Users Manual
Link 10
Front Top
Product Tour
For more product information, please visit jbl.com
Button panel
Lights when active
Wi-Fi status indicator
Microphone
Back
Battery level indicator
Power on/off
Mic mute/unmute
USB connector
for charging
Restart
Bluetooth paring
Volume down/up
Press to start your request
Press to stop audio,
timers, alarms, and
responses
Micro USB cable
TR03992_C
Specication
• Transducer: 2 x 40mm
• Output power: 2 x 8W
• Frequency response: 70Hz-20kHz
• Signal-to-noise ratio: >80dB
• Battery type: Lithium-ion Polymer (3.7V, 4000mAh)
• Battery charge time: 4 hours @5V 1A
• Music play time: up to 5 hours (varies by volume level and
content)
•Wireless network: 802.11b/g/n/ac (2.4/5GHz)
• Bluetooth version: 4.1
• Supported audio formats: HE-AAC, LC-AAC, MP3, Vorbis,
WAV (LPCM), FLAC, Opus
• Dimensions (Dia x H): 86 x 169 mm
• Weight: 670g
IPX 7 Waterproof
JBL Link 10 is IPX7 waterproof.
IPX7 waterproof is defined as the speaker can be immersed in
water up to 1m for up to 30 minutes.
IMPORTANT: To ensure that the JBL Link 10 is waterproof, please
remove all cable connections and tightly close the cap; exposing
the JBL Link 10 to liquids without doing so may result in
permanent damage to the speaker. And do not expose JBL Link
10 to water while charging, as doing so may result in permanent
damage to the speaker or power source.
Get Started
1.
Press to power on
2.
Download and run the Google Home app on a phone or tablet.
Set up your JBL Link 10 in the Google Home app.
The Wi-Fi CERTIFIED Logo is a certification mark of the Wi-Fi
Alliance. The Wi-Fi Protected Setup Identifier Mark is a mark of the
Wi-Fi Alliance.
The Bluetooth®word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by
HARMAN International Industries, Incorporated is under license.
Other trademarks and trade names are those of their respective
owners.
Chromecast is a trademark of Google Inc. Google Play, and the
Google Play logo are trademarks of Google Inc.
This equipment complies with FCC/IC RSS-102 radiation exposure
limits set forth for an uncontrolled environment. This eqipment
should be installed and operated with minimum distance 20cm
between the radiator & your body.
ce matériel est conforme aux limites de dose d'exposition aux
rayonnements, fac / ic rss-102 énoncée dans un autre
environnement.cette eqipment devrait être installé et exploité avec
distance minimale de 20 entre le radiateur et votre corps.
