The Drive + Play 2 system
Instruction Manual
The Harman Kardon Drive + Play 2 is the premier product
for in-car connectivity of portable music players and digital
devices, including the Apple iPod, Microsoft Zune, USB
flash memory drives, and many other music players.
Equipped with a sleek dash-mounted color display and
wireless ergonomic control wheel, the DP2 and your
portable combine to give you the most sophisticated and
elegant music experience on the road today.
DP2 is also the first device to utilize Harman’s new rev-net
interface, which allows you to mix and match additional
portables -- such as Bluetooth phones and satellite radio
tuners -- all on the same display. The rev-net software
quickly and intuitively organizes all of your digital content
and creates “channels” for your music, allowing for a
simply superior entertainment experience.
Display
Control Wheel
Lighter Hub
most every portable music player
Bluetooth phones Sirius Portable tuners
with expansion kits
54mm • Control the screen
without looking at your
hand!
• Full rotation control
wheel with smooth
detents
• 1 year battery life
• Easily sticks or
screws to any surface
• All digital audio
system and expansion
port housed in a
cigarette lighter
• Intelligent iPod
charging circuit
• Built-in FM
modulator and high
quality line-level
outputs
• Cigarette lighter stalk snaps off to
reveal switched power, battery, and
ground connections
• Easily hidden in the dash for a
clean professional installation
rev-net
expansion
line and FM-
level
outputs
display
connector
portable device
connector
• Shortcuts let you quickly transition
to an artist or album without
browsing through menus
• High performance 200MHz processor
• 3.5” Color Screen
• rev-net compatible for future-proof
expansion
• Anti-aliased fonts
• Sound effects
•Skinning
• Album art
• Easy, elegant installation on dashboard
or windshield
• Automatically makes ‘channels’ of
music, grouped according to your
taste and habits
• Totally change the appearance
with built-in themes, or download
additional themes from the web
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undersired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/ TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the grantee of this device could
void the user's authority to operate the equipment.
