User Manual
57.791
Quick Start Guide
Guide de demarrage rapide
Buttons
Connections
App
Battery Power
Connect with power cable
What’s in the box
x1
RESETWPS
harmankardon.com/Omni50+
Full owner's manual
Mode d'emploi complet
Manual del propietario
Manual do usuário completo
Bedienungsanleitung
Manuale di istruzioni completo
Volledige handleiding
Fullstendig brukerveiledning
Täydellinen omistajan ohjekirja
Полное руководство пользователя
Komplett bruksanvisning
Komplet betjeningsvejledning
正式な所有者用のマニュアル
사용자 설명서 전문
完整的用户手册
完整的擁有者手冊
Panduan pengguna keseluruhan
Download the Harman Kardon Controller app to setup
and control your Harman Kardon OMNI 50+.
Téléchargez l'application Harman Kardon Controller pour
configurer et commander votre Harman Kardon OMNI 50+.
Descargue la aplicación Harman Kardon Controller para
configurar y controlar su Harman Kardon OMNI 50+.
Baixe o app de controle da Harman Kardon para configurar e
controlar o Harman Kardon OMNI 50+.
Laden Sie die Harman Kardon Controller-App herunter, um Ihren
Harman Kardon OMNI 50+ konfigurieren und bedienen zu können.
Scarica l’app Harman Kardon Controller per impostare e
controllare il tuo Harman Kardon OMNI 50+.
Download de Harman Kardon Controller app om uw
Harman Kardon Omni 2.0 te installeren en te bedienen.
Last ned Harman Kardon Kontroll-appen for å sette opp og
kontrollere Harman Kardon OMNI 50+.
Lataa Harman Kardon Controller-sovellus, jotta voit määrittää
Harman Kardon OMNI 50+ -laitteen asetukset ja hallita sitä.
Загрузите приложение Harman Kardon Controller, чтобы настроить
свой продукт Harman Kardon OMNI 50+ и управлять им.
Hämta appen Harman Kardon Controller för att ställa in och styra
din Harman Kardon OMNI 50+.
Hent applikationen Harman Kardon Controller, så du kan
konfigurere og styre din Harman Kardon OMNI 50+.
Harman Kardon Controller
(ハーマンカードン・コントローラー)アプ
リをダウンロードしてセットアップし、お持ちの
Harman Kardon
OMNI 50+
(ハーマンカードン・オムニ
20
）をコントロールしてくだ
Harman Kardon Controller
앱을 다운로드하여
Harman Kardon OMNI
50+
을 설정하고 제어합니다.
下载
Harman Kardon Controller 应用以设置和控制您的 Harman
Kardon
OMNI 50+。
下載
Harman Kardon Controller
應用程式以設定並控制的
Harman
Kardon
OMNI 50+。
Unduh aplikasi Harman Kardon Controller untuk persiapan dan
mengontrol Harman Kardon OMNI 50+ Anda.
