Hi G Tek IGST50433 ISO 18000-7 SECURITY TRANSPONDER User Manual

Hi-G-Tek Ltd ISO 18000-7 SECURITY TRANSPONDER Users Manual

Users Manual

ProprietaryNotice
ThisdocumentcontainsHi‐G‐TekInc.proprietaryconfidentialinformationandmaynotbeusedor
disclosedtootherpartiesinwholeorinpartwithoutpriorwrittenauthorizationfromHi‐G‐Tek
Inc.
UM4902REV1.1
18.7SecureSeriesTags
ContainerSecurityTransponder
CLIN:0004DA,0006DA
Installation&OperationManual
Unisys
Delivering Global Visibility.
Installation&Operation:ContainerSecurityTransponder
V-2 Page 3 of 12
UM4902_Rev1.1Page3of12
DisclaimerandLimitationofLiability
Hi‐G‐TekInc.affiliates,officers,directors,employeesandagentsprovidetheinformationcontained
inthisManualonan“as‐is”basisanddonotmakeanyexpressorimpliedwarrantiesor
representationswithrespecttosuchinformationincluding,withoutlimitation,warrantiesasto
non‐infringement,reliability,fitnessforaparticularpurposeorapplication,usefulness,
completenessoraccuracy.
Hi‐G‐TekInc.shallnotinanycircumstancesbeliabletoanypersonforanyspecial,incidental,
indirectorconsequentialdamages,includingwithoutlimitation,damagesresultingfromuseofor
relianceoninformationpresentedherein,orlossofprofitsorrevenuesorcostsofreplacement
goods,evenifinformedinadvanceofthepossibilityofsuchdamages.
CopyrightNotice
Allrightsreserved.
Nopartofthisdocumentmaybereproducedortransmittedinanyformbyanymeans,
photographic,electronic,mechanicalorotherwise,orusedinanyinformationstorageandretrieval
system,withoutthepriorwrittenpermissionofHi‐G‐TekInc.
Thisdocumentissubjecttochangewithoutpriornotice.
ATTENTION
•ThisHi‐G‐Tekproductisdesignedforcommercial/industrialuseonly,andshouldonlybehandledby
personnelauthorizedbyHi‐G‐Tekrepresentatives.
•InstallationmustbeperformedaccordingtothisGuide.
•Usingonlycertifiedantennas:Itistheresponsibilityoftheinstallertoensurethatwhenusingthe
outdoorantennakitsintheUnitedStates(orwhereFCCrulesapply),onlythoseantennascertifiedwith
theproductareused.
•Theuseofanyantennaotherthanthosecertifiedwiththeproductisexpresslyforbiddeninaccordance
withFCCrulesCFR47part15.204andpart15.203.
TheFCCWantsYoutoKnow
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
toPart15oftheFCCrules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbe
determinedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrecttheinterference
byoneormoreofthefollowingmeasures:
a)Reorientorrelocatethereceivingantenna.
b)Increasetheseparationbetweentheequipmentandreceiver.
c)Connecttheequipmenttoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
d)Consultthedealeroranexperiencedradio/TVtechnician.
Installation&Operation:ContainerSecurityTransponder
V-2 Page 4 of 12
UM4902_Rev1.1Page4of12
FCCWarning
Modificationsnotexpresslyapprovedbythemanufacturercouldvoidtheuserauthoritytooperatethe
equipmentunderFCCRules.
Instructionsconcerninghumanexposuretoradiofrequencyelectromagneticfields:
Adistanceofatleast20cm.betweentheequipmentandallpersonsshouldbemaintainedduringthe
operationoftheequipment.
FCCID:OB6‐IGST50433
ContainerSecurityTransponder:IG‐ST‐50‐433CLIN#0004DA
SpareParts
Hi‐G‐Tekrecommendsthatonlyoriginalproducts,spareandreplacementpartsauthorizedbyHi‐
G‐TekInc.beusedforinstallation,serviceandrepair.
Hi‐G‐TekInc.doesnotacceptanyresponsibilityandwillnotbeliableforanyconsequencesdueto
impropermaterialsused.
Hi‐G‐Tek,Inc.
1445ResearchBlvd.
Suite150
Rockville,MD20850
USA
info@higtek.com
Office.+1‐301‐279‐0022
Fax+1‐301‐279‐0055
Installation&Operation:ContainerSecurityTransponder
V-2 Page 5 of 12
UM4902_Rev1.1Page5of12
TableofContent
1 Introduction..........................................................................................................................................6
2 Functionaldescription......................................................................................................................7
3 Installation.............................................................................................................................................7
3.1 Preparingfordeployment.....................................................................................................7
3.2 MountingtheContainerTransponder.............................................................................8
4 TechnicalSpecifications................................................................................................................10
ListofFigures
Figure1:ContainerSecurityTransponder–frontview..............................................................6
Figure2:Transponder‐rearview........................................................................................................6
Figure3:Batteryinsertion.......................................................................................................................7
Figure4:MountingTransponderondoor.........................................................................................8
