Harman Becker Automotive Systems BE2808 Extension Module User Manual Corolla touch screen 12F69E
Harman Becker Automotive Systems, Inc. Extension Module Corolla touch screen 12F69E
User Manual
2
DA_EXT_COROLLA_touch screen_EE
Introduction
■EXISTENCE OF NAVIGATION CAPABILITIES
Existence of navigation capabilities can be confirmed by performing the follow-
ing method:
INFORMATION
●This illustration is for left-hand drive vehicles.
●The button positions and shapes differ for right-hand drive vehicles.
3
DA_EXT_COROLLA_touch screen_EE
XVehicles without smart entry & start system
1 When the engine switch is turned to the “ACC” or “ON” position, the initial
screen will be displayed and the system will begin operating.
XVehicles with smart entry & start system
1 When the engine switch is turned to the ACCESSORY or IGNITION ON
mode, the initial screen will be displayed and the system will begin operating.
2 Press the “MAP/NAV” button.
zEither of the following screens will be displayed.
XMultimedia system XNavigation system
4
DA_EXT_COROLLA_touch screen_EE
SYMBOLS USED IN ILLUSTRATIONS
Safety symbol
The symbol of a circle with a slash through it means “Do not”, “Do not
do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turning, etc.)
used to operate switches and other
devices.
Indicates the outcome of an operation (e.g.
a lid opens).
HOW TO READ THIS MANUAL
No. Name Description
Operational Outlines An outline of the operation is explained.
Main Operations The steps of an operation are explained.
Related Operations A main operation’s supplementary operations are described.
Information Useful information for the user is described.
5
DA_EXT_COROLLA_touch screen_EE
This manual explains the operation of the navigation/multimedia system.
Please read this manual carefully to ensure proper use. Keep this manual in
your vehicle at all times.
The screen shots in this document and the actual screens of the navigation/mul-
timedia system differ depending on whether the functions and/or a contract ex-
isted and the map data available at the time of producing this document.
Please be aware that the content of this manual may be different from the nav-
igation system in some cases, such as when the system’s software is updated.
The Navigation System is one of the most technologically advanced vehicle ac-
cessories ever developed. The system receives satellite signals from the Global
Positioning System (GPS) operated by the U.S. Department of Defense. Using
these signals and other vehicle sensors, the system indicates your present po-
sition and assists in locating a desired destination.
The navigation system is designed to select efficient routes from your present
starting location to your destination. The system is also designed to direct you
to a destination that is unfamiliar to you in an efficient manner. The system is
developed by “Harman International” using “NAVTEQ” maps. The calculated
routes may not be the shortest nor the least traffic congested. Your own person-
al local knowledge or “short cut” may at times be faster than the calculated
routes.
The navigation system’s database includes Point of Interest categories to allow
you to easily select destinations such as restaurants and hotels. If a destination
is not in the database, you can enter the street address or a major intersection
close to it and the system will guide you there.
The system will provide both a visual map and audio instructions. The audio in-
structions will announce the distance remaining and the direction to turn in ap-
proaching an intersection. These voice instructions will help you keep your eyes
on the road and are timed to provide enough time to allow you to maneuver,
change lanes or slow down.
Please be aware that all current vehicle navigation systems have certain limita-
tions that may affect their ability to perform properly. The accuracy of the vehi-
cle’s position depends on the satellite condition, road configuration, vehicle
condition or other circumstances. For more information on the limitations of the
system, refer to page 217.
NAVIGATION SYSTEM OWNER’S MANUAL
NAVIGATION SYSTEM
navigation/multimedia
6
DA_EXT_COROLLA_touch screen_EE
For safety reasons, this manual indicates items requiring particular attention
with the following marks.
IMPORTANT INFORMATION ABOUT THIS MANUAL
CAUTION
●This is a warning against anything which may cause injury to people if the warning is
ignored. You are informed about what you must or must not do in order to reduce the risk
of injury to yourself and others.
NOTICE
●This is a warning against anything which may cause damage to the vehicle or its equip-
ment if the warning is ignored. You are informed about what you must or must not do in
order to avoid or reduce the risk of damage to your vehicle and its equipment.
7
DA_EXT_COROLLA_touch screen_EE
To use this system in the safest possible
manner, follow all the safety tips shown
below.
Do not use any feature of this system to
the extent it becomes a distraction and
prevents safe driving. The first priority
while driving should always be the safe op-
eration of the vehicle. While driving, be
sure to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly famil-
iar with it. Read the entire Navigation sys-
tem Owner's manual to make sure you
understand the system. Do not allow other
people to use this system until they have
read and understood the instructions in
this manual.
For your safety, some functions may be-
come inoperable when driving. Unavail-
able screen buttons are dimmed.
To use this system in the safest possible
manner, follow all the safety tips shown
below.
This system is intended to assist in reach-
ing the destination and, if used properly,
can do so. The driver is solely responsible
for the safe operation of your vehicle and
the safety of your passengers.
Do not use any feature of this system to
the extent it becomes a distraction and
prevents safe driving. The first priority
while driving should always be the safe op-
eration of the vehicle. While driving, be
sure to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly famil-
iar with it. Read the entire Navigation sys-
tem Owner’s manual to make sure you
understand the system. Do not allow other
people to use this system until they have
read and understood the instructions in
this manual.
For your safety, some functions may be-
come inoperable when driving. Unavail-
able screen buttons are dimmed.
SAFETY INSTRUCTION
(MULTIMEDIA SYSTEM)
CAUTION
●For safety, the driver should not operate
the multimedia system while he/she is
driving. Insufficient attention to the road
and traffic may cause an accident.
SAFETY INSTRUCTION
(NAVIGATION SYSTEM)
8
DA_EXT_COROLLA_touch screen_EE
While driving, listen to the voice instruc-
tions as much as possible and glance at
the screen briefly and only when it is safe.
However, do not totally rely on voice guid-
ance. Use it just for reference. If the sys-
tem cannot determine the current vehicle
position correctly, there is a possibility of
incorrect, late, or non-voice guidance.
The data in the system may occasionally
be incomplete. Road conditions, including
driving restrictions (no left turns, street clo-
sures, etc.) frequently change. Therefore,
before following any instruction from the
system, look to see whether the instruction
can be done safely and legally.
This system cannot warn about such
things as the safety of an area, condition of
streets, and availability of emergency ser-
vices. If unsure about the safety of an ar-
ea, do not drive into it. Under no
circumstances is this system a substitute
for the driver’s personal judgement.
Use this system only in locations where it
is legal to do so.
CAUTION
●For safety, the driver should not operate
the navigation system while he/she is
driving. Insufficient attention to the road
and traffic may cause an accident.
●While driving, be sure to obey the traffic
regulations and maintain awareness of
the road conditions. If a traffic sign on
the road has been changed, route guid-
ance may not have the updated informa-
tion such as the direction of a one way
street.
9
DA_EXT_COROLLA_touch screen_EE
10
TABLE OF CONTENTS
DA_EXT_COROLLA_touch screen_EE
1. QUICK GUIDE ................................. 14
SYSTEM FUNCTION INDEX ................ 14
OVERVIEW BUTTONS......................... 16
2. CONTROLS AND FEATURES........ 16
TOUCH SCREEN GESTURES............. 18
TOUCH SCREEN OPERATION ........... 19
1. BASIC OPERATION........................ 26
QUICK REFERENCE............................ 26
SOME BASICS...................................... 27
2. RADIO OPERATION ....................... 30
AM/FM RADIO ...................................... 30
3. MEDIA OPERATION ....................... 36
CD ......................................................... 36
USB MEMORY...................................... 42
iPod ....................................................... 47
AUX....................................................... 52
Bluetooth® AUDIO................................. 55
4. AUDIO REMOTE CONTROLS........ 62
STEERING SWITCHES ........................ 62
5. TIPS FOR OPERATING
THE AUDIO SYSTEM.................... 64
OPERATING INFORMATION............... 64
1. BASIC INFORMATION
BEFORE OPERATION ................. 74
QUICK REFERENCE ............................ 74
HANDS-FREE SYSTEM........................ 77
REGISTERING AN ENTRY................... 81
2. PHONE OPERATION ..................... 85
CALLING ON A Bluetooth® PHONE ..... 85
RECEIVING CALLS ON A
Bluetooth® PHONE............................. 90
TALKING ON A
Bluetooth® PHONE............................. 91
3. SHORT MESSAGE FUNCTION ..... 95
SHORT MESSAGE FUNCTION............ 95
4. WHAT TO DO IF... ........................ 100
TROUBLESHOOTING......................... 100
1. VEHICLE INFORMATION............. 108
QUICK REFERENCE .......................... 108
FUEL CONSUMPTION........................ 109
1QUICK GUIDE
2AUDIO SYSTEM
3Bluetooth® HANDS-FREE
SYSTEM
4VEHICLE INFORMATION
11
1
2
3
4
5
6
7
8
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION.................... 112
QUICK REFERENCE .......................... 112
GENERAL SETTINGS......................... 114
DISPLAY SETTINGS........................... 117
Bluetooth® SETTINGS......................... 119
CONNECTIVITY SETTINGS ............... 126
TELEPHONE SETTINGS .................... 139
AUDIO SETTINGS............................... 140
VEHICLE SETTINGS........................... 142
1. REAR VIEW MONITOR
SYSTEM...................................... 144
REAR VIEW MONITOR SYSTEM ....... 144
REAR VIEW MONITOR SYSTEM
PRECAUTIONS ................................ 148
THINGS YOU SHOULD KNOW .......... 154
1. BASIC INFORMATION
BEFORE OPERATION................ 158
QUICK REFERENCE.......................... 158
DISPLAYING THE NAVIGATION
SCREEN........................................... 163
NAVIGATION SYSTEM FUNCTION
INDEX............................................... 165
2. MAP SCREEN OPERATION
AND MAP ICONS........................ 167
MAP SCREEN OPERATION .............. 167
MAP ICONS........................................ 170
3. DESTINATION SEARCH .............. 178
DESTINATION SEARCH INDEX ........ 178
SEARCH OPERATION ....................... 179
4. ROUTE GUIDANCE...................... 186
STARTING ROUTE GUIDANCE......... 186
ROUTE GUIDANCE............................ 189
SETTING AND DELETING
THE ROUTE..................................... 192
5. MY DESTINATIONS...................... 200
REGISTERING AN ENTRY ................ 200
DISPLAYING AND EDITING
THE ENTRY INFORMATION ........... 206
SENDING AND RESTORING
STORED CONTACTS USING
A USB MEMORY.............................. 209
6. NAVIGATION SETTING................ 211
MAP SETTINGS.................................. 211
ROUTE SETTINGS............................. 214
TRAFFIC MESSAGE SETTINGS ....... 215
7. NAVIGATION SYSTEM
INFORMATION............................ 217
LIMITATIONS OF THE
NAVIGATION SYSTEM.................... 217
NAVIGATION DATABASE
UPDATES......................................... 219
5SETUP
6REAR VIEW MONITOR
SYSTEM
7NAVIGATION SYSTEM
12
TABLE OF CONTENTS
DA_EXT_COROLLA_touch screen_EE
1. APPLICATIONS OPERATION...... 222
QUICK REFERENCE.......................... 222
PICTURE SLIDESHOW ...................... 225
E-MAIL ................................................ 227
MirrorLink.......................................... 229
TOYOTA EUROCARE ........................ 230
2. CONNECTED SERVICE................ 232
CONNECTED SERVICE
OVERVIEW ...................................... 232
BEFORE USING CONNECTED
SERVICE.......................................... 236
ONLINE SEARCH............................... 239
LOADING POIs/ROUTE...................... 244
OPERATING AN APPLICATION
USING CONNECTED SERVICE...... 245
ALPHABETICAL INDEX ................... 248
8APPLICATION
INDEX
1
13
1
2
3
4
5
6
DA_EXT_COROLLA_touch screen_EE
7
8
1. SYSTEM FUNCTION INDEX......... 14
1. OVERVIEW BUTTONS ................. 16
2. TOUCH SCREEN GESTURES...... 18
3. TOUCH SCREEN
OPERATION................................ 19
ENTERING SCREEN OPERATION...... 20
LIST SCREEN OPERATION................. 21
1QUICK GUIDE
2CONTROLS AND FEATURES
QUICK GUIDE
14
DA_EXT_COROLLA_touch screen_EE
1. QUICK GUIDE
1. SYSTEM FUNCTION INDEX
To access the audio system, press the
“MEDIA” button. The audio control screen
will be displayed. (→P.25)
To access the Bluetooth® hands-free sys-
tem, press the button. Each time
the button is pressed, the screen
will change between the “Phone” menu
screen and the “Extras”/“Toyota online”
menu screen. The driver can make or re-
ceive phone calls without taking their
hands off the steering wheel. (→P.73)
To access the vehicle information system,
press the “CAR” button. Fuel consump-
tion can be checked. (→P.108)
To customise the function settings, press
the “SETUP” button. (→P.111)
AUDIO SYSTEM
Bluetooth® HANDS-FREE
SYSTEM
VEHICLE INFORMATION
SETUP
15
1. QUICK GUIDE
1
QUICK GUIDE
DA_EXT_COROLLA_touch screen_EE
Shifting into the “R” position will automati-
cally show the view behind the rear of the
vehicle on the display screen. (→P.143)
To access the navigation system, press
the “MAP/NAV” button. Each time the
“MAP/NAV” button is pressed, the screen
will change between the map screen and
“Navigation” menu screen. (→P.157)
To access the application system, press
the button. Each time the
button is pressed, the screen will change
between the “Phone” menu screen and the
“Extras”/“Toyota online” menu screen. The
driver can use applications. (→P.221)
REAR VIEW MONITOR SYSTEM
NAVIGATION SYSTEM
APPLICATION SYSTEM
16
DA_EXT_COROLLA_touch screen_EE
2. CONTROLS AND FEATURES
1. OVERVIEW BUTTONS
No. Function Page
By touching the screen with your finger, you can control the selected
functions. 18
Insert a disc into this slot. The CD player turns on immediately. 36
Press to customise the function settings. 111
Turn the tune/scroll knob to select a radio station or skip to the next or
previous track. This knob can also be used to magnify or reduce the map
scale. (Navigation system only)
30, 168
Press to access the Bluetooth® hands-free system and applications. 73, 221
Press to access the vehicle information system. 108
Press to access the navigation system. (Navigation system only) 157
2. CONTROLS AND FEATURES
17
2. CONTROLS AND FEATURES
1
QUICK GUIDE
DA_EXT_COROLLA_touch screen_EE
Press the “ ” or “ ” button to seek up or down for a radio station or to
access a desired track or file.
30, 36, 42,
47, 55
Press to access the audio system. The audio system turns on in the last
mode used. 26, 27, 28
Press the power/volume knob to turn navigation/multimedia system on
and off, and turn it to adjust the volume. 27
Press to eject a disc. 29
INFORMATION
●This illustration is for left-hand drive vehicles.
●The button positions and shapes differ for right-hand drive vehicles.
No. Function Page
18
DA_EXT_COROLLA_touch screen_EE
2. CONTROLS AND FEATURES
2. TOUCH SCREEN GESTURES
*: The above operations may not be performed on all screens.
Operations are performed by touching the touch screen directly with your finger.
Operation method Outline Main use
Touch
Quickly touch and release
once.
Changing and selecting various set-
tings.
Drag*
Touch the screen with
your finger, and move the
screen to the desired posi-
tion.
•Scrolling the lists
•Using scroll bar in lists
•Adjusting the zoom bar of the map
(→P.168)
•Adjusting manual tune scales for
FM and AM (→P.33)
•Adjusting the displayed screen’s
position sliders (→P.117)
•Adjusting balance/fader (→P.141)
•Moving position of elements in the
stopover/destination list (→P.193,
194)
Flick*
Quickly move the screen
by flicking with your finger.
•Scrolling the main screen page
•Returning to the menu screen from
the sub-menu screen (screen one
level below)
•Going to the next/previous picture
(→P.225)
•Going to the next/previous traffic
message in the details view
(→P.175)
•Going to the next/previous route
segment in the full screen view
(turn list) (→P.196)
19
1
QUICK GUIDE
DA_EXT_COROLLA_touch screen_EE
2. CONTROLS AND FEATURES
3. TOUCH SCREEN OPERATION
This system is operated mainly by the
screen buttons.
When a screen button is touched, a
beep sounds. (To set a beep sound,
→P.114.)
NOTICE
●To prevent damaging the screen, lightly
touch the screen buttons with your fin-
ger.
●Do not use objects other than your finger
to touch the screen.
●Wipe off fingerprints using a glass clean-
ing cloth. Do not use chemical cleaners
to clean the screen, as they may dam-
age the touch screen.
●To prevent the battery from being dis-
charged, do not leave the system on
longer than necessary when the engine
is not running.
INFORMATION
●If the system does not respond to a
touch on a screen button, move your fin-
ger away from the screen and then
touch it again.
●Dimmed screen buttons cannot be oper-
ated.
●The displayed image may become
darker and moving images may be
slightly distorted when the display is
cold.
●Under extremely cold conditions, the
screen may not be displayed and the
data input by a user may be deleted.
Also, the screen buttons may be harder
than usual to depress.
●When you look at the screen through
polarized material such as polarized
sunglasses, the screen may be dark and
hard to see. If so, look at the screen
from different angles, adjust the screen
settings (→P.117), or take off your sun-
glasses.
●Select to return to the previous
screen.
20
2. CONTROLS AND FEATURES
DA_EXT_COROLLA_touch screen_EE
1Select the keys directly to enter letters
or numbers.
2Select “OK”.
ENTERING SCREEN
OPERATION
When searching for a name, letters
and numbers, etc. can be entered via
the screen.
ENTERING LETTERS AND
NUMBERS
No. Function
Select to delete one letter. Select
and hold to continue deleting letters.
Select to enter symbols.
Select to select lower case or upper
case.
Select to change keyboard types.
INFORMATION
●When a character is entered, a hint will
appear displaying a possible match for
the word to be searched.
●Currently unavailable screen buttons will
be dimmed.
●When an entry is too long to be dis-
played in the enter field, the last section
of the enter text will be displayed with
the initial section displayed as “...”.
●In the following situations, the enter
mode will automatically change between
upper and lower case.
• When the keyboard layout is changed
to upper case input, the layout will
automatically change back to lower
case input after one letter has been
entered.
• When “/”, “&”, “.” or “(” is entered,
the keyboard layout will automatically
be changed to upper case input.
• When all characters are deleted, the
keyboard layout will automatically
change to upper case input.
21
2. CONTROLS AND FEATURES
1
QUICK GUIDE
DA_EXT_COROLLA_touch screen_EE
1Enter letters.
zIf a candidate entry text displayed in the
enter field is what is desired, select “OK”
or the candidate entry text.
zSelect to display the candi-
date entry text list. The number of match-
ing items is shown. Up to 300 items are
displayed.
zThe list will be displayed automatically, if
the number of matching entries is 5 or
less.
2Select the desired item.
zBy selecting and holding or , the
screen can be scrolled up or down. Scroll-
ing will automatically stop when the top/
bottom of the list is reached.
zChanging pages can also be changed the
following ways:
• Selecting the desired point on the scroll
bar.
• Dragging the scroll bar marking to the
desired point.
ENTERING FROM THE LIST OF
MATCHING ENTRIES
On certain screens, a candidate entry
text or word prediction list based on the
input letters will be displayed. The de-
sired item can be selected and en-
tered.
LIST SCREEN OPERATION
When a list is displayed, use the appro-
priate screen button to scroll through
the list.
No. Function
Select to shift to the next or previous
page.
This indicates the displayed
screen’s position.
22
2. CONTROLS AND FEATURES
DA_EXT_COROLLA_touch screen_EE
■AUTOMATIC TEXT SCROLLING
1Select one of the character screen but-
tons.
Entries that are too long to fit in the cur-
rent field are scrolled automatically
from right to left.
This function is not available while driv-
ing.
INFORMATION
●This function can be changed to on or
off. (→P.114)
CHARACTER JUMP BUTTONS
IN LISTS
Some lists contain character screen
buttons, “A-C”, “D-F” etc., which al-
low a direct jump to list entries that be-
gin with the same letter as the
character screen button.
INFORMATION
●Every time the same character screen
button is selected, the list starting with
the subsequent character is displayed.
24
DA_EXT_COROLLA_touch screen_EE
2
25
1
4
3
2
5
6
DA_EXT_COROLLA_touch screen_EE
7
8
1. QUICK REFERENCE.................... 26
2. SOME BASICS.............................. 27
TURNING THE AUDIO SYSTEM
ON OR OFF ........................................ 27
SELECTING AN AUDIO SOURCE........ 28
INSERTING OR EJECTING A DISC ..... 28
USB/AUX PORT .................................... 29
1. AM/FM RADIO .............................. 30
OVERVIEW............................................ 30
PRESETTING A STATION.................... 33
MANUAL TUNING ................................. 33
RDS (RADIO DATA SYSTEM) .............. 34
FM RADIO OPTIONS ............................ 35
1. CD.................................................. 36
OVERVIEW............................................ 36
PLAYING AN AUDIO CD....................... 39
PLAYING AN MP3/WMA/AAC DISC ..... 39
AUDIO CD OR MP3/WMA/AAC
DISC OPTIONS................................... 40
2. USB MEMORY .............................. 42
OVERVIEW........................................... 42
PLAYING A USB MEMORY.................. 46
USB MEMORY OPTIONS..................... 46
3. iPod ............................................... 47
OVERVIEW........................................... 47
iPod AUDIO........................................... 51
iPod AUDIO OPTIONS.......................... 51
4. AUX................................................ 52
OVERVIEW........................................... 52
5. Bluetooth® AUDIO........................ 55
OVERVIEW........................................... 55
CONNECTING Bluetooth® AUDIO ....... 59
LISTENING TO Bluetooth® AUDIO....... 60
Bluetooth® AUDIO OPTIONS ............... 60
1. STEERING SWITCHES................. 62
1. OPERATING INFORMATION ....... 64
RADIO RECEPTION............................. 64
iPod ....................................................... 66
CARING FOR YOUR CD PLAYER
AND DISCS ........................................ 67
FILE INFORMATION............................. 69
CD-R AND CD-RW DISCS ................... 71
TERMS.................................................. 71
1BASIC OPERATION
2RADIO OPERATION
3MEDIA OPERATION
4AUDIO REMOTE CONTROLS
5TIPS FOR OPERATING THE
AUDIO SYSTEM
AUDIO SYSTEM
Some of the functions cannot be operated while driving.
26
DA_EXT_COROLLA_touch screen_EE
1. BASIC OPERATION
1. QUICK REFERENCE
To access the audio system, press the “MEDIA” button. The audio system turns
on in the last mode used.
Function Page
Using the radio 30
Playing an audio CD or MP3/WMA/AAC disc 36
Playing a USB memory 42
Playing an iPod 47
Using the AUX port 52
Playing a Bluetooth® device 55
Using the steering wheel audio switches 62
Audio settings 140
INFORMATION
●This illustration is for left-hand drive vehicles.
●The button positions and shapes differ for right-hand drive vehicles.
27
DA_EXT_COROLLA_touch screen_EE
1. BASIC OPERATION
2
AUDIO SYSTEM
2. SOME BASICS
The power/volume knob: Press this knob
to turn the audio system on and off. Turn
this knob to adjust the volume. The system
turns on in the last mode used.
“MEDIA” button: Press this button to dis-
play screen buttons for the audio system.
This section describes some of the ba-
sic features of the audio system. Some
information may not pertain to your
system.
XVehicles without smart entry & start
system
Your audio system works when the en-
gine switch is turned to the “ACC” or
“ON” position.
XVehicles with smart entry & start sys-
tem
Your audio system works when the en-
gine switch is turned to ACCESSORY
or IGNITION ON mode.
CAUTION
NOTICE
●To prevent the battery from being dis-
charged, do not leave the audio system
on longer than necessary when the
engine is not running.
CAUTION:
THIS PRODUCT IS A CLASS 1 LASER
PRODUCT. USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RE-
SULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS
AND DO NOT REPAIR BY YOUR-
SELF. REFER SERVICING TO QUAL-
IFIED PERSONNEL.
TURNING THE AUDIO
SYSTEM ON OR OFF
INFORMATION
●If the volume is adjusted while music is
paused or muted, the pause or mute will
be cancelled.
28
1. BASIC OPERATION
DA_EXT_COROLLA_touch screen_EE
1Press the “MEDIA” button.
zThe audio system turns on in the last
mode used.
2Select or press the “MEDIA”
button to display the audio source se-
lection screen.
3Select a desired audio source.
1Insert a disc with the label side up.
zWhen a disc is correctly inserted into the
slot, the CD player will automatically start
playing from the first track or the first track
of the first folder on a disc.
SELECTING AN AUDIO
SOURCE
INFORMATION
●You cannot select dimmed screen but-
tons.
INSERTING OR EJECTING A
DISC
INSERTING A DISC
INFORMATION
●If the label is facing down, “Disc error
occurred” will appear on the screen.
NOTICE
●Never try to disassemble or oil any part
of the CD player. Do not insert anything
other than a disc into the slot.
29
1. BASIC OPERATION
2
AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
1Press the button.
zThe disc will be ejected.
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a device.
zIf a device is inserted, it starts playing
automatically. As soon as it is ready to
play, the audio control screen is shown
automatically.
zIf a USB hub is plugged-in, two devices
can be connected at a time.
zEven if a USB hub is used to connect
more than two USB devices, only the first
two connected devices will be recognized.