SOURCE PLAY/PAUSE POWER
ON/OFF
VOLUME - VOLUME +LINK
AUDIO IN POWER USB
Status
Charging
Full power
LED
Not connect with power cable
Status
Battery level
Power is less than 20%
Power is less than 10%
LED
Wi-Fi streaming via Harman Kardon Controller app
SONGSALBUMS ARTISTS PLA
Song name
Artist name
Basement
Study
Guest Bedroom
GardenLiving room
Drag to the room you want to play
1s
Wi-Fi streaming
Wi-Fi connected
Auto standby (10 minutes)
Multi-room music streaming
Local Source
Bluetooth®
x1
x1
Setup video
Harman Kardon Controller|
Harman Kardon Controller
Bluetooth AUX-In
Bluetooth
AUX-in
>3s
HK OMNI 50+
Pairing mode
Bluetooth connected
Bluetooth streaming
5s
Party Mode
>3s
OMNI 50+
FPO
FR
•Nom de modèle : HK OMNI 50+
•Transducteurs : 2 x 89 mm graves, 2 x 20 mm aigus
•Puissance nominale : 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Réponse en fréquence : 53 Hz ~ 20 kHz (-6dB)
•Rapport signal sur bruit : > 80 dB
•Connexions d'entrée : Bluetooth®, Aux-in, Wi-Fi
•Dimensions (L x P x H) : 333 mm x 175 mm x 214 mm
•Poids : 3337 g
•Alimentation : 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Plage de fréquences de l'émetteur Bluetooth® : 2 402 − 2 480 MHz
•Puissance de l'émetteur Bluetooth® : 0-4dBm
•Modulation de l'émetteur Bluetooth® : GFSK π/4 DQPSK 8DPSK
•Plage de fréquences de l'émetteur 2.4G Wi-Fi : 2 412 MHz ~ 2 472 MHz
(bande ISM 2,4 GHz, USA 11 canaux, Europe 13 canaux)
•Puissance de l'émetteur 2.4G Wi-Fi : < 20 dBm (ERIP)
•Modulation 2.4G Wi-Fi : OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•Compatibilité réseau 2.4G Wi-Fi : IEEE 802.11b/g/n
•Puissance de l'émetteur 5G Wi-Fi : <18.5dBm
•Modulation 5G Wi-Fi : OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•Compatibilité réseau 5G Wi-Fi : IEEE 802.11ac
•Network standby power<3W
PT
•Nome do modelo: HK OMNI 50+
•Transdutores: 2 woofers de 89 mm e 2 tweeters de 20 mm
•Potência nominal: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Resposta de frequência: 53 Hz~20 kHz (-6 dB)
•Razão sinal-ruído: >80 dB
•Conexões de entrada: Bluetooth®, Aux-in,Wi-Fi
•Dimensões (L x P x A): 333 mm x 175 mm x 214 mm
•Peso: 3337 g
•Fonte de alimentação: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Intervalo de frequência de transmissão Bluetooth®: 2402 − 2480 MHz
•Potência de transmissão Bluetooth®: 0-4 dBm
•Modulação da transmissão Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Intervalo de frequência do transmissor Wi-Fi 2,4 G: 2412 − 2472 MHz
(banda ISM 2,4 GHz, 11 canais padrão EUA, Europa e outros 13 canais)
•Potência do transmissor Wi-Fi 2,4 G: <20 dBm (EIRP)
•Modulação Wi-Fi 2,4 G: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•Compatibilidade de rede Wi-Fi 2,4 G: IEEE 802.11b/g/n
•Potência do transmissor Wi-Fi 5 G: <18.5dBm
•Modulação Wi-Fi 5 G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM,64QAM,256QAM
•Compatibilidade de rede Wi-Fi 5 G: IEEE 802.11ac
•Network standby power<3W
ES
•Nombre del modelo: HK OMNI 50+
