User Manual Safety Guide
Aruba 300 Series Wireless Access Point
Regulatory Compliance and Safety Information Guide
0511891-02 | September 2016 1
Introduction
This document contains domestic and international regulatory compliance and safety information for 300 Series access points.
To ensure that this device complies with the regulatory standards for your region, please refer to the sections below.
Electrical and Environmental Specifications
Regulatory Information
Proper Disposal of Aruba Equipment
Electrical and Environmental Specifications
For additional specifications on this product, please refer to the product data sheet at www.arubanetworks.com/
safety_addendum.
Electrical
Ethernet:
One 100/1000 Base-T auto-sensing Ethernet RJ45 interface
Power over Ethernet IEEE 802.3at 56VDC (nominal) and 802.3af 48VDC (nominal).
Power:
Maximum (worst-case) power consumption: 13.5W (802.3af PoE) or 12W (DC)
Excludes power consumed by external USB device (and internal overhead); this could add up
to 6W (PoE) or 5.5W (DC) for 5W/1A USB device
Direct DC source: 12Vdc nominal, +/- 5%
Power over Ethernet (PoE): 802.3at and 802.3af complaint source
Connect only to IEC 60950-1 or IEC 60601-1 3rd edition products and power sources.
Environmental
Operating:
Temperature: 0°C to +50°C (+32°F to +122°F)
Humidity: 5% to 93% non-condensing
Storage and transport:
Temperature: -40°C to +70°C (40°F to +158°F)
Regulatory Information
The following regulatory model names apply to the 300 Series access points:
AP-304/IAP-304: APIN0304
AP-305/IAP-305: APIN0305
All Aruba access points should be professionally installed by an Aruba Certified Mobility Professional (ACMP). The installer is
responsible for ensuring that grounding is available and meets applicable national and electrical codes.
Tous les points d'accès Aruba doivent impérativement être installés par un professionnel agréé. Ce dernier doit s'assurer
que l'appareil est mis à la terre et que le circuit de mise à la terre est conforme aux codes électriques nationaux en vigueur.
If a power adapter other than the Aruba-approved adapter is used in the US or Canada, it should be NRTL listed, with an
output rated 12Vdc, minimum 2A, marked “LPS” and “Class 2”, and suitable for plugging into a standard power receptacle in
the US and Canada.
2Aruba 300 Series Wireless Access Point | Regulatory Compliance and Safety Information Guide
Aruba Networks provides a multi-language document that contains country-specific restrictions and additional safety and
regulatory information for all Aruba access points. This document can be viewed or downloaded at www.arubanetworks.com.
FCC
This device is electronically labeled.
To view the FCC ID for controller-managed access points:
1. Log into the controller WebUI
2. Navigate to Maintenance > Controller > About
To view the FCC ID for Instant access points:
1. Log into the virtual controller WebUI
2. Navigate to Maintenance > About
FCC Class B Part 15
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the manufacturer’s instructions, may cause interference harmful to radio communications.
Operation is subject to the following conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference that may cause undesired operation.
If this equipment does cause interference, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio or TV technician for help.
Users are advised that high power Radars are allocated as primary users of the bands 5250-5350 MHz and 5650-5850
MHz and these Radars could cause interference and/or damage to Licensed Exempt WLAN devices.
Canada
Complies with the Class B limits for radio noise emissions as set out in the interference-causing equipment standard entitled
“Digital Apparatus,” CAN ICES-3(B)/NMB-3(B).
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or
lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the
antenna type and its gain should be so chosen that the equivalent isotropically radiated power (E.I.R.P.) does not exceed the
limit necessary for successful communication.
This device complies with Industry Canada license-exempt RSS standard(s).
RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits. This equipment should
be installed and operated with a minimum distance of 7.87 inches (20cm) between the radiator and your body for 2.4 GHz
and 5 GHz operations. This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
Déclaration sur les limites d'exposition aux radiofréquences :cet équipement est conforme aux limites d'exposition aux
rayonnements radioélectriques spécifiées par la FCC. Il doit être installé et utilisé à une distance minimale de 20 cm par
rapport à votre corps pour les fréquences de 2,4 et 5 GHz. Cet émetteur-récepteur ne doit pas être utilisé ou situé à
proximité d'autres antennes ou émetteurs-récepteurs.