EJECTING A DISC USB/AUX PORT
30
DA_EXT_COROLLA_touch screen_EE
2. RADIO OPERATION
1. AM/FM RADIO
■CONTROL PANEL
OVERVIEW
The radio operation screen can be reached by the following method:
Press the “MEDIA” button, then select “AM” or “FM” to display the radio control
screen.
32
2. RADIO OPERATION
DA_EXT_COROLLA_touch screen_EE
No. Function
The tune/scroll knob:
•Preset tuning screen: Turn to select a preset station.
•Station list screen: Turn to move up/down the station list.
•Manual tuning screen: Turn to step up/down frequencies.
•Preset tuning screen: Press to move up/down the preset stations.
•Station list screen: Press to move up/down the station list.
•Manual tuning screen: Press and hold to seek up/down available stations while being
pressed.
•Press to display the media mode selection screen.
•Pressing the button again will display the radio control screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
Select to tune to preset stations.
Select to display the radio options screen.
Select to display the manual tuning screen.
Select to display the station list.
Select to display the preset station.
Select to display the audio source selection screen.
INFORMATION
●The radio automatically changes to stereo reception when a stereo broadcast is received.
33
2. RADIO OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
1Tune in the desired station.
2Select one of the station selector but-
tons (1-6) and hold it until a beep is
heard.
zThe station’s frequency or name will be
displayed in the screen button.
zTo change the preset station to a different
one, follow the same procedure.
XAM/FM
1Select “Manual”.
2Tune the desired station.
PRESETTING A STATION MANUAL TUNING
No. Function
•Select to move up/down a station.
•Select and hold to seek stations
non-stop. When released, the cur-
rently received station will be
selected.
•Select to step up/down frequen-
cies.
•Select and hold to seek frequen-
cies non-stop. When released, the
system will stop at the current fre-
quency.
It is possible to drag and drop the
marker by sliding your finger on the
screen (in the area where the mark-
er is shown). Relocating the marker
by a single select on the frequency
band is also possible.
トルツメ
キャプションイキ
EN1017DC
EN1018DC
34
2. RADIO OPERATION
DA_EXT_COROLLA_touch screen_EE
OFF mode: For switching over to a broad-
casting station within the same RDS net-
work; convenient for following the
appropriate stations in a wide region.
ON mode: For switching over to a broad-
casting station within the same local pro-
gram network.
1A pop-up message is displayed on the
screen when the radio seeks out a TP
station.
2Select “Continue”.
■TRAFFIC ANNOUNCEMENT VOL-
UME
RDS (RADIO DATA SYSTEM)
Depending on the availability of RDS
infrastructure, the service may not
function.
FM ALTERNATIVE
FREQUENCY (AF)
A better reception frequency of the
same broadcasting program will be au-
tomatically tuned if the reception of the
current frequency degrades.
REGIONAL CODE CHANGE
TA (TRAFFIC
ANNOUNCEMENT) FUNCTION
The tuner will automatically seek a sta-
tion that regularly broadcasts traffic in-
formation and the station broadcasts
when the traffic information program
starts.
INFORMATION
●When TA is set to on (→P.35), the radio
will begin seeking a TP station.
●When the program ends, the initial oper-
ation resumes.
●EON (Enhanced Other Network) sys-
tem: If the RDS station (with EON data)
currently being listened to is not broad-
casting a traffic information program in
the TA (Traffic Announcement) mode,
the radio will be switched to the traffic
information program automatically by
using the EON AF list. After the traffic
information ends, the radio will return to
the initial program automatically.
The volume level of a received traffic
information sound is stored in the
memory.
トルツメ
35
2. RADIO OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
1Display the FM radio control screen.
(→P.30)
2Select .
3Select the button to be set.
FM RADIO OPTIONS
No. Function
Select to select “By broadcaster” or
“Alphabetical” for the listing order of
the station list.
The tuner will automatically seek a
station that regularly broadcasts
traffic information and the station
broadcasts when the traffic informa-
tion program starts.
Select to set automatic selection of a
station providing good reception if
current reception worsens on/off.
Select to switch to a broadcasting
station within the same local pro-
gram network.
Select to set the FM radio text fea-
ture on/off.
INFORMATION
●The current setting of each item is dis-
played on its right.
38
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
No. Function
Select to display the audio setting screen.
The tune/scroll knob:
•Turn to select a track.
•Turn to move up/down the list.
•Press to select a track.
•Press and hold to fast forward/rewind.
•Press to display the media mode selection screen.
•Pressing the button again will display the audio CD, MP3/WMA/AAC disc control
screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
Press to eject a disc.
Disc slot
Shows progress
Select to display audio CD, MP3/WMA/AAC disc options screen.
•Audio CD: Select to display a track list.
•MP3/WMA/AAC disc: Select to display a folder list.
Select to set random playback.
Select to set repeat playback.
Select to display the media source selection screen.
Select to play/pause.
INFORMATION
●If a disc contains CD-DA files and MP3/WMA/AAC files, only the CD-DA files can be
played back.
●If a CD-TEXT disc is inserted, the title of the disc and track will be displayed.
●If the disc contains no CD-TEXT, only the track number would be displayed on the
screen.
39
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat → off
1Select .
zEach time is selected, the mode
changes as follows:
• random → off
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat → folder repeat → off
PLAYING AN AUDIO CD
REPEATING
The track currently being listened to
can be repeated.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
PLAYING AN MP3/WMA/AAC
DISC
REPEATING
The track or folder currently being lis-
tened to can be repeated.
41
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
∗1: MP3/WMA/AAC disc only
∗2: Navigation system only
No. Function Page
•Audio CD: Select to
display a track list.
•MP3/WMA/AAC disc:
Select to display a
folder list.
Select to resume play-
back of tracks from the
beginning of the track
list when the playback
of the last track on the
list is finished.
Select to set random
playback track.
39,
40
Select to set repeat
playback track. 39
∗1Select to set repeat
playback folder. 39
∗1, 2 Select to set random
and repeat playback
folder.
39,
40
44
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
No. Function
Select to display the audio setting screen.
The tune/scroll knob:
•Turn to select a track.
•Turn to move up/down the list.
•Press to select a track.
•Press and hold to fast forward/rewind.
•Press to display the media mode selection screen.
•Pressing the button again will display the USB control screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
Shows progress
Select to display the USB options screen.
Select to display the browse options selection screen.
Select to set random playback.
Select to set repeat playback.
Select to display the media source selection screen.
Select to switch between “USB1” and “USB2” when 2 USB memory devices are connect-
ed.
Select to play/pause.
45
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
CAUTION
●Do not operate the player’s controls or connect the USB memory while driving.
NOTICE
●Depending on the size and shape of the USB memory that is connected to the system,
the auxiliary box may not close fully.
In this case, do not forcibly close the auxiliary box as this may damage the USB memory
or the terminal, etc.
●Do not leave a portable player in the vehicle. In particular, high temperatures inside the
vehicle may damage the portable player.
●Do not push down on or apply unnecessary pressure to the portable player while it is con-
nected as this may damage the portable player or its connector.
●Do not insert foreign objects into the port as this may damage the portable player or its
connector.
INFORMATION
●Navigation system only: This system supports MTP devices.
46
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat → off
1Select .
zEach time is selected, the mode
changes as follows:
• random → off
1Display the USB memory control
screen. (→P.42)
2Select .
3Select the button to be set.
PLAYING A USB MEMORY
REPEATING
The track or folder currently being lis-
tened to can be repeated.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
USB MEMORY OPTIONS
No. Function Page
Select to select a track.
Select to display the play
mode selection screen.
Select to resume playback
of tracks from the begin-
ning of the track list when
the playback of the last
track on the list is finished.
Select to set random play-
back. 46
Select to set repeat play-
back track. 46
48
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
■CONTROL SCREEN
49
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
No. Function
Select to display the audio setting screen.
The tune/scroll knob:
•Turn to select a track.
•Turn to move up/down the list.
•Press to select a track.
•Press and hold to fast forward/rewind.
•Press to display the media mode selection screen.
•Pressing the button again will display the iPod audio control screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
Shows progress
Select to display the iPod audio options screen.
Select to display the browse options selection screen.
Select to set random playback.
Select to set repeat playback.
Select to display the media source selection screen.
•Displays cover art
•Select to display a track list.
Select to switch between “iPod1” and “iPod2” when 2 iPods are connected.
Select to play/pause.
50
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
CAUTION
●Do not operate the player’s controls or connect the iPod while driving.
NOTICE
●Depending on the size and shape of the iPod that is connected to the system, the auxil-
iary box may not close fully.
In this case, do not forcibly close the auxiliary box as this may damage the iPod or the
terminal, etc.
●Do not leave a portable player in the vehicle. In particular, high temperatures inside the
vehicle may damage the portable player.
●Do not push down on or apply unnecessary pressure to the portable player while it is con-
nected as this may damage the portable player or its connector.
●Do not insert foreign objects into the port as this may damage the portable player or its
connector.
INFORMATION
●When an iPod is connected using a genuine iPod cable, the iPod starts charging its bat-
tery.
●Depending on the iPod and the songs in the iPod, iPod cover art may be displayed. It
may take time to display iPod cover art, and the iPod may not be operated while the
cover art display is in process. Only iPod cover art that is saved in JPEG format can be
displayed.
●When an iPod is connected and the audio source is changed to iPod mode, the iPod will
resume playing from the same point it was last used.
●Depending on the iPod that is connected to the system, certain functions may not be
available.
51
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat → off
1Select .
zEach time is selected, the mode
changes as follows:
• random → off
1Display the iPod control screen.
(→P.47)
2Select .
3Select the button to be set.
iPod AUDIO
REPEATING
The track currently being listened to
can be repeated.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
iPod AUDIO OPTIONS
No. Function Page
Select to select a track.
Select to display the play
mode selection screen.
Select to resume playback
of tracks from the begin-
ning of the track list when
the playback of the last
track on the list is finished.
Select to set random play-
back. 51
Select to set repeat play-
back track. 51
53
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
■CONTROL SCREEN
No. Function
Select to display the audio setting screen.
•Press to display the media mode selection screen.
•Pressing the button again will display the AUX control screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
Select to display the media source selection screen.
54
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
CAUTION
●Do not connect portable audio device or operate the controls while driving.
NOTICE
●Depending on the size and shape of the portable audio device that is connected to the
system, the auxiliary box may not close fully.
In this case, do not forcibly close the auxiliary box as this may damage the portable audio
device or the terminal, etc.
●Do not leave a portable audio device in the vehicle. The temperature inside the vehicle
may become high, resulting in damage to the player.
●Do not push down on or apply unnecessary pressure to the portable audio device while it
is connected as this may damage the portable audio device or its connector.
●Do not insert foreign objects into the port as this may damage the portable audio device
or its connector.
55
DA_EXT_COROLLA_touch screen_EE
3. MEDIA OPERATION
2
AUDIO SYSTEM
5. Bluetooth® AUDIO
■CONTROL PANEL
*: Bluetooth is a registered trademark of Bluetooth SIG, Inc.
The Bluetooth® audio system enables users to enjoy listening to music that is
played on a portable player on the vehicle speakers via wireless communication.
This audio system supports Bluetooth®, a wireless data system capable of playing
portable audio music without cables. If your device does not support Bluetooth®,
the Bluetooth® audio system will not function.
OVERVIEW
The Bluetooth® audio operation screen can be reached by the following methods.
Depending on the type of portable player connected, some functions may not be
available and/or the screen may look differently than shown in this manual.
XConnecting a Bluetooth® audio device (→P.59)
XPress the “MEDIA” button, then select “Bluetooth*” to display the Bluetooth® con-
trol screen.
56
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
■CONTROL SCREEN
57
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
No. Function
Select to display the audio setting screen.
The tune/scroll knob:
•Turn to select a track.
•Turn to move up/down the list.
•Press to select a track.
•Press and hold to fast forward/rewind.
•Press to display the media mode selection screen.
•Pressing the button again will display the Bluetooth® audio control screen again.
The power/volume knob:
•Turn to adjust volume.
•Press to turn the audio system on/off.
•Press and hold to restart the audio system.
Shows progress
Select to display the Bluetooth® audio options screen.
Select to display the playlist screen.
Select to set random playback.
Select to set repeat play.
Select to display the media source selection screen.
Select to play/pause.
58
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
CAUTION
●Do not operate the player’s controls or connect to the Bluetooth® audio system while driv-
ing.
●Your audio unit is fitted with Bluetooth® antennas. People with implanted pacemakers or
cardiac defibrillators should maintain a reasonable distance between themselves and the
Bluetooth® antennas. The radio waves may affect the operation of such devices.
●Before using Bluetooth® devices, users of any electrical medical device other than
implanted pacemakers and implanted cardiac defibrillators should consult the manufac-
turer of the device for information about its operation under the influence of radio waves.
Radio waves could have unexpected effects on the operation of such medical devices.
NOTICE
●Do not leave a portable player in the vehicle. In particular, high temperatures inside the
vehicle may damage the portable player.
INFORMATION
●In the following conditions, this system may not function:
• The Bluetooth® device is turned off.
• The Bluetooth® device is not connected.
• The Bluetooth® device has a low battery.
●It may take time to connect the telephone when Bluetooth® audio is being played.
●For operating a portable player, see the instruction manual that came with it.
●If the Bluetooth® device is disconnected due to poor reception from the Bluetooth® net-
work when the engine switch is in the following status, the system will automatically
reconnect to the portable player.
XVehicles without smart entry & start system
The engine switch is turned to the “ACC” or “ON” position.
XVehicles with smart entry & start system
The engine switch is turned to ACCESSORY or IGNITION ON mode.
●If the Bluetooth® device is disconnected by turning it off, automatic reconnection will not
take place. Reconnect the portable player manually.
●Bluetooth® device information is registered when the portable player is connected to the
Bluetooth® audio system. When selling or disposing of the vehicle, remove the
Bluetooth® audio information from the system.
59
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
■IF NO DEVICE HAS BEEN CON-
NECTED
XMultimedia system (→P.120)
XNavigation system (→P.127)
■CONNECTING AN ADDITIONAL DE-
VICE
XMultimedia system (→P.120)
XNavigation system (→P.127)
■SELECTING A CONNECTED DE-
VICE
XMultimedia system (→P.124)
XNavigation system (→P.134)
CONNECTING Bluetooth®
AUDIO
In order to use the Bluetooth® audio
system, it is necessary to pair a porta-
ble player and connect the audio pro-
file (A2DP) with the system.
Once you have connected a device
with audio profile (A2DP), you can en-
joy your music on the vehicle’s audio
system.
If you have not yet connected a porta-
ble player with audio profile (A2DP),
you must first connect a portable play-
er with audio profile (A2DP) according
to the following procedures. Connect
your portable player with audio profile
(A2DP) after bringing the vehicle to a
complete stop.
60
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select .
zEach time is selected, the mode
changes as follows:
• track repeat → off
1Select .
zEach time is selected, the mode
changes as follows:
• random → off
1Display the Bluetooth® control screen.
(→P.55)
2Select .
3Select the button to be set.
LISTENING TO Bluetooth®
AUDIO
REPEATING
The track currently being listened to
can be repeated.
RANDOM ORDER
Tracks can be automatically and ran-
domly selected.
Bluetooth® AUDIO OPTIONS
No. Function Page
Select to select a track.
Select to display the play
mode selection screen.
Select to resume playback
of tracks from the begin-
ning of the track list when
the playback of the last
track on the list is finished.
Select to set random play-
back. 60
Select to set repeat play-
back track. 60
61
3. MEDIA OPERATION
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
INFORMATION
●If a portable device supports AVRCP 1.4
and browsing, title list and browse for
music will be available. (If the device
does not support browsing, these menu
entries will be displayed grayed out.)
Lower grade devices do not support
these features.
For these devices, the title list and
browse for music will be displayed
grayed out.
62
DA_EXT_COROLLA_touch screen_EE
4. AUDIO REMOTE CONTROLS
1. STEERING SWITCHES
X“MODE/HOLD” switch
Some parts of the navigation/multimedia system can be adjusted with the switches
on the steering wheel.
No. Switch
Enter switch
“” “” “” “” switch
“MODE/HOLD” switch
Volume control switch
Mode Operation Function
AM/FM Radio,
AUX
Press Change audio modes
Press and hold Mute
Audio CD,
MP3/WMA/AAC
disc, USB, iPod,
Bluetooth® audio
Press Change audio modes
Press and hold Pause
63
4. AUDIO REMOTE CONTROLS
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
X“” “” switch
X“” “” switch
XEnter switch
XVolume control switch
Mode Operation Function
AM/FM Radio
Press
Preset station up/down (Preset tuning screen)
Station list up/down (Station list screen)
Seek up/down (Manual tuning screen)
Press and hold Seek up/down continuously while the switch is being
pressed (Manual tuning screen)
Audio CD,
MP3/WMA/AAC
disc, USB, iPod,
Bluetooth® audio
Press Track up/down
Press and hold Fast forward/rewind
Mode Operation Function
Tab screen Press Change the tab
Mode Operation Function
Control screen Press Show list screen
List screen Press Select cursor entry
Mode Operation Function
All Press Volume up/down
64
DA_EXT_COROLLA_touch screen_EE
5. TIPS FOR OPERATING THE AUDIO SYSTEM
1. OPERATING INFORMATION
NOTICE
●To avoid damaging the audio system:
• Be careful not to spill beverages over
the audio system.
• Do not put anything other than appro-
priate discs into the CD player slot.
INFORMATION
●The use of a cellular phone inside or
near the vehicle may cause a noise from
the speakers of the audio system which
you are listening to. However, this does
not indicate a malfunction.
RADIO RECEPTION
Usually, a problem with radio reception
does not mean there is a problem with
your radio it is just the normal result
of conditions outside the vehicle.
For example, nearby buildings and ter-
rain can interfere with FM reception.
Power lines or telephone wires can in-
terfere with AM signals. And of course,
radio signals have a limited range, and
the farther you are from a station, the
weaker its signal will be. In addition, re-
ception conditions change constantly
as your vehicle moves.
Here are some common reception
problems that probably do not indicate
a problem with your radio.
65
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
Fading and drifting stations: Generally,
the effective range of FM is about 25 miles
(40 km). Once outside this range, you may
notice fading and drifting, which increase
with the distance from the radio transmit-
ter. They are often accompanied by distor-
tion.
Multi-path: FM signals are reflective, mak-
ing it possible for two signals to reach your
antenna at the same time. If this happens,
the signals will cancel each other out,
causing a momentary flutter or loss of re-
ception.
Static and fluttering: These occur when
signals are blocked by buildings, trees, or
other large objects. Increasing the bass
level may reduce static and fluttering.
Station swapping: If the FM signal you
are listening to is interrupted or weakened,
and there is another strong station nearby
on the FM band, your radio may tune in the
second station until the original signal can
be picked up again.
Fading: AM broadcasts are reflected by
the upper atmosphere especially at
night. These reflected signals can interfere
with those received directly from the radio
station, causing the radio station to sound
alternately strong and weak.
Station interference: When a reflected
signal and a signal received directly from a
radio station are very nearly the same fre-
quency, they can interfere with each other,
making it difficult to hear the broadcast.
Static: AM is easily affected by external
sources of electrical noise, such as high
tension power lines, lightening, or electri-
cal motors. This results in static.
FM AM
66
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
z“Made for iPod”, “Made for iPhone” and
“Made for iPad” mean that an electronic
accessory has been designed to connect
specifically to iPod, iPhone, or iPad,
respectively, and has been certified by the
developer to meet Apple performance
standards.
zApple is not responsible for the operation
of this device or its compliance with safety
and regulatory standards. Please note
that the use of this accessory with iPod,
iPhone, or iPad may affect wireless perfor-
mance.
ziPad, iPhone, iPod, iPod classic, iPod
nano, and iPod touch are trademarks of
Apple Inc., registered in the U.S. and
other countries. Lightning is a trademark
of Apple Inc.
The following iPod®, iPod nano®, iPod
classic®, iPod touch® and iPhone® devic-
es can be used with this system.
Made for
• iPod touch (5th generation)
• iPod touch (4th generation)
• iPod touch (3rd generation)
• iPod touch (2nd generation)
• iPod touch (1st generation)
• iPod classic (except 5th generation)
• iPod nano (7th generation)
• iPod nano (6th generation)
• iPod nano (5th generation)
• iPod nano (4th generation)
• iPod nano (3rd generation)
• iPod nano (1st generation)
• iPhone 5
• iPhone 4S
• iPhone 4
• iPhone 3GS
• iPhone 3G
•iPhone
Depending on differences between mod-
els or software versions etc., some models
might be incompatible with this system.
iPod COMPATIBLE MODELS
●The Lightning connector works with iPhone 5, iPod touch (5th generation), and iPod
nano (7th generation).
●The 30-pin connector works with iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G, iPhone,
iPod touch (1st through 4th generation), iPod classic (except 5th generation), and iPod
nano (1st, 3rd, 4th, 5th and 6th generation).
●USB works with iPhone 5, iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G, iPhone, iPod
touch (1st through 5th generation), iPod classic (except 5th generation), and iPod nano
(1st, 3rd, 4th, 5th, 6th and 7th generation).
67
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
zExtremely high temperatures can keep
your CD player from working. On hot
days, use air conditioning to cool the vehi-
cle interior before you listen to a disc.
zBumpy roads or other vibrations may
make your CD player skip.
zIf moisture gets into your CD player, you
may not hear any sound even though your
CD player appears to be working. Remove
the discs from the CD player and wait until
it dries.
zUse only discs marked as shown above.
The following products may not be play-
able on your CD player.
• SACDs
•dts CDs
• Copy-protected CDs
• Video CDs
XSpecial shaped discs
XTransparent/translucent discs
XLow quality discs
XLabeled discs
CARING FOR YOUR CD
PLAYER AND DISCS
CAUTION
●CD player uses an invisible laser beam
which could cause hazardous radiation
exposure if directed outside the unit. Be
sure to operate the CD player correctly.
Audio CDs
68
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
zHandle discs carefully, especially when
you are inserting them. Hold them on the
edge and do not bend them. Avoid getting
fingerprints on them, particularly on the
shiny side.
zDirt, scratches, warping, pin holes, or
other disc damage could cause the CD
player to skip or to repeat a section of a
track. (To see a pin hole, hold the disc up
to the light.)
zRemove discs from the CD player when
you are not using them. Store them in their
plastic cases away from moisture, heat,
and direct sunlight.
zTo clean a disc: Wipe it with a soft, lint-
free cloth that has been dampened with
water. Wipe in a straight line from the cen-
tre to the edge of the disc (not in a circle).
Do not use a conventional record cleaner
or anti-static device.
NOTICE
●Do not use special shaped, transparent/
translucent, low quality or labeled discs
such as those shown in the illustrations.
The use of such discs may damage the
player, or it may be impossible to eject
the disc.
●This system is not designed for use of
Dual Disc. Do not use Dual Disc
because it may cause damage to the
player.
●Do not use discs with a protection ring.
The use of such discs may damage the
player, or it may be impossible to eject
the disc.
●Do not use printable discs. The use of
such discs may damage the player, or it
may be impossible to eject the disc.
Correct Wrong
69
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
■COMPATIBLE USB DEVICES
■COMPATIBLE COMPRESSED
FILES
■CORRESPONDING SAMPLING
FREQUENCY
■CORRESPONDING BIT RATES
(Variable Bit Rate (VBR) compatible)
FILE INFORMATION
USB communica-
tion formats
USB 2.0 HS (480
Mbps) and FS (12
Mbps)
File formats FAT 16/32
Correspondence
class Mass storage class
Item USB DISC
Compatible file
format (audio) MP3/WMA/AAC
Folders in the
device
Maximum
3000
Maximum
192
Files in the de-
vice
Maximum
9999
Maximum
255
Files per folder Maximum
255
File type Frequency (kHz)
MP3 files:
MPEG 1 LAYER 3 32/44.1/48
MP3 files:
MPEG 2 LSF LAYER 3 16/22.05/24
WMA files:
Ver. 7, 8, 9 (9.1/9.2) 32/44.1/48
AAC files:
MPEG4/AAC-LC
11.025/12/16/
22.05/24/32/
44.1/48
File type Bit rate (kbps)
MP3 files:
MPEG 1 LAYER 3 32 - 320
MP3 files:
MPEG 2 LSF LAYER 3 8 - 160
WMA files:
Ver. 7, 8 CBR 48 - 192
WMA files:
Ver. 9 (9.1/9.2) CBR 48 - 320
AAC files:
MPEG4/AAC-LC 16 - 320
70
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
zMP3 (MPEG Audio Layer 3), WMA
(Windows Media Audio) and AAC
(Advanced Audio Coding) are audio com-
pression standards.
zThis system can play MP3/WMA/AAC files
on CD-R, CD-RW discs and USB memory.
zThis system can play disc recordings com-
patible with ISO 9660 level 1 and level 2
and with the Romeo and Joliet file system.
zWhen naming an MP3/WMA/AAC file, add
an appropriate file extension
(.mp3/.wma/.m4a).
zThis system plays back files with
.mp3/.wma/.m4a file extensions as
MP3/WMA/AAC files respectively. To pre-
vent noise and playback errors, use the
appropriate file extension.
zThis system can play only the first session
when using multi-session compatible CDs.
zMP3 files are compatible with the ID3 Tag
Ver. 1.0, Ver. 1.1, Ver. 2.2 and Ver. 2.3 for-
mats. This system cannot display disc
title, track title and artist name in other for-
mats.
zWMA/AAC files can contain a WMA/AAC
tag that is used in the same way as an ID3
tag. WMA/AAC tags carry information
such as track title and artist name.
zThe emphasis function is available only
when playing MP3/WMA files recorded at
32, 44.1 and 48 kHz.
zThis system can play back AAC files
encoded by iTunes.
zThe sound quality of MP3/WMA files gen-
erally improves with higher bit rates. In
order to achieve a reasonable level of
sound quality, discs recorded with a bit
rate of at least 128 kbps are recom-
mended.
zM3u playlists are not compatible with the
CD player.
zMP3i (MP3 interactive) and MP3PRO for-
mats are not compatible with the audio
player.
zThe player is compatible with VBR (Vari-
able Bit Rate).
zWhen playing back files recorded as VBR
(Variable Bit Rate) files, the play time will
not be correctly displayed if the fast for-
ward or reverse operations are used.
zIt is not possible to check folders that do
not include MP3/WMA/AAC files.
zMP3/WMA/AAC files in folders up to 8 lev-
els deep can be played. However, the
start of playback may be delayed when
using discs containing numerous levels of
folders. For this reason, we recommend
creating discs with no more than 2 levels
of folders.
zThe play order of the compact disc with
the structure shown above is as follows:
zThe order changes depending on the per-
sonal computer and MP3/WMA/AAC
encoding software you use.