•Transductores: 2 woofer x 89 mm, 2 altavoz de agudos x 20 mm
•Potencia de entrada nominal: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Intervalo de frecuencias: 53 Hz ~ 20 kHz (-6 dB)
•Relación señal-ruido: >80 dB
•Conexiones de entrada: Bluetooth®, Aux-in, Wi-Fi
•Dimensiones (Ancho x Alto x Profundidad): 333mm x 175mm x 214mm
•Peso: 3337g
•Alimentación: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Alcance de frecuencia del transmisor Bluetooth®: 2402 − 2480 MHz
•Potencia del transmisor Bluetooth®: 0-4 dBm
•Modulación del transmisor Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Intervalo de frecuencias del transmisor Wi-Fi 2.4G: 2412 − 2472 MHz
(Banda ISM 2,4 GHz, 11 canales en USA, 13 canales en Europa y otros)
•Potencia del transmisor Wi-Fi 2.4G: <20 dBm (EIRP)
•Modulación Wi-Fi 2.4G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•Compatibilidad de red Wi-Fi 2.4G: IEEE 802.11b/g/n
•Potencia del transmisor Wi-Fi 5G: <18.5dBm
•Modulación Wi-Fi 5G: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM,64QAM,256QAM
•Compatibilidad de red Wi-Fi 5G: IEEE 802.11ac
•Network standby power<3W
IT
•Nome Modello: HK OMNI 50+
•Trasduttori: 2 x 89mm woofer, 2 x 20mm tweeter
•Potenza nominale: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Risposta in frequenza: 53Hz~20kHz (-6dB)
•Rapporto segnale-rumore: >80dB
•Connessioni in ingresso: Bluetooth®, Aux-in, Wi-Fi
•Dimensioni (L x P x A): 333mm x 175mm x 214mm
•Peso: 3337g
•Alimentazione: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Gamma di frequenza trasmettitore Bluetooth®: 2402 – 2480MHz
•Potenza trasmettitore Bluetooth®: 0-4dBm
•Modulazione trasmettitore Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Gamma di frequenza trasmettitore Wi-Fi 2.4G: 2412 – 2472MHz
(Banda 2.4GHz ISM, USA 11 Canali, Europa ed altri 13 Canali)
•Potenza trasmettitore Wi-Fi 2.4G: <20dBm (EIRP)
•Modulazione Wi-Fi 2.4G: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•Compatibilità network Wi-Fi 2.4G: IEEE 802.11b/g/n
•Potenza trasmettitore Wi-Fi 5G: <18.5dBm
•Modulazione Wi-Fi 5G: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•Compatibilità network Wi-Fi 5G: IEEE 802.11ac
•Network standby power<3W
DE
•Modellbezeichnung: HK OMNI 50+
•Signalumwandler: 2 x 89mm Tieftöner, 2 x 20mm Hochtöner
•Nennleistung:4x25W(DCmode)4x15W(Batterymode)
•Frequenzbereich: 53Hz~20kHz (-6dB)
•Rauschabstand: >80dB
•Eingangsverbindungen: Bluetooth®, Aux-in, WLAN
•Abmessungen (B x T x H): 333mm x 175mm x 214mm
•Gewicht: 3337g
•Energieversorgung: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Frequenzbereich für die Bluetooth®-Übertragung: 2402 – 2480MHz
•Bluetooth®-Übertragungsleistung: 0-4dBm
•Bluetooth®-Übertragungsmodulation: GFSK, π/4 DQPSK, 8DPSK
•2.4G WLAN-Übertragungsfrequenzbereich: 2412 − 2472MHz
(2.4GHz ISM-Band, USA 11 Kanäle, Europa und andere Länder 13 Kanäle)
•2.4G WLAN-Übertragungsleistung: <20dBm (EIRP)
