What’s in the box
Buttons
1
2
Quick Start Guide
Guide de démarrage rapide
x1
x1
Connections
3
Quick Start Guide
Guide de démarrage rapide
Bluetooth®
2. Music control
4
1. Bluetooth connection
JBL Clip 2
Quick Start Guide
Guide de démarrage rapide
x2
Wireless daisy chain
5
Quick Start Guide
Guide de démarrage rapide
>5s
Speaker A
Speaker B
>5s
Speaker A
Step 1
JBL Clip 2
JBL Clip 2
JBL Clip 2
Step 2
Step 3
Quick Start Guide
Guide de démarrage rapide
Speakerphone
6
Carabiner
7
Quick Start Guide
Guide de démarrage rapide
LED indication
8
Status LED indication
Fast blinking
Pairing mode / Incoming call
OnConnected
Fast blinking
Low power
Charging
Wireless daisy chain pairing
Wireless daisy chain connected On
Blinking
On
Warning
9
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
Quick Start Guide
Guide de démarrage rapide
FPO
FPO
FPO
FPO
FPO
FPO
Quick Start Guide
Guide de démarrage rapide
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
EN FR
Quick Start Guide
Guide de démarrage rapide
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
JBL Clip 2 is IPX7 waterproof.
IMPORTANT: To ensure that the JBL Clip 2 is waterproof, please remove all cable connections and
tightly close the cap; exposing the JBL Clip 2 to liquids without doing so may result in permanent
damage to the speaker. And do not expose JBL Clip 2 to water while charging, as doing so may result
in permanent damage to the speaker or power source.
IPX7 waterproof is defined as the speaker can be immersed in water up to 1m for up to 30 minutes.
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
ES PT
DE IT
Quick Start Guide
Guide de démarrage rapide
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
NL NO
FI RU
Quick Start Guide
Guide de démarrage rapide
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
SV DA
PLJP
Quick Start Guide
Guide de démarrage rapide
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
KO CHS
ID
CHT
Quick Start Guide
Guide de démarrage rapide
• Bluetooth
®
version: 4.2
• Support: A2DP V1.3, AVRCP V1.5, HFP
V1.6, HSP V1.2
• Transducer: 1 x 40mm
• Output power: 1 x 3W
• Frequency response: 160Hz–20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion polymer
(3.7V/730mAh)
• Battery charge time: 2.5 hour @ 5V, 0.5A
• Music playing time: up to 8 hours (varies
by volume level and audio content)
• Bluetooth transmitter frequency
range: 2.402 – 2.480GHz
• Bluetooth transmitter modulation:
GFSK, π/4 DQPSK, 8DPSK
• Dimensions (H x W x D):
141 x 94 x 42 (mm)
• Weight: 178g
FPO
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by HARMAN International Industries,
Incorporated is under license. Other trademarks and
trade names are those of their respective owners.
HE
Торговая марка: JBL
Назначение товара: Активная акустическая система
Изготовитель: Харман Интернешнл Индастриз
Инкорпорейтед, США, 06901 Коннектикут,
г.Стэмфорд, Атлантик Стрит 400, офис 1500
Страна происхождения: Китай, Вьетнам
Импортер в Россию: OOO “ХАРМАН РУС СиАйЭс“,
РОССИЯ, 127018, г.МОСКВА, УЛ. ДВИНЦЕВ, Д.12,
КОРПУС 1
Гарантийный период: 3 года
Информация о сервисных центрах:
www.harman.com/ru тел. +7-800-700-0467
Срок службы: 3 года
Срок хранения: не ограничен
Условия хранения: Cтандартные при нормальных
значениях климатических факторов внешней среды
Номер документа соответствия: Товар
сертифицирован
Дата производства: Дата изготовления устройства
второй группы символов серийного номера
изделия, следующих после разделительного знака
«-». Кодировка соответствует порядку букв
латинского алфавита, начиная с января 2010 года:
000000-MY0000000, где «M» - месяц производства (А
- январь, B - февраль, C - март и т.д.) и «Y» - год
производства (A - 2010, B - 2011, C - 2012 и т.д.).
TR01600_A
2280
XXXX-XX-XXXX
Este equipamento opera em caráter secundário, isto é,
não tem direito a proteção contra interferência prejudicial,
mesmo de estações do mesmo tipo, e não pode causar
interferência a sistemas operando em caráter primário.
Este produto está homologado pela ANATEL, de acordo
com os procedimentos regulamentados pela Resolução
242/2000, e atende aos requisitos técnicos aplicados.
Para maiores informações, consulte o site da ANATEL –
www.anatel.gov.br
Quick Start Guide
Guide de démarrage rapide
1.5
FPO

Navigation menu