001.mp3
002.wma
Folder 1
003.mp3
Folder 2
004.mp3
005.wma
Folder 3
006.aac
001.mp3 002.wma . . . 006.aac
71
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
2
AUDIO SYSTEM
zCD-R/CD-RW discs that have not been
subject to the “finalizing process” (a pro-
cess that allows discs to be played on a
conventional CD player) cannot be
played.
zIt may not be possible to play CD-R/CD-
RW discs recorded on a music CD
recorder or a personal computer because
of disc characteristics, scratches or dirt on
the disc, or dirt, condensation, etc. on the
lens of the unit.
zIt may not be possible to play discs
recorded on a personal computer depend-
ing on the application settings and the
environment. Record with the correct for-
mat. (For details, contact the appropriate
application manufacturers of the applica-
tions.)
zCD-R/CD-RW discs may be damaged by
direct exposure to sunlight, high tempera-
tures or other storage conditions. The unit
may be unable to play some damaged
discs.
zIf you insert a CD-RW disc into the MP3/
WMA player, playback will begin more
slowly than with a conventional CD or CD-
R disc.
zRecordings on CD-R/CD-RW cannot be
played using the DDCD (Double Density
CD) system.
zThis is a general term that describes the
process of writing data on-demand to CD-
R, etc., in the same way that data is writ-
ten to floppy or hard discs.
zThis is a method of embedding track-
related information in an MP3 file. This
embedded information can include the
track title, the artist’s name, the album
title, the music genre, the year of produc-
tion, comments, cover art and other data.
The contents can be freely edited using
software with ID3 tag editing functions.
Although the tags are restricted to the
number of characters, the information can
be viewed when the track is played back.
zWMA files can contain a WMA tag that is
used in the same way as an ID3 tag. WMA
tags carry information such as track title,
artist name.
CD-R AND CD-RW DISCS TERMS
PACKET WRITE
ID3 TAG
WMA TAG
72
5. TIPS FOR OPERATING THE AUDIO SYSTEM
DA_EXT_COROLLA_touch screen_EE
zThis is the international standard for the
formatting of CD-ROM folders and files.
For the ISO 9660 format, there are two
levels of regulations.
zLevel 1: The file name is in 8.3 format (8
character file names, with a 3 character
file extension. File names must be com-
posed of one-byte capital letters and num-
bers. The “_” symbol may also be
included.)
zLevel 2: The file name can have up to 31
characters (including the separation mark
“.” and file extension). Each folder must
contain fewer than 8 hierarchies.
zPlaylists created using “WINAMP” soft-
ware have a playlist file extension (.m3u).
zMP3 is an audio compression standard
determined by a working group (MPEG) of
the ISO (International Standard Organiza-
tion). MP3 compresses audio data to
about 1/10 the size of that on conventional
discs.
zWMA (Windows Media Audio) is an audio
compression format developed by
Microsoft®. It compresses files into a size
smaller than that of MP3 files. The decod-
ing formats for WMA files are Ver. 7, 8,
and 9.
zThis product is protected by certain intel-
lectual property rights of Microsoft Corpo-
ration and third parties. Use or distribution
of such technology outside of this product
is prohibited without a license from
Microsoft or an authorized Microsoft sub-
sidiary and third parties.
zAAC is short for Advanced Audio Coding
and refers to an audio compression tech-
nology standard used with MPEG2 and
MPEG4.
ISO 9660 FORMAT
m3u
MP3
WMA
AAC
3
73
1
2
5
4
3
6
7
8
DA_EXT_COROLLA_touch screen_EE
1. QUICK REFERENCE.................... 74
2. HANDS-FREE SYSTEM ............... 77
USING THE PHONE SWITCH/
MICROPHONE.................................... 78
ABOUT THE PHONE BOOK IN THIS
SYSTEM.............................................. 79
WHEN YOU RELEASE YOUR CAR...... 79
CONNECTING A Bluetooth® PHONE ... 80
3. REGISTERING AN ENTRY........... 81
REGISTERING A NEW ENTRY ............ 81
DISPLAYING AND EDITING
THE ENTRY INFORMATION.............. 83
SENDING STORED CONTACTS
TO A USB MEMORY .......................... 84
1. CALLING ON A Bluetooth®
PHONE........................................ 85
BY DIAL................................................. 85
BY CONTACTS LIST............................. 86
BY PHONE BOOK................................. 86
BY CALL LISTS ..................................... 87
CALLING USING A SHORT
MESSAGE........................................... 88
BY POI* CALL........................................ 88
BY SELECTING SOS SCREEN
BUTTON.............................................. 89
2. RECEIVING CALLS ON A
Bluetooth® PHONE .................... 90
3. TALKING ON A Bluetooth®
PHONE ........................................ 91
SENDING TONES................................. 92
DIALING A SECOND NUMBER............ 93
ADJUSTING THE RECEIVER
VOLUME............................................. 94
1. SHORT MESSAGE FUNCTION .... 95
RECEIVING A SHORT MESSAGE....... 95
CHECKING RECEIVED SHORT
MESSAGES........................................ 95
CHECKING SENT SHORT
MESSAGES........................................ 96
SENDING A NEW SHORT
MESSAGE.......................................... 97
1. TROUBLESHOOTING................. 100
1BASIC INFORMATION BEFORE
OPERATION
2PHONE OPERATION
3SHORT MESSAGE FUNCTION
4WHAT TO DO IF...
Bluetooth® HANDS-FREE SYSTEM
Some of the functions cannot be operated while driving.
*: Point of Interest
74
DA_EXT_COROLLA_touch screen_EE
1. BASIC INFORMATION BEFORE OPERATION
1. QUICK REFERENCE
■“Phone” MENU SCREEN
Pressing the button allows access to the “Phone” menu screen.
Each time the button is pressed, the screen will change between the
“Phone” menu screen and the “Extras”/“Toyota online” menu screen.
When the button is pressed, the screen that was last displayed will be
shown.
Select to display the “Phone” menu screen.
75
1. BASIC INFORMATION BEFORE OPERATION
3
Bluetooth® HANDS-FREE SYSTEM
DA_EXT_COROLLA_touch screen_EE
No. Function Page
Select to display the “Dial” screen.
A call can be made by dialing the number. 85
Select to display the “Contacts” screen.
An entry from the list of contacts in the “Stored” and “Phone book” screen
can be selected and called.
86
Select to display the “Call lists” screen.
An entry from the missed, received or dial call lists can be selected and
called.
87
Select to display the “Messages” screen.
A list of received and sent short messages and a menu to create new short
messages can be displayed.
95
Select the corresponding icon to change to the “Dial”, “Contacts”, “Call
lists” or “Messages” screen.
76
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
■“Dial” SCREEN
zThis screen can be displayed by selecting
on any of the phone screens.
■“Contacts” SCREEN
zThis screen can be displayed by selecting
on any of the phone screens.
■“Call lists” SCREEN
zThis screen can be displayed by selecting
on any of the phone screens.
■“Messages” SCREEN
zThis screen can be displayed by selecting
on any of the phone screens.
77
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
2. HANDS-FREE SYSTEM
Bluetooth® hands-free system allows
you to make or receive a call without
taking your hands off the steering
wheel by connecting your cellular
phone.
This system supports Bluetooth®.
Bluetooth® is a wireless data system
by which you can call without your
cellular phone being connected with a
cable or placed on a cradle.
The operating procedure of the system
is explained in this section.
CAUTION
●Use a cellular phone or connect the
Bluetooth® phone only when safe and
legal to do so.
●Your audio unit is fitted with Bluetooth®
antennas. People with implanted pace-
makers or cardiac defibrillators should
maintain a reasonable distance between
themselves and the Bluetooth® anten-
nas. The radio waves may affect the
operation of such devices.
●Before using Bluetooth® devices, users
of any electrical medical device other
than implanted pacemakers and
implanted cardiac defibrillators should
consult the manufacturer of the device
for information about its operation under
the influence of radio waves. Radio
waves could have unexpected effects on
the operation of such medical devices.
NOTICE
●Do not leave your cellular phone in the
vehicle. The temperature inside may rise
to a level that could damage the phone.
INFORMATION
●If your cellular phone does not support
Bluetooth®, this system will not function.
●In the following conditions, the system
may not function:
• The cellular phone is turned off.
• The current position is outside the
communication area.
• The cellular phone is not connected.
• The cellular phone has a low battery.
●When using Bluetooth® audio and
hands-free at the same time, the follow-
ing problems may occur.
• The Bluetooth® connection may be
cut.
• Noise may be heard on the Bluetooth®
audio playback.
78
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
XSteering switch
Volume control switch
zPress the “+” side to increase the volume.
zPress the “-” side to decrease the volume.
Off hook switch
On hook switch
XMicrophone
USING THE PHONE SWITCH/
MICROPHONE
By pressing the phone switch, a call
can be received or ended without tak-
ing your hands off the steering wheel.
The microphone is used when talking
on the phone.
INFORMATION
●The other party’s voice will be heard
from the front speakers. The audio sys-
tem will be muted during phone calls.
●Talk alternately with the other party on
the phone. If you talk at the same time,
your voices may not reach each other. (It
is not a malfunction.)
●Keep the volume of receiving voice
down. Otherwise, an echo will be heard
and receiving voice can be heard out-
side of the vehicle. When you talk on the
phone, speak clearly towards the micro-
phone.
●In the following situations, your voice
may not reach the other party.
• Driving on an unpaved road. (Due to
traffic noise.)
• Driving at high speed.
• A window is open.
• Turning the air-conditioning vents
towards the microphone.
• The sound of the air-conditioning fan is
loud.
• There is an effect from the cellular
phone network.
79
1. BASIC INFORMATION BEFORE OPERATION
3
Bluetooth® HANDS-FREE SYSTEM
DA_EXT_COROLLA_touch screen_EE
zThe following data is stored for every reg-
istered phone. When another phone is
connecting, you cannot read the regis-
tered data.
• Phone book data
• Call history data zYou can initialize the following data in the
system.
• Phone book data
• Call history data
• Volume setting
• Bluetooth® setting
• All telephone settings
• Short message template
ABOUT THE PHONE BOOK IN
THIS SYSTEM
INFORMATION
●When you delete the phone, the above-
mentioned data is also deleted.
WHEN YOU RELEASE YOUR
CAR
A lot of personal data is registered
when you use the Hands-free system.
When you release your car, initialize
your data. (→P.116)
INFORMATION
●Once the data is initialized, all personal
data will be erased. Pay due care when
initializing the data.
80
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
1Press the button.
2Select “Yes”.
zThis screen can be displayed by pressing
the switch on the steering wheel.
3Follow the steps “PAIRING A
Bluetooth® DEVICE”. (→P.120, 127)
CONNECTING A Bluetooth®
PHONE
In order to use the hands-free system,
it is necessary to pair the phone and
connect the phone’s profile (HFP) with
the system.
Once the profile has been connected,
hands-free calls can be made.
If you have not yet connected any
Bluetooth® phones with phone profile
(HFP), you must first connect your
phone with phone profile (HFP)
according to the following procedure.
Connect your Bluetooth® phone with
phone profile (HFP) after bringing the
vehicle to a complete stop.
81
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
3. REGISTERING AN ENTRY
1Display the “Phone” menu screen and
select “Contacts”. (→P.74)
2Select the “Stored” tab.
3Select “Create new entry”.
4Select one of 4 phone types ( ,
, or ) and enter a
number.
zYou can enter one phone number for each
phone type.
5Select .
6Enter the entry name and then select
“OK”.
7Check that the entry is registered in the
“Stored” list.
1Display the “Phone” menu screen.
(→P.74)
2Select “Dial”.
3Enter the numbers.
4Select .
5Follow the steps “REGISTERING
FROM THE “Contacts” SCREEN” from
“STEP 6”. (→P.81)
REGISTERING A NEW ENTRY
Up to 200 numbers can be registered
with this system.
REGISTERING FROM THE
“Contacts” SCREEN
zSelect to display and edit the
entry information. (→P.83)
REGISTERING FROM THE
“Dial” SCREEN
INFORMATION
●The phone type is registered as .
82
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
1Search the entry by “Phone book”.
(→P.86)
2Select for desired item.
3Select “Add to stored contacts”.
4Follow the steps “REGISTERING
FROM THE “Contacts” SCREEN” from
“STEP 6”. (→P.81)
1Search for the entry by “Call lists”.
(→P.87)
2Select next to the desired item.
3Follow the steps “REGISTERING
FROM THE “Contacts” SCREEN” from
“STEP 6”. (→P.81)
REGISTERING FROM THE
“Phone book” SCREEN
INFORMATION
●The phone type is registered as .
●Navigation system only: If the contact
includes an address and a phone num-
ber, they will be stored in the “Stored” list
on the “My destinations” screen and
“Contacts” screen. (→P.81, 200)
REGISTERING FROM THE “Call
lists” SCREEN
INFORMATION
●The phone type is registered as .
REGISTERING FROM AN
EXTERNAL DEVICE∗
“vCard” formatted data can be trans-
ferred from a USB memory to this sys-
tem. Transferred addresses and
numbers will be stored in the “Stored”
list on the “My destinations” screen and
“Contacts” screen. (→P.81, 200)
∗: Navigation system only
83
1. BASIC INFORMATION BEFORE OPERATION
3
Bluetooth® HANDS-FREE SYSTEM
DA_EXT_COROLLA_touch screen_EE
1Display the “Phone” menu screen and
select “Contacts”. (→P.74)
2Select the “Stored” tab or the “Phone
book” tab.
3Select next to the desired entry.
XEntry options screen of the “Stored” list
XEntry options screen of the “Phone
book” list
DISPLAYING AND EDITING
THE ENTRY INFORMATION
Detailed information of entries in the
list can be displayed or edited.
No. Function
Select to display the details of the
entry information.
•Select the desired entry to call it.
Select to change the entry name. (→
P.84)
Select to edit phone numbers. (→
P.84)
Select to delete the entry.
Select to delete all entries.
Select to register the entry in the
“Stored” list on the “My destinations”
screen (navigation system only) and
“Contacts” screen. (→ P.82, 200)
84
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select “Rename”.
2Enter the entry name and then select
“OK”.
1Select “Edit phone numbers”.
2Select one of 4 phone types and enter
a number and then .
CHANGING THE ENTRY NAME
EDITING PHONE NUMBERS
INFORMATION
●If an entry that is transferred from a cel-
lular phone is edited, the change will
affect the entry in the “Stored” list on the
“My destinations” screen (navigation
system only) and “Contacts” screen.
(→P.81, 200)
SENDING STORED
CONTACTS TO A USB
MEMORY∗
The entries stored in the “Stored” list
on the “My destinations” screen and
“Contacts” screen can be transferred
to a USB memory. (→P.209)
∗: Navigation system only
85
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
2. PHONE OPERATION
1. CALLING ON A Bluetooth® PHONE
1Display the “Phone” menu screen and
select “Dial”. (→P.74)
2Enter a phone number.
3Select .
4Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
After a Bluetooth® phone has been
connected, a call can be made using
the hands-free system.
How to make a call list Page
By dial 85
By contacts list 86
By phone book 86
By call lists 87
By using a short message 88
By POI call∗88
By selecting SOS screen button∗89
By using the Toyota Eurocare∗230
∗: Navigation system only
BY DIAL
INFORMATION
●Depending on the type of Bluetooth®
phone being connected, it may be nec-
essary to perform additional steps on
the telephone.
●When “Dial” is selected, the last dialed
number will be shown grayed out. Select
to redial the number.
●Navigation system only: Select “0/+” to
enter “0”. Select and hold to enter “+” for
international calls.
●When the missed calls icon or new short
message icon is displayed at the bot-
tom, selecting the icon will display the
list.
86
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the “Phone” menu screen and
select “Contacts”. (→P.74)
2Select the “Stored” tab.
3Select the desired entry.
zIf there are 2 or more phone numbers,
select the desired number in the list.
4Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
1Display the “Phone” menu screen and
select “Contacts”. (→P.74)
2Select the “Phone book” tab.
3Select the desired entry.
zIf there are 2 or more phone numbers,
select the desired number in the list.
“Search contact”: Select to search by the
contact’s name.
4Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
BY CONTACTS LIST
To use this function, it is necessary to
register the entry. (→P.81)
zSelect to display and edit the
entry information. (→P.83)
BY PHONE BOOK
Calls can be made using the phone
book data of the connected cellular
phone. The phone book changes de-
pending on the phone connected.
zSelect to display and edit the
entry information. (→P.8 3)
87
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
1Display the “Phone” menu screen and
select “Call lists”. (→P.74)
2Select the desired tab.
zThe state of a call is shown by the follow-
ing icons.
: Missed
: Received
: Dialed
INFORMATION
●When a phone is connected for the first
time, its phone book must be down-
loaded. If the phone book can not be
downloaded, a pop-up window will be
displayed.
●If the contact does not have phone num-
ber stored, the entry will be dimmed.
●The phone book list can be updated.
(→P.139)
BY CALL LISTS
Each call list (missed, received, and di-
aled) stores up to 15 entries.
No. Function
Select to display all numbers.
Select to display missed calls.
Select to display received calls.
Select to display dialed numbers.
88
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
3Select the desired entry.
4Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
1Select “Call sender”.
2Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
1Select .
2Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
zWhen is selected, the entry is
registered in the “Stored” list on the
“Contacts” screen. (→P.82 )
CALLING USING A SHORT
MESSAGE
Calls can be made to a short message
sender’s phone number. (→P.95)
BY POI CALL∗
Calls can be made to a POI when its
details are displayed on the screen.
(→P.173, 181)
∗: Navigation system only
89
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
1Display the “Phone” menu screen and
select “Dial”. (→P.74)
2Select “SOS”.
3Select “Yes” when the confirmation
screen appears.
4The following screen will be displayed.
zThe geographic coordinates of the current
location will be displayed at the top-left cor-
ner of the screen.
zWhen “...” appears on the screen, select
to display the following position details.
On freeways: Freeway number, driving
direction and next exit.
On other roads: Address information.
Each time “...” is selected, the screen
changes between the geographical coor-
dinates and position details.
BY SELECTING SOS SCREEN
BUTTON∗
112 EMERGENCY CALL
SUPPORT
This feature is used to make a 112
emergency call with the select of a but-
ton.
This function is not available when the
hands-free system is not connected.
This call can only be placed in a coun-
try where the 112 emergency call ser-
vice is available.
∗: Navigation system only
EN2088DC
90
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
2. RECEIVING CALLS ON A Bluetooth® PHONE
1Press the switch on the steering
wheel.
“Accept”: Select to talk on the phone.
“Reject”: Select to reject the call.
zThe layout of the incoming call screen
may differ depending on the information
available from the connected phone.
zPressing the switch on the steering
wheel also reject a call.
zRingtone volume can be adjusted by turn-
ing the power/volume knob.
2The following screen is displayed.
XSingle call
zFor details about this screen: →P.91
XCall waiting
zThe first call is put on hold and the infor-
mation of the party will be dimmed.
zFor details about this screen: →P.91
When a call is received, this screen is
displayed and a sound is heard.
INFORMATION
●During international telephone calls, the
other party’s name or number may not
be displayed correctly depending on the
type of cellular phone you have.
●Ringtone and ringtone volume can also
be set. (→P.139)
EN2089DC
91
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
3. TALKING ON A Bluetooth® PHONE
XSingle call
XCall waiting
While you are talking on a Bluetooth®
phone, a telephone conversation
screen is displayed. The operations
outlined below can be performed on
this screen.
No. Function
Select to hang up the phone.
•The switch on the steering
wheel can also be pressed to
hang up the phone.
Select to dial a second number.
(→P.93)
Select to put a call on hold. To
cancel this function, select “Acti-
vate”.
Select to send a tone. (→P.92)
Select to transfer the call. Select
“Transfer” to change from a
hands-free call to a cellular
phone call. Select “Hands-free”
to change from cellular phone
call to hands-free call.
Displays the other party’s infor-
mation. The information shown
here may differ depending on the
information available from your
phone.
Displays a call duration.
Select to mute your voice to the
other party. The icon will be high-
lighted during mute mode. To
cancel muting your voice, select
this icon again.
Select to change parties.
Select to change to a conference
call.
入れ替え
3
キャプション変更
キャプションイキ
EN2089DC
92
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select “Keypad”.
2Enter the numbers.
zSelect to return the previous
screen.
INFORMATION
●When you change from a cellular phone
call to a hands-free call, the hands-free
screen will be displayed and the call can
be operated on the screen.
●Depending on the cellular phone con-
nected, the Bluetooth® connection may
be canceled if and when a call is trans-
ferred to the cellular phone.
●Transferring methods will be different
depending on the type of cellular phone
which you have.
●For the operation of the cellular phone,
see the manual that comes with your
cellular phone.
SENDING TONES
93
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
1Select “Dial”.
2Select the desired method to call.
XWhen “Dial number” is selected
3Enter the number and then select
.
XWhen “Dial from contacts” is selected
3Select the desired list and then select
the desired entry.
XWhen “Dial from call lists” is selected
3Select the desired list and then select
the desired entry.
4Check that the connecting screen is
displayed.
zTo cancel a call, select “End call”.
5When a new call has been established,
the following screen will be displayed.
zThe first call is put on hold and the infor-
mation of the party will be dimmed.
zThe second call’s information is displayed
below the first call information.
DIALING A SECOND NUMBER
94
2. PHONE OPERATION
DA_EXT_COROLLA_touch screen_EE
■CHANGING PARTIES
1Select “Swap calls”.
zEvery time “Swap calls” is selected, the
party who is on hold will be switched.
zThe other party can also be switched by
selecting the picture of the desired party
(navigation system only) or pressing the
switch on the steering wheel.
■CHANGING TO A CONFERENCE
CALL
1Select “Link calls”.
1Turn the power/volume knob to adjust
the volume of the other party’s voice.
INFORMATION
●Interrupt call operation may differ
depending on your phone company and
cellular phone.
ADJUSTING THE RECEIVER
VOLUME
INFORMATION
●The receiver volume can also be
adjusted using the volume control switch
on the steering wheel.
95
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
3. SHORT MESSAGE FUNCTION
1. SHORT MESSAGE FUNCTION
1Select “Show” to check a received
short message.
2Check that the message is displayed.
1Display the “Phone” menu screen and
select “Messages”. (→P.74)
2Select the “Inbox” tab.
3Select the desired short message.
zThe state of a message is shown by the
following icons.
: Read message
: Unread message
4Check that the message is displayed.
Received short messages can be for-
warded from the connected Bluetooth®
phone, enabling checking and replying
using this system.
Depending on the type of Bluetooth®
phone connected, received short mes-
sage may not be transferred to the
message inbox.
If the phone does not support the short
message function, this function cannot
be used.
RECEIVING A SHORT
MESSAGE
When a new short message is re-
ceived, a pop-up window is displayed
on the screen.
INFORMATION
●This function can be set to on or off.
(→P.139)
CHECKING RECEIVED
SHORT MESSAGES
No. Function
Select to call the sender.
Select to reply to the short message
by free text.
Select to reply to the short message
by template.
96
3. SHORT MESSAGE FUNCTION
DA_EXT_COROLLA_touch screen_EE
1Select “Reply free text” or “Reply
template”.
zWhen “Reply template” is selected,
select the desired template.
2Enter the message and then select
“OK”.
zThe short message will be sent.
1Display the “Phone” menu screen and
select “Messages”. (→P.74)
2Select the “Sent” tab.
3Select the desired short message.
zNavigation system only: The state of a
message is shown by the following icons.
: Sent succeeded
: Sent failed
: Sending
4Check that the message is displayed.
“Re-send”∗: Select to re-send the mes-
sage.
z“Re-send” is displayed if sending the text
message has failed.
REPLYING TO A SHORT
MESSAGE
INFORMATION
●“Reply free text” function is not available
while driving.
CHECKING SENT SHORT
MESSAGES
∗: Navigation system only
97
3. SHORT MESSAGE FUNCTION
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
1Display the “Phone” menu screen and
select “Messages”. (→P.74)
2Select the “Create new” tab.
