LOADING AND UNLOADING A DISC
LOADING A DISC
CAUTION
lNever try to disassemble or oil any part of the CD player. Do
not insert anything other than a disc into the slot.
1.
Insert a disc into the disc slot.
●After insertion, the disc is automatically loaded.
NOTE
lCompatible Disc: →P.72
lWhen inserting a disc, gently insert the disc with the label facing
up.
UNLOADING A DISC
1.
Press and remove the disc.
NOTE
lDiscs can be unloaded even when the ignition switch is turned
off.
BASIC INFORMATION BEFORE OPERATION
35
BASIC FUNCTION
2
CONNECTING AND
DISCONNECTING A USB MEMORY
DEVICE/PORTABLE DEVICE
CONNECTING A DEVICE
1.
Connect a device.
●Turn on the power of the device if it is not turned on.
NOTE
lCompatible USB memory device: →P.75
lCompatible iPod: →P.75
lThis unit does not support commercially available USB hubs.
lBy connecting a device such as a cellular phone, charging starts
depending on the device.
TOUCH SCREEN GESTURES
Operations are performed by touching the touch screen
directly with your nger.
Operation method Outline Main use
Touch
Quickly touch
and release
once.
Changing
and selecting
various settings
Double Touch
with one
nger*1
Quickly touch
and release
twice with one
nger.
Enlarging the
scale of the map
screen
Double Touch
with two
ngers*1
Quickly touch
and release
twice with two
ngers.
Reducing the
scale of the map
screen
BASIC INFORMATION BEFORE OPERATION
36
Operation method Outline Main use
Drag*2
Touch the
screen with
your nger,
and move the
screen to the
desired position.
• Scrolling the
lists
• Scrolling the
map screen*1
Swipe*2
Quickly move
the screen by
swiping with
your nger.
• Scrolling the
lists
• Scrolling the
map screen*1
Pinch*1
Move your two
ngers further
apart (pinch-
out) to zoom in
the map. Move
your two ngers
closer together
(pinch-in) to
zoom out the
map.
Changing the
scale of the map
screen
*1: 8-inch with Navi system only
*2: The above operations may not be performed on all screens.
NOTE
lSwipe operations may not be performed smoothly in high
altitudes.
BASIC INFORMATION BEFORE OPERATION
37
BASIC FUNCTION
2
TOUCH SCREEN OPERATION
This system is operated mainly by the buttons on the
screen. (Referred to as screen buttons in this manual.)
●When a screen button is touched, a beep sounds.
The beep sound can be turned on/off. (→P.71)
CAUTION
lTo prevent damaging the screen, lightly touch the screen
buttons with your nger.
lDo not use objects other than your nger to touch the screen.
lWipe off ngerprints using a glass cleaning cloth. Do not use
chemical cleaners to clean the screen, as they may damage
the touch screen.
NOTE
lIf the system does not respond to touching a screen button,
move your nger away from the screen and then touch it again.
lDimmed screen buttons cannot be operated.
lThe displayed image may become darker and moving images
may be slightly distorted when the screen is cold.
lIn extremely cold conditions, the map may not be displayed
and the data input by a user may be deleted. Also, the screen
buttons may be harder than usual to depress.
NOTE
lWhen is displayed on the screen, select to close
a pop-up screen.
BASIC INFORMATION BEFORE OPERATION
38
ENTERING LETTERS AND
NUMBERS/LIST SCREEN
OPERATION
ENTERING LETTERS AND NUMBERS
When searching by an address, name, etc., or entering
data, letters and numbers can be entered via the screen.
No. Information/Function
Input eld
• The input eld contains text to assist the user in
completing tasks.
• The position of the cursor can be moved by selecting
the desired location in the input eld.
Select to clear the input eld.
Displays candidate items based on the input letters.
The desired item can be selected.
Select to erase one character.
Select to enter the item.
Select to change keyboard types.
Select to enter symbols.
Select to enter characters in lower case or in upper case.
NOTE
lThe appearance of the keyboard may change or the input
method may be limited depending on the circumstances where
the software keyboard is displayed.
BASIC INFORMATION BEFORE OPERATION
39
BASIC FUNCTION
2
LIST SCREEN OPERATION
The list screen can be scrolled by a swipe gesture.
For details on the operation: →P. 36
The list screen can also be scrolled by the “TUNE/
SCROLL” knob and pressing the knob will enter it.
No. Information/Function
Select to skip to the next or previous page.
This indicates the displayed screen’s position.
Faster scrolling is possible by dragging the position
indicator.
No. Information/Function
Some lists contain character screen buttons which allow
users to jump directly to list entries that begin with the
same letter as the character screen button.
Every time the same character screen button is selected,
the list starting with the subsequent character is
displayed.
BASIC INFORMATION BEFORE OPERATION
40
