some monitors require

the vehicle to follow a prescribed “drive cycle” routine as part of the

enabling criteria. Drive cycles vary among vehicles and for each

monitor in any particular vehicle.

OBD II Drive Cycle -- A specific mode of vehicle operation that

provides conditions required to set all the readiness monitors

applicable to the vehicle to the “ready” condition. The purpose of

completing an OBD II drive cycle is to force the vehicle to run its

onboard diagnostics. Some form of a drive cycle needs to be performed

after DTCs have been erased from the PCM’s memory or after the

battery has been disconnected. Running through a vehicle’s complete

drive cycle will “set” the readiness monitors so that future faults can be

detected. Drive cycles vary depending on the vehicle and the monitor

that needs to be reset. For vehicle specific drive cycle, consult the

vehicle’s Owner’s Manual.

7

Freeze Frame Data -- When an emissions related fault occurs, the

OBD II system not only sets a code but also records a snapshot of the

vehicle operating parameters to help in identifying the problem. This

set of values is referred to as Freeze Frame Data and may include

important engine parameters such as engine RPM, vehicle speed, air

flow, engine load, fuel pressure, fuel trim value, engine coolant

temperature, ignition timing advance, or closed loop status.

3. Using the Code Reader

3.1 Tool Description

① OBD II CONNECTOR -- Connects the code reader to the

vehicle’s Data Link Connector (DLC).

② LCD DISPLAY -- Indicates test results.

③ ENTER/EXIT BUTTON -- Confirms a selection (or action)

from a menu list, or returns to previous menu.

④ SCROLL BUTTON -- Scrolls through menu items. It is also used

to enter system setup menu when pressed.

8

9

3.2 Specifications

1) Display: Backlit, 128 x 64 pixel display

2) Operating Temperature: 0 to 60°C (32 to 140 F°)

3) Storage Temperature: -20 to 70°C (-4 to 158 F°)

4) Power: 8 to 18 Volts provided via vehicle battery

5) Dimensions:

Length Width Height

110.3 mm (4.34”) 69.5 mm (2.74”) 20.2 mm (0.80”)

6) 0.18Kg (0.39lb), GW: 0.21Kg (0.46lb)

3.3 Accessories Included

1) User’s Manual -- Instructions on tool operations

2) OBD2 cable -- Provides power to tool and communicates between

tool and vehicle.

3.4 Navigation Characters

Characters used to help navigate the code reader are:

1) “►” -- Indicates current selection.

2) “Pd” -- Identifies a pending DTC when viewing DTCs.

3) “$” -- Identifies the control module number from which the data

is retrieved.

3.5 Vehicle Power

The power of the code reader is provided via the vehicle Data Link

Connector (DLC). Follow the steps below to turn on the code reader:

1) Connect the OBD II cable to the code reader.

2) Find DLC on vehicle.

• A plastic DLC cover may be found for some vehicles and you

need to remove it before plugging the OBD2 cable.

3) Plug OBD II cable to the vehicle’s DLC.

3.6 Product Setup

The code reader allows you to make the following adjustments and

settings:

1) Language: Selects desired language.

2) Unit of measure: Sets the unit of measure to English or Metric.

3) Contrast adjustment: Adjusts the contrast of the LCD display.

• The Settings of the unit will remain until change to the existing

settings is made.

To enter the setup menu

From the second startup screen, press SCROLL button to enter

System Setup menu. Follow the instructions to make adjustments and

settings as described in the following setup options.

10

z The number “x/x” to the upper right corner of the screen

indicates total number of items under the menu and

sequence of currently selected item.

Language Setup

• English is the default language.

1) From System Setup menu, use SCROLL button to select

Language, and press ENTER/EXIT button.

……………….System Setup………… ….

1/4

………………System Setup………… .

1/4

►1) Language

2) Unit of Measure

3) Contrast

4) Exit

► 1) Language

2) Unit of Measure

3) Contrast

4) Exit

2) Use SCROLL button to select the desired language and press

ENTER/EXIT button to save your selection and return to

previous menu.

…………………Language………………….

1/3

► English

Français

Español

Unit of Measurement

• Metric is the default measurement unit.

1) From System Setup menu, use SCROLL button to select Unit of

Measure and press ENTER/EXIT button.

