Users Manual

Quick Start Guide
Guide de demarrage rapide
Download the Harman Kardon Controller app to setup and
control your Harman Kardon Omni 20+.
Téléchargez l'application Harman Kardon Controller pour
configurer et commander votre Harman Kardon Omni 20+.
Descargue la aplicación Harman Kardon Controller para
configurar y controlar su Harman Kardon Omni 20+.
Baixe o app de controle da Harman Kardon para configurar e
controlar o Harman Kardon Omni 20+.
Laden Sie die Harman Kardon Controller-App herunter, um Ihren
Harman Kardon Omni 20+ konfigurieren und bedienen zu können.
Scarica l’app Harman Kardon Controller per impostare e
controllare il tuo Harman Kardon Omni 20+.
Download de Harman Kardon Controller app om uw
Harman Kardon Omni 1.0+ te installeren en te bedienen.
Last ned Harman Kardon Kontroll-appen for å sette opp og
kontrollere Harman Kardon Omni 20+.
Lataa Harman Kardon Controller-sovellus, jotta voit määrittää
Harman Kardon Omni 20+ -laitteen asetukset ja hallita sitä.
Загрузите приложение Harman Kardon Controller, чтобы
настроить свой продукт Harman Kardon Omni 20+ и управлять им.
Hämta appen Harman Kardon Controller för att ställa in och styra
din Harman Kardon Omni 20+.
Hent applikationen Harman Kardon Controller, så du kan
konfigurere og styre din Harman Kardon Omni 20+.
Harman Kardon Controller
(ハーマンカードン・コントローラー)アプ を
ダウンロードしてセットアップし、お持ちの
Harman Kardon Omni 20+
(
ハーマンカードン・オムニ10）をコントロールしてください。
Harman Kardon Controller
앱을 다운로드하여
Harman Kardon
Omni 20+
을 설정하고 제어합니다.
下载
Harman Kardon Controller 应用以设置和控制您的
Harman Kardon Omni 20+
。
下載
Harman Kardon Controller
應用程式以設定並控制󲯠的
Harman Kardon Omni 20+
。
Unduh aplikasi Harman Kardon Controller untuk persiapan dan
mengontrol Harman Kardon Omni 20+ Anda.
What’s in the box
x1
x1
Connections
Stand mount screw holes
Trous de vis de montage du pied
Orificios para los tornillos del soporte de montaje
Buracos dos parafusos de montagem do suporte
Löcher für die Befestigungsschrauben
Fori per le viti di montaggio del supporto
Schroefgaten montagestand
Skruehull for veggstativ
Telineen ruuvikiinnityksen reiät
Отверстия для винтов для монтажа стойки
Skruvhål för montering på stativ
Skruehuller til montering af holder
スタンド取り付け用ねじ穴
스탠드 장착 나사 구멍
坐地安装螺丝孔
立式安裝螺孔
Lubang sekrup pemasangan berdiri
AUDIO INETHERNET PORT POWER
Buttons
RESETWPS
SOURCE PLAY/PAUSE
VOLUME - VOLUME +
LINK
OMNI 20+
Wi-Fi streaming via Harman Kardon Controller app
SONGSALBUMS ARTISTS PLA
Song name
Artist name
Basement
Study
Guest Bedroom
GardenLiving room
Drag to the room you want to play
1s
Wi-Fi streaming
Wi-Fi connected
Auto standby (10 minutes)
Bluetooth AUX-In
Local Source
Bluetooth
AUX-in
Bluetooth®
>3s
harmankardon.com/Omni20+
Multi-room music streaming
Party Mode
>3s
Full owner's manual
Mode d'emploi complet
Manual del propietario
Manual do usuário completo
Bedienungsanleitung
Manuale di istruzioni completo
Volledige handleiding
Fullstendig brukerveiledning
Täydellinen omistajan ohjekirja
Полное руководство пользователя
Komplett bruksanvisning
Komplet betjeningsvejledning
正式な所有者用のマニュアル
사용자 설명서 전문
完整的用户手册
完整的擁有者手冊
Panduan pengguna keseluruhan
Pairing mode
Bluetooth connected