•2.4G WLAN-Modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2.4G WLAN-Netzwerkkompatibilität: IEEE 802.11b/g/n
•5G WLAN-Übertragungsleistung: <18.5dBm
•5G WLAN-Modulation: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•5G WLAN-Netzwerkkompatibilität: IEEE 802.11ac
•Network standby power<3W
NO
•Modellnavn: HK OMNI 50+
•Signalomformere: 2 x 89 mm woofer, 2 x 20 mm tweeter
•Nominell effekt: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Frekvensrespons: 53 Hz~20 kHz (-6 dB)
•Signal-til-lyd-ratio: >80 dB
•Innganger: Bluetooth®, Aux-in, Wi-Fi
•Dimensjoner (L x B x H): 333mm x 175mm x 214mm
•Vekt: 3337g
•Strømforsyning: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Frekvensområde for Bluetooth®-sender: 2402 – 2480 MHz
•Strøm for Bluetooth®-sender: 0-4dBm
•Modulasjon for Bluetooth®-sender: GFSK, π/4 DQPSK, 8DPSK
•2,4G WiFi-frekvensområde for sender: 2412 – 2472 MHz (2,4 GHz
ISM-bånd, USA 11 kanaler, Europa og andre 13 kanaler)
•Strøm for 2,4 G Wi-Fi-sender: <20 dBm (EIRP)
•2,4 G Wi-Fi-modulasjon: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•2,4 G Wi-Fi-nettverkskompatibilitet: IEEE 802.11 b/g/n
•Strøm for5G Wi-Fi-sender: <18.5dBm
•5G Wi-Fi-modulasjon: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•5G Wi-Fi-nettverkskompatibilitet: IEEE 802.11ac
•Network standby power<3W
NL
•Modelnaam: HK OMNI 50+
•Transducers: 2 x 89mm woofer, 2 x 20mm tweeter
•Nominaal vermogen: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Frequentiebereik: 53Hz~20kHz (-6dB)
•Signaal-ruis-verhouding: >80dB
•Ingangen: Bluetooth®, Aux-in, Wi-Fi
•Afmetingen (B x D x H): 333mm x 175mm x 214mm
•Gewicht: 3337g
•Voeding: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth® zendfrequentiebereik: 2402 – 2480MHz
•Bluetooth® zendvermogen: 0-4dBm
•Bluetooth® zendermodulatie: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi zendfrequentiebereik: 2412 – 2472MHz (2.4GHz ISM Band,
USA 11 kanalen, Europa en andere 13 kanalen)
•2.4G Wi-Fi zendvermogen: <20dBm (EIRP)
•2.4G Wi-Fi modulatie: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•2.4G Wi-Fi netwerk compatibiliteit: IEEE 802.11b/g/n
•5G Wi-Fi zendvermogen: <18.5dBm
•5G Wi-Fi modulatie: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•5G Wi-Fi netwerk compatibiliteit: IEEE 802.11ac
•Network standby power<3W
RU
•Название модели: HK OMNI 50+
•Преобразователи: 2 низкочастотных динамика 89 мм,
2 высокочастотных динамика 20 мм
•Номинальная мощность: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Частотная характеристика: 53 Гц ~ 20 КГц (-6 дБ)
•Отношение "сигнал-шум": >80 дБ
•Входные соединения: Bluetooth®, Aux-in, Wi-Fi
•Габариты(ДxШxВ):333ммx175ммx214мм
•Вес: 3337 г
•Источник питания: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Частотный диапазон передатчика Bluetooth®: 2402 – 2480 МГц
•Мощность передатчика Bluetooth®: макс. 0-4 дБ/мВт
•Модуляция передатчика Bluetooth®: гаусс. част. модул., π/4 относ.
квадрат. фаз. модул., относ. восьмер. фаз. модул.