Figure5:Transpondermountedondoor..........................................................................................8
Figure6:Transpondermountedoncontainer................................................................................9
Installation&Operation:ContainerSecurityTransponder
V-2 Page 6 of 12
UM4902_Rev1.1Page6of12
1 I
In
nt
tr
ro
od
du
uc
ct
ti
io
on
n
TheSecureSeries18000‐7ContainerSecurityTransponderCLIN#0004DAisan
activeRFIDtagforsecuringcontainers.Thetransponderisdesignedtobe
attachedtoacontainerdoor,mountedontheleftsidedoor,andprovides
protectionfromintrusion.
TheTransponderisequippedwithintrusionsensorsandenvironmentcontrol
sensors–toverifycontinuous24/7protectionandproperclimatecontrol–for
sensitivegoodsstoredincontainer.
Figure1:ContainerSecurityTransponder–frontview
Figure2:Transponderrearview
Test
Indicators
pushbutton
Installation&Operation:ContainerSecurityTransponder
V-2 Page 7 of 12
UM4902_Rev1.1Page7of12
2 F
Fu
un
nc
ct
ti
io
on
na
al
l
d
de
es
sc
cr
ri
ip
pt
ti
io
on
n
TheContainerSecurityTransponderoperatesintheUHF433.92MHzband.Itis
designedtobeattachedtoacontainerdoor.
TheTransponderhasintrusionandenvironmentalsensorsthatinclude:
• DoorBreachsensor:formonitoringillegalopeningofcontainerdoors.
• LightIntrusion:Monitorsilluminationeventsinsidethecontainer.
• Temperature:MonitorsTemperatureinsidecontainer.
• Humidity:Monitorshumidityinsidecontainer.
• Shocksensor:monitorsextremebehaviorofcontainer.
Allthesensorsincludeindicationsforactivation/deactivationandalarmstatus.
Theindicatorscolorsare:
• Greencolordesignatesallnormalcondition.
• Redcolor–indicatesanalarmeventoccurred.
Eachsensorhasthresholdvalues–thatmaybeconfiguredbythecontrol
software.
TheTransponderisbatterypowereddevice,andrespondstostatusrequisitions
fromanearbyinterrogator–locatedup300ft.fromthetransponder.
ControlofTransponder’sfeaturesandparametersisfacilitatedbycontrol
software.Accesscontrolmaybeachievedeitherviaaninterrogatorordirectlyby
USBconnectiontocontrolPC.
3 I
In
ns
st
ta
al
ll
la
at
ti
io
on
n
3.1 Preparingfordeployment
Beforedeploymentofthetransponder,openthetransponderbatterycoverbyhalf
rotatingitcounterclockwise,removethebatteryandreplaceitbackwiththepoles
reversed,(+)shouldpointout–inthecorrectpolarity.
Figure3:TopView:Batteryinsertion
“+”side
placed
outwardly
Installation&Operation:ContainerSecurityTransponder
V-2 Page 8 of 12
UM4902_Rev1.1Page8of12
Whenyouhearashortbeep,thetransponderisactivatedandreadyforoperation.
Ifnobeepisheard,eitherthebatteryisnotorientedcorrectlyoritneedstobe
replaced.Note:ReplacementofDepletedBattery:
Whenrequired,useonlysize3.8VLithiumLi‐SOCl2batteries
3.2 MountingtheContainerTransponder
Carefullyopenthecontainer’sdoors.Insertthetagintotheleftdoorofthe
container:Doorsensorisfacinginward(Tag’sindicatorsarepointedout)see
Figure4.
Figure4:MountingTransponderondoor
ProperlyalignthetagwiththecontainerdoorperFigure5,keepaminimum
heightof5ft.containergroundbase.
Figure5:Transpondermountedondoor
Installation&Operation:ContainerSecurityTransponder
V-2 Page 9 of 12
UM4902_Rev1.1Page9of12
Closeandlocktherightsidedoorofcontainer.Oncethedoorisclosed,ittriggers
theTransponderforoperation
Figure6:Transpondermountedoncontainer
4 O
Op
pe
er
ra
at
ti
io
on
n
TheTransponderoperatesonlyuponarequestfromtheinterrogatororwhen
operatedbyacontrolPCconnectedtoitviaUSB.
4.1 LampTest
• presstheLEDtestbutton–seeFigure1
• AlltheLEDSblinkredoncethenblinkoncegreenandthenblink3
timesandshowsensorstatusasfollows:
Green:sensorisactive
Red:sensorhasdetectedanalarm(thedetectedsignalwas
abovethedefinedthresholdlevel)
Nolight:sensorisdisabled
Mounted
Transponder
(Indicators
panelplaced
outwardly)
Installation&Operation:ContainerSecurityTransponder
V-2 Page 10 of 12
UM4902_Rev1.1Page10of12
5 T
Te
ec
ch
hn
ni
ic
ca
al
l
S
Sp
pe
ec
ci
if
fi
ic
ca
at
ti
io
on
ns
s
Communications
• Operatingfrequency
• OmniDirectional
read/writerange
433.92MHZ
Upto300feet(100meters)openspace
Memory
Memorysize 128Kbytesofavailabledatabasetablememory
Sensordatalogging 32Kbytesofmemoryforsensordatalogging
Dataretention Dataisstoredforaminimumoffiveyears
PowerRequirements
Battery
• Replaceable batteries, meet the requirements of
theDoDtransponderbatteryguidelines.
• Canbereplacedwithouttheneedforatool
• Supports reverse battery insertion for battery
storage
Batterytype 3.8VLithiumLi‐SOCl2batteries
Batterylife
3yearminimum
SerialCommunication
USB:forlocalaccessandconfiguration
Environmental
Operatingtemperature ‐30ºCto+70ºC
Storagetemperature ‐40ºCto+70ºC
Humidity 90%non‐condensing
Vibrationandshock ComplieswithMIL‐STD‐810Dformobile
Hardenedweatherproof ComplieswiththeIEC60529IP64rating
PhysicalDimensions
Size 185x60x50mm
Weight 250gr
Mountingbracket
Weight
185x68x17mm
160gr
Antenna Internal
Attachmentmethods:

Attachmentmethod(ISO20’,40’shipping
containers)isanintegrateddoormountedBracket
Installation&Operation:ContainerSecurityTransponder
V-2 Page 11 of 12
UM4902_Rev1.1Page11of12
Sensors
SecureContainerTag
• DoorBreach
• LightIntrusion
• Temperature
• Humidity
• Shock
Indicators
• Audiblebeepindicatorforpoweron.
• Eachsensorhasitsindicationforactivation/deactivationandalarmstatus
• BatteryhasanindicationforbatteryOKandundervoltageindication
Installation&Operation:ContainerSecurityTransponder
V-2 Page 12 of 12
UM4902_Rev1.1Page12of12
Standards
• CompliantwithISO18000‐7:2008standardsandtheDoDinteroperability
guidelines
• FCCpart15subpartBclassB,subpartCsection15.231
• Hazardousenvironment:CertifiedasNon‐Incendive(NI)foroperationin
environmentwhereflammableandexplosivegasesandvaporsmaybepresent
• CompliantwithHEROenvironmenttestingat1‐inchseparation
• ComplieswithapplicableDoD,nationalandinternationalspectrum
managementpoliciesandregulationstoincludespectrumcertificationsin
accordancewithDoDDirective4650.1“ManagementanduseoftheRadio
FrequencySpectrum”andDoDDirective5000.1

Navigation menu