………………System Setup………… …..

2/4

1) Language

► 2) Unit of Measure

3) Contrast

4) Exit

2) From Unit of Measure menu, use SCROLL button to select the

desired unit of measurement.

………….Unit of Measure……… …….

2/2

English

► Metric

3) Press ENTER/EXIT button to save your selection and return to

previous menu.

11

Contrast Adjustment

1) From System Setup menu, use SCROLL button to select

Contrast, and press ENTER/EXIT button.

…………….System Setup………… …….

3/4

1) Language

2) Unit of Measure

►3) Contrast

4) Exit

2) From Contrast menu, use SCROLL button to adjust contrast.

…………….…..Contrast ………………….

Contrast （35%）

12

3) Press ENTER/EXIT button to save your settings and return to

previous menu.

Exiting System Setup

1) Use SCROLL button to select Exit and press ENTER/EXIT

button to return to startup menu.

Use to change

………………System Setup…………… ..

4/4

1) Language

2) Unit of Measure

3) Contrast

► 4) Exit

13

3.7 Vehicle Coverage

ITEM 98568 OBDII/EOBD Code Reader is specially designed to work

with all OBD II compliant vehicles, including those equipped with the

next-generation protocol -- Control Area Network (CAN). It is

required by EPA that all 1996 and newer vehicles (cars and light trucks)

sold in the United States must be OBD II compliant and this includes

all Domestic, Asian and European vehicles.

A small number of 1994 and 1995 model year gasoline vehicles are

OBD II compliant. To verify if a 1994 or 1995 vehicle is OBD II

compliant, check the Vehicle Emissions Control Information (VECI)

Label which is located under the hood or by the radiator of most

vehicles. If the vehicle is OBD II compliant, the label will designate

“OBD II Certified”. Additionally, Government regulations mandate

that all OBD II compliant vehicles must have a “common” sixteen-pin

Data Link Connector (DLC).

For your vehicle to be OBD II compliant it must have a 16-pin DLC

(Data Link Connector) under the dash and the Vehicle Emission

Control Information Label must state that the vehicle is OBD II

compliant.

14

4. OBD II Diagnostics

When more than one vehicle control module is detected by the

scan tool, you will be prompted to select the module where the

data may be retrieved. The most often to be selected are the

Powertrain Control Module [PCM] and Transmission Control

Module [TCM].

CAUTION: Don’t connect or disconnect any test equipment with

ignition on or engine running.

1) Turn the ignition off.

2) Locate the vehicle’s 16-pin Data Link Connector (DLC).

3) Plug into the OBDII cable to the vehicle’s DLC.

4) Turn the ignition on. Engine can be off or running.

5) Press ENTER/EXIT button to enter Diagnostic Menu. A

sequence of messages displaying the OBD2 protocols will be

observed on the display until the vehicle protocol is detected.

 If the code reader fails to communicate with the vehicle’s

ECU (Engine Control Unit), a “LINKING ERROR!”

message shows up on the display.

9 Verify that the ignition is ON;

9 Check if the code reader’s OBD II connector is securely

connected to the vehicle’s DLC;

9 Verify that the vehicle is OBD2 compliant;

9 Turn the ignition off and wait for about 10 seconds. Turn the

ignition back to on and repeat the procedure from step 5.

 If the “LINKING ERROR” message does not go away, then

there might be problems for the code reader to communicate

with the vehicle. Contact your local distributor or the

manufacturer’s customer service department for assistance.

6) After the system status is displayed (MIL status, DTC counts,

Monitor status), wait a few seconds or press any key for

Diagnostic Menu to come up.

……………. System Status…………… …

Codes Found 1

Monitors N/A 4

Monitors OK 3

Monitors INC 3

15

4.1 Reading Codes

1) Use SCROLL button to select Read Codes from Diagnostic

Menu and press ENTER/EXIT button.

.............Diagnostic Menu....... ...

1/6

► 1) Read Codes

2) Erase Codes

3) View Freeze Frame

4) I/M Readiness

z If more than one module is detected, you will be prompted

to select a module before test.

z Use SCROLL button to select a module, and press

ENTER/EXIT button.

2) View DTCs and their definitions on screen.