•Частотный диапазон передатчика 2.4G Wi-Fi: 2412 - 2472 МГц (2,4 ГГц
диапазона ISM, США 11 каналов, Европа и другие страны 13 каналов)
•Мощность передатчика 2.4G Wi-Fi: <20 дБ/мВт (ERIP)
•Модуляция 2.4G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•Сетевой стандарт 2.4G Wi-Fi: IEEE 802.11b/g/n
•5 G Wi-Fi-lähettimen teho: <18.5dBm
•5 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•5 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11ac
•Network standby power<3W
FI
•Mallin nimi: HK OMNI 50+
•Muuntimet: 2 x 89 mm:n alibassokaiutin, 2 x 20 mm:n diskanttikaiutin
•Nimellisottoteho: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Taajuusvaste: 53 Hz~20 kHz (-6 dB)
•Signaali-kohina-suhde: >80 dB
•Tuloliitännät: Bluetooth®, Aux-tulo, Wi-Fi
•Mitat(LxKxH):333mmx175mmx214mm
•Paino: 3337g
•Virransyöttö: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth®-lähettimen taajuusalue: 2402 – 2480 MHz
•Bluetooth®-lähettimen teho: 0-4dBm
•Bluetooth®-lähettimen modulaatio: GFSK, π/4 DQPSK, 8 DPSK
•2,4 G Wi-Fi-lähettimen taajuusalue: 2412 – 2472 MHz
(2,4 GHz ISM-kaista, Yhdysvallat 11 kanavaa, Eurooppa ja muut
13 kanavaa)
•2,4 G Wi-Fi-lähettimen teho: < 20 dBm (EIRP)
•2,4 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2,4 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11b/g/n
•5 G Wi-Fi-lähettimen teho: <18.5dBm
•5 G Wi-Fi-modulaatio: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM,64QAM,256QAM
•5 G Wi-Fi-verkon yhteensopivuus: IEEE 802.11ac
•Network standby power<3W
DA
•Modelnavn: HK OMNI 50+
•Transducere: 2 x 89 mm woofer, 2 x 20 mm tweeter
•Nominel effekt: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Frekvensområde: 52 ~ 20 kHz (-6 dB)
•Signal til støj-forhold: >80 dB
•Indgangstilslutninger: Bluetooth®, Aux-indgang, Wi-Fi
•Mål (B x D x H): 333mm x 175mm x 214mm
•Vægt: 3337 g
•Strømforsyning: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Frekvensområde for Bluetooth®-sender: 2402 – 2480 MHz
•Bluetooth®-sendereffekt: 0-4 dBm
•Bluetooth®-sendemodulation: GFSK, π/4 DQPSK, 8DPSK
•Frekvensområde for 2,4 G Wi-Fi-sender: 2.412 – 2.472 MHz
(2,4 GHz ISM-bånd, USA:11 kanaler, Europa og andre lande: 13 kanaler)
•2,4 G Wi-Fi-sendereffekt: <20 dBm (EIRP)
•2,4 G Wi-Fi-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2,4 G Wi-Fi-netværkskompatibilitet: IEEE 802.11b/g/n
•5 G Wi-Fi-sendereffekt: <18.5dBm
•5GWi-F
i-modulation: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM,64QAM,256QAM
•5 G Wi-Fi-netværkskompatibilitet: IEEE 802.11ac
•Network standby power<3W
SV
•Modellnamn: HK OMNI 50+
•Högtalarelement: 2 x 89 mm woofer, 2 x 20 mm diskant
•Klassad effekt: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Frekvensomfång: 53 Hz~20 kHz (-6 dB)
•Signal-brus-förhållande: >80 dB
•Ingångar: Bluetooth®, Aux-in, Wi-Fi
•Dimensioner (B x D x H): 333 x 175 x 214 mm
•Vikt: 3337 g
•Strömförsörjning: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth®-sändarens frekvensomfång: 2 402–2 480 GHz