Bluetooth streaming
5s
HK OMNI 20+
App
Setup video
Harman Kardon Controller|
Harman Kardon Controller
FPO
FR
•Nom de modèle : HK OMNI 20+
•Transducteurs : 2 x 75 mm graves, 2 x 19 mm aigus
•Puissance nominale : 4 x 15 W
•Réponse en fréquence : 53 Hz ~ 20 kHz -6dB
•Rapport signal sur bruit : > 80 dB
•Connexions d'entrée : Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensions (L x P x H) : 260 mm x 164 mm x 166 mm
•Poids : 2 125 g
•Alimentation : 100−240 V ~ 50/60 Hz
•Plage de fréquences de l'émetteur Bluetooth® : 2 402 − 2 480 MHz
•Puissance de l'émetteur Bluetooth® : 0-4 dBm
•Modulation de l'émetteur Bluetooth® : GFSK π/4 DQPSK 8DPSK
•Plage de fréquences de l'émetteur 2.4G Wi-Fi : 2 412 MHz ~ 2 472 MHz
(bande ISM 2,4 GHz, USA 11 canaux, Europe 13 canaux)
•Puissance de l'émetteur 2.4G Wi-Fi : < 20 dBm (ERIP)
•Modulation 2.4G Wi-Fi : OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•Compatibilité réseau 2.4G Wi-Fi : IEEE 802.11b/g/n
•Puissance de l'émetteur 5G Wi-Fi : < 18.5 dBm
•Modulation 5G Wi-Fi : OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•Compatibilité réseau 5G Wi-Fi : IEEE 802.11ac
•Network standby power<3W
PT
•Nome do modelo: HK OMNI 20+
•Transdutores: 2 woofers de 75 mm e 2 tweeters de 19 mm
•Potência nominal: 4 x 15 W
•Resposta de frequência: 53 Hz~20 kHz -6 dB
•Razão sinal-ruído: >80 dB
•Conexões de entrada: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensões (L x P x A): 260 mm x 164 mm x 166 mm
•Peso: 2.125 g
•Fonte de alimentação: 100−240 V~50/60 Hz
•Intervalo de frequência de transmissão Bluetooth®: 2402 − 2480 MHz
•Potência de transmissão Bluetooth®: 0-4 dBm
•Modulação da transmissão Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Intervalo de frequência do transmissor Wi-Fi 2,4 G: 2412 − 2472 MHz
(banda ISM 2,4 GHz, 11 canais padrão EUA, Europa e outros 13 canais)
•Potência do transmissor Wi-Fi 2,4 G: <20 dBm (EIRP)
•Modulação Wi-Fi 2,4 G: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•Compatibilidade de rede Wi-Fi 2,4 G: IEEE 802.11b/g/n
•Potência do transmissor Wi-Fi 5 G: <18,5 dBm
•Modulação Wi-Fi 5 G: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•Compatibilidade de rede Wi-Fi 5 G: IEEE 802.11ac
•Network standby power<3W
ES
•Nombre del modelo: HK OMNI 20+
•Transductores: 2 woofer x 75 mm, 2 altavoz de agudos x 19 mm
•Potencia de entrada nominal: 4 x 15W
•Intervalo de frecuencias: 53 Hz ~ 20 kHz -6 dB
•Relación señal-ruido: >80 dB
•Conexiones de entrada: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps
Ethernet port
•Dimensiones (Ancho x Alto x Profundidad): 260mm x 164mm x 166mm
•Peso: 2.125g
•Alimentación: 100 − 240 V ~ 50/60 Hz
•Alcance de frecuencia del transmisor Bluetooth®: 2402 − 2480 MHz
•Potencia del transmisor Bluetooth®: 0-4 dBm
•Modulación del transmisor Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Intervalo de frecuencias del transmisor Wi-Fi 2.4G: 2412 − 2472 MHz
(Banda ISM 2,4 GHz, 11 canales en USA, 13 canales en Europa y otros)
•Potencia del transmisor Wi-Fi 2.4G: <20 dBm (EIRP)
•Modulación Wi-Fi 2.4G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•Compatibilidad de red Wi-Fi 2.4G: IEEE 802.11b/g/n
