Hastech >
user manual
Universal Bluetooth Wireless and Wired
Aluminum Keyboard with backlit
User Manual
PACKAGE CONTENTS
1. Aluminum Keyboard with backlit
2. Micro-USB Cable
3. User Manual
INDICATOR LIGHTS DESCRIPTION
①Caps Lock Indicator ②USB/Bluetooth State Switch ③Power Indicator
Charging Indicator
Battery Power Display Indicator
④Power button ⑤Micro port
①Caps Lock Indicator: The blue light will flash.
②USB / Bluetooth State Switch Indicator:
Press “Fn+ ” switch to wireless connection, it will be blue.
Press “Fn+ ” switch to wired connection, it will be green.
Bluetooth Status Indicator: Blue light will flash after pressing the“FN + ”
keys together.
③Power Indicator: Slide the power button to right side, the indicator will be
green.
Charging Indicator: Red light will turn on when the keyboard is charging and
turns off once fully charged.
Battery Power Display Indicator: Press “Fn+ ”, flashing Green.
（Every blinking represents 25% battery. That is to say, flashing once means
the remaining battery is 25%; flashing twice, the remaining battery is 50%;
flashing three times, 75%; flashing four times, 100%.)
④Power button: To turn on ,Slide the button to right side.
To turn off, Slide the button to left side.
⑤Micro Port: For wireless charging and wired connecting.
BACKLIT FUNCTION INTRODUCTION
1. Fn + : Lighting ON/OFF Key.
Press first time is turning on the light.
Press second time is increasing brightness.
Press third time is lighting off.
2. + / to change the backlit colors. (7-color backlit)
3. When the battery is less than 20%, the backlit will be turnt off.
4. The backlit won’t work until the keyboard paired with device.
KEYS AND FUNCTIONS
For the Windows tablets, Press Fn key and hot key together to activate action.
For
Android
For
iOS
For
Windows
Fn+
Windows
Back
N/A
N/A
N/A
Home
Home
F1
Web Browser
Select all
Select all
F2
Select all
Copy
Copy
F3
Copy
Paste
Paste
F4
Paste
Search for
Search for
F5
Search for
N/A
Language
change
F6
N/A
Previous
track
Previous
track
F7
Previous
track
Play/Pause
Play/Pause
F8
Play/Pause
Next track
Next track
F9
Next track
Volume down
Volume down
F10
Volume down
Volume up
Volume up
F11
Volume up
Screen Lock
Screen Lock
F12
Screen Lock
Fn +
N/A
Keyboard
Display
N/A
N/A
Fn +
Backlit on /off
Backlit on /off
Backlit on /off
N/A
Fn +
Battery
Power
Display
Battery
Power
Display
Battery
Power
Display
N/A
Fn + |
|
Fn + <
<
Fn + >
>
SPECIAL NOTE:
1. For Android users: The Caps Lock indicator may not light up, but will still
function normally.
2. Press FN and Q,W or E keys together to shift between Android ,Win or iOS
systems after successful connection. Otherwise the keyboard’s function key
will be invalid.
Q- Android W - Win E - iOS
WIRELESS AND WIRED FUNCTION INTRODUCTION
1. Bluetooth wireless connection: Fit for devices with bluetooth function, like
tablets, smartphones, etc.
2. USB wired connection: Fit for devices which can be connected with USB
cable, like notebooks, PC, etc.
3. USB Cable: Charging function for bluetooth devices.
Connection for wired devices.
I. PAIRING WITH WIRELESS DEVICES
HOW TO PAIR THE KEYBOARD WITH PHONE OR TABLETS
Step 1. Slide the Power button to right side, the keyboard turns on, green light
will be on for 5 seconds.
Step 2. Press “Fn+ ” switch to wireless connection, State Indicator will be
blue.
Step 3. Press the “FN+ ” keys together to enter pairing mode. The
Bluetooth indicator will flash blue.
Step 4. On your device, go to “Settings”. Activate its Bluetooth function and
search for the keyboard device.
Step 5. The device will display “Bluetooth 3.0 Keyboard” as an available
device.
Step 6. Select “Bluetooth 3.0 Keyboard” on your device, click on it, the
keyboard will now be paired to your device and the Bluetooth indicator will be
off.
Step 7. Press “FN + Q / Android, W / Windows, E / iOS” keys on the keyboard
according to the operating system you are using.
PAIRING WITH DESKTOP
Step 1. Connect the Bluetooth dongle to the USB port on your computer. The
Bluetooth driver will be installed automatically. (Bluetooth dongle is not
included)
Step 2. Slide the Power button to right side, the keyboard turns on, green light
will be on for 5 seconds.
Step 3. Press “Fn+ ” switch to wireless connection, State Indicator will be
blue.
Step 4. Press the “FN+ ” keys together to enter pairing mode. The
Bluetooth indicator will flash blue.
Step 5. Click the Bluetooth icon positioned on the right corner of your desktop,
and start searching for the keyboard device. Add the “Bluetooth 3.0 Keyboard”
as a Bluetooth device after it is found.
Step 6. Once the “Bluetooth 3.0 Keyboard” has successfully connected to your
device, the Bluetooth indicator will turn off.
Step 7. Press “FN + W / Windows” keys on the keyboard switch to the
Windows operating system.
II .PAIRING WITH WIRED DEVICES
Step 1. Slide the Power button to right side, the keyboard turns on, green light
will be on for 5 seconds.
Step 2. Get the cable to connect with keyboard and devices.
Step 3. Press “Fn+ ” together, the Status Indicator Light will be Green,
connect successfully.
Step 4. Press “FN + W / Windows” keys on the keyboard switch to the
Windows operating system.
HOW TO SWITCH KEYBOARD LANGUAGE
Samsung Android: Shift +Space
Google Android: Ctrl +Space
Windows: Win+Space
iOS 8: Win+Space
iOS 9: Ctrl+Space
NOTE FOR WIRELESS MODE:
1. Only one device can be actively paired at one time.
2. For other Bluetooth enabled devices, please verify the Bluetooth
standard&compatibility before attempting to connect to the keyboard.
3. After pairing for the first time, your device will connect to the keyboard
automatically when opening the keyboard.
4. In case of connection failure, delete the pairing record from your device, and
try the above procedures again.
POWER SAVING MODE
The keyboard will enter sleep mode after being idle for 30 minutes. To activate
it, press any key and wait for 3 seconds.
HOW TO CHARGE
1. Use the included USB cable for charging. Connect one end to a USB
charger, and the other to the keyboard.
2. In charging, the power indicator will turn red. Generally, it takes
approximately 4 hours for a full charge. (USB charger is not included)
CAUTION
When not in use for a prolonged period of time, it is recommended that you
turn off the keyboard to lengthen the battery life.
WARNING
1. Keep the keyboard away from sharp objects that could damage it.
2. Do not put heavy objects on the keyboard.
3. Do not stretch, twist or apply force to the keyboard.
4. To clean the keyboard, gently wipe it by using a moist cotton cloth.
5. Make sure the keyboard is turned off before cleaning. Do not use liquid
cleanser.
6. Please do not spill coffee, tea or other liquids on the keyboard.
TROUBLESHOOTING
If you are unable to connect the keyboard to your tablet, please try the
following:
1. Starting with a full charge on both devices ensures that process won’t be
interrupted by a low battery.
2. Make sure your tablet’s Bluetooth is on.
3. Make sure that the keyboard is within the effective operation distance of 33
feet (10 M).
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