•Bluetooth®-sändarens effekt: 0-4 dBm
•Bluetooth®-sändarens modulering: GFSK, π/4 DQPSK, 8DPSK
•2,4 G Wi-Fi-sändarens frekvensomfång: 2 412 MHz~2 472 MHz
(2,4 GHz ISM-band, USA 11-kanaler, Europa 13-kanaler)
•2,4 G Wi-Fi-sändarens effekt: < 20 dBm (ERIP)
•2,4 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM, 64QAM
•2,4 G Wi-Fi nätverkskompatibilitet: IEEE 802.11b/g/n
•5 G Wi-Fi-sändarens effekt: <18.5dBm
•5 G Wi-Fi-modulering: OFDM, DSSS, DBPSK, DQPSK, CCK,
16QAM,64QAM,256QAM
•5 G Wi-Fi nätverkskompatibilitet: IEEE 802.11ac
•Network standby power<3W
KO
•모델명: HK OMNI 50+
•변환기: 2 x 89mm 우퍼, 2 x 20mm 트위터
•정격 전력: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•주파수 응답: 53Hz~20kHz (-6dB)
•신호 대 잡음비:>80dB
•입력 연결:블루투스®, 보조 입력,Wi-Fi
•치수(너비 x 깊이 x 높이): 333mm x 175mm x 214mm
•중량: 3337g
•전원 공급 장치: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•블루투스®송신기 주파수 범위: 2402 ~ 2480MHz
•블루투스®송신기 출력: 0-4dBm
•블루투스®송신기 변조: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi 송신기 주파수 범위: 2412 ~ 2472MHz (2.4GHz ISM 밴드,
미국 11 채널,유럽 및 기타 지역 13 채널)
•2.4G Wi-Fi 송신기 출력: <20dBm(EIRP)
•2.4G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•2.4G Wi-Fi 네트워크 호환성: IEEE 802.11b/g/n
•5G Wi-Fi 송신기 출력: <18.5dBm
•5G Wi-Fi 변조: OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,64QAM,256QAM
•5G Wi-Fi 네트워크 호환성: IEEE 802.11ac
•Network standby power<3W
JP
•モデル名：HK OMNI 50+
•トランスデューサ ー：ウーファー 2x89mm、ツイーター 2x20mm
•定格出力：4 x 25W (DC mode) 4 x 15W (Battery mode)
•周波数特性：53Hz～20kHz (-6dB)
•S/N比：80dB以下
•入力接続：Bluetooth®、Aux 端子、Wi-Fi
•寸法（幅x奥行x高さ）：333mm x175mm x214mm
•重量：3337g
•電源：19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth® 対応トランスミッター周波数帯域：2402∼2480MHz
•Bluetooth® 対応トランスミッター出 力：0-4dBm以上
•Bluetooth® 対応トランスミッター変 調：GFSK、π/4 DQPSK、8DPSK
•2.4G WiFiトランスミッター周波数帯域：2412∼2472MHz
(2.4GHz ISMバンド、USA 11チャンネル、Europeとその他の地域
13チャンネ ル)
•2.4G WiFiトランスミッター出 力：20dBm(EIRP)以上
•2.4G WiFi変調：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、64QAM
•2.4G WiFiネットワークへの互換性：IEEE 802.11b/g/n
•5G WiFiトランスミッター出 力：<18.5dBm以上
•5G WiFi変調：OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,64QAM,256QAM
•5G WiFiネットワークへの互換性：IEEE 802.11ac
•Network standby power<3W
CHT
•型號名稱：HK OMNI 50+
•轉換器：2x89mm低音喇叭，2x20mm高音喇叭
•額定功率：4 x 25W (DC mode) 4 x 15W (Battery mode)
•頻率回應：53Hz~20kHz (-6dB)
•雜訊比：>80dB
•輸入連接：Bluetooth®、Aux 輸入、Wi-Fi
•尺寸（寬 x 深 x 高）： 333mm x 175mm x 214mm
•重量：3337 克
•電源：
19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth® 發射機頻率範圍：2402 – 2480MHz
•Bluetooth® 發射機功率：0-4dBm
•Bluetooth® 發射機調變：GFSK、π/4 DQPSK、8DPSK
•2.4G Wi-Fi 發射機頻率範圍：2412 – 2472MHz（2.4GHz ISM 頻帶、美國
11個頻道、歐洲和其他 13 個頻道）
•2.4G Wi-Fi 發射機功率：<20dBm (EIRP)
•2.4G Wi-Fi 調變：OFDM、DSSS、DBPSK、DQPSK、CCK、16QAM、64QAM
•2.4G Wi-Fi 網路相容性：IEEE 802.11b/g/n
•5G Wi-Fi 發射機功率：<18.5dBm
•5G Wi-Fi 調變：OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,64QAM,256QAM
•5G Wi-Fi 網路相容性：IEEE 802.11ac
•Network standby power<3W
CHS
•型号名称：HK OMNI 50+
•换能器：2个89mm 低音扬声器，2个20mm 高音扬声器
•额定功率：4 x 25W (DC mode) 4 x 15W (Battery mode)