•Potencia del transmisor Wi-Fi 5G: <18.5 dBm
•Modulación Wi-Fi 5G: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•Compatibilidad de red Wi-Fi 5G: IEEE 802.11ac
•Network standby power<3W
IT
•Nome Modello: HK OMNI 20+
•Trasduttori:2x75mmwoofer,2x19mmtweeter
•Potenza nominale: 4 x 15W
•Risposta in frequenza: 53Hz~20kHz -6dB
•Rapporto segnale-rumore: >80dB
•Connessioni in ingresso: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps
Ethernet port
•Dimensioni (L x P x A): 260mm x 164mm x 166mm
•Peso: 2125g
•Alimentazione: 100–240V~50/60Hz
•Gamma di frequenza trasmettitore Bluetooth®: 2402 – 2480MHz
•Potenza trasmettitore Bluetooth®: 0-4dBm
•Modulazione trasmettitore Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Gamma di frequenza trasmettitore Wi-Fi 2.4G: 2412 – 2472MHz
(Banda 2.4GHz ISM, USA 11 Canali, Europa ed altri 13 Canali)
•Potenza trasmettitore Wi-Fi 2.4G: <20dBm (EIRP)
•Modulazione Wi-Fi 2.4G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•Compatibilità network Wi-Fi 2.4G: IEEE 802.11b/g/n
•Potenza trasmettitore Wi-Fi 5G: <18.5dBm
•Modulazione Wi-Fi 5G: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM, 256QAM
•Compatibilità network Wi-Fi 5G: IEEE 802.11ac
•Network standby power<3W
DE
•Modellbezeichnung: HK OMNI 20+
•Signalumwandler: 2 x 75mm Tieftöner, 2 x 19mm Hochtöner
•Nennleistung: 4 x 15W
•Frequenzbereich: 53Hz~20kHz -6dB
•Rauschabstand: >80dB
•Eingangsverbindungen: Bluetooth®, Aux-in, WLAN, 10/100 Mbps
Ethernet port
•Abmessungen (B x T x H): 260mm x 164mm x 166mm
•Gewicht: 2125g
•Energieversorgung: 100–240 V ~50/60 Hz
•Frequenzbereich für die Bluetooth®-Übertragung: 2402 – 2480MHz
•Bluetooth®-Übertragungsleistung: 0-4 dBm
•Bluetooth®-Übertragungsmodulation: GFSK, π/4 DQPSK, 8DPSK
•2.4G WLAN-Übertragungsfrequenzbereich: 2412 − 2472MHz
(2.4GHz ISM-Band, USA 11 Kanäle, Europa und andere Länder 13 Kanäle)
•2.4 G WLAN-Übertragungsleistung: <20dBm (EIRP)
•2.4G WLAN-Modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2.4G WLAN-Netzwerkkompatibilität: IEEE 802.11b/g/n
•5G WLAN-Übertragungsleistung: <18.5dBm
•5G WLAN-Modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
•5G WLAN-Netzwerkkompatibilität: IEEE 802.11ac
•Network standby power<3W
NO
•Modellnavn: HK OMNI 20+
•Signalomformere: 2 x 75 mm woofer, 2 x 19 mm tweeter
•Nominell effekt: 4 x 15 W
•Frekvensrespons: 53 Hz~20 kHz -6 dB
•Signal-til-lyd-ratio: >80 dB
•Innganger: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensjoner (L x B x H): 260mm x 164mm x 166mm
•Vekt: 2,125g
•Strømforsyning: 100–240 V ~ 50/60 Hz
•Frekvensområde for Bluetooth®-sender: 2402 – 2480 MHz
•Strøm for Bluetooth®-sender: 0-4 dBm
•Modulasjon for Bluetooth®-sender: GFSK, π/4 DQPSK, 8DPSK
•2,4G WiFi-frekvensområde for sender: 2412 – 2472 MHz (2,4 GHz
ISM-bånd, USA 11 kanaler, Europa og andre 13 kanaler)
•Strøm for 2,4 G Wi-Fi-sender: <20 dBm (EIRP)
•2,4 G Wi-Fi-modulasjon: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•2,4 G Wi-Fi-nettverkskompatibilitet: IEEE 802.11 b/g/n
•Strøm for 5 G Wi-Fi-sender: <18.5 dBm
•5GWi-F
i-modulasjon: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
•5 G Wi-Fi-nettverkskompatibilitet: IEEE 802.11 ac
