Aruba AT-BT10 Asset Tracker
Installation Guide
About the AT-BT10
The Aruba AT-BT10 Asset Tracker location beacon is a Bluetooth low energy
(BLE) device capable of providing real-time asset location tracking using
Meridian Mobile Engagement tools.
Features of the AT-BT10 include:
Highly-accurate asset location identification
Low power consumption
Easy to deploy, test, and use
Figure 1 AT-BT10 Front view
Package Contents
AT-BT10 location beacon
Adhesive pads
Installation Guide (this document, printed)
Activation
To activate the AT-BT10, insert a coin or flathead screwdriver into the
indention located at the center of the rear panel and turn counterclockwise
until the indicator arrow is aligned with the “I” marking.
Figure 2 Activating the AT-BT10
To deactivate the AT-BT10, rotate the back cover clockwise until the
indicator arrow is aligned with the “0” marking.
Installation
Use the adhesive pads to install the device on a flat surface in an indoor
environment.
Before installing the device, ensure that:
the mounting surface is indoor, flat, clean, and dust-free.
It is recommended to clean the surface using a solvent with a 50/50
Isopropyl Alcohol and water mixture.
the grooves for adhesive pads on the bottom of the device is dust-free.
the device is activated.
Installation
1. Remove the paper from one side of the adhesive pads to attach them to
the three corresponding grooves on the bottom of the device, as shown
in Figure 3.
Figure 3 Attaching the Adhesive Pads
2. Peel off the remaining paper from the pads to attach the device onto a
flat surface.
Configuring/Provisioning AT-BT10 Devices
The AT-BT10 devices are configured/provisioned using the Aruba Beacons
app. For more informations, see
http://docs.meridianapps.com/developers/beacons_app
Product Specifications
Physical
Device dimensions
Diameter: 34mm
Height: 11mm
Electrical
Power Supply: One CR2032 coin battery
Coin battery capacity: 225 mAh
Voltage: 3 V
RF Performance
Tx = -23 dBm to 0dBm (23 dB dynamic range)
Rx sensitivity = Approximately -90 dBm (1 Mbps)
Working Frequency range: 2402-2480MHz
Operation temperature: 0 °C to 50 °C
Safety and Regulatory Compliance
Refer to the following sections for safety and regulatory information for the
AT-BT10.
Regulatory Model Names
The regulatory model name for the AT-BT10 is ARBT0201.
For complete regulatory model information, refer to the label located on
the back panel of this device.
RFCC Class B Part 15
This device complies with Part 15 of the Federal Communications
Commission (FCC) Rules. Operation is subject to the following two
conditions:
This device may not cause harmful interference.
This device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
manufacturer’s instructions, may cause interference harmful to radio
communications.
If this equipment does cause interference, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio or TV technician for help.
Canada
Under Industry Canada regulations, this radio transmitter may only operate
using an antenna of a type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential radio interference to
other users, the antenna type and its gain should be so chosen that the
equivalent isotropically radiated power (e.i.r.p.) is not more than that
necessary for successful communication.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
This device may not cause interference
This device must accept any interference, including interference that
may cause undesired operation of the device.
Complies with the Class B limits for radio noise emissions as set out in the
interference-causing equipment standard entitled “Digital Apparatus,” ICES-
003 of Industry Canada.
Cet apareil numerique de la classe B respecte toutes les exigencies du
Reglement sur le materiel brouilleur du Canada.
EU Regulatory Conformance
This product is CE marked according to the provisions of the R &
TTE Directive (1999/5/EC) - CE. Aruba Networks Inc., hereby
declares that the ARBT0100 device model is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC -CE
The Declaration of Conformity made under Directive 1999/5/EC is available
for viewing at the following location: http://support.arubanetworks.com
European Union RoHS
Aruba products also comply with the EU Restriction of
Hazardous Substances Directive 2011/65/EC (RoHS). EU
RoHS restricts the use of specific hazardous materials in
the manufacture of electrical and electronic equipment. Specifically,
restricted materials under the RoHS Directive are Lead (including Solder
used in printed circuit assemblies), Cadmium, Mercury, Hexavalent
Chromium, and Bromine. Some Aruba products are subject to the
exemptions listed in RoHS Directive Annex 7 (Lead in solder used in printed
circuit assemblies). Products and packaging will be marked with the “RoHS”
label shown at the left indicating conformance to this Directive.