3Select “Create message” or “Use
template”.
4Enter the message and then select
“OK”. (→P.98)
5Select the desired number/contact to
whom the short message should be
sent.
XWhen “New number” is selected
6Enter the number and then select
“OK”.
zThe short message will be sent.
XWhen “Select contact” or “Select
from call lists” is selected
6Select the desired list.
7Select the desired contact.
zIf there are 2 or more phone numbers,
select the desired number in the list.
zThe short message will be sent.
SENDING A NEW SHORT
MESSAGE
INFORMATION
●The “Create message” and “Prepare
template message” functions are not
available while driving.
98
3. SHORT MESSAGE FUNCTION
DA_EXT_COROLLA_touch screen_EE
■WHEN “Create message” IS SE-
LECTED
1Enter the message and then select
“OK”.
■WHEN “Use template” IS SELECT-
ED
1Select the desired template.
: Select to delete the template.
2Edit the short message and then select
“OK”.
CREATE A NEW SHORT
MESSAGE INFORMATION
●10 messages have already been regis-
tered to the message template screen.
●Navigation system only: When route
guidance is currently active, “I will arrive
at XX:XX.” template is available.
(“XX:XX” is the current estimated time of
arrival.) This template cannot be
deleted.
●The cursor’s position can be moved by
selecting the desired location in the
enter screen.
●The short messages can contain up to
160 characters. If the entered text
exceeds the characters available for one
short message, a new short message
will begin automatically. This is indicated
by a separation line and an icon in the
enter field, which is shown as soon as
there are only 10 characters left for the
short message.
●The number of characters left for the
short message is displayed.
●A maximum of 3 short messages can be
written in series.
●Entering the text function is not available
while driving.
100
DA_EXT_COROLLA_touch screen_EE
4. WHAT TO DO IF...
1. TROUBLESHOOTING
XWhen using the hands-free system with a Bluetooth® device
If there is a problem with the hands-free system or a Bluetooth® device, first check
the table below.
Symptom Likely cause Solution
Page
Cellular
phone
This
system
The hands-free sys-
tem or Bluetooth®
device does not
work.
The connected de-
vice may not be a
compatible
Bluetooth® cellular
phone.
For a list of specific
devices which opera-
tion has been con-
firmed on this
system, check with
your Toyota dealer.
∗
The Bluetooth® ver-
sion of the connected
cellular phone may
be older than the
specified version.
Use a cellular phone
with Bluetooth® ver-
sion 1.1 or higher
(recommended: Ver.
3.0 +EDR or higher).
∗122, 132
101
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
XWhen pairing/connecting a cellular phone
Symptom Likely cause Solution
Page
Cellular
phone
This
system
A cellular phone can-
not be paired.
An incorrect pass-
code was entered on
the cellular phone.
Enter the correct
passcode on the cel-
lular phone.
∗
The pairing operation
has not been com-
pleted on the cellular
phone side.
Complete the pairing
operation on the cel-
lular phone (approve
pairing on the tele-
phone).
∗
Old pairing informa-
tion remains on ei-
ther this system or
the cellular phone.
Delete the existing
pairing information
from both this system
and the cellular
phone, then pair the
cellular phone you
wish to connect to
this system.
∗124, 134
102
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
A Bluetooth® con-
nection cannot be
made.
Another Bluetooth®
device is already
connected.
Manually connect the
cellular phone you
wish to use to this
system.
124, 134
Bluetooth® function
is not enabled on the
cellular phone.
Enable the
Bluetooth® function
on the cellular
phone.
∗
Automatic
Bluetooth® connec-
tion on this system is
set to off.
XVehicles with-
out smart entry
& start system
Set automatic
Bluetooth®
connection on this
system to on when
the engine switch is
turned to the “ACC”
or “ON” position.
XVehicles with
smart entry &
start system
Set automatic
Bluetooth®
connection on this
system to on when
the engine switch is
turned to
ACCESSORY or
IGNITION ON mode.
119, 126
Old registration infor-
mation remains on
either this system or
the cellular phone.
Delete the existing
registration informa-
tion from both this
system and the cellu-
lar phone, then regis-
ter the cellular phone
you wish to connect
to this system.
∗124, 134
Symptom Likely cause Solution
Page
Cellular
phone
This
system
103
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
XWhen making/receiving a call
XWhen using the phone book
Symptom Likely cause Solution
Page
Cellular
phone
This
system
A call cannot be
made/received.
Your vehicle is in a
no service area.
Move to an area
where the service
signal appears on
the display.
Symptom Likely cause Solution
Page
Cellular
phone
This
system
Phone book data
cannot be trans-
ferred manually/au-
tomatically.
The profile version of
the connected cellu-
lar phone may not be
compatible with
transferring phone
book data.
For a list of specific
devices which opera-
tion has been con-
firmed on this
system, check with
your Toyota dealer.
∗
Transfer operation
on the cellular phone
has not completed.
Complete transfer
operation on the cel-
lular phone (approve
transfer operation on
the phone).
∗
104
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
XWhen using the Bluetooth® message function
Symptom Likely cause Solution
Page
Cellular
phone
This
system
Messages cannot be
viewed.
Message transfer is
not enabled on the
cellular phone.
Enable message
transfer on the cellu-
lar phone (approve
message transfer on
the telephone).
∗
New message notifi-
cations are not dis-
played.
Notification of
SMS/E-mail recep-
tion on this system is
set to off.
Set notification of
SMS/E-mail recep-
tion on this system to
on.
∗139
105
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
3
Bluetooth® HANDS-FREE SYSTEM
XIn other situations
∗: For details, refer to the owner’s manual that came with the cellular phone.
Symptom Likely cause Solution
Page
Cellular
phone
This
system
Even though all con-
ceivable measures
have been taken, the
symptom status does
not change.
The cellular phone is
not close enough to
this system.
Bring the cellular
phone closer to this
system.
Radio interference
has occurred.
Turn off Wi-Fi® de-
vices or other devic-
es that may emit
radio waves.
The cellular phone is
the most likely cause
of the symptom.
Turn the cellular
phone off, remove
and reinstall the bat-
tery pack, and then
restart the cellular
phone.
∗
Enable the cellular
phone’s Bluetooth®
connection.
∗
Disable the Wi-Fi®
connection of the cel-
lular phone.
∗
Stop the cellular
phone’s security soft-
ware and close all
applications.
∗
Before using an ap-
plication installed on
the cellular phone,
carefully check its
source and how its
operation might af-
fect this system.
∗
106
4. WHAT TO DO IF...
DA_EXT_COROLLA_touch screen_EE
109
DA_EXT_COROLLA_touch screen_EE
1. VEHICLE INFORMATION
4
VEHICLE INFORMATION
2. FUEL CONSUMPTION
*: The average fuel consumption displayed
on the multi-information display will also be
updated.
TRIP INFORMATION
No. Information/Function
Average speed
Cruising range
Current fuel consumption per
minute
Select to delete trip information da-
ta.
Elapsed time
Previous fuel consumption per
minute
INFORMATION
●The trip information display indicates
general driving conditions. Accuracy
varies with driving habits and road con-
ditions.
●The image is an example only, and may
vary slightly from actual conditions.
PAST RECORD
No. Information/Function
Best recorded fuel economy
Current fuel economy
Select to delete past record data.
Select to update the average fuel
consumption data.*
Previous fuel economy record
INFORMATION
●The image is an example only, and may
vary slightly from actual conditions.
110
1. VEHICLE INFORMATION
DA_EXT_COROLLA_touch screen_EE
5
111
1
2
3
4
6
7
DA_EXT_COROLLA_touch screen_EE
5
8
1. QUICK REFERENCE .................. 112
2. GENERAL SETTINGS................. 114
GENERAL SETTINGS SCREEN ........ 114
3. DISPLAY SETTINGS................... 117
4. Bluetooth® SETTINGS ............... 119
Bluetooth® FUNCTION ON/OFF......... 119
PAIRING A Bluetooth® DEVICE ......... 120
PAIRED DEVICE LIST........................ 124
SETTING PIN...................................... 125
EDITING THE SYSTEM NAME .......... 125
5. CONNECTIVITY SETTINGS ....... 126
Bluetooth® SETTINGS ........................ 126
QUICK SETUP OF AN INTERNET
CONNECTION.................................. 136
TOYOTA WEB ACCOUNT
SETTINGS........................................ 136
6. TELEPHONE SETTINGS ............ 139
7. AUDIO SETTINGS....................... 140
8. VEHICLE SETTINGS................... 142
1SETUP OPERATION
SETUP
Some of the functions cannot be operated while driving.
112
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
1. QUICK REFERENCE
■“Setup” SCREEN
XMultimedia system
XNavigation system
To customise the function settings, press the “SETUP” button.
イラスト再挿入
113
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
No. Function Page
Select to set language, operation sound, etc. 114
Select to adjust the contrast and brightness of the screens, turn the screen
off, etc. 117
Select to adjust sound. 140
Select to connect to Bluetooth® device. Settings are available for Bluetooth®
phones and Bluetooth® audio devices. 119
Select to connect. Settings are available for Bluetooth® phones, Bluetooth®
audio devices, internet devices via Bluetooth®, internet connection methods
and Toyota web account.
126
Select to adjust phone sound, set a phone book, etc. 139
Select to customise the vehicle. 142
115
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
No. Function
Select to change the language.
Select to set the volume for the
phone/navigation. (→P.116)
∗1Select to change the unit of mea-
sure for distance.
Select to set the sounds beeps on/
off.
∗2Select to set animations on/off.
Select to set the automatic text
scrolling on/off. This function is not
available while driving.
∗1
The entries stored in the “Stored”
list on the “My destinations” screen
and “Contacts” screen (→P.81,
200) can be transferred to a USB
memory. (→P.209)
∗1
“vCard” formatted data can be
transferred from a USB memory to
this system. Transferred address-
es and numbers will be stored in
the “Stored” list on the “My desti-
nations” screen and “Contacts”
screen. (→P.210)
Select to delete all personal data
stored in this system. (→P.116)
XMultimedia system
Select to display the system infor-
mation.
XNavigation system
Select to display the system infor-
mation.
Select the “Audio information”
on the screen to switch the system
information screen.
Select to display an open source
information.
Notices related to third party soft-
ware used in this product are en-
listed. (This includes instructions
for obtaining such software, where
applicable.)
∗1: Navigation system only
∗2: Multimedia system only
INFORMATION
●The current setting of each item is dis-
played on its right.
No. Function
116
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the general settings screen.
(→P.114)
2Select “Volume settings”.
3Select “+” or “-” to adjust the a vol-
ume.
1Display the general settings screen.
(→P.114)
2Select “Delete all personal data”.
3Select “Yes” when the confirmation
screen appears.
zRegistered or changed personal settings
will be deleted or returned to their default
conditions.
VOLUME SETTINGS
Volume is shown numerically for each
of the different functions.
No. Item
∗Navigation prompt volume.
Reception volume for phone calls
Sending volume for phone calls
Ringtone volume.
∗: Navigation system only
DELETE ALL PERSONAL DATA
117
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
5
SETUP
3. DISPLAY SETTINGS
1Display the “Setup” screen. (→P.112)
2Select “Display”.
3Select items to be set.
The contrast and brightness of the
screen display and the image of the
camera display can be adjusted. The
screen can also be turned off, and/or
changed to either day or night mode.
No. Function Page
Select to set day mode on/
off. 118
Select to turn the screen
off. To turn it on, press any
button on the audio panel.
Select or to adjust
the contrast of display.
•: Increases the con-
trast of the screen
•: Decreases the con-
trast of the screen
Select or to adjust
the brightness of display.
•: Brightens the
screen
•: Darkens the screen
Select to adjust the camera
display. 118
INFORMATION
●Contrast and brightness can be adjusted
by touching and dragging the marker on
the screen with your finger or touching
the desired position on the scale.
118
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the display settings screen.
(→P.117)
2Select “Day mode”.
1Display the display settings screen.
(→P.117)
2Select “Camera”.
3Select or to adjust the contrast
or brightness.
CHANGING BETWEEN DAY
AND NIGHT MODE
Depending on the position of the head-
light switch, the screen changes to day
or night mode. This feature is available
when the headlight is switched on.
INFORMATION
●If the screen is set to day mode with the
headlight switch turned on, this condition
is memorized even when the engine
switch is in the following status.
XVehicles without a smart entry & start
system
The engine switch is turned to the
“LOCK” position.
XVehicles with a smart entry & start sys-
tem
The engine switch is turned off.
ADJUSTING THE CAMERA
DISPLAY
The contrast and brightness of the
camera display can be adjusted.
No. Function
Contrast
: Increases the
contrast of the screen
: Decreases the
contrast of the screen
Bright-
ness
: Brightens the
screen
: Darkens the
screen
INFORMATION
●Contrast and brightness can be adjusted
by touching and dragging the marker on
the screen with your finger or touching
the desired position on the scale.
119
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
5
SETUP
4. Bluetooth® SETTINGS
1Display the “Setup” screen. (→P.112)
2Select “Bluetooth*”.
3The following screen will be displayed. 1Display the Bluetooth® settings
screen. (→P.119)
2Select “Bluetooth*”.
When “Bluetooth*” is on:
XVehicles without smart entry & start sys-
tem
The Bluetooth® device is automatically
connected when the engine switch is
turned to the “ACC” or “ON” position.
XVehicles with smart entry & start system
The Bluetooth® device is automatically
connected when the engine switch is
turned to ACCESSORY or IGNITION ON
mode.
When “Bluetooth*” is off:
The Bluetooth® device is disconnected,
and the system will not connect to it next
time.
zEven if the Bluetooth® function is set to
off, it will turn on automatically when a
phone or other Bluetooth® device is con-
nected.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Function Page
Bluetooth® function on/off 119
Pairing a Bluetooth® device 120
Paired device list 124
Editing the system name 125
Setting PIN 125
Bluetooth® FUNCTION ON/
OFF
120
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the Bluetooth® settings
screen. (→P.119)
2Select “Add new device”.
XWhen another Bluetooth® device is con-
nected
zTo disconnect the Bluetooth® device,
select “YES”.
XWhen 4 Bluetooth® devices have al-
ready been paired
zA paired device needs to be replaced.
Select “OK”, and select the device to be
replaced.
3When this screen is displayed, search
for the device on the screen of your
Bluetooth® device.
zTo cancel the registration, select “Can-
cel”.
4Pairing the Bluetooth® device using
your Bluetooth® device.
zA PIN code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth® devices. Depending on the
type of Bluetooth® device being con-
nected a message confirming registration
may be displayed on the Bluetooth®
device’s screen. Respond and operate the
Bluetooth® device according to the confir-
mation message.
5Check that the following screen is dis-
played.
XIf the automatic connection failed, the
following screen will be displayed. Se-
lect the desired profile to be connected.
PAIRING A Bluetooth®
DEVICE
Up to 4 Bluetooth® devices can be
paired. A paired device can be con-
nected to any of its supported profiles
such as phone (HFP), music (A2DP).
ADDING A NEW DEVICE
No. Function Page
Select to connect the
phone profile. 124
Select to connect the music
profile. 124
Select to connect all pro-
files. 124
121
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
zOnce you have connected the Bluetooth®
device, it is automatically connected
whenever the engine switch is in the fol-
lowing status.
XVehicles without smart entry & start sys-
tem
The engine switch is turned to the “ACC”
or “ON” position.
XVehicles with smart entry & start system
The engine switch is turned to ACCESSO-
RY or IGNITION ON mode.
zIf the Bluetooth® device is disconnected
on purpose, such as it was turned off, this
does not happen. Reconnect it manually
using either of the following methods:
• Select a Bluetooth® device again.
(→P.124)
• Connect the audio profile/phone profile.
(→P.124)
INFORMATION
●For details on device detection and the
operation of your Bluetooth® device, see
the manual that comes with the
Bluetooth® device.
●The music profiles the paired device
supports can be connected individually
as desired. Some devices do not allow
individual profiles to be connected. In
that case, a pop-up window is displayed.
RECONNECTING Bluetooth®
DEVICE
If a Bluetooth® device is disconnected
due to poor reception from the
Bluetooth® network when the engine
switch is in the following status, the
system will automatically reconnect
the Bluetooth® device.
XVehicles without smart entry & start
system
The engine switch is turned to the
“ACC” or “ON” position.
XVehicles with smart entry & start sys-
tem
The engine switch is turned to ACCES-
SORY or IGNITION ON mode.
122
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
PROFILES
This system supports the following services.
Bluetooth®
device Specification Function Require-
ments
Recom-
menda-
tions
Bluetooth®
Phone/
Bluetooth®
Audio Play-
er
Bluetooth® Specification
Registering a
Bluetooth®
device
Ver. 1.1 Ver. 3.0
+EDR
Bluetooth®
device Profile Function Require-
ments
Recom-
menda-
tions
Bluetooth®
Phone
HFP (Hands-Free Profile) Hands-free
system Ver. 1.0 Ver. 1.6
PBAP (Phone Book Access
Profile)
Transferring the
contacts Ver. 1.0 Ver. 1.1
MAP (Message Access Profile) Bluetooth®
phone message Ver. 1.0
Bluetooth®
Audio Play-
er
A2DP (Advanced Audio
Distribution Profile) Bluetooth®
audio system
Ver. 1.0 Ver. 1.2
AVRCP (Audio/Video Remote
Control Profile) Ver. 1.0 Ver. 1.4
INFORMATION
●If your cellular phone does not support HFP, registering the Bluetooth® phone or using
PBAP or MAP profiles individually will not be possible.
●If the connected Bluetooth® device version is older than recommended or incompatible,
the Bluetooth® device function may not work properly.
123
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
STATUS DISPLAY
The condition of the Bluetooth® con-
nection, as well as the level of recep-
tion and the amount of device battery
charge left, are displayed on the status
bar.
No. Function
Displays the charge level of the de-
vice’s battery
•The amount displayed does not
always correspond with the
amount displayed on the device.
The amount of battery charge left
may not be displayed depending
on the device. This system does
not have a charging function.
•If this information is not available
from the connected device, the
icon will be shown with a question
mark.
Displays the level of reception
•The level of reception does not
always correspond with the level
displayed on the device.
•The level of reception may not be
displayed depending on the
device.
•If this information is not available
from the connected device, the
icon will be shown with a question
mark.
“R” is displayed when receiving in a
roaming area.
•The receiving area may not be
displayed depending on the
phone.
INFORMATION
●An antenna for the Bluetooth® connec-
tion is built into the instrument panel.
The system may not function when you
use the Bluetooth® device in the follow-
ing conditions and places:
• When the device is obstructed by cer-
tain objects (such as when it is behind
the seat or in the glove box and con-
sole box).
• When the device touches or is covered
with metal materials.
124
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the Bluetooth® settings
screen. (→P.119)
2Select “Paired device list”.
3Select the desired device.
zDimmed icons can be selected to connect
to the function directly.
zThe tone of the icons show which profiles
the device supports. (Dimmed icons are
not available.)
zThe device’s currently connected profiles
are highlighted.
4Check that the following screen is dis-
played.
1Select “Rename”.
2Enter the device name and then select
“OK”.
1Select “Delete pairing”.
2Select “Yes” when the confirmation
screen appears.
PAIRED DEVICE LIST
Each profile connection status can be
changed using the “Paired device list”.
No. Function Page
Select to change the de-
vice name. 124
Select to delete the paired
device. 124
Select to connect/discon-
nect individually a paired
device’s profiles.
XWhen “Connect all”
displayed
•Select to connect all sup-
ported profiles.
XWhen “Disconnect all”
displayed
•Select to disconnect all
supported profiles.
CHANGING THE DEVICE NAME
DELETING A PAIRED DEVICE
125
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
1Display the Bluetooth® settings
screen. (→P.119)
2Select “Set PIN for pairing”.
3Enter the desired number and then se-
lect “OK”.
zA PIN code must be 4 digits.
1Display the Bluetooth® settings
screen. (→P.119)
2Select “Set system name”.
3Enter a name and then select “OK”.
SETTING PIN
EDITING THE SYSTEM NAME
126
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
5. CONNECTIVITY SETTINGS∗
1Display the “Setup” screen. (→P.112)
2Select “Connectivity”.
3Select items to be set.
1Display the connectivity settings
screen. (→P.126)
2Select “Bluetooth*”.
3Select items to be set.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Settings are available for Bluetooth®
devices, internet connection methods
and Toyota web account.
No. Function Page
Select to display a sub-
menu for Bluetooth® where
you can connect phone,
audio devices and internet
devices via Bluetooth®.
126
Select to search for avail-
able internet connection
methods.
136
Select to add or change
your Toyota web account. 136
∗: Navigation system only
Bluetooth® SETTINGS
Function Page
Bluetooth® function on/off 127
Pairing a Bluetooth® device 127
Paired device list 134
Setting the system name and PIN 135
Setting charge warnings 135
127
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
1Select “Bluetooth*”.
When “Bluetooth*” is on:
XVehicles without smart entry & start sys-
tem
The Bluetooth® device is automatically
connected when the engine switch is
turned to the “ACC” or “ON” position.
XVehicles with smart entry & start system
The Bluetooth® device is automatically
connected when the engine switch is
turned to ACCESSORY or IGNITION ON
mode.
When “Bluetooth*” is off:
The Bluetooth® device is disconnected,
and the system will not connect to it next
time.
zEven if the Bluetooth® function is set to
off, it will turn on automatically when a
phone or other Bluetooth® device is con-
nected.
■PAIRING FROM THE SYSTEM
1Select “Search device”.
XWhen another Bluetooth® device is con-
nected
zTo disconnect the Bluetooth® device,
select “YES”.
XWhen 4 Bluetooth® devices have al-
ready been paired
zA paired device needs to be replaced.
Select “OK”, and select the device to be
replaced.
2Select the desired device.
zConnectable Bluetooth® devices will be
displayed in the list.
*: Bluetooth is a registered trademark of
Bluetooth SIG, Inc.
Bluetooth® FUNCTION ON/OFF PAIRING A Bluetooth® DEVICE
Up to 4 Bluetooth® devices can be
paired. A paired device can be con-
nected to any of its supported profiles
such as phone (HFP), music (A2DP)
and/or internet (DUN/PAN).
128
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
3Confirm the PIN.
zA PIN code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth® devices. Depending on the
type of Bluetooth® device being con-
nected a message confirming registration
may be displayed on the Bluetooth®
device’s screen. Respond and operate the
Bluetooth® device according to the confir-
mation message.
4Check that the following screen is dis-
played.
zThe system waits for connection requests
coming from the paired device. All
requested profiles are connected automat-
ically.
zInternet profile is not connected automati-
cally. For details on connecting internet
profile (→P.130).
XIf the automatic connection failed, the
following screen will be displayed. Se-
lect the desired profile to be connected.
No. Function Page
Select to connect the
phone profile. 134
Select to connect the music
profile. 134
Select to connect the inter-
net profile.
130,
134
Select to connect all pro-
files. 134
129
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
zOnce you have connected the Bluetooth®
device, it is automatically connected
whenever the engine switch is in the fol-
lowing status.
XVehicles without smart entry & start sys-
tem
The engine switch is turned to the “ACC”
or “ON” position.
XVehicles with smart entry & start system
The engine switch is turned to ACCESSO-
RY or IGNITION ON mode.
■PAIRING FROM THE DEVICE
1Select “Make system discoverable”.
XWhen another Bluetooth® device is con-
nected
zTo disconnect the Bluetooth® device,
select “YES”.
XWhen 4 Bluetooth® devices have al-
ready been paired
zA paired device needs to be replaced.
Select “OK”, and select the device to be
replaced.
2When this screen is displayed, search
for the device on the screen of your
Bluetooth® device.
zTo cancel the registration, select “Can-
cel”.
3Pairing the Bluetooth® device using
your Bluetooth® device.
zA PIN code is not required for SSP
(Secure Simple Pairing) compatible
Bluetooth® devices. Depending on the
type of Bluetooth® device being con-
nected a message confirming registration
may be displayed on the Bluetooth®
device’s screen. Respond and operate the
Bluetooth® device according to the confir-
mation message.
INFORMATION
●For details on device detection and the
operation of your Bluetooth® device, see
the manual that comes with the
Bluetooth® device.
●The music profiles the paired device
supports can be connected individually
as desired. Some devices do not allow
individual profiles to be connected. In
that case, a pop-up window is displayed.
130
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
■LOGIN PROCESS INTERNET PRO-
FILE
XIf “Connect for Internet” is selected
1Select “Connect for Internet”.
zIf the automatic connection failed, the fol-
lowing screen will be displayed. Select the
desired provider to be connected.
2Select the desired provider.
3Select “Provider username”, “Pro-
vide password” or “APN” and enter
the name, password or APN.
4Select “Confirm provider informa-
tion”.
XIf is selected
1Select .
2Follow the steps “LOGIN PROCESS
INTERNET PROFILE” from “STEP 2”.
(→P.130)
131
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
■RECONNECTING Bluetooth® DE-
VICE
zIf the Bluetooth® device is disconnected
on purpose, such as it was turned off, this
does not happen. Reconnect it manually
using either of the following methods:
• Select a Bluetooth® device again.
(→P.134)
• Connect the audio profile/phone profile.
(→P.134)
If a Bluetooth® device is disconnected
due to poor reception from the
Bluetooth® network when the engine
switch is in the following status, the
system will automatically reconnect
the Bluetooth® device.