$11 Pd 1/6

P0115 Generic

………………Control Module……………

1/3

► Engine

Module $A4

Exit

Engine Coolant Temperature

Sensor 1 Circuit

z The control module number, sequence of the DTCs, total

number of codes detected and type of codes (Generic or

Manufacturer specific, Stored or Pending codes) will be

observed on the upper right hand corner of the display.

3) If more than one DTC is found, use SCROLL button, as

necessary, until all the codes have been shown up.

z If no codes are detected, a “No codes are stored in the

module!” message displays on the screen.

z If retrieved DTCs contain any manufacturer specific or

enhanced codes, the display indicates “Manufacturer

control”.

$09 4/6

P1324 Other

Manufacturer control

4) Press ENTER/EXIT button to return to previous menu.

4.2 Erasing Codes

CAUTION: Erasing the Diagnostic Trouble Codes may allow the

code reader to delete not only the codes from the vehicle’s on-board

computer, but also “Freeze Frame” data and manufacturer

enhanced data. Further, the I/M Readiness Monitor Status for all

vehicle monitors is reset to Not Ready or Not Complete status. Do not

erase the codes before the system has been checked completely by a

technician.

z This function is performed with key on engine off (KOEO). Do

not start the engine.

1) If you decide to erase the DTCs, use SCROLL button to select

Erase Codes from Diagnostics Menu and press ENTER/EXIT

button.

16

...........Diagnostic Menu...... ......

2/6

1) Read Codes

►2) Erase Codes

3) Freeze Frame

4) I/M Readiness

2) A warning message comes up asking for your confirmation.

.............Erase Codes............. ...

Erase trouble codes!

Are you sure?

YES NO

3) If you want to proceed with erasing the codes, press

ENTER/EXIT button to erase.

z If the codes are cleared successfully, an “Erase Done!”

message shows up.

z If the codes are not cleared, then an “Erase Failure. Turn

Key on with Engine off!” message displays.

4) Wait a few seconds or press any key to return to Diagnostic

Menu.

z If you do wish to proceed to erase the codes, then press

SCROLL button to select NO and press ENTER/EXIT. A

“Command Canceled” message shows up. Press any key

or wait a few seconds to return to Diagnostic Menu.

4.3 Viewing Freeze Frame Data

1) To view freeze frame, use SCROLL button to select View

Freeze Frame from Diagnostic Menu and press ENTER/EXIT

button.

17

............Diagnostic Menu...... ....

3/6

1) Read Codes

2) Erase Codes

►3) View Freeze Frame

4) I/M Readiness

z If more than one module is detected, you will be prompted

to select a module before test.

…………….Control Module………… ….

1/3

► Engine

Module $A4

Exit

z Use SCROLL button to select a module and press

ENTER/EXIT button.

2) Wait a few seconds while the code reader validates the PID MAP.

18

3) If the retrieved information covers more than one screen, use

SCROLL button, as necessary, until all data have been shown up.

…………..View Freeze Frame…… ….

1/4

……………View Freeze Frame…….. .

Reading PID.01

- Please Wait -

DTCFRZF P2770

FUELSYS1 OL

FUELSYS2 N/A

LOAD_PCT (%) 0.0

19

z The number “x/x” to the upper right corner of the screen

indicates total number of screens the retrieved freeze frame

covers and sequence of currently displayed data.

z If there is no freeze frame data available, an advisory

message “No Freeze Frame Data Stored!” shows on the

display.

4) Press ENTER/EXIT to return to Diagnostic Menu.

4.4 Retrieving I/M Readiness Status

I/M Readiness function is used to check the operations of the

Emission System on OBD2 compliant vehicles. It is an excellent

function to use prior to having a vehicle inspected for compliance

to a state emissions program.

Some latest vehicle models may support two types of I/M

Readiness tests:

A. Since DTCs Cleared - indicates status of the monitors since the

DTCs are erased.

B. This Drive Cycle - indicates status of monitors since the

beginning of the current drive cycle.

An I/M Readiness Status result of “NO” does not necessarily

indicate that the vehicle being tested will fail the state I/M

inspection. For some states, one or more such monitors may be

allowed to be “Not Ready” to pass the emissions inspection.

9 “OK” -- Indicates that a particular monitor being checked has

completed its diagnostic testing.

9 “INC” -- Indicates that a particular monitor being checked has

not completed its diagnostic testing.

