Connect pillow speaker
A 1/4 stereo style pillow speaker jack js on the side of the TV.
Please connect to the pillow speaker jack and select the pillow
speaker switch to the on mode.
Note: If the pillow speaker is connected.. no sound will be heared from the TV
speaker.Also,Auto volume will be grayed out and not accessible on the
Sound menu. Use a pillow speaker that is a UL recognized pendant control
bearing the warming:"Risk of re if used in oxygen enriched atmosphere.
Keep pendant control away from oxygen equipment."
Bedside Wall Plate
Jumper
Across Room Wiring
Wall Plate Behind 1
Brightness
Pillow speaker choose the type of pillow speaker you use.
Digital or Analog.
Video MPG2
Dynamic
pillow speaker–choose the type of pillow speaker you use
Digital or Analog.
Note: If you choose the wrong pillow speaker type, the TV won’t be
work with it.
Power saver
Power saver
Model
TV type
TV panel
TV system
Receiving channels
Audio out
Power requirement
Power consumption
(with Max backlight)
Weight
Dimensions
(W×H×D with stand)
Wall Mounting
VESA Size
Input terminals
Output terminals
Control terminals
Video Input
Component Input
PC Input
HDMI Input
Wall-mount
screws pattern
Audio multiples
LHD32K366HS
LED
32-inch TFT LED
NTSC-M, ATSC
BTSC system
AC 120V, 60Hz
55W
19.84 lbs (9 kg)
100×100 mm
M4 (4 pc)
Composite video/L and R audio (1)
Component video/L and R audio (1)
HDMI (2)
VGA/audio (1)
ANT/Cable In (1)
USB (1)
480I/60Hz 480P/60Hz
720P/60Hz
1080I/60Hz 1080P/60Hz
VGA (640×480 60Hz)
SVGA (800×600 60Hz)
SGA (1024×768 60Hz)
RGB/60Hz (640×480 800×600 1024×768)
YUV/60Hz (480I 480P 720P 1080I 1080P)
Digital Coaxial Audio (1)
Headphone (1)
SERVICE PORT (2)
NTSC-M
29.55 × 20.31 × 7.87 in
750.6 × 516 × 200 mm
5W×2
VHF: 2-13 UHF: 14-69 CATV: 1-125 CADTV: 1-135 DTV: 2-69
Internal Speaker Mute
Source Lock

Navigation menu