•Network standby power<3W
NL
•Modelnaam: HK OMNI 20+
•Transducers: 2 x 75mm woofer, 2 x 19mm tweeter
•Nominaal vermogen: 4 x 15W
•Frequentiebereik: 53Hz~20kHz -6dB
•Signaal-ruis-verhouding: >80dB
•Ingangen: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Afmetingen (B x D x H): 260mm x 164mm x 166mm
•Gewicht: 2.125g
•Voeding: 100–240V~50/60Hz
•Bluetooth® zendfrequentiebereik: 2402 – 2480MHz
•Bluetooth® zendvermogen: 0-4dBm
•Bluetooth® zendermodulatie: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi zendfrequentiebereik: 2412 – 2472MHz (2.4GHz ISM Band,
USA 11 kanalen, Europa en andere 13 kanalen)
•2.4G Wi-Fi zendvermogen: <20dBm (EIRP)
•2.4G Wi-Fi modulatie: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2.4G Wi-Fi netwerk compatibiliteit: IEEE 802.11b/g/n
•5G Wi-Fi zendvermogen: <18.5dBm
•5G Wi-Fi modulatie: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
•5G Wi-Fi netwerk compatibiliteit: IEEE 802.11ac
•Network standby power<3W
RU
•Название модели: HK OMNI 20+
•Преобразователи: 2 низкочастотных динамика 75 мм,
2 высокочастотных динамика 19 мм
•Номинальная мощность: 4 x 15 Вт
•Частотная характеристика: 53 Гц ~ 20 КГц -6 дБ
•Отношение "сигнал-шум": >80 дБ
•Входные соединения: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Габариты(ДxШxВ):260ммx164ммx166мм
•Вес: 2125 г
•Источник питания: 100–240 В ~50/60 Гц
•Частотный диапазон передатчика Bluetooth®: 2402 – 2480 МГц
•Мощность передатчика Bluetooth®: макс. 0-4 дБ/мВт
•Модуляция передатчика Bluetooth®: гаусс. част. модул., π/4 относ.
квадрат. фаз. модул., относ. восьмер. фаз. модул.
•Частотный диапазон передатчика 2.4G Wi-Fi: 2412 – 2472 МГц
(2,4 ГГц диапазона ISM, США 11 каналов, Европа и другие страны
13 каналов)
•Мощность передатчика 2.4G Wi-Fi: <20 дБ/мВт (ERIP)
•Модуляция 2.4G Wi-Fi: OFDM, DSSS, DBPSK,DQPSK,CCK,16QAM,64QAM
•Сетевой стандарт 2.4G Wi-Fi: IEEE 802.11b/g/n
•Мощность передатчика 5G Wi-Fi: <18.5 дБ/мВт
•Модуляция 5G Wi-Fi: OFDM, DSSS, DBPSK,DQPSK,CCK,16QAM,
64QAM, 256QAM
•Сетевой стандарт 5G Wi-Fi: IEEE 802.11ac
•Network standby power<3W
FI
•Mallin nimi: HK OMNI 20+
•Muuntimet: 2 x 75 mm:n alibassokaiutin, 2 x 19 mm:n diskanttikaiutin
•Nimellisottoteho: 4 x 15 W
•Taajuusvaste: 53 Hz~20 kHz -6 dB
•Signaali-kohina-suhde: >80 dB
•Tuloliitännät: Bluetooth®, Aux-tulo, Wi-Fi, 10/100 Mbps Ethernet port
•Mitat(LxKxH):260mmx164mmx166mm
•Paino: 2 125g
•Virransyöttö: 100–240 V ~ 50/60 Hz
•Bluetooth®-lähettimen taajuusalue: 2402 – 2480 MHz
•Bluetooth®-lähettimen teho: 0-4 dBm
•Bluetooth®-lähettimen modulaatio: GFSK, π/4 DQPSK, 8 DPSK
•2,4 G Wi-Fi-lähettimen taajuusalue: 2412 – 2472 MHz
(2,4 GHz ISM-kaista, Yhdysvallat 11 kanavaa, Eurooppa ja muut
13 kanavaa)
•2,4 G Wi-Fi-lähettimen teho: < 20 dBm (EIRP)
•2,4 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•2,4 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11b/g/n
•5 G Wi-Fi-lähettimen teho: < 18.5 dBm
•5 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•5 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11ac
•Network standby power<3W
DA
•Modelnavn: HK OMNI 20+
•Transducere: 2 x 75 mm woofer, 2 x 19 mm tweeter
•Nominel effekt: 4 x 15 W
•Frekvensområde: 53 ~ 20 kHz -6 dB