•频率响应：53Hz~20kHz (-6dB)
•信噪比：>80dB
•输入连接：Bluetooth®、辅助输入、Wi-Fi
•尺寸（宽 x 长 x 高)：333mm x 175mm x 214mm
•重量：3337g
•电源：19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth® 发射器频率范围：2402 – 2480MHz
•Bluetooth® 发射器功率：0-4dBm
•Bluetooth® 发射器调制：GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi 发射器频率范围：2412 – 2472MHz（2.4GHz ISM 频带，
美国 11 个频道，欧洲和其他国家/地区 13 个频道）
•2.4G Wi-Fi 发射器功率：<20dBm (EIRP)
•2.4G Wi-Fi 调制：OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•2.4G Wi-Fi 网络兼容性：IEEE 802.11b/g/n
•5G Wi-Fi 发射器功率：<18.5dBm
•5G Wi-Fi 调制：
OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,64QAM,256QAM
•5G Wi-Fi 网络兼容性：IEEE 802.11ac
•Network standby power<3W
ID
•Nama Model: HK OMNI 50+
•Transduser: 2 x 89mm woofer, 2 x 20mm tweeter
•Nilai daya: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Respons frekuensi: 53Hz~20kHz (-6dB)
•Rasio sinyal-ke-bunyi: >80dB
•Input koneksi: Bluetooth®, Aux-in, Wi-Fi
•Dimensi (W x D x H): 333mm x 175mm x 214mm
•Berat: 3337g
•Catu daya: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Rentang frekuensi pemancar Bluetooth®: 2402 – 2480MHz
•Daya pemancar Bluetooth®: 0-4dBm
•Modulasi pemancar Bluetooth®: GFSK, π/4 DQPSK, 8DPSK
•Rentang frekuensi pemancar 2.4G Wi-Fi: 2412 – 2472MHz
(2.4GHz ISM Band, USA 11 Kanal, Eropa dan 13 Kanal lain)
•Daya pemancar 2.4G Wi-Fi: <20dBm (EIRP)
•Modulasi 2.4G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK, 16QAM, 64QAM
•Kompatibilitas jaringan 2.4G Wi-Fi: IEEE 802.11b/g/n
•Daya pemancar 5G Wi-Fi: <18.5dBm
•
Modulasi 5G Wi-Fi: OFDM, DSSS, DBPSK, DQPSK, CCK,16QAM,64QAM,256QAM
•Kompatibilitas jaringan 5G Wi-Fi: IEEE 802.11ac
•Network standby power<3W
EN
•Model Name: HK OMNI 50+
•Transducers: 2 x 89mm woofer, 2 x 20mm tweeter
•Rated power: 4 x 25W (DC mode) 4 x 15W (Battery mode)
•Frequency response: 53Hz~20kHz (-6dB)
•Signal-to-noise ratio: >80dB
•Input connections: Bluetooth®, Aux-in, Wi-Fi
•Dimensions (W x D x H): 333mm x 175mm x 214mm
•Weight: 3337g
•Power supply: 19VDC, 3.0A
•Battery Life: 5 hours
•Slash proof: IPX 5
•Bluetooth® transmitter frequency range: 2402 − 2480MHz
•Bluetooth® transmitter power: 0-4dBm
•Bluetooth® transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
•2.4G Wi-Fi transmitter frequency range: 2412 − 2472MHz
(2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
•2.4G Wi-Fi transmitter power: <20dBm (EIRP)
•2.4G Wi-Fi modulation: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM, 64QAM
•2.4G Wi-Fi network compatibility: IEEE 802.11b/g/n
•5G Wi-Fi transmitter power: <18.5dBm
•5G Wi-Fi modulation: OFDM, DSSS, DBPSK,DQPSK,CCK,
16QAM,64QAM,256QAM
•5G Wi-Fi network compatibility: IEEE 802.11ac
•Network standby power<3W
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International
Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners.
This Mark Certifies that this product is compliant with the BLACKFIRE ALLIANCE Standard.
Please refer to WWW.BLACKFIREALLIANCE.COM for more information.
