Contents

W9HLCDD0049_User Manual 3

ES-A
*******
Important Safety Information
and Warranty Card
Please read this thoroughly and keep it for future reference.
1
IMPORTANT INFORMATION
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
WARNING:
FCC Regulations state that any unauthorized changes or modifications to this equipment not expressly approved by the
manufacturer could void the user's authority to operate this equipment.
CAUTION:
This product satises FCC regulations when shielded cables and connectors are used to connect the unit to other equipment. To
prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded cables and connectors for
connections.
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Wireless Radio
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-
channel mobile satellite systems.
Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz, 5470-5600 MHz and 5650-5725 MHz.
This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or transmitter except in
accordance with FCC multi-transmitter product procedures.
This device is restricted for indoor use.
Important:
Any changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.
Devices will not permit operations on channels 120-132 for 11a and 11n/a which overlap the 5600 - 5650 MHz band.
The lightning flash with arrow-head symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within a triangle is intended to
alert the user to the presence of important operating
and maintenance (servicing) instructions in the
literature accompanying the product.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
2
Industry Canada Statement
This Class B digital apparatus complies with CAN ICES-003(B)/NMB-3(B)
Wireless Radio
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other channels is not possible.
The device for operation in the band 5150–5250 MHz is only for indoor use to reduce the potential for harmful interference to co-
channel mobile satellite systems.
Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz, 5470-5600 MHz and 5650-5725 MHz.
This device and its antenna(s) must not be co-located with any other transmitters except in accordance with IC multi-transmitter
product procedures.
Referring to the multi-transmitter policy, multiple-transmitter(s) and module(s) can be operated simultaneously without reassessment
permissive change.
For indoor use only.
Important: Any changes or modications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102 radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20 cm between the radiator & your body.
The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the
equipment still complies with the e.i.r.p. limit.
The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the equipment still complies with
the e.i.r.p. limits specied for point-to-point and non-point-to-point operation as appropriate.
Users should also be advised that high-power radars are allocated as primary users (i.e. priority users) of the bands 5250-5350
MHz and 5650-5850 MHz and that these radars could cause interference and/or damage to LE-LAN devices.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820 of the National Electrical Code that provides
guidelines for proper grounding and, in particular, species that the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.
3
DEAR SHARP CUSTOMER
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and many years of trouble-free operation of
your product, please read the Important Safety Instructions carefully before using this product.
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result
in electric shock and/or re. In order to prevent potential danger, please observe the following instructions when installing, operating
and cleaning the product. To ensure your safety and prolong the service life of your Liquid Crystal Television, please read the
following precautions carefully before using the product.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
Additional Safety Information
15. Power Sources—This product should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instructions.
16. Overloading—Do not overload wall outlets, extension cords, or integral convenience receptacles as this can result in a risk of fire
or electric shock.
17. Object and Liquid Entry—Never push objects of any kind into this product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric shock. Never spill liquid of any kind on the product.
18. Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to qualified service personnel under the
following conditions:
a. When the AC cord or plug is damaged,
b. If liquid has been spilled, or objects have fallen into the product,
c. If the product has been exposed to rain or water,
d. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result
in damage and will often require extensive work by a qualified technician to restore the product to its normal operation,
4
e. If the product has been dropped or damaged in any way, and
f. When the product exhibits a distinct change in performance - this indicates a need for service.
19. Replacement Parts—When replacement parts are required, be sure the service technician has used replacement parts specified
by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
20. Safety Check—Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
21. Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer.
Outdoor Antenna Grounding — If an outside antenna is
connected to the television equipment, be sure the antenna
system is grounded so as to provide some protection
against voltage surges and built-up static charges.
Article 810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regard to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA LEAD
IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
Water and Moisture Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink, or laundry
tub; in a wet basement; or near a swimming pool; and the like.
When using the TV outside, please make sure it is protected
against moisture (rain, splashing water). Never expose to
moisture.
Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product on an unstable base can cause
the product to fall, resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket
or table recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer's instructions. Use only the mounting hardware recommended by the manufacturer.