XVehicles without smart entry & start
system
The engine switch is turned to the
“ACC” or “ON” position.
XVehicles with smart entry & start sys-
tem
The engine switch is turned to ACCES-
SORY or IGNITION ON mode.
132
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
■PROFILES
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
This system supports the following services.
Bluetooth®
device Specification Function Require-
ments
Recom-
menda-
tions
Bluetooth®
Phone/
Bluetooth®
Audio Play-
er
Bluetooth® Specification
Registering a
Bluetooth®
device
Ver. 1.1 Ver. 3.0
+EDR
Bluetooth®
device Profile Function Require-
ments
Recom-
menda-
tions
Bluetooth®
Phone
HFP (Hands-Free Profile) Hands-free
system Ver. 1.0 Ver. 1.6
PBAP (Phone Book Access
Profile)
Transferring the
contacts Ver. 1.0 Ver. 1.1
MAP (Message Access Profile) Bluetooth®
phone message Ver. 1.0
DUN (Dial-up Networking
Profile) Connected
service
Ver. 1.1
PAN (Personal Area Networking) Ver. 1.0
Bluetooth®
Audio Play-
er
A2DP (Advanced Audio
Distribution Profile) Bluetooth®
audio system
Ver. 1.0 Ver. 1.2
AVRCP (Audio/Video Remote
Control Profile) Ver. 1.0 Ver. 1.4
INFORMATION
●If your cellular phone does not support HFP, registering the Bluetooth® phone or using
PBAP, MAP, DUN or PAN profiles individually will not be possible.
●If the connected Bluetooth® device version is older than recommended or incompatible,
the Bluetooth® device function may not work properly.
133
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
■STATUS DISPLAY
The condition of the Bluetooth® con-
nection, as well as the level of recep-
tion and the amount of device battery
charge left, are displayed on the status
bar.
No. Function
Displays the charge level of the de-
vice’s battery
•The amount displayed does not
always correspond with the
amount displayed on the device.
The amount of battery charge left
may not be displayed depending
on the device. This system does
not have a charging function.
•If this information is not available
from the connected device, the
icon will be shown with a question
mark.
Displays the level of reception
•The level of reception does not
always correspond with the level
displayed on the device.
•The level of reception may not be
displayed depending on the
device.
•If this information is not available
from the connected device, the
icon will be shown with a question
mark.
“R” is displayed when receiving in a
roaming area.
•The receiving area may not be
displayed depending on the
phone.
INFORMATION
●An antenna for the Bluetooth® connec-
tion is built into the instrument panel.
The system may not function when you
use the Bluetooth® device in the follow-
ing conditions and places:
• When the device is obstructed by cer-
tain objects (such as when it is behind
the seat or in the glove box and con-
sole box).
• When the device touches or is covered
with metal materials.
134
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select “Paired device list”.
2Select the desired device.
zDimmed icons can be selected to connect
to the function directly.
zThe tone of the icons show which profiles
the device supports. (Dimmed icons are
not available.)
zThe device’s currently connected profiles
are highlighted.
3Check that the following screen is dis-
played.
■CHANGING THE DEVICE NAME
1Select “Rename”.
2Enter the device name and then select
“OK”.
■DELETING A PAIRED DEVICE
1Select “Delete pairing”.
2Select “Yes” when the confirmation
screen appears.
PAIRED DEVICE LIST
Each profile connection status can be
changed using the “Paired device list”.
No. Function Page
Select to change the de-
vice name. 134
Select to delete the paired
device. 134
Select to connect/discon-
nect individually a paired
device’s profiles.
XWhen “Connect all”
displayed
•Select to connect all sup-
portedprofiles.
XWhen “Disconnect all”
displayed
•Select to disconnect all
supported profiles.
135
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
1Select “Set system name and PIN”.
2Select items to be set.
1Select “Charge warnings”.
2Select items to be set.
SETTING THE SYSTEM NAME
AND PIN
No. Function
Select to enter a name. To confirm,
select “OK”.
Select to enter a desired number. To
confirm, select “OK”.
•A PIN code must be 4 digits.
SETTING CHARGE WARNINGS
No. Function
Select to set the cost warnings func-
tion on/off. When set to on, a pop-up
window will be displayed.
Select to set the roaming warning
function on/off.
136
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the connectivity settings
screen. (→P.126)
2Select “Connect me to Internet”.
zWhen an Internet connection is already
active, a popup window is displayed. To
return to the previous screen, select the
“OK”.
3Select the desired device.
zThe system search for devices which sup-
port the Internet profile.
4Select “Provider username”, “Pro-
vide password” or “APN” and enter
the name, password or APN.
5Select “Confirm provider informa-
tion”.
1Display the connectivity settings
screen. (→P.126)
2Select “Toyota web account”.
3Select items to be set.
QUICK SETUP OF AN
INTERNET CONNECTION
This function is a shortcut for an inter-
net connection.
TOYOTA WEB ACCOUNT
SETTINGS
The following detailed Toyota web ac-
count settings can be set.
No. Function
Shows active account
Select to add a new account or
change to another account.
(→P.137)
Select to receive the remotely cust-
omised vehicle settings data from
the Toyota portal site.
Select to send the vehicle’s settings
data that can be customised re-
motely to the Toyota portal site.
137
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
1Display the Toyota web account set-
tings screen. (→P.136)
2Select “Change account”.
3Select “New account” or .
4Select items to be set.
ADDING A NEW ACCOUNT OR
CHANGING AN ACCOUNT
DETAILS
No. Function
Select to enter a username. To con-
firm, select “OK”.
Select to enter a password. To con-
firm, select “OK”.
Select to turn the remember user lo-
gin information function on or off.
When this function is activated, the
entered user login information will
be remembered for every user login.
Select to turn the automatic down-
load of POIs and routes function on
or off. When this function is activat-
ed, the POIs and routes from the
server will be downloaded automati-
cally and saved in the “Stored” list
on the “My destinations” screen.
(→P.200)
Select to delete your Toyota web ac-
count from the navigation system.
(→P.138)
138
1. SETUP OPERATION
DA_EXT_COROLLA_touch screen_EE
■DELETING USER NAME AND
PASSWORD
1Select “Delete account”.
2Select “Yes” when the confirmation
screen appears.
139
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
5
SETUP
6. TELEPHONE SETTINGS
1Display the “Setup” screen. (→P.112)
XMultimedia system
2Select “Telephone”.
XNavigation system
2Select “Phone”.
3Select items to be set.
Settings are available for ringtone se-
lection, announcing incoming short
messages and e-mails etc.
No. Function
Select to set the incoming short
message announcement function
on/off.
Select to set the incoming e-mail an-
nouncement function on/off.
Select to set the desired ringtone.
Select to update the phone book of
the connected phone manually. The
updating takes place by referring to
the phone book lists in the naviga-
tion system and phone. (→P.81,
200)
INFORMATION
●The current setting of each item is dis-
played on its right.
トルツメ
140
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
7. AUDIO SETTINGS
1Display the “Setup” screen. (→P.112)
2Select “Audio”.
3Select items to be set.
1Display the audio settings screen.
(→P.140)
2Select “Bass/Mid/Treble”.
3Adjust the level of the bass, mid and
treble selecting or .
No. Function Page
Select to adjust the bass/
mid/treble. 140
Select to adjust the bal-
ance/fader. 141
Select to set the ASL to
low, mid, high or off. 141
TONE
How good an audio program sounds is
largely determined by the mix of the
treble, mid and bass levels. In fact, dif-
ferent kinds of music and vocal pro-
grams usually sound better with
different mixes of treble, mid and bass.
141
1. SETUP OPERATION
5
SETUP
DA_EXT_COROLLA_touch screen_EE
1Display the audio settings screen.
(→P.140)
2Select “Balance/Fader”.
3Adjust the balance or fader selecting
arrows.
BALANCE
A good balance of the left and right ste-
reo channels and of the front and rear
sound levels is also important.
Keep in mind that when listening to a
stereo recording or broadcast, chang-
ing the right/left balance will increase
the volume of one group of sounds
while decreasing the volume of anoth-
er.
No. Function
Fader Increases the volume to
the front side
Fader Increases the volume to
the rear side
Balance Increases the volume to
the left side
Balance Increases the volume to
the right side
INFORMATION
●Sound balance can also be adjusted by
touching and dragging the marker on the
screen with your finger or touching the
quadrants.
AUTOMATIC SOUND
LEVELIZER (ASL)
The system adjusts to the optimum vol-
ume and tone quality according to ve-
hicle speed to compensate for
increased vehicle noise.
142
DA_EXT_COROLLA_touch screen_EE
1. SETUP OPERATION
8. VEHICLE SETTINGS
1Display the “Setup” screen. (→P.112)
XMultimedia system
2Select “Car customisation”.
XNavigation system
2Select “Vehicle”.
3Select “Vehicle customisation”.
4Check that the “Vehicle customisation”
list is displayed.
5Select the desired item.
zFor a list of the settings that can be
changed, refer to “Owner’s manual”.
zA message indicating that the settings are
being saved will appear. Do not perform
any other operations while this message is
displayed.
Vehicle customisation settings can be
changed.
トルツメ
6
143
1
2
3
4
5
7
DA_EXT_COROLLA_touch screen_EE
6
8
1. REAR VIEW MONITOR
SYSTEM .................................... 144
REAR VIEW MONITOR SYSTEM ...... 144
DRIVING PRECAUTIONS .................. 144
SCREEN DESCRIPTION.................... 146
2. REAR VIEW MONITOR
SYSTEM PRECAUTIONS......... 148
AREA DISPLAYED ON SCREEN ....... 148
THE CAMERA..................................... 149
DIFFERENCES BETWEEN
THE SCREEN AND
THE ACTUAL ROAD........................ 150
WHEN APPROACHING
THREE-DIMENSIONAL
OBJECTS ......................................... 152
3. THINGS YOU SHOULD
KNOW........................................ 154
IF YOU NOTICE ANY SYMPTOMS.... 154
1REAR VIEW MONITOR
SYSTEM
REAR VIEW MONITOR SYSTEM
Some of the functions cannot be operated while driving.
144
DA_EXT_COROLLA_touch screen_EE
1. REAR VIEW MONITOR SYSTEM
1. REAR VIEW MONITOR SYSTEM
REAR VIEW MONITOR
SYSTEM
The rear view monitor system assists
the driver by displaying an image of the
view behind the vehicle with fixed
guide lines on the screen while backing
up, for example while parking.
INFORMATION
●The screen illustrations used in this text
are intended as examples, and may dif-
fer from the image that is actually dis-
played on the screen.
DRIVING PRECAUTIONS
The rear view monitor system is a sup-
plemental device intended to assist the
driver when backing up. When backing
up, be sure to visually check all around
the vehicle both directly and using the
mirrors before proceeding. If you do
not, you may hit another vehicle, and
could possibly cause an accident.
Pay attention to the following precau-
tions when using the rear view monitor
system.
145
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
6
REAR VIEW MONITOR SYSTEM
CAUTION
●Never depend on the rear view monitor
system entirely when backing up. The
image and the position of the guide lines
displayed on the screen may differ from
the actual state.
Use caution, just as you would when
backing up any vehicle.
●Be sure to back up slowly, depressing
the brake pedal to control vehicle speed.
●The instructions given are only guide-
lines. When and how much to turn the
steering wheel will vary according to
traffic conditions, road surface condi-
tions, vehicle condition, etc. when park-
ing. It is necessary to be fully aware of
this before using the rear view monitor
system.
●When parking, be sure to check that the
parking space will accommodate your
vehicle before maneuvering into it.
CAUTION
●Do not use system in the following
cases:
• On icy or slick road surfaces, or in
snow
• When using tyre chains or emergency
tyres
• When the trunk is not closed com-
pletely
• On roads that are not flat or straight,
such as curves or slopes.
●In low temperatures, the screen may
darken or the image may become faint.
The image could distort when the vehi-
cle is moving, or you may become
unable to see the image on the screen.
Be sure to visually check all around the
vehicle both directly and using the mir-
rors before proceeding.
●If the tyre sizes are changed, the posi-
tion of the fixed guide lines displayed on
the screen may change.
●The camera uses a special lens. The
distances between objects and pedestri-
ans that appear in the image displayed
on the screen will differ from the actual
distances.(→P.150)
146
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
SCREEN DESCRIPTION
XVehicles without smart entry & start system
The rear view monitor system screen will be displayed if the shift lever is shifted to
the “R” position while the engine switch is in the “ON” position.
XVehicles with smart entry & start system
The rear view monitor system screen will be displayed if the shift lever is shifted to
the “R” position while the engine switch is in ON mode.
Guide lines are displayed on the screen.
Guide lines shown differ from those shown on the actual screen.
No. Display Function
Vehicle width extension
guide lines
Displays a guide path when the vehicle is being backed
straight up.
•The displayed width is wider than the actual vehicle
width.
Vehicle centre guide lines These lines indicate the estimated vehicle centre on the
ground.
Distance guide lines Shows distance behind the vehicle.
•Displays a point approximately 1.5 ft. (0.5 m) (red) from
the edge of the bumper.
Distance guide line Shows distance behind the vehicle.
•Displays a point approximately 3 ft. (1 m) (blue) from
the edge of the bumper.
147
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
6
REAR VIEW MONITOR SYSTEM
zWhen the shift lever is shifted to the “R” position and any mode button (such as
“MEDIA”) is pressed
¨
The rear view monitor system is canceled, and the screen is switched to the mode
of the button that was pressed.
CANCELING REAR VIEW MONITOR SYSTEM
The rear view monitor system is canceled when the shift lever is shifted into any
position other than the “R” position.
148
DA_EXT_COROLLA_touch screen_EE
1. REAR VIEW MONITOR SYSTEM
2. REAR VIEW MONITOR SYSTEM PRECAUTIONS
zThe image adjustment procedure for the
rear view monitor system screen is the
same as the procedure for adjusting the
navigation/multimedia system screen.
(→P.117)
AREA DISPLAYED ON
SCREEN
The rear view monitor system displays
an image of the view from the bumper
of the rear area of the vehicle.
Screen
Displayed area
Corners of bumper
INFORMATION
●The area displayed on the screen may
vary according to vehicle orientation
conditions.
●Objects which are close to either corner
of the bumper or under the bumper can-
not be displayed.
●The camera uses a special lens. The
distance of the image that appears on
the screen differs from the actual dis-
tance.
●Items which are located higher than the
camera may not be displayed on the
monitor.
149
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
6
REAR VIEW MONITOR SYSTEM
THE CAMERA
The camera for the rear view monitor
system is located as shown in the illus-
tration.
USING THE CAMERA
If the camera lens becomes dirty, it
cannot transmit a clear image. If water
droplets, snow or mud adhere to the
lens, rinse with water and wipe with a
soft cloth. If the lens is extremely dirty,
wash it with a mild cleanser and rinse.
NOTICE
●The rear view monitor system may not
operate properly in the following cases.
• If the back of the vehicle is hit, the
position and mounting angle of the
camera may change.
• As the camera has a water proof con-
struction, do not detach, disassemble
or modify it. This may cause incorrect
operation.
• Do not strongly rub the camera lens. If
the camera lens is scratched, it cannot
transmit a clear image.
• Do not allow organic solvent, car wax,
window cleaner or glass coat to adhere
to the camera. If this happens, wipe it
off as soon as possible.
• If the temperature changes rapidly,
such as when hot water is poured on
the vehicle in cold weather, the system
may not operate normally.
• When washing the vehicle, do not
apply intensive bursts of water to the
camera or camera area. Doing so may
result in the camera malfunctioning.
●Do not expose the camera to strong
impact as this could cause a malfunc-
tion. If this happens, have the vehicle
inspected by your Toyota dealer or
another duly qualified and equipped pro-
fessional as soon as possible.
150
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
zThe distance guide lines and the vehicle
width extension guide lines may not actu-
ally be parallel with the dividing lines of the
parking space, even when they appear to
be so. Be sure to check visually.
zThe distances between the vehicle width
extension guide lines and the left and right
dividing lines of the parking space may not
be equal, even when they appear to be
so. Be sure to check visually.
zThe distance guide lines give a distance
guide for flat road surfaces. In any of the
following situations, there is a margin of
error between the fixed guide lines on the
screen and the actual distance /course on
the road.
DIFFERENCES BETWEEN
THE SCREEN AND THE
ACTUAL ROAD
WHEN THE GROUND BEHIND
THE VEHICLE SLOPES UP
SHARPLY
The distance guide lines will appear to
be closer to the vehicle than the actual
distance. Because of this, objects will
appear to be farther away than they ac-
tually are. In the same way, there will
be a margin of error between the
guidelines and the actual distance/
course on the road.
151
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
6
REAR VIEW MONITOR SYSTEM
WHEN THE GROUND BEHIND
THE VEHICLE SLOPES DOWN
SHARPLY
The distance guide lines will appear to
be further from the vehicle than the ac-
tual distance. Because of this, objects
will appear to be closer than they actu-
ally are. In the same way, there will be
a margin of error between the guide-
lines and the actual distance/course on
the road.
WHEN ANY PART OF THE
VEHICLE SAGS
When any part of the vehicle sags due
to the number of passengers or the dis-
tribution of the load, there is a margin
of error between the fixed guide lines
on the screen and the actual distance/
course on the road.
A margin of error
152
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
XVehicle width extension guide lines
WHEN APPROACHING
THREE-DIMENSIONAL
OBJECTS
The distance guide lines are displayed
according to flat surfaced objects
(such as the road). It is not possible to
determine the position of three-dimen-
sional objects (such as vehicles) using
the distance guide lines. When ap-
proaching a three-dimensional object
that extends outward (such as the flat-
bed of a truck), be careful of the follow-
ing.
VEHICLE WIDTH EXTENSION
GUIDE LINES
Visually check the surroundings and
the area behind the vehicle. In the case
shown below, the truck appears to be
outside of the vehicle width extension
guide lines and the vehicle does not
look as if it hits the truck. However, the
rear body of the truck may actually
cross over the vehicle width extension
guide lines. In reality if you back up as
guided by the vehicle width extension
guide lines, the vehicle may hit the
truck.
153
1. REAR VIEW MONITOR SYSTEM
DA_EXT_COROLLA_touch screen_EE
6
REAR VIEW MONITOR SYSTEM
DISTANCE GUIDE LINES
Visually check the surroundings and
the area behind the vehicle. On the
screen, it appears that a truck is park-
ing at point B. However, in reality if you
back up to point A, you will hit the truck.
On the screen, it appears that A is clos-
est and C is furthest away. However, in
reality, the distance to A and C is the
same, and B is farther than A and C.
Positions of A, B and C
C
A
B
C
AB
154
DA_EXT_COROLLA_touch screen_EE
1. REAR VIEW MONITOR SYSTEM
3. THINGS YOU SHOULD KNOW
If you notice any of the following symptoms, refer to the likely cause and the so-
lution, and re-check.
If the symptom is not resolved by the solution, have the vehicle inspected by
your Toyota dealer or another duly qualified and equipped professional.
IF YOU NOTICE ANY SYMPTOMS
Symptom Likely cause Solution
The image is difficult to see •The vehicle is in a dark
area
•The temperature around
the lens is either high or low
•The outside temperature is
low
•There are water droplets on
the camera
•It is raining or humid
•Foreign matter (mud etc.) is
adhering to the camera
•Sunlight or headlights are
shining directly into the
camera
•The vehicle is under fluo-
rescent lights, sodium
lights, mercury lights etc.
Back up while visually check-
ing the vehicle’s surround-
ings. (Use the monitor again
once conditions have been
improved.)
The procedure for adjusting
the picture quality of the rear
view monitor system is the
same as the procedure for
adjusting the navigation/mul-
timedia system screen.
(→P.117)
The image is blurry Dirt or foreign matter (such as
water droplets, snow, mud
etc.) is adhering to the cam-
era.
Rinse the camera lens with
water and wipe it clean with a
soft cloth.
Wash with a mild soap if the
dirt is stubborn.
The image is out of alignment The camera or surrounding
area has received a strong
impact.
Have the vehicle inspected by
your Toyota dealer or another
duly qualified and equipped
professional.
The fixed guide lines are very
far out of alignment
The camera position is out of
alignment.
Have the vehicle inspected by
your Toyota dealer or another
duly qualified and equipped
professional.
•The vehicle is tilted (there is
a heavy load on the vehicle,
tyre pressure is low due to
a tyre puncture, etc.)
•The vehicle is used on an
incline.
If this happens due to these
causes, it does not indicate a
malfunction.
Back up while visually check-
ing the vehicle’s surround-
ings.
156
DA_EXT_COROLLA_touch screen_EE
1. QUICK REFERENCE................... 158
2. DISPLAYING THE
NAVIGATION SCREEN............. 163
DISPLAYING MAP SCREEN.............. 163
DISPLAYING THE NAVIGATION
MENU SCREEN ............................... 163
3. NAVIGATION SYSTEM
FUNCTION INDEX..................... 165
1. MAP SCREEN OPERATION....... 167
CURRENT VEHICLE POSITION
DISPLAY........................................... 167
SCREEN SCROLL OPERATION........ 168
MAP CONFIGURATIONS ................... 168
2. MAP ICONS ................................. 170
DISPLAYING VARIOUS
INFORMATION ON THE MAP ......... 170
POI* ICONS ........................................ 170
TRAFFIC MESSAGES........................ 174
1. DESTINATION SEARCH
INDEX........................................ 178
2. SEARCH OPERATION ............... 179
SEARCHING BY REGISTERED
POINTS............................................. 179
SEARCHING FROM PREVIOUS
DESTINATIONS................................ 179
SEARCHING BY PHONE BOOK ........ 180
SEARCHING BY ADDRESS ............... 180
SEARCHING BY POIs* ....................... 181
SEARCHING ON THE MAP................ 184
SEARCHING BY COORDINATES ...... 184
1. STARTING ROUTE
GUIDANCE ............................... 186
STARTING ROUTE GUIDANCE
SCREEN ........................................... 186
ADJUSTING THE ROUTE................... 187
2. ROUTE GUIDANCE .................... 189
ROUTE GUIDANCE SCREEN ............ 189
VOICE GUIDANCE.............................. 190
1BASIC INFORMATION BEFORE
OPERATION
2MAP SCREEN OPERATION
AND MAP ICONS
3DESTINATION SEARCH
4ROUTE GUIDANCE
7
157
1
7
3
4
5
6
2
8
DA_EXT_COROLLA_touch screen_EE
3. SETTING AND DELETING
THE ROUTE.............................. 192
STOPPING ROUTE GUIDANCE......... 193
ADDING AND EDITING
STOPOVERS.................................... 193
DISPLAYING ROUTE
INFORMATION ................................. 195
DISPLAYING THE TURN LIST............ 196
BLOCKING ROAD AHEAD.................. 196
DETOURING A SEGMENT
ON THE ROUTE ............................... 197
RECALCULATING THE ROUTE
BY THE TRAFFIC MESSAGES........ 199
1. REGISTERING AN ENTRY......... 200
REGISTERING A NEW ENTRY .......... 200
2. DISPLAYING AND EDITING
THE ENTRY
INFORMATION......................... 206
DISPLAYING AND EDITING
THE ENTRY INFORMATION............ 206
3. SENDING AND RESTORING
STORED CONTACTS USING
A USB MEMORY ...................... 209
SENDING STORED CONTACTS
TO A USB MEMORY ........................ 209
RESTORING STORED CONTACTS
FROM A USB MEMORY................... 210
1. MAP SETTINGS .......................... 211
SETTING THE MAP............................ 211
2. ROUTE SETTINGS...................... 214
SETTING THE ROUTE OPTIONS...... 214
3. TRAFFIC MESSAGE
SETTINGS................................. 215
TRAFFIC MESSAGE SETTINGS ....... 215
1. LIMITATIONS OF THE
NAVIGATION SYSTEM............. 217
2. NAVIGATION DATABASE
UPDATES.................................. 219
UPDATING NAVIGATION
DATABASE....................................... 219
5MY DESTINATIONS
6NAVIGATION SETTING
7NAVIGATION SYSTEM
INFORMATION
NAVIGATION SYSTEM
Some of the functions cannot be operated while driving.
*: Point of Interest
158
DA_EXT_COROLLA_touch screen_EE
1. BASIC INFORMATION BEFORE OPERATION
1. QUICK REFERENCE
■“Navigation” MENU SCREEN
To display the “Navigation” menu screen, select “NAV” on the map or press the
“MAP/NAV” button. When “NAV” is selected or the “MAP/NAV” button is
pressed, the screen that was last displayed is returned to. Select or press
the “MAP/NAV” button again to display the “Navigation” menu screen. From this
screen, destinations can be entered and route-related settings can be changed.
159
1. BASIC INFORMATION BEFORE OPERATION
7
NAVIGATION SYSTEM
DA_EXT_COROLLA_touch screen_EE
No. Function Page
Select to display the “My destinations” screen.
A destination can be entered by selecting an item from the list of stored
destinations, previous destinations or the addresses from the connect-
ed phone’s phone book.
164
Select to display the “Enter destination” screen.
A destination can be entered by address, POI or using advanced op-
tions.
164
Select to display the “Traffic messages” screen.
It contains a list of traffic messages relating to the set route, all traffic
messages and warnings.
164
Select to display the “Route options” screen.
The route preferences and avoidance criteria can be adjusted. 164
Select the corresponding icon to change to the “My destinations”, “En-
ter destination”, “Traffic messages” or “Route options” screen.