9 “N/A” -- The monitor is not supported on that vehicle.

1) Use SCROLL button to select I/M Readiness from Diagnostic

Menu and press ENTER/EXIT.

............Diagnostic Menu......... ..

4/6

1) Read Codes

2) Erase Codes

3) View Freeze Frame

► 4) I/M Readiness

20

z If more than one module is detected, you will be prompted

to select a module before test.

z Use the SCROLL button to select a module, and press

ENTER/EXIT button.

2) Wait a few seconds while the code reader validates the PID MAP.

3) If the vehicle supports both types of tests, then both types shows

on the screen for selection.

……………..I/M Readiness……… ……..

1/3

► Since DTCs Cleared

This Drive Cycle

Exit

……….……I/M Readiness……………… .

Reading PID…

- Please Wait -

…………..Control Module………… …..

1/3

► Engine

Module $A4

Exit

4) Use SCROLL button to view the status of the MIL light (“ON” or

“OFF) and the following monitors:

z Misfire monitor -- Misfire monitor

z Fuel System Mon -- Fuel System Monitor

z Comp. Component -- Comprehensive Components Monitor

z EGR -- EGR System Monitor

z Oxygen Sens Mon -- O2 Sensors Monitor

z Catalyst Mon -- Catalyst Monitor

z EVAP System Mon -- Evaporative System Monitor

z Oxygen Sens htr --O2 Sensor Heater Monitor

z Sec Air System -- Secondary Air Monitor

z Htd Catalyst -- Heated Catalyst Monitor

z A/C Refrig Mon -- A/C system Monitor

………..Since DTCs Cleared…………..

1/3

MIL Status OFF

Misfire Monitor OK

Fuel System Mon. OK

Comp. Component OK

5) If the vehicle supports readiness test of “This Drive Cycle”, a

screen of the following will be displayed:

………….This Drive Cycle………… ….

1/3

MIL Status ON

Misfire Monitor OK

Fuel System Mon OK

Comp. Component OK

z The number “x/x” to the upper right corner of the screen

indicates total number of screens the retrieved data cover

and sequence of currently displayed data.

6) Press ENTER/EXIT button to return to previous menu.

21

4.5 Viewing Vehicle Information

The Vehicle Info. function enables retrieval of the Vehicle

Identification No. (VIN), Calibration ID(s), Calibration

Verification Nos. (CVNs) and In-use Performance Tracking on

2000 and newer vehicles that support Mode 9.

1) Use SCROLL button to select Vehicle Info. from Diagnostic

Menu and press ENTER/EXIT button.

............Diagnostic Menu......... ..

5/6

►5) Vehicle Info.

6) Exit

2) Wait a few seconds or press ENTER/EXIT button to continue.

……………..Vehicle Info.

Turn key on

with engine off!

Press [ENTER] to con.

22

z If the vehicle does not support this mode, a “The selected

mode is not supported!” message shows on the display.

z If more than one module is detected, you will be prompted

to select a module before test.

…………..Control Module… …

1/3

► Engine

Module $A4

Exit

z Use SCROLL button to select a module, and press

ENTER/EXIT button.

3) Wait a few seconds while the code reader reads vehicle

information.

… Vehicle Info.

Reading Info…

- Please Wait -

4) From Vehicle Info. menu, use SCROLL button to select an

available items to view and press ENTER/EXIT button.

Vehicle Info.

1/4

► Vehicle ID Number

Calibration ID

Cal. Verif. Number

Exit

5) View retrieved vehicle information on the screen.

………….Vehicle ID Number……. .….

VIN:

2HGES16684H907941

6) Press ENTER/EXIT to return to previous menu.

4.6 Exiting OBDII Test

1) To exit OBDII test, use SCROLL button to select Exit from

Diagnostic Menu and press ENTER/EXIT button.

23

............Diagnostic Menu... .... ...

6/6

5) Vehicle Info.

►6) Exit

24

2) A warning message comes up asking your confirmation.

…………… … Exit Test…………………...

Exit OBDII Test!

Are you sure?

YES NO

3) If you do want to exit OBDII test, press ENTER/EXIT button.

z If you do not want to exit, use SCROLL button the select

NO and press ENTER/EXIT button to return.