Selecting the location — Select a place with no direct sunlight and good ventilation.
Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these vents and
openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not place the product
on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is not designed for built-in
installation; do not place the product in an enclosed place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer's instructions are followed.
The front panel used in this product is made of glass. Therefore, it can break when the product is dropped or applied with impact.
Be careful not to be injured by broken glass pieces in case the panel breaks.
Heat The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
The Liquid Crystal panel is a very high technology product with millions of pixels, giving you fine picture details. Occasionally, a
few non-active pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the
performance of your product.
Lightning For added protection for this television equipment during a lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and disconnect the antenna. This will prevent damage to the equipment due
to lightning and power-line surges.
Power Lines An outside antenna system should not be located in the vicinity of overhead power lines or other electric light
or power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care
should be taken to keep from touching such power lines or circuits as contact with them might be fatal.
To prevent fire, never place any type of candle or flames on the top or near the TV set.
To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
Do not display a still picture for a long time, as this could cause an afterimage to remain.
5
To prevent fire or shock hazard, do not expose this product to dripping or splashing. No objects filled
with liquids, such as vases, should be placed on the product. Above containers might get pushed
over, which would endanger electric safety.
Do not insert foreign objects into the product. Inserting objects in the air vents or other openings
may result in fire or electric shock. Exercise special caution when using the product around children.
Precautions when transporting the TV
When transporting the TV, never carry it by holding or otherwise putting pressure onto
the display. Be sure to always carry the TV by two people holding it with two hands.
Caring for the cabinet
Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.
Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of
the main unit cabinet or cause cracking.
Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.
If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral detergent diluted with water and
thoroughly wrung out, and then wipe with a soft dry cloth.
Avoid using benzene, thinner, and other solvents, as these may deform the cabinet and cause the paint to peel off.
Do not apply insecticides or other volatile liquids. Also, do not allow the cabinet to remain in contact with rubber or vinyl products
for a long period of time. Plasticizers inside the plastic may cause the cabinet to deform and cause the paint to peel off.
Caring for the front panel
Turn off the main power and unplug the AC cord from the wall outlet before handling.
Gently wipe the surface of the front panel with a soft cloth (cotton, flannel, etc.).To
protect the front panel, do not use a dirty cloth, liquid cleaners, or a chemical cloth
(wet/dry sheet type cloth, etc.). This may damage the surface of the front panel.
Wiping with a hard cloth or using strong force may scratch the surface of the front
panel.
Use a soft damp cloth to gently wipe the front panel when it is really dirty.(It may scratch the surface of the front panel when
wiped strongly.)
If the front panel is dusty, use an anti-static brush, which is commercially available, to clean it.
To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved cleaning cloths are available
directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-CLOTH-3) packs. Call 1-800-BE-SHARP for ordering, or
VISIT http://www.sharpusa.com/SharpDirect.
Disconnect device
where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily
operable.
6
CHILD SAFETY:
PROPER TELEVISION PLACEMENT MATTERS
THE CONSUMER ELECTRONICS INDUSTRY CARES
• Manufacturers, retailers and the rest of the consumer electronics industry are committed to making
home entertainment safe and enjoyable.
• As you enjoy your television, please note that all televisions – new and old- must be supported on
proper stands or installed according to the manufacturer’s recommendations. Televisions that are
inappropriately situated on dressers, bookcases, shelves, desks, speakers, chests, carts, etc., may fall
over, resulting in injury.
TUNE IN TO SAFETY
• ALWAYS follow the manufacturer’s recommendations for the safe installation of your television.
• ALWAYS read and follow all instructions for proper use of your television.
• NEVER allow children to climb on or play on the television or the furniture on which the television is
placed.
• NEVER place the television on furniture that can easily be used as steps, such as a chest of drawers.
• ALWAYS install the television where it cannot be pushed, pulled over or knocked down.
• ALWAYS route cords and cables connected to the television so that they cannot be tripped over,
pulled or grabbed.