Proper Disposal of Aruba Equipment
Waste of Electrical and Electronic Equipment
Aruba products at end of life are subject to separate
collection and treatment in the EU Member States, Norway,
and Switzerland and therefore are marked with the symbol
shown at the left (crossed-out wheelie bin). The treatment
applied at end of life of these products in these countries
shall comply with the applicable national laws of countries
implementing Directive 2002/96EC on Waste of Electrical and
Electronic Equipment (WEEE).
China RoHS
Aruba products also comply with China environmental
declaration requirements and are labeled with the “EFUP 10”
label shown at the left.
本產品符合低功率電波輻射性電機管理辦法:
第十二條
經形式認證合格之低功率射頻電機,非經許可,公司、商號或使用者均不得擅自
變更頻率、加大功率或變更原設計之特性及功能。
第十四條
低功率射頻電機之使用不得影響飛航安全及干擾合法通信;經發現有干擾現象
時,
應立即停用,並改善至無干擾時方的繼續使用。
前項合法通信,指依電信規定作業之無線電信。低功率射頻電機須忍受合法通信
或工業、科學及醫療用電波輻射性電機設備之干擾。
NOTE
RF Radiation Exposure Statement: This equipment complies with
FCC RF radiation exposure limits. This equipment should be
installed and operated with a minimum distance of 7.9 inches (20
cm) between the radiator and your body for 2.4 GHz operation.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.
Changes or modifications to this unit that are not expressly
approved by the party responsible for compliance could void the
user’s authority to operate this equipment.
10
᳝↦᳝ᆇ⠽䋼ໄᯢ
Hazardous Materials Declaration
᳝↦᳝ᆇ⠽䋼៪ܗ㋴(Hazardous Substance)
䚼ӊৡ⿄
(Parts) 䪙
3E
∲
+J
䬝
&G
݁Ӌ䫀
&U

໮⒈㘨㣃
3%%
໮⒈Ѡ㣃䝮
3%'(
⬉䏃ᵓ
(PCA Boards) hƻ ƻ ƻ ƻ ƻ
ᴎẄ㒘ӊ
(Mechanical Sub-Assemblies) hƻ ƻ ƻ ƻ ƻ
ƻ˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼೼䆹䚼ӊ᠔᳝ഛ䋼ᴤ᭭Ёⱘ৿䞣ഛ೼
SJ/T11363-2006
ᷛޚ㾘ᅮⱘ䰤䞣㽕∖ҹϟDŽ
Indicates that the concentration of the hazardous substance in all homogeneous materials in the parts is
below the relevant threshold of the SJ/T11363-2006 standard.
h˖ 㸼⼎䆹᳝↦᳝ᆇ⠽䋼㟇ᇥ೼䆹䚼ӊⱘᶤϔഛ䋼ᴤ᭭Ёⱘ৿䞣䍙ߎ6-7ᷛޚ㾘ᅮⱘ䰤䞣㽕∖DŽ
Indicates that the concentration of the hazardous substance of at least one of all homogeneous materials
in the parts is above the relevant threshold of the SJ/T11363-2006 standard.
ᇍ䫔ଂП᮹ⱘ᠔ଂѻકᴀ㸼ᰒ⼎կᑨ䫒ⱘ⬉ᄤֵᙃѻકৃ㛑ࣙ৿䖭ѯ⠽䋼DŽ
This table shows where these substances may be found in the supply chain of electronic information
products, as of the date of sale of the enclosed product.
ℸᷛᖫЎ䩜ᇍ᠔⍝ঞѻકⱘ⦃ֱՓ⫼ᳳᷛᖫᶤѯ䳊䚼ӊӮ᳝ϔϾϡৠⱘ⦃ֱՓ⫼ᳳ
՟བ⬉∴ऩܗ῵ഫ䌈೼݊ѻકϞ
ℸ⦃ֱՓ⫼ᳳ䰤া䗖⫼Ѣѻકᰃ೼ѻક᠟ݠЁ᠔㾘ᅮⱘᴵӊϟᎹ԰
The Environment- Friendly Use Period (EFUP) for all enclosed products and their parts are
per the symbol shown here. The Environment- Friendly Use Period is valid only when the
product is operated under the conditions defined in the product manual.
Aruba AT-BT10 Asset Tracker
Installation Guide
a Hewlett Packard
Enterprise company