160
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
■OVERVIEW GUIDANCE SCREEN
161
1. BASIC INFORMATION BEFORE OPERATION
7
NAVIGATION SYSTEM
DA_EXT_COROLLA_touch screen_EE
No. Function Page
Displays the distance, the estimated arrival time or remaining time to
the destination. 189
Displays the distance to the next turn with the arrow indicating the turn
direction. 189
Guidance route
Select to change the map scale. 168
This symbol indicates a map layout. Selecting this symbol changes the
map layout. 169
Select to change map modes between the normal map and traffic map. 174
Select to repeat the last navigation announcement. 190
Select to display the “Navigation” menu screen. 158
Select to display the options screen. 162
Current position 167
Displays the name of the current street or the next street. (when ap-
proaching a maneuver point)
162
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
■OPTIONS SCREEN
*: During route guidance
To display the options screen, select on the map.
No. Function Page
*Select to stop the current route guidance. 193
Select to change the map setting. 211
*Select to display the destination and stopover information. The route
preferences and the avoidance criteria for the route calculation can be
changed.
195
*Select to display a list of the different segments of the route. It is also
possible to define a detour. 196
*Select to block a fixed distance on the road ahead. 196
Select to display the current location, geo-coordinates and GPS infor-
mation. 167
163
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
2. DISPLAYING THE NAVIGATION SCREEN
1Press the “MAP/NAV” button.
zWhen the “MAP/NAV” button is pressed,
any of the navigation screens is displayed,
press the “MAP/NAV” button again.
2Select “Confirm”.
zAfter about a few seconds, the caution
screen automatically switches to the map
screen.
1Select “NAV” on the map or press the
“MAP/NAV” button.
DISPLAYING MAP SCREEN
INFORMATION
XVehicles without smart entry & start
system
●The caution screen will be displayed
when the screen is changed to the map
screen for the first time after the engine
switch is turned to the “ACC” or “ON”
position.
XVehicles with smart entry & start sys-
tem
●The caution screen will be displayed
when the screen is changed to the map
screen for the first time after the engine
switch is turned to ACCESSORY or
IGNITION ON mode.
DISPLAYING THE
NAVIGATION MENU SCREEN
164
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
2Check that the “Navigation” menu is
displayed.
zWhen “NAV” is selected or the “MAP/
NAV” button is pressed, the screen that
was last displayed is returned to. Select
or press the “MAP/NAV” button
to display the “Navigation” menu screen.
■“My destinations” screen
zThis screen can be displayed by selecting
on any of the navigation screens.
■“Enter destination” screen
zThis screen can be displayed by selecting
on any of the navigation screens.
■“Traffic messages” screen
zThis screen can be displayed by selecting
on any of the navigation screens.
■“Route options” screen
zThis screen can be displayed by selecting
on any of the navigation screens.
No. Function
Select to display the “My destina-
tions” screen.
Select to display the “Enter destina-
tion” screen.
Select to display the “Traffic mes-
sages” screen.
Select to display the “Route options”
screen.
165
1. BASIC INFORMATION BEFORE OPERATION
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
3. NAVIGATION SYSTEM FUNCTION INDEX
XMap
XRoute guidance
Displaying maps Page
Viewing the map screen 163
Displaying the current vehicle position 167
Viewing the current vehicle position vicinity map 168
Changing the scale 168
Changing the map layout 169
Displaying various information on the map 170
Displaying Point of Interest Icons 170
Viewing traffic messages 174
Searching destination Page
Searching the destination 179
Setting the entry registered with the system as the destination 179
Before starting route guidance Page
Recalculating the route 187
Viewing alternative routes 186
Starting route guidance 186
Before starting or during route guidance Page
Viewing the route 195
Adding destinations 193
Recalculating the route 187
Changing the estimated arrival time and remaining time display 189
During route guidance Page
Stopping route guidance 193
Adjusting route guidance volume 190
Displaying the entire route map 195
167
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
2. MAP SCREEN OPERATION AND MAP ICONS
1. MAP SCREEN OPERATION
zThe current vehicle position mark
appears in the centre of the map screen.
■CURRENT LOCATION AND GPS IN-
FORMATION
1Select on the map.
2Select “Location & GPS informa-
tion”.
3Check that current location information
is displayed.
CURRENT VEHICLE
POSITION DISPLAY
When starting the navigation system,
the current position is displayed first.
This screen displays the current vehi-
cle position and a map of the surround-
ing area.
INFORMATION
●While driving, the current vehicle posi-
tion mark is fixed on the screen and the
map moves.
●The current position is automatically set
as the vehicle receives signals from the
GPS (Global Positioning System). If the
current position is not correct, it is auto-
matically corrected after the vehicle
receives signals from the GPS.
●After battery disconnection, or on a new
vehicle, the current position may not be
correct. As soon as the system receives
signals from the GPS, the correct cur-
rent position is displayed.
No. Information
The information provided varies, de-
pending whether the road currently
being travelled on is a motorway or
a street.
Latitude and Longitude
Amount of available satellites and
the altitude.
Select to register the current posi-
tion in the “Stored” list on the “My
destinations” screen. (→P.200)
168
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
zIf a finger is continuously held on the
screen, the map will continue scrolling in
that direction until the finger is removed.
zA street name or geo-coordinates of the
selected point will be shown, depending
on the scale of the map.
zAfter the screen is scrolled, the map
remains centred at the selected location
until another function is activated. The cur-
rent vehicle position mark will continue to
move along your actual route and may
move off the screen. When is
selected, the current vehicle position mark
returns to the centre of the screen and the
map moves as the vehicle proceeds along
the designated route.
zWhen the scroll feature is used, the cur-
rent vehicle position mark may disappear
from the screen. Select to display
the current vehicle position on the map
screen.
1Select the zoom bar button.
2Select “+” or “-” to change the scale of
the map screen.
zThe scale of the map screen can also be
changed the following ways:
• Selecting the desired scale point.
• Dragging the scale bar marking to the
desired point.
• Turning the tune/scroll knob.
SCREEN SCROLL
OPERATION
When any point on the map is select-
ed, that point moves to the centre of
the screen and is shown by the cursor
mark .
zWhen “Go” is selected, the starting
route guidance screen is displayed.
(→P.186)
zWhen “Save” is selected, the point is
registered in the “Stored” list on the “My
destinations” screen. (→P.200)
MAP CONFIGURATIONS
CHANGING MAP SCALE
INFORMATION
●The scale range is from 150 ft to 250
miles (10 m to 500 km).
●The scale has been changed, the new
scale indicator will be displayed for a
while.
169
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Select the map layout button.
zEach time the map layout button is
selected, the map layout changes as fol-
lows:
3D heading ( ) → 2D heading
() → 2D north ( )
X3D heading
X2D heading
X2D north
CHANGING MAP LAYOUT
INFORMATION
●Map layout can be also changed by
selecting then “Map settings”.
(→P.211 )
170
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
2. MAP ICONS
■SPEED LIMITS
■SAFETY CAMERAS
DISPLAYING VARIOUS
INFORMATION ON THE MAP
Various information can be displayed
on the map.
The speed limit of the road currently
being travelled on can be displayed.
Safety cameras can be displayed as
icons on the map.
INFORMATION
●The above items will be displayed
depending on the map scale.
●The above items will be displayed
depending on the available map data.
●The displaying of the above items can
be switched off. (→P.211)
POI ICONS
DISPLAYING POI ICONS
Points of Interest such as petrol sta-
tions and restaurants can be displayed
on the map screen. Their location can
also be set as a destination.
INFORMATION
●A particular type of POI icons displayed
on the screen can be selected. (→P.212)
171
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■LIST OF POI ICONS
XPublic
XTraffic
Icon Name
Library
College/University
School
Tourist office
Cemetery, funeral director
Government Office, Institution,
City hall, Community gen.
Community
Court house
Place of worship
Accommodation, Hotel/Motel
Pharmacy
Convention Centre, Exhibition
Centre
Finance, Bank
Cash Dispenser
Post Office
Business, B. Company, B. Gen-
eral, B. facility
Medical, Doctor, Health & Care
Ambulance, Hospital/Polyclinic
Fire Station
Police Station
Phone Box, Communication
Dentist
Veterinarian
Icon Name
Car Dealer/Repairer, Repair Fa-
cility, Repair General, Car Wash,
Tyre Repair
Car Dealer
Highway Exit
Airport, Dep. /Arrival, Ground, In-
ternational, Domestic
Bus Terminal, Bus Stop, Trans-
portation, Public Transp. Stop,
Transport general
Railway Station
Metropolitan Train
Petrol Station
Icon Name
172
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
XClubbing
XSport
XLeisure
Rent-a-Car,-Facility, -Parking
Ferry Terminal
Parking, Open Parking Area, P.
Area general
Parking Garage
Open P.A. P+R
Rest Area
Motoring Organization, Automo-
bile Club
Mover, Moving Company
Motorcycle Dealer
Icon Name
Multiple POI
Bar, Nightlife
Leisure, Cultural Centre, The-
ater, Music Centre, Concert Hall
Cinema
Casino
Cafe/Bar, Cafe
Icon Name
Restaurant, French, Belgian,
Chinese, German, Greek, Vege-
tarian, Fast Food, Grill, Sea
Food, Sandwich, Steak...
Icon Name
Sport, Sport General, sport activ-
ities
Golf Course
Race Track
Stadium, Sports Centre, Hippo-
drome
Water Sports
Bowling
Ski resorts
Icon Name
Amusement Park
Winery
Museum
Shopping, Market Place, Shop-
ping Centre, Factory Outlet
Shop, Department Store, Drive-
through-bottle-shop
Icon Name
173
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Select the desired POI icon on the
map.
2Select .
XOne POI
XMultiple POI
Tourist Attractions, Important
Tourist Attractions
Park/Recreational Area
Yacht Basin, Harbour
Camping Ground
Grocery Store
Historical Monument
RV Park, Camping
Bookstore
Hair & Beauty
Photography
Shoestore
Wine & Liquor
Clothing
Cleaning & Laundry
Icon Name DISPLAYING POI
INFORMATION
174
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
3Check that the POI information is dis-
played.
1Select the traffic icon.
zEach time the traffic icon is selected, the
map mode changes.
XNormal map mode
XTraffic map mode
zTraffic message icons and speed limit dis-
play are shown.
zTraffic flow information is highlighted.
No. Function Page
Select to call the registered
telephone number. 88
Select to register the point
in the “Stored” list on the
“My destinations” screen.
200
Select to display the start-
ing route guidance screen. 186
TRAFFIC MESSAGES
CHANGING TO TRAFFIC MAP
MODE
The map screen can change modes to
normal map mode or traffic map mode.
175
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■DISPLAYING DETAILED TRAFFIC
MESSAGE ICONS
1Select the desired traffic message icon
on the map.
2Check that the traffic message infor-
mation is displayed.
■DISPLAYING TRAFFIC MESSAGE
LIST
1Display the “Navigation” menu screen
and select “Traffic messages”.
(→P.163)
2Select the desired tab to select the list.
DISPLAYING DETAILED
TRAFFIC INFORMATION
No. Function
Select to display the traffic messag-
es relating to the set route.
Select to display all traffic messag-
es.
Select to display traffic messages
with warnings.
176
2. MAP SCREEN OPERATION AND MAP ICONS
DA_EXT_COROLLA_touch screen_EE
3Select the desired message. 4Check that the traffic message is dis-
played.
No. Information
Street number
Route segment
If route segment is not available,
information such as street name,
city name, region or country will
be displayed.
: Icon of an incident
: Icon of an incident on the
route
: Icon of an incident on
the detoured route
Distance to incident and direction
from vehicle
z“Detour”/“Detour off”: Select to detour
or cancel detouring the segment.
(→P.198)
178
DA_EXT_COROLLA_touch screen_EE
3. DESTINATION SEARCH
1. DESTINATION SEARCH INDEX
There are several ways to search for a destination.
How to search a destination list Page
Searching by registered points in the system. 179
Searching from previously set destinations. 179
Searching by the phone book of a connected cellular phone. 180
Searching by address. 180
Searching by POIs. 181
Searching on the map. 184
Searching by coordinates. 184
179
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
2. SEARCH OPERATION
1Display the “Navigation” menu screen
and select “My destinations”.
(→P.163)
2Select the “Stored” tab.
3Select the desired entry.
zThe route will be calculated.
1Display the “Navigation” menu screen
and select “My destinations”.
(→P.163)
2Select the “Last” tab.
3Select the desired entry.
zThe route will be calculated.
SEARCHING BY
REGISTERED POINTS
To use this function, it is necessary to
register the entry. (→P.200)
zSelect to display and edit the
entry information. (→P.206)
INFORMATION
●If “Home” has not been registered, a
message will be displayed and the
setting screen will automatically
appear. (→P.201)
●Transferred POIs and routes from an
external device or the server will be
stored in this list. (→P.204, 244)
●Transferred routes are marked by the
specific icon.
SEARCHING FROM
PREVIOUS DESTINATIONS
zSelect to display and edit the
entry information. (→P.206)
INFORMATION
●The list can contain a maximum of
100 entries. When the maximum is
reached, the oldest destination is
deleted, making room for the new des-
tination to be stored in the list.
180
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
1Display the “Navigation” menu screen
and select “My destinations”
(→P.163)
2Select the “Phone book” tab.
3Select the desired entry.
“Search contact”: Select to search by the
contact’s name.
zThe route will be calculated.
1Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
2Select the “Address” tab.
3Select “Country” to enter the desired
country.
4Select “Town” or “Code” to enter the
town name or postal code.
zWhen either a “Town” or “Code” is
entered, the other will be entered automat-
ically.
5Select “Street” to enter the street
name.
6Select “No.” or “Intersection” to en-
ter a house number or intersection
name.
zIt is not possible to enter a house number
and intersection at the same time.
7Select “Calculate route”.
zThe route will be calculated.
SEARCHING BY PHONE
BOOK
Before using this function, connect a
Bluetooth® phone with a phone profile.
(→P.127)
If a contact does not have address in-
formation stored, the entry will be
dimmed.
zSelect to display and edit the
entry information. (→P.206)
SEARCHING BY ADDRESS
181
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
2Select the “POI” tab.
3Select the desired item.
INFORMATION
●“Calculate route” can be selected once
a “Town” or “Code” has been entered.
If “Calculate route” is selected when
only “Town” or “Code” has been
entered, a route search starts with the
centre of the town entered as the desti-
nation.
●If is selected, entered data other
than “Country” will be deleted.
SEARCHING BY POIs
No. Function Page
Select to search by catego-
ry. 182
Select to search by name. 183
Select to search by map. 183
Select to search by online
search. 239
182
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
■SEARCHING BY CATEGORY
1Select “By category”.
2Select the desired item to search the
area.
3Select the desired category.
4Select the desired subcategory.
5Select for the desired POI.
zIf you select the desired POI, the route will
be calculated.
6Select “Go”.
zThe route will be calculated.
No. Function
Select to set around the current po-
sition.
Select to set around the main desti-
nation. POIs around stopovers will
not be searched.
Select to set around the current
route.
Select to set the desired city.
Select “Enter city” to enter the city
name and then select “OK”.
zWhen “Save” is selected, the point is
registered in the “Stored” list on the “My
destinations” screen. (→P.202)
zDepending on the POI information,
“Details” will be displayed. To display
detailed POI information, select
“Details”.
zWhen is selected, the registered
telephone number is called.
183
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■SEARCHING BY NAME
1Select “By name”.
2Select the desired area to search.
(→P.182)
3Enter POI name and then select “OK”.
4Follow the steps “SEARCHING “By
category”” from “STEP 5”. (→P.182)
■SEARCHING BY MAP
1Select “By map”.
2Select the desired POI icon on the
map.
3Follow the steps “SEARCHING “By
category”” from “STEP 5”. (→P.182)
INFORMATION
●Search areas are available as follows.
Search by “At current position”, “At
destination” or a town name:
Search radius is 30 miles (50km).
Search by “Along route”:
Search area is within 0.3 mile (500m) on
both sides of the route.
●The POI search result list is sorted by
the distance to the POI from the follow-
ing points.
Search by “At current position” or
“Along route”:
The distance will be calculated from the
current position to the POI.
Search by “At destination”: The dis-
tance will be calculated from the desti-
nation to the POI.
Search by a town name: The distance
will be calculated from town centre to the
POI.
INFORMATION
●Depending on the current map scale,
not all POI icons will be available for
selection.
184
3. DESTINATION SEARCH
DA_EXT_COROLLA_touch screen_EE
1Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
2Select the “Advanced” tab.
3Select “Select point on map”.
4Select the desired point on the map.
5Select “Go”.
zThe route will be calculated.
1Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
2Select the “Advanced” tab.
3Select “Enter geo-coordinates”.
4Select “N” or “S”.
5Enter the latitude.
6Select “W” or “E”.
7Enter the longitude.
8Select “OK”.
SEARCHING ON THE MAP
zWhen “Save” is selected, the point is
registered in the “Stored” list on the “My
destinations” screen. (→P.202)
SEARCHING BY
COORDINATES
Geo coordinates can be entered in
DMS format (Degrees°, Minutes’, Sec-
onds”). Only coordinate values that
can potentially exist are able to be en-
tered. Impossible coordinate values
and their relevant screen buttons will
be dimmed.
186
DA_EXT_COROLLA_touch screen_EE
4. ROUTE GUIDANCE
1. STARTING ROUTE GUIDANCE
1Select “Go”.
zStarts route guidance. (→P.189)
STARTING ROUTE
GUIDANCE SCREEN
After searching the destination, the
starting route guidance screen will be
displayed.
According to the setting, either the rec-
ommended route screen or route alter-
natives screen will be displayed.
(→P.214)
CAUTION
●Be sure to obey traffic regulations and
keep road conditions in mind while driv-
ing. If a traffic sign on the road has been
changed, the route guidance may not
indicate such changed information.
RECOMMENDED ROUTE
SCREEN
The recommended route will be dis-
played on the map.
z“Route options”: Select to adjust the
route preferences for current route and
the avoidance criteria of current route
before starting the route guidance.
(→P.187)
INFORMATION
●The default recommended route can be
changed. (→P.214)
●The arrival time or the remaining time
will be displayed in the upper left area of
the map. Each time the area is selected,
the display switches between displaying
the arrival time and remaining time.
●Distance of the entire route is displayed
on the map.
●The starting route guidance screen will
always be displayed in 2D north.
●If “Go” is selected and held, demo
mode will start. Select “Quit” to end
demo mode.
187
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Select one of the three route alterna-
tives to select it.
zStarts route guidance. (→P.189)
XThe recommended route screen
1Select “Route options”.
2Select the desired item to adjust the
route preferences and the avoidance
criteria.
3Select “Route options”.
zThe route will be recalculated and then the
starting route guidance screen will be dis-
played.
ROUTE ALTERNATIVES
SCREEN
Three route alternatives are displayed
on the map.
z“Avoid”: Select to adjust the avoidance
criteria of current route before starting
the route guidance. (→P.187)
INFORMATION
●The default avoidance criteria can be
changed. (→P.214)
●The arrival time and distance of the
entire route will be displayed in the list.
●The starting route guidance screen will
always be displayed in 2D north.
ADJUSTING THE ROUTE
188
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
XThe route alternatives screen
1Select “Avoid”.
2Select the desired item to adjust the
avoidance criteria.
3Select “Avoid”.
zThe route will be recalculated and then the
starting route guidance screen will be dis-
played.
INFORMATION
●Adjusting the route preference and
avoidance in the above method affects
current route only. Route option defaults
can be changed from the “Route
options” screen. (→P.214)
189
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
2. ROUTE GUIDANCE
■SIGNPOSTS
■MOTORWAY JUNCTION SCREEN
■TUNNEL JUNCTION SCREEN
ROUTE GUIDANCE SCREEN
While guiding the route, the route guid-
ance screen will be displayed.
No. Information
Distance and arrival or remaining
time to the destination
Each time information box is select-
ed, the screen will change between
arrival time and remaining time to
the destination.
Guidance route
Select to repeat the last navigation
announcement.
The name of the current street or the
next street (when approaching a
maneuver point)
Current position
Distance to the next turn with the ar-
row indicating the turn direction
When approaching the turn, a signpost
will automatically be displayed.
When approaching a motorway junc-
tion, junction view images will automat-
ically be displayed.
When approaching a tunnel junction,
tunnel junction view images will auto-
matically be displayed.
190
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
■LANE RECOMMENDATION
zThe voice guidance volume can be
adjusted by turning the power/volume
knob.
zIf is selected, the last navigation
announcement will be repeated.
When approaching a maneuver point,
the lane recommendation will automat-
ically be displayed.
INFORMATION
●If the vehicle goes off the guided route,
the route will be recalculated.
●For some areas, the roads have not
been completely digitized in our data-
base. For this reason, the route guid-
ance may select a road that should not
be traveled on.
●The above items will be displayed
depending on the map scale.
●The displaying of the above items can
be switched off. (→P.211)
VOICE GUIDANCE
The voice guidance provides various
messages as you approach an inter-
section, or other points where maneu-
vering the vehicle is necessary.
INFORMATION
●The voice guidance may not pronounce
certain street names correctly or clearly
due to the limitations of the text-to-
speech function.
●On motorways, interstates or other high-
ways with higher speed limits, the voice
guidance will be made at earlier points
than on city streets in order to allow time
to maneuver the vehicle.
●If the system cannot determine the cur-
rent vehicle position correctly (in cases
of poor GPS signal reception), the voice
guidance may be early or delayed.
●The voice guidance volume can also be
changed. (→P. 116)
191
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
CAUTION
●Be sure to obey the traffic regulations
and keep the road condition in mind
especially when you are driving on IPD
roads (roads that are not completely dig-
itized in our database). The route guid-
ance may not have the updated
information such as the direction of a
one way street.
192
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
3. SETTING AND DELETING THE ROUTE
During route guidance, routes can be checked, changed or recalculated.
Information Page
Stopping route guidance 193
Adding and editing stopovers 193
Displaying route information 195
Displaying the turn list 196
Avoiding a road on the route 196
Detouring a maneuver point on the route 197
Recalculating the route by traffic information 199
193
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Select on the map.
2Select “Stop guidance”.
1Search for an additional stopover in the
same way as a destination search.
(→P.178)
2Select the desired item.
XIf “Replace” is selected
zThe route will be recalculated.
XIf “Add” is selected
3Select “Go”.
zThe route will be recalculated.
zThe last entered stopover is added as the
first stopover and highlighted.
zThe order of stopovers and destination
can be changed by dragging the entry to
the desired position in the list.
zIf the maximum number of stopovers have
already been set, a confirmation screen
will appear. To delete a stopover, select
“Yes” and select next to the
desired stopover to delete it.
STOPPING ROUTE
GUIDANCE
ADDING AND EDITING
STOPOVERS
ADDING STOPOVERS
In addition to the main destination, a
maximum of 9 stopovers can be set.
No. Function
Select to replace the existing desti-
nation or a stopover with a new one.
Select to add a stopover.
Select to return to the last displayed
screen.
194
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
■DELETING STOPOVERS
1Display the route information screen.
(→P.195)
2Select next to the desired stop-
over.
3Select the desired item.
zWhen the stopover(s) is deleted, the route
will be recalculated
■CHANGING THE ORDER OF THE
STOPOVERS
1Display the route information screen.
(→P.195)
2Drag a stopover to the desired posi-
tion.
zThe route will be recalculated.
EDITING STOPOVERS
No. Function
Select to register the stopover in the
“Stored” list on the “My destina-
tions” screen. (→P.200)
Select to delete the stopover.
Select to delete all stopovers.
INFORMATION
●If the main destination is deleted, the
last stopover before the deleted destina-
tion will become the new main destina-
tion.
195
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Select on the map.
2Select “Route information”.
3Check that the destination information
screen is displayed.
XDestination information (displayed when
no stopovers are set)
XRoute information for stopovers
DISPLAYING ROUTE
INFORMATION
No. Information
Arrival time, remaining time and dis-
tance to destination
Address of destination
Distance to the destination
Select to change the route prefer-
ence and avoidance criteria.
(→P.187)
Select to display route overview.
Address of stopovers
Select to edit the stopover/destina-
tion. (→P.194)
196
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
1Select on the map.
2Select “Turn list”.
3Select the desired item to display the
segment.
zGuidance arrow, street name, distance to
the point are displayed.
4Check that the detail of the segment is
displayed.
1Select on the map.
2Select “Block road ahead”.
3Select the desired item to select the
desired detour distance.
zThe route will be recalculated.
zA blocked route will be marked in the map.
zAfter the blocked route has been
detoured, the block road ahead function
will automatically be deactivated.
DISPLAYING THE TURN LIST
z“Detour”: Select to detour the segment.
(→P.197)
BLOCKING ROAD AHEAD
A fixed distance on the road ahead can
be blocked.
No. Function
Select to deactivate the function.
Select to detour the next 1 mile ~ 12
miles (2 km ~ 20km) of the current
route (road).
197
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■DETOURING THE SEGMENT
1Display the turn list. (→P.196)
2Select the desired segment to detour.
3Select “Detour”.
zThe route will be recalculated.
■CANCELLING THE DETOURED
SEGMENT
1Display the turn list. (→P.196)
2Select “Detours”.
3Select “Detour off”.
zIf there is more than one point to detour, a
list of points to detour will be displayed.
Select points from the list to cancel
detouring them.
zThe route will be recalculated.