The device could automatically discontinue transmission in case of absence of information to transmit, or
operational failure. Note that this is not intended to prohibit transmission of control or signaling information
or the use of repetitive codes where required by the technology.
Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la conformité est
susceptible d'annuler son droit d'utilisation.
Aruba 300 Series Wireless Access Point | Regulatory Compliance and Safety Information Guide 3
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept
any interference, including interference that may cause undesired operation of the device.
Déclaration d’Industrie Canada
Cet appareil numerique de la classe B respecte toutes les exigencies du Reglement sur le materiel brouilleur du Canada.
Conformément aux réglementations d’Industrie Canada, cet émetteur-récepteur radio doit être utilisé uniquement avec une
antenne dont le type et le gain maximal doivent être approuvés par Industrie Canada. Pour réduire les interférences radio
potentielles, le type d’antenne et son gain doivent être choisis de façon à ce que la puissance isotrope rayonnée équivalente
(PIRE) ne dépasse pas les valeurs nécessaires à une communication efficace.
Ce périphérique est conforme aux règlements RSS exempts de licence d’Industrie Canada. L’utilisation de ce périphérique est
soumise aux deux conditions suivantes : (1) ce périphérique ne doit pas provoquer d’interférences, et (2) ce périphérique doit
accepter toute interférence, y compris les interférences susceptibles de provoquer un dysfonctionnement.
EU Regulatory Conformance
Aruba Networks Inc., hereby declares that this product is in compliance with the directives listed below:
EMC Directive 2014
Low Voltage Directive 2014
R&TTE Directive 1999
REACH Regulation (EC) No.: 1907/2006
RoHS Directive 2011
WEEE Directive 2012
A Declaration of Conformity for these directives is available for viewing at www.arubanetworks.com.
EMC Class B Warning
이 기기는 가정용 (B 급 ) 전자파적합기기로서 주로 가정에서 사용하는 것을 목적으로 하며 , 모든 지역에서 사용할 수
있습니다 .
RF Warning
해당무선설비는 전파혼신의 가능성이 있으므로 인명안전과 관련된 서비스는 할 수 없습니다
Medical
1. Equipment not suitable for use in the presence of flammable mixtures.
2. Connect to only IEC 60950-1 or IEC 60601-1 3rd edition certified products and power sources. The end user is responsible
for the resulting medical system complies with the requirements of IEC 60601-1 3rd edition.
3. Wipe with a dry cloth, no additional maintenance required.
This equipment complies with IC RSS-102 RF exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20 cm between the radiator and your
body.
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la
source de rayonnement et votre corps.
Under Industry Canada regulations, when operated in 5150 to 5250 MHz frequency range, this device is
restricted to indoor use to reduce the potential for harmful interference with co-channel Mobile Satellite
Systems. Users are advised that high power radars are allocated as primary users (i.e. priority users) of the
bands 5250-5350 MHz and 5650-5850MHz and that these radars could cause interference and/or damage to
LE-LAN devices.
Conformément aux réglementations d’Industrie Canada, en cas d'utilisation dans la plage de fréquences de
5150 à 5250 MHz, cet appareil doit uniquement être utilisé en intérieur afin de réduire les risques
d'interférence avec les systèmes satellites mobiles partageant le même canal. Les utilisateurs êtes avisés que
les utilisateurs de radars de haute puissance sont désignés utilisateurs principaux (c.-à-d., qu'ils ont la priorité)
pour les bandes 5250-5350 MHz et 5650-5850 MHz et que ces radars pourraient causer du brouillage et/ou des
dommages aux dispositifs LAN-EL
© Copyright 2016 Hewlett Packard Enterprise Development LP
www.arubanetworks.com
1344 Crossman Avenue
Sunnyvale, California 94089
Phone: 408.227.4500
Fax: 408.227.4550
4Aruba 300 Series Wireless Access Point | Regulatory Compliance and Safety Information Guide
4. No serviceable parts, the unit must be sent back to the manufacturer for repair.
5. No modifications are allowed without Aruba approval.
第十二條 →經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性及功能。
第十四條 →低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
Proper Disposal of Aruba Equipment
Dispose of Aruba products per local regulation. For the most current information about Global Environmental Compliance and
Aruba products, visit www.arubanetworks.com.