WALL OR CEILING MOUNT YOUR TELEVISION
• ALWAYS contact your retailer about professional installation if you have any doubts about your ability
to safely mount your television.
• ALWAYS use a mount that has been recommended by the television manufacturer and has a safety
certification by an independent laboratory (such as UL, CSA, ETL).
• ALWAYS follow all instructions supplied by the television and mount manufacturers.
• ALWAYS make sure that the wall or ceiling where you are mounting the television is appropriate.
Some mounts are not designed to be mounted to walls and ceilings with steel studs or cinder block
construction. If you are unsure, contact a professional installer.
• Televisions can be heavy. A minimum of two people is required for a wall or ceiling mount installation.
MOVING AN OLDER TELEVISION TO A NEW PLACE IN YOUR HOME
• Many new television buyers move their older CRT televisions into a secondary room after the purchase
of a flat-panel television. Special care should be made in the placement of older CRT televisions.
• ALWAYS place your older CRT television on furniture that is sturdy and appropriate for its size and
weight.
• NEVER place your older CRT television on a dresser where children may be tempted to use the
drawers to climb.
• ALWAYS make sure your older CRT television does not hang over the edge of your furniture.
CE.org/safety
7
LIMITED WARRANTY FOR SHARP TVs
Congratulations on your purchase!
Hisense USA Corporation ("Hisense"), under its one or more licenses from Sharp Corporation, hereby warrants to the
first purchaser for this Sharp, Aquos or Quattron television (“Product”), when shipped in its original container and sold
or distributed in the United States and Puerto Rico by an authorized Hisense dealer, and provided that this Product
was not sold either “as is”, “with all faults”, “sales final” or per similar terms, that this Product will, during the applicable
warranty period as stated solely in this Limited Warranty, be free from defects in material and workmanship. Hisense
will, solely within the applicable warranty period, and at Hisense’s sole discretion, either repair the defective Product or
provide the first purchaser with a like refurbished product of similar or better quality.
HOW TO GET SERVICE
Warranty service may be obtained upon delivery of the Product, together with proof of original purchase (including
the date of purchase) and a copy of this Limited Warranty to an authorized Hisense service provider or an authorized
Hisense service center or dealer. Hisense’s contact information is provided below.
ON-SITE SERVICE
On-site service requires that an authorized service provider be given clear, complete and easy access to the Product.
On-site service does not include that the service provider removes, reinstalls or transports the Product. It is possible
that certain on-site repairs will need to be completed off site, and at Hisense's discretion, require that the Product to be
shipped directly to Hisense’s warehouse. Once Hisense receives the Product and repairs or replaces it, Hisense will
return the repaired/replaced Product back to the original purchaser.
TERMS AND CONDITIONS
This limited warranty shall not apply to:
(a) Any defects caused or repairs required as a result of abusive operation, negligence, accident, improper installation
or inappropriate use as outlined in the owner's manual or other applicable Product documentation. The United States
and Puerto Rico.
(b) Any defects caused or repairs required as a result of any Product that has been tampered with, modified, adjusted
or repaired by any person other than Hisense, a Hisense authorized service provider or a Hisense authorized service
center or dealer.
(c) Any defects caused or repairs required as a result of the use of the Product with items not expressly specified or
approved by Hisense in writing, including but not limited to, head cleaning tapes and/or chemical cleaning agents.
(d) Any replacement of accessories, glassware, consumable or peripheral items required through normal use of the
Product, including but not limited to, earphones, remote controls, batteries, etc.
(e) Any cosmetic damage to the Product surface or exterior that has been defaced or caused through normal wear and
tear.
(f) Any defects caused or repairs required as a result of damage caused by any external or environmental conditions,
including but not limited to, transmission line/power line voltage or liquid spillage or acts of God.
IMPORTANT: Please keep the original packaging materials and original receipt in case your TV needs to
be serviced.