DETOURING A SEGMENT ON
THE ROUTE
DETOURING A SEGMENT
FROM THE TURN LIST
198
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
■DETOURING THE SEGMENT
1Display the traffic message list.
(→P.175)
2Select the “On route” tab.
3Select the desired segment to detour.
4Select “Detour”.
zThe route will be recalculated.
zThe mark of the TMC on the “On route”
screen changes into .
■CANCELLING THE DETOURED
SEGMENT
1Display the traffic message list.
(→P.175)
2Select the “On route” tab.
3Select the detoured segment.
4Select “Detour off”.
zThe route will be recalculated.
zThe mark of the TMC on the “On route”
screen changes to .
DETOURING A SEGMENT
FROM THE TRAFFIC MESSAGE
LIST
199
4. ROUTE GUIDANCE
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
XIf “Automatic” is selected
1Check that the confirmation screen is
displayed.
zThe route will be recalculated automati-
cally.
XIf “Manual” is selected
1Check that the confirmation screen is
displayed.
2Select “Show detour”.
zSelect “Ignore” to return to the previous
screen.
3Select “Detour”.
zThe route will be recalculated.
zSelect “Ignore” to return to the previous
screen.
RECALCULATING THE
ROUTE BY THE TRAFFIC
MESSAGES
You will be informed about relevant
traffic messages on the route by a pop-
up window.
A pop-up window may differ depending
on the traffic message settings.
(→P.215)
200
DA_EXT_COROLLA_touch screen_EE
5. MY DESTINATIONS
1. REGISTERING AN ENTRY
1Display the “Navigation” menu screen
and select “My destinations”.
(→P.163)
2Select the “Stored” tab.
3Select “Create new entry”.
4Enter the entry address (→P.180) and
then select “Save new entry”.
5 Enter the entry name and then select
“OK”.
6Check that the entry is registered in the
“Stored” list.
REGISTERING A NEW ENTRY
Up to 200 entries can be registered
with this system.
REGISTERING FROM THE
“Stored” LIST
zSelect to display and edit the
entry information. (→P.206)
201
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■REGISTERING “Home”
1Select “Home”.
2Select “Yes” when the confirmation
screen appears.
3Select the desired method to search
the point.
zFor details about searching the point on
the map: →P.179.
XIf you select “Use current location”
zThe entry is registered as “Home” in the
“Stored” list.
XIf you search the destination by “Enter
address”
4Enter the address and then select
“Save as Home address”.
XIf you search the destination by “Select
point on map”
4Select the desired point on the map
and then select “Save”.
XIf you search the destination by “Enter
geo-coordinates”.
4Enter geo-coordinates and then select
“Save”.
XIf you search the destination by the other
methods
4Select the desired entry from the list.
If “Home” has not been registered, se-
lecting “Home” allows a home ad-
dress to be registered.
zSelect to display and edit the
entry information. (→P.206)
202
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
1Select the desired point on the map.
2Select “Save”.
3Follow the steps “REGISTERING
FROM THE “Stored” LIST” from “STEP
5”. (→P.200)
1Display location & GPS information
screen. (→P.167)
2Select “Save current location”.
3Follow the steps “REGISTERING
FROM THE “Stored” LIST” from “STEP
5”. (→P.200)
1Search the point by “POI”. (→P.181)
2Select “Save”.
3Follow the steps “REGISTERING
FROM THE “Stored” LIST” from “STEP
5”. (→P.200)
REGISTERING FROM THE MAP REGISTERING THE CURRENT
POSITION
REGISTERING FROM POI
203
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Display entry options screen.
(→P.206)
2Select “Add to stored contacts”.
3Follow the steps “REGISTERING
FROM THE “Stored” LIST” from “STEP
5”. (→P.200)
1Display the route information screen.
(→P.195)
2Select next to the desired stop-
over or main destination.
3Select “Add to stored contacts”.
4Follow the steps “REGISTERING
FROM THE “Stored” LIST” from “STEP
5”. (→P.200)
REGISTERING FROM ENTRY
OPTIONS SCREEN
INFORMATION
●If the contact includes an address and a
phone number, they will be stored in the
“Stored” list on the “My destinations”
screen and “Contacts” screen. (→P.86,
200)
REGISTERING FROM THE
ROUTE INFORMATION
SCREEN
204
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
■LOADING POIs AND ROUTES VIA A
USB MEMORY
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
4Select the “Advanced” tab.
5Select “Load POIs and routes from
USB”.
6Check that a progress bar is being dis-
played while the data loading is in
progress.
zTo cancel this function, select “Cancel”.
7Check that a confirmation screen is
displayed when the operation is com-
plete.
8Check that the entry is registered in the
“Stored” list on the “My destinations”
screen. (→P.200)
REGISTERING FROM AN
EXTERNAL DEVICE
“vCards” formatted data can be trans-
ferred from a USB memory to this sys-
tem. Transferred POIs and routes will
be stored in the “Stored” list on the “My
destinations” screen. (→P.200)
INFORMATION
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
• If the USB memory is removed before
downloading is complete
●If the maximum number of possible
stored contacts has been reached, a
confirmation screen appears.
Delete contact(s) to make room for new
contact(s). (→P.83)
205
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
■LOADING POIs AND ROUTES
FROM A SERVER
POIs and routes can be added by
downloading from the Toyota portal
site. They will be stored in the “Stored”
list on the “My destinations” screen.
(→P.200) For detailed information
about connected service: →P.232
206
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
2. DISPLAYING AND EDITING THE ENTRY INFORMATION
1Display the “Navigation” menu screen
and select “My destinations”.
(→P.163)
2Select the desired tab.
3Select next to the desired entry.
XThe entry options screen of “Stored” list.
(When the entry is selected)
XThe entry options screen of “Stored” list.
(When the route is selected)
XThe entry options screen of “Last” list
XThe entry options screen of “Phone
book” list
DISPLAYING AND EDITING
THE ENTRY INFORMATION
No. Function Page
Select to display detailed
entry information. 207
Select to change the entry
name. 207
Select to edit the address. 207
Select to delete the entry/
route/destination.
Select to delete all entries/
routes/destinations.
Select to edit the route. 208
Select to register the entry
in the “Stored” list on the
“My destinations” screen
and “Contacts” screen.
203
207
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Display the entry options screen.
(→P.206)
2Select “Show details”.
3Check the details of the entry informa-
tion.
zThe address will be marked on the map.
zThe address and a picture, if available, of
the contact from the system’s phone book
will be displayed.
1Display the entry options screen.
(→P.206)
2Select “Rename”.
3Enter the new name and then select
“OK”.
1Display the entry options screen.
(→P.206)
2Select “Edit address”.
3Enter the new address. (→P.180)
4Select “Save changes”.
INFORMATION
●If an entry that is transferred from a cel-
lular phone is edited, the change will
affect the entry in the “Stored” list on the
“My destinations” screen and “Contacts”
screen. (→P.86, 200)
DISPLAYING DETAILS OF THE
ENTRY INFORMATION
zWhen “Go” is selected, the starting
route guidance screen will be displayed.
CHANGING THE ENTRY NAME
EDITING THE ADDRESS
208
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
1Display the entry options screen.
(→P.206)
2Select “Edit route”.
3Select next to the desired entry.
zThe order of stopover can be changed by
dragging a destination to the desired posi-
tion.
4Select the desired item.
EDITING THE ROUTE
No. Function
Select to edit address. (→P.207)
Select to delete stopover.
Select to delete all stopovers.
209
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
3. SENDING AND RESTORING STORED CONTACTS USING A USB MEMORY
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Press the “SETUP” button.
4Select “General”.
5Select “Backup stored contacts to
USB”.
6Check that a progress bar is being dis-
played while the data sending is in
progress.
7Check that a confirmation screen is
displayed when the operation is com-
plete.
SENDING STORED
CONTACTS TO A USB
MEMORY
The entries stored in the “Stored” list
on the “My destinations” screen and
“Contacts” screen (→P.86, 200) can
be transferred to a USB memory.
INFORMATION
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
• If the USB memory is removed before
downloading is complete
210
5. MY DESTINATIONS
DA_EXT_COROLLA_touch screen_EE
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Press the “SETUP” button.
4Select “General”.
5Select “Restore contact backup
from USB”.
6Check that a progress bar is being dis-
played while the data loading is in
progress.
7Check that a confirmation screen is
displayed when the operation is com-
plete.
RESTORING STORED
CONTACTS FROM A USB
MEMORY
Backed-up data can be transferred
from a USB memory to this system.
Transferred entries will be stored in the
“Stored” list on the “My Destinations”
screen and “Contacts” screen.
(→P.86, 200)
INFORMATION
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
• If the USB memory is removed before
downloading is complete
211
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
6. NAVIGATION SETTING
1. MAP SETTINGS
1Select on the map.
2Select “Map settings”.
3Select the item to be set.
SETTING THE MAP No. Function Page
Select to set the map lay-
out to 3D heading, 2D
heading or 2D north.
169
Select to set the screen
mode to “Automatic”,
“Day” or “Night”.
213
Select to set the arrival in-
formation display to arrival
time, remaining time to the
destination, or off.
Select to set displayed POI
icon categories. 212
Select to set speed limit in-
formation on/off. 213
Select to set the automatic
zooming function (when
approaching a guidance
point) on/off.
Select to set the display of
the route guidance arrow
with distance to the next
maneuver point on/off.
189
Select to set the display of
the name of the current
street or the next street
(when approaching a ma-
neuver) on/off.
189
Select to set the display of
signposts on/off. 189
Select to set the display of
the junction view on/off. 189
Select to set the recom-
mended lane display on/
off.
189
Select to set the display of
the traffic message icons
on/off.
175
212
6. NAVIGATION SETTING
DA_EXT_COROLLA_touch screen_EE
1Display the “Map settings” screen.
(→P.211)
2Select “POIs on map”.
3Select the desired POI categories.
Select to set the display of
the safety cameras icons
on/off.
170
INFORMATION
●The current setting of each item is dis-
played on its right.
No. Function Page POIs ON MAP
No. Function
Select to display all categories.
Select to hide all icons.
Select to select main categories.
Select to select subcategories.
213
6. NAVIGATION SETTING
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
1Display the “Map settings” screen.
(→P.211)
2Select “Day/Night mode”.
3Select the desired item.
1Display the “Map settings” screen.
(→P.211)
2Select “Speed limits”.
3Select the desired item.
DAY/NIGHT MODE
No. Function
Select to change the screen to day
or night mode depending on the po-
sition of the headlight switch.
Select to always display the map in
day mode.
Select to always display the map in
night mode.
SPEED LIMITS
No. Function
Select to display the speed limits on
the map.
Select to receive an audible warn-
ing, if the speed limit will be exceed-
ed by a certain range.
214
6. NAVIGATION SETTING
DA_EXT_COROLLA_touch screen_EE
2. ROUTE SETTINGS
1Display the “Navigation” menu screen
and select “Route options”.
(→P.163)
2Select the “Preferences” tab.
3Select the desired item.
1Display the “Navigation” menu screen
and select “Route options”.
(→P.163)
2Select the “Avoid” tab.
3Select the desired item.
SETTING THE ROUTE
OPTIONS
SETTING THE ROUTE
CALCULATION
No. Function
Select to select “Fast route”,
“Short route” or “Ecological
route” route type.
Select to include the traffic informa-
tion history in the route calculation.
Select to display the 3 routes (fast-
est, shortest and ecological) on the
map after route calculation.
Select to have the route automati-
cally calculated back to the starting
point after the set destination has
been reached.
Entered stopovers will also be con-
sidered on the way back to the start-
ing point.
INFORMATION
●“Show route alternatives” and “Make
a round trip” are not selectable at the
same time.
SETTING THE AVOIDANCE
CRITERIA FOR THE ROUTE
CALCULATION
No. Function
Select to avoid motorways.
Select to avoid toll roads.
Select to avoid tunnels.
Select to avoid ferries and car trains.
215
6. NAVIGATION SETTING
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
3. TRAFFIC MESSAGE SETTINGS
1Display the “Navigation” menu screen
and select “Traffic messages”.
(→P.163)
2Select the “Settings” tab.
3Select the desired item.
1Display the “Settings” screen.
(→P.215)
2Select “Dynamic reroute”.
3Select the desired item.
TRAFFIC MESSAGE
SETTINGS
No. Function Page
Select to set the reroute
method. 215
Select to set display of traf-
fic messages in the traffic
message list on/off.
Select to set automatic dis-
play of traffic messages
within the set radius in the
traffic message list.
Select to set selection of
traffic stations to auto/man-
ual.
216
SETTING REROUTE METHOD
No. Function
Select to disable receiving traffic
messages and no reroute will be cal-
culated.
Select to enable relevant traffic
messages on the route to be dis-
played as a pop-up window and ac-
tivate automatic reroute calculation.
Select to enable relevant traffic
messages on the route to be dis-
played as a pop-up window but dis-
able automatic reroute calculation.
The user decides if reroute calcula-
tion is desirable or not.
216
6. NAVIGATION SETTING
DA_EXT_COROLLA_touch screen_EE
1Display the “Settings” screen.
(→P.215)
2Select “TMC radio station”.
3Select the desired item.
■SETTING RADIUS FILTER
1Select “Radius filter”.
2Select desired item.
SETTING RADIUS FOR
DISPLAYING TRAFFIC
MESSAGES AND SELECTING
RADIO STATIONS
No. Function
Select to set the radius for display-
ing traffic messages.
Select to allow the system to auto-
matically tune to a TMC station with
the best reception.
Select to manually tune to a TMC
station. Select or when
these buttons are made available.
INFORMATION
●When the manually tuned station can no
longer be received, the station with the
best reception is selected by the system
and the manually tuned station will be
dimmed. Once the manually tuned sta-
tion can be received again, it will be
used as the TMC station.
No. Function
Select to deactivate the function.
Select to set the radius from 6 miles
to 60 miles (10 km to 100 km).
217
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
7. NAVIGATION SYSTEM INFORMATION
1. LIMITATIONS OF THE NAVIGATION SYSTEM
The Global Positioning System (GPS) de-
veloped and operated by the U.S. Depart-
ment of Defense provides an accurate
current vehicle position, normally using 4
or more satellites, and in some case 3 sat-
ellites. The GPS system has a certain level
of inaccuracy. While the navigation system
will compensate for this most of the time,
occasional positioning errors of up to 300
feet (100 m) can and should be expected.
Generally, position errors will be corrected
within a few seconds.
The GPS signal may be physically ob-
structed, leading to inaccurate vehicle po-
sition on the map display. Tunnels, tall
buildings, trucks, or even the placement of
objects on the instrument panel may ob-
struct the GPS signals.
The GPS satellites may not send signals
due to repairs or improvements being
made to them.
Even when the navigation system is re-
ceiving clear GPS signals, the vehicle po-
sition may not be shown accurately or
inappropriate route guidance may occur in
some cases.
zAccurate current vehicle position may not
be shown in the following cases:
• When driving on a small angled Y-
shaped road.
• When driving on a winding road.
• When driving on a slippery road such as
in sand, gravel, snow, etc.
• When driving on a long straight road.
• When motorway and surface streets run
in parallel.
• After moving by ferry or vehicle carrier.
• When a long route is searched during
high speed driving.
• When driving without setting the current
position calibration correctly.
• After repeating a change of direction by
going forward and backward, or turning
on a turntable in the parking lot.
• When leaving a covered parking lot or
parking garage.
• When a roof carrier is installed.
• When driving with tyre chains installed.
• When the tyres are worn.
• After replacing a tyre or tyres.
• When using tyres that are smaller or
larger than the factory specifications.
• When the tyre pressure in any of the four
tyres is not correct.
This navigation system calculates the
current vehicle position using satellite
signals, various vehicle signals, map
data, etc. However, an accurate posi-
tion may not be shown depending on
satellite condition, road configuration,
vehicle condition or other circumstanc-
es.
NOTICE
●The installation of window tinting may
obstruct the GPS signals. Most window
tinting contains some metallic content
that will interfere with GPS signal recep-
tion of the antenna. We advise against
the use of window tinting on vehicles
equipped with navigation systems.
218
7. NAVIGATION SYSTEM INFORMATION
DA_EXT_COROLLA_touch screen_EE
zInappropriate route guidance may occur in
the following cases:
• When turning at an intersection off the
designated route guidance.
• If you set more than one destination but
skip one of them, auto reroute will dis-
play a route returning to the destination
that was skipped.
• When turning at an intersection for which
there is no route guidance.
• When passing through an intersection
for which there is no route guidance.
• During auto reroute, the route guidance
may not be available for the next turn to
the right or left.
• It may take a long time to operate auto
reroute during high speed driving. In
auto reroute, a detour route may be
shown.
• After auto reroute, the route may not be
changed.
• An unnecessary U-turn may be shown or
announced.
• A location may have multiple names and
the system will announce one or more.
• Some routes may not be searched.
• If the route to your destination includes
gravel, unpaved roads or alleys, the
route guidance may not be shown.
• Your destination point might be shown
on the opposite side of the street.
• When a portion of the route has regula-
tions prohibiting the entry of the vehicle
that vary by time or season or other rea-
sons.
• The road and map data stored in the
navigation system may not be complete
or may not be the latest version.
INFORMATION
●This navigation system uses tyre turning
data and is designed to work with fac-
tory-specified tyres for the vehicle.
Installing tyres that are larger or smaller
than the originally equipped diameter
may cause inaccurate display of the cur-
rent vehicle position. The tyre pressure
also affects the diameter of the tyres so
make sure the tyre pressure of all four
tyres is correct.
219
7. NAVIGATION SYSTEM INFORMATION
DA_EXT_COROLLA_touch screen_EE
7
NAVIGATION SYSTEM
2. NAVIGATION DATABASE UPDATES
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Select “Yes” when the confirmation
screen appears.
4Enter license key.
zIf the license key is invalid, the navigation
database will not be updated.
5Select “Confirm”.
6Check that the updating screen is dis-
played.
UPDATING NAVIGATION
DATABASE
Navigation database that contains sys-
tem software and map data, etc. can
be updated using a USB memory.
For details, contact Toyota dealer or
refer to Toyota portal site
(www.my.toyota.eu).
INFORMATION
●Updating may not complete correctly in
the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during updating.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during updating.
• If the USB memory is removed before
updating is complete
●The amount of time required to complete
the update process depends on the size
of the data.
220
7. NAVIGATION SYSTEM INFORMATION
DA_EXT_COROLLA_touch screen_EE
8
221
1
2
8
4
5
6
7
3
DA_EXT_COROLLA_touch screen_EE
1. QUICK REFERENCE.................. 222
2. PICTURE SLIDESHOW .............. 225
DISPLAYING THE PICTURES ............ 225
OPERATING A PICTURE
SLIDESHOW..................................... 226
3. E-MAIL ........................................ 227
RECEIVING AN E-MAIL ...................... 227
CHECKING E-MAIL............................. 228
4. MirrorLink................................ 229
5. TOYOTA EUROCARE ................ 230
REGISTERING A COUNTRY .............. 230
USING THE TOYOTA EUROCARE .... 231
1. CONNECTED SERVICE
OVERVIEW................................ 232
2. BEFORE USING CONNECTED
SERVICE ................................... 236
OBTAINING A PORTAL SITE
ACCOUNT........................................ 236
LOGIN PROCESS CONNECTED
SERVICES........................................ 237
3. ONLINE SEARCH ....................... 239
ONLINE SEARCH ............................... 239
VIEWING POI* DETAILS .................... 242
SELECTING A SEARCH ENGINE...... 243
4. LOADING POIs*/ROUTE ............ 244
DOWNLOADING VIA A CELLULAR
PHONE............................................. 244
DOWNLOADING FROM A
USB MEMORY ................................. 244
5. OPERATING AN APPLICATION
USING CONNECTED
SERVICE ................................... 245
DOWNLOADING AN APPLICATION
TO THE SYSTEM............................. 245
OPERATING AN APPLICATION ........ 246
1APPLICATIONS OPERATION 2CONNECTED SERVICE
APPLICATION
Not all connected services may be available in all countries.
Some of the functions cannot be operated while driving.
*: Point of Interest
222
DA_EXT_COROLLA_touch screen_EE
1. APPLICATIONS OPERATION
1. QUICK REFERENCE
XMultimedia system
■“Extras” MENU SCREEN
The applications can be accessed by pressing the button.
Each time the button is pressed, the screen will change between the
“Phone” menu screen and the “Extras”/“Toyota online” menu screen.
When the button is pressed, the screen that was last displayed is returned
to. Select to display the “Extras”/“Toyota online” menu screen.
224
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
No. Function Application Page
∗Select to access connected service.
Online search 239
Loading POIs/Routes 244
Vehicle customisation “Owner’s
manual”
Select to access preinstall application.
Pictures∗225
Emails 227
MirrorLink229
Toyota Eurocare∗230
∗Select to close the application.
∗Select to display the application's option screen. 246
∗Select to downloaded application.
∗: Navigation system only
INFORMATION
●The shown screen in the illustrations may differ from your vehicle's screen in terms of
equipment.
225
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
2. PICTURE SLIDESHOW∗
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Display the “Toyota online” menu
screen. (→P.222)
4Select “Pictures”.
zThe slideshow starts automatically.
Pictures stored on a USB memory can
be viewed.
INFORMATION
●This function is not available while driv-
ing.
●When the vehicle starts moving while
viewing pictures, a pop-up window will
be displayed and pictures cannot be dis-
played. Select “Leave function” to
return to the “Toyota online” menu
screen.
●Available image data format: JPEG,
PNG and BMP
∗: Navigation system only
DISPLAYING THE PICTURES
INFORMATION
●All readable pictures on the device are
displayed in chronological order. The
slideshow will repeat when it is finished.
●The pictures will be changed every few
seconds.
226
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
1Select .
2Check that the operating switches are
displayed.
OPERATING A PICTURE
SLIDESHOW
A slideshow can be played, paused,
and desired images can be selected.
No. Function
Select to display the previous/ next
picture.
Select to pause the slideshow.
Select to play the slideshow
again.
Select to close the operating switch-
es.
INFORMATION
●When the slideshow is playing, the
pause and skip screen buttons disap-
pear automatically after a few seconds.
227
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
3. E-MAIL
1Select “Show” to check the e-mail.
2Check that the e-mail is displayed.
Incoming e-mails to a connected
Bluetooth® phone can be downloaded.
Before using this application, connect
a Bluetooth® phone with a phone
profile. (→P.119, 126)
INFORMATION
●This function may not be available
depending on the phone.
●E-mails cannot be sent using this func-
tion.
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
RECEIVING AN E-MAIL
When a new e-mail is received, a pop-up
window is displayed on the screen.
INFORMATION
●This function can be set to on or off.
(→P.139)
228
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
1Display the “Extras”/“Toyota online”
menu screen. (→P.222)
2Select “Emails”.
zWhen the downloading of an e-mail has
been completed, the mail list will be dis-
played.
3Select the desired e-mail.
zThe state of an e-mail is shown by the fol-
lowing icons.
: Unread mail
: Read mail
4Check that the message is displayed.
CHECKING E-MAIL
229
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
4. MirrorLink
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a MirrorLink device.
zOnly one MirrorLink device can be con-
nected at a time.
3Display the “Extras”/“Toyota online”
menu screen. (→P.222)
4Select a desired application, when
available MirrorLink applications are
displayed.
zThe MirrorLink application display may
be different than shown depending on the
connected MirrorLink device or applica-
tion.
5Check that a confirmation screen is
displayed and then select “Confirm”.
When a MirrorLink compatible device
is connected via USB, a MirrorLink
screen is displayed on the navigation/
multimedia system display. The Mirror-
Link device can be operated via nav-
igation/multimedia system.
INFORMATION
●This function may not be available
depending on the device.
230
1. APPLICATIONS OPERATION
DA_EXT_COROLLA_touch screen_EE
5. TOYOTA EUROCARE∗
1Display the “Toyota online” menu
screen. (→P.222)
2Select “Toyota Eurocare”.
3Select the country.
4Check that the country is displayed on
the screen.
1Display the “Toyota online” menu
screen. (→P.222)
2Select “Toyota Eurocare”.
3Select the registered country.
4Select another country to replace the
existing country.
5Check that the country is displayed on
the screen.
This feature is used to make a call to
Toyota Eurocare service.
Before using this function, connect a
Bluetooth® phone with a phone profile.
(→P.126)
REGISTERING A COUNTRY
∗: Navigation system only
CHANGING A COUNTRY
231
1. APPLICATIONS OPERATION
8
APPLICATION
DA_EXT_COROLLA_touch screen_EE
1Display the “Toyota online” menu
screen. (→P.222)
2Select “Toyota Eurocare”.
3Select “Call Eurocare”.
4Select “Yes” when the confirmation
screen appears.
5Check that the following screen will be
displayed.
zThe geographic coordinates of the current
location will be displayed at the top-left cor-
ner of the screen.
zWhen “...” appears on the screen, select
to display the following position details.
On freeways: Freeway number, driving
direction and next exit.
On other roads: Address information.
Each time “...” is selected, the screen
changes between the geographical coor-
dinates and position details.
USING THE TOYOTA
EUROCARE
INFORMATION
●The call must be placed in a country
where Toyota Eurocare service is avail-
able.