•Signal til støj-forhold: >80 dB
•Indgangstilslutninger: Bluetooth®, Aux-indgang, Wi-Fi, 10/100 Mbps
Ethernet port
•Mål (B x D x H): 260mm x 164mm x 166mm
•Vægt: 2.125 g
•Strømforsyning: 100–240 V ~ 50/60 Hz
•Frekvensområde for Bluetooth®-sender: 2402 – 2480 MHz
•Bluetooth®-sendereffekt: 0-4 dBm
•Bluetooth®-sendemodulation: GFSK, π/4 DQPSK, 8DPSK
•Frekvensområde for 2,4 G Wi-Fi-sender: 2.412 – 2.472 MHz
(2,4 GHz ISM-bånd, USA:11 kanaler, Europa og andre lande: 13 kanaler)
•2,4 G Wi-Fi-sendereffekt: <20 dBm (EIRP)
•2,4 G Wi-Fi-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2,4 G Wi-Fi-netværkskompatibilitet: IEEE 802.11b/g/n
•5 G Wi-Fi-sendereffekt: <18,5 dBm
•5 G Wi-Fi-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
•5 G Wi-Fi-netværkskompatibilitet: IEEE 802.11ac
•Network standby power<3W
SV
•Modellnamn: HK OMNI 20+
•Högtalarelement: 2 x 75 mm woofer, 2 x 19 mm diskant
•Klassad effekt: 4 x 15 W
•Frekvensomfång: 53 Hz~20 kHz -6 dB
•Signal-brus-förhållande: >80 dB
•Ingångar: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensioner (B x D x H): 260 x 164 x 166 mm
•Vikt: 2 125 g
•Strömförsörjning: 100–240 V~50/60 Hz
•Bluetooth®-sändarens frekvensomfång: 2 402–2 480 GHz
•Bluetooth®-sändarens effekt: 0-4 dBm
•Bluetooth®-sändarens modulering: GFSK, π/4 DQPSK, 8DPSK
•2,4 G Wi-Fi-sändarens frekvensomfång: 2 412 MHz~2 472 MHz
(2,4 GHz ISM-band, USA 11-kanaler, Europa 13-kanaler)
•2,4 G Wi-Fi-sändarens effekt: < 20 dBm (ERIP)
•2,4 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2,4 G Wi-Fi nätverkskompatibilitet: IEEE 802.11b/g/n
•5 G Wi-Fi-sändarens effekt: < 18.5 dBm
•5 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM, 256QAM
•5 G Wi-Fi nätverkskompatibilitet: IEEE 802.11ac
•Network standby power<3W
KO
•모델명: HK OMNI 20+
•변환기: 2 x 75mm 우퍼, 2 x 19mm 트위터
•정격 전력:4x15W
•주파수 응답: 53Hz~20kHz -6dB
•신호 대 잡음비:>80dB
•입력 연결:블루투스®, 보조 입력,Wi-Fi、10/100 Mbps Ethernet port
•치수(너비 x 깊이 x 높이): 260mm x 164mm x 166mm
•중량: 2125g
•전원 공급 장치: 100~240V 50/60Hz
•블루투스®송신기 주파수 범위: 2402 ~ 2480MHz
•블루투스®송신기 출력: 0-4dBm
•블루투스®송신기 변조: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi 송신기 주파수 범위: 2412 ~ 2472MHz (2.4GHz ISM 밴드,
미국 11 채널,유럽 및 기타 지역 13 채널)
•2.4G Wi-Fi 송신기 출력: <20dBm(EIRP)
•2.4G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•2.4G Wi-Fi 네트워크 호환성: IEEE 802.11b/g/n
•5G Wi-Fi 송신기 출력: <18.5dBm
•5G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM,
256QAM
•5G Wi-Fi 네트워크 호환성: IEEE 802.11ac
•Network standby power<3W
JP
•モデル名：HK OMNI 20+
•トランスデューサ ー：ウーファー 2x75mm、ツイーター 2x19mm
•定格出力：4x 15W
•周波数特性：53Hz～20kHz -6dB
•S/N比：80dB以下
•入力接続：Bluetooth®、Aux 端子、Wi-Fi、10/100 Mbps Ethernet port
•寸法（幅x奥行x高さ）：260mm x164mm x166mm
•重量：2125g
•電源：100–240V~50/60Hz
•Bluetooth® 対応トランスミッター周波数帯域：2402∼2480MHz
•Bluetooth® 対応トランスミッター出力：0-4dBm以上
•Bluetooth® 対応トランスミッター変 調：GFSK、π/4 DQPSK、8DPSK
•2.4G WiFiトランスミッター周波数帯域：2412∼2472MHz
(2.4GHz ISMバンド、USA 11チャンネ ル、Europeとその他の地域
13チャンネル )
•2.4G WiFiトランスミッター出力：20dBm(EIRP)以上
•2.4G WiFi変調：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、64QAM
•2.4G WiFiネットワークへの互換性：IEEE 802.11b/g/n
•5G WiFiトランスミッター出力：18.5dBm以上
•5G WiFi変調：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、