Waste of Electrical and Electronic Equipment
Aruba products at end of life are subject to separate collection and treatment in the EU Member States,
Norway, and Switzerland and therefore are marked with the symbol shown at the left (crossed-out wheelie
bin). The treatment applied at end of life of these products in these countries shall comply with the
applicable national laws of countries implementing Directive 2002/96/EC on Waste of Electrical and
Electronic Equipment (WEEE).
India RoHS
This product complies with RoHS requirements as prescribed by E-Waste (Management & Handling) Rules, governed by the
Ministry of Environment & Forests, Government of India.
European Union RoHS
Aruba products also comply with the EU Restriction of Hazardous Substances Directive 2011/65/EC
(RoHS). EU RoHS restricts the use of specific hazardous materials in the manufacture of electrical and
electronic equipment. Specifically, restricted materials under the RoHS Directive are Lead (including
Solder used in printed circuit assemblies), Cadmium, Mercury, Hexavalent Chromium, and Bromine.
Some Aruba products are subject to the exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed circuit
assemblies). Products and packaging will be marked with the “RoHS” label shown at the left indicating conformance to this
directive.
China RoHS
Aruba products also comply with China environmental declaration requirements and are labeled with the
“EFUP 10” label shown at the left.
Expected Service Life 10 years. For additional compliance information, refer to the regulatory label on the back of this device.
10
ᴹᴹ∂ᴹᇣ⢙䍘༠᰾
Hazardous Materials Declaration
䜘Ԧ〠
(Parts)
ᴹ∂ᴹᇣ⢙䍘ᡆݳ㍐˄Hazardous Substance˅
䫵
˄Pb˅
⊎
˄Hg˅
䭹
˄Cd˅
ޝԧ䬜
˄Cr6+˅
ཊⓤ㚄㤟
˄PBB˅
ཊⓤҼ㤟䟊
˄PBDE˅
⭥䐟⁑ඇ
(circuit modules) XOOOO O
⭥㔶৺⭥㔶㓴Ԧ
(Cables & Cable A
ssemblies)
OOOOO O
䠁䜘Ԧ
(Metal Parts) OOOOO O
ກᯉ઼㚊ਸ⢙䜘Ԧ
(
Plastic and Polymeric Parts)
OOOOO O
O: 㺘⽪䈕ᴹ∂ᴹᇣ⢙䍘൘䈕䜘Ԧᡰᴹ൷䍘ᶀᯉѝⲴਜ਼䟿൷൘ SJ/T11363-2006 ḷ߶㿴ᇊⲴ䲀䟿㾱≲
ԕлDŽ
Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts
is below the relevant threshold of the SJ/T11363-2006 standard.
X: 㺘⽪䈕ᴹ∂ᴹᇣ⢙䍘㠣ቁ൘䈕䜘ԦⲴḀа൷䍘ᶀᯉѝⲴਜ਼䟿䎵ࠪ SJ/T11363-2006 ḷ߶㿴ᇊⲴ䲀
䟿㾱≲DŽIndicates that the concentration of the hazardous substance of at least one of all homogeneous
materials in the parts is above the relevant threshold of the SJ/T11363-2006 standard.
ሩ䬰ѻᰕⲴᡰӗ૱ˈᵜ㺘ᱮ⽪ᓄ䬮Ⲵ⭥ᆀؑӗ૱ਟ㜭वਜ਼䘉Ӌ⢙䍘DŽ
This table shows where these substances may be found in the supply chain of
electronic information
products, as
of the date of sal
e of the enclosed product.
↔ḷᘇѪ䪸ሩᡰ⎹৺ӗ૱Ⲵ⧟؍֯⭘ᵏḷᘇ.ḀӋ䴦䜘ԦՊᴹањн਼Ⲵ⧟؍֯⭘ᵏ
(
ֻྲ,⭥⊐অݳ⁑ඇ)䍤൘ަӗ૱к.
↔⧟؍֯⭘ᵏ䲀ਚ䘲⭘Ҿӗ૱ᱟ൘ӗ૱ѝᡰ㿴ᇊⲴᶑԦлᐕ.
The Environment
-
Friendly Use Period (EFUP) for all enclosed products and their parts are
per the symbol shown here. The Environment
-
Friendly Use Period is valid only when the
product is operated under the conditions defined in the product manual.