EN2087DC
232
DA_EXT_COROLLA_touch screen_EE
2. CONNECTED SERVICE
1. CONNECTED SERVICE OVERVIEW∗
XOnline search
The following services are available by connecting the navigation system to Toyota
portal site via the internet using a cellular phone.
zOnline search: New establishments, such as restaurants, bars etc., that are not reg-
istered in the navigation system can be set as a destination.
zImporting memory points and routes: Establishments that were searched using a
computer can be set as a destination and can be registered in the “Stored” list on the
“My destinations” screen. (→P.81)
zVehicle customisation: Some vehicle settings can be changed via the connected
services, by vehicle's settings data to and from the Toyota portal site. (→P.136)
zApplication: Various functions can be added by downloading applications using a
USB memory.
No. Name Operation
Navigation system Enter a keyword.
Toyota portal site*/
Contents provider
The keyword is sent to the search engine, the results are re-
ceived and sent to the navigation system.
*: For details about Toyota portal site, refer to www.my.toyota.eu.
∗: Navigation system only
233
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
XImporting memory points and routes: Downloading via a cellular phone
XImporting memory points and routes: Downloading from a USB memory
No. Name Operation
Your personal comput-
er and Toyota portal
site*
Access the portal site and search POIs and routes.
Toyota portal site* The POIs and routes are saved at Toyota portal site.
Navigation system
Via the internet, the POIs and routes are downloaded to the
navigation system.
Via the USB the POIs and routes are downloaded to the nav-
igation system.
USB memory The POIs and routes are saved to a USB.
*: For details about Toyota portal site, refer to www.my.toyota.eu.
234
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
XVehicle customisation: Sending vehicle's settings data to and from the Toyota por-
tal site
No. Name Operation
Navigation system Via the internet, the vehicle’s settings are sent to/receive from
the Toyota portal site.
Toyota portal site* The vehicle’s settings are saved at Toyota portal site.
Your personal comput-
er and Toyota portal
site*
Access the portal site and change the vehicle’s settings.
*: For details about Toyota portal site, refer to www.my.toyota.eu.
235
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
XApplication
No. Name Operation
Your personal comput-
er and Toyota portal
site*
Access the portal site and download application.
USB memory The downloaded application is saved to a USB.
Navigation system
Via the USB the application is downloaded to the navigation
system.
Runs applications on the navigation system.
Contents provider Contents received via a cellular phone.
*: For details about Toyota portal site, refer to www.my.toyota.eu.
236
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
2. BEFORE USING CONNECTED SERVICE∗
zIn order to use this service, a Bluetooth®
DUN/PAN capable cellular phone with a
valid data plan subscription is required.
zWhen using the connected services,
depending on your phone subscription,
some related fees might apply.
zWhen a cellular phone is used in a roam-
ing situation (when outside the geographi-
cal coverage area of mobile network
provider) connection fees will be more
expensive.
1Press the “SETUP” button.
2Select “General”.
3Select “System information”.
OBTAINING A PORTAL SITE
ACCOUNT
Before using connected services, it is
necessary to first access Toyota portal
site (www.my.toyota.eu) via a personal
computer and create an account.
Vehicle Identification Number (VIN) is
required to obtain an account from the
navigation system. For details on the
Vehicle Identification Number, refer to
“Owner’s manual”.
∗: Navigation system only
CHECKING DEVICE
IDENTIFICATION
237
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
4Check that the device ID is displayed.
1Activate any connected service.
zWhen the cost warning or roaming warn-
ing screen is displayed, select “Con-
tinue”. This function can be set to on or
off. (→P.135)
2Select “Username”.
3Input the server username and then
select “OK”.
4Select “Password”.
5Input the server password and then se-
lect “OK”.
No. Function
Displays the device ID
Select to copy system information to
the USB memory connected to the
device.
LOGIN PROCESS
CONNECTED SERVICES
Before using connect services, con-
nect a Bluetooth® phone with an inter-
net profile. (→P.126)
How to activate connected service Page
Online search 239
Loading POIs/Routes 244
Download an application 245
Vehicle customisation 136
238
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
6Select “Confirm login information”.
zWhen “Remember password” is on, the
entered user login information will be
remembered for every login.
zIf the account already has 5 cars regis-
tered, it is not possible to register another
car.
239
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
3. ONLINE SEARCH∗
1Display the “Toyota online” menu
screen. (→P.222)
2Select “Online search”
zOnline search can be entered on the “POI”
screen. (→P.181)
3Select to select the desired search en-
gine.
zIf there is more than one online search
engine available, these engines will be
displayed.
zThe desired online search engine can be
changed. (→P.243)
4Select the desired search area.
5Enter the search word and then select
“OK”.
: Select to enter keywords from pre-
viously set keywords list. (→P.241)
ONLINE SEARCH
A destination can be selected via
connected service.
Online search will not be available in all
countries.
∗: Navigation system only
No. Function
Select to set a location around the
current position.
Select to set the location around the
main destination.
Select to set the desired city.
Select “Enter city” to enter the city
name and then select “OK”.
Select to set a location by using a
point on the map.Select the desired
point on the map and then select
“Select”.
240
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
6Check that the search results is dis-
played. Select the desired item.
zAt the end of the list “Download more”
will be shown. Select “Download more”
to search up to 20 new items.
•“Download more” will not be shown if
the list includes only less than 20 entries.
• Select “Previous results” to display the
previous result.
7Select “Go”.
zThe route will be recalculated.
No. Function
Search results
•Up to 20 search results are down-
loaded at a time.
•Highlighted advertisements may
be displayed at the top of the
search result list.
Select to display a full screen map.
No. Function Page
Select to display the de-
tailed information. 242
Select to call the registered
telephone number. 88
INFORMATION
●After establishments acquired using
“Online search” have been set as a des-
tination once, they will be stored in the
“Stored” list on the “My Destinations”
screen.
241
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
1Select on the search word enter-
ing screen.
2Select the desired word.
3Select “OK”.
■DELETE SEARCH WORDS HISTO-
RY
1Select .
2Select the desired item.
3Select “Yes”.
ENTERING KEYWORDS FROM
THE LIST
Search can be again started from the
history of a search word.
The maximum number of search word
history is 10.
242
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
1Select on the POI information
screen.
2Check that the details of the selected
POI are displayed.
zSelect the desired picture to display full
screen. (if available)
■RATING POI INFORMATION
1Display the last page of POI informa-
tion and select “Provide feedback
about POI”.
2Check that the following screen is dis-
played.
3Select “Submit”.
VIEWING POI DETAILS
Your rating of the selected POI can be
submitted. If the information is incor-
rect, you can notify the search provider
by selecting the appropriate button.
This function may not be available de-
pending on the search provider.
No. Function
Select to enter your rating.
Select to notify the search provider
of incorrect information.
243
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
1Select the search engine logo.
zA list of available other search engine is
shown.
2Select the desired search engine.
zAfter selection of one of the search engine
the search process starts from beginning
with this provider.
zIf there are no other search engines avail-
able, selecting the search engine logo will
have no effect.
SELECTING A SEARCH
ENGINE
Throughout the entire search process
it is possible to change the search en-
gine by selecting on the logo of the cur-
rent search engine.
INFORMATION
● or : Indicates if online con-
nection is active or not.
After a timeout of 1 minute, an active
online connection will automatically be
terminated.
244
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
4. LOADING POIs/ROUTE∗
1Display the “Navigation” menu screen
and select “Enter destination”.
(→P.163)
2Select the “Advanced” tab.
3Select “Load POIs and routes from
server”.
4Check that a loading the data screen is
displayed.
5Check that a confirmation screen is
displayed when the operation is com-
plete.
zThe entry is registered in the “Stored” list
on the “My destinations” screen. (→P.81)
POIs and routes can be added by
downloading from the Toyota portal
site. They will be stored in the “Stored”
list on the “My destinations” screen.
(→P.81)
DOWNLOADING VIA A
CELLULAR PHONE
∗: Navigation system only
INFORMATION
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
●If the “Automatic download of POIs
and routes” function is on, POIs and
routes from the server will be down-
loaded automatically. (→P.137)
●If the maximum number of possible
stored contacts has been reached, a
confirmation screen appears. Delete
contact(s) to make room for new con-
tact(s). (→P. 83 )
DOWNLOADING FROM A
USB MEMORY
For details about downloading from a
USB memory. (→P.204)
245
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
8
APPLICATION
5. OPERATING AN APPLICATION USING CONNECTED SERVICE
∗
1Open the cover of the auxiliary box and
then open the cover of the USB/AUX
port.
2Connect a USB memory.
3Select “Yes” when the confirmation
screen appears.
4Select “Enter Key” and then enter the
license key.
zIf the license key is invalid, the application
will not be downloaded.
5Select “Confirm”.
6Check that the updating screen is dis-
played.
DOWNLOADING AN
APPLICATION TO THE
SYSTEM
To download an application, a USB
memory that contains the application
data is required. For details about an
application, refer to Toyota portal site
(www.my.toyota.eu).
∗: Navigation system only
INFORMATION
●Downloading may not complete cor-
rectly in the following cases:
• Vehicles without a smart entry & start
system: If the engine switch is turned
to the “LOCK” position during down-
loading.
• Vehicles with a smart entry & start sys-
tem: If the engine switch is turned off
during downloading.
• If the USB memory is removed before
downloading is complete
246
2. CONNECTED SERVICE
DA_EXT_COROLLA_touch screen_EE
1Display the “Toyota online” menu
screen. (→P.222)
2Select the desired application.
1Display the “Toyota online” menu
screen. (→P.222)
2Select next to the desired applica-
tion.
3Check that the application option
screen is displayed.
OPERATING AN
APPLICATION
For details about operating the appli-
cation, refer to www.my.toyota.eu.
SETTING AN APPLICATION No. Function
Displays information about the ap-
plication.
If the check box has been activated,
application will be started automati-
cally after this system turn on.
Select to delete the application.
247
DA_EXT_COROLLA_touch screen_EE
1
2
3
4
5
6
7
8
INDEX
248
ALPHABETICAL INDEX
DA_EXT_COROLLA_touch screen_EE
A
AAC .............................................. 36, 69, 71
Adding and editing stopovers................. 193
Address .................................................. 180
AF (Alternative frequency)........................ 34
AM ............................................................ 30
Application.............................................. 222
Arrival time.............................................. 189
Audio ........................................................ 26
Basic operation ..................................... 27
Inserting or ejecting a disc .................... 28
Switching audio source......................... 28
System on/off........................................ 27
USB/AUX port....................................... 29
Audio operating information......................64
CD player and discs.............................. 67
CD-R and CD-RW discs........................71
File (audio) ............................................ 69
iPod....................................................... 66
Radio.....................................................64
Terms....................................................71
Audio settings .........................................140
AUX .......................................................... 52
Control panel/screen.............................52
AUX port ................................................... 29
Average speed........................................109
249
DA_EXT_COROLLA_touch screen_EE
B
Before using connected service ............. 236
Login process...................................... 237
Portal site account .............................. 236
Blocking road ahead............................... 196
Bluetooth®.......................... 55, 73, 119, 126
Bluetooth® audio ...................................... 55
Connecting............................................ 59
Control panel/screen............................. 55
Listening................................................ 60
Options.................................................. 60
Bluetooth® phone ..................................... 74
Bluetooth® settings................................. 119
Function on/off............................ 119, 127
Paired device list......................... 124, 134
Pairing a Bluetooth® device........ 120, 127
Profiles........................................ 122, 132
Status display.............................. 123, 133
C
Calibration................................................. 21
Call lists .................................................... 87
Calling on a Bluetooth® phone ................. 85
Call lists.................................................87
Contacts list........................................... 86
Dial........................................................ 85
Phone book........................................... 86
POI call.................................................. 88
Short message...................................... 88
SOS screen button................................ 89
250
ALPHABETICAL INDEX
DA_EXT_COROLLA_touch screen_EE
CD ............................................................ 36
Control panel/screen............................. 36
Options.................................................. 40
Playing an audio CD ............................. 39
Playing an MP3/WMA/AAC disc ........... 39
CD player and discs ................................. 67
CD-R and CD-RW discs........................... 71
Cellular phone .......................................... 74
Connected service.................................. 232
Contacts ................................................... 86
Contacts list.............................................. 86
Coordinates ............................................ 184
Current vehicle position.......................... 167
D
Deleting personal data............................116
Destination search..................................178
Address...............................................180
Coordinates.........................................184
Map ..................................................... 184
Phone book.........................................180
POIs .................................................... 181
Previous destinations..........................179
Registered points ................................179
Detouring a segment on the route ..........197
Dial............................................................ 85
Dialing a second number..........................93
Display settings....................................... 117
Camera display ...................................118
Day mode............................................118
Displaying route information ................... 195
Displaying the turn list.............................196
Download application..............................245
Downloading an application ................245
Operating an application ..................... 246
251
DA_EXT_COROLLA_touch screen_EE
E
e-mail...................................................... 227
Checking............................................. 228
Receiving ............................................ 227
Editing route ........................................... 192
Adding and editing stopovers.............. 193
Blocking road ahead........................... 196
Detouring a segment on the route ...... 197
Displaying route information ............... 195
Displaying the turn list......................... 196
Recalculating by the traffic
messages........................................ 199
Stopping route guidance..................... 193
Entry information ............................................ 206
F
File (audio)................................................ 69
FM............................................................. 30
Fuel consumption ...................................108
Past record..........................................109
Trip information ...................................109
G
General settings......................................114
Volume settings...................................116
H
Hands-free system....................................77
Connecting Bluetooth® phone...............80
Phone book........................................... 79
Phone switch/microphone..................... 78
Release your car................................... 79
Heading-up .............................................169
Aとして、P.256にイドウ
252
ALPHABETICAL INDEX
DA_EXT_COROLLA_touch screen_EE
I
Icon information...................................... 170
Inserting or ejecting a disc........................ 28
Internet connection................................. 130
Quick setup of an internet
connection....................................... 136
iPod .................................................... 47, 66
Audio..................................................... 51
Control panel/screen............................. 47
Options.................................................. 51
L
List screen ................................................ 21
Loading POIs/route................................. 244
Cellular phone..................................... 244
USB memory....................................... 244
M
Map.........................................................167
Map icons ...............................................170
Icon information...................................170
POI icons.............................................170
Map screen..................................... 163, 167
Configurations..................................... 168
Current vehicle position....................... 167
Scrolling the map ................................ 168
Map settings ........................................... 211
Memory point..........................................200
MirrorLink.............................................229
MP3 .............................................. 36, 69, 71
253
DA_EXT_COROLLA_touch screen_EE
N
Navigation............................................... 158
Navigation database updates................. 219
Navigation menu screen......................... 163
Navigation system function index........... 165
North-up.................................................. 169
O
Online search ......................................... 239
POI details .......................................... 242
Selecting a search engine................... 243
Overview buttons...................................... 16
P
Phone ....................................................... 74
Phone book.................................79, 86, 180
Phone switch/microphone......................... 78
Picture.....................................................225
Picture slideshow.................................... 225
Displaying the pictures........................225
POI call .....................................................88
POI category...........................................181
POI icons................................................ 170
POIs........................................................ 181
Previous destinations.............................. 179
254
ALPHABETICAL INDEX
DA_EXT_COROLLA_touch screen_EE
R
Radio .................................................. 30, 64
Control panel/screen............................. 30
Options.................................................. 35
Presetting a station ............................... 33
RDS (Radio Data System).................... 34
Tuning................................................... 33
RDS (Radio Data System)........................ 34
Rear view monitor system...................... 144
Camera ............................................... 149
Guide lines.......................................... 146
Screen................................................. 146
Recalculating by
the traffic messages............................ 199
Receiving calls on
a Bluetooth® phone...............................90
Registered points....................................179
Registering entry...............................81, 200
Displaying and editing........................... 83
Registering............................................ 81
Sending to USB memory.......................84
Road preference.....................................214
Route guidance.......................................186
Adjusting .............................................187
Starting................................................186
Route guidance screen........................... 189
Route settings.........................................214
255
DA_EXT_COROLLA_touch screen_EE
S
Scrolling the map.................................... 168
Search engine ........................................ 243
Sending tones........................................... 92
Setup ...................................................... 112
Short message ................................... 88, 95
Checking received short
messages.......................................... 95
Receiving .............................................. 95
Sending................................................. 97
SMS.......................................................... 95
SOS screen button ................................... 89
Steering switches ..................................... 62
Stopping route guidance......................... 193
Stored contacts....................................... 209
Restoring from a USB memory........... 210
Sending to a USB memory ................. 209
Stored route............................................ 200
System function index .............................. 14
T
TA (Traffic announcement).......................34
Talking on a Bluetooth® phone................. 91
Dialing a second number ...................... 93
Receiver volume ................................... 94
Sending tones .......................................92
Telephone settings ................................. 139
Touch screen gestures .............................18
Touch screen operation............................ 19
Entering screen..................................... 20
List screen.............................................21
Toyota Eurocare ..................................... 230
Registering a country .......................... 230
Using the Toyota Eurocare ................. 231
Toyota web account settings ..................136
Traffic message settings.........................215
Traffic messages ....................................174
Travel time.............................................. 189
Tuning....................................................... 33
Turn list................................................... 196
256
ALPHABETICAL INDEX
DA_EXT_COROLLA_touch screen_EE
U
USB memory ............................................ 42
Control panel/screen............................. 42
Options.................................................. 46
Playing a USB memory......................... 46
USB/AUX port........................................... 29
V
Vehicle settings ...................................... 142
Voice guidance....................................... 190
W
WMA............................................. 36, 69, 71
P.251よりＡイレル
ただし、階層１とする
257
DA_EXT_COROLLA_touch screen_EE
Map database information
END-USER TERMS
The data (“Data”) is provided for your
personal, internal use only and not for
resale. It is protected by copyright, and
is subject to the following terms and
conditions which are agreed to by you,
on the one hand, and Harman
(“Harman”) and its licensors (including
their licensors and suppliers) on the
other hand.
© 2011 NAVTEQ B.V., © Bundesamt für
Eich- und Vermessungswesen, ©
EuroGeographics, source: © IGN 2009 -
BD TOPO ®, Die Grundlagendaten
wurden mit
Genehmigung der zustaendigen
Behoerden entnommen, Contains
Ordnance Survey data © Crown
copyright and database right 2010
Contains Royal Mail data © Royal Mail
copyright and database right 2010,
Copyright Geomatics Ltd., Copyright ©
2003; Top-Map Ltd., La Banca Dati
Italiana è stata prodotta usando quale
riferimento anche cartografia numerica
ed al tratto prodotta e fornita dalla
Regione Toscana., Copyright © 2000;
Norwegian Mapping Authority, Source:
IgeoE – Portugal, Información
geográfica propiedad del CNIG, Based
upon electronic data Ó National Land
Survey Sweden., Topografische
Grundlage: Ó Bundesamt für
Landestopographie.. All rights reserved.
TERMS AND CONDITIONS
PLEASE READ THIS END USER
LICENSE AGREEMENT CAREFULLY
BEFORE USING THE NAVTEQ
DATABASE
NOTICE TO THE USER
THIS IS A LICENSE AGREEMENT -
AND NOT AN AGREEMENT FOR SALE
– BETWEEN YOU AND NAVTEQ B.V.
FOR YOUR COPY OF THE NAVTEQ
NAVIGABLE MAP DATA-BASE,
INCLUDING ASSOCIATED
COMPUTER SOFTWARE, MEDIA AND
EXPLANATORY PRINTED
DOCUMENTATION PUBLISHED BY
NAVTEQ (JOINTLY “THE
DATABASE”). BY USING THE
DATABASE, YOU ACCEPT AND
AGREE TO ALL TERMS AND
CONDITIONS OF THIS END USER
LICENSE AGREEMENT
(“AGREEMENT”). IF YOU DO NOT
AGREE TO THE TERMS OF THIS
AGREEMENT, PROMPTLY RETURN
THE DATABASE, ALONG WITH ALL
OTHER ACCOMPANYING ITEMS, TO
YOUR SUP-PLIER FOR A REFUND.
OWNERSHIP
The Database and the copyrights and
intellectual property or neighboring
rights therein are owned by NAVTEQ or
its licensors. Ownership of the media on
which the Database is contained is
retained by NAVTEQ and/or your
supplier until after you have paid in full
any amounts due to NAVTEQ and/or
your supplier pursuant to this Agreement
or similar agreement(s) under which
goods are provided to you.
258
DA_EXT_COROLLA_touch screen_EE
LICENSE GRANT
NAVTEQ grants you a non-exclusive
license to use the Database for your
personal use or, if applicable, for use in
your business’ internal operations. This
license does not include the right to
grant sub-licenses.
LIMITATIONS ON USE
The Database is restricted for use in the
specific system for which it was created.
Except to the extent explicitly permitted
by mandatory laws (e.g. national laws
based on the European Software
Directive (91/250) and the Database
Directive (96/9)), you may not extract or
reutilize substantial parts of the contents
of the Database nor reproduce, copy,
modify, adapt, translate, disassemble,
decompile, reverse engineer any portion
of the Database. If you wish to obtain
interoperability information as meant in
(the national laws based on) the
European Software Directive, you shall
grant NAVTEQ reasonable opportunity
to provide said information on
reasonable terms, including costs, to be
determined by NAVTEQ.
TRANSFER OF LICENSE
You may not transfer the Database to
third parties, except when installed in the
system for which it was created or when
you do not retain any copy of the
Database, and provided that the
transferee agrees to all terms and
conditions of this Agreement and
confirms this in writing to NAVTEQ.
Multi-disc sets may only be transferred
or sold as a complete set as provided by
NAVTEQ and not as subset thereof.
LIMITED WARRANTY
NAVTEQ warrants that, subject to the
warnings set out below, for a period of
12 months after acquisition of your copy
of the Database, it will perform
substantially in accordance with
NAVTEQ’s Criteria for Accuracy and
Completeness existing on the date you
acquired the Database; these criteria are
available from NAVTEQ at your request.
If the Database does not perform in
accordance with this limited warranty,
NAVTEQ will use reasonable efforts to
repair or replace your non-conforming
copy of the Database. If these efforts do
not lead to performance of the Database
in accordance with the warranties set out
herein, you will have the option to either
receive a reasonable refund of the price
you paid for the Database or to rescind
this Agreement. This shall be NAVTEQ’s
entire liability and your sole remedy
against NAVTEQ. Except as expressly
provided in this section, NAVTEQ does
not warrant nor make any
representations regarding the use of
results of the use of the Database in
terms of its correctness, accuracy,
reliability, or otherwise. NAVTEQ does
not warrant that the Database is or will
be error free. No oral or written
information or advice provided by
NAVTEQ, your supplier or any other
person shall create a warranty or in any
way increase the scope of the limited
warranty described above. The limited
warranty set forth in this Agreement
does not affect or prejudice any statutory
legal rights that you may have under the
legal warranty against hidden defects.
259
DA_EXT_COROLLA_touch screen_EE
If you did not acquire the Database from
NAVTEQ directly, you may have
statutory rights against the person from
whom you have acquired the Database
in addition to the rights granted by
NAVTEQ hereunder according to the
law of your jurisdiction. The above
warranty of NAVTEQ shall not affect
such statutory rights and you may assert
such rights in addition to the warranty
rights granted herein.
LIMITATION OF LIABILITY
The price of the Database does not
include any consideration for
assumption of risk of consequential,
indirect or unlimited direct damages
which may arise in connection with your
use of the Database. Accordingly, in no
event shall NAVTEQ be liable for any
consequential or indirect damages,
including without limitation, loss of
revenue, data, or use, incurred by you or
any third party arising out of your use of
the Database, whether in an action in
contract or tort or based on a warranty,
even if NAVTEQ has been advised of
the possibility of such damages. In any
event NAVTEQ’s liability for direct
damages is limited to the price of your
copy of the Database.
THE LIMITED WARRANTY AND
LIMITATION OF LIABILITY, SET
FORTH IN THIS AGREE-MENT, DO
NOT AFFECT OR PREJUDICE YOUR
STATUTORY RIGHTS WHERE YOU
HAVE ACQUIRED THE DATABASE
OTHERWISE THAN IN THE COURSE
OF A BUSINESS.
WARNINGS
The Database may contain inaccurate or
incomplete information due to the
passage of time, changing
circumstances, sources used and the
nature of collecting comprehensive
geographic data, any of which may lead
to incorrect results. The Database does
not include or reflect information on -
inter alia - neighborhood safety; law
enforcement; emergency assistance;
construction work; road or lane closures;
vehicle or speed restrictions; road slope
or grade; bridge height, weight or other
limits; road or traffic conditions; special
events; traffic congestion; or travel time.
GOVERNING LAW
This Agreement shall be governed by
the laws of the jurisdiction, in which you
reside at the date of acquisition of the
Database. Should you at that moment
reside outside the European Union or
Switzerland, the law of the jurisdiction
within the European Union or
Switzerland where you acquired the
Database shall apply. In all other cases,
or if the jurisdiction where you acquired
the Database cannot be defined, the
laws of the Netherlands shall apply. The
courts competent at your place of
residence at the time you acquired the
Database shall have jurisdiction over
any dispute arising out of, or relating to
this Agreement, without prejudice to
NAVTEQ’ right to bring claims at your
then current place of residence.
260
DA_EXT_COROLLA_touch screen_EE
Certification
261
DA_EXT_COROLLA_touch screen_EE
262
DA_EXT_COROLLA_touch screen_EE
263
DA_EXT_COROLLA_touch screen_EE
264
DA_EXT_COROLLA_touch screen_EE
Regulatory
257
CAUTION
Changes
or modifications not expressly
approved by the party responsible for
compliance could void the user
’s
authority to operate the equipment.