64QAM, 256QAM
•5G WiFiネットワークへの互換性：IEEE 802.11ac
•Network standby power<3W
CHT
•型號名稱：HK OMNI 20+
•轉換器：2x75mm低音喇叭，2x19mm高音喇叭
•額定功率：4x15W
•頻率回應：53Hz~20kHz -6dB
•雜訊比：>80dB
•輸入連接：Bluetooth®、Aux 輸入、Wi-Fi, 10/100 Mbps Ethernet port
•尺寸（寬 x 深 x 高）： 260mm x 164mm x 166mm
•重量：2125 克
•電源：100–240V~50/60Hz
•Bluetooth® 發射機頻率範圍：2402 – 2480MHz
•Bluetooth® 發射機功率：0-4dBm
•Bluetooth® 發射機調變：GFSK、π/4 DQPSK、8DPSK
•2.4G Wi-Fi 發射機頻率範圍：2412 – 2472MHz（2.4GHz ISM 頻帶、美國
11個頻道、歐洲和其他 13 個頻道）
•2.4G Wi-Fi 發射機功率：<20dBm (EIRP)
•2.4G Wi-Fi 調變：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、64QAM
•2.4G Wi-Fi 網路相容性：IEEE 802.11b/g/n
•5G Wi-Fi 發射機功率：<18.5dBm
•5G Wi-Fi 調變：OFDM、DSSS、DBPSK、DQPSK、CCK、
16QAM、64QAM、256QAM
•5G Wi-Fi 網路相容性：IEEE 802.11ac
•Network standby power<3W
CHS
•型号名称：HK OMNI 20+
•换能器：2个75mm 低音扬声器，2个19mm 高音扬声器
•额定功率：4个，每个 15W
•频率响应：53Hz~20kHz -6dB
•信噪比：>80dB
•输入连接：Bluetooth®、辅助输入、Wi-Fi, 10/100 Mbps Ethernet port
•尺寸（宽 x 长 x 高)：260mm x 164mm x 166mm
•重量：2125g
•电源：100–240V~50/60Hz
•Bluetooth® 发射器频率范围：2402 – 2480MHz
•Bluetooth® 发射器功率：0-4dBm
•Bluetooth® 发射器调制：GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi 发射器频率范围：2412 – 2472MHz（2.4GHz ISM 频带，
美国 11 个频道，欧洲和其他国家/地区 13 个频道）
•2.4G Wi-Fi 发射器功率：<20dBm (EIRP)
•2.4G Wi-Fi 调制：OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•2.4G Wi-Fi 网络兼容性：IEEE 802.11b/g/n
•5G Wi-Fi 发射器功率：<18.5dBm
•5G Wi-Fi 调制：OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•5G Wi-Fi 网络兼容性：IEEE 802.11ac
•Network standby power<3W
ID
•Nama Model: HK OMNI 20+
•Transduser:2x75mmwoofer,2x19mmtweeter
•Nilai daya: 4 x 15W
•Respons frekuensi: 53Hz~20kHz -6dB
•Rasio sinyal-ke-bunyi: >80dB
•Input koneksi: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensi (W x D x H): 260mm x 164mm x 166mm
•Berat: 2125g
•Catu daya: 100–240V~50/60Hz
•Rentang frekuensi pemancar Bluetooth®: 2402 – 2480MHz
•Daya pemancar Bluetooth®: 0-4dBm
•Modulasi pemancar Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Rentang frekuensi pemancar 2.4G Wi-Fi: 2412 – 2472MHz
(2.4GHz ISM Band, USA 11 Kanal, Eropa dan 13 Kanal lain)
•Daya pemancar 2.4G Wi-Fi: <20dBm (EIRP)
•Modulasi 2.4G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•Kompatibilitas jaringan 2.4G Wi-Fi: IEEE 802.11b/g/n
•Daya pemancar 5G Wi-Fi: <18.5dBm
•Modulasi 5G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM,
64QAM, 256QAM
•Kompatibilitas jaringan 5G Wi-Fi: IEEE 802.11ac
•Network standby power<3W
EN
•Model Name: HK OMNI 20+
•Transducers: 2 x 75mm woofer, 2 x 19mm tweeter
•Ratedpower:4x15W
•Frequency response: 53Hz~20kHz -6dB
•Signal-to-noise ratio: >80dB
•Input connections: Bluetooth®, Aux-in, Wi-Fi, 10/100 Mbps Ethernet port
•Dimensions (W x D x H): 260mm x 164mm x 166mm
•Weight: 2125g
•Power supply: 100−240V~50/60Hz
•Bluetooth® transmitter frequency range: 2402 − 2480MHz
•Bluetooth® transmitter power: 0-4dBm
•Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz
(2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
•2.4G Wi-Fi transmitter power: <20dBm (EIRP)
•2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•2.4G Wi-Fi network compatibility: IEEE 802.11b/g/n
•5G Wi-Fi transmitter power: <18.5dBm
•5G Wi-Fi modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,
