1 User Information
1.1 Purpose
This document describes the features, functionality and usage of the P104 headphone featured by
Kleer technology. It contains and specifies all relevant information about the headphone’s
appearance and the environment it is designated to be used in.
The P104 is designed to combine the comfort and acoustical performance of premium headphones
with compliance to automotive requirements.
Two variants are offered; one to be used only in the front and one to be used on every passenger
seat in the car.
2 Main Features
Small size
Folding mechanism for easy storage
Rich sound through 40mm transducer
High-quality digital audio with Kleer technology
Comfortable through ergonomic fit and gimbaled earphones
Adjustable from children to adults
2.1 Product Description
P104 is wireless stereo headphones, featuring Kleer technology for lossless digital audio
transmission and operates in 2.4GHz ISM band. They are designed for individual entertainment in
vehicles and meets the relevant requirements, such as widened operating temperature range, low
battery consumption for longer battery life and low signal latency for lip-sync. The channel switch
provides the facility to select between three different sources (front right, rear left, rear right).
P104 is powered with two AAA batteries. Both, disposable and rechargeable can be used. An LED
indicates the functional state, but also turns from green to red when the batteries’ voltage reaches
the low level to signalize that they have to be changed soon.
Acoustical characteristic is semi-closed with supra-aural earphones. Sound radiation to the
environment is low, so that other passengers will not be disturbed.
The mechanic design guarantees comfortable wearing constantly for several hours.
User Instruction P104
P104_UserManual-SV_130226.docx Version 1.0 4/9
User Instruction P104
P104_UserManual-SV_130226.docx Version 1.0 5/9
User Instruction P104
P104_UserManual-SV_130226.docx Version 1.0 6/9
User Instruction P104
P104_UserManual-SV_130226.docx Version 1.0 7/9
3 Technical Information
3.1 Mechanical Features
• P104 is adjustable in size to fit from children to adults
• Foldable for easy storage
• When placed on the seat, the product will withstand an adult person accidentally sitting on it.
• The headphone features round edges to prevent injury.
• The design of the headphone bears the OEM-logo, printed on both ear cups.
3.2 Materials
P104 is in compliance with the latest releases of directives RoHS (2002/95/EC) and ELV
(2000/53/EC), and also the REACH regulation (EC) No. 1907/2006.
Marking of polymer parts acc. to VDA 260 respectively EN ISO 1043.
3.3 Declaration of Conformity to EC regulation R&TTE