BLACKFIRE RESEARCH™ is a Registered Trademark (No. 3,898,359) of BLACKFIRE RESEARCH CORP.
All rights reserved.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi Alliance.
The Wi-Fi Protected Setup Identifier Mark is a mark of the Wi-Fi Alliance.
“Made for iPod,”“Made for iPhone,” and“Made for iPad”mean that an electronic accessory has been designed to connect specifically to iPod, iPhone,
or iPad, respectively, and has been certified by the developer to meet Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod, iPhone, or iPad may affect
wireless performance.
AirPlay, iPad, iPhone, iPod, iPod classic, iPod nano, iPod touch, and Retina are trademarks of Apple Inc., registered in the U.S. and other countries. iPad
Air, iPad mini, and Lightning are trademarks of Apple Inc. In Japan,The trademark “iPhone” is used with a license from Aiphone K.K
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPOFPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
FPO
IC Caution:
User should also be advised that:
(i) the device for operation in the band 5150 - 5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems;
(ii) the maximum antenna gain permitted for devices in the bands 5250 - 5350 MHz and 5470 - 5725 MHz shall comply with the e.i.r.p. limit: and
(iii) the maximum antenna gain permitted for devices in the band 5725 - 5825 MHz shall comply with the e.i.r.p. limits specified for point-to-point and non point-to-point operation as
appropriate.
(iv) Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that these radars could cause
interference and/or damage to LE-LAN devices.
Les utilisateurs devraient aussi être avisés que
(i) les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
(ii) le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5 250-5 350 MHz et 5 470-5 725 MHz doit se conformer à la limite de p.i.r.e.;
(iii) le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5 725-5 825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à
point, selon le cas.De plus, les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu’ils ont la priorité) pour les bandes 5 250-5 350 MHz et 5 650-5 850 MHz et
que ces radars pourrai ent causer du brouillage et/ou des dommages aux dispositifs LAN-EL.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
º Reorient or relocate the receiving antenna.
º Increase the separation between the equipment and receiver.
º Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
º Consult the dealer or an experienced radio/TV technician for help.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz and 5.65 to 5.85 GHz bands. These radar stations can cause interference with and/or damage this device. No
configuration controls are provided for this wireless equipment allowing any change in the frequency of operations outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
“FCC RF Radiation Exposure Statement Caution: To maintain compliance with the FCC’s RF exposure guidelines, place the product at least 20cm from nearby persons.”
Use Restriction Attention In France, operation is limited to indoor use within the band 5150-5350 MHz.
해당무선설비는전파혼신가능성이있으므로인명안전과관련된서비스는할수없음
0560
Торговая марка : harman/kardon
Назначение товара : АКТИВНАЯ АКУСТИЧЕСКАЯ СИСТЕМА
Изготовитель : ХАРМАН ИНТЕРНЕШНЛ ИНДАСТРИЗ ИНКОРПОРЕЙТЕД,
США, 06901 КОННЕКТИКУТ, г.СТЭМФОРД, АТЛАНТИК СТРИТ 400, ОФИС 1500
Страна происхождения : Китай
Импортер в Россию : OOO “ХАРМАН РУС СиАйЭс“, РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12, КОРПУС 1
Гарантийный период : 1 год
Информация о
сервисных центрах : www.harman.com/ru тел. +7-800-700-0467
Срок службы : 5 лет
Срок хранения : не ограничен
Условия хранения : Cтандартные при нормальных значениях климатических факторов внешней среды
Номер документа
соответствия : Товар сертифицирован
Дата производства : Дата изготовления устройства определяется по двум буквенным обозначениям из второй группы
символов серийного номера изделия, следующих после разделительного знака «-». Кодировка
соответствует порядку букв латинского алфавита, начиная с января 2010 года: 000000-MY0000000,
где «M» - месяц производства (А - январь, B - февраль, C - март и т.д.) и «Y» - год производства
(A - 2010, B - 2011, C - 2012 и т.д.).
TR01541_A