64QAM, 256QAM
•5G Wi-Fi network compatibility: IEEE 802.11ac
•Network standby power<3W
TR01525_A
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
This Mark Certifies that this product is compliant with the BLACKFIRE ALLIANCE Standard.
Please refer to WWW.BLACKFIREALLIANCE.COM for more information.
BLACKFIRE RESEARCH™ is a Registered Trademark (No. 3,898,359) of BLACKFIRE RESEARCH CORP.
All rights reserved.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.
“Made for iPod,”“Made for iPhone,” and“Made for iPad”mean that an electronic accessory has been designed to connect specifically to iPod, iPhone,
or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect
wireless performance.
AirPlay, iPad, iPhone, iPod, iPod classic, iPod nano, iPod touch, and Retina are trademarks of Apple Inc., registered in the U.S. and other countries. iPad
Air, iPad mini, and Lightning are trademarks of Apple Inc. In Japan,The trademark “iPhone” is used with a license from Aiphone K.K
IC Caution:
User should also be advised that:
(i) the device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250 - 5350 MHz and 5470 - 5725 MHz shall comply with the e.i.r.p. limit: and
(iii) the maximum antenna gain permitted for devices in the band 5725 - 5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as
appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that these radars could cause
interference and/or damage to LE-LAN devices.
Les utilisateurs devraient aussi être avisés que
(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à
point, selon le cas.De plus, les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et
que ces radars pourrai ent causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
º Reorient or relocate the receiving antenna.
º Increase the separation between the equipment and receiver.
º Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
º Consult the dealer or an experienced radio/TV technician for help.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
“FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons.”
Use Restriction Attention In France, operation is limited to indoor use within the band 5150-5350 MHz.
해당무선설비는전파혼신가능성이있으므로인명안전과관련된서비스는할수없음
0560
Торговая марка : harman/kardon
Назначение товара : АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
Изготовитель : ХАРМАН ИНТЕРНЕШНЛ ИНДАСТРИЗ ИНКОРПОРЕЙТЕД, США, 06901 КОННЕКТИКУТ,
г.СТЭМФОРД, АТЛАНТИК СТРИТ 400, ОФИС 1500
Страна происхождения : Китай
Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12, КОРПУС 1
Гарантийный период : 1 год
Информация о
сервисных центрах : www.harman.com/ru тел. +7-800-700-0467
Срок службы : 5 лет
Срок хранения : не ограничен
Условия хранения : Cтандартные при нормальных значениях климатических факторов внешней среды
Номер документа
соответствия : Товар сертифицирован
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы
символов серийного номера изделия, следующих после разделительного знака «-». Кодировка
соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000,
где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства
(A - 2010, B - 2011, C - 2012 и т.д.).