Warranty Service and Troubleshooting Information for Customers in the
United States and Puerto Rico
To obtain warranty service and troubleshooting information, contact the Hisense Consumer Electronics Care
Center at 1-888-935-8880 (Monday-Friday from 9 a.m. to 9 p.m. EST, Saturday-Sunday from 9 a.m. to 6 p.m.) or
Email support@sharptvusa.com. You can also visit our website at www.sharptvusa.com.
Warranty for USA
8
(g) Warranty claims for Products returned with illegible or without appropriate model, factory serial number and CSA/
cUL markings.
(h) Any Products used for rental or commercial purposes.
(i) Any installation, consumer instruction, delivery, setup, adjustment, and/or programming charges.
(j) A Product that is not installed in accordance with installation instructions included with the Product.
(k) Any signal reception problems (including antenna), images “burnt” into the screen, availability of third-party provided
services or content (including, without limitation, image, audio or video content).
No other entity other than Hisense is authorized to extend, enlarge or transfer this warranty on behalf of Hisense.
The express warranties in this limited warranty are, in lieu of and, except to the extent prohibited by applicable law,
Hisense disclaims all other warranties and conditions, express or implied, whether arising by law, statute, by course
of dealing or usage of trade, including, without limitation, implied warranties or conditions of merchantability and/or
quality, fitness for a particular use or purpose, and/or non-infringement. Limitations: (a) Hisense shall not be liable
for any incidental, special, consequential, economic, exemplary or indirect damages of any kind or nature (including
lost profits or damages for loss of time or loss of use or loss of data) arising from or in any connection with the use or
performance of a Product or a failure of a Product, even if Hisense is aware of or has been advised of the possibility
of such damages; (b) the remedies described in this limited warranty constitute complete fulfillment of all obligations
and responsibilities of Hisense to the purchaser with respect to the Product and shall constitute full satisfaction of all
claims, whether based on contract, negligence, strict liability or otherwise. Some states may not allow the exclusion or
limitation of certain damages, or limits on the duration or voiding of implied warranties or conditions; in such states, the
exclusions and limits herein may not apply. This limited warranty is governed by the laws of the Georgia, USA.
WARRANTY PERIODS
All warranty periods shall be calculated from the date of original purchase.
LCD/LED TV: 1 year (replacement Product and parts assume the remaining original warranty period, or ninety (90)
days, whichever is longer).
3D Glasses and Remote Control: Ninety (90) days.
This Warranty is only valid in the United States and Puerto Rico and only applies to Products sold/distributed and
serviced in the United States and Puerto Rico.
NO WARRANTIES (WHETHER EXPRESS OR IMPLIED) INCLUDING BUT NOT LIMITED TO ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL APPLY AFTER THE
EXPRESS WARRANTY PERIOD STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN
(BY ANY PERSON, FIRM OR ENTITY WITH RESPECT TO THE PRODUCT) SHALL BE BINDING ON HISENSE.
THIS WARRANTY IS THE EXCLUSIVE WARRANTY WITH RESPECT TO THE PRODUCT AND HISENSE IS THE
EXCLUSIVE WARRANTY PROVIDER FOR THE PRODUCT. REPAIR OR REPLACEMENT IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. HISENSE SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THE PRODUCT. NOTWITHSTANDING THE
FOREGOING, CONSUMER’S RECOVERY AGAINST HISENSE SHALL NOT EXCEED THE PURCHASE PRICE OF
THE PRODUCT SOLD BY HISENSE. THIS WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THEN THE
ORIGINAL PURCHASER WHO PURCHASED THE PRODUCT AND IS NOT TRANSFERABLE.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental or
consequential damages or allow limitations on warranties; therefore, the limitations or exclusions stated above may not
apply to purchaser. This Warranty gives purchaser specific rights and purchaser may have other rights, and purchaser
may also have other rights which vary from state to state.
CUSTOMER RECORD (Please retain for your records)
Date of Purchase: .................................................................. Store/Dealer: ...................................................................
Model No.: ............................................................................. Serial No.: ........................................................................
Warranty for USA

Navigation menu
