Hisense Electric LCDC0010 Part15 Subpart B-LCD TV User Manual ES J111003
Hisense Electric Co., Ltd. Part15 Subpart B-LCD TV ES J111003
User Manual
Model Name
Dimension
Weight(Kg)
LCD Panel Minmum size(diagonal)
Screen resolution
Power consumption
Audio power
Power supply
Receiving systems
Component Input
VGA Input
HDMI Input
Without Stand
With Stand
Without Stand
With Stand
RF
AV
H32V75C
792×515×121.5
792×558×251
10kg
13kg
WxHxD(mm)
800mm
1366x768
110W
6W+6W
Refer to rating label
NTSC/ATSC/QAM
NTSC
480l/60Hz、480P/60Hz、
720P/60Hz、1080l/60Hz
VGA (640x480/60Hz)、SVGA (800x600/60Hz)
XGA (1024x768/60Hz)
RGB/60Hz (640x480、800x600、1024x768)
YUV/60Hz (480I、480P、720P、1080I、1080P)