FPO
FPO
FPO
FPO
FPO
FPOFPO
FPO FPO
FPO
FPO
FPO
FPO FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO FPO
LTHCyan LTHMagenta LTHYellow LTHBlack
TR & Job No:
Job Description:
Date:
Other:
Developed by
RESTRICTED
DESIGN ADAPTATION / IMAGE / FINAL ART
IMPORTANT NOTE : THE PRINT/PDF IS FOR LAYOUT AND TEXT ILLUSTRATION ONLY. THE COLOURS INDICATED HERE MAY NOT APPEAR SAME IN THE FINAL PROOF. ALTHOUGH
EVERY EFFORT HAS BEEN MADE TO CHECK THE CORRECTION OF LAYOUT AND TEXT. IT IS CLIENT RESPONSIBILITY TO VERIFY BEFORE GIVING THE FINAL APPROVAL.
TR01525_HK_Omni_20+_QSG_A
Version : 8
TR01525
2016-02-23
GP01/MNR2/MNR3/MNR4/MNR5/EDI6/EDI07/GP08
N/A
EQUITY COLORS:
REPRESENTATION:
The device meets the exemption from the routine
evaluation limits in section 2.5 of RSS 102 and compliance
with RSS-102 RF exposure, users can obtain Canadian
information on RF exposure and compliance.
Le dispositif rencontre l'exemption des limites courantes
d'évaluation dans la section 2.5 de RSS 102 et la
conformité à l'exposition de RSS-102 rf, utilisateurs peut
obtenir l'information canadienne sur l'exposition et la
conformité de rf.
This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter. This
equipment should be installed and operated with a
minimum distance of 20 centimeters between the radiator
and your body.
Cet émetteur ne doit pas être Co-placé ou ne fonctionnant
en même temps qu'aucune autre antenne ou émetteur.
Cet équipement devrait être installé et actionné avec une
distance minimum de 20 centimètres entre le radiateur et
votre corps.
This device complies with FCC radiation exposure limits set
forth for an uncontrolled environment and it also complies with
Part 15 of the FCC RF Rules. This equipment must be installed
and operated in accordance with provided instructions and the
antenna(s) used for this transmitter must be installed to provide
a separation distance of at least20 cmfrom all persons and must
not be co-located or operating in conjunction with any other
antenna or transmitter. End-users and installers must be
provide with antenna installation instructions and consider
removing the no-collocation statement.
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
Caution!
A
ny changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority
to operate the equipment.
For Wi-Fi 5G device
FCC Caution:
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to
5.85 GHz bands. These radar stations can cause interference with and/or damage this
device. No configuration controls are provided for this wireless equipment allowing any
change in the frequency of operations outside the FCC grant of authorization for US
operation according to Part 15.407 of the FCC rules.
IC Caution:
User should also be advised that:
(i) The device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce
the potential for harmful interference to co-channel mobile satellite systems; (ii) the
maximum antenna gain permitted for devices in the bands 5250 - 5350 MHz and
5470 - 5725 MHz shall comply with the e.i.r.p. limit: and
(iii) The maximum antenna gain permitted for devices in the band 5725 - 5825 MHz
shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point
operation as appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary users
(i.e. priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that these
radars could cause interference and/or damage to LE-LAN devices.
Exposure of humans to RF fields (RSS-102)
The computers employ low gain integral antennas that do not emit RF field in excess of
Health Canada limits for the general population; consult Safety Code 6, obtainable from
Health Canada’s Web site at http://www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless adapters conforms to
the IC limit of the RF exposure requirement regarding IC RSS-102, Issue 5 clause 4. SAR
tests are conducted using recommended operating positions accepted by the FCC/ RSS
with the device transmitting at its highest certified power level in all tested frequency
band without distance attaching away from the body. Non-compliance with the above
restrictions may result in violation of FCC RF exposure guidelines.
Use Restriction Attention in France, operation is limited to indoor use within the band
5150-5350 MHz.
EN 50332-1:2013
EN 50332-2:2013
This device complies with Industry Canada's licence-exempt
RSSs. Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage;
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
the device for operation in the band 5150-5250 MHz is
only for indoor use to reduce the potential for harmful
interference to co-channel mobile satellite systems
les dispositifs fonctionnant dans la bande 5150-5250
MHz sont réservés uniquement pour une utilisation à
l'intérieur afin de réduire les risques de brouillage
préjudiciable aux systèmes de satellites mobiles
utilisant les mêmes canaux;
14/02/2014
2013/56/EU
1/07/2015
2013/56/EU
2014/30/EU 2012/27/EU
2012/27/EU
2014/53/EU
2014/35/EU

Navigation menu
